OWNER’S MANUAL
Outdoor LP Gas Barbecue Grill
Model No. GBT926W
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
WARNING
FOR YOUR SAFETY:
1.Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.
2.Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.
3.Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.
Save these instructions for future reference.
If you are assembling this unit for someone else, give this manual to him or her to read and save for future reference.
Made from 70% Bagasse
(Environmentally Friendly Sugar
Cane Pulp By-product)
Table of Contents
Important Safeguards . . . . . . . . . . . . . . . . . . . . . |
Page 2 |
||
Exploded View & Hardware . . . . . . . . . . . . . . . . . . . |
. . |
|
3 |
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . |
. . |
|
4 |
Operating Instructions . . . . . . . . . . . . . . . . . . . . . |
. . |
|
7 |
Checking for Leaks . . . . . . . . . . . . . . . . . . . . . |
. . |
|
7 |
First Use . . . . . . . . . . . . . . . . . . . . . . . . . . |
. |
. |
7 |
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 |
|||
Turning Off . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 |
|||
Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . |
. |
. |
7 |
Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . |
|
7 |
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . 7 |
|||
Product Registration . . . . . . . . . . . . . . . . . . . . . . |
. |
. |
8 |
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . |
. . |
|
8 |
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . |
. |
. |
8 |
The use and installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2,or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.
California Proposition 65: Chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm are created by the combustion of propane.
Manufactured in China for: Blue Rhino Global Sourcing, Inc Winston-Salem, NC USA
1.800.762.1142, www.bluerhino.com
© 2009 Blue Rhino Global Sourcing, Inc. All Rights Reserved
GBT926W-OM-103 ES
Outdoor LP Gas Barbecue Grill Model No. GBT926W
DANGER
If you smell gas -
1.Shut off gas to appliance.
2.Extinguish any open flame.
3.Open lid.
4.If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department.
WARNING
FOR YOUR SAFETY
1.Do not store or use gasoline or other flammable liquids or vapors in the vincinity of this or any other appliance.
2.An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
DANGER
Do not leave a lit grill unattended.
DANGER: Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property.
WARNING:
This grill is for outdoor use only, and shall not be used in a building, garage, or any other enclosed area.
This grill is NOT for commercial use.
This is not a tabletop grill. Therefore, do not operate this grill on any type of tabletop surface
This grill is for use with liquid propane (LP) gas only. The conversion to or attempted use of natural gas in this LP gas grill is dangerous and will void your warranty.
LP gas Characteristics:
a.LP gas is flammable and hazardous if handled improperly. Become aware of the characteristics before using any LP gas product.
b.LP gas is explosive under pressure, heavier than air, and settles and pools in low areas.
c.LP gas in its natural state has no odor. For your safety, an odorant is added that smells like rotten cabbage.
d.Contact with LP gas can cause freeze burns to skin.
LP gas tank needed to operate. Only tanks marked “propane” may be used.
The LP gas supply tank must be constructed and marked in accordance with the Specifications for LP gas Cylinders of the U.S. Department of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods; and Commission.
LP gas tank must be arranged for vapor withdrawal.
Dented or rusted LP gas tanks may be hazardous and should be checked by your LP gas supplier prior to use.
The LP gas tank should not be dropped or handled roughly.
LP gas tanks must be stored outdoors out of the reach of children and must not be stored in a building, garage, or any other enclosed area. Your tank must never be stored where temperatures can reach over 125°F.
Never attempt to attach this grill to the self-contained LP gas system of a camper trailer, motor home, or house.
Do not store a spare LP gas tank under or near this appliance.
The use of alcohol or prescription or non-prescription drugs may impair the consumer’s ability to properly assemble or safely operate the appliance.
Never use charcoal, lighter fluid, lava rocks, gasoline, kerosene, or alcohol with this product.
Your grill has been checked at all factory connections for leaks. Recheck all connections, as movement in shipping can loosen connections.
Check for leaks even if your unit was assembled for you by someone else.
Do not operate if gas leak is present. Gas leaks may cause a fire or explosion.
You must follow all leak-checking procedures before operating. To prevent fire or explosion hazard when testing for a leak:
a.Always perform leak test before lighting the grill and each time the tank is connected for use.
b.Do not use or permit sources of ignition in the area while conducting a leak test. No smoking.
c.Conduct the leak test outdoors in a well-ventilated area.
d.Do not use matches, lighters, or a flame to check for leaks.
e.Do not use grill until any and all leaks are corrected.
If you are unable to stop a leak, disconnect the LP gas supply. Call our customer care, gas appliance serviceman or your local LP gas supplier.
Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
Keep all combustible items and surfaces at least 21 inches (53 cm) away from the grill at all times. DO NOT use this grill or any gas product under any overhead or near any unprotected combustible constructions.
It is essential to keep the grill’s valve compartment, burners, and circulating air passages clean. Inspect grill before each use.
Do not alter grill in any manner. Any altering will void your warranty.
Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
This grill should be thoroughly cleaned and inspected on a regular basis.
Use only the regulator provided. Any replacement regulator shall be specified by the manufacturer.
Use only Blue Rhino Global Sourcing, Inc. factory authorized parts. The use of any part that is not factory authorized can be dangerous. This will also void your warranty.
Do not use this appliance without reading “Operating Instructions” in this manual.
Do not touch metal parts of grill until it has completely cooled (about 45 min.) to avoid burns, unless you are wearing protective gear (pot holders, gloves, BBQ mittens, etc.).
Do not install or use in or on boats or recreational vehicles.
When cooking, fire extinguishing materials shall be readily accessible. In the event of an oil grease fire, do not attempt to extinguish with water. Use type BC dry chemical fire extinguisher or smother with dirt, sand or baking soda.
Do not use grill in high winds.
Never lean over the grill when lighting.
Do not leave a lit grill unattended. Keep children and pets away from grill at all times.
Do not attempt to move grill when in use. Allow the grill to cool (approximately 45 minutes) before moving or storing.
Storage of grill indoors is permissible only if the tank is disconnected, removed from the grill and properly stored outdoors.
While wearing a protective glove or mit, open grill lid carefully and slowly as heat and steam trapped within grill can severely burn you.
Do not attempt to disconnect the gas regulator from the tank or any gas fitting while the grill is in use.
Disconnect cylinder when not in use.
Always use your grill on a hard, non-combustable level surface. An asphalt or blacktop surface may not be acceptable for this purpose.
Do not use directly on wooden decks.
Keep all electrical cords away from a hot grill.
Do not use grill for indoor cooking or heating. TOXIC fumes can accumulate and cause asphyxiation.
After a period of storage and/or nonuse check for leaks and burner obstructions.
Failure to open lid while igniting the grill’s burner, or not waiting 5 minutes to allow the gas to clear if the grill does not light, may result in an explosive flame-up.
If grill is not in use, the gas must be turned off at the supply tank.
Never operate grill without heat plate installed.
Always use a meat thermometer to ensure food is cooked to a safe temperature.
Please use protective gloves when assembling this product.
Do not force parts together as this can result in personal injury or damage to the product.
Never cover entire cooking area with aluminum foil.
Deaths, serious injury or damage to property may occur if the above is not followed exactly.
Contact 1.800.762.1142 for assistance. Do not return to place of purchase. For great recipes and tips, visit recipes.uniflame.com
page no.
Parts List
1 |
Warming Rack |
55-09-333 |
|
|
|
|
|
2 |
Handle |
55-09-237 |
|
|
|
|
|
3 |
Temperature Gauge |
55-07-233 |
|
|
|
|
|
4 |
Temperature Gauge |
55-09-378 |
|
Support |
|||
|
|
||
5 |
Lid |
55-09-327 |
|
|
|
|
|
6 |
Cooking Grid |
55-09-325 |
|
|
|
|
|
7 |
Top Hinge (2) |
55-15-330 |
|
|
|
|
|
8 |
Burner |
55-07-214 |
|
|
|
|
|
9 |
Heat Plate Support (2) |
55-09-330 |
|
|
|
|
|
10 |
Wind Guard |
55-09-254 |
|
|
|
|
|
11 |
Heat Plate |
55-09-329 |
|
|
|
|
|
12 |
Botom Hinge (2) |
55-15-329 |
|
|
|
|
|
13 |
Igniter Wire |
55-15-060 |
|
|
|
|
|
14 |
Bottom Bowl |
55-09-324 |
|
|
|
|
|
15 |
Lock |
55-09-328 |
|
|
|
|
|
16 |
Regulator/Control Valve |
55-14-986 |
|
|
|
|
|
17 |
Rear Leg |
55-09-331 |
|
|
|
|
|
18 |
Front Leg |
55-09-329 |
Exploded View
1
2
3
4
6
5
|
7 |
11 |
9 |
|
|
|
8 |
10
12
13
14
9
17 |
15 |
16 |
|
|
18
Hardware |
|
|
Tools Required for Assembly (Not Included) |
||
A |
Screw |
M6x15 Nickel Plated Phillips Truss Head |
4 pcs |
#2 Phillips Head Screwdriver |
1 pc |
|
|
||||
B |
|
|
|
|
|
Wing Bolt |
M6x8 Nickel Plated |
5 pcs |
|
|
|
C |
Wing Nut |
M6 Nickel Plated |
6 pcs |
|
|
D |
Washer |
ø6.4 Nickel Plated |
7 pcs |
|
|
E |
Washer |
ø6 Heat Resistant |
2 pcs |
|
|
F |
Lock Washer |
ø6 Nickel Plated |
7 pcs |
|
|
G |
Pin |
ø5 x 32 Nickel Plated |
2 pcs |
|
|
H |
Cotter Pin |
ø1.2 x 30 Black |
2 pcs |
|
|
|
|
|
|
|
|
Outdoor LP Gas Barbecue Grill Model No. GBT926W
Assembly Instructions
1 |
DO NOT RETURN PRODUCT TO STORE. |
2 |
Fold Legs |
For assistance call 1.800.762.1142 toll free. Please have |
|
||
your owner’s manual and serial number available for |
|
reference.
For Easiest Assembly:
•To avoid losing any small components or hardware, assemble your product on a hard level surface that does not have cracks or openings.
•Clear an area large enough to layout all components and hardware.
•When applicable, tighten all hardware connections by hand first. Once the step is completed go back and fully tighten all hardware.
•Follow all steps in order to properly assemble your product.
To complete assembly you will need:
•(1) Leak Detection Solution (Instructions on how to make solution are included in “Operating Instructions” section)
•(1) 14.1 oz or (1) 16.4 oz LP gas tank.
Note: You must follow all steps to properly assemble grill.
Typical assembly: approximately 30 minutes.
|
4 Attach Heat Plate Suports |
3 Attach Legs |
|
A |
x 4 |
B |
x 4 |
|
|
C |
x 4 |
D |
x 4 |
F |
x 4 |
Contact 1.800.762.1142 for assistance. Do not return to place of purchase. For great recipes and tips, visit recipes.uniflame.com
page no.
|
|
|
|
|
|
|
|
|
|
|
|
5 |
Attach Burner and Igniter Wire |
6 |
Attach Wind Guard and Regulator/Control Valve |
||
|
|
|
|
Note: Once attached, the regulator/control valve will freely rotate to accomodate for the LP gas tank.
B |
D |
x 1 |
x 1 |
|
|
|
F |
x 1 |
|
|
|
7 Attach Handle and Temperature Gauge |
8 Attach Lid |
C |
|
x 2 |
E |
x 2 |
|
|
|
||
D |
x 2 |
|
F |
x 2 |
|
|
|
|
G |
x 2 H |
x 2 |
|
|
Outdoor LP Gas Barbecue Grill Model No. GBT926W
Assembly Instructions (continued)
|
|
|
|
|
9 |
Insert Warming Rack |
10 |
Insert Heat Plate and Cooking Grid |
|
|
|
|
|
|
11 |
Lock Lid |
12 |
Fold Up Legs |
|
Note: Always lock lid before folding legs. |
Unlock Lid |
|
Unfold Legs |
|
|
Note: Always open legs completely and are secured in place before lighting. |
