OWNER’S MANUAL

Made from 70% Bagasse

(Environmentally Friendly Sugar

Cane Pulp By-product)

Outdoor LP Gas Barbecue Grill

Model No. GBT830L

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only

(outside any enclosure)

WARNING

FOR YOUR SAFETY:

1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.

2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.

3. Failure to follow these instructions could result in ﬁre or explosion, which could cause property damage, personal injury, or death.

Table of Contents

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2

Exploded View & Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Checking for Leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

First Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Lighting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Turning Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Cooking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Save these instructions for future reference. If you are assembling this unit for someone else, give this manual to him or her to read and save for future reference.

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

The use and installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas

and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2,or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.

California Proposition 65: Chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm are created by the combustion of propane.

Manufactured in China for: Blue Rhino Global Sourcing, Inc. Winston-Salem, NC USA

1.800.762.1142, www.bluerhino.com

Outdoor LP Gas Barbecue Grill Model No. GBT830L

DANGER

If you smell gas -

1. Shut off gas to appliance.

2. Extinguish any open flame.

3. Open lid.

4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department.

DANGER: Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion

causing damage to property.

WARNING: This grill is for outdoor use only, and shall not be used in a building,

garage, or any other enclosed area. This grill is NOT for commercial use. This is not a tabletop grill. Therefore, do not operate this grill on any type

of tabletop surface This grill is for use with liquid propane (LP) gas only. The conversion to

or attempted use of natural gas in this LP gas grill is dangerous and will

void your warranty. LP gas Characteristics:

a. LP gas is flammable and hazardous if handled improperly. Become

aware of the characteristics before using any LP gas product.

b. LP gas is explosive under pressure, heavier than air, and settles and

pools in low areas.

c. LP gas in its natural state has no odor. For your safety, an odorant is

added that smells like rotten cabbage.

d. Contact with LP gas can cause freeze burns to skin.

LP gas tank needed to operate. Only tanks marked “propane” may be

used. The LP gas supply tank must be constructed and marked in accordance

with the Specifications for LP gas Cylinders of the U.S. Department of

Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339,

Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods;

and Commission.

LP gas tank must be arranged for vapor withdrawal. Dented or rusted LP gas tanks may be hazardous and should be checked

by your LP gas supplier prior to use. The LP gas tank should not be dropped or handled roughly. LP gas tanks must be stored outdoors out of the reach of children and

must not be stored in a building, garage, or any other enclosed area. Your

tank must never be stored where temperatures can reach over 125°F. Never attempt to attach this grill to the self-contained LP gas system of

a camper trailer, motor home, or house. Do not store a spare LP gas tank under or near this appliance. The use of alcohol or prescription or non-prescription drugs may impair

the consumer’s ability to properly assemble or safely operate the

appliance. Never use charcoal, lighter fluid, lava rocks, gasoline, kerosene, or

alcohol with this product. Your grill has been checked at all factory connections for leaks. Recheck

all connections, as movement in shipping can loosen connections. Check for leaks even if your unit was assembled for you by

someone else. Do not operate if gas leak is present. Gas leaks may cause a fire or

explosion. You must follow all leak-checking procedures before operating. To

prevent fire or explosion hazard when testing for a leak:

a. Always perform leak test before lighting the grill and each time the

tank is connected for use.

b. Do not use or permit sources of ignition in the area while conducting

a leak test. No smoking. c. Conduct the leak test outdoors in a well-ventilated area. d. Do not use matches, lighters, or a flame to check for leaks. e. Do not use grill until any and all leaks are corrected. If you are unable to stop a leak, disconnect the LP gas supply. Call our

customer care, gas appliance serviceman or your local LP gas supplier.

Do not use in an explosive atmosphere. Keep grill area clear and free

from combustible materials, gasoline and other flammable vapors and liquids.

Keep all combustible items and surfaces at least 21 inches (53 cm) away

from the grill at all times. DO NOT use this grill or any gas product under any overhead or near any unprotected combustible constructions.

It is essential to keep the grill’s valve compartment, burners, and

circulating air passages clean. Inspect grill before each use.

1. Do not store or use gasoline or other flammable liquids or vapors in the vincinity of this or any other appliance.

2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

Do not alter grill in any manner. Any altering will void your warranty. Do not use the grill unless it is COMPLETELY assembled and all parts are

securely fastened and tightened. This grill should be thoroughly cleaned and inspected on a regular basis. Use only the regulator provided. Any replacement regulator shall be

specified by the manufacturer. Use only Blue Rhino Global Sourcing, Inc. factory authorized parts. The

use of any part that is not factory authorized can be dangerous. This will

also void your warranty. Do not use this appliance without reading “Operating Instructions” in

this manual. Do not touch metal parts of grill until it has completely cooled (about

45 min.) to avoid burns, unless you are wearing protective gear (pot

holders, gloves, BBQ mittens, etc.). Do not install or use in or on boats or recreational vehicles. When cooking, fire extinguishing materials shall be readily accessible.

In the event of an oil grease fire, do not attempt to extinguish with water.

Use type BC dry chemical fire extinguisher or smother with dirt, sand or

baking soda. Do not use grill in high winds. Never lean over the grill when lighting. Do not leave a lit grill unattended. Keep children and pets away from grill

at all times. Do not attempt to move grill when in use. Allow the grill to cool

(approximately 45 minutes) before moving or storing. Storage of grill indoors is permissible only if the tank is disconnected,

removed from the grill and properly stored outdoors. While wearing a protective glove or mit, open grill lid carefully and

slowly as heat and steam trapped within grill can severely burn you. Do not attempt to disconnect the gas regulator from the tank or any gas

fitting while the grill is in use. Disconnect cylinder when not in use. Always use your grill on a hard, non-combustable level surface. An

asphalt or blacktop surface may not be acceptable for this purpose. Do not use directly on wooden decks. Keep all electrical cords away from a hot grill. Do not use grill for indoor cooking or heating. TOXIC fumes can

accumulate and cause asphyxiation. After a period of storage and/or nonuse check for leaks and burner

obstructions. Failure to open lid while igniting the grill’s burner, or not waiting 5

minutes to allow the gas to clear if the grill does not light, may result in

an explosive flame-up. If grill is not in use, the gas must be turned off at the supply tank. Never operate grill without heat plate installed. Always use a meat thermometer to ensure food is cooked to a safe

temperature. Please use protective gloves when assembling this product. Do not force parts together as this can result in personal injury or

damage to the product. Never cover entire cooking area with aluminum foil.

Deaths, serious injury or damage to property may occur if the above is

not followed exactly.

WARNING

FOR YOUR SAFETY

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Parts List

Branding Plate

Lid Handle

Thermometer Assembly

Lid

Warming Rack

Cooking Grid

Top Hinge (2)

Heat Plate

Bottom Hinge (2)

Burner

Electrode

Heat Plate Support (2)

Bottom Bowl

55-08-045

55-08-049

55-08-052

55-08-048

55-15-328

55-15-293

55-15-305

55-15-301

55-15-304

55-15-292

55-15-295

55-15-302

55-08-044

Exploded View

Wind Cover

Regulator/Control Valve

Grease Tray Support (2)

Left Side Handle

Right Side Handle

Igniter Wire

Igniter

Leg (2)

Grease Tray

Lock (2)

55-07-683

55-15-322

55-15-298

55-08-050

55-08-051

55-15-307

55-15-306

55-08-053

55-15-296

55-15-316

Hardware

Screw

Wing Nut

Washer

Lock Washer

A B C D E F G H

M4x10 Zinc Plated Phillips Truss Head

M5x12 Zinc Plated Phillips Truss Head

M6x8 Zinc Plated Phillips Truss Head

M6x12 Zinc Plated Phillips Truss Head

M4 Steel

M5 Steel

ø4 Zinc Plated

ø5 Zinc Plated

ø6 Heat Resistant

ø4 Zinc Plated

8 pcs

16 pcs

7 pcs

2 pcs

8 pcs

20 pcs

8 pcs

2 pcs

8 pcs

Tools Required for Assembly (Included)

#2 Phillips Head Screwdriver

K L

Lock Washer

Cotter Pin

ø5 Zinc Plated

ø5 x 30 Zinc Plated

ø1.4 x 30 Steel

8 pcs

2 pcs

Assembly Instructions

Outdoor LP Gas Barbecue Grill Model No. GBT830L

DO NOT RETURN PRODUCT TO STORE.

For assistance call 1.800.762.1142 toll free. Please have your owner’s manual and serial number available for reference.

For Easiest Assembly:

• To avoid losing any small components or hardware, assemble your product on a hard level surface that does not have cracks or openings.

• Clear an area large enough to layout all components and hardware.

• When applicable, tighten all hardware connections by hand first. Once the step is completed go back and fully tighten all hardware.

• Follow all steps in order to properly assemble your product.

To complete assembly you will need:

• (1) Leak Detection Solution (Instructions on how to make solution are included in “Operating Instructions” section)

• (1) 14.1 oz or (1) 16.4 oz LP gas tank.

Note: You must follow all steps to properly assemble grill.

Attach Branding Plate

Typical assembly: approximately 30 minutes.

Attach Lid Handle and Thermometer Assembly

Attach Top Hinges

x 2

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Attach Bottom Hinges

Attach Locks

Attach Grease Tray Supports

x 4

A E

Insert Heat Plate Supports

x 4

A E

x 4

Assembly Instructions (continued)

Outdoor LP Gas Barbecue Grill Model No. GBT830L

Assemble Legs

Attach Legs

Attach Burner and Igniter Wire

x 6

x 2

Attach Wind Guard and Regulator/Control Valve

x 6

x 1

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Attach Lid

Insert Warming Rack

Insert Heat Plate and Cooking Grid

x 2

Insert Grease Plate

Outdoor LP Gas Barbecue Grill Model No. GBT830L

LOCK

OFF

LOW

MED

HIGH

PUSH

TURN ON

LOCK

OFF

LOW

MED

HIGH

PUSH

TURN ON

1/2"

12.7 mm

6.4mm

0mm

1/4"

Assembly Instructions (continued)

Lock Lid

Unlock Lid

Operating Instructions

This grill is designed to operate with a one pound 7-3/8” high disposable / 16.4 oz. or 14.1 oz. propane gas tank (DOT 39 Cylinder).

DO NOT ATTEMPT TO REFILL ANY ONE POUND (16.4 oz. or 14.1 oz.) PROPANE GAS TANKS!

Figure 1a Figure 1b

Connecting Gas Tank

1. Make sure the regulator/control valve is in the “LOCK OFF” position. (Figure 1a)

2. Lubricate the threads of the regulator valve with petroleum jelly, insert the gas tank into the regulator valve and hand-tighten firmly. (Figure 1b)

3. Test for leaks

Checking for Leaks

Burner Connection

1. Make sure the control valve is securely fastened to the burner. (Figure 2) If your unit was assembled for you, visually check the connection between the burner and control valve.

WARNING: Failure to inspect this

connection or follow these instructions could cause a fire or an explosion which can cause death, serious bodily injury, or damage to property.

2. If the burner pipe does not rest flush to the control valve, please contact 1.800.762.1142 for assistance.

Figure 2

Figure 3

Regulator / 1# LP Gas Tank Connection

1. Make 2-3 oz. of leak solution by mixing one part liquid dishwashing soap with three parts water.

2. Make sure control knob is “OFF”. (Figure 3)

3. Spoon several drops of solution, or use squirt bottle, at the LP gas tank to regulator connection. (Figure 4)

4. Inspect the solution at the connection, looking for bubbles. a. If NO bubbles appear, the connections are

secure.

b. If bubbles appear, you have a leak.

1. Loosen and retighten this connection, making sure the connection is secure.

2. Retest with solution. a. If you continue to see bubbles after several attempts, disconnect propane

source and contact 1.800.762.1142 for assistance.

First Use

1. Make sure all labels, packaging and protective films have been removed from the grill.

2. Remove manufacturing oils before cooking on this grill for the first time, by operating the grill for at least 15 minutes on “HIGH” with the lid closed. This will “heat clean” the internal parts and dissipate odors.

Figure 4

Figure 5

Lighting

Caution: Keep outdoor gas cooking

appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.

Caution: Do not obstruct the flow of

combustion and ventilation air.

Caution: Check and clean burner/venturi

tubes for insects and insect nests. A clogged tube can lead to a fire beneath the grill.

1. Make sure all labels, packaging and protective films have been removed from the grill.

2. Open lid. Attempting to light the burner with the lid closed may cause an explosion!

3. Make sure there are no obstructions of airflow to the gas unit. Spiders and insects can nest within and clog the burner / venturi tube at the orifice.

A clogged burner tube can lead to a fire

beneath the appliance.

4. Control knob must be in the “LOCK OFF” position. (Figure 3)

5. Turn the control knob to “HIGH”

Figure 6

Flame

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

Cleaning and Care (continued)

page no.

6. Press the Igniter button repeatedly to light burner.

7. If ignition does not occur in 5 seconds, turn burner control knob OFF, wait 5 minutes and repeat lighting procedure.

8. If igniter does not light burner, use a lit match secured with the lighting rod provided to light burner manually. Access the burner through the hole in bottom bowl as indicated. (Figure 5)

9. Turn the grill to “LOW” and position the lit match near side of the burner.

Important: Always use the lighting rod provided when lighting burners with a match.

10. After lighting, observe the burner flame. Make sure all burner ports are lit and flame height

matches illustration. (Figure 6)

Caution: If burner flame goes out during operation, immediately turn

the gas “OFF” and open lid to let the gas clear for about 5 minutes before re-lighting.

Turning Off

1. Turn control knob to the “LOCK OFF” position.

2. Remove LP gas tank and properly store tank.

Cooking

1. Open lid and ignite burner per lighting instructions.

2. Close lid and preheat grill on “HIGH”.

3. Adjust controls to desired temperature.

4. Wear protective gloves and use long handle tongs to place food onto cooking grids above the lit burners.

5. With lid open or closed, cook until desired internal food temperatures are achieved.

6. Turn grill “OFF” by turning control knob to the “LOCK OFF” position. Remove LP gas tank and properly store tank.

Tips for Better Cookouts and Longer Grill Life

1. For food safety tips visit: http://www.fsis.usda.gov/Fact_Sheets/Barbecue_Food_Safety/

2. Use the upper cooking grid (warming rack) for keeping cooked food warm, toasting breads or cooking delicate foods in aluminum foil pouches.

3. To keep food from sticking to the grids, spray or coat with cooking oil before lighting.

4. To reduce flare-up keep grill clean, use lean cuts of meat (or trim fat) and avoid cooking on very high temperatures.

5. Place delicate foods like fish and vegetables in aluminum foil pouches and place on upper cooking levels (warming rack).

6. To avoid losing natural juices, use long handled tongs or spatulas instead of forks and turn foods over just once during cooking.

7. Enhance food flavors by using wood chips in smoker boxes or aluminum foil pouches. Follow the wood manufacturer’s instructions.

8. Clean cooking grids and racks after every use with a quality grill bush designed for your grid material. Wear protective gloves and gently remove the build-up while grids are hot.

9. After every use, allow grill to cool. Then protect clean cooking grids with a light coat of cooking oil, empty grease pan (if included), wipe outside surfaces with a suitable kitchen cleaner and store in a cool dry place.

10. Visit websites like www.bluerhino.com, watch barbecue themed TV shows or purchase

related barbecue cookbooks to learn more interesting tips.

Cleaning Burner

1. Turn gas off at the control knob and remove LP gas tank.

2. Remove regulator and wind guard.

3. Remove cooking grids and heat plate.

4. Disconnect wire from igniter.

5. Remove burner.

6. Clean inlet of burner with small bottle brush or compressed air.

7. Remove all food residue and dirt on burner surface.

8. Clean any clogged ports with a stiff wire (such as an opened paper clip)

9. Inspect burner for any damage (cracks or holes). If damage is found, replace with new burner.

10. Reinstall burner. Reconnect igniter, wind guard, and regulator.

11. Replace heat plate and cooking grid

12. Preform leak test.

Product Registration

For faster warranty service, please register your product immediately at www.bluerhino.com or call 1.800.762.1142.

Limited Warranty

Blue Rhino Global Sourcing, Inc (“Vendor”) warrants to the original retail purchaser of this product, and to no other person, that if this product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in such product shall be free from defects in material and workmanship. Vendor may require reasonable proof of your date of purchase. Therefore, you should retain your sales slip or invoice. This Limited Warranty shall be limited to the repair or replacement of parts, which prove defective under normal use and service and which Vendor shall determine in its reasonable discretion upon examination to be defective. Before returning any parts, you should contact Vendor’s Customer Service Department using the contact information listed below. If Vendor conﬁrms, after examination, a defect covered by this Limited Warranty in any returned part, and if Vendor approves the claim, Vendor will replace such defective part without charge. If you return defective parts, transportation charges must be prepaid by you. Vendor will return replacement parts to the original retail purchaser, freight or postage prepaid.

This Limited Warranty does not cover any failures or operating difﬁculties due to accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance or service by you or any third party, or failure to perform normal and routine maintenance on the product as set out in this owner’s manual. In addition, the Limited Warranty does not cover damage to the ﬁnish, such as scratches, dents, discoloration, rust or other weather damage, after purchase.

This Limited Warranty is in lieu of all other express warranties. Vendor disclaims all warranties for products that are purchased from sellers other than authorized retailers or distributors, including the warranty of merchantability or the warranty of ﬁtness for a particular purpose. VENDOR ALSO DISCLAIMS AND ANY ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. VENDOR SHALL NO LIABILITY TO PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. Vendor further disclaims any implied or express warranty of, and assumes no responsibility for, defects in workmanship caused by third parties.

Cleaning and Care

Caution:

1. All cleaning and maintenance should be done when grill is cool and with the fuel supply disconnected.

2. DO NOT clean any grill part in a self cleaning oven. The extreme heat will damage the finish.

Notices

1. Abrasive cleaners will damage this product.

2. Never use oven cleaner to clean any part of grill.

3. Do not clean any grill part in a self cleaning oven. The extreme heat will damage the

finish.

4. This grill should be thoroughly cleaned and inspected on a regular basis.

Cleaning Surfaces

1. Wipe surfaces clean with mild dishwashing detergent or baking soda.

2. For stubborn surfaces use a citrus based degreaser and a nylon scrubbing brush.

3. Rinse clean with water.

This Limited Warranty gives the purchaser speciﬁc legal rights; a purchaser may have other rights depending upon where he or she lives. Some jurisdictions do not allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long a warranty lasts, so the above exclusion and limitations may not apply to everyone.

Vendor does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment, and no such representations are binding on Vendor.

Blue Rhino Global Sourcing, Inc Winston-Salem, North Carolina USA (800) 762-1142

Outdoor LP Gas Barbecue Grill Model No. GBT830L

Troubleshooting

Problem Possible Cause Prevention/Cure

Burner will not light with match

Irregular flame pattern, flame does not run the full length of burner.

Flame is yellow or orange

Flame blow out

Flare-up

Persistent grease fire.

Flashback (fire in burner tube(s)) Inside of lid or cooking grid is peeling

For more assistance please visit us online at www.bluerhino.com or call 1.800.762.1142 for immediate assistance.

No gas ﬂow. Check if LP gas tank is empty. Obstruction of gas ﬂow. Clear burner. Spider webs or insect nest in burner tube. Clean burner tube. Burner ports clogged or blocked. Clean burner ports. Burner ports are clogged or blocked. Clean burner ports.

New burner may have residual manufacturing oils. Burn grill for 15 minutes with the lid closed. Spider webs or insect nest in burner tube. Clean burner tube. Food residue, grease or seasoning salt on burner. Clean burner. High or gusting winds. Turn front of grill to face wind or increase ﬂame height. Low on LP Gas. Replace LP gas tank. Grease buildup. Clean grill. Excess fat in meat. Trim fat from meat before grilling. Excessive cooking temperature. Adjust (lower) temperature accordingly. Grease trapped by food buildup around burner system. Turn knobs to “LOCK OFF” position. Leave lid in closed position

and let ﬁre burn out. After grill cools, remove and clean all parts. Burner and/or burner tube is blocked. Clean burner and/or burner tube. Baked on grease buildup has turned to carbon and is ﬂaking off. Clean thoroughly.

+ 22 hidden pages
