TD-8840 User Guide
External ADSL2+ Router
Rev: 1.0.2 1910010008
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice.
is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2008 TP-LINK TECHNOLOGIES CO., LTD.
All rights reserved.
http://www.tp-link.com
II
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1)This device may not cause harmful interference.
2)This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
III
EC DECLARATION OF CONFORMITY (EUROPE)
In compliance with the EMC Directive 89/336/EEC, Low Voltage Directive 73/23/EEC, this product meets the requirements of the following standards:
•EN55022
•EN55024
•EN60950
SAFETY NOTICES
Caution:
Do not use this product near water, for example, in a wet basement or near a swimming pool.
IV
Package Contents
The following items should be found in your package:
¾One TD-8840 External ADSL2+ Router
¾One AC power Adapter for TD-8840 External ADSL2+ Router
¾One Resource CD for TD-8840 External ADSL2+ Router, including:
•This Guide
•Other Helpful Information
•Quick installation Guide Program
¾Quick installation Guide
¾One RJ45 cable
¾Two RJ11 cables
¾One ADSL splitter
) Note:
Make sure that the package contains the above items. If any of the listed items are damaged or missing, please contact with your distributor.
V
|
|
CONTENTS |
|
Chapter 1. |
Introduction ........................................................................................ |
1 |
|
1.1 |
Product Overview...................................................................................................... |
1 |
|
1.2 |
Main Features ........................................................................................................... |
1 |
|
1.3 |
Supporting Protocol................................................................................................... |
1 |
|
1.4 |
Transmit Data-rate .................................................................................................... |
2 |
|
1.5 |
ATM Property ............................................................................................................ |
2 |
|
1.6 |
System Support......................................................................................................... |
2 |
|
1.7 |
Working Environment................................................................................................ |
2 |
|
1.8 |
Conventions .............................................................................................................. |
3 |
|
Chapter 2. |
Hardware Installation ......................................................................... |
4 |
|
2.1 |
System Requirement................................................................................................. |
4 |
|
|
2.1.1 |
LED Explanation............................................................................................................... |
4 |
2.2 |
Rear-panel ................................................................................................................ |
4 |
|
2.3 |
Hardware Installation Procedures ............................................................................. |
5 |
|
Chapter 3. |
System Configuration ........................................................................ |
6 |
|
3.1 |
Computer Configuration ............................................................................................ |
6 |
|
3.2 |
Login ......................................................................................................................... |
7 |
|
3.3 |
Web Setup ................................................................................................................ |
9 |
|
3.4 |
Software Dial........................................................................................................... |
18 |
|
Chapter 4. Advantage Management Setup ....................................................... |
20 |
||
Appendix A: FAQ.................................................................................................... |
21 |
||
Appendix B: Default Config................................................................................... |
23 |
||
VI
TD-8840 External ADSL2+ Router User Guide
Chapter 1.Introduction
Thank you for choosing the TD-8840 External ADSL2+ Router.
1.1Product Overview
With the excellent circuit design and high quality production, we guarantee the ADSL2+ Router’s high performance, great stability and easy to use.
The TD-8840 uses integrated ADSL2+ transceiver. The AFE supports full-rate ADSL connectivity conforming to the ITU and ANSI specifications.
In addition to the basic DMT physical layer functions, the ADSL PHY supports dual latency ADSL framing (fast and interleaved) and the I.432 ATM Physical Layer.
The TD-8840 is a complete plug-and-play solution. With standard Ethernet interface, it can be directly connected to any 10M/100M Ethernet devices, support Auto-MDIX.
The TD-8840 not only uses html (web mode through Ethernet port) to configure the Router but also uses external utility software. You can download it from our website (http://www.tp-link.com).
1.2Main Features
¾High speed and asymmetry data transmit mode, built-in 4-port switch realize multi-user to share wide-band internet access
¾Support All ADSL2+ industrial standards
¾Compatible with all mainstream DSLAM (CO)
¾Firmware upgradeable
¾Provide integrated access of internet and route function which face to SOHO user
¾Advanced DMT modulation and demodulation
¾Real-time Configuration and device monitoring
¾Quick response semi-conductive surge protect circuit, provides reliable ESD and surge-protect function
1.3Supporting Protocol
-G.992.1 (G.dmt) - Annex A/B/C
-G.992.2 (G.lite) - Annex A/B/C
-ANSI T1.413
-G.992.3 (ADSL2) - Annex A/B/C/M and Annex L (RE-DSL) compliant
-G.992.5 (ADSL2+) Annex A/B/C and Annex L (RE-DSL) compliant
1
TD-8840 External ADSL2+ Router User Guide
-ADSL dual latency (fast path and interleaved path)
-I.432 ATM physical layer compliant
-Supports RFC2364 (PPPoA)
-Supports RFC2516 (PPPoE)
-Supports RFC1483 (EoA) (Bridged *and Router)
-Supports RFC1577 (IPoA)
) Note:
“*” Needs the third-party software.
1.4Transmit Data-rate
¾Max download data-rate: 24Mbps
¾Max upload data-rate: 3.5Mbps
¾Max line length: 6Km
1.5 ATM Property
¾ AAL0, AAL5, OAM, RM, and raw cell types supported
¾ Direct hardware support for 4 Receive VCs, with additional RX VCs and TX VCs supported in software
¾ Full 24-bit Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI)
1.6 System Support
¾Support PVC
¾Support NAT DHCP and so on
¾Support IEEE 802.3 IEEE 802.3u
¾Support 10Base-T/100BASE-TX full-duplex or half duplex Ethernet
¾Support Auto-MDIX
1.7Working Environment
¾Operating temperature: 0 ~40
¾Storage temperature: -40 ~70
2
TD-8840 External ADSL2+ Router User Guide
¾Humidity: 10%~90% (non-condensing)
1.8Conventions
The Router or TD-8840, or device mentioned in this User guide stands for TD-8840 External ADSL2+ Router without any explanations.
Parameters provided in the pictures are just references for setting up the product, which may differ from the actual situation.
You can set the parameters according to your demand.
3
