Page 1

E439BBD_EN.book Page 2 Wednesday, May 31, 2006 4:01 PM

Introduction

Precautions

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

WARNING

THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note is located on the rear of the cabinet.

Laser Safety

This unit employs a laser. Only a qualified service personnel should remove the cover or attempt to service this unit, due to the possibility of eye injury.

CAUTION: USE OF CONTROLS OR

ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER

RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK

MECHANISM.

Caution

1. Do not attempt to open the cabinet. There are no

2. Slots and openings in the cabinet at the sides and

3. Keep the unit away from radiators and other heat

4. Avoid use near strong magnetic fields.

5. Do not push objects of any kind into the unit

6. Do not spill liquid on the unit. If liquid is spilled

Power Supply

The power supply is connected and the unit is live when the mains cable is plugged into a 220–240 V , 50 Hz AC outlet. To operate the unit, press

[ ON / STANDBY].

WARNING: LIVE PARTS INSIDE.

DO NOT REMOVE ANY SCREWS.

7. Do not stand the unit vertically. Use the unit in a

8. This product is in Stand-by mode when turned off

9. Do not place any combustible objects on the

10. Before moving the unit, be sure to remove any

11. Disconnect the mains plug to shut off when find

12. The mains plug shall remain readily operable.

13. Read both manual instructions to ensure correct

14. Keep the distances 20 cm around apparatus of

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

parts inside you can service. Refer all servicing to qualified service personnel.

underneath are provided for ventilation. To ensure reliable operation and to protect the unit from overheating, these openings must not be blocked or covered. Avoid installation in enclosed spaces such as bookcases unless suitable ventilation is provided.

sources.

through the cabinet slots or openings as they could touch electrically live parts or short circuit parts resulting in a fire or electric shock.

and enters the unit, consult qualified service personnel.

horizontal (flat) position only.

while the mains cable is connected.

device (candles, etc.).

discs and unplug the mains cable from the AC outlet.

troubles or not in use.

and safe installation and interconnection of the unit in multimedia systems.

ventilation openings.

Page 2

E439BBD_EN.book Page 3 Wednesday, May 31, 2006 4:01 PM

Declaration of Conformity

This product complies with the requirement of the directives EMC-Directive: 89 / 336 / EEC Low Voltage Directive: 73 / 23 / EEC CE Marking: 93 / 68 / EEC

We declare that the following product:

HDD & DVD / Video Cassette Recorder Model RD-XV45KB Trade Name: TOSHIBA

is in compliance with following Regulations.

EN55013: 2001+A1:2003, EN55020: 2002+A1:2003, EN61000-3-2: 2000, EN61000-3-3: 1995 + A1: 2001 EN60065: 2002 EN60825-1 Edition 1.2: 2001

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

This product consists of materials which can be recycled and reused if disassembled by a specialised company. Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

It is important that the colour of the replacement fuse cover corresponds with the rating marking on the base of the plug. If the plug has to be changed because it is not suitable for your socket, or becomes damaged, it should be cut off and an appropriate plug fitted following the wiring instructions below. The plug removed must be disposed of safely as insertion into a 13A socket is likely to cause an electrical hazard. For your own safety read the following instructions carefully before attempting to connect this unit to mains. The wires in this mains lead are coloured in accordance with the following code:

BLUE=NEUTRAL, BROWN=LIVE

Important

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. No connection is to be made to the earth terminal of the plug. If a 13 Amp (BS 1363) Plug is used, a 3 Amp Fuse must be fitted, or if any other type of Plug is used a 3 or 5 Amp Fuse must be fitted, either in the Plug or Adaptor, or on the Distribution Board.

Mains Supply: 220 - 240V 50 Hz - AC only

Do not make any connection to the larger pin marked with the letter “E” or by the symbol or coloured green or green and yellow.

Introduction Connections Basic Setup Playback

Recording

Make your contribution to the environment!!!

• Exhausted batteries do not belong in the dustbin.

• You can dispose of them at a collection point for exhausted batteries or special waste.

• Contact your council for details.

For Customer Use: Carefully read the Model No. and Serial No. located at the back of the unit and enter the information below. Retain this information for future reference. Model No. _____________________ Serial No. _____________________

Connection to Power

Before Switching on make sure that the voltage of your electricity supply is the same as that indicated on the rating plate.

Mains Cord

This appliance may be fitted with a non-rewireable plug. If it is necessary to change the fuse in a nonrewireable plug the fuse cover must be refitted. If the fuse cover is lost or damaged, the plug must not be used until a replacement available from the appliance manufacturer is obtained.

FUSE

BROWN

BLUE

(Neutral)

OUTER SHEATH OF THE WIRE

(Live)

CORD GRIP

Installation Location

For safety and optimum performance of this unit:

• Install the unit in a horizontal and stable position.

• Do not place anything directly on top of the unit.

• Do not place the unit directly on top of the TV.

• Shield the unit from direct sunlight and keep away from sources of intense heat. Avoid dusty or humid locations. Avoid locations with insufficient ventilation for suitable heat dissipation. Do not block the ventilation holes on the sides of the unit. Avoid locations subject to strong vibration or strong magnetic fields.

Editing

Function Setup

VCR Functions Others

Page 3

E439BBD_EN.book Page 4 Wednesday, May 31, 2006 4:01 PM

Avoid the Hazards of Electrical Shock and Fire

• Do not handle the mains cable with wet hands.

• Do not pull on the mains cable to disconnect it from AC outlet. Grasp it by the plug.

• If the water is spilled onto the unit accidentally, unplug the mains cable immediately and take the unit to an Authorized Service Centre for servicing.

Moisture Condensation Warning

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, after heating a cold room, or under conditions of high humidity. Do not use the unit for at least 2 hours to allow the inside to dry.

About Copyright

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

“Dolby® Digital Stereo Creator enables consumers to create stereo DVD-Videos with stunning Dolby Digital sound tracks at home. The technology, when utilized instead of PCM recording, also saves recordable disc space, allowing for higher video resolution or extended recording time on each DVD. DVDs mastered using Dolby Digital Stereo Creator will play back on all DVD-Video players.” Note: This is true when the players are compatible

with actual recordable DVD discs.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.

Page 4

E439BBD_EN.book Page 5 Wednesday, May 31, 2006 4:01 PM

Accessories Supplied

• Remote control with two R6 (AA) batteries

OPEN/

TIMER

INPUT

PROG.

SELECT

.@/: ABC DEF

123

PROG.

GHI JKL MNO

456

PQRS TUV

WXYZ

SPACE

SET UP

AUDIO CLEAR

SYSTEM

MENU/LIST

TOP MENU

ENTER

DISPLAY RETURN

VARIABLE

REPLAY

SKIP

REV FWDPLAY

SLOW

PAUSESTOP

REC MONITOR

VCR HDD DVD

REC MODE

REC/OTR REC/OTR REC/OTR

III

DUBBING MODE

SEARCH MODE

•RF cable

Introduction Connections Basic Setup Playback

HDD HDD HANDLING

• HDD is a precision apparatus that is susceptible to vibration, strong impact or dirt. Depending on the installation environment or handling, the unit may become partially damaged or in the worst case, recording or replaying may not be available. Especially while the HDD is in motion, do not subject it to vibration or strong impact or pull out the power plug. And if a power failure occurs, the content of the recording / replaying programme may be lost.

HDD MOVING THE UNIT

• HDD rotates at high speed when in operation. Be sure that rotation has stopped and then move the unit without subjecting it to strong impact or vibration.

• Owner’s Manual

Owner's Manual

•Quick Guide

• Registration card

Maintenance

SERVICING

• Please refer to relevant topics on the “Troubleshooting” on pages 92 to 96 before returning the product.

• If this unit becomes inoperative, do not try to correct the problem by yourself. There are no userserviceable parts inside. Turn the unit off, unplug the mains cable, and consult your dealer or an Authorized Service Centre.

CLEANING THE CABINET

• Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasive.

DVD CLEANING DISCS

• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the centre out. Do not wipe in a circular motion.

• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analogue records.

DVD CLEANING THE DISC LENS

• If this unit still does not perform properly although you refer to the relevant sections and to “Troubleshooting” in this Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Centre for inspection and cleaning of the laser optical pickup unit.

DVD DISC HANDLING

• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

• Always store the disc in its protective case when it is not used.

VCR AUTO HEAD CLEANING

• Automatically cleans video heads as you insert or remove a videotape, so that you can see a clear picture.

• Playback picture may become blurred or interrupted while the TV programme reception is clear. Dirt accumulated on the video heads after a long extended period of use, or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during playback, the video heads in the unit may need to be cleaned.

1. Please visit your local Audio / Video store and

purchase a good quality VHS Video Head Cleaner.

2. If a Video Head Cleaner does not solve the

problem, please consult your dealer or an Authorized Service Centre.

Note

• Remember to read the instructions along with the video head cleaner before use.

• Clean video heads only when problems occur.

Recording

Editing

Function Setup

VCR Functions Others

Page 5

E439BBD_EN.book Page 6 Wednesday, May 31, 2006 4:01 PM

Table of contents

Introduction ............................................ 2

Precautions ........................................................... 2

Features ................................................................ 7

Choosing a disc..................................................... 9

Guide to the Owner’s Manual.............................. 14

Functional Overview............................................ 15

Installing batteries in the remote control ............. 19

HDD / DVD / VCR modes switching.................... 19

Guide to Display Information............................... 20

Guide to Setup Menu .......................................... 20

Front Panel Display Guide .................................. 21

Connections ......................................... 22

Connections ........................................................ 22

Basic Setup........................................... 24

For the first time use ........................................... 24

Channel Setting................................................... 24

Setting the clock.................................................. 26

Selecting the TV aspect ratio .............................. 27

Recording ............................................. 28

Information on supported media ......................... 28

Formatting a disc................................................. 31

Selecting the sound mode................................... 33

Basic Recording .................................................. 34

One-touch Timer Recording (OTR)..................... 35

Timer Recording.................................................. 36

Satellite Link........................................................ 38

Information on dubbing ....................................... 40

Settings for external equipment .......................... 48

Dubbing from the external devices...................... 48

Setting disc protection......................................... 49

Finalising a disc................................................... 49

Editing ................................................... 69

Disc editing .......................................................... 69

Deleting titles ....................................................... 70

Protecting / Undo protecting titles........................ 72

Editing title names ...............................................72

Deleting a part of a title........................................ 73

Dividing a title ......................................................75

Combining titles ................................................... 76

Moving titles......................................................... 77

Chapter Marker.................................................... 78

Adding titles to a Playlist...................................... 80

Function Setup .....................................81

Tour of the Setup Menus ..................................... 81

Playback Setting.................................................. 83

Display Setting..................................................... 87

Reset to factory default........................................ 88

VCR Functions......................................89

Playback .............................................................. 89

Recording and One-touch Timer Recording

(OTR)................................................................... 89

Search .................................................................90

Other operations.................................................. 91

Hi-Fi Stereo Sound System ................................. 91

Others .................................................... 92

Troubleshooting................................................... 92

Language code.................................................... 97

Glossary .............................................................. 98

Specifications ...................................................... 99

Playback ............................................... 51

Information on playback ...................................... 51

Basic playback .................................................... 52

PBC function for Video CDs................................ 59

Special playback ................................................. 60

Repeat / Random / Programme playback /

Slide Show .......................................................... 63

Search................................................................. 65

Selecting the format of audio and video.............. 67

Page 6

E439BBD_EN.book Page 7 Wednesday, May 31, 2006 4:01 PM

Features

The following features are available with this unit.

Recording

This unit allows you to record on the HDD, a DVD-RW disc (rewritable) and a DVD-R disc (one-time write) as well as a videotape. You can choose any one for your convenience.

HDD DVD VCR

One-touch Timer Recording (OTR)

Page 35 (HDD / DVD) or Page 90 (VCR)]

[ This feature allows you to start the recording right away with just one-touch. And each press of [REC / OTR I] (HDD / DVD / VCR) increases the recording time by 30 minutes.

Left channel stereo recording

The unit can record monaural sound from the Left channel as pseudo stereo sound (same Left and Right channels) automatically. (AV3 only)

HDD DVD

Timer Programming up to 32 programmes

[ Pages 36-38] You can programme the unit to record up to 32 programmes within a one-month period. Daily or weekly repeating programmes can also be programmed.

Recording Monitor [ Page 32] You can check how the actual recording picture and the sound will be in the selected Rec Mode before attempting to record.

Automatic Chapter Marker [ Page 32] Each recorded title is automatically marked with chapter marks.

Automatic Playlist Making (VR mode discs and HDD only)

[ Page 70] Playlists are automatically copied from the Original List, so that you can edit titles.

HDD

160 GB Hard Disc [ Pages 28-30]

This unit is equipped with a 160 GB hard disc which allows you to record up to 340 hours (with SEP mode). The HDD operates just like a VR mode DVD-RW disc. Most of the functions which are available with a VR mode DVD-RW disc can be performed on the HDD too.

PDC [ Page 37] This system assures that the TV programme you wish to record using timer recording will be recorded exactly from beginning to end even if the actual broadcasting time differs.

DVD

Automatic DVD Menu Making (Video mode only)

[ Page 50] DVD Menus are made automatically when a Video mode disc is finalised.

Automatic Finalise (Video mode only)

[ Page 50] You can set the disc to be finalised automatically when a dubbing or One Touch Dubbing is completed. Relay Recording [ Page 36] During Timer Recording to a DVD, if the disc runs out of the space, or if there is no recordable disc in the unit, it automatically changes the recording media to the HDD.

Dubbing

With this unit, you can enjoy bi-directional dubbing with HDD, DVD or VCR.

HDD DVD

Maximum of x 20 HDD to VR mode DVD-RW disc dubbing speed (High Speed Dubbing)

[ Pages 44-46] Up to 20 times high speed dubbing from HDD to VR mode DVD-RW disc is possible if you use the compatible disc.

Just Dubbing [ Page 44] When dubbing from HDD to DVD, if you set the Rec Mode to “Auto”, this unit will automatically select the most suitable Rec Mode for the dubbing.

Playback

HDD DVD VCR

Simultaneous Playback and Recording

Page 61]

[ You can play back a title while recording.

HDD DVD

Theatre-quality Sound at Home [ Page 23]

When connecting the unit to an amplifier or a decoder that is compatible with Dolby Digital, you can experience a theatre-quality sound environment.

Variable Skip [ Page 62] You can skip forward a certain time, which is specified in the Setup Menu in advance, with one-touch while playback.

Variable Replay [ Page 62] You can skip back a certain time, which is specified in the Setup Menu in advance, with one-touch while playback.

HDD

Time Shift Playback [ Page 61]

You can play back a title being recorded from the beginning while recording continues.

Series Search [ Page 66] You can search for the group of titles made with the same Periodical Timer Recordings.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 7

E439BBD_EN.book Page 8 Wednesday, May 31, 2006 4:01 PM

Editing

HDD DVD

Deleting Titles [ Pages 70-71]

You can delete titles which you do not need anymore.

Making Playlists [ Pages 70-80] While the Original List remains as it is, you can edit titles in the Playlist.

Putting Names on Titles Setting / Clearing Chapter Marks Dividing / Combining Titles Deleting Parts of Titles Moving Titles

Protecting Titles [ Page 72] You can prevent accidental editing or title erasing.

Compatibility

DVD

Playing back discs recorded in Video mode on any regular DVD player:

Discs recorded in Video mode can be played back on regular DVD players, including computer DVD drives compatible with DVD-Video playback. You will need to finalise the discs recorded in Video mode to play back in other DVD players.

• DVD-Video Format (Video mode) is a new format for recording on DVD-RW / R discs that was approved by the DVD Forum in 2000. Adoption of this format is optional for manufactures of DVD playback devices and there are DVD-Video players, DVD-ROM drives and other DVD playback devices available that cannot play back DVD-RW / R discs recorded in the DVD-Video Format.

Page 8

E439BBD_EN.book Page 9 Wednesday, May 31, 2006 4:01 PM

Choosing a disc

When you want to play DVD or CD software or copy programmes from the HDD to a recordable DVD, load an appropriate disc into the recorder. There are many types and formats of discs. Please use the following information to select an appropriate disc.

Note

• Handle the disc according to the disc instruction manual.

• Toshiba cannot guarantee that all discs bearing the DVD or CD logos will operate as expected. Additionally, Toshiba cannot guarantee those discs recorded in this device will operate properly in other DVD players, recorders and/or personal computer drives.

For recording / playback

Disc Mark Specification Remarks

DVD-R •

4.7 GB for General Ver. 2.0 (8 cm (3 1/4 in.)) (12 cm (4 3/4 in.))

Read carefully the section “On DVD-R discs” (Page 11). Depending on the disc status or the recording equipment, playback of the disc may not be possible on this recorder.

Introduction Connections Basic Setup Playback

DVD-RW •

4.7 GB for Ver. 1.1 and 1.2 (8 cm (3 1/4 in.)) (12 cm (4 3/4 in.))

Read carefully the section “On DVD-RW discs” (Page 11). Depending on the disc status or the recording equipment, playback of the disc may not be possible on this recorder.

Using different disc types for different purposes

DVD-RW / R discs when creating your own original discs for distribution DVD-R discs are designed to comply with the global standard DVD-Video format, and can be recorded only once. DVD-R discs are convenient when you edit your original content (recorded personal events such as a wedding party) with this recorder, transfer them to the recorder and make copies to send to your friends or relatives. The discs can be played on other compatible DVD players. DVD-RW discs, which are rewritable, can be used as well.

We cannot guarantee that DVD-RW / R discs recorded on this recorder will be playable on all DVD recorders/ players. Similarly, there is no guarantee that all DVD-RW / R discs recorded on other recorders will be playable on this recorder.

Recording

Editing

Function Setup

VCR Functions Others

Page 9

E439BBD_EN.book Page 10 Wednesday, May 31, 2006 4:01 PM

For playback only

Disc Mark Specification Remarks

DVD video • 8 cm (3 1/4 in.)

Audio CD (CD-DA)

CD-R

CD-RW

12 cm (4 3/4 in.)

• Region number

• 8 cm (3 1/4 in.) 12 cm (4 3/4 in.)

• 12 cm (4 3/4 in.)

• CD-DA (audio CD) format, MP3, JPEG, DivX files

The region number of this DVD recorder is 2. The region number marked on the rear panel must correspond to a specific playable area, that is printed on your DVD video disc.

If you do not find Region 2 or ALL regions, or the disc is encoded to permit playback only in regions other than Region 2, disc playback will not be allowed by the recorder.

Depending on the disc status, playback may not be possible.

VCD (VIDEO CD)

• 12 cm (4 3/4 in.)

• Version 1.1 and 2.0

is a trademark of DVD Format/Logo Licensing Corporation.

• You cannot play discs other than those listed above.

• You cannot play non-standardized discs even if they may be labelled as above.

• You cannot play discs with specialized encoding (such as SACD discs) or the DVD audio portions of DVD Audio discs.

• Toshiba cannot guarantee that all discs bearing the DVD or CD logos will operate as expected.

This label indicates playback compatibility with DVD-RW discs recorded in VR mode (Video Recording Format).

Note

• This unit cannot play the DVD-R discs recorded in VR mode (Video Recording Format).

• Toshiba is not liable for any damage or loss caused directly or indirectly by the malfunction of this recorder, including, without limitation, any one of the following:

• Failure to record contents intended to be recorded by the consumer.

• Failure to edit contents as intended by the consumer.

• When a DVD-RW / R disc created on this recorder is used (e.g., insertion, playback, recording or editing) in another DVD player, recorder or personal computer drive.

• When a DVD-RW / R disc that is used in the manner described in the immediately preceding bullet point is used again in this recorder.

• When a DVD-RW / R disc that was recorded in another DVD recorder, or in a personal computer drive is used in this recorder.

• Some functions may not work with personal computer discs.

• Discs recorded in this recorder may not operate as expected on other DVD players, recorders or personal computer drives.

Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot guarantee that product will play every feature of every DVD bearing the DVD logo and/or every CD bearing the CD logo. As one of the creators of DVD technology, Toshiba DVD players are manufactured using the highest standards of quality, and as a result, such incompatibilities are rare.

Page 10

E439BBD_EN.book Page 11 Wednesday, May 31, 2006 4:01 PM

On DVD-R discs

Standards

• DVD-R for General Ver. 2.0 discs can be used for recording and playback.

• Discs compatible with the following recording mode speed can also be used: Ver. 2.0/2x Ver. 2.0/4x Ver. 2.0/8x Ver. 2.0/16x

• Select discs labelled “for video”, “for recording”, “120 min.” etc.

Recording conditions

• Images for which copying is prohibited or restricted (copy once or copy prohibited) cannot be recorded.

• We strongly recommend using any DVD-R 2x or 8x to assure good recording quality.

Discs that have been tested and are proven to be compatible with this recorder:

Verbatim DVD-R 8x Maxell DVD-R

On DVD-RW discs

Standards

• Discs labelled DVD-RW Ver. 1.1 or 1.2 can be used.

• Discs compatible with the following recording mode speeds can also be used: Ver. 1.1/2x Ver. 1.2/4x

• Select discs labelled “for video”, “for recording”, “120 min.” etc.

Recording conditions

• Images for which copying is prohibited (copy prohibited) cannot be recorded. If the disc is labelled as CPRM compatible, images for which copying is restricted (copy once) can be recorded in VR mode.

• We strongly recommend using any DVD-RW 4x disc to assure good recording quality.

Discs that have been tested and are proven to be compatible with this recorder:

TDK DVD-RW 2x JVC DVD-RW 4x

Marks on DVD video discs

The following are examples of marks and the meanings.

Mark Meanings

Number of audio streams recorded in

4:3

16:9 LB

16:9 PS

the disc. (2 streams such as English and Japanese in this example.)

Number of subtitle languages recorded in the disc. (2 subtitle languages are recorded in this example.)

Number of camera angles recorded in the disc. (3 camera angles are recorded in this example.)

Pictures are recorded in the standard picture shape (4:3 aspect ratio).

Pictures are recorded in the letter box picture shape (4:3 aspect ratio with horizontal black bars in the top and bottom of pictures).

Pictures are recorded in the 16:9 wide picture shape. TVs with 4:3 aspect ratio will display them in the letter box style.

Pictures are recorded in the 16:9 wide picture shape. TVs with 4:3 aspect ratio will display them in the pan scan style (one or both sides of pictures are cut).

Actual picture shape may vary depending on the aspect ratio or mode selection of the TV.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 11

E439BBD_EN.book Page 12 Wednesday, May 31, 2006 4:01 PM

Structure of disc contents

Normally, DVD video discs are divided into titles, and the titles are subdivided into chapters. Video CDs/Audio CDs are divided into tracks.

DVD video disc

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3

Video CD/Audio CD

Track 1 Track 2 Track 3 Track 4 Track 5

MP3, JPEG, DivX

Group 1 Group 2

Track 1 Track 2 Track 3 Track 4 Track 5

Title: Divided contents of a DVD video disc.

Roughly corresponds to a story title in short stories.

Chapter: Divided contents of a title. This corresponds

to a chapter in a story.

Track: Divided contents of a Video CD or an Audio

CD.

Group: Divided contents of a MP3, JPEG or DivX

data disc. Consists of number of tracks.

Each title, chapter, or track is assigned a number, which is called “title number”, “chapter number” or “track number” respectively. Some discs may not have these numbers.

When you record on the HDD, one recording will always equal one title. You can divide a title into several chapters by marking borders in it to facilitate scene search.

On handling discs

• Do not touch the playback side of the disc.

Yes

• Do not stick paper or tape to discs.

Playback side

On cleaning discs

• Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the centre outwards with a soft cloth. Always keep the disc clean.

Yes

• Do not use any type of solvent such as thinners, benzine, commercially available cleaners or antistatic spray for vinyl LPs. It may damage the disc.

On storing discs

• Do not store discs in a place subject to direct sunlight or near heat sources.

• Do not store discs in places subject to moisture and dust such as a bathroom or near a humidifier.

• Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.

Page 12

E439BBD_EN.book Page 13 Wednesday, May 31, 2006 4:01 PM

Discs and purposes

The table shows main functions which are available on this recorder per disc category. This will help you choose discs.

DVD-RW disc Video mode DVD-RW disc VR mode DVD-R disc Video mode

Characteristics on this recorder

For the first use Initialise the disc. Initialise the disc. No preparatory steps required.

Recording a TV programme Yes Yes Yes

Erasing recorded contents Yes Yes Yes

Indexing recorded contents Yes Yes Yes

Naming a title Yes Yes Yes

Creating a thumbnail Yes Yes Yes

Collecting favourite scenes (Playlist Editing)

Making a new title from a Playlist containing favourite scenes (Copy within the same disc)

Playing contents recorded on this recorder, on other devices

When a message appears and the loaded disc cannot be used:

Suitable for saving data in Video mode format to play on compatible devices.

You can erase recorded contents to use the disc repeatedly.

If the disc has been executed Video mode finalising process, first cancel the process then delete contents.

After you execute Video mode finalising process on a recorded disc, you cannot name a title or create a thumbnail.

No Yes No

Execute Video mode finalising process on this recorder. This process makes the disc playable on other compatible devices. (Some models excepted.)

Initialise the disc. Initialise the disc.

Suitable for saving data in VR mode format to play on compatible devices.

You can erase recorded contents to use the disc repeatedly.

You can erase recorded contents without cancelling the finalising process.

After you execute VR mode finalising process on a recorded disc, you can name a title or create a thumbnail.

Execute VR mode finalising process on this recorder. This process makes the disc playable on other compatible devices. (Some models excepted.)

Suitable for saving data in Video mode format to play on compatible devices.

Once you execute Video mode finalising process on a recorded disc so that it can be played on other players. You cannot make additions, corrections and deletions of contents on the disc.

Deleting contents cannot restore the disc space. After you execute Video mode finalising process on a recorded disc, you cannot delete contents of the disc.

After you execute Video mode finalising process on a recorded disc, you cannot name a title or create a thumbnail.

Execute Video mode finalising process on this recorder. This process makes the disc playable on other compatible devices. (Some models excepted.)

–

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 13

VCD

MP3

JPEG

DivX

E439BBD_EN.book Page 14 Wednesday, May 31, 2006 4:01 PM

Guide to the Owner’s Manual

Symbols used in the Owner’s Manual

To show what recording mode or disc type applies to each function, the following symbols appear at the beginning of each operating item.

Symbol Description

HDDHDD

Available to (internal) HDD

DVD-VDVD-V

Video

DVD-RWDVD-RW

DVD-RDVD-R

CDCDCD

VCD

MP3

JPEG

DivX

VCRVCR

Available to DVD-Videos

Available to DVD-RW discs in Video mode

Available to DVD-RW discs in VR mode

Available to DVD-R discs in Video mode

Available to Audio CDs

Available to Video CDs

Available to CD-RW / R discs with MP3 files

Available to CD-RW / R discs with JPEG files

Available to DVD-RW / R and CD-RW / R discs with DivX

Available to VHS tapes Use only cassettes marked VHS ( ).

files

PAL

Page 14

E439BBD_EN.book Page 15 Wednesday, May 31, 2006 4:01 PM

Functional Overview

Front Panel

6* 7

Introduction Connections Basic Setup Playback

ON / STANDBY

1 ON / STANDBY button: Press to turn the

unit on / off.

2 ON / STANDBY indicator: Lights up when

the power is on.

3 Cassette compartment: Insert a tape here. 4 REC indicator (VCR): Lights up during VCR

recording.

5 DUBBING indicator 6 OPEN / CLOSE O button* (DVD): Press to

open / close the disc tray.

7 REC indicators (HDD / DVD): Lights up

during HDD / DVD recording.

8 Disc tray: Place a disc here. 9 RESET: Press with a sharp pointed object to

restart the unit. Also refer to the “Note” right below.

10 S-VIDEO input jack (AV3)

(HDD / DVD / VCR)

output of an external device here using a commercially available S-Video cable.

11 VIDEO input jack (AV3)

(HDD / DVD / VCR)

of an external device here using a commercially available Video cable.

12 AUDIO input jacks (AV3)

(HDD / DVD / VCR)

of an external device here using a commercially available Audio (L / R) cable.

13 I REC button (HDD / DVD): Press once to

start a basic recording. Press repeatedly to start an OTR (One-touch Timer Recording). Each press increases the recording time by 30 minutes up to 8 hours.

14 PLAY P button* (HDD / DVD): Press to start

or resume playback.

15 STOP S button* (HDD / DVD): Press to stop

playback, recording or dubbing.

Button names described in the Owner’s Manual

The instructions in this manual are described mainly with the operations using the remote control. Some operations can be carried out using the buttons on the front panel.

VCR

REC

24 22

23 2125

: Lights up during dubbing.

: Connect the S-Video

: Connect the video output

: Connect the audio output

PROGRAM

DUBBING

HDD

VCR

DVD

VCR

DVD

HDD

16 Device Select Buttons / Indicators:

VCR: Press to activate the VCR. Lights up when

VCR is selected.

HDD: Press to activate the HDD. Lights up when

HDD is selected.

DVD: Press to activate the DVD. Lights up when

DVD is selected.

17 DUBBING HDD DVD button: Press to start

One Touch Dubbing from HDD to DVD.

18 DUBBING VCR DVD button: Press to start

One Touch Dubbing from VCR to DVD.

19 PROGRAM / buttons: Press to change

the channel.

20 Front Panel Display: Shows information and

messages. Refer to “Front Panel Display Guide” on page 21.

21 I REC button (VCR): Press once to start a

basic recording. Press repeatedly to start an OTR (One-touch Timer Recording). Each press increases the recording time by 30 minutes up to 8 hours.

22 PLAY P button (VCR): Press to start playback. 23 F.FWD f button (VCR): Press to fast

forward or fast search.

24 REW r button (VCR): Press to rewind or

rewind search.

25 STOP / EJECT O/S button (VCR): Press to

eject the videotape. Press to stop recording or playback.

(*)

You can also turn on the unit by pressing these buttons.

Note

After pressing [RESET],

• The settings for the items listed below will be lost;

- Clock Setting

- Timer Programme

- Resume point

• The settings for the item listed below will not be lost, but need to be set again;

- Channel Setting

• All other settings will remain as memorized.

DVD

15*

HDD/DVD

14*

HDD

REC

DVD

S-VIDEO

VIDEO L

AV3

Recording

Editing

Function Setup

VCR Functions Others

Page 15

E439BBD_EN.book Page 16 Wednesday, May 31, 2006 4:01 PM

Rear Panel

1 Mains cable

• Connect to a standard AC outlet.

2 AV2(DECODER) (HDD / DVD / VCR)

• Connect to VCR, camcorder, or other Audio-Video equipment. Use a commercially available Scart cable.

3 AV1(TV) (HDD / DVD / VCR)

• Connect to the Scart socket on your TV. Use a commercially available Scart cable.

4 DIGITAL AUDIO OUT (COAXIAL) jack

(HDD / DVD)

• Connect to an amplifier with a digital input jack such as a Dolby Digital decoder or DTS decoder. Use a commercially available Coaxial cable.

HDD / DVD / VCR

AV2 (DECODER)

AV1

(TV)

DIGITAL

AUDIO OUT

COAXIAL

HDD/DVD

AUDIO

OUT

S-VIDEO

OUT

HDD/DVD/VCR

72134 5 86

5 AUDIO OUT jacks (HDD / DVD)

• Connect to the audio input jacks on your TV. Use a commercially available Audio cable.

6 S-VIDEO OUT jack (HDD / DVD)

• Connect to the S-Video input jack on your TV. Use a commercially available S-Video cable.

7 AERIAL (HDD / DVD / VCR)

• Connect to an antenna or cable.

8 RF OUT (HDD / DVD / VCR)

• Connect to the Aerial jack on your TV, cable box or direct broadcast system. Use the supplied RF cable.

AERIAL

RF OUT

Note

• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

• This unit does not have an RF modulator.

Page 16

E439BBD_EN.book Page 17 Wednesday, May 31, 2006 4:01 PM

Remote Control

OPEN/

TIMER

.@/: ABC DEF

123

GHI JKL MNO

456

PQRS TUV

SYSTEM

MENU/LIST

DISPLAY RETURN

REV FWDPLAY

10 11 12

SLOW

REC MONITOR

REC MODE

DUBBING MODE

(*)

You can also turn on the unit by pressing these buttons when the remote control is in VCR / HDD / DVD mode.

(**)

This button does not function for this unit.

1 OPEN / CLOSE O button*

(DVD / VCR)

or eject a videotape.

2 Number buttons:

Press to select channel numbers. Press to select a title / chapter / track on the display. Press to enter setting values. Press to enter the index number / desired time to search in VCR mode.

3 SETUP button: Press to display the Setup

Menu. The unit switches to the HDD / DVD mode when this button is pressed.

: Press to open / close the disc tray

INPUT

PROG.

SELECT

WXYZ

SPACE

AUDIO CLEAR

SETUP

ENTER

VARIABLE

REPLAY

SKIP

VCR HDD DVD

REC/OTR REC/OTR REC/OTR

III

SEARCH MODE

PROG.

TOP MENU

VARIABLE

SKIP

PAU SESTOP

27 29

31 33

26*

28 30

4 MENU / LIST button (HDD / DVD):

Displays the Disc Menu. Changes the Original List and the Playlist.

5Cursor U / D / L / P buttons: Selects items

or settings.

6 DISPLAY button: Displays the on-screen

menu.

7SKIP B / F buttons (HDD / DVD):

During playback, press to skip to the previous / next chapter or track. Or when playback is paused, press to play back in forward / reverse step by step.

8 REV r button:

(HDD / DVD) During playback, press to play back

in fast reverse. Or when playback is paused, press to play back in slow reverse. (VCR) Press to rewind the videotape or to view the picture rapidly in reverse during the playback mode.

9PLAY P button*:

Press to start or resume playback. If the resume point has been set, the playback will start from the resume point.

10 SLOW button (VCR): During playback,

press to view the videotape in slow motion.

11 REC MONITOR button (HDD / DVD):

Press to check the picture and the audio qualities for recording.

12 REC MODE button: Press to select the Rec

Mode.

13 DUBBING MODE button: Press to display the

Dubbing Menu. The unit switches to the HDD / DVD mode when this button is pressed.

14 TIMER PROG. button: Press to display the

Timer Programming List. The unit switches to the HDD / DVD mode when this button is pressed.

15 INPUT SELECT button: Press to select an

external input mode (“AV1”, “AV2” or “AV3”).

16 ON / STANDBY button: Press to turn the

unit on / off.

17 PROG. / buttons:

Press to change the channel up / down. (VCR) Press to adjust the tracking during playback or in slow motion of the videotape. Also while playback is in still mode, you can stabilize the still picture.

18 CLEAR button:

(HDD / DVD) Press to clear the information once

entered, etc. (DVD) Press to erase the track number entered in the programme play screen for Video / Audio CDs.

(VCR) Press to reset the tape counter.

19 AUDIO button: During playback, press to

change the audio settings.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 17

E439BBD_EN.book Page 18 Wednesday, May 31, 2006 4:01 PM

20 TOP MENU button (HDD / DVD): Displays

the Title List.

21 ENTER button: Press to confirm or select

menu items.

22 RETURN button: Press to return to the

previously displayed Menu Screen.

23 VARIABLE SKIP button (HDD / DVD):

Skips by the amount of time set in advance.

24 VARIABLE REPLAY button

(HDD / DVD)

in advance.

: Replays by the amount of time set

25 FWD f button:

(HDD / DVD) During playback, press to play back

in fast forward. Or when playback is paused, press to play back in slow forward. (VCR) Press to rapidly advance the videotape or view the picture rapidly in forward during playback.

26 STOP S button*: Press to stop playback,

recording, or dubbing.

27 PAUSE p button: Press to pause playback or

recording.

Device Select Buttons:

28 VCR button:

Press to activate the remote control in VCR mode. (See page 19.) Press to activate the VCR.

29 HDD button:

Press to activate the remote control in HDD mode. (See page 19.) Press to activate the HDD.

30 DVD button:

Press to activate the remote control in DVD mode. (See page 19.) Press to activate the DVD.

31 REC / OTR I button (VCR):

Press once to start a basic VCR recording. Press repeatedly to start a One-touch Timer Recording in VCR mode.

32 REC / OTR I button (HDD):

Press once to start a basic HDD recording. Press repeatedly to start a One-touch Timer Recording in HDD mode.

33 REC / OTR I button (DVD):

Press once to start a basic DVD recording. Press repeatedly to start a One-touch Timer Recording in DVD mode.

34 SEARCH MODE button (VCR):

Press to call up the index or time search menu.

Button names described in the Owner’s Manual

The instructions in this manual are described mainly with the operations using the remote control. Some operations can be carried out using the buttons on the front panel.

Page 18

O P E N

C L O S E

.@ / :

A B C

D E

G H IJ

K L

M N O

P R O

G .

P Q R

S T

V S P A C

S Y S

T E M

S E T

U P

M E N

U /L I

S T

E N T E

T O

P M

E N U

U D I O

C L E

W X

Y Z

T I M

E R

R O G

I N P U

S E L E C

E439BBD_EN.book Page 19 Wednesday, May 31, 2006 4:01 PM

Introduction Connections Basic Setup Playback

Installing batteries in the remote control

Install two R6 (AA) batteries (supplied) into the remote control, carefully match with the polarity indicated inside the battery compartment.

Caution

• Incorrect use of batteries can result in hazards such as leakage and bursting.

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together.

• Make sure that the + and - ends of each battery match the indications inside the battery compartment.

• Remove batteries if the equipment will not be used for a month or more.

• When disposing used batteries, please comply with governmental regulations or the public instructions for environmental protection that apply in your country or area.

• Do not recharge, short-circuit, heat, burn or disassemble batteries.

About the remote control

• Make sure there is no obstacle between the remote control and the remote control sensor on the unit.

• Use within the operating range and angle as shown.

HDD / DVD / VCR modes switching

Because this product is a combination of a VCR, a HDD and a DVD recorder, you must select first which component you wish to operate.

Device Select Buttons / Indicators

OPEN/

TIMER

INPUT

PROG.

VCR

I /

ON / STANDBY

REC

PROGRAM

HDD/DVD

REC

DUBBING

HDD

VCR

DVD

VCR

HDD

DVD

HDD

VCR HDD DVD

DVD button / indicator

HDD button / indicator

VCR button / indicator

VCR button

HDD button

DVD button

HDD mode

Press [HDD] on the remote control. (Verify that the HDD indicator is lit.)

DVD mode

Press [DVD] on the remote control. (Verify that the DVD indicator is lit.)

SELECT

.@/: ABC DEF

123

PROG.

GHI JKL MNO

456

WXYZ

PQRS TUV

SPACE

AUDIO CLEAR

SETUP

SYSTEM

TOP MENU

MENU/LIST

ENTER

DISPLAY RETURN

VARIABLE

REPLAY

SKIP

REV FWDPLAY

PAUSESTOP

SLOW

REC MONITOR

VCR HDD DVD

REC MODE

REC/OTR REC/OTR REC/OTR

III

DUBBING MODE SEARCH MODE

Recording

I /

O N

/ S T

A N

D B

30˚

V C

E C

P R O G

R A M

D U B B

IN G

V C

R V C R

H D

D V

H D D

D V

D D

/D V

R E C

H D D

D V D

Within about 7 m

30˚

Remote control

• The maximum operable range as follows:

Line of sight: approximately 7 m Either side of centre: approximately 7 m within

• Remote control operation may become unreliable if the remote control sensor of the unit is being exposed by the strong sunlight or fluorescent light.

• Remote controls for different devices can interfere with each other. Be careful when using remote controls for other equipment located close to the unit.

• Replace the batteries when the operating range of the remote control reduces.

30 degrees

VCR mode

Press [VCR] on the remote control. (Verify that the VCR indicator is lit.)

Note

• Pressing the device select button on the front panel DOES NOT switch the device mode of the remote control. You MUST select the correct device mode on the remote control.

• If you press [REC / OTR

I] of each device,

recording starts in its device mode.

• When the buttons listed below are pressed, the unit switches to the HDD / DVD mode.

- [TIMER PROG.]

- [SETUP]

- [DUBBING MODE]

Editing

Function Setup

VCR Functions Others

Page 19

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Advanced Menu

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

Auto Clock Setting

Clock Setting

E439BBD_EN.book Page 20 Wednesday, May 31, 2006 4:01 PM

Guide to Display Information

The Display Menu gives you information on the playback status of the HDD or DVD.

Display Example:

Press [DISPLAY] once to show the information on the current operation mode. Press [DISPLAY] one more time to see more information, and to call up the icons for the available features.

DVD MODE

DVD Play AAA

Press [DISPLAY] once.

DVD MODE

8 / 8 1 / 4 0:00:04/ 1:30:00

2 3

Guide to Setup Menu

This unit uses the following on-screen menu for most operations. It allows you to change the settings of the unit to match the environment, and to customise the settings as you prefer. “Easy Setting Menu” and “Advanced Menu” are available. “Easy Setting Menu” consists of those frequently needed. You can make all required settings using “Advanced Menu.”

How to use Setup Menus:

Press [SETUP] to display “Easy Setting Menu” or “Advanced Menu.” Choose either menu using

[Cursor

• CD Menu is available only when a CD is loaded.

U / D], then press [ENTER].

Example: Advanced Menu

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

DVD Recording Format

Press [DISPLAY] twice.

Each section includes the information as listed below:

1 Device mode 2 • Current title number / total number of the titles

• Current chapter number / total number of the chapters

• Elapsed playback time of the current title / total time of the title

3 • Playback status

• Name of the current title

4 Playback status icon 5 Icons for the available features:

: SEARCH

: AUDIO

: SUBTITLE

: ANGLE

: REPEAT

: ZOOM

: NOISE REDUCTION

Note

• This is an example screen only for explanation. Displayed items varies depending on the actual mode.

• The information will not appear under the following conditions;

- When there is no title recorded in the HDD/DVD.

- During recording (DVD only).

Select a menu using [Cursor

U / D], then press

[ENTER].

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Select an item to set using [Cursor

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

U / D], then

press [ENTER]. Sub menu or option window will appear.

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Clock Setting

Channel Setting

Clock Setting

Playback

Clock Setting

Record

Auto Clock Setting

Display

Reset to factory default

Make your desirable selection using

[Cursor

U / D / L / P], then press [ENTER].

Available menus vary among discs.

Page 20

E439BBD_EN.book Page 21 Wednesday, May 31, 2006 4:01 PM

Front Panel Display Guide

Introduction Connections Basic Setup Playback

TIME SHIFT

1 TIME SHIFT

Appears during the Time Shift Playback (HDD).

2 Title / Track and Chapter mark

: Appears when indicating a title / track

number.

: Appears when indicating a chapter

number.

3 Current status of the unit

: Appears when Timer Recording is in

Standby, or is proceeding. Disappears when all the Timer Recordings are finished. (Does not appear while in the Satellite Link standby mode or the Satellite Link Recording is in progress.)

: Appears when a videotape is in the unit.

DB : Lights up during a dubbing process.

VCR HDD

DVD

CD R W

5 Disc type and current status of the unit

: Appears when an Audio CD or a disc with

MP3 / JPEG / DivX

R : Appears when a DVD-R disc is loaded on

the disc tray.

RW : Appears when a DVD-RW disc is loaded on

the disc tray.

6 Displays the following

• Played-back time

• Current title / chapter / track number

• Recording time

•Clock

• Channel number

• VCR tape counter

• Remaining time for a One-touch Timer Recording

files is on the disc tray.

Recording

I VCR : Lights up during VCR recording.

I HDD : Lights up during HDD recording. I DVD : Lights up during DVD recording.

Display Messages

Appears when the unit is turning on.

Appears when the disc tray is opening.

Appears when the disc tray is closing.

Editing

Appears when the unit is turning off.

Function Setup

Appears when a disc is loaded on the disc tray.

VCR Functions Others

Page 21

E439BBD_EN.book Page 22 Wednesday, May 31, 2006 4:01 PM

Connections

To A e r ia l j ac k

Scart cable (not supplied)

HDD / DVD / VCR

AV2 (DECODER)

AV1

(TV)

Connections

Connecting to a TV

Connect the unit to a TV after considering the capabilities of your existing equipment.

Before installation, unplug your TV and this unit. Using the Scart socket

1 Connect the antenna or cable to the

AERIAL jack of this unit.

2 Connect the RF OUT jack of this unit

to the Aerial jack of your TV. Use the supplied RF cable.

Connect AV1(TV) Scart socket of this unit to the Scart socket of your TV. Use a commercially available Scart cable.

Note

• If your TV does not have a Scart socket, use a commercially available Scart adaptor or Scart / RCA cable to connect. Use only AV1(TV) or AV2(DECODER) socket for the VCR output signals of this unit.

• Teletext can only be output in VCR mode through AV1(TV) out.

Using the S-VIDEO OUT jack and the AUDIO OUT jacks (only for HDD / DVD)

If your TV has an S-Video input jack, use S-Video and Audio cables to connect.

1 Follow steps 1 and 2 above. 2

Connect S-VIDEO OUT jack of this unit to the S-Video input jack of your TV. Use a commercially available S-Video cable.

3 Connect the AUDIO OUT jacks of this

unit to the analogue Audio input jacks of your TV. Use a commercially available Audio cable.

Antenna

Audio/Video cable (not supplied)

Scart/RCA cable (not supplied)

DIGITAL

AUDIO OUT

COAXIAL

HDD/DVD

AUDIO

S-VIDEO

OUT

Scart adaptor (not supplied)

HDD/DVD/VCR

AERIAL

RF OUT

RF cable (supplied)

RF cable (not supplied)

AUDIO IN S-VIDEO IN

Audio cable (not supplied)

HDD / DVD / VCR

AV2 (DECODER)

AV1 (TV)

HDD/DVD

AUDIO

S-VIDEO

DIGITAL

OUT

AUDIO OUT

COAXIAL

Note for a TV with no S-Video input jack or Scart socket:

• This unit has no RF modulator, so this type of TV cannot be used.

Connecting to external equipment

This unit has three input terminals, AV1(TV) or AV2(DECODER) on the rear panel and AV3 on the front panel. Be sure that all the units are off before making any connections.

Recording from a HDD / DVD player, VCR, Satellite Box or other Audio-Video equipment with a Scart output socket (AV2)

AV output socket (Scart)

Scart cable (not supplied)

AV2 (DECODER)

HDD / DVD / VCR

AV2 (DECODER)

AV1 (TV)

Cable Signal

S-Video cable (not supplied)

HDD/DVD/VCR

AERIAL

RF OUT

HDD/DVD

AUDIO

S-VIDEO

DIGITAL

OUT

AUDIO OUT

HDD/DVD/VCR

AERIAL

COAXIAL

RF OUT

Page 22

PROGRAM

DUBBING

VCR

HDD

DVD

HDD

DVD

REC

HDD/DVD

S-VIDEO

VIDEO L

AV3

E439BBD_EN.book Page 23 Wednesday, May 31, 2006 4:01 PM

Note

• When you record a TV programme from a Satellite Box, you must connect a Scart cable to AV2(DECODER). (See page 38.)

• If the external equipment connected to the AV2(DECODER) socket supplies control voltage to this unit via Pin 8 of the Scart cable, the display functions (e.g.P01) of the remote control cannot be seen on the TV. In this case, turn off the external equipment to prevent control voltage.

Recording from a camcorder or other Audio-Video equipment with no Scart output socket (AV3)

If no S-Video input jack is available, connect to VIDEO input jack on the front panel using an RCA Video cable. Set “S-Video In” when using S-VIDEO input jack. (See page 48.)

AV3 ( F r o n t )

S-Video cable (not supplied)

S-VIDEO

OUT

Audio cable (not supplied)

AUDIO

OUT

Digital audio for better sound quality (only for HDD / DVD)

Digital audio input jack

COAXIAL

Coaxial cable (not supplied)

Dolby Digital decoder, DTS decoder or MPEG decoder, etc.

HDD/DVD

AUDIO

S-VIDEO

DIGITAL

OUT

AUDIO OUT

COAXIAL

OUT

1 For clear digital sound quality, use

the DIGITAL AUDIO OUT (COAXIAL) jack to connect your digital audio equipment.

If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

Connecting a Dolby Digital™ decoder, DTS decoder or MPEG decoder

• Connecting Multi-channel Dolby Digital decoder allows you to enjoy the Multi-channel Dolby Digital surround system as well as DTS decoder, Multichannel surround system.

• After connecting to a Dolby Digital decoder, set “Dolby Digital” to “Stream” in “Audio Out”. (See page

85.)

• After connecting to a DTS decoder, set “DTS” to “On” in “Audio Out”. (See page 85.)

• After connecting to a MPEG decoder, set “MPEG” to “Stream” in “Audio Out”. (See page 85.)

Connecting to an MD deck or DAT deck

• The audio source recorded in Dolby Digital Multichannel surround format cannot be recorded using an MD or DAT deck as a digital sound.

• If not connected to a Dolby Digital decoder, set “Dolby Digital” to “PCM” in “Audio Out” (see page

85). Playing back a DVD using incorrect settings may generate noise distortion, and damage speakers.

• Set “Dolby Digital” and “MPEG” to “PCM” and set “DTS” to “Off” in “Audio Out” (see page 85) for connecting to an MD or DAT deck.

• You can use AUDIO OUT jacks for the connection of your audio system.

After you have completed connections

Switch the input selector on your TV to an appropriate external input channel. For details, refer to the Owner’s Manual of your TV.

Note

• Connect this unit directly to the TV. If the AV cables are connected to a VCR, pictures may be distorted due to the effects of the copy protection system.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

HDD / DVD / VCR

AV2 (DECODER)

AV1 (TV)

HDD/DVD

AUDIO

S-VIDEO

DIGITAL

OUT

AUDIO OUT

HDD/DVD/VCR

AERIAL

COAXIAL

RF OUT

VCR Functions Others

The connections illustrated above are optional for better sound.

Page 23

E439BBD_EN.book Page 24 Wednesday, May 31, 2006 4:01 PM

Basic Setup

For the first time use

Right after the purchase of the unit, do the Initialise Setting by doing the following procedures. This menu may not appear if you have already turned on the unit.

1 After making all the necessary

connections, turn on the TV. Select the appropriate external input channel.

(See pages 22 to 23.)

2 Press [ ON / STANDBY].

The following screen will automatically appear and the Auto Channel Tuning will start. If you like to skip this step, press [RETURN].

Auto Tuning

Channel Setting

Auto Tuning

Although your unit may automatically memorise the channels you receive when you turn it on for the first time, you can set up the channels again.

1 Press [ ON / STANDBY] to turn on

the unit.

2 Turn the TV on and select the input

to which the unit is connected.

3 In stop mode, press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

4 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

5 Select “Channel Setting” using

[Cursor

U / D], then press [ENTER].

6 Select “Auto Tuning” using

[Cursor

The unit will start storing channels available in your area.

U / D], then press [ENTER].

Auto Tuning

• Wait for several minutes to finish channel storing.

After Auto Tuning has stopped:

•Use [PROG. / ] or [the Number Buttons] to

change the channel.

• When you use [the Number Buttons], press [0]

first for a single digit number.

•Use [INPUT SELECT] to select an external input

channel (“AV1”, “AV2” or “AV3”) of this unit.

To cancel auto tuning: Press [SETUP] or [RETURN] during scanning.

Note

• The selection will be affected by how you receive TV channels in your local area.

• If the auto tuning is cancelled during scanning, some channels not yet tuned may not be received.

• You cannot change the channel when either HDD, DVD or VCR is in any recording mode (normal recording, One-touch Timer Recording or Timer Recording).

• Sorting of TV channels from P01 to P06 will be performed automatically as follows. P01: BBC1 P02: BBC2 P03: ITV P04: CH4 P05: CH5 P06: SKY NEWS

* If you are using a satellite receiver, turn it on and

select SKY NEWS before commencing tuning.

Manual Tuning

Tune each channel manually.

1 In stop mode, press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

2 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

3 Select “Channel Setting” using

[Cursor

U / D], then press [ENTER].

4 Select “Manual Tuning” using

[Cursor

U / D], then press [ENTER].

Manual Tuning

Position

Channel

Decoder

Skip

P12

123

Off

Page 24

E439BBD_EN.book Page 25 Wednesday, May 31, 2006 4:01 PM

5 Select “Position” using

[Cursor [Cursor

U / D], then press P].

6 Select the position number you want

using [the Number buttons] or [Cursor [Cursor

You can select position numbers 01 to 99.

U / D], then press L].

7 Select “Channel” using

[Cursor [Cursor

U / D], then press P].

8 Press [Cursor U / D] to start

scanning.

• The tuner will begin to search up or down automatically. When a channel is found, the unit will stop searching and the picture will appear on the TV screen.

• You can select a desired channel number using [the Number buttons]. Refer to the following Channel Plan table and press the three digits to select the channel number. (To select channel 4, press [0] first and then press [0] and [4]. Or press [4] and then “– – 4” appears and wait for 2 seconds.)

• If this is the channel you want, press

[Cursor

This unit can receive the Hyper and Oscar frequency bands.

• If “Skip” is set to “On,” select “Skip” using

[Cursor “Off” using [Cursor [Cursor

• If you want to decode scrambled signals, select “Decoder” using [Cursor

[Cursor

then press [Cursor

• To store another channel, repeat steps 5 to 8.

L].

Channel Plan

CH Indication TV Channel

01 – 10 IRA-IRJ, GAP 21 – 69 E21 – E69 74 – 78 X, Y, Z, Z+1, Z+2

80 – 99, 100 S1 – S20, GAP

121 – 141 S21 – S41

U / D], then press [Cursor P]. Select

U / D], then press

L].

U / D], then press

P]. Select “On” using [Cursor U / D],

L].

9 After completion, press [SETUP] to

exit.

To select a channel

Notes on using [the Number buttons]:

• Enter channel numbers as a two-digit number for the quickest result. For example, to select channel 6, press [0] and [6]. If you only press [6], channel 6 will be selected after 2 seconds. You can only select channels 1 to 99.

About an external input:

• You can select the external input mode “AV1,” “AV2” or “AV3” using [INPUT SELECT].

• You cannot change the channel when either HDD, DVD or VCR is in any recording mode (normal recording, One-touch Timer Recording or Timer Recording).

To skip a preset channel

You can set the unit to skip channels you can no longer receive or seldom watch when you access channels using [PROG. / ].

1 Follow steps 1 to 4 in “Manual

tuning”.

(See page 24.)

2 Select “Position” using

[Cursor [Cursor

U / D], then press P].

3 Select the position number you want

to skip using [the Number buttons] or [Cursor [Cursor

U / D], then press

L].

4 Select “Skip” using [Cursor U / D],

then press [Cursor

P].

5 Select “On” using [Cursor U / D],

then press [Cursor

• To skip another channel, repeat steps 2 to 5.

L].

6 Press [SETUP] to exit.

Move

You can replace two channels.

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

2 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

3 Select “Channel Setting” using

[Cursor

Channel Setting Menu will appear.

U / D], then press [ENTER].

4 Select “Move” using [Cursor U / D],

then press [ENTER].

Option window will appear.

5 Select the position number of which

you want to change the channel using [Cursor

U / D], then press

[ENTER].

You cannot select a position number where “– – –” appears next to the number, because “Skip” is set to “On” for that position number.

6 Move the channel to another

position number using [Cursor

• To move another channel, repeat steps 5 to 6.

U / D], then press [ENTER].

7 Press [SETUP] to exit.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 25

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Advanced Menu

Auto Clock Setting

Clock Setting

Off

Auto Clock Setting

E439BBD_EN.book Page 26 Wednesday, May 31, 2006 4:01 PM

Setting the clock

Auto Clock Setting

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

Advanced Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

DVD Disc Format

DVD Recording Format

Finalise

Disc Protect

Delete Playlist

2 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

3 Select “Clock Setting” using

[Cursor

Clock Setting Menu will appear.

U / D], then press [ENTER].

Clock Setting

Auto Clock Setting

4 Select “Auto Clock Setting” using

[Cursor

Option window will appear.

U / D], then press [ENTER].

Auto Clock Setting

On Off

5 Select “On” using [Cursor U / D],

then press [ENTER].

Note

• If you want to cancel “Auto Clock Setting”, select

“Off” using [Cursor

U / D] at step 5, and then press

[ENTER].

• The default setting of “Auto Clock Setting” is “On”.

• The clock may set itself automatically after you connect the antenna cable to the unit and plug in the mains cable. In this case, the current time will appear on the front panel display.

• To set the clock automatically, the channel assigned to “P04” must receive the PDC signal and the Decoder must be Off.

• The clock cannot be set automatically if you are not receiving a channel in your area that carries a time signal. In this case, set the clock manually.

• Once the auto clock setting is performed, the unit will correct the current time by receiving PDC broadcasts whenever the unit is in standby mode.

• The unit will correct the current time automatically at 8:00, if the unit is in standby mode.

• From 23:00 to 1:00, the Auto Clock function will not operate even if the unit is in standby mode.

Manual Clock Setting

1 Follow the steps 1 to 3 in “Auto

Clock Setting” on the left.

2 Select “Clock Setting” using

[Cursor

Clock Setting Window will appear.

U / D], then press [ENTER].

Clock Setting

(Sun)

12 2006 22 3231

/ / :

3 Move to the item you want to set

using [Cursor setting to suit your preference using [Cursor

L / P], and change the

U / D].

4 When all the information is entered,

press [ENTER].

Your setting is activated. Although seconds are not displayed, they will be counted from zero.

5 Press [SETUP] to exit.

Note

• Your clock setting will be lost if either there is a power failure or this unit has been unplugged for more than 30 seconds.

6 Press [SETUP] to exit. 7 Press [ ON / STANDBY] to turn the

unit to standby mode.

The Auto Clock function is activated. This unit will search for the time only when the unit is in standby mode. Leave the unit for several minutes to give it time to set the clock.

Page 26

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Advanced Menu

Angle Icon

Variable Replay/Skip Speed

Audio Out

Subtitle Language

Audio Language

Disc Menu Language

Parental Lock

TV Aspect

Playback

TV System

Media

DivX

E439BBD_EN.book Page 27 Wednesday, May 31, 2006 4:01 PM

Selecting the TV aspect ratio

You can select the TV aspect ratio to match the formats of what you are playing back on the unit and your TV screen (4:3 standard or 16:9 widescreen TV).

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear. If “Advanced Menu” is displayed, proceed to step

Easy Setting Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Advanced Menu

DVD Disc Format

DVD Recording Format

Finalise

Disc Protect

Delete Playlist

2 Select “Advanced Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

6 Select a desired option using

[Cursor

Your setting is activated.

• The default setting is “4:3 Letter Box”.

U / D], then press [ENTER].

7 Press [SETUP] to exit.

Note

• If you have a standard TV: Select “4:3 Letter Box” for full-length picture with black bars on the top and bottom of the screen. Select “4:3 Pan & Scan” for a full-height picture with both sides trimmed.

• If you have a widescreen TV: Select “16:9 Wide”.

Introduction Connections Basic Setup Playback

Recording

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

4 Select “Playback” using

[Cursor

Playback Menu will appear.

U / D], then press [ENTER].

Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Audio Out

Variable Replay/Skip Speed

Angle Icon

TV System

Media

DivX

5 Select “TV Aspect” using

[Cursor

Option window will appear.

U / D], then press [ENTER].

Editing

Function Setup

VCR Functions Others

TV Aspect

4:3 Letter Box

4:3 Pan & Scan

16:9 Wide

Page 27

E439BBD_EN.book Page 28 Wednesday, May 31, 2006 4:01 PM

Recording

Information on supported media

Media types

✬✬✬: Most suitable. ✬✬: Can be used. ✬: Some functions are limited. —: Cannot be used.

You want to HDD DVD-RW VR DVD-RW Video DVD-R VCR

Record TV programmes ✬✬✬ ✬✬✬ ✬✬✬ ✬✬✬ ✬✬✬

Reuse by deleting unwanted contents ✬✬✬ ✬✬✬ ✬✬ — ✬✬

Edit recorded contents ✬✬✬ ✬✬✬ ✬ ✬ —

Edit / Record from connected equipment ✬✬✬ ✬✬✬ ✬✬✬ ✬✬✬ ✬

Copy discs for distribution — ✬✬

Play on other HDD / DVD / VCR equipment

*1 VR mode DVD-RW can only be played on DVD equipment that is VR compatible. *2 Programmes can be recorded from other equipment, but they cannot be edited.

Features HDD DVD-RW VR DVD-RW Video DVD-R VCR

Recording

Rewritable Yes Yes Yes No Yes

Can create chapters at fixed intervals (auto.)

Can create chapters wherever you like (manual)

Can record 16:9 size pictures Yes Yes Yes Yes No

Can record copy-once programmes

Editing

Can perform basic edit functions Yes Yes Yes Yes No

Can perform advanced edit functions (Playlist edit)

*1 CPRM compatible disc only.

— ✬✬

Yes Yes Yes Ye s No

Yes Yes No No No

Yes Ye s

Yes Yes No No No

✬✬✬ ✬✬✬ —

✬✬✬ ✬✬✬ ✬✬✬

No No Yes

Note

• For details of the above functions and implied restrictions, see the explanations inside this Owner’s Manual.

Information:

This unit can record on DVD-RW discs and DVD-R discs. DVD-R discs allow you to record programmes only once, and the recorded contents cannot be erased. DVD-RW discs allow you to record programmes

You can record and edit material repeatedly. It is impossible to record additional materials on a disc formatted in VR mode and already recorded in another video system other than PAL, such as NTSC.

Logo Attributes

repeatedly, and the recorded contents can be erased. There are 2 recording format: VR mode and Video mode. VR and Video modes are available for DVD-RW discs while as only Video mode is available for DVD-R discs.

Video mode is the same recording format as used on the pre-recorded DVD-Videos you purchase in local

8 cm / 12 cm, single-sided, single layer disc Max. recording time (SEP mode, approx.): 600 minutes (4.7 GB) (for 12 cm) 180 minutes (1.4 GB) (for 8 cm)

shops. You can play back the discs recorded in this format on most of the DVD players. You will need to finalise such discs (see page 49) before playing them back on other DVD players. Unless finalised, you can record additional materials or edit discs recorded in Video mode with this unit. VR (Video Recording) mode is a basic recording format for DVD-RW discs.

If you want to record repeatedly on the same disc, or if you want to edit the disc after recording, use a rewritable DVD-RW type disc. If you want to save recordings without any alteration, use a non-rewritable DVD-R type disc.

Page 28

E439BBD_EN.book Page 29 Wednesday, May 31, 2006 4:01 PM

Recordable discs

• Discs that can be used with this recorder: DVD-R: 2x, 4x, 8x or 16x DVD-RW: 2x or 4x

• Discs that have been tested and are proven to be compatible with this recorder: Maxell DVD-R, TDK DVD-RW 2x, Verbatim DVD-R 8x, JVC DVD-RW 4x

Disc type Disc format Functions

Video mode Playing back,

Video

DVD-RWDVD-RW

VR mode Playing back,

DVD-RWDVD-RW

Video mode

DVD-RDVD-R

Limited recording, Limited editing

Recording, Original / Playlist editing

Playing back, Limited recording, Limited editing

DVD players bearing the logo are capable of playing back DVD-RW discs recorded in VR mode.

Rec Mode

You can select a Rec Mode among 6 options. And the recording time and the picture / audio quality of recorded material depends on the Rec Mode you select.

Disc size

8 cm Disc

12 cm Disc

HDD (Internal)

Rec Mode

XP 18 min ✬✬✬✬✬✬ (good)

SP 36 min ✬✬✬✬✬

LP 72 min ✬✬✬✬

EP 108 min ✬✬✬

SLP 144 min ✬✬

SEP 180 min ✬ (poor)

XP 60 min ✬✬✬✬✬✬ (good)

SP 120 min ✬✬✬✬✬

LP 240 min ✬✬✬✬

EP 360 min ✬✬✬

SLP 480 min ✬✬

SEP 600 min ✬ (poor)

XP 34 hrs ✬✬✬✬✬✬ (good)

SP 68 hrs ✬✬✬✬✬

LP 136 hrs ✬✬✬✬

EP 204 hrs ✬✬✬

SLP 272 hrs ✬✬

SEP 340 hrs ✬ (poor)

Recording time

Video / Sound Quality

To select the Rec Mode you prefer, press [REC MODE]. The information of the selected media (internal HDD or DVD) will be displayed.

HDD P07 XP 17:32

Indicates the remaining time of the disc when recorded with the selected Rec Mode.

Press [REC MODE] repeatedly to change the Rec Mode. The speed will be changed each time you press it with the following order:

XP SP LP

EPSLPSEP

The information will disappear in a few seconds, or press [DISPLAY] to exit.

* The recording time is an estimate and actual

recording time may differ.

* Audio and video quality of the content being

recorded may degrade if the recording time becomes longer.

* Each time you press [REC MODE], remaining

recording time is displayed.

Note

• This recorder cannot record on CD-RW or CD-R discs.

• DVD-RW / R discs and CD-RW / R discs recorded on a personal computer or a DVD or CD recorder may not be played back if the disc is damaged or dirty or if there is condensation on the player’s lens.

• If you record on a disc using a personal computer, there are cases in which it may not be played back because of the settings of the application software used to create the disc, even if it is recorded in a compatible format. (Check with the software publisher for more detailed information.)

• Discs recorded in Video mode on this unit cannot record additionally using other DVD recorders.

• Since the recording is made by the variable bit rate (VBR) method, the actual remaining time for recording may be a little bit shorter than the remaining time displayed on the OSD, depending on the picture you are recording.

• Playlist will be created automatically when recording to VR mode DVD-RW disc and HDD.

• DVD-RW once formatted with other DVD recorders cannot be recorded on this unit and vice versa.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 29

E439BBD_EN.book Page 30 Wednesday, May 31, 2006 4:01 PM

Restrictions on recording

You cannot record copy-protected video using this unit. Copy-protected video includes DVD-Videos and some satellite broadcasts. If copy-protected material is detected, recording will pause or stop automatically and an error message appears on the screen. You can only record “Copy-once only” video using a DVD-RW disc in VR mode with Content Protection for Recordable Media (CPRM). When recording a TV broadcast or an external input, you can display copy control information on the screen.

CPRM is a scrambling copy protection system for the protection of “copy-once” broadcast programmes. This unit is CPRM compatible, which means that you can record copy-once broadcast programmes, but you cannot make a copy of those recordings. CPRM recordings can only be played back on DVD players that are specifically compatible with CPRM.

Maximum recordable numbers of title / chapters: HDD: 300 titles per each Playlist and

Original List 999 chapters per title

VR mode DVD: 99 titles per each Playlist and

Original List 999 chapters per each Playlist and Original List

Video mode DVD: 99 titles per disc

99 chapters per title

Information on copy control

Some satellite broadcasts include copy-protected information. If you wish to record them, refer to the following.

Copy-

Disc type / format

HDDHDD

ver. 1.1 / ver. 1.2

DVD-RWDVD-RW

DVD-RDVD-R

VCRVCR

ver. 1.1 / ver. 1.2 CPRM compatible

ver. 1.1 / ver. 1.2

Video

ver. 1.1 / ver. 1.2 CPRM compatible

ver. 2.0

: Recordable : Not recordable

free

once

Copyprohibited

Making discs playable in other DVD players (Finalise)

After recording, you must finalise the disc to play it back on other players. (See page 49.) You cannot finalise discs in other DVD recorders.

• For Video mode discs, the finalisation is required.

• For VR mode discs, the finalisation is recommended.

• For the information on videotapes, refer to “VCR Functions” on pages 89 to 91.

About HDD

HDD is a special component which has high recording density and is suited for long-time recording or highspeed cueing but by contrast, has many factors which can cause breakage. Use HDD on the premise that you should dub the recorded programmes to a DVD disc or a videotape to protect your precious videos.

HDD is a temporary storage location:

HDD is not a permanent storage location of the recorded contents. Be sure to use it as a temporary storage location until you watch the programmes once, edit them, or dub them to a DVD disc or a videotape.

Be sure to dub (back up) data promptly if you find abnormalities in HDD:

If there is mechanical trouble with the HDD, grinding or other sounds may be heard or blocky noise may appear on the image. If you continue to use as it is, deterioration may continue and eventually the HDD may not be used at all. If you notice these symptoms of a failing HDD, promptly dub the data to a DVD disc or a videotape. When an HDD fails, recovery of recorded content (data) may be impossible.

About the remaining capacity of HDD recording time:

In recording to HDD, the Remaining Capacity Display may differ from the actual recordable time as this unit adopts Variable Bit Rate encoding, which varies the recording (storage) amount of data in conformity with the information amount of video. Before recording to the HDD, ensure there is sufficient space on the HDD by deleting unnecessary titles in advance. (Remaining capacity will not increase if you only delete Playlists.)

Page 30

VD Recording Foror

mat

Video

mat disc?

E439BBD_EN.book Page 31 Wednesday, May 31, 2006 4:01 PM

Formatting a disc

Selecting the recording format type

DVD-RWDVD-RWVRDVD-RWDVD-RW

The recording format type you set here will be memorized and applied to the disc whenever you format DVD-RW discs.

Video

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

Advanced Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

DVD Disc Format

DVD Recording Format

Finalise

Disc Protect

Delete Playlist

Formatting a pre-recorded disc (Disc Format)

DVD-RWDVD-RWVRDVD-RWDVD-RW

If you format a pre-recorded disc, all the data contained in it will be erased and the disc will return to the blank media status. This feature is only available for the DVD-RW disc.

Video

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

Advanced Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

DVD Disc Format

DVD Recording Format

Finalise

Disc Protect

Delete Playlist

Introduction Connections Basic Setup Playback

Recording

2 Select “DVD Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “DVD Recording Format”

using [Cursor [ENTER].

Option window will appear.

U / D], then press

DDVD Recording F

Video

mat

4 Select “VR” or “Video” using

[Cursor

Your setting is activated.

• The default setting is “VR”.

U / D], then press [ENTER].

5 Press [SETUP] to exit.

Auto Format:

Whenever you load a brand new DVD-RW disc, the unit will automatically format the disc in the recording format type you set in this section. The following message will appear if a Timer Recording is programmed to start in 15 minutes: “In the middle of programming timer. Format disc?” If you select “Yes”, the formatting process will continue. If you select “No”, or do not reply within 1 minute, the formatting will not be performed. Auto Format will not be performed under the conditions listed below;

- During HDD Playback or recording.

Note

• The Recording Format Setting is effective only for DVD-RW discs. You cannot change the recording format for a DVD-R disc. DVD-R discs will always be in Video mode.

• You cannot mix two formats on one DVD-RW disc. When you load a disc once recorded before, the recording format cannot be changed even if you change it in the Setup Menu.

2 Select “DVD Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “DVD Disc Format” using

[Cursor

Confirmation window will appear.

U / D], then press [ENTER].

FForormat disc?

Yes No

4 Select “Yes” using [Cursor L / P],

then press [ENTER].

Final confirmation window will appear.

Are you sure?

Yes No

5 Select “Yes” using [Cursor L / P],

then press [ENTER].

Formatting will start. The progress bar extends depending on the progress status of formatting.

DVD Disc Format

Editing

Function Setup

VCR Functions Others

Page 31

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Advanced Menu

E439BBD_EN.book Page 32 Wednesday, May 31, 2006 4:01 PM

6 Formatting is complete when the

progress bar reaches to the right end.

Completed

• The screen returns to normal after formatting is completed.

• This operation may take awhile to be completed.

Note

• When you reformat the disc, all contents of the disc will be erased.

• A disc once formatted with this unit cannot be used on other DVD recorders unless finalised.

Monitoring the recording quality

HDDHDD

DVD-RWDVD-RWVRDVD-RWDVD-RW

Before recording on a DVD, you can confirm the quality of the picture and sound with the recording speed you selected.

If you are recording to the HDD, press [HDD] first. If you are recording to a disc, press [DVD] first.

Video

DVD-RDVD-R

1 In stop mode, press [REC MONITOR].

The TV will display the programme and output the sound you are about to record in the quality of the picture and sound (determined by the recording speed) you selected.

• If you want to change the Rec Mode (to improve

the recording quality), press [REC MODE] repeatedly. The Rec Mode is changed each time you press the button.

XP SP LP

Creating chapter marks automatically

HDDHDD

DVD-RWDVD-RWVRDVD-RWDVD-RW

You can sort out the recording by inserting chapter marks every set time interval.

Video

DVD-RDVD-R

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear. If “Advanced Menu” is displayed, proceed to step 3.

Easy Setting Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Advanced Menu

DVD Disc Format

DVD Recording Format

Finalise

Disc Protect

Delete Playlist

2 Select “Advanced Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

4 Select “Record” using

[Cursor

Record Menu will appear.

U / D], then press [ENTER].

Record

Auto Finalise

Auto Chapter

Bilingual Recording Audio

External Input Audio

• You cannot change the Rec Mode during recording.

2 Press [REC MONITOR] again to exit.

EPSLPSEP

5 Select “Auto Chapter” using

[Cursor

U / D], then press [ENTER].

Option window will appear.

Auto Chapter

Off

5 minutes

10 minutes

15 minutes

30 minutes

60 minutes

6 Select the desired time option using

[Cursor

Your setting is activated.

• The default setting is “15 minutes”.

U / D], then press [ENTER].

7 Press [SETUP] to exit.

Page 32

E439BBD_EN.book Page 33 Wednesday, May 31, 2006 4:01 PM

Note

• The actual setting time for chapter marks may differ from the time you selected in Video mode.

• Depending the recording time, a chapter with no image may be created at the end.

• Chapter marks will automatically be inserted at the set interval with “Auto Chapter”. (Chapter marks will not be inserted while recording is paused.) For chapter marks insertion at other points, refer to “Chapter Marker” on pages 78 to 79.

• With Video mode DVDs discs, you cannot add / delete chapter marks.

Selecting the sound mode

This unit can receive bilingual broadcasts.

You can switch between modes by pressing [AUDIO ] on the remote control. Each mode is indicated on the TV screen as follows.

• During reception of bilingual broadcasts

Display on

Mode Audio output

Main

Sub

Main / Sub

Main audio from both speakers

Sub audio from both speakers

• Main audio from the left speaker

• Sub audio from the right speaker

the TV

screen

Main

Sub

Main / Sub

Setting External Input Audio

HDDHDD

When the external input audio is a bilingual broadcast, or when copying a video tape to a DVD disc, you can choose “Stereo” or “Bilingual” to record on a DVD.

DVD-RWDVD-RWVRDVD-RWDVD-RW

Video

DVD-RDVD-R

1 In stop mode, press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear. If “Advanced Menu” is displayed, proceed to step 3.

2 Select “Advanced Menu” using

[Cursor

U / D], then press [ENTER].

Introduction Connections Basic Setup Playback

Recording

3 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

4 Select “Record” using

[Cursor

U / D], then press [ENTER].

5 Select “External Input Audio” using

[Cursor

U / D], then press [ENTER].

6 Select “Stereo” or “Bilingual” using

[Cursor

L / P], then press [ENTER].

External Input Audio

Stereo Bilingual

7 Press [SETUP] to exit.

Hint

• If you select “Stereo”: The audio will be recorded as “stereo audio”.

• If you select “Bilingual”: The audio will be recorded as “bilingual audio” (see “Setting Bilingual Recording Audio” on page 34 for more detail).

Editing

Function Setup

VCR Functions Others

Page 33

E439BBD_EN.book Page 34 Wednesday, May 31, 2006 4:01 PM

Setting Bilingual Recording Audio

Video

DVD-RWDVD-RW

You can select either “Main” or “Sub” audio to record a bilingual broadcast in Video mode.

DVD-RDVD-R

Basic Recording

HDDHDD

Follow the steps below to record a TV programme.

DVD-RWDVD-RWVRDVD-RWDVD-RW

Video

DVD-RDVD-R

1 In stop mode, press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear. If “Advanced Menu” is displayed, proceed to step 3.

2 Select “Advanced Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

4 Select “Record” using

[Cursor

U / D], then press [ENTER].

5 Select “Bilingual Recording Audio”

using [Cursor [ENTER].

U / D], then press

6 Select “Main” or “Sub” using

[Cursor

L / P], then press [ENTER].

Bilingual Recording Audio

Main Sub

7 Press [SETUP] to exit.

Note

• If you are recording onto a VR mode disc, both “Main” and “Sub” will be recorded regardless of your setting here. And when you play back, you can choose either audio format or a combination of both as your playback audio.

• Use only the HDD or CPRM-compatible VR mode DVD-RW discs for recording copy-once programmes. (See page 30.)

If you are recording to the HDD, press [HDD] first. If you are recording to a disc, press [DVD] first. Insert a recordable disc if you are recording to a DVD.

1 Turn on the TV. Select the

appropriate external input channel.

(See pages 22 to 23.)

2 Select a Rec Mode using

[REC MODE].

(See page 29.)

3 Select the desired channel to record

using [PROG. [the Number buttons].

/ ] or

4 Press [REC / OTR I] (HDD / DVD) to

start recording.

The information will be displayed for 5 seconds.

To pause the recording, press [PAUSE p]. Press [REC / OTR I] (HDD / DVD) or [PAUSE p] to resume the recording.

5 Press [STOP S] to stop the

recording.

Note

• Recording starts immediately after you press [REC / OTR I] (DVD) and continues until the disc is full or you stop recording.

• When the Clock Setting has not been made, the space for a date and time of title names in the Original List or Playlist will be blank.

• Up to 300 titles can be recorded on the HDD.

• Up to 99 titles can be recorded on the DVD-RW / R discs.

• You cannot change the recording mode during HDD/ DVD recording.

• If you want to monitor the programme that you are recording, make sure the device such as a Satellite Box is turned off when it is connected to AV2.

• NTSC recording is prohibited in this unit.

Page 34

E439BBD_EN.book Page 35 Wednesday, May 31, 2006 4:01 PM

One-touch Timer Recording (OTR)

HDDHDD

This is a simple way to set the recording time in blocks of 30 minutes.

If you are recording to the HDD, press [HDD] first. If you are recording to a disc, press [DVD] first.

Preparing for OTR:

• Check that the recording media has enough

• If you are recording to a DVD, insert a

• Use only the HDD or CPRM-compatible VR

DVD-RWDVD-RWVRDVD-RWDVD-RW

recordable space for the time you set.

recordable disc.

mode DVD-RW discs for recording copy-once programmes. (See page 30.)

Video

DVD-RDVD-R

1 Turn on the TV. Select the

appropriate external input channel.

(See pages 22 to 23.)

2 Select a Rec Mode using

[REC MODE].

Refer to “Rec Mode” on page 29.

• You can check the current Rec Mode by

pressing [REC MONITOR].

3 Select a desired channel to record

using [PROG. [the Number Buttons].

/ ] or

4 Press [REC / OTR I] (HDD / DVD).

Recording will start.

HDD MODE

HDD Rec 0:06:50 P08

65:56

5 Press [REC / OTR I] (HDD / DVD)

repeatedly to change the recording time.

HDD MODE

HDD Rec 0:06:50 P08

65:56LP

OTR (0:30)

0:30

(Normal Recording)

1:00

8:00 7:30

The recording time will be extended by 30 minutes every time you press [REC / OTR I] (HDD / DVD).

• The maximum recording time is 8 hours.

• With HDD / DVD OTR, the recording time that exceeds the remaining time of the recording media will not be displayed.

• To change the recording time during the One-touch Timer Recording, press [REC / OTR I] (HDD / DVD) repeatedly.

6 When OTR ends, the unit will turn off

automatically except under conditions listed below.

- If a Timer Recording is programmed to start in 5 minutes.

- During playback of HDD / DVD / VCR.

- During recording of HDD / DVD / VCR.

- While displaying menus or information on the screen.

• To cancel the OTR in progress, press

[STOP S].

Note

• The remaining recording time will be displayed on the Front Panel Display during a One-touch Timer Recording. Press [DISPLAY] to see it on the TV screen.

• You cannot pause a One-touch Timer Recording.

• The unit will turn off automatically under the following conditions.

- When a power failure occurs.

• If you want to monitor the programme that you are recording, make sure the device such as a Satellite Box is turned off when it is connected to AV2.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 35

E439BBD_EN.book Page 36 Wednesday, May 31, 2006 4:01 PM

Timer Recording

HDDHDD

DVD-RWDVD-RWVRDVD-RWDVD-RW

You can programme the unit to record up to 32 programmes within a month in advance. Daily or weekly recordings are available.

Preparing for Timer Recording:

• Be sure to set the clock before programming a Timer Recording. Refer to “Setting the clock” on page 26.

• Check that the recording media (internal HDD or DVD) has enough recordable space for the time you set.

• Insert a recordable disc if you are recording to a DVD.

• Use only the HDD or CPRM-compatible VR mode DVD-RW discs for recording copy-once programmes. (See page 30.)

Video

DVD-RDVD-R

1 Press [TIMER PROG.].

Timer Programming List will appear.

Mode

1:00HDD SP

PDC

1 / 1

TIMER PROGRAMMING

Wed 20 / 12 23:30

Start

Date

Sun

31/12 19:00 20:00 P12 HDD Off

End CH

New Program

HDD/DVD

• You can access this screen from the Setup Menu also.

2 Select a line indicated “New

Program” using [Cursor press [ENTER].

Timer Programming Window will appear.

Start

Sun

Date

31/12

End

19:00 20:00

1 Recording Date:

When pressing [Cursor D] at the current date, the setting will change as follows.

e.g., 1st January

01/01

Daily

Mon-Fri

W-Sat

W-Fri

W-Sun

31/01

2 Start Time: 3 End Time: 4 Recording Channel:

To record from an external input, select “AV1”, “AV2” or “AV3”. (Using camcorder or other source.)

HDD/DVD

P12 HDD OffSP

U / D], then

Mode PDC

5 Recording Media (HDD or DVD):

To record onto the HDD, select “HDD”. To record onto a disc, select “DVD”. VCR is not compatible with Timer Recording.

6 Rec Mode:

Refer to “Rec Mode” on page 29.

7 Available recording time left on the HDD /

DVD under the programmed Rec Mode.

• If there are more than one programme, the recording time of the programmes other than the one being edited currently will not be counted in the calculation of the total remaining time on the HDD disc.

8 PDC system:

Refer to “PDC (Programme Delivery Control)” on page 37.

• PDC system is only available for HDD.

3 Select an item to set using

[Cursor to suit your preference using [Cursor

• Pressing [RETURN] will reset all the information entered.

L / P], and set the contents

U / D].

4 Press [ENTER] when all the

information is entered.

The icon will appear on the Front Panel Display indicating one or more Timer Recordings are in standby.

• To set another programme, repeat steps 2 to 4.

• When programmes are overlapped, a warning message “Timer program overlap.” will appear. For details on overlapped Timer Programmings, refer to “Hints for Timer Recording” on page 38.

5 Press [TIMER PROG.] to exit.

• If you press [ ON / STANDBY] to turn the unit to standby mode, it will turn on before 3 minutes from the programmed recording time, and start recording at the programmed recording time. When the recording is completed, you will be asked whether to turn off the unit. The unit will be turned off automatically if you select “Yes” or if you

0:39HDD SP

do not make any selection within 1 minute.

• To stop recording in progress, press and hold [STOP S] for 2 seconds, or press [STOP S] on the front panel.

Relay Recording:

If the disc runs out of the space during Timer Recording to a DVD, or if there is no recordable disc in the unit, it automatically detects it and change the recording media to the HDD. This feature is available only for Timer Recording but not for OTR.

Note

• If you have not set the clock, the clock setting window will appear instead of Timer Programming List at step 1. Continue from step 3 in “Setting the clock” on page 26 before programming the timer.

• If a basic recording or One-touch Timer Recording is in progress on the VCR and the Timer Recording set for HDD or DVD is about to begin, the unit will automatically switch to the programmed channel within 15 seconds before the programmed time, and the recording in progress on the VCR will be cancelled UNLESS their recording channel is the same. If their recording channel is the same, the Timer Recording for HDD or DVD will start without cancelling the recording currently in progress on the VCR. In this case, the recording of the same channel will be made on both VCR and the HDD or DVD.

Page 36

Space Right

Left BS

Clear

Decide

Return

E439BBD_EN.book Page 37 Wednesday, May 31, 2006 4:01 PM

• If the starting time and the end time are the same, it will be recognised as 24 hours recording.

• If the starting time you entered is already in the past, the recording will start as soon as you activate the Timer Recording by pressing [ENTER] at step 4.

Editing the Timer Programming information

1 Press [TIMER PROG.].

Timer Programming List will appear.

TIMER PROGRAMMING

Wed 20 / 12 23:30 1:00HDD SP

Start

Date

Sun 31/12 19:00 20:00 P12 HDD OffSP

Sun 31/12 19:30 20:30 P10 HDD OffSP

Sun 31/12 20:30 21:00 P08 HDD OffSP

End CH

HDD/DVD

1 / 1

PDCMode

2 Select the programme you want to

edit using [Cursor [ENTER].

Editing Menu will appear.

U / D], then press

Program Change

Edit Title Name

Delete

3 To change the setting of a

programme:

1 Select “Program Change” using

[Cursor

Timer Programming Window will appear.

Date

Sun

2 Move to the item you want to change using

[Cursor

change the setting.

To edit a title name:

1 Select “Edit Title Name” using [Cursor

then press [ENTER].

Editing window will appear.

U / D], then press [ENTER].

31/12

Start

End

19:00 20:00

HDD/DVD

P12 HDD OffSP

L / P], then press [Cursor U / D] to

TIMER PROGRAMMING

B G L Q V

" ,

Decide

CDE HIJF

MNOK

RSTP

WXYU

3 #

[

b g

h m

n o s

(

)

;

{

]

}

Return

Space Right

Left BS

Clear

Mode PDC

t y

* >

0:39HDD SP

U / D],

Confirmation window will appear.

Delete this Timer Program?

Yes

You can access this screen by pressing [CLEAR] instead of [ENTER] at step 2. 2 If you want to delete the title, select “Yes” using

[Cursor

L / P].

4 Press [TIMER PROG.] to exit.

Note

• As to the Timer Programme in progress (which is shown in red in the Timer Programming List), you only can edit the end time. The changes made during recording will be recognised as only specific to that recording in progress and it will not affect the daily or the weekly recording setting.

PDC (Programme Delivery Control)

Programme Delivery Control (PDC) assures that the TV programmes you have programmed for timer recording are recorded exactly from beginning to end, even if the actual broadcasting time differs from the scheduled time due to a delayed start or extension of the programme duration. Furthermore, if a programme is interrupted, the recording will also be interrupted automatically and resumed when the programme starts again.

If the PDC signal drops out because the broadcast signal is weak, or if a broadcasting station does not transmit a regular PDC signal, the timer recording is performed in normal mode (without PDC) even if it was programmed for PDC. If the starting time of the PDC timer recording is between 0:00 and 3:59 on a given day, the PDC function will operate from 20:00 on the previous day to 4:00 on the next day. If the starting time of the PDC timer recording is between 4:00 and 23:59 on a given day, the PDC function will operate from 0:00 on the given day to 4:00 on the next day. This means that if the relevant programme is broadcasted within this period, it is recorded correctly. If the timer is not programmed correctly, the incorrect timer setting stays in effect unless you cancel it. To cancel an incorrect timer setting, refer to “Editing the Timer Programming information” on the left.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

2 By following the steps in “Guide to Edit Title

Name” on page 73, edit the title name. When you finish entering the title name, press

[PLAY P]. Or select “Decide” using [Cursor

U / D / L / P], then press [ENTER].

To delete a programme from the list: 1 Select “Delete” using [Cursor

U / D], then

press [ENTER].

Page 37

Satellite Link

Off

E439BBD_EN.book Page 38 Wednesday, May 31, 2006 4:01 PM

Hints for Timer Recording

The priority of overlapped settings:

When the Timer Programmings are overlapped, you will receive a warning message. If this happens, check the Timer Programming List and change it as necessary. Otherwise, the unit will prioritize recording as described below.

If the starting time is same:

• The Timer Programming set first (PROG. 1) has priority.

PROG. 1

PROG. 2

Actual recording

The first 15 seconds (approx.) will be cut off.

Different start time and different end time:

• A program with the earlier start time has the priority.

PROG. 1

PROG. 2

PROG. 3

Actual recording

The first 15 seconds (approx.) will be cut off.

PROG. 1 PROG. 2

PROG. 3 PROG. 2

PROG. 1

PROG. 2 recording will start after PROG. 1 recording is completed.

Satellite Link

You can set the unit to start recording whenever it detects the scart control signal from the external tuner.

• This feature is only available to HDD.

Preparing for the Satellite Link Timer Recording:

[Preparation of the external tuner]

• The external tuner should be equipped with some kind of timer function. Using timer function of the tuner, set it to be turned on when it comes to the time you want to start recording, and off when it comes to the time you want to finish recording. (Refer to the tuner’s manual on how to set the timer.)

• Make sure to turn off the external tuner when you finish setting.

[Preparation of this unit]

• Make sure to select the desired Recording mode beforehand.

External tuner (not supplied)

Scart cable (not supplied)

If the recording time entirely overlaps:

• The shorter Timer Programming (PROG. 2) is not recorded.

PROG. 1

PROG. 2

Actual recording

PROG. 1

If the End time of the programme currently being recorded and the Start time of the subsequent programme are same:

• If PROG. 1 is a DVD recorded programme, the beginning of PROG. 2 may be cut off.

PROG. 1

PROG. 2

Actual recording

The last 30 seconds (approx.) will be cut off.

PROG. 2PROG. 1

* The amount of time cut off differs depending on

the recording media.

HDD / DVD / VCR

AV2 (DECODER)

AV1

HDD/DVD

AUDIO

S-VIDEO

DIGITAL

OUT

AUDIO OUT

COAXIAL

(TV)

1 Press [SETUP].

Setup Menu will appear.

2 Select “Timer Program” using

[Cursor

U / D], then press [ENTER].

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Satellite Link

Timer Program

3 Select “Satellite Link” using

[Cursor

Confirmation message will appear.

U / D], then press [ENTER].

Satellite Link

OnOnOff

HDD/DVD/VCR

AERIAL

RF OUT

Page 38

E439BBD_EN.book Page 39 Wednesday, May 31, 2006 4:01 PM

4 Select “On” using [Cursor L / P],

then press [ENTER].

• “Warning The unit is now turned off to be in Satellite Link standby mode.” will appear and the unit will be turned off automatically as it goes into the Satellite Link standby mode.

• “sat” will appear on the front panel display at the start time.

• When the Satellite Link Recording starts, “sat IHDD” will appear on the front panel display.

• When the Satellite Link Timer Recording is over, the unit returns to the Satellite Link standby mode unless you cancel the Satellite Link function.

To cancel the Satellite Link function while in the Satellite Link standby mode: Press [ ON / STANDBY] to turn on the unit.

To cancel the Satellite Link function while the Satellite Link Recording is in progress: Press [ ON / STANDBY], and then press [STOP S].

• When a regular Timer Recording and the Satellite Link Timer Recording are overlapped, the regular Timer Recording has priority.

Example 1

Timer Recording

Satellite Link

Actual Recording

Example 2

Timer Recording

Satellite Link

Actual Recording

Example 3

Timer Recording

Satellite Link

Actual Recording

Example 4

Timer Recording

Satellite Link

Actual Recording

Introduction Connections Basic Setup Playback

Recording

Note

• You cannot set the Start / End time for the Satellite Link Timer Recording on this unit.

• The Satellite Link will not be activated unless the unit is in standby mode.

• Recording will be paused while the copy protection signal is being detected, and will resume when the copy protection signal is no longer detected.

• When a regular Timer Recording is completed, “Switch power off ?” will appear. If you select “Yes” or do not reply in one minute, the unit will be turned off automatically, and returns to the Satellite Link standby mode. If you select “No”, the unit will not be turned off and the Satellite Link function will not be activated as a result.

• When there is not enough space on the HDD, the unit cannot go into the Satellite Link Standby mode. Delete the unnecessary titles from the HDD in such case.

• If the unit is turned on during the Satellite Link Recording, the Satellite Link function will become ineffective at that point.

Editing

Function Setup

VCR Functions Others

Page 39

VCR

E439BBD_EN.book Page 40 Wednesday, May 31, 2006 4:01 PM

Information on dubbing

HDDHDD

VCR

DVD-RWDVD-RWVRDVD-RWDVD-RW

You can copy a HDD / DVD disc to a videotape or copy a videotape to a HDD / DVD disc. This function will be possible only if the DVD disc or the videotape is not copy protected. Before starting this function, prepare for the recording on the DVD-RW / R disc or the videotape. Refer to pages 28 to 30 (HDD / DVD) or page 89 (VCR).

Difference between Copy (dubbing) and Move:

COPY (dubbing) MOVE

programme

HDD

(internal)

The programme remains.

programme programme

DVD-RW DVD-RW

Available dubbing direction for copy-once programme:

From To

DVD-RW (VR) (CPRM-compatible)

HDD (Internal)

DVD-RW (VR)

Videotape

DVD-RW (Video)

DVD-R X

Videotape O

HDD (Internal) X

Videotape O

HDD (Internal) O

DVD-RW (VR) (CPRM-compatible)

DVD-RW (VR) (Not CPRM-compatible)

DVD-R X

O: Available X: Not available

*1: The programme (recorded) moves. (It will be

deleted from HDD.)

*2: You cannot dub the recorded programme to HDD

or DVD-RW again. (Copy control signal will be recorded to the videotape.) (Refer to page 30 for details about CPRM.)

Note

• When you dub using [DUBBING MODE], be aware that all the programmes in the Dubbing List will be erased when you switch Original List and Playlist. If you want to dub programmes from both lists (Original List and Playlist), finish up the dubbing of one list first and then make dubbing of the other list.

• NTSC dubbing is prohibited in this unit.

Video

DVD-RDVD-R

programme

HDD

(internal)

The programme does not remain.

One Touch Dubbing from HDD to DVD

With One Touch Dubbing, you can start dubbing right away with just one touch.

• Recordable DVD must be in the unit. (See pages 28 to 30.)

• There should be enough space on the recording DVD.

• Make sure to press the corresponding Device Select Button before using the device of your choice.

Limitations:

• You cannot dub to the finalised Video mode DVDs.

• You cannot dub to the protected VR mode DVDs.

• If the unit detects that the dubbing will not finish by 3 minutes before the Timer Recording, the dubbing cannot be started. Be noted that with HDD to DVD dubbing, the duration of the dubbing is the duration of the dubbing title (except for the High Speed Dubbing).

• If a copy control signal is detected, the dubbing cannot be started.

• You cannot dub to the DVD if the number of the titles or the chapters of the disc is at its limit.

• Dubbing cannot be executed during HDD or DVD recording.

• Dubbing cannot be executed while the Setup Menu is showing (except for the Title List).

*1,*2

1 There are three ways to start One

Touch Dubbing.

Method 1: Play the title you want to dub. When it

Method 2: Select the title you want to dub in the

comes to the point where you want to start dubbing from, press [STOP S] or

[PAUSE p]. Then, press [DUBBING HDD DVD] on the front

panel. The dubbing will start from there to the end.

• If there is not enough space left on the disc, the prohibited icon “ ” will appear and the dubbing will not be started.

Original List or Playlist. With the title selected (highlighted), press [DUBBING HDD DVD] on the front panel. Or with the title selected (highlighted), press [ENTER] to call up the Title List Menu. And select “Dubbing” using [Cursor

U / D], then press

[ENTER].

• The dubbing will start from the beginning of the title to the end of the title.

• When the disc runs out of the space, dubbing stops automatically.

Page 40

E439BBD_EN.book Page 41 Wednesday, May 31, 2006 4:01 PM

Method 3: If you press [DUBBING HDD DVD] on

the front panel in stop mode without selecting any title, the unit will start dubbing the last title in the Original List or the Playlist. It will start dubbing the title in the Original List if the Original List was the last selected list. It will start dubbing the title in the Playlist if the Playlist was the last selected list.

• If the title was in the resume stop mode, the dubbing will start from the resume point to the end.

• If the title was in the regular stop mode, the dubbing will start from the beginning of the title to the end.

• If there is not enough space left on the disc, the prohibited icon will appear and the dubbing will not be started.

Dubbing

Title 1 : 00 :56 (XP)

Dubbing HDD DVD XP

2 The dubbing will stop automatically

when it reaches the end of the title. If you want to stop the dubbing manually, follow the instructions below.

To stop the dubbing in preparation mode:

•Press [DVD], then press [STOP S].

To stop the dubbing in progress:

•Press [DVD], then press and hold [STOP S] for 2 seconds. Or press [STOP S] on the front panel.

Dubbing HDD DVD

Note

• You cannot switch the device mode except between DVD and VCR during HDD to DVD dubbing.

• High Speed Dubbing is not available for the One Touch Dubbing.

One Touch Dubbing from videotape to DVD

With One Touch Dubbing feature, you can start dubbing right away with just one touch.

• Recordable DVD must be in the unit. (See pages 28 to 30.)

• There should be enough space on the recording DVD.

• A videotape to be dubbed must be in the unit.

• Make sure to press the corresponding Device Select Button before using the device of your choice.

Limitations:

• You cannot dub to the finalised Video mode DVDs.

• You cannot dub to the protected VR mode DVDs.

• If a copy control signal is detected during dubbing, the dubbing will be stopped.

• Copy-once programmes which are recorded directly from the TV can be dubbed to the HDD / DVD.

• Copy-once programmes which are copied from the HDD / DVD to a videotape cannot be dubbed further from the videotape to the HDD / DVD.

• If the unit detects that the dubbing will not finish by 3 minutes before the Timer Recording, the dubbing cannot be started. Be noted that with VCR to DVD dubbing, the unit recognise DVD’s remaining time as the dubbing duration although the actual dubbing will end when the videotape ends.

• You cannot dub to the DVD if the number of the titles or the chapters of the disc is at its limit.

• Dubbing cannot be executed during recording of any device.

• Dubbing cannot be executed while the Setup Menu is showing (except for the Title List).

1 Play the contents you want to dub.

When it comes to the point where you want to start dubbing from, press [STOP S] or [PAUSE p].

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Dubbing HDD DVD XP

• This operation may take awhile to be completed.

Page 41

Dubbing VCR DVD

HDD D

VD HDD

HDD

VCR

VCR HDD

VCR

VCR DVDVD

High

E439BBD_EN.book Page 42 Wednesday, May 31, 2006 4:01 PM

2 Press [DUBBING VCR DVD] on the

front panel.

The dubbing will start.

Dubbing VCR DVD

To stop the dubbing in preparation mode:

•Press [DVD], then press [STOP S].

To stop the dubbing in progress:

•Press [DVD], then press and hold [STOP S] for 2 seconds. Or press [STOP S] on the front panel.

Dubbing VCR DVD

Dubbing VCR DVD XP

• This operation may take awhile to be completed.

Note

• When dubbing starts, the video image may be distorted because of the Digital Tracking function. This is not a malfunction. Play the videotape until the image clears up and then start the dubbing.

• Playback audio is determined by the setting you make in “Selecting the Sound Mode” section on page 91.

• Dubbing takes as much time as the playback does.

• You cannot switch the device mode except between HDD and DVD.

• If you want to watch the duplicated material, after the VCR to DVD duplication, press [DVD] first then press [PLAY P].

Dubbing from HDD / DVD to videotape

You can copy the contents of the HDD / DVD to a videotape.

Limitations:

• If a copy control signal is detected during dubbing, the dubbing will be stopped.

• If the unit detects that the dubbing will not finish by 3 minutes before the Timer Recording, it will display a confirmation message asking if you really want to continue with the dubbing. If you select “Yes”, you can continue with the dubbing, and the Timer Recording will start after the dubbing ends. Be noted that with HDD / DVD to VCR dubbing, the duration of the dubbing is the duration of the dubbing title.

• An error message will appear if you try to add a programme to the Dubbing List when the total playback time of all the programmes in the Dubbing List exceeds 10 hours and 30 minutes.

Limitation (DVD to VCR):

• Only the contents of the VR mode DVDs or the Video mode DVDs made on this unit can be dubbed. Any other discs cannot be dubbed.

Preparing for dubbing:

• Insert a recordable videotape with a record tab intact.

• Make sure that the videotape has enough space to record the contents.

• Make sure the desired Rec Mode (SP / LP) is selected on the VCR in advance. (See page 89.) (You can change the Rec Mode during dubbing also.)

• If you are dubbing a title contains both main and sub audio, set the audio type you want to dub. To set the audio type, refer to “Switching audio soundtrack” on pages 67 and 68. If you want to dub both main and sub audio, select “Main / Sub” when you set the audio type.

Preparing for dubbing (DVD to VCR):

• If you are dubbing from a disc, insert a disc to be dubbed.

1 Press [DUBBING MODE].

The Dubbing Direction and the Rec Mode Menu will appear.

DUBBING

Dubbing Direction

HDD D

DVD HDD

HDD

VCR HDD

DVD

VCR D

VCR

Rec Mode

High

XP SP LP

EP SLP SEP Auto

Page 42

Direction HDD

VCR

Direction HDD

VCR

HDD

VCR Dub

E439BBD_EN.book Page 43 Wednesday, May 31, 2006 4:01 PM

2 For HDD to VCR dubbing:

Select “HDD VCR” using [Cursor

U / D], then press [ENTER].

For DVD to VCR dubbing: Select “DVD VCR” using [Cursor

Dubbing Top Menu will appear.

U / D], then press [ENTER].

Example: HDD ➞ VCR

DUBBING

Direction HDD

Select Program

Dubbing Start

VCR

Dubbing List

3 Select “Select Program” using

[Cursor

Program List will appear.

U / D], then press [ENTER].

DUBBING

Program List (Original)

1 Title 1

2 Title 2

3 Title 3

4 Title 4

5 Title 5

6 Title 6

7 Title 7

8 Title 8

Dubbing List

4 Select a desired programme using

[Cursor

Program List Menu will appear.

U / D], then press [ENTER].

Add to Dubbing List

Playlist

Decide

6 Repeat the steps 4 to 5 until you

select all programmes to be dubbed.

7 After selecting all the programmes

you want, press [RETURN] to go back to the Dubbing Top Menu. Or press [ENTER] to call up the option window and select “Decide”. Then press [ENTER] to go back to the Dubbing Top Menu.

DUBBING

Direction HDD

Select Program

Dubbing Start

VCR

Dubbing List

2 Title 2

4 Title 4

8 Select “Dubbing Start” using

[Cursor

Confirmation window will appear.

U / D], then press [ENTER].

Start Dubbing?

Yes No

9 Select “Yes” using [Cursor L / P],

then press [ENTER].

Dubbing will start.

Introduction Connections Basic Setup Playback

Recording

Editing

5 Select “Add to Dubbing List” using

[Cursor

The selected programme is added to the Dubbing List.

• If you want to select programmes from the

Playlist, select “Playlist” and press [ENTER] to call up the Playlist. Then follow the steps 4 to 5. (Be noted that Original List programmes and the Playlist programmes cannot be entered together in one Dubbing List.)

• If more than one programme is already in the Dubbing List, a green line will appear in the Dubbing List. Move the line to the position you want to insert the programme using

[Cursor

programme is inserted in the selected position.

U / D], then press [ENTER].

DUBBING

Program List (Original)

1 Title 1

2 Title 2

3 Title 3

4 Title 4

5 Title 5

6 Title 6

7 Title 7

8 Title 8

U / D], then press [ENTER]. The

Dubbing List

2 Title 2

HDD

VCR Dub

bing

• It may take awhile to prepare for the dubbing.

To stop the dubbing while in the dubbing preparation mode:

•Press [VCR] first, then press [STOP S]. Or press [STOP / EJECT O/S] on the front panel.

To stop the dubbing in progress:

•Press [VCR] first, then press and hold [STOP S] for 2 seconds. Or press [STOP / EJECT O/S] on the front panel.

Note

• You cannot change the device mode between VCR and HDD / DVD during the HDD / DVD to VCR dubbing.

• If you want to watch the duplicated material, after the DVD to VCR duplication, press [VCR] first then press [PLAY P].

Function Setup

VCR Functions Others

Page 43

HDD D

VD HDD

HDD

VCR

VCR HDD

VCR

VCR DVDVD

High

HDD DVDVD

VD HDD

HDD

VCR

VCR HDD

VCR

VCR D

Direction HDD DVDVD

Mode XP

E439BBD_EN.book Page 44 Wednesday, May 31, 2006 4:01 PM

Bi-directional Dubbing between HDD and DVD

You can copy the contents of the HDD to a DVD, or vice versa.

Limitation:

• If the unit detects that the dubbing will not finish by 3 minutes before the Timer Recording, the dubbing cannot be started. Be noted that with HDD to DVD dubbing (or vice versa), the duration of the dubbing is the duration of the dubbing title (except for the High Speed Dubbing).

Limitations (HDD to DVD):

• You cannot dub to the finalised Video mode DVDs.

• You cannot dub to the protected VR mode DVDs.

• If you try to dub copy-once programmes, you will be warned that the copy-once programmes cannot be copied but only be moved. If you still want to continue with the dubbing (moving), select “Yes” and continue with the steps. Moving of the copy-once programmes is only available with VR mode DVD-RW (CPRM compatible) discs.

• An error message will appear if you try to add a programme to the Dubbing List under the following conditions;

- When the number of programmes in the

“Dubbing List” exceeds 32 programmes.

- When the total number of titles in the DVD will

exceed 99 titles.

- When the total number of chapters in the DVD

will exceed 999 chapters for VR mode DVDs.

Just Dubbing:

When dubbing from HDD to DVD if you select “Auto” in the Rec Mode Menu, the unit will calculate the duration of the dubbing material and the remaining time in the disc and automatically select the most suitable Rec Mode for the dubbing.

1 Press [DUBBING MODE].

The Dubbing Direction and the Rec Mode Menu will appear.

DUBBING

Dubbing Direction

HDD D

DVD HDD

HDD

VCR HDD

DVD

VCR D

VCR

Rec Mode

High

XP SP LP

EP SLP SEP Auto

2 For HDD to DVD dubbing:

Select “HDD DVD” using [Cursor For DVD to HDD dubbing: Select “DVD HDD” using [Cursor

U / D], then press [ENTER].

Example: HDD ➞ DVD

DUBBING

Dubbing Direction

HDD D

DVD HDD

HDD

VCR HDD

DVD

VCR D

VCR

Rec Mode

High

EP SLP SEP Auto

Limitations (DVD to HDD):

• If a copy control signal is detected during dubbing, the dubbing will be stopped.

• The contents of the Video mode DVDs recorded on other unit cannot be dubbed using this unit.

• An error message will appear if you try to add a programme to the Dubbing List under the following conditions;

- When the total number of titles will exceed 300

titles.

Preparing for dubbing (HDD to DVD):

• Insert a recordable DVD. (See pages 28 to 30.)

• Make sure there is enough space on the DVD.

Preparing for dubbing (DVD to HDD):

• Insert a disc to be dubbed.

• Make sure there is enough space on the HDD.

High Speed Dubbing:

When dubbing from the HDD Original List to the VR mode DVD-RW, High Speed Dubbing will be available. High Speed Dubbing offers you the dubbing speed of 20 times the SEP mode dubbing. To perform the High Speed Dubbing, select “High” at step 3.

3 Select a desired Rec Mode using

[Cursor

Dubbing Top Menu will appear.

• If you select “Auto” for the Rec Mode, the unit will automatically calculate the remaining time and select the most suitable Rec Mode (HDD to DVD dubbing only).

• High Speed Dubbing is available only when dubbing the titles in the HDD Original List to the VR mode DVD.

U / D], then press [ENTER].

DUBBING

Direction HDD D

Mode XP

Select Program

Dubbing Start

Dubbing List

Page 44

Decide

Direction HDD DVDVD

Mode XP

E439BBD_EN.book Page 45 Wednesday, May 31, 2006 4:01 PM

4 Select “Select Program” using

[Cursor

Program List will appear.

U / D], then press [ENTER].

DUBBING

Program List (Original)

1 Title 1

2 Title 2

3 Title 3

4 Title 4

5 Title 5

6 Title 6

7 Title 7

8 Title 8

Dubbing List

5 Select a desired programme using

[Cursor

Program List Menu will appear.

U / D], then press [ENTER].

Add to Dubbing List

Playlist

Decide

6 Select “Add to Dubbing List” using

[Cursor

The selected programme is added to the Dubbing List.

U / D], then press [ENTER].

DUBBING

Program List (Original)

1 Title 1

2 Title 2

3 Title 3

4 Title 4

5 Title 5

6 Title 6

7 Title 7

8 Title 8

Dubbing List

2 Title 2

8 After selecting all the programmes

you want, press [RETURN] to go back to the Dubbing Top Menu. Or press [ENTER] to call up the option window and select “Decide”. Then press [ENTER] to go back to the Dubbing Top Menu.

DUBBING

Direction HDD D

Mode XP

Select Program

Dubbing Start

Dubbing List

2 Title 2

4 Title 4

9 Select “Dubbing Start” using

[Cursor

Confirmation window will appear.

Select “Yes” using [Cursor L / P], then press [ENTER].

Dubbing will start.

U / D], then press [ENTER].

Start Dubbing?

Yes No

Dubbing

Title 1 : 00 :56 (XP)

Introduction Connections Basic Setup Playback

Recording

• If you want to select programmes from the

Playlist, select “Playlist” and press [ENTER] to call up the Playlist. Then follow the steps 5 and

6. (Be noted that Original List programmes and the Playlist programmes cannot be entered together in one Dubbing List.)

• If more than one programme is already in the Dubbing List, a green line will appear in the Dubbing List. Move the line to the position you want to insert the programme using

[Cursor

U / D], then press [ENTER]. The

programme is inserted in the selected position.

7 Repeat the steps 5 to 6 until you

select all programmes to be dubbed.

Dubbing HDD DVD XP

Dubbing HDD DVD

• It may take awhile to prepare for the dubbing.

• During High Speed Dubbing, the playback picture will not appear.

Editing

Function Setup

VCR Functions Others

Page 45

Delete from Dub

Decide

osition Change

Delete from Dub

E439BBD_EN.book Page 46 Wednesday, May 31, 2006 4:01 PM

To stop the dubbing while in the dubbing preparation mode:

• Press the Device Select Button of the recording device first (for example, if you are dubbing to DVD, press [DVD] first), then press [STOP S].

To stop the dubbing in progress:

• Press the Device Select Button of the recording device first (for example, if you are dubbing to DVD, press [DVD] first). Then press and hold [STOP S] for 2 seconds. Or press [STOP S] on the front panel.

Note

• When dubbing from HDD to DVD (or vice versa), even if the selected Rec Mode is set to the higher quality than that of the material to be dubbed, the programme will not be recorded in the higher quality. It only protects the current picture quality.

• You cannot switch the device mode between HDD and DVD during the bi-directional dubbing between HDD and DVD.

• When you dub a copy-once programme from HDD to DVD, it will be moved to the disc (not copied) and the original data will be erased from the HDD.

Note on the High Speed Dubbing:

• Duration of the High Speed Dubbing will depend on the Rec Mode, the length, the disc type of the material to be dubbed.

• High Speed Dubbing is available only when dubbing the titles in the HDD Original List to the VR mode DVD.

Deleting a programme from the Dubbing List

1 If you are in the Dubbing Top Menu,

select “Select Program” and press [ENTER].

Program / Dubbing List will appear. If you are already in the Program / Dubbing List, proceed to step 2.

2 Press [Cursor P] to move to the

Dubbing List.

3 Select a programme you want to

delete using [Cursor press [ENTER].

Dubbing List Menu will appear.

Delete from Dub

Position Change

U / D], then

bing List

Decide

4 Select “Delete from Dubbing List”

using [Cursor [ENTER].

The programme is deleted.

U / D], then press

5 Press [RETURN] to go back to the

Dubbing Top Menu.

Changing the order of the dubbing list

1 If you are in the Dubbing Top Menu,

select “Select Program” and press [ENTER].

Program / Dubbing List will appear. If you are already in the Program / Dubbing List Screen, proceed to step 2.

2 Press [Cursor P] to move to the

Dubbing List.

3 Select a programme you want to

move using [Cursor press [ENTER].

Dubbing List Menu will appear.

Delete from Dub

Position Change

U / D], then

bing List

Decide

4 Select “Position Change” using

[Cursor

The selected programme will be replaced by a single line.

U / D], then press [ENTER].

5 Move the line to the desired position

using [Cursor [ENTER].

The programme is inserted in the selected position.

Dubbing from videotape to HDD / DVD

You can copy the contents of a videotape to HDD or DVD disc.

Limitation:

• If a copy control signal is detected during dubbing, the dubbing will be stopped.

Limitations (VCR to HDD):

• If the unit detects that the dubbing will not finish by 3 minutes before the Timer Recording, it will display a confirmation message asking if you really want to continue with the dubbing. If you select “Yes”, you can continue with the dubbing, and the Timer Recording will start after the dubbing ends. Be noted that with VCR to HDD dubbing, the unit recognise the HDD’s remaining time as the dubbing duration. The maximum possible duration is 10 hours and 30 minutes.

U / D], then press

Page 46

HDD D

VD HDD

HDD

VCR

VCR HDD

VCR

VCR DVDVD

HDD DVDVD

VD HDD

HDD

VCR

VCR HDD

VCR

VCR D

Direction

VCR HDD

Mode XP

E439BBD_EN.book Page 47 Wednesday, May 31, 2006 4:01 PM

Limitations (VCR to DVD):

• You cannot dub to the finalised Video mode DVDs.

• You cannot dub to the protected VR mode DVDs.

• Copy-once programmes which are recorded directly from the TV can be dubbed to the HDD and CPRM compatible VR mode DVD-RW.

• Copy-once programmes which are copied from the HDD / DVD to a videotape cannot be dubbed further from the videotape to the HDD / DVD.

• If the unit detects that the dubbing will not finish by 3 minutes before the Timer Recording, it will display a confirmation message asking if you really want to continue with the dubbing. If you select “Yes”, you can continue with the dubbing, and the Timer Recording will start after the dubbing ends. Be noted that with VCR to DVD dubbing, the unit recognise DVD’s remaining time as the dubbing duration although the actual dubbing will end when the videotape ends.

Preparing for dubbing:

• Insert a videotape to be dubbed.

Preparing for dubbing (VCR to HDD):

• Make sure there is enough space on the HDD.

Preparing for dubbing (VCR to DVD):

• Insert a recordable DVD. (See pages 28 to 30.)

• Make sure there is enough space on the DVD.

Press [VCR] first.

1 Press [PLAY P] to start playback of

the videotape, and press [STOP S] when it reaches the point you want to start dubbing.

2 Press [DUBBING MODE].

The Dubbing Direction and the Rec Mode Menu will appear.

DUBBING

Dubbing Direction

HDD D

DVD HDD

HDD

VCR HDD

DVD

VCR D

VCR

Rec Mode

High

EP SLP SEP Auto

Example: VCR ➞ HDD

DUBBING

Dubbing Direction

HDD D

DVD HDD

HDD

VCR HDD

DVD

VCR D

VCR

Rec Mode

SLP

SEP

4 Select a desired Rec Mode using

[Cursor

Dubbing Top Menu will appear.

U / D], then press [ENTER].

DUBBING

Direction

VCR HDD

Mode XP

Dubbing Start

Dubbing List

5 With “Dubbing Start” selected, press

[ENTER].

Confirmation window will appear.

Start Dubbing?

Yes No

6 Select “Yes” using [Cursor L / P],

then press [ENTER].

Dubbing will start.

To stop the dubbing while in the dubbing preparation mode:

• Press the Device Select Button of the recording device first (for example, if you are dubbing to DVD, press [DVD] first), then press [STOP S].

To stop the dubbing in progress:

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

3 For HDD dubbing:

Select “VCR HDD” using [Cursor For DVD dubbing: Select “VCR DVD” using [Cursor

U / D], then press [ENTER].

Note

• The device mode change is available only between HDD and DVD during the videotape to the HDD / DVD dubbing.

• After starting dubbing, the picture may be distorted because of the digital tracking function. This is not a malfunction. Be advised to playback the videotape until the picture is stabilized, then set the starting point at which you wish to start recording, and start dubbing.

• Playback audio is determined by the setting you make in the “Selecting the Sound Mode” section on page 91.

VCR Functions Others

Page 47

VCR

3 (FFrroonntt))

S-Viiddeeoo IInn

VCR

E439BBD_EN.book Page 48 Wednesday, May 31, 2006 4:01 PM

Settings for external equipment

Connection to external equipment

HDDHDD

VCR

Connect the external equipment using either the input jacks, AV1(TV) (Rear), AV2(DECODER) (Rear) or AV3 (Front). However, for AV3 jacks, you have to select S-VIDEO input or VIDEO input jacks depending on the connected devices. Use a commercially available Scart, S-Video or Video cable and an Audio cable for this connection.

DVD-RWDVD-RWVRDVD-RWDVD-RW

Video

DVD-RDVD-R

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear. If “Advanced Menu” is displayed, proceed to step 3.

2 Select “Advanced Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

4 Select “Display” using

[Cursor

Display Menu will appear.

U / D], then press [ENTER].

Display

Select Video

FL Dimmer

Screen Saver

5 Select “Select Video” using

[Cursor

U / D], then press [ENTER].

6 Select the video input type you use,

“Video In” or “S-Video In”, using [Cursor

Your setting is activated.

• The default setting is “Video In”.

U / D], then press [ENTER].

AAVV3 (

VViiddeeoo IIn

S-V

7 Press [SETUP] to exit.

Dubbing from the external devices

HDDHDD

VCR

Before recording from an external device, connect the external device correctly by following the direction on the left, and turn the power of the unit and the external device on.

DVD-RWDVD-RWVRDVD-RWDVD-RW

Video

DVD-RDVD-R

1 Turn on the TV. Select the

appropriate external input channel.

(See pages 22 to 23.)

2 Select the recording media.

Recording to HDD: Press [HDD] first.

Recording to DVD: Press [DVD] first and insert a disc.

• It may take awhile to load the disc.

Recording to a videotape: Press [VCR] and insert a videotape.

3 Select the appropriate external input

channel of this unit by pressing [INPUT SELECT]. You also can use [PROG.

• If you are using the jacks on the front, set the channel to “AV3”.

• If you are using the jacks on the rear, set the channel to “AV1” and “AV2”.

/ ].

4 Select a Rec Mode by pressing

[REC MODE].

Refer to “Rec Mode” on page 29 for HDD / DVD or page 89 for VCR.

5 Press [I REC] (of the recording

device) on this unit to start recording.

6 Press the PLAY button on the

external device to record from.

7 For HDD or DVD:

Press [STOP S] on the recording unit (this unit) first to stop recording.

• This operation may take awhile to be completed.

Then stop the external device.

For VCR: Press [STOP / EJECT O/S] on the recording unit (this unit) first to stop recording.

Then stop the external device.

Note

• To avoid mistakes, it is recommended to use the buttons on the front panel to operate.

• Read also the instructions for the external device thoroughly.

• If you want to monitor the programme that you are recording, make sure the device such as a Satellite Box is turned off when it is connected to AV2.

• NTSC dubbing is prohibited in this unit.

Page 48

E439BBD_EN.book Page 49 Wednesday, May 31, 2006 4:01 PM

Introduction Connections Basic Setup Playback

Setting disc protection

DVD-RWDVD-RW

To prevent accidental over-recording, editing or erasing of recordings, you can protect them using the Setup Menu.

1 In stop mode, press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

2 Select “DVD Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “Disc Protect” using

[Cursor

• If the disc has already been protected, “Disc Undo Protect” will be listed in the menu instead of “Disc Protect”. To undo the disc protection, select “Disc Undo Protect” and press [ENTER].

U / D], then press [ENTER].

4 Select “Yes” using [Cursor L / P],

then press [ENTER].

5 Select “Yes” again using

[Cursor

The disc is protected.

Note

• Disc Protect is available only for VR mode DVDs.

L / P], then press [ENTER].

Finalising a disc

Finalise

DVD-RWDVD-RWVRDVD-RWDVD-RW

You must first finalise the disc before playing it back on other unit.

Video

DVD-RDVD-R

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

Advanced Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

DVD Disc Format

DVD Recording Format

Finalise

Disc Protect

Delete Playlist

2 Select “DVD Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “Finalise” using

[Cursor

Confirmation window will appear.

U / D], then press [ENTER].

Finalise disc?

Yes No

Recording

• If the disc has already been finalised, “Undo Finalise” will be listed in the menu instead of “Finalise” (DVD-RW only). To Undo the finalisation of the disc, select “Undo Finalise” and press [ENTER].

4 Select “Yes” using [Cursor L / P],

then press [ENTER].

Final confirmation window will appear.

Are you sure?

Yes No

5 Select “Yes” using [Cursor L / P],

then press [ENTER].

A progress bar will appear, and finalising will start.

• If you want to stop the process, press [ENTER].

Finalise

• This operation may take awhile to be completed.

• Finalising ends when the progress bar reaches the right end.

Cancel

Editing

Function Setup

VCR Functions Others

Page 49

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Advanced Menu

E439BBD_EN.book Page 50 Wednesday, May 31, 2006 4:01 PM

Note

• If “ ” appears when [ENTER] is pressed, that

means the finalising process has reached the critical point and cannot be stopped.

• You cannot cancel finalising the DVD-R disc once it has started.

Auto Finalise

Video

DVD-RWDVD-RW

DVD-RDVD-R

You can finalise discs automatically when the disc space runs out if you set this in the Setup menu. This feature is available only for the Video mode DVDs.

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

Example: DVD-R (Advanced Menu)

Advanced Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

DVD Recording Format

Finalise

2 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

4 Select “Auto Finalise” using

[Cursor

Option window will appear.

The unit automatically finalises the disc when the disc space runs out.

U / D], then press [ENTER].

Auto Finalise

On Off

5 Select “On” using [Cursor L / P],

then press [ENTER].

Your setting is activated.

6 Press [SETUP] to exit.

Note

• Although finalisation is recommended, you may be able to play the VR mode discs on other unit without finalising. With regard to the Video mode discs, you MUST finalise them before playing them back on other unit.

• After DVD-R discs are finalised:

- A DVD Menu is created automatically.

- Undo finalisation is impossible.

- Additional recording or editing is impossible.

• After Video mode DVD-RW discs are finalised:

- A DVD Menu is created automatically.

- Undo finalisation is possible.

- Additional recording or editing is possible if you undo finalise.

• After VR mode DVD-RW discs are finalised:

- A DVD Menu is not created.

- Undo finalisation is possible.

- Additional recording or editing is possible even without undo finalisation.

• When DVD Menu is created Title List will no longer be available.

• If timer programmes are set, you cannot finalise the disc from 1 hour (Video Mode) or 1 hour and half (VR Mode) before the timer programmes start.

• If you are using the “Easy Setting Menu”, proceed to step 4.

3 Select “Record” using

[Cursor

Record Menu will appear.

U / D], then press [ENTER].

Record

Auto Finalise

Auto Chapter

Bilingual Recording Audio

External Input Audio

Page 50

E439BBD_EN.book Page 51 Wednesday, May 31, 2006 4:01 PM

Playback

Information on playback

Read the following information before you play back a DVD.

Playable discs

You can play back all the discs listed on the right. Before attempting to play back a DVD, make sure it meets the requirements for Region Codes and Colour Systems as described in this section. Discs that bear any of the logos shown below will be played back correctly in this unit. Other disc types are not guaranteed to be played back.

Colour systems

DVDs are recorded using different colour systems throughout the world. The most common colour system, used primarily in the U.K. and other EU countries, is PAL. This unit uses the PAL system. However, it is also possible to play back DVDs using other colour systems, such as NTSC.

Disc Logo

DVD-Video

DVD-RW (VIDEO/VR mode,

files)

DivX

DVD-R (VIDEO mode,

files)

DivX

CD-DA (AUDIO CD)

VCD (VIDEO CD)

Introduction Connections Basic Setup Playback

Recording

DIGITAL VIDEO

Region codes

This unit has been designed to play back DVDs for Region Two (2). It is only possible to play back DVDs in this unit that are labelled for Region 2 or for ALL regions. You cannot play back DVDs that are labelled for other regions. Look for DVDs that bear either of the symbols shown below. If these region symbols do not appear on your DVD, you cannot play back the DVD in this unit.

The number inside the globe refers to region of the world. A DVD labelled for a specific region can only be played back in the unit with the same region code.

CD-RW (CD-DA FORMAT, MP3, JPEG, DivX

CD-R (CD-DA FORMAT, MP3, JPEG, DivX

is a trademark of DVD Format/Logo

Licensing Corporation.

files)

Editing

Function Setup

VCR Functions Others

Page 51

E439BBD_EN.book Page 52 Wednesday, May 31, 2006 4:01 PM

Basic playback

Hint for HDD / DVD playback

The contents of a HDD / DVD are generally divided into titles. Titles are sometimes further subdivided into chapters.

Start Rec. Stop/Start Stop Rec.

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2

Direct Playback

HDDHDD

DVD-RDVD-R

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

CDCDCD

Video

1 Turn on the TV. Select the

appropriate external input channel.

(See pages 22 to 23.)

• If you are playing the HDD, proceed to step 5.

2 Press [OPEN / CLOSE O] to open the

disc tray.

3 Place the disc on the disc tray with

its label facing up. Be sure to align the disc with the disc tray guide.

Disc tray guide

4 Press [OPEN / CLOSE O] to close

the disc tray.

5 Press [PLAY P] to start playback.

Playback will start.

• Depending on the media, the playback may start from a resume point. (See page 60.)

• If you are playing back a DVD-Video, a Disc Menu may appear. Refer to page 58 for more details about the Disc Menu.

6 Press [STOP S] to stop playback.

Note

• Some discs may start playback automatically.

• If no resume point is set when you stop HDD playback, it will start from beginning of the last title.

Playback from the Title List

HDDHDD

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-RWDVD-RWVRDVD-RWDVD-RW

Video

DVD-RDVD-R

1 Follow steps 1 to 4 in “Direct

Playback” on the left.

• If you are playing the HDD, follow step 1 in “Direct Playback”.

2 Press [TOP MENU].

Title List will appear. Press [MENU / LIST] to switch Original List / Playlist if necessary.

• To exit the Title List, press [TOP MENU] or [RETURN].

3 Select a desired title using

[Cursor [PLAY P].

Playback will start.

•Use [Cursor titles one by one, and use [FWD f] or [REV r] to jump to the next / previous Title List page.

• For HDD, playback will start from the resume point. If you want to start it from the beginning, use the Title List Menu.

U / D / L / P], then press

U / D / L / P] to move among the

4 Press [STOP S] to stop playback.

Playback from the Title List Menu

HDDHDD

(Not available for the DVD-Videos, the finalised Video mode DVDs, or the Video mode discs made on other unit)

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-RWDVD-RWVRDVD-RWDVD-RW

Video

DVD-RDVD-R

1 Follow steps 1 to 4 in “Direct

Playback” on the left.

• If you are playing the HDD, follow step 1 in “Direct Playback”.

2 Press [TOP MENU].

Title List will appear. Press [MENU / LIST] to switch Original List / Playlist if necessary.

• To exit the Title List, press [TOP MENU] or [RETURN].

3 Select a desired title using

[Cursor [ENTER].

Title List Menu will appear.

•Use [Cursor titles one by one, and use [FWD f] or [REV r] to jump to the next / previous Title List page.

U / D / L / P], then press

U / D / L / P] to move among the

Page 52

VCD

MP3

FILE LIST

E439BBD_EN.book Page 53 Wednesday, May 31, 2006 4:01 PM

4 If you want to play the title from the

beginning, select “Play From Start” using [Cursor

U / D].

Select “Resume Play” (HDD only) if you want to play the title from the point where it is stopped last time. Then press [ENTER].

Playback will start.

5 Press [STOP S] to stop the playback.

Playback from the DVD Menu

Video

DVD-RWDVD-RW

With finalised Video mode DVDs or the Video mode DVDs made on other units, a DVD Menu may be appeared instead of the Title List. DVD Menus are created automatically when you finalise a Video mode disc. With such discs, Title List is no longer available. Follow the steps below to play back a disc using the DVD Menu.

Press [DVD] first.

DVD-RDVD-R

1 Insert a disc.

DVD Menu may appear automatically. Otherwise press [TOP MENU] to call up the DVD Menu.

D V D M E N U

13/01 11:30 P01 XP

14/01 14:59 P03 SP

15/01 18:00 P02 SP

18/01 16:00 P02 SP

18/01 22:00 P02 SP

20/01 7:00 P02 SP

22/01 8:00 P02 SP

22/01 10:00 P02 SP

1 / 2

Press [STOP S] if you want to exit from the menu.

2 Select a desired title using

[Cursor or [ENTER].

Playback will start.

•Use [Cursor

previous Title List page.

U / D], then press [PLAY P]

L / P] to jump to the next /

3 Press [STOP S] to stop playback.

Note

• Operation may vary depending on the discs.

Playing back a DVD-Video / Video CD / CD

DVD-VDVD-V VCD

VCD CDCDCD

1 Follow steps 1 to 4 in “Direct

Playback” on page 52.

2 Press [PLAY P] to start playback.

Playback will start.

If you are playing back a DVD-Video or a Video CD, a menu may appear. See pages 58 to 59 for details.

3 Press [STOP S] to stop playback.

Playing back an MP3

MP3

Press [DVD] first.

1 The MP3 Menu will appear

automatically when you insert a disc. Or in stop mode, press [TOP MENU] to call up the MP3 List.

FILE LIST

<DIR>

FOLDER NAME 1 FOLDER NAME 2 FOLDER NAME 3 FOLDER NAME 4 FOLDER NAME 5 FOLDER NAME 6

1 FILE NAME 1.MP3 2 FILE NAME 2.MP3

• To exit the menu, press [TOP MENU] again.

1/2

2 Press [Cursor U / D] to select the

desired folder (group) or file (track), then press [ENTER].

If a file is selected:

Playback will start.

If a folder is selected:

The files in the folder will appear. Press [Cursor want, then press [ENTER].

•Press [ENTER] or [FWD f] to move to any lower folders.

•Press [REV r] or [RETURN] to move back to the folder above.

U / D] to select a file or folder you

3 Press [STOP S] to stop playback.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 53

E439BBD_EN.book Page 54 Wednesday, May 31, 2006 4:01 PM

Hints for MP3 files:

• Folders are known as Groups, Files are known as Tracks.

• Folders are shown with the icon.

• The system can recognise up to 999 groups (or folders) per disc, and up to 999 tracks (or files) per disc.

• The maximum displayable number of letters for the group or the track name varies depending on their names. Unrecognisable characters will be replaced with asterisks (✶).

• Unplayable groups and tracks may be displayed depending on the recording conditions.

• For MP3 file recorded in Variable Bit Rate (VBR), the unit may not display the actual elapsed time.

It is recommended that files to be played back in this unit are recorded under the following specifications:

[MP3]

• Sampling frequency: 44.1 kHz or 48 kHz

• Constant Bit Rate: 112 kbps to 320 kbps

Note

• MP3 files cannot be recorded as digital sound using an MD or DAT deck.

• Files with extensions other than “.mp3 (MP3)” will not be listed in the File List.

• Some folders or files listed in the File List may be unplayable due to their recording status.

• The File List displays only up to 8 folder and file names.

3 Press [STOP S] to stop playback.

Notes on JPEG:

After the file is displayed for 5 seconds or 10 seconds (see “Slide Show” on page 64), the display will move to the next file. During JPEG playback, press [Cursor

[Cursor

counterclockwise respectively. (Not available when the display menu appears.) Files with extensions other than “.jpg/.jpeg (JPEG)” will not be listed in the File List.

[JPEG] Size of picture

• Upper limit: 6300 x 5100 dots

• Lower limit: 32 x 32 dots

• Capacity limit: less than 2.2 MB

• High resolution or large-size JPEG files take a few

• It is impossible to play back progressive JPEGs

• It is impossible to play back JPEG files of 2.2 MB or

L] to rotate a picture 90 degrees clockwise or

moments to be displayed.

(JPEG files saved in progressive format) on this unit.

more.

P] or

Playing back a JPEG

JPEGJPEG

Press [DVD] first.

1 Press [TOP MENU].

JPEG

• To exit the JPEG list, press [TOP MENU] again,

• If there are more than one page of JPEG list,

S] or [RETURN].

[STOP

press [FWD f] to jump to the next page or press [REV r] to jump to the previous page.

2 3

2 Press [Cursor U / D / L / P] to select

a desired file to be played back, then press [PLAY P] or [ENTER].

An image will be played back from the selected file and go to the next one in turn.

Page 54

FILE LIST

E439BBD_EN.book Page 55 Wednesday, May 31, 2006 4:01 PM

Playing back a DivX

DivX®DivX

1 The DivX

Menu will appear

automatically when you insert a disc. Or in stop mode, press [TOP MENU] to call up the DivX

FILE LIST

movie

Video on Demand Rental Video Download

1. Subtitle 1.avi

2. Movie.divx

3. Subtitle 2.avi

To exit the File List, press [TOP MENU] again.

List.

2/2

2 Press [Cursor U / D] to select the

desired folder (group) or file (track), then press [ENTER].

If a file is selected:

Playback will start.

If a folder is selected:

The files in the folder will appear. Press [Cursor you want, then press [ENTER].

•Press [ENTER] or [FWD f] to move to any

lower folders.

•Press [REV r] or [RETURN] to move back to

the folder above.

It is recommended that files to be played back in this unit are recorded under the following specifications:

]

[DivX

• Official DivX

• Plays all versions of DivX with standard playback of DivX

• Maximum size of image : 720 x 480 @30 fps

• Sampling frequency of audio : 8 kHz - 48 kHz

• Audio type : MPEG1 audio layer2,

Hint for the purchased or rental official DivX Certified product

• When you purchased or rental a DivX the DivX

registration code is required every time you get the new file from the DivX

VOD” on page 57.

“DivX

• Some DivX playable times (you cannot play them back beyond the limit). If your DivX playback confirmation screen will appear.

U / D] to select the file or folder

Certified product

video (including DivX® 6)

media files.

720 x 576 @25 fps

MP3 (MPEG1, 2, 2.5 audio layer3), Dolby Digital

file through

Video-On-Demand (VOD) services, a

VOD services. Refer to

VOD files are restricted with the limited

VOD file has such limit, the

Use [Cursor

L / P] to select “Yes” if you want to

play back the file, or to select “No” if you do not wish to play it back. Then, press [ENTER] to confirm the selection.

DivX VOD Rental

This rental has views left.

Do you want to use one

of your views now?

Yes No

• You cannot play back the DivX

VOD files, of which

rental period has been expired. In such case, press [TOP MENU] and select other files that can be played back.

Rental Expired

This rental is expired.

Please push ‘TOP MENU’.

Hint

•DivX® is a codec (compression/decompression) that can compress images to a very small amount of data. The software can compress video data from almost any sources to the size that can be sent on the Internet without compromising visual quality of the images.

• A file with an extension of “.avi” and “.divx” is called

file. All files with the “.avi” extention are

a DivX recognised as MPEG4.

• Files whose extension other than “.avi” and “.divx” will not be listed on the DivX

menu. However, unplayable groups or tracks may be displayed, depending on the recording conditions.

• Even if the file has an extension of either “.avi” and “.divx”, this unit cannot play it back if it is recorded in the format other than DivX

• Folders are known as Groups; files are known as tracks.

• A maximum of 255 folders or 999 files may be recognised in one disc.

• Up to 8 hierarchies can be recognised in one folder. Files in the 9th or deeper hierarchies cannot be played back.

• If the track extends beyond the scope of screen, a down arrow “D” appears, indicating that the user can view another part on the previous page. The current page number and the number of total pages are shown on the right of the down arrow “D”.

• The name of group and track can be displayed up to 29 characters. Unrecognisable characters will be replaced with asterisks (✶).

• You can play back the disc recorded in multisession.

• Playback will be paused if the File List is displayed during the playback.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 55

E439BBD_EN.book Page 56 Wednesday, May 31, 2006 4:01 PM

• It may take awhile for audio and images to be output

after you inserted a disc and pressed [PLAY P].

• When playing back the files recorded in high bit rates, the images can be interrupted in some occasions.

• Although DivX

logo has been obtained for this unit, it may not be able to play back some data, depending on the characteristics, bit rates, or audio format settings, etc.

• Use the software recognised by the DivX, Inc. when you make DivX

•A DivX

files.

file whose file size exceeds 2 GB cannot be

played back.

• When using tools or utilities to make up DivX read their instruction manual beforehand.

• Never use the MPEG4 tools when you make DivX files. Otherwise, noise or disturbance of the picture and sound may be generated.

• If a large-sized DivX

file is selected, it may take awhile to start the playback (over 20 seconds sometimes).

• If DivX

files written on CD discs cannot be played back, rewrite them on a DVD disc and try to play back.

• For more information for DivX http://www.divx.com

• You cannot play back the DivX

, please visit

VOD files obtained

with different registration codes on this unit. Press [TOP MENU] and select other files that can be played back.

files,

DivX® Subtitle

The subtitle created by the user can be displayed during DivX

1 After the DivX

playback.

file is selected, the

Subtitle List will appear.

Subtitle List

File

Subtitle 1

Off

Smi

Srt

Sub

2 Press [Cursor U / D] to select the

desired extension you want to display, then press [ENTER]. DivX with the subtitle starts playback. The subtitle cannot be displayed when the setting is “Off”.

• If there is more than one extension, the extension selection will appear in the Subtitle List.

Authorization Error

This player is not authorized to play

this video.

Please push ‘TOP MENU’.

Note

•DivX® subtitle can only be displayed according to the same name with an extension of the DivX

file

name.

• Files whose extension is other than “.SMI”, “.smi”, “.SRT”, “.srt”, “.SUB” and “.sub” will not be listed in the Subtitle List.

• This unit cannot be recognised if the DivX

file and

its subtitle file are not in the one folder.

• The subtitle may not be displayed if the file size is too large.

• To change the subtitle, refer to “DivX Subtitle” on page 86 if multiple subtitles are available.

• The subtitle cannot display if the on-screen information is displayed.

• If “DivX Subtitle” is set to “Off” in Playback menu, the Subtitle List will not be displayed even if you select a DivX

file with created subtitle. (Refer to

“DivX Subtitle” on page 86.)

• Unrecognisable characters will be replaced with asterisks (✶).

Page 56

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Advanced Menu

Angle Icon

Variable Replay/Skip Speed

Audio Out

Subtitle Language

Audio Language

Disc Menu Language

Parental Lock

TV Aspect

Playback

TV System

Media

DivX

E439BBD_EN.book Page 57 Wednesday, May 31, 2006 4:01 PM

Playing back discs contains mixture of different type of media

For playing back a CD-RW / R that contains mixture of different type of media (DivX need to setup which media to play.

, MP3, JPEG etc.), you

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear. If “Advanced Menu” is displayed, proceed to step 3.

Easy Setting Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Advanced Menu

DVD Disc Format

DVD Recording Format

Finalise

Disc Protect

Delete Playlist

2 Select “Advanced Menu” using

[Cursor

U / D], then press [ENTER].

3 Select “Initial Setup” using

[Cursor

U / D], then press [ENTER].

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Clock Setting

Channel Setting

Playback

Record

Display

Reset to factory default

DivX® VOD

DivX®DivX

This unit allows you to play back the files purchased or rented from DivX services. The files are available on the internet. When you purchase or rent DivX

Video-On-Demand (VOD)

VOD files on the internet, you will be asked to enter a registration code. This menu item provides you the registration code.

1 Follow the steps 1 to 4 on the left to

display the Playback Menu.

2 Select “DivX” using

[Cursor

DivX Menu will appear.

3 Select “DivX

[Cursor

Your registration code will appear.

U / D], then press [ENTER].

DivX

DivX®VOD

DivX Subtitle

VOD” using

U / D], then press [ENTER].

DivX VO D

Your registration code is :

12345678 To learn more visit www.divx.com/vod

Introduction Connections Basic Setup Playback

Recording

4 Select “Playback” using

[Cursor

Playback Menu will appear.

U / D], then press [ENTER].

Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Audio Out

Variable Replay/Skip Speed

Angle Icon

TV System

Media

DivX

5 Select “Media” using [Cursor U / D],

then press [ENTER].

Media Menu will appear.

Media

Video

Audio


6 Select the media to play using

[Cursor

Video : To play DivX® files. Audio : To play MP3 files. Picture : To play JPEG files.

U / D], then press [ENTER].

Note

• One registration code is only valid for one DivX® VOD file.

• You must first download the file from the internet and play it back on this unit before you are able to get another code.

• You must follow this step every time you purchase or rent a DivX

• For more information for DivX http://www.divx.com/vod

VOD file from the internet.

, please visit

Editing

Function Setup

VCR Functions Others

Page 57

E439BBD_EN.book Page 58 Wednesday, May 31, 2006 4:01 PM

Playing back discs using the Disc menu

DVD-VDVD-V

A DVD contains a disc menu, which lists the contents and enables you to customize playback. The menu may offer choices for subtitle languages, special features, and chapter selection. Usually this information appears automatically when you start playback, but sometimes you need to press

[MENU / LIST] to display the menu.

Press [DVD] first.

1 Press [MENU / LIST].

Disc Menu will appear. If the feature is not available, “ ” may appear on the TV screen.

2 Select an item using

[Cursor [ENTER].

Repeat this step until all the features you want are set up or to start playing back the disc from the menu. The following operations are available.

[MENU / LIST] button:

Displays the DVD Menu, which will vary among discs, and may be same with the Title menu.

[Cursor Move the cursor from item to item on the screen.

[ENTER] button:

Selects the currently highlighted menu option.

[the Number buttons]:

Selects a numbered menu option (available on certain discs).

U / D / L / P], then press

U / D / L / P] buttons:

3 Press [MENU / LIST] to exit the disc

menu.

Playing back discs using the Title menu

DVD-VDVD-V

Some DVDs have a title menu, which lists the titles available on the DVD. You can start playing back such discs at a specific title.

Press [DVD] first.

1 Press [TOP MENU].

Title Menu will appear. If the feature is not available, “ ” may appear on the TV screen.

2 Select a desired item using

[Cursor [ENTER].

The disc will start playing back at the title you selected. The following operations are available.

[TOP MENU] button:

Displays the DVD “Title Menu” which will vary between discs.

[Cursor Move the cursor from item to item on the screen.

[ENTER] button:

Selects the currently highlighted menu option.

[the Number buttons]:

Selects a numbered menu option (available on certain discs).

U / D / L / P], then press

U / D / L / P] buttons:

3 Press [TOP MENU] to exit.

Note

• [TOP MENU] will not be available for some DVDs.

• Menus vary among discs. Refer to the information accompanying the disc for details.

Note

• Menus vary among discs. Refer to the information accompanying the disc for details.

Page 58

VCD

DTS

PBC

Off

E439BBD_EN.book Page 59 Wednesday, May 31, 2006 4:01 PM

PBC function for Video CDs

Introduction Connections Basic Setup Playback

Cancelling and Recalling the PBC function

VCDVCD

This unit conforms to ver.1.1 and ver.2.0 of the Video CD standard playback control (PBC) function. This enables you to play back interactive software using menu screens. Refer to the information accompanying the Video CD. Ver.1.1 (without PBC function): You can still enjoy playback of pictures and music from the CD. Ver.2.0 (with PBC function): “Pbc” will appear on the front panel display when playing back a Video CD with the PBC function.

Hint

• When playing back Video CDs with the PBC function, “Pbc” is displayed instead of the playing back time and current track indications on the front panel display.

Note

• Some operations cannot be performed unless the function is cancelled either automatically or intentionally by you.

• Operations that are not available when the PBC function is set to “On” are indicated by the following symbol in this manual:

VCD

(PBC OFF)

Playing back a Video CD using the menu

VCDVCD

1 When playing back a Video CD with

the PBC function, the menu will appear automatically.

VCDVCD

Insert a Video CD.

1 In stop mode, press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

2 Select “CD” using [Cursor U / D],

then press [ENTER].

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Random Play

Program Play

PBC

3 Select “PBC” using [Cursor U / D],

then press [ENTER].

PBC Menu will appear.

PBC

Off

DTS

4 Select “Off” using [Cursor L / P],

then press [ENTER].

5 Press [SETUP] to exit.

To recall the PBC function, select “On” at step 4 above.

Note

• The default setting of “PBC” is “On.”

Recording

Editing

2 Press [the Number buttons] to select

the desired track.

Playback will start at the selected track.

3 Press [RETURN] to go back to the

menu.

Note

• While the Display appears, you cannot perform steps 2 and 3.

Function Setup

VCR Functions Others

Page 59

VCD JPEG

DivX

VCD

MP3

DivX

E439BBD_EN.book Page 60 Wednesday, May 31, 2006 4:01 PM

Special playback

Resume playback

HDDHDD

DVD-RDVD-R CDCDCD

DivX

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCD

(PBC OFF)

MP3MP3 JPEG

You can resume playback from the point where you stopped it before.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

Video

JPEG

1 During playback, press [STOP S].

Press [STOP S] twice will cancel the Resume function.

2 Press [PLAY P].

In a few seconds, playback will resume from the point at which you stopped it before. Even if you turn off the unit, you can resume playback at the same point after the unit is powered on.

For HDD: You can set a resume point per every title.

• If you play back from the Title List Menu, you can choose “Play From Start” or “Resume Play”. Otherwise the playback will start from the resume point of the last played title.

•Press [STOP S] twice at step 1 if you do not want to set a resume point. In this case, next time you press [PLAY P], the playback will start from the beginning of the last title in the Title List.

For DVDs: You can set only one resume point per disc.

• If a resume point is set, the playback will start from the resume point next time you press [PLAY P].

•Press [STOP S] twice at step 1 if you do not want to set a resume point. In this case, next time you press [PLAY P], the playback will start from the beginning of the first title in the Title List.

For Video CD, CD, MP3 and JPEG: You can set only one resume point per disc.

• If a resume point is set, the playback will start from the resume point next time you press [PLAY P] if you are playing a CD or Video CD with PBC off. As for the MP3 and JPEG files, the resume playback will start from the beginning of the track last played.

•Press [STOP S] twice at step 1 if you do not want to set a resume point. In this case, next time you press [PLAY P], the playback will start from the beginning of the disc.

To cancel the resume playback and start playing back the disc from the beginning: Press [STOP S] while playback is stopped.

Note

• For Video CDs, if you turn “PBC” on using the setting menu, the resume function is cancelled.

• For MP3 and JPEG files, playback will resume from the beginning of the track at which playback was stopped.

• Resume point will be lost when you;

- Open / Close the disc tray.

- Switch Original List and Playlist.

Fast forward / Fast reverse playback

HDDHDD

DVD-RDVD-R CDCDCD VCD

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCD

MP3

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

Video

DivX

1 During playback, press [FWD f] or

[REV r].

Each time you press [FWD f] or [REV r], the approximate speed will change as follows.

Press button

: +1

-3 -2 -1 0 +1 +2 +3

: -1

Speed

(HDD/DVD)

Speed

Speed (VCD)

Speed (MP3)

Speed

(DivX

indication

(CD)

OSD

x40 x20 x1

--x8

x16 x8 x2

- - x16

x40 x20 x5

)

• For HDD / DVD discs, sound will be output only during x1.5 fast forward if you set “Fast Forward with Audio” to “On” in the Setup Menu, otherwise the sound will be muted.

• For Audio CDs, approximate speed is fixed at x8 with sound.

• For Video CDs, approximate forward speeds are x1.5, x8 and x16, and approximate reverse speeds are x2, x8 and x16.

• For MP3 files, approximate speed is fixed at x16.

•For DivX

files, approximate forward speeds are x1.5, x20 and x40, and approximate reverse speeds are x5, x20 and x40.

• To return to playback at normal speed, press

[PLAY P].

• Picture quality of DivX lower than that in fast forward.

• For some DivX

files, Fast forward/Fast reverse

may not function.

Note

• Fast forward or fast reverse playback across titles (for HDD/DVD) or tracks (for VCD/MP3/DivX impossible.

Normal

x1.5 x20 x40

speed

Normal

x8 - -

speed

Normal

x1.5 x8 x16

speed

Normal

x16 - -

speed

Normal

x1.5 x20 x40

speed

files in fast reverse is

) is

Page 60

VCD

DivX

VCR

VCD

MP3

JPEG

DivX

E439BBD_EN.book Page 61 Wednesday, May 31, 2006 4:01 PM

Slow forward / Slow reverse playback

HDDHDD

DVD-RDVD-R VCD

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCD DivX

DivX

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

Video

1 During playback, press [PAUSE p],

then press [FWD f] or [REV r].

Each time you press [FWD f] or [REV r], the approximate speed change as follows. (The sound will remain muted.)

Press button

: +1

-3 -2 -1 0 +1 +2 +3

: -1

Speed

(HDD/DVD)

VCD,DivX®---

indication

x1/4 x1/8 x1/16

OSD

To return to normal playback, press [PLAY P].

Note

•For some DivX® files, Slow forward may not function.

• Only slow forward is available when playing back Video CDs and discs with DivX

Normal

x1/16 x1/8 x1/2

speed

Normal

x1/16 x1/8 x1/2

speed

files.

Simultaneous playback and recording

HDDHDD

DVD-RDVD-R

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCR

You can play back a title on one device while making a recording on other device. To do so, simply select the device (HDD, DVD or VCR) you like to use for the playback by pressing [HDD], [DVD] or [VCR] button during HDD/DVD/VCR recording. And then follow the normal playback procedure.

Only with regard to the HDD, you can playback a title in the same device (HDD). To do so, press [TOP MENU] during recording and select a title you like to play, and then press [PLAY P]. To playback a title being recorded while continuing to record, refer to “Time shift playback” on the left.

Note

• Video CDs, Audio CDs, MP3, JPEG and DivX® can also be played back during HDD/VCR recording.

Video

Pause

HDDHDD

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

Video

Introduction Connections Basic Setup Playback

Recording

Time shift playback

HDDHDD

You can playback a title being recorded from the beginning while recording continues.

Press [HDD] first.

1 Press [PLAY P] during recording.

Playback of the title you are recording will start from the beginning.

• Elapsed playback time will be displayed in the Front Panel Display.

2 To stop the playback, press [STOP S]

once

• The Front Panel Display will switch back to show the elapsed recording time.

Important

• If you press [STOP S] twice, it will stop the

recording.

Note

• You cannot use the OTR function during Time shift playback.

• Before you start Time shift playback, make sure no resume point is set on other titles.

DVD-RDVD-R

DivX

CDCDCD

VCD

VCD MP3

MP3

JPEG

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

1 During playback, press [PAUSE p].

Playback will pause with the sound muted.

2 Press [PLAY P] to resume playback.

Editing

Function Setup

VCR Functions Others

Page 61

VCD

DivX

VCD

JPEG

DivX

E439BBD_EN.book Page 62 Wednesday, May 31, 2006 4:01 PM

Step by step playback

HDDHDD

DVD-RDVD-R VCD

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCD DivX

DivX

Video

1 During playback, press [PAUSE p]. 2 Press [SKIP B / F] repeatedly.

Each time you press [SKIP F], playback will go forward one frame (or step) at a time with the sound muted. To go backward one frame (or step), press [SKIP B].

3 Press [PLAY P] to resume playback.

Note

• Only step by step forward is available when playing back Video CDs and discs with DivX

Variable replay / Variable skip

HDDHDD

DVD-RDVD-R

During playback, you can skip forward or backward by the amount of time you set in the Setup Menu. To set the time amount, refer to “6. Variable Replay/ Skip Speed” on page 86.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

Press [VARIABLE SKIP] if you want to skip forward. Press [VARIABLE REPLAY] if you want to skip backward.

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

files.

Video

Zoom

DivX

Video

HDDHDD

DVD-RDVD-R

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCD

VCD JPEG

JPEG DivX

1 During playback, press [DISPLAY]

twice.

Icons for the available features will appear.

2 Select the icon using

[Cursor

Option window will appear.

Four options are available, “x1.0”, “x1.2”, “x1.5” and “x2.0”. These are displayed excluding the current zoom rate.

L / P], then press [ENTER].

DVD MODE

1 / 1 1 / 1 0:00:04/ 1:30:00TC

1. 2

1. 5

2. 0

3 Select the desired zoom factor to

zoom using [Cursor press [ENTER].

The zoom area is displayed.

U / D], then

4 Select the desired zoom position

using [Cursor press [ENTER].

U / D / L / P], then

Zoom playback will start.

Note

• If selecting a smaller factor than that currently selected, the zoom area is not displayed.

• To cancel the zoom function, select “x1.0” using [Cursor

• You cannot slide the zoomed picture on some JPEG files.

U / D], then press [ENTER].

Page 62

VCD JPEG

DivX

VCD JPEG

E439BBD_EN.book Page 63 Wednesday, May 31, 2006 4:01 PM

Repeat / Random / Programme playback / Slide Show

Repeat playback

HDDHDD

DVD-RDVD-R CDCDCD

DivX

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCD

(PBC OFF)

MP3MP3 JPEG

Video

JPEG

1 During playback, press [DISPLAY]

twice.

2 Select the icon using

[Cursor

L / P], then press [ENTER].

3 Select the desired option to repeat

using [Cursor [ENTER].

The selected repeat playback will start. The following operations are available.

Title:

(Not available during Time shift playback) The current title will be played back repeatedly. (HDD and DVD)

Chapter:

(Not available during Time shift playback) The current chapter will be played back repeatedly. (HDD and DVD)

All:

The current disc will be played back repeatedly. (DVD-RW (VR mode), Audio CD, Video CD, MP3, JPEG and DivX

A-B:

The A-B point will be played back repeatedly. (HDD, DVD, Audio CD, Video CD and DivX

1. Select “A-B” using [Cursor [ENTER].

2. Press [ENTER] to set point “A”.

3. Press [ENTER] again to set the ending point “B” after point “A” is set.

The A-B Repeat Setting is activated.

Track:

The current track will be played back repeatedly. (Audio CD, Video CD, MP3, JPEG and DivX

Group:

The current group will be played back repeatedly. (MP3 and DivX

U / D], then press

)

U / D], then press

)

Introduction Connections Basic Setup Playback

Hint

• To cancel the repeat playback, select “Off” at step 3. The repeat setting is also cancelled when you stop playback.

Note

• You can only set A-B repeat playback within the current title (for HDD and DVD) or current track (for Audio CDs, Video CDs and discs with DivX

• Group Repeat is not available during the Random Playback.

•For some DivX not function.

• For Video CDs with PBC function, repeat playback does not work while PBC function is on.

files, A - B Repeat playback may

files).

Random playback

VCD

CDCD

(PBC OFF)

You can use this function to play back a disc randomly instead of recorded order.

MP3MP3 JPEG

JPEG

Recording

1 In stop mode, press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

2 Select “CD” using [Cursor U / D],

then press [ENTER].

3 Select “Random Play” using

[Cursor

Random playback will start.

Hint

• To cancel random playback, press [STOP S] twice during random playback.

• For Video CDs, if you select random playback with the PBC function on, the PBC function will be turned off automatically and random playback starts.

)

Note

• During random playback, if you forward the track to the end, the playback speed of the next track will be normal.

• During random playback, you cannot use the search function except for the search with [SKIP B / F]. By pressing [SKIP B], you can return only to the beginning of the current track.

U / D], then press [ENTER].

Editing

Function Setup

VCR Functions Others

Page 63

VCD

E439BBD_EN.book Page 64 Wednesday, May 31, 2006 4:01 PM

Programme playback

CDCD

VCD

(PBC OFF)

You can programme the disc to play back in your desired order.

1 Follow steps 1 and 2 in “Random

playback” on page 63.

2 Select “Program Play” using

[Cursor

Program play screen will appear.

U / D], then press [ENTER].

PROGRAM PLAY

12 345678910

12 34567891012 345678910

11 12 13 14 15 16 17 18 19 20

11 12 13 14 15 16 17 18 19 2011 12 13 14 15 16 17 18 19 20

21 22 23 24 25 26 27 28 29 30

21 22 23 24 25 26 27 28 29 3021 22 23 24 25 26 27 28 29 30

31 32 33 34 35 36 37 38 39 40

31 32 33 34 35 36 37 38 39 4031 32 33 34 35 36 37 38 39 40

41 42 43 44 45 46 47 48 49 50

41 42 43 44 45 46 47 48 49 5041 42 43 44 45 46 47 48 49 50

0:00:00Total

3 Select the desired track using

[Cursor or [Cursor

U / D], then press [ENTER]

P].

Slide Show

JPEGJPEG

You can select the display time between 5 seconds and 10 seconds.

1 Follow steps 1 and 2 in “Random

playback” on page 63.

2 Select “Slide Show” using

[Cursor

U / D], then press [ENTER].

3 Select the display time using

[Cursor

U / D], then press [ENTER].

4 Press [SETUP] to exit.

Note

• Large-size JPEG files take a few moments to be displayed.

4 Press [PLAY P] to start programme

playback.

Hint

• To erase tracks you entered, select the track and

then press [CLEAR].

• You can make up to 50 track settings.

• To cancel programme playback, press [STOP S]

twice during programme playback.

• You may also select the desired track using

[the Number buttons] at step 3.

• For Video CDs, if you select programme playback with the PBC function on, the PBC function will be turned off automatically and programme playback starts.

Note

• During programme playback, if you forward the track to the end, the playback speed of the next track will be normal.

• During programme playback, you cannot use the search function except for the search with [SKIP B / F].

Page 64

VCD JPEG

DivX

E439BBD_EN.book Page 65 Wednesday, May 31, 2006 4:01 PM

Title / Chapter search

HDDHDD

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

Video

Track search

MP3MP3 JPEG

CDCDCD

VCD

(PBC OFF)

Press [DVD] first.

Using [SKIP B / F] buttons

JPEG

DivX

Introduction Connections Basic Setup Playback

DVD-RDVD-R

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

Using [SKIP B / F] buttons

1 During playback, press [SKIP F] to

skip the current title or chapter and move to the next.

The unit moves to the next title or chapter one after the other.

To go back to the previous title or chapter, press

[SKIP B] twice in quick successions.

Using the [DISPLAY] button

1 During playback, press [DISPLAY]

twice.

2 Select the icon using

[Cursor

Searching for a Title:

L / P], then press [ENTER].

for the title number is highlighted.

3 Enter the desired title number to

search for using [Cursor [the Number buttons], then press [ENTER].

Title search will start.

Hint

• Total number of chapters and playback time of the selected title are also displayed.

Searching for a Chapter:

U / D] or

3 Press [Cursor L / P] to highlight the

number displayed in the right side of the icon.

1 During playback, press [SKIP F] to

skip the current track and move to the next.

The unit moves to the next track one after the other. To go back to the previous track, press

[SKIP B] twice in quick successions.

Using the [DISPLAY] button

1 During playback, press [DISPLAY]

twice.

2 Select the icon using

[Cursor

L / P], then press [ENTER].

for the track number is highlighted.

3 Enter the desired track number to

search for using [Cursor [the Number buttons], then press [ENTER].

Track search will start.

Hint

• For Video CDs, you can perform the track search function in stop mode without turning PBC off manually.

Note

• During random playback or programme playback, you cannot search the desired track.

U / D] or

Recording

Editing

Function Setup

4 Enter the desired chapter number to

search for using [Cursor [the Number buttons], then press [ENTER].

Chapter search will start.

Hint

• The title number and playback time of the selected chapter are also displayed.

U / D] or

VCR Functions Others

Page 65

VCD

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

No Ser

ies

002 Mon-F

i 10:00 P08

001

-Mon 10:00 P08

Select Ser

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

E439BBD_EN.book Page 66 Wednesday, May 31, 2006 4:01 PM

Time search

HDDHDD

DVD-RDVD-R CDCDCD

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCD

(PBC OFF)

DivX®DivX

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

Video

1 During playback, press [DISPLAY]

twice.

2 Select the icon using

[Cursor

L / P], then press [ENTER].

for the title or track number is highlighted.

3 Move the cursor to the elapsed time

counter using [Cursor

P].

4 Enter the desired time to search for

using [Cursor [the Number buttons], then press [ENTER].

Time search will start.

Hint

• For Video CDs, you can perform the time search function in stop mode without turning PBC off manually.

Note

• During random playback or programme playback, you cannot search the desired time.

• The title number and chapter number of the setting time are also displayed.

• Time search function is available only in the same track or title.

• If the time search is not available, – –:– –:– – / – –:– –:– – (or 0:00:00 / 0:00:00 for CD) is displayed instead of the time count.

U / D] or

Series search

HDDHDD

You can search for the group of titles made with the same Periodical Timer Recordings. We refer to such a group of titles as “series”. This feature is available only with the HDD.

Press [HDD] first.

1 Press [TOP MENU].

Title List will appear.

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

0:15

15/06/06

11:05

01/05/06

05/07/06

23:40

0:15

DVD

HDD

ORG

04/06/06

10:00

18/07/06

10:00

1 2

Press [MENU / LIST] to switch Original List / Playlist if necessary.

2 Select any title that belongs to the

series you want to search using [Cursor

U / D / L / P], then press

[ENTER].

Title List Menu will appear.

Play From Start

Resume Play

Protect

Delete

Edit

Dubbing

3 Select “Search” using

[Cursor U / D], then press [ENTER].

Series List will appear.

Select Ser

ies

001

W-Mon 10:00 P08

002 Mon-F

ri 10:00 P08

No Ser

ies

Highlight will be on the series that contains the

1/1

selected title.

4 Select the desired series using

[Cursor

Title List of the selected series will appear.

U / D], then press [ENTER].

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

18/07/06

10:00

08/08/06

10:00

25/07/06

10:00

15/08/06

10:00

DVD

HDD

ORG

01/08/06

10:00

22/08/06

10:00

1 2

Page 66

002 Mon-F

-Mon 10:00 P08

VCD

DivX

E439BBD_EN.book Page 67 Wednesday, May 31, 2006 4:01 PM

5 Select a desired title to play using

[Cursor [PLAY P]. Or press [ENTER] to call up the Title List Menu and select your desired playback style.

To show the regular Title List, select “Display All Program” from the Title List Menu. Then press

[ENTER].

1 Series List

• Up to 8 series can be displayed on 1 page.

• The series that contains the oldest title comes first on the list.

2 Information on the series.

• Type of the Periodical Recording (example: every Monday), start time, and the recording channel. (In the example here, the information tells you this series is recorded on every Monday, starting at 10:00 on P08.)

3 No Series

• All recordings which are not periodical fall into this category.

• “No Series” will always be at the last on the list.

4 Current page / Total number of pages.

• Up to 38 pages (300 series) are available.

Note

• The unit exits the Series search mode when you switch the list type or the device mode.

U / D / L / P], then press

Select Series

001 W-Mon 10:00 P08

ri 10:00 P08

002 Mon-F

No Series

1/1

Selecting the format of audio and video

You can select the format of audio and video to suit the content of the disc you are playing back.

Switching subtitles

DVD-VDVD-V DVD-RWDVD-RWVRDivX®DivX

Many DVD-Videos have subtitles in one or more languages. The available languages are usually printed on the disc case. You can switch subtitle languages at any time during playback.

Press [DVD] first.

1 During playback, press [DISPLAY]

twice.

2 Select the icon using

[Cursor

L / P], then press [ENTER].

3 Select the desired subtitle language

using [Cursor [ENTER].

Subtitles are displayed in the selected language. If you select “Off,” subtitles will disappear.

Note

• With some discs, it is only possible to change the subtitle language from the disc menu. Press [MENU / LIST] to display the disc menu.

• If a 4-digit language code appears in the subtitle menu at step 3, refer to the “Language code” on page 97.

• For discs with DivX the number of subtitle languages.

Switching audio soundtrack

HDDHDD

MP3MP3

When playing back a DVD-Videos recorded with two or more soundtracks (often in different languages), you can switch among them during playback. When playing back Audio CDs, Video CDs or MP3 files, you can switch among the left (L), the right (R) channel, and stereo (L / R).

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-VDVD-V DVD-RWDVD-RWVRCDCD

DivX

U / D], then press

files, the screen only displays

VCD

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 67

Dolby Digital 2ch English

Dolby Digital 5.1ch English

3. Dolby Digital 2ch English

L / R

1. MP3

2. MP3

3. MP3

4. MP2

5. Dolby Digital

7. MP3

8. MP3

1.Dolby Digital DUAL Main

Main

Sub

Main / Sub

VCD

DivX

E439BBD_EN.book Page 68 Wednesday, May 31, 2006 4:01 PM

1 During playback, press [AUDIO ]

to call up the available audio settings on the TV screen.

<Example: DVD-Video>

Dolby Digital 2ch English

Dolby Digital 5.1ch English

3. Dolby Digital 2ch English

<Example: CD / MP3 / Video CD>

L / R

<Example: DivX

1. MP3

2. MP3

3. MP3

4. MP2

5. Dolby Digital

7. MP3

8. MP3

2 Select a desired setting using

[Cursor

As in the example below, if the title contains both main and sub audio, you can further select “Main”, “Sub” or “Main / Sub”. Example:VR mode DVD-RW disc

Press [ENTER].

Using [Cursor then press [ENTER] to activate the setting.

U / D], then press [ENTER].

1.Dolby Digital DUAL Main

Main

Sub

Main / Sub

U / D], select the desired setting,

3 Press [DISPLAY] to exit.

[DISPLAY] button can also lead you to the AUDIO Menu. Simply press [DISPLAY] twice during playback to show the icons for the available features, then using [Cursor

and press [ENTER].

select

Note

• With some discs, it is only possible to change the

soundtrack from the disc menu. Press [TOP MENU] to display the disc menu.

L / P],

Switching camera angles

DVD-VDVD-V

Some DVD-Videos feature scenes shot from two or more angles. The disc case is usually marked with an angle icon if the disc has multi-angle scenes.

Press [DVD] first.

1 During playback, press [DISPLAY]

twice.

The angle icon appears when a switching camera angle is available. (Available only when the angle icon appears in bottom right on the TV screen.)

2 Select the icon using

[Cursor

The angle will switch each time you press

[ENTER].

Note

• “ ” will appear when Angle feature is not available.

Visual noise reduction

HDDHDD

DVD-RDVD-R VCD

This feature allows you to reduce visual noise during playback.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

L / P], then press [ENTER].

DVD-VDVD-V DVD-RWDVD-RWVRDVD-RWDVD-RW

VCD DivX

DivX

Video

1 During playback, press [DISPLAY]

twice.

2 Select the icon using

[Cursor

Option window will appear.

L / P], then press [ENTER].

3 Select the desired option using

[Cursor

This function reduces noise in the playback picture. When playing back discs recorded in long time modes such as SLP or SEP, select “Type 1” or “Type 2”. “Type 2” is more effective. When playing back discs with a little noise, such as DVD-Videos, select “Off”.

U / D], then press [ENTER].

Page 68

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

E439BBD_EN.book Page 69 Wednesday, May 31, 2006 4:01 PM

Editing

Disc editing

You can edit a disc recorded using the PAL system. It is impossible to edit discs recorded using the NTSC system.

Guide to the Title List

When you record programmes to the HDD / DVD, a title list will be created. Title list is the thumbnails of the recorded programmes (titles). You can call up the Title List by pressing [TOP MENU] and select the title of your choice from the list and can play or edit it from the Title List Menu.

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

15/06/06

0:15

11:05

01/05/06

0:15

05/07/06

23:40

DVD

HDD

ORG

04/06/06

18/07/06

1 2

10:00

Introduction Connections Basic Setup Playback

1 Selected device (HDD or DVD) and selected list

type (Original List or Playlist)

2 The number of the current Title List page / the

total number of the Title List pages Use [FWD f] to jump to the next page. Use

[REV r] to jump to the previous page. Use [Cursor

L / P] to move among titles one by one.

3 Date, time, recorded channel and Rec Mode (if

the title name has not been assigned yet, the date and the time of the recording was made, the recorded channel (Original List Titles in the HDD or VR mode DVD-RW only), and the Rec Mode (Original List only) will be assigned as the title name automatically.)

4 Thumbnails of the titles

Only the highlighted thumbnail can be seen in

motion.

5 Date and time of the title was recorded 6 Protect icon

This icon appears only when the title is protected (Original List only).

7 Status bar 8 Preview window

Recording

9 Progress bar

10 Command bar

Available Menus

Play From Start

Resume Play

Protect/Undo Protect Delete Edit Dubbing

Title List Menu

Protect/Undo Protect Delete Edit Title Name Scene Delete Divide Combine

Edit Menu

Move Chapter Mark Add To Playlist

: Available

{

× : Not available

SCENE DELETING

Item

HDD ORG

0:00:00

Start Point

Return

Media

Video Mode DVDs

VR mode DVDs

Original Playlist Original Original Playlist

{

{{{{{

{{

××

{

{{{{{

{{

{

{{

{{{

×××

{{{

{

×××

{

{{

××

{{

Page DescriptionHDD

52-53 To play from the beginning of the title.

To resume playback from the point where it is

stopped last time.

72 To protect/undo protect the title.

70-71 To delete a title.

40-47 To make copies.

To search for the group of titles made with the same

65-67

Periodical Timer Recordings

72 To protect/undo protect the title. 70-71 To delete a title. 72-73 To edit title names. 73-75 To delete a part of the title.

{

75 To divide a title into two titles.

To combine two titles into one.

To rearrange the order of the Title List.

78-79

To add/delete the chapter marks.

To add a title to the Playlist.

Editing

Function Setup

VCR Functions Others

Page 69

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

E439BBD_EN.book Page 70 Wednesday, May 31, 2006 4:01 PM

What are Original List and Playlist?

There are 2 types for the title list: Original List and Playlist.

Original List:

Original List is the list of the recorded programmes (titles) which are created automatically when they are recorded. Original List is available for HDD, DVD-RW and DVD-R. Please note that editing the titles in the Original List is like editing the original data. For example, if you erase a title in the Original List, the title cannot be recovered. So, please be careful when you work in the Original List.

Playlist:

Playlist is the copy of the Original List. You can edit the titles in the Playlist as you like without affecting the original data in the Original List. It works like a back up for the Original List. Delete a title from the Playlist does not delete the corresponding title in the Original List. But delete a title from the Original List, the corresponding title in the Playlist will be deleted. With HDD and VR mode DVD-RW, the Playlist is created automatically. Playlist is available only for the HDD and the VR mode DVDs. There is no Playlist for the Video mode DVDs.

Deleting titles

1 Press [TOP MENU].

Title List will appear.

Example: HDD Original List

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

0:15

15/06/06

11:05

01/05/06

05/07/06

23:40

0:15

DVD

HDD

ORG

04/06/06

10:00

18/07/06

10:00

1 2

Press [MENU / LIST] to switch Original List / Playlist if necessary.

2 Select a desired title to delete using

[Cursor [ENTER].

Title List Menu will appear.

U / D / L / P], then press

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

Play From Start

Resume Play

01/04/06

15/06/06

0:15

11:05

Protect

MAY/01/06

12:15

Delete

Edit

Dubbing

JUL/05/06

11:40

HDD

ORG

04/06/06

10:00

18/07/06

10:00

DVD

ORG

1 2

Deleting selected titles

HDDHDD

DVD-RWDVD-RWVRDVD-RWDVD-RW

[VIDEO] [VR] [ORIGINAL] [PLAYLIST]

You can delete titles which you do not need anymore. Be advised that the titles once deleted cannot be recovered. With DVD-R discs, deleting titles will not affect the recordable disc space. With Video mode DVD-RW discs, the disc space will increase only when the last title in the Original List is deleted. With VR mode DVD-RW discs, the disc space will increase when any title in the Original List is deleted. Deleting a title in the Playlist will not delete the corresponding title in the Original List.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

Video

DVD-RDVD-R

3 Select “Delete” using

[Cursor

Confirmation window will appear.

U / D], then press [ENTER].

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

0:15

15/06/06

11:05

Play From Start

Resume Play

Protect

MAY/01/06

Delete this program?

12:15

Delete

Yes No

Edit

Dubbing

JUL/05/06

11:40

DVD

HDD

ORG

04/06/06

10:00

18/07/06

10:00

1 2

4 Select “Yes” using [Cursor L / P],

then press [ENTER].

Final confirmation window will appear.

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

0:15

15/06/06

11:05

Play From Start

Resume Play

Protect

MAY/01/06

Delete this program?

Are you sure?

12:15

Delete

Yes No

Edit

Dubbing

JUL/05/06

11:40

DVD

HDD

ORG

04/06/06

18/07/06

1 2

10:00

Page 70

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Advanced Menu

Erase All in HDD

Pla

ylist All

iginal All

ase All in HDD

Delete all progrr

ams?

Are y

ou sure?

E439BBD_EN.book Page 71 Wednesday, May 31, 2006 4:01 PM

5 Select “Yes” using [Cursor L / P],

then press [ENTER].

The selected title is deleted.

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

0:15

05/07/06

23:40

01/05/06

0:15

18/07/06

10:00

DVD

HDD

ORG

15/06/06

11:05

20/07/06

11:30

1 2

6 Press [TOP MENU] to exit.

Note

• When a title is deleted from an Original List, corresponding title on the Playlist(s) will be also deleted.

• Deleting a Playlist will not increase the recordable disc space.

Deleting all titles in HDD

HDDHDD

3 With “Erase All in HDD” selected,

press [ENTER].

Option window will appear.

ErErase All in HDD

OrOriginal All

Pla

ylist All

4 Select the desired option using

[Cursor

Confirmation window will appear.

U / D], then press [ENTER].

Delete all prog

ams?

YYesesNo

5 Select “Yes” using [Cursor L / P],

then press [ENTER].

Final confirmation window will appear.

Are y

ou sure?

YYesesNo

6 Select “Yes” using [Cursor L / P],

then press [ENTER].

All titles in the selected list are erased.

Introduction Connections Basic Setup Playback

Recording

[ORIGINAL] [PLAYLIST]

Press [HDD] first.

1 Press [SETUP].

“Easy Setting Menu” or “Advanced Menu” will appear.

Advanced Menu

DVD Menu

HDD MENU

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

DVD Disc Format

DVD Recording Format

Finalise

Disc Protect

Delete Playlist

2 Select “HDD Menu” using

[Cursor

U / D], then press [ENTER].

Advanced Menu

DVD Menu

HDD Menu

Initial Setup

Timer Program

Easy Setting Menu

Erase All in HDD

Editing

Function Setup

VCR Functions Others

Page 71

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

Scene Delete

Edit Title Name

Delete

Protect

Add To Playlist

Chapter Mark

E439BBD_EN.book Page 72 Wednesday, May 31, 2006 4:01 PM

Protecting / Undo protecting titles

HDDHDD

[VR] [ORIGINAL]

To prevent accidental editing or title erasing, you can protect the contents in the Original List.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-RWDVD-RW

1 Press [TOP MENU].

Title List will appear.

Example: HDD Original List

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

15/06/06

11:05

0:15

01/05/06

0:15

05/07/06

23:40

DVD

HDD

ORG

04/06/06

10:00

18/07/06

10:00

1 2

Press [MENU / LIST] to switch to Original List if necessary.

2 Select a desired title to protect using

[Cursor [ENTER].

Title List Menu will appear.

U / D / L / P], then press

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

Play From Start

Resume Play

01/04/06

15/06/06

11:05

0:15

Protect

MAY/01/06

12:15

Delete

Edit

Dubbing

JUL/05/06

11:40

HDD

ORG

04/06/06

10:00

18/07/06

10:00

DVD

ORG

1 2

Editing title names

HDDHDD

DVD-RWDVD-RWVRDVD-RWDVD-RW

[VIDEO] [VR] [ORIGINAL] [PLAYLIST]

You can name titles or change the title names from this menu. The names you put on the titles will be displayed on a Title List.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

Video

DVD-RDVD-R

1 Press [TOP MENU].

Title List will appear.

Example: HDD Original List

DVD

HDD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

0:15

15/06/06

11:05

01/05/06

05/07/06

23:40

0:15

DVD

HDD

ORG

04/06/06

10:00

18/07/06

10:00

1 2

Press [MENU / LIST] to switch Original List / Playlist if necessary.

2 Select a desired title to edit using

[Cursor [ENTER].

Title List Menu will appear.

U / D / L / P], then press

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

Play From Start

Resume Play

01/04/06

15/06/06

0:15

11:05

Protect

MAY/01/06

12:15

Delete

Edit

Dubbing

JUL/05/06

11:40

HDD

ORG

04/06/06

10:00

18/07/06

10:00

DVD

ORG

1 2

3 Select “Protect” using

[Cursor

The protect icon will appear at the upper left corner of the thumbnail.

If the title has already been protected, “Undo Protect” will be listed in the Title List Menu instead of “Protect”. To cancel the protection, select “Undo Protect” and press [ENTER]. The protect icon will disappear.

U / D], then press [ENTER].

4 Press [TOP MENU] to exit.

To protect the disc itself, refer to “Setting disc protection” on page 49.

3 Select “Edit” using [Cursor U / D],

then press [ENTER].

Edit Menu will appear.

DVD

HDD

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

01/04/06

0:15

15/06/06

11:05

Protect

Delete

Edit Title Name

MAY/01/06

12:15

Scene Delete

Chapter Mark

Add To Playlist

05/07/06

23:40

DVD

HDD

ORG

04/06/06

05/07/06

1 2

10:00

Page 72

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

Scene Delete

Edit Title Name

Delete

Protect

Add To Playlist

Chapter Mark

E439BBD_EN.book Page 73 Wednesday, May 31, 2006 4:01 PM

4 Select “Edit Title Name” using

[Cursor

Editing Screen will appear.

U / D], then press [ENTER].

DVD

HDD

PROGRAM EDITING

P02 LP _

Space

Right

Left

Clear

Decide

[

]

Return

DVD

HDD

ORG

(

)

;

{

}

5 To enter a title name, refer to “Guide

to Edit Title Name” below.

6 When you finish entering the title

name, press [PLAY P]. Or select “Decide” using [Cursor

U / D / L / P], then press

[ENTER].

Your setting is activated.

7 Press [TOP MENU] to exit.

Guide to Edit Title Name

Method 1: By selecting the letters on the screen:

Method 2: By entering the letters directly using

• If you want to enter the same letters successively, for example if you want to enter AA, press [ENTER] after you enter the first A ( ), then enter the other A by pressing ( ) one more time.

•Press [FWD f] for a space.

•Press [SKIP B / F] to move the cursor to the left or right.

•Press [REV r] for a back space.

•Press [CLEAR] to erase all letters entered.

• You can enter up to 64 letters, for the titles in the HDD and the VR mode DVDs.

• You can enter up to 30 letters, for the titles in the Video mode DVDs.

Move to a desired letter or a command key using [Cursor

U / D / L / P], then press

[ENTER]. The selected letter will be entered in the field at the top of the screen.

[the Number Buttons]:

Following the list below, press [the Number Buttons] repeatedly until the desired letter appears.

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

Press

space , 0

. @ / : 1

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

Note

• Unidentified letters

in a title name are

shown by “ you delete them,

adjoining letters

may change to “

or other.

ABC

press

A B C a

”. If

...

Deleting a part of a title

HDDHDD

[VR] [ORIGINAL] [PLAYLIST]

You can delete a specific part of a title. Even if a part of a title is deleted from the Playlist, the title in the Original List will remain as it was, and recordable disc space will not increase.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-RWDVD-RW

1 Press [TOP MENU].

Title List will appear.

Example: HDD Original List

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

15/06/06

11:05

0:15

01/05/06

0:15

05/07/06

23:40

HDD HDD ORG

Press [MENU / LIST] to switch Original List / Playlist if necessary.

2 Select a desired title to edit using

[Cursor [ENTER].

Title List Menu will appear.

U / D / L / P], then press

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

Play From Start

Resume Play

01/04/06

15/06/06

0:15

11:05

Protect

MAY/01/06

12:15

Delete

Edit

Dubbing

JUL/05/06

11:40

HDD HDD ORG

3 Select “Edit” using [Cursor U / D],

then press [ENTER].

”

Edit Menu will appear.

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

01/04/06

15/06/06

Edit Title Name

0:15

Scene Delete

Chapter Mark

Add To Playlist

11:05

Protect

Delete

MAY/01/06

12:15

05/07/06

23:40

HDD HDD ORG

04/06/06

05/07/06

04/06/06

18/07/06

04/06/06

10:00

18/07/06

10:00

Introduction Connections Basic Setup Playback

DVD

ORG

1 2

Recording

10:00

DVD

ORG

1 2

Editing

Function Setup

DVD

ORG

1 2

VCR Functions Others

Page 73

Start Point

Return

SCENE DELETING

Start Point Cancel

End Point

Return

SCENE DELETING

End Point Cancel

Return

Update

SCENE DELETING

Delete selected scene?

SCENE DELETING

Return

SCENE DELETING

E439BBD_EN.book Page 74 Wednesday, May 31, 2006 4:01 PM

4 Select “Scene Delete” using

[Cursor

Editing Screen will appear.

U / D], then press [ENTER].

SCENE DELETING

Start Point

Return

0:00:00

HDD ORG

5 Press [PLAY P] to start playback.

Play the title up to the point where you want to set a start point for the scene to be deleted.

SCENE DELETING

Start Point

Return

0:12:45

HDD ORG

• If you want to quit the process, select “Return”

with [Cursor

L / P]. Then press [ENTER].

6 When it reaches the desired start

point, press [ENTER], or press [PAUSE p] or [STOP S] and then [ENTER].

A start point is marked and the display shown below will appear.

8 When it reaches the desired end

point, press [ENTER], or press [PAUSE p] or [STOP S] and then [ENTER].

An end point is marked, and the display shown below will appear.

SCENE DELETING

End Point Cancel

Return

• If you want to reset the end point, select “End

Point Cancel” with [Cursor [ENTER].

• If you want to quit the entire process, select

“Return” with [Cursor

L / P], then press

[ENTER].

HDD ORG

0:25:32

Update

L / P], then press

9 With “Update” selected, press

[ENTER].

Confirmation window will appear.

Update

0:25:32

HDD ORG

SCENE DELETING

End Point Cancel

Delete selected scene?

Yes

Return

SCENE DELETING

Start Point Cancel

End Point

Return

• If you want to reset the start point, select “Start

Point Cancel” with [Cursor

L / P], then press

[ENTER].

• If you want to quit the entire process, select

“Return” with [Cursor

L / P], then press

[ENTER].

7 Press [PLAY P] to start play back

again.

Play the title up to the point where you want to set an end point for the scene to be deleted.

0:20:38

HDD ORG

Select “Yes” using [Cursor L / P], then press [ENTER].

Final confirmation window will appear.

SCENE DELETING

Are you sure?

Delete Selected Scene?

Yes No

Yes

Start Point

End Point Cancel

Select “Yes” using [Cursor L / P],

Return

Return Update

0:00:00

0:25:32

HDD

ORG

then press [ENTER].

The scene is deleted.

If you want to delete other parts, repeat steps 5 to 11. Otherwise, select “Return” and press [ENTER].

Select “Yes” using [Cursor L / P], then press [ENTER] to finish the editing.

Press [TOP MENU] to exit.

Page 74

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

PROGRAM DIVIDING

Divide

0:45:10

E439BBD_EN.book Page 75 Wednesday, May 31, 2006 4:01 PM

Note

• If a certain scene is deleted from the title in the Original List, the title in the Playlist that contains the corresponding scene will be deleted also.

• When you search for the start / end point, you can use [SKIP B / F], [FWD f / REV r],

[VARIABLE REPLAY / VARIABLE SKIP], [PAUSE p] or [PLAY P] as usual.

Dividing a title

HDDHDD

[VR] [PLAYLIST]

You can divide a title into two new titles.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-RWDVD-RW

1 Press [TOP MENU].

Title List will appear.

Example: HDD Playlist

DVD

01/05/06

0:15

05/07/06

23:40

HDD

ORG

04/06/06

10:00

18/07/06

10:00

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

01/04/06

0:15

15/06/06

11:05

Press [MENU / LIST] to switch to Playlist if necessary.

2 Select a desired title to edit using

[Cursor [ENTER].

Title List Menu will appear.

U / D / L / P], then press

Delete

MAY/01/06

12:15

Edit

05/07/06

23:40

HDD

ORG

04/06/06

10:00

18/07/06

10:00

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

Play From Start

01/04/06

15/06/06

Resume Play

0:15

Dubbing

11:05

DVD

ORG

1 2

3 Select “Edit” using [Cursor U / D],

then press [ENTER].

Edit Menu will appear.

DVD

Delete

Divide

12:15

Move

JUL/05/06

11:40

HDD

ORG

04/06/06

10:00

18/07/06

10:00

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

Edit Title Name

01/04/06

15/06/06

Scene Delete

MAY/01/06

Combine

Chapter Mark

Add To Playlist

0:15

11:05

4 Select “Divide” using

[Cursor

Editing Screen will appear.

U / D], then press [ENTER].

PROGRAM DIVIDING

Divide

0:00:00

HDD

5 Press [PLAY P] to start playback.

Play the title up to the point where you want to divide the title.

6 When it reaches the desired dividing

point, press [ENTER], or press [PAUSE p] or [STOP S] and then [ENTER].

Confirmation window will appear.

PROGRAM DIVIDING

Divide program here?

Yes No

Divide

0:45:10

HDD

7 Select “Yes” using [Cursor L / P],

then press [ENTER].

The title is divided.

8 Press [TOP MENU] to exit.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Note

• If a disc contains the maximum number of recordings (HDD: 300, DVD-RW disc: 99), you cannot divide any titles.

• With DVD-RW disc, you cannot divide the titles if the total number of chapters has already reached 999.

• When you search for the dividing point, you can use

[SKIP B / F], [FWD f / REV r], [VARIABLE REPLAY / VARIABLE SKIP], [PAUSE p] or [PLAY P] as usual.

Page 75

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

PROGRAM EDITING

E439BBD_EN.book Page 76 Wednesday, May 31, 2006 4:01 PM

Combining titles

HDDHDD

[VR] [PLAYLIST]

You can combine two titles into a single title.

Steps on how to combine title 1 and 2 are shown here as an example.

If you are playing the HDD, press [HDD] first. If you are playing a disc, press [DVD] first.

DVD-RWDVD-RW

1 Press [TOP MENU].

Title List will appear.

Example: HDD Playlist

DVD

PREVIOUS RECORDINGS

01/04 0:15 P03 LP P03 LP

HDD

ORG

4 Select “Combine” using

[Cursor

The selected title will disappear temporarily, and the frame of the next title will be highlighted.

U / D], then press [ENTER].

DVD

04/06/06

10:00

18/07/06

10:00

HDD

ORG

15/06/06

11:05

20/07/06

11:30

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

01/05/06

0:15

05/07/06

23:40

1 2

5 Select a title to combine (title 2)

using [Cursor press [ENTER].

Confirmation window will appear.

1 2

PROGRAM EDITING

01/04 0:15 P03 LP P03 LP

U / D / L / P], then

HDD

ORG

DVD

ORG

1 2

01/04/06
