Winbond Electronics W742E81A, W742C81A Datasheet

Preliminary W742E81A/W742C81A

4-BIT MICROCONTROLLER

1. GENERAL DESCRIPTION

The W742E81A/W742C81A is a high-performance 4-bit microcontroller (µC) that provides an LCD
driver. The device contains a 4-bit ALU, two 8-bit timers, two dividers (for two oscillators) in dual­clock operation, a 40 × 4 LCD driver, six 4-bit I/O ports (including 1 output port for LED driving), and
one channel DTMF generator. There are also five interrupt sources and 16-levels subroutine nesting
for interrupt applications. The W742E81A/W742C81A operates on very low current and has two
power reduction modes, that is the dual-clock slow operation and STOP mode, which help to
minimize power dissipation.

2. FEATURES

•

Operating voltage: 2.4V−3.8V

•

Dual-clock operation or single-clock operation (By option)

•

Main-oscillator

− Connect to 3.58 MHz crystal or 400 KHz that can be selected by option code

− Crystal or RC oscillator can be selected by code option (W742E81A)

− Connect to 2 MHz typical RC oscillator (W742C81A)

•

Sub-oscillator

− Connect to 32768 Hz crystal only

•

Memory

− 16384 x 16 bits program flash EEPROM (including 64K x 4 bit look-up table)

− 2048 x 4 bits data RAM (including 16 nibbles x 16 pages working registers)

− 40 x 4 LCD data RAM

•

24 input/output pins

− Port for input only: 1 ports/4 pins(RC)

− Input/output ports: 3 ports/12 pins(RA, RB & RD)

− High sink current output port for LED driving: 1 port /4 pins(RE)

− Port for output only: 1 port/ 4 pins(RF)

•

Power-down mode

− Hold function: no operation (main-oscillator and sub-oscillator still operate)

− Stop function: no operation (main-oscillator and sub-oscillator are stopped)

− Dual-clock slow operation mode: system is operated by the sub-oscillator (F
stopped)

•

Five types of interrupts

− Four internal interrupts (Divider0, Divider1, Timer 0, Timer 1)

− One external interrupts (RC Port)

OSC

=Fs and Fm is

Publication Release Date: April 2000

- 1 - Revision A1

Preliminary W742E81A/W742C81A

bit watchdog timer selectable for system reset; enable the watch dog timer or not is

•

LCD driver output

− 40 segments x 4 commons

− 1/4 duty 1/3 bias driving mode

− Clock source should be the sub-oscillator clock in the dual-clock operation mode

•

MFP output pin

− Output is software selectable as modulating or nonmodulating frequency

− Works as frequency output specified by Timer 1

•

DTMF output pin

− Output is one channel Dual Tone Multi-Frequency signal for dialling

•

Two built-in 14-bit frequency dividers

− Divider0: the clock source is the output of the main-oscillator

− Divider1: the clock source is the output of the sub-oscillator (dual-clock mode) or the Fosc/128
(single-clock mode)

•

Two built-in 8-bit programmable countdown timers

− Timer 0: one of two internal clock frequencies (F

OSC

− Timer 1: with auto-reload function and one of three internal clock frequencies (F
Fs) can be selected by MR1 register; and the specified frequency can be delivered to MFP pin

•

Built-in 18/15-

determined by code option

•

Powerful instruction set: 142 instructions

•

16-levels subroutine (include interrupt) nesting

/4 or F

OSC

/1024) can be selected

OSC, FOSC

/64 or

- 2 -

3. PIN CONFIGURATION

For W742E81A

X
O

X

D

U

I

T

R

NCNCN

N

C

C

T

N

M

E

1

1

F

S

Preliminary W742E81A/W742C81A

S

S

S

S

S

S

X
O

X

D

U

I

V

H

T

N

D

1

2

2

D

C

V

V

O

D

D

D

M

D

D

H

0

2

1

2

S

E

E

E

E

C

C

C

O

O

O

M

M

M

3

2

1

G

G

G

G

3

3

3

3

6

7

8

9

S

E

E

E

E

G

G

G

G

3

3

3

3

3

4

5

2

N
CNCNC

NC
MFP

RA0
RA1
RA2
RA3
RB0
RB1
RB2
RB3
RC0
RC1
RC2
RC3
RD0
RD1
RD2
RD3
NC
NC

80 79 78 77 76 75 74 73 72 717069 68 67 666564 63 62

81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100

1 2 3

4 5 6 7 8 91011 12 13 14 15 16 17 18 19

R

N
C

NCR

R

R

R

R

R

R

S

S

N

E

E

E

E

F

F

F

C

1

2

0

3

F

0

1

2

3

S

V

E

E

E

S

G

G

G

S

0

1

2

61 60 59 58 57

20 21 22 23 24

S

S

S

S

S

E

E

G

G

3

4

S

E

E

E

E

G

G

G

G

5

6

7

8

S

S

E

E

G

G

9

56 55 54 53 52

25 26 27 28 29

S

S

E

E

G

G

1

1

1

0

1

2

51

50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31

30

S

S
E
G

1
3

N

NCN

E

C

C

G

1
4

NC
NC
SEG31
SEG30
SEG29
SEG28
SEG27
SEG26
SEG25

SEG24
SEG23
SEG22
SEG21
SEG20
SEG19

SEG18

SEG17

SEG16

SEG15
NC

Publication Release Date: April 2000

- 3 - Revision A1

For W742C810

Preliminary W742E81A/W742C81A

S

S

S

S

S

S

X

X

O

X

O

X

D

U

I

T

R

NCNCN

N

C

C

T

N

M

E

1

1

F

S

D

U

I

V

H

T

N

D

1

2

2

D

C

V

V

O

D

D

D

M

D

D

H

0

2

1

2

S

E

E

E

C

C

C

O

O

M

M

2

1

G

G

G

O

3

3

3

M

7

8

9

3

E

E

E

E

G

G

G

G

3

3

3

3

3

4

5

6

NCNCN

N

C

C

NC
MFP

RA0
RA1
RA2
RA3
RB0
RB1
RB2
RB3
RC0
RC1
RC2
RC3
RD0
RD1
RD2
RD3
RE0
NC

80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62

81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100

1 2 3

4 5 6 7 8 91011 12 13 14 15 16 17 18 19

R

N

N

C

C

R

R

R

R

R

R

S

S

N

N

E

E

E

F

F

F

C

C

1

2

3

F

0

1

2

3

S

V

E

E

E

S

G

G

G

S

0

1

2

61 60 59 58 57

20 21 22 23 24

S

S

S

S

S

E

E

G

G

3

4

S

E

E

E

E

G

G

G

G

5

6

7

8

S
E

G
9

56 55 54 53 52

25 26 27 28

S

S

S

E

E

E

G

G

1

1

0

1

51

50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31

30

29

S
E

G

G

1

1

2

3

N

NCN

N

C

C

C

NC
SEG32
SEG31
SEG30
SEG29
SEG28
SEG27
SEG26
SEG25
SEG24
SEG23
SEG22
SEG21
SEG20
SEG19
SEG18
SEG17
SEG16
SEG15
SEG14

- 4 -

O
O

RES

Preliminary W742E81A/W742C81A

4. PIN DESCRIPTION

SYMBOL I/O FUNCTION

XIN2 I Input pin for sub-oscillator.

Connected to 32.768 KHz crystal only.

XOUT2 O Output pin for sub-oscillator with internal oscillation capacitor. Connected

to 32.768 KHz crystal only.

XIN1 I Input pin for main-oscillator.

Connected to 3.58 MHz or 400 KHz crystal or RC to generate system
clock.

XOUT1 O Output pin for main-oscillator.

Connected to 3.58 MHz or 400 KHz crystal or RC to generate system
clock.

RA0−RA3

RB0−RB3

RC0−RC3

RD0−RD3

RE0−RE3
RF0−RF3

MFP

DTMF O This pin can output dual-tone multifrequency signal for dialling.

SEG0−SEG39
COM0−COM3

DH1, DH2 I Connection terminals for voltage doubler (halver) capacitor.

DD1

V

DD2

V
VDD I Positive power supply (+).
VSS I Negative power supply (-).

I/O Input/Output port.

Input/output mode specified by port mode 1 register (PM1).

I/O Input/Output port.

Input/output mode specified by port mode 2 register (PM2).

I 4-bit port for input only.

Each pin has an independent interrupt capability.

I/O Input/Output port.

Input/output mode specified by port mode 5 register (PM5).
Output port only. With high sink current capacity for the LED application.
Output port only.

O Output pin only.

This pin can output modulating or nonmodulating frequency, or Timer 1
specified frequency. It can be selected by bit 0 of BUZCR (BUZCR.0).

I System reset pin with pull-high resistor.
O LCD segment output pins.
O LCD common signal output pins.

The LCD alternating frequency can be selected by code option.

I Positive (+) supply voltage terminal.

Refer to Functional Description.

Publication Release Date: April 2000

- 5 - Revision A1

Preliminary W742E81A/W742C81A

Pin Description, continued

SYMBOL I/O FUNCTION

VPP I Voltage control pin for the flash EEPROM programming, erasing and verifying.

This pin has the built-in pull-low resistor.

MODE I This pin can be used as mode selection control; data read/write clock;

program/erase control or address counter control in the flash EEPROM erasing,
programming or verifying mode. This pin has the built-in pull-low resistor.

DATA I/O Data I/O pin with the built-in pull-low resistor.

5. BLOCK DIAGRAM

VPP
DATA
MODE

RAM

(2048*4)

Flash
EEROM

(16384*16)

(look_up table
64K*4)

+1(+2)

PC

STACK

(16 Levels)

Timer 0

(8 Bit)

Watch Dog Timer

(4 Bit)

SEG0~SEG39 COM0~COM3

LCD DRIVER

ACC

ALU

Central Control

Unit

PEFHEFIEF

HCF

EVF SEF

PSR0 SCR PR

MR0

DTMF

Divider 0
(14 Bit)

MR1

DTCR

Modulation
Frequency
Pulse

PM0
PM1

. . .

Timer 1

(8 Bit)

VDD1-2 DH1-2

PORT RA

PORT RB

PORT RC

PORT RD

PORT RE

PORT RF

DTMF

Generator

Divider 1

(12/14 Bit)

Timing Generator

SEL

MUX

RA0-3

RB0-3

RC0-3

RD0-3

RE0-3

RF0-3

DTMF

MFP

VDD
VSS

RES

- 6 -

XIN1

XOUT1

XIN2 XOUT2

Preliminary W742E81A/W742C81A

6. FUNCTIONAL DESCRIPTION

6.1 Program Counter (PC)

Organized as an 14-bit binary counter (PC0 to PC13), the program counter generates the addresses
of the 16384 × 16 on-chip ROM containing the program instruction words. Before the jump or
subroutine call instructions are to be executed, the destination ROM page must be determined firstly.
The confirmation of the ROM page can be done by executing the MOV ROMPR, #I or MOV ROMPR,
R instruction. When the interrupt or initial reset conditions are to be executed, the corresponding
address will be loaded into the program counter directly. The format used is shown below.

Table 1 Vector address and interrupt priority

ITEM ADDRESS INTERRUPT PRIORITY

Initial Reset 0000H ­INT 0 (Divider0) 0004H 1st
INT 1 (Timer 0) 0008H 2nd
INT 2 (Port RC) 000CH 3rd
INT 3 (Divider1) 0014H 4th
INT 4 (Timer 1) 0020H 5th
JP Instruction XXXXH ­Subroutine Call XXXXH -

6.2 Stack Register (STACK)

The stack register is organized as 49 bits x 16 levels (first-in, last-out). When either a call subroutine
or an interrupt is executed, the program counter will be pushed onto the stack register automatically.
At the end of a call subroutine or an interrupt service subroutine, the RTN instruction must be
executed to pop the contents of the stack register into the program counter. (Refer to Table 8)
When the stack register is pushed over the sixteen levels, the contents of the first level will be lost. In
other words, the stack register is always sixteen levels deep.

6.3 Program Memory (ROM)

The read-only memory (ROM) is used to store program codes; and the look-up table is arranged as
65536 x 4 bits. The program ROM is divided into eight pages; the size of each page is 2048 x 16 bits.
So the total ROM size is 16384 x 16 bits. Before the jump or subroutine call instructions are to be
executed, the destination ROM page must be determined firstly. The ROM page can be selected by
executing the MOV ROMPR,#I or MOV ROMPR, R instruction. But the branch decision instructions
(e.g. JB0, SKB0, JZ, JC, ...) must jump to the same ROM page which the branch decision instructions
are in. The whole ROM can store both instruction codes and the look-up table. Each look-up table
element is composed of 4 bits, so the look-up table can be addressed up to 65536 elements.
Instruction MOVC R is used to read the look-up table content and transfer table data to the RAM. But
before reading the addressed look-up table content, the content of the look-up table pointer (TAB)
must be determined firstly. The address of the look-up table element is allocated by the content of
TAB. The MOV TAB0 (TAB1, TAB2, TAB3), R instructions are used to allocate the address of the
wanted look-up table element. The TAB0 register stores the LSB 4 bits of the look-up table address.

Publication Release Date: April 2000

- 7 - Revision A1

Preliminary W742E81A/W742C81A

:

:

:

:

:

:

:

:

:

:

:

:

The organization of the program memory is shown in Figure 6-1

16 bits

Look-up table address:

0000H

:

0FFFH

Look-up table address:

2000H

:

2FFFH

Look-up table address:

3000H

:

3FFFH

Look-up table address:

E000H

:

EFFFH

Look-up table address:

F000H

:

FFFFH

16384 x 16 bits

Each element (4 bits) of the look-up table

Look-up table address:

1000H

:

1FFFH

1st page

2nd page

8th page

0000H

03FFH
0400H

07FFH
0800H

0BFFH
0C00H

0FFFH

3800H

3BFFH
3C00H

3FFFH

.

Figure 6-1 Program Memory Organization

6.3.1 ROM Page Register (ROMPR)

The ROM page register is organized as a 4-bit binary register. The bit descriptions are as follows:

0123

Note: W means write only.

ROMPR

W

Bit 3 is reserved.
Bit 2, Bit 1, Bit 0 ROM page preselect bits:
000 = ROM page 0 (0000H - 07FFH)

001 = ROM page 1 (0800H - 0FFFH)
010 = ROM page 2 (1000H - 17FFH)
011 = ROM page 3 (1800H - 1FFFH)
100 = ROM page 4 (2000H - 27FFH)
101 = ROM page 5 (2800H - 2FFFH)
110 = ROM page 6 (3000H - 37FFH)
111 = ROM page 7 (3800H - 3FFFH)

- 8 -

W

W

Preliminary W742E81A/W742C81A

:

:

:

6.4 Data Memory (RAM)

6.4.1 Architecture

The static data memory (RAM) used to store data is arranged as 2048 × 4 bits. The data RAM is
divided into sixteen banks; each bank has 128 × 4 bits. Executing the MOV DBKR,WR or MOV
DBKR,#I instruction can determine which data bank is used. The data memory can be addressed
directly or indirectly. But the data bank must be confirmed firstly; and the page in the data bank will
be done in the indirect addressing mode, too. In indirect addressing mode, each data bank will be
divided into eight pages. Before the data memory is addressed indirectly, the page which the data
memory is in must be confirmed. The organization of the data memory is shown in Figure 6-2.

2048

addresses

000H

(or Working Registers bank)

07FH
080H

(or Working Registers bank)

0FFH

780H
7FFH

4 bits

1st data bank

2nd data bank

3rd data bank

:
:

16th data bank

2048 * 4 bits

Figure 6-2 Data Memory Organization

1st data RAM page

2nd data RAM page

3rd data RAM page

8th data RAM page

(or 1st WR page)

(or 2nd WR page)

(or 3rd WR page)

:
:

(or 8th WR page)

00H
0FH

10H
1FH

20H
2FH

70H
7FH

:

:

:

:

The 1st and 2nd data bank (00H to 7FH & 80H to FFH) in the data memory can also be used as the
working registers (WR). It is also divided into sixteen pages. Each page contains 16 working registers.
When one page is used as WR, the others can be used as the normal data memory. The WR page
can be switched by executing the MOV WRP,R or MOV WRP,#I instruction. The data memory cannot
operate directly with immediate data, but the WR can do. The relationship between data memory
locations and the page register (PAGE) in indirect addressing mode is described in the next sub­section.

6.4.2 Page Register (PAGE)

The page register is organized as a 4-bit binary register. The bit descriptions are as follows:

0123

Note: R/W means read/write available.

PAGE

R/W R/W R/W

Bit 3 is reserved.
Bit 2, Bit 1, Bit 0 Indirect addressing mode preselect bits:

000 = Page 0 (00H - 0FH)

Publication Release Date: April 2000

- 9 - Revision A1

Preliminary W742E81A/W742C81A

001 = Page 1 (10H - 1FH)
010 = Page 2 (20H - 2FH)
011 = Page 3 (30H - 3FH)
100 = Page 4 (40H - 4FH)
101 = Page 5 (50H - 5FH)
110 = Page 6 (60H - 6FH)
111 = Page 7 (70H - 7FH)

6.4.3 WR Page Register (WRP)

The WR page register is organized as a 4-bit binary register. The bit descriptions are as follows:

0123

Note: R/W means read/write available.

Bit 3, Bit 2, Bit 1, Bit 0 Working registers page preselect bits:
0000 = WR Page 0 (00H - 0FH)

0001 = WR Page 1 (10H - 1FH)
0010 = WR Page 2 (20H - 2FH)
0011 = WR Page 3 (30H - 3FH)
0100 = WR Page 4 (40H - 4FH)
0101 = WR Page 5 (50H - 5FH)
0110 = WR Page 6 (60H - 6FH)
0111 = WR Page 7 (70H - 7FH)
1000 = WR Page 8 (80H - 8FH)
1001 = WR Page 9 (90H - 9FH)
1010 = WR Page A (A0H - AFH)
1011 = WR Page B (B0H - BFH)
1100 = WR Page C (C0H - CFH)
1101 = WR Page D (D0H - DFH)
1110 = WR Page E (E0H - EFH)
1111 = WR Page F (F0H - FFH)

WRP

R/W

R/W R/W R/W

6.4.4 Data Bank Register (DBKR)

The data bank register is organized as a 4-bit binary register. The bit descriptions are as follows:

0123

Note: R/W means read/write available.

DBKR

R/W

R/W R/W R/W

- 10 -

Preliminary W742E81A/W742C81A

Bit 3, Bit 2, Bit 1, Bit 0 Data memory bank preselect bits:
0000 = Data bank 0 (000H - 07FH)
0001 = Data bank 1 (080H - 0FFH)
0010 = Data bank 2 (100H - 17FH)
0011 = Data bank 3 (180H - 1FFH)
0100 = Data bank 4 (200H - 27FH)
0101 = Data bank 5 (280H - 2FFH)
0110 = Data bank 6 (300H - 37FH)
0111 = Data bank 7 (380H - 3FFH)
1000 = Data bank 8 (400H - 47FH)
1001 = Data bank 9 (480H - 4FFH)
1010 = Data bank A (500H - 57FH)
1011 = Data bank B (580H - 5FFH)
1100 = Data bank C (600H - 67FH)
1101 = Data bank D (680H - 6FFH)
1110 = Data bank E (700H - 77FH)
1111 = Data bank F (780H - 7FFH)

6.5 Accumulator (ACC)

The accumulator (ACC) is a 4-bit register used to hold results from the ALU and transfer data
between the memory, I/O ports, and registers.

6.6 Arithmetic and Logic Unit (ALU)

This is a circuit which performs arithmetic and logic operations. The ALU provides the following
functions:

•

Logic operations: ANL, XRL, ORL

•

Branch decisions: JB0, JB1, JB2, JB3, JNZ, JZ, JC, JNC, DSKZ, DSKNZ, SKB0, SKB1, SKB2,

SKB3

•

Shift operations: SHRC, RRC, SHLC, RLC

•

Binary additions/subtractions: ADC, SBC, ADD, SUB, ADU, DEC, INC

After any of the above instructions are executed, the status of the carry flag (CF) and zero flag (ZF) is
stored in the internal registers. CF can be read out by executing MOV R, CF.

6.7 Main-Oscillator

The W742E81A/W742C81A provides a crystal or RC oscillation circuit to generate the system clock
through external connections. If a crystal oscillator is used, The 3.58 MHz or 400KHz crystal must
be connected to XIN1 and XOUT1, and a capacitor must be connected to XIN1 and VSS if an accurate
frequency is needed.

Publication Release Date: April 2000

- 11 - Revision A1

Preliminary W742E81A/W742C81A

XIN1

Crystal

3.58 MHz
or

400 KHz

Figure 6-3 System Clock Oscillator Configuration

XOUT1

or

XIN1

XOUT1

6.8 Sub-Oscillator

The sub-oscillator is used in dual-clock operation mode. In the sub-oscillator application, just only the
32768 Hz crystal could be connected to XIN2 and XOUT2, and it would not be oscillated in STOP
mode.

6.9 Dividers

Each divider is organized as a 14-bit binary up-counter designed to generate periodic interrupts.
When the main oscillator starts action, the Divider0 is incremented by each clock (F
overflow occurs, the Divider0 event flag is set to 1 (EVF.0 = 1). Then, if the Divider0 interrupt enable
flag has been set (IEF.0 = 1), the interrupt is executed, while if the hold release enable flag has been
set (HEF.0 = 1), the hold state is terminated. And the last 4-stage of the Divider0 can be reset by
executing CLR DIVR0 instruction.

If the sub-oscillator starts action, the Divider1 is incremented by each clock (Fs in dual-clock mode or
Fosc/128 in single-clock mode). When an overflow occurs, the Divider1 event flag is set to 1 (EVF.4
= 1). Then, if the Divider1 interrupt enable flag has been set (IEF.4 = 1), the interrupt is executed,
while if the hold release enable flag has been set (HEF.4 = 1), the hold state is terminated. And the
last 4-stage of the Divider1 can be reset by executing CLR DIVR1 instruction. Same as EVF.0, the
EVF.4 is set to 1 periodically. But there are two period time (125 mS & 500mS) that can be selected
by setting the SCR.3 bit. When SCR.3 = 0 (default), the 500 mS period time is selected; SCR.3 = 1,
the 125 mS period time is selected.

OSC

). When an

6.10 Dual-clock operation

This operation mode is selected by option code. In the dual-clock mode, the clock source of the LCD
frequency selector should be the sub-oscillator clock (32768 Hz) only. But in the signal-clock mode,
the clock source of the LCD frequency selector will be Fm/128(Fm : main oscillator clock, See figure

So before the STOP instruction is executing, the LCD must be turned off in the signal-

6-4).

clock mode or dual-clock mode

In this dual-clock mode, the normal operation is performed by generating the system clock from the
main-oscillator clock (Fm). As required, the slow operation can be performed by generating the
system clock from the sub-oscillator clock (Fs). The exchange of the normal operation and the slow
operation is performed by resetting or setting the bit 0 of the System clock Control Register (SCR). If
the SCR.0 is reset to 0, the clock source of the system clock generator is main-oscillator clock; if the
SCR.0 is set to 1, the clock source of the system clock generator is sub-oscillator clock. In the dual­clock mode, the main-oscillator can stop oscillating when the STOP instruction is executing or the
SCR.1 is set to 1.

.

- 12 -

Preliminary W742E81A/W742C81A

When the SCR is set or reset, we must care the following cases:

1. X000B → X011B: we should not exchange the F
simultaneously. We could first exchange the F

OSC

oscillator. So it should be X000B→X001B→X011B.

2. X011B → X000B: we should not enable Fm and exchange the F
simultaneously. We could first enable the main-oscillator; the 2nd step is calling a delay subroutine
to wait the main-oscillator oscillating stably; then exchange the F
step. So it should be X011B→X001B→delay the Fm oscillating stably time→X000B. The

suggestion of the Fm oscillating stably time is 3.5 mS for 455 KHz and 0.8ms for 4 MHz.
We must remember that the X010B state is inhibitive, because it will induce the system shutdown.
The organization of the dual-clock operation mode is shown in Figure 6-4.

SCR.0

XIN1

XOUT1

SCR.1

enable/disable

Main Oscillator

STOP

Fm
Fs

Fosc

OSC

from Fm into Fs and disable Fm

from Fm into Fs, then disable the main-

OSC

from Fs into Fm

OSC

from Fs into Fm is the last

HOLD

T1

System Clock

Generator

T2
T3
T4

Divider 0

XIN2

XOUT2

Sub-Oscillator

Dual/Single Colck
Option code is 1/0

Fs or Fosc/128

SCR : System clock Control Register ( default = 00H )

Bit0Bit1Bit3

Daul clock operation mode :

- SCR.0=0, Fosc=Fm : SCR.0=1, Fosc=Fs

- Flcd=Fs, In STOP mode LCD work continue.

Figure 6-4 Organization of the dual-clock operation mode

LCD Frequency

Divider 1

0 : Fosc = Fm
1 : Fosc = Fs
0 : Fm enable
1 : Fm disable

0 : 14 bit
1 : 12 bit

Selector

SCR.3(14/12 bit)

Fosc/128

INT4
HCF.4

F

LCD

Publication Release Date: April 2000

- 13 - Revision A1

Preliminary W742E81A/W742C81A

S

RRR

R

S

6.11 WatchDog Timer (WDT) and WatchDog Timer Register(WDTR)

The watchdog timer (WDT) is organized as a 4-bit up counter designed to prevent the program from
unknown errors. When the corresponding option code bit of the WDT set to 1, the WDT is enabled,
and if the WDT overflows, the chip will be reset. At initial reset, the input clock of the WDT is

OSC

F

/2048. The input clock of the WDT can be switched to F
WDTR.3 to 1. The contents of the WDT can be reset by the instruction CLR WDT. In normal
operation, the application program must reset WDT before it overflows. A WDT overflow indicates
that operation is not under control and the chip will be reset. The WDT overflow period is 1 S when
the sub-system clock (Fs) is 32 KHz and WDT clock input is Fs/2048. When the corresponding option
code bit of the WDT set to 0, the WDT function is disabled. The organization of the Divider0 and
watchdog timer is shown in Figure 6-5.

OSC

/16384 (or F

OSC

/2048) by setting

Fosc

Q1 Q2 Q9 Q10 Q11 Q12

Fosc/16384
Fosc/2048

Fss/16384
Fss/2048

Q1 Q2 Q9 Q10 Q11 Q12

Fss=Fs or Fosc/128

Divider0

...

WDTR.3

Divider1

...

Q13

Option code is "0"

WDTR.2

Option code is "1"

Q13

SCR.3

Q14

Disable

Enable

Q14

EVF.0

Q

R

WDT

Qw1 Qw2 Qw4Qw3

Q

R

EVF.4

HEF.0

IEF.0

1. Reset

2. CLR EVF,#01H

3. CLR DIVR0

Overflow signal

1. Reset

2. CLR WDT

HEF.4
IEF.4

Hold mode release
(HCF.0)

Divider interrupt (INT0)

System Reset

Hold mode release
(HCF.4)

Divider interrupt
(INT1)

1.

2. CLR EVF,#10H

3. CLR DIVR1

Figure 6-5 Organization of Divider0, Divider1 and WatchDog Timer

- 14 -

Preliminary W742E81A/W742C81A

0123

Note: R/W means read/write available, R means read only.
Power On reset default is : 0000

Bit 3 = 0 F
= 1 F

WDTR

OSC/
OSC/

R/W R/W

2048(Select Divider0) or Fss/2048(Select Divider1) as the WDT source.
16384(Select Divider0) or Fss/16384(Select Divider1) as the WDT source.

R/W R

Bit 2 = 0 Select Divider0.
= 1 Select Divider1.
Bit 1 = 0 Refer to Table 2.
= 1 Refer to Table 2.
Bit 0 = 0 No time out.
= 1 Time out.

WDTR.0 will be set to one when WDT time out and can be reset to zero by:
Power On Reset, RESET pin, CLR WDT
Table 2 The bit 1 of WatchDog Timer Register (WDTR) reset item

RESET ITEM WDTR.1 = 1 WDTR.1 = 0

Program Counter (PC) 0000H 0000H
Stack Pointer (SP) - Reset
ROMPR, PAGE, DBKR, WRP, ACC, CF, ZF,

SCR registers
IEF, HEF, SEF, HCF, PEF, EVF flags IEF = Reset Reset
DIV0, DIV1 - Reset
TM0, TM1, MR0, MR1 registers - Reset
Timer 0 input clock - FOSC/4
Timer 1 input clock - FOSC
MFP output - Low
PM0 register - Reset
PM1, PM2, PM5 registers - Set (1111B)
PSR0 register - Reset
Input/output ports RA, RB, RD - Input mode
Output ports RE, RF - High
RA, RB ports output type - CMOS type
RC port pull-high resistors - Disable
Input clock of the watchdog timer - FOSC/2048
DTMF output - Hi-Z
BUZCR register - Reset
FLCD - Q5 to Q9 Reset
LCD display - OFF
LCDR - Reset
Segment output mode - LCD drive output

-: keep the status
Note: SCR.2 is reserved

- Reset

Publication Release Date: April 2000

- 15 - Revision A1

Preliminary W742E81A/W742C81A

6.12 Timer/Counter

6.12.1 Timer 0 (TM0)

Timer 0 (TM0) is a programmable 8-bit binary down-counter. The specified value can be loaded into
TM0 by executing the MOV TM0L(TM0H),R instructions. When the MOV TM0L(TM0H),R instructions
are executed, it will stop the TM0 down-counting (if the TM0 is down-counting) and reset the MR0.3 to
0, and the specified value can be loaded into TM0. Then we can set MR0.3 to 1, that will cause the
event flag 1 (EVF.1) is reset and the TM0 starts to count. When it decreases and underflow to FFH,
Timer 0 stops operating and generates an underflow (EVF.1 = 1). Then, if the Timer 0 interrupt
enable flag has been set (IEF.1 = 1), the interrupt is executed, while if the hold release enable flag 1
has been set (HEF.1 = 1), the hold state is terminated. The Timer 0 clock input can be set as

OSC

F

/1024 or F

OSC

F

/4. The organization of Timer 0 is shown in Figure 6-6.

OSC

/4 by setting MR0.0 to 1 or resetting MR0.0 to 0. The default timer value is

If the Timer 0 clock input is F
Desired Timer 0 interval = (preset value +1) × 4 × 1/F
If the Timer 0 clock input is F

OSC

OSC

/4:

OSC

/1024:

Desired Timer 0 interval = (preset value +1) × 1024 × 1/F

Preset value: Decimal number of Timer 0 preset value

OSC

F

: Clock oscillation frequency

1. Reset

2. CLR EVF,#02H

3. Reset MR0.3 to 0

4.MOV TM0L,R or MOV TM0H,R

MR0.0

Fosc/1024

Fosc/4

Set MR0.3 to 1

Disable

8-Bit Binary

Down Counter

(Timer 0)

Enable

MOV TM0H,R MOV TM0L,R

4

4

S
R

Q

OSC

EVF.1

HEF.1
IEF.1

Hold mode release (HCF.1)

Timer 0 interrupt (INT1)

1. Reset

2. CLR EVF,#02H

3.Set MR0.3 to 1

Figure 6-6 Organization of Timer 0

- 16 -

Preliminary W742E81A/W742C81A

6.12.2 Timer 1 (TM1)

Timer 1 (TM1) is also a programmable 8-bit binary down counter, as shown in Figure 6-7. Timer 1
can be used as to output an arbitrary frequency to the MFP pin. The input clock of Timer 1 can be
one of three sources: F

OSC

mode register 1 (MR1). At initial reset, the Timer 1 clock input is F
MOV TM1H,R instruction is executed, the specified data are loaded into the auto-reload buffer; but
the TM1 down-counting will keep going on. If the bit 3 of MR1 is set (MR1.3 = 1), the content of the
auto-reload buffer will be loaded into the TM1 down counter, and Timer 1 starts to down count, and
the event flag 7 is reset (EVF.7 = 0). When the timer decreases and underflow to FFH, it will generate
an underflow (EVF.7 = 1) and be auto-reloaded with the specified data, after which it will continue to
count down. Then, if interrupt enable flag 7 has been set to 1 (IEF.7 = 1), an interrupt is executed; if
hold mode release enable flag 7 is set to 1 (HEF.7 = 1), the hold state is terminated. The specified
frequency of Timer 1 can be delivered to the MFP output pin by programming bit 2 of MR1. Bit 3 of
MR1 can be used to make Timer 1 stop or start counting.

In a case where Timer 1 clock input is FT:
Desired Timer 1 interval = (preset value +1) / FT
Desired frequency for MFP output pin = F
Preset value: Decimal number of Timer 1 preset value

OSC

F

: Clock oscillation frequency

/64, F

OSC

, or Fs. The source can be selected by setting bit 0 and bit 1 of

OSC

. When the MOV TM1L, R or

T

÷

(preset value + 1) ÷ 2 (Hz)

(Timer 1)

MOV TM1L,R

4

8 bits

8 bits

Reset

Underflow signal

Set

MR1.3 to 1

circuit

Reset

S

Q

R

EVF.7

1. Reset

2. INT7 accept

3. CLR EVF, #80H

4. Set MR1.3 to 1

2

MFP

output pin

MFP
signal

BUZCR.0

Fosc/64

Fosc

Fs

MR1.0

MR1.1

F

MR1.3

T

MOV TM1H,R

4

Auto-reload buffer

Enable

8-Bit Binary

Down Counter

Disable

MOV WR,TM1

Figure 6-7 Organization of Timer 1

Publication Release Date: April 2000

- 17 - Revision A1

Preliminary W742E81A/W742C81A

For example, when FT equals 32768 Hz, depending on the preset value of TM1, the MFP pin will
output a single tone signal in the tone frequency range from 64 Hz to 16384 Hz. The relation between
the tone frequency and the preset value of TM1 is shown in the table below.

MOV WR,TM1 can read back the content of TM1, It will save the TM1 MSB to WR and the TM1 LSB
to ACC.

Table 3 The relation between the tone frequency and the present value of TM1

3rd octave 4th octave 5th octave

Tone

frequency

C

130.81

#

C

138.59

D

T
O
N

E

Note: Central tone is A4 (440 Hz).

146.83

#

D

155.56

E

164.81

F

174.61

#

F

185.00

G

196.00

#

G

207.65

A

220.00

#

A

233.08

B

246.94

TM1 preset value
& MFP frequency

7CH
75H
6FH
68H
62H
5DH
58H
53H
4EH
49H
45H
41H

6.12.3 Mode Register 0 (MR0)

131.07

138.84

146.28

156.03

165.49

174.30

184.09

195.04

207.39

221.40

234.05

248.24

Tone

frequency

261.63

277.18

293.66

311.13

329.63

349.23

369.99

392.00

415.30

440.00

466.16

493.88

TM1 preset value
& MFP frequency

3EH
3AH
37H
34H
31H
2EH
2BH
29H
26H
24H
22H
20H

260.06

277.69

292.57

309.13

327.68

372.36

390.09

420.10

443.81

442.81

468.11

496.48

Tone

frequency

523.25

554.37

587.33

622.25

659.26

698.46

739.99

783.99

830.61

880.00

932.23

987.77

TM1 preset value
& MFP frequency

1EH

528.51

1CH

564.96

1BH

585.14

19H

630.15

18H

655.36

16H

712.34

15H

744.72

14H

780.19

13H

819.20

12H

862.84

11H

910.22

10H

963.76

Mode Register 0 is organized as a 4-bit binary register (MR0.0 to MR0.3). MR0 can be used to control
the operation of Timer 0. The bit descriptions are as follows:

0123

Note: W means write only.

MR0

W

Bit 0 = 0 The fundamental frequency of Timer 0 is F
= 1 The fundamental frequency of Timer 0 is F

OSC
OSC

W

/4.

/1024.
Bit 1 & Bit 2 are reserved
Bit 3 = 0 Timer 0 stops down-counting.
= 1 Timer 0 starts down-counting.

- 18 -

Preliminary W742E81A/W742C81A

6.12.4 Mode Register 1 (MR1) & MFP Control Pin (BUZCR)

Mode Register 1 is organized as a 4-bit binary register (MR1.0 to MR1.3). MR1 can be used to control
the operation of Timer 1. The bit descriptions are as follows:

0123

Note: W means write only.

Bit 0 = 0 The internal fundamental frequency of Timer 1 is F
= 1 The internal fundamental frequency of Timer 1 is F
Bit 1 = 0 The fundamental frequency source of Timer 1 is the internal clock.
= 1 The fundamental frequency source of Timer 1 is the sub-oscillator frequency Fs (32768

Hz).
Bit 2 is reserved.
Bit 3 = 0 Timer 1 stops down-counting.
= 1 Timer 1 starts down-counting.

MFP control pin is organized as a 4-bit binary register.

Note: W means write only.

Bit 0 = 0 The specified waveform of the MFP generator is delivered to the MFP output pin.
= 1 The specified frequency of Timer 1 is delivered to the MFP output pin.
Bit 1, Bit 2 & Bit 3 are reserved.

MR1

BUZCR

WW W W

OSC

.

OSC

/64.

W

0123

6.13 Interrupts

The W742E81A/W742C81A provides four internal interrupt sources (Divider 0, Divider 1, Timer 0,
Timer 1) and one external interrupt source (port RC). Vector addresses for each of the interrupts are
located in the range of program memory (ROM) addresses 004H to 020H. The flags IEF, PEF, and
EVF are used to control the interrupts. When EVF is set to "1" by hardware and the corresponding bits
of IEF and PEF have been set by software, an interrupt is generated. When an interrupt occurs, all of
the interrupts are inhibited until the EN INT or MOV IEF,#I instruction is invoked. The interrupts can
also be disabled by executing the DIS INT instruction. When an interrupt is generated in hold mode,
the hold mode will be released momentarily and interrupt subroutine will be executed. After the RTN
instruction is executed in an interrupt subroutine, the µC will enter hold mode again. The operation
flow chart is shown in Figure 6-9. The control diagram is shown in Figure 6-9.

Publication Release Date: April 2000

- 19 - Revision A1

Preliminary W742E81A/W742C81A

Divider 0

overflow signal

Timer 0

underflow signal

RC port

signal change

Divider 1

overflow signal

Timer 1

underflow signal

SRQ

SRQ

SRQ

SRQ

SRQ

EN INT

MOV IEF,#I

EVF.0

EVF.1

EVF.2

EVF.4

EVF.7

Figure 6-8 Interrupt event control diagram

Initial Reset

IEF.0

IEF.1

IEF.2

IEF.4

IEF.7

Initial Reset
CLR EVF,#I instruction

Interrupt
Process

Circuit

Disable

Enable

Interrupt

Vector

Generator

DIS INT instruction

004H

008H

00CH

014H

020H

6.14 Stop Mode Operation

In stop mode, all operations of the µC cease, and the MFP pin is kept to high. The µC enters stop
mode when the STOP instruction is executed and exits stop mode when an external trigger is
activated (by a falling signal on the RC). When the designated signal is accepted, the µC awakens
and executes the next instruction. To prevent erroneous execution, the NOP instruction should follow
the STOP command. But In the dual-clock slow operation mode, the STOP instruction will also
disable the sub-oscillator oscillating; all operations of the µC cease.

6.14.1 Stop Mode Wake-up Enable Flag for RC Port (SEF)

The stop mode wake-up flag for port RC is organized as an 4-bit binary register (SEF.0 to SEF.3).
Before port RC may be used to make the device exit the stop mode, the content of the SEF must be
set first. The SEF is controlled by the MOV SEF, #I instruction. The bit descriptions are as follows:

3

Note: W means write only.

SEF w w w

SEF.0 = 1 Device will exit stop mode when falling edge signal is applied to pin RC.0
SEF.1 = 1 Device will exit stop mode when falling edge signal is applied to pin RC.1

- 20 -

012
w

Preliminary W742E81A/W742C81A

SEF.2 = 1 Device will exit stop mode when falling edge signal is applied to pin RC.2
SEF.3 = 1 Device will exit stop mode when falling edge signal is applied to pin RC.3

6.15 Hold Mode Operation

In hold mode, all operations of the µC cease, except for the operation of the oscillator, Timer, Divider,
LCD driver, DTMF generator and MFP generator. The µC enters hold mode when the HOLD
instruction is executed. The hold mode can be released in one of five ways: by the action of timer 0,
timer 1, divider 0, divider 1, the RC port. Before the device enters the hold mode, the HEF, PEF, and
IEF flags must be set to define the hold mode release conditions. For more details, refer to the
instruction-set table and the following flow chart.

Divider 0, Divider 1, Timer
0, Timer 1, Signal Change
at RC Port

In
HOLD
Mode?

Interrupt

Enable?

Yes

IEF

Flag Set?

Yes

Reset EVF Flag

Execute

Interrupt Service Routine

(Note)

Disable interrupt

HOLD

Note: The bit of EVF corresponding to the interrupt signal will be reset.

No

HEF

Flag Set?

NoYes

Interrupt

Enable?

Yes

IEF

Flag Set?

Yes

Reset EVF Flag

Execute

Interrupt Service Routine

YesNo

Disable interrupt

PC <- (PC+1)

NoNo

No

(Note)

Figure 6-9 Hold Mode and Interrupt Operation Flow Chart

Publication Release Date: April 2000

- 21 - Revision A1

Preliminary W742E81A/W742C81A

6.15.1 Hold Mode Release Enable Flag (HEF)

The hold mode release enable flag is organized as an 8-bit binary register (HEF.0 to HEF.7). The
HEF is used to control the hold mode release conditions. It is controlled by the MOV HEF, #I
instruction. The bit descriptions are as follows:

34567

012

Note: W means write only.

HEF.0 = 1 Overflow from the Divider 0 causes Hold mode to be released.
HEF.1 = 1 Underflow from Timer 0 causes Hold mode to be released.
HEF.2 = 1 Signal change at port RC causes Hold mode to be released.
HEF.3, HEF.5 & HEF.6 are reserved.
HEF.4 = 1 Overflow from the Divider 1 causes Hold mode to be released.
HEF.7 = 1 Underflow from Timer 1 causes Hold mode to be released.

HEF w w w w

w

6.15.2 Interrupt Enable Flag (IEF)

The interrupt enable flag is organized as a 8-bit binary register (IEF.0 to IEF.7). These bits are used
to control the interrupt conditions. It is controlled by the MOV IEF, #I instruction. When one of these
interrupts is accepted, the corresponding to the bit of the event flag will be reset, but the other bits are
unaffected. In interrupt subroutine, these interrupts will be disable till the instruction MOV IEF, #I or
EN INT is executed again. Otherwise, these interrupts can be disable by executing DIS INT
instruction. The bit descriptions are as follows:

w w

123

ww

4

7

Note: W means write only.

IEF.0 = 1 Interrupt 0 is accepted by overflow from the Divider 0.
IEF.1 = 1 Interrupt 1 is accepted by underflow from the Timer 0.
IEF.2 = 1 Interrupt 2 is accepted by a signal change at port RC.
IEF.3, IEF.5 & IEF.6 are reserved.
IEF.4 = 1 Interrupt 4 is accepted by overflow from the Divider 1.
IEF.7 = 1 Interrupt 7 is accepted by underflow from Timer 1.

IEF

56 0

w

6.15.3 Port Enable Flag (PEF)

The port enable flag is organized as 4-bit binary register (PEF.0 to PEF.3). Before port RC may be
used to release the hold mode or preform interrupt function, the content of the PEF must be set first.
The PEF is controlled by the MOV PEF, #I instruction. The bit descriptions are as follows:

- 22 -

Preliminary W742E81A/W742C81A

3

Note: W means write only.

PEF.0: Enable/disable the signal change at pin RC.0 to release hold mode or perform interrupt.
PEF.1: Enable/disable the signal change at pin RC.1 to release hold mode or perform interrupt.
PEF.2: Enable/disable the signal change at pin RC.2 to release hold mode or perform interrupt.
PEF.3: Enable/disable the signal change at pin RC.3 to release hold mode or perform interrupt.

PEF w w w

012
w

6.15.4 Hold Mode Release Condition Flag (HCF)

The hold mode release condition flag is organized as a 8-bit binary register (HCF.0 to HCF.7). It
indicates by which interrupt source the hold mode has been released, and is loaded by hardware. The
HCF can be read out by the MOVA R, HCFL and MOVA R, HCFH instructions. When any of the HCF
bits is "1," the hold mode will be released and the HOLD instruction is invalid. The HCF can be reset
by the CLR EVF or MOV HEF,#I (HEF = 0) instructions. When EVF and HEF have been reset, the
corresponding bit of HCF is reset simultaneously. The bit descriptions are as follows:

67

Note: R means read only.

HCF.0 = 1 Hold mode was released by overflow from the divider 0.
HCF.1 = 1 Hold mode was released by underflow from the timer 0.
HCF.2 = 1 Hold mode was released by a signal change at port RC.
HCF.3 is reserved.
HCF.4 = 1 Hold mode was released by overflow from the divider 1.
HCF.5 = 1 Hold mode was released by underflow from the timer 1.
HCF.6 and HCF.7 are reserved.

R RHCF

R R R

012345

6.15.5 Event Flag (EVF)

The event flag is organized as a 8-bit binary register (EVF.0 to EVF.7). It is set by hardware and reset
by CLR EVF,#I instruction or the occurrence of an interrupt. The bit descriptions are as follows:

67

Note: R means read only.

- 23 - Revision A1

R R REVF

Publication Release Date: April 2000

012345
RR

Preliminary W742E81A/W742C81A

RES

EVF.0 = 1 Overflow from divider 0 occurred.
EVF.1 = 1 Underflow from timer 0 occurred.
EVF.2 = 1 Signal change at port RC occurred.
EVF.3 is reserved.
EVF.4 = 1 Overflow from divider 1 occurred.
EVF.5 & EVF.6 are reserved.
EVF.7 = 1 Underflow from Timer 1 occurred.

6.16 Reset Function

The W742E81A/W742C81A is reset either by a power-on reset or by using the external
The initial state of the W742E81A/W742C81A after the reset function is executed is described below.

Table 4 The initial state after the reset function is executed

Program Counter (PC) 000H
WDTR registers Reset
BUZCR registers Reset
ACC, CF, ZF registers Reset
MR0, MR1, PAGE registers Reset
PSR0, SCR, TM0, TM1 registers Reset
IEF, HEF, HCF, PEF, EVF, SEF flags Reset
WRP, DBKR, PAGE registers Reset
Timer 0 input clock F
Timer 1 input clock F
MFP output Low
DTMF output Hi-Z
Input/output ports RA, RB, RD Input mode
Output port RE & RF High
RA, RB ports output type CMOS type
RC ports pull-high resistors Disable
Input clock of the watchdog timer F
LCD display OFF

OSC
OSC

OSC

/4

/2048

pin.

- 24 -

Preliminary W742E81A/W742C81A

6.17 Input/Output Ports RA, RB & RD

Port RA consists of pins RA.0 to RA.3. Port RB consists of pins RB.0 to RB.3. Port RD consists of
pins RD.0 to RD.3. At initial reset, input/output ports RA, RB and RD are all in input mode. When
RA, RB are used as output ports, CMOS or NMOS open drain output type can be selected by the
PM0 register. But when RD is used as output port, the output type is just fixed to be CMOS output
type. Each pin of port RA, RB and RD can be specified as input or output mode independently by the
PM1, PM2 and PM5 registers. The MOVA R, RA or MOVA R, RB or MOVA R, RD instructions
operate the input functions and the MOV RA, R or MOV RB, R or MOV RD, R operate the output
functions. For more details, refer to the instruction table and Figure 6-10 and Figure 6-11 .

Input/Output Pin of the RA(RB)

PM0.0(PM0.1)

DATA

BUS

DATA

BUS

Output
Buffer

Enable

MOV RA,R(MOV RB,R)
instruction

PM1.n (PM2.n)

Enable

MOVA R,RA(MOVA R,RB) instruction

Figure 6-10 Architecture of RA (RB) Input/Output Pins

Input/Output Pin of the RD

Output
Buffer

Enable

MOV RD,R instruction

PM5.n

Enable

MOVA R,RD instruction

I/O PIN

RA.n(RB.n)

I/O PIN

RD.n

Figure 6-11 Architecture of RD Input/Output pins

6.17.1 Port Mode 0 Register (PM0)

The port mode 0 register is organized as 4-bit binary register (PM0.0 to PM0.3). PM0 can be used to

Publication Release Date: April 2000

- 25 - Revision A1

Preliminary W742E81A/W742C81A

determine the structure of the input/output ports; it is controlled by the MOV PM0, #I instruction. The
bit descriptions are as follows:

3

012

Note: W means write only.

Bit 0 = 0 RA port is CMOS output type. Bit 0 = 1 RA port is NMOS open drain output type.
Bit 1 = 0 RB port is CMOS output type. Bit 1 = 1 RB port is NMOS open drain output type.
Bit 2 = 0 RC port pull-high resistor is disabled. Bit 2 = 1 RC port pull-high resistor is enabled.
Bit 3 is reserved.

PM0 w w w

w

6.17.2 Port Mode 1 Register (PM1)

The port mode 1 register is organized as 4-bit binary register (PM1.0 to PM1.3). PM1 can be used to
control the input/output mode of port RA. PM1 is controlled by the MOV PM1, #I instruction. The bit
descriptions are as follows:

3

Note: W means write only.

Bit 0 = 0 RA.0 works as output pin; Bit 0 = 1 RA.0 works as input pin
Bit 1 = 0 RA.1 works as output pin; Bit 1 = 1 RA.1 works as input pin
Bit 2 = 0 RA.2 works as output pin; Bit 2 = 1 RA.2 works as input pin
Bit 3 = 0 RA.3 works as output pin; Bit 3 = 1 RA.3 works as input pin
At initial reset, port RA is input mode (PM1 = 1111B).

PM1 w w w

012
w

6.17.3 Port Mode 2 Register (PM2)

The port mode 2 register is organized as 4-bit binary register (PM2.0 to PM2.3). PM2 can be used to
control the input/output mode of port RB. PM2 is controlled by the MOV PM2, #I instruction. The bit
descriptions are as follows:

- 26 -

012
w

3

Note: W means write only.

Bit 0 = 0 RB.0 works as output pin; Bit 0 = 1 RB.0 works as input pin
Bit 1 = 0 RB.1 works as output pin; Bit 1 = 1 RB.1 works as input pin
Bit 2 = 0 RB.2 works as output pin; Bit 2 = 1 RB.2 works as input pin
Bit 3 = 0 RB.3 works as output pin; Bit 3 = 1 RB.3 works as input pin
At initial reset, the port RB is input mode (PM2 = 1111B).

PM2 w w w

Preliminary W742E81A/W742C81A

6.17.4 Port Mode 5 Register (PM5)

The port mode 5 register is organized as 4-bit binary register (PM5.0 to PM5.3). PM5 can be used to
control the input/output mode of port RD. PM5 is controlled by the MOV PM5, #I instruction. The bit
descriptions are as follows:

3

012

Note: W means write only.

Bit 0 = 0 RD.0 works as output pin; Bit 0 = 1 RD.0 works as input pin
Bit 1 = 0 RD.1 works as output pin; Bit 1 = 1 RD.1 works as input pin
Bit 2 = 0 RD.2 works as output pin; Bit 2 = 1 RD.2 works as input pin
Bit 3 = 0 RD.3 works as output pin; Bit 3 = 1 RD.3 works as input pin
At initial reset, the port RD is input mode (PM5 = 1111B).

PM5 w w w

w

6.18 Input Ports RC

Port RC consists of pins RC.0 to RC.3. Each pin of port RC can be connected to a pull-up resistor,
which is controlled by the port mode 0 register (PM0). When the PEF, HEF, and IEF corresponding to
the RC port are set, a signal change at the specified pins of port RC will execute the hold mode
release or interrupt subroutine. Port status register 0 (PSR0) records the status of ports RC, i.e., any
signal changes on the pins that make up the ports. PSR0 can be read out and cleared by the MOV R,
PSR0, and CLR PSR0 instructions. In addition, the falling edge signal on the pin of port RC specified
by the instruction MOV SEF, #I will cause the device to exit the stop mode. Refer to Figure 6-12
and the instruction table for more details.

Publication Release Date: April 2000

- 27 - Revision A1

RC.0

PM0.2

DATA BUS

Signal
change
detector

PEF.0

Preliminary W742E81A/W742C81A

PSR0.0

D

Q

ck

R

RC.1

RC.2

RC.3

PM0.2

PM0.2

PM0.2

Signal
change
detector

Signal
change
detector

Signal
change
detector

Falling
Edge
detector

Falling
Edge
detector

Falling
Edge
detector

Falling
Edge
detector

PEF.1

PEF.2

PEF.3

SEF.0

SEF.1

SEF.2

SEF.3

EVF.2

PSR0.1

D

Q

ck

R

D

Q

ck

R

HEF.2

HCF.2

IEF.2

INT 2

PSR0.2

D

Q

ck

R

CLR EVF, #I

Reset

D

ck

PSR0.3

Q

R

Reset
MOV PEF, #I
CLR PSR0

To Wake Up Stop Mode

Figure 6-12 Architecture of Input Ports RC

6.18.1 Port Status Register 0 (PSR0)

Port status register 0 is organized as 4-bit binary register (PSR0.0 to PSR0.3). PSR0 can be read or
cleared by the MOVA R, PSR0, and CLR PSR0 instructions. The bit descriptions are as follows:

0123

Note: R means read only.

PSR0

RR R R

- 28 -

Preliminary W742E81A/W742C81A

1

2 3 A

4 5 6 B

7 8 9 C

0 # D

R1

R2

R3

R4 C1

C4

Bit 0 = 1 Signal change at RC.0
Bit 1 = 1 Signal change at RC.1
Bit 2 = 1 Signal change at RC.2
Bit 3 = 1 Signal change at RC.3

6.19 Output Port RE & RF

Output port RE is used as an output of the internal RT port. When the MOV RE, R instruction is
executed, the data in the RAM will be output to port RT through port RE. It provides a high sink
current to drive an LED. RF port is just used as a output port. When the MOV RF, R instruction is
executed, the data in the RAM will be output to RF.

6.20 DTMF Output Pin (DTMF)

This pin should output the dual tone multi-frequency signal from the DTMF generator. There is the
DTMF register that can specify the wanted low/high frequency. And control whether the dual tone will
be output or not. The tones are divided into two groups (Row group and Col group) and one tone from
each group is selected to represent a digit. The relation between the DTMF signal and the
corresponding touch tone keypad is shown in Figure 6-13.

C2 C3

Row/Col Frequency

R1 697 Hz
R2 770 Hz
R3 852 Hz
R4 941 Hz
C1 1209 Hz
C2 1336 Hz
C3 1477 Hz
C4 1633 Hz

Figure 6-13 The relation between the touch tone keypad and the frequency

6.20.1 DTMF register

DTMF register is organized as 4-bit binary register. By controlling the DTMF register, one tone of the
low/high group can be selected. The MOV DTMF,R instruction can specify the wanted tones. The bit
descriptions are as follows:

0123

Note: W means write only.

DTMF

WW W W

Publication Release Date: April 2000

- 29 - Revision A1

Preliminary W742E81A/W742C81A

B3 B2 B1 B0 SELECTED TONE

X X 0 0 1209 Hz

High X X 0 1 1336 Hz
Group X X 1 0 1477 Hz

X X 1 1 1633 Hz
0 0 X X 697 Hz

Low 0 1 X X 770 Hz
Group 1 0 X X 852 Hz

1 1 X X 941 Hz

Note: X means this bit do not care.

6.20.2 Dual Tone Control Register (DTCR)

Dual tone control register is organized as 4-bit binary register. The output of the dual or single tone
will be controlled by this register. The MOV DTCR,#I instruction can specify the wanted status. The bit
descriptions are as follows:

0123

Note: W means write only.

Bit 0 = 1 Low group tone output is enabled.
Bit 1 = 1 High group tone output is enabled.
Bit 2 = 1 DTMF output is enabled. When Bit 2 is reset to 0, the DTMF output pin will be Hi-Z

state.
Bit 3 is reserved.

DTCR

W W W

6.21 MFP Output Pin (MFP)

The MFP output pin can output the Timer 1 clock or the modulation frequency; the output of the pin is
determined by bit 0 of BUZCR (BUZCR.0). The organization of MR1 is shown in Figure 6-7. When
bit 0 of BUZCR is reset to "0," the MFP output can deliver a modulation output in any combination of
one signal from among DC, 4096 Hz, 2048 Hz, and one or more signals from among 128 Hz, 64 Hz,
8 Hz, 4 Hz, 2 Hz, or 1 Hz (when using a 32.768 KHz crystal). The MOV MFP, #I instruction is used to
specify the modulation output combination. The data specified by the 8-bit operand and the MFP
output pin are shown in next page.

- 30 -

Preliminary W742E81A/W742C81A

Table 5 The relation between the MFP output frequncy and the data specified by 8-bit operand

(Fosc = 32.768 KHz)

R7 R6 R5 R4 R3 R2 R1 R0 FUNCTION

0 0 0 0 0 1 0 0 8 Hz

0 1 0 0 0 1 0 0 8 Hz

1 0 0 0 0 1 0 0 2048 Hz * 8 Hz

1 1 0 0 0 1 0 0 4096 Hz * 8 Hz

0 0 0 0 0 0 Low level
0 0 0 0 0 1 128 Hz
0 0 0 0 1 0 64 Hz

0 0 1 0 0 0 4 Hz

0 1 0 0 0 0 2 Hz
1 0 0 0 0 0 1 Hz
0 0 0 0 0 0 High level
0 0 0 0 0 1 128 Hz
0 0 0 0 1 0 64 Hz

0 0 1 0 0 0 4 Hz
0 1 0 0 0 0 2 Hz
1 0 0 0 0 0 1 Hz
0 0 0 0 0 0 2048 Hz
0 0 0 0 0 1 2048 Hz * 128 Hz
0 0 0 0 1 0 2048 Hz * 64 Hz

0 0 1 0 0 0 2048 Hz * 4 Hz
0 1 0 0 0 0 2048 Hz * 2 Hz
1 0 0 0 0 0 2048 Hz * 1 Hz
0 0 0 0 0 0 4096 Hz
0 0 0 0 0 1 4096 Hz * 128 Hz
0 0 0 0 1 0 4096 Hz * 64 Hz

0 0 1 0 0 0 4096 Hz * 4 Hz
0 1 0 0 0 0 4096 Hz * 2 Hz
1 0 0 0 0 0 4096 Hz * 1 Hz

Publication Release Date: April 2000

- 31 - Revision A1

Preliminary W742E81A/W742C81A

6.22 LCD Controller/Driver

The W742E81A/W742C81A can directly drive an LCD with 40 segment output pins and 4 common
output pins for a total of 40 × 4 dots. The LCD driving mode is 1/3 bias 1/4 duty. The alternating
frequency of the LCD can be set as Fw/64, Fw/128, Fw/256, or Fw/512. The structure of the LCD
alternating frequency (F

Fs or Fosc/128
(By Dual or single
clock Option)

LCD

) is shown in the Figure 6-14.

Fw

Q1 Q2 Q3 Q4 Q5 Q6 Q7 Q8 Q9

Fw/64

Fw/128

Fw/256

Fw/512

Selector

F

LCD

Figure 6-14 LCD alternating frequency (FLCD) circuit diagram

Fw = 32.768 KHz, the LCD frequency is as shown in the table below.
Table 6 The relationship between the FLCD and the duty cycle

LCD FREQUENCY Fw/64 (512Hz) Fw/128 (256Hz) Fw/256 (128Hz) Fw/512 (64Hz)

1/4 DUTY 128 Hz 64 Hz 32 Hz 16 Hz

Corresponding to the 40 LCD drive output pins, there are 40 LCD data RAM segments. Instructions
such as MOV LPL,R, MOV LPH,R, MOV @LP,R, and MOV R,@LP are used to control the LCD data
RAM. The data in the LCD data RAM are transferred to the segment output pins automatically without
program control. When the bit value of the LCD data RAM is "1," the LCD is turned on. When the bit
value of the LCD data RAM is "0," LCD is turned off. The contents of the LCD data RAM (LCDR) are
sent out through the segment0 to segment39 pins by a direct memory access. The relation between
the LCD data RAM and segment/common pins is shown below.

Table 7 The reation between the LCDR and segment/common pins used as LCD drive output pins

COM3 COM2 COM1 COM0

LCD DATA RAM OUTPUT PIN BIT 3 BIT 2 BIT 1 BIT 0

LCDR00 SEG0 0/1 0/1 0/1 0/1
LCDR01 SEG1 0/1 0/1 0/1 0/1

:
:

:
:

:
:

:
:

:
:

:

:
LCDR26 SEG38 0/1 0/1 0/1 0/1
LCDR27 SEG39 0/1 0/1 0/1 0/1

- 32 -

Preliminary W742E81A/W742C81A

The LCDON instruction turns the LCD display on (even in HOLD mode), and the LCDOFF instruction
turns the LCD display off. At initial reset, all the LCD segments are unlit. When the initial reset state
ends, the LCD display is turned off automatically. To turn on the LCD display, the instruction LCDON
must be executed.

6.22.1 LCD RAM addressing method

There are 40 LCD RAMs (LCDR00 - LCDR27) that should be indirectly addressed. The LCD RAM
pointer (LP) is used to point to the address of the wanted LCD RAM. The LP is organized as 6-bit
binary register. The MOV LPL,R and MOV LPH,R instructions can load the LCD RAM address to the
LP from R. The MOV @LP,R and MOV R,@LP instructions can access the pointed LCD RAM
content.

6.22.2 The output waveforms for the LCD driving mode

1/3 bias 1/4 duty Lighting System (Example)
Normal Operating Mode

COM0

COM1

COM2

COM3

LCD driver
outputs for
only seg. on
COM0 side
being lit

LCD driver
outputs for
only seg. on
COM1 side
being lit

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

Publication Release Date: April 2000

- 33 - Revision A1

Continued

Preliminary W742E81A/W742C81A

LCD driver
outputs for
seg. on COM0,
COM1 sides
being lit

LCD driver
outputs for
seg. on COM1,
COM2,3 sides
being lit

LCD driver
outputs for
seg. on COM1
COM2 sides
being lit

LCD driver
outputs for
seg. on COM0
COM2,3 sides
being lit

LCD driver
outputs for
seg. on COM0
COM1,2,3 sides
being lit

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

VDD3
VDD2
VDD1
VSS

The power connections for the 1/3 bias 1/4 duty LCD driving mode are shown below.

1/3 Bias at VDD = 3.0 V

DH1

0.1uF

DH2

VSS

C
H

I
P

VDD

VDD1

VDD2

0.1uF

VDD = 3.0 V

- 34 -

6.23 Mode Description

Preliminary W742E81A/W742C81A

The built-in program code memory of the
memory can be programmed, erased and verified through the VPP, MODE and DATA pins.

W742E81A/W742C81A

is the EEPROM structure. This

7. ABSOLUTE MAXIMUM RATINGS

PARAMETER RATING UNIT

Supply Voltage to Ground Potential -0.3 to +7.0 V
Applied Input/Output Voltage -0.3 to +7.0 V
Power Dissipation 120 mW
Ambient Operating Temperature 0 to +70
Storage Temperature -55 to +150

Note: Exposure to conditions beyond those listed under Absolute Maximum Ratings may adversely affect the life and reliability
of the device.

°

C

°

C

8. DC CHARACTERISTICS

(VDD-VSS = 3.0 V, Fm = 3.58 MHz, Fs = 32.768 KHz, TA = 25° C, LCD on; unless otherwise specified)

PARAMETER SYM.

Op. Voltage VDD - 2.4 - 3.8 V

Op. Current (Crystal type) I

Op. Current (Crystal type) I

Hold Current (Crystal type) I

Hold Current (Crystal type) I

Stop Current (Crystal type) I

OP1

OP3

HM1

HM3

SM1

CONDITIONS MIN. TYP. MAX. UNIT

No load (Ext-V)

In dual-clock normal

operation

No load (Ext-V)

In dual-clock slow operation

and Fm is stopped

Hold mode No load (Ext-V)

In dual-clock normal

operation

Hold mode No load (Ext-V)

In dual-clock slow operation

and Fm is stopped

Stop mode No load (Ext-V)

In dual-clock normal

operation

- 0.9 2.5 mA

-

-

-

-

20

-

15

1

30

450

30

2

µ

A

µ

A

µ

A

µA

Publication Release Date: April 2000

- 35 - Revision A1

DC Characteristics, continued

Preliminary W742E81A/W742C81A

PARAMETER SYM.

Input Low Voltage VIL - VSS - 0.3

CONDITIONS MIN. TYP. MAX. UNIT

V

VDD

Input High Voltage VIH - 0.7

DD

V
MFP Output Low Voltage VML I
MFP Output High Voltage VMH I
Port RA, RB, RD and RF

ABL

V

I

OL

= 3.5 mA - - 0.4 V

OH

= 3.5 mA 2.4 - - V

OL

= 2.0 mA - - 0.4 V

- VDD V

Output Low Voltage
Port RA, RB, RD and RF

V

ABH

I

OH

= 2.0 mA 2.4 - - V

Output high Voltage
LCD Supply Current I
SEG0-SEG39 Sink

Current (Used as LCD

LCD

All Seg. ON - - 6

OL1

I

VOL = 0.4V

LCD

V

= 0.0V

90 - -

µ

A

µ

A

output)
SEG0-SEG39 Drive

Current

OH1

I

V

OH

V

LCD

= 2.4V

= 3.0V

90 - -

µ

A

(Used as LCD output)
Port RE Sink Current IEL V
Port RE Source Current IEH V
DTMF Output DC level V

TDC

DTMF Distortion THD

DTMF Output Voltage VTO Low group,

OL

= 0.9V 9 - - mA

OH

= 2.4V 0.4 1.2 - mA

RL = 5 KΩ,

DD

V

= 2.5 to 3.8V

RL = 5 KΩ,

DD

V

= 2.5 to 3.8V

1.1 - 2.8 V

- -30 -23 dB

130 150 170

mVrms

RL = 5 KΩ
Pre-emphasis Col/Row 1 2 3 dB
DTMF Output Sink Current ITL V
Pull-up Resistor RC Port RC 100 350 1000
RES Pull-up Resistor R

RES

- 20 100 500

TO

= 0.5V 0.2 - - mA

KΩ
KΩ

9. AC CHARACTERISTICS

PARAMETER SYM. CONDITIONS MIN. TYP. MAX. UNIT

Op. Frequency F
Instruction Cycle time TI One machine cycle - 4/F
Reset Active Width T
Interrupt Active Width T

OSC

Crystal type - 3.58 - MHz

OSC

- S

RAW

IAW

F

F

OSC

= 32.768 KHz 1 - -

OSC

= 32.768 KHz 1 - -

- 36 -

µS
µ

S

10. INSTRUCTION SET TABLE

SCR:

Preliminary W742E81A/W742C81A

Symbol Description

ACC: Accumulator
ACC.n: Accumulator bit n
WR: Working Register
WRP: WR Page Register
PAGE: Page Register
DBKR: Data Bank Register
ROMPR: ROM Page Register
MR0: Mode Register 0
MR1: Mode Register 1
PM0: Port Mode 0
PM1: Port Mode 1
PM2: Port Mode 2
PM5: Port Mode 5
PSR0: Port Status Register 0
R: Memory (RAM) of addres s R
WDTR: WatchDog Timer Register
LPL: LCD data RAM pointer
LPH: LCD data RAM pointer
R.n: Memory bit n of address R

System Control Register
BUZCR: Buzzer Control Register
RA: I/O Port RA
RC: I/O Port RC
DTMF: DTMF Register
DTCR: MTMF Control Pin
MFP: MFP Output Pin

Publication Release Date: April 2000

- 37 - Revision A1

Preliminary W742E81A/W742C81A

Symbol Description, continued

I: Constant parameter
L: Branch or Jump address
CF: Carry Flag
ZF: Zero Flag
PC: Program Counter
TM0L: Low nibble of the Timer 0 counter
TM0H: High nibble of the Timer 0 counter
TM1L: Low nibble of the Timer 1 counter
TM1H: High nibble of the Timer 1 counter
TAB0: Look-up table address buffer 0
TAB1: Look-up table address buffer 1
TAB2: Look-up table address buffer 2
TAB3: Look-up table address buffer 3
IEF.n: Interrupt Enable Flag n
HCF.n: HOLD mode release Condition Flag n
HEF.n: HOLD mode release Enable Flag n
SEF.n: STOP mode wake-up Enable Flag n
PEF.n: Port Enable Flag n
EVF.n: Event Flag n
! =: Not equal
&: AND
^: OR
EX: Exclusive OR

←

:
[PAGE*10H+()]: Contents of address PAGE (bit2, bit1, bit0)*10H+()
[P()]: Contents of port P

Transfer direction, result

- 38 -

Preliminary W742E81A/W742C81A

Machine code Mnemonic Function Flag affected W/C

Arithmetic

0001 1000 0xxx xxxx

0001 1100 iiii nnnn

0001 1001 0xxx xxxx

0001 1101 iiii nnnn

0000 1000 0xxx xxxx

0000 1100 iiii nnnn

0000 1001 0xxx xxxx

0000 1101 iiii nnnn

0010 1000 0xxx xxxx

0010 1100 iiii nnnn

0010 1001 0xxx xxxx

0010 1101 iiii nnnn

0001 1010 0xxx xxxx

0001 1110 iiii nnnn

0001 1011 0xxx xxxx

0001 1111 iiii nnnn

0000 1010 0xxx xxxx

0000 1110 iiii nnnn

0000 1011 0xxxxxxx

0000 1111 iiii nnnn

0100 1010 0xxx xxxx

0100 1010 1xxx xxxx

ADD R, ACC ACC←(R) + (ACC) ZF, CF 1/1
ADD WRn, #I ACC←(WRn) + I ZF, CF 1/1
ADDR R, ACC ACC, R←(R) + (ACC) ZF, CF 1/1
ADDR WRn, #I ACC, WRn←(WRn) + I ZF, CF 1/1
ADC R, ACC ACC←(R) + (ACC) + (CF) ZF, CF 1/1
ADC WRn, #I ACC←(WRn) + I + (CF) ZF, CF 1/1
ADCR R, ACC ACC, R←(R) + (ACC) + (CF) ZF, CF 1/1
ADCR WRn, #I ACC, WRn←(WRn) + I + (CF) ZF, CF 1/1
ADU R, ACC ACC←(R) + (ACC) ZF 1/1
ADU WRn, #I ACC←(WRn) + I ZF 1/1
ADUR R, ACC ACC, R←(R) + (ACC) ZF 1/1
ADUR WRn, #I ACC, WRn←(WRn) + I ZF 1/1
SUB R, ACC ACC←(R) - (ACC) ZF, CF 1/1
SUB WRn, #I ACC←(WRn) - I ZF, CF 1/1
SUBR R, ACC ACC, R←(R) - (ACC) ZF, CF 1/1
SUBR WRn, #I ACC, WR←(WR) - I ZF, CF 1/1
SBC R, ACC ACC←(R) - (ACC) - (CF) ZF, CF 1/1
SBC WRn, #I ACC←(WRn) - I - (CF) ZF, CF 1/1
SBCR R, ACC ACC, R←(R) - (ACC) - (CF) ZF, CF 1/1
SBCR WRn, #I ACC, WRn←(WRn) - I - (CF) ZF, CF 1/1
INC R ACC, R←(R) + 1 ZF, CF 1/1
DEC R ACC, R←(R) - 1 ZF, CF 1/1

Publication Release Date: April 2000

- 39 - Revision A1

Preliminary W742E81A/W742C81A

Instruction set, continued

Machine code Mnemonic Function Flag affected W/C

Logic

0010 1010 0xxx xxxx

0010 1110 iiii nnnn

0010 1011 0xxx xxxx

0010 1111 iiii nnnn

0011 1010 0xxx xxxx

0011 1110 iiii nnnn

0011 1011 0xxx xxxx

0011 1111 iiii nnnn

0011 1000 0xxx xxxx

0011 1100 iiii nnnn

0011 1001 0xxx xxxx

0011 1101 iiii nnnn

Branch

0111 0aaa aaaa aaaa

1000 0aaa aaaa aaaa

1001 0aaa aaaa aaaa

1010 0aaa aaaa aaaa

1011 0aaa aaaa aaaa

1110 0aaa aaaa aaaa

1100 0aaa aaaa aaaa

1111 0aaa aaaa aaaa

1101 0aaa aaaa aaaa

0100 1000 0xxx xxxx

0100 1000 1xxx xxxx

1010 1000 0xxx xxxx

1010 1000 1xxx xxxx

1010 1001 0xxx xxxx

1010 1001 1xxx xxxx

ANL R, ACC

ANL WRn, #I

ANLR R, ACC

ANLR WRn, #I

ORL R, ACC

ORL WRn, #I

ORLR R, ACC

ORLR WRn, #I

XRL R, ACC

XRL WRn, #I

XRLR R, ACC

XRLR WRn, #I

JMP L

JB0 L

JB1 L

JB2 L

JB3 L

JZ L

JNZ L

JC L

JNC L

DSKZ R

DSKNZ R

SKB0 R

SKB1 R

SKB2 R

SKB3 R

ACC←(R) & (ACC)

ACC←(WRn) & I

ACC, R←(R) & (ACC)

ACC, WRn←(WRn) & I

ACC←(R) ∧ (ACC)

ACC←(WRn) ∧ I

ACC, R←(R) ∧ (ACC)

ACC, WRn←(WRn) ∧ I

ACC←(R) EX (ACC)

ACC←(WRn) EX I

ACC, R←(R) EX (ACC)

ACC, WRn←(WRn) EX I

PC12~PC0←(ROMPR)×800H+L10~L0

PC10~PC0←L10~L0; if ACC.0 = "1"

PC10~PC0←L10~L0; if ACC.1 = "1"

PC10~PC0←L10~L0; if ACC.2 = "1"

PC10~PC0←L10~L0; if ACC.3 = "1"

PC10~PC0←L10~L0; if ACC = 0

PC10~PC0←L10~L0; if ACC ! = 0

PC10~PC0←L10~L0; if CF = "1"

PC10~PC0←L10~L0; if CF != "1"

ACC, R←(R) - 1; PC ← (PC) + 2 if ACC =

ACC, R←(R) - 1; PC ← (PC) + 2 if ACC !=
PC ← (PC) + 2 if R.0 = "1"

PC ← (PC) + 2 if R.1 = "1"
PC ← (PC) + 2 if R.2 = "1"
PC ← (PC) + 2 if R.3 = "1"

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

ZF, CF 1/1

ZF, CF 1/1

1/1

1/1

1/1

1/1

- 40 -

Preliminary W742E81A/W742C81A

Instruction set, continued

Machine code Mnemonic Function Flag affected W/C

Data move

0001 0000 0000 iiii

1110 1nnn nxxx xxxx

1001 1001 iiii nnnn

1111 1nnn nxxx xxxx

0110 1nnn nxxx xxxx

0111 1nnn nxxx xxxx

0101 1001 1xxx xxxx

0100 1110 1xxx xxxx

1011 1iii ixxx xxxx

1100 1nnn n000 qqqq

1101 1nnn n000 qqqq

1000 1100 0xxx xxxx

1000 1100 1xxx xxxx

1000 1110 0xxx xxxx

1000 1110 1xxx xxxx

1000 1101 0xxx xxxx

Input & Output

MOV ACC, #I

MOV WRn, R

MOV WRn, #I

MOV R, WRn

MOVA WRn, R

MOVA R, WRn

MOV R, ACC

MOV ACC, R

MOV R, #I

MOV WRn, @WRq

MOV @WRq, WRn

MOV TAB0, R

MOV TAB1, R

MOV TAB2, R

MOV TAB3, R

MOVC R

ACC←I
WRn←(R)
WRn←I
R←(WRn)
ACC, WRn←(R)
ACC, R←(WRn)
R←(ACC)
ACC←(R)
R←I
WRn←[(DBKR)×80H+(PAGE)x10H +(WRq)]
[(DBKR)×80H+(PAGE)x10H +(WRq)]←WRn
TAB0←(R)
TAB1←(R)
TAB2←(R)
TAB3←(R)
R←[(TAB3)×1000H+(TAB2)x100H+(TAB1)

x10H + (TAB0)]

ZF 1/1

1/1

1/1

1/1

ZF 1/1

ZF 1/1

1/1

ZF 1/1

1/1

1/2

1/2

1/1

1/1

1/1

1/1

1/2

0101 1011 0xxx xxxx

0101 1011 1xxx xxxx

0100 1011 0xxx xxxx

0100 1011 1xxx xxxx

0101 1010 0xxx xxxx

0101 1010 1xxx xxxx

0100 1010 0xxx xxxx

1010 1100 1xxx xxxx

0101 1110 0xxx xxxx

1010 1110 0xxx xxxx

MOVA R, RA

MOVA R, RB

MOVA R, RC

MOVA R, RD

MOV RA, R

MOV RB, R

MOV RC, R

MOV RD, R

MOV RE, R

MOV RF, R

ACC, R←[RA]
ACC, R←[RB]
ACC, R←[RC]
ACC, R←[RD]
[RA]←(R)
[RB]←(R)
[RC]←(R)
[RD]←(R)
[RE]←(R)
[RF]←(R)

ZF 1/1

ZF 1/1

ZF 1/1

ZF 1/1

1/1

1/1

1/1

1/1

1/1

1/1

Publication Release Date: April 2000

- 41 - Revision A1

Preliminary W742E81A/W742C81A

Instruction set, continued

Machine code Mnemonic Function Flag affected

Flag & Register

0101 1111 1xxx xxxx

0101 1110 1xxx xxxx

0101 0110 1000 0iii

1001 1101 1xxx xxxx

1001 1100 1xxx xxxx

0011 0101 1000 iiii

1001 1101 0000 nnnn

1001 1111 0000 nnnn

1001 1100 0000 nnnn

0011 0101 0000 iiii

0011 0100 0000 0iii

1000 1000 0xxx xxxx

1000 1001 0xxx xxxx

0101 1001 0xxx xxxx

0101 1000 0xxx xxxx

0100 1001 0xxx xxxx

0100 1001 1xxx xxxx

0101 0011 0000 iiii

0101 0111 0000 iiii

0101 0111 1000 iiii

0011 0111 1000 iiii

0100 0000 i00i 0iii
0101 1101 0xxx xxxx
0101 1101 1xxx xxxx
0100 0001 i00i 0iii
0101 0001 i00i 0iii
0100 0011 0000 iiii
0101 0010 0000 iiii

MOVA R, PAGE

MOV PAGE, R

MOV PAGE, #I

MOV R, WRP

MOV WRP, R

MOV WRP, #I

MOV WRn,DBKR

MOV WRn,TM1

MOV DBKR, WRn

MOV DBKR, #I

MOV ROMPR, #I

MOV ROMPR, R

MOV R, ROMPR

MOVA R, CF

MOV CF, R

MOVA R, HCFL

MOVA R, HCFH

MOV PM0, #I

MOV PM1, #I

MOV PM2, #I

MOV PM5, #I

CLR EVF, #I Clear Event Flag if In = 1 1/1
MOVA R, EVFL
MOVA R, EVFH
MOV HEF, #I Set/Reset HOLD mode release Enable Flag 1/1
MOV IEF, #I Set/Reset Interrupt Enable Flag 1/1
MOV PEF, #I Set/Reset Port Enable Flag 1/1
MOV SEF, #I

ACC, R←PAGE (Page Register)
PAGE←(R)
PAGE←I
R←WRP
WRP←(R)
WRP←I

WRn←DBKR

WRn←TM1.4 - TM1.7, ACC←TM1.0 ­TM1.3

DBKR←WRn

DBKR←I

ROMPR←I

ROMPR←(R)

R←(ROMPR)

ACC.0, R.0←CF

CF←(R.0)

ACC, R←HCF.0~HCF.3

ACC, R←HCF.4~HCF.7

Port Mode 0← I

Port Mode 1← I

Port Mode 2← I

Port Mode 5← I

R← EVF.0 - EVF.3
R← EVF.4 - EVF.7

Set/Reset STOP mode wake-up Enable Flag
for RC port

W/C

ZF 1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

ZF 1/1

CF 1/1

ZF 1/1

ZF 1/1

1/1

1/1

1/1

1/1

1/1
1/1

1/1

- 42 -

Preliminary W742E81A/W742C81A

Instruction set, continued

Machine code Mnemonic Function Flag affected

Flag & Register

0101 0100 0000 i0ii

0100 1111 0xxx xxxx

0100 0010 0000 0000
0101 0000 0100 0000
0101 0000 0000 0000
0001 0111 0000 0000
0101 0101 1000 0000
0101 0110 0000 iiii

0101 1111 0xxx xxxx

0001 0111 1000 0000

DTMF

1001 1110 1xxx xxxx

0011 0100 1000 0iii

Shift & Rotate

0100 1101 0xxx xxxx

0100 1101 1xxx xxxx

0100 1100 0xxx xxxx

0100 1100 1xxx xxxx

MOV SCR, #I

MOVA R, PSR0

CLR PSR0 Clear Port Status Register 0 1/1
SET CF Set Carry Flag CF 1/1
CLR CF Clear Carry Flag CF 1/1
CLR DIVR0 Clear the last 4-bit of the Divider 0 1/1
CLR DIVR1 Clear the last 4-bit of the Divider 1 1/1
MOV WDTR, #I

MOVA R,WDTR

CLR WDT Clear Watchdog Timer 1/1

MOV DTMF,R

MOV DTCR,I

SHRC

RRC R

SHLC R

RLC R

R

SCR←I

ACC, R←Port Status Register 0

WDTR←I
ACC, R←Watchdog Timer Register

DTMF←(R)
DTCR←I

ACC.n, R.n←(R.n+1);
ACC.3, R.3←0; CF←R.0

ACC.n, R.n←(R.n+1);
ACC.3, R.3←CF; CF←R.0

ACC.n, R.n←(R.n-1);
ACC.0, R.0←0; CF←R.3

ACC.n, R.n←(R.n-1);
ACC.0, R.0←CF; CF←R.3

W/C

1/1

ZF 1/1

1/1

1/1

1/1

1/1

ZF, CF

ZF, CF 1/1

ZF, CF 1/1

ZF, CF 1/1

1/1

Publication Release Date: April 2000

- 43 - Revision A1

Preliminary W742E81A/W742C81A

MOV

Instruction set, continued

Machine code Mnemonic Function Flag affected W/C

LCD

1001 1000 0xxx xxxx

1001 1000 1xxx xxxx

1001 1010 0xxx xxxx

1001 1011 0xxx xxxx

0000 0010 0000 0000

0000 0010 1000 0000

MFP

0011 0110 0000 000i

1000 1010 0xxx xxxx

1000 1011 0xxx xxxx

0001 0010 iiii iiii

Timer

1010 1010 0xxx xxxx

1010 1010 1xxx xxxx

1010 1011 0xxx xxxx

1010 1011 1xxx xxxx

0001 0011 1000 i00i

0001 0011 0000 iiii

Other

0000 0000 1000 0000

0000 0000 1100 0000

0000 0000 0000 0000

0101 0000 1100 0000

0101 0000 1000 0000

Subroutine

0110 0aaa aaaa aaaa

0000 0001 iiii iiii

MOV LPL, R

MOV LPH, R

MOV @LP, R

MOV R, @LP

LCDON LCD ON 1/1

LCDOFF LCD OFF 1/1

MOV BUZCR, #I

MOV BUZCR, R

MOV R,BUZCR

MOV MFP, #I

MOV TM0L, R

MOV TM0H, R

MOV TM1L, R

MOV TM1H, R

MR0,#I

MOV MR1,#I

HOLD Enter Hold mode 1/1

STOP Enter Stop mode 1/1

NOP No operation 1/1

EN INT Enable interrupt function 1/1

DIS INT Disable interrupt function 1/1

CALL L

RTN #I

LPL←(R)
LPH←(R)
[(LPH)×10H+(LPL)]←(R)
R←[(LPH) ×10H+(LPL)]

BUZCR← I
BUZCR←(R)
R←(BUZCR)
[MFP]← I

TM0L←(R)
TM0H←(R)
TM1L←(R)
TM1H←(R)
MR0←(R)

MR1←(R)

Push Stack:
STACK <- PC+1, TAB0, TAB1, TAB2, TAB3,
DBKR, WRP, ROMPR, PAGE, ACC, CF;
PC12~PC0<- (ROMPR)x800H+L10~L0

(PC) <- STACK; Pop other register by I Table
setting (Refer to Table 8)

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

1/1

- 44 -

Preliminary W742E81A/W742C81A

Table 8 The bit definition of RTN

BIT DEFINITION OF I

I = 0000 0000
bit0 = 1
bit1 = 1
bit2 = 1
bit3 = 1
bit4 = 1
bit5 = 1
bit6 = 1

Pop PC from stack only
Pop PC and
Pop PC and
Pop PC and
Pop PC and
Pop PC and
Pop PC and

TAB0, TAB1, TAB2, TAB3
DBKR

from stack

WRP

from stack

ROMPR
PAGE
ACC

from stack

from stack

from stack

Pop PC and CF from stack

from stack

Headquarters

No. 4, Creation Rd. III,
Science-Based Industrial Park,
Hsinchu, Taiwan
TEL: [phone]
FAX: [phone]
http://www.winbond.com.tw/
Voice & Fax-on-demand: 886-2-27197006

Taipei Office

11F, No. 115, Sec. 3, Min-Sheng East Rd.,
Taipei, Taiwan
TEL: [phone]
FAX: [phone]

Note: All data and specifications are subject to change without notice.

Winbond Electronics (H.K.) Ltd.

Rm. 803, World Trade Square, Tower II,
123 Hoi Bun Rd., Kwun Tong,
Kowloon, Hong Kong
TEL: [phone]
FAX: [phone]

Winbond Electronics North America Corp.
Winbond Memory Lab.
Winbond Microelectronics Corp.
Winbond Systems Lab.

2727 N. First Street, San Jose,
CA 95134, U.S.A.
TEL: [phone]

FAX: [phone]

Publication Release Date: April 2000

- 45 - Revision A1
