Velleman DVMEMF User Manual [en, de, es, fr]

DVMEMF

MICROWAVE LEAKAGE DETECTOR

MIKROWELLEN

-

LECK

-

TESTER

USER MANUAL

BEDIENUNGSHANDLEITUNG

DETECTOR VOOR MICROGOLFLEKKAGE
DÉTECTEUR DE FUITES MICRO-ONDES
DETECTOR DE FUGAS MICROONDAS

GEBRUIKERSHANDLEIDING
NOTICE D’EMPLOI
MANUAL DEL USUARIO

DVMEMF VELLEMAN

DVMEMF VELLEMAN

DVMEMF – MICROWAVE LEAKAGE DETECTOR

1. Introduction

To all residents of the European Union
Important environmental information about this product

This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the
environment. Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a
specialized company for recycling. This device should be returned to your distributor or to a local recycling
service. Respect the local environmental rules.

If in doubt, contact your local waste disposal authorities.

Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into service. If the device was
damaged in transit, do not install or use it and contact your dealer. Damage caused by disregard of certain guidelines in this
manual is not covered by the warranty and the dealer will not accept responsibility for any ensuing defects or problems.

According to a survey 56% of the microwave ovens older than 2 years present a leakage radiation level 10% higher than
the safety standard of 5mW/cm². Independent studies have revealed that exposure to levels higher than this standard can
cause skin cancer, headaches, dizziness, cataracts, increased stress, temporary sterility in men … Since microwave
radiation is odourless and invisible and therefore hard to detect, this detector can help you to determine the radiation level
leakage at home. If the meter does detect a dangerous leak, you should not use the microwave oven until it is properly
repaired.

2. Use

Press to switch on the detector. Press and hold ZERO to adjust the zero point. Approach the detector to take the
measurement. Press MAX to display the maximum value, press to activate the backlight. Switch off the detector by
pressing .

3. Technical Specifications

Range 0 ~ 9.99mW/cm²
Warning Value 5.0mW/cm²
Accuracy ± 1dB
Power Supply 1 x 9V alkaline E-block (order code 6LR61, incl.)
Working Temperature 0°C ~ 40° C
Relative Ambient Humidity 0% ~ 85%
Dimensions 160 x 60 x 42mm
Weight 150g
Contents detector, manual, battery, carrying case

Use this device with original accessories only. Velleman nv cannot be held responsible in the event of damage or
injury resulted from (incorrect) use of this device.

For more info concerning this product, please visit our website www.velleman.eu.
The information in this manual is subject to change without prior notice.

DVMEMF VELLEMAN
