Weider PRO XT20 User Manual

Model No. WEBE11923
Serial No.

Write the serial number in the space
above for reference.

CAUTION

Read all precautions and instruc­tions in this manual before using
this equipment. Save this manual
for future reference.

Serial Number Decal (under seat)

Visit our website at

www.weiderfitness.com

new products, prizes,

fitness tips, and much more!

USER’S MANUAL

QUESTIONS?

As a manufacturer, we are com­mitted to providing complete
customer satisfaction. If you have
questions, or if there are missing
parts, we will guarantee complete
satisfaction through direct assis­tance from our factory.

TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL­FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge to you.

CUSTOMER HOT LINE:

1-800-999-3756

Mon.–Fri., 6 a.m.–6 p.m. MST

TABLE OF CONTENTS

WARNING DECAL PLACEMENT

2

WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PART IDENTIFICATION CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

The decal shown at the right has
been placed on the weight bench in
the indicated location. If the decal is
missing or illegible, please call our
Customer Service Department toll­free at 1-800-999-3756, Monday
through Friday, 6 a.m. until 6 p.m.
Mountain Time, to order a free
replacement decal. Apply the
replacement decal in the location
shown.

WEIDER is a registered trademark of ICON Health & Fitness, Inc.

!

WARNING

• Misuse of this product may result in serious
injury.

• Read user’s manual and follow all warnings
and operating instructions prior to use.

• Do not allow children on or around machine.

• Replace label if damaged, illegible, or removed.

3

1. Read all instructions in this manual before
using the weight bench. Use the weight
bench only as described in this manual.

2. It is the responsibility of the owner to ensure
that all users of the weight bench are ade­quately informed of all precautions.

3. The weight bench is intended for home use
only. Do not use the weight bench in any
commercial, rental, or institutional setting.

4. Use the weight bench only on a level surface.
Cover the floor beneath the weight bench to
protect the floor.

5. Keep hands and feet away from moving parts.

6. Keep children under the age of 12 and pets
away from the weight bench at all times.

7. Inspect and tighten all parts each time you
use the weight bench. Replace any worn
parts immediately.

8. Always wear athletic shoes for foot protec­tion while exercising.

9. T

he weight bench is designed to support a
maximum of 560 pounds, including the user
and weights (not included). Do not place
more than 150 pounds on the leg lever.

10. If you feel pain or dizziness while exercising,
stop immediately and begin cooling down.

WARNING:Before beginning this or any exercise program, consult your physician. This

is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.

WARNING: To reduce the risk of serious injury, read the following important precautions

before using the weight bench.

IMPORTANT PRECAUTIONS

4

Weight Tube

Curl Pad

Backrest

Backrest Knob

Wheel

Leg Lever

Seat

Thank you for selecting the versatile WEIDER®PRO
XT20 weight bench. The PRO XT20 is designed to be
used with your weight set (not included) to help you
develop every major muscle group of the body.
Whether your goal is a shapely figure, dramatic
increase in muscle size and strength, or a healthier
cardiovascular system, the WEIDER

®

PRO XT20 will

help you achieve the specific results you want.

For your benefit, read this manual carefully before
using the WEIDER

®

PRO XT20 weight bench. If you

have additional questions, please call our Customer

Service Department toll-free at 1-800-999-3756,
Monday through Friday, 6 a.m. until 6 p.m. Mountain
Time (excluding holidays). To help us assist you,
please note the product model number and serial
number before calling. The model number is
WEBE11923. The serial number can be found on a
decal attached to the weight bench (see the front
cover of this manual).

Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.

BEFORE YOU BEGIN

5

Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST on page 14. Note: Some small parts may have

been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.

PART IDENTIFICATION CHART

M10 Nylon Locknut (11)

M8 Nylon Locknut (9)

M10 Washer (6)

M6 x 64mm Screw (4)

10mm Spacer (20)

M6 Washer (30)

M8 Flat Washer (13)

M10 x 45mm Bolt (38)

M8 x 58mm Bolt (16)

M10 x 58mm Carriage Bolt (8)

M10 x 65mm Bolt (23)

M10 x 22mm Bolt (7)

M6 x 16mm Screw (3)

M10 x 180mm Bolt (22)

M10 x 68mm Bolt (39)
