GAS/SET2
GAS SOLDERING IRON SET
GAS-SOLDEERBOUT SET
JEU DE FER À SOUDER AU GAZ
JUEGO CON SOLDADOR A GAS
GASLÖTKOLBEN-SATZ
USER MANUAL 3
GEBRUIKERSHANDLEIDING 6
MODE D'EMPLOI 9
MANUAL DEL USUARIO 12
BEDIENUNGSANLEITUNG 15
GAS/SET2
V. 01 – 24/11/2014 2 ©Velleman nv
GAS/SET2
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children shall be supervised to ensure that they do not play with the appliance.
Indoor use only. Keep this device away from rain, moisture, splashing and
dripping liquids. Never put objects filled with liquids on top of or close to the
device.
Do not use near inflammable products or in explosive atmospheres. Heat can cause
fire to inflammable products even when they are not in sight. Only use in properly
ventilated rooms.
Incorrect use may cause fire.
Do not touch the shafts, tips, or hot soldering iron as this can cause serious burns.
Keep the tips away from the body, clothes, or other flammable material. Do not
aim the soldering iron at the eyes. Use gloves and/or heat-resistant tools to pick up
the PCB assembly to prevent burns. Always return the irons and gun to their stands
between uses; always let the device cool down after use and before storage.
Place the device on a level, stable, and fire resistant working surface.
Do not inhale solder fumes. The vapours that are released during soldering are
harmful. Therefore, you shall only use the soldering station in well-ventilated areas
or under an exhaust hood (solder fume extractor). Dispose of fume filters and
solder residue in accordance with local regulations.
Never use the device on live electronic circuits. Make sure power to the work piece
is cut and capacitors are discharged.
Do not block the blow head. This may cause heat reflection and may damage the
heating element.
Warning! This tool must be placed on a stand when not in use; do not leave the
tool unattended when switched on.
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, do not install or use it and contact your dealer.
2. Safety Instructions
This symbol on the device or the package indicates that disposal of the device after its lifecycle
could harm the environment. Do not dispose of the unit (or batteries) as unsorted municipal
waste; it should be taken to a specialized company for recycling. This device should be returned
to your distributor or to a local recycling service. Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Use the soldering iron on a heatproof workbench.
Let a hot soldering iron cool down naturally and do not immerse in water.
V. 01 – 24/11/2014 3 ©Velleman nv
GAS/SET2
1
gas filler valve
5 soldering tip
2
ignition button
6 metal sleeve
3
safety lock
7 flame switch
4
head
8 adjustment lever
a
off
b continuous
3. General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
Protect this device from shocks and abuse. Avoid brute force when operating the device.
Keep this device away from rain, moisture, splashing and dripping liquids.
Familiarise yourself with the functions of the device before actually using it.
All modifications of the device are forbidden for safety reasons. Damage caused by user modifications
to the device is not covered by the warranty.
Only use the device for its intended purpose. Using the device in an unauthorised way will void the
warranty.
Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and
the dealer will not accept responsibility for any ensuing defects or problems.
Nor Velleman nor its dealers can be held responsible for any damage (extraordinary, incidental or
indirect) – of any nature (financial, physical…) arising from the possession, use or failure of this
product.
Keep this manual for future reference.
4. Features
cordless soldering iron
can also be used as a torch and as a hot blower
kit contains:
o torch
o 3 soldering tips
o deflector
o sponge
o solder wire
o tip cap
portable soldering tool powered by butane gas
auto ignition
5. Overview
Refer to the illustrations on page 2 of this manual.
6. Fuelling/Refuelling the Soldering Iron
1. Before (re)fuelling, make sure to slide the flame switch [7] to the far left off position.
2. Follow the directions on the butane gas fuel can (not included). Insert the tip into the gas filler
valve [1]. Use a pumping action for best results. Use only high-quality butane gas.
3. After (re)fuelling, allow the gas to stabilize a few minutes before ignition.
7. Operation
7.1 Ignition
1. Make sure the exhaust vent is facing upward to avoid damaging your desk.
2. Press the safety lock [3] and simultaneously pull down the trigger with your thumb.
3. Hold the ignition button [2] and release the safety lock [3].
4. Slide the flame switch [7] to the right for a constant flame.
V. 01 – 24/11/2014 4 ©Velleman nv
GAS/SET2
Note:
Longer flames may cause the torch to flare or shut off. Please decrease the flame until the flame
reaches a blue glow.
problem
probable cause
possible solution
The soldering iron does not
ignite
Empty fuel
Refuel
Gas pressure too high/low
Slide the adjustment lever to
the left/right
Excessive gas flow
Setting is too high
Adjust the flame gradually
Low gas pressure
Low fuel
Refuel
Cold fuel
Hold in your hands to warm up
autonomy
90 min. (average use)
gas container capacity
15 ml
temperature
soldering temperature
up to 500° C
hot blow temperature
up to 600° C
torch temperature
up to 1300° C
dimensions
Ø 29 x 245 mm
7.2 Flame Adjustment
1. Slide the adjustment lever [8] to the right to increase the flame.
2. Slide the adjustment lever [8] to the left to decrease the flame.
7.3 Shut-Off
1. Slide the flame switch [7] to the far left.
2. Let the soldering iron cool down.
7.4 Other Functions
Torch
1. Rotate the nut in an anticlockwise direction and remove the soldering tip [5], the head [4] and the
metal sleeve [6].
2. Disassemble the soldering tip [5], the head [4] and the metal sleeve [6] assembly.
3. Re-install the metal sleeve [6] and secure with the nut.
4. The soldering iron can now be used as a torch. Operate the soldering iron as described under
7. Operation.
Hot Blower
1. Remove the soldering tip [5] by rotating it in an anticlockwise direction.
2. The soldering iron can now be used as a hot blower. Operate the soldering iron as described under
7. Operation.
8. Troubleshooting
9. Technical Specifications
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulting from (incorrect) use of this device. For more info
concerning this product and the latest version of this manual, please visit our website
www.velleman.eu. The information in this manual is subject to change without prior notice.
