ST7232X-EVAL

Insem’s ST-STEP64 Evaluation Board for ST7232x and ST7252x

DATA BRIEF

The

Insem ST-STEP64 Evaluation Board

(ST7232X-EVAL)

evaluation board that allows you to try out the
features of the ST7232x and ST7252x, and
develop applications for these microcontrollers. Its
innovative design allows stand-alone operation
(application running on the included ST72F521R
microcontroller), or operation while connected to
your host-PC using the low-cost ST7MDT20­DVP3 emulator.

is an adaptable, full-featured

Evaluation Board Architecture

Figure 1. ST-STEP64 evaluation board

ST-STEP64 evaluation board

evaluation board (PWM, LCD, I
CAN, potentiometer, LEDs, I/Os,... etc.), it
includes connectors and accessories to facilitate
switching between operation with a
microcontroller or the ST7MDT20-DVP3 emulator.
The ST-STEP64 also integrates a 10-pin ICC
connector for easy programming of the
microcontroller using an in-circuit programming
tool for ST7.

TQFP64 14x14 Core Module with
ST72F521R9T – included daughter board with

ST72F521R97 that makes it possible to run your
application in stand-alone mode on the
microcontroller.

Also Includes pre-wired daughter board PCBs,
ready for mounting of connectors and supported
MCUs in TQFP80 (14x14), TQFP64 (10x10) and
TQFP32, so that you can make your own Core
Module for an ST7232x or ST7252x.

ST7MDT20-DVP3 emulator (not included)

low-cost ST7-DVP3 series emulator provides a
hardware interface with the host PC for debugging
application software and in-circuit programming of
the ST72F521R97 or other ST7 flash
microcontroller. The evaluation board comes with
the additional flat cable and the adapter required
for connection to an ST7MDT20-DVP3 emulator.

– a full-featured

2

C, UART, SPI,

– this

For more information about the ST7MDT20­DVP3, please refer to the

ST7 Visual Develop (STVD7)

integrated development environment for ST7
featuring simulator and full integration of Cosmic
and Metrowerks C toolsets. STVD7 runs on the
host PC, allowing you to debug applications with
an emulator, or to in-circuit program an application
to the target ST7 and in-circuit debug the
application while it runs on the ST7 on your
evaluation board.

For more information, please refer to

Visual Develop Key Features

ST7-DVP3 Data Brief

– the free

AN978 ST7

.

.

Key Features

ST-STEP64 Evaluation board:

The ST-STEP64 includes a complete range of
features for evaluating the ST7232x and ST7252x
microcontrollers, including:

Rev 1

December 2005 1/3

For further information contact your local STMicroelectronics sales office.

www.st.com

3

ST7232X-EVAL

■ 128 x 64 Graphic LCD display on a removable board.

■ Motor speed and beep control using PWM

■ RS232, I

■ External interrupt with 4 TACT switches

■ Internal variable resistance for ADC design

■ 8 LEDs for checking I/O port operating status

■ Integrated 7-Segment display for dynamic checking of I/O port operating status

■ IR sensor

■ ST-standard ICC connection for easy in-circuit programming

■ Wrapping area

2

C, SPI and CAN interfaces

For further information about this and other development tools for ST7, please refer to

Revision history

Date Revision Changes

18-November-2005 1 Initial release.
