WaveSystem
User Guide
2
WaveSytem Toolbar
Quick Start, V12 and Higher
Use the Toolbar at the top of a plugin to compare parameter settings, manage your presets, and contr ol t he plugi n view.
Toolbar Functions
Open the plugin About box.
Undo Undo the last 32 actions.
Redo Redo t he last 32 undone actions.
Presets Menu Load, save, and manage presets.
Previous/Next Load the previous or next preset.
Copy A→B Copy the settings of the current setup to the second setup.
Setup (A or B) A/B between the two setups.
Save Save the current plugin settings as a new preset.
Toolbar Menu Adjust plugin size, open user guides, and access other functions.
A/B Settings
Use Setup A/Setup B to compare two versions of a plugin’s settings.
1. Select A or B and adjust the plugin as you like.
2. Click B→A (or A→B) to copy the plugin settings to t he other s et up. The setups are now the same.
3. Adjust the plugin settings on either setup.
4. Use Setup A/Setup B to compare the two setups.
WaveSystem / User Guide
3
Presets
A preset is a complete snapshot of a plugin’s settings. Each preset is a unique file with an “xps” extension. Presets are
managed in the Preset Menu. Click on the preset name in the middle of the Toolbar to open the menu.
Preset Menu
OAD A PRESET
L
The name of the loaded preset appears on the Preset Menu button on the Toolbar. An asterisk next to
the name indicates that the preset has been modified since it was loaded.
• Factory Presets are created by Waves or Waves artists and are installed with the plugin. They cannot
be modified.
• User Presets are created by the user and can be modified, deleted, and moved to subfolders.
SEARCH FOR PRESETS
• Use the Preset Browser to search for a preset by name.
SAVE A USER PRESET
• Click Save As in the Presets menu or Save on the Toolbar. By default, the preset is saved to the User
Presets folder.
• Click Save [user preset name] to overwrite the currently loaded preset.
SET A DEFAULT PRESET
• Set as Default Preset defines the current plugin settings as the default settings when the plugin is
inserted.
MANAGE PRESETS
• Show User Presets Folder opens the default User Presets folder. You can name, move, copy,
and delete presets and create new subfolders. Only presets that are in this folder will appear in the
Preset Menu under “User Presets.”
e Copy/Paste to copy and paste presets between plugin instances of the same plugin type.
• Us
LOADING OTHER PRESETS
Click Load… and then locate the preset file you want to load (or the preset folder that contains several preset files). You can
also load a preset by dragging its .xps file directly onto the plugin.
Once a preset is loaded, you can save it as a user preset or copy the preset file/folder into the User Presets folder.
WaveSystem / User Guide
4
Preset Browser
The Preset Browser lets you search for and load presets. Open the Preset Browser from the Preset Menu.
SEARCH FOR A PRESET BY NAME
• Type any part of a preset’s name. Search results appear in a list below.
• Click the small arrow to expand or collapse a folder in the list. To expand or
collapse everything, click the +/- button next to the search window.
SELECT OR LOAD A PRESET
• Click on a preset name with the mouse.
• You can also use the up/down keyboard arrows. A preset will load when you scroll
over its name.
RETURN THE PLUGIN TO ITS DEFAULT SETTINGS
•
Click Reset to Default.
SAVE PRESETS FROM THE PRESET BROWSER
Click the Menu icon at the top of the Browser to access the Save and Load
functions. These functions are also found in the Presets Menu.
MAKE THE
Select Open Browser by Default and the Preset Browser will open when you click the Preset
Menu button on the Toolbar. When this is not selected, the Presets Menu is the default view.
PRESET BROWSER THE DEFAULT VIEW
WaveSystem / User Guide
5
Managing Preset Files
User presets are located in each plugin’s User Preset folder. You can
rename, copy, move, and delete presets. You can also create subfolders to
help organize your presets.
The organization of folders, subfol ders, a nd preset s in the User Pr esets
folder are reflected in the Pres ets Men u and the Preset s Brows er.
DELETE A USER PRESET
Option One
Delete the preset file fr om the Us er Preset
folder.
Option Two
Hold CMD (Mac) or Ctrl (Win) while opening the
Presets Menu. You will see “Delete” before
each user preset name.
Select the preset you want to delete. You will
be prompted with “Are you sure you want to
delete [preset]?”
MIDI MAPPING
MIDI Instrument plugins have an additional MIDI map save options.
WaveSystem / User Guide
6
Other Toolbar Functions
Click the Toolbar Menu icon on the right side of the WaveSystem Toolbar for additional
options.
RESIZE PLUGIN WINDOWS
Plugin windows can be resized. Choose between five magnifications. This action affects the
currently selected plugin window. New instances of the same plugin will open with this
magnification. Choose Apply as Default to All to set this magnification for all f ut ure new
instances of all plugins.
PLUGIN-SPECIFIC CONTROLS IN THE TOOLBAR MENU
Certain Plugins have global controls that are not part of their interface windows. These appear as Toolbar M enu items. A
typical example is Analog Noise On/Off.
USER GUIDES
• User Manual is the user guide for the current Waves plugin.
• Waves System Guide concerns the WaveSystem Toolbar and interface controls (this document ) .
WaveSystem / User Guide
7
Plugin-Specific Toolbars
Certain plugins and applications have additional controls in their WaveSystem Toolbar s . Thes e controls govern “safe
parameters while loading presets,” sample libraries, mode controls, views, and more. Here are some examples:
Codex
Some virtual instruments and synths have “preset safe” checkboxes in the Toolbar (e.g., “MIDI,” “Arp-Seq,” and
Tempo”) to determine whether selected settings are change d when a n ew preset is loa ded.
FlowMotion
The FlowMotion Toolbar includes mode-select buttons (“Flow” and “Motion”) .
Electric 88
Certain virtual instrument Toolbars include a tuning control. This instrument’s sample libraries are accessed on the left
side of the Toolbar.
Renaissance EQ
Many Toolbars include a drop-down menu for selecting a skin view, as shown on the left. Also, certain EQ plu gins
feature a “Flat” button that resets all gains to zero, while maintaining Frequency and Q settings.
WaveSystem / User Guide
8
WaveSystem Interface Controls
This WaveSystem is a set of standards that apply to all Waves plugins. It provides consistency between pl ugins for
easier movement from one product to another. Different types of plugins have different controls, but the conventions are
similar with all plugins.
Most controls can be adjusted by dragging wit h the m ouse or f inger (t ouch screen), by scro lling over the
control with the mouse whe el, or by enter ing a va lue in the contr ol’s va lue box. Hold Alt/ Opt a nd click o n a
parameter control to reset it to it s default positi on.
PLUGINS WITH GRAPHIC DISPLAYS
Not Active
The current parameter control is not engaged. In certain plugins, such as EQs, this indicates that the
band is bypassed. Double-click on the graphic marker to turn the band on or off.
Active
The band or range control is active. In certain plugins, such as EQs, this indicates that the cur r ent band
is active.
Active and Selected
The active control is currently being adjusted.
When adjusting a graphic equalizer, move a graphic marker up or down to adjust gain and left to right to adj ust band
frequency. Hold Opt/Alt and drag up or down to adjust Q value. Hold Ctrl and drag up or down to adjust gain without
changing frequency and Q values. Similarly, hold Ctrl and drag left or right to change only t he frequenc y.
WaveSystem / User Guide
9
Renaissance EQ output fader linking (from left):
FADERS AND SLIDERS
Depending on the context, faders and sliders will indicate fader position and resulting value.
Some plugins have link buttons between a pair of faders, allowing click-and-drag adjustment while retaining
the offset between the controls. With certain EQ plugins, you can select which of the linked faders is the
“master” of the pair, and which channel follows. Any offset between the faders will be maintained when they
are linked.
No fader linking; Faders li nked, lef t contr ols r ight; Fa ders lin ked, right cont rols l eft
EQ FILTER TYPES
Click repeatedly on the Type button to cycle through the filter types that are available for the band
or set the Type directly with the drop-down menu.
TOGGLE BUTTONS
Toggle buttons display the state of a control and allow switching between two or m ore states. Single-click to
change the control’s state. Some toggle buttons have a text display that updates with the current s etting, and
others (bypass, solo, or monitoring toggles) illuminate when the control is active.
WaveSystem / User Guide
10
AUTOMATION AND EXTERNAL CONTROLLERS
A red band around a control indicates that it is being controlled by automation or external contr ollers .
VALUE BOXES
Value boxes display the value of a control and allow click-and-drag adjustment or direct control via the key board. A value
box can be a dedicated window above or below the control, or a value that appears when the control is touched or
manipulated, or part of a fader or slider itself. Adjusting a control directly from its value box enables v er y pr ec ise,
number-based adjustment.
Using the mouse, click and drag on the value window to adjust the parameter. Some value windows suppor t
left/right, some support up/down. You may also use the mouse wheel to adjust parameter values.
Using the arrow keys, click once with the mouse to select the button or simply hover over the control. Then use
the up/down or left/right arrows (depending on the direction supported by that butt on) to move in the smallest
incremental steps across the range of the button. Note: holding down the arrow keys will allow you to move faster
through the range.
Using key entry, double-click on the button to open the value window, and then enter the value from your
keyboard. If you enter an out-of-range number, the button stays selected but remains at the current sett ing. Note:
the system beeps if system sounds are on).
PRECISION CONTROL
Hold CMD (Mac) or Windows (PC) while moving a variable contorl to slow its movement and increase r es olut ion. This
does not apply to certain controls.
WaveSystem / User Guide
11
MULTIPLE CONTROL SELECTION
One of the most powerful features of the WaveSystem is its ability to select and adjust multiple controls s im ult aneously.
Using the mouse, draw a box around a group or controls you want to control together. Changes to any one control will
correspondingly change all other selected controls. Any offsets will remain.
You can also select more than one control by holding Shift while selecting. This is particularly useful when you need to
select multiple controls that are not adjacent.
TAB FUNCTIONS
You can use the Tab key to move between controls without using the mouse.
• Tab moves the Selected status to the next control.
• Shift/Tab moves the selection in the reverse direction.
• Additionally, with Mac, you can use the Option+Tab function for “down” movement and Shift+Option+Tab for
“up” movement where applicable.
• If you have several value window buttons selected, Tab functions will take you through the selected controls only .
Clicking Esc or Return will return the “focus” to the DAW application.
WaveSystem / User Guide
12
Miscellaneous
AUTOMATION
When you automate settings in Stereo mode, your settings will be saved for the specific channel (L or R) that you have
selected, but will affect both L and R.
When you automate L and R to different values in modes other than Stereo, but then wish to return to Stereo mode, you
will need to delete your settings for one of the sides (L or R) before you return to Stereo mode in order to avoid
conflicting values.
If you wish to change the Link mode of an automated plugin, we recommend that you use a second instance of that
plugin in order to automate the status of the Link while automating the bypass for both instances. This helps avoid
conflicts in Link mode and automation later on.
WAVES PREFERENCES (PRO TOOLS ONLY)
When launching Pro Tools, hold the Shift key to view the Waves Plugin Preferences window. Depen ding on your
configuration, other options may be available.
