TP-Link MC110CS, MC100CM Installation Guide

LED Explanation

PWR

On: Power on

Power o

O:

©2019 TP-Link 7106508387 REV6.2.0

Enlarge Your Ethernet Network

Fast Ethernet Media Converter

For technical support and other information, please visit

https://www.tp-link.com/support, or simply scan the QR code.

Package Contents: Converter, Power Adapter, User Guide

For MC100CM/MC110CS

Scenario 1: Connect Devices with and without Optical Interfaces

FX
Link/Act

On: Valid link
Flashing: Transmitting or receiving data

O: Invalid link

TP
Link/Act

On: Valid link
Flashing: Transmitting or receiving data

O: Invalid link

Ethernet Device

Media Converter

with Optical Interfaces

100BASE-X (Fiber) Interface

TX RX

PWR

FX

Link/Act

TP

Link/Act

LC-SC Fiber Cable

Scenario 2: Connect Devices without Optical Interfaces

Ethernet Device

without Optical Interfaces

10BASE-T/100BASE-TX Interface

Note:

1. Please use two Media Converters of the same model to work properly.

2. Please connect the TX port of one converter to the RX port of the other using a ber cable.

Media Converter Media Converter

10/100M

Link/Act

TP

Link/Act

FX

PWR

TX RX

Fiber CableTwisted-Pair Cable Twisted-Pair Cable

10/100M

TX RX

10BASE-T/100BASE-TX Interface

Twisted-Pair Cable

PWR

FX

Link/Act

TP

Link/Act

10BASE-T/100BASE-TX Interface

10/100M

Ethernet Device

without Optical Interfaces

Ethernet Device

without Optical Interfaces

For MC111CS/MC112CS

Scenario 1: Connect Devices with and without Optical Interfaces

Ethernet Device

Media Converter

with Optical Interfaces

PWR

FX

Link/Act

100BASE-X (Fiber) Interface

LC-SC Fiber Cable

TP

Link/Act

10/100M

10BASE-T/100BASE-TX Interface

Twisted-Pair Cable

Scenario 2: Connect Devices without Optical Interfaces

Ethernet Device

without Optical Interfaces

10BASE-T/100BASE-TX Interface

Note: Please use one MC111CS and one MC112CS to work properly.

Media Converter Media Converter

10/100M

Link/Act

TP

Link/Act

FX

PWR

PWR

FX

Link/Act

TP

Link/Act

SC-SC Fiber CableTwisted-Pair Cable Twisted-Pair Cable

10BASE-T/100BASE-TX Interface

10/100M

Specications

General Specifications Environmental and Physical Specifications

Standards

IEEE 802.3, IEEE 802.3i, IEEE802.3u

LED PWR, FX Link/Act, TP Link/Act

1 SC ber optic; 1 RJ45 jackConnector

Twisted-Pair

10BASE-T: 2-pair UTP/STP of Cat. 3 or above (≤100m)
100BASE-Tx: 2-pair UTP/STP of Cat. 5 or above (≤100m)

For MC100CM:

Fiber

62.5/125μm multi-mode (≤2km); 50/125μm multi-mode (≤2km)

For MC110CS/ MC111CS/MC112CS:

9/125μm single-mode ber (≤20km)

For MC100CM/MC110CS: 1310nm

Wave Length

For MC111CS: 1550nm TX, 1310nm RX
For MC112CS: 1310nm TX, 1550nm RX

External Power Adapter: 9V/0.6APower

Operation Temperature

Storage Temperature

Operation Humidity

Storage Humidity

0˚C to 40˚C (32˚F to 104˚F)

-40˚C to 70˚C (-40˚F to 158˚F)

10% to 90% RH non-condensing

5% to 90% RH non-condensing

Ethernet Device

without Optical Interfaces

Ethernet Device

without optical Interfaces

Safety Information

Keep the device away from water, re, humidity or hot environments.

Do not attempt to disassemble, repair, or modify the device.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Adapter shall be installed near the equipment and shall be easily accessible.
Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning.
Do not point or stare directly into the beam or into the optical port of the transceiver when it is operating, as this can
injure your eyesight.

EU declaration of conformity

TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of
directives 2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.

The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce
