Auto-Publisher System

Model: AP220N

2 DVD Recorders, 220-Disc Capacity
Publishing System

• All-In-One Disc Publishing System

• Choices of Thermal or InkJet Printer

• Copy and Print Discs in One Easy Step

• Stand-Alone Publisher

• Networkable Capability

• 220-Disc Production Capacity

TEAC’s new Auto-Publisher with choices of TEAC 4800dpi color
Inkjet Printing or TEAC color Dye-Sub Thermal Printing is a full auto­mated 2-DVD Drive Publishing System. It makes it easy and quick
to automatically copy and print up to 220 discs. Advanced Robotic
Mechanism is used to transport discs from the input bins to the
integrated TEAC Printer and then to the output bins.

Thermal Printer Specification

Printer Model: P-55 (TEAC Thermal Dye-Sublimation Disc Printer)
Printing Method: Thermal Re-transfer/Dye-sublimation

Ribbon Capacity: 500 images/ ribbon (Full Color)
Print Resolution: 400 dpi
Dimensions: 15.312"D x 11.875"W x 9.5"H
Weight: 48.5lbs

InkJet Printer Specification

Printer Model: PIJ (TEAC Color Inkjet Disc Printer)
Printing Method: InkJet
Printing Resolution: up to 4800 x 1200 dpi
Dimensions: 14.5"L x 18"W x 13.5"H

(cm: 37.25D x 34.5H x 46W)

Weight: 39lbs (13.5kg) approx.

General Auto-Publisher System Specifications

Printer Model: AP220N
DVD Recorders: Two (2) DVD Recordable Drives
Hard Drive: One (1) IDE Hard Drive
HD Memory: 32MB or 80GB
Controller: Series 5 with TrueCopy System Technology
Interface: Gigabit Ethernet Technology
Voltage Requirement: 110v / 220v Auto Switch
Power Consumption: 100W
Environment:

- Temperature: 40-95F (5-35C)

- Humidity: 20%-80% non condensing

Supported Formats: Read/Write/Record CD-ROM Mode 1,

Playstation (Developer), CD-XA Mode 2
(Form 1 & 2),Rockridge, Joliet, CD-DA (Red Book
Audio with sub codes), CD-I (Green Book), Single
Session, CD-Extra (Blue Book aka Enhanced CD,
CD Plus), MultiSession, Video CD (White Book),
Track At Once (TAO), Mixed Mode, Session At
Once (SAO), Kodak Photo CD, Disc At Once
(DAO),Hybrid, CD Text, ISO9660, UFS, HFS.

Dimensions: 30"L x 24"W x 19"H
Weight: 50lbs

Specifications subject to change without notice.

For the most remarkable print quality, speed and performance, look
to the TEAC Color Printers. With incredible print resolution – the best
in the world - all of your discs will have the sharpest text, graphics
and photos. Colors are bright, vibrant and truly professional photo­quality, creating a positive, lasting impression.

© 2008 TEAC America, Inc. All rights reserved. All trademarks and registered trademarks mentioned herein are the property of their respective companies.

TEAC America, Inc., 7733 Telegraph Road, Montebello, CA 90640 • Email [e-mail] • Phone [phone] • Fax [phone]
