Page 1

E9NG1BD_EN.book Page 1 Monday, April 7, 2008 5:54 PM

DVD VIDEO RECORDER / VIDEO CASSETTE RECORDER

D-VR18DTKB

Introduction Connections Basic Setup Playback

OWNER’S MANUAL

PAL

ON/STANDBY

VCR

REC

DVD/VIDEO CASSETTE RECORDER D-VR18DT

PROGRAM

DUBBING

Recording

Editing

Function Setup

DVD -RW/R +RW/R RECORDING

VCR/DVD

REC

DVD

DVDVCR

VCR Functions Others

Page 2

E9NG1BD_EN.book Page 2 Monday, April 7, 2008 5:54 PM

Introduction

Precautions

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

WARNING

THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note is located on the rear of the cabinet.

Laser Safety

This unit employs a laser. Only a qualified service personnel should remove the cover or attempt to service this unit, due to the possibility of eye injury.

CAUTION: USE OF CONTROLS OR

ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER

RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK

MECHANISM.

Caution

1. Do not attempt to open the cabinet. There are no

2. Slots and openings in the cabinet at the sides and

3. Keep the unit away from radiators and other heat

4. Avoid use near strong magnetic fields.

5. Do not push objects of any kind into the unit

6. Do not spill liquid on the unit. If liquid is spilled

Power Supply

The power supply is connected and the unit is live when the mains cable is plugged into a 220–240 V , 50 Hz AC outlet. To operate the unit, press

[ ON / STANDBY].

WARNING: LIVE PARTS INSIDE.

DO NOT REMOVE ANY SCREWS.

7. Do not stand the unit vertically. Use the unit in a

8. Before attempting to operate the unit, make sure

9. This product is in Stand-by mode when turned off

10. Do not place any combustible objects on the

11. Before moving the unit, be sure to remove any

12. Disconnect the mains plug to shut off the unit, if

13. The mains plug shall remain readily operable.

14. Read both instruction manuals to ensure correct

15. Keep a distance of 20 cm around the ventilation

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

parts inside you can service. Refer all servicing to qualified service personnel.

underneath are provided for ventilation. To ensure reliable operation and to protect the unit from overheating, these openings must not be blocked or covered. Avoid installation in enclosed spaces such as bookcases unless suitable ventilation is provided.

sources.

through the cabinet slots or openings as they could touch electrically live parts or short circuit parts resulting in a fire or electric shock.

and enters the unit, consult qualified service personnel.

horizontal (flat) position only.

that the timer recording mode is off.

while the mains cable is connected.

device (candles, etc.).

discs and unplug the mains cable from the AC outlet.

you suspect a fault has developed, or if it will not be used for an extended period.

and safe installation and interconnection of the unit in multimedia systems.

openings of the apparatus.

Page 3

E9NG1BD_EN.book Page 3 Monday, April 7, 2008 5:54 PM

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

This product consists of materials which can be recycled and reused if disassembled by a specialised company. Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

Make your contribution to the environment!!!

• Exhausted batteries do not belong in the dustbin.

• You can dispose of them at a collection point for exhausted batteries or special waste.

• Contact your council for details.

For Customer Use: Carefully read the Model No. and Serial No. located at the back of the unit and enter the information below. Retain this information for future reference. Model No. _____________________ Serial No. _____________________

Connection to Power

Before Switching on make sure that the voltage of your electricity supply is the same as that indicated on the rating plate.

The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. No connection is to be made to the earth terminal of the plug. If a 13 Amp (BS 1363) Plug is used, a 5 Amp Fuse must be fitted, or if any other type of Plug is used a 3 or 5 Amp Fuse must be fitted, either in the Plug or Adaptor, or on the Distribution Board.

Mains Supply: 220 - 240V 50 Hz - AC only

Do not make any connection to the larger pin marked with the letter “E” or by the symbol or coloured green or green and yellow.

FUSE

BROWN

BLUE

(Neutral)

OUTER SHEATH OF THE WIRE

(Live)

CORD GRIP

Installation Location

For safety and optimum performance of this unit:

• Install the unit in a horizontal and stable position.

• Keep the unit away from electronic equipment such as an amplifier, TV, etc. to prevent warping, damage, fire and malfunction.

• Shield the unit from direct sunlight and keep away from sources of intense heat. Avoid dusty or humid locations. Avoid locations with insufficient ventilation for suitable heat dissipation. Do not block the ventilation holes on the sides of the unit. Avoid locations subject to strong vibration or strong magnetic fields.

Introduction Connections Basic Setup Playback

Recording

Mains Cord

This appliance may be fitted with a non-rewireable plug. If it is necessary to change the fuse in a nonrewireable plug the fuse cover must be refitted. If the fuse cover is lost or damaged, the plug must not be used until a replacement available from the appliance manufacturer is obtained. It is important that the colour of the replacement fuse cover corresponds with the rating marking on the base of the plug. If the plug has to be changed because it is not suitable for your socket, or becomes damaged, it should be cut off and an appropriate plug fitted following the wiring instructions below. The plug removed must be disposed of safely as insertion into a 13A socket is likely to cause an electrical hazard. For your own safety read the following instructions carefully before attempting to connect this unit to mains. The wires in this mains lead are coloured in accordance with the following code:

BLUE=NEUTRAL, BROWN=LIVE

Important

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

Avoid the Hazards of Electrical Shock and Fire

• Do not handle the mains cable with wet hands.

• Do not pull on the mains cable to disconnect it from AC outlet. Grasp it by the plug.

• If, by accident, water is spilled on the unit, unplug the mains cable immediately and take the unit to an authorised service centre for servicing.

Moisture Condensation Warning

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, after heating a cold room, or under conditions of high humidity. Do not use the unit for at least 2 hours to allow the inside to dry.

About Copyright

Unauthorised copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorised by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorised by Macrovision. Reverse engineering or disassembly is prohibited.

Editing

Function Setup

VCR Functions Others

Page 4

E9NG1BD_EN.book Page 4 Monday, April 7, 2008 5:54 PM

Notice for the Progressive Scan Outputs

Consumers should note that not all high definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of picture problems with 480 or 576 progressive scan output, it is recommended that the user switch the connection to the ‘standard definition’ output. If there are questions regarding your TV set compatibility with this 480p or 576p DVD recorder, please contact our customer service centre.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Dolby Digital Recording

Digital Recording enables consumers to

“Dolby record high-quality video with stereo sound on recordable DVD discs. The technology, when utilised instead of PCM recording, also saves recordable disc space, allowing for higher video resolution or extended recording time on each DVD. DVDs created using Dolby Digital Recording will play back on all DVD-Video players.” Note: This is true when the players are compatible with actual recordable DVD discs.

Manufactured under license under U.S. Patent #: 5,451,942 & other U.S. and worldwide patents issued & pending. DTS and DTS Digital Out are registered trademarks and the DTS logos and Symbol are trademarks of DTS, Inc. © 1996-2007 DTS, Inc. All Right Reserved.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.

DVB is a registered trademark of the DVB project

Page 5

E9NG1BD_EN.book Page 5 Monday, April 7, 2008 5:54 PM

EU Conformity Statement

“This product is marked with “CE” and complies therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC and the EMC Directive 2004/108/EC.”

Responsible for CE-marking is TOSHIBA INFORMATION SYSTEMS (U.K.) LTD, Toshiba Court, Weybridge Business Park, Addlestone Road, Weybridge,Surrey, KT15 2UL, United Kingdom

Maintenance

CLEANING THE UNIT

Use a soft cloth slightly moistened with a mild detergent solution. Do not use solutions containing alcohol, spirits, ammonia or abrasives.

CLEANING DISCS

If a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the centre out. Do not wipe in a circular motion. Do not use solvents such as benzine, thinners, commercially available cleaners, detergent, abrasives cleaning agents or antistatic spray intended for analogue records.

DISC HANDLING

Handle the discs so that fingerprints and dust do not adhere to the disc surfaces. Always store the disc in its protective case when it is not in use.

SERVICING

If the unit becomes inoperative, do not try to correct the problem by yourself. There are no user serviceable parts inside. Turn the unit off, unplug the mains cable, and consult your dealer or an authorised service centre.

CLEANING THE DISC LENS

If the unit does not perform correctly even though you have referred to “Troubleshooting” and the relevant sections in the Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an authorised service centre for inspection and cleaning of the laser optical pickup unit.

AUTO HEAD CLEANING

• Automatically cleans video heads as you insert or remove a cassette, so you can see a clear picture.

• Playback picture may become blurred or interrupted while the TV programme reception is clear. Dirt accumulated on the video heads after a long period of use, or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during playback, the video heads in the unit may need to be cleaned.

1. Please visit your local Audio / Video store and

purchase a good quality VHS Video Head Cleaner.

2. If a Video Head Cleaner does not solve the

problem, please consult your dealer or an authorised service centre.

Note

• Remember to read the instructions along with the video head cleaner before use.

• Clean video heads only when problems occur.

Accessories Supplied

• Remote control with two R6 (AA) batteries

INPUT

OPEN/

SELECT

HDMI

.@/:

ABC DEF

123

GHI JKL MNO PROG.

456

PQRS TUV WXYZ TIME SLIP

7809

SAT.LINK SPACE CLEAR INFO

TEXT AUDIO SUBTITLE GUIDE

TOP MENU DISC MENU

ENTER /OK

RETURN

DISPLAY

/BACK

REV PLAY FWD

SKIP STOP SKIP

PAUSE VCR DVD

INSTANT SKIP

DUBBING REC REC MODE

SETUP

TIMER SET

TIMER PROG. 1.3x/0.8xPLAY

SE-R0307

• RF cable

• Owner’s Manual

Owner's Manual

• Quick Setup Guide

• Registration card

• Helpline Sheet

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 6

E9NG1BD_EN.book Page 6 Monday, April 7, 2008 5:54 PM

Table of Contents

Introduction ............................................ 2

Precautions ........................................................... 2

Features ................................................................ 7

Guide to the Owner’s Manual................................ 8

Functional Overview............................................ 11

Installing Batteries in the Remote Control........... 15

Switching DVD / VCR mode................................ 15

Guide to On-Screen Displays.............................. 16

Front Panel Display Guide .................................. 19

Connections ......................................... 20

Connections ........................................................ 20

Basic Setup........................................... 23

Initial Setting........................................................ 23

Channel Setting................................................... 23

TV View Operation .............................................. 29

DVB Menu Setting............................................... 31

Setting the Clock ................................................. 33

Recording ............................................. 34

Information on DVD Recording ........................... 34

Formatting a Disc ................................................ 35

Selecting the Sound Mode .................................. 38

Basic Recording .................................................. 39

One-touch Timer Recording (OTR)..................... 40

Timer Recording.................................................. 41

Timer Recording (EPG)....................................... 44

Series Link Timer Recording............................... 45

Satellite Link........................................................ 46

Settings for External Equipment.......................... 47

Information on DV Dubbing................................. 48

DVC to DVD Dubbing.......................................... 49

Dubbing Mode..................................................... 50

Setting a Disc to Protect...................................... 52

Finalising Discs ................................................... 52

Editing ................................................... 69

Guide to a Title List.............................................. 69

Editing Discs........................................................ 69

Function Setup .....................................76

Playback .............................................................. 78

Display................................................................. 81

Video ................................................................... 81

................................................................... 82

DivX

HDMI ................................................................... 83

Reset All .............................................................. 84

VCR Functions......................................85

Playback .............................................................. 85

Recording and One-touch Timer Recording

(OTR)................................................................... 85

Search ................................................................. 87

Other Operations ................................................. 87

Hi-Fi Stereo Sound System ................................. 88

Others ....................................................89

Troubleshooting................................................... 89

Language Code ................................................... 93

Glossary .............................................................. 94

Specifications ...................................................... 95

Playback ............................................... 54

Basic Playback.................................................... 54

PBC Function for Video CDs............................... 59

Special Playback................................................. 60

Search................................................................. 64

Repeat / Random / Programme Playback / Slide

Show ................................................................... 65

Selecting the Format of Audio and Video............ 67

Page 7

E9NG1BD_EN.book Page 7 Monday, April 7, 2008 5:54 PM

Features

The following features are available with this unit.

Recording

The unit is compatible with DVD-RW, DVD+RW discs, which are recordable repeatedly, and DVD-R, DVD+R discs, which are recordable only once. Also, this unit allows you to record to a videotape. You can choose either one for your convenience.

DVD VCR

Recording up to 12 programmes:

You can programme the unit to record up to 12 programmes, up to a month in advance. Daily or weekly programme recordings are also possible.

One-touch Timer Recording:

You can set your required recording time easily. Every time [REC recording time will be increased by 30 minutes up to 8 hours. It will be turned off automatically when the recording time you set is finished.

Dubbing mode:

You can copy a DVD disc to a videotape or copy a videotape to a DVD disc. This function will be available only if the DVD disc and the videotape are not copy-protected.

Left channel stereo recording:

This unit can record the sound of the Left channel monaural input as Left and Right channels automatically (available only for AV3 jacks on the front panel).

PDC:

This system assures that the TV programme you want to record using timer recording will be recorded exactly from beginning to end even if the actual broadcasting time differs. This feature is only available for analogue channels.

DVD

Automatic Chapter marker setting:

Chapter markers will be added to recordings as you set them in “Setup” menu before starting to record.

Automatic Title menu making (Video, +VR mode only):

The unit creates Title menus automatically when finalising discs.

Automatic Playlist making (VR mode DVD-RW discs only):

The unit creates a Playlist automatically after recording.

Automatic finalising (Video mode DVD-RW/-R, DVD+R discs only):

You can finalise discs automatically at the end of the disc space if you set this in “Setup” menu.

DVD VCR

DV dubbing:

[ Pages 48 - 50] (DVD) [ Page 86 ] (VCR) This function helps you to easily copy the contents of the DVC (digital video camcorder) to DVD/VCR.

I] is pressed during recording, the

Playback

DVD

Theatre surround sound:

When the unit is connected to an amplifier or a decoder compatible with Dolby Digital or DTS, you can enjoy theatre-quality surround sound from discs recorded with the surround sound system.

Chasing Playback during Recording and Simultaneous Playback and Recording:

You can play the already recorded part of the current recording or another title during recording.

Quick search:

You can easily find the part you want to watch using the search function. Search for a desired point on a disc by title, chapter / track or time.

Playback from Original or a Playlist (VR mode DVD-RW discs only):

You can play back titles using either the Original list or a Playlist.

Virtual Surround System:

You can enjoy stereophonic space through your existing 2 channel stereo system.

Playing back on MP3 / JPEG / DivX

You can enjoy MP3 / JPEG / DivX recorded on CD-RW/-R.

files can also be recorded on DVD-RW/-R and

DivX DVD+RW/+R discs.

VCR

Quick search:

You can easily find the part you want to watch using the Index or Time search functions. An index mark will be assigned at the beginning of each recording you make. For Time search function, you can go to a specific point on a tape by entering the exact amount of time you want to skip.

files:

files which are

Editing

DVD

Set / clear chapter markers (Video mode DVD-RW disc only): [ Page 72]

You can easily add chapter markers at every selected time interval in your recordings for easy editing.

Adding or Deleting Chapter Marks Manually:

[ Page 71] You can add or delete chapter marks.

Creating Titles to a Playlist (VR mode DVD-RW discs only): [ Page 74]

You can create a title to the Playlist.

Deleting Titles: [ Page 70] You can delete titles which you do not need anymore.

Deleting a Scene of a Title (VR mode DVD-RW discs only): [ Page 75]

You can delete a specific scene of a title.

Editing title name: [ Pages 70 - 71] You can name titles or change the title name.

Combining Titles (VR mode DVD-RW discs only): [ Pages 73 - 74] You can combine two titles into a single title.

Dividing Titles (VR mode DVD-RW, DVD+RW discs only): [ Page 73]

You can divide a title into two new titles.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 8

VD+RWW

VD+R

VCD

MP3

JPEG

DivX

E9NG1BD_EN.book Page 8 Monday, April 7, 2008 5:54 PM

Protecting titles (VR mode DVD-RW disc only):

[ Page 73] To avoid accidental editing or erasing of titles, the protect function is useful when set to “ON” in the Original list.

Hiding chapters (+VR mode only): [ Page 72] To keep others from playing back some chapters without permission, you can hide chapters.

Compatibility

DVD

Playing back discs recorded in Video mode on any regular DVD player:

Discs recorded in Video mode can be played back on regular DVD players, including computer DVD drives compatible with DVD-Video playback. You will need to finalise the discs recorded in Video mode to play back in other DVD players. Although DVD+RW/+R discs are playable on other units without finalisation in most cases, it is recommended to finalise in order to stabilise the performance.

* DVD-Video Format (Video mode) is a new format for

recording on DVD-RW/-R discs that was approved by the DVD Forum in 2000. Adoption of this format is optional for manufactures of DVD playback devices and there are DVD-Video players, DVD-ROM drives and other DVD playback devices available that cannot play back DVD-RW/-R discs recorded in the DVD-Video Format.

Others

DVD

Progressive scan system:

Unlike conventional interlace scanning, the progressive scan system provides less flickering and images in higher resolution than that of traditional television signals.

HDMI (High-Definition Multimedia Interface):

You can enjoy clearer audio/video output when connecting this unit to a display device with an HDMIcompatible port.

Guide to the Owner’s Manual

Symbols Used in the Owner’s Manual

To show what recording mode or disc type applies to each function, the following symbols appear at the beginning of each operating item.

Symbol Description

DVD-VDVD-V

Video

DVD-RWDVD-RW

DVD-RDVD-R

DDVD+R

DVD+RW

DDVD+R

DVD+R

CDCDCD

VCD

MP3

JPEG

DivX

VCRVCR

Symbols for Tuner Setting

The following is the description for the symbols for tuner setting used in this manual.

ANALOG : Settings only for the Analogue mode

Available to DVD-Videos

Available to DVD-RW discs in Video mode

Available to DVD-RW discs in VR mode

Available to DVD-R discs in Video mode

Available to DVD+RW discs

Available to DVD+R discs

Available to Audio CDs

Available to Video CDs

Available to CD-RW/-R discs with MP3 files

Available to CD-RW/-R, discs with JPEG files

Available to DVD-RW/-R, DVD+RW/+R

and CD-RW/-R discs with DivX

Available to VHS tapes Use only cassettes marked VHS ( ).

files

DVB : Settings only for the DVB mode

Page 9

VD+RWW

VD+R

E9NG1BD_EN.book Page 9 Monday, April 7, 2008 5:54 PM

Discs for Recording, Playing

Disc Type

Logo

Introduction Connections Basic Setup Playback

DVD-RW DVD-R DVD+RW DVD+R

Format

Icon

Maximum Record Time

Recordable/Playable

Recording Features

Record TV Programmes

Reuse by deleting the current contents

Record 16:9 size pictures

Available Features

Record copy-once programmes

Create chapters at fixed intervals (auto chapter)

Editing Features

Scene Delete

Edit Title Name

Create chapters wherever you like (chapter mark)

Divide a title

Combine titles

Hide chapters

Delete a title

Create a Playlist

Protect a title

Versions

Compatibility

Automatically formatted in Video mode

DVD-RDVD-R DDVD+R

480 min (12 cm) 144 min (8 cm)

Ver. 2 .0 Ver. 2.0/4× Ver. 2.0/8× Ver. 2.0/16×

Playable on most DVD players. Finalisation necessary. (Title menu will be created)

Can be formatted in VR or Video mode

Video Mode VR Mode

Video

DVD-RWDVD-RW

480 min (12 cm) 144 min (8 cm)

Ver. 1.1,1.2 Ver. 1.1/2× CPRM compatible Ver. 1.2/4× CPRM compatible

Playable on most DVD players. Finalisation necessary. (Title menu will be created)

DVD-RWDVD-RW

480 min (12 cm) 144 min (8 cm)

Playable only on VR mode compatible unit. Finalisation recommended.

✔✔✔✔✔

✔✔ ✔

✔✔✔

✔*

✔✔✔✔✔

Playlist Original

✔✔

✔✔✔✔ ✔ ✔

✔✔ ✔✔

✔ ✔

✔

✔✔✔✔ ✔ ✔

✔

Automatically formatted in +VR mode

DVD+RW DDVD+R

480 min (12 cm) 144 min (8 cm)

1×-4× 1×-16×

Playable on DVD+RW compatible players. Finalisation recommended. (Title menu will be created)

Automatically formatted in +VR mode

DVD+R

480 min (12 cm) 144 min (8 cm)

Playable on most DVD players. Finalisation recommended. (Title menu will be created)

✔✔

✔: Available Grey: Not available

*CPRM compatible disc only.

Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot guarantee that product will play every feature of every DVD bearing the DVD logo and/or every CD bearing the CD logo. As one of the creators of DVD technology, Toshiba DVD players are manufactured using the highest standards of quality, and as a result, such incompatibilities are rare.

Recording

Editing

Function Setup

VCR Functions Others

DVD players with are capable of playing DVD-RW recorded in VR mode.

Page 10

VCD

MP3

JPEG

DivX

E9NG1BD_EN.book Page 10 Monday, April 7, 2008 5:54 PM

Discs for Playing

Disc Type

DVD-VIDEO CD-DA Video CD CD-RW CD-R

Logo

Icon

Typ e of

title

Icon

DVD-VDVD-V CDCDCD VCD

Files for Playing

MP3 JPEG DivX

MP3

MP3 JPEG

JPEG DivX

DivX

CD-RW/-R

Media

CD-RW/-R CD-RW/-R

DVD-RW/-R

DVD+RW/+R

is a trademark of DVD Format/Logo Licensing

Corporation.

• Official DivX® Certified product

• Plays all versions of DivX with standard playback of DivX

• Discs containing the DivX (Global Motion Compensation) playback feature, which is DivX

supplemental function, cannot be

video (including DivX® 6)

media files.

files with the DivX® GMC

played back on this unit.

Unplayable Discs

The following discs will not play back on this unit.

• CD-ROM • Compact Disc-Interactive (CD-I)

• Video Single Disc (VSD) • DVD-ROM

• DVD-audio • Unfinalised disc

• DVD contains MP3, Windows Media™ Audio or JPEG files

• DVD-RW/-R recorded in non compatible recording format

• Blu-ray Disc • HD DVD

On the following disc, the sound may not be heard.

• Super Audio CD - Only the sound on the CD layer can be heard. The sound on the high-density Super Audio CD layer cannot be heard.

Colour Systems

DVDs are recorded using different colour systems throughout the world. The most common colour system, used primarily in the U.K. and other EU countries, is PAL. This unit uses the PAL system. However, it is also possible to play back DVDs using other colour systems, such as NTSC.

Region Codes

This unit has been designed to play DVD with region 2. DVD must be labelled for ALL regions or for region 2 in order to play on the unit. You cannot play back DVDs that are labelled for other regions. Look for the symbols on the right on your DVD. If these region symbols do not appear on your DVD, you cannot play back a DVD in this unit.

VCD CDCDCD CDCDCD

The number inside the globe refers to region of the world. A DVD labelled for a specific region can only play back on the unit with the same region code.

Following discs are recommended for good recording quality and are proven to be compatible with this unit. However, depending on the media condition the unit may not read the disc properly. Verbatim DVD+R 8x, DVD+RW 4x, DVD-R 8x,

DVD-RW 2x JVC DVD-RW 4x Maxell DVD+R 4x/8x/16x, DVD-R 8x/16x SONY DVD+R 4x/8x/16x, DVD+RW 4x TDK DVD+R 4x/8x/16x Performance of any other discs are not guaranteed.

• Toshiba is not liable for any damage or loss caused directly or indirectly by the malfunction of this unit, including, without limitation, any one of the following:

• Failure to record contents intended to be recorded by the consumer.

• Failure to edit contents as intended by the consumer.

• When a DVD-RW/-R, DVD+RW/+R disc created on this unit is used (e.g., insertion, playback, recording or editing) in another DVD player, recorder or personal computer drive.

• When a DVD-RW/-R, DVD+RW/+R disc that is used in the manner described in the immediately preceding bullet point is used again in this unit.

• When a DVD-RW/-R, DVD+RW/+R disc that was recorded in another DVD recorder, or in a personal computer drive is used in this unit.

• Some functions may not work with personal computer discs.

• Discs recorded in this unit may not operate as expected on other DVD players, recorders or personal computer drives.

Page 11

E9NG1BD_EN.book Page 11 Monday, April 7, 2008 5:54 PM

Functional Overview

Front Panel

1 23*475116

Introduction Connections Basic Setup Playback

ON/STANDBY

VCR

DVD/VIDEO CASSETTE RECORDER D-VR18DT

REC

19 15 1420*21* 17 1618* 1312 9*10 8

1 ON / STANDBY button

• Press to turn on or off the unit.

• Green LED lights up when power is ON.

2 Cassette compartment (VCR)

• Insert a tape here.

3 O (OPEN / CLOSE) button* (DVD)

• Press to open or close the disc tray.

4 Disc tray (DVD)

• Place the disc here when the disc tray is opened.

5 VIDEO input jack (AV3) (DVD / VCR)

• Use to connect external equipment with a standard Video cable.

6 AUDIO input jacks (AV3) (DVD / VCR)

• Use to connect external equipment with a standard Audio cable.

7 DV input jack (AV4) (DVD / VCR)

• Use to connect the DV output of external device with a DV cable.

8 I REC button (DVD)

• Press once to start recording.

• Press repeatedly to start a One-touch Timer Recording.

9 P (PLAY) button* (DVD)

• Press to start or resume playback.

10 S (STOP) button (DVD)

• Press to stop a playback or recording.

• Press to stop a timer recording.

11 VCR/DVD indicator (DVD / VCR)

• Indicates the selected component (DVD or VCR).

12 VCR/DVD button (DVD / VCR)

• Press to select the DVD mode or the VCR mode.

PAL

DUBBING

PROGRAM

(*)

You can also turn on the unit by pressing these buttons.

VCR/DVD

DVDVCR

DVD -RW/R +RW/R RECORDING

REC

DVD

VIDEO L R

13 DUBBING button (DVD / VCR)

• Press to start VCR to DVD (DVD to VCR) duplication which you set in “Setup” menu.

14 PROGRAM / buttons (DVD / VCR)

• Press to change the channel up or down.

15 Display (DVD / VCR)

• Shows information and messages.

• Refer to “Front Panel Display Guide” on page 19.

16 Infrared sensor window

• Receive signals from your remote control so that you can control the unit from a distance.

17 I REC button (VCR)

• Press once to start recording.

• Press repeatedly to start a One-touch Timer Recording.

18 P (PLAY) button* (VCR)

• Press to start playback.

• Press to turn on the unit and start playback when the unit is off with a tape inserted.

19 O/S (EJECT / STOP) button (VCR)

• Press to remove the tape from the unit.

• Press to stop the tape playback.

• Press to stop the proceeding timer recording.

20 f (FWD) button* (VCR)

• Press to rapidly advance the video tape.

• Press to view the picture rapidly in forward during playback. (Forward Search)

• Press to turn the unit on when the video tape is inserted and start rapidly advancing the tape.

21 r (REW) button* (VCR)

• Press to rewind the video tape.

• Press to view the picture rapidly in reverse during the playback mode. (Rewind Search)

• Press to turn the unit on when the video tape is inserted and start rewinding the tape.

AV3

Recording

Editing

Function Setup

VCR Functions Others

Button names described in the Owner’s Manual

The instructions in this manual are described mainly with the operations using the remote control. Some operations can be carried out using the buttons on the front panel.

Page 12

E9NG1BD_EN.book Page 12 Monday, April 7, 2008 5:54 PM

Rear Panel

HDMI OUT

1 Mains cable

• Connect to a standard AC outlet.

2 HDMI OUT jack (DVD)

• Connect to a display with an HDMI compatible port. Use a commercially available HDMI cable.

3 DIGITAL AUDIO OUT (COAXIAL) jack

(DVD)

• Connect to an amplifier with a digital input jack such as a Dolby Digital decoder, DTS decoder or MPEG decoder. Use a commercially available Coaxial cable.

4 AUDIO OUT (L/R) jacks (DVD)

• Connect to the audio input jacks on your TV. Use a commercially available Audio cable.

5 COMPONENT VIDEO OUT jacks (DVD)

• Connect to the component video input jacks on your TV. Use a commercially available Component Video cable.

DVD

DIGITAL

COMPONENT

VIDEO OUT

COAXIAL

AUDIO

AUDIO OUT

OUT

PB /CBPB/CB

PR /CR

DVD/VCR

AV2(DECODER)

ANTENNA

AV1(TV)

6 AV2 (DECODER) socket (DVD / VCR)

• Connect to VCR, camcorder, or other Audio-Video equipment. Use a commercially available Scart cable.

7 AV1 (TV) socket (DVD / VCR)

• Connect to the Scart socket on your TV. Use a commercially available Scart cable.

8 ANTENNA OUT

• Connect to the Aerial jack on your TV, cable box or direct broadcast system to output the signal received at ANTENNA IN. Use the supplied RF cable.

9 ANTENNA IN

• Connect to an antenna or a cable.

OUT

93784 61

Note

• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

• This unit does not have an RF modulator.

Page 13

E9NG1BD_EN.book Page 13 Monday, April 7, 2008 5:54 PM

Remote Control

1 2

5 6 7

12 13

15 16 17

1 INPUT SELECT button (DVD / VCR)

• Press to select the DVB, analogue mode or appropriate input.

INPUT

OPEN/

SELECT

.@/:

1203

GHI JKL

456

PQRS

789

SAT.LINK SPACE CLEAR INFO

TEXT

TOP MENU DISC MENU

DISPLAY

REV PLAY FWD

SKIP STOP SKIP

PAUSE VCR DVD

DUBBING REC REC MODE

SETUP

HDMI

ABC DEF

MNO PROG.

TUV WXYZ TIME SLIP

AUDIO

SUBTITLE

ENTER

/OK

INSTANT SKIP

TIMER SET

TIMER PROG. 1.3x/0.8xPLAY

SE-R0307

GUIDE

RETURN

/BACK

18 19

27 28

32 34

36 37

6 AUDIO button (DVD / VCR)

• When receiving a bilingual broadcast, press to change the audio out setting to “Main”, “Sub” and “Main/Sub”.

• Press to change the bilingual audio source of an external equipment to “Main”, “Sub” or “Main/ Sub”. (Available only when the “External Input Audio” in “Setup” menu is set to “Bilingual” in advance.)

• Press to select the sound mode for DVB channels.

(DVD)

• Press to display the audio menu during playback.

(VCR)

• During playback of a Hi-Fi video tape, press to change the audio out setting to “STEREO”, “LEFT”, “RIGHT” and “MONO”.

7 TOP MENU button (DVD)

• Press to display the Title menu.

8Direction U / D / L / P buttons

(DVD / VCR)

• Press to move the cursor and determine items or settings.

9 DISPLAY button (DVD / VCR)

• Press to display the On-Screen Display.

10 REV r button (DVD / VCR)

(DVD)

• During playback, press to reverse fast.

• When playback is paused, press to reverse slowly.

(VCR)

• Press to rewind the video tape.

• Press to view the picture rapidly in reverse during the playback mode.

11 PLAY P button (DVD / VCR)

• Press to start or resume playback.

Introduction Connections Basic Setup Playback

Recording

Editing

2 OPEN/CLOSE button (DVD / VCR)

• Press to open or close the disc tray.

• Press to remove the tape from the unit.

3 Number buttons (DVD / VCR)

• Press to select channel numbers.

• Press to select a title / chapter / track on the display.

• Press to enter values for settings in “Setup” menu.

• Press to enter the number in the Index or Time search in VCR mode.

• Press to enter the characters in edit function.

4 SAT.LINK button (DVD / VCR)

• Press to call up the Satellite Link setting.

5 TEXT button

• Press to switch Teletext on or off.

12 SKIP B button (DVD)

• During playback, press twice in quick successions to skip to the previous chapter or track.

• When playback is paused, press to play reverse step by step.

13 PAUSE p button (DVD / VCR)

• Press to pause playback or recording.

14 VCR button (DVD)

• Press to select the VCR output mode. (See page 15.)

15 DUBBING button (DVD / VCR)

• Press to start VCR to DVD (DVD to VCR) duplication which you set in “Setup” menu.

16 SETUP button (DVD / VCR)

• Press to display “Setup” menu in stop mode.

Function Setup

VCR Functions Others

Page 14

E9NG1BD_EN.book Page 14 Monday, April 7, 2008 5:54 PM

17 TIMER SET button (DVD / VCR)

• Press to set the unit in timer-standby mode. In the timer-standby mode, press to cancel the mode and to turn on the unit.

18 HDMI button

• Press to set the HDMI connector’s video signal output mode.

19 ON / STANDBY button (DVD / VCR)

• Press to turn on or off the unit.

20 PROG. / buttons (DVD / VCR)

(DVD)

• Press to change the channel up or down.

(VCR)

• Press to change the channel up or down.

• Press to adjust the tracking during playback or in slow motion of the tape.

• While playback is in still mode, you can adjust the vertically blurred picture.

21 TIME SLIP button (DVD)

• Press once to start recording the TV programme you are watching. Press again to watch the content being recorded from the beginning while recording continues. (VR mode DVD-RW discs with the recording mode of LP, EP or SLP only)

22 CLEAR button (DVD / VCR)

(DVD)

• Press to clear the password once entered.

• Press to cancel the programming for a disc.

• Press to clear the selecting marker number in the marker setup mode.

• Press to clear the programme once entered in the timer recording setting mode.

(VCR)

• Press to reset the tape counter.

23 INFO button

• Press to display the DVB programme information.

24 GUIDE button

• Press to call up the EPG list in DVB mode.

25 SUBTITLE button

• During playing back DVD or watching a DVB channel which has subtitle information, press to call up the Subtitle menu.

26 DISC MENU button (DVD)

• Press to display the Disc menu during playback.

• Press to change the Original and Playlist on the TV screen. (VR mode only)

27 ENTER/OK button (DVD / VCR)

• Press to acknowledge or approve a menu selection.

• While watching a DVB channel, press to display the “Quick select” menu.

28 RETURN/BACK button (DVD / VCR)

• Press to return to the previously displayed menu screen.

29 RED/GREEN/YELLOW/BLUE button

• Press to follow the DVB instruction displayed on-screen.

SEARCH (BLUE) button (VCR)

• Press to call up the index or time search menu.

30 FWD f button (DVD / VCR)

(DVD)

• During playback, press to forward fast.

• When playback is paused, press to forward slowly.

(VCR)

• Press to advance the video tape rapidly.

• Press to view the picture rapidly in forward during playback.

• When playback is paused, press to forward slowly.

31 STOP S button (DVD / VCR)

• Press to stop playing back or recording.

32 SKIP F button (DVD)

• During playback, press to skip to the next chapter or track.

• When playback is paused, press to advance step by step.

33 DVD button (VCR)

• Press to select the DVD output mode. (See page 15.)

34 INSTANT SKIP button (DVD)

• During playback, press to skip 30 seconds. (See page 60.)

35 REC I button (DVD / VCR)

• Press once to start a recording.

• Press repeatedly to start a One-touch Timer Recording.

36 REC MODE button (DVD / VCR)

• Press to switch the recording mode.

37 1.3x/0.8x PLAY button (DVD)

• During playback, press to playback in a slightly faster/slower speed while keeping the sound output.

38 TIMER PROG. button (DVD / VCR)

• Press to display the timer programme setting menu.

Button names described in the Owner’s Manual

The instructions in this manual are described mainly with the operations using the remote control. Some operations can be carried out using the buttons on the front panel.

Note

• If you turn off this unit, [OPEN / CLOSE O] on the

remote control is not available. Be sure to use

(OPEN / CLOSE)] or [O/S (EJECT / STOP)] on

the unit.

Page 15

E9NG1BD_EN.book Page 15 Monday, April 7, 2008 5:54 PM

Introduction Connections Basic Setup Playback

Installing Batteries in the Remote Control

Install two R6 (AA) batteries (supplied) into the remote control, carefully match with the polarity indicated inside the battery compartment.

21 3

Caution

• Incorrect use of batteries can result in hazards such as leakage and bursting.

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together.

• Make sure that the plus (+) and minus (-) ends of each battery match the indications inside the battery compartment.

• Remove batteries if the equipment will not be used for a month or more.

• When disposing of used batteries, please comply with governmental regulations or the public instructions for environmental protection that apply in your country or area.

• Do not recharge, short-circuit, heat, burn or disassemble batteries.

About the Remote Control

• Make sure there is no obstacle between the remote control and the remote control sensor on the unit.

• Use within the operating range and angle as shown.

PAL

ON/STANDBY

DVD/VIDEO CASSETTE RECORDER D-VR18DT

REC

VCR

DUBBING

PROGRAM

DVD -RW/R +RW/R RECORDING

REC

VCR/DVD

DVD

DVDVCR

Switching DVD / VCR mode

Because this product is a combination of DVD recorder and VCR recorder, you must select which component you want to operate first.

PAL

ON/STANDBY

DVD/VIDEO CASSETTE RECORDER D-VR18DT

REC

VCR

DUBBING

PROGRAM

VCR indicator DVD indicator

DVD

Press [DVD] on the remote control.

VCR

Press [VCR] on the remote control.

Note

• You can also press [VCR/DVD] on the front panel to

switch between DVD and VCR mode.

DVD -RW/R +RW/R RECORDING

REC

VCR/DVD

DVD

DVDVCR

VCR/DVD

DVDVCR

VCR button

DVD button

OPEN/

INPUT

SELECT

HDMI

.@/:

DEF

ABC

123

GHI JKL

MNO PROG.

456

PQRS TUV WXYZ TIME SLIP

7809

CLEAR INFO

SAT.LINK SPACE

TEXT AUDIO SUBTITLE GUIDE

TOP MENU DISC MENU

ENTER

/OK

DISPLAY

REV PLAY FWD

SKIP STOP SKIP

PAUSE VCR DVD

DUBBING REC REC MODE

TIMER SET

TIMER PROG. 1.3x/0.8xPLAY

SETUP

SE-R0307

INSTANT SKIP

RETURN

/BACK

Recording

Editing

Within about 7 m

Remote control

• The maximum operable range as follows:

Line of sight: approximately 7 m Either side of centre: approximately 7 m within

30 degrees

• Remote control operation may become unreliable if the remote control sensor of the unit is being exposed by the strong sunlight or fluorescent light.

• Remote controls for different devices can interfere with each other. Be careful when using remote controls for other equipment located close to the unit.

• Replace the batteries when the operating range of the remote control reduces.

Function Setup

VCR Functions Others

Page 16

E9NG1BD_EN.book Page 16 Monday, April 7, 2008 5:54 PM

Guide to On-Screen Displays

Title name information

Title Name

My Title

DISPLAY Menu

DVD

Press [DVD] first.

With a disc inserted into the unit, press [DISPLAY] to display the On-Screen Display. The menu shows information about what is recorded on the disc.

1/ 5 1/ 5

55 66 11

This is an example screen for explanation. Displayed items vary depending on the actual mode.

1 Indicates a disc type and format mode. 2 Indicates a type of titles for VR mode

DVD-RW disc.

3 Indicates a channel number, station

name (analogue channel only) or selected external input mode.

4 Indicates a recording mode and possible

recording time left.

5 Indicates a title number, chapter number,

elapsed time and total of disc playback.

6 Each icon means:

: Search

: Audio

: Subtitle

: Angle

: Repeat

: Marker

RW VR ORG

901 BBC1

SP 1:53

(only when DVD+RW/+R, VR mode DVD-RW/-R or unfinalised Video mode DVD-RW/-R disc is in playback)

(only when a CD with MP3 files is in playback)

Title name information

Title Name

Artist name information

Artist Name

Album name information

Album Name

480p

BitstreamAudio Info. :

Video Info. : / YCbCr

(only for the images output through the HDMI output)

1 Indicates the resolution of the HDMI

output image. 2 Indicates the HDMI video format. 3 Indicates the HDMI audio format.

• “- - -” will be displayed, when it does not have any

information.

VCR

Press [VCR] first. Press [DISPLAY] to display the On Screen Display.

12:00

AV2

STEREO

Note

• In some descriptions on this manual, only one disc type is indicated as an example.

Press [DISPLAY] while the On-Screen Display is displayed for the following Information.

File name information

File Name

My File

(only when a CD with MP3/JPEG/DivX® files is in playback)

7 66

This is an example screen for explanation. Displayed items are depending on the actual mode.

0:00:00

STEREOSP

1 Current time 2 Position number 3 Audio status of the receiving broadcast

or external equipment

Page 17

E9NG1BD_EN.book Page 17 Monday, April 7, 2008 5:54 PM

4 Audio status of the currently playing

back video tape 5 Tape counter 6 Recording or playing back speed 7 Status of the current tape

While in the VCR mode, the On Screen Display of the VCR mode is displayed.

INFO Menu

DVB

Press [INFO ] while viewing a DVB programme to display the programme information.

4 UKTV Gold

10:00-11:00 TV gossip show 11:00-12:00 Cooking show

2 3 4

1 Channel number 2 Channel name 3 Current programme information 4 Next programme information

The window will automatically exit after 3 seconds, or press [INFO ] to exit.

Main Menu

Press [SETUP] to display the main menu. Then use

K / L] to select a menu and press [ENTER / OK] to

[

display the sub menu. These menus provide entries to all main functions of the unit.

4 5 6

Setup

General Setting

Timer Programming

Title List

DVD Menu

DVB Menu

CD Playback Mode

General Setting

1 2

Playback Display

Video

Recording Clock

Channel

DivX HDMI

Reset All

Parental Lock Audio Out Disc Menu Language Audio Language Subtitle Language Angle Icon Still Mode TV System

1 Playback:

To set up the unit to play discs as you prefer.

2 Display:

To set up the OSD screen as you prefer.

3Video:

To set up the video setting.

4 Recording:

To set up the unit to record to discs as you prefer.

5 Clock:

To set up the clock of the unit as you need.

6 Channel:

To adjust the channel setting of the unit as you prefer.

7DivX:

To set up the setting for the DivX® playback.

8HDMI:

To set up the HDMI connection setting. You can select only when the HDMI cable is connected.

9 Reset All:

To reset all settings to the factory default.

DVB Menu

1 2 3

DVB Me nu

Adult Lock Language About

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

1 General Setting:

To go to General Setting menu.

2 Timer Programming:

To programme a timer recording.

3 Title List:

To call up the title list.

4DVD Menu:

To set up the DVD disc setting.

5DVB Menu:

To set up the DVB setting.

6 CD Playback Mode:

To set up the CD playback setting.

• “CD Playback Mode” is available only when an

Audio CD, a Video CD, a CD-RW/-R with MP3 / JPEG / DivX

files is inserted into the unit.

1 Adult Lock:

To set the Pincode for “Adult Lock”.

2 Language:

To set up the language for audio, subtitle and teletext.

3 About:

To check the current DVB system software version of this unit.

VCR Functions Others

Page 18

E9NG1BD_EN.book Page 18 Monday, April 7, 2008 5:54 PM

DVD Menu / CD Playback Mode

DVD Menu

Format

Finalise Disc Protect OFF ON

Delete All Playlists

CD Playback Mode

Random Play

Programme Play PBC (Video CD only)

Slide Show

1 Format (DVD-RW, DVD+RW only):

Allows you to format the disc.

2Finalise:

Allows you to finalise a disc containing recorded titles.

3 Disc Protect (VR mode DVD-RW,

DVD+RW/+R disc only):

Allows you to protect a disc from accidental editing or recording.

4 Delete All Playlists (VR mode DVD-RW

disc only):

Allows you to delete Playlist.

5Random Play:

Allows you to activate the random playback feature.

6 Programme Play (Audio CD/Video CD

only):

Allows you to activate the programme playback feature.

7 PBC (Video CD only):

Allows you to select images or information on the menu screen by activating PBC (playback control) function.

8 Slide Show (JPEG files only):

Allows you to select the display time of the slide show mode.

Page 19

E9NG1BD_EN.book Page 19 Monday, April 7, 2008 5:54 PM

Front Panel Display Guide

Introduction Connections Basic Setup Playback

1 Title / Track and Chapter number

: Title / track number : Chapter number

2 Current status of the unit

p : Appears when disc playback is paused.

Appears during step by step playback.

B : Appears when playing back a disc.

: Appears during slow forward / reverse

playback.

: Appears when the timer programming or

One-touch Timer Recording (OTR) is set and is operating, or when the unit goes into the Satellite Link standby mode. Flashes when there is an error in programming.

I: Appears when recording.

Flashes when recording being paused.

Display Messages

VCR

DVD

: Appears when a tape is in the unit.

: Appears when a disc is in this unit. DB: Appears when dubbing. DVD: Appears when this unit is in DVD output

mode, or the timer-standby mode for DVD recording.

VCR: Appears when this unit is in VCR output

mode, or the timer-standby mode for VCR recording.

3 Displays the following

• Playback time

• Current title / chapter / track number

• Recording time / remaining time

•Clock

• Channel number

• One-touch Timer Recording (OTR) remaining

time

• Selected HDMI output mode

Recording

The disc tray is opening.

DVD

The PBC function of the Video CD is

DVD

activated.

The disc tray is closing.

DVD

A disc is loading.

DVD

Data is being recorded on a disc.

DVD

Appears when the Satellite Link Recording is in standby.

Appears when HDMI output mode

DVD

(480p) is selected.

Appears when HDMI output mode

DVD

(576p) is selected.

Appears when HDMI output mode

DVD

(720p) is selected.

Appears when HDMI output mode

DVD

(1080i) is selected.

Appears when HDMI output mode

DVD

(1080p) is selected.

Editing

Function Setup

VCR Functions Others

Page 20

E9NG1BD_EN.book Page 20 Monday, April 7, 2008 5:54 PM

Connections

Audio/Video cable (not supplied)

Scart/RCA cable

Scart adaptor (not supplied)

HDMI OUT

DVD

COMPONENT

DIGITAL

VIDEO OUT

AUDIO OUT

COAXIAL

AUDIO

/CBPB/CB

OUT

PR /CR

(not supplied)

DVD/VCR

Connections

Connecting to a TV

Connect the unit to a TV after considering the capabilities of your existing equipment.

Before installation, plug off your TV and this unit.

1 Connect the antenna or cable to the

ANTENNA IN jack of this unit.

2 Connect the ANTENNA OUT jack of

this unit to the Aerial jack of your TV. Use the supplied RF cable.

Using the Scart socket

3 Connect AV1 (TV) Scart socket of

this unit to the Scart socket of your TV. Use a commercially available Scart cable.

Note

• If your TV does not have a Scart socket, use a commercially available Scart adaptor or Scart/RCA cable to connect. Use only AV1 (TV) or AV2 (DECODER) socket for the VCR output signals of this unit.

• Connect this unit directly to the TV. If the AV cables are connected to a VCR, pictures may be distorted due to the copy protection system.

• Teletext can only be output in VCR mode through AV1 (TV) out.

• When changing the “Video Out” setting (“SCART (RGB)”, “Component (Interlace)” or “Component (Progressive)”), connect to the corresponding jack on the TV. If the setting is changed, for example, to “Component (Interlace)” or “Component (Progressive)” while the scart cable is connected to the TV, a distorted video signal may result.

To A e r i al j a c k

Antenna

Cable Signal

Scart cable

(not supplied)

AV2(DECODER)

ANTENNA

AV1(TV)

OUT

Selecting Progressive Scan (576p/480p or Interlaced 576i/480i) Playback

• If your TV is compatible with progressive scanning (576p/480p), connect the TV to the COMPONENT VIDEO OUT jacks of the unit and set “Video Out” setting to “Component (Progressive)” in “Setup” menu. (See pages 81 to 82.) Next, set your TV to the progressive scan mode.

• If your TV is not compatible with progressive scan, set “Video Out” setting to “Component (Interlace)”.

• Use a commercially available adaptor if the Video input jacks of your TVs or monitors are the BNC type.

• Only component and HDMI connections are compatible with the Progressive Scan.

RF cable (supplied)

RF cable (not supplied)

Using the COMPONENT VIDEO OUT jacks and the AUDIO OUT jacks (for DVD or Tuner)

If your TV has a Component Video input jack, use a Component Video cable (to connect the COMPONENT VIDEO OUT jacks) and an Audio Cable (to connect the AUDIO OUT(L/R) jacks).

• Component connection provides the better quality picture.

1 Follow the steps 1 and 2 on this page

in “Connecting to a TV”.

2 Connect the COMPONENT VIDEO

OUT jacks of this unit to Component Video input jacks of your TV. Use a commercially available Component video cable.

3 Connect the AUDIO OUT (L/R) jacks

of this unit to the analogue Audio input jacks of your TV. Use a commercially available Audio cable.

Page 21

E9NG1BD_EN.book Page 21 Monday, April 7, 2008 5:54 PM

COMPONENT VIDEO OUT

PB /CBPB/CB

PR /CR

Component

Video IN

YPB/CB PR/CR

AV2(DECODER)

DVD/VCR

AV1(TV)

Component Video Cable (not supplied)

ANTENNA

OUT

Audio cable (not supplied)

HDMI OUT

AUDIO IN

DVD

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

Connecting to a TV with an HDMI Compatible Port (for DVD or Tuner)

[HDMI CONNECTION]

A simple 1-cable connection with a device having an HDMI (high-definition multimedia interface) connector allows digital transfer of both digital video signals and multi-channel audio signals. This is the best method to connect this unit. It can minimise the deterioration of image quality. Use the HDMI cable (commercially available) for connection. Connect the HDMI output jack of this unit to the HDMI input jack of TV.

HDMI cable (not supplied)

To H DM I input jack

HDMI OUT

this unit

Selecting HDMI mode

Press [HDMI] to select the HDMI output mode. The output mode changes as follows every time [HDMI] is pressed. 576p (PAL) / 480p (NTSC) J 720p J 1080i J 1080p (An HDMI mode that is not supported by the display device will be skipped.)

Actual Output Modes by Media

Audio recording format of the disc

Dolby Digital

LPCM

DVD-video

DTS

MPEG

Dolby Digital

DivX

MP3

MP2

For Audio CD, Video CD and MP3 files, 2 channel PCM will be output regardless of the “Dolby Digital” setting.

Dolby Digital / DTS / MPEG setting of this unit

PCM 2channel PCM Stream Dolby Digital PCM Stream ON DTS OFF PCM 2channel PCM Stream MPEG PCM 2channel PCM Stream Dolby Digital PCM Stream PCM 2channel PCM Stream MPEG

HDMI IN

Actual output

2channel PCM

If the connected device is not compatible with HDMI BITSTREAM, audio will be output as PCM even if you select “Stream” in “Dolby Digital” setting. (See page 79.)

To play back the digital video images of a DVD via an HDMI connection, it is necessary that both the player and the display device (or an AV amplifier) support a copyright protection system called HDCP (highbandwidth digital content protection system). HDCP is copy protection technology that comprises data encryption and authentication of the connected AV device. This unit supports HDCP. Please read the operating instructions of your display device (or AV amplifier) for more information. *HDMI: High Definition Multimedia Interface

Note

• Because HDMI is an evolving technology, it is possible that some devices with an HDMI input may not operate properly with this unit.

• When using an HDCP-incompatible display device, the image will not be viewed properly.

• This unit does not support Regza link or CEC control.

• The audio signals from the HDMI connector (including the sampling frequency, the number of channels and bit length) may be limited by the device that is connected.

• Among the monitors that support HDMI, some do not support audio output (for example, projectors). In connections with device such as this unit, audio signals are not output from the HDMI output connector.

• When this unit’s HDMI connector is connected to a DVI-D compatible monitor (HDCP compatible) with an HDMI-DVI converter cable, the signals are output in digital RGB.

• If the connected equipment is not compatible with HDMI BITSTREAM, DTS sound will not be output.

• When the power failure occurs, or when you unplug the unit, some problems in the HDMI setting might occur. Please check and set the HDMI setting again.

Connecting to an External Equipment

This unit has four input terminals which can be selected using [INPUT SELECT ] on the remote control, AV1 or AV2 on the rear panel and AV3 or DV (AV4) on the front panel. Be sure that all the units are off before making connections.

Recording from a DVD player, VCR, Satellite Box or other Audio-Video equipment with a Scart output socket (AV2)

AV output socket (Scart)

Scart cable (not supplied)

AV2 ( D E C O D E R )

DVD

DIGITAL

COMPONENT

AUDIO OUT

VIDEO OUT

COAXIAL

AUDIO

/CBPB/CB

OUT

PR /CR

AV2(DECODER)

DVD/VCR

ANTENNA

AV1(TV)

OUT

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 22

E9NG1BD_EN.book Page 22 Monday, April 7, 2008 5:54 PM

Note

• When you record a TV programme from a Satellite Box, you must connect a Scart cable to AV2(DECODER). (See pages 46 to 47.)

• When AV2 is connected, the signal from the AV2 will be output automatically. If you want to monitor the signal from other input, you must press [DISPLAY] first. Then, select the desired input to monitor with [INPUT SELECT ].

Recording from a camcorder or other Audio-Video equipment with no Scart output socket (AV3)

Connect to AUDIO/VIDEO input jacks on the front panel using RCA Audio Video cables. When connecting a DV-camcorder, use DV input jack of AV4(Front).

AV3/ AV 4 ( F r o n t )

DVD -RW/R +RW/R RECORDING

VCR/DVD

Video cable (not supplied)

REC

DVD

DVDVCR

AV3

VIDEO L R

DV cable (4-pin) (not supplied) (for DVD or Tuner)

DV OUT

VIDEO

OUT

Audio cable (not supplied)

AUDIO

OUT

AV3 AV4

Note

• When connecting an external device of monaural output to this unit, use AUDIO L jack of AV3.

Digital Audio for Better Sound Quality (for DVD or Tuner)

Dolby Digital decoder, DTS decoder or MPEG decoder, etc.

Digital audio

input jack

COAXIAL

1 For clear digital sound quality, use

the DIGITAL AUDIO OUT (COAXIAL) jack to connect your digital audio equipment.

If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

Connecting a Dolby Digital™ decoder, DTS decoder or MPEG decoder

• Connecting multi-channel Dolby Digital decoder allows you to enjoy the Multi-channel Dolby Digital surround system as well as DTS decoder, Multichannel surround system.

• After connecting to a Dolby Digital decoder, set “Dolby Digital” to “Stream” in “Audio Out” menu. (See page 79.)

• After connecting to a DTS decoder, set “DTS” to “ON” in “Audio Out” menu. (See page 79.)

• After connecting to a MPEG decoder, set “MPEG” to “Stream” in “Audio Out” menu. (See page 79.)

Connecting to an MD deck or DAT deck

• The audio source recorded in Dolby Digital Multichannel surround format cannot be recorded using an MD or DAT deck as a digital sound.

• If not connected to a Dolby Digital decoder, set “Dolby Digital” to “PCM” in “Audio Out” menu. Playing back a DVD using incorrect settings may generate noise distortion and damage speakers.

• Set “Dolby Digital” and “MPEG” to “PCM” and set “DTS” to “OFF” in “Audio Out” menu for connecting to an MD or DAT deck.

• You can use AUDIO OUT(L/R) jacks for the connection of your audio system.

After You Have Completed Connections

Switch the input selector on your TV to an appropriate external input channel. For details, refer to the Owner’s Manual of your TV.

Note

• Connect this unit directly to the TV. If the AV cables are connected to a VCR, pictures may be distorted due to the effects of the copy protection system.

DVD

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

HDMI OUT

DVD

DIGITAL

COMPONENT

AUDIO OUT

VIDEO OUT

COAXIAL

AUDIO

OUT

AV2(DECODER)

DVD/VCR

AV1(TV)

The connections illustrated above are optional for better sound.

Coaxial cable (not supplied)

ANTENNA

OUT

Page 23

E9NG1BD_EN.book Page 23 Monday, April 7, 2008 5:54 PM

Basic Setup

Introduction Connections Basic Setup Playback

Initial Setting

When you turn on this unit for the first time, you need to follow these steps.

1 Press [ ON / STANDBY]. 2 Turn the TV on. Select the input to

which the unit is connected.

3 Select your desired channel preset

type using [U / D]. Then press [ENTER / OK].

Initial Setting

Auto Tuning

Make sure the antenna is connected to “ANTENNA IN” jack.

Digital tuning

Digital & Analog tuning

Analog tuning

The unit will start getting channels available in your area.

Digital tuning:

Only the DVB channels receivable in your area are automatically scanned and memorised.

Digital & Analog tuning:

Both analogue and DVB channels receivable in your area are scanned and memorised automatically.

Analog tuning:

Only the analogue channels receivable in your area are automatically scanned and memorised.

• If no channel has been memorised, the antenna confirmation display will appear. Press

[ENTER / OK] to start auto scanning again or press [RETURN / BACK] to cancel the initial setting.

4 After finishing channel setting,

“Clock Setting” will appear. Then press [ENTER / OK].

Initial Setting

Clock Setting

- - / - - / - - - - ( - - - )

- - : - -

Channel Setting

You can retune this unit or edit the channel setting by the following methods.

Auto Tuning (DVB & ANALOG)

Programme the tuner to scan both analogue and DVB channels you can receive in your area.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

“General Setting” menu will appear.

2 Select “Channel” using [U / D], then

press [ENTER / OK].

3 Select “Auto Tuning (DVB &

ANALOG)” using [U / D], then press [ENTER / OK].

The unit will start storing channels available in your area.

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Wait for several minutes to finish channel storing.

• Analogue channels will be stored in channel 901-999 after it is scanned by this unit.

Auto Tuning (DVB & ANALOG) DVB Channel Setup ANALOG Channel Setup

4 Press [SETUP] to exit.

You can select only the channels memorised in this unit by using [PROG. / ].

To cancel auto tuning

Press [RETURN / BACK] or [SETUP] during scanning.

Note

• The selection will be affected by how you receive TV channels in your local area.

• If the auto tuning is cancelled during scanning, some channels not yet tuned may not be received.

• You cannot change the channel when this unit is in any recording mode (normal recording, One-touch Timer Recording or timer recording).

Recording

Editing

Function Setup

VCR Functions Others

5 Follow to the step 5 on page 33 in

“Manual Clock Setting”.

Page 24

E9NG1BD_EN.book Page 24 Monday, April 7, 2008 5:54 PM

Auto Tuning (ANALOG)

ANALOG

Programme the tuner to scan only the analogue channels you can receive in your area.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Channel” using [U / D], then

press [ENTER / OK].

3 Select “ANALOG Channel Setup”

using [U / D], then press [ENTER / OK].

4 Select “Auto Tuning” using [U / D],

then press [ENTER / OK].

The unit will start storing channels available in your area.

ANALOG Channel Setup

Auto Tuning Manual Tuning Move

Wait for several minutes to finish channel storing.

• Analogue channels will be stored in channel 901-999 after it is scanned by this unit.

5 Press [SETUP] to exit.

You can select only the channels memorised in this unit by using [PROG. / ].

To cancel auto tuning

Press [RETURN / BACK] or [SETUP] during scanning.

Note

• The selection will be affected by how you receive TV channels in your local area.

• If the auto tuning is cancelled during scanning, some channels not yet tuned may not be received.

• You cannot change the channel when this unit is in any recording mode (normal recording, One-touch Timer Recording or timer recording).

• Sorting of TV channels from 901 to 906 will be performed automatically as follows. 901: BBC1 902: BBC2 903: ITV 904: CH4 905: CH5 906: SKY NEWS

• If you are using a satellite receiver, or a cable box, turn it on and select Sky News before commencing tuning. If the Sky News channel is not available to you, choose another channel that you can recognise easily, and move this reception to preset 906 after the automatic tuning has finished. Instructions on page 25 explain how to move channels.

Manual Tuning (ANALOG)

ANALOG

You can preset an analogue channel manually and individually.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Channel” using [U / D], then

press [ENTER / OK].

3 Select “ANALOG Channel Setup”

using [U / D], then press [ENTER / OK].

4 Select “Manual Tuning” using

[U / D], then press [ENTER / OK].

5 Select “Position” using [U / D], then

press [P].

Manual Tuning

Position

Channel

Decoder

Skip

901

OFF

6 Select the position number you want

to use using [the Number buttons] or [U / D], then press [L].

• You can select position number 901 to 999.

•With [the Number buttons], you only need to

enter the last 2-digit numbers.

7 Select “Channel” using [U / D], then

press [P].

8 Press [U / D] to start scanning.

• The tuner will begin to search up or down automatically. When a channel is found, the unit will stop searching and the picture will appear on the TV screen.

• You can select a desired channel number using [the Number buttons]. Refer to the following Channel Plan table and press the three digits to select the channel number. (To select channel 4, press [0] first and then press [0] and [4]. Or press [4] and then “– – 4” appears and wait for 2 seconds.)

• If this is the channel you want, press [L].

Channel Plan

CH Indication TV Channel

01 - 10 IRA-IRJ, GAP

21 - 69 E21 - E69

74 - 78 X, Y, Z, Z+1, Z+2

80 - 99, 100 S1 – S20, GAP

121 - 141 S21 - S41

This unit can receive the Hyper and Oscar frequency bands.

• If “Skip” is set to “ON”, select “Skip” using

[U / D], then press [P]. Select “OFF” using [U / D], then press [L].

• If you want to decode scrambled signals, select “Decoder” using [U / D], then press [P]. Select “ON” using [U / D], then press [L].

• To store another channel, repeat steps 5 to 8.

9 Press [SETUP] to exit.

Page 25

E9NG1BD_EN.book Page 25 Monday, April 7, 2008 5:54 PM

Skip a Preset Channel

ANALOG

You can set the unit to skip channels. You can no longer receive or watch when you access channels using [PROG. / ].

1 Follow steps 1 to 4 in “Manual

Tuning (ANALOG)” on the previous page.

2 Select “Position” using [U / D], then

press [P].

3 Select the position number you want

to skip using [the Number buttons] or [U / D], then press [L].

4 Select “Skip” using [U / D], then

press [P].

5 Select “ON” using [U / D], then

press [L].

• To skip another channel, repeat steps 2 to 5.

6 Press [SETUP] to exit.

Move

ANALOG

You can replace two channels.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Channel” using [U / D], then

press [ENTER / OK].

3 Select “ANALOG Channel Setup”

using [U / D], then press [ENTER / OK].

4 Select “Move” using [U / D], then

press [ENTER / OK].

5 Select the position number that you

wish to move the channel to using [U / D], then press [ENTER / OK].

You cannot select a position number where “– – –” appears next to the number, because “Skip” is set to “ON” for that position number.

6 Move the channel to another

position number using [U / D], then press [ENTER / OK].

• To move another channel, repeat steps 5 to 6.

7 Press [SETUP] to exit.

Auto Tuning (DVB)

DVB

You can programme the tuner to scan only the DVB channels that you can receive in your area.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Channel” using [U / D], then

press [ENTER / OK].

3 Select “DVB Channel Setup” using

[U / D], then press [ENTER / OK].

4 Select “Auto Tuning” using [U / D],

then press [ENTER / OK].

The unit will start storing channels available in your area.

DVB Channel Setup

Edit Channels Auto Tuning Manual Tuning Signal Information

The tuner scans and memorises all the active DVB channels (TV / Radio) in your area.

Channel search

S. No. TV channel

ITV1 701 BBC Radio 1

ITV2

Channel

4 E4

Channel48 UHF

Progress

•Press [ENTER / OK] after Auto Tuning is completed, then the lowest memorised DVB channel appears on the screen.

S. No. Radio channel

702

BBC Radio 2

703

Magic Radio Classic FM

704

690000kHz/8M

60%

5 Press [SETUP] to exit.

You can use [PROG. / ] for the memorised DVB channels.

Note

• If you press [RETURN / BACK] during the

scanning, the screen will return to the previous displayed menu, and Auto Tuning will be cancelled.

• If you press [SETUP] during the scanning, this

operation will stop and the lowest memorised DVB channel will appear on the TV screen.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 26

E9NG1BD_EN.book Page 26 Monday, April 7, 2008 5:54 PM

Manual Tuning (DVB)

DVB

You can preset a DVB channel manually and individually.

1 Follow steps 1 to 3 in “Auto Tuning

(DVB)” on page 25.

2 Select “Manual Tuning” using

[U / D], then press [ENTER / OK].

3 Select your desired position number

using [U / D], then press [ENTER / OK].

Manual Tuning (DVB)

Channel Auto

• You can also switch the mode by using

[PROG. / ].

• You can select any DVB channels using

[the Number buttons] when you are in analogue or external input (AV1/AV2/AV3/DV(AV4)) mode.

• You can select any analogue channels using

[the Number buttons] when you are in DVB mode.

Quick Select

DVB

With “Quick select” menu, you can select your favourite DVB channel quickly. Refer to “Edit Group Lists” on page 27.

1 Press [ENTER / OK] while watching a

DVB channel.

• “Quick select” menu will appear.

Quick select

All

S. No. Channel name

Moving picture 576i

ITV1

ITV2

ITV3

Channel

More 4

• The tuner will begin to search up or down automatically. When a DVB channel is found, the unit will stop searching.

• When “Auto” is selected the unit will search for the channels which have not been stored in channels memory.

4 Press [SETUP] to activate the

setting.

Select a Channel

You can select a channel using [the Number buttons].

e.g.) 6 ch: Press [6], then wait for 2 seconds or

press [0],[0],[6].

15 ch: Press [1],[5], then wait for 2 seconds or

press [0],[1],[5].

You can also select a channel using [PROG. / ] .

• You can only select channels 1 to 999.

• Analogue channels will be stored in channel 901999 and DVB channels will be stored in channel 1900 after it is scanned by this unit.

To switch DVB, analogue and external input (AV1/ AV2 / AV 3 /DV(AV4 ) ) m ode.

You can switch between DVB, analogue and external input (AV1/AV2/AV3/DV(AV4)) mode by pressing [INPUT SELECT ] repeatedly. The mode changes as follows:

DVB mode  Analogue mode  AV1  AV 2  AV3  DV(AV4)

2 Press [L / P] to select your favourite

group list. (“All”, “Group1” “Group8”)

• “All” shows a list of all the memorised DVB channels.

• If the favourite group does not have any channels, the group will be skipped.

3 Select the DVB channel you want to

watch using [U / D], then press [ENTER / OK].

4 Press [RETURN / BACK] to exit.

Page 27

E9NG1BD_EN.book Page 27 Monday, April 7, 2008 5:54 PM

Edit Channels (DVB)

DVB

With “Edit Channels” menu, you can see all the memorised DVB channels and sort them into the group lists (“Quick select”) or set the viewer limitation (“Adult Lock”), etc.

1 Follow steps 1 to 3 in “Auto Tuning

(DVB)” on page 25.

2 Select “Edit Channels” using

[U / D], then press [ENTER / OK].

• “Edit Channels” menu will appear.

Edit Channels

S. No. Channel name Fav Skip Lock Del

Moving picture 576i

ITV1

ITV2

ITV3

Channel

England Crystal Palac 562000kHz/8M

1 Channel numbers 2 Channel names 3 Channel information 4 Channel Setting

4 4

3 Press [SETUP] to exit.

Note

•Press [INFO ] to display the user guide. You can

see each explanation of the buttons which can be used in “Edit Channels” menu. Press [RETURN / BACK] to return to “Edit Channels” menu.

Edit Group Lists

DVB

You can sort each DVB channel into 8 different favourite group lists (“Group1” -“Group8”). With “Quick select” menu, you can select your favourite DVB channel quickly. Refer to “Quick Select” on page 26.

1 Follow steps 1 to 2 in “Edit Channels

(DVB)” on this page.

2 Select the DVB channel you want to

add to the favourite group list using [U / D], then select the number of the favourite group list you want to add to using [the Number buttons] ([1] - [8]).

Edit Channels

S. No. Channel name Fav Skip Lock Del

Moving picture 576i

ITV1

ITV2

ITV3

Channel

England Crystal Palac 562000kHz/8M

• The number you selected will appear.

•Press [0] to cancel from the favourite group list.

4 4

3 Press [SETUP] to exit.

Skip Channels

DVB

You can set the unit to skip the unwanted DVB channels when you use [PROG. / ].

1 Follow steps 1 to 2 in “Edit Channels

(DVB)” on this page.

Introduction Connections Basic Setup Playback

Recording

Editing

2 Select the DVB channel you want to

Function Setup

skip using [U / D], then press [GREEN].

Edit Channels

S. No. Channel name Fav Skip Lock Del

Moving picture 576i

ITV1

ITV2

ITV3

Channel

England Crystal Palac 562000kHz/8M

VCR Functions Others

4 4

• “ ” will appear.

•Press [GREEN] to cancel. “ ” will disappear.

3 Press [SETUP] to exit.

Page 28

E9NG1BD_EN.book Page 28 Monday, April 7, 2008 5:54 PM

Adult Lock

DVB

You can set the unit to limit the access to the DVB channels.

1 Follow steps 1 to 2 in “Edit Channels

(DVB)” on page 27.

2 Select the DVB channel you want to

limit the access to using [U / D], then press [YELLOW].

Edit Channels

S. No. Channel name Fav Skip Lock Del

Moving picture 576i

ITV1

ITV2

ITV3

Channel

England Crystal Palac 562000kHz/8M

• “ ” will appear.

•Press [YELLOW] to cancel. “ ” will disappear.

4 4

3 Press [SETUP] to exit.

• Once you turn off the unit, Pincode will be required to view the locked channels.

• To set the Pincode, refer to “Pincode Setting for Adult Lock” on page 31.

Delete Channels

DVB

You can delete the DVB channels from the memorised DVB channels.

1 Follow steps 1 to 2 in “Edit Channels

(DVB)” on page 27.

2 Select the DVB channel you want to

delete using [U / D], then press [BLUE].

Edit Channels

S. No. Channel name Fav Skip Lock Del

Moving picture 576i

ITV1

ITV2

ITV3

Channel

England Crystal Palac 562000kHz/8M

• “ ” will appear.

•Press [BLUE] to cancel. “ ” will disappear.

4 4

3 Press [SETUP] to exit.

• The channel has been deleted from the “Edit Channels” menu.

Channel Move

DVB

You can change the order of the DVB channels when you use [PROG. / ] by swapping positions of two channels.

1 Follow steps 1 to 2 in “Edit Channels

(DVB)” on page 27.

2 Select the DVB channel of which you

want to change the position using [U / D], then press [ENTER / OK].

3 Select the channel you want to swap

the position with using [U / D], then press [ENTER / OK].

• The two channels swap positions.

4 Press [SETUP] to exit.

Edit Channel Names

DVB

You can edit the DVB channel names as you want.

1 Follow steps 1 to 2 in “Edit Channels

(DVB)” on page 27.

2 Select the DVB channel of which you

want to edit the name using [U / D], press [RED].

• Name editing display will appear.

Edit Channels

Fav Skip Lock Del

DEF

MNO

4 4

562000kHz/8M

ABC

@S#

JKL

GHI

TUV

PQRS9WXYZ

SPACE

0-9 A->a INS DEL

3 Edit the name using [the Number

buttons].

•Press [the Number buttons] repeatedly until

the desired letter appears.

•Press [L / P] to move the cursor left or right.

•Press [RED] to select alphabets or numbers.

•Press [GREEN] to select capital or lower case

letters.

•Press [YELLOW] to move the letter on the

cursor to the right.

•Press [BLUE] to delete the letter on the cursor,

and move the cursor to the left.

4 After completion, press

[ENTER / OK].

5 Press [SETUP] to exit.

Note

• You can enter up to 19 letters.

Page 29

E9NG1BD_EN.book Page 29 Monday, April 7, 2008 5:54 PM

Signal Information

DVB

You can check the detailed information of the current DVB channel.

1 Follow steps 1 to 3 in “Auto Tuning

(DVB)” on page 25.

2 Select “Signal Information” using

[U / D], then press [ENTER / OK].

• Signal Information display will appear.

15 CITV

DVB-T 8M England

Frequency 474000KHz A.PID 0274

Bandwidth 8M V.PID 0273

12:00-15:00 CITV 576i

15:00-18:00 CITV 576i

Signal

Quality

P.PID 0512

80%

90%

3 Press [SETUP] to exit.

• “Signal Information” is not available for analogue channel and external input (AV1/AV2/ AV3/DV(AV4)).

• “Signal Information” is also not available while the Pincode input field for locked DVB channel is displayed.

TV View Operation

The following operations are available while viewing TV channels through this unit’s tuner.

Selecting the TV Aspect Ratio

You can select the TV aspect ratio to match the format of the programme you are playing back with the unit and that of your TV screen (4:3 standard or 16:9 wide screen TV).

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Video” using [U / D], then

press [ENTER / OK].

3 Select “TV Aspect” using [U / D],

then press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

TV Aspect Video out

Introduction Connections Basic Setup Playback

Recording

4 Select the desired option using

[U / D], then press [ENTER / OK].

TV Aspect

4:3 Letter Box 4:3 Pan & Scan 16:9 Wide

5 Press [SETUP] to exit.

Hint

If you have a standard TV:

• Select “4:3 Letter Box” for a full width picture with black bars at the top and bottom.

• Select “4:3 Pan & Scan” for a full height picture with both sides trimmed.

If you have a wide screen TV:

• Select “16:9 Wide”.

Editing

Function Setup

VCR Functions Others

Page 30

E9NG1BD_EN.book Page 30 Monday, April 7, 2008 5:54 PM

Selecting the Audio Mode

ANALOG

You can switch between TV audio modes by pressing [AUDIO ]. Each mode is indicated on the TV screen.

• During reception of analogue bilingual broadcasts

Mode Audio output

Main Main audio from both speakers Main

Sub Sub audio from both speakers Sub

Main /

• Main audio from the left speaker

Sub

• Sub audio from the right speaker

• If the programme does not have more than one

sound track, [AUDIO ] is not effective.

Display on

the TV screen

Main / Sub

Digital Teletext Reception

DVB

Many broadcasters provide a DVB Teletext service in the form of a dedicated Teletext channel. This Digital service includes high quality text and graphics along with advanced navigation options.

1 Press [TEXT] to display Teletext

screen.

• Teletext for the TV channel you have selected will be displayed.

2 Use [RED] / [GREEN] / [YELLOW] /

[BLUE] to follow the instructions on screen.

3 Press [TEXT] to switch the Teletext

display off.

Note

• [TEXT] is not available during recording.

• This unit supports MHEG5 data service.

• This unit does not support MHP data service.

e.g.) Daily mode

Daily mode

Date 18/01/2008 Time 10:30:56

1 ITV1 2 ITV2 3 ITV3 4 Channel 5 E4 6 More 4

10:25-11:10 The Montel

D/W Series Extended Timer

18/01/2008 (Friday)

10:25-11:10 news

12:00-13:00 show

13:00-13:30 musical 13:30-14:35 variety show 19:30-20:00 news 20:00-21:00 drama

7 5

1 EPG menu mode 2 Date / Time 3 Date 4 Channel number / name 5 Channel programme 6 Programme you select now 7 Programmes set for the timer recording

: Programmes set for the series link timer

recording.

: Once only timer recording.

• For the series link timer recording, refer to

•Press [GUIDE] to exit.

•Press [RED] to switch between “Daily mode” and

•Press [GREEN] to see another series/part of the

•Press [BLUE] to set a timer recording for the

•Press [YELLOW] to see more detailed information

Using user guide

Press [INFO ] to display the user guide. You can see each explanation of the buttons which can be used in “EPG” menu. Press [RETURN / BACK] to return to “EPG” menu.

“Series Link Timer Recording” on page 45.

“Weekly mode”.

selected programme or recommended programme related to the selected programme.

selected TV programme.

of the selected programme.

Note

• EPG cannot be displayed during recording.

EPG (Electronic Programme Guide)

Electronic programme guide (EPG) gives you a list of the DVB programmes and detailed information about the programmes. To call up EPG while viewing DVB/ analogue channel or external input (AV1/AV2/AV3/ DV(AV4)), press [GUIDE]. You can also call up EPG by following steps.

1 In stop mode, press [SETUP]. Select

“Timer Programming” using [U / D], then press [ENTER / OK].

2 Select “EPG” using [U / D], then

press [ENTER / OK].

• Select the TV programme using [U / D / L / P],

then press [SETUP] or [GUIDE] to exit.

• From the EPG screen, you can also set the timer recording. Select the TV programme using

[U / D / L / P], then press [ENTER / OK] or [BLUE] to go to “Timer Programming” menu.

Refer to “Timer Recording (EPG)” on page 44.

Multiaudio

DVB

Many DVB channels transmit Multi audio information along with their DVB channels. You can select the desired audio mode and audio language.

1 While viewing a DVB programme,

press [AUDIO ].

Multiaudio

Stereo

English

Page 31

E9NG1BD_EN.book Page 31 Monday, April 7, 2008 5:54 PM

2 Select “Stereo”, “Right” or “Left”

using [L / P].

3 Select your desired audio language

using [U / D].

• The available audio language varies depending on the DVB broadcasts.

4 Press [ENTER / OK] to activate the

settings.

Note

• If the programme is changed, the audio language will be switched back to the default language you set in the “DVB Menu”. Refer to “Language Setting” on page 32.

Subtitle

DVB

Many DVB channels transmit Subtitle information along with their DVB channels. You can retrieve and display it on the TV screen.

1 While viewing a DVB programme,

press [SUBTITLE].

• If the programme has no subtitle information, “No information” will appear.

Subtitle

English

DVB Menu Setting

You can make settings of the digital tuner from the DVB Menu.

Pincode Setting for Adult Lock

DVB

You can set “Adult Lock” to “ON” or “OFF” and also change Pincode.

1 In stop mode, press [SETUP]. 2 Select “DVB Menu” using [U / D],

then press [ENTER / OK].

3 Select “Adult Lock” using [U / D],

then press [ENTER / OK].

DVB Menu

Adult Lock Language About

4 Select “ON” or “OFF” using [U / D],

then press [ENTER / OK].

Introduction Connections Basic Setup Playback

Recording

2 Select “On” using [L / P].

• If you do not want to display the subtitle, select “Off” using [L / P].

3 Select your desired subtitle

language using [U / D].

• The available subtitle language varies depending upon the broadcast.

4 Press [ENTER / OK] to activate the

settings.

Note

• If the programme is changed, the subtitle language will be switched back to the default language you set in the “DVB Menu”. Refer to “Language Setting” on page 32. If the default subtitle language is not available on the new programme, no subtitle will be displayed.

5 To set “Adult Lock” to “ON”:

1) Enter your desired Pincode using

[the Number buttons], then press [ENTER / OK].

2) For confirmation, enter the Pincode again using

[the Number buttons] then press [ENTER / OK].

To set “Adult Lock” to “OFF”:

Enter the Pincode using [the Number buttons].

• While entering the Pincode, use [L] or [CLEAR]

to clear any numbers erroneously entered.

6 Press [SETUP] to exit.

Note

• Once “Adult Lock” has been set to “ON”, Pincode will be required in order to view the locked channels or make the timer recording of them, and when you try to execute the “Auto Tuning” for DVB or “Edit Channels”.

• If you forget the Pincode, press [4], [7], [3], [7] to cancel the Pincode.

Editing

Function Setup

VCR Functions Others

Page 32

E9NG1BD_EN.book Page 32 Monday, April 7, 2008 5:54 PM

Language Setting

DVB

1 Follow steps 1 to 2 in “Pincode

Setting for Adult Lock” on page 31.

2 Select “Language” using [U / D],

then press [ENTER / OK].

3 Select the item by which you want to

change the language using [U / D], then press [ENTER / OK].

DVB Menu

Adult Lock Language About

Audio : Set the Audio language Subtitle : Set the Subtitle language Data Service : Set the Digital Teletext language

Audio Subtitle Data Service

4 Select a language using [U / D],

then press [ENTER / OK].

About

DVB

You can check the current DVB system software version of this unit.

1 Follow steps 1 to 2 in “Pincode

Setting for Adult Lock” on page 31.

2 Select “About” using [U / D], then

press [ENTER / OK].

3 Press [SETUP] to exit.

5 Press [SETUP] to exit.

Note

• The Audio and Subtitle setting may not be available for some broadcasts.

• To change the audio language, refer to “Multiaudio” on pages 30 to 31.

• To display the subtitle or choose the subtitle language, refer to “Subtitle” on page 31.

Page 33

E9NG1BD_EN.book Page 33 Tuesday, April 8, 2008 6:21 PM

Setting the Clock

Auto Clock Setting

This unit receives time signals from the analogue / DVB channels, and sets the clock automatically. Set the channel tuning before setting Auto Clock.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Clock” using [U / D], then

press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

3 Select “Auto Clock Setting” using

[U / D], then press [ENTER / OK].

• If any DVB channel has been set, the auto clock is on. “Auto Clock Setting” will be displayed in grey and you cannot select it.

4 Select “ON” using [U / D], then

press [ENTER / OK].

The current time will be set automatically.

5 Press [SETUP] to exit. 6 Press [ ON / STANDBY] to turn

off.

The Auto clock function is activated.

• This unit will search for the time every time when the power is turned off.

• Leave the unit off for several minutes to give it time to set the clock.

• The clock cannot be set automatically if you are not receiving a channel in your area that carries a time signal. In this case, set the clock manually.

• The unit will also correct the current time automatically at 8:00 and 1:10 if the unit is in standby mode or if you are watching DVB channel.

Manual Clock Setting

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Clock” using [U / D], then

press [ENTER / OK].

3 Select “Clock Setting” using [U / D],

then press [ENTER / OK].

Default date will appear.

4 Press [ENTER / OK] again.

Clock Setting

01 / 01 / 2008 ( TUE )

0 : 00

5 Enter the date (day / month / year)

using [U / D].

Press [P] to move the cursor to the next field. If you want to go back to the previous field, press [L].

6 Enter the time (hours / minutes)

using [U / D], then press [ENTER / OK].

The clock will start.

• Although seconds are not displayed, they will be counted from zero.

7 Press [SETUP] to exit.

Note

• Your clock setting will be lost if either there is a power failure or the unit is unplugged for more than 30 seconds.

• If you have set the timer recording, “Clock” will be displayed in grey and you cannot select it.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

Hint

• If you want to cancel “Auto Clock Setting”, select

“OFF” using [U / D], and then press [ENTER / OK] at the step 4.

Note

• The default setting of “Auto Clock Setting” is “ON”.

• The clock may set itself automatically after you connect the antenna cable to the unit and plug in the mains cable. In this case, the current time will appear on the front panel display.

• If there are only analogue channels memorised in this unit:

- The channel assigned to “904” must receive the

PDC signal in order to set the clock automatically.

- The unit will correct the current time by receiving

PDC broadcasts whenever the power is turned off.

- Between 23:00 and 1:00, the Auto Clock function

will not operate even when the power is turned off.

VCR Functions Others

Page 34

DVD-RW

DVD-R

DVD+RW

DVD+R

VCR

E9NG1BD_EN.book Page 34 Monday, April 7, 2008 5:54 PM

Recording

Information on DVD Recording

Type of Discs

This unit can record on DVD-RW/-R discs and DVD+RW/+R discs. DVD-R/+R discs allow you to record programmes only once, and the recorded contents can be erased although the space left on the disc does not change. DVD-RW/+RW discs allow you to record programmes repeatedly, and the recorded contents can be erased. There are 3 recording formats: VR mode, Video mode and +VR mode. VR and Video modes are available for DVD-RW discs while as only Video mode is available for DVD-R discs. +VR mode is available for DVD+RW/+R discs.

Video mode is the same recording format as used on the pre-recorded DVD-Videos you purchase in local shops. You can play back the discs recorded in this format in most of the DVD players. You will need to finalise such discs (see pages 52 to 53) before playing them back in other DVD players. Unless finalised, you can record additional materials or edit discs recorded in Video mode with this unit. VR (Video Recording) mode is a basic recording format for DVD-RW discs. VR mode offers advanced editing, and you can record and edit material repeatedly, however it is playable only on VR mode compatible unit. Finalisation is recommended before playing them back in other unit. +VR mode is a recording format for DVD+RW/+R disc. +VR mode offers basic editing, and it is playable in most DVD players. Finalisation is recommended before playing them back in other unit.

Restrictions on Recording

You cannot record copy-protected video using this unit. Copy-protected video includes DVD-Videos and some satellite broadcasts. If copy-protected material is detected, recording will pause or stop automatically and an error message appears on the screen. You can only record “Copy-once only” video using a DVD-RW disc in VR mode with Content Protection for Recordable Media (CPRM). When recording a TV broadcast or an external input, you can display copy control information on the screen. CPRM is a scrambling copy protection system for the protection of “copy-once” broadcast programmes. This unit is CPRM compatible, which means that you can record copy-once broadcast programmes, but you cannot then make a copy of those recordings. CPRM recordings can only be played back on DVD players that are specifically compatible with CPRM.

Information on Copy Control

Some satellite broadcasts include copy-protected information. If you wish to record them, refer to the following.

Copy-

Disc type / format

ver. 1.1 / ver. 1.2

DVD-RW

DVD-R

DVD+RW

ver. 1.1 / ver. 1.2 CPRM compatible

ver. 1.1 / ver. 1.2

Video

ver. 1.1 / ver. 1.2 CPRM compatible

ver. 2.0

free

once

Copyprohibited

Recording Mode

You can select a recording mode from 5 options. The recording time will vary depending on the recording mode you select as follows.

Recording

mode

XP 60 min 18 min

SP 120 min 36 min

LP 240 min 72 min

EP 360 min 108 min

SLP 480 min 144 min

• This table is intended for a standard new singlesided 12 cm / 8 cm disc. The recording times are estimates and actual recording time may differ.

• The audio and video quality becomes poorer as the recording time gets longer.

Recording time

12 cm 8 cm

Sound Quality

Video /

DVD+R

VCR

: Recordable : Not recordable

Note

• This unit cannot record on CD-RW or CD-R discs.

• DVD-RW/-R, DVD+RW/+R and CD-RW/-R discs recorded on a personal computer or a DVD or CD recorder may not be played back if the disc is damaged or dirty or if there is condensation on the recorder’s lens.

• If you record a disc using a personal computer, even if it is recorded in a compatible format, it may not be played back because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

• Discs recorded in Video mode on this unit cannot record additional information using other DVD recorders.

Page 35

E9NG1BD_EN.book Page 35 Monday, April 7, 2008 5:54 PM

• Since recording is performed using the Variable Bit Rate (VBR) method, the actual remaining time for recording may be a little shorter than the remaining time displayed on the OSD, depending on the picture you are recording.

Making Discs Playable in Other DVD Players (Finalise)

After recording, you must finalise the disc to play it back in other players. (See pages 52 to 53.) You cannot finalise discs in other DVD recorders.

After finalising

• After DVD-R discs are finalised:

- A Title menu is created automatically.

- Undo finalising is not possible.

- Additional recording or editing is not possible.

• After DVD-RW (Video mode) discs are finalised:

- A Title menu is created automatically.

- Undo finalising is possible. (See pages 52 to 53.)

- Additional recording or editing is possible if you

undo finalise. (See pages 52 to 53.)

• After DVD-RW (VR mode) discs are finalised:

- A Title menu is not created.

- Undo finalising is possible. (See pages 52 to 53.)

- Additional recording or editing is possible if you

undo finalise. (See pages 52 to 53.)

• After DVD+RW discs are finalised:

- A Title menu is created automatically.

- Undo finalising is possible. (See pages 52 to 53.)

- Additional recording or editing is possible even

without undo finalising.

• After DVD+R discs are finalised:

- A Title menu is created automatically.

- Undo finalising is not possible.

- Additional recording or editing is not possible.

Maximum Recordable Numbers of Title / Chapters

VR mode DVD:

99 titles per each Playlist and Original 999 chapters per each Playlist and Original

Video mode DVD:

99 titles per disc 99 chapters per title

+VR mode DVD:

49 titles per discs 254 chapters per disc 99 chapters per title

Formatting a Disc

Choosing the Recording Format of a Blank DVD-RW Disc

Video

DVD-RWDVD-RW

When inserting a brand-new DVD-RW/+RW disc, the unit automatically starts to initialise the disc. DVD+RW disc will always be formatted in +VR mode, and DVD-RW disc will be formatted either Video or VR mode according to the recording format mode setting of the unit. Before inserting a brand-new DVD-RW disc, you need to set the recording format to the desired mode. You can also manually format a DVD-RW disc once it has been used.

DVD-RWDVD-RW

1 In stop mode, press [SETUP]. 2 Select “DVD Menu” using [U / D],

then press [ENTER / OK].

3 Select “Format” using [U / D], then

press [ENTER / OK].

4 Select “Format Mode” using [U / D],

then press [ENTER / OK].

5 Select “Video mode” or “VR mode”

using [U / D], then press [ENTER / OK].

Format Mode

Video mode VR mode

Video mode

DVD Player Compatibility mode.

VR mode

Editing possibility mode.

6 Press [SETUP] to exit. 7 Insert a blank disc.

Formatting will start.

8 Formatting is complete.

“100%” is indicated.

Note

• The recording format setting is effective only for DVD-RW discs. You cannot change the recording format for a DVD-R disc and DVD+RW/+R disc.

• You cannot mix two formats on one DVD-RW disc. If you insert a disc that has been recorded before, the recording format cannot be changed even if you change it in “Setup” menu.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 36

VD+R

VD+RWW

VD+R

E9NG1BD_EN.book Page 36 Monday, April 7, 2008 5:54 PM

Make Recording Compatible

DVD+RWDVD+RW DDVD+R

Use this feature to make the unfinalised +VR mode discs recorded on other unit recordable on this unit. When you make an additional recording on this unit with “Make Recording Compatible” set to “ON”, the title list is automatically converted to this unit’s style.

DVD+R

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “Make Recording Compatible”

using [U / D], then press [ENTER / OK].

4 Select “ON” or “OFF” using [U / D],

then press [ENTER / OK].

Make Recording Compatible

ON OFF

ON: Title list will be replaced when you make

additional recordings to the discs recorded by other units.

OFF: Prohibiting additional record to the disc that has

a title list created by other units.

5 Press [SETUP] to exit.

Setting Aspect Ratio for Video Mode Recording

Video

DVD-RWDVD-RW

You can set aspect ratio for video mode recording.

DVD-RDVD-R

4 Select your desired setting using

[U / D], then press [ENTER / OK].

Aspect Ratio (Video mode)

Auto 4 : 3 16 : 9

Auto (default): It will be recorded with whichever

4:3 : Recorded in the aspect ratio of 4:3. 16:9 : Recorded in the aspect ratio of 16:9.

aspect ratio the broadcaster transmitted.

5 Press [SETUP] to exit.

Note

• For VR mode DVD-RW disc, the image will be recorded in whichever the ratio that the programme you record is broadcasted with, regardless of the “Aspect Ratio (Video mode)” setting.

• For DVD+RW/+R disc, the image will always be recorded in aspect ratio of 4:3.

Setting Auto Chapter

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

The unit inserts a chapter mark periodically (every 15 minutes by default) during recording. Using the Auto Chapter menu, you can set this function off or change the time period.

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “Auto Chapter” using [U / D],

then press [ENTER / OK].

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “Aspect Ratio (Video mode)”

using [U / D], then press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise Aspect Ratio (Video mode) Dubbing Mode Make Recording Compatible Bilingual Recording Audio External Input Audio Video Colour System

Page 37

E9NG1BD_EN.book Page 37 Monday, April 7, 2008 5:54 PM

4 If you want to set “Auto Chapter” off,

select “OFF” using [U / D], then press [ENTER / OK].

Auto Chapter

OFF 5 minutes 10 minutes 15 minutes 30 minutes 60 minutes

If you want to change the time period for “Auto Chapter”, select the required time period using [U / D], then press [ENTER / OK].

5 Press [SETUP] to exit.

Note

• The interval for auto chapter may be up to 2 minutes different from the time option you set.

• A blank chapter may be created depending on the remaining time of the disc.

• While recording, no more chapter marks will be added when the maximum chapter mark number is reached.

Reformatting a Disc Manually

Video

DVD-RWDVD-RW

If you are using a DVD-RW/+RW disc, you can format the disc by performing “Format”. You can format DVD-RW disc for either Video mode recording or VR mode recording. DVD+RW disc can be formatted in order to erase all content of the disc.

DVD-RWDVD-RWVRDVD+RWDVD+RW

5 Select “Yes” using [U / D], then

press [ENTER / OK].

e.g.) VR mode DVD-RW disc

Are you sure?

Yes

Formatting will start. If you want to cancel formatting, select “No”.

6 Formatting is complete.

Note

• It is not possible to use a disc formatted with this unit in other DVD recorder. When you use a disc with another DVD recorder, format a disc using that DVD recorder.

Introduction Connections Basic Setup Playback

Recording

Note

• When you reformat the disc, the contents of the disc are erased.

• Make sure that the recording format is set to the desired mode. (See the steps 1 to 6 in “Choosing the Recording Format of a Blank DVD-RW Disc” on page 35.)

Insert a recordable disc.

1 In stop mode, press [SETUP]. 2 Select “DVD Menu” using [U / D],

then press [ENTER / OK].

3 Select “Format” using [U / D], then

press [ENTER / OK].

4 Select “Start” using [U / D], then

press [ENTER / OK].

For DVD+RW, use [U / D] to select “Yes”, then press [ENTER / OK]. A pop up window will appear and prompt you to confirm.

Editing

Function Setup

VCR Functions Others

Page 38

VD+RWW

VD+R

VD+RWW

VD+R

VD+RWW

VD+R

E9NG1BD_EN.book Page 38 Monday, April 7, 2008 5:54 PM

Selecting the Sound Mode

This unit can receive bilingual broadcasts.

You can switch between modes by pressing [AUDIO ]. Each mode is indicated on the TV. When you record a DVB channel, only output sound channel will be recorded.

Setting External Input Audio

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

When the external input audio is a bilingual broadcast, you can choose “Stereo” or “Bilingual” to record on a DVD. This setting is only for recording external input (AV1/AV2/AV3).

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “External Input Audio” using

[U / D], then press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise Aspect Ratio (Video mode) Dubbing Mode Make Recording Compatible Bilingual Recording Audio External Input Audio Video Colour System

4 Select “Stereo” or “Bilingual” using

[U / D], then press [ENTER / OK].

External Input Audio

Stereo Bilingual

5 Press [SETUP] to exit.

Hint

• If you select “Stereo”: The audio will be recorded as “stereo audio”.

• If you select “Bilingual”: The audio will be recorded as “bilingual audio”. (See “Setting Bilingual Recording Audio” on this page for more detail.)

Setting Bilingual Recording Audio

Video

DVD-RWDVD-RW

You can select either “Main” or “Sub” audio to record a bilingual broadcast in Video mode or +VR mode. This setting is only for recording analogue channel.

DVD-RDVD-R DDVD+R

DVD+RW DDVD+R

DVD+R

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “Bilingual Recording Audio”

using [U / D], then press [ENTER / OK].

4 Select “Main” or “Sub” using

[U / D], then press [ENTER / OK].

Bilingual Recording Audio

Main Sub

5 Press [SETUP] to exit.

Note

• If you are recording onto a VR mode disc, both “Main” and “Sub” will be recorded regardless of your setting here. And when you play back, you can choose either audio format or a combination of both as your playback audio.

Recording Audio Select (XP)

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

You can enjoy high quality sound recording. This function works only when the recording mode is set at XP.

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “Recording Audio Select

(XP)” using [U / D], then press [ENTER / OK].

Page 39

VD+RWW

VD+R

E9NG1BD_EN.book Page 39 Monday, April 7, 2008 5:54 PM

4 Select “PCM” or “Dolby Digital”

using [U / D], then press [ENTER / OK].

Recording Audio Select (XP)

PCM Dolby Digital

PCM: Records PCM audio for the best

Dolby Digital: Records Dolby Digital audio for good

quality sound.

5 Press [SETUP] to exit.

Note

• “PCM” stands for Pulse Code Modulation. It changes analogue sound to digital sound without compressing audio data.

• When the recording mode is set at other than XP, the unit records “Dolby Digital” audio automatically even if you selected “PCM”.

Basic Recording

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

Follow the steps below to record a TV programme. (See pages 85 to 86 for VCR recording.)

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

1 Press [ ON / STANDBY] to turn on

the unit.

Turn on the TV and be sure to select the input to which the unit is connected.

2 Press [DVD]. 3 Press [OPEN / CLOSE O] to open the

disc tray.

4 Place the disc on the disc tray with

its label facing up. Be sure to align the disc with the disc tray guide.

8 Press [REC I] to start recording.

The “●” mark will be displayed on the TV screen briefly.

To pause the recording, press [PAUSE p]. Press [PAUSE p] or [REC recording.

I] again to restart the

9 Press [STOP S] to stop the recording.

This operation may take a few moments to complete.

Hint

• You can change the channel while in the REC pause mode.

Note

• Recording starts immediately and continues until the disc is full or you stop the recording.

• If the clock is not set, the date and time of title names will be 01/01/08 and 00:00.

• You cannot change the recording mode in the REC or REC pause mode.

• Even if the broadcast you are recording is in the SECAM system, this unit automatically converts it to the PAL system when recording.

• If the external equipment is connected to AV2, the picture of the external equipment will be output except during the DVD playback of this unit. Turn off the external equipment or press [DISPLAY] to output the picture from this unit.

• Up to 99 titles can be recorded on the DVD-RW/-R discs.

• Up to 49 titles can be recorded on the DVD+RW/+R discs.

• NTSC recording is prohibited in this unit.

• You can play back a title on one device while making a recording on other device. To do so, simply select the device (DVD or VCR) you want to use for the playback by pressing [DVD] or [VCR] during DVD / VCR recording. And then follow the normal playback procedure.

Introduction Connections Basic Setup Playback

Recording

Editing

Disc tray guide

5 Press [OPEN / CLOSE O] to close

the disc tray.

6 Select the recording mode using

[REC MODE]. (See page 34.)

7 Press [INPUT SELECT ] to select

DVB, analogue or external input mode, then select the desired channel to record using [PROG. [the Number buttons].

/ ] or

Function Setup

VCR Functions Others

Page 40

VD+RWW

VD+R

E9NG1BD_EN.book Page 40 Monday, April 7, 2008 5:54 PM

One-touch Timer Recording (OTR)

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

This is a simple way to set the recording time in blocks of 30 minutes. Check that the disc you are recording onto has enough space left for the time you set. (See page 86 for VCR recording.)

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

1 Follow steps 1 to 7 in “Basic

Recording” on page 39.

2 Press [REC I] repeatedly until the

desired recording time (30 minutes to 8 hours) appears on the TV screen.

One-touch Timer Recording will start.

0:30

Normal

Recording

1:00

Note

• You cannot use the pause function during Onetouch Timer Recording.

• The unit will be turned off automatically under the following conditions.

- No space remains on the disc.

- If a power failure occurs.

• If DVD One-touch Timer Recording is completed during VCR playback or recording, the DVD will be in stop mode and the VCR keeps the current mode.

• When One-touch Timer Recording is finished and the power is turned off, the unit will switch to the timer-standby mode automatically if a timer recording has been programmed. Press [TIMER SET] to cancel the timer-standby mode to use the unit continuously.

8:00 7:30

• When the unit reaches the specified time, it will be turned off automatically.

• To change the recording length during Onetouch Timer Recording, press [REC repeatedly until the desired length appears.

• To cancel One-touch Timer Recording within the specified time, press [STOP S].

Hint

• The remaining recording time will appear on the TV screen during One-touch Timer Recording. Press [DISPLAY] to see it on the TV screen.

• The remaining recording time will be displayed on the front panel display during One-touch Timer Recording.

• Unlike the timer recording, you can perform the following operations during One-touch Timer Recording.

- Turn off the power. (One-touch timer recording will

be cancelled.)

-Use [REC

I] or [STOP S] on the remote control.

Page 41

VD+RWW

VD+R

VCR

E9NG1BD_EN.book Page 41 Monday, April 7, 2008 5:54 PM

Timer Recording

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

VCR

DVD+RW

You can set the unit to record up to 12 programmes, up to a month in advance. Daily or weekly programme recordings are also available.

• Be sure to set the clock before entering a timer programming.

Insert a recordable disc or a tape with a record tab.

1 In stop mode, press [TIMER PROG.].

“Timer Programming” list will appear.

2 Select “New Programme” using

[U / D], then press [ENTER / OK].

Timer Programming

0:00 THU 06/12

STTL

End

Start

Date 06/12 07/12

9:00

7:00

9:30

9:00

New Programme

• If there are 7 programmes or more, use

SKIP B / F] to turn the page.

[

901 902

PDC

1/1

3 Enter the date using [U / D], then

press [P].

Each time you press [D] at the current date, the timer recording date will change as follows.

e.g., 1st January

01/01

Daily

M-F

(Mon.-Fri.)

W-SAT

W-FRI

W-SUN

31/01

Timer Programming

0:00 THU 06/12

Date

01/01

REC To

DVD SP OFF

Start End CH

--:-- --:-- 901 BBC1

Mode

New Program

PDC

SP 2:00

4 Enter the time to start and to end

using [U / D], then press [P].

5 Select the channel number to record

using [U / D], then press [P].

To record from the external input, select “AV1”, “AV2”, or “AV3”.

6 Select the recording media (“DVD”

or “VCR”) using [U / D], then press [P].

7 Select the recording mode using

[U / D], then press [P].

Refer to “Recording Mode” on page 34 for DVD or page 85 for VCR.

8 For DVB channel recording:

Select “STTL” to “ON” or “OFF” using [U / D].

If you set “STTL” to “ON”, subtitle will be recorded too.

• When analogue channel is selected, “PDC” will be displayed instead of “STTL”.

For analogue channel recording: Select “PDC” to “ON” or “OFF” using [U / D].

Refer to “PDC (Programme Delivery Control)” on page 42.

• When DVB channel is selected, “STTL” will be displayed instead of “PDC”.

9 Press [ENTER / OK] when all

information required is entered.

Your programme setting is stored.

• To set another programme, repeat the steps 2 to

• To exit, press [TIMER PROG.].

• When 2 or more programmes are overlapped, “Timer programme overlapped” appears, and the overlapped programme will be displayed in blue. To correct the timer Programme, Refer to “Checking, Cancelling or Correcting the Timer Programming Information” on page 42.

Press [TIMER SET].

Timer Programming

0:00 THU 06/12

End

Start

Date 06/12 07/12 07/12

9:00

7:00

9:30

9:00

18:00

17:00

New Programme

The icon will appear on the front panel display and the unit enters to the timer-standby mode.

901 902 903

STTL

PDC

1/1

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

1/1

Page 42

E9NG1BD_EN.book Page 42 Monday, April 7, 2008 5:54 PM

Note

• If you have not set the clock, the clock setting window will appear instead of the Timer Programming list. Continue from the step 4 in “Manual Clock Setting” on page 33 to set the clock, before programming the timer.

•Use [L / P] to move the cursor to the left and the right in the entry screen for the timer programming.

• If a basic recording or One-touch Timer Recording is in progress on one component (e.g. VCR) and the timer recording set for the other component (e.g. DVD) is about to begin, the unit automatically switches to the programmed channel for timer recording 2 minutes before the programmed starting time, and the recording in progress (for VCR) will be cancelled UNLESS their recording channels are the same. If their recording channels are the same, the timer recording will start without cancelling the recording currently in progress. In this case, the recording of the same channel will be made on both DVD and VCR.

• Cancel the timer-standby mode by pressing [TIMER SET] before operation for either DVD or VCR. When finished operating, press [TIMER SET] to resume the timer-standby mode.

• In the timer-standby mode, you can turn on the power and use the component (VCR or DVD) which is not currently timer-programmed.

PDC (Programme Delivery Control)

Programme Delivery Control (PDC) assures that the TV programmes you have programmed for timer recording are recorded exactly from beginning to end, even if the actual broadcasting time differs from the scheduled time due to a delayed start or extension of the programme duration. Furthermore, if a programme is interrupted, the recording will also be interrupted automatically and resumed when the programme starts again.

If the PDC signal drops out because the broadcast signal is weak, or if a broadcasting station does not transmit a regular PDC signal, the timer recording is performed in normal mode (without PDC) even if it was programmed for PDC. If the starting time of the PDC timer recording is between 0:00 and 3:59 on a given day, the PDC function will operate from 20:00 on the previous day to 4:00 on the next day. If the starting time of the PDC timer recording is between 4:00 and 23:59 on a given day, the PDC function will operate from 0:00 on the given day to 4:00 on the next day. This means that if the relevant programme is broadcasted within this period, it is recorded correctly. If the timer is not programmed correctly, the incorrect timer setting stays in effect unless you cancel it. To cancel an incorrect timer setting, refer to “Checking, Cancelling or Correcting the Timer Programming Information” on this page.

Note

• This feature is only available for analogue channels.

• If you have a timer programme with the EPG system (see page 44), this feature may not work.

Checking, Cancelling or Correcting the Timer Programming Information

1 Press [TIMER SET] so that the

icon disappears from the front panel display.

2 Press [TIMER PROG.].

“Timer Programming” list will appear.

3 Check the information on the list you

want to edit.

4 A) To delete the timer programme:

1) Select the programme you want to delete using

[U / D], then press [ENTER / OK].

2) Select “Delete” using [U / D], then press

[ENTER / OK]. Confirmation window will appear.

3) Select “Yes” using [U / D], then press

[ENTER / OK].

B) To correct the timer programme:

1) Select the programme you want to correct

using [U / D], then press [ENTER / OK].

2) Select “Programme Change” using [U / D],

then press [ENTER / OK].

3) Correct the timer programme by using

[U / D / L / P], then press [ENTER / OK].

5 Press [TIMER PROG.] to exit. 6 Press [TIMER SET] to return to the

timer-standby mode.

To check the timer programming in progress. Press [TIMER PROG.].

Note

• If a timer recording is proceeding, that programme is highlighted in red. In such a case, you cannot select any other programmes.

• When you check the timer programming in progress by pressing [TIMER PROG.] during operations of the component (DVD or VCR) which is not currently used for the timer recording, the programme will not be highlighted. In this case, you cannot select other programmings.

• If you delete or correct one of the series link timer recording programmes, all related programmes will be deleted or corrected.

• For series link timer recording programme, you can only correct the “REC To”, “Mode” and “STTL”.

Stop the Timer Recording in Progress

On the front panel of the unit, press [

(STOP)] to stop the disc recording or

[

O/S

(EJECT / STOP)] to stop the tape

recording.

Note

• [STOP S] on the remote control is not effective.

Page 43

E9NG1BD_EN.book Page 43 Monday, April 7, 2008 5:54 PM

If the Timer Programming did not Complete Correctly

The error number appears on the Timer Programming list.

Timer Programming

E40

Date

06/12

Start

End

7:00

9:00CH901

New Programme

0:00 THU 06/12

STTL PDC

1/1

The error programme will be displayed in grey with an error number.

The error numbers indicate:

E1–E22, E37–E39: Recording error E23–E24: Unrecordable disc E25/E51 : • Copy prohibited programme

• Cannot record because of the NTSC / PAL-60 signal is received.

E26–E28: Copy prohibited programme E29 : Disc protected E30 : Disc full E31 : Already recorded 99 titles (Video

mode) E32 : Already recorded 99 titles (VR mode) E33 : Already recorded 999 chapters E34 : No space for Control Information E35 : PCA (Power Calibration Area) full E36 : Already finalised Video format disc E40 : • There are some unrecorded parts due

the overlapped timer programmes.

• Recording did not start at the start time.

• There is no tape in the cassette compartment.

• Tape recording reaches to the tape end during timer recording.

E41 : Power failure E42 : No disc E43 : Already 49 titles recorded (+VR mode) E44 : Already 254 chapters recorded (+VR mode) E45 : Copy prohibited programme E46 : It is impossible to record additionally on

a disc recorded by other units when setting “Make Recording Compatible”

to “OFF”. (+VR mode) The error programme will be deleted once you check the error in the programme list, or once you cancel the timer-standby mode and re-enter it.

Hints for the Timer Recording

• If there is a power failure or the unit is unplugged for more than 30 seconds, the clock setting and all timer settings will be lost.

• If there is no disc or an unrecordable disc in the tray (finalised DVD-RW/-R, finalised DVD+R, a fully recorded disc, etc.), the DVD on the front panel display will flash and the timer recording will not occur. Insert a recordable disc.

• If there is no tape or a tape with a record tab is not in the cassette compartment, the VCR on the front panel display will flash and the timer recording cannot be performed. Please insert a recordable tape.

• When all timer recordings are complete, the icon flashes. To play back or eject the recorded disc, press [TIMER SET], and then press [PLAY P] or [OPEN / CLOSE O].

• The timer recording cannot be performed in DVD and VCR at the same time. If you set two programmings with the same channel and time both in DVD and VCR, the programming that has priority will be recorded.

• You cannot make any DVD operation during DVD timer recording.

• You cannot make any VCR operation during VCR timer recording.

• Timer recording whose recording time exceeds 12 hours cannot be made.

• When 2 or more programmes are overlapped, “Timer programme overlapped” appears, and the overlapped programme will be displayed in blue. To correct the timer programme refer to “Checking, Cancelling or Correcting the Timer Programming Information” on page 42.

• If the Start time is earlier and the End time is later than the current time, the recording will start immediately after you press [TIMER SET].

• If a videotape ends during the timer recording, the unit will automatically stop, eject the videotape, and turn itself off. To continue recording, insert a recordable tape.

Priority of overlapped settings

The unit records programmes according to priority if the timer programmes overlap.

If the starting time is same:

• The timer programming set first (PROG. 1) has priority.

PROG. 1

PROG. 2

Actual recording

The first 2 minutes (at the longest) will be cut off.

PROG. 1 PROG. 2

PROG. 2 recording will start after PROG. 1 recording i completed.

When the starting time and the ending time for each programmes are different:

• A programme that has earlier start time has priority.

PROG. 1

PROG. 2

PROG. 3

Actual recording

The first 2 minutes (at the longest) will be cut off.

PROG. 1

PROG. 3

PROG. 2

If the recording time is partially overlapped:

• The timer programming with the earlier start time (PROG. 2) has priority. PROG. 1 will start after PROG. 2 recording is complete.

PROG. 1

PROG. 2

Actual recording

The first 2 minutes (at the longest) will be cut off.

PROG. 2 PROG. 1

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 44

VD+RWW

VD+R

E9NG1BD_EN.book Page 44 Monday, April 7, 2008 5:54 PM

If the recording time entirely overlaps:

• The shorter timer programming (PROG. 1) is not recorded.

PROG. 1

PROG. 2

Actual recording

PROG. 2

Note for DVD recording

• If the recording time of two programmes are overlapped, or the End time of a programme and the Start time of another is same, the first 2 minutes (at the longest) of the subsequent programme will be cut off.

Timer Recording (EPG)

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

With EPG system, you can programme DVB channel recording much easier. You can only choose one programme and enter the selection.

1 While viewing DVB channel, press

[GUIDE].

List of DVB channels will be displayed.

If the End time of the programme currently being recorded and the Start time of the subsequent programme are same:

• If PROG. 1 is a DVD recorded programme, the beginning of PROG. 2 may be cut off.

PROG. 1

PROG. 2

Actual recording

PROG. 2PROG. 1

The first 2 minutes (at the longest) will be cut off.*

* If the cut off time exceeds 3 minutes, the error

number “E40” will appear in the Timer Programming list.

e.g.) Daily mode

Daily mode

Date 18/01/2008 Time 10:30:56

1 ITV1 2 ITV2 3 ITV3 4 Channel 5 E4 6 More 4

10:25-11:10 The Montel

D/W Series Extended Timer

18/01/2008 (Friday)

10:25-11:10 news

12:00-13:00 show

13:00-13:30 musical 13:30-14:35 variety show 19:30-20:00 news 20:00-21:00 drama

Press [RED] to switch between “Daily mode” and “Weekly mode”.

2 Select a desired programme using

[U / D / L / P], then press [ENTER / OK] or [BLUE].

3 Set “REC To”, “Mode” and “STTL”

using [U / D / L / P], then press [ENTER / OK].

Page 45

VD+RWW

VD+R

VCR

E9NG1BD_EN.book Page 45 Monday, April 7, 2008 5:54 PM

Series Link Timer Recording

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

VCR

DVD+RW

With the EPG system, when you set a TV programme into the timer recording, you can also set for future episodes of that series to be recorded. It is also possible to set for the broadcaster to recommend related programmes to you.

1 While viewing a DVB programme,

press [GUIDE].

List of DVB programmes will be displayed.

2 Select a desired programme using

[U / D / L / P], then press [GREEN].

Other series of the TV programme and recommended programme related to the TV programme will be displayed in “Series list”.

3 Press [BLUE] or [ENTER / OK].

Introduction Connections Basic Setup Playback

Note

• If you delete or correct one of the series link timer recording programmes, all related programmes will be deleted or corrected.

Recording split programmes

Some TV programmes are split into 2 or more parts. With EPG system, when you set the first part of the split TV programme for the timer recording, whole parts will be set to the timer programme automatically.

Alternate instance recording

If a timer programming you set overlaps, this unit will search for same TV programme broadcasted in different time, and if this unit finds the programme, you will be asked whether to record the programme in different time instead.

Recording

Series list

Date 01/04/2008

12:05:15Time

261 SIT 1 2008/04/01 12:05-12:07 News Updat

261 SIT 1 2008/04/01 12:10-12:11 Wheather

261 SIT 1 2008/04/01 12:05-12:07 News Updat

261 SIT 1 2008/04/01 12:10-12:11 Wheather

Extended Timer

• Use the scroll bar using [U / D], then press

[YELLOW] to see more detailed information of

the selected programme.

• If the programmes in “Series list” are already set for timer recording, “ ” or “ ” will be displayed.

• “ ” refers to recommended programme related to the TV programme.

4 Set “REC To”, “Mode” and “STTL”

using [U / D / L / P], then press [ENTER / OK].

• In “Timer Programming” list, “ ” will be displayed for the Series Link Timer Recording programmes.

Timer Programming

Series (Part 2)

Date

01/04

Start

12:07

12:10CH261

New Programme

End

STTL PDC

01/04SAT12:07LP ( 0:03)

Editing

Function Setup

VCR Functions Others

1/1

Page 46

E9NG1BD_EN.book Page 46 Monday, April 7, 2008 5:54 PM

Satellite Link

You can set the unit to start recording whenever it detects the video scart control from the external tuner.

6 Press [ENTER / OK].

“To Standby Mode” is highlighted.

Satellite Link

Preparing for the Satellite Link Timer Recording:

[Preparation of the external tuner]

• The external tuner should be equipped with some kind of timer function. Using timer function of the tuner, set it to be turned on when it comes to the time you want to start recording, and off when it comes to the time you want to finish recording. (Refer to the tuner’s manual on how to set the timer.)

• Make sure to turn off the external tuner when you finish setting.

[Preparation of this unit]

• Make sure to select the desired Recording mode beforehand.

External tuner

(not supplied)

Scart cable (not supplied)

HDMI OUT

DVD

COMPONENT

DIGITAL

VIDEO OUT

AUDIO OUT

COAXIAL

AUDIO

/CBPB/CB

OUT

PR /CR

AV2(DECODER)

DVD/VCR

ANTENNA

AV1(TV)

OUT

1 Press [SAT.LINK]. 2 Select the time, media or mode using

[U / D], then press [ENTER / OK].

Satellite Link

DVD VCR

Mode

Start

0:00 DVD

To Standby Mode

DVD

Start

3:00 DVD

To Standby Mode

VCR

Mode

7 Press [ENTER / OK] again.

In a second, the unit will be turned off automatically as it goes into the Satellite Link standby mode.

• Until the time you set in “Start”, the clock will appear on the front panel display.

• “Sat” will appear on the front panel display at the start time.

To cancel the Satellite Link function in the Satellite Link standby mode: Press [TIMER SET] to turn on the unit.

To cancel the Satellite Link function while the Satellite Link Recording is in progress: Press [S (STOP)] on the front panel of the unit.

Note

• If you have not set the clock, the clock setting window will appear at the step 1. Follow to the step 4 in “Manual Clock Setting” on page 33.

• You cannot set the End time for the Satellite Link Timer Recording on this unit.

• Recording picture will be distorted if the copy protection signal is being detected during Satellite Link Timer Recording.

• When a regular Timer Recording and the Satellite Link Timer Recording are overlapped, the examples are given below.

Example 1

3 Set the desired start time using

[U / D], then press [P].

• The hour can be selected among 0-23.

• Repeat this step to set the desired minutes.

4 Select the recording media using

[U / D], then press [P].

5 Select the recording mode using

[U / D].

Refer to “Recording Mode” on page 34 for DVD or page 85 for VCR.

• If you want to edit the time, media or mode

press [L], then press [U

/ D] to correct them.

Timer Recording

Satellite Link

Actual Recording

Timer Recording

Satellite Link

Actual Recording

Example 2

Page 47

VD+RWW

VD+R

VCR

E9NG1BD_EN.book Page 47 Monday, April 7, 2008 5:54 PM

Example 3

Timer Recording

Satellite Link

Actual Recording

Settings for External Equipment

Video Colour System

When you record from external equipment or copy a videotape to a DVD disc, you can set the format Auto, PAL or SECAM.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “Video Colour System” using

[U / D], then press [ENTER / OK].

4 Select “Auto”, “PAL” or “SECAM”

using [U / D], then press [ENTER / OK].

Introduction Connections Basic Setup Playback

Recording

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto: The video colour system will be set

PAL: The video colour system will be set to

SECAM:The video colour system will be set

automatically according to the recording material.

PAL .

SECAM.

Auto Chapter Recording Audio Select (XP) Auto Finalise

Video Colour System

Aspect Ratio (Video Mode)

Auto

Make Recording Compatible

PAL

Bilingual Recording Audio

SECAM

External Input Audio Video Colour System

5 Press [SETUP] to exit.

Note

• During recording, when a signal other than PAL or SECAM is detected, an error message appears on the screen and recording will be paused. Recording will be resumed when a PAL or SECAM signal is detected.

Recording from External Equipment

Video

DVD-RWDVD-RW

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

Editing

Function Setup

VCR Functions Others

VCR

DDVD+R

DVD+R

Before recording from external equipment, see pages 21 to 22 for connection instructions.

VCR

1 Turn the TV and the unit on, and

select the input of the TV to which the unit is connected.

Page 48

E9NG1BD_EN.book Page 48 Monday, April 7, 2008 5:54 PM

2 When you want to record to the disc:

Press [DVD]. Press [OPEN / CLOSE O] to open the disc tray, then place the disc to record on. Press [OPEN / CLOSE O] again to close the disc tray.

Information on DV Dubbing

This function helps you to copy the contents in the DVC (digital video camcorder) to DVD or VCR easily. (See page 86 for DVC to VCR dubbing.) You can control basic operations of the DVC from the remote control of this unit if the DVC is in video mode.

When you want to record to a videotape: Press [VCR]. Insert the videotape with a record tab into the cassette compartment.

3 Select the input terminal to which the

external equipment is connected. (AV1, AV2, or AV3)

To use the input jacks on the back of the unit, select the “AV1” or “AV2” position by pressing [INPUT SELECT ] on the remote control or using [PROG. / ]. To use the input jacks on the front of this unit, select “AV3” position by pressing [INPUT SELECT ] on the remote control or using [PROG. / ].

4 Select a recording mode using

[REC MODE].

Refer to “Recording Mode” on page 34 for DVD or page 85 for VCR.

5 Press [I REC] (DVD / VCR) on the

unit to start recording.

6 Press the PLAY button on the

external equipment.

7 For disc:

Press [S (STOP)] on the unit to stop recording.

For videotape: Press [O/S (EJECT / STOP)] on the unit to stop recording.

Note

• During recording, recording will be paused when a signal other than PAL or SECAM is detected. (See “Video Colour System” on page 47 for details.)

• If you wish to make a recording from the DV input (AV4) on the front panel, see instructions for this starting on the following.

Guide to DV and On-Screen Display

1 Connect your DVC to the DV input

jack on the front panel using a DV cable. (Use the DV cable that has 4pin input jack and is compliance with the IEEE 1394 standards.)

2 Press [INPUT SELECT ] repeatedly

to select the appropriate external input channel for DV input jack (AV4).

3 Press [DISPLAY] to display the DVC

information on the screen.

When the DVC is in video mode...

1/ 1 1/ 1

T C

RW VR ORG

AB-1234

0:12:34

SP 2:00

RW VR ORG

AB-1234

0:12:34

2:00

Control DVD

DV Audio Stereo1 Start Rec

When the DVC is in camera mode...

The menu changes according to the mode of DVC. Switch the mode on the DVC to video mode for the dubbing information.

1/ 1 1/ 1

T C

Page 49

VD+RWW

VD+R

E9NG1BD_EN.book Page 49 Monday, April 7, 2008 5:54 PM

The following instructions are described with the operations using the remote control of this unit.

1DV icon 2 Indicator of active device

• With “Control” highlighted, press [ENTER / OK]

to display the available devices to control with the remote control of this unit. Select the device you want to operate using [U / D], then press [ENTER / OK].

- Select “DVD” to control this unit with the remote control of this unit.

- Select “DVC” to control your DVC with the remote control of this unit.

3 Recording audio mode

• “DV Audio” can be changed. With “DV Audio” selected, press [ENTER / OK] to display “DV Audio” menu. Select the audio you want to output using [U / D], then press [ENTER / OK].

- Select “Stereo1” to copy the stereo sound.

- Select “Stereo2” to copy the sound that was added after the recording.

- Select “Mix” to copy the stereo1 and stereo2.

4 Command menu

• “Start Rec” or “Pause Rec” will appear.

5 External input channel 6 Product name of your DVC

• If the unit cannot recognise the input signal from the DVC or if it is the unknown product, “No Device” or “****” will appear instead.

7 Status of the current operation and the

time counter

Each icon means (Available icons may vary depending on the DVC):

DVC is in stop mode.

DVC is in playback mode.

DVC is in pause mode.

DVC is fast forwarding. (standard speed)

DVC is fast forwarding. (faster than above)

DVC is slow forwarding. (standard speed)

DVC is slow forwarding. (faster than above)

DVC is fast forwarding. (without picture)

DVC is fast reversing. (without picture)

DVC is fast reversing. (standard speed)

DVC is fast reversing. (faster than above)

DVC is in slow reverse playback.

DVC is in recording.

DVC is in recording pause mode.

Please also read the operating instructions of your DVC for more information.

DVC to DVD Dubbing

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

Before recording from DVC, see pages 21 to 22 for connection instructions. (See page 86 for DVC to VCR dubbing.)

Preparing for DV dubbing (DVC to DVD):

• Insert a recordable DVD.

• Make sure your DVC is in video mode.

If you are copying to a disc, press [DVD] first.

DVD-RWDVD-RWVRDVD-RDVD-RDVD-RDVD-R DDVD+R

DVD+RW

1 Select “DV” channel using

[INPUT SELECT ] or [PROG.

/ ].

AB-1234

0:00:00

2 Press [REC MODE] to select a

recording mode. (See page 34.)

3 Press [DISPLAY]. 4 With “Control” highlighted, press

[ENTER / OK] to display the available devices to control with the remote control of this unit. Select “DVC” using [U / D], then press [ENTER / OK].

e.g.) DVC to DVD dubbing

1/ 1 1/ 1

T C

Control DVD DV Audio Stereo 1

Start Rec

Now you can operate your DVC with the remote control of this unit.

RW VR ORG

AB-1234

0:00:00

2:00

5 Press [PLAY B] to start playing back

the DVC, and find where you want to start dubbing. Press [STOP

C] when it comes to the

desired start point.

6 Select “Start Rec” using [U / D],

then press [ENTER / OK].

The dubbing will start.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 50

VD+RWW

VD+R

VCR

E9NG1BD_EN.book Page 50 Monday, April 7, 2008 5:54 PM

To stop dubbing;

1 Select “Control” using [U / D], then press

[ENTER / OK].

2 Select “DVD” using [U / D], then press

[ENTER / OK].

3 Press [STOP C].

Note

• The tape will rewind a few seconds when you press

[ENTER / OK] at step 6 so that the dubbing starts exactly where you press [PAUSE F] instead of

C] at step 5.

[STOP

• The unit does not send out the output signal to DVC.

• For the proper operation, connect DVC to the unit directly. Do not connect this unit and DVC via any other unit.

• Do not connect more than one DVC.

• The unit can only accept DVC. Other DV device such as cable/satellite box or D-VHS VCR cannot be recognised.

• If no video signal is detected from the DVC during DVC to DVD dubbing, the recording will be paused

I” will flash on the TV screen. The recording

and “ will resume when the unit detects the video signal again.

• When the DVC is in camera mode, refer to “Guide to DV and On-Screen Display” on pages 48 to 49.

• Date / time and cassette memory data will not be recorded.

• Pictures with a copy-guard signal cannot be recorded.

• A DV terminal is a terminal that can use the transmission mode conforming to the IEEE 1394 standards called “Fire Wire”. It serves as the interface that connects the PC and peripheral device such as “i.Link” (registered trademark of SONY). It enables digital dubbing between DV devices with little degradation.

Dubbing Mode

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

You can copy a DVD disc to a videotape or copy a videotape to a DVD disc. This function will be available only if the DVD disc or the tape is not copyprotected. Before starting this function, prepare for the recording on the DVD-RW/-R, DVD+RW/+R disc or the videotape. See pages 39 and 85 to 86.

DVD-RWDVD-RWVRDVD-RDVD-RDVD-RDVD-R DDVD+R

VCR

DVD+RW

Note for recording to a videotape:

• The videotape’s record tab is intact.

• The videotape is long enough to record the DVD disc.

Note for recording to a disc:

• The DVD disc is satisfied with the recording status. See pages 34 to 35.

Insert a disc and a videotape with a record tab.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “Dubbing Mode” using

[U / D], then press [ENTER / OK].

Option window will appear.

VCR to DVD

4 Select “VCR DVD” using [U / D],

then press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise

Dubbing Mode

Aspect Ratio (Video mode)

VCR DVD

Dubbing Mode

DVD VCR

Make Recording Compatible Bilingual Recording Audio External Input Audio Video Colour System

5 Press [SETUP] to exit. 6 Press [VCR]. 7 Press [PLAY P], and then press

[PAUSE p] where you want to start recording.

8 Press [DVD].

Make sure to select a recording mode using [REC MODE]. (See page 34.)

Page 51

E9NG1BD_EN.book Page 51 Monday, April 7, 2008 5:54 PM

9 Press [DUBBING].

VCR to DVD duplication will start.

Press [STOP S] to stop the recording.

Note for VCR to DVD duplication:

• During duplication, recording will be paused when a signal other than PAL or SECAM is detected. (See “Video Colour System” on page 47 for details.)

• After starting VCR to DVD duplication, the picture may be distorted because of the auto tracking function. This is not a malfunction. Be advised to play back the tape until the picture is stabilised, then set the starting point at which you want to start recording, and start VCR to DVD duplication.

• This unit will automatically stop the duplication if playback with no image detected for more than 3 minutes during VCR to DVD duplication.

• If the playback sound mode of VCR is set to “STEREO”, “LEFT” or “RIGHT”, the sound mode upon dubbing is automatically switched to “STEREO”. If the playback sound mode is set to “MONO”, the sound mode upon dubbing is also “MONO”.

• If you set “External Input Audio” to “Stereo”, the sound is recorded in “Stereo” (Video mode, VR mode and +VR mode).

• While in Video mode or +VR mode, if you set “External Input Audio” to “Bilingual”, the audio set in “Bilingual Recording Audio” mode is recorded. While in VR mode, if you set “External Input Audio” to “Bilingual”, bilingual audio is recorded.

• The main and sub audio will be simultaneously recorded (VR mode). You can select audio modes during playback.

• If you want to watch the duplicated material, after the VCR to DVD duplication, press [DVD] first then press [PLAY P].

8 Press [VCR].

Make sure to select a recording mode using [REC MODE]. (See page 85.) Rewind or fast forward the tape to the point where you want to start recording.

9 Press [DUBBING].

DVD to VCR duplication will start.

Press [STOP S] to stop the recording.

Note

• NTSC dubbing is prohibited in this unit.

• Dubbing Mode is available only if the tape or disc is not copy-protected.

• You cannot change the output mode during VCR to DVD or DVD to VCR duplication.

• If you want to watch the duplicated material, after the DVD to VCR duplication, press [VCR] first and then press [PLAY P].

Introduction Connections Basic Setup Playback

Recording

DVD to VCR

4 Select “DVD VCR” using [U / D],

then press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise

Dubbing Mode

Aspect Ratio (Video mode)

VCR DVD

Dubbing Mode

DVD VCR

Make Recording Compatible Bilingual Recording Audio External Input Audio Video Colour System

5 Press [SETUP] to exit “Setup” menu. 6 Press [DVD]. 7 Press [PLAY P], and then press

[PAUSE p] at the point you want to start recording.

Editing

Function Setup

VCR Functions Others

Page 52

VD+R

VD-RWW

VD+RWW

VD+R

E9NG1BD_EN.book Page 52 Monday, April 7, 2008 5:54 PM

Setting a Disc to Protect

DVD-RWDVD-RWVRDVD+RWDVD+RW DDVD+R

To prevent accidental over-recording, editing or erasing of recordings, you can protect them using “Setup” menu.

Insert a recordable disc.

DVD+R DDVD-R

1 In stop mode, press [SETUP]. 2 Select “DVD Menu” using [U / D],

then press [ENTER / OK].

3 Select “Disc Protect OFF ON”

using [U / D], then press [ENTER / OK].

4 Select “Yes” using [U / D], then

press [ENTER / OK].

The disc is protected.

5 Press [SETUP] to exit.

Note

• The Disc Protect setting is available only when a disc recorded in VR or +VR mode is inserted.

• You can select only “Disc Protect ON when a protected disc is inserted.

To cancel the disc protect:

• Select “Disc Protect ON OFF” at the step 3, then select “Yes”.

• If you insert a disc protected with this unit, “Disc Protect ON “OFF ON”.

OFF” will appear instead of

OFF”

Finalising Discs

Video

DVD-RW

DDVD+R

DVD+R

You will need to finalise discs to play them back in other players. Finalising may take between several minutes and an hour. A shorter recording period on the disc will require a longer time period for finalisation. Do not unplug the mains cable during finalisation.

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

Insert a recordable disc before finalising.

1 In stop mode, press [SETUP]. 2 Select “DVD Menu” using [U / D],

then press [ENTER / OK].

3 Select “Finalise” using [U / D], then

press [ENTER / OK].

4 Select “Yes” using [U / D], then

press [ENTER / OK].

e.g.) VR mode DVD-RW disc

Finalise disc?

Yes

Finalising will start.

To cancel finalising (DVD-RW disc only):

At the step 4, press [STOP S]. Select “Yes” using

/ D], then press [ENTER / OK]. Finalising is

cancelled and the unit switches to stop mode.

Do you want to cancel ?

Yes

Finalising

If “ ” appears when [STOP S] is pressed, you cannot cancel finalising because the finalising has already reached at a critical point in its process.

If “No” is selected and [ENTER / OK] or [RETURN / BACK] is pressed, finalising is continued.

You cannot cancel finalising a DVD-R and DVD+RW/+R disc once it has started.

10%

5 Finalising is complete.

Page 53

VD+R

E9NG1BD_EN.book Page 53 Monday, April 7, 2008 5:54 PM

Hint

• Finalising a disc in Video mode and +VR mode automatically creates a Title menu.

• After you finalise the DVD+RW disc, you can call up the title list by pressing [TOP MENU], or you can call up the Title menu by pressing [DISC MENU].

• Even after DVD+RW disc is finalised, you can still record or edit. After you finalise DVD-RW/-R or DVD+R disc, you cannot edit or record anything else on that disc.

• To release the finalisation of the disc, select “Undo Finalise” at the step 3.

• To release the finalisation of the DVD+RW disc, make an additional recording to the disc.

• For DVD+RW disc, if you have added or deleted chapters, or made chapters hidden, you must finalise the disc before being able to see those effects on other units. To play back discs other than DVD+RW disc in other DVD players, you will need to finalise.

Note

• If you insert a DVD-RW disc finalised with this unit, “Undo Finalise” will appear instead of “Finalise”.

• DO NOT power off during finalising. This may result in a malfunction.

Introduction Connections Basic Setup Playback

Recording

Auto Finalise

Video

DVD-RWDVD-RW

You can finalise discs automatically when the disc space runs out if you set this in “Setup” menu.

DVD-RDVD-R DDVD+R

DVD+R

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Recording” using [U / D],

then press [ENTER / OK].

3 Select “Auto Finalise” using [U / D],

then press [ENTER / OK].

4 Select “ON” using [U / D], then

press [ENTER / OK].

Auto Finalise

ON OFF

5 Press [SETUP] to exit.

Note

• Auto finalise function is not available for discs formatted in VR mode or a DVD+RW disc.

Editing

Function Setup

VCR Functions Others

Page 54

VD+RWW

VD+R

VCD

E9NG1BD_EN.book Page 54 Monday, April 7, 2008 5:54 PM

Playback

Basic Playback

Hint for DVD Playback

The contents of a DVD are generally divided into titles. Titles are sometimes further subdivided into chapters.

Start Rec. Stop/Start Stop Rec.

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2

Playing Back a DVD-RW / DVD-R / DVD+RW / DVD+R Disc

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

1 Press [ ON / STANDBY] to turn on

the unit.

Turn on the TV and be sure to select the input to which the unit is connected.

2 Press [DVD]. 3 Press [OPEN / CLOSE O] to open the

disc tray.

4 Place the disc on the disc tray with

its label facing up. Be sure to align the disc with the disc tray guide.

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

7 Select the desired title using

[U / D / L / P], then press [ENTER / OK].

Pop up window will appear.

8 Select “Play From Start” using

[U / D], then press [ENTER / OK].

Playback will start.

9 Press [STOP S] to stop playback.

To eject the disc, press [OPEN / CLOSE O] to open the disc tray, then remove the disc. Press [OPEN / CLOSE O] to close the disc tray before turning off the unit.

Hint

• For DVD-R (Video mode), DVD-RW (Video mode) and DVD+R discs that are already finalised, a Title menu will be displayed instead of thumbnails.

• After you finalise the DVD+RW, you can call up the title list by pressing [TOP MENU], or you can call up the Title menu by pressing [DISC MENU].

• You can resume playback from where you stopped (Resume playback). See page 60 for details.

• You can also start playback by pressing [PLAY P] instead of [ENTER / OK] at the steps 7 and 8.

Note

• Some discs may start playback automatically.

Playing Back a DVD-V / Video CD (without PBC Function)

DVD-VDVD-V VCD

VCD

1 Follow the steps 1 to 5 in “Playing

Back a DVD-RW / DVD-R / DVD+RW / DVD+R Disc” on this page.

2 Press [PLAY P] to start playback.

Playback will start.

Disc tray guide

5 Press [OPEN / CLOSE O] to close

the disc tray.

6 Press [TOP MENU] to display the title

list.

You can switch between the “Original” and “Playlist” in the VR mode DVD-RW disc using [DISC MENU].

If you are playing back a DVD-Video, a menu may appear. See page 58 for details.

3 Press [STOP S] to stop playback.

Note

• Some discs may start playback automatically.

• For playing back a Video CD with PBC function, see page 59.

Page 55

MP3

JPEG

E9NG1BD_EN.book Page 55 Monday, April 7, 2008 5:54 PM

Playing Back an Audio CD, MP3 or JPEG

CDCD MP3

MP3 JPEG

JPEG

1 Follow the steps 1 to 5 in “Playing

Back a DVD-RW / DVD-R / DVD+RW / DVD+R Disc” on page 54.

The “File List” will appear.

File List

DISC NAME

A B 1 JPEG file1 2 JPEG file2 3 MP3 file1 4 MP3 file2 5 MP3 file3 6 MP3 file4

1/ 2

To exit the File List, press [TOP MENU] again or press [STOP S]. To resume the File List, press [TOP MENU].

2 Press [U / D] to select the desired

folder or track / file, then press [ENTER / OK].

If a track / file is selected:

Playback will start.

If a folder is selected:

The files in the folder will appear. Press [U / D] to select the folder you want, then press [ENTER / OK].

•Press [PLAY P], [ENTER / OK] or [P] to move

to any lower folders.

•Press [L] or [RETURN / BACK] to move back

to the folder above.

Hints for Audio CD tracks and MP3 / JPEG files:

• Folders are shown with the icon.

• Audio CD tracks are shown by icon.

• MP3 files are shown with the icon. Playback will start from the selected track and continue with each one after.

• JPEG files are shown with the icon.

• The unit can recognise up to 255 folders and up to 99 tracks / 999 files.

• Letters of a file / folder name overflowing the given space will be displayed as “…”.

• Unplayable folders and tracks / files may be displayed depending on the recording conditions.

• For MP3 file recorded in Variable Bit Rate (VBR), the unit may not display the actual elapsed time.

• If there are no files in the folder, “No Files” is displayed.

• High resolution or large-size JPEG files take a few moments to be displayed.

• It is not possible to play back progressive JPEGs (JPEG files saved in progressive format) on this unit.

• It is not possible to play back JPEG files of 12 Mbytes or more.

It is recommended that files to be played back in this unit are recorded under the following specifications:

[MP3]

• Sampling frequency : 44.1 kHz or 48 kHz

• Constant Bit Rate : 112 kbps to 320 kbps

[JPEG] Size of picture

• Upper limit : 6,300 x 5,100 dots

• Lower limit : 32 x 32 dots

• Capacity limit : less than 12 Mbytes

Note

• MP3 files cannot be recorded as digital sound using an MD or DAT deck.

• Files with extensions other than “.mp3 (MP3)” or “.jpg / .jpeg (JPEG)” will not be listed in the File List.

• Some folders or tracks listed in the File List may be unplayable due to their recording status.

• The File List displays only up to 8 folder and file names.

Notes on JPEG:

After file is displayed for 5 seconds or 10 seconds (set in the “Slide Show” on page 66), the display moves to the next file. During JPEG playback, press [P] or [L] to rotate a picture 90 degrees clockwise or counterclockwise respectively. (Not available when the display menu appears.)

Playing Back a DivX

DivX®DivX

1 Follow the steps 1 to 5 in “Playing

Back a DVD-RW / DVD-R / DVD+RW / DVD+R Disc” on page 54.

The “File List” will appear.

File List

DISC NAME

Folder1 Folder2 1 DivX File1 2 DivX File2

1/ 1

To exit the File List, press [TOP MENU] again or press [STOP S]. To resume the File List, press [TOP MENU].

2 Press [U / D] to select the desired

folder or file, then press [ENTER / OK].

If a file is selected:

Playback will start.

If a folder is selected:

The files in the folder will appear. Press [U / D] to select the file or folder you want, then press [ENTER / OK].

•Press [PLAY P], [ENTER / OK] or [P] to move

to any lower folders.

•Press [L] or [RETURN / BACK] to move back

to the folder above.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 56

E9NG1BD_EN.book Page 56 Monday, April 7, 2008 5:54 PM

DivX® Subtitle

The subtitle created by the user can be displayed during DivX

1 After the DivX

playback.

file is selected, the

“Subtitle List” will appear.

Subtitle List

DivX File1

OFF

SMI SRT SUB ASS SSA TXT

2 Select the desired extension you

want to display using [U / D], then press [ENTER / OK]. DivX subtitle starts playback. The subtitle cannot be displayed when the setting is “OFF”.

• If there is more than one extension available, the choices will appear in “Subtitle List”.

Note

• “DivX Subtitle” must be activated in the DivX Menu. (Refer to “DivX Subtitle” on page 82.)

• Playback file and the subtitle file must have the same name.

• Playback file and the subtitle file must locate in the same folder.

• Only the subtitle files with the following extensions are supported; .smi (.SMI), .srt (.SRT), .sub (.SUB), .ass (.ASS), .ssa (.SSA), .txt (.TXT). (.sub (.SUB) and .txt (.TXT) files may not be recognised.)

• The subtitles that exceed the playback time of the

file will not be displayed.

DivX

with the

DivX® VOD

DivX®DivX

This unit allows you to play back the files purchased or rented from DivX services. The files are available on the internet. When you purchase or rent DivX

Video-On-Demand (VOD)

VOD files on the internet, you will be asked to enter a registration code. This menu item provides you with the registration code.

1 Press [SETUP]. 2 Select “General Setting” using

[U / D], then press [ENTER / OK].

3 Select “DivX” using [U / D], then

press [ENTER / OK].

4 Select “DivX®VOD” using [U / D],

then press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Your registration code will appear.

Your registration code is :

Note

• One registration code is only valid for one DivX®

VOD file.

• You must first download the file from the internet

and play it back on this unit before you are able to get another code.

• You must follow this step every time you purchase

or rent a DivX

VOD file from the internet.

• For more information for DivX

http://www.divx.com/vod

VOD

DivX DivX Subtitle

DivX

VOD

To learn more visit :

www.divx.com/vod

, please visit

It is recommended that files to be played back in this unit are recorded under the following specifications:

[DivX

]

• Official DivX

• Playable Codec of AVI files : DivX

• Maximum size of image : 720 x 480 @30 fps

• Sampling frequency of audio: 8 kHz - 48 kHz

• Audio type : MPEG1 audio layer 3

Certified product

3.x,

DivX®4.x,

DivX

5.x,

DivX®6.x

720 x 576 @25 fps

(MP3), MPEG1 audio layer 2, Dolby Digital

Page 57

E9NG1BD_EN.book Page 57 Monday, April 7, 2008 5:54 PM

Hint for the purchased or rental official DivX® Certified product

• When you purchased or rental a DivX the official site of DivX

Video which is called DivX®

file through

Video-On-Demand (VOD) services, a registration code is required every time you get the new file from

the DivX page 56.

• Some DivX playable times (you cannot play them back beyond the limit). If your DivX

VOD services. Refer to “DivX® VOD” on

VOD files are restricted with the limited

VOD file has such limit, the

playback confirmation screen will appear.

Use [L / P] to select “Yes” if you want to play back the file, or to select “No” if you do not want to play it back. Then press [ENTER / OK] to confirm the selection.

DivX VOD Rental

This rental has 3 views left.

Do you want to use one

of your 3 views now?

Yes

• You cannot play back the DivX

VOD files of which

rental period has been expired. In such case, press [TOP MENU] and select other files that can be played back.

Rental Expired

This rental is expired.

Please push ‘TOP MENU’.

Hint

•DivX® is a codec (compression/decompression) that can compress images to a very small amount of data. The software can compress video data from almost any source to a size that can be sent on the Internet without compromising visual quality of the images.

• A file with an extension of “.avi” and “.divx” is called an DivX

file. All files with the “.avi” extension are

recognised as MPEG4.

• Files whose extension other than “.avi” and “.divx” will not be listed on the DivX

menu. However, unplayable groups or tracks may be displayed, depending on the recording conditions.

• Even if the file has an extension of either “.avi” and “.divx”, this unit cannot play it back if it is recorded in the format other than DivX

• Folders are known as Groups; files are known as tracks.

• A symbol of is shown on the top of the file name.

• A maximum of 255 folders or 999 files may be recognised in one disc.

• Up to 8 hierarchies can be recognised in one folder. Files in the 9th or deeper hierarchies cannot be played back.

• If the track extends beyond the scope of screen, a down arrow “ ” appears, indicating that the user can view another part on the previous page. The current page number and the number of total pages are shown on the right of the down arrow “ ”.

• Letters of a file / folder name overflowing the given space will be displayed as “…”.

• You can play back the disc recorded in multisession.

• It may take awhile for audio and images to be output after you inserted a disc and pressed [PLAY P].

• When playing back the files recorded in high bit rates, the images can be interrupted in some occasions.

• Although DivX

logo has been obtained for this unit, it may not be able to play back some data, depending on the characteristics, bit rates, or audio format settings, etc.

• Use the software recognised by the DivX, Inc. when you make DivX

•A DivX cannot be played back.

• If you try to play back the DivX

file whose file size exceeds 2 Gbytes

files.

file that has the screen resolution which this unit does not support, the playback will be stopped and error message will appear.

• If a large-sized DivX

file is selected, it may take awhile over 20 seconds sometimes to start the playback.

• If DivX

files written on CD discs cannot be played back, rewrite them on a DVD disc and try to play back.

• For more information for DivX http://www.divx.com

• If you insert a CD-RW/-R with DivX

, please visit

files that are mixed with MP3 and JPEG files, the Playback Media Selection screen will be displayed. Please select “Video” and proceed to next step.

Please select the media

to play back.

Video

Audio & Picture

•Press [DISC MENU] to call up the Playback Media

Selection screen in stop mode.

• If you select “Audio & Picture” instead of “Video” on the Playback Media Selection screen, this unit can play back MP3/JPEG files.

• You cannot play back the DivX

VOD files obtained

with different registration codes this unit. Press [TOP MENU] and select other files that can be played back.

• This unit does not support the DivX

file with UDF

format.

Authorization Error

This player is not authorized to

play this video.

Please push ’TOP MENU’.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 58

VD+RWW

VD+R

E9NG1BD_EN.book Page 58 Monday, April 7, 2008 5:54 PM

Playing Back Discs Using the Disc Menu

DVD-VDVD-V DVD-VDVD-V DVD-RWDVD-RW

A DVD contains a disc menu, which lists the contents and enables you to customise playback. The menu may offer choices for subtitle languages, special features, and chapter selection. Usually this information appears automatically when you start playback, but sometimes you need to press

[DISC MENU] to display the menu.

Press [DVD] first.

1 Press [DISC MENU].

If the feature is not available, “ ” may appear on the TV screen.

2 Select an item using [U / D / L / P],

then press [ENTER / OK].

Repeat this step until all the features you want are set up or to start playing back the disc from the menu. The following operations are available.

[DISC MENU] button:

Displays the disc menu, which will vary among discs, and may be same with the Title menu.

[U / D / L / P] buttons:

Move the cursor from item to item on the screen.

[ENTER / OK] button:

Selects the currently highlighted menu option.

[the Number buttons]:

Selects a numbered menu option (available on certain discs).

3 Press [DISC MENU] to exit the disc

menu.

Note

• Menus vary among discs. Refer to the information accompanying the disc for details.

Playing Back a Disc Using the Title Menu

DDVD+R

DVD+R

Some DVDs have a Title menu, which lists the titles available on the DVD. You can start playing back such discs at a specific title. On this unit, if you finalise Video mode or +VR mode discs, a Title menu will be created automatically.

Press [DVD] first.

1 Press [TOP MENU].

The Title menu will appear.

• For some discs, the Title menu appears automatically.

If the feature is not available, “ ” may appear on the TV screen.

2 Select a desired item using

[U / D / L / P], then press [ENTER / OK].

The disc will start playing back at the title you selected. The following operations are available.

[TOP MENU] button:

Displays the DVD “Title Menu” which will vary between discs.

[U / D / L / P] buttons:

Move the cursor from item to item on the screen.

[ENTER / OK] button:

Selects the currently highlighted menu option.

[the Number buttons]:

Selects a numbered menu option (available on certain discs).

3 Press [TOP MENU] to exit.

Note

• [TOP MENU] will not be available for some DVDs.

• Menus vary among discs. Refer to the information accompanying the disc for details.

• For DVD+RW discs finalised on this unit, press [DISC MENU] to display the Title menu.

Video

DVD-RDVD-R DDVD+R

DVD+RW

Page 59

VCD

E9NG1BD_EN.book Page 59 Monday, April 7, 2008 5:54 PM

PBC Function for Video CDs

Introduction Connections Basic Setup Playback

Cancelling and Recalling the PBC Function

VCDVCD

This unit conforms to ver.1.1 and ver.2.0 of the Video CD standard playback control (PBC) function. This enables you to play back interactive software using menu screens. Refer to the information accompanying the Video CD. Ver.1.1 (without PBC function): You can still enjoy playback of pictures and music from the CD. Ver.2.0 (with PBC function): “Pbc” will appear on the screen and display when playing back a Video CD with the PBC function.

Hint

• When playing back Video CDs with the PBC function, “Pbc” is displayed instead of the playing back time and current track indications on the front panel display.

Note

• Some operations cannot be performed unless the function is cancelled either automatically or intentionally by you.

• Operations that are not available when the PBC function is set to “ON” are indicated by the following symbol in this manual:

VCD

(PBC OFF)

Playing Back a Video CD Using the Title Menu

VCD

(PBC OFF)

Insert a Video CD.

1 In stop mode, press [SETUP]. 2 Select “CD Playback Mode” using

[U / D], then press [ENTER / OK].

3 Select “PBC (Video CD only)” using

[U / D], then press [ENTER / OK].

CD Playback Mode

Random Play Program Play PBC (Video CD only)

Slide Show

4 Select “OFF” using [U / D], then

press [ENTER / OK].

5 Press [SETUP] to exit.

To recall the PBC function, select “ON” at the step 4 above.

Recording

VCDVCD

1 When playing back a Video CD with

the PBC function, the Title menu will appear automatically.

2 Press [the Number buttons] to select

the desired title.

Playback will start at the selected title.

3 Press [RETURN / BACK] to go back

to the Title menu.

Note

• Until the On-Screen Display appears, you cannot perform the steps 2 and 3.

Note

• The default setting of “PBC (Video CD only)” is “ON”.

Editing

Function Setup

VCR Functions Others

Page 60

VD+RWW

VD+R

VCD JPEG

DivX

VD+RWW

VD+R

VCD

MP3

DivX

VD+RWW

VD+R

VD+RWW

VD+R

VCD

MP3

JPEG

DivX

VD+RWW

VD+R

E9NG1BD_EN.book Page 60 Monday, April 7, 2008 5:54 PM

Special Playback

Resume Playback

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

JPEG

JPEG DivX

You can resume playback from the point where you stopped it before.

Video

DVD+R CDCDCD

DivX

DVD-RWDVD-RWVRDVD-RDVD-R

VCD

(PBC OFF)

MP3MP3

1 During playback, press [STOP S].

The resume message will appear.

2 Press [PLAY P].

In a few seconds, playback will resume from the point at which you stopped it before. Even if you turn off the unit, you can resume playback at the same point after turning back on the unit.

To cancel the resume playback and start playing back the disc from the beginning: Press [STOP S] while playback is stopped.

For DVD-Videos, DVD+RW/+R, DVD-RW/-R, Video CD, Audio CD, MP3 files, JPEG files, and

DivX

files:

You can set only one resume point per disc.

Note

• For Video CDs, if you turn PBC on using “Setup” menu, the resume function is cancelled.

• For MP3 and JPEG files, playback will resume from the beginning of the track at which playback was stopped.

Fast Forward / Fast Reverse

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

DivX

Video

DVD+R CDCDCD VCD

DVD-RWDVD-RWVRDVD-RDVD-R

VCD MP3

MP3

1 During playback, press [FWD f] or

[REV r].

Each time you press [FWD f] or [REV r], the approximate speed will change as follows. Fast forward or fast reverse playback across titles (for DVDs) or tracks / files (for VCD / MP3 / DivX is not possible.

FWD

REV

FWD

20x 2x 20x5x 40x40x

REV

Normal

speed

playback

FWD

REV

FWD

REV

FWD

REV

• Picture quality of DivX lower than that in fast forward.

• For some DivX

files in fast reverse is

files, Fast forward/Fast reverse

may not function.

Hint

• Forward / reverse speeds are indicated with icons as follows.

Forward (Approx. Speed): 2x: 20x: 40x: Reverse (Approx. Speed): 5x: 20x: 40x:

Skipping TV Commercials during Playback

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

To enjoy recorded programmes without any interruptions, press [INSTANT SKIP].

Video

DVD+R

DVD-RWDVD-RWVRDVD-RDVD-R

1 During playback, press

[INSTANT SKIP].

Normal playback will start 30-second advanced point from the point at which you press [INSTANT SKIP]. Each time you press [INSTANT SKIP], the start point will move another 30 seconds forward and playback resume automatically. You can press [INSTANT SKIP] up to 6 times (180 seconds).

Pause

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

JPEG

JPEG DivX

Video

DVD+R CDCDCD VCD

DivX

DVD-RWDVD-RWVRDVD-RDVD-R

VCD MP3

MP3

1 During playback, press [PAUSE p].

Playback will pause with the sound muted.

2 Press [PLAY P] to resume playback.

)

Rapid Playback

DVD-VDVD-V DVD-RWDVD-RW

Video

DVD-RWDVD-RWVRDVD-RDVD-R

• For Audio CDs and MP3 files approximate speed is fixed at 8x with sound.

• For Video CDs, approximate forward / reverse speeds are 2x, 8x and 16x.

•For DivX

files, approximate forward speeds are 2x, 20x and 40x, and approximate reverse speeds are 5x, 20x and 40x.

• To return to playback at normal speed, press

[PLAY P].

DDVD+R

DVD+RW DDVD+R

DVD+R

Rapid Playback function is available only during playback.

Available only on discs recorded in the Dolby Digital format, Rapid Playback plays back in a slightly faster/ slower speed while keeping the sound output.

Page 61

VD+RWW

VD+R

VCD

DivX

VD+RWW

VD+R

VCD

DivX

VD+RWW

VD+R

VCD

JPEG

DivX

E9NG1BD_EN.book Page 61 Monday, April 7, 2008 5:54 PM

1 During playback, press

[1.3x/0.8x PLAY].

Px0.8 : Press [1.3x/0.8x PLAY] once during

playback. Plays back approximately at 0.8 times of normal playback.

Px1.3 : Press [1.3x/0.8x PLAY] twice during

playback. Plays back approximately at 1.3 times of normal playback.

P :Press [1.3x/0.8x PLAY] thrice to play

back in normal speed. No effects.

2 Press [PLAY P] to continue the

normal playback.

Note

• Audio (language) setting cannot be changed while using this mode.

• This feature may not work at some point in a disc.

• Audio is PCM during Rapid Playback mode.

• When you select “PAL” in “TV System” (see page

80), this function is not available with discs recorded using the NTSC system.

Step by Step Playback

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

Video

DVD+R VCD

DVD-RWDVD-RWVRDVD-RDVD-R

VCD DivX

DivX

1 During playback, press [PAUSE p]. 2 Press [SKIP B / F] repeatedly.

Each time you press [SKIP F], playback will go forward one frame (or step) at a time with the sound muted. To go backward one frame (or step), press [SKIP B].

Press and hold [SKIP F] to continue going forward. To continue going backward, press and hold [SKIP B].

3 Press [PLAY P] to resume playback.

Note

• Only step by step forward is available when playing back Video CDs and discs with DivX

files.

Slow Forward / Slow Reverse Playback

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

Video

DVD+R VCD

DVD-RWDVD-RWVRDVD-RDVD-R

VCD DivX

DivX

1 During playback, press [PAUSE p],

then press [FWD f] or [REV r].

Each time you press [FWD f] or [REV r], the approximate speed change as follows. (The sound will remain muted.)

FWD

/8x

1/1

/4x

REV

To return to normal playback, press [PLAY P].

REV

Pause

FWD

1/16x1

REV

FWD

REV

/8x

FWD

REV

/3x

Hint

• Forward / reverse speeds are indicated with icons as follows.

Forward (Approx. Speed): 1 / 16x: 1 / 8x: 1 / 3x: Reverse (Approx. Speed): 1 / 16x: 1 / 8x: 1 / 4x:

Note

•For some DivX® files, Slow forward may not function.

• Only slow forward is available when playing back Video CDs and discs with DivX

files.

Zoom

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

Video

DVD+R VCD

DVD-RWDVD-RWVRDVD-RDVD-R

VCD JPEG

JPEG DivX

DivX

1 During playback, press [DISPLAY]. 2 Select the icon using [L / P], then

press [ENTER / OK] within 1 second, or wait for 1 second to display the selection menu.

1/ 5 1/ 5

0:01:00 / 1:23:45

× 1.2 × 1.5 × 2.0

DVD

Video

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Four options are available, “x1.0”, “x1.2”, “x1.5” and “x2.0”. These are displayed excluding the current zoom rate.

3 Select the desired zoom factor to

zoom using [U / D], then press [ENTER / OK].

The zoom area is displayed.

Page 62

VD+RWW

VD+R

VCD

E9NG1BD_EN.book Page 62 Monday, April 7, 2008 5:54 PM

4 Select the desired zoom position

using [U / D / L / P], then press [ENTER / OK].

Zoom playback will start.

Hint

• To cancel the zoom function, select “x1.0” using

[U / D], then press [ENTER / OK].

Note

• If selecting a smaller factor than that currently selected, the zoom area is not displayed.

• You cannot slide the zoomed picture on some JPEG files.

Marker Setup

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

You can assign a specific point on a disc to return later.

Video

DVD+R CDCDCD

DVD-RWDVD-RWVRDVD-RDVD-R

VCD

(PBC OFF)

1 During playback, press [DISPLAY]. 2 Select the icon using [L / P],

then press [ENTER / OK] within 1 second, or wait for 1 second to display the marker list.

e.g.) Marker setup menu for DVD-Video

Note

• All markers are erased when you perform the following operations.

- Opening the disc tray.

- Turning off the power.

- Making additional recording on the disc.

(DVD only)

- Editing any title. (DVD only)

- Changing the mode between Original and Playlist.

(VR mode DVD-RW disc only)

• Marker setting is not available when you play back the Video CD with PBC function.

Chasing Playback during Recording

DVD-RWDVD-RW

You can play back a title being recorded from the beginning while recording continues. This function works from 1 minute after the start of the recording. Make sure to use a DVD-RW disc in VR mode, and the recording mode is set to LP, EP or SLP.

1 Press [PLAY B] during recording.

Playback will start from the beginning of the programme that you are currently recording. Screen for the current playback:

1/ 5 1/ 5 0:01:00 / 1:23:45

RW VR ORG

1/ 5 1/ 5

---

0:01:00 / 1:23:45

DVD

Video

3 Select the desired marker number

using [U / D]. When the disc reaches the desired point, press [ENTER / OK].

The title (track) number and the time are displayed.

4 To return to the marker, select the

desired marker number using [U / D], then press [ENTER / OK].

Hint

• To clear a marker, select the marker number you

want to clear, then press [CLEAR].

• You can mark up to 6 points.

If you play the fast forward playback and the playback reaches the scene recorded 1 minute before, the forwarding playback will automatically return to the normal playback.

2 To stop the playback, press [STOP C]

once.

The resume message will appear. Screen for the current recording:

1/ 5 1/ 5 0:01:00 / 1:23:45

RW VR ORG

901 BBC1

LP 1:01Resume ON

To stop recording, press [STOP To cancel the resume, press [STOP

C] again.

Page 63

E9NG1BD_EN.book Page 63 Monday, April 7, 2008 5:54 PM

Using the [TIME SLIP] button

With [TIME SLIP], if you leave your couch while you are watching TV through this unit, you can come back and watch rest of the programme from right where you left with just one button. Please make sure to put VR mode DVD-RW disc and set the recording mode to LP, EP or SLP.

1 While viewing a TV broadcast via

this unit, press [TIME SLIP].

This unit start to record the TV broadcast.

2 Press [TIME SLIP] again.

Playback will start from where you press [TIME SLIP] first while recording continues.

• While viewing the recorded content, you can pause and resume the playback by pressing [TIME SLIP].

3 To stop the recording, press

[STOP

Note

• Playback image may freeze momentarily using this function. However this does not affect the recording.

• The 2x fast forward playback is not available.

• [REC

• You must cancel this function first by pressing

[STOP

OTR (one-touch timer recording) function or change recording time for the OTR.

• “Wait for a moment.” will be displayed on the screen if you press [PLAY

• This function is available only when you are recording on a DVD-RW disc in VR mode, with the recording mode LP, EP or SLP.

• Use DVD-RW disc capable of 2x or 4x speed recording.

Simultaneous Playback and Recording

DVD-RWDVD-RW

You can also play back a recorded title during current recording or the Timer Recording on the same disc.

C] twice.

I] is not available during this function.

C] once. Then you can use [REC I] to use

B] before 1 minute of recording.

1 During recording, press [DISPLAY].

Chapter: To move to for chapter, press [ Enter a desired chapter number to search

U / D] or [the Number buttons], then

using [ press [ENTER / OK].

Selected chapter playback will start.

If you play the currently recording programme and the playback reaches the scene recorded 1 minute before, the forwarding playback will automatically return to the normal playback.

B].

3 Press [STOP C] once to stop

playback.

The resume message will appear.

1/ 5 1/ 5 0:01:00 / 1:23:45

RW VR ORG

901 BBC1

LP 1:01Resume ON

To stop recording, press [STOP To cancel the resume, press [STOP

Note

• Playback image may freeze momentarily using this function. However this does not affect the recording.

• The 2x fast forward playback is not available.

• This function is available only when you are recording on a DVD-RW disc in VR mode, with the recording mode LP, EP or SLP.

• Only the titles (chapters) in the Original can be selected. You cannot select titles from the title list.

• When you stop the playback after the Timer recording is completed, the unit will be switched to the timer standby mode if another programme has been set (refer to “Hints for the Timer Recording” on pages 43 to 44).

• Use DVD-RW disc capable of 2x or 4x speed recording.

C] again.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

1/ 5 1/ 5 0:01:00 / 1:23:45

RW VR ORG

901 BBC1

2 Select icon using [L / P], then

press [ENTER / OK].

The title number next to will be highlighted.

Title: Enter a desired title number to search using

U / D] or [the Number buttons], then press

[ [ENTER / OK].

Selected title playback will start.

VCR Functions Others

Page 64

VD+RWW

VD+R

VCD JPEG

DivX

E9NG1BD_EN.book Page 64 Monday, April 7, 2008 5:54 PM

Title / Chapter Search

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

Using [SKIP B / F] buttons

Video

DVD+R

DVD-RWDVD-RWVRDVD-RDVD-R

1 During playback, press [SKIP F] to

skip the current title or chapter and move to the next.

The unit moves to the next title or chapter one after the other.

To go back to the previous title or chapter, press

[SKIP B] twice in quick successions.

Using the [DISPLAY] button

1 During playback, press [DISPLAY]. 2 Select the icon using [L / P],

then press [ENTER / OK].

for the title number is highlighted.

Searching for a Title:

3 Enter the desired title number to

search for using [U / D] or [the Number buttons], then press [ENTER / OK].

Title search will start.

Hint

• Total number of chapters and playback time of the selected title are also displayed.

Searching for a Chapter:

3 Press [L / P] to highlight the number

displayed in the right side of the icon.

4 Enter the desired chapter number to

search for using [U / D] or [the Number buttons], then press [ENTER / OK].

Chapter search will start.

Hint

• The title number and playback time of the selected chapter are also displayed.

Track Search

CDCDCD

VCD

(PBC OFF)

MP3MP3

JPEG

JPEG DivX

DivX

Using [SKIP B / F] buttons

1 During playback, press [SKIP F] to

skip the current track and move to the next.

The unit moves to the next track one after the other. To go back to the previous track, press [SKIP B] twice in quick succession. The unit moves backward one track at a time.

Using the [DISPLAY] button

For Audio CD, skip to the step 2.

1 During playback, press [DISPLAY]. 2 Select the icon using [L / P],

then press [ENTER / OK].

for the track number is highlighted.

3 Enter the desired track number to

search for using [U / D] or [the Number buttons], then press [ENTER / OK].

Track search will start.

Hint

• For Video CDs, you can perform the track search function in stop mode without turning PBC off manually.

Note

• During Random playback or Programme playback, you cannot search the desired track.

Direct Search

CDCD

You can search the desired track directly.

Using [the Number buttons]

1 During playback, if the display menu

is not displayed, press [the Number buttons] to enter the desired track number.

Note

• During Random playback or Programme playback, you cannot search the desired track directly.

Page 65

VD+RWW

VD+R

VCD

VD+RWW

VD+R

VCD JPEG

DivX

E9NG1BD_EN.book Page 65 Monday, April 7, 2008 5:54 PM

Time Search

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

For Audio CD, skip to the step 2.

Video

DVD+R CDCDCD

DVD-RWDVD-RWVRDVD-RDVD-R

VCD

(PBC OFF)

1 During playback, press [DISPLAY]. 2 Select the icon using [L / P],

then press [ENTER / OK].

for the title or track number is highlighted.

3 Press [L / P] to highlight . 4 Enter the desired time to search for

using [U / D] or [the Number buttons], then press [ENTER / OK].

Time search will start.

Note

• During Random playback or Programme playback, you cannot search the desired time.

• The title number and chapter number of the setting time are also displayed.

• Time search function is available only in the same track or title.

DivX®DivX

Introduction Connections Basic Setup Playback

Repeat / Random / Programme Playback / Slide Show

Repeat Playback

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

JPEG

JPEG DivX

For Audio CD or MP3, skip to the step 2.

Video

DVD+R CDCDCD

DivX

DVD-RWDVD-RWVRDVD-RDVD-R

VCD

(PBC OFF)

MP3MP3

1 During playback, press [DISPLAY]. 2 Select the icon using [L / P], then

press [ENTER / OK] within 1 second, or wait for 1 second to display the selection menu.

3 Select the desired option to repeat

using [U / D], then press [ENTER / OK].

The selected repeat playback will start. The following operations are available.

Title:

The current title will be played back repeatedly. (DVD only)

Chapter:

The current chapter will be played back repeatedly. (DVD only)

All:

The current disc will be played back repeatedly. (DVD-RW (VR mode), Audio CD, Video CD, MP3, JPEG and DivX

A-B:

The A-B point will be played back repeatedly. (DVD, Audio CD, Video CD and DivX

•Press [ENTER / OK] to decide the starting point

(A).

•Press [ENTER / OK] after setting point (A) to

select the ending point (B).

Track:

The current track will be played back repeatedly. (Audio CD, Video CD, MP3, JPEG and DivX

Group:

The current group will be played back repeatedly. (MP3, JPEG and DivX

Hint

• To cancel the repeat playback, select “OFF” at the step 3. The repeat setting is also cancelled when you stop playback.

Note

• You can only set A-B repeat playback within the current title (for DVDs) or current track (for Audio CDs, Video CDs and discs with DivX

• You cannot select “Group” during the random playback of MP3 and JPEG files.

only)

files).

only)

Recording

Editing

Function Setup

VCR Functions Others

Page 66

VCD JPEG

VCD

E9NG1BD_EN.book Page 66 Monday, April 7, 2008 5:54 PM

• Chapter/Track repeat will be cancelled whenever a Chapter/Track is skipped forward or backward.

• For some DivX function.

• For Video CDs with PBC function, repeat play does not work while the PBC function is on.

files, A-B Repeat playback may not

Random Playback

CDCD

VCD

(PBC OFF)

You can use this function to play back a disc randomly instead of in the recorded order.

MP3MP3

JPEG

1 In stop mode, press [SETUP]. 2 Select “CD Playback Mode” using

[U / D], then press [ENTER / OK].

“CD Playback Mode” menu will appear.

3 Select “Random Play” using [U / D],

then press [ENTER / OK].

Random playback will start.

Hint

• To cancel random playback, press [STOP S] twice during random playback. “OFF” appears on the screen.

• For Video CDs with PBC function, the PBC setting will be switched to off automatically when you start random playback.

Note

• During random playback, if you forward the track to the end, the playback speed of the next track will be normal.

• During random playback, you cannot use the search function except for the search with [SKIP B / F]. By pressing [SKIP B], you can return only to the beginning of the current track.

3 Select the desired track using

[U / D], then press [ENTER / OK] or [P].

CD Playback Mode

Programme Play

-- -- -- -- -- -- -- -- --

-- -- -- -- -- -- -- -- -- --

0:00:00Tot al

4 Press [PLAY P] to start programme

playback.

Hint

• To erase tracks you selected, press [CLEAR].

• You can make up to 50 track settings.

• To cancel programme playback, press [STOP S]

twice during programme playback. “OFF” appears on the screen.

• You may also select the desired track using

[the Number buttons] at the step 3.

• For Video CDs with PBC function, the PBC setting will be switched to off automatically when you start programme playback.

Note

• During programme playback, if you forward the track to the end, the playback speed of the next track will be normal.

• During programme playback, you cannot use the search function except for the search with [SKIP B / F].

Slide Show

JPEGJPEG

Programme Playback

VCD

CDCDCD

(PBC OFF)

You can programme the disc to play back in your desired order.

1 Follow the steps 1 and 2 in “Random

Playback” on this page.

2 Select “Programme Play” using

[U / D], then press [ENTER / OK].

You can select the display time between 5 seconds and 10 seconds.

1 Follow the steps 1 and 2 in “Random

Playback” on this page.

2 Select “Slide Show” using [U / D],

then press [ENTER / OK].

3 Select the display time using

[U / D], then press [ENTER / OK].

4 Press [SETUP] to exit.

Note

• Large-size JPEG files take a few moments to be displayed.

Page 67

VD+R

VD-V

VD-RWW

VCD

VD+RWW

VD+R

MP3

E9NG1BD_EN.book Page 67 Monday, April 7, 2008 5:54 PM

Selecting the Format of Audio and Video

You can select the format of audio and video to suit the content of the disc you are playing back.

Switching subtitles

DVD-VDVD-V DVD-RWDVD-RWVRDivX®DivX®DVD+RWDVD+RW

DDVD+R

DVD+R

Many DVD-Videos have subtitles in one or more languages. The available languages are usually printed on the disc case. You can switch subtitle languages at any time during playback.

1 During playback, press [DISPLAY].

Or press [SUBTITLE] during playback and follow from the step 3.

2 Select the icon using [L / P], then

press [ENTER / OK] within 1 second, or wait for 1 second to display the selection menu.

3 Select the desired subtitle language

using [U / D], then press [ENTER / OK].

Subtitles are displayed in the selected language. If you select “OFF”, subtitles will disappear.

Note

• With some discs it is only possible to change the subtitle language from the disc menu. Press [TOP MENU] or [DISC MENU] to display the disc menu.

• If a 4-digit language code appears in the subtitle menu at the step 3, refer to the “Language Code” on page 93.

• For discs with DivX the number of subtitle languages.

files, the screen only displays

Switching Audio Soundtrack

VCD

DDVD-V

DVD-V DDVD-R

When playing back a DVD-Videos recorded with two or more soundtracks (often in different languages), you can switch among them during playback. When playing back DVD-RW discs recorded in VR mode, you can switch to main audio (L), sub audio (R) or a combination of both (L / R). When playing back Audio CDs or Video CDs, you can switch among the left, the right channel and stereo. For Audio CD, skip to the step 2 or press [AUDIO ] and skip to the step 3.

DVD-RWVRCDCD

VCD

DivX®DivX

1 During playback, press [DISPLAY].

Or press [AUDIO ] during playback and follow from the step 3.

2 Select the icon using [L / P], then

press [ENTER / OK] within 1 second, or wait for 1 second to display the selection menu.

3 Select a desired audio soundtrack or

audio channel using [U / D], then press [ENTER / OK].

With a DVD Video, VR mode DVD-RW, or DivX® files: Audio soundtrack will switch. Example: English → Spanish → French

If the title contains both main and sub audio, you can further select “L” (main), “R” (sub), “L/R” (mixed of main and sub).

With an Audio CD or Video CD: The Audio channel will switch. Example: L/R → L → R

Note

• For some discs, it is only possible to change the

soundtrack from the disc menu. Press [TOP MENU] or [DISC MENU] to display the disc menu.

Switching Virtual Surround System

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

You can enjoy stereophonic virtual space through your existing 2 channel stereo system. For Audio CD or MP3, skip to the step 2.

Video

DVD+R CDCDCD MP3

DVD-RWDVD-RWVRDVD-RDVD-R

MP3

1 During playback, press [DISPLAY].

Display menu will appear.

2 Select the icon using [L / P], then

press [ENTER / OK] within 1 second, or wait for 1 second to display the selection menu.

Virtual Surround menu will appear.

e.g.) DVD-Video

1/ 5 1/ 5

0:01:00 / 1:23:45

DVD

Video

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 68

VD+RWW

VD+R

VCD

DivX

E9NG1BD_EN.book Page 68 Monday, April 7, 2008 5:54 PM

3 Select “OFF”, “Type 1” or “Type 2”

using [U / D], then press [ENTER / OK].

e.g.) DVD-Video

1/ 5 1/ 5

• OFF: No effect

• Type 1: Natural effect

• Type 2: Emphasised effect

Note

• Select Virtual Surround to “OFF” in a case the sound is distorted.

• The setting will be kept “OFF” when the unit is turned off.

OFF Type 1 Type 2

0:01:00 / 1:23:45

DVD

Video

Switching Camera Angles

DVD-VDVD-V

Some DVD-Videos feature scenes shot from two or more angles. The disc case is usually marked with an angle icon if the disc has multi-angle scenes.

1 During playback, press [DISPLAY].

The angle icon appears when a switching camera angle is available. (Available only when the angle icon appears in bottom right on the TV screen.)

2 Select the icon using [L / P],

then press [ENTER / OK].

The angle will switch each time you press

[ENTER / OK].

Hint

• If the Angle Icon setting is “OFF” in “Setup” menu, the icon will appear only when the disc is played back and the Display menu appears. (See page 80.)

• Even when the select the angle if the currently played back title has at least two multi-angle scenes.

icon is not displayed, you can

This function reduces noise in the playback picture. When playing back discs recorded in long time modes such as EP or SLP, select “Type 1” or “Type 2”. “Type 2” is more effective. When playing back discs with a little noise, such as DVD-Videos, select “OFF”.

Reducing Block Noise

DVD-VDVD-V DVD-RWDVD-RW

DDVD+R

DVD+RW DDVD+R

Video

DVD+R VCD

DVD-RWDVD-RWVRDVD-RDVD-R

VCD DivX

1 During playback, press [DISPLAY]. 2 Select the icon using [L / P],

then press [ENTER / OK] within 1 second, or wait for 1 second to display the selection menu.

Noise Reduction menu will appear.

3 Select the desired option using

[U / D], then press [ENTER / OK].

DivX

Page 69

E9NG1BD_EN.book Page 69 Monday, April 7, 2008 5:54 PM

Editing

Guide to a Title List

Title list allows you to check the titles recorded on the disc easily. You can choose a title to play back from this list and easily edit the titles as you prefer.

Press [DVD], then press [TOP MENU].

456

Title List

ORG

01/ 01/ 08 12:00 901 LP 12:00 (2:00:00) 01/ 01/ 08 901 LP

1 2 3

4 5 6

231 3

Edit

ORG

Scene Delete

Edit Title Name

Chapter Mark

Protect

01/ 01/ 08 12:00 901 LP

1:05:00

1011 9 78

1 Title list: List of titles recorded on the disc. Each

title is indicated by its index picture. Index picture for the selected title can be seen in motion. Following icons may be displayed on the index picture.

: Indicating the title is protected.

2 The protect icon, which appears when the title

has been protected. (Original titles only)

3 Arrow: Indicating there is a previous / next page. 4 Title list icon, which indicates a type of the

displayed title list.

: VR (Original) mode

ORG

: VR (Playlist) mode

:+VR mode

+VR

: Video mode

Video

5 Title name. 6 Title information, which displays recorded time,

length of the title, date / month / year, recorded CH, and the recording mode.

7 Submenu: Submenus for the selected menu are

displayed here.

8 Title name (editable): If you do not name the title,

the recorded date, time, channel, and the recording mode are displayed here.

9 Progress bar: Indicating the progress of the

playback.

1 / 2

10 Preview window: Preview of the selected title is

displayed here.

11 Playback status: Indicating the current playback

status of the selected title.

Press [RETURN / BACK] to exit the title list.

Editing Discs

You will find editing discs is easy. This unit offers convenient edit functions which are possible only with DVD-RW/-R and DVD+RW/+R discs.

You can edit the following from a title list.

• Assigning a name to a title

• Dividing a title

• Combining titles

• Adding titles to a Playlist

• Erasing all Playlists

• Setting or releasing title protection

• Adding or deleting chapter marks

• Deleting titles or parts of titles

(Possible editing functions depend on the recording format and editing method.)

Original and Playlist (VR mode)

For VR mode DVD-RW disc, you can edit the recordings in Playlist without changing the original recordings. Playlist does not take up much disc space.

What “Original” or “Playlist” is for?

There are 2 types for the title list: Original and Playlist

• Original content refers to what’s actually recorded

on the VR mode DVD-RW disc.

• Playlist content refers to the edited version of the

VR mode DVD-RW disc; how the Original content is to be played.

Finalising a Disc

• This will allow a disc that is recorded on this unit to be played back on a different DVD player — without finalisation it will not be playable on another player.

• After finalising a DVD-RW/-R or DVD+R disc, you cannot edit any information that is on that disc.

• If you have recorded in DVD+RW disc, then editing is still permitted after finalising.

Using these editing functions to modify copyrighted content for any purpose other than your private viewing may be prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Note

• A Playlist is not available for DVD-R or Video mode DVD-RW and DVD+RW/+R discs.

• It is not possible to edit a disc recorded in another video system other than PAL, such as NTSC.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 70

VD+RWW

VD+R

VD+RWW

VD+R

E9NG1BD_EN.book Page 70 Monday, April 7, 2008 5:54 PM

Deleting Titles

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

You can delete titles you do not want to keep. When an Original is deleted from VR mode DVD-RW disc, the recordable disc space will increase. When a Playlist is deleted, the original of the Playlist will remain, and recordable disc space will not increase. Recordable disc space of Video mode DVD-RW and DVD+RW disc will increase when the last title on the title list is deleted. However, deleting the title will not change recordable disc space for DVD-R and DVD+R disc. In finalised DVD-R, Video mode DVD-RW or DVD+R discs, you cannot select the title list because it cannot be edited once finalised.

Note

• It is not possible to retrieve deleted titles.

Press [DVD] first.

DVD-RWDVD-RW

DVD-RDVD-R

DDVD+R

DVD+RW

1 In stop mode, press [TOP MENU].

“Title List” will appear. For DVD-RW, press [DISC MENU] to switch between “Original” and “Playlist” if the disc is recorded in VR mode.

2 Press [ENTER / OK] at the desired

title with [U / D / L / P].

e.g.) VR mode DVD-RW disc

Title List

ORG

01/01/08 12:00 901 LP 12:00 (2:00:00)

Pop up window will appear.

01/01/08 901 LP

1 2 3

4 5 6

1 / 2

3 Select “Title Delete” using [U / D],

then press [ENTER / OK].

Play From Start

Edit

Title Delete

Add To Playlist

4 Select “Yes” using [U / D], then

press [ENTER / OK].

Delete this title?

Yes

“Are you sure?” will appear. Select “Yes” using [U / D], and then press [ENTER / OK]. Title is deleted.

5 Press [RETURN / BACK] or [STOP S]

to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

Note

• If you delete the title in DVD+RW disc, deleted title will be displayed as “Empty”.

• You cannot overwrite on the “Empty”.

Editing Title Name

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

You can edit the title names from this menu. The title names you edit will appear on the title list.

Press [DVD] first.

DVD-RWDVD-RW

DVD-RDVD-R

DDVD+R

DVD+RW

1 In stop mode, press [TOP MENU].

“Title List” will appear. For DVD-RW, press [DISC MENU] to switch between “Original” and “Playlist” if the disc is recorded in VR mode.

2 Press [ENTER / OK] at the desired

title with [U / D / L / P].

e.g.) VR mode DVD-RW disc

Title List

ORG

01/01/08 12:00 901 LP 12:00 (2:00:00)

Pop up window will appear.

01/01/08 901 LP

1 2 3

4 5 6

1 / 2

3 Select “Edit” with [U / D], then

press [ENTER / OK].

Edit menu will appear.

4 Select “Edit Title Name” using

[U / D], then press [ENTER / OK].

A window for entering the title name will appear.

5 To enter the title name, refer to

“Guide to Editing Title Names” on page 71.

Edit -

Edit Title Name

ORG

A B C a b c 1 2 3 @ ! ?

1/01/08 12:00 901 LP

1 : 05 : 00

When you finish entering the title name, press [ENTER / OK].

Page 71

VD+R

E9NG1BD_EN.book Page 71 Monday, April 7, 2008 5:54 PM

6 Select “Yes” using [U / D], then

press [ENTER / OK].

The name you edited becomes the title.

7 Press [RETURN / BACK] and then

[RETURN / BACK] or [STOP S] to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

Guide to Editing Title Names

Step 1: Select the desired character set using

[U / D], then press [ENTER / OK].

Step 2: Using the list below as a guide, press

[the Number buttons] repeatedly until the

desired letter appears.

Select

Press

• Characters set will be changed to the “@!?”

automatically if you press [1] after you selected the “ABC” or “abc” mode.

Note

• To delete letters, press [CLEAR] repeatedly. Press and hold [CLEAR] to delete all letters.

•Press [L / P] to move the cursor to the left or right.

• You can enter up to 30 letters.

• Unrecognisable characters will be replaced with asterisks (*). If you delete them, adjoining characters may change to asterisks (*) or other.

Adding or Deleting Chapter Markers

ABC

––

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

abc @ ! ?

123

! ” # $ % & ’ ( )

+ , - . / : ; < = >

∗

? @ [ ] ^ _ { | }

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

–

3 Use [SKIP B / F], [REV r],

[FWD f], [PLAY P] and [PAUSE p] to find where you create a new chapter marker. Or, use [SKIP B / F] to find a chapter marker that you want to delete.

4 Select “Add” or “Delete” accordingly

using [U / D], then press [ENTER / OK].

e.g.) VR mode DVD-RW disc Original

Edit - Chapter Mark

ORG

Add

Delete

Chapter 3 / 5

01/01/08 12:00 901 LP

1 : 05 : 00

You cannot delete the first chapter of a title.

5 Select “Yes” using [U / D], then

press [ENTER / OK].

e.g.) VR mode DVD-RW disc Original

Edit - Chapter Mark - Add

ORG

Yes

Chapter 3 / 5

01/01/08 12:00 901 LP

1 : 05 : 00

A chapter marker is added.

Adding a chapter marker:

If you select “Add” at the step 4, a new chapter marker is created at the point you specified.

Deleting a chapter marker:

If you select “Delete” at the step 4, the chapter marker you selected is deleted.

6 Press [RETURN / BACK].

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

DVD-RWDVD-RWVRDVD+RWDVD+RW DDVD+R

You can add chapter markers to a title. After a title is marked with chapters, you can use the chapter search feature. You can set a chapter marker anywhere you want. You cannot set more than 999 chapter markers in the Playlist.

DVD+R

Press [DVD] first.

1 Follow the steps 1 to 3 in “Editing

Title Name” on pages 70 to 71.

2 Select “Chapter Mark” using [U / D],

then press [ENTER / OK].

7 Press [RETURN / BACK] again and

then [RETURN / BACK] or [STOP S] to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

Note

• Maximum numbers of chapter for each DVD: VR mode DVD : 999 chapters per entire

Original and Playlist

+VR mode DVD : 254 chapters per disc, 99

chapters per title

• Besides the above-mentioned, it is not likely to be

able to add according to recorded time and number of chapters.

VCR Functions Others

Page 72

VD+R

E9NG1BD_EN.book Page 72 Monday, April 7, 2008 5:54 PM

Adding or Deleting Chapter Markers for Video Mode DVD-RW Disc

Video

DVD-RWDVD-RW

For titles in Video mode DVD-RW disc, you set or edit chapter at every selected time interval. You can clear the chapter mark in once too. You can specify the interval of chapter marks for titles last more than 5 minutes.

Press [DVD] first.

1 Follow the steps 1 to 3 in “Editing

Title Name” on pages 70 to 71.

2 Select “Chapter Mark” using [U / D],

then press [ENTER / OK].

Edit

Video

Edit Title Name

Chapter Mark

04/01/08 12:00 901 LP

1 : 05 : 00

3 Select the desired interval using

[U / D], then press [ENTER / OK].

Hiding Chapters

DVD+RWDVD+RW DDVD+R

You can hide chapters from the title list. Hidden chapters are skipped during playback.

Press [DVD] first.

DVD+R

1 Follow the steps 1 to 3 in “Editing

Title Name” on pages 70 to 71.

2 Select “Hide Chapter” using [U / D],

then press [ENTER / OK].

3 Use [SKIP B / F], [PLAY P] and

[PAUSE p] to decide the chapter to be hidden.

4 Select “Hidden” using [U / D], then

press [ENTER / OK].

Edit - Hide Chapter

+VR

Visible

Hidden

Chapter 3 / 5 Visible

02/01/08 12:00 901 LP

1 : 05 : 00

Edit - Chapter Mark

Video

OFF

5 minutes

10 minutes

15 minutes

30 minutes

60 minutes

04/01/08 12:00 901 LP

1 : 05 : 00

4 Select “Yes” using [U / D], then

press [ENTER / OK].

Chapter markers are added. If you select “OFF” at the step 3, all the chapter markers are erased.

5 Press [RETURN / BACK] and then

[RETURN / BACK] or [STOP S] to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

Note

• You cannot select the chapter mark of the title which is less than 5 minutes.

• You cannot select a chapter marker interval that exceeds the length of a title.

• The length of chapters may slightly deviate from the one specified at the step 3.

• A chapter marker may be delayed depending on the recording content.

• Maximum number of chapter for Video mode DVD is 99 chapters per disc and title.

5 Press [RETURN / BACK]. 6 Press [RETURN / BACK] again and

then [RETURN / BACK] or [STOP S] to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

If you want hidden chapters to be “Visible”, select the chapter to be shown. Then use [U / D] to select “Visible” at the step 4 above.

Data will be written onto the disc momentarily.

Note

• “Hidden” will be displayed in the preview window while previewing the hidden chapter.

• When you make all chapters in the title “Hidden”, “Hidden” is displayed in a thumbnail of the title list.

Page 73

DVD-RW

E9NG1BD_EN.book Page 73 Monday, April 7, 2008 5:54 PM

Protecting Titles

DVD-RW

Original

To prevent the accidental editing or erasing of the titles, you can protect them in the Original menu.

Press [DVD] first.

1 Follow the steps 1 to 3 in “Editing

Title Name” on pages 70 to 71.

2 Select “Protect” using [U / D], then

press [ENTER / OK].

Edit

ORG

Scene Delete

Edit Title Name

Chapter Mark

Protect

01/01/08 12:00 901 LP

1 : 05 : 00

3 Press [ENTER / OK] again.

Edit - Protect

ORG

OFF ON

01/01/08 12:00 901 LP

1 : 05 : 00

4 Press [RETURN / BACK] and then

[RETURN / BACK] or [STOP S] to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

To protect a whole disc (VR mode DVD-RW and DVD+RW/+R discs only):

Select “Disc Protect OFF ON” from the Disc Menu, then select “Yes”. Refer to “Setting a Disc to Protect” on page 52.

Hint

• The protected title is marked with a protect icon in the Original list.

Dividing a Title

DVD-RW

Playlist

You can divide a title into two new titles.

Press [DVD] first.

DVD+RWDVD+RW

1 Follow the steps 1 to 3 in “Editing

Title Name” on pages 70 to 71.

2 Use [SKIP B / F], [REV r],

[FWD f], [PLAY P] and [PAUSE p] to find where you want to divide the title.

3 Select “Title Dividing” using [U / D],

then press [ENTER / OK].

4 Select “Yes” using [U / D], then

press [ENTER / OK].

e.g.) VR mode DVD-RW disc Playlist

Edit - Title Dividing

Yes

01/01/08 12:00 901 LP

1 : 05 : 00

The title is divided into two new titles with the same title names. For DVD+RW : Writing on the disc starts.

For VR mode DVD-RW : Proceed to the step 5.

It may take awhile to write the data on a disc.

5 Press [RETURN / BACK] or [STOP S]

to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

Note

• You cannot divide a title of the disc when the number of recording titles reaches the maximum of 99 (-RW) or 49 (+RW), and the number of recording chapters reaches the maximum of 999 (-RW) or 254 (+RW).

Combining Titles

DVD-RW

Playlist

You can combine two titles into a single title.

Press [DVD] first.

1 Follow the steps 1 to 3 in “Editing

Title Name” on pages 70 to 71.

2 Select “Title Combining” using

[U / D], then press [ENTER / OK].

3 Select another title to combine using

[U / D / L / P], then press [ENTER / OK].

4 Select “Yes” using [U / D], then

press [ENTER / OK].

The two titles will combine into a single title.

Edit - Title Combining

03/01/08 12:00 901 LP 12:00(0:30:00)

1 + 2

Combine selected titles?

4 5 6

03/01/08

Yes No

901 LP

2 3

1 / 6

Title List

01/01/08 12:00 901 LP 12:00 (2:30:00)

4 5 6

01/01/08

901 LP

2 3

1 / 6

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 74

DVD-RW

E9NG1BD_EN.book Page 74 Monday, April 7, 2008 5:54 PM

5 Press [RETURN / BACK] or [STOP S]

to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

Note

• You cannot select the same title twice and combine it into a single title.

• If either one of the two original titles is deleted, the combined new title is also deleted.

Adding Titles to a Playlist

DVD-RW

Original

For VR mode DVD-RW disc, you can add a title to the Playlist as you want. You can add up to 99 titles to a Playlist (as long as the total number of the Playlist does not exceed 999 chapters).

Press [DVD] first.

1 Follow the steps 1 to 2 in “Deleting

Titles” on page 70.

2 Select “Add To Playlist” using

[U / D], then press [ENTER / OK].

Play From Start

Edit

Title Delete

Add To Playlist

3 Select “Yes” using [U / D], then

press [ENTER / OK].

The title is added to Playlist.

4 Press [RETURN / BACK] or [STOP S]

to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

Hint

• To delete a title from the Playlist, refer to “Deleting Titles” on page 70.

• When the disc contains 99 titles or more, or 999 chapters or more, “Add To Playlist” cannot be selected.

Deleting All Playlists

DVD-RWDVD-RW

All Playlists can be deleted if they are no longer needed.

Press [DVD] first.

1 Press [SETUP].

Main menu will appear.

2 Select “DVD Menu” using

[U / D], then press [ENTER / OK].

3 Select “Delete All Playlists” using

[U / D], then press [ENTER / OK].

DVD Menu

Format Finalise Disc Protect OFF ON Delete All Playlists

4 Select “Yes” using [U / D], then

press [ENTER / OK].

Delete entire playlist?

Yes

“Are you sure?” will appear. Select “Yes” using [U / D], and then press [ENTER / OK]. All Playlists are deleted.

Writing on the disc starts. It may take awhile to write the data onto a disc.

Note

• Deleting a Playlist will not increase the available recording time on the disc.

Page 75

E9NG1BD_EN.book Page 75 Monday, April 7, 2008 5:54 PM

Deleting Parts of Titles

DVD-RWDVD-RW

You can delete a specific part of a title. Even when a title is deleted from the Playlist, the original title will remain as it is. The available recording time on the disc will not increase.

Press [DVD] first.

1 Follow the steps 1 to 3 in “Editing

Title Name” on pages 70 to 71.

2 Select “Scene Delete” using [U / D],

then press [ENTER / OK].

e.g.) VR mode DVD-RW disc Playlist

Edit

Scene Delete

Edit Title Name

Chapter Mark

Title Dividing

Title Combining

01/01/08 12:00 901 LP

1 : 05 : 00

3 Use [SKIP B / F], [REV r],

[FWD f], [PLAY P] and [PAUSE p] to find the start point, then press [ENTER / OK].

Edit - Scene Delete

Start

End

Preview

Delete

01/01/08 12:00 901 LP

1 : 05 : 00

Then use [SKIP B / F], [REV r], [FWD f], [PLAY P] and [PAUSE p] again to move to the end point, and press [ENTER / OK].

Edit - Scene Delete

Start

End

Preview

Delete

4 Select “Delete” using [U / D], then

press [ENTER / OK].

Edit - Scene Delete

Start

End

Preview

Delete

01/01/08 12:00 901 LP

1 : 05 : 00

5 Select “Yes” using [U / D], then

press [ENTER / OK].

“Are you sure?” will appear. Select “Yes” using [U / D], and then press [ENTER / OK].

Edit - Scene Delete

Are you sure?

Yes

01/01/08 12:00 901 LP

1 : 05 : 00

The part of the title is deleted.

6 Press [RETURN / BACK] and then

[RETURN / BACK] or [STOP S] to exit.

Writing on the disc starts. It may take awhile to write the data on a disc.

Note

• You cannot select “Scene Delete” if the number of chapter markers in the Original or Playlist is 999. (Depends on the content, there is a case that you cannot select “Scene Delete” before the number of chapter marks reaches 999.)

• The recordable disc space will not increase after deleting parts of titles.

• When a scene is deleted from an Original, the scene on the Playlist will also be deleted.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

01/01/08 12:00 901 LP

1 : 05 : 00

The cursor will move to “Preview”. The bar at the bottom of the screen indicates the total and the elapsed time of the title, and the area selected for deletion is indicated in red. You can check the preview by pressing [ENTER / OK].

• Before and after 5 seconds of the deleted point will be playback for preview.

Page 76

E9NG1BD_EN.book Page 76 Monday, April 7, 2008 5:54 PM

Function Setup

The following table is the contents which you can set and the default settings. Refer to the following table for useful operation.

Setup Items (highlight is the default) Contents

Playback Parental Lock

General Setting

Display Screen Saver

Video TV Aspect

page 78

Audio Out

pages 78-79

Disc Menu Language

page 79

Audio Language

page 79

Subtitle Language

page 80

Angle Icon

page 80

Still Mode

page 80

TV System

page 80

page 81

FL Dimmer

page 81

Video Out

pages 81-82

Dynamic Range Control

PCM

Dolby Digital

MPEG

DTS

All level 1 to 8

ON OFF

48kHz 96kHz

PCM Set whether to convert Dolby Digital into PCM Stream

PCM Stre am

ON OFF

English Other

Original English Other

OFF English Other

ON OFF

Auto Field Frame

PAL

Auto OFF

5 minutes

10 minutes

15 minutes 30 minutes

Auto

Bright

Dark OFF

4:3 Letter Box 4:3 Pan & Scan

16:9 Wide SCART (RGB)

Component (Progressive) Component (Interlace)

Set the parental level for DVD disc playback.

Compressing the range of sound volume.

Set whether the sound recorded in 96kHz will be down sampled to 48kHz.

or to output Dolby Digital signals. Set whether to convert MPEG into PCM or to

output MPEG signals. Set whether DTS signal is output or not.

Set the language for Disc Menu.

Set the language for audio.

Set the language for subtitles.

Set whether or not to display the angle icon.

Set the type of still image in pausing playback.

Set the TV system.

Set the idling time before the screen saver starts.

Set the brightness of the Front Panel Display.

Set a picture size according to aspect ratio of your TV.

Sets the video output mode.

Page 77

E9NG1BD_EN.book Page 77 Monday, April 7, 2008 5:54 PM

Setup Items (highlight is the default) Contents

Recording Auto Chapter

Clock Auto Clock Setting

Channel Auto Tuning (DVB & ANALOG)

General Setting

DivX DivX®VOD page 56

HDMI Format

Reset All

page 84

pages 36-37

Recording Audio Select (XP)

pages 38-39

Auto Finalise

page 53

Aspect Ratio(Video mode)

page 36

Dubbing Mode

pages 50-51

Make Recording Compatible

page 36

Bilingual Recording Audio

page 38

External Input Audio

page 38

Video Colour System

page 47

page 33

Clock Setting

page 33

page 23

DVB Channel Setup

ANALOG Channel Setup

DivX Subtitle

page 82

page 83

HDMI Audio

page 83

RGB Range

page 83

Edit Channels

Auto Tuning

Manual Tuning

Signal Information

Auto Tuning

Manual Tuning

Move

page 27

page 25

page 26

page 29

page 24

page 25

OFF 5 minutes 10 minutes 15 minutes 30 minutes 60 minutes

PCM Set the recording audio type. (Only when the Dolby Digital

ON Set the unit to finalise the disc automatically. OFF

Auto 4:3 16:9

VCR→DVD DVD→VCR

ON Set to prohibiting additional recording (OFF) or OFF

Main Sub

Stereo Bilingual

Auto

PAL SECAM

ON OFF

OFF English French Span is h German Italian Swedish Dutch Russian1 Russian2 Hungarian Polish Czech Hebrew

RGB YCbCr

ON OFF

Normal Enhanced

Insert chapter marks periodically.

recording mode is set to “XP”.)

Set a aspect ratio for Video mode recording.

Set the dubbing selection.

to replace the title list after recording (ON). Set the audio type for recording.

Set the external input audio type for recording.

Set the video colour system to “PAL” or “SECAM” automatically. Set the video colour system to “PAL”. Set the video colour system to “SECAM”.

Set the clock automatically.

Set the clock manually.

Tune the DVB and analogue channels automatically.

Lock the DVB channels, edit the favourite lists.

Tune the DVB channels automatically.

Tune the DVB channels manually.

Display the detailed information of the current DVB channel.

Tune the analogue channels automatically.

Tune the analogue channels manually.

Move the analogue channels to different position.

Provide DivX® VOD registration code. Set the language for DivX

Set the colour space for the HDMI output.

Set whether to output the HDMI audio signal or not.

Set the black-white contrast level for HDMI RGB output.

Set to the default setting.

Subtitle.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Note

• Your change to each setting stays on even when the power is switched off.

• An item which is not currently available is greyed in the settings.

Page 78

E9NG1BD_EN.book Page 78 Monday, April 7, 2008 5:54 PM

Playback

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Playback” using [U / D],

then press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

3 Select a desired item using [U / D],

then press [ENTER / OK].

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

TV System

4 Refer to 1. to 8. on the following

pages to help set the selected item.

5 When you finish with the setting,

press [SETUP] to exit.

1. Parental Lock (Default: All) (DVD only)

Set “Parental Lock” level.

Change “Parental Lock” level using [U / D], then press [ENTER / OK].

Proceed with either of the following steps.

Parental Lock

All 8 7 6 5 4 3 2 1

Parental level

All: All parental locks are cancelled.

8: DVD software of any grade (adult /

general / children) can be played back.

7 to 2: Only DVD software intended for general

use and children can be played back.

1: Only DVD software intended for children

can be played back.

Note

• “Parental Lock” function may not be available on some discs.

• It may be difficult to determine if some DVDs support “Parental Lock” function. Be sure to confirm that “Parental Lock” function operates in the way that you have set.

• Record the password in case you forget it.

A password is not yet set

Select “Yes” using [U / D], then press [ENTER / OK]. Enter a new password using [the Number buttons], then press [ENTER / OK].

Change Password?

Yes

Your setting is activated.

If you select “No”, press [SETUP] to exit.

A password is already set

Yes

Password Input

Enter the current password using [the Number buttons].

Password Input

If you want to change the password, select “Yes” using [U / D], then press [ENTER / OK].

Change Password?

Yes

Enter a new password using [the Number buttons], then press [ENTER / OK].

Password Input

Your setting is activated.

Note

•Press [CLEAR] to erase numbers entered incorrectly.

• If you forget your password or you want to clear all settings in “Parental Lock”, enter [4], [7], [3], [7] using [the Number buttons] at the option window. Your password is cleared and parental levels are set to “All”.

2. Audio Out

Choose the appropriate audio setting for your external device.

It will only affect a disc playback.

Select a desired item using [U / D], then press [ENTER / OK].

Audio Out

Dynamic Range Control PCM Dolby Digital MPEG DTS

Page 79

E9NG1BD_EN.book Page 79 Monday, April 7, 2008 5:54 PM

Dynamic Range Control (Default: ON) (DVD only)

Introduction Connections Basic Setup Playback

Settings for MPEG (Default: PCM) (DVD only)

Set to “ON” to make the dynamic range narrower.

Select a setting using [U / D], then press [ENTER / OK].

Dynamic Range Control

ON OFF

Your setting is activated. “Dynamic Range Control” function is effective only with analogue audio connection.

Note

• “Dynamic Range Control” function is available only on discs recorded in the Dolby Digital format.

PCM sampling (Default: 48kHz)

Select a setting using [U / D], then press [ENTER / OK].

PCM

48kHz 96kHz

Your setting is activated.

48kHz: If your amplifier / decoder is NOT compatible

with 96 kHz PCM, select “48kHz”. Sound recorded at 96 kHz is down sampled to 48 kHz.

96kHz: If your amplifier / decoder is compatible with

96 kHz PCM, select “96kHz”. Sound is sampled at 96 kHz.

Note

When playing back a disc with copyright protection:

• Even if you select “96kHz”, the sound is down sampled to 48 kHz.

Dolby Digital conversion (Default: Stream)

Select a setting using [U / D], then press [ENTER / OK].

Dolby Digital

PCM Stream

Your setting is activated.

PCM: Converts the Dolby Digital into PCM

(2 channel). If your amplifier / decoder is NOT compatible with Dolby Digital, set to “PCM”.

Stream: Outputs Dolby Digital signals.

If your amplifier / decoder is compatible with Dolby Digital, set to “Stream”.

Hint

When playing back a DVD-RW disc recorded in VR mode:

• If the audio source on a disc is in Dolby Digital format, set “Dolby Digital” to “PCM” so that you can switch to main audio (L), sub audio (R), or a combination of both (L / R) using your amplifier / decoder.

Select a setting using [U / D], then press [ENTER / OK].

MPEG

PCM Stream

Your setting is activated.

PCM: Converts MPEG into PCM.

If your amplifier / decoder is NOT compatible with MPEG, set to “PCM”.

Stream: Outputs MPEG Audio signals.

If your amplifier / decoder is compatible with MPEG, set to “Stream”.

Settings for DTS (Default: ON) (DVD only)

Select a setting using [U / D], then press [ENTER / OK].

DTS

ON OFF

Your setting is activated.

ON: Outputs DTS signals.

If your amplifier / decoder is compatible with DTS, set to “ON”.

OFF: No DTS signal is output.

If your amplifier / decoder is NOT compatible with DTS, set to “OFF”.

3. Disc Menu Language (Default: English) (DVD only)

Set “Disc Menu language”.

Select a language using [U / D], then press [ENTER / OK].

Disc Menu Language

English Other

Your setting is activated.

4. Audio Language (Default: Original) (DVD only)

Set “Audio language”.

Select a language using [U / D], then press [ENTER / OK].

Audio Language

Original English Other

Your setting is activated. If “Original” is selected, the audio language is the default of the inserted disc.

Recording

Editing

Function Setup

VCR Functions Others

Page 80

E9NG1BD_EN.book Page 80 Monday, April 7, 2008 5:54 PM

5. Subtitle Language (Default: OFF) (DVD only)

Set “Subtitle language”.

Select a language using [U / D], then press [ENTER / OK].

Subtitle Language

OFF English Other

Your setting is activated.

If “Other” is selected, enter the appropriate 4-digit code using [the Number buttons].

Refer to “Language Code” on page 93.

Code Input

----

When you finish entering the code, press [ENTER / OK].

Hint

• You can also change or switch off the subtitles on a

DVD from the disc menu if it is available.

•Press [CLEAR] or [L] to erase numbers entered

incorrectly.

Note

• You can only select the languages supported by the

inserted disc.

• “Audio Language” setting may not be available for

some discs.

6. Angle Icon (Default: ON) (DVD only)

Set “Angle Icon”.

Select a setting using [U / D], then press [ENTER / OK].

Angle Icon

ON OFF

Your setting is activated.

7. Still Mode (Default : Auto)

Auto: Automatically select the best resolution

Field: Select “Field” when the pictures are still

Frame: Select “Frame” to display relatively

setting (“Frame” or “Field”) based on the data characteristics of the pictures.

unstable even if “Auto” is selected. “Field” stabilises the pictures, although the picture quality may become coarse due to the limited amount of data.

motionless pictures in higher resolution. “Frame” improves the picture quality, although it may destabilise the picture due to simultaneous output of two fields of data.

Note

• An individual picture on TV screen is called Frame, which consists of two separate images called Field. Some pictures may be blurred at the “Auto” setting in still mode due to their data characteristics.

8. TV System (Default: PAL)

Select a setting using [U / D], then press [ENTER / OK].

TV System

PAL Auto

Your setting will be activated.

PAL: Outputs a modified PAL signal for viewing

discs recorded with the NTSC system on a PAL system TV.

Auto: Changes the video system (PAL / NTSC)

automatically according to the format of the inserted disc.

Note

• With discs recorded using the PAL system, a PAL signal is output for viewing on a PAL system TV.

• Discs recorded with the PAL system cannot be viewed on an NTSC system TV.

• With discs recorded using the NTSC system, an NTSC signal is output for viewing on an NTSC or Multi system TV.

• With discs recorded using the NTSC system, select PAL to view on a PAL system TV.

Select a setting using [U / D], then press [ENTER / OK].

Still Mode

Auto Field Frame

Your setting is activated.

Page 81

E9NG1BD_EN.book Page 81 Monday, April 7, 2008 5:54 PM

Introduction Connections Basic Setup Playback

Display

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Display” using [U / D], then

press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

3 Select the desired item using

[U / D], then press [ENTER / OK].

Screen Saver

FL Dimmer

4 Refer to 1. and 2. on this page and

set the selected item.

5 When you finish with the setting,

press [SETUP] to exit.

1. Screen Saver (Default: 10 minutes)

Set the screen saver time delay.

Select a setting using [U / D], then press [ENTER / OK].

Screen Saver

OFF 5 minutes 10 minutes 15 minutes 30 minutes

Your setting is activated.

2. FL Dimmer (Default: Bright)

Set the front panel display brightness.

Select a setting using [U / D], then press [ENTER / OK].

FL Dimmer

Auto Bright Dark OFF

You can choose one from “Auto”, “Bright”, “Dark” or “OFF”. If “Auto” is selected, the display gets dark when the power is off. If “OFF” is selected, you can lower the power consumption while the power is off. The brightness of the front panel display is dark while the power is on, and the front panel display is off while the power is off.

Note

• If you set “FL Dimmer” to “OFF”, output of the picture from the external device through AV2 to AV1 (input of the picture from AV2 and output of the picture from AV1.) is not available when this unit is off.

Video

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Video” using [U / D], then

press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

3 Select the desired item using

[U / D], then press [ENTER / OK].

TV Aspect

Video Out

4 Refer to 1. and 2. on this page and

set the selected item.

5 When you finish with the setting,

press [SETUP] to exit.

1. TV Aspect (Default: 16:9 Wide)

You can select the TV aspect ratio to match the formats of what you are playing back with the unit and your TV screen (4:3 standard or 16:9 widescreen TV).

Select the desired setting using [U / D], then press [ENTER / OK].

TV Aspect

4:3 Letter Box 4:3 Pan & Scan 16:9 Wide

If you have a standard TV:

Select “4:3 Letter Box”, so that black bars appear on the top and bottom of the TV screen when playing back a wide-screen picture. Select “4:3 Pan & Scan” for a full height picture with both sides trimmed when playing back wide-screen picture.

If you have a widescreen TV:

Select “16:9 Wide”.

2. Video Out (Default: SCART(RGB))

This unit is compatible with the Progressive Scan System. The feature provides you with the higher definition images than the traditional output system does. To utilise this feature, you must set Video Output mode in “Setup” menu by following the steps on the right. “SCART (RGB)” is selected as the default.

Recording

Editing

Function Setup

VCR Functions Others

Page 82

E9NG1BD_EN.book Page 82 Monday, April 7, 2008 5:54 PM

1 Select the desired setting using

[U / D], then press [ENTER / OK].

Video Out

SCART (RGB) Component (Progressive) Component (Interlace)

• If your TV is compatible with progressive scanning (576p/480p), connect the TV to the COMPONENT VIDEO OUT jacks of this unit and select “Component (Progressive)” and set your TV to the progressive scan mode.

• If your TV is not compatible with progressive scan, select “Component (Interlace)” for component connection, or select “SCART (RGB)” for Scart cable connection.

• Refer to pages 20 and 21 for more details.

Only if you select the “Component (Progressive)”, proceed to step 2. If you select “Component (Interlace)” or “SCART (RGB)”, your setting is activated.

2 Using [L / P] to select “Yes”. Press

[ENTER / OK].

Activating progressive scan: Check your TV has progressive scan and connect with component video cable.

NOTE:

If there is no picture or picture is distorted after selecting “Yes”, wait about 15 seconds for autorecovery.

Activate?

Final confirmation window will appear.

3 Using [U / D] to select “Yes”. Press

[ENTER / OK] within 15 seconds.

Confirm again to use progressive scan. If picture is good, select “Yes”.

Yes

Your setting is activated.

Note

• When changing “Video Out” setting (“SCART (RGB)”, “Component (Interlace)” or “Component (Progressive)”), connect to the corresponding jack on the TV. If the setting is changed, for example, to “SCART (RGB)” while the COMPONENT VIDEO OUT jacks are used to connect to the TV, a distorted video signal may result.

DivX

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “DivX” using [U / D], then

press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

3 Select the desired item using

[U / D], then press [ENTER / OK].

DivX®VOD

DivX Subtitle

For “DivX®VOD”, refer to page 56 for details.

DivX Subtitle (Default: OFF)

NoYe s

Select the desired setting using [U / D], then press [ENTER / OK].

DivX Subtitle

OFF English French Spanish German Italian Swedish

4 When you finish with the setting,

press [SETUP] to exit.

Page 83

E9NG1BD_EN.book Page 83 Monday, April 7, 2008 5:54 PM

HDMI

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

• Make sure that the HDMI cable is connected and the TV input is set to HDMI.

2 Select “HDMI” using [U / D], then

press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

3 Select the desired item using

[U / D], then press [ENTER / OK].

Format

HDMI Audio

RGB Range

2. HDMI Audio (Default: ON)

If you do not want to output the audio through HDMI (when you digitally output the audio through the DIGITAL AUDIO OUT (COAXIAL) jack to your audio system, etc.), you can set the HDMI audio output off.

Select a setting using [U / D], then press [ENTER / OK].

• Set to “OFF” when the HDMI sound is not required.

HDMI Audio

ON OFF

Your setting is activated.

3. RGB Range (Default: Normal)

You can adjust the RGB range to make the dark areas of the HDMI images brighter.

Select a setting using [U / D], then press [ENTER / OK].

• Select “Enhanced” if the black-white contrast is not clear.

• This setting is effective only for HDMI RGB output.

RGB Range

Normal Enhanced

Your setting is activated.

Introduction Connections Basic Setup Playback

Recording

4 Refer to 1. to 3. on this page and set

the selected item.

5 When you finish with the setting,

press [SETUP] to exit.

1. Format (Default: RGB)

You can select the colour space for HDMI output. Set the appropriate colour space for your display device.

Select a setting using [U / D], then press [ENTER / OK].

• When the connected device is not compatible with the Y/Cb/Cr, HDMI signal is output as RGB regardless of the setting.

Format

RGB YCbCr

Your setting is activated.

Editing

Function Setup

VCR Functions Others

Page 84

E9NG1BD_EN.book Page 84 Monday, April 7, 2008 5:54 PM

Reset All

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER / OK].

2 Select “Reset All” using [U / D],

then press [ENTER / OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

3 Select “Yes” using [U / D], then

press [ENTER / OK].

Reset to factory default?

Yes

“Are you sure?” will appear. Select “Yes” using [U / D], and then press [ENTER / OK].

4 When you finish with the setting,

press [SETUP] to exit.

Note

• The settings listed below will remain unchanged even after resetting to the factory default.

- Clock setting

- Channel setting

- Parental lock setting

VOD code

-DivX

- Timer Programmes

Page 85

E9NG1BD_EN.book Page 85 Monday, April 7, 2008 5:54 PM

VCR Functions

Introduction Connections Basic Setup Playback

Playback

VCRVCR

1 Press [ ON / STANDBY] to turn on

the unit.

To play back a tape, turn on the TV and be sure to select the input to which the unit is connected.

2 Press [VCR]. 3 Insert a pre-recorded tape, then

press [PLAY P] to start playback.

4 During playback, press [PAUSE p].

Playback will be paused and sound will be muted.

5 Press [PLAY P] to resume playback. 6 Press [STOP S] to stop playback. 7 Press [OPEN / CLOSE O] to eject the

tape.

Note

• When a tape without record tab is inserted, the unit will start playback automatically.

• Tracking will be automatically adjusted upon playback. To adjust the tracking manually, press [PROG. / ].

Recording and One-touch Timer Recording (OTR)

Basic Recording

VCRVCR

Before recording, make sure:

• The desired channel is selected by pressing

[the Number buttons] or [PROG. / ] on the remote control.

• There is a tape with a record tab in the unit.

Tape speed Recording / Playback Time

Type of tape E60 E120 E180 E240

SP mode 1 hour 2 hours 3 hours 4 hours

LP mode 2 hours 4 hours 6 hours 8 hours

• Refer to pages 41 to 42 for instructions on timer recording.

1 Turn on the unit and insert a

recordable tape.

Make sure that the TV input is set on the unit.

2 Press [VCR]. 3 Select the recording mode using

[REC MODE].

• The desired recording mode is selected in SP (standard play) or LP (long play) mode by pressing [REC MODE].

4 Select the desired channel to record

using [PROG. [the Number buttons].

/ ] or

5 Press [REC I] to start recording.

To temporarily stop recording or to resume it, press [PAUSE p].

Recording

Editing

Function Setup

After the unit has been in pause mode for 5 minutes, it will stop automatically to protect the tape and the video head from damage.

6 Press [STOP S] when the recording

is completed.

VCR Functions Others

Page 86

E9NG1BD_EN.book Page 86 Monday, April 7, 2008 5:54 PM

Accidental erasure prevention

To prevent accidental recording on a recorded cassette, remove its record tab. To record on it later, cover the hole with cellophane tape.

Record tab

One-touch Timer Recording

VCRVCR

This feature allows you to set the recording length simply by pressing [REC I].

1 Turn on the unit and insert a

recordable tape.

Make sure that the TV input is set on the unit.

2 Press [VCR]. 3 Select the recording mode using

[REC MODE]. (See page 85.)

4 Select the desired channel to record

using [PROG. [the Number buttons].

/ ] or

5 Press [REC I] repeatedly until the

desired recording time (30 minutes to 8 hours) appears on the TV screen.

One-touch Timer Recording will start.

0:30

DVC to VCR Dubbing

VCRVCR

This function helps you to copy the contents in the DVC (digital video camcorder) to VCR.

Preparing for DV dubbing (DVC to VCR):

• Insert a recordable videotape.

• Make sure your DVC is in video mode.

1 Press [VCR]. 2 Select “DV” channel using

[INPUT SELECT ] or [PROG.

/ ].

3 Select the recording mode using

[REC MODE].(See page 85.)

4 Stop or pause the DVC where you

want to start dubbing.

5 Play back the DVC 6 Press [REC I].

The dubbing will start.

Note

• Dubbing will start from where the tape is stopped.

Normal Recording

1:00

8:00 7:30

• When the unit reaches the specified time, it will be turned off automatically.

• To change the recording length during One-touch Timer Recording, press [REC I] repeatedly until the desired length appears.

• To cancel One-touch Timer Recording within the specified time, press [STOP S].

Hint

• The remaining recording time will appear on the TV screen during One-touch Timer Recording. Press

[DISPLAY] to see it on the TV screen.

Note

• If VCR One-touch Timer Recording is completed during DVD playback or recording, the VCR will be in stop mode and the DVD keeps the current mode.

• You cannot use the pause function during Onetouch Timer Recording.

Page 87

E9NG1BD_EN.book Page 87 Monday, April 7, 2008 5:54 PM

Introduction Connections Basic Setup Playback

Index Search

VCRVCR

1 Press [VCR]. 2 Press [SEARCH] so that the index

search menu appears.

3 Enter the number of recordings you

want to skip using [the Number buttons] within 30 seconds.

4 Press [FWD f] or [REV r] to start

index search.

If you want to go in the forward direction, press [FWD f]. If you want to go in the reverse direction, press [REV r]. After index search, the VCR will play back the tape automatically.

Note

• This function is not available during recording.

• Every time a tape is recorded, an index mark is written on the tape.

• You can make the index mark up to 20.

Time Search

VCRVCR

This feature allows you to go to a specific point on a tape by entering the exact amount of time you want to skip in order to reach the point.

1 Press [VCR].

Other Operations

VCRVCR

Press [VCR] first.

To cue or review picture during playback (Picture Search):

Press [FWD f] or [REV r] during playback. Press it again and the unit will search in super high speed (in the LP mode only).

To freeze the picture on TV screen during playback (Still mode):

Press [PAUSE p]. Each time you press the button, the picture will be forwarded frame by frame. If the picture begins to vibrate vertically during the still mode, stabilise the picture by pressing the [PROG. / ]. If the picture is distorted or rolling vertically, adjust the vertical hold control on your TV, if equipped.

To reset the tape counter: Press [CLEAR].

To play back in slow forward motion: During playback, press [PAUSE p], then press [FWD f].

If the noise bars appear on the TV screen, you can reduce it by pressing [PROG. / ]. Slow reverse is not available in VCR mode.

Note

• Still / Slow / Pause mode will be automatically cancelled after 5 minutes to prevent damage to the tape and the video head.

• To return to normal play back from the Picture Search / Still / Slow mode, press [PLAY P].

Recording

Editing

2 Press [SEARCH] repeatedly until the

time search menu appears.

3 Enter your desired time to skip using

[the Number buttons] within 30 seconds.

4 Press [FWD f] or [REV r] to start

time search.

If you want to go in the forward direction, press [FWD f]. If you want to go in the reverse direction, press [REV r]. After time search, the unit will play back the tape automatically.

Note

• This function is not available during recording.

•Press [STOP S] to stop the search.

• If the tape reaches the end during the search, this unit will cancel it and rewind the tape.

• You can set the time up to 9:59.

Function Setup

VCR Functions Others

Page 88

E9NG1BD_EN.book Page 88 Monday, April 7, 2008 5:54 PM

Hi-Fi Stereo Sound System

This unit will record and playback Hi-Fi stereo sound. In addition, it has a NICAM stereo sound decoder. This unit will receive stereo and bilingual broadcasts and it is possible to record in several ways and to play back the sound.

Selecting the Sound Mode

You can select each mode by pressing [AUDIO ] on the remote control. Each mode is indicated on the TV screen as follow.

• During playback of the recorded tape in Hi-Fi mode

Mode Audio output

Stereo Stereo STEREO

L L audio from both speakers LEFT

R R audio from both speakers RIGHT

Normal Monaural MONO

Display on

the TV screen

• During reception of bilingual broadcasts

Mode Audio output

Main audio from the both

Main

speakers

Sub audio from the both

Sub

speakers

Main /

• Main audio from the left

Sub

speaker

• Sub audio from the right speaker

Display on

the TV screen

Main

Sub

Main

Sub

Note

• If you play back non-Hi-Fi tapes, the unit will play back automatically in monaural regardless of the mode you set.

• If the stereo signal becomes weak, the broadcast is automatically recorded in monaural.

Page 89

E9NG1BD_EN.book Page 89 Monday, April 7, 2008 5:54 PM

Others

Troubleshooting

Before requesting service for this unit, check the table below for a possible cause of the problem you are experiencing. Some simple checks or a minor adjustment on your part may eliminate the problem and restore proper operation.

Symptom Remedy

The power does not turn on. • Check that the AC power cord is connected securely.

The unit turns on automatically without any

POWER

operation.

The unit does not function. • “ ” or error message appears if the operation is prohibited.

No picture, sound or menu appears on the screen.

“Clock” setting and “Channel” setting cannot be performed.

The unit does not operate properly. • Moisture has condensed inside the unit. Remove the disc and leave the

The clock display does not appear on the front panel display.

When you forget the password for parental lock.

DV signal cannot be input. • Before connection, turn on the power supplies for both this unit and the

The DVC cannot be operated with this unit. • Signal input or DVC operation from this unit may be disabled depending

GENERAL

Certain functions of the DVC cannot operate. • Some functions may not operate depending on the type of DVC. For

DV audio signal cannot be switched. • For recording with the DVC, the recording audio signal can be set to 12

No image from HDMI connection. • Check the HDMI connection. (Check the status of the HDMI related

• Batteries of the remote control are weak.

• The unit turns on automatically 2 seconds before the timer recording.

• Batteries of the remote control are weak or exhausted.

• Check if the connections are made securely and correctly.

• Check if the cables are damaged.

• Check if a correct external input channel is selected on your TV. (See pages 21 to 22.)

• Check if you have completed “Channel” setting. (See pages 23 to 29.)

• If a recording is in progress, these operations cannot be performed.

unit turned on for about 2 hours until the moisture evaporates. (See page 3.)

• Check that the AC power cord is connected securely.

• (In case of power failure) Check the breaker and “Clock” setting.

• Please cancel the password and the set level. (See page 78.)

DVC, and make sure that these units have stopped.

• Only a “DVC-SD” signal can be input from the DVC to this unit. Other types of signals are not supported.

• Do not connect any device other than the DVC. Even if a recorder or PC with another DV terminal is connected, the DV function will not operate.

• If the DVC is not recognised after connection, turn off the power supply for the unit and re-connect the DVC.

on the type of DVC.

• If a DVC signal cannot be input, use an external input (AV2/AV3) for analogue connection via audio/video cables. Use Scart adaptor for connecting to AV2.

• DVC control may be disabled depending on the type of DVC, even in a mode other than camera mode. In this case, switch to DVD control and execute the normal recording procedure while operating the DVC.

example, if the DVC does not support slow playback mode, the slow playback function is disabled.

• With DV (AV4), the disc display menu does not appear unless disc playback is executed.

bits or 16 bits. However, when 16-bit recording mode is selected, audio signal cannot be switched. To record an audio signal, set it to 12 bits.

indications.)

• Check whether the connected monitor device or other device supports HDCP. (This unit will not output a video signal unless the other device supports HDCP.)

• Check the setting of HDMI.

• Check whether the output format of this unit (HDMI FORMAT) matches the supported input format of other connected device.

• If the unit is connected to the unauthorised display device with an HDMI cable, the audio and video signals may not be output when playing back a commercial DVD-video.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Page 90

E9NG1BD_EN.book Page 90 Monday, April 7, 2008 5:54 PM

Symptom Remedy

TV channels cannot be changed. • Check if the connections are made securely and correctly.

Only specific channels do not appear. • The channels may be set to be skipped. (See page 25.)

CHANNEL

The external input channels (such as AV2 or AV3) cannot be skipped.

The image from the external device cannot be displayed or recorded.

GENERAL

Recording is impossible. • This unit cannot record programmes that contain copy protection signal.

Timer recording cannot be performed. • The internal clock of the unit may have been stopped due to a power

“Repairing” appears on the TV screen. • If there is a power failure or unplugging during recording, finalising,

DVD

RECORDING

Repairing

In a case you intend to cancel the repairing process.

Do you want to cancel a repairing

process? When selecting “Yes”,

the disc may not be usable.

Yes

Repairing

• Check if the cables are damaged.

• Try channel setting by following the steps on pages 23 to 29.

• This unit does not skip the external input channels. This is not a malfunction.

• Try pressing [INPUT SELECT ] repeatedly.

• Turn on all connected devices.

• Check if the connections are made securely and correctly.

This is not a malfunction.

• The space of the recording media may be used up. Try deleting unnecessary titles, or exchange it with the recordable media.

• The maximum number of titles or chapters has exceeded. Delete the unnecessary titles to make enough space or insert a new recordable media.

• Check if the disc is CPRM compatible. Copy-once programmes can only be copied onto the disc which is CPRM compatible.

• Check if the disc is protected or finalised. Undo the protection or the finalisation.

• DVD-RW once formatted in other unit cannot be recorded in this unit unless formatted in this unit.

• Check if the connections are made securely and correctly.

failure that lasted for more than 30 seconds. Reset the clock. (See page

33.)

formatting or editing (even after “Repairing” disappears), a repairing process will begin automatically just after turning the unit on again.

• It may take several minutes up to about several hours.

• If you intend to cancel the repairing process, press [A OPEN / CLOSE] on the front panel, then select “Yes” and press [ENTER / OK]. After that, press [OPEN / CLOSE A] to take out the disc. The disc cancelled during the repairing process MAY NOT work.

Writing to Disc

The indication

Writing to Disc

“ ” does not disappear.

100%

Recording does not start immediately after pressing [REC I].

VCR

TV aspect ratio does not match your TV screen.

Playback picture is distorted. Colour of the picture is abnormal.

There is no sound, or no subtitle. • Turn on all connected devices.

GENERAL

PLAYBACK

• “ ” may remain on screen for the maximum of 20 seconds even after it reached 100%. This is not a malfunction.

• Make sure the videotape has a recorded tab when you record to a videotape. If needed, cover the hole with cellophane tape.

• Check the “TV Aspect” setting. (See page 81.)

• A different aspect ratio will be used when the aspect ratio specified by the disc is not supported by this unit.

• During fast forward or fast reverse, playback picture may be distorted. This is not a malfunction.

• Connect to TV directly. When you connect this unit with the television via VCR or other devices, the picture may be distorted due to the copyprotection signal.

• Check if the cables are damaged.

• Keep the equipment which may cause electrical disturbances, such as a cellular phone, away.

• Check if the external input channel is set correctly.

• Check if the connections are made securely and correctly.

• If using the HDMI connection, sound is not output when “HDMI Audio” is set to “OFF”.

• Check the RCA audio cable connection. If you are using HDMI-DVI conversion cable, you must connect the RCA audio cable, too.

• If using the HDMI connection, check whether the output format of this unit (HDMI FORMAT) matches the supported input format of other connected device.

100%

Page 91

E9NG1BD_EN.book Page 91 Monday, April 7, 2008 5:54 PM

Symptom Remedy

Playback does not start from the beginning. • Resume function may be activated. Refer to page 60 to cancel the

Playback cannot be performed. • Check if the playable disc is inserted.

There is no sound, or no subtitle. • Check if all the connections are made correctly.

DVD

Digital audio setting cannot be changed to main audio (L), sub audio (R) or combination of both.

PLAYBACK

Audio language or the subtitle language of the DVD cannot be changed.

Angles cannot be changed. • Even though the multi-angle feature is supported by the disc, that does

The disc cannot be played back on other player even though it is finalised properly.

Picture noise appears. • Adjust tracking control for better picture by pressing [PROG. / ]

VCR

The unit does not play back the videotape. • Check if a videotape is in this unit.

The motor rotates even when playback / recording is stopped.

Titles cannot be edited or deleted. • The titles or the disc itself may be protected. Cancel the protection by

Dubbing cannot be executed. • When the number of the titles or the chapters exceed the maximum

DVD

Titles cannot be edited or deleted. • The titles in the DVD+R/-R cannot be edited or deleted if they are

EDITING

The capacity of the disc doesn’t increase even if the recorded programme is deleted.

The remote control does not function. • No batteries in the remote control or the batteries may be weak. Replace

resume point.

• Check if the disc is loaded correctly with the labelled side facing up.

• Discs made on other devices or on personal computers cannot be played back on this unit unless it is finalised on the device.

• Even if it is finalised, the performance of those discs are not guaranteed on this unit.

• The disc may be dirty or flawed. Clean the disc.

• Check if all the connections are made correctly.

• Check “Parental Lock” setting. (See page 78.)

• Playback of DVD is prohibited from 2 minutes before the programmed start time of a timer recording when the recording media is DVD.

• Check if the “Audio Out” is set correctly. (See pages 78 to 79.)

• There is a possibility that the selected subtitle language is not supported by the disc.

• If the audio source is in the Dolby Digital format, set “Dolby Digital” setting to “PCM” in “Playback” menu. (available only for DVD) (See page

79.)

• Multilingual subtitles are not supported by the disc.

• Some audio languages or the subtitle languages can be changed only from the disc menu. Please refer to the disc’s manual.

not mean all the scenes are shot from multi-angles. Changing angles is available only for those scenes shot from the multi-angle.

• Some DVD players do not play back the disc made on other recorder. Refer to the manual of the unit.

while you are playing back a videotape.

• Head cleaning for VCR may be necessary. Refer to “AUTO HEAD CLEANING” on page 5.

• The motor may rotate for the duration of approximately 5 minutes for efficient operation. This is not a malfunction.

following the steps on page 73 for title protection and page 52 for disc protection.

recordable number, the dubbing will not be executed.

• Check if the disc is compatible for recording. (See pages 34 to 35.)

finalised. If it is DVD-RW, undo the finalisation by following the steps on pages 52 to 53.

• With DVD+RW and video mode DVD-RW, the disc space will increase only when the last title in the Original is deleted. With DVD-R/+R, deleting a title will not increase the disc space.

the batteries.

• Make sure there is no obstacle between the remote control and the unit.

• Try getting closer to the unit. (See page 15.)

• If above solutions do not solve the problem, please call an Authorised Service Centre.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

REMOTE CONTROL

VCR Functions Others

Page 92

E9NG1BD_EN.book Page 92 Monday, April 7, 2008 5:54 PM

Error message Cause Solution

Disc Error — Please eject the disc. — Playback feature may not be available on this disc.

Region Error — Please eject the disc. — Playback is not authorized in your region.

Parental Lock On The current selected parental level prohibits playback.

Recording Error This programme is not allowed to be recorded.

Recording Error This programme is not recordable in Video mode.

Recording Error Cannot record on this disc.

Recording Error This programme is not allowed to be recorded on this disc.

Recording Error This disc is protected and not recordable.

Recording Error Disc is full. (No area for new recording)

Recording Error You cannot record more than 99 titles on one disc. (The maximum is 99)

Recording Error You cannot record more than 999 chapters on one disc. (The maximum is 999)

Recording Error You cannot record more than 49 titles on one disc. (The maximum is 49)

Recording Error You cannot record more than 254 chapters on one disc. (The maximum is 254)

Recording Error You cannot record on this disc as Control Information is full.

Recording Error You cannot record on this disc as Power Calibration Area is full.

Recording Error This disc is already finalised.

Recording Error The disc has no recording compatibility. Set “Make Recording Compatible” to “ON” to convert the disc.

• An unplayable disc is inserted in the unit.

• The disc is upside down.

• Playback is not authorised in the region of the DVD-Video that you inserted in the unit.

• The current selected parental level in “Setup” menu prohibits playback.

• The recording function encountered a copy prohibited programme.

• Original source is in NTSC system.

• You are trying to record a copy-once programme onto a DVD-RW disc in Video mode.

• You are trying to record onto a disc that is unrecordable, or the disc status does not satisfy recording requirements.

• The disc is dirty.

• The disc is damaged.

• You are trying to record onto a VR mode DVD-RW disc which contained recordings from another recorder.

• You are trying to record a copy-once programme onto a DVD disc that is not compatible with CPRM.

• You are trying to record onto the VR mode DVD-RW, DVD+RW/+R disc that is set as protected in “Setup” menu.

• You are trying to record onto the VR mode DVD-RW disc that has no space for recording.

• You are trying to record onto the DVD-RW/-R disc on which the number of recorded titles has reached the maximum (99).

• You are trying to record onto the VR mode DVD-RW disc on which the number of recorded chapters has reached the maximum (999).

• You are trying to record onto the DVD+RW/+R disc on which the number of recording titles comes up to the maximum (49).

• You are trying to record onto the DVD+RW disc on which the number of recording chapters comes up to the maximum (254).

• This disc has no space to write Control Information when recording or deleting contents.

• When editing has been repeatedly performed, the control information area may become full even though the recording area has enough space.

• When recordings are performed repeatedly onto an unstable disc, this area may become full.

• Every time you insert a disc for recording, part of the disc’s working area will be used. If you repeat this frequently, it will be used up quicker and you may not be able to record full 99 titles.

• You are trying to record onto a disc that is already finalised.

• You are trying to record onto the unfinalised +VR mode discs recorded on other unit.

* If you are still having trouble with the unit after checking all the Troubleshooting points, write down the error code

and the error description and consult your dealer or an authorised service centre.

• Insert a standard disc. (See pages 9 to

10.)

• Insert the disc with the labelled side facing up.

• Insert a DVD-Video with region codes 2 or ALL.

• Check the “Parental Lock” setting. (See page 78.)

• You cannot record copy prohibited programmes.

• Set “Format Mode” to “VR mode”. (See page 35.)

• Insert a recordable disc, and ensure the disc status satisfies the recording requirements. (See pages 34 to 35.)

• Clean the disc with a cleaning cloth.

• Replace the disc.

• Disc may need formatting.

• Insert a ver. 1.1 or ver. 1.2 DVD-RW disc (compatible with CPRM.)

• Remove the disc protect setting in “DVD Menu” menu. (See page 52.)

• Insert a recordable disc with enough recording space.

• Delete unnecessary original titles. (See page 70.)

• Delete unnecessary chapter marker from an Original list. (See page 71.)

• Delete unnecessary titles. (See page 70.)

• Delete unnecessary chapter marks. (See page 71.)

• Delete unnecessary original titles. (See page 70.)

• Insert a new disc.

• Release the finalising for the disc. (See pages 52 to 53.)

• Set “Make Recording Compatible” to “ON” to rewrite the menu, after that you will record to disc. (See page 36.)

Page 93

E9NG1BD_EN.book Page 93 Monday, April 7, 2008 5:54 PM

Language Code

Introduction Connections Basic Setup Playback

Language Code

Abkhazian 4748

Afar 4747

Afrikaans 4752

Albanian 6563

Amharic 4759

Arabic 4764

Armenian 5471

Assamese 4765

Aymara 4771

Azerbaijani 4772

Bashkir 4847

Basque 5167

Bengali;Bangla 4860

Bhutani 5072

Bihari 4854

Bislama 4855

Breton 4864

Bulgarian 4853

Burmese 5971

Language Code

French 5264

Frisian 5271

Galician 5358

Georgian 5747

German 5051

Greek 5158

Greenlandic 5758

Guarani 5360

Gujarati 5367

Hausa 5447

Hebrew 5569

Hindi 5455

Hungarian 5467

Icelandic 5565

Indonesian 5560

Interlingua 5547

Interlingue 5551

Inupiak 5557

Irish 5347

Language Code

Lithuanian 5866

Macedonian 5957

Malagasy 5953

Malay 5965

Malayalam 5958

Maltese 5966

Maori 5955

Marathi 5964

Moldavian 5961

Mongolian 5960

Nauru 6047

Nepali 6051

Norwegian 6061

Occitan 6149

Oriya 6164

Oromo (Afan) 6159

Panjabi 6247

Pashto; Pushto 6265

Persian 5247

Language Code

Sindhi 6550

Singhalese 6555

Siswat 6565

Slovak 6557

Slovenian 6558

Somali 6561

Spanish 5165

Sundanese 6567

Swahili 6569

Swedish 6568

Tagalog 6658

Tajik 6653

Tamil 6647

Tatar 6666

Telugu 6651

Thai 6654

Tibetan 4861

Tigrinya 6655

Tonga 6661

Recording

Byelorussian 4851

Cambodian 5759

Catalan 4947

Chinese 7254

Corsican 4961

Croatian 5464

Czech 4965

Danish 5047

Dutch 6058

English 5160

Esperanto 5161

Estonian 5166

Faroese 5261

Fiji 5256

Finnish 5255

Italian 5566

Japanese 5647

Javanese 5669

Kannada 5760

Kashmiri 5765

Kazakh 5757

Kinyarwanda 6469

Kirghiz 5771

Kirundi 6460

Korean 5761

Kurdish 5767

Laothian 5861

Latin 5847

Latvian; Lettish 5868

Lingala 5860

Polish 6258

Portuguese 6266

Quechua 6367

Rhaeto-Romance 6459

Romanian 6461

Russian 6467

Samoan 6559

Sangho 6553

Sanskrit 6547

Scots Gaelic 5350

Serbian 6564

Serbo-Croatian 6554

Sesotho 6566

Setswana 6660

Shona 6560

Tsonga 6665

Turkish 6664

Turkmen 6657

Twi 6669

Ukrainian 6757

Urdu 6764

Uzbek 6772

Vietnamese 6855

Volapuk 6861

Welsh 4971

Wolof 6961

Xhosa 7054

Yiddish 5655

Yoruba 7161

Zulu 7267

Editing

Function Setup

VCR Functions Others

Page 94

E9NG1BD_EN.book Page 94 Monday, April 7, 2008 5:54 PM

Glossary

Analogue audio

An electrical signal that directly represents sound. In contrast, digital audio can also be an electrical signal, but is an indirect representation of sound. See also “Digital audio”.

Aspect ratio

The width of a TV screen relative to its height. Conventional TVs are 4:3 (i.e., the screen is almost square). Widescreen models are 16:9 (the screen is almost twice as wide as its height).

Chapter

Just as a book is split up into several chapters, a title on a DVD disc is usually divided into chapters. See also “Title”.

Component video output

Each signal of luminance(Y) and component (P independent to output so that you can experience picture colour as it is intended to be. Also, due to compatibility with progressive video (576p/480p), you can experience higher-definition picture than that in interlace (576i/ 480i signal).

CPRM (Content Protection for Recordable Media)

CPRM is a scrambling copy protection system for the protection of “copy-once” broadcast programmes (e.g. some satellite broadcasts).

Digital audio

An indirect representation of sound using numbers. During recording, the sound is measured at discrete intervals (44,100 times a second for CD audio) by an analogue-to-digital converter, generating a stream of numbers. On playback, a digital-toanalogue converter generates an analogue signal based on these numbers. See also “Sampling frequency” and “Analogue audio”.

Dolby Digital

A system developed by Dolby Laboratories that compresses digital sound. It works with stereo (2ch) or multi-channel audio.

DTS (Digital Theater System)

DTS is a multi channel surround sound system. By connecting to DTS decoder, you can enjoy dynamic and realistic sound like movie theatre. DTS surround sound technologies were developed by DTS, Inc.

B/CB, PR/CR) is

Finalise

To make DVDs that have been recorded playable in DVD players. It is possible to finalise DVD-RW/-R and DVD+RW/+R discs with this unit.

HDMI (High Definition Multimedia Interface)

A digital interface between audio and video source. It can transmit component video, audio, and control signal with one cable connection.

INSTANT SKIP

This unit can skip TV commercials during DVD Video playback. Once [INSTANT SKIP] is pressed, the start point will be set forward 30 seconds and playback resume automatically. (You can press

[INSTANT SKIP] up to 6 times.)

JPEG (Joint Photographic Experts Group)

JPEG is a method of compressing still image files. You can copy JPEG files on CD-RW/-R discs from a computer and play back the files on this unit.

MP3 (MPEG Audio Layer 3)

MP3 is a method of compressing files. You can copy MP3 files on CD-RW/-R discs from a computer and play back the files on this unit.

PBC (Video CD only) (Playback Control)

This function enables you to play back interactive software using a menu screen. See also “Title”.

PCM (Pulse Code Modulation)

PCM is a format that converts audio into digital data. It is mainly used for Audio CDs and DAT. This unit can play back sounds as realistic as possible by converting even compressed Dolby Digital and MPEG audio to PCM.

Playlist

From this list, you can play back contents of a disc in your desired order or in sequence. It is also possible to directly search for a specific scene.

Progressive Scan (576p/480p)

A type of display that does not split each frame into fields, and instead scans directly through all the scanlines of each frame in order. Progressive Scan provides less flickering and higher image resolution than traditional (576i/ 480i) TV signals. Refer to pages 20 to 21 and 81 to 82 for instructions on the Progressive Scan mode selection.

Region code

Regions associate discs and players with particular areas of the world. This unit will only play back discs that have compatible region codes. You can find the region code of your unit by looking on the rear panel. Some discs are compatible with more than one region (or all regions).

Sampling frequency

The rate at which sound is measured by a specified interval to turn it into digital audio data. The number of samples in one second is defined as the sampling frequency. The higher the rate is, the better the possible sound quality.

Title (DVD)

A collection of chapters on a DVD. See also “Chapter”.

(Video CD)

The contents of a Video CD. When playing back a Video CD with the PBC function, the Title menu will appear automatically.

Track

Audio CDs and Video CDs use tracks to divide the contents of a disc. The DVD equivalent is called a chapter. See also “Chapter”.

Video mode

Video mode is the same recording format as used on the DVD-Videos you purchase in local shops. You can play back the discs recorded in this format in most DVD players, however it offers only limited editing. You will need to finalise discs recorded in Video mode before playing them back on other unit.

VR mode

A basic recording format for DVD-RW. VR mode offers advanced editing, and you can record and edit material repeatedly, however it is playable only on VR mode compatible unit. Finalisation is recommended before playing them back on other unit.

+VR mode

A recording format for DVD+RW/+R. +VR mode offers basic editing, and it is playable on most DVD players. Finalisation is recommended before playing them back in other unit.

Page 95

E9NG1BD_EN.book Page 95 Monday, April 7, 2008 5:54 PM

Specifications

General

VCR video heads Four heads

Power requirements 220–240 V ± 10%, 50 Hz ± 0.5%

Power consumption 35 W

Power consumption (standby) 5.0 W (When “FL Dimmer” is set to “OFF”: 3.3 W)

Weight 4.9 kg

Dimensions (width x height x depth) 435 x 99.5 x 388 mm

Operating temperature 5°C to 40°C

Operating humidity Less than 80% (no condensation)

TV system PAL-I

Recording

Recording format Video Recording (VR) format (DVD-RW only),

Recordable discs DVD-ReWritable, DVD-Recordable, DVD+ReWritable,

Video recording format

Sampling frequency Compression format

Audio recording format

Sampling frequency Compression format

Tun er

Receivable channels IRA-E69 (For analogue channels)

Input/Output

Front Panel : (AV3)

Video input Input level

Audio input Input level

DV input DV 4-pin jack

Rear Panel :

VHF/UHF antenna input/output terminal VHF/UHF set 75 Ω

Audio input /output Two 21-pin scart sockets (AV1, AV2)

Video input /output Input /output level

Component video output Output level

Audio output Output level

Digital audio output Output level

HDMI output HDMI jack

Video format (DVD-RW, DVD-R) +VR format (DVD+RW, DVD+R)

DVD+Recordable

13.5 MHz MPEG

48 kHz Dolby Digital

E21-E69 (For DVB-T channels)

One RCA connector 1Vp-p (75 Ω)

Two RCA connectors 2Vrms (input impedance: more than 10kΩ)

IEEE 1394

Two 21-pin scart sockets (AV1, AV2) 1Vp-p (75 Ω) each

Three RCA connectors Y: 1.0Vp-p (75 Ω)

B/CB, PR/CR: 0.7Vp-p (75 Ω) each

Two RCA connectors 2Vrms (output impedance: 680 Ω)

One Coaxial pin jack 500mVp-p (75 Ω)

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

VCR Functions Others

Note

The specifications and design of this product are subject to change without notice.

Page 96

E9NG1BD_EN.book Page 96 Monday, April 7, 2008 5:54 PM

Printed in China 1VMN25253 / E9NG1BD ★★★★★

Toshiba D-VR18DTKB Owner Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
