2. Description of the router

2.1. Introduction

EDGE router is a compact electronic device based on the module which enables data

transfers using GSM, GPRS and EDGE technologies.

Primarily, the router expands the capabilities of the module by the option of connecting
more PCs by means of the built-in Ethernet interface. In addition, the firmware of the router
provides automatic establishment and maintenance of GPRS connection. By means
of integration of a DHCP server it provides the users with simple installation and Internet
access.

In addition, the router is equipped with a USB 2.0 Host interface which is designed only
for connection to a USB device.

By customer request it is possible to equip the router with the PORT1 module, PORT2
module and extend the function of the EDGE router about RS232, RS485/RS422,
ETHERNET, M-BUSD or CNT (I/O module).

The EDGE router has two versions. The first version is basic ER75i v2 and the second
version is ER75i v2 SL in the aluminum box.

Examples of Possible Applications

• mobile office

• fleet management

• security system

• telematic

• telemetric

• remote monitoring

• vending and dispatcher machines

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

6

EXPANSION PORT MOUNTING

2.2. Delivery Identification

Specimen Label:

Trade name Type name Other

ER75i v2 Basic ER75i -5-v2 Basic version
ER75i v2 SL Basic ER75i -5-v2-SL Basic version in the aluminum box
ER75i v2 Full ER75i -5-v2-Full Full version
ER75i v2 SL Full ER75i -5-v2-SL-Full Full version in the aluminum box

Example of expansion port PORT1:

Trade name Type name Power supply

Expansion port RS232 XC-232 Internal power supply
Expansion port RS485-RS422 XC-485422 Internal/external power supply
Expansion port ETHERNET XC-ETH Internal power supply
Expansion port M-BUSD XC-MBUSD External power supply
Expansion port CNT XC-CNT Internal power supply

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

7

EXPANSION PORT MOUNTING

Basic delivered set of router includes:

• EDGE router,

• power supply,

• crossover UTP cable,

• external antenna,

• clips for the DIN rail,

• installation CD containing instructions.

In addition to the basics it is possible to deliver:

• one or two expansion ports RS232, RS485/RS422, ETHERNET, M-BUSD or CNT

(separation columns are in distribution),

Module can be connected only
PORT1 RS232, RS485/422, ETHERNET, M-BUSD, CNT

as follows.

PORT2 RS232, RS485/422, M-BUSD

The router standard designed for:

• mounting to a panel using through holes (only ER75i v2 version),

• possibility to be put on a work surface,

• for mounting onto a DIN rail, the clips are included.

2.3. Antenna Connection

The antenna is connected to the router using the SMA connector on the front panel.
External antennas:

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

8

EXPANSION PORT MOUNTING

2.4. SIM Card Reader

The SIM card reader for 3 V and 1.8 V SIM cards is located on the front panel
of the router. To initiate the router into operation it is necessary to insert an activated SIM card
with unblocked PIN in the reader. The SIM cards might be of different adjusted APN (Access
Point Name).

2.5. Power Supply

The router requires +10 V DC to +30 V DC supply. Protection against reversed polarity
without signaling is built into the router.

data sending is 5.5W. For correct operation it is necessary that the power source is able
to supply a peak current of 500mA.

The power consumption during receiving is 1W. The peak power consumption during

2.6. Technical parameters

ER75i v2

Complies with standards EN 301 511, V9.0.2

EN ETSI 301 489-1 V1.9.1
EN 60950-1:06 ed.2 + A11:09

Frequency bands EGSM850, EGSM900, GSM1800

and GSM1900

Transmit power Class 4 (2 W) for EGSM850

Class 4 (2 W) for EGSM900
Class 1 (1 W) for GSM1800
Class 1 (1 W) for GSM1900

Temperature range Operation

Storage

Protection rating Freely

In switch board
Supply voltage +10 až +30 V DC
Consumption Reception

Transmission
Dimensions 42x76x113 mm (DIN 35mm)
Weight ER75i v2 – 150 g

Antenna connector SMA – 50 Ohm
User interface ETH

USB
PORT1

PORT2

-30 oC to +60 oC

-40 oC to +85 oC
IP20
IP56

1 W
5,5 W

ER75i v2 SL – 280 g

Ethernet (10/100 Mbit/s)
USB 2.0 type A host
Optional RS232/RS485/ETHERNET/M-BUSD
or inputs/outputs (I/O)
Optional RS232/RS485/M-BUSD

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

9

EXPANSION PORT MOUNTING

2.7. Description of the individual components of the router

2.7.1. GSM/GPRS/EDGE module

is integrated into the printed circuit board. The two slide-out SIM card readers is accessible
from the front panel. The SMA antenna connector is accessible from the front panel.

GSM/GPRS/EDGE module

• Communicates in four GSM bands (850MHz, 900MHz, 1800MHz, and 1900MHz).

The EDGE/GPRS module is used for GSM network wireless communication. It

• In the GPRS mode it is able to transmit in three „Time Slot“ and receive in two (GPRS
multi-slot class 10 – the maximum bit rate of reception is 42.8 kb/s) or transmit in one
„Time Slot“ and receive in four (GPRS multi-slot class 12 – the maximum bit rate
of reception is 85.6 kb/s).

• In the EDGE mode it is able to transmit in three „Time Slot“ and receive in two (EDGE
multi-slot class 10 – the maximum bit rate of reception is 118.4 kb/s) or transmit in one
„Time Slot“ and receive in four (GPRS multi-slot class 12 – the maximum bit rate
of reception is 236.8 kb/s).

• Supports coding schemes CS1 to CS4 and MCS1 to MCS9.

Beware! The transmitting and receiving in timeslots depends on the operator networks
possibilities.

2.7.2. Control microcomputer

128MB FLASH, 1MB MRAM, serial interface RS-232 and an Ethernet interface 10/100 Mbit/s.
The microcomputer is connected to the EDGE EES3 module through the USB interface
and controls the communication via EDGE/GPRS. Towards to the user it is connected
on the Ethernet interface.

The core of the router is a 32-bit ARM microprocessor with 512MB DDR2 SDRAM,

be done through a web interface (HTTP), which is protected by security password.

The software is built on the Linux operating system.
The router support services as like DHCP, NAT, Open VPN, IPsec tunnels, etc.
The modem settings are saved in the FLASH memory. All modem configurations can

Actual firmware version: 2.1.1 (4.5.2011)

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

10

EXPANSION PORT MOUNTING

2.8. User interfaces (Connectors)

On the front and back panel of router the following connectors are located

• one MRT 2pin connector (PWR) – for connection of the power supply adapter

• one RJ45 connector (ETH) – for connection into the local equipment

• one RJ45 connector (optional PORT1) – for connection of the local any arrangement over

RS232, RS485/422, ETHERNET, M-BUSD or CNT

• one RJ45 connector (optional PORT2) – for connection of the local any arrangement over
RS232, RS485/422, M-BUSD

• one FME or SMA connector (ANT) – for connection of the antenna

• one USB-A Host connector (USB) – for connection of the devices to the router, USB

supports equipments with PL-2303 and FTDI USB/RS232 converter

• One MRT 3pin connector (I/O) – for connection of the binary input and output

Front panel ER75i v2 SL.

Front panel ER75i v2.

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

11

EXPANSION PORT MOUNTING

2.8.1. Connection of the PWR Supply Connector

Panel socket MRT 2pin.

Pin

number

1 +UN Positive pole of DC supply voltage (+10 to +30 VDC)
2 GND Negative pole of DC supply voltage

Signal

mark

Description

Circuit example:

DC

+

Pin 1 – +UN
Pin 2 – GND

Router

The positive pole +UN is marked by a red socket on the power supply.

2.8.2. Connection of binary input and output

Panel socket MRT 3pin.

Pin
no.

1 BIN0 Binary input Input
2 GND Ground – signal ground

3 OUT0 Binary output Output

of binary output signal. Binary output is not switched to ground, by default configuration.

Circuit example of a Binary or output equipment with router:

Signal

mark

The user interface I/O is for processing of binary input signal and to control (settings)

Description Data flow

direction

+12 V

Pin 1 - BIN
Pin 2 - GND
Pin 3 - OUT

Router

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

12

EXPANSION PORT MOUNTING

2.8.3. Connection of the Port1 Connector – RS232

Panel socket RJ45 (RS232 – DCE – Data Communication Equipment).

Pin

number

Signal

mark

Description Data flow direction

1 RTS Request To Send Input
2 CTS Clear To Send Output
3 DTR Data Terminal Ready Input
4 DSR Data Set Ready – connected to +4 V through

330 Ohm
5 GND GROUND – signal ground
6 RXD Receive Data Output
7 CD Carrier Detect Output
8 TXD Transmit Data Input

Output

Circuit example:

Meter

GND
RXD
TXD

Pin 1 – RTS
Pin 2 – CTS
Pin 3 – DTR
Pin 4 – DSR
Pin 5 – GND
Pin 6 – RXD
Pin 7 – CD
Pin 8 – TXD

Router

The router connection to the PC:

Cable KD-2

• cable KD2 is connected to serial port PC (example COM1)

ETH
PORT1
PWR

Router

The router connection to equipment with full-value RS232 interface:

Cable KD-2

ETH
PORT1
PWR

Router

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

13

EXPANSION PORT MOUNTING

2.8.4. Connection of the Port1 Connector – RS485

ATTENTION! Power supply is selected on the expansion port RS485 by help
of a jumper, 2.11. If galvanic separation is required the converter must have an external

power supply.
Circuit example of the equipment with a router with data cable length less than 10 m:

Panel socket RJ45.

Pin

number

1 GND Signal and supply ground
2 GND Signal and supply ground
3 TxRx- RS485 B (-) Input/Output
4 TxRx+ RS485 A (+) Input/Output
5 TxRx- RS485 B (-) Input/Output
6 TxRx+ RS485 A (+) Input/Output
7 +12 V EXT External power supply
8 +12 V EXT External power supply

Signal

mark

Description Data flow direction

Circuit example of the equipment with a router with data cable length more than 10 m:

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

With a RS485 data cable more than 10m it is necessary to use overvoltage protection
on the router side!

14

EXPANSION PORT MOUNTING

2.8.5. Connection of the Port1 Connector – RS422

Pin

number

1 SGND Signal and power supply ground
2 SGND Signal and power supply ground
3 RxD- Receive Data (-) Output
4 RxD+ Receive Data (+) Output
5 TxD- Transmit Data (-) Input
6 TxD+ Transmit Data (+) Input
7 +12V EXT External power supply
8 +12V EXT External power supply

ATTENTION! Power supply is selected on the expansion port RS422 by help
of a jumper, 2.9. If galvanic separation is required the converter must have an external
power supply.

Signal

mark

Description Data flow direction

Circuit example of the equipment with router with data cable length less than 10 m:

Circuit example of the equipment with a router with data cable length more than 10 m:

With a RS422 data cable more than 10m it is necessary to use overvoltage protection
on the router side!

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

15

EXPANSION PORT MOUNTING

2.8.6. Connection of the Port1 Connector – M-BUSD

Panel socket RJ45.

Pin

number

1 GND Signal and supply ground
2 GND Signal and supply ground
3 TxRx- M-BUS B (-) Input/Output
4 TxRx+ M-BUS A (+) Input/Output
5 TxRx- M-BUS B (-) Input/Output
6 TxRx+ M-BUS A (+) Input/Output
7 +12 V EXT External power supply
8 +12 V EXT External power supply

ATTENTION! External supply is for converter M-BUSD!
If galvanic separation is required the converter must have external power supply.

Signal

mark

Description Data flow direction

Circuit example of the equipment with a router with data cable length less than 10 m:

Circuit example of the equipment with a router with data cable length more than 10 m:

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

With a M-BUS data cable more than 10m it is necessary to use overvoltage protection
on the router side!

16

EXPANSION PORT MOUNTING

2.8.7. Connection of the Port1 Connector – CNT

Panel socket RJ45.

Pin

number

1 BIN1/CNT1 Binary input/counter input Input
2 BIN2/CNT2 Binary input/counter input Input
3 BIN3 Binary input Input
4 BIN4 Binary input Input
5 GND Signal ground
6 OUT1 Binary output (open collector) Output
7 AN1 Analogue input Input
8 AN2 Analogue input Input

The user interface CNT is for monitoring and processing of analogue and binary signals
and to control (settings) of binary signals. Available are 2 counter and 2 binary inputs or 4
binary inputs, 2 analogue inputs and 1 binary output. The settings of binaries and counter
inputs by the help of firmware in which the single input and output is defined. Binary output
is off by default configuration (it is not switched to ground).

Signal mark

Description Data flow direction

Typical connection of the router measuring circuits:

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

The router does not support to modify any signals of the CNT port, for example logical
functions.

17

PWR

PWR

EXPANSION PORT MOUNTING

2.8.8. Connection of the ETH Connector

ATTENTION! Port ETH is not POE (Power Over Ethernet) compatible!

The ETH router connection:

Panel socket RJ45.

Pin

number

1 TXD+ Transmit Data – positive pole Input/Output
2 TXD- Transmit Data – negative pole Input/Output
3 RXD+ Receive Data – positive pole Input/Output
4 --- ---
5 --- ---
6 RXD- Receive Data – negative pole Input/Output
7 --- ---
8 --- ---

Signal mark

Description Data flow direction

Switch

UTP cable

USB
ETH
PORT1

Router

2.8.9. Connection of the Connector USB

Panel socket USB-A.

Pin

number

1 VCC Positive pole of 5V DC supply voltage
2 USB data - USB data signal – negative pole Input/Output
3 USB data + USB data signal – positive pole Input/Output
4 GND Negative pole of DC supply voltage

The USB router connection:

Signal mark

Description Data flow direction

USB cable A-B

USB
ETH
PORT1

Router

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

18

EXPANSION PORT MOUNTING

2.9. Technical specification of optional PORT1 and PORT2

• Expansion port RS232

Expansion port RS232

Power supply Internal ....

Operating temperature -30 .. +60 °C Environment

Standards

RS232 specifications
(EN 1434)

Storage temperature -30 .. +85 °C
Emission EN 55022/B
Immunity ETS 300 342
Safety EN 60950
Max. operating bus current 15 mA
Max. bit rate 230400 bps
Max. overvoltage ±30 V
Max. total cable length
(300Bd, 200nF/km)

20 m

LED port indicator

Green LED Indicates Receive data
Yellow LED Indicates Transmit data

be made by wiring jumpers J2 and J3 on this module. If external power supply of the module
is required, jumpers J2 and J3 must be connected to pins 2 - 3. Internal power supply
is made by connecting pins 1 - 2 with jumpers J2 and J3.

• Expansion port RS485-RS422

Expansion port RS485-RS422 RS485 RS422

Power supply

Standards

RS485 specifications
(EN 1434)

External +10 .. +30 V

Internal ....

Supply power Max. 1 W
Supply current Max. 4 mA
Operating temperature -30 .. +60 °C Environment
Storage temperature -30 .. +85 °C
Emission EN 55022/B
Immunity ETS 300 342
Safety EN 60950
Max. devices (each 1,5 mA) 256
Max. bit rate 38400 bps
Short circuit strength Permanent
Max. total cable length
(300Bd, 200nF/km)

1200 m

LED port indicator

Green LED Indicates Receive data

Yellow LED Indicates Transmit data

External or internal power supply of module Expansion port RS485/RS422 can

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

19

EXPANSION PORT MOUNTING

jumpers J4, J5 and J6 on this module. If RS485 is required, jumpers J4 and J5 must be
connected and jumper J6 disconnected. If RS422 is required, jumpers J4 and J5 must be
disconnected and jumper J6 connected.

Interface behaviour of module Expansion port RS485/RS422 can be made by wiring

RS485/RS422 from TOP layer). We recommend that internal power supply is only chosen
in the event that it is not possible to ensure external power supply. If internal power supply
is chosen, converter RS485/RS422 is not galvanic separated.

Jumper placement can be seen in the picture below (module Expansion port

Jumper J3

Jumper J2

Jumper J3

Jumper J2

The jumper circuitry for internal supply The jumper circuitry for external supply

The jumper circuitry for RS485 The jumper circuitry for RS422

Jumpery J4 a J5

Jumper J6

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

20

EXPANSION PORT MOUNTING

• Expansion port ETHERNET

Expansion port ETH

Power supply Internal ....

Operating temperature -30 .. +60 °C Environment

Standards

(IEEE 802.3)

Storage temperature -30 .. +85 °C
Emission EN 55022/B
Immunity ETS 300 342
Safety EN 60950
Max. bit rate 100 Mbps Ethernet
Max. total cable length

(300Bd, 200nF/km)

100 m

LED port indicator

Green LED

Yellow LED On........................ the network cable is connected

• Expansion port M-BUSD

On ...................... selected 100 Mbit/s

Off ...................... selected 10 Mbit/s

Blinking ……….... data transmission

Off ....................... the network cable is not connected

Expansion port M-BUSD

Voltage +10 .. +30 V Power supply
Supply power Max. 4 W
Operating temperature -30 .. +60 °C Environment

Standards

M-BUS specifications
(EN 1434)

Storage temperature -30 .. +85 °C
Emission EN 55022/B
Immunity ETS 300 342
Safety EN 60950
Max. devices (each 1,5 mA) 30
Max. operating bus current 60 mA
Overload detection 100 mA
Short circuit strength Permanent
Bus voltage mark 36 .. 43 V
Bus voltage space 24 .. 31 V
Max. total cable length

(300Bd, 200nF/km)

1000 m

LED port indicator

Green LED

Yellow LED Indicates Transmit data
Both LED lights Indicates short circuit on the MBUS

Indicates Receive data

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

21

EXPANSION PORT MOUNTING

• Expansion port CNT

Expansion port CNT

Power supply

Standards

Inputs/Outputs

Internal ….
Sleep 100 µA (counter

is functional)
Operation 2 mA
Operating temperature -30 .. +60 °C Environment
Storage temperature -30 .. +85 °C
Emission EN 55022/B
Immunity ETS 300 342
Safety EN 60950
Isolation EN 60747
2x counter Max. 100 Hz,

ratio max. 1:10
2x analogue inputs 0 .. 20 mA,

Rin 100 Ohms
2x binary inputs reed contact

with J4 – 20mA

without J4 8µA
1x output (open collector) 30V/100 mA
Voltage resistance Permanent Others
Sleeping mode Controlled

LED port indicator

Green LED

Yellow LED Indicates Binary input Bin1

Indicates Binary input Bin0

jumper J4(viz. picture) is mounted on pins, electric current value is 20 mA. When jumper J4
is not mounted, electric value is 8µA. If current value is 20mA, CNT has higher consumption,
also it has higher resistance to industrial noise.

If active level is set as log. 1, electric current can be selected with jumper. When

Jumper J4

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

22

EXPANSION PORT MOUNTING

2.10. Technical specification of Binary input and output

Port IO

Input/Output

Binary input reed contact

Binary output 120 mA/max. 30 V

with trigger level 1,3
up to 1,4 V

2.11. Modem status indication

which inform on the modem status. On every port are two LED indicators, which inform port
status.

On the front and back panel of the modem there are altogether eight LED indicators,

Panel Color Description

Front Green PWR

Blinking ......................... router is ready

Permanently on ………..starting of the router

Description

Front Red GSM Blinking ……….. communication in progress

Front Yellow PPP On......................join PPP connection

Front Yellow USR Function selected by user

Front Green OUT On.......................Binary output active

Front Green IN On...................... Binary input active

Front Green ETH

Front Yellow ETH

Front Green PORT Description by port (viz. Technical specification)

On ...................... selected 100 Mbit/s

Off ...................... selected 10 Mbit/s

On........................ the network cable is connected

Blinking ……….... data transmission

Off ....................... the network cable is not connected

Front Yellow PORT Description by port (viz. Technical specification)

Front Yellow SIM1 On......................SIM card 1 is active

Front Yellow SIM2 On......................SIM card 2 is active

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

23

EXPANSION PORT MOUNTING

2.12. Putting into operation

Before putting the ER75i v2 or ER75i v2 SL router into operation it is necessary
to connect all components needed for the operation of your applications and the SIM card
must be inserted (the modem is off).

The modem is put into operation by connection of the power supply to the modem.
In the default setting the modem starts to login automatically to the preset APN. The behavior
of the modem can be modified by means of the web interface which is described
in the following chapter.

2.13. Mechanical external dimensions and mounting recommendations

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

24

EXPANSION PORT MOUNTING

to recognize two sorts of environments:

For the majority of applications with a built-in modem in a switch board it is possible

• no public and industry environment of low voltage with high interference,

• public environment of low voltage without high interference.

the following there is no need to have examination immunity or issues in connection with
EMC according to EN 60439-1 ed.2:00 + A1:04.

For both of these environments it is possible to mount modems to a switch board,

to observe next assembly of the modem to the switch - board:

For compliance of EN 60439-1 ed.2:00 + A1:04 specification it is necessary

• for round antennas we recommend to observe a distance of 6 cm from cables

and metal surfaces on every side according to the next picture due to the elimination

of interference, while using an external antenna except for the switch-board it is

necessary to fit a lightening conductor,

• before mounting a modem on sheet-steel we recommend using an external antenna,

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

25

EXPANSION PORT MOUNTING

• for single cables we recommend to bind the bunch according to the following picture,

for this use we recommend:

 length of the bunch (combination of power supply and data cables) can

be maximum 1,5 m, if the length of data cables exceeds 1,5 m
or in the event of, the cable leads towards the switch - board, we
recommend installing over - voltage protectors (surge suppressors),

 with data cables they mustn't carry cables with reticular tension

~ 230 V/50 Hz,

 all signals to sensors must be twisted pairs.

• sufficient space must be left before individual connectors for handling of cables,

• for correct function of the modem we recommend to use in the switch-board earth-

bonding distribution frame for grounding of power supply of modem, data cables

and antenna,

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

26

EXPANSION PORT MOUNTING

• the circuit diagram of the modem is on the following pictures.

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

27

EXPANSION PORT MOUNTING

3. Expansion port mounting

3.1. Expansion port mounting for ER75i v2

Attention! Expansion port PORT1 and PORT2 include when the router ER75i v2 SL

is switched off.

After removing front head of the box it is possible to take out the B-RB-v2
motherboard (position 1). The expansion port PORT1 (position 2) is connected to connector
J8 (see below) of the router B-RB-v2 motherboard (position 1) from TOP side. The
expansion port PORT2 (position 3) is connected to connector J3 (see below) of the router B­RB-v2 motherboard (position 1) from TOP side. The expansion port is mounted to the
motherboard by the help of three spacers (position 10). After mounting the expansion port
the box is inserted motherboard into box and kneaded front head in the box.

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

28

EXPANSION PORT MOUNTING

Parts list and description

Part

1 UMTS router motherboard 1
2 Expansion port PORT1 1
3 Expansion port PORT2 1
4 Box 1
5 Front head 1
6 Spacers for expansion port PORT1 mounting to motherboard 6

Description Number

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

29

Connector J3

EXPANSION PORT MOUNTING

3.2. Expansion port mounting for ER75i v2 SL

Attention! Expansion port PORT1 and PORT2 include when the router ER75i v2 SL

is switched off.

After unscrewing four screws (position 11) on the rear panel (position 6)
and removing it is possible to take out the B-RB-v2 motherboard (position 1). The expansion
port PORT1 (position 2) is connected to connector J8 (see below) of the router B-RB-v2
motherboard (position 1) from TOP side. The expansion port PORT2 (position 3)
is connected to connector J3 (see below) of the router B-RB-v2 motherboard (position 1)
from TOP side. The expansion port is mounted to the motherboard by the help of three
spacers (position 10). After mounting the expansion port the box is screwed together
by the help of four screws(position 11).

Connector J8

LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de

30
