Telefunken TF-1633U User manual

PORTABLE RADIO RECEIVER /
ПОРТАТИВНЫЙ РАДИОПРИЁМНИК

TF-1633U

Instruction manual

Руководство по
эксплуатации

Instruction manual

Dear customer!

Thank you for purchasing our product. For safety, it is strongly recommended to read
this manual carefully before connecting, operating and/or adjusting the product and keep
the manual for reference in future.

Description

Top panel

1. USB port

2. ALARM button

3. SLEEP button

4. STOP/MEM-UP button

5. MEMORY button

6. VOLUME regulator

7. DISPLAY button

8. SKIP UP button

9. /MEM-DN button

10. SNOOZE/DIMMER
button

11. SKIP DN button

12. FUNCTION button

13. SET button

14. SD/MMC slot

USB

ALARMSLEEP MEMORY DISPLAY

SET

SD
MMC

STOP

MEM-UP

MEM-DN

SKIP DN SKIP UP FUNCTION

SNOOZE

Back panel

1. Battery compartment

2. AUX input

3. Power (DC6V) input

4. DISPLAY ON/OFF switch

Not indicated: display (front panel)

2

Instruction manual

Utilization of the product

If you want to dispose of this product, do not
mix it with general household waste. There is a
separate collection system for used electronic
products in accordance with legislation that
requires proper treatment, recovery and
recycling.

Please contact your local authorities for
the correct method of disposal. By doing so,
you will ensure that your disposed product
undergoes the necessary treatment, recovery
and recycling and thus prevent potential
negative effects on the environment and
human health.

Important safeguards

• The instruction manual contains important
operating and maintenance instructions. For
your safety, it is necessary to refer to the
manual. Keep the manual for use in future.

• Do not hit or drop the unit.

• Do not expose the unit to vibration, direct
sunlight, too high or low temperature or humidity.

• Do not disassemble the unit yourself.
Refer servicing to qualified service personnel.

• When the battery is exhausted, it should
be removed from the set to prevent leakage.

Additional power

• There are 2 extra AG13 batteries (1.5 V)
included with the receiver to be inserted to the
terminal inside the battery compartment. This
is additional power intended for saving the
clock and alarm settings. Without the additional
power the time and alarm settings will not be
stored if the power is switched off.

• When the batteries are exhausted they
should be replaced. New batteries should be
aquired by user. Replace the batteries only
with batteries of the same type.

ATTENTION: AG13 batteries are

consumables not covered by warranty, and
their failure (discharge) is not a ground for
addressing to service and repair centers

AC adaptor power

• Plug the supplied AC/DC power adaptor
into the power input on the back of the unit.
Connect the power cord to a household mains
outlet. Make sure the voltage is compatible.

• Always remember to disconnect the
power cord from the main supply before
disconnecting it from the unit.

• Disconnect the power cord from the mains
when not in use.

General operations

Power supply

Battery power

• Open the battery compartment cover.
Insert 4 x AA (1.5 V) batteries (not included).
Please observe correct battery polarities
or the unit will not work. Close the battery
compartment cover.

• When the batteries are exhausted, they
should be replaced.

• Do not use new and old batteries together.

Clock

• In clock mode press and hold SET button
to enable time setting mode. Press repeatedly
SET button to go to setting of parameters in
following sequence: 12/24 hours => hours =>
minutes => year => month => date => exit.
The selected parameter will blink meaning
readiness for adjustment.

• Press SKIP UP button to adjust the
parameter up. Press SKIP DN adjust the
parameter down.

• Day of week will be set automatically.

• In time setting mode, if no button is pressed
within 10 seconds after a parameter is selected,

3

Instruction manual

the unit will automatically go to clock mode.

• In time setting mode, press MODE button

twice to return to clock mode.

• Press DISPLAY button, year/month/date/
time will display cicrularly, press this button
repeatedly to return to clock mode.

AUX input

To connect an external audio device (e.g.
MP3-player), please use a standard stereo
cable with 3.5 mm to 3.5 mm plugs to connect
the audio line-out of the external device to the
AUX input socket of this unit.

LED display functions

• You can turn off the display by setting the
DISPLAY OFF/ON switch to “OFF“ position. In
this mode you can switch it on for 10 seconds
by pushing any button or by a loud sound (eg.
clapping your hands).

• The brightness of the display is set to
be half-bright during 21:00PM - 6:59:59AM.
Alternatively, press the SNOOZE button to
adjust brightness manually.

Radio operation

• In clock mode press the FUNCTION
button to select the radio mode.

• Press SKIP UP/SKIP DN buttons on the
unit to change the current frequency upwards
or downwards by 100 KHz. Press and hold
SKIP UP/SKIP DN buttons to search the
nearest strong signal station upwards or
downwards automatically.

• Press MEMORY button, P01 will blink on
the screen. Press repeatedly MEM-UP/MEM­DN buttons to select the position number for
the current frequency. Press MEMORY to save
the frequency in selected position (P01-P20).

• Press and hold the MEMORY button:
the device will start scanning from the lowest
frequency and automatically save all available
stations in positions (up to 20). When stations
are saved in the memory, repeatedly press
MEM-UP/MEM- DN buttons to select the saved
stations.

During program saving, if no button is
pressed within several seconds, the unit will
return to normal radio mode.

• To adjust volume, in radio mode turn the

VOLUME regulator.

• To switch off the radio, hold the FUNCTION

button.

USB/SD/MMC operation

Connecting USB/SD/MMC

• Insert a USB device into the USB port or
insert a memory card into the memory card
slot. Press FUNCTION button to enable USB/
SD/MMC mode. The unit will start reading the
device.

Playback operations

• During playback press (PLAY/PAUSE)
button to pause playback. Press this button
again to resume playback.

• During playback press SKIP UP/SKIP DN
buttons to go to previous or next track.

• To adjust volume, turn the VOLUME
regulator.

• In playback mode, press STOP to button
switch off the player and go to clock mode.

General USB/SD/MMC notes

• This unit is equipped with a USB socket
that can accept and play MP3 files stored on
standard USB flash (compatible with USB
version 2.0) up to 32 GB.

• This unit is also equipped with an SD/
MMC card socket that can accept and play
MP3 files stored on standard SD/MMC cards
up to 32 GB.

Always switch off the unit or change
mode to another one before removing a
USB flash drive or SD/MMC card, to prevent
damage to your USB device or memory card.

Note: Although this product is fully

compatible with USB 2.0 and SD/MMC card
standard formats, a small percentage of USB
flash drives and SD/MMC cards might not be
