WHIRLPOOL WFC 3C24 PF IN Daily Reference Guide

Daily

Reference Guide

DAILY REFERENCE

3

1

2

8

13

1454 6 7 10 11 129

GUIDE

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT. You can download the Safety Instructions and the Use

Before using the appliance carefully read Health and Safety guide.

PRODUCT DESCRIPTION

APPLIANCE

EN

and Care Guide, by visiting our website
www.whirlpoolindia.com and following the
Instructions on the back of this booklet.

1

4

7

8

10

12

Service:

0000 000 00000

13

CONTROL PANEL

2

3

5
6
9

11

1.Upper rack

2.

Cutlery rack

3.Foldable flaps

4.Upper rack height adjuster

5.Upper spray arm

6.Lower rack

7.Space Zone

8.Lower spray arm

9.Filter Assembly

10.Salt reservoir

11.Detergent and Rinse Aid dispensers

12.Rating plate

13.Control panel

1. On-Off/Reset button with indicator light
Program selection button with indicator light

2.

3.

Multizone button with indicator light / Key lock

4.

Eco program indicator light

5. Key lock indicator light

6. Display

7. Program number and remaining time indicator

8.

Tab let ( Tab) in d icato r light

9. Closed water tap indicator light

10. Rinse Aid refill indicator light

11. Salt refill indicator light

12. Power Clean button with indicator light / Tablet (Tab)

13. Delay button with indicator light

14. Start/Pause button with indicator light / Drain out

5
