Teac LCDV1950SD User Manual
WARRANTY REGISTRATION
Please read this warranty card.
Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service.
Warranty Terms & Conditions
1. TEAC warrants to the original retail purchaser only, that this product is free from defects in material and
workmanship under normal domestic use and authorises free service during the warranty period at any TEAC
Authorised Service Centre only. TEAC warranty only applies to products purchased, used and serviced in
Australia.
2. Subject to the terms herein, this warranty effectively covers the equipment as specified in the Warranty Periods
Table below from the date of purchase.
TEAC PRODUCT
WARRANTY PERIOD
Plasma TV 106 cm and above 1 Year (In-Home Service Available)
LCD Televisions 59cm and above 1 Year (In-Home Service Available)
Televisions – 59cm and above 1 Year (In-Home Service Available)
All Televisions under 59 cm 1 Year (No In-Home Service)
Digital Set Top Boxes & Module 1 Year (No In-Home Service)
VCR 1 Year (No In-Home Service)
DVD & Module 1 Year (No In-Home Service)
DVD Recorder & PVR Module 1 Year (No In-Home Service)
Audio Systems 1 Year (No In-Home Service)
3. In home service will only be provided as part of this warranty if all the following conditions are met;
a) The product as indicated in the Warranty Period Table.
b) The product is within the warranty period.
c) The product is located within the normal service area of the local TEAC Authorised Service Centre.
In any other situation or circumstance, where an in home service call is made, a service fee will be charged by the
Service Provider including a travel fee if outside normal service area.
If TEAC determines that the product is not repairable on site, TEAC can complete the repair by taking the product
to a TEAC Authorised Service Centre.
Where in-home service is not available, the purchaser is required to send the product to the nearest TEAC
Authorised Service Centre for repair. In this event, a copy of this warranty card and a copy of your receipt of
purchase must be enclosed to be a valid warranty. Such equipment or part must be sent freight prepaid to your
nearest TEAC Authorised Service Centre. After the repair, the product will be available for collection by or return to
the purchaser at purchaser’s cost. The warranty does not cover freight or insurance. In all cases of transit damage or
lost, a claim must be filed against the carrier by the purchaser, even if shipment is arranged by TEAC. TEAC inhome service may also be available at a fee upon request.
4. Accessories, Remote, including power adaptors, AV box, TV tuners, etc, are warranted to be defect free for 1 year.
5. Replacement of spare parts under normal usage; except cabinet, front panel, knob, removable accessories, battery,
consumable, AC cord, connecting cord and other accessories, are warranted as specified in Warranty Periods Table,
and will be repaired or replaced at the sole judgement of TEAC.
6. The warranties hereby conferred do not extend to, and exclude, any cost associated with the installation, de-
installation or re-installation of a product (be it in-home or otherwise), including costs related to the mounting,
demounting or remounting of any screen, (and any other ancillary activities), delivery, handling, freighting,
transportation or insurance of the product or any part thereof or replacement of and do not extend to, and exclude,
any damage or loss occurring by reason of, during, associated with, or related to such installation, de-installation,
re-installation or transit.
7. Normal customer maintenance as described in the owner’s manual is not covered by this warranty (such as cleaning
VCR heads etc.)
8. Service will be provided only during normal business hours and under safety conditions and circumstances.
9. This warranty does not apply to equipment showing abuse, damage or that it may have been tampered with, altered
or repaired outside any TEAC Authorised Service Centre. If so, the warranty will be void.
*Your nearest Authorised TEAC Service Centre is listed in your Owners Manual
10. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with
the sale of any equipment other than as stated in this warranty and outlined above.
11. In no event will TEAC be responsible or liable for indirect or consequential damages from interrupted operations or
other causes.
12. Warranty is not transferable to any subsequent purchaser if the product is sold during the warranty period,
* Extended promotional warranty may apply to certain products (for more info please contact: service@teac.com.au)
In home service administration fee is applied after 1
st
year of warranty.
WARRANTY PROCEDURES
Please keep this information for your own records.
Please refer to the owner’s manual to ensure that you have followed the correct installation and operating procedures.
1. Read owner’s manual carefully
2. If you require Warranty Service, please contact the TEAC Authorised Service Centre
3. Please have your purchase receipt as your proof of purchase and the following details completed for a valid
Warranty.
Owner’s Name
Owner’s Address
Postcode
Model Name/No. Serial No.
Dealer’s Name
Dealer’s Address
Postcode
4. Please ensure that your product is packed appropriately upon return to the service centre.
If you have any other queries regarding service or warranty please contact the TEAC Customer Care Centre below:
service@teac.com.au
www.teac.com.au
1800 656 700
Table Of Contents
Important Safety Instructions ............................................................................. 1
Disc Information................................................................................................... 3
Front Panel ...........................................................................................................5
Rear Panel ............................................................................................................6
Remote Control ....................................................................................................7
System Connections ......................................................................................... 12
Connecting Power Supply ...................................................................................................... 12
Connecting Earphone ........................................................................................................... 12
Connecting External AV Signal Source .................................................................................. 13
Connecting External AV Signal Source (YPbPr) ................................................................... 13
Connecting External AV Device (AV Output)………………………………………………………14
Connecting DVB-T Antenna…………………………………………………………………………14
Connecting PC ....................................................................................................................... 15
Connecting TV Antenna ........................................................................................................ .16
TV Function ........................................................................................................ 17
Preparations........................................................................................................................... 17
Image Setting ......................................................................................................................... 17
Audio Setting.......................................................................................................................... 20
Setup Setting.......................................................................................................................... 21
NICAM Function .................................................................................................24
DVD Playback Operation................................................................................... 25
USB and SD/MS/MMC Card Function............................................................... 30
DVD System Setup............................................................................................. 31
DVB System Setup............................................................................................. 38
Troubleshooting................................................................................................. 46
Specifications..................................................................................................... 47
1
Important Safety Instructions
CAUTION: USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION
1. The product contains a low-power laser device. In order to ensure the safety of the laser
device, do not remove any cover and attempt to repair the unit. If any service is needed,
please contact the distributor or its authorized service center.
2. To reduce the risk of electric shock, do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel. Unplug the
product from the wall outlet before servicing or when it is unused for a long period of time.
3. The manufacturer should not hold responsibility for the damage caused by any
substitutions and modifications of the product without authorization from the manufacturer
or authorized unit.
WARNING
The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
The images in this manual are only for reference and they may be different from the
actual ones.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of un-insulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric to persons.
The exclamation point within an equilateral triangle is intended to alert the use
r
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
CAUTION: Laser radiation when open. Do not stare into
beam.
2
Important Safety Instructions
NOTES
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus
near water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. Maintain well-ventilated conditions around the product. Do not put product on
bed, sofa or anything that blocks ventilation. Install according to the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Read, heed and follow all instructions to ensure correct and safe installation and
interconnection of the apparatus;
10. The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus;
11. The mains socket-outlet shall be installed near the apparatus and the mains plug shall
remain readily operable;
12. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
13. Only use attachments/accessories specified by the manufacturer.
14. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
15. Unplug the apparatus during lightning storms or when unused for long periods of time.
16. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
17. The apparatus shall be connected to a mains socket outlet with a protective earthing
connection.
Note: Do not touch the color TFT LCD screen by hand directly.
Copyright Protection
This product incorporates copyright protection technology that is protected by U.S. patents and
other intellectual property rights. Use of this copyright protection technology must be authorized by
Macrovision, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or disassembly is prohibited.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. DANGER: Visible laser radiation when open and
interlock failed or defeated. Avoid direct exposure to
beam.
3. CAUTION: Do not open the top cover. There are no
user serviceable parts inside the unit. Leave all
servicing to qualified service personnel.
3
Recommendation to Avoid or Minimize Phosphor Burn-in
Like all phosphor-based display devices and all TFT LCD Displays, LCD TV' s can be susceptible to
phosphor burn under certain circumstances. Certain operating conditions, such as the continuous
display of a static image over a prolonged period of time, can result in phosphor burn if proper
precautions are not taken. To protect your investment in this LCD TV, please adhere to the following
guidelines and recommendations for minimizing the occurrence of image burn.
1.Always enable and use your computer's screen-saver function during use with a computer input
source.
2.Display a moving image whenever possible.
3.Change the position of the menu display from time to time.
4.Always power down the LCD TV when you are finished using it.
5.Lower the brightness and contrast levels as much as possible without impairing image readability.
6.Display an image with many colour and colour gradations (i.e. photographic or photorealistic
images).
7.Create image content with minimal contrast between light and dark areas, for example white
characters on black backgrounds. Use complementary or pastel colors whenever possible.
8.Avoid displaying images with few colors and distinct, sharply defined borders between colors.
Burn-in is not covered by the warranty.
Cell Defect
The TFT LCD panel consists of fine cells. Although the panels are produced with more than
99.9percent active cells, there may be some cells that do not produce light or remain lit.
Warranty
Warranty does not cover any damage caused by image retention.
4
Disc Information
Discs Supported
DISC LOGO CONTENTS SIZE MAXIMUM TIME
133min(SS-SL)
242min(SS-DL)
266min(DS-SL)
DVD
Audio + Video
(Active picture)
12cm
484min(DS-DL)
CD
Audio 12cm 74min
JPEG
Still pictures with
high resolution
12cm
DIVX
Audio + Video
(Active picture)
12cm
Operating systems and features of individual DVD discs are specified by the software maker.
Please refer to the instructions accompanying the disc.
Disc Terms
Titles
A DVD disc is often divided into TITLES. A title can be a separate item or a segment of a film. On
many discs the ROOT menu and the TITLE menu are the same.
Chapters
Each TITLE is subdivided into CHAPTERS and each chapter is numbered for easy searching.
So by knowing the right command, you can play the whole disc, or any part of the disc.
Tracks
Picture and music CDs are divided into TRACKS. Each track is numbered for searching.
- 5 -
Front Panel
1. Color TFT screen
2. SOURCE button
Press to select mode among TV,
Composite, S-VIDEO, COMPONENT, VGA,
DVD and DVB.
On setup menu, the same function as
ENTER button.
3. MENU button
Press to enter or exit the setup menu.
4. CH
▲/▼ button
Press to select channels in TV mode; on
system setup menu, the same function as
▲/▼ direction buttons.
5. VOL
▲/▼ button
Press to decrease or increase the volume;
on system setup menu, the same function
as ◄/► direction buttons.
6. PLAY button
Press to play the disc in DVD mode.
7. ■ STOP button
Press to stop disc playback.
8. Eject button
Press to eject the disc out.
9. Power button
Press to enter or exit the standby mode.
10. SD/MS/MMC Card Port
Insert the SD, MS or MMC card into the
port.
11. Disc Tray Slot
Used to load disc.
12. Earphone Jack
When connected to earphone, the internal
speakers will automatically turn off.
13. USB Connecting Port
Connect the USB device.
14. Remote Sensor
15. Power Indicator
During work, it is blue;In standby mode, it
is red.
16. Speakers
- 6 -
Rear Panel
Jack Panel
Open the back cover on the right side of the unit’s rear panel, and you will see all jacks, as shown
below:
1. Y/Pb/Pr Input Jack
Connect the Y/Pb/Pr input in
COMPONENT mode.
2. Y/Pb/Pr L/R Audio Input Jack
Connect the L/R signal source in
COMPONENT mode.
3. Composite Audio/Video Output Jack
Output the Audio/Video signals in the
Composite mode.
4. L/R Audio Input Jacks (for COMPOSITE
and S-VIDEO)
Connect L/R audio signal source in
Composite or S-VIDEO mode.
5. VGA Input Jack
Connect VGA signal source.
6. DVB-T Input Jack
Input the DVB signal in the DVB mode.
7. PC AUDIO Input Jack
Connect VGA audio signal source.
8. TV Signal Input Jack
Connect TV aerial.
9. DC 12V Input Jack
Connect supplied adaptor.
- 7 -
Remote Control
For TV Operation
1. POWER button
Press to enter or exit standby mode.
2. TV button
Press to shift to TV mode.
3. PICTURE button
Press to shift the screen picture modes
among User, Standard, Soft, Bright and
Shine.
4. SOUND button
Press to shift the sound modes among
User, Standard, Music, Movie and
Speech.
5. 0~9 Number buttons
Press to select numbers such as TV
channel.
6. STEREO/AUDIO button
Press to change sound parameters when
receiving Nicam or A2 broadcasts in TV
mode.
7. VOL+/- button
Press to increase or decrease the volume.
8. MUTE button
Press to turn on or off speaker output.
9. EXIT button
Press to exit from the setup menu.
10. Direction buttons (▲▼◄►)
In the setup menu, press the ▲▼ button
to select a desired item and press the ◄►
button to adjust or set.
11. ENTER button
Press to confirm your selection.
12. SOURCE button
Press to select TV, Composite, S-VIDEO,
COMPONENT, VGA, DVD and DVB.
13. PC button
Press to shift to VGA mode.
14. DISPLAY button
Press to display the reference information
of the current program.
15. SET FAV button
Press to set the current channel as the
favorite channel.
16.
/+10 buttons
When in TV mode, press to select
numbers more than 10 or to return to the
channel previously viewed.
17. FAV button
Press to shift to the favorite channel.
18. SCAN/SUBTITLE button
When in TV mode, press to scan the
programs and press again to stop
scanning.
19. CH +/- button
When in TV mode, press to select
channel.
20. ASPECT button
Press to shift the aspect ratio of the
screen between Fill Screen and Normal
Aspect.
21. MENU button
Press to enter or exit the setup menu.
22. SLEEP button
This feature allows you to set up sleep
time when in TV mode. Press the button
repeatedly to select the desired sleep time
or “Off” to close this function.
23. GOTO button
Under TV mode, press to display the
realclock and press the EXIT button to
exit.
- 8 -
Remote Control
For DVD Operation
1. DVD button
Press to shift to DVD mode.
2. 0~9 Number buttons
Press to select numbers.
3. STEREO/AUDIO button
Press to select audio language or audio
track in DVD mode.
4. VOL+/- button
Press to increase or decrease the volume.
5. EXIT button
Press to exit from the setup menu.
6. Direction buttons (▲▼◄►)
In the setup menu, press the ▲▼ button to
select a desired item and press the ◄►
button to adjust or set.
7. ENTER button
Press to confirm your selection.
8. PLAY button
Press to play a disc when in the DVD
mode.
9. PAUSE button
When in DVD mode, press to pause
playback. Press the PLAY button to
resume normal playback.
10. / FB/FF button
Press to search backward or forward when
in DVD mode.
Under teletext mode, it’s the teletext color
button
11. TITLE button
When a DVD is playing, press the TITLE
button to go to the title menu and display
disc contents.
Under TV 、S-VIDEO or Composite mode,
press to display/close the teletext.
12. MENU button (under DVD mode)
Press to enter disc menu when in DVD
mode.
Under teletext mode, press to disable
teletext display and press again to resume.
13. SETUP button
Press to enter or exit setup menu in DVD
mode; press to display index page in
teletext mode.
14. SLOW button
Press to activate slow playback function
when in DVD mode.
Under teletext mode, press once to display
the concealed information, such as
solution of riddles or puzzles; press again
to resume the riddles information from the
display.
- 9 -
Remote Control
15.
/+10 buttons
When in DVD mode, press to select
numbers greater than 10.
16. SCAN/SUBTITLE button
When in DVD mode, press to select
alternate subtitle languages during
playback of a multiple language DVD disc.
17.
Eject button
Press to eject the disc from the unit.
18. ■ STOP button
Press to stop disc playback when in DVD
mode.
19. / PREV/NEXT button
Press to skip to the previous or next
chapter/track when in DVD mode.
Under teletext mode, it’s the teletext color
button.
20. REPEAT button
Press to repeat a chapter, track, title or all
program content when in DVD mode.
Under teletext mode, press to freeze the
current page and press again to resume.
21. ANGLE button
Press to select various camera angles (if
the DVD supports multiple camera angles)
when in DVD mode.
Under teletext mode, press the button first
time to double the size of teletext letters in
the upper half of the screen, second to
double the size of teletext letters in the
lower half of the screen and third to
resume normal status.
22. CARD button
Press to shift among disc playback, USB
playback and SD/MS/MMC playback.
Under teletext mode, press to select four
groups 3-digit numbers that displayed in
different colors at the bottom of the screen.
Press the color buttons on the remote
control to select, then use the number
buttons to input the corresponding number
to display the page.
Repeat the above procedures for each
page to be stored, using a different color
button accordingly each time.
23. GOTO button
Press to select the desired disc starting
time, title or chapter when in DVD mode.
- 10 -
Remote Control
For DVB Operation
1. DVB button
Press to shift to DVB mode.
2. SET FAV button
Press to set the current channel as the
favorite channel.
3. Direction buttons (▲▼◄►)
In the setup menu, press the ▲▼ button to
select a desired item and press the ◄►
button to adjust or set.
4. ENTER button
Press to confirm your selection.
5. FB（RED） button
In DVB mode, press the button to select
the red page.
6. FF（GREEN） button
In DVB mode, press the button to select
the green page.
7. EPG button
Press to display or close EPG（Electronic
Program Guide） in DVB mode.
8. FAV button
Press to shift to the favorite channel.
9. SETUP button
Press to enter or exit setup menu in DVB
mode.
10. EXIT button
Press to exit from the setup menu.
11. NEXT（BLUE）button
In DVB mode, press the button to select
the blue page.
12. PREV（YELLOW） button
In DVB mode, press the button to select
the yellow page.
13. INFO button
Press to display the current mode
information.
14. TVR button
Press to shift channels between TV and
Radio in DVB mode.
15. AUDIO button
Press to select audio language or audio
track in DVB mode.
16. TTX button
Press to display the teletext information in
DVB mode.
- 11 -
Remote Control
Preparation of Remote Control
Softly push the back cover to open the battery
compartment.
Insert two batteries (1.5V, size AAA), please
make sure the polarity matches the marks
inside the compartment.
Softly press the back cover to close it.
Under normal use the battery will last for
six months.
Take out battery when the remote is not in
use for a long time.
Using of Remote control
Point the remote control unit from no more than
about 7m from the remote control sensor and
within about 60 degrees of the front of the unit.
• The operating distance may vary
depending to the brightness around.
Notes:
• Do not point bright lights directly at the
remote control sensor.
• Do not place objects between the remote
control unit and the remote control sensor.
• Do not use this remote control unit while
simultaneously operating the remote
control unit of any other equipment.
- 12 -
System Connections
• Do not connect the power cord until all other connections have been made.
• Ensure that you observe the color cables when connecting audio and video cables.
• Before connecting, open the cover on the right side of the unit’s rear panel.
Connecting Power Supply
Power is supplied through the provided power adapter. Connect one end of the adaptor to the unit’s
power jack on the jack panel of the unit and the other end to the wall AC outlet.
Connecting Earphone
Connect earphone (headphone) to earphone jack on the rear panel of the unit for listening.
After connecting earphone, the internal speaker output will turn off automatically.
Note: Excessively loud volume could damage your hearing. So turn down the volume before
connecting earphone, and then raise the volume to comfortable level.
- 13 -
System Connections (Continued)
Connecting External AV Signal Source
Use the AV cables to connect external AV signal source to AV input jacks on the jack panel of the
unit. And use the S-VIDEO cable to connect external S-VIDEO signal source to the S-VIDEO input
jack on the rear panel of the unit.
After connection, turn on the unit and the external AV signal source and press the SOURCE button
to shift to Composite or S-VIDEO mode.
Note: The L/R audio input jacks can be used in the both Composite and S-VIDEO modes
Connecting External AV Signal Source（YPbPr）
Use the AV cables to connect external AV signal source to the Y/Pb (Cb) /Pr (Cr) input jacks on the
jack panel of the unit.
After connection, turn on the unit and external AV signal source and press the SOURCE button to
shift to COMPONENT mode.
Loading...
