TL-MC1400
Datasheet
Media Converters & Chassis
MC200CM
MC210CS
MC220L
MC112CS
TL-MC1400
MC111CS
MC100CM MC110CS
Overview
The Chassis-based Media Converters include a number of independent media converters and a chassis
capable of housing up to 14 media converters. You can start with single media converters, each equipped with
its own housing and AC power adapter. When you require more room, you can mount a chassis in your
equipment rack and install your media converters in the chassis - the media converters can be slid into the
chassis.
Page 1
www.tp-link.com
TL-MC1400 14-Slot Rackmount Chassis
The TL-MC1400 14-Slot Rackmount Chassis is specially designed for accommodating chassis-based Media
Converters. It is a standard 19-inch 2U height rackmount chassis which can be suitably mounted in the
standard 19-inch rack.
The chassis lets you install multiple media converters in an equipment rack together with the network devices
for which they provide media conversion. This provides for space saving, and the cabling will look neat. The
chassis comes with its own universal AC to DC power supply. For maximum power availability, an optional
redundant power supply is available for installation in the chassis.
Features:
14 bays to house up to 14 media converters*
Standard 19-inch rack-mountable, 2U height
Non-stop operation & minimal downtime
Allows hot-swapping of media converters
Hot swappable redundant power supplies
Cooling fans on back side (together with power supplies)
Second AC to DC power supply for load-sharing purposes (Optional)
Media converter power isolation for electrical isolation from each bay
Oers over-voltage and over-current protections
Specifications:
Input: 100-240V~50/60Hz 3.0A(Max)
Output: +9.5VDC, 9.5A(Max.)
Power Supply
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Vripple: ≤50mv
Noise: ≤100mv
0°C~40°C (32°F~104°F)
-40°C~70°C (-40°F~158°F)
10%~90% non-condensing
5%~90% non-condensing
Dimensions (W
Weight
X DX H)
19.0 x 14.1 x 3.4 in. (482 x 358 x 86 mm)
Standard 19-Inch, 2U height
8Kg
*The TL-MC1400 supports MCXXX ver: 2.0 and 3.0, not ver: 1.0.
Page 2
www.tp-link.com
MC200CM
The MC200CM media converter converts 1000BASE-SX ber to 1000Base-T copper media or vice versa. It is
designed for use with 850nm multi-mode ber cable utilizing the SC-Type connector, transmitting data up to
0.55 kilometers away. What's more, MC200CM can work as a stand alone device (no chassis required) or with
TP-LINK´s 19” system chassis.
Features:
Works at 1000Mbps in Full-Duplex mode for both TX port and FX port
Supports Auto MDI/MDIX for TX port
Provides switch conguration of Force /Auto transfer mode for FX port
Extends ber distance up to 0.55km
Easy-to-view LED indicators provide status to monitor network activity easily
Specifications:
Standards
Basic Function
Wave Length
Interface
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
Full Duplex Flow Control (IEEE 802.3x)
Extends ber distance up to 0.55km using 50/125um ber, 0.22km using 62.5/125um
ber
850nm
1 1000Mbps SC port
1 1000Mbps RJ45 port (Auto MDI/MDIX)
1000BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-FX: Multi-mode Fiber
PWR, LINK, RX
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Power Supply
Page 3
External Power Adapter, 9V/0.6A or 5V/1A
www.tp-link.com
MC210CS
The MC210CS media converter converts 1000BASE-LX/LH ber to 1000Base-T copper media or vice versa. It is
designed for use with 1310nm single-mode ber cable utilizing the SC-Type connector, transmitting data up
to 15 kilometers. What's more, MC210CS can work as a stand alone device (no chassis required) or with
TP-LINK’s 19” system chassis.
Features:
Works at 1000Mbps in Full-Duplex mode for both TX port and FX port
Supports Auto MDI/MDIX for TX port
Provides switch conguration of Force /Auto transfer mode for FX port
Extends ber distance up to 15km
Easy-to-view LED indicators provide status to monitor network activity easily
Specifications:
Standards
Basic Function
Wave Length
Interface
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
Power Supply
IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
Full Duplex Flow Control (IEEE 802.3x)
Extends ber distance up to 15km
1310nm
1 1000Mbps SC port
1 1000Mbps RJ45 port (Auto MDI/MDIX)
1000BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-FX: Multi-mode Fiber
PWR, LINK, RX
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
External Power Adapter, 9V/0.6A or 5V/1A
Page 4
www.tp-link.com
MC220L
The MC220L converts 1000BASE-SX/LX/LH ber to 1000Base-T copper media or vice versa. It is designed for
use with 850nm multi-mode/1310nm single-mode/WDM ber cable utilizing the LC-Type connector,
transmitting data up to 0.55 kilometers or 10 kilometers. What's more, MC220L can work as a stand alone
device (no chassis required) or with TP-LINK’s 19” system chassis.
Features:
Works at 1000Mbps in Full-Duplex mode for both TX port and FX port
Supports Auto MDI/MDIX for TX port
Provides switch conguration of Force /Auto transfer mode for FX port
FX port support hot-swappable
Extends ber distance up to 0.55 km for multi-mode ber and 10 km for single-mode ber
Easy-to-view LED indicators provide status to monitor network activity easily
Specifications:
Standards
Basic Function
Wave Length
Interface
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
Power Supply
IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
Full Duplex Flow Control (IEEE 802.3x)
Extends ber distance up to 10km
Depend on the used SFP module
1 SFP port
1 1000Mbps RJ45 port (Auto MDI/MDIX)
1000BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-FX: Multi-mode Fiber
PWR, LINK, RX
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
External Power Adapter, 9V/0.6A or 5V/1A
Page 5
www.tp-link.com
MC100CM
The MC100CM media converter converts 100BASE-FX ber to 100Base-TX copper media or vice versa. It is
designed for use with 1310nm multi-mode ber cable utilizing the SC-Type connector, transmitting data up to
2 kilometers. What's more, MC100CM can work as a stand alone device (no chassis required)or with TP-LINK’s
19’’ system chassis, and is equipped with Link Fault Pass Through which minimizes the loss caused by link
failure.
Features:
Auto-negotiation of 10/100Mbps and Auto MDI/MDIX for TX port
Provide switch conguration of Half-Duplex / Full-Duplex transfer mode for TX port
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
Extend ber distance up to 2km
Easy-to-view LED indicators provide status to monitor network activity easily
Specifications:
Standards
Basic Function
Interface
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
IEEE 802.3u, IEEE 802.3x
Half/Full-Duplex transfer mode for TX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends ber distance up to 2km
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
1 100Mbps SC port
1 100Mbps RJ45 port (Auto MDI/MDIX)
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-FX: Multi-mode Fiber
PWR, SPD, LFP, FDX/Col, Link/Act
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Power Supply
Page 6
External Power Adapter, 9V/0.6A or 5V/1A
www.tp-link.com
MC110CS
The MC110CS is a media converter designed to convert 100BASE-FX ber to 100Base-TX copper media or vice
versa. It’s designed for use with single-mode ber cable utilizing the SC-Type connector, transmitting data up
to 20 kilometers. What’s more, MC110CS can work as a stand alone device (no chassis required) or with
TP-LINK’s 19’’ system chassis, and is equipped with Link Fault Pass Through which minimizes the loss caused by
link failure.
Features:
Auto negotiation of 10/100Mbps and Auto MDI/MDIX for TX port
Provide switch conguration of Half-Duplex / Full-Duplex transfer mode for TX port
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
Extend ber distance up to 20km
Easy-to-view LED indicators provide status to monitor network activity easily
Specifications:
Standards
Basic Function
Interface
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
IEEE 802.3u, IEEE 802.3x
Half/Full-Duplex transfer mode for TX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends ber distance up to 20km
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
1 100Mbps SC port
1 100Mbps RJ45 port (Auto MDI/MDIX)
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-FX: Single-mode Fiber
PWR, SPD, LFP, FDX/Col, Link/Act
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Power Supply
Page 7
External Power Adapter, 9V/0.6A or 5V/1A
www.tp-link.com
MC111CS
The MC111CS is a media converter designed to convert 100BASE-FX ber to 100Base-TX copper media or vice
versa. It’s designed for use with single-mode ber cable utilizing the SC-Type connector. Adopting WDM
technology, MC111CS takes only one ber to transmit and receive data, which saves you half of the cabling
cost. On this ber, it works at 1550nm on transferring data and at 1310nm on receiving data. So the other end
device cooperating with the MC111CS will work at 1310nm on transferring data and at 1550nm on receiving
data. Another of TP-LINK’s media converters, the MC112CS is just one example of potential devices with which
to cooperate with the MC111CS.Moreover, MC111CS can work as a stand alone device (no chassis required) or
with TP-LINK’s 19’’ system chassis, and is equipped with Link Fault Pass Through which minimizes the loss
caused by link failure.
Features:
Auto negotiation of 10/100Mbps and Auto MDI/MDIX for TX port
Provide switch conguration of Half-Duplex / Full-Duplex transfer mode for TX port
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
Adopts WDM technology, transmitting and receiving data on one single ber
Extend ber distance up to 20km
Easy-to-view LED indicators provide status to monitor network activity easily
Specifications:
Standards
Basic Function
Interface
Wave Length
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
Power Supply
IEEE 802.3u, IEEE 802.3x
Half/Full-Duplex transfer mode for TX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends ber distance up to 20km
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
1 100Mbps SC port
1 100Mbps RJ45 port (Auto MDI/MDIX)
TX: 1550nm
RX: 1310nm
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-FX: Single-mode Fiber
PWR, SPD, LFP, FDX/Col, Link/Act
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
External Power Adapter, 9V/0.6A or 5V/1A
Page 8
www.tp-link.com
MC112CS
The MC112CS is a media converter designed to convert 100BASE-FX ber to 100Base-TX copper media or vice
versa. It’s designed for use with single-mode ber cable utilizing the SC-Type connector. Adopting WDM
technology, MC112CS takes only one ber to transmit and receive data, which saves you half of the cabling
cost. On this ber, it works at 1310nm on transferring data and at 1550nm on receiving data. So the other end
device cooperating with the MC112CS will work at 1550nm on transferring data and at 1310nm on receiving
data. Another of TP-LINK’s media converters, the MC111CS is just one example of potential devices with which
to cooperate with the MC111CS. Moreover, MC112CS can work as a stand alone device (no chassis required) or
with TP-LINK’s 19’’ system chassis, and is equipped with Link Fault Pass Through which minimizes the loss
caused by link failure.
Features:
Auto negotiation of 10/100Mbps and Auto MDI/MDIX for TX port
Provide switch conguration of Half-Duplex / Full-Duplex transfer mode for TX port
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
Adopts WDM technology, transmitting and receiving data on one single ber
Extend ber distance up to 20km
Easy-to-view LED indicators provide status to monitor network activity easily
Specifications:
Standards
Basic Function
Interface
Wave Length
Network Media
LED Indicators
Certications
Dimensions (W x D x H)
Environment
Power Supply
IEEE 802.3u, IEEE 802.3x
Half/Full-Duplex transfer mode for TX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends ber distance up to 20km
Link Fault Pass Through and Far End Fault minimize the loss caused by link failure timely
1 100Mbps SC port
1 100Mbps RJ45 port (Auto MDI/MDIX)
TX: 1310nm
RX: 1550nm
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-T: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-FX: Single-mode Fiber
PWR, SPD, LFP, FDX/Col, Link/Act
FCC, CE
3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm)
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
External Power Adapter, 9V/0.6A or 5V/1A
Page 9
www.tp-link.com
More information of the 100Mbps series Media Converter
Type Connector Transmission Distance Transmission Media Wave Length
MC100CM
MC110CS
MC111CS
MC112CS
RJ45--SC
RJ45--SC
RJ45--SC
RJ45--SC
2km
20km
20km
20km
Multi-mode Fiber,TP
Single-mode Fiber,TP
Single-mode Fiber,TP
Single-mode Fiber,TP
1310nm
1310nm
1550nmTX/1310nmRX
1310nmTX/1550nmRX
More information of the 1000Mbps series Media Converter
Model NO. Interface Transmission Distance Transmission Media Wave Length
MC200CM
MC210CS
MC220L
RJ45--SC
RJ45--SC
RJ45--SFP
0.55km(50/125um),
0.22km(62.5/125um)
15km
0.55km /10km
Multi-mode Fiber,TP
Single-mode Fiber,TP
Multi/Single-mode Fiber, TP
850nm
1310nm
Depend on used SFP module
Specifications are subject to change without notice. is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are trademarks or registered
trademarks of their respective holders. No part of the specificationsmay be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd. Copyright © 2012 TP-LINK Technologies Co., Ltd. All rights reserved.
Page 10
www.tp-link.com
Loading...
