HDB843
AUSTRALIA
Contents
Contents
Notice
Safety and Warning
MEPS Standard
What s in the box'
Main unit
Remote control key actions
Connections and preparation
Connecting to TV
Connecting to S-Video
Connecting to YPbPr
First Time Installation
Basic Operations
Switching On and Off
Changing Channels
Volume
Mute
Information Banner
Closed Caption
TV Screen Format
Channel Lists
Date and time
Switching between TV and Radio channels
EPG
Using the On-Screen Setup Menu
Favourite list
Add channels to a favourite list
Change the group name of a favourite list
Remove channels from a favourite list
Installation
Auto Scan
Manual Scan
System Info
Factory Reset
Channel Organizer
Edit the channel name
Delete the channel
Configuration
Audio & Video Setting
Region & Language
Time Zone Setting
Specification
Help and advice
1
2
3
5
5
6
7
9
9
10
11
12
13
13
13
13
13
14
14
14
15
15
15
16
17
18
18
18
18
19
19
21
21
21
22
22
22
23
23
24
24
25
26
Notice
Read this manual carefully and make sure you understand the provided instructions. For your
safety, know what the reaction upon each action will be.
Warnings, Cautions and Notes
Throughout the whole manual, pay special attention to the following marks that indicate
hazardous situations.
Warning
Indicates a hazardous situation which, if not avoided, could result in (serious) injury.
Caution
Indicates a situation which, if not avoided, could damage the equipment or other apparatus.
Note
Indicates additional information to the user to make the user aware of possible problems
and information of any importance to help the user to understand, to use and to maintain
the installation.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
To reduce the risk of electric shock, do not remove cover (or
back). No user serviceable parts inside. Refer servicing to
qualified service personnel.
This symbol indicates dangerous voltage inside the product
that presents a risk of electric shock or personal injury.
This symbol indicates important instructions accompanying the
product.
This product complies with Australia AS/NZS 4251.1 and
AS/NZS 4252.1 electromagnetic compatibility directives.
This product complies with Australia and New Zealand MEPS
Mark III standard
2
Safety and Warning
This digital terrestrial receiver has been manufactured to satisfy international safety
standards.Please read the following safety precautions carefully.
Safety Instructions and Precautions
1. MAINS SUPPLY
AC 100 ~ 240V 50/60Hz Max 1.0A
Operate your product only from the type of power source indicated on the marking
label. If you are not sure of the type of power supplied to your home, consult local
power company. Disconnect the receiver from the mains before you start any
maintenance or installation procedure.
2. OVERLOADING
Do not overload a wall outlet, extension cord or adapter as this may result in electric
fire or shock.
3. LIQUIDS
The receiver should not be exposed to any liquids such as dripping or splashing. In
addition, no objects filled with liquids, such as vase, shall be placed on the apparatus.
4. CLEANING
Disconnect the receiver from the wall outlet before cleaning. Use a light damp cloth
(no solvents) to dust the receiver.
5. VENTILATION
The slots on top of the receiver must be left uncovered to allow proper airflow to the
unit. Do not stand the receiver on soft furnishings or carpets. Do not stack electronic
equipments on top of the receiver.
6. ATTACHMENTS
Do not use any unsupported attachments as these may be hazardous or cause
damage the receiver.
7. CONNECTION TO THE AERIAL
Disconnect the receiver from the mains before connecting or disconnecting the cable
from the aerial. Failure to do so can damage the aerial.
8. CONNECTION TO THE TV
Disconnect the receiver from the mains before connecting or disconnecting the cable
from the aerial. Failure to do so can damage the TV.
9. EARTHING
The aerial cable must be buried in the ground. The buried cable of the system must
comply with SABS 061.
3
Safety and Warning
10.LOCATION
Place the receiver indoors to avoid exposing it to lightening, rain or sun. Do not place
it near a radiator or heat register.
Make sure it has more than 10 cm clearance from any appliances susceptible to
electromagnetic influences, such as TV and VCR.
Do not block these openings with any object, and do not place the product on a bed,
sofa, rug, or other similar surface.
If you place the product on a rack or bookcase, ensure that there is adequate
ventilation and that you have followed the manufacturer's instructions for mounting.
Do not place the product on an unstable cart, stand, tripod, bracket, or table where it
can fall.
A falling product can cause serious injury to a child or adult, and serious damage to
the appliance.
11.LIGHTNING, STORM, or NOT IN USE
Unplug the product from the wall outlet and disconnect the aerial during a lightning
storm or when left unattended and unused for long periods of time. This will prevent
damage to the unit due to lightning and power-line surges.
12.EXTRANEOUS OBJECTS
Do not insert anything through the openings in the unit, where they can touch
dangerous voltage point or damage parts.
13.REPLACEMENT of PARTS
When the replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the same
characteristics as the original part. Unauthorized substitutions may result in additional
damage to the unit.
Warning
1. Follow these directions in order not to damage the power cord or plug.
Do not modify or process the power cord or plug arbitrarily.
Do not bend or twist the power cord too much.
Make sure to disconnect the power cord with the plug held.
Keep heating appliances as far as possible from the power cord in order to prevent
the cover vinyl from melting.
2. Follow these directions. Failure to follow one of them may cause electrical shock.
Do not open the main body.
Do not insert metals or inflammable objects inside the product.
Do not touch the power plug with a wet hand.
Disconnect the power cord in case of lightening.
3. Do not use the product when it is out of order. If you continue to use the product
when defective, serious damage can be caused toit. Make sure to contact your local
product distributor if the product is out of order.
4
MEPS Standard
This equipment is compliant with MEPS standards of Australia and
New Zealand, which power consumption is less than 10 watt in active
mode and less than 1 watt in standby mode. It is a High Efficiency
Products - accords with Performance mark IV standard.
What s in the box'
You will find the following items.
The set-top box
1
2
A remote control
3
A user guide
4
Two AAA batteries
5
AV
Cable
The set-top box
HDVR843
SUBT TV/RADIO F
POWER
1
MUTEAUDIO
4
2
7
5
3
A
S
P
E
C
T
8
6
0
MENU
EPG INFO
9
EXIT
+V
OK
OLUME-
P+
P
-
A
V
TIME
User Guide
AAA Batteries
5
AV Cable
Remote Control
Main unit
Front panel
STANDBY
1
1
STANDBY Switches between standby on off
2
MENU Displays the main menu or go back to the previous menu
3
:,
OK Selects a menu or confirms the selected operation
4
:/
:,
:
To change channels up
MENU OK
2
4556677
3
High Definition Digital Receiver
:To change channels down
:
Volume down
:
Volume up
8
DISPLAY Display the channel number
:
15
Rear panel
8
YPbPr
HDMI
R
ANT OUT
ANT IN
1110
10
Tuner in Receive the signal from antenna:
11
Tuner out Support a share antenna output
12
HDMI High-Definition Multimedia Interface
13
.:
R L 2 channel audio output
14
CVBS Composite video output
//:
Y Pb Pr Component video output
-:-
S Video S Video output
OPTICAL Digital audio optical output
17
USB USB port for software upgrade
18
19
POWER SWITCH Power switch
:
:
:
:
:
12
:
L
13
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SHOCK HAZARD DO NOT OPEN
:
RISQUE CHOC NE PAS ENLEVER
:
SVIDEO-
CVBS
14
OPTICAL
USB
()For upgrade only
1615171618 19
6
AC90 240V
-
50Hz 60Hz
/
10W max
ON
OFF
Remote control key actions
Ref Key on remote. Action on the receiver
1
2
3
4
5
6
7
8
9
10
11
POWER
AUDIO
MUTE
NUMBER KEYS
ASPECT
()RECALL
EPG
INFO
MENU
EXIT
UP, DOWN,
LEFT, RIGHT
This key switches between operation and standby mode
This selects audio mode and audio languagekey
This turns on/off the volumekey
These s select channel numbers and you can also
use them to enter numbers and characters in menus
This switches between the last two channels you
were watching, and you can also use it to go back to the
previous menu
This opens the 7-day electronic programme guidekey
This key displays information about the channel you
are watching
This displays the main menu, and you can also
use it to go back to the previous menu as the RECALL
This exists from the main menukey
These keys move between items in a menu
key
This selects the screen formatkey
key
key
key
12
13
14
15
16
17
18
19
OK
+ VOLUME -
P+/ P-
SUBT
TV RADIO/
FAV
TIME
COLOUR KEYS
This selects an item in a menu, and you can also
key
use it to display the channel list
This adjust the volume up or downkey
These s change channels up (P+) or down (P-)key
This turns closed caption on / offkey
This switches between TV and Radio channelskey
This displays the favorite channel list menukey
This displayskey current data and time
These s are used to operate specific functions as
shown on some menu
key
7
Remote control key actions
11
13
POWER
Red
1
MUTEAUDIO
3
2
1
4
4
7
ASPECT
5
7
MENU
2
5
8
0
EPG INFO
9
OK
+VOLUME-
3
6
9
EXIT
P+
10
12
1
6
8
4
15
16
1
P-
18
SUBT TV/RADIO FAV TIME
Red
9
Green
HDB843
Yellow
Blue
17
1
9
8
Connections and preparation
Connecting to TV
Connect the three AV cable between the 'CVBS R L' or 'YPbPr' sockets on the STB
s
and the same sockets on your TV.You can do it follow the figure below.
8
Turn on the power switch in the back of the set-top box
ANTENNA
ANT IN
ANT OUT
HDMI
YPbPr
R
CVBS
L
SVIDEO
-
OPTICAL
()For upgrade only
SHOCK HAZARD DO NOT OPEN
RISQUE CHOC NE PAS ENLEVER
USB
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
:
:
AC90 240V
-
50Hz 60Hz
/
10W max
ON
OFF
TO AERIAL INPUT
SOCKET ON TV SET
S VIDEO-
VIDEO R AUDIO L--
9
Connections and preparation
Connecting to S-Video
ANTENNA
ANT IN
ANT OUT
YPbPr
HDMI
R
YPbPr
R
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SHOCK HAZARD DO NOT OPEN
:
RISQUE CHOC NE PAS ENLEVER
:
SVIDEO
-
CVBS
L
CVBS
L
S VIDEO-
OPTICAL
USB
()For upgrade only
AC90 240V
50Hz 60Hz
10W max
ON
/
OFF
VIDEO R AUDIO L--
10
Connections and preparation
Connecting to YPbPr
ANTENNA
ANT IN
ANT OUT
YPbPr
HDMI
R
YPbPr
R
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SHOCK HAZARD DO NOT OPEN
:
RISQUE CHOC NE PAS ENLEVER
:
SVIDEO
-
CVBS
L
CVBS
L
Y
Pb
Pr
OPTICAL
R AUDIO L--
USB
()For upgrade only
AC90 240V
50Hz 60Hz
10W max
ON
/
OFF
Best possible connections
The capabilities of your existing equipment, especially your TV, will determine your
connection possibilities. However, the following guidelines describe which options
provide the best picture and sound quality.
HDMI
:
provides best possible picture quality
Component YPbPr
S Video
-.
Composite ideo
Digital udio
-( )
red green blue cable
provides excellent picture quality
() .
V
A
a yellow video jack provides good picture quality
connections provide the clearest sound Connect to your Hi Fi System
for the best sound quality
If digital audio connections are not possible connect to red and white
Analog Audio
out jacks to the audio in jacks of your TV or Hi Fi System
and sound
provides best possible picture quality
.-
.
,
-.
11
First Time Installation
After all the connections have been made properly, turn on your TV and switch the TV to
the input that the set-top box is connected to. Make sure the receiver is connected to the
mains and turn on the power switch on the rear panel. If you are using the receiver for the first
time, you should do some settings first. Use the remote controller to finish the installation.
1
When the receiver is on, you can see the logo of “ ” first on the screen. After a
while the menu will be shown. Press the keys
you can choose the where you live. is . The
setting of is fixed to Australia and is fixed to .
First Time Installation LEFT / RIGHT
Time Zone The default Time Zone VIC
Country Menu Language English
TEAC
First Time Installation
Time zone
Country
Menu Language
OK
After you chose the Time Zone and press , then another menu will be shown
2
which allow user to set the , and .
Press the keys to choose.
LEFT/RIGHT
Screen TV format Video Output Screen definition
OK
key
VIC
Australia
English
First Time Installation
16 9 Full Screen
Screen TV format
HD Video Output
HD definition
OK EXIT RECALL
Press the key to start channel scan. Wait to complete the scanning. The channels
3
:
YPbPr
1080i
OK
already found will be stored.
Auto Scan
Scan Progress
Scanned Channel 6 Scanning:
TV Channels 4 Audio Channels 2
ABC HDTV ABC DIG Radio
ABC TV Melbou ABC DIG Jazz
ABC2
ABC TV
Signal Level
Signal Quality
When finished, all active channels found will be stored automatically. The first found
4
CH 35 586 MHz:
::
channel will be displayed.
12
TV 21 ABC2 SD MPEG 10 11［］［ ］ :
Engle Benjy Snow Fun
10 01 10 11
10 11 10 17 Ja5per The Penguin Wet Paine
:-:
:-: :
Basic Operations
Once channel search is completed, you can start to watch digital terrestrial TV channels
and radio broadcasts. Some typical operations are given in this chapter.
Switching On and Off
Whenever you are not using the receiver, press the key on remote control to put
it into standby mote, you also can press it to startup the receiver.
Changing Channels
You can change the current channel using one of the following methods.:
POWER
Press the keys to go to the previous/next channel.
Enter your desired channel numeric using the keys to move to the
channel directly.
Note:
1.You can switch channel using Program Guide or Channel List. Please refer to related
Chapters for more information.
2.If the channel number you have entered is not a stored channel, your TV will remain
in the original channel unchanged.
P+/P-
NUMERICAL (0-9)
Volume
Press the keys to adjust the volume.VOLUME+ /VOLUME-
Mute
Press the key to enable or disable the audio output.MUTE
13
Basic Operations
Information banner
Whenever you change channel, using the keys or the number keys, the receiver
displays the channel picture along with an information banner at the bottom of the screen. This
will remain on the screen for approximately three seconds. The information banner can also
be displayed at any time while watching TV by press the key on the remote control.
Press the key twice to display the detailed information of the current program while
playing; press key again will display the detailed information of the next program or
press the keys to switch between current program and next program; the
INFO
INFO
LEFT/RIGHT
information will disappear if you press the key or key again.
Program Info
10 11 10 17 Jasper The Penguin Wet Paint Children s G
:-: : ［ '］［
Not long ago Jasper lived at the South Pole One day he got
too close to the breaking ice cap Suddenly there was a large
crack and the drifted away into a world of adventure
TV 21 ABC2 SD MPEG 10 11［］［ ］ :
Jasper The Penguin WetPaont
10 11 10 17
10 17 10 29 Fireman Sam Chemistry Set
,.,
:-:
:-:
:
.
.
］
Closed Caption
P+/P-
INFO
EXIT INFO
You can press the key to turn on/off closed caption on the screen. The available
SUBT
closed caption depend on the broadcaster. The default language of closed caption is English.
In 1516 Francois I King of France,, ,
TV screen format
Press the key to change the TV screen format, including, 4:3 Full Screen, 4:3
Letter Box or 16:9 Full Screen. The function depends on the broadcaster. and your TV set. It's
recommended that you choose 16:9 Full Screen as default if your TV is wide screen format, or
4:3 Full Screen if your TV is standard-format.
ASPECT
4:3 Letter Box
4:3 Full Screen
14
Basic Operations
Channel lists
Press the or key to display the channel list, there are 8 different modes of the
OK LIST
channel list, including All Channel, TV, Radio and 5 favorite channel list. You can press
LEFT/RIGHT
keys to switch between these modes and press OK key again to confirm the
mode change, and the highlighted channel will be displayed. You can't change to a channel
list mode without any channel included.
All Channel
2 ABC TV Melbourne
20 ABC HDTV
21
ABC2
22
ABC TV
200 ABC DiG Radio
201 ABC DiG Jazz
801 SZTVM01
802 SZTVM02
Radio
200 ABC DiG Radio
201 ABC DiG JaZZ
2 ABC TV Melbourne
20 ABC HDTV
21
22
801 SZTVM01
802 SZTVM02
803 SZTVM03
805 Data
2 ABC TV Melbourne
20 ABC HDTV
21
22
ABC2
ABC TV
ABC2
ABC TV
TV
Fav1
Date and time
The time is displayed on the information banner with other information, and if you want to
see the date and time while you are watching a programme, press the TIME key, your TV will
display the current date and time in a panel on the right-top of the screen.
450 430/:
Switching between TV and Radio channels
Press key on your remote control to switch between TV channels and
Radio channels
Note:If you changed to TV/Radio channels, the channel list mode will also be changed.
/
TV RADIO
.
15
Basic Operations
EPG
As well as broadcasting TV and Radio programmes, some broadcasters also send
information about current and future programmes such as : programme titles, show times and a
brief descriptions of what the programme is about. This set-top box displays this information on
the Electronic Program Guide (EPG).
The set-top box provides two EPG display options. They are called 'Now&Next' and '7 Day'.
In 'Now&Next' mode, the EPG page will contain the information about the current and the
next program, while in '7 Day' mode you can see information about the channels for the next
seven days (depending on the broadcaster)
The default mode is '7 Day', you can press MENU key to switch between these two modes.
Program Guide
2 ABC TV Melbo TV
Romantic tale based on Shakespeare s
Taming of the Shrew following the courtship
between a surly teenager and a
All Services
2 ABC TV Melbourn
20 ABC HDTV
21 ABC2
22 ABC TV
200 ABC DiG Radio
201 ABC DiG Jazz
,
10 01 10 15 We Are From France
10 15 10 29 We Are From Sweden
OK EXIT MENU
'
...
7 Day Guide Wed 00 00 03 00:-:
:-: :-: -
Change Day Day Time Time+- + -
Program Guide
2 ABC TV Melbo TV
Sean crosses the line with a volatile Paul Dev
decides to spruce himself up Tracet disregards
advice and refuses to change her plea
All Services
2 ABC TV Melbourn
20 ABC HDTV
21 ABC2
22 ABC TV
200 ABC DiG Radio
201 ABC DiG Jazz
OK EXIT MENU
.
.
.
Now Next Wed/
01 15 Coronation Street
:
01 45 10 Things I Hate about You
:
Change
To view EPG in 7 Day mode:
1
Press the key to display the Program Guide menu.
Press keys to switch between channel list on the right and the program list
2
EPG
LEFT/RIGHT
on the left.
The program information received are organized into 8 pages a day, and each page
3
contains program information in 3 hours, you can press key to view the program
information in the next 3 hours or key to the previous 3 hours.
4
5
BLUE YELLOW
Press key to the next day, while Pressing key to the previous day.
UP/DOWN
Press keys to navigate the lists, the details of the highlighted program will be
RED
GREEN
shown on the top.
6
Press the or key to exit the Program Guide menu.
EXIT EPG
Note:
1.In 7 Day mode, if there is nothing found in the page of a specific 3 hours,
maybe you can find it in the previous pages because the duration of some
program may last more than 3 hours.
2.In Now&Next mode, the keys are useless.
COLOUR
16
Using the On-Screen Setup Menu
The receiver features an on-screen menu providing access to a variety of setup and
management controls. Use the remote control to navigate through the menu and activate
required settings.
When you are in the set-up mode of the main menu, Press the key if you
want to go back the previous menu . If you press key you will eventually close the main
EXIT
menu.
Main Menu
Favourite List
OK EXIT
How to display the Main Menu:
Press the key.MENU
Your TV will display the main menu.
The following options are available:
or MENU
i. Favourite lists
ii. Installation
iii. Guide
iv. Channel Organizer
v. Configuration
Press the keys to navigate the itemsRIGHT/LEFT
Press the key to select the item you have selected. Or you can close the main menu
by pressing the key.
OK
EXIT
Note:
1. When your TV displays the main menu or any sub menus, the volume control
will not work.
2. There is a brief description in the bottom of the menu page indicating which
keys can be used in this menu.
17
Favourite list
Press the Menu key on the remote control to enter the Main Menu, choose the Favourite
list option and press key, then you can enter the Favourite Lists menu. Press the or
MENU EXIT
key you can return to the Main Menu, or press the key to leave.
Favourite list function let you to:
Add channels to a favourite list
1
Change the group name of a favourite list
2
3
Remove channels from a favourite list
Add channels to a favourite list
There are five existing favourite groups with default name as FAV1 to FAV5, in this function
you can add channels to any of these favourite lists. After entering the Favourite List menu,
you must select the first and press keys to highlight list,
then press keys to select the channel and press key to add the selected
channel to this favourite group.
Favourite List
Fav Group Channel Name All Channel
Fav1 ABC TV Melbou ABC TV Melbou
Fav2 ABC HDTV ABC HDTV
Fav3 ABC2 ABC2
Fav4 ABC TV ABC TV
Fav5 ABC DiG Radio
UP/DOWN BLUE
EXIT RECALL
OK
Fav Group RIGHT/LEFT All Channel
ABC DiG Jazz
sztvm01
Add Edit Del
Change the group name of a favourite list
In this function you can change the name of favourite group as you like. Make sure you
have highlighted the list and press key to edit the name of the favourite
Fav Group GREEN
group you choose. An Edit dialog will pop up and you can press 0~9 keys to input the
numbers and characters. Press key to confirm and save the modification while key
OK EXIT
will cancel the modification and back to Favourite List menu.
Favourite List
Fav Group Channel Name All Channel
Fav1 ABC TV Melbou
Fav2 ABC HDTV
Fav3 ABC2
Fav4 ABC TV
Fav5 ABC DiG Radio
OK EXIT RECALL
Edit
Edit Fav Group Name
BKN
ABC DiG Jazz
sztvm01
Remove channels from a favourite list
In this function you can remove channels from the favourite list which you don't need it.
You must press keys to highlight the list first and press
UP/DOWN
then press key to remove it.
RED
RIGHT/LEFT Channel Name
keys to choose the channel which you don't want to remain in this favourite list,
18
Installation
Press the key on the remote control to enter the Main Menu, choose the
Installation option and press key. Then you can press the keys on the remote
MENU
OK UP/DOWN
control to select a submenu. Press the key you can return to the Main Menu, or press
the key to leave, and then the changes have been done will be stored. Here is some
EXIT
information about submenu.
The Installation function let you to:
1
Auto Scan
Manual Scan
2
System Info
3
Factory Reset
4
How to select the functions listed above in the Installation function page:
Select 'Installation' in the 'Main Menu'.
1
Press the keys until the item you want is highlighted.
2
Press the key.
3
UP/DOWN
OK
Auto Scan
If your receiver is connected to the aerial and TV, you can automatically scan channels
without entering any other information.
Before starting the scan, a box asking you to confirm what you want to do will appear.
Press the key, and the set-top box will begin to search through channel 6 in VHF to
OK
channel 69 in UHF, and the TV and Radio channels it finds will be listed separately on the
page.
If you choose EXIT, you will go back to the Installation menu page.
Auto Scan
Scan Progress
Warning
Scanned Channel 6 Scanning:
In Auto Scan all the channels
TV Channels 4 Audio Channels 2
stored before and private
ABC HDTV ABC DIG Radio
ABC TV Melbou ABC DIG Jazz
settings will be cleared please
ABC2
confirm to start
ABC TV
Signal Level
Signal Quality
CH 35 586 MHz:
::
,
,
.
OK EXIT
Auto Scan
Scan Progress
Scanned Channel 6 Scanning:
TV Channels 4 Audio Channels 2
ABC HDTV ABC DIG Radio
ABC TV Melbou ABC DIG Jazz
ABC2
ABC TV
Signal Level
Signal Quality
CH 35 586 MHz:
::
Note: In this function all channel information stored before such as favourite settings
will be removed.
19
Installation
If the set-top box couldn't find any channels, your TV screen will display the picture as
below. You can press key to try to search for channels again or press key to quite the
Auto Scan menu page.
If your TV displays this message when you have tried to search for channels again,
please turn to the help and advice page.
OK EXIT
Auto Scan
Scan Progress
TV Channel 6 Scanning:
Signal Level
Signal Quality
CH 35 586 MHz:
Scan Failed
Scan failed Would you like to try
!
again
?
OK EXIT
Otherwise, please wait for a while until all the findings are stored in its memory in the order
of the logical channel numbers (LCN), then the Auto Scan page will close and the set-top box
will tune the TV to the first programme in the list and display it.
Auto Scan
Scan Progress
Scanned Channel 6 Scanning:
Signal Level
Signal Quality
CH 35 586 MHz:
Sorting the Channel
Sorting and saving channel
information please wait
, ...
TV 21 ABC2 SD MPEG 10 11［］［ ］ :
Engle Benjy Snow Fun
10 01 10 11
10 11 10 17 Ja5per The Penguin Wet Paint
:-:
:-: :
20
Manual Scan
You can use this function when you know the ' channel number ' of the channel you want
to find. Press keys until the desired channel number is selected, when changing
channel number, the appropriate frequency value is also changed below. And you can see the
signal level and signal quality in the bottom.
Manual Scan
Channel
Frequency
Bandwidth
Scan
TV Channels Audio Channels::
Signal Level
Signal Quality
RIGHT/LEFT
22
482000
8MHz
Stopped
EXIT RECALL
Press keys to highlight the Scan item, then press keys to start
UP/DOWN RIGHT/LEFT
the scan. After scan is completed, you can see the channels newly searched and the first
channel will be displayed in the small window. If no new channels are found, a warning
message will appear.
Manual Scan
Channel
Frequency
Bandwidth
Scan
TV Channels Audio Channels::
Signal Level
Signal Quality
36
585500
7MHz
Scanning
Start
Start the scan please wait, ...
OK EXIT
EXIT RECALL
Manual Scan
Channel
Frequency
Bandwidth
Scan
TV Channels 4 Audio Channels 0::
SZTVM01
SZTVM02
SZTVM03
Data
Signal Level
Signal Quality
52
722000
8MHz
Stopped
EXIT RECALL
System Info
In System Info page you can check the information about the version of software and
hardware
System Info
.
Press key to go back the previous menu while key to quit.
Hardware Version
Manufactured by
Software Stack
Software Version
:
KhznTek-08-11-26
:
COMIVISION
:
MAGNET_CORE
:
RELEASE-20090224-b90
EXIT
Factory Reset
Factory Reset
All private settings and other
user data will be erased Do you
want to proceed.?
Factory Reset
In the Factory Reset you can reset the unit back to 'First Time Installation'.
Note: Once you perform Factory Reset, all data such as Channel List, and User
Configured data will be cleared.
OK EXIT
21
Channel Organizer
Press the key on the remote control to enter the Main Menu, choose the Channel
Organizer option and press key. Then you can see the page list all channel names the
MENU
OK ,
related content provider and the channel number. The Channel Organizer function lets you
Edit the channel name
1
Delete the channel
2
Edit the channel name
You can rename a channel with up to 14 different characters or numbers (this includes
spaces) in the name. You can enter more than 14 characters for the new name but only first
14 characters will be stored and the list will only display the first 10.
Channel Organiser
LCN SeviceName Network CH
2 ABC TV M ABC 8
20 ABC HDTV ABC 8
21 ABC2 ABC 8
22 ABC TV ABC 8
200 ABC DiG R ABC 8
201 ABC DiG Ja ABC 8
801 SZTVM01 Harmonic 25
802 SZTVM02 Harmonic 25
803 SZTVM03 Harmonic 25
OK EXIT RECALL
NOTE:
How to input characters using NUMBER keys
NUM 0: 0
NUM 1: 1
NUM 2: A, B, C, 2
NUM 3: D, E, F, 3
NUM 4: G, H, I, 4
Edit
Edit Channel Name
NUM 5: J, K, L, 5
NUM 6: M, N, O, 6
NUM 7: P, Q, R, S, 7
NUM 8: T, U, V, 8
NUM 9: W, X, Y, Z, 9
Delete the channel
Press key when you highlight the channel you want to delete, a warning dialog box
will pop up, press key to confirm the delete while key to cancel the operation.
Channel Organiser
LCN SeviceName Network CH
2 ABC TV M ABC 8
20 ABC HDTV ABC 8
21 ABC2 ABC 8
22 ABC TV ABC 8
200 ABC DiG R ABC 8
201 ABC DiG Ja ABC 8
801 SZTVM01 Harmonic 25
802 SZTVM02 Harmonic 25
803 SZTVM03 Harmonic 25
RED
OK EXIT RECALL
OK EXIT
Warning
Are you sure to
delete the channel!?
OK EXIT
22
Configuration
Press the key on the remote control to enter the Main Menu,choose the
Configuration option and press key. Then you can press the keys on the
MENU
OK UP/DOWN
remote control to select a submenu. Press the key you can return to the Main Menu, or
press the key to leave, and then the changes have been done will be stored. Here is
some information about submenu.
EXIT
Configuration
The configuarion function let you choose to:
1
Audio & Video
Region & Lang.
2
Time Zone Setting
3
OK EXIT RECALL
How to select the functions listed above in the Installation function page:
1
Select 'Configuration' in the 'Main Menu'.
2
Press the keys until the item you want is highlighted.
3
Press the key.
UP/DOWN
OK
Audio & Video Setting
Enter the submenu. You can see the set information about audio
and video:
OSD Transparency.
Audio Video Setting&
Audio & Video Setting
Screen TV format, Screen definition, Audio output, HD video, SD video and
Screen TV format
Screen definition
Audio output
HD Video
S
D Video
OSD Transparency
EXIT RECALL
Screen TV type have three options: 4:3 Full Screen, 4:3 Letter Box or 16:9 Full Screen.
You can change the Screen TV type by pressing keys.
LEFT/RIGHT
HD definition have two options: 720p and 1080i. You can change the definition by pressing
LEFT/RIGHT
keys.
Audio output have three options: Stereo, Left and Right. You can change the Audio output
channels by pressing keys.
HD video is fixed as YPbPr
LEFT/RIGHT
.
SD video output is fixed as CVBS and S-Video.
OSD transparency have six options: 0%, 10%, 20%,30%,40% and 50%, the default is
30% transparent. You can change the TV output signal by pressing keys.
LEFT/RIGHT
23
Configuration
Region & Language
Enter the Region & Language page via The Region & Language Setting
function let you choose the region where you live the country is fixed to Australia and
the Menu Language is fixed to English
You can press keys to change the region
Region & Language
Region
Country
Menu Language
/.LEFT RIGHT
VIC
Australia
English
Configuration
,
,
,
Time Zone Setting
Enter the Time Zone Setting page via Configuration Menu. The Time Zone Setting
function let you choose to:
Mode
1
Time Zone Adjust
2
Daylight Saving
3
How to select the functions listed above in the Parental Setting function page:
Select in the menu.
1
Press the keys until the item you want is highlighted.
2
Press keys to change the setting.
3
Note:
1.The default Mode is Automatic, it will get the time zone setting automatically from
2.If you want to change the time zone and daylight saving mode manually, you
Time Zone Setting Configuration
UP/DOWN
LEFT/RIGHT
the broadcaster. In this mode you can't access to Time Zone Adjust and Daylight
Saving.
should first set the Mode to Manual.
24
Specification
General
Size 280x190x45mm
Weight 1 4
Power consumption
System
Processor STI7710 32bit 200 Mhz
Flash memory 4Mbyte
DDR 64Mbyte
Reception
Frequency range
Signal level
Transmission standards
Demodulation
FEC
Audio Video Output
Output mode
Video
Audio
Connections
RF IN
RF OUT
HDMI High-Definition Multimedia Interface
YPbPr
.
RL
CVBS
-
S VIDEO
OPTICAL
USB
Kg
.
10W max
VHF Band III 177500 226500 KHz
UHF Band IV
UHF Band V
82 3dBm
-.
DVB T MPEG 2
COFDM with 2K 8K FFT mode
All DVB modes
PAL43169
@/
MP ML
MPEG Layer I II AC 3 Dolby Digital
Receive the signal from antenna
Support a share antenna output loop through
Component video output
2 channel audio output
Composite video output
-
S Video output
Digital audio optical output
USB port for software upgrade only
.
-, -
,:/ :
MP HL
@
@
-
522500 578500 KHz
585500 816500 KHz
/
&, -
-
-
()
25
Help and advice
If you have difficulties using your set-top box and none of the suggestions below work, try
switching your set-top box off, and then on again. If this does not work, contact the shop you
bought your set-top box from or a qualified repair technician. Never try to repair your set-top
box yourself.
Problem Possible cause What to do
Standby light not lit
No signal found
No picture or sound
Scrambled channel
message
No response to remote
control
The remote control
will not operate your
receiver
After moving the
receiver to another
room you findyou are
no longer able to
receive the digital
reception
Mains lead unplugged
Mains fuse blown
Aerial is disconnected
Aerial is damaged misaligned
Out of digital signal area
Tuned to digital teletext channel
Channel is scrambled
Receiver off
Handset not aimed correctly
Front panel obstructed
Handset batteries exhausted
1 The batteries in your remote
.
control need replacing
2 There is an obstruction
.
blocking the signal path
between the remote control
and the receiver
he aerial feed from new point
T
may come through a distribution
system which may reduce the
digital signal
/
level to the receiver
Check mains lead
Check fuse
Check aerial lead
Check aerial
Check with dealer
Retune to another channel
Select alternative channel
Plug in and turn on receiver
Aim handset at front panel
Check for obstructions
Replace handset batteries
1 Replace the batteries
.
2 Check that there is nothing
.
blocking
the remote control and the
receiver
Try a direct feed from the
a
ntenna
the path between
26
TEAC CUSTOMER CARE CENTRE (TCCC)
Free call: 1800 656 700
Between Monday to Friday EST 9AM to 5PM
Loading...
