Ubiquiti UCK-PLUS Specsheet

Datasheet

Hybrid Cloud Key Technology
with Integrated Application Server

Model: UCK-G2-PLUS

Fully Integrated, Stand-Alone UniFi® Controller with 1TB HDD

Multi-Site Network Management and IP Video Surveillance

Remote, Private Cloud Access to UniFi SDN and UniFi Protect

UniFi Controller with Hybrid Cloud

UniFi UCK-G2-Plus

Datasheet

The UniFi Cloud Key Gen2 Plus is an integrated hardware
controller and self-contained application server designed
to monitor and manage your UniFi network devices and
camera surveillance system. It features an eight-core
processor with 3 GB RAM, a 1 TB SATA HDD for video

storage, and 32 GB eMMC ash storage, and utilizes the

latest version of the UniFi Controller with hybrid cloud
technology.

Breakthrough Efciency

The UniFi Cloud Key Gen2 Plus is fully capable of

conguring and managing dozens of UniFi devices

on your network, and offers an ultra-low energy PoE
replacement for a dedicated server or computer, with
virtually no digital footprint.

Hybrid Cloud Technology

The Ubiquiti® hybrid cloud conguration provides a

secure, private SSO (Single Sign-On) to access all of your
UniFi deployments from anywhere in the world. With the
Ubiquiti hybrid cloud, a third-party hosted cloud service
is not required, so all of your personal data and network
information remains local and secure–the way it should be.

Incredible, Agile Scalability

Add, provision, congure, monitor, and manage all of

your UniFi devices, whether in one or hundreds of private

networks–all from a centralized control panel.

Easily accessible through one of our downloadable apps
or a standard web browser (Chrome recommended),
the UniFi Cloud Key Gen2 Plus is a powerful solution for
managing your UniFi networks across the campus or
across the globe.

UniFi Protect System

Front Entrance

Warehouse Garages

UniFi Switch

LAN

UniFi Security Gateway Pro
(DHCP Server)

WAN

Loading Dock

Front Hall

Rear Entrance

Reception

East Alley

Remote Access to

UniFi Protect

Internet

2

Overview

Designed for convenient monitoring and complete
management of your camera surveillance system,
the UniFi Protect Controller allows you to set up,

congure, and monitor your UniFi cameras using a

graphical user interface. As one of the built-in apps
on the Cloud Key Gen2 Plus, there are no separate
software, licensing, hosting, or support fees.

Features

Easy Setup Using a standard web browser

or Bluetooth setup from your mobile device,
deployment of your UniFi Protect controller can

be set up and congured in a matter of minutes.

Feature-Packed User Interface Accessible from
a web browser, the UniFi Protect was designed
to be easy-to-use yet packed with advanced
features. The UniFi Protect interface is incredibly
intuitive and loaded with powerful features such
as statistical reporting, multiple live views options,
versatile camera settings, advanced analytics, and

customizable event recordings.

Plug and Play Installation Automatic camera
detection in UniFi Protect makes it easy to install
and deploy cameras. All of the camera settings
are integrated into the software. You can also

congure, reboot, or upgrade the rmware on any

camera from within the UniFi Protect interface.

Live View

View up to 20 live camera feeds in a single window. With basic
and advanced template options available, choose the live view
template that’s right for you.

Time Lapse

The new Time Lapse feature allows you to scroll through video
events and recordings quickly and efciently. Now you can
sift through hundreds of hours of video in just minutes.

Datasheet

Additional Live Views Playlists can be created

with a congurable live camera feed rotation.
Dene the cameras you want included in the

playlist and how long you want them to appear on
the screen before moving on to the next live feed.

Cost-Effective Solution Shattering conventional
industry thinking, UniFi Protect provides powerful
IP surveillance software without the huge up-front
costs or monthly subscription fees.

Mobile App The downloadable app provides
free remote cloud access to your UniFi Protect
system. It also allows you to securely access video
recordings that are privately stored on the Cloud
Key Gen2 Plus and not a third-party server or
internet cloud.

9:30 AM

9:15 AM

9:00 AM

8:45 AM

8:30 AM

Events

Video recordings are stored privately on the
With a built-in 1 TB HDD, you can retain hundreds of recording
hours without third-party storage or online digital footprints.

Cloud Key Gen2 Plus

.

3

UniFi SDN Controller

Designed for convenient management, the
UniFi SDN Controller software allows admins

to congure and monitor UniFi devices using a

graphical user interface. There are no separate

Datasheet

software, licensing, hosting, or support fees.

Dashboard

UniFi provides a visual representation of your network’s status
and delivers basic information about each network segment.

Multi-Site Management

A UniFi Cloud Key Gen2 Plus installed at each
deployment site provides an always-on, private
UniFi cloud service. Every site is accessible through
its assigned secure SSO. Each Cloud Key Gen2 Plus
is independent with its own network monitoring,

conguration, maps, statistics, and admin

accounts.

Improved User Experience

Redesigned to be more intuitive and easier to
navigate, the new UI raises the bar for enterprise

network management efciency. Important
network details are logically organized for a
simplied, yet powerful, interface.

Network Overview

A comprehensive overview of your network
health is readily available in the new dashboard.

Monitor your network’s vitals and make on‑the‑y

adjustments as needed.

SDN Mobile App

The downloadable app provides free remote cloud access to

your UniFi Controller. It also allows you to analyze and manage
the health and trafc of your UniFi network from anywhere in the

world using your single-signon Ubiquiti account.

Detailed Analytics

Use the congurable reporting and analytics

to monitor large user groups and expedite
troubleshooting.

LAN/WLAN Groups

The UniFi SDN Controller can manage exible
congurations of large deployments. Create

multiple LAN and WLAN groups and assign them
to the respective UniFi devices.

Wi-Fi Management

Use the UniFi SDN Controller to provision UniFi

APs, congure wireless networks, map out
networks, and quickly manage system trafc.

Powerful Wi-Fi management features include:

• RF monitoring and device mapping

• Detailed RF performance analysis

• Band steering support

• Guest portal/hotspot support

Statistics

The Statistics tab provides a visual representation of the network

clients and network trafc carried by your managed UniFi

Switches and APs.

Router and Switch Management

Use the UniFi Controller to provision UniFi Security

Gateways and Switches. Congure a variety of

features:

• WAN/LAN/VLAN conguration

• Operation mode (switching, mirroring, or

aggregate) per port

• PoE setting per port (device dependent)

• Jumbo frame and ow control services

• Monitor and analyze performance of each port

4

UniFi UCK-G2-Plus

Good

Fair

Poor

Great

Network:

Switches12Gateway

Ulizaon

18%

Internet

Capacity

43%

Clients

412

Guests

113

IoT

45

Everything is

great

My Dashboard

Edit Widgets

-24hrs

-24hrs

Max

980

Min

0

Now

Now

Throughput

Latency

ISP Load:

Great

-24hrs

Max

0

Now

Airtime

-24hrs

High

Low

Now

Retry Rate

Great

Wi-Fi Load:

225.2 Mbps

125.2 Mbps

1

Wi-Fi Trac Distribution

3661140444852566064100

104

108

112

116

120

124

128

132

136

140

149

153

157

161

165

5 GHz

2.4 GHz

Access Points

20

Last 24 Hrs

Most Active APs

Office

Back Room

Storage

Roof

Hallway We ...

91 GB

86 GB

53 GB

48 GB

45 GB

Top 5 Applications

YouTube

35 Clients

Instagram

19 Clients

Squarespace

17 Clients

Google

12 Clients

Facebook

20 Clients

Top Interference

Hallway We ...

Roof

Storage

51%

45%

44%

Top CPU Usage

Office

Back Room

Home

51%

45%

43%

Most Active Clients

Wi-Fi Key Metrics

91 Clients

iPhone

87 Clients

Android

45 Clients

MacBook

35 Clients

PC Laptop

12 Clients

iPad

Top Memory Usage

Client Frequency Distribution

Device Distribution

HD-Kitchen

HD-Conference

Storage

Roof

Hallway We ...

56.9%

35.6%

34%

28%

24%

Longest Client Uptime

Wi-Fi Summary

Routing Utilization

Switch Summary

iPad-1

APs Online

Gateway - USG Main

Controller - Office CK

Controller - Office 2 CK

25% CPU Ulizaon

50% CPU Ulizaon

33% CPU Ulizaon

Online

MBP-2

Clients

iPad-2

Ulizaon

Clients

Port Ulizaon

8d 4h 0m3224

2d 8h 30m

1,324

2d 5h 15m

64%

1,324

32%

Port Usage

VPN Name

Status

Users

Guests

Purpose

Average Data

Port 1- GB

VPN-LA-PDX

212Corporate

320 GB

Port 2- GB POE+

VPN-LA-PDX2

60VLAN Only

11 GB

Port 3- 10 GB

Remote-Office-1

430VLAN Only

12 GB

120

80

32

HD-Conference

42%

Office - Art Dept

42%

MBP-1

Traffic

Devices

Traffic

2d 3h 10m

248 GB

536

1,248 GB

Port 4- GB POE

Transfer-1

712VLAN Only

0 GB

13

5GHz

50%

13 LAN

03 WLAN

01 WAN

0%

0%

0%

100%

100%

100%

Average Capacity

500 Mbps

Average Airme Ulizaon

8%

Average Spectral Efficiency

2.1 (b/s) Hz

64% 11ac W2

28% 11ac

08% 11n

1300 Mbps

0 Mbps

100%

0%

(b/s) Hz

3.76 (b/s) Hz

Internet Connection:

30 Mbps

40 Mbps

50 Mbps

20 Mbps

10 Mbps

0 Mbps

-24 hrs

-12 hrs

Now

Download

Theorecal Capacity

Throughput

Portlan d

SDN

Most Active Switches

UniFi SDN System

UVC-G3-Flex Camera

UniFi AP SHD

UniFi Switch

LAN

Wireless Clients

Wired Clients

Server

Remote Access to

UniFi SDN and UniFi Protect

Datasheet

UniFi Security Gateway Pro
(DHCP Server)

WAN

Internet

SW-24A

56.9%

SW-8A

35.6%

SW-8B

34%

SW-24E

28%

SW-24D

24%

Rackmount Accessory

Now you can mount the Cloud Key Gen2 Plus in a
standard 19" rack, along with other UniFi switches

LED

Display

Window

Reset

Button

and network devices. Sold separately, the optional
Rackmount Accessory, model CKG2-RM, features
a docking bay for the Cloud Key Gen2 Plus and an
alternate Ethernet port1 for power and network
connectivity.

Ethernet

Port

The Docking Bay is also designed to house the
Cloud Key Gen2 model, UCK-G2. Simply press the
Locking Tab on the back of the Rackmount

Accessory and adjust the size of the Docking Bay.

Locking

Tab

Docking

Bay

CKG2-RM with UCK-G2-Plus installed

¹ To prevent creating a loop or other unfavorable behavior on the network, only one Ethernet connection should be used. Do not use the Ethernet port on the

Cloud Key Gen2 Plus and the Rackmount Accessory simultaneously

5

Specications

UCK-G2-PLUS

Dimensions 131.16 x 27.10 x 134.20 mm (5.16 x 1.07 x 5.28")

Datasheet

Weight 582 g (1.28 lb)

Enclosure Anodized Aluminum

Management Interface UniFi Management Portal; UniFi SDN; UniFi Protect

Hard Drive Capacity 1 TB 2.5" SATA HDD (user-upgradeable)

Device Capacity

UniFi Protect Mode
UniFi SDN + UniFi Protect

Processor APQ8053 8 Core with 3 GB RAM

eMMC Memory 32 GB

Networking Interface (1) 10/100/1000 Ethernet Port

Buttons (1) Power; (1) Reset

LEDs (1) Power, White/Blue

Up to 15 UniFi Cameras and 50 UniFi Devices

Up to 20 UniFi Cameras

Power Method

Supported Voltage Range Standard 802.3af PoE or 9VDC, 2A

Max. Power Consumption 12.95W (PoE); USB-C Power

Operating Temperature 0 to 35° C (32 to 104° F)

Operating Humidity 20 to 80% Noncondensing

Certications CE, FCC, IC

Standard 802.3af PoE; Quick Charge 2.0/3.0 Power Adapter (9VDC, 2A)

AJ091318

6

©2018 Specications are subject to change. Ubiquiti products are sold with a limited warranty described at: www.ubnt.com/support/warranty
Ubiquiti Networks, Inc. All rights reserved. Ubiquiti, Ubiquiti Networks, the Ubiquiti U logo, the Ubiquiti beam logo, TOUGHCable, UniFi, and UniFi
Protect are trademarks or registered trademarks of Ubiquiti Networks, Inc. in the United States and in other countries. Apple and the Apple logo are
trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc., registered in the U.S. and other countries.
Android, Google, Google Play, the Google Play logo and other marks are trademarks of Google Inc. All other trademarks are the property of their
respective owners.

www.ubnt.com
