ST ST72321AR6, ST72321R6, ST72321AR7, ST72321J7, ST72321R7 User Manual

8-bit MCU for automotive with 32/60 Kbyte Flash/ROM,

LQFP64

10 x 10

LQFP64

14 x 14

LQFP44

10 x 10

ADC, 5 timers, SPI, SCI, I2C interface

Features

Memories

■ 32 to 60 Kbyte dual voltage High Density Flash

(HDFlash) or ROM ROM with readout
protection capability. In-application
programming and in-circuit programming for
HDFlash devices

■ 1 to 2 Kbyte RAM

■ HDFlash endurance: 100 cycles, data retention

20 years

Clock, reset and supply management

■ Enhanced low voltage supervisor (LVD) for

main supply and auxiliary voltage detector
(AVD) with interrupt capability

■ Clock sources: crystal/ceramic resonator

oscillators, internal RC oscillator and bypass
for external clock

■ PLL for 2x frequency multiplication

■ 4 power saving modes: Halt, Active Halt, Wait

and Slow

Interrupt management

■ Nested interrupt controller

■ 14 interrupt vectors plus TRAP and RESET

■ Top Level Interrupt (TLI) pin on 64-pin devices

■ 15 external interrupt lines (on 4 vectors)

1 analog peripheral

■ 10-bit ADC with up to 16 input ports

Up to 48 I/O ports

■ 48//32 multifunctional bidirectional I/O lines

■ 34//22 alternate function lines

■ 16//12 high sink outputs

ST72321xx-Auto

5 timers

■ Main clock controller with Real-time base,

Beep and Clock-out capabilities

■ Configurable watchdog timer

■ Two 16-bit timers with 2 input captures, 2

output compares, external clock input on 1
timer, PWM and pulse generator modes

■ 8-bit PWM auto-reload timer with 2 input

captures, 4 PWM outputs, output compare and
time base interrupt, external clock with event
detector

3 communications interfaces

■ SPI synchronous serial interface

■ SCI asynchronous serial interface

2

■ I

C multimaster interface

Instruction set

■ 8-bit data manipulation

■ 63 basic instructions

■ 17 main addressing modes

■ 8x8 unsigned multiply instruction

Development tools

■ Full hardware/software development package,

ICT capability

Table 1. Device summary

Reference Part number

ST72321AR6-Auto,
ST72321R6-Auto,

ST72321xx-Auto

ST72321AR7-Auto,
ST72321J7-Auto, ST72321R7-Auto
ST72321AR9-Auto,
ST72321J9-Auto, ST72321R9-Auto

August 2010 Doc ID 13829 Rev 1 1/243
