VTech KidiJamz Studio, KidiLook, KidiLook-Digital Photo Frame Pink User Manual
2008
91-002348-000
KIDILOOK
TM
INTRODUCTION
Thank you for purchasing the VTech® Kidilook™!
Kidilook
™
is a digital photo frame that allows kids to view and
share their favorite pictures. With Kidilook™, you can store and
view up to 100 photos, create your own picture stories with a digital
ash card feature, and even switch to a digital clock display.
With the use of a simple PC application, you can quickly download
photos and picture stories to share with friends and family on your
Kidilook
™
. Also, with the easy one-click download feature, you
can even download photos from a Kidizoom Camera™ directly to
your Kidilook™ through PC.
PRODUCT FEATURES
Left arrow
Button
Hole for
hand strap
Right arrow
Button
Shufe Button
Clock Button
Photo Story Button
Photo Album Button
Introduction & Product Features
3
Power Button
Press this button to turn the Kidilook™ ON or OFF.
Left /Right arrow Button
Press direction buttons to view previous/next photo.
Photo Album Button
Press this button to view the photos.
Photo Story Button
Press this button to view your stories created on the PC.
Clock Button
Press this button to show the time.
Shufe Button
Hold this button and shake the unit to see a special effect in some
modes.
Reset Button
Press this button with an object tip to reset the unit if it stops
working properly.
USB Jack
Plug the included USB cable into this USB port to connect to your
PC.
Speaker
Power Button
Reset Button
USB Jack with
cover door
Battery door
Product Features
4
INCLUDED IN THIS PACKAGE
• 1 VTech® Kidilook
™
• 1 PC installation CD-ROM
• 1 USB cable
• 1 User’s Manual
• 1 wrist strap
WARNING:
All packing materials such as tape, plastic sheets, wire ties and
tags are not part of this toy, and should be discarded for your
child’s safety.
PRODUCT SPECIFICATION
Display: 1.8” color LCD
Memory: Stores around 100 photos in the Kidilook™.
Photo Format Supported: JPEG, BMP
Hardware Supported: USB Connection to PC
GETTING STARTED
BATTERY INSTALLATION
Note: Adult assembly is required for battery installation. Tools
required for battery installation: screwdriver (not included).
• Make sure the Kidilook™ is turned OFF.
• Locate the battery cover on the
back of the Kidilook™. Loosen the
screws using a screwdriver and
remove the battery cover.
• Install 2 new “AAA” batteries
as illustrated on the right. (The
use of new, alkaline batteries
is recommended for maximum
performance.)
• Replace the battery cover and tighten the screws. Do not over-
tighten screws.
Included In This Package
5
