ViewSonic PX705HD, PA505W, LS800WU, LS800HD, PX725HD User Manual

PX705HD/PA505W
DLP Projector

User Guide

Model No. VS16964/VS16963

IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specic languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual”

i

Compliance Information

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the follow­ing two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa­tion. This equipment generates, uses, and can radiate radio frequency energy, and
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer­ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:

y Reorient or relocate the receiving antenna.
y Increase the separation between the equipment and receiver.
y Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

y Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modications not expressly approved

by the party responsible for compliance could void your authority to operate the
equipment.

For Canada

CAN ICES-3 (B)/NMB-3(B)

CE Conformity for European Countries

The device complies with the EMC Directive 2014/30/EU and Low Voltage
Directive 2014/35/EU.

Following information is only for EU-member states:

The mark is in compliance with the Waste Electrical and Electronic
Equipment Directive 2012/19/EU (WEEE).

The mark indicates the requirement NOT to dispose the equipment
including any spent or discarded batteries or accumulators as unsorted
municipal waste, but use the return and collection systems available.

If the batteries, accumulators and button cells included with this equipment,
display the chemical symbol Hg, Cd, or Pb, then it means that the battery
has a heavy metal content of more than 0.0005% Mercury or more than,

0.002% Cadmium, or more than 0.004% Lead.

ii

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this unit near water.

6. Clean with a soft, dry cloth.

7. Do not block any ventilation openings. Install the unit in accordance with the
manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves,

or other devices (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade and the third
prong are provided for your safety. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs.

Convenience receptacles and the point where they exit from the unit. Be sure
that the power outlet is located near the unit so that it is easily accessible.

11. Only use attachments/accessories specied by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specied by

the manufacturer, or sold with the unit. When a cart is used, use
caution when moving the cart/unit combination to avoid injury from
tipping over.

13. Unplug this unit when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the

unit has been damaged in any way, such as: if the power-supply cord or plug is
damaged, if liquid is spilled onto or objects fall into the unit, if the unit is exposed
to rain or moisture, or if the unit does not operate normally or has been dropped.

iii

Declaration of RoHS2 Compliance

This product has been designed and manufactured in compliance with Directive
2011/65/EU of the European Parliament and the Council on restriction of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Directive) and is deemed to comply with the maximum concentration values issued
by the European Technical Adaptation Committee (TAC) as shown below:

Substance

Proposed Maximum
Concentration

Actual Concentration

Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%

Certain components of products as stated above are exempted under the Annex III
of the RoHS2 Directives as noted below:

Examples of exempted components are:

1. Mercury in cold cathode uorescent lamps and external electrode uorescent

lamps (CCFL and EEFL) for special purposes not exceeding (per lamp):
(1) Short length (≦500 mm): maximum 3.5 mg per lamp.
(2) Medium length (＞500 mm and ≦1,500 mm): maximum 5 mg per lamp.
(3) Long length (＞1,500 mm): maximum 13 mg per lamp.

2. Lead in glass of cathode ray tubes.

3. Lead in glass of uorescent tubes not exceeding 0.2% by weight.

4. Lead as an alloying element in aluminium containing up to 0.4% lead by weight.

5. Copper alloy containing up to 4% lead by weight.

6. Lead in high melting temperature type solders (i.e. lead-based alloys containing

85% by weight or more lead).

7. Electrical and electronic components containing lead in a glass or ceramic other

than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.

iv

Copyright Information

Copyright © ViewSonic® Corporation, 2017. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks
of Microsoft Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered
trademarks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association.
DPMS and DDC are trademarks of VESA.
PS/2, VGA and XGA are registered trademarks of International Business Machines
Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors
or omissions contained herein; nor for incidental or consequential damages resulting
from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves
the right to change product specications without notice. Information in this docu­ment may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means,

for any purpose without prior written permission from ViewSonic Corporation.

Product Registration

To fulfill possible future product needs, and to receive additional product information
as it becomes available, please visit your region section on ViewSonic’s website to
register your product online.
Registering your product will best prepare you for future customer service needs.
Please print this user guide and fill the information in the “For Your Records” section.
For additional information, please see the “Customer Support” section in this guide.

For Your Records

Product Name: PX705HD/PA505W

ViewSonic DLP Projector

Model Number: VS16964/VS16963
Document Number: PX705HD/PA505W_UG_ENG Rev. 1A 10-18-17

Serial Number: ________________________________________
Purchase Date: ________________________________________

Product disposal at end of product life

The lamp in this product contains mercury which can be dangerous to you and the
environment. Please use care and dispose of in accordance with local, state or
federal laws.
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic
website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/eu/support/call-desk/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

1

Table of contents

Important safety

instructions .......................2

Introduction......................4

Projector features .................................4

Shipping contents................................. 5

Projector exterior view.........................6

Controls and functions ......................... 7

Positioning your

projector .........................12

Choosing a location............................12

Projection dimensions ........................ 13

Connection......................17

Connecting a computer or a monitor.. 18

Connecting Video source devices ...... 18

Playing sound through the projector .. 20

Operation........................21

Starting up the projector..................... 21

Using the menus.................................22

Utilizing the password function .........23

Switching input signal........................ 25

Adjusting the projected image ........... 26

Magnifying and searching

for details............................................27

Selecting the aspect ratio.................... 28

Optimizing the image......................... 29

Setting the presentation timer ............33

Hiding the image................................34

Locking control keys.......................... 34

Operating in a high altitude

environment .......................................34

Using the CEC function .....................35

Using the 3D functions ...................... 35

Using the projector in standby mode. 36

Adjusting the sound ........................... 36

Shutting down the projector .............. 37

Menu operation.................................. 38

Maintenance ...................46

Care of the projector .......................... 46

Lamp information .............................. 47

Troubleshooting .............50

Specifications..................51

Projector specifications...................... 51

Dimensions ........................................ 52

Ceiling mount installation ................. 52

Timing chart ................... 53

Copyright information ..57

Appendix.........................58

IR control table .................................. 58

RS232 command table....................... 59

2

Important safety instructions

Your projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that you
follow the instructions mentioned in this manual and marked on the product.

Safety Instructions

1. Please read this manual before you operate your projector. Save it for future
reference.

2. Do not look straight at the projector lens during operation. The intense light beam
may damage your eyes.

3. Refer servicing to qualified service personnel.

4. Always open the lens shutter or remove the lens cap when the projector lamp is

on.

5. In some countries, the line voltage is NOT stable. This projector is designed to operate
safely within a mains voltage between 100 to 240 volts AC, but could fail if power
cuts or surges of ±10 volts occur. In areas where the mains voltage may fluctuate

or cut out, it is recommended that you connect your projector through a power
stabilizer, surge protector or uninterruptible power supply (UPS).

6. Do not block the projection lens with any objects when the projector is under
operation as this could cause the objects to become heated and deformed or even
cause a fire. To temporarily turn off the lamp, press BLANK on the projector or
remote control.

7. The lamp becomes extremely hot during operation. Allow the projector to cool for
approximately 45 minutes prior to removing the lamp assembly for replacement.

8. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps
beyond the rated life could cause them to break on rare occasions.

9. Never replace the lamp assembly or any electronic components unless the projector is
unplugged.

10. Do not place this product on an unstable cart, stand, or table. The product may fall,
sustaining serious damage.

11. Do not attempt to disassemble this projector. There are dangerous high voltages inside
which may cause death if you should come into contact with live parts. The only user
serviceable part is the lamp which has its own removable cover.

Under no circumstances should you ever undo or remove any other covers. Refer
servicing only to suitably qualified professional service personnel.

12. Do not place this projector in any of the following environments.

- Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls
and free flow of air around the projector.

- Locations where temperatures may become excessively high, such as the inside of a
car with all windows rolled up.

- Locations where excessive humidity, dust, or cigarette smoke may contaminate optical
components, shortening the projector's life span and darkening the picture.

- Locations near fire alarms

- Locations with an ambient temperature above 40°C / 104°F

- Locations where the altitudes are higher than 3000 m (10000 feet).

3

13. Do not block the ventilation holes. If the ventilation holes are seriously obstructed,
overheating inside the projector may result in a fire.

- Do not place this projector on a blanket, bedding or any other soft surface.

- Do not cover this projector with a cloth or any other item.

- Do not place inflammables near the projector.

14. Always place the projector on a level, horizontal surface during operation.

- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of
more than 15 degrees front to back. Using the projector when it is not fully horizontal
may cause a malfunction of, or damage to, the lamp.

15. Do not stand the projector on end vertically. Doing so may cause the projector to fall
over, causing injury or resulting in damage to the projector.

16. Do not step on the projector or place any objects upon it. Besides probable physical
damage to the projector, doing so may result in accidents and possible injury.

17. Do not place liquids near or on the projector. Liquids spilled into the projector may
cause it to fail. If the projector does become wet, disconnect it from the power
supply's wall socket and call your local service center to have the projector serviced.

18. This product is capable of displaying inverted pictures for ceiling mount installation.

Use only qualified ceiling mount kit for mounting the projector and ensure it is
securely installed.

19. When the projector is under operation, you may sense some heated air and odor from
its ventilation grill. It is a normal phenomenon and not a product defect.

20. Do not use the Security bar for transporting or installation. It should be used with a
commercially available theft prevention cable.

Safety instructions for ceiling mounting of the
projector

We want you to have a pleasant experience using your projector, so we need to bring this
safety matter to your attention to prevent damage to person and property.

If you intend to mount your projector on the ceiling, we strongly recommend that you use a
proper fitting projector ceiling mount kit and that you ensure it is securely and safely
installed.

If you use an inappropriate projector ceiling mount kit, there is a safety risk that the
projector may fall from the ceiling due to an improper attachment through the use of the
wrong gauge or length screws.

You can purchase a projector ceiling mount kit from the place you purchased your projector.
We recommend that you also purchase a separate security cable and attach it securely to
both the anti-theft lock slot on the projector and the base of the ceiling mount bracket. This
will perform the secondary role of restraining the projector should its attachment to the
mounting bracket become loose.

As with any bright light source, do not stare into the beam, RG2
IEC 62471-5:2015.

4

Introduction

Projector features

The projector integrates high-performance optical engine projection and a user-friendly
design to deliver high reliability and ease of use.

The projector offers the following features.

• Dynamic mode adjusting the power consumption of the lamp according to the
brightness of the image being projected

• Power saving function decreasing the power consumption of the lamp by up to 70%
when no input signal can be detected for a set period of time.

• Presentation timer for better control of time during presentations

• Supports 3D display

•Color Management allowing color adjustments to your liking

• Less than 0.5W power consumption when power saving mode is turned on

• Screen Color correction allowing projection on surfaces of several predefined colors

• Quick auto search speeding up the signal detecting process

• Color modes providing choices for different projection purposes

• Selectable quick power off function

• One-key auto-adjustment to display the best picture quality

• Digital keystone correction to correct distorted images

• Adjustable color management control for data/video display

• Ability to display 1.07 billion colors

• Multi-language On-Screen Display (OSD) menus

• Switchable normal and economic modes to reduce the power consumption

• Component HDTV compatibility (YP

bPr)

• HDMI CEC (Consumer Electronics Control) function allows synchronized power ON/
OFF operation between the projector and a CEC-compatible DVD player device
connected to the HDMI input of the projector

The apparent brightness of the projected image will vary depending on the ambient lighting
conditions, selected input signal contrast/brightness settings, and is directly proportional to
projection distance.

The lamp brightness will decline over time and may vary within the lamp manufacturers
specifications. This is normal and expected behavior.

5

Shipping contents

Carefully unpack and verify that you have all of the items shown below. If any of these
items are missing, please contact your place of purchase.

Standard accessories

The supplied accessories will be suitable for your region, and may differ from those
illustrated.

Optional accessories

1. Replacement lamp

Projector Power Cord VGA Cable

Quick Start Guide

Remote Control &

Batteries

Home Projector

Quick Start Guide

ViewSonic Corporation (US/Canada/Latin America)

: www.viewsonic.com/support/product-registration
: 14035 Pipeline Ave. Chino, CA 91710, USA
: 909-468-1240

ViewSonic Europe Ltd.

: www.viewsoniceurope.com
: 1st Floor, Salamanca Place,9 Albert Embankment, London
SE1 7SP, United Kingdom
: [phone]

United States

1-800-688-6688
[e-mail]

Canada

1-866-463-4775
[e-mail]

Europe

http://www.viewsoniceurope.com/eu/support/call-desk/

ViewSonic China Limited

: www.viewsonic.com.cn/?fservice_register

Puerto Rico & Virgin Islands

1-800-688-6688 (English)
http://www.viewsonic.com/
la/soporte/servicio-tecnico
(Español)
[e-mail]
[e-mail]

Latin America

http://www.viewsonic.com/la/
[e-mail]

Chile

1230-020-7975

Mexico

001-8882328722

Peru

0800-54565

Argentina

0800-4441185

http://vsweb.us/

http://vsweb.us

UG Link

6

Projector exterior view

1. Lamp cover

2. Front IR remote sensor

3. Projection lens

4. Focus ring

5. Zoom ring

6. Power button and LED indicators

7. External control panel
(See "Projector" on page 7 for
details.)

8. Vent (air inlet)

9. AC power cord inlet

10. HDMI-1 port

11. HDMI-2 port

12. RGB (PC)//Component video
(YPbPr/YCbCr) signal input
socket-2

13. RGB (PC)//Component video
(YPbPr/YCbCr) signal input
socket-1

14. RS232 control port

15. Monitor out socket

16. Video input socket

17. Audio signal output socket

18. Audio signal input socket

19. USB port (5V/1.5A out)

20. Mini USB port

21. Kensington Security Slot

22. Adjuster foot

Warning

• THIS APPARATUS MUST BE EARTHED.

• When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring,
or connect the power plug to an easily accessible socket-outlet near the unit. If a fault should
occur during operation of the unit, operate the disconnect device to switch the power supply
off, or disconnect the power plug.

1 2 3 4 5 6 7 8

Front/upper

9

1917 181615 20 21

10 11

1312 14

22

Rear/lower side

7

Controls and functions

Projector

1. Focus ring

Adjusts the focus of the projected image.

2. Zoom ring

Adjusts the size of the projected image.

3. Power

Toggles the projector between standby
mode and Power ON.

4. (Power indicator light)

Lights up or flashes when the projector is
under operation.

5. (Temperature indicator light)

Lights up red if the projector's temperature
becomes too high.

6. (Lamp indicator light)

Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem.

7. (Menu up)

Selects the desired menu items and makes
adjustments.

(Keystone key)

Manually corrects distorted images
resulting from an angled projection.

8. Blank

Makes the screen blank.

9. Menu

Turns on the On-Screen Display (OSD)
menu.

Exit

Goes back to previous OSD menu, exits
and saves menu settings.

10. Source

Displays the source selection bar.

(Help)

Displays the HELP menu by a long press
for 3 seconds.

11. (Volume down)

Decrease the volume level.

(Left)

Selects the desired menu items and makes
adjustments.

12. (Menu down)

Selects the desired menu items and makes
adjustments.

(Keystone key)

Manually corrects distorted images
resulting from an angled projection.

13. Enter

Enacts the selected On-Screen Display
(OSD) menu item.

14. Color Mode

Selects an available picture setup mode.

15. (Volume up)

Increase the volume level.

(Right)

Selects the desired menu items and makes
adjustments.

21

223 4 5 6 7 8

10 11 12 13 14 159

8

Remote control

1. Power

Toggles the projector between standby
mode and Power ON.

2. VIDEO

Selects Video source for display.

3. COMP

Selects D-Sub / Comp. source for
display.

4. Auto Sync

Automatically determines the best
picture timings for the displayed
image.

5. / (Keystone keys)

Manually corrects distorted images
resulting from an angled projection.

Left/ Right/ Up/ Down

Selects the desired menu items and
makes adjustments.

6. (Information)

Displays the Information menu.

7. Menu

Turns on the On-Screen Display
(OSD) menu.

8. Freeze

Freezes the projected image.

9. Aspect

Selects the display aspect ratio.

17

21

22
23

24

25

26

18

19

20

16

1
2

3

4

5

6

7
8
9

10
11
12
13
14

15

9

Remote control code

The projector can be assigned to 8 different remote control
codes, 1 to 8. When several adjacent projectors are in
operation at the same time, switching the remote control codes
can prevent interference from other remote controls. Set the
remote control code for the projector first before changing that
for the remote control.

To switch the code for the projector, select from among 1 to 8
in the SYSTEM SETTING: ADVANCED > Remote
Control Code menu.

To switch the code for the remote control,
press ID set and the number button
corresponding to the remote control code
set in the projector OSD together for 5
seconds or more. The initial code is set to

1. When the code is switched to 8, the
remote control can control every
projector.

If different codes are set on the projector and remote control, there will be no response from
the remote control. When that happens, a message will display to remind you to switch the
code for the remote control.

10. PgUp (Page Up)/

Operates your display software program
(on a connected PC) which responds to
page up commands (like Microsoft
PowerPoint) when the mouse mode is
activated.

11. (Volume up)

Increase the volume level.

12. PgDn (Page Down)

Operates your display software program
(on a connected PC) which responds to
page down commands (like Microsoft
PowerPoint).

Only available when a PC input signal is
selected.

13. (Volume down)

Decrease the volume level.

14. Eco Mode

Selects a lamp mode.

15. (Mute)

Toggles the projector audio between on and
off.

16. LED indicator

17. Power Off

Turns the projector off.

18. HDMI

Selects HDMI source for display.

19. Source

Displays the source selection bar.

20. Enter

Enacts the selected On-Screen Display
(OSD) menu item.

21. Exit

Goes back to previous OSD menu, exits
and saves menu settings.

22. Pattern

Displays embedded test pattern.

23. Blank

Hides the screen picture.

24. (Zoom in)

Magnifies the projected picture size.

25. (Zoom out)

Reduces the projected picture size.

26. Color Mode

Selects an available picture setup mode.

HDMI
/MHL

10

Using the remote PgUp/PgDn function

The capability of operating your computer with the remote control gives you more
flexibility when delivering presentations.

1. Set the input signal to a PC signal.

2. Connect the projector to your PC or notebook with a USB cable prior to using the
remote control in place of your computer’s mouse. See "Connecting a computer or a

monitor" on page 18 for details.

3. To operate your display software program (on a connected PC) which responds to
page up/down commands (like Microsoft PowerPoint), press PgUp/PgDn.

Remote control effective range

The Infra-Red (IR) remote control is located on the
front of the projector. The remote control must be held
at an angle within 30 degrees perpendicular to the
projector's IR remote control sensor to function
correctly. The distance between the remote control and
the sensor should not exceed 8 meters (~ 26 feet).

Make sure that there are no obstacles between the
remote control and the IR sensor on the projector that
might obstruct the infra-red beam.

Approx. 30°

A

pp

r

ox

.

30

°

11

Replacing the remote control batteries

1. To open the battery cover, turn the remote control over to view its back, press on the
finger grip on the cover and pull it up in the direction of the arrow as illustrated.

2. Remove any existing batteries (if necessary) and install two AAA batteries observing
the battery polarities as indicated in the base of the battery compartment. Positive (+)
goes to positive and negative (-) goes to negative.

3. Refit the cover by aligning it with the base and pushing it back down into position.
Stop when it clicks into place.

WARNING

• Avoid leaving the remote control and batteries in an excessive heat or humid environment

like the kitchen, bathroom, sauna, sunroom or in a closed car.

• Replace only with the same or equivalent type recommended by the battery manufacturer.

• Dispose of the used batteries according to the manufacturer's instructions and local

environment regulations for your region.

• Never throw the batteries into a fire. There may be danger of an explosion.

• If the batteries are drained or if you will not be using the remote control for an extended

period of time, remove the batteries to avoid damage to the remote control from possible
battery leakage.

• RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

• DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

12

Positioning your projector

Choosing a location

Your room layout or personal preference will dictate which installation location you select.
Take into consideration the size and position of your screen, the location of a suitable power
outlet, as well as the location and distance between the projector and the rest of your
equipment.

Your projector is designed to be installed in one of the following 4 possible installation
locations:

1. Front Table

Select this location with the projector placed near
the floor in front of the screen. This is the most
common way to position the projector for quick
setup and portability.

2. Front Ceiling

Select this location with the projector suspended
upside-down from the ceiling in front of the screen.

Purchase the projector ceiling mount kit from your
dealer to mount your projector on the ceiling.

Set Front Ceiling in the SYSTEM > Projector

Position menu after you turn the projector on.

3. Rear Ceiling

Select this location with the projector suspended
upside-down from the ceiling behind the screen.

Note that a special rear projection screen and the
projector ceiling mounting kit are required for this
installation location.

Set Rear Ceiling in the SYSTEM > Projector

Position menu after you turn the projector on.

4. Rear Table

Select this location with the projector placed near
the floor behind the screen.

Note that a special rear projection screen is
required.

Set Rear Table in the SYSTEM > Projector
Position menu after you turn the projector on.

13

Projection dimensions

PX705HD

The "screen" mentioned below refers to the projection screen usually consisting of a screen
surface and a support structure.

(f): Center of lens(e): Screen

• 16:9 image on a 16:9 screen

• 16:9 image on a 4:3 screen

(a) Screen Size

16:9 image on a 16:9 Screen

(b) Projection distance

(c) Image height

(d) Vertical offset

min. max. min. max.

inch mm inch mm inch mm inch mm inch mm inch mm

50 1270 65 1651 72 1829 25 635 2.2 55 3.7 93

60 1524 78 1981 86 2184 29 737 2.6 66 4.4 112

70 1778 92 2337 101 2565 34 864 3 77 5.2 131

80 2032 105 2667 115 2921 39 991 3.5 88 5.9 149

90 2286 118 2997 129 3277 44 1118 3.9 99 6.6 168

100 2540 131 3327 144 3658 49 1245 4.3 110 7.4 187

110 2794 144 3658 158 4013 54 1372 4.8 121 8.1 205

120 3048 157 3988 173 4394 59 1499 5.2 131 8.8 224

130 3302 170 4318 187 4750 64 1626 5.6 142 9.6 243

140 3556 183 4648 201 5105 69 1753 6 153 10.3 262

150 3810 196 4978 216 5486 74 1880 6.5 164 11 280

170 4318 222 5639 244 6198 83 2108 7.3 186 12.5 318

190 4826 248 6299 273 6934 93 2362 8.2 208 14 355

14

(a) Screen Size

16:9 image on a 4:3 Screen

(b) Projection distance

(c) Image height

(d) Vertical offset

min. max. min. max.

inch mm inch mm inch mm inch mm inch mm inch mm

54 1372 65 1651 72 1829 25 635 2.2 55 3.7 93

65 1651 78 1981 86 2184 29 737 2.6 66 4.4 112

76 1930 92 2337 101 2565 34 864 3 77 5.2 131

87 2210 105 2667 115 2921 39 991 3.5 88 5.9 149

98 2489 118 2997 129 3277 44 1118 3.9 99 6.6 168

109 2769 131 3327 144 3658 49 1245 4.3 110 7.4 187

120 3048 144 3658 158 4013 54 1372 4.8 121 8.1 205

131 3327 157 3988 173 4394 59 1499 5.2 131 8.8 224

142 3607 170 4318 187 4750 64 1626 5.6 142 9.6 243

153 3886 183 4648 201 5105 69 1753 6 153 10.3 262

163 4140 196 4978 216 5486 74 1880 6.5 164 11 280

185 4699 222 5639 244 6198 83 2108 7.3 186 12.5 318

207 5258 248 6299 273 6934 93 2362 8.2 208 14 355

15

PA505W

The "screen" mentioned below refers to the projection screen usually consisting of a screen
surface and a support structure.

(b)

(c)

(a)

(d)

(f)

(f): Center of lens(e): Screen

• 16:10 image on a 16:10 screen

• 16:10 image on a 4:3 screen

(b)

(a)

(d)

(c)

(e)

(a) Screen Size

16:10 image on a 16:10 Screen

(b) Projection distance

(c) Image height

(d) Vertical offset

min. max. min. max.

inch mm inch mm inch mm inch mm inch mm inch mm

50 1270 67 1691 73 1863 25 635 1.5 38

60 1524 80 2029 88 2236 29 737 1.8 45

70 1788 93 2367 103 2608 34 864 2.1 53

80 2032 107 2705 117 2981 39 991 2.4 60

90 2286 120 3043 132 3354 44 1118 2.7 68

100 2540 133 3382 147 3726 49 1245 3.0 75

110 2794 146 3720 161 4099 54 1372 3.3 83

120 3048 160 4058 176 4472 59 1499 3.6 90

130 3302 173 4396 191 4844 64 1626 3.9 98

140 3556 186 4734 205 5217 69 1753 4.2 106

150 3810 200 5072 220 5589 74 1880 4.5 113

170 4318 226 5749 249 6335 83 2108 5.0 128

190 4826 253 6425 279 7080 93 2362 5.6 143

16

There is 3% tolerance among these numbers due to optical component variations. It is
recommended that if you intend to permanently install the projector, you should physically
test the projection size and distance using the actual projector in situ before you permanently
install it, so as to make allowance for this projector's optical characteristics. This will help you
determine the exact mounting position so that it best suits your installation location.

(a) Screen Size

16:10 image on a 4:3 Screen

(b) Projection distance

(c) Image height

(d) Vertical offset

min. max. min. max.

inch mm inch mm inch mm inch mm inch mm inch mm

54 1372 68 1723 75 1898 27 686 1.5 38

65 1651 82 2074 90 2285 33 826 1.8 46

76 1930 95 2425 105 2672 38 965 2.1 54

87 2210 109 2776 120 3058 44 1105 2.4 62

98 2489 123 3126 136 3445 49 1245 2.7 70

109 2769 137 3477 151 3823 55 1384 3.1 78

120 3048 151 3828 166 4218 60 1524 3.4 85

131 3327 165 4179 181 4605 66 1644 3.7 93

142 3607 178 4530 197 4992 71 1803 4.0 101

153 3886 192 4881 212 5379 77 1943 4.3 109

163 4140 205 5200 226 5730 82 2070 4.6 116

185 4699 232 5902 256 6503 93 2350 5.2 132

207 5258 260 6604 286 7277 104 2629 5.8 147

17

Connection

When connecting a signal source to the projector, be sure to:

1. Turn all equipment off before making any connections.

2. Use the correct signal cables for each source.

3. Ensure the cables are firmly inserted.

In the connections shown below, some cables may not be included with the projector (see

"Shipping contents" on page 5). They are commercially available from electronics stores.

The connection illustrations below are for reference only. The rear connecting jacks available
on the projector vary with each projector model.

For detailed connection methods, see pages 18-20.

1. VGA to DVI-A cable

2. VGA cable

3. HDMI cable

4. RS232 cable

5. Audio cable

6. Video cable

7. USB power supply 5V/1.5A

8. Mini USB cable

9. Component Video to VGA (D-Sub)
adapter cable

6

9

5

5

4

3

3

5

8

Y Pb Pr

7

221

Notebook or desktop
computer

A/V device

Speakers

or

Monitor

or(DVI) (VGA)

18

Connecting a computer or a monitor

Connecting a computer

1. Take the supplied VGA cable and connect one end to the D-Sub output socket of the
computer.

2. Connect the other end of the VGA cable to the COMPUTER IN signal input socket
on the projector.

Many notebooks do not turn on their external video ports when connected to a projector.
Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a
function key labeled CRT/LCD or a function key with a monitor symbol on the notebook. Press
FN and the labeled function key simultaneously. Refer to your notebook's documentation to
find your notebook's key combination.

Connecting a monitor

If you want to view your presentation close-up on a monitor as well as on the screen, you
can connect the MONITOR OUT signal output socket on the projector to an external
monitor with a VGA cable following the instructions below:

1. Connect the projector to a computer as described in "Connecting a computer" on page

18.

2. Take a suitable VGA cable (only one supplied) and connect one end of the cable to the
D-Sub input socket of the video monitor.

Or if your monitor is equipped with a DVI input socket, take a VGA to DVI-A cable
and connect the DVI end of the cable to the DVI input socket of the video monitor.

3. Connect the other end of the cable to the MONITOR OUT socket on the projector.

The MONITOR OUT output only works when COMPUTER IN connection is made to the
projector.

To use this connection method when the projector is in standby mode, turn on the Active VGA
Out function under the SOURCE > Standby Settings menu.

Connecting Video source devices

You can connect your projector to various Video source devices that provide any one of the
following output sockets:

• HDMI

• Component Video

• Video (composite)

You need only connect the projector to a Video source device using just one of the above
connecting methods, however each provides a different level of video quality. The method
you choose will most likely depend upon the availability of matching terminals on both the
projector and the Video source device as described below:

Best video quality

The best available video connection method is HDMI. If your source device is equipped
with an HDMI socket, you can enjoy uncompressed digital video quality.

See "Connecting an HDMI device" on page 19 for how to connect the projector to an HDMI
source device and other details.

If no HDMI source is available, the next best video signal is Component video (not to be
confused with composite video). Digital TV tuner and DVD players output Component

19

video natively, so if available on your devices, this should be your connection method of
choice in preference to (composite) video.

See "Connecting a Component Video source device" on page 19 for how to connect the
projector to a component video device.

Least video quality

Composite Video is an analog video and will result in a perfectly acceptable, but less than
optimal result from your projector, being the least video quality of the available methods
described here.

See "Connecting a composite Video source device" on page 20 for how to connect the
projector to a composite Video device.

Connecting audio

The projector has built-in mono speaker(s) which is designed to provide basic audio
functionality accompanying data presentations for business purposes only. It is not designed
for, nor intended for stereo audio reproduction use as might be expected in home theater or
home cinema applications. Any stereo audio input (if provided), is mixed into a common
mono audio output through the projector speaker.

If you wish, you can make use of the projector (mixed mono) speaker in your presentations,
and also connect separate amplified speakers to the Audio Out socket of the projector. The
audio output is a stereo signal and controlled by the projector Volume and Mute settings.

If you have a separate sound system, you will most likely want to connect the audio output
of your Video source device to that sound system, instead of to the mono audio projector.

Connecting an HDMI device

You should use an HDMI cable when making connection between the projector and HDMI
devices.

1. Take an HDMI cable and connect one end to the HDMI output port of the video
device.

2. Connect the other end of the cable to the HDMI input port on the projector.

In the unlikely event that you connect the projector to a DVD player via the projector’s HDMI
input and the projected picture displays wrong colors, please change the color space to YUV.
See "Changing HDMI input settings" on page 25 for details.

The projector is only capable of playing mixed mono audio, even if a stereo audio input is
connected. See "Connecting audio" on page 19 for details.

Connecting a Component Video source device

Examine your Video source device to determine if it has a set of unused Component Video
output sockets available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

1. Take a VGA (D-Sub)-Component adaptor cable and connect the end with 3 RCA type
connectors to the Component Video output sockets of the Video source device. Match
the color of the plugs to the color of the sockets; green to green, blue to blue, and red
to red.

2. Connect the other end of the VGA (D-Sub)-Component adaptor cable (with a D-Sub
type connector) to the COMPUTER IN socket on the projector.

The projector is only capable of playing mixed mono audio, even if a stereo audio input is
connected. See "Connecting audio" on page 19 for details.

20

If the selected video image is not displayed after the projector is turned on and the correct
video source has been selected, check that the Video source device is turned on and
operating correctly. Also check that the signal cables have been connected correctly.

Connecting a composite Video source device

Examine your Video source device to determine if it has a set of unused composite Video
output sockets available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

1. Take a Video cable and connect one end to the composite Video output socket of the
Video source device.

2. Connect the other end of the Video cable to the VIDEO socket on the projector.

The projector is only capable of playing mixed mono audio, even if a stereo audio input is
connected. See "Connecting audio" on page 19 for details.

If the selected video image is not displayed after the projector is turned on and the correct
video source has been selected, check that the Video source device is turned on and
operating correctly. Also check that the signal cables have been connected correctly.

You need only connect to this device using a composite Video connection if Component Video
input is unavailable for use. See "Connecting Video source devices" on page 18 for details.

Playing sound through the projector

You can make use of the projector (mixed mono) speaker in your presentations, and also
connect separate amplified speakers to the AUDIO OUT socket of the projector.

If you have a separate sound system, you will most likely want to connect the audio output
of your Video source device to that sound system, instead of to the mono audio projector.

Once connected, the audio can be controlled by the projector On-Screen Display (OSD)
menus. See "Adjusting the sound" on page 36 for details.
