Whirlpool ACM 376, ACM 375, ACM 394, ACM 392, ACM 398 INSTRUCTION FOR USE

...

Download

N C

INTRODUCTION

BEFORE STARTING

1. Remove the cardboard and accessories from inside the oven.

2. Clean the hob.

3. The first time you use the oven heat it at the maximum setting for about two hours to eliminate

odours and fumes due to the protective grease.

ROUTINE USE

Hob

1. Turn the knob to the required setting (see “Using the glass-ceramic hob”).

2. To switch off, turn the knob to “0”.

Oven

1. Arrange the food in the oven.

2. Select the required cooking function (see “Using the oven”).

3. Select the temperature.

To get the most out of your new appliance, be sure to read the instructions in this booklet.

127

M Y

N C

CONTENTSGB

THE APPLIANCE AND ITS COMPONENTS Page 129

CONTROL PANEL Page 129

GENERAL PRECAUTIONS AND RECOMMENDATIONS Page 131

USING THE GLASS-CERAMIC HOB Page 132

USING THE OVEN Page 134

USING THE CONVENTIONAL OVEN – mod. ACM 376 – ACM 375 Page 135

USING THE CONVENTIONAL FAN-ASSISTED OVEN – mod. ACM 394 Page 138

USING THE MULTIFUNCTION OVEN – mod. ACM 392, 398, 377 Page 142

USING THE ELECTRONIC PROGRAMMER – ACM 398 – ACM 377 Page 146

CLEANING AND MAINTENANCE Page 150

TROUBLE-SHOOTING GUIDE Page 152

AFTER SALES SERVICE Page 152

INSTALLATION Page 153

TABLES Page 155

128

M Y

N C

THE APPLIANCE AND ITS COMPONENTS

ACM376–ACM375–ACM394–ACM392

1. Control panel

2. Residual heat indicator

3. High-speed radiant plate – ø 145 – 1200 W

4. High-speed radiant plate – ø 180 – 1800 W

5. High-speed radiant plate – ø 145 – 1200 W

6. High-speed radiant plate – ø 210 – 2100 W

7. Oven light

8. Grill elements (self-cleaning)

9. Side racks

10. Oven door

11. Door handle

12. Child lock

13. Warming drawer (with safety device)

14. Plinth (not for Denmark cookers)

1. Front lh plate (6) control knob

2. Rear lh plate (5) control knob

3. Rear rh plate (4) control knob

4. Front rh plate (3) control knob

A, B, C, D:

Guides for baking trays, grids or drip tray (see cooking time tables).

Accessories:

2 enamel baking trays 1 enamel drip tray 1 grid for grilling, roasting or baking 2 adjustable feet

CONTROL PANEL

5. Oven function selector knob

6. Oven thermostat knob

7. Plate on indicator light

8. Oven thermostat indicator light

129

M Y

N C

THE APPLIANCE AND ITS COMPONENTS

ACM 398 – ACM 377

1. Control panel

2. Residual heat indicator

3. High-speed radiant plate – ø 145 – 1200 W

4. High-speed radiant plate – ø 180 – 1800 W

5. Double high-speed radiant plate – Oval – 1800 W

6. Double high -speed radiant plate – ø 210 – 2100 W

7. Oven light

8. Grill elements (self-cleaning)

9. Catalytic back wall (mod. ACM 377 only)

10. Side racks

11. Oven door

12. Door handle

13. Child lock

14. Warming drawer (with safety device)

15. Plinth (not for Denmark cookers)

CONTROL PANEL

1. Digital lock

2. Front lh plate (6) control knob

3. Rear lh plate (5) control knob

4. Rear rh plate (4) control knob

130

A, B, C, D:

Guides for baking trays, grids or drip tray (see cooking time tables).

Accessories:

2 enamel baking trays 1 enamel drip tray 1 grid for grilling, roasting or baking 2 adjustable feet

5. Front rh plate (3) control knob

6. Oven function selector knob

7. Oven thermostat knob

8. Plate on indicator lights

9. Oven thermostat indicator light

M Y

N C

GENERAL PRECAUTIONS AND RECOMMENDATIONS

Before starting

1. Packaging materials (plastic film, expanded

polystyrene, etc.) are potentially dangerous and must be kept out of the reach of children.

2. The packaging materials can be recycled, as

confirmed by the symbol

3. Make sure the appliance has not been damaged

during transport and that the oven door closes correctly.

4. Installation and electrical connection of the appliance

must be entrusted to skilled personnel in accordance with the instructions supplied by the manufacturer and in compliance with established safety standards.

5. Remove packaging residues from inside and outside

the appliance. Remove the accessories. Keep cardboard and plastic protective packages in a safe place for future use, or dispose of them properly.

6. Glass-ceramic hob

Clean thoroughly with a clean damp cloth and a drop of washing-up liquid. Rinse with clean water and dry with a clean cloth.

Never cook the food directly on the glass ceramic hob, but always use pans or containers.

7. Oven

Empty the oven and close the door. Heat the oven at the maximum temperature setting for around two hours to eliminate the odour of grease and fumes from the manufacturing process. Make sure that the kitchen is well ventilated and do not remain in the room during this process.

Clean the oven and accessories with warm water and washing-up liquid.

During and after use of the oven, certain parts will become very hot (e.g. the oven door inspection window). Do not touch hot parts.

Keep children well away from the appliance while it is in use.

Fire risk! Do not store flammable material in the oven, above the glass ceramic hob or in the accessory drawer.

Make sure that electrical cables connecting other appliances near the cooker cannot come into contact with the hob or be trapped in the oven door.

Do not line the oven walls with aluminium foil. Do not place baking trays or the drip tray on the floor of the oven chamber.

Do not allow heavy or sharp objects to drop on the glass ceramic hob. If the hob is cracked or otherwise damaged by falling objects etc., disconnect the electrical power cord and call Customer Service.

Do not lean aluminium sheets or plastic containers above the hot hob.

Do not scratch the hob with sharp objects. Do not use the hob as a work surface.

The manufacturer declines all liability for injury to persons or damage to property caused by incorrect or improper use of the appliance.

The various components of the appliance are recyclable. Dispose of them in accordance with the regulations in force in your country. If the appliance is to be scrapped, cut off the power cord.

131

M Y

N C

USING THE GLASS-CERAMIC HOB

Radiant plates

All the radiant plates are equipped with automatic thermostat; the front lh radiant plate has an adjustable thermostat.

Automatic radiant plates

The knobs do not have fixed positions. To switch on the radiant plates, turn the knob to position

12. Once the required temperature has been reached, turn the knob to the required setting for cooking. Observe the recommendations in the table.

Automatic start radiant plate

This function is on the front lh radiant plate. The automatic thermostat on this radiant plate is activated when the knob is set anywhere between 1 and 7. To avoid the risk of fat fires at higher temperatures the thermostat function is not active on between positions 8 and 12. The thermostat automatically switches from high starting temperature to lower holding temperatures as cooking proceeds so there is no need to turn the knob from the starting position to a lower heat position. If you wish to use this function, position the knob between 1 and 7 and pull it gently outwards. If the knob is inadvertently pulled outwards or if you have set the function and want to cancel it, reset the knob to 0. If you select the wrong setting, just correct it by repositioning the knob on the required setting. Starting temperature will be automatically adapted to the new setting.

Double radiant plates (Mod. ACM 398 – ACM 377 only)

By switching on the second element, the surface area of the rear lh and front lh radiant plates can be extended. For this purpose, turn the control knob fully to the right (position

X·

Now return the knob to the required position. This knob functions in the same way as described in the previous heading “Automatic start radiant plate”

Heat setting table

Setting Function

X·

12 Boiling large quantities of water; pasta.

11-12 Chips; meat dishes such as stew.

10-11

9-10

8-9 Tender meat, sausages, liver, eggs, fritters

5-7 Large portions, single course meals, soups.

4-6 Boiled potatoes, minestrone.

3-5 Boiled vegetables, stew.

3-5 Rice pudding

2-4

1-2

0 Residual heat only, radiant plate is off.

Switching on the second element

(Double radiant plate only)

Croquets; fillet of steak, steaks, breaded meat.

Meat: scallops, cutlets etc., omelettes, meatballs, roasts

Rice and milk based foods, small quantities of potatoes and vegetables; warming precooked food.

Omelettes, scrambled egg, sauces, hollandaise sauce; for warming, melting butter, chocolate and gelatine.

Double radiant plate knob

(mod. ACM 398 – ACM 377 only)

132

M Y

N C

USING THE GLASS-CERAMIC HOB

RESIDUAL HEAT INDICATOR

The indicator remains active as long as glass ceramic hob temperature exceeds 60

C (also after the glass ceramic hob has been switched off or after power has been restored following a mains failure). Do not touch the glass ceramic hob when the residual heat indicator is illuminated.

POWER SAVING TIPS

To save power, make use of the residual heat. 5 or 10 minutes before you finish cooking, set the control knob to “0” .

USING THE IDEAL PANS

Use special pans for electric hobs with smooth, flat and solid bottoms (pans with the test mark for glass-ceramic hobs are available from specialist shops).

The diameter of the pan should be the same as the radiant plate or slightly larger.

Do not use pans with damaged or rough bottoms (cast iron pans). The hob surface could be scratched or the decoration may be damaged. Do not slide pots across the hob.

To save electricity, use lids whenever possible.

Pots with aluminium bottoms may leave silver streaks or spots on the hob.

Pots and pans should be dry. Place pans on the cooking areas marked on the hob.

Do not leave wet or damp lids on the hob.

The glass-ceramic surface and pans must be clean. Carefully eliminate any food remains (especially containing sugar), dirt etc. with the aid of a cleansing agent.

Never cook the food directly on the glass ceramic cooktop but in special pans or containers.

133

M Y

N C

USING THE OVEN

CHILD LOCK

The cookers are equipped with a “Child lock” safety device.

USE OF THE SAFETY DEVICE

x USE: The door closes normally and is

blocked by the safety device. To open the door move lever C to the R.

x ACTIVATION: Open the oven door and

with a coin slacken screw B. Lever C moves to the L after screw B is tightened in position 1.

x DEACTIVATION: With the door open

move lever C to the R and block it in this position by screwing screw B in position 2.

In order to open drawer please act as shown in the picture.

134

M Y

N C

USING THE CONVENTIONAL OVEN

ACM 376 – ACM 375

Side racks

The oven has two removable side racks which allow for four different oven-loading positions. They provide support for the drip tray, baking tray and/or grid, which slide between the two guides on either side of the oven, at the same height. When you fit the tray or grid, take care to position it correctly so that it is horizontal. For the choice of the best oven position, refer to the baking and grilling tables.

Upper and lower heating elements

Installing and removing the side racks

Hook up the side racks to the oven walls.

Slide the required grip or tray into the guides.

Inside the oven the heating elements are located on the oven floor and ceiling. Heat is supplied by radiation.

135

M Y

N C

USING THE CONVENTIONAL OVEN

ACM 376 – ACM 375

Switching on and off

To switch on the oven turn the cooking mode selector

and the temperature selectorPto the required

positions.

The cooking mode selector direction.

The temperature selector knob the right to switch on the oven and to the left, position

, to switch it off.

Preheating

Preheating is unnecessary when preparing roasts, casseroles, and slow-cooking dishes in general. Oven preheating is recommended, however, for delicate cooking and dishes that require shorter cooking times (pastries, etc.). Consult the cooking time tables at the back of the handbook.

The outdoor parts of the oven become hot during operation. Keep children well out of reach.

can be turned in either

must be turned to

Summary table Cooking functions and temperatures

The following table shows cooking modes and temperatures for oven and grill cooking.

Control

knob

Temperature Cooking

C function

Off Lower and upper

heating elements

Lower heating element

Upper heating element

Grill

Booster (grill & lower heating elements)

Energy saving tips

You can utilise residual heat by setting the control knob to “0” for approximately 5 or 10 minutes to finish nearly all types of cooking. You can also cook side dishes, such as potatoes, rice or vegetables, together with the meat course.

Oven light

Turning the knob to any setting switches on the oven light. The oven remains alight while any of the functions is on.

-250

-150

-200

Þ 2

ñ W

136

M Y

N C

USING THE CONVENTIONAL OVEN

ACM 376 – ACM 375

TRADITIONAL CONVECTION

COOKING

Conventional cooking with heating from top and bottom. In this position the lower and upper heating elements are switched on. Heating takes place through natural convection and thermostat temperature can be set between 50

C. This type of cooking requires oven preheating.

250

Tip:

This function is particularly suitable for desserts that must be heated from below, such as fruit pies, bread, pizzas and roasts, e.g. chicken.

LOWER HEATING ELEMENT

In this position only the lower element is switched on. Heat is distributed by natural convection. The thermostat can be set between 50 are not available.

Tip:

This mode is particularly suitable to complete cooking of dishes that require higher temperature at the bottom.

UPPER HEATING ELEMENT

In this position only the upper element is switched on. Heat is distributed by natural convection. The thermostat can be set between 50 are not available.

Tip:

This mode is particularly suitable to complete cooking of dishes that require higher temperature at the top.

C and 150oC; higher temperatures

Cand

NORMAL GRILL

In this position the infrared heating element is working. Heat is supplied by radiation. The thermostat must be settomax.200

Tip:

This function is particularly useful for gratins or browning, for example onion soup, toast and sausages.

Warning: During grilling the oven door becomes very hot. Keep children away! The operation of the grill should not exceed 30 minutes.

Quick oven heating.

In this position the infrared heating element and the lower element are working. Heat is supplied by radiation and convection. The thermostat must be set to max. 200 Use with the oven door closed.

Tip:

This function is particularly useful for preheating the oven quickly and for very fast cooking.

Roasts

For traditional roasts allow the meat to cook evenly. Make sure the temperature is between 180

200

C and set cooking time in relation to the quantity

and type of meat you are preparing.

Warning: When using this function, the oven door becomes very hot. Keep children away.

C. Use with the oven door closed.

BOOSTER

Cand

137

M Y

N C

USING THE CONVENTIONAL FAN-ASSISTED OVEN

ACM 394

Upper and lower heating elements

Inside the oven the heating elements are located on the oven floor and ceiling. Heat is supplied by radiation.

Fan-assisted convection system

Grill

The grill is secured to the rear wall of the oven on a hinge system that allows it to be lowered to allow proper access when cleaning the oven ceiling.

Side racks

4 3

The heat produced by the upper and lower element is distributed by the fan. This function assures uniform heat distribution in the oven and permits simultaneous cooking of food on any of the three oven levels. Temperatures for convection cooking are lower than those for conventional radiant heat cooking (see “Temperature selection”).

138

2 1

The oven is equipped with two removable side supports which form 4 guides for the insertion of the drip tray, baking trays and grids. The grid, baking trays, and drip tray must be inserted between the pairs of steel bars located at the same height on each side. This system prevents the containers from tipping when they are extracted from the oven chamber. Recommended grid/baking tray levels are shown in the tables at the end of this handbook.

Removing the side racks improves access to the oven ceiling for cleaning (after the grill heating element has been lowered).

M Y

N C

USING THE CONVENTIONAL FAN-ASSISTED OVEN

ACM 394

Switching on and off

To switch on the oven turn the cooking mode selector

and the temperature selectorÎto the required

positions.

The cooking mode selector direction.

The temperature selector knob the right to switch the oven on and to the left, position

, to switch it off.

Preheating

can be turned in either

must be turned to

Summary table Cooking functions and temperatures

The following table shows cooking modes and temperatures for oven and grill cooking.

Control

knob

Temperature Cooking

C function

Off Lower and upper

heating elements Convection cooking

with fan Fan convection cooking

with grill

Normal grill

Booster (grill and lower heating elements)

Energy saving tips

-Max

-250

-200

Þ V X

Selecting the temperature for convection cooking

Fan convection cooking temperatures are generally between 20 temperatures (heat exclusively supplied from above and below).

Cand40oC lower than natural convection

139

M Y

N C

USING THE CONVENTIONAL FAN-ASSISTED OVEN

ACM 394

OVEN LIGHT

To switch on the oven light turn the cooking function selector knob direction).

toÅ(the knob can turn in either

TRADITIONAL CONVECTION COOKING

Conventional cooking with heating from top and bottom. In this position the lower and upper heating

elements are switched on. Heating takes place through natural convection and thermostat temperature can be set between 50 oven preheating.

Tip:

This function is particularly suitable for desserts that must be heated from below, such as fruit pies, bread, pizzas and roasts, e.g. chicken.

The upper and lower heating elements and the fan turn on. The heat coming from the top and bottom is diffused by forced convection. The temperature must be regulated between 50 250

Tip:

For foods of large volume and quantity which require the same internal and external degree of cooking; e.g.: rolled roasts, turkey, legs, cakes, etc.

C and Max. This type of cooking requires

CONVECTION COOKING WITH FAN

C. with the thermostat knob.

Cand

GRILL COOKING WITH FAN

In this position the grill heating element operates together with the fan. Heat distribution is by means of air circulation and temperatures are higher towards the top of the oven. The thermostat can be used to set temperatures between 50 Use with the oven door closed.

Warning: When using this function, the oven door becomes very hot. Keep children away!

Tip:

This mode is particularly suitable for dishes that call for long cooking at high temperatures. This grill convection cooking is also recommended for keeping oven-cooked food such as roasts and grilled dishes warm, or for delicate reheating of pre-cooked dishes.

NORMAL GRILL

In this position the infrared heating element operates. Heat is supplied by radiation. The thermostat must be set to max. 200

Tip:

This function is particularly useful for gratins or browning, for example onion soup, toast and sausages.

Warning: When using this function, the oven door becomes very hot. Keep children away!

Quick oven heating.

In this position the infrared heating element and the lower element operate. Heat is supplied by radiation and convection. The thermostat must be set to max. 200 Use with the oven door closed.

C. Use with the oven door closed.

BOOSTER

C and 200oC.

Tip:

This function is particularly useful for preheating the oven quickly and for very fast cooking.

Warning: When using this function, the oven door becomes very hot. Keep children away! The operation of the grill cooking with fan should not exceed 30 minutes.

140

M Y

N C

USING THE CONVENTIONAL FAN-ASSISTED OVEN

ACM 394

Grilling and browning

function is used for perfect spit skewer type

The

cooking without using a spit, because the forced air circulation ensures even cooking on all sides. Preheat the oven, setting the thermostat on 200 meat or other food to be grilled, close the oven door and set the temperature between 50 Just before cooking is complete, spread butter on the food so that a thin crust forms, similar to au gratin preparation.

Roasts

For traditional roasts allow the meat to cook evenly. Make sure the temperature is between 180

200

C and set cooking time in relation to the quantity

and type of meat you are preparing.

C. Put in the

and 200oC.

Cand

Simultaneous cooking of different food

Set the mode selector knob to kinds of food at the same time. For example, you can grill fish or meat at the top of the oven while baking a cake at the bottom, without any risk of contamination of flavour or aroma.

For this type of cooking observe the following basic rules:

- Cooking temperature for each food type must be

roughly the same (difference within 20

- Cooking times may differ. This oven function allows

considerable energy savings.

to cook different

-25oC).

141

M Y

N C

USING THE MULTIFUNCTION OVEN

ACM 392 – ACM 398 – ACM 377

Fan convection system

The air is drawn in through openings on the rear panel of the oven and then heated before being returned to the oven chamber. The convection function assures uniform heat distribution in the oven and permits simultaneous cooking of food on any of the three oven levels. Temperature for convection cooking are lower than those for conventional radiant heat cooking (see “Temperature selection”).

Upper and lower heating elements

Grill

The grill is secured to the rear wall of the oven on a hinge system that allows it to be lowered to allow proper access when cleaning the oven ceiling.

Side racks

4 3

Inside the oven the heating elements are located on the oven floor and ceiling. Heat is supplied by radiation.

142

2 1

Removing the side racks improves access to the oven ceiling for cleaning (after the grill heating element has been lowered).

M Y

N C

USING THE MULTIFUNCTION OVEN

ACM 392 – ACM 398 – ACM 377

Switching on and off

To switch on the oven turn the cooking mode selector

and the temperature selectorÎto the required

positions.

The cooking mode selector direction.

The temperature selector knob the right to switch the oven on and to the left, position

, to switch it off.

Preheating

Selecting the temperature for convection cooking

Fan convection cooking temperatures are generally between 20 temperatures (heat exclusively supplied from above and below).

Cand40oC lower than natural convection

can be turned in either

must be turned to

Summary table Cooking functions and temperatures

The following table shows cooking modes and temperatures for oven and grill cooking.

Control

knob

Temperature Cooking

C function

Off

Oven light

Lower and upper heating elements

Normal grill

Turbo grill

Booster – Quick heat Booster – Quick cooking

Lower heating element

Fan convection cooking with lower heating element

Fan convection cooking

Energy saving tips

x x

-Max

-200

-250

-150

-250

Þ W

2 Z

143

M Y

N C

USING THE MULTIFUNCTION OVEN

ACM 392 – ACM 398 – ACM 377

To switch on the oven light turn the cooking function selector knob direction).

OVEN LIGHT

toÅ(the knob can turn in either

TRADITIONAL CONVECTION COOKING

Conventional cooking with heating from top and bottom. In this position the lower and upper heating

elements are switched on. Heating takes place through natural convection and thermostat temperature can be set between 50 oven preheating.

Tip:

This function is particularly suitable for desserts that must be heated from below, such as fruit pies, bread, pizzas and roasts, e.g. chicken.

In this position the infrared heating element is working. Heat is supplied by radiation. The thermostat must be set to max. 200

Tip:

This function is particularly useful for gratins or browning, for example onion soup, toast and sausages.

C and Max. This type of cooking requires

NORMAL GRILL

C. Use with the oven door closed.

TURBO GRILL

In this position the upper heating element and the grill element are on simultaneously so that the corner areas are also heated. Heat is radiated over the entire surface area of the grill. Set the thermostat to max. 200 with the door closed.

Warning: During grilling the oven door becomes very hot. Keep children away! The operation of the grill should not exceed 30 minutes.

BOOSTER

1.- Quick oven heating.

In this position the grill heating element operates together with the perimeter heating element and the fan. The thermostat can be used to set temperatures between

C and 200oC. Use with the oven door closed.

Tip:

This function is particularly useful for preheating the oven quickly.

2.- Quick fan convection cooking with grill.

Heat distribution is by means of air circulation and temperatures are higher towards the top of the oven. The thermostat can be used to set temperatures between

C and 250oC.

Tip:

This mode is particularly suitable for dishes that call for fast cooking at high temperatures.

C. Use

Warning: When using this function, the oven door becomes very hot. Keep children away.

LOWER HEATING ELEMENT

In this position only the lower element is switched on. Heat is distributed by natural convection. The thermostat can be set between 50 are not available.

144

C and 150oC; higher temperatures

M Y

N C

USING THE MULTIFUNCTION OVEN

ACM 392 – ACM 398 – ACM 377

FAN CONVECTION COOKING WITH

LOWER HEATING ELEMENT

This mode combines the lower heating element, the perimeter heating element and the fan. The food is cooked by forced air circulation with additional heat from the bottom of the oven. The thermostat can be set between 50

Tip:

This cooking mode is ideal for large joints of meat and large quantities of food that call for uniform cooking inside and out, e.g. roasts, turkey, chicken, cakes, etc.

In this position the perimeter resistance and the fan are on. Heat is distributed by air circulation. Thermostat temperature can be adjusted between 50 Preheating is not required.

Tip:

This function is particularly useful when using more than one oven level to prepare cakes, pastry, etc. or roasts such as beef, pork or lamb.

C and 250oC.

FAN CONVECTION COOKING

C and 250oC.

Fan cooking and browning

The

skewer type cooking without using a spit, because the forced air circulation ensures even cooking on all sides. Preheat the oven, setting the thermostat on 250 in the meat or other food to be grilled, close the oven door and set the temperature between 50 200 on the food so that a thin crust forms, similar to au gratin preparation.

Roasts

For traditional roasts allow the meat to cook evenly. Make sure the temperature is between 180 200 and type of meat you are preparing.

Simultaneous cooking of different food

For this type of cooking observe the following basic rules:

- Cooking temperature for each food type must be

- Cooking times may differ. This oven function allows

Zç

C. Just before cooking is complete, spread butter

C and set cooking time in relation to the quantity

roughly the same (difference within 20

considerable energy savings.

functions are used for perfect spit

C. Put

Cand

to cook different

-25oC).

145

M Y

N C

USING THE ELECTRONIC PROGRAMMER

ACM 398 – ACM 377

The electronic programmer is a device which groups together the following functions:

- 24 hour clock with illuminated display

- Timer (up to 23 hours and 59 minutes)

- Program for automatic oven cooking

- Program for semi-automatic oven cooking.

Description of the buttons:

Timer

Cooking time

End of cooking time

Manual position and cancellation of the entered

cooking programme

Advancement of the numbers of all programmes

Turning back of the numbers of all programmes

–

and changing the frequency of the audible signal.

(10.1)

Description of the lighted symbols: AUTO -flashing – Programmer in automatic position

but not programmed

AUTO -always lighted – Programmer in automatic

position with programme entered.

Automatic cooking taking place

Timer in operation

and AUTO -flashing – Programme error. (The

time of day lies between the calculated cooking start and end time).

Note: Select a function by means of its button and, in 5 seconds, set the required time with the buttons (“one-hand” operation). A power cut makes the clock go to zero and cancels the set programmes.

+/–

(10.2)

ELECTRONIC CLOCK

The programmer is equipped with an electronic clock with lighted numbers which indicates hours and minutes. Upon immediate connection of the oven or after a power cut, three zeros will flash on the programmer panel. To set the hour push the

–

button until you have set the exact hour (fig. 10.2). Another way is to push the two simultaneously and at the same time push the button.

Note: The hour setting delete any program.

(fig. 10.2)

button and then the+or

buttons

+or–

146

M Y

N C

USING THE ELECTRONIC PROGRAMMER

ACM 398 – ACM 377

NORMAL COOKING WITHOUT THE USE OF THE PROGRAMMER

To use the oven manually, that is, without the aid of the programmer, cancel the flashing AUTO by pushing the button symbol

Attention: If the AUTO is lighted up steadily (which means a cooking programme has already been entered), push the button and switch to manual.

If the oven is switched on, switch it off manually.

(AUTO will be switched off and the

will light up – Fig. 10.3).

to cancel the programme

(10.3)

ELECTRONIC TIMER

(fig. 10.4) The timer programme consists only of a buzzer which

may be set for a maximum period of 23 hours and 59 minutes. If the AUTO is flashing push the To set the time, push the until you obtain the desired time in the panel (fig. 10.4). Having finished the setting, the clock hour will appear on the panel and the The symbol will light up. The countdown will start immediately and may be seen at any moment on the panel by simply pressing the button At the end of the time, the and an intermittent buzzer will sound; this can be stopped by pressing any of the buttons.

button and the+or

lights up.

symbol will switch off

button.

–

(10.4)

SETTING THE FREQUENCY OF THE AUDIBLE SIGNAL

Choose from 3 different sounds by pressing the button.

–

147

M Y

N C

USING THE ELECTRONIC PROGRAMMER

ACM 398 – ACM 377

SEMI – AUTOMATIC COOKING

This is used to switch the oven off automatically after the desired cooking time has elapsed. There are two ways of obtaining semi-automatic cooking:

1. Set the length of the cooking time by pushing the

button and the+button to advance, or–to go

backwards if you have passed the desired time (Fig.

10.7).

2. Set the end of the cooking time by pushing the

button and the+button to advance, or–to go backwards if you have passed the desired time (Fig.

10.8). AUTO and the Then set the temperature and the cooking programme

using the oven switch and thermostat knobs (see specific chapters). The oven is switched on and it will switch off automatically at the end of the desired time. During cooking, the pressing the button remains till the end of cooking.

The cooking program can be cancelled at any time by pushing the

cooking, the oven and the AUTO will flash and a buzzer will sound; it can be stopped by pushing any of the buttons. Turn the switch and thermostat knobs to zero and put the programmer to “manual” by pressing the button.

symbol will be on.

symbol remains on and by

you can see the time that

button. At the end of

symbol will turn off, the

(10.5)

(10.6)

148

M Y

N C

USING THE ELECTRONIC PROGRAMMER

ACM 398 – ACM 377

AUTOMATIC OVEN COOKING

To cook food automatically in the oven:

1. Set the length of the cooking time

2. Settheendofthecookingtime

3. Set the temperature and the oven cooking programme.

These operations are done in the following way:

1. Set the length of the cooking time by pushing the

button and the+button to advance, or–to go

back if you have passed the desired time (fig. 10.5). The AUTO and the

2. Settheendofthecookingtimebypressingthe

button (the cooking time already added to the clock time will appear), and the you pass the desired time you may go back by pushing the After this setting, the this setting, the AUTO flashes on the panel and a buzzer gives off, it means there was an error in the programming, that is that the cooking cycle has been superimposed on the clock. In this case, modify the end of cooking time or the cooking time itself by following the above-mentioned instructions again.

3. Set the temperature and the cooking programme by

using the oven switch and thermostat knobs (see specific chapters).

–

button.

symbol will be on.

button (fig. 10.6); if

symbol will go off. If after

(10.7)

Now the oven is programmed and everything will work automatically, that is the oven will turn on at the right time to end the cooking at the hourset. During cooking,

symbol remains on.

the

Push the the end of cooking.

button to see the time that remains until

(10.8)

The cooking program may be cancelled at any time by pushing

At the end of the cooking time the oven will turn off automatically, the flash and a buzzer will sound, which can be turned off by pushing any of the buttons.

Turn the switch and thermostat knobs to zero and put the programmer to “manual” by pressing the button.

Attention: A power cut makes the clock go to zero and cancels the set programmes. After a power cut, three zeros will flash on the panel.

symbol will turn off, AUTO will

149

M Y

N C

CLEANING AND MAINTENANCE

CLEANING THE GLASS-CERAMIC HOB

Before any cleaning and maintenance operation make sure that the appliance is switched off.

Clean the glass-ceramic hob only when it is completely cold. Individual cooking areas must be clean before they are used. Clean with a cloth or sponge.

Use a scraper to remove stubborn stains (observe the attached instructions).

Do not use scouring powder. Use only specific commercially available cleaning agents for glassceramic hobs.

CLEANING THE OVEN AND THE ACCESSORY

Following each oven cooking session, allow the oven to cool and then clean it. This precaution eliminates the risk of burning food residues the next time the oven is used.

Do not use scouring powder. To remove accumulated dirt, use a specific commercially available cleaning agent and follow the manufacturer’s instructions.

Clean outer surfaces of the appliance with a damp cloth and hot water. Do not use scouring powder or abrasive cleaners under any circumstances.

Clean the oven door window and the light cover with a cleaning agent.

Theaccessoriescanbewashedbyhandorina dishwasher, using a specific detergent for ovens.

After prolonged use of the oven, it may be necessary to dry the water that tends to condense inside the door and around the gasket [seal].

Do not use a steam cleaner because the moisture can get into the appliance thus make it unsafe.

GRILL HEATING ELEMENT

The heating element is self-cleaning and does not require maintenance.

INNER GLASS OF OVEN DOOR

To clean the oven door thoroughly, remove the inner pane by unscrewing the fixing screws.

CHANGING THE OVEN LIGHT

1. Disconnect the electrical power supply (for example,

by switching off the main power switch).

2. Unscrew the light cover

3. Fit a new bulb.

4. Refit the cover.

Note:

Use only bulbs designed to resist up to 300 following characteristics: 15 W, 230 V, type E-14. Spare bulbs can be ordered from Customer Service.

Cwiththe

150

M Y

N C

CLEANING AND MAINTENANCE

DISMANTLING THE DOOR

Please operate as follows:

Open the door completely.

The swivel retainers of the rh and lh hinges are hooked onto the metal bar above them.

Lift the oven door slightly. The noch on the bottom of the hinge will disengage.

Now pull the oven door forwards off the appliance. Release both hinge sections from the slots.

DOOR ASSEMBLY

Grip the door (as indicated in figure) and refit it in reverse order of removing procedure.

151

M Y

N C

TROUBLE-SHOOTING GUIDE

1. Hotplate not working

Check:

that the corresponding knob is on the required temperature setting.

that the appliance is receiving electrical power.

2. Oven not working.

Check:

that the function selector knob is on the required position

that the temperature knob is on the required position.

that the appliance is receiving electrical power.

3. Oven light not working.

Check:

that the appliance is receiving electrical power.

that the light is not burnt out (if it is, fit a new light).

AFTER SALES SERVICE

Before you contact the after-sales service:

Check the instructions in the “Troubleshooting” section to see whether you can deal with the problem without help.

Connect the appliance to the power supply again to see if the problem persists.

If the problem persists, call in the after-sales service.

When you call the after-sales service, please provide the following details:

A brief description of the fault;

The appliance’s exact service number (the number indicated alongside the word

Your full address;

Your telephone number and local dialling code;

When you can be contacted.

The service number can be seen on the bottom lefthand side when you open the oven door.

152

M Y

N C

INSTALLATION

GENERAL INFORMATION

1. The appliance is built in compliance with applicable

safety regulations and national/international EU directives.

2. The appliance must be installed by a licensed

electrician in compliance with the laws in force in your country and in observation of the instructions supplied by the manufacturer.

3. Remove all packing material from around and inside

the appliance.

The

to the following EU directives:

marking confirms that the appliance conforms

90/683; 73/23 (low voltage directive) and amendments;

89/336 (electromagnetic compatibility) and amendments.

The connection of the appliance to the grounding unit is mandatory. The manufacturer declines every responsability for any inconvenience resulting from the inobservance of this condition.

Once the cooker has been installed the switch or socket must always be accessible.

ADJUSTABLE PLINTH (not for Denmark)

153

M Y

N C

INSTALLATION

LOCATION

The cooker has type “Y” overheating protection so that it can be installed in a cabinet.

The kitchen furniture near the sides of the cooker should be made of heat-resistant material.

AMENDED INSTRUCTIONS

ANTI-TILT BRACKET

This cooker must not be used until it has been fastened to the anti-tilt bracket.

Attaching the anti-tilt bracket:

After you have located where the cooker is to be positioned mark, on the wall, the place where the 2 screws of the anti-tilt bracket have to be fitted. Please follow the dimensions given in the drawing below.

Maketwoholesofdiameterø8mmonthewall and insert the plastic plugs.

Move the cooker to the wall and adjust the height of the anti-tilt bracket so that it can engage in one slot of the cooker back.

Attach the anti-tilt brachet tightly.

Push the cooker against the wall so that the anti-tilt bracket is fully inserted in one slot of the cooker back.

Only for DENMARK

For 850 mm high cookers, an additional base can be ordered separately which can be installed under the cooker itself, thus bringing the overall height to 900 mm.

154

Cookers with plinth (H = 900 mm) A = 130 mm Cookers without plinth (H = 850 mm) A = 80 mm

M Y

N C

TABLES

The cooking times indicated are approximate; the temperature can be increased or decreased depending on the starting temperature of the food to be cooked, its size, etc. First set the lower temperature indicated, then the higher one if necessary.

Levels A, B, C and D are (from the top)

1. Confectionery

Confectionery

Kouglof 150 » 160 C 160 » 190 D or C 0:55 » 1:15 Biscuits preheat the oven preheat the oven

Pastry 170 » 180 C or B 200 » 220 D or C 0:15 » 0:30 Fruit cake 160 » 170 C or B 180 » 210 D or C 0:45 » 1:00 Cheese cakes 140 » 160 C or B 170 » 190 D or C 1:00 » 1:30

Croissants 150 » 170 C 180 » 200 C 0:25 » 0:40 Bread if necessary 230

Confectionery to be cooked on baking tray

Cake with thick trimmings 1 layer 160 » 180 B 180 » 200 C or B 0:30 » 0:45 2 layers 150 » 170 C and A - - 0:40 » 0:55 3 layers 150 » 170 D; B; A - - 0:40 » 1:00

Fruit cake 1 layer 150 » 170 B 180 » 200 C or B 0:30 » 0:45 2layers

Rolled biscuits preheat the oven

2. Cooking meat and fish

Meat

Boneless roast (1 kg) 140 » 160 C 175 » 200 C 1:40 » 2:20 Roast with rind (1 kg) 160 » 170 C 190 » 210 C 1:40 » 2:20 Roast beef 150 » 170 C 190 » 210 C 1:00 » 1:30 Meat loaf (1/2 kg) 140 » 160 C 190 » 210 C 1:00 » 1:10 Roast with bone (1 kg) 150 » 160 C 175 » 200 C 2:00 » 2:40 Chops 150 » 160 C 180 » 200 C 1:20 » 1:50

Poultry

Chicken 160 » 180 C 190 » 210 C or B 1:00 » 1:30 Duck (1/2 kg) 160 » 170 C 190 » 210 C 1:50 » 2:10 Goose 140 » 160 C 180 » 200 C 2:30 » 3:00

Fish

Whole fish up to 2 kg 150 » 170 C or B 200 » 220 C or B 0:45 » 1:00 Steam cooking up to 2 kg - - 180 » 190 C 0:35 » 1:00

Gameandroastsinapan

Depending on the food 180 » 230 D or C 200 » 230 D or C 0:50 » 2:00

Static/Fan function

Temperature Shelf Temperature Shelf

C] position [oC] position

[

150 » 160 C 160 » 180 D or C 0:30 » 0:45

preheat preheat the oven

180 » 200 C 200 » 230 C 0:50 » 1:10

if necessary preheat

150 » 170 C and A - - 0:35 » 0:50

160 » 180 C or B 190 » 210 C 0:10 » 0:20

Grill with fan function

Temperature Shelf Temperature Shelf

C] position [oC] position

[

Static function

preheat the oven

Static function

Cooking times [Hours:min]*

Gratinating

* The cooking times refer to a meat temperature of 10oC.

Bigger roasts and frozen meats require a longer cooking time.

230 » 250 C or A 250 B or A 0:15 » 0:30

155

M Y

N C

TABLES

Put the drip tray in the oven as indicated in the grill section. Preheat the grill for 5 minutes. Often the first side of the food needs longer cooking than the second.

3. Grill

Meat

Rump steak, 200 g 250 A 5 » 8 per side Steak, fillet up 2.5 cm thick 250 A 7 » 9 per side Steak, ficker fillet 250 B 10 » 15 per side Thin fillet 225 » 250 B 12 » 15 per side Hamburger 225 » 250 A 6 » 8 per side Liver (in slices) 225 » 250 A 5 » 7 per side Chicken thighs 210 » 250 B 15 » 20 per side

Roast beef, 500 g 210 » 225 B 15 » 20 per side Chicken (half) 200 » 225 B 20 » 25 per side

Fish

Mackerel 200 » 220 B 6 » 10 per side Herring 200 » 225 B 5 » 8 per side Fillets 225 » 250 A 6 » 8 per side

Gratinating

Toasted cheese sandwich 225 » 250 B or A 5 » 8 Onion soup 225 » 250 B 6 » 8

Fruit and vegetables

Bananas (halved) 210 » 225 A 5 » 7 Stuffed tomatoes 225 » 250 A 6 » 8

Temperature Shelf Cooking time

[

C] position [min]

156

M Y

N C

TABLESTABLES

4. Fan cooking

Defrosting

Chicken 50 C or B 1:20 » 1:35 Confectionery 150 » 170 C or B 0:05 » 0:20 Pre-cooked dishes 150 » 170 C or B 0:30 » 0:50

Drying without changing colour 100 » 120 - -

Bread, pizza 190 » 220 B – D 0:20 » 0:25

(respect the degree of resistance at the Pre-heat I temperature heat declared by the manufacturer). regulation

Biscuits, puff pastry, kouglof 140 » 160 C or B 0:16 » 0:20

Croissants, defrosting frozen products 150 » 170 B – D 0:18 » 0:22 (pre-cooked food), sterilise Pre-heat I temperature

Cheese cake, main dishes and 140 » 160 C or B 1:00 » 1:30 confectionery which does not require a high temperature

Meat

Boneless roast (1 kg) 140 » 160 C 1:40 » 2:20 Meat loaf (1/2 kg) 140 » 160 C 1:00 » 1:10 Roast with bone (1 kg) 150 » 160 C 2:00 » 2:40 Chops 150 » 160 C 1:20 » 1:50

Fish

Whole fish up to a 2 kg 150 » 170 C or B 0:45 » 1:00 Steaming up to 2 kg 150 » 160 C 0:35 » 1:00

Temperature Shelf Cooking time

[

C] position [Hours:min]

Pre-heat I temperature

regulation

Game and roasts in a pot

Depending on the food 180 » 230 D or C 0:50 » 2:00

157

M Y

N C

Ecological Paper − Cod. 1101748 − Whirlpool is a registered trademark of Whirlpool, U.S.A.

5019 100 70243

M Y

567O2

Printed in Italyr1/01/01

Whirlpool ACM 376, ACM 375, ACM 394, ACM 392, ACM 398 INSTRUCTION FOR USE

Specifications and Main Features

Frequently Asked Questions

User Manual
