U-Line ULNSS1095FD03A, ULNSS1095FD20A, ULNSP18FCW20A, ULNSP18FCB03A, ULNSS1095FC03A INSTALLATION INSTRUCTIONS AND OPERATION MANUAL
...
QUICK START GUIDE
Ice Makers • 115 V / 60 Hz & 220-240 V / 50 Hz
QUICK START GUIDE
u-line.com
WELCOME TO U-LINE
Congratulations on your U-Line purchase. Your product comes from a company with over five decades and three generations of premium modular ice making, refrigeration, and wine preservation experience. U-Line continues to be the American leader, delivering versatility and flexibility for multiple applications including residential, light commercial, outdoor and marine use. U-Line’s complete product collection includes modular Wine Captain® Models, Beverage Centers, Clear Ice Machines, Crescent Ice Makers, Glass & Solid Door Refrigerators, Drawer Models, Freezers, and Combo® Models.
U-Line has captivated those with an appreciation for the finer things with exceptional functionality, style, inspired innovations and attention to even the smallest details. We are known and respected for our unwavering dedication to product design, quality and selection. U-Line is headquartered in Milwaukee, Wisconsin with a west coast office located in Laguna Beach, California and European support in Dublin, Ireland. U-Line has shipped product to five continents for over two decades and is proud to have the opportunity to ship to you.
PRODUCT INFORMATION
Looking for additional information on your product? User Guides, Quick Reference Guides, CAD Drawings, Compliance Documentation, and Product Warranty information are all available for reference and download at u-line.com under Documentation.
PROPERTY DAMAGE / INJURY CONCERNS
In the unlikely event property damage or personal injury is suspected related to a U-Line product, please take the following steps:
1.U-Line Customer Care must be contacted immediately at +1.800.779.2547.
2.Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been altered or repaired in the field without prior written approval from U-Line, claims will not be eligible.
SERVICE INFORMATION
Answers to Customer Frequently Asked Questions are available at u-line.com under Customer Care or you may contact our Customer Care group directly, contact information below.
GENERAL INQUIRIES
U-Line Corporation
8900 N. 55th Street
Milwaukee, Wisconsin 53223 USA
Monday - Friday 8:00 am to 4:30 pm CST T: +1.414.354.0300
F: +1.414.354.7905 Email: sales@u-line.com u-line.com
CONNECT WITH US
SERVICE & PARTS ASSISTANCE
Monday - Friday 8:00 am to 5:30 pm CST T: +1.800.779.2547
F: +1.414.354.5696
Service Email: onlineservice@u-line.com Parts Email: onlineparts@u-line.com
Designed, engineered and assembled in WI, USA
QUICK START GUIDE
u-line.com
Contents
1 Model List
3Safety and Warning
4Environmental Requirements
5Electrical
6Water Hookup
9Door Swing
10Door Latch
11General Installation
12Integrated Panel Installation
14First Use
14Ice
15Warranty
QUICK START GUIDE
u-line.com
Model List
This guide provides the basics to get you started. Looking for more information? Visit u-line.com to view detailed User Guides for all U-Line products.
Crescent Ice Makers
U-BI1215S-00A
U-BI1215INT-00A
U-BI1215B-00A
U-BI1215W-00A
ADA Height Compliant Series
U-BI95B-00A |
U-BI98B-00A |
U-ADA15IMS-00A |
U-BI95W-00A |
U-BI98W-00A |
U-ADA15IMB-00A |
|
Outdoor Series
U-BI1215SOD-00A
1
QUICK START GUIDE
u-line.com
Marine Series
ULN-BI95FCB-03A ULN-WH95FC-03A ULN-SS1095FC-03A
ULN-BI95FCB-20A ULN-WH95FC-20A ULN-SS1095FC-20A
ULN-SS1095FD-03A
ULN-SS1095FD-20A
ULN-SS1095NF-03A
ULN-SS1095NF-20A
ULN-SP18FCS-03A ULN-SS98NF-03A
ULN-SP18FCS-20A ULN-SS98N5-20A
ULN-SP18FCB-03A
ULN-SP18FCB-20A
ULN-SP18FCW-03A
ULN-SP18FCW-20A
Visit http://www.u-line.com/product-literature/userguides or scan this QR code to view all user guides online.
2
QUICK START GUIDE
u-line.com
Safety and Warning
NOTICE
PLEASE READ all instructions before installing, operating, or servicing the appliance.
SAFETY ALERT DEFINITIONS
Throughout this guide are safety items labeled with a Danger, Warning or Caution based on the risk type:
that they do not play with this appliance. Cleaning and user maintenance shall not be performed by children without supervision.
! DANGER
Do not use electrical appliances inside the food storage compartment of this appliance.
! DANGER
Danger means that failure to follow this safety statement will result in severe personal injury or death.
! WARNING
Keep ventilation openings in the appliance enclosure or in the built in structure clear of obstruction.
! WARNING
Warning means that failure to follow this safety statement could result in serious personal injury or death.
! WARNING
Do not store explosive substances such as aerosol cans with flammable propellant in this appliance.
! CAUTION
Caution means that failure to follow this safety statement may result in minor or moderate personal injury, property or equipment damage.
GENERAL PRECAUTIONS
Use this appliance for its intended purpose only and follow these general precautions with those listed throughout this guide.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure
! WARNING
Requirement for an external switch in the fixed wiring is specified.
! WARNING
To avoid a hazard due to instability of the appliance, it must be fixed in accordance with the instructions.
3
