Ordering Information
All orders should specify quantity, model numbers, voltage, hinging (if applicable), shipping dates and ship-to address. Orders are to be placed with:
Toastmaster
5600 13th Street
Menominee, MI 49858
Phone |
(906)863-4401 |
|
Fax |
(906)863-5889 |
- Sales |
|
(906)863-6322 |
- Service |
Freight Terms
F.O.B. Menominee, MI with freight pre-paid and added to invoice. Free freight (within the 48 contiguous United States) is allowed on all orders that total $8,000.00 net price, if shipped at same time to same location. Weight may vary due to packing material.
Shortage and damage claims must be filed by consignee with the delivering carrier. The carrier must be notified of concealed damage by consignee immediately upon delivery. All discrepancies, shortages, overage, damage or damaged cartons should be indicated on carriers’ freight bills. Please save all cartons, crates and interior packaging until inspection has been made by delivering carrier.
Return Goods Policy
Prior authorization must be obtained to return equipment. Authorized returns for credit must be in the original case, undamaged and shipped pre-paid. Credit will be based upon invoice price less 35% restocking charge. Equipment returned without prior written authorization will be refused. Refurbishing, if necessary, will be an additional charge and will be deducted from any credit that may be allowed.
Telephone: 1-906-863-4401 |
1 |
www.toastmastercorp.com |
|
Warranty |
Warranty |
Warranty
This warranty is effective on all Toastmaster equipment sold on or after July 1, 2003, and supersedes all previous warranties.
Toastmaster warrants equipment that it manufactures to be free from defects in material and workmanship. Toastmaster’s obligation is limited to repairing or replacing, at Toastmaster’s option, without cost to the customer, any part found to be defective, as well as any labor or material expense required to replace the part.
Length of Warranty
This warranty is effective for a period of 18 months from the date of shipment from Toastmaster, or 12 months from the date of purchase by the end user, whichever is earlier.
Exceptions
•This warranty is valid only for the original end user owner/operator of the equipment.
•This warranty does not apply to normal maintenance functions, including (but not limited to) improper operation, installation or the use of an improper utility supply.
•This warranty is valid only if the equipment is used in a commercial setting.
The equipment is designed and constructed for commercial use by trained professionals only. Any use of the equipment in private or domestic applications immediately voids this warranty.
•This warranty does not apply to any parts, labor and material expenses for service that is not pre-approved and performed by a Toastmaster authorized service agent. Any such service immediately voids this warranty.
•This warranty does not apply to any parts, labor and material expenses associated with the installation of parts that are not factory-approved for use in the equipment. Any use of such parts immediately voids this warranty.
•This warranty is not valid if terms of payment have not been met.
•For warranty service on Pop-up toasters and light countertop equipment, an exchange program would supersede a service call. Please find Warranty Exchange Program’ authorization to follow.
Toastmaster reserves the right to change the design and specifications of this equipment or any related documentation at any time. The end user is not entitled to upgrades resulting from these changes.
This warranty is exclusive and supercedes all other warranties for the equipment, both expressed and implied. There are no implied warranties of merchantability or of fitness for a particular purpose.
The foregoing is Toastmaster’s sole and exclusive obligation and the end user sole and exclusive remedy for any action including breach of contract or negligence. In no event shall Toastmaster be liable for a sum in excess of the purchase price of the equipment, or for any prospective or lost profits of the end user.
Telephone: 1-906-863-4401 |
2 |
www.toastmastercorp.com |
|
Exchange Program |
Exchange Program |
WarrantyExchangeProgram
Contact Name:
Contact Phone Number: |
|
Store #: |
||||||
Store Address: |
|
|
|
|
|
|||
Model #: |
|
|
Voltage: |
|
||||
Serial #: |
|
|
Date of Purchase: |
|
||||
Ship To: |
|
|
|
|
|
Billing Address:
A reconditioned toaster will be shipped as a replacement. If a reconditioned unit is not available at the time of the request, Toastmaster will ship a new toaster.
NOTE: DO NOT DESTROY CARTON OF REPLACEMENT TOASTER
Place the defective unit in this carton. Contact Toastmaster Customer Service at 906-863-4401 or 800-338-9886, to schedule UPS pick-up.
I authorize my credit card to be charged for a replacement toaster if the original unit is not returned within 30 days.
Name as it appears on Credit Card:
Account #: |
|
|
|
|
|
Expiration: |
|
||||
Visa: |
|
|
MasterCard: |
|
American Express: |
|
|
||||
Signature: |
|
|
|
|
|
|
Date: |
|
Telephone: 1-906-863-4401 |
3 |
www.toastmastercorp.com |
|
Toasters |
Toasters |
Pop-up Toasters
Toastmaster’s commercial electronic pop-up food toasters are designed to toast bread, frozen waffles and many other foods consistently.
General Information: The bread and Texas Toast Toasters have either two or four toasting slots in the top. Each slot is 1-1/8” wide x 5-1/4” long. Each toasting chamber is equipped with oven guide wires and lowering rack.
The bagel and bun toasters have four extra wide slots in the top. Each slot is 1-3/4” wide x 5-1/4” long. Each chamber of the bagel and bun toasters provides one sided toasting only.
The combo toasters for bread and bagels contain 2 slots for bread or Texas toast, and 2 slots for one sided bagel and bun toasting.
Construction: All of the Toastmaster pop-up toasters are constructed of formed and welded sheet steel. Finish is brushed stainless steel with a mirrored finish on the front panel. A front pullout crumb tray is provided for easy cleaning.
Electrical: Each pop-up toaster is furnished with a 36” cord and NEMA plug, and operate on 1 phase only. (Please refer to corresponding unit chart for exact NEMA plug and electrical requirements.)
Heating: Insulated ceramic etched foil heaters are installed on one or both sides of each toasting chamber, depending upon the individual model.
Controls: Each two slot section is controlled by a lever operated mechanism. It is equipped with color selector knob coupled with solid state controls having temperature and voltage compensators. When operating lever is depressed, bread racks are lowered and elements are energized. At the end of the toasting cycle, elements are de-energized and bread racks are automatically raised.
Telephone: 1-906-863-4401 |
4 |
www.toastmastercorp.com |
|
Toasters |
Toasters |
BreadandTexas Toast Toasters
For two-sided toasting of breads, frozen waffles, Texas toast and English muffins
|
|
TP409/424/430 |
|
|
|
|
TP209/224 |
Models shown may ship UPS |
ID3CS |
|
|||
|
|
|||||
|
|
|
|
|
|
|
|
TWO SLOT |
|
FOUR SLOT |
|
||
Model Number |
TP209 |
TP224 |
TP409 |
TP4C09 |
TP424 |
TP430 |
Slots |
2 |
2 |
4 |
4 |
4 |
4 |
Slices per |
|
|
|
|
|
|
Hour |
150 |
150 |
250 |
250 |
250/300 |
250/300 |
Supply |
|
|
|
|
|
|
(1 phase) |
120 V |
208/240 V |
120 V |
120 V |
208/240 V |
208/240 V |
Current |
|
|
|
|
|
|
Draw |
9.0 A |
4.8/5.4 A |
18.3 A |
18.3 A |
9.6/10.8 A |
12.5 A |
Rated Heat |
|
|
|
|
|
|
Input |
1.1 KW |
1.0/1.3 KW |
2.2 KW |
2.2 KW |
2.0/2.6 KW |
2.6 KW |
Factory Installed |
|
|
|
|
|
(Canada) |
Cord & Plug |
NEMA 5-15P |
NEMA 6-15P |
NEMA 5-20P |
NEMA 5-30P |
NEMA 6-15P |
NEMA 6-20P |
Slot Width |
1-1/8” |
1-1/8” |
1-1/8” |
1-1/8” |
1-1/8” |
1-1/8” |
Slot Depth |
5-1/4” |
5-1/4” |
5-1/4” |
5-1/4” |
5-1/4” |
5-1/4” |
Width |
6-5/8” |
6-5/8” |
11-7/16” |
11-7/16” |
11-7/16” |
11-7/16” |
Depth |
13-3/8” |
13-3/8” |
13-3/8” |
13-3/8 |
13-3/8 |
13-3/8 |
|
|
|
|
|
|
|
Height |
9-3/16” |
9-3/16” |
9-3/16” |
9-3/16” |
9-3/16” |
9-3/16” |
Ship Weight |
12.3 lbs. |
12.3 lbs. |
21 lbs. |
21 lbs. |
21 lbs. |
21 lbs. |
Unit Price |
$839.00 |
$839.00 |
$1,131.00 |
$1,131.00 |
$1,131.00 |
$1,13100 |
|
|
|
|
|
|
|
ACCESSORIES
Model Number |
Description |
Weight |
Use With |
Dimensions |
Price |
|
Stainless stand |
|
All 4 slot bread |
11-7/8” W x |
|
ID3CS |
- Holds 2 |
|
or bun toaster |
9-7/16” H x |
|
Toasters |
5 lbs. |
models |
20-3/4” L |
$250.00 |
|
|
|
|
|
|
|
Telephone: 1-906-863-4401 |
5 |
www.toastmastercorp.com |
|
Toasters |
Toasters |
BagelandBunToasters
For fast one-sided toasting |
Model Number |
BTW09 |
BTW24 |
||
with extra wide slots |
Slots |
4 |
4 |
||
|
|
Slices per |
|
|
|
|
|
Hour |
250 |
250 |
|
|
|
Supply |
|
|
|
|
|
(1 phase) |
120 V |
208/240 V |
|
|
|
Current |
|
|
|
|
|
Draw |
15.0 A |
7.7/7.5 A |
|
|
|
Rated Heat |
|
|
|
|
|
Input |
1.8 KW |
1.6/1.8 KW |
|
|
|
Factory Installed |
|
|
|
|
|
Cord & Plug |
NEMA 5-20P |
NEMA 6-15P |
|
|
|
Slot Width |
1-5/8” |
1-5/8” |
|
|
|
Slot Depth |
5-1/4” |
5-1/4” |
|
|
|
Width |
11-7/16” |
11-7/16” |
|
BTW09 |
Depth |
13-3/8” |
13-3/8” |
||
|
|
||||
|
|
Height |
9-3/16” |
9-3/16” |
|
Models shown may ship UPS |
|
|
|
||
Ship Weight |
21 lbs. |
21 lbs. |
|||
|
|
||||
|
|
Unit Price |
$1,131.00 |
$1,131.00 |
|
|
|
|
|
|
ComboToastersfor Bread & Bagels
Two bread slots with twosided toasting PLUS two bagel/bun slots with one sided toasting
HT409
Models shown may ship UPS
Model Number |
HT409 |
HTC409 |
HT424 |
Slots |
4 |
4 |
4 |
Slices per |
|
|
|
Hour |
150/150 |
150/150 |
150/190 |
Supply |
|
|
|
(1 phase) |
120 V |
120 V |
208/240 V |
Current |
|
|
|
Draw |
16.6 A |
16.6 A |
8.0/9.2 A |
Rated Heat |
|
|
|
Input |
2.0 KW |
2.0 KW |
1.7/2.2 KW |
Factory Installed |
|
|
|
Cord & Plug |
NEMA 5-20P |
NEMA 5-30P |
NEMA 6-15P |
Slot Width |
1-1/8”/1-5/8” |
1-1/8”/1-5/8” |
1-1/8”/1-5/8” |
Slot Depth |
5-1/4” |
5-1/4” |
5-1/4” |
Width |
11-7/16” |
11-7/16” |
11-7/16” |
Depth |
13-3/8” |
13-3/8” |
13-3/8” |
Height |
9-3/16” |
9-3/16” |
9-3/16” |
|
|
|
|
Ship Weight |
21 lbs. |
21 lbs. |
21 lbs. |
Unit Price |
$1,131.00 |
$1,131.00 |
$1,131.00 |
|
|
|
|
Telephone: 1-906-863-4401 |
6 |
www.toastmastercorp.com |
|
Toasters |
Toasters |
Conveyor Toasters
Toastmaster’s commercial electronic conveyor toasters are designed to toast foods in large quantities consistently, using continuous feed methods.
General Information: The TC13 conveyors are designed specifically for breads and Texas Toast, with a chamber opening of 1-3/8” high, while the TC17 and TC21 units have a chamber opening height of 3”, providing the additional capability of toasting a broader variety of product including buns, bagels and muffins.
All Toastmaster conveyor toasters come equipped with a loading rack that is angled to feed the product into the toaster continuously. The unique air flow design keeps case, top and sides cool. Units are equipped with an auto cool-down feature which allows the fan to cool the outer skin when the unit is turned off.
Construction: Steel construction with a stainless steel finish is used for durability. Includes a stainless steel, slide out crumb tray for easy cleaning. Both the TC17 and TC21 models include a fiberglass return tray, while the TC13 models have this feature built in.
Electrical: The TC13 and TC17 models are available in 120V, 208V or 240V single phase, while the TC21 models are available in 208V or 240V single phase only. A factory installed 6 foot cord and plug is included. (Please refer to individual unit chart for exact NEMA plug and electrical requirements.)
Heating: When control is set to “ON”, top and bottom quartz infrared elements (TC13) or tubular elements (TC17 and TC21) will turn on to toast both sides of the bread. Lightness and darkness of product is achieved by adjusting the top and bottom heat controls (TC17 and TC21) or by adjusting the conveyor belt speed (TC13). Standby position allows for energy savings during non-peak periods.
Controls: Rotary 3 position dial selects ON/OFF/STANDBY positions. Heat dials control the upper and lower heating elements (TC17 and TC21) and a conveyor speed dial controls the conveyor speed.
Telephone: 1-906-863-4401 |
7 |
www.toastmastercorp.com |
|
Toasters |
Toasters |
MiniConveyorToasters
For toasting a variety of breads, buns, rolls
and bagels.
Standard Features:
•10” wide conveyor belt
•Automatic cool-down feature
•Energy-saving standby mode
•Stainless steel exterior construction
•Air-cooled case construction
•Single-piece stainless steel crumb tray
•Damage resistant calrod heating elements
•All models toast bread, buns and bagels
•Convection air dries product faster
•Large, easy-to-operate dial controls
•Separate upper and lower heat settings and conveyor belt speed
• High volume (250 slices per hour) |
TC13A3674 |
• Factory installed NEMA cord and plug |
|
Model Shown: |
Model Number |
TC13A3674 |
TC13A3663 |
TC13A3666 |
|
May ship UPS |
Product |
|
|
|
|
|
Delivery |
Front return |
Front return |
Front return |
|
|
Width |
14-7/32” |
14-7/32” |
14-7/32” |
|
Optional |
Depth (w/cord |
|
|
|
|
clearance) |
18-3/32” |
18-3/32” |
18-3/32” |
||
Stacking Kit |
Height w/4” Legs |
13-3/8” |
13-3/8” |
13-3/8” |
|
Available |
|||||
Toasting |
10-1/4” W x |
10-1/4” W x |
10-1/4” W x |
||
|
|||||
|
Chamber |
1-1/2” H x |
1-1/2” H x |
1-1/2” H x |
|
|
Dimensions |
12-3/4” L |
12-3/4” L |
12-3/4” L |
|
|
Loading Height |
1-3/8” |
1-3/8” |
1-3/8” |
|
|
Capacity |
250 |
250 |
250 |
|
|
(slices per hour) |
|
|
|
|
|
Supply (1 phase) |
120 V |
208 V |
240 V |
|
|
|
|
|
|
|
|
Current draw |
13.4 A |
5.5 A |
6.4 A |
|
|
Rated heat input |
1.6 KW |
1.1 KW |
1.5 KW |
|
|
|
|
|
|
|
|
Factory Installed |
|
|
|
|
|
Cord & Plug |
NEMA 5-20P |
NEMA 6-20P |
NEMA 6-20P |
|
|
Shipping Weight |
57 lbs. |
57 lbs. |
57 lbs. |
|
|
Unit Price |
$1,243.00 |
$1,243.00 |
$1,243.00 |
|
|
|
|
|
|
Telephone: 1-906-863-4401 |
8 |
www.toastmastercorp.com |
|
Toasters |
Toasters |
ConveyorToasters
Featuring a 3” loading height to accommodate a variety of product thicknesses
Standard Features:
•10” wide conveyor belt
•Automatic cool-down feature
•Energy-saving standby mode
•Stainless steel exterior construction
•Air-cooled case construction
•Single-piece stainless steel crumb tray
•Damage resistant calrod heating elements
•All models toast bread, buns and bagels
•Convection air dries product faster
•Large, easy-to-operate dial controls
•Separate upper and lower heat
•Settings and conveyor belt speed
•High volume (400 slices per hour)
•Factory installed NEMA cord and plug
Model Shown: |
|
|
|
|
|
May ship UPS |
|
TC17D3674 |
|
||
|
|
|
|
|
|
|
Model Number |
TC17D3674 |
TC17D3663 |
TC17D3666 |
TC17D3666UK |
|
Product |
Front or |
Front or |
Front or |
Front or |
|
Delivery |
rear exit |
rear exit |
rear exit |
rear exit |
|
Width |
14-5/8” |
14-5/8” |
14-5/8” |
14-5/8” |
|
Depth (w/cord |
|
|
|
|
|
clearance) |
24” |
24” |
24” |
24” |
|
Height w/4” Legs |
15-3/4” |
15-3/4” |
15-3/4” |
15-3/4” |
|
Toasting |
10-1/2” W x |
10-1/2” W x |
10-1/2” W x |
10-1/2” W x |
|
Chamber |
3” H x |
3” H x |
3” H x |
3” H x |
|
Dimensions |
17” L |
17” L |
17” L |
17” L |
|
Loading Height |
3” |
3” |
3” |
3” |
|
Capacity |
|
|
|
|
|
(slices per hour) |
400+ |
400+ |
400+ |
400+ |
|
Supply (1 phase) |
120 V |
208 V |
240 V |
240 V |
|
|
|
|
|
|
|
Current draw |
16.4 A |
12.6 A |
11.0 A |
11.0 A |
|
Rated heat input |
1.97 KW |
2.62 KW |
2.62 KW |
2.41 KW |
|
|
|
|
|
|
|
Factory Installed |
|
|
|
|
|
Cord & Plug |
NEMA 5-20P |
NEMA 6-20P |
NEMA 6-20P |
TYPE E |
|
Shipping Weight |
57 lbs. |
57 lbs. |
57 lbs. |
57 lbs. |
|
Unit Price |
$1,637.00 |
$1,881.00 |
$1,881.00 |
$1,898.00 |
|
|
|
|
|
|
Telephone: 1-906-863-4401 |
9 |
www.toastmastercorp.com |
|
Toasters |
Toasters |
ConveyorToasters
Featuring a 3” loading height to accommodate a variety of product thicknesses
Standard Features:
•10” wide conveyor belt
•Automatic cool-down feature
•Energy-saving standby mode
•Stainless steel exterior construction
•Air-cooled case construction
•Single-piece stainless steel crumb tray
•Damage resistant calrod heating elements
•All models toast bread, buns and bagels
•Convection air dries product faster
•Large, easy-to-operate dial controls
•Separate upper and lower heat
•Settings and conveyor belt speed
•High volume (900 slices per hour)
•Factory installed NEMA cord and plug
Model Shown: |
|
TC21D3666 |
|
|
May ship UPS |
|
|
||
|
|
|
||
|
|
|
|
|
|
Model Number |
TC21D3666 |
TC21D3663 |
TC21D3663UK |
|
Product |
front or |
front or |
front or |
|
Delivery |
rear exit |
rear exit |
rear exit |
|
Width |
14-5/8” |
14-5/8” |
14-5/8” |
|
Depth (w/cord |
|
|
|
|
clearance) |
27” |
27” |
27” |
|
Height w/4” Legs |
14-15/16” |
14-15/16” |
14-15/16” |
|
Toasting |
10-1/2” W x |
10-1/2” W x |
10-1/2” W x |
|
Chamber |
3” H x |
3” H x |
3” H x |
|
Dimensions |
21” L |
21” L |
21” L |
|
Loading Height |
3” |
3” |
3” |
|
Capacity |
900 |
900 |
900 |
|
(slices per hour) |
|
|
|
|
Supply (1 phase) |
240 V |
208 V |
208 V |
|
|
|
|
|
|
Current draw |
13.9 / 12.1 A |
11.7 A |
13.9 A |
|
Rated heat input |
2.9 KW |
2.9 KW |
2.9 KW |
|
|
|
|
|
|
Factory Installed |
6-20 P |
6-20 P |
TYPE E |
|
Cord & Plug |
NEMA |
NEMA |
NEMA |
|
Shipping Weight |
52 lbs. |
52 lbs. |
52 lbs. |
|
Unit Price |
$1,924.00 |
$1,924.00 |
$1,924.00 |
|
|
|
|
|
Telephone: 1-906-863-4401 |
10 |
www.toastmastercorp.com |
|
Hot Plates |
Hot Plates |
Hot Plates & Gas and Electric
Toastmaster’s countertop gas and electric hot plates are the most economical and flexible countertop hot plates in the food service industry. They offer unsurpassed performance, combining a proven control system with Toastmaster quality and durability.
General Information: The electric model is available with (2) 9” cooking plates, while the gas model is available in 3 different sizes - 12”, 24” and 36”.
Construction: Stainless steel front including top rail, with aluminized steel rear and sides. Gas units include full crumb tray for easy cleaning.
Electrical: The TECHP1132 is wired with combination voltage of 208/240 Volts, single phase. There is no electrical requirement on the gas units.
Gas: The TMDO gas units contain 2 burners per 12”. The TMDO12’s have a total of 2 burners, the TMDO24’s have a total of 4 burners, and the TMDO36’s have a total of 6 burners.
Heating: On the electric models, heating is accomplished with 9” solid round hotplate with element embedded in ceramic and permanently bonded to the plate.
In the gas units, each burner is controlled by independent control of flame. One standing pilot services each burner. A 3/4” rear connection is standard. Each burner is rated for 26,000 BTU/hr for natural gas and 22,000 BTU/hr for propane gas.
Controls: One front panel mounted control knob per burner or plate, to allow adjustable flame height or heat control.
Telephone: 1-906-863-4401 |
11 |
www.toastmastercorp.com |
|
Hot Plates |
Hot Plates |
CountertopGasHot Plates
Standard Features:
•2 adjustable burners per 12” cooking zone
•Removable heavy duty cast iron grates
•Natural gas or LP
Model Number |
TMDO1200 |
TMDO1200P |
TMDO2400 |
TMDO2400P |
TMDO3600 |
TMDO3600P |
Gas Type |
Natural |
LP |
Natural |
LP |
Natural |
LP |
Cook Zone |
|
|
|
|
|
|
Size |
12” |
12” |
24” |
24” |
36” |
36” |
BTU/hr |
40,000 |
40,000 |
80,000 |
80,000 |
120,000 |
120,000 |
Weight |
105 lbs. |
105 lbs. |
160 lbs. |
160 lbs. |
245 lbs. |
245 lbs. |
Dimensions |
12-1/4” W x |
12-1/4” W x |
24-3/8” W x |
24-3/8” W x |
36-1/2” W x |
36-1/2” W x |
|
12” H x |
12” H x |
12” H x |
12” H x |
12” H x |
12” H x |
|
27” L |
27” L |
27” L |
27” L |
27” L |
27” L |
Unit Price |
$783.00 |
$783.00 |
$1,276.00 |
$1,276.00 |
$1,834.00 |
$1,834.00 |
|
|
|
|
|
|
|
CountertopElectric Hot Plates
Standard Features: |
Model Number |
TECHP113272 |
||
|
|
|||
Supply |
208/240 V 1 Phase |
|||
• (2) 9” solid state plates |
||||
|
|
|||
• Infinite thermostat with six position settings |
Current |
208/1 - 21.7 |
||
• 208/240 Volts |
Draw (Amps) |
240/1 - 18.8 |
||
Total KW |
208 V - 3.9 |
|||
|
|
|||
|
|
|
240 V - 5.2 |
|
|
|
Incoming |
|
|
|
|
Supply AWG |
|
|
|
|
(min) |
1AW NAC |
|
|
|
Cook Zone Size |
(2) 9” Plates |
|
|
|
Weight |
40 lbs. |
|
|
|
Dimensions |
15” W x |
|
|
|
|
16-5/8” H x |
|
|
|
|
25” L |
|
|
|
Unit Price |
$890.00 |
|
|
|
|
|
|
TECHP113272 |
Model Shown: |
|
||
May ship UPS |
|
Telephone: 1-906-863-4401 |
12 |
www.toastmastercorp.com |
|
Charbroilers |
Charbroilers |
Charbroilers
Toastmaster’s countertop gas charbroilers are the most economical and flexible countertop charbroiler in the food service industry. They offer unsurpassed performance, combining a proven control system with Toastmaster quality and durability. Available in 3 different sizes - 24”, 36” and 48”.
General Information: Both standard radiant units and lava rock units are available in natural or LP gas configurations. Lava rock units include 1 bag of lava rock per 12” section.
Construction: Stainless steel front including top rail, with aluminized steel rear and sides. Full crumb tray for easy cleaning. Narrow grates have drain channels.
Electrical: None required.
Heating: U shaped burner is controlled by independent control of flame. One standing pilot services each burner. A 3/4” rear connection is standard. Area over burners is covered by stainless steel radiant. Each burner is rated for 35,000 BTU/hr for natural gas and 30,000 BTU/hr for propane gas. The TMDC units have one U shaped burner per 12” of charbroiler - The TMDC24’s have a total of 2 burners, the TMDC36’s have a total of 3 burners and the TMDC 48’s have a total of 4 burners. Dual branding cast iron grates are reversible, allowing for a 1/4” or 1/8” brand.
Controls: One front panel mounted control knob per burner, to allow adjustable flame height. One burner per 12” of charbroiler.
Telephone: 1-906-863-4401 |
13 |
www.toastmastercorp.com |
|
Charbroilers |
Charbroilers |
CountertopGasCharbroilers
Standard Features:
•Adjustable flame per 12” cooking zone
•Reversible double branding grates
•Natural gas or LP
TMDC2400
RadiantCharbroilers
Model Number |
TMDC2400 |
TMDC2400P |
TMDC3600 |
TMDC3600P |
TMDC4800 |
TMDC4800P |
Gas Type |
Natural |
LP |
Natural |
LP |
Natural |
LP |
Cook Zone |
|
|
|
|
|
|
Size |
24” |
24” |
36” |
36” |
48” |
48” |
BTU/hr |
60,000 |
60,000 |
90,000 |
90,000 |
120,000 |
120,000 |
Weight |
215 lbs. |
215 lbs. |
255 lbs. |
255 lbs. |
310 lbs. |
310 lbs. |
Dimensions |
24” W x |
24” W x |
36” W x |
36” W x |
48” W x |
48” W x |
|
16” H x |
16” H x |
16” H x |
16” H x |
16” H x |
16” H x |
|
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
Unit Price |
$1,754.00 |
$1,754.00 |
$2,376.00 |
$2,376.00 |
$3,266.00 |
$3,266.00 |
|
|
|
|
|
|
|
LavaRockCharbroilers
Model Number |
TMDCL2400 |
TMDCL2400P |
TMDCL3600 |
TMDCL3600P |
TMDCL4800 |
TMDCL4800P |
Gas Type |
Natural |
LP |
Natural |
LP |
Natural |
LP |
Cook Zone |
|
|
|
|
|
|
Size |
24” |
24” |
36” |
36” |
48” |
48” |
BTU/hr |
60,000 |
60,000 |
90,000 |
90,000 |
120,000 |
120,000 |
Weight |
235 lbs. |
235 lbs. |
285 lbs. |
285 lbs. |
340 lbs. |
340 lbs. |
Dimensions |
24” W x |
24” W x |
36” W x |
36” W x |
48” W x |
48” W x |
|
14” H x |
14” H x |
14” H x |
14” H x |
14” H x |
14” H x |
|
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
Unit Price |
$1,320.00 |
$1,320.00 |
$1,888.00 |
$1,888.00 |
$2,642.00 |
$2,642.00 |
|
|
|
|
|
|
|
Telephone: 1-906-863-4401 |
14 |
www.toastmastercorp.com |
|
Griddles |
Griddles |
Griddles - Gas and Electric
Toastmaster’s countertop gas and electric griddles are the most economical and flexible countertop griddles in the food service industry. They offer unsurpassed performance, combining a proven control system with Toastmaster quality and durability.
General Information: The Toastmaster gas and electric countertop griddles are available in 3 different widths - 24”, 36” and 48”.
Construction: Stainless steel front including top rail, with aluminized steel rear and sides, with 4” high rear and side splash guards and full width stainless steel grease trough and easy to access grease drawer. Gas units have 3/4” polished rolled steel plate, while the electric units have 1/2” thick polished rolled steel plate.
Electrical: The electric griddles are available in 208/240 Volts, single phase or 480 Volt 3 phase. There is no electrical requirement on the gas units.
Gas: The gas units have one U shaped burner per 12” of griddle. The TMDG24’s have a total of 2 burners, TMDG36’s have a total of 3 burners, and the TMDG48’s have a total of 4 burners.
Heating: The electric models contain tubular heating elements that are pressure clamped to the underside of the griddle surface. The heaters are designed to provide perimeter heat to assure even heating.
The U shaped burners in the gas units are controlled by independent control of flame. One standing pilot services each burner. A 3/4” rear connection is standard. Each burner is rated for 35,000 BTU/hr for natural gas and 30,000 BTU/hr for propane gas.
Controls: On gas units, one front panel mounted control knob per burner to allow adjustable flame height. On electric units, temperature is controlled by thermostat adjustable from 150 to 450O F.
Telephone: 1-906-863-4401 |
15 |
www.toastmastercorp.com |
|
Griddles-Gas |
Griddles-Gas |
CountertopGasGriddles
Standard Features:
•3/4” griddle plate
•Adjustable flame per 12” cooking zone
•Natural gas or LP
TMDG2400
Thermostatic
Model Number |
TMDG2400T |
TMDG2400TP |
TMDG3600T |
TMDG3600TP |
TMDG4800T |
TMDG4800TP |
Gas Type |
Natural |
LP |
Natural |
LP |
Natural |
LP |
Cook Zone |
|
|
|
|
|
|
Size |
24” |
24” |
36” |
36” |
48” |
48” |
BTU/hr |
40,000 |
40,000 |
60,000 |
60,000 |
80,000 |
80,000 |
Weight |
215 lbs. |
215 lbs. |
290 lbs. |
290 lbs. |
365 lbs. |
365 lbs. |
Dimensions |
24” W x |
24” W x |
36” W x |
36” W x |
48” W x |
48” W x |
|
14” H x |
14” H x |
14” H x |
14” H x |
14” H x |
14” H x |
|
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
Unit Price |
$2,209.00 |
$2,209.00 |
$3,109.00 |
$3,109.00 |
$3,194.00 |
$3,194.00 |
|
|
|
|
|
|
|
Manual
Model Number |
TMDG2400 |
TMDG2400P |
TMDG3600 |
TMDG3600P |
TMDG4800 |
TMDG4800P |
Gas Type |
Natural |
LP |
Natural |
LP |
Natural |
LP |
Cook Zone |
|
|
|
|
|
|
Size |
24” |
24” |
36” |
36” |
48” |
48” |
BTU/hr |
40,000 |
40,000 |
60,000 |
60,000 |
80,000 |
80,000 |
Weight |
215 lbs. |
215 lbs. |
290 lbs. |
290 lbs. |
365 lbs. |
365 lbs. |
Dimensions |
24” W x |
24” W x |
36” W x |
36” W x |
48” W x |
48” W x |
|
14” H x |
14” H x |
14” H x |
14” H x |
14” H x |
14” H x |
|
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
27-9/16” L |
Unit Price |
$1,283.00 |
$1,283.00 |
$1,835.00 |
$1,835.00 |
$2,569.00 |
$2,569.00 |
|
|
|
|
|
|
|
Telephone: 1-906-863-4401 |
16 |
www.toastmastercorp.com |
|
Griddles-Electric |
Griddles-Electric |
CountertopElectric Griddles
Standard Features:
•1/2” griddle plate
•Adjustable temperature control from 100-450OF
•Thermostat with positive “OFF” position
TECG732467
Model Number |
TECG732467 |
TECG732470 |
TECG733667 |
TECG733670 |
TECG734867 |
TECG734870 |
|
|
|
|
|
|
|
Supply |
480 V |
208/240 V |
480 V |
208/240 V |
480 V |
208/240 V |
|
3 Phase |
3 Phase |
3 Phase |
3 Phase |
3 Phase |
3 Phase |
Current |
480/3 - 31.01 |
208/3 - 32.6 |
480/3 - 22.4 |
208/3 - 39 |
480/3 - 31.01 |
208/3 - 54.1 |
Draw (Amps) |
480/1 - 21.7 |
240/3 - 37.5 |
480/1 - 34.2 |
240/3 - 44.9 |
480/1 - 44.8 |
240/3 - 62.2 |
|
|
208/1 - 37.6 |
|
208/1 - 59.2 |
|
208/1 - 77.9 |
|
|
240/1 - 43.3 |
|
240/1 - 68.5 |
|
240/1 - 89.7 |
Total KW |
10.4 |
208/3 - 7.8 |
16.4 |
208/3 - 12.3 |
21.5 |
208/3 - 16.2 |
|
|
240/3 - 10.4 |
|
240/3 - 16.4 |
|
240/3 - 21.5 |
|
|
208/1 - 7.8 |
|
208/1 - 12.3 |
|
208/1 - 16.2 |
|
|
208/1 - 10.4 |
|
208/1 - 16.4 |
|
208/1 - 21.5 |
Incoming |
480/3 - 12 |
208 V - 8 |
480/3 - 10 |
208/3 - 8 |
480/3 - 8 |
208/3 - 8 |
Supply AWG |
480/1 - 10 |
240 V - 8 |
480/1 - 8 |
240/3 - 6 |
480/1 - 8 |
240/3 - 8 |
(min) |
|
|
|
208/1 - 4 |
|
208/1 - 6 |
|
|
|
|
240/1 - 4 |
|
240/1 - 6 |
Cook Zone Size |
24” |
24” |
36” |
36” |
48” |
48” |
Weight |
162 lbs. |
162 lbs. |
230 lbs. |
230 lbs. |
340 lbs. |
340 lbs. |
Dimensions |
24” W x |
24” W x |
36” W x |
36” W x |
48” W x |
48” W x |
|
16-5/8” H x |
16-5/8” H x |
16-5/8” H x |
16-5/8” H x |
16-5/8” H x |
16-5/8” H x |
|
28-1/8” L |
28-1/8” L |
28-1/8” L |
28-1/8” L |
28-1/8” L |
28-1/8” L |
Unit Price |
$1,764.00 |
$1,764.00 |
$2,125.00 |
$2,125.00 |
$2,940.00 |
$2,940.00 |
|
|
|
|
|
|
|
Telephone: 1-906-863-4401 |
17 |
www.toastmastercorp.com |
|
Fryers |
Fryers |
Fryers - Gas and Electric
Toastmaster’s countertop gas and electric fryers are the most economical and flexible countertop fryers in the food service industry. They offer unsurpassed performance, combining a proven control system with Toastmaster quality and durability.
General Information: The Toastmaster gas and electric countertop fryers come complete with twin plated wire mesh baskets with coated heat resistant handles. Large cold zone is provided to capture food particles, which reduces flavor transfer and extends oil life.
Construction: Stainless steel. Baskets can be used on left or right hand side.
Electrical: The electric fryers are available in 208/240 Volts, single phase or 480 Volt 3 phase. There is no electrical requirement on the gas units.
Gas: Available in natural or LP gas. Each unit contains three burners with a total of 50,000 BTU/hr.
Heating: The electric fryers contain immersion type stainless steel tubular heating elements which swing up using the handle provided and burn clean pyrolytically in the raised position. The elements surround the sides, front, back and bottom of the shortening container.
The cast iron burners in the gas units are rated 16,660 BTU/hr.
Controls: Both gas and electric units contain high limit controls to automatically shut down if an overheated condition exists.
On gas units, controls include manual shut off, 100% safety shut off pilot gas valve, pilot adjustment and 175 - 375O F adjustable thermostat.
On electric units, shortening temperature is controlled by a thermostat from 250 - 400O F with positive OFF position.
Telephone: 1-906-863-4401 |
18 |
www.toastmastercorp.com |
|
