TP-Link M7650 User Manual
User Guide
LTE-Advanced Mobile Wi-Fi
M7450 / M7650
REV1.0.1 1910012213
Contents
About This Guide |
..........................................................................................................1 |
Chapter 1. Get to Know About Your Mobile Wi-Fi . . . . . . . . . . . . . . . . . . . . . 2
1. 1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 1. 2. Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1. 2. 1.The Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1. 2. 2.The Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Chapter 2. Set Up Internet Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2. 1. Install the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 2. 1. 1.Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 2. 1. 2.Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2. 2. Connect to the Mobile Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 3. Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3. 1. |
Via Phone Login Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
17 |
3. 2. |
Via PC Login Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
17 |
3. 3. |
Via tpMiFi App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
18 |
Chapter 4. Manage Your Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4. 1. Track Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 4. 1. 1.Check Data Usage on Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 4. 1. 2.Check Data Usage on the Web Management Page . . . . . . . . . . . . . . . . . . . 21 4. 1. 3.Check Data Usage via SMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 4. 1. 4.Revise Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4. 2. Limit Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 4. 2. 1.Limit Data Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 4. 2. 2.Limit Monthly Data Usage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4. 3. Set up Free Data Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 4. 4. Enable Mobile Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 4. 5. Enable Data Roaming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Chapter 5. Secure Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5. 1. Secure Wireless Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5. 2. Block Unwelcome Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5. 3. Lock SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Chapter 6. Share Files on SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6. 1. Access via Wi-Fi Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 6. 2. Access via USB Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Chapter 7. Customize Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7. 1. Specify Network Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7. 2. Specify Network Band. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7. 3. Configure Dial-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7. 3. 1.Configure Dial-up Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7. 3. 2.Configure Network Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7. 4. Configure DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Chapter 8. NAT Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8. 1. Translate Address and Port by ALG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 8. 2. Share Local Resources on the Internet by Virtual Servers . . . . . . . . . . . . . . . . . . . 52 8. 3. Open Ports Dynamically by Port Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 8. 4. Make Applications Free from Port Restriction by DMZ. . . . . . . . . . . . . . . . . . . . . . . 54 8. 5. Make Xbox Online Games Run Smoothly by UPnP. . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Chapter 9. Manage Your Mobile Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9. 1. Save the Mobile Wi-Fi’s Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 9. 2. Change Login Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 9. 3. Set Up System Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 9. 4. Restore Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 9. 5. Update the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 9. 6. Update ISP Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 9. 7. USSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 9. 8. System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
FAQ................................................................................................................................. |
67 |
About This Guide
This guide is a complement of Quick Installation Guide. The Quick Installation Guide provides instructions for quick internet setup, while this guide contains details of each function and demonstrates how to configure them.
When using this guide, please notice that features of the Mobile Wi-Fi may vary slightly depending on the model, the software version you have, your location, system language, and internet service provider. All screenshots, images, parameters and descriptions documented in this guide are used for demonstration only.
Conventions
In this guide the following conventions are used:
Convention |
Description |
|
Underlined |
Underlined words or phrases are hyperlinks. You can click to redirect to a website or a |
|
specific section. |
||
|
||
Teal |
Contents to be emphasized and texts on the web page are in teal, including the menus, |
|
items, buttons and so on. |
||
|
The menu structures to show the path to load the corresponding page. For example,
>Advanced > Wireless > Black List means the Black List page is under the Wireless menu that is located in the Advanced tab.
|
|
|
Note: |
Ignoring this type of note might result in a malfunction or damage to the device. |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
Tips: |
Indicates important information that helps you make better use of your device. |
|
|
|
|
||
|
|
|
|
||
More Info
The latest software, management app and utility are available at Download Center at www.tp-link.com/support.
The Quick Installation Guide can be found in the same place you found this guide or inside the package of the Mobile Wi-Fi.
Specifications can be found on the product page at http://www.tp-link.com.
A Technical Support Forum is provided for you to discuss our products at http://forum.tp-link.com.
Our Technical Support contact information can be found at Contact Technical Support page at www.tp-link.com/support.
1
Chapter 1
Get to Know About Your Mobile Wi-Fi
This chapter introduces what the Mobile Wi-Fi can do and its appearance. It includes the following sections:
•Product Overview
•Physical Description
Chapter 1 |
Get to Know About Your Mobile Wi-Fi |
1. 1. Product Overview
The Faster Connections, The More You Can Do
Just insert a 4G SIM card to create your reliable personal Wi-Fi hotspot and share instant 4G/3G connectivity with friends. The Mobile Wi-Fi, supporting the latest generation 4G LTE network, can reach a faster download speed so that users can enjoy HD movies without interruption, download files in seconds, and hold a video chat without dropouts.
Artful Little Gadget and Built-in Battery for Life on the Go
The TP-Link Mobile Wi-Fi features a compact, elegant design and rechargeable powerful battery very suitable for travel, business trips and outdoor activities. With added flexibility, the device can be charged via a micro USB cable connected to an adapter, laptop or portable charger for endless hours of 4G sharing.
Easy Management with the tpMiFi App
With the tpMiFi App, you can conveniently access and manage the Mobile Wi-Fi right on your iOS/Android devices. The tpMiFi app allows you to set data limits, control Wi-Fi access, send messages, and share media files to/from a removable micro SD card.
3
Chapter 1 |
Get to Know About Your Mobile Wi-Fi |
1. 2. Physical Description
1. 2. 1. The Exterior
560
5.
Carrier Name
Menu Button Power Button
Button Explanation
Button |
Description |
• Press to enter the Menu Screen from the Home Screen. Menu Button • Press to switch between icons or options.
•Press to light on the screen.
•Press and hold to power on/off the Mobile Wi-Fi.
Power Button • Press to turn on/off the screen display.
• Press to select an icon.
4
Chapter 1 Get to Know About Your Mobile Wi-Fi
Screen Display
Home Screen |
Displayed Item |
Indication |
||||||||
|
|
|
|
|
|
|
|
|
|
Indicates the signal strength of the current network. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4G/3G/2G |
Indicates successful network connection and the current network |
|||||
|
|
|
|
type: 4G, 3G or 2G. |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
R |
Indicates you are in roaming service. |
||||
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
560 |
|
2 |
|
|
Indicates that there is un-read message(s) and the number of them. |
||||
|
5. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Displays the Wi-Fi status and the number of connected wireless |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Carrier Name |
|
2 |
|
|
devices. |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
100% |
|
|
|
Displays the remaining battery power. |
||
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
560MB |
Indicates the total data used. It will be cleared after the Mobile Wi-Fi |
|||||
|
|
|
|
is reset. |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5.0 M/S |
Indicates the current download speed of the data transmission. |
|||||
|
|
|
|
|
|
|
|
|
|
|
Menu Screen |
Menu |
Description |
|||
|
|
|
|
Home |
Displays the information of data, signal strength, battery life and so |
|
|
|
|
on. |
|
|
|
|
|
Device Info |
Displays the SSID (network name), password and login address of |
|
|
|
|
the Mobile Wi-Fi. |
|
|
|
|
|
|
If enabled, the Wi-Fi will be shut down if no wireless devices are |
|
|
|
|
Power Saving |
connected to the Mobile Wi-Fi for 10 minutes; and the Wi-Fi range |
|
|
|
|
will be midium. For more information, please refer to Save the Mobile |
|
|
|
|
|
||
|
|
|
|
|
Wi-Fi’s Power. |
|
|
Device Info |
|
|
To enable the WPS function. Enable this function and immediately |
|
|
|
|
WPS |
press the WPS button on your wireles device. A success message |
|
|
|
|
|
will appear on the screen, indicating successful WPS connection. |
|
|
|
|
Wi-Fi Band |
To change the Wi-Fi band to 2.4GHz or 5GHz as needed. |
|
|
|
|
Network Mode |
To change the network mode: 4G preferred, 4G only or 3G only as |
|
|
|
|
needed. |
|
|
|
|
|
|
To enable or disable the Data Roaming function as needed. We |
|
|
|
|
Data Roaming |
recommend you to enable it when you are out of the mobile carrier |
|
|
|
|
|
service area. |
|
|
|
|
App Download |
Scan the QR code to download the tpMiFi app to manage your |
|
|
|
|
Mobile Wi-Fi. |
|
5
Chapter 1 |
Get to Know About Your Mobile Wi-Fi |
1. 2. 2. The Interior
Micro SD Card Slot
Micro SIM Card Slot
Reset Butt |
Micro USB Input Port |
Item |
Description |
|
Micro SIM Card Slot |
Insert a SIM card into the slot. A nano SIM card must be converted using the provided |
|
SIM card tray. |
||
|
||
Micro SD Card Slot |
Slide and lift up the slot cover, insert a SD card and slide the cover back to lock. The |
|
inserted SD card can be used for storage and media sharing. |
||
|
||
Micro USB Input Port |
Plug in the USB cable to this port to charge your Mobile Wi-Fi or share contents in the |
|
SD card. |
||
|
||
Reset Button |
With the Mobile Wi-Fi powered on, use a pin to press and hold this button until “Power |
|
Off” appears on the screen to reset the Mobile Wi-Fi. |
||
|
6
Chapter 2
Set Up Internet
Connection
This chapter introduces how to install the hardware and set up the internet connection of your Mobile Wi-Fi.
It includes the following sections:
•Install the Hardware
•Connect to the Mobile Wi-Fi
Chapter 2 |
Set Up Internet Connection |
2. 1. Install the Hardware
2. 1. 1. Installation
1. Remove the cover and the battery.
2.Slide and lift up the SIM card slot cover and insert the SIM card. And then slide to lock the SIM card slot.
SIM
Note:
•A nano SIM card must be converted using the provided SIM card tray.
•The SIM card is not provided by TP-Link.
3.(Optional) Slide and lift up the SD card slot cover and insert a micro SD card. The inserted SD card can be used for storage and media sharing.
Note:
•To learn how to store and share files via the SD card, please refer to Share Files on SD Card.
•The SD card is not provided by TP-Link.
4. Fit the battery into the slot.
8
Chapter 2 |
Set Up Internet Connection |
2
5. Replace the cover.
1
2. 1. 2. Power On
Press and hold
(power button) until the welcome screen appears.
Note:
To power off, press and hold
(power button) until Power Off appears on the screen.
9
Chapter 2 |
Set Up Internet Connection |
2. 2. Connect to the Mobile Wi-Fi
1. After the Mobile Wi-Fi is powered on, you will see the following screen.
|
|
|
|
4G |
100% |
|
0MB
0.0 K/S
Carrier Name
Note: If other messages appear on the screen, please refer to Q2 of FAQ.
2. Follow the instructions to connect to the Mobile Wi-Fi. Here are two methods.
Note: If you use a computer to connect to the Mobile Wi-Fi, please set your computer’s setting to obtain an IP address automatically.
Method One: Using SSID and Wireless Password
a.Find the SSID (network name) and wireless password from the screen or on the product label.
•On the screen:
1 ) Press |
|
|
(menu button) to enter the Menu page and switch to the Device |
|
|||
|
|
||
Info page. |
|
||
Device Info
2 ) Press
(power button) to enter the Device Info page.
10
Chapter 2 |
Set Up Internet Connection |
Device
Info
SSID: TP-Link_XXXX
Password: XXXXXXXX
Device Info
Login Address:
http://tplinkmifi.net
•On the product label:
1 ) Remove the cover and the battery of the Mobile Wi-Fi.
2 ) Take down the SSID and Wireless Password printed on the product label.
MAC: XX-XX-XX-XX-XX-XX
IMEI: XXXXXXXXXXXXXXX
SSID:
TP-Link_XXXX
Wireless Password:
XXXXXXXX
b.Go to Wi-Fi settings of your smart device or click the network icon of your computer, then select the SSID and enter the Wireless Password that you found to join the Wi-Fi.
Smart Device |
Computer |
< Settings |
Wi-Fi |
|
|
Wi-Fi
CHOOSE A NETWORK...
TP-Link_XXXX
Other...
Connections are available
OR |
Wireless Network Connection |
|
TP-LINK_XXXX |
|
|
|
Connect |
|
|
Connect automatically |
11
Chapter 2 |
Set Up Internet Connection |
Method Two: Via WPS (Wi-Fi Protected Setup)
If you have a WPS-supported device (such as Android phones or tablets), you can connect to the Mobile Wi-Fi more easily using WPS button or PIN.
Note:
To use the WPS function, please make sure the SSID Broadcast function and wireless function are enabled.
•Via the WPS button
1) Press
(menu button) to enter the menu page and switch to the WPS menu.
4G R |
1 2 100% |
WPS
2 ) Press
(power button) to enter the WPS page.
WPS
3 ) Press
(menu button) and
(power button) together to enable the WPS function, and then the Mobile Wi-Fi starts to scan WPS-supported devices.
12
Chapter 2 |
Set Up Internet Connection |
WPS
Connecting
4 ) On your WPS-supported device, go to Settings, turn on Wi-Fi, and click Connect via WPS within 2 minutes.
Note:
The interfaces of the WPS function may vary in different wireless devices.
5 ) The status of WPS will change from Connecting to Succeeded indicating your WPS-supported device is connected to the Mobile Wi-Fi.
WPS
Succeeded
13
Chapter 2 |
Set Up Internet Connection |
•Via the PIN
1) On your WPS-supported device, go to Settings, turn on Wi-Fi, and go to the WPS page to get the PIN.
Note:
The interfaces of the PIN verification may vary in different wireless devices.
2 ) Connect the Mobile Wi-Fi to your computer with a USB cable, visit http://tplinkmifi.net, and log in with the default password: admin.
14
Chapter 2 |
Set Up Internet Connection |
3 ) Go to Device > Advanced > WPS, check the PIN box and enter the PIN of your WPS-supported device in the field.
4 ) Click Start to start the WPS process, and the Current Status will change from Idle to Succeed indicating your WPS-supported device is connected to the Mobile Wi-Fi.
15
Chapter 3
Login
This chapter introduces 3 methods to log in to the web management page. Demonstrations in this guide use the phone web management interfaces, while some use the computer as those functions are only available on the computer’s web management page.
Before login, make sure your device is connected to the Mobile Wi-Fi’s SSID. If not, refer to Chapter 2 for detailed instructions.
This chapter includes the following sections:
•Via Phone Login Entry
•Via PC Login Entry
•Via tpMiFi App
Chapter 3 |
Login |
3. 1. Via Phone Login Entry
1.On your smart phone, visit http://tplinkmifi.net, and log in with the default password: admin.
2. Create a new login password for security purposes and click Done.
3. Use the password you just created for future logins.
3. 2. Via PC Login Entry
On the PC web management interfaces, you can enjoy more features, such as DHCP settings.
17
Chapter 3 |
Login |
1.Visit http://tplinkmifi.net from the PC entry, and log in with the password: admin.
2.Go to Wizard, create a new login password for security purposes and click Confirm.
3. Use the password you just created for future logins.
3. 3. Via tpMiFi App
1.Search “tpMiFi“ at the App Store or Google Play Store or simply scan the QR code to download the tpMifi app.
18
Chapter 3 |
Login |
2.Connect your device to the Mobile Wi-Fi.
3.Launch the tpMiFi app, create a new password for security purposes and click Log In.
4. Use the password you just created for future logins.
19
Chapter 4
Manage Your Data Usage
This chapter explains how to manage the data usage of your Mobile Wi-Fi. It includes the following sections:
•Track Data Usage
•Limit Data Usage
•Setup Free Data Period
•Enable Mobile Data
•Enable Data Roaming
Loading...
