Datasheet
TP-LINK
JetStream 28-Port Gigabit
Stackable L2+ Managed Switch
T2700G-28TQ
Overview
TP-LINK’s T2700G-28TQ is an L2+ managed switch designed to build a highly accessible,
scalable, and robust network. The switch is equipped with 24 Gigabit RJ-45 ports, 4 Combo
Gigabit SFP and up to 4 10Gbps SFP slots, giving network administrator great network
exibility. It supports basic Layer3 features like static routing and RIP v1/v2 by default and
can be upgraded to support abundant Layer 3 features such OSPF/ECMP/PIM/VRRP with
the addition of a Layer3 license. What’s more, with physical stacking feature and optional
redundant external power unit, T2700G-28TQ provides a robust network with ecient
redundancy. T2700G-28TQ provides robust security to help secure your enterprise
network.
TP-LINK’s T2700G-28TQ L2+ managed switch provides a reliable and cost-eective solution
for enterprise, campus and ISP networks.
www.tp-link.com
Please contact with TP-LINK’s authorized distributor to purchase the license key if
(T2700G-28TQ-L1000) needed and then go to T2700G-28TQ page at TP-LINK website to
download the license with the license key.
Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product
names are trademarks or registered trademarks of their respective holders. Copyright @ 2015 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
Specifications
Hardware Features & Performance
Product Picture
Datasheet
Model
Hardware Features
Standards and Protocols
Interfaces
Network Media
Dimensions ( W x D x H )
Fan Quantity
Power Consumption
Power Supply
Certications
Environment
Physical Stacking
Installable SFP+ Transceivers
and Direct Attach Copper
(DAC) Cables
Max Number of Stacking Ports
Installable
Stacking Speed (Per Port)
Number of Units Per Stack
Performance
Switching Capacity
Packet Forwarding Rate
Backplane
Packet Buer
MAC Address Table
Number of Routes
Number of Static Routes
Number of IP Interfaces
Jumbo Frame
T2700G-28TQ
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ae, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d,
IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p
24 10/100/1000Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
4 combo gigabit SFP Slots
Up to 4 10G SFP+ Slots (2 xed and 2 optional 10G SFP+ Slots)
1 Console Port
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
100BASE-FX: MMF, SMF
1000BASE-X: MMF, SMF
10GBASE-LR
10GBASE-SR
17.32*13*1.73 in. (440*330*44 mm)
4
63W (220V/50Hz) max
100-240V AC, 50/60Hz
CE, FCC, RoHS
Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing
TXM431-SR
TXM431-LR
TXC432-CU1M
TXC432-CU3M
2 SFP+
20 Gbps (Full-Duplex)
8
Up to 128Gbps for a standalone switch
Up to 95.2Mpps for a standalone switch
Up to 320Gbps when 8 units in the stack
2 MB
32K
12K
256
128
10240 Bytes
