Sunbeam 4744 User Manual

Instruction Manual and Recipe Booklet

ICE CREAM/FROZEN YOGURT MAKER

Thank you for purchasing the SUNBEAM Ice Cream/Frozen

Yogurt Maker. Before you use this product for the first time, please take a few moments to read these instructions and keep it for reference and enjoyment of the recipes.

Pay particular attention to the Safety Instructions provided. Please review the

product service and warranty statements. For your future reference, please note:

Date product received:

Service number:

(located on the bottom of the machine)

When using electrical appliances, basic safety precautions should always be followed, including the following:

• READ AND SAVE ALL INSTRUCTIONS.

• To protect against risk of electrical shock do not put motor base in water or other liquid.

• Close supervision is necessary when any appliance is used by or near children or incapacitated persons.

• Unplug from outlet when not in use, before putting on or taking off parts, and before cleaning.

• Avoid contacting moving parts.

• Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Return appliance to the nearest authorized Sunbeam Appliance Service Center for examination, repair or electrical or mechanical adjustment.

• The use of attachments not recommended or sold by the appliance manufacturer may cause fire, electric shock or injury.

• Do not use outdoors or for commercial purposes.

• Do not let cord hang over edge of table or counter or touch hot surfaces.

HISUNITISFORHOUSEHOLD

USEO

NLY

FOR PRODUCTS PURCHASED IN THE U.S. AND CANADA ONLY

To reduce the risk of electrical shock, this appliance has a polarized plug (one blade iswider than the other). This plug fits a polarized outlet only one way; if the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature.

SAVE THESE INSTRUCTIONS

IMPORTANT SAFEGUARDS

Congratulations on owning a SUNBEAM “Quick Freeze” Ice Cream/Frozen Yogurt Maker! This easy-to-use appliance makes all your favorite frozen creations in a snap!

From sinful ice creams to rich custards . . . ices . .

Try each one of the taste-tempting recipes in this cookbook. . . then let your

imagination run wild! Chop up a candy. bar or puree your favorite fruit in your OSTERIZER

combinations you can create. Best of all, some of “your specialties” can be

ready in just 10 minutes!

The SUNBEAM “Quick Freeze” Ice Cream/Frozen Yogurt Maker. . . it makes your kitchen even more versatile.

This unit uses ordinary table salt and ice cubes. It is

salt or crushed ice in this unit.

. you’ll be the most famous “cook” on the block.

blender and mix it into a basic recipe. There’s no end to the

creamy ice sorbets to refreshing

,not

necessary to use rock

BEFORE USING FOR THE FIRST TIME

After unpacking, disassemble unit before using for the first time. Wash all parts

(except ice bucket and

DO NOT IMMERSE ICE BUCKET OR MOTOR BASE.

motor

base) in warm, soapy water. Rinse and dry immediately.

MAINTENANCE

1. If the Canister stalls or fails to rotate while processing: A) Turn off unit and allow to cool.

B) After cooling, turn unit on. If canister still fails to rotate,

return unit to an Authorized Service Station.

2. Any other servicing needed be performed only by an Authorized Service Station.

3. Always specify the SUNBEAM product model number located

on the bottom of the Ice Bucket when service is required.

INSTRUCTIONS

HOW TO ASSEMBLE ICE BUCKET COVER

1. Position Ice Bucket on motor base.

2. Pour ice cream mixture into Cream Canister.

3. Place Freezing Cover on Cream Canister.

4. Position Cream Canister in Ice Bucket.

5. Add ice and salt as directed.

6. Remove Freezing Cover.

7. Insert Paddle.

8. Place Mixing Cover on Cream Canister.

9. Place Ice Bucket Cover on Bucket engaging Paddle with Center Feed on both covers.

10. Swing Latches up and interlock with Notches on Cover.

Center Feed

Ice Feed

Corner

Paddle

Cream

Canister

Pivot Pin

Kitchen Center Appliance Motor Base

Ice Bucket Cover

Mixing Cover

Notch

Slot

Ice Bucket

Latch

Freezing Cover

TO PROCESS YOUR FAVORITE RECIPE

You will need approximately: 2 cups (500 ml) table salt and 6 trays of ice cubes. It is NOT NECESSARY to use rock salt or crushed ice in this unit.

1. Prepare recipe as directed.

2. Pour into Cream Canister. (To prevent overload and damage

to the product do not prepare more than one batch of ice cream at a time.)

3. Put Freezing Cover in place.

4. Position Cream Canister in Ice Bucket.

5. Layer ice and salt solution as follows: A. Pour 1 cup (250 ml) cold water into Ice Bucket. B. Place a 1 inch (2.5 cm) layer of ice cubes around Cream Canister in Ice Bucket.

(Hint: Cream Canister should stand straight while layering.)

C. Sprinkle 1/3 cup (75 ml) table salt or 1/4 cup (50 ml) Kosher (coarse)

salt on ice. D. Continue layering ice and salt to the top of the Ice Bucket. E. Pour 1 cup (250 ml) cold water over top ice layer.

6. Remove Freezing Cover.

7. Insert Paddle and put Mixing Cover in place.

8. Place Ice Bucket Cover on Ice Bucket. Latch.

9. Turn unit on.

10. As ice melts, add more ice cubes through Ice Feed Corners. For each 1 cup (250 ml) of ice cubes added, add 1/4 cup (50 ml) salt.

11. Process until frozen mixture reaches Mixing Cover or until desired consistency is reached. REMINDER: DO NOT OVER-PROCESS ICE CREAM. DAMAGE TO UNIT COULD OCCUR.
