VTech CS6419-2, CS6419, CS6419-15, CS6419-16, CS6419-3 User Manual
...
1
CS6419/CS6419-2/
CS6419-3/CS6419-4
DECT 6.0 cordless telephone
Introduction
To protect our environment and conserve natural resources, this user’s
manual provides you with the basic installation and use instructions.
A limited set of features are described in abbreviated form.
Please refer to the complete online CS6419/CS6419-2/CS6419-3/CS6419-4
user’s manual for a full set of installation and operation instructions at
www.vtechcanada.com.
Before using this VTech product, please read Important safety instructions
on page 11 of this user’s manual.
Table of contents
Parts checklist ............................... 1
Telephone base and
charger installation ..................... 2
Battery installation ......................... 2
Battery charging ............................ 2
Tabletop to wall mount
installation .................................. 3
Telephone base overview.............. 3
Handset overview .......................... 4
Using the menu ............................. 4
Telephone settings ........................ 4
Telephone operation...................... 5
Directory ........................................ 7
Speed dial...................................... 8
Caller ID......................................... 8
Call log........................................... 8
Add and register a handset ........... 9
Replace a handset......................... 9
Troubleshooting ............................. 9
Important safety instructions........ 11
Precautions for users of implanted
cardiac pacemakers ................. 12
Operating range........................... 12
Maintenance ................................ 12
About cordless telephones .......... 12
The RBRC® seal .......................... 12
Limited warranty .......................... 13
FCC, ACTA and IC regulations ....13
Technical specications............... 14
Parts checklist
Your telephone package contains the following items. Save your sales
receipt and original packaging in the event warranty service is necessary.
Telephone base
Telephone base
power adapter
Telephone line
cord
Battery
(1 for CS6419,
2 for CS6419-2,
3 for CS6419-3 and
4 for CS6419-4)
Battery compartment cover
(1 for CS6419, 2 for CS6419-2,
3 for CS6419-3 and 4 for CS6419-4)
User’s manual
User’s manual
Charger and
charger adapter
(1 for CS6419-2,
2 for CS6419-3 and
3 for CS6419-4)
Handset
(1 for CS6419,
2 for CS6419-2,
3 for CS6419-3 and
4 for CS6419-4)
Wall mount bracket
User’s manual
(Canada version)
2
Telephone base and charger installation
Install the telephone base and charger as shown below.
Telephone
line cord
Telephone base
Charger
Telephone base
power adapter
If you have DSL
high speed Internet
service, a DSL lter
(not included) is
required.
Electrical
outlet not
controlled by a
wall switch
Electrical
outlet not
controlled by
a wall switch
Telephone
wall jack
Charger adapter
Use only the power adapter and battery supplied with this product.
To order a replacement, visit our website at www.vtechcanada.com or
call 1 (800) 267-7377.
The power adapter is intended to be correctly oriented in a vertical or
oor mount position. The prongs are not designed to hold the plug in
place if it is plugged into a ceiling, under-the-table or cabinet outlet.
•
•
Battery installation
Install the battery as shown below.
3
Slide the battery compartment
cover towards the center of the
handset until it clicks into place.
4
Place the handset in the
telephone base or charger
to charge.
CHARGE light
remains on when
charging.
1
Plug the battery connector
securely into the socket.
2
Place the battery with the label
THIS SIDE UP facing up and
the wires inside the battery
compartment.
If the handset will not be used for a long time, disconnect and remove the
battery to prevent possible leakage.
Battery charging
Once you have installed the battery, the screen indicates the battery status
(see the table on page 3). For best performance, keep the handset in the
telephone base or charger when not in use. The battery is fully charged
after 10 hours of continuous charging. Refer to the online user’s manual for
battery operating times.
3
If you place the handset in the telephone base or charger without plugging
in the battery, the screen displays NO BATTERY.
Tabletop to wall mount installation
The telephone comes ready for tabletop use. Follow the steps below to
mount your telephone on a wall.
1
Plug one end of the telephone
line cord into the TEL LINE
jack at the bottom of the
telephone base and the base
power adapter into the
POWER jack.
2
Position the telephone base
against the wall mount bracket
as shown. Insert the extended
tabs marked B on the wall
mount bracket into the slots
marked B on the back of the
telephone base.
Route the telephone line cord
through the hole on the wall
mount bracket and plug it into
the telephone wall jack. Route
the power cord out of the
telephone base and plug it into
an electrical outlet not controlled
by a wall switch.
4
Align the holes on the bracket
with the standard wall plate and
slide the bracket down until it
locks securely. Bundle the
telephone line cord and power
adapter cord neatly with
twist ties.
/FIND HANDSET
Press once and then release to
page all system handsets.
IN USE light
On when the handset is in use.
Flashes quickly when there is an
incoming call.
Flashes slowly when another
telephone sharing the same line
is in use.
Telephone base overview
Battery indicators Battery status Action
The screen is blank,
or shows PLACE IN
CHARGER and ashes.
Battery has no charge
or very little charge. The
handset cannot
be used.
Charge without
interruption (at least
30 minutes).
The screen shows
LOW BATTERY and
ashes.
Battery has enough
charge to be used for
a short time.
Charge without
interruption (at least
30 minutes).
The screen shows
HANDSET X.
Battery is charged. To keep the batter y
charged, place it in
the telephone base or
charger when not in use.
3
4
Handset overview
CID /VOLUME
Review the call log when the
telephone is not in use.
Decrease the listening volume
during a call.
Scroll down while in a menu, or in
the directory, call log or redial list.
Move the cursor to the left when
entering numbers or names.
/FLASH
Make or answer a call.
Answer another incoming
call during a call.
MUTE/DELETE
Mute the microphone during
a call.
Delete digits or characters
while using the dialling keys.
Silence the ringer temporarily
while the handset is ringing.
Delete the displayed entry
while in the directory, call log
or redial list.
CHARGE light
On when the handset is charging.
TONE
Switch to tone dialing
temporarily during a call.
Dialing keys
Enter numbers or characters.
/VOLUME
Review the directory when
the telephone is not in use.
Increase the listening volume
during a call.
Scroll up while in a menu, or
in the directory, call log or
redial list.
Move the cursor to the right
when entering numbers
or names.
MENU/SELECT
Show the menu.
While in a menu, press to
select an item, or save an
entry or setting.
OFF/CANCEL
Hang up a call.
Silence the ringer
temporarily while the
handset is ringing.
Press and hold to erase the
missed call indicator while
the telephone is not in use.
Press to return to the
previous menu, or
press and hold to return
to idle mode, without
making changes.
REDIAL/PAUSE
Press repeatedly to review the
redial list.
Press and hold to insert a dialing
pause while entering numbers in the
director y.
# (pound key)
Press repeatedly to show
other dialing options when
reviewing a call log entry.
1
Press repeatedly to add or
remove 1 in front of the call
log entry before dialing or
saving it to the directory.
(speakerphone)
Press to make or answer a call
using the handset speakerphone.
During a call, press to switch
between the speakerphone
and the handset.
INT (intercom)
Start an intercom conversation or
transfer a call (for multi-handset
models only).
Using the menu
To enter the handset menu:
Press MENU/SELECT when the telephone is not in use.
Press or until the screen displays the desired feature menu.
Press MENU/SELECT to enter that menu.
To return to the previous menu, press OFF/CANCEL.
To return to idle mode, press and hold OFF/CANCEL.
Telephone settings
Default settings are indicated by asterisks (*).
Screen display Function Options
LCD LANGUAGE Set the screen display language. ENGLISH*
FRANÇAIS
ESPAÑOL
CLR VOICEMAIL Turn off the voicemail indicators. TURN OFF
INDICATOR?
KEY TONE Turn an audible beep on or off whenever
a key is pressed.
ON*
OFF
SET DATE/TIME Set the date and time shown on
the handset.
-:-- --/--
HOME AREA CODE Enter your home area code if you dial only
seven digits for local calls.
_ _ _
DIAL MODE Set the telephone to be tone or
pulse dialing.
TONE*
PULSE
1.
2.
3.
•
•
5
The following are some of the telephone features you may wish to set.
Refer to Telephone settings in the online user’s manual for detailed
instructions on setting all telephone features.
Ringer volume
You can adjust the ringer volume level, or turn the ringer off.
Press MENU/SELECT when the handset is not in use.
Scroll to >RINGERS, then press MENU/SELECT.
Press MENU/SELECT to select >RINGER VOLUME.
Press or to sample each volume level.
Press MENU/SELECT to save.
If the handset ringer volume is set to off, that handset is silenced for all
incoming calls except paging tone.
The ringer volume also determines the ringer volume of the intercom
calls and the volume of the paging tone.
Set date and time
If you subscribe to caller ID service, the day, month and time are set
automatically with each incoming call.
To set the date and time manually:
Press MENU/SELECT when the handset is not in use.
Scroll to select >SETTINGS, then press MENU/SELECT.
Scroll to select >SET DATE/TIME, then press MENU/SELECT.
Use the dialing keys (0-9) to enter the month, date and year.
Press MENU/SELECT to advance to set the time.
Use the dialing keys (0-9) to enter the hour and minute.
Press or to choose AM or PM, or press 2 for AM or 7 for PM. Press
MENU/SELECT to save.
Voicemail indicators
If you subscribe to voicemail service offered by your telephone service
provider, NEW VOICEMAIL and appear on the handset when you have
new voicemail messages. Contact your telephone service provider for
more information and assistance about using your voicemail service. Refer
to Clear voicemail indicators in the online user’s manual on how to clear
the voicemail indicators.
Telephone operation
Make a call
Press /FLASH or , and then dial the telephone
number.
-OR-
Predial by rst dialing the telephone number and
then press /FLASH or .
Answer a call
Press /FLASH, or any dialing key (0-9, TONE or #).
End a call
Press OFF/CANCEL or put the handset to the telephone base or charger.
Speakerphone
During a call, press to switch between speakerphone and normal
handset use.
Volume
During a call, press /VOLUME or /VOLUME to adjust the
listening volume.
The handset earpiece volume setting and speakerphone volume setting
are independent.
Mute
The mute function allows you to hear the other party but the other party
cannot hear you.
During a call, press MUTE/DELETE. The screen displays MUTED for a few
seconds and then MUTE appears until the mute function is turned off.
Press MUTE/DELETE again to resume the conversation. The screen
temporarily displays MICROPHONE ON.
1.
2.
3.
4.
5.
•
•
1.
2.
3.
4.
5.
6.
•
•
•
•
•
•
1.
2.
Loading...
