MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
155-921304-00-13 HANDSET ASS'Y FOR R/C:9213 SGS IC 47P.
CAB:TEAC DESIGN 9213 CT-M341MKII RC-616
180-9313T0-28-22 NON-COMMON PART ASS'Y PAL/BG W/AV IN RCA
JACK {SGS IC} 47 PROG.
180-9313T0-28-CP COMMON PART ASS'Y (PAL/BG W/AV IN)
NEW SGS 3 CHIP IC "FOR TEAC"
1/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
155-921304-00-13 HANDSET ASS'Y FOR R/C:9213 SGS IC 47P.
CAB:TEAC DESIGN 9213 CT-M341MKII RC-616
107-800455-46 455K HZ RESONATOR "KYOCERA" 1
X701
113-100005-17 CARBON FILM RESISTOR 10 OHM 1/16W +-5% 1
R701
113-103005-17 CARBON FILM RESISTOR 10K OHM 1/16W +-5% 1
R703
113-229005-17 CARBON FILM RESISTOR 2.2 OHM 1/16W +-5% 1
R702
113-330005-17 CARBON FILM RESISTOR 33 OHM 1/16W +-5% 1
R704
123-101350-60 CERAMIC CAP. 100 PF 50V +-10% (SL TYPE) "SMART 2
GOOD"
C702,703
127-476042-03 ELECT. CAP. 47 MFD 16V +-20% 1
C701
130-134148-01 SILICON DIODE IN4148 2
D701,702
130-600101-00 INFRARED EMITTER EL-1L1 KODENSHI 1
LED 701
131-210719-29 TRANSISTOR 2SA719R/S MATSUSHITA 1
Q702
131-230945-00 TRANSISTOR 2SC945 NEC 1
Q701
133-830041-31 IC M3004LAB1 (SGS) 1
IC701
172-626010-42 UL 1007 TOP COAT WIRE AWG 26 100MM RED 10 X 10MM 1
FOR REMOTE P.C.B. `+' TO BATTERY CONTACT PLATE `+'
172-626012-40 UL 1007 TOP COAT WIRE AWG 26 120MM BLACK 10 X 10 1
MM
FOR REMOTE P.C.B. `-' TO BATTERY CONTACT PLATE `-'
172-726000-99 BARE WIRE 54MM 0
W701,702
190-921306-02 REMOTE P.C.B. 1
514-260410-00 SELF-TAPPING SCREW 2.6 X 10 B/T (HARDEN) {BLACK} 1
CAB. MTG.
774-931301-00 BATTERY SPRING (+-) 1
774-931302-00 BATTERY SPRING (+) 1
774-931303-00 BATTERY SPRING (-) 1
810-041104-13 POLYBAG 4" X 11" X 0.04MM W/RE-CYCLING MARK 1
FOR HANDSET
849-921302-00 CONTACT RUBBER KEY PAD (24 KEYS) 1
892-921302-04 DIAL KEY PLATE - ENG STD (24 KEYS) "47 PROG." 1
910-921301-01 BATTERY DOOR (3A) 1
964-921301-01 SENSOR LENS 1
900-921311-73 HANDSET TOP CAB. - TEAC DESIGN 9213 (CT-M341MKII 1
RC-616)
900-921341-73 HANDSET TOP CAB. - TEAC DESIGN 9213 (CT-M341MKII 0
RC-616)
902-921311-01 HANDSET BOTTOM CAB. - BLACK MOULDED (3A) 1
902-921341-01 HANDSET BOTTOM CAB. - BLACK MOULDED (3A) 0
2/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
180-9313T0-28-22 NON-COMMON PART ASS'Y PAL/BG W/AVACK {SGS IC} 47
PROG.
002-114022-40 14" CRT #37SX110Y22-DC05A S/H CAI HONG 1
003-131414-02 TUNER (OSCAR ) UVE33-W14 MITSUMI (HIGH JACK) 1
TUNER
107-738900-07 SAW FILTER TOSHIBA (F1044PS) 1
SA101
160-102255-27 PIN CONNECTOR 2 PINS PLUG STRAIGHT (UL) (S.H.S) 1
CN202
162-110010-00 ANTENNA MATCHING TRANSFORMER (300 OHM TO 75 OHM) 1
166-162030-00 SPEAKER 3" 2W 16 OHM "TCL" 1
171-550084-D0 84" AC LINE CORD W/SAA APP. 10A 250V 1
172-726000-99 BARE WIRE 54MM 0
W158,104
179-105000-00 UL PVC TUBE 5mm DIA 0
400MM FOR CN202
186-624500-11 HI-WATT SUPER HEAVY DUTY 1.5V 0% MERCURY 3A ER03X 2
ALUM.CASE
191-201017-07 2 PIN SOCKET ASS'Y L=460MM (PIN 1 RED, PIN 2 1
BLACK)
CN202 `1' TO SPK. `+', `2' TO SPK. `-'
191-400042-07 4 PINS SOCKET ASS'Y AWG 20 420 MM 1
514-400408-10 SELF-TAPPING SCREW 4 X 8 B/T (HARDEN) 2
FOR SWIVEL STAND
515-303408-10 SELF-TAPPING SCREW 3 X 8 W/B/T (HARDEN) 1
FOR FRONT CAB. TO FRONT PANEL
610-931301-53 GIFT BOX - TEAC (A) DESIGN (CT-M341MKII) 1
663-230458-98 SERIAL NO.LABEL - OC:GT-458/98 0
663-230464-98 SERIAL NO.LABEL - OC:GT-464/98 0
663-230517-98 SERIAL NO.LABEL - OC:GT-517/98 2
1PC STUCK ON RATING LABEL, 1PC STUCK ON CARTON
669-881301-4N RATING LABEL - TEAC (A) DESIGN {CT-M341MKII} 1
{220V}
670-931300-1B INSTRUCTION MANUAL - TEAC (C) DESIGN {CT-M341MKII} 1
{47P.}
678-931301-16 CB NUMBER LABEL {I} - TEAC DESIGN (CT-M341TXT) 2
LARGE SIZE
2PC STUCK ON EACH CTN
678-931306-07 SCREEN STICKER - TEAC DSEIGN (CT-M341MKII) 1
TO TOP RIGHT OF THE SCREEN
678-931314-05 EASY TUNE CARD (B) - TEAC (B) DESIGN 1
678-931315-07 TOTAL CARE LAEBL - TEAC (B) DESIGN 1
1PC STUCK ON BACK CABINET
690-942039-02 WARRANTY CARD -TEAC (C) DESIGN 1
693-931301-08 EAN CODE LABEL - 9313060007775 1
737-154510-00 METAL WASHER 2
FOR SWIVEL STAND
782-721952-10 DOUBLE ROD ANTENNA 5 SECTIONS 850MM "TIMPOLAR" 1
800-931305-00 POLYFOAM (1) 1
800-931306-00 POLYFOAM (2) 1
800-931307-00 POLYFORM (3) 1
800-931308-00 POLYFOAM (4) 1
3/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
810-052204-14 POLYBAG 5" X 22" X 0.04MM W/RE-CYCLING MARK {P/O 1
MAT}
FOR AC LINE CORD
810-091504-13 POLYBAG 9" X 15" X 0.04MM W/ RE-CYCLING P.E.MARK 1
FOR I/MANUAL
810-303004-61 POLYBAG 30"X30"X0.04MM W/PUNCH TEAC DESIGN 1
(CT-M341 TXT)
FOR UNIT
826-221505-00 FOAM SHEET 22" X 15" X 0.5MM 1
FOR UNIT
830-931301-02 STAND RUBBER FOOT (GREY) 4
FOR SWIVEL STAND
884-881303-01 JACK PLATE - W/AV IN/WHITE SS 1
884-931314-02 PRESET PLATE - TEAC DEISGN 1
889-931302-00 COVER PLATE (PAL) 1
889-931304-00 COVER PLATE - W/O BAND SW. AND TACT SW. HOLE 1
FOR REAR CAB.
900-931301-10 FRONT CABINET (A) - METALLIC GREY (8403C) SPRAYED 1
902-931306-U5 REAR CAB.-METALLIC GREY{8403C} W/SINGLE SPEAKER 1
{HIPS UL94V0}
917-931301-00 REMOTE LENS (A-A) TRANSLUCENT RED 1
919-931302-33 P/DOOR-TEAC DESIGN CT-M341MKII METALLIC GREY 1
{8403C}
930-931302-14 FRONT PANEL (A-B) (PAL) - TEAC DESIGN METALLIC 1
GREY (8403C)
959-931301-04 SWIBEL STAND - ABS METALLIC GREY {8403C} 1
986-931301-06 NAME PLATE - TEAC DESIGN 1
991-931301-05 POWER KNOB (A-A) - METALLIC GREY {8403C} 1
4/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
180-9313T0-28-CP COMMON PART ASS'Y (PAL/BG W/AV IN)
NEW SGS 3 CHIP IC "FOR TEAC"
001-214189-05 FLYBACK TRANSFORMER 154-189H GOLDSTAR "FOR CAIHONG 1
CRT"
T402
008-550151-05 DEGAUSSING COIL 40T (W/FIVE LAYERS OF TAPE) 1
L903
012-102340-06 SEMI-FIXED RESISTOR EVND8AA 03B13 1KB 1
VR901
012-103340-06 SEMI-FIXED RESISTOR EVND8AA 03B14 10KB 2
VR101,404
012-201340-06 SEMI-FIXED RESISTOR EVND8AA 03B22 200B 1
VR405
012-202340-06 SEMI-FIXED RESISTOR EVND8AA 03B23 2KB 1
VR302
012-204340-06 SEMI-FIXED RESISTOR EVND8AA 03B25 200KB 1
VR401
012-301330-06 SEMI-FIXED RESISTOR EVND2AA 03B32 300B 2
VR503,505
012-501340-06 SEMI-FIXED RESISTOR EVND 8AA 03B52 500B 1
VR402
012-502330-06 SEMI-FIXED RESISTOR EVND2AA 03B53 5KB 3
VR501,502,504
012-502340-06 SEMI-FIXED RESISTOR EVND8AA 03B53 5KB 1
VR307
012-503340-06 SEMI-FIXED RESISTOR EVND8AA 03B54 50KB 1
VR303
013-100004-00 GLASS DELAY LINE ENF-650A11-0 WEI HAW 1
DLY302
013-200005-00 Y-DELAY LINE YBL50F18X 1
DLY301
101-191009-96 HORIZONTAL DRIVE TRANSFORMER (R1009) 1
T401
101-288820-95 LINE FILTER 70MH 1
L901
101-414214-94 SWITCHING POWER TRANSFORMER HL4025B (HIGHLIGHT) 1
T901
102-370600-02 TANK COIL / AFC COIL COILS 707851 2
T103,101
102-670100-02 SOUND IF COILS 707532 1
T102
102-770200-02 SECAM COLOR PAL DELAY LINE MATCHING COILS 707850 1
T301
105-100103-08 FIXED INDUCTOR COIL 10 UH +-10% AXIAL 1
L105
105-101103-08 FIXED INDUCTIVE COIL 100UH +-10% (WITTIS) 1
L501
105-109103-08 FIXED INDUCTIVE COIL 1.0UH +-10% (WITTIS) 2
L102,109
105-150102-06 LINEARITY COIL 15UH FOR 29" RCA CRT 1
L402
105-150103-08 FIXED INDUCTOR COIL 15 UH +-5% AXIAL 2
L401,104
5/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
105-180103-08 FIXED INDUCTIVE COIL 18 UH 1
L302
105-201106-02 CHOKE COIL 200UH 10% CH9012- 201K (ELEC PRODUCT) 1
L903
105-270103-08 FIXED INDUCTIVE COIL 27UH 1
L601
105-689103-08 FIXED INDUCTOR COIL 6.8 UH +-10% AXIAL 1
L301
105-828103-08 FIXED INDUCTIVE COIL 0.82 UH +-10% AXIAL 1
L101
107-105500-66 SOUND TRAP CERAMIC FILTER 5.5MHZ WEI HAW 1
CF102
107-305500-16 SOUND BYPASS CERAMIC FILTER 5.5MHZ WEI HAW 1
CF101
107-808000-66 RESONATOR 8MHZ 1
X601
113-101105-17 CARBON FILM RESISTOR 100 OHM 1/4W +-5% 4
R314,316,318,438
113-101205-12 CARBON FILM RESISTOR 100 OHM 1/2W +-5% 1
R649
113-102105-17 CARBON FILM RESISTOR 1K OHM 1/4W +-5% 0
R140,134,114,432,669,326,004,006,009,329
113-102305-75 METAL OXIDE FILM RESISTOR 1K OHM 1W +-5% 1
R411
113-103105-17 CARBON FILM RESISTOR 10K OHM 1/4W +-5% 9
R418,908,204,650,309,129,130,122,622
113-103105-17 CARBON FILM RESISTOR 10K OHM 1/4W +-5% 0
R104,120,118,640,617,005,013,010,012,108
113-103105-17 CARBON FILM RESISTOR 10K OHM 1/4W +-5% 3
R109,110,623
113-104105-17 CARBON FILM RESISTOR 100K OHM 1/4W +-5% 7
R422,642,634,119,681,682,CF103
113-104205-12 CARBON FILM RESISTOR 100K OHM 1/2W +-5% 1
R923
113-104305-75 METAL OXIDE FILM RESISTOR 100K OHM 1W +-5% 1
R921
113-109205-12 CARBON FILM RESISTOR 1 OHM 1/2W +-5% 1
R410
113-120305-75 METAL OXIDE FILM RESISTOR 12 OHM 1W +-5% 1
R911
113-120405-75 METAL OXIDE FILM RESISTOR 12 OHM 2W +-5% 1
R920
113-120505-75 METAL OXIDE FILM RESISTOR 12 OHM 3W +-5% 1
R414
113-121105-17 CARBON FILM RESISTOR 120 OHM 1/4W +-5% 1
R648
113-122105-17 CARBON FILM RESISTOR 1.2K OHM 1/4W +-5% 3
R407,665,303
113-123105-17 CARBON FILM RESISTOR 12K OHM 1/4W +-5% 4
R436,441,327,306
113-124105-17 CARBON FILM RESISTOR 120K OHM 1/4W +-5% 1
R451
6/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
113-129405-42 FUSING RESISTOR 1.2 OHM 2W +-5% 1
R501
113-151105-17 CARBON FILM RESISTOR 150 OHM 1/4W +-5% 4
R307,116,017,001
113-152105-17 CARBON FILM RESISTOR 1.5K OHM 1/4W +-5% 3
R419,310,304
113-153105-17 CARBON FILM RESISTOR 15K OHM 1/4W +-5% 4
R302,014,320,321
113-153405-75 METAL OXIDE FILM RESISTOR 15K OHM 2W +-5% 3
R510,511,505
113-182105-17 CARBON FILM RESISTOR 1.8K OHM 1/4W +-5% 3
R907,312,126
113-183105-17 CARBON FILM RESISTOR 18K OHM 1/4W +-5% 2
R657,313
113-184105-17 CARBON FILM RESISTOR 180K OHM 1/4W +-5% 2
R618,658
113-184205-12 CARBON FILM RESISTOR 180K OHM 1/2W +-5% 1
R415
113-202105-17 CARBON FILM RESISTOR 2K OHM 1/4W +-5% 1
R328
113-202605-75 METAL OXIDE FILM RESISTOR 2K OHM 5W +-5% 1
R413
113-203105-17 CARBON FILM RESISTOR 20K OHM 1/4W +-5% 1
R325
113-221105-17 CARBON FILM RESISTOR 220 OHM 1/4W +-5% 3
R423,117,666
113-221205-12 CARBON FILM RESISTOR 220 OHM 1/2W +-5% 1
R406
113-222105-17 CARBON FILM RESISTOR 2.2K OHM 1/4W +-5% 8
R206,513,509,507,514,515,516,008
113-222205-12 CARBON FILM RESISTOR 2.2K OHM 1/2W +-5% 1
R405
113-223105-17 CARBON FILM RESISTOR 22K OHM 1/4W +-5% 2
R435,137
113-224105-17 CARBON FILM RESISTOR 220K OHM 1/4W +-5% 3
R207,408,107
113-225105-17 CARBON FILM RESISTOR 2.2M OHM 1/4W +-5% 1
R324
113-229105-17 CARBON FILM RESISTOR 2.2 OHM 1/4W +-5% 2
R208,404
113-229405-75 METAL OXIDE FILM RESISTOR 2.2 OHM 2W +-5% 2
R902,201
113-270105-17 CARBON FILM RESISTOR 27 OHM 1/4W +-5% 1
R115
113-270405-75 METAL OXIDE FILM RESISTOR 27 OHM 2W +-5% 1
R912
113-272105-17 CARBON FILM RESISTOR 2.7K OHM 1/4W +-5% 8
R319,317,315,426,662,663,664,638
113-272205-12 CARBON FILM RESISTOR 2.7K OHM 1/2W +-5% 5
R922,412,503,502,504
113-273101-67 METAL FILM RESISTOR 27K OHM 1/4W +-1% 1
R151
7/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
113-273105-17 CARBON FILM RESISTOR 27K OHM 1/4W +-5% 2
R425,138
113-274105-17 CARBON FILM RESISTOR 270K OHM 1/4W +-5% 1
R619
113-303101-67 METAL FILM RESISTOR 30K OHM 1/4W +-1% 1
R428
113-303105-17 CARBON FILM RESISTOR 30K OHM 1/4W +-5% 2
R123,305
113-330105-17 CARBON FILM RESISTOR 33 OHM 1/4W +-5% 1
R433
113-331105-17 CARBON FILM RESISTOR 330 OHM 1/4W +-5% 1
R905
113-332105-17 CARBON FILM RESISTOR 3.3K OHM 1/4W +-5% 5
R904,205,403,301,128
113-333105-17 CARBON FILM RESISTOR 33K OHM 1/4W +-5% 4
R670,660,676,003
113-334105-17 CARBON FILM RESISTOR 330K OHM 1/4W +-5% 2
R401,686
113-334305-75 METAL OXIDE FILM RESISTOR 330K OHM 1W +-5% 1
R913
113-338405-75 METAL OXIDE FILM RESISTOR 0.33 OHM 2W +-5% 1
R914
113-390605-75 METAL OXIDE FILM RESISTOR 39 OHM 5W +-5% 1
R915
113-391105-17 CARBON FILM RESISTOR 390 OHM 1/4W +-5% 3
R506,508,450
113-393105-17 CARBON FILM RESISTOR 39K OHM 1/4W +-5% 2
R606,409
113-471105-17 CARBON FILM RESISTOR 470 OHM 1/4W +-5% 4
R654,127,125,007
113-472101-67 METAL FILM RESISTOR 4.7K OHM 1/4W +-1% 1
R674
113-472105-17 CARBON FILM RESISTOR 4.7K OHM 1/4W +-5% 11
R910,602,603,601,427,139,672,673,653,016,011
113-472105-17 CARBON FILM RESISTOR 4.7K OHM 1/4W +-5% 3
R607,605,604
113-472205-75 METAL OXIDE FILM RESISTOR 4.7K OHM 1/2W +-5% 1
R349
113-473105-17 CARBON FILM RESISTOR 47K OHM 1/4W +-5% 2
R612,699
113-475105-17 CARBON FILM RESISTOR 4.7M OHM 1/4W +-5% 2
R322,323
113-479105-17 CARBON FILM RESISTOR 4.7 OHM 1/4W +-5% 1
R160
113-479605-51 WIRE WOUND CEMENT RES. 4.7 OHM 5W +-5% 1
R901
113-511105-17 CARBON FILM RESISTOR 510 OHM 1/4W +-5% 1
R512
113-514105-17 CARBON FILM RESISTOR 510K 1/4W +-5% 1
R420
113-561105-17 CARBON FILM RESISTOR 560 OHM 1/4W +-5% 1
R431
8/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
113-562105-17 CARBON FILM RESISTOR 5.6K OHM 1/4W +-5% 10
R203,202,421,105,101,102,103,106,113,668
113-563105-17 CARBON FILM RESISTOR 56K OHM 1/4W +-5% 5
R156,136,635,002,671
113-565210-92 CARBON COMPOSITION RESISTOR 5.6M OHM 1/2W +-10% 2
R916,917
113-680405-75 METAL OXIDE RESISTOR 68 OHM 2W +-5% 1
R442
113-681105-17 CARBON FILM RESISTOR 680 OHM 1/4W +-5% 2
R402,124
113-682105-17 CARBON FILM RESISTOR 6.8K OHM 1/4W +-5% 3
R909,903,153
113-683105-17 CARBON FILM RESISTOR 68K OHM 1/4W +-5% 1
R698
113-688205-42 FUSING RESISTOR 0.68 OHM 1/2W +-5% 2
R918,919
113-688305-42 FUSING RESISTOR 0.68 OHM 1W +-5% 2
R417,416
113-820105-17 CARBON FILM RESISTOR 82 OHM 1/4W +-5% 1
R112
113-821105-17 CARBON FILM RESISTOR 820 OHM 1/4W +-5% 3
R639,610,609
113-822105-17 CARBON FILM RESISTOR 8.2K OHM 1/4W +-5% 1
R906
113-822505-75 METAL OXIDE FILM RESISTOR 8.2K OHM 3W +-5% 1
R132
113-823105-17 CARBON FILM RESISTOR 82K OHM 1/4W +-5% 1
R429
114-210200-01 THERMISTOR (NICHICON ZPB53 BL 200C) 1
TH901
123-100340-60 CERAMIC CAP. 10PF +-5% 50V (SL TYPE) 1
C612
123-101340-93 CERAMIC CAP. 100PF 50V +-5% (NPO) 1
C103
123-101350-60 CERAMIC CAP. 100 PF 50V +-10% (SL TYPE) "SMART 1
GOOD"
C605
123-102850-10 CERAMIC CAP. 0.001 MFD 2KV +-10% MATSUSHITA 1
C501
123-103370-90 CERAMIC CAP. 0.01 MFD 50V +80 -20% 8
C402,304,125,122,118,115,116,114
123-104270-90 CERAMIC CAP. 0.1 MFD 25V +80 -20% 1
C681
123-122551-90 CERAMIC CAP. 0.0012 MFD 500V +-10% (B TYPE) 1
MATSUSHITA
C433
123-150340-93 CERAMIC CAP. 15 PF 50V +-5% (NPO) 3
C609,610,319
123-181350-60 CERAMIC CAP. 180 PF 50V +-10% (SL TYPE) 3
C431,438,503
123-221350-60 CERAMIC CAP. 220 PF 50V +-10% (SL TYPE) 2
C427,502
9/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
123-221551-90 CERAMIC CAP. 220 PF 500V +-10% MATSUSHITA 1
C915
123-222350-90 CERAMIC CAP. 0.0022 MFD 50V +-10% (B TYPE) 2
C601,607
123-222466-50 CERAMIC CAP. 0.0022 MFD 400VAC +-20% ECKDNA222ME 1
"MATSUSHITA"
C912
123-222850-10 CERAMIC CAP. 0.0022 MFD 2KV +-10% MATSUSHITA 1
C911
123-223370-90 CERAMIC CAP. 0.022 MFD 50V +80 -20% 3
C626,627,628
123-240340-93 CERAMIC CAP 24PF 50V +-5%(NPO) 2
C602,603
123-271350-60 CERAMIC CAP. 270 PF 50V +-10% (SL TYPE) 1
C504
123-302350-90 CERAMIC CAP. 0.003 MFD 50V +-10% (B TYPE) 1
C005
123-390340-93 CERAMIC CAP. 39PF 50V +-5% (NPO) 1
C604
123-470340-60 CERAMIC CAP. 47 PF 50V +-5% (SL TYPE) 1
C123
123-471350-60 CERAMIC CAP. 470 PF 50V +-10% (SL TYPE) 1
C126
123-472550-90 CERAMIC CAP. 0.0047 MFD 500V +-10% (B TYPE) 3
C419,424,913
123-472552-90 CERAMIC CAP. 0.0047 MFD 500V +-10% (B TYPE) SMALL 3
SIZE
C903,904,907
123-680340-93 CERAMIC CAP. 68 PF 50V +-5% (NPO) 1
C303
123-821850-10 CERAMIC CAP. 820 PF 2KV +-10% (SL TYPE) MATSUSHITA 2
C914,437
126-102071-01 MYLAR CAP. 0.001 MFD 50V +-10% 1
C428
126-103071-01 MYLAR CAP. 0.01 MFD 50V +-10% 2
C441,121
126-104071-01 MYLAR CAP. 0.1 MFD 50V +-10% 12
C908,205,208,411,317,318,407,429,306,307,108,106
126-104071-01 MYLAR CAP. 0.1 MFD 50V +-10% 3
C313,314,606
126-104101-31 POLYPROPYLENE CAP. 0.1 MFD 100V +-10% 1
C440
126-153071-01 MYLAR CAP. 0.015 MFD 50V +-10% 1
C422
126-154071-01 MYLAR CAP. 0.15 MFD 50V +-10% 1
C128
126-222070-31 POLYPROPYLENE CAP. 0.0022 MFD 50V +-5% 1
C421
126-222071-01 MYLAR CAP. 0.0022 MFD 50V +-10% 2
C204,621
126-223071-01 MYLAR CAP. 0.022 MFD 50V +-10% 3
C207,409,425
10/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
126-224071-01 MYLAR CAP 0.22 MFD 50V +-10% 1
C104
126-332071-01 MYLAR CAP. 0.0033 MFD 50V +-10 % 1
C316
126-332161-41 METALIZED POLYPROPYLENE CAP. 0.0033 MFD 1600V 2
+-10%
C435,436
126-333071-01 MYLAR CAP. 0.033 MFD 50V +-10% 1
C906
126-334071-01 MYLAR CAP. 0.33 MFD 50V +-10% 1
C403
126-473071-01 MYLAR CAP. 0.047 MFD 50V +-10% 2
C315,426
126-473222-41 METALIZED POLYPROPYLENE CAP. 0.047 MFD 275V +-20% 1
"OKAYA"
C902
126-474071-01 MYLAR CAP. 0.47 MFD 50V +-10% 1
C430
126-474201-31 POLYPROPYLENE CAP 0.47 MFD 200V +-10% 1
C414
126-474222-41 METALIZED POLYPROPYLENE CAP. 0.47 MFD 275VAC +-20% 1
"OKAYA"
C901
127-105071-05 ELECT CAP. 1 MFD 50V +-10% (TIME CONSTANT) 1
C413
127-105072-03 ELECT. CAP. 1 MFD 50V +-20% 6
C210,423,611,112,410,124
127-105132-03 ELECT. CAP. 1 MFD 160V +-20% 2
C415,320
127-106042-03 ELECT. CAP. 10 MFD 16V +-20% 9
C619,110,309,312,308,624,616,006,008
127-106042-23 ELECT.CAP. BIPOLAR 10MFD 16V +-20% 1
C009
127-106072-03 ELECT. CAP. 10 MFD 50V +-20% 1
C201
127-106104-03 ELECT CAP. 10 MFD 100V +-20% 105øC 1
C910
127-107042-03 ELECT. CAP. 100 MFD 16V +-20% 3
C408,119,310
127-107062-03 ELECT. CAP. 100 MFD 35V +-20% 1
C202
127-107132-03 ELECT. CAP. 100 MFD 160V +-20% "NICHICON" 2
C434,918
127-107402-03 ELECT. CAP. 100 MFD 400V +-20% 1
C905
127-108052-03 ELECT. CAP. 1000 MFD 25V +-20% 1
C211
127-108062-03 ELECT CAP. 1000 MFD 35V +-20% 1
C442
127-225072-03 ELECT. CAP 2.2 MFD 50V +-20% 3
C129,620,109
127-226042-03 ELECT. CAP. 22 MFD 16V +-20% 3
C321,132,617
11/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
127-227042-03 ELECT. CAP. 220 MFD 16V +-20% 2
C622,625
127-227062-03 ELECT. CAP. 220 MFD 35V +-20% 2
C916,416
127-228042-03 ELECT. CAP. 2200 MFD 16V +-20% 1
C412
127-228052-03 ELECT. CAP. 2200 MFD 25V +-20% 1
C417
127-335042-03 ELECT. CAP. 3.3 MFD 16V +-20% 1
C699
127-336042-03 ELECT. CAP. 33 MFD 16V +-20% 1
C001
127-336042-23 ELECT. CAP. BIPOLAR 33 MFD 16V +-20% 2
C003,007
127-336252-03 ELECT CAP. 33 MFD 250V +-20% 1
C420
127-474072-03 ELECT. CAP. 0.47 MFD 50V +-20% 2
C206,203
127-475052-03 ELECT. CAP. 4.7 MFD 25V +-20% 5
C305,107,111,113,117
127-476042-03 ELECT. CAP. 47 MFD 16V +-20% 2
C401,618
127-476072-07 ELECT.CAP. 47 MFD 50V +-20% NICHICON 1
C406
127-476094-07 ELECT CAP. 47 MFD 63V +-20% 105øC "NICHICON" 1
C909
127-477042-03 ELECT. CAP. 470 MFD 16V +-20% 3
C209,160,432
130-134148-01 SILICON DIODE IN4148 12
D501,502,503,608,613,301,303,612,001,002,003,610
130-134148-01 SILICON DIODE IN4148 9
D101,103,102,604,302,408,FOR D606,FOR R305,D409
130-310012-00 RECTIFIER DIODE RU2 SANKEN 1
D404
130-311441-64 BRIDGE RECTIFIER 1J4B41 TOSHIBA 1
BR901
130-311541-60 RECTIFIER DOIDE 1R5JU41 1
D904
130-314004-00 RECTIFIER DIODEN 1N4004 2
D401,402
130-315295-00 RECTIFIER DIODE S5295G TOSHIBA 9
D903,901,902,905,405,403,407,907,908
130-410039-01 ZENER DIODE 3.9V 1
ZD101
130-410051-01 ZENER DIODE 5.1V 1/2W +-5% 1
ZD601
130-410056-01 ZENER DIODE 5.6V 1
ZD604
130-410082-01 ZENER DIODE 8.2V 1
ZD901
130-410100-01 ZENER DIODE 10V 1/2W 1
ZD405
12/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
130-410100-01 ZENER DIODE 10V 1/2W 1
ZD403
130-410574-00 ZENER DIODE UPC 574J NEC 1
ZD102
130-411091-01 ZENER DIODE 9.1V 3
ZD902,401,402
130-422120-00 ZENER DIODE 1W 12V 1
ZD404
130-422120-00 ZENER DIODE 1W 12V 1
ZD406
130-512044-00 LED 3MM RED 204HDC 1
LED601
131-211013-18 TRANSISTOR 2SA1013 (R) TOSHIBA 1
Q906
131-211015-00 TRANSISTOR 2SA1015 TOSHIBA 7
Q101,102,103,610,002,003,699
131-220774-0A TRANSISTOR 2SB774/Q/R/S MATSUSHITA 1
Q907
131-230945-00 TRANSISTOR 2SC945 NEC 5
Q604,504,505,506,105
131-231317-00 TRANSISTOR 2SC1317 MATSUSHITA 1
Q603
131-231809-0A TRANSISTOR 2SC1809 ROHM 1
Q104
131-231815-00 TRANSISTOR 2SC1815Y FO SHAN 1
Q698
131-231815-0A TRANSISTOR 2SC1815 TOSHIBA 11
Q903,901,609,107,108,001,004,005,681,301,302
131-232230-00 NPN-TR 2SC2230A-Y (TOSHI) TO92 VCE=180V IC=.1A 1
HFE=120-240
Q608
131-232335-30 TRANSISTOR 2SC2335 L/K NEC 1
Q905
131-232482-0A TRANSISTOR 2SC2482 TOSHIBA 4
Q402,501,502,503
131-232703-25 TRANSISTOR 2SC2703-Y TOSHIBA 2
Q201,401
131-241554-00 TRANSISTOR 2SD1554 TOSHIBA 1
Q403
131-242498-13 TRANSISTOR 2SD2498(M) TOSHIBA 1
Q904
131-462369-0A TRANSISTOR PH2369 PHILIPS 1
Q106
133-108213-31 IC TDA8213 SGS 1
IC101
133-108217-31 IC TDA8217 SGS 1
IC301
133-201013-33 I.C. TDA1013B PHILIPS 1
IC201
133-208214-31 IC TDA8214B SGS 1
IC401
133-306356-31 IC ST6356BB1/BJT SGS-THOMSON 1
IC601
13/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
136-500005-00 REMOTE CONTROL RECEIVER MM-005E (JUNGPOONG) 1
OPT601
137-443618-20 CRYSTAL 4.43 MHz "TEC" 1
X301
146-100006-14 POWER SWITCH PS5E-B "CHINA LANDMARK" 1
S602
146-104112-01 TACT SWITCH 4 PIN L=8.35 100G #1102VC-4 10
"PROMOTION"
S607,608,609,610,612,603,604,605,606,601
160-101001-08 PIN CONNECTOR 1 PIN PLUG STRAIGHT 3
CN501,901,903
160-102805-08 PIN CONNECTOR 2 PIN PLUG STRAIGHT 1
CN902
160-104805-08 PIN CONNECTOR 4 PIN PLUG STRAIGHT 1
CN401
160-109255-27 PIN CONNECTOR 9 PINS PLUG 1
CN301
161-470002-00 RCA JACK HYJ-032-03BB BLACK "MING FUNG" 1
J002
161-470003-00 RCA JACK HYJ-032-03BY YELLOW "MING FUNG" 1
J001
161-540105-00 CRT SOCKET ISL-01 IN CHANG 1
FOR CRT P.C.B.
172-120034-40 UL 1007 STANDARD WIRE AWG 20 340MM BLACK 10 X 10MM 1
CN402 `2' TO CRT P.C.B. `L'
172-620005-40 UL 1007 TOP COAT WIRE AWG 20 50MM BLACK 5 X 5MM 1
FOR IC201 PIN `1' TO `9'
172-620007-40 UL 1007 TOP COAT WIRE #20 70MM BLACK 5 X 5 MM 1
MAIN P.C.B. `L' TO `L'
172-620014-40 UL 1007 TOP COAT WIRE AWG 20 140MM BLACK 10 X 10 1
MM
MAIN P.C.B. `D' TO `D'
172-626004-40 UL 1007 TOP COAT WIRE AWG 26 40MM BLACK 5 X 5 MM 1
JUMPER WIRE W184 TO CF103
172-626008-40 UL 1007 TOP COAT WIRE AWG 26 80MM BLACK 10 X 10 MM 3
Q904 LUG TO MAIN PCB `I', MAIN PCB `C' TO `C'
172-626008-40 UL 1007 TOP COAT WIRE AWG 26 80MM BLACK 10 X 10 MM 0
C126 ANODE TO Q108 COLLECTOR
172-626010-40 UL 1007 TOP COAT WIRE AWG 26 100MM BLACK 10 X 10 1
MM
Q403 LUG TO MAIN PCB `E'
172-626010-44 UL 1007 TOP COAT WIRE AWG 26 100MM YELLOW 10 X 10 1
MAIN P.C.B. `X' TO `X'
172-626010-46 UL 1007 TOP COAT WIRE AWG 26 100MM BLUE 10 X 10 MM 1
MAIN P.C.B. `J' TO `J'
172-626012-40 UL 1007 TOP COAT WIRE AWG 26 120MM BLACK 10 X 10 1
MM
MAIN P.C.B.`N' TO `N'
172-626012-44 UL 1007 TOP COAT WIRE AWG 26 120MM YELLOW 10 X 10 1
MM
MAIN P.C.B. `G' TO `G'
14/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
172-626014-43 UL 1007 TOP COAT WIRE AWG 26 140MM ORANGE 10 X 10 1
MAIN P.C.B. `A' TO `A'
MM
172-626018-43 UL 1007 TOP COAT WIRE AWG 26 180MM ORANGE 10 X 10 2
MAIN P.C.B. `B' TO `B',`K' TO `K'
MM
172-626036-43 UL 1007 TOP COAT WIRE AWG 26 360MM ORANGE 10 X 1
CN402 `3' TO CRT P.C.B. `J'
10MM
172-626036-44 UL 1007 TOP COAT WIRE AWG 26 360MM YELLOW 10 X 1
CN402 `1' TO CRT PCB `K'
10MM
172-726000-99 BARE WIRE 54MM 5
W093,101-102,105-112,116,118-148,151-152,R148,R452
172-726000-99 BARE WIRE 54MM 0
W154-157,159-171,174,176-186,189,191-192,114
172-726000-99 BARE WIRE 54MM 0
W199-201,203-204,206-209,215-216,218,502,503
172-726000-99 BARE WIRE 54MM 0
W086,088-090,092,195-197,822
172-830080-99 FLAT BRIDED WIRE 1200MM 0
FOR CRT GND
173-633022-50 SINGLE SHIELD WIRE L=220MM 1
`T' TO `T',`U' TO `U' (GND)
179-001010-00 OIL SLEEVING 1 mm DIA. 0
BR901,D904,404,C440,442,R911-914,411,413,C424,C422
179-001010-00 OIL SLEEVING 1 mm DIA. 0
20MM FOR R918,919,R416,417,D407,20MM FOR L402
179-105000-00 UL PVC TUBE 5mm DIA 0
120MM FOR AC LINE CORD,120MM FOR (F)(G) WIRE
179-107300-00 UL PVC TUBE 7.3MM DIA. 0
220MM FOR `F',`G'
179-110500-00 UL PVC TUBE 11MM DIA. 0
60MM-AC LINE CORD
179-403080-00 SHRINKABLE TUBE 0
FOR SOLDERING LUG
179-405030-00 5 mm DIA SHRINKABLE TUBE 0
L=120MM 60MM FOR AC LINE CORD,60MM FOR (F)(G) WIRE
182-222000-03 FUSE T2A 250V 1
F901
190-881309-00 CRT P.C.B. (250294) 1
190-931301-07 SENSOR P.C.B. (191194) 1
190-93135L-XB MAIN P.C.B. (270498) 1
191-100030-09 1 PIN SOCKET ASSM'Y L=300MM 1
FOR CN501
191-101016-07 1 PIN DOUBLE INSOLATION WIRE AWG 18 L=340MM BLUE 1
CN903 TO `F'
191-101017-07 1 PIN DOUBLE INSOLATION WIRE AWG 18 L=340MM BROWN 1
CN901 TO `G'
191-901000-07 9 PIN SOCKET ASS'Y L=360MM 1
CN301 TO CRT PCB `1' TO `A', `2' TO `B', `3' TO`C'
191-901000-07 9 PIN SOCKET ASS'Y L=360MM 0
`4' TO `D', `5' TO `E', `6' TO `F',`7' TO `G'
15/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
191-901000-07 9 PIN SOCKET ASS'Y L=360MM 0
`8' TO `H', `9' TO `I'
514-400425-10 SELF-TAPPING SCREW 4 X 25 B/T (HARDEN) 6
REAR CAB.TO FRONT CAB.
514-500435-10 SELF-TAPPING SCREW B/T 5 X 35 HEAD DIA. =8.5MM 4
4 FOR CRT MTG.
(MAX)(HARDEN)
515-303408-10 SELF-TAPPING SCREW 3 X 8 W/B/T (HARDEN) 1
FOR SPK. WIRE
517-303312-10 SELF-TAPPING SCREW 3 X 12 W/A W/H=7MM (HARDEN) 2
FOR HEAT SINK (A) & (B)
540-020030-01 EYELET 2 X 3 MM 13
2-L402,2-R411,2-R413,4-L901,2-T402 PIN `1' `2',
540-020030-01 EYELET 2 X 3 MM 0
1-Q403 `C'
540-020040-01 BRASS EYELET 2X4MM 3
3 FOR CN402
580-101004-00 STAND OFF TWIST TIE #ST-3 1
FOR CN903,CN901
580-101261-01 CABLE TIE L=100MM 10
4- CRT PCB, 2- FLYBACK, 2- DY, 2- MAIN WIRE
580-101261-01 CABLE TIE L=100MM 3
3- POWER SWITCH
622-882802-00 FELT L240 X W17 X T0.5MM W/TAPE 4
FOR REAR CABINET
728-931302-00 SENSOR P.C.B. SUPPORT 2
FOR SENSON PCB
744-881301-00 SPRING FOR C.R.T. MOUNTING 5.2 X 42 X 0.6MM 1
746-063101-00 TEST PIN:TOTAL LENGTH 18.6mm THK:0.8mm 2
TP103,104
746-063101-01 AC LINE CORD PIN 4
FOR AC LINE CORD -2,(F)(G) WIRE -2
750-063101-00 SOLDERING LUG LEG:8X4MM 2
FOR HEAT SINK (A) & (B)
750-063102-01 35MM SOLDERING LUG OD:7 ID:3.2 LEG:4X35MM 1
FOR SPK. CONNECTOR
766-686801-00 FUSE HOLDER 2
FOR F901
777-881301-00 SPRING IN 10 X L12 1
FOR POWER KNOB
780-931301-00 BRASS HEAT SINK 1
FOR IC401
781-882001-02 ALUMINIUM HEAT SINK (B) 1
FOR Q403
781-882102-05 ALUMIMIUM HEAT SINK (A) 1
FOR Q904
783-931301-01 SHIELD CAN 1
783-931302-02 SHIELD CAN COVER 1
834-230802-00 RUBBER WASHER OD=23, ID=8, T=2 4
FOR CRT MTG.
840-011024-21 PAD CORD L240 X W10 X T1 MM W/TAPE 4
BETWEEN CRT AND CRT SURFACE
16/17
MODEL NO: CT-M341MKII
SYSTEM: PAL/BG/AVIN M.GRAY{8403C} 240V SAA 47P
PART NUMBER DESCRIPTION QTY.
840-051020-11 RUBBER PAD (UL 94VO) 5
1-T901, 2-T402, 1-BETWEEN FBT & HEAT SINK
840-051020-11 RUBBER PAD (UL 94VO) 0
1 - BETWEEN HEAT SINK A.B.
929-931302-00 LED HOLDER BLACK ABS 1
FOR LED601
939-942101-00 POWER KNOB ADAPTOR 1
948-881302-00 DEGAUSSING COIL MTG. CLIP 4
FOR POWER SW.
954-882804-00 HIGH VOLTAGE CABLE SPACER 1
FOR CRT
954-931301-00 STUD POST BLACK ABS 4
FOR FRONT CAB.
17/17
Loading...
