WARNINGS

To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

Use the supplied AC adaptor only. If you use other types, it may cause fire, electrical shocks or a malfunction.

For customers in the U.S.A. and Canada

Caution

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

The use of optical instruments with this product will increase eye hazard.

WARNINGS

This appliance is classified as a CLASS 1 LASER product under IEC60825-1: 2001.

For customers in the U.S.A.

If you have questions about this product, call our technical support line at 1-800-345-7669, or write to: Sony Computer Entertainment America Consumer Services/Technical Support PO Box 5888, San Mateo, CA 94402-0888 U.S.A.

Declaration of Conformity

Trade Name : Model No. : Responsible Party : Address :

Telephone No. :

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference tha t may cause undesired operation.

SONY PSP-1001 Sony Electronics Inc. 16530 Via Esprillo, San Diego, CA 92127 U.S.A 858-942-2230

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

FCC Radiation Exposure Statement

This transmitter complies with FCC radiation exposure limit set forth for an uncontrolled environment. To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any changes to the antenna or the device could result in the device exceeding the RF exposure requirements and void user authorization to operate the equipment. In addition, this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

For customers in Canada

This Class B digital apparatus complies with Canadian ICES-003. The term "IC" before the equipment certification number only signifies that the Industry Canada technical specifications were met.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

IC Radiation Exposure Statement

This transmitter complies with IC radiation exposure limit set forth for an uncontrolled environment. To comply with the IC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any changes to the antenna or the device could result in the device exceeding the RF exposure requirements and void user authorization to operate the equipment. In addition, this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

WARNINGS

Photosensitivity/Epilepsy/Seizures Radio waves

A very small percentage of individuals may experience epileptic seizures or blackouts when exposed to certain light patterns or flashing lights. Exposure to certain patterns or backgrounds on a sc reen or when playing video games may trigger epileptic seizures or blackouts in these individuals. These conditions may trigger previously undetected epileptic symptoms or seizures in persons who have no history of prior seizures or epilepsy. If you, or anyone in your family, has an epileptic condition or has had seizures of any kind, consult your physician before playing.

IMMEDIATELY DISCONTINUE use and consult your physician before resuming gameplay if you or your child experience any of the following health problems or symptoms:

• dizziness,

• altered vision,

• eye or muscle twitches,

• loss of awareness,

• disorientation,

• seizures, or

• any involuntary movement or convulsion.

RESUME GAMEPLAY ONLY ON APPROVAL OF YOUR PHYSICIAN.

Use and handling of video games to reduce the likelihood of a seizure

• Use in a well-lit area and keep the screen a safe distance from your face.

• Avoid prolonged use of the PSP® system. Take a 15-minute break during each hour of play.

• Avoid playing when you are tired or need sleep.

WARNINGS

Radio waves may affect electronic equipment or medical devices (for example, pacemakers), which may cause malfunctions and possible injuries.

• If you use a pacemaker or other medical device, consult your physician or the manufacturer of your medical device before using the wireless LAN feature.

• Do not use the wireless LAN feature in the following locations: – Areas where wireless LAN use is prohibited, such as in hospitals.

Abide by medical institution regulations when using the system on their premises.

– Areas near fire alarms, automatic doors and other types of

automated equipment.

About DNAS

Sony Computer Entertainment Inc. uses DNAS (Dynamic Network Authentication System), a proprietary authentication system, to help protect copyright and security in connecting the PSP® system to a network. DNAS may retrieve information about a user's hardware and software for authentication, copy protection, account blocking, system, rules, or game management and other purposes. The information collected does not identify the user personally. The unauthorized transfer, exhibition, export, import or transmission of programs and devices circumventing its authentication scheme may be prohibited by law.

System software

The system software included within this product is subject to a limited license from Sony Computer Entertainment Inc. Refer to http://www.scei.co.jp/psp-eula for further details.

WARNINGS

Table of contents About the PSP® system

WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

About the PSP

x Before use

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Compatible media . . . . . . . . . . . . . . . . . . . . . . . . . . 14

x Troubleshooting

Before requesting service . . . . . . . . . . . . . . . . . . . . 16

x Limited warranty

LIMITED HARDWARE WARRANTY AND

LIABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

x Additional information

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Table of contents

® system documentation . . . . . . . . . . 6

documentation

The PSP® (PlayStation®Portable) system documentation includes the following:

Safety and Support (this document)

This document contains safety information related to the use of the PSP® system, troubleshooting, specifications and other information.

Quick Reference

This document contains information on basic hardware operations of the PSP® system.

User's Guide (http://manuals.playstation.net/document/)

This online document is accessed through the Internet and contains detailed information related to use of the PSP® system software.

Notice

For up-to-date information regarding the PSP® system, visit http://www.us.playstation.com/psp.

Various accessories for the PSP® system are mentioned throughout this documentation. Note however that the accessories supplied with your system depend on the product purchased.

Before use

Precautions

Before using this product, carefully read this manual and retain it for future reference.

Safety

This product has been designed with the highest concern for safety. However, any electrical device, if used improper ly, has the potential for causing fire, electrical shock or personal injury. To help ensure accident-free operation, follow these guidelines:

• Observe all warnings, precautions and instructions.

• Regularly inspect the AC adaptor and AC power cord.

• Stop use, unplug the AC power cord from the electrical outlet and disconnect any other cables immediately if the device functions in an abnormal manner, produces unusual sounds or smells or becomes too hot to touch.

• Call SCEA Consumer Services at 1-800-345-7669 if the device does not operate properly.

Use and handling

• Use in a well-lit area and keep the screen a safe distance from your face.

• Avoid prolonged use of the PSP® system. To help prevent eyestrain, take a break of about 15 minutes during every hour of play.

• If you experience any of the following health problems, discontinue use of the system immediately. If symptoms persist, consult with your physician.

– Dizziness, nausea, fatigue or symptoms similar to motion sickness – Discomfort or pain in a part of the body, such as eyes , ears, hands

or arms

• Exercise care when setting the volume. If you set the volume too high, it may harm your hearing or damage the speakers.

• Keep the system and accessories out of the reach of small children. Small children may swallow the Memory Stick Duo™ or wrap the cables/straps around themselves, which may inflict injury or cause an accident or a malfunction.

• Do not use the system while driving or riding a bicycle. Looking at the screen or operating the system while driving an automobile or riding a bicycle may result in a traffic accident.

• Take extra care when using the system while walking.

• Be careful not to pinch your fingers when closing the disc cover.

• Do not use the system or accessories near water.

• Use only attachments/accessories specified by the manufacturer.

• Do not use the headphones if they cause discomfort to your skin. If the headphones cause discomfort to your skin, discontinue use immediately. If symptoms do not subside even after discontinuing use, seek medical attention.

• Do not expose the system or accessories to high temperatures, high humidity, or direct sunlight.

• Do not leave the system or accessories in a car with the windows closed (particularly in summer).

• Do not expose the system or accessories to dust, smoke or steam.

• Do not allow liquid or small particles to get into the system or accessories.

• Do not place the system or accessories on surfaces that are tilted, unstable or subject to vibration.

• Do not throw, drop or step on the system or accessories, and do not subject the devices to strong physical shock. Sitting down with the PSP® system in a pocket or placing the system in the bottom of a backpack along with heavy objects may cause damage to the system.

• Do not forcibly twist the PSP® system or expose the system to strong physical shock during gameplay, as doing so can damage the system

Before use

Precautions

or cause the disc cover to open, ejecting the disc. Handle the analog stick with care.

• Do not put heavy objects on the system or accessories.

• Do not touch or insert foreign objects into the connectors of the system or accessories.

• Do not place the syste m close to items with a magnetic strip, such as credit cards.

• Depending on the conditions of use, the system or AC adaptor may reach temperatures of 40 °C/104 °F or more. Do not touch the system or AC adaptor for an extended period of time under these conditions. Extended contact under these conditions may cause low-temperature burns*.

* Low-tempe rature burns are burns that occur when t he skin is in contact

with objects of relatively low temperatures (40°C or more/104°F or more) for an extended period of time.

AC adaptor and AC power cord use

• Do not touch the plug of the AC power cord with w et hands.

• Do not touch the AC power cord, AC adaptor or the system, if connected to an electrical outlet, during an electrical storm.

• Do not use a power source other than the supplied battery pack, AC adaptor and AC power cord.

• Unplug the AC power cord from the electrical outlet and remove the battery pack from the system before cleaning or when you do not intend to use the system for an extended period of time.

• Protect the AC power cord from being walked on or pinched particularly at plugs, convenience receptacles and the point where they exit from the system.

• When disconnecting the AC power cord, hold it by the plug and pull straight out from the electrical socket. Never pull by the cord and do not pull at an angle.

• Do not use the system to play games or video when the system is covered with any type of fabric. If you want to pause or temporarily

Precautions

store the system while playing games or video, put the system in sleep mode before placing it in the pouch. Also do not use the AC adaptor when covered with fabric. This may help to avoid overheating.

• Do not connect the AC power cord to a voltage transformer or inverter. Connecting the AC power cord to a voltage transformer for overseas travel or an inverter for use in an automobile may cause heat to build up in the AC adaptor and may cause burns or a malfunction.

• The socket-outlet shall be installed near the equipment and shall be easily accessible.

LCD screen

• The LCD screen is made of glass and may crack if subjected to excessive force.

• Black (dark) pixels and continuously lit pixels may appear in certain locations on the LCD screen. The appearance of such spots is a normal occurrence associated with LCD screens and is not a sign of a system malfunction. LCD screens are made using highly precise technology. However, a very small number of dark pixels or continuously lit pixels exist on each screen. Also, a distorted image may remain on the screen for several seconds after the system has been turned off.

• Direct exposure to sunlight may damage the system's LCD screen. Be careful when using the system outdoors or near a window.

• When using the system in a cold environment, you may notice shadows on the graphics or the screen may appear dar ker than usual. This is not a malfunction, and the screen will return to normal when the temperature goes up.

• Do not leave still images displayed on the screen for an extended period of time. This may cause a faint image to be left permanently on the screen.

Memory Stick Duo™

For best results, follow these guidelines:

• Do not touch the connector area (A) with your hands or with metal

objects.

• Do not press hard when writing on the memo area (B).

• Do not insert a Memory Stick Duo™ into a device designed to accept only standard-size Memory Stick™ media.

• Do not use or store a Memory Stick Duo™ in the following: – Places subject to high temperatures, such as in a hot vehicle – Locations exposed to direct sunlight – Locations that are very humid or conducive to corrosion

• Use the case supplied with the Memory Stick Duo™ to carry or store the media.

• When using Memory Stick Duo™ media without an erasure prevention switch, take care not to overwrite or delete data by accident. If your Memory Stick Duo™ media has an erasure prevention switch, you can prevent data from being saved, edited, or deleted by setting the switch in the LOCK position.

Recorded data

Do not use the Memory Stick Duo™ in the following ways, as doing so may result in data loss or corruption:

• Removing the Memory Stick Duo™ or turning off the system while it is loading or saving data or being formatted.

• Using it in a location that is exposed to static electricity or electrical interference.

If, for any reason, software or data loss or corruption occurs, it is usually not possible to recover the software or data. It is recommended that you regularly back up software and data. Sony Computer Entertainment Inc. and its subsidiaries and affiliates will not be held liable for any damages or injury in the case of software or data loss or corruption.

In accordance with copyright law, no recorded data may be used for purposes other than personal enjoyment without permission from the copyright holder.

Pouch

• If you want to pause or temporarily store the system while playing games or video, put the system in sleep mode before placing it in the pouch. This may help to avoid overheating.

• Put both the PSP® system and the remote control in hold mode to help prevent unintended operation.

Never disassemble the system or accessories

Use the PSP® system and accessories according to th e instructions in this manual. No authorization for the analysis or modification of the system, or the analysis and use of its circuit configur ations, is provided. Disassembling will void the system warranty. Additionally, there is a risk of fire, electrica l shock or malfunction. The LCD screen, in particular, contains dangerous, high-voltage parts, and the laser beam for readi ng UMD™ may cause visual impairment i f exposed directly to the eyes.

Precautions

Before use

Using the access point

When using the PSP® system's 'Scan' function to select the wireless LAN access point, access points that are not intended for public use may be displayed. Only connect to a personal access point that you are authorized to use, or one that is available through a public wireless LAN or hotspot service. User is responsible for all fees associated with wireless LAN access.

Overseas use

Depending on the country, there are limitations on the use of certain types of radio waves. In some cases, use of the system may lead to a fine or other penalty.

Moisture condensation

If the PSP® system or UMD™ is brought directly from a cold location to a warm one, moisture may condense on the lens inside the system or on the UMD™. Should this occur, the system may not operate properly. In this case, remove the UMD™ and turn off and unplug the system. Do not put the UMD™ back in until the moisture evaporates (this may take several hours). If the system still does not operate properly, contact our technical support line at 1-800-345-7669 for assistance.

UMD™ handling

• Do not touch the opening on the rear of the disc (recorded surface of the disc) with your fingers.

Precautions

• Do not allow dust, sand, foreign objects or other types of dirt to get on the disc.

• If the UMD™ becomes dirty, gently wipe the exterior and recorded surfaces of the UMD™ using a soft cloth. Do not use solvents or other chemicals.

• Do not use a UMD™ that is cracked or warped or has been repaired. The UMD™ may break inside the PSP® system, leading to injury or malfunction.

Use and handling of the system

Follow the guidelines listed below to help avoid deterioration or discoloration of the PSP® system:

• Do not use solvents or other chemicals to clean the exterior surface.

• Do not allow the system to remain in direct contact with rubber or vinyl products for an extended period of time.

• Do not use a chemically-treated cleaning cloth to wipe off the system.

Before using the analog stick

For best results, go to (Settings) (System Settings) and then with the "System Information" screen displayed, rotate the analog stick in a circular motion. This will adjust the analog stick's range of movement.

Cleaning

For safety reasons, unplug the AC power cord from the electrical outlet and remove the battery pack from the system before cleaning.

Cleaning the exterior surface and LCD screen

Wipe gently with a soft cloth.

Cleaning the connectors

If the headphones or remote control connectors become dirty, this could cause noise or interruptions in sound. Wipe the connectors with a dry, soft cloth to keep in clean condition.

Battery pack precautions

Warnings

Do not handle a damaged or leaking battery pack.

Handle the battery pack with care.

The battery pack may explode or present a fire or chemical burn hazard if it is not handled carefully.

• Do not allow the battery pack to come into contact with fire or subject it to extreme temperatures such as in direct sunlight, in a vehicle exposed to the sun or near a heat source.

• Do not cause the battery pack to short-circuit.

• Do not disassemble or tamper with the battery pack.

• Prevent damage to the battery pack. Do not carry or store the battery pack with metal items such as coins or keys. If damaged, discontinue use.

• Do not throw or drop the battery pack or subject it to strong physical shock.

• Do not put heavy objects on or apply pressure to the battery pack.

• Do not allow the battery pack to come into contact with liquids. If it becomes wet, discontinue use until it is completely dry.

• Keep the battery pack out of the reach of small children.

• If the PSP® system will not be used for an extended period of time, remove the battery pack and store it in a cool, dry place out of the reach of children.

• Use only the supplied battery pack or a replacement marked for use with the PSP® system.

• Use only the designated AC adaptor to charge the battery pack.

Before use

Precautions

Estimated battery duration

Game Approximately 3 - 6 hours

Video playback Approximately 3 - 5 hours

*1 Based on tests conducted using the supplied battery pack, with the system

in single player mode, with headphones with remote control in use, and with wireless LAN not in use.

*2 Based on tests conducted using variables of system speakers versus

headphones, volume level and screen brightness level.

Hint

Battery duration may vary depending on the type of content being played or usage conditions such as screen brightness and environmental factors. As battery ages, anticipate lower battery duration.

Battery pack life

• The battery pack has a limited lifespan. Battery duration will

decrease with repeated usage and age. If the battery duration becomes extremely short, it may be time to replace the battery pack.

• The battery pack lifespan varies depending on how it is stored, the

conditions of use and environmental factors, such as temperature.

Replacing the battery pack

• For safety reasons, turn off the system and remove the power cord

from the electrical outlet before replacing the battery pack.

• If the system is left unused after the battery pack has been removed,

the date and time settings may be reset. If this occurs, the date and time setting screen will be displayed the next time the PSP® system is turned on.

Estimating the battery charge time

When using the supplied battery pack, it takes approximately 2 hours and 20 minutes to fully charge the battery using the AC adaptor after the battery has run out.

Hints

• Charge in a temperature of 10°C to 30°C/50°F to 86°F. Charging may not be as effective in other environments.

• Charging may take longer when the system is turned on during charging.

Precautions

Storing the battery pack

When the system will not be used for an extended period of time, remove the battery pack from the system. Store the battery pack in a cool, dry place out of the reach of children.

Recycling Lithium-Ion Batteries

Lithium-Ion batteries are recyclable. You can help preserve our environment by returning your used rechargeable batteries to the collection and recycling location nearest you.

For more information regarding recycling of rechargeable batteries, call toll free 1-800-822-8837, or visit http://www.rbrc.org/

Caution

Do not handle damaged or leaking Lithium-Ion batteries.

Before use

Precautions

Compatible media

The media types listed below can be used on the PSP® system. Throughout this manual, the term "Memory Stick Duo™" is used to refer to all types of Memory Stick™ media in the table below.

Type Logo

UMD™

Memory Stick Duo™ (not MagicGate™-comp atible)

• If a Memory Stick Duo™ is formatted in a device other than the PSP® system, such as a PC, it is possible that the system will not recognize it. If this happens, go to (System Settings) "Format Memory Stick™" and re-format th e Memory Stick Duo™.

UMD™

UMD™ contain a region code that is assigned to each sales region. This system can play UMD™ marked with either region code "ALL" or "1".

MagicGate™ Memory Stick Duo™

Memory Stick Duo™ (MagicGate™

*1 *2

compatible)

Memory Stick PRO Duo™

*1 Comp atible with MagicGate™ *2 Compatible with high-speed data transfer over a parallel interface. The

actual data-transfer speed will vary depending on the Memory Stick Duo™-compatible device.

Hints

• Performance of all Memory Stick™ media is not guaranteed.

Compatible media

*1 *2

Memory Stick™

There are two sizes of Memory Stick™: the standard size and the smaller size. The PSP® system is compatible with Memory Stick Duo™, the smaller sized type. The standard-size Memory Stick™ cannot be used with the system.

Memory Stick Duo Adaptor (sold separately)

The Memory Stick Duo Adaptor (MSAC-M2: a Sony product sold separately) allows a Memory Stick Duo™ to be used with devices that take a standard-size Memory Stick™.

Parallel data transfer (high-speed data transfer)

Parallel data transfer is a high-speed data-transfer technology that allows multiple data input/output connectors on the Memory Stick™ to be used at the same time (parallel interface).

MagicGate™-compatible Memory Stick Duo™

MagicGate™-compatible Memory Stick Duo™ media has been designed with an indented area (A) to allow it to be differentiated by touch from Memory Stick Duo™ media that is not MagicGate™-compatible.

Before use

MagicGate

developed by Sony Corporation.

products bearing the "MagicGate" trademark.

is a term of copyright-protection technology

does not guarantee compatibility with other

Compatible media

Troubleshooting

Before requesting service

Go through this section if you experience difficulty in operating the PSP® system. For additional troubleshooting information, visit www.us.playstation.com/support. Should any problem persist, call SCEA Consumer Services at 1-800-345-7669 for assistance.

Power, battery and charging issues

The power does not turn on.

, Check that the battery is charged. , Check that the battery pack is properly inserted.

The battery does not charge, or does not fully recharge.

, Check that the AC adaptor and the AC power cord are properly

inserted in the system and the electrical outlet.

, Check that the WLAN function is not in use while charging. The

battery cannot be recharged when the WLAN function is in use.

, Check that the correct AC adaptor for this product is being used. , Check that the AC adaptor connector is clean. If not, wipe it with

a dry, soft cloth.

, If charging the battery in an extremely cold location, it may take

longer to fully charge the battery.

, There may be a problem with the battery pack. Try using a

replacement battery pack that is marked for use with the PSP® system, if available.

Before requesting service

The battery charge doesn't last long.

, When using the system in extremely hot or cold locations, the

charge may not last as long. Try to avoid using the system in such environments.

, There may be a problem with the battery pack. Try using a

replacement battery pack that is marked for use with the PSP® system, if available.

The power indicator is on, but the LCD screen is not displayed.

, Check that the LCD screen's backlight is not turned off. If it is,

press any of the system buttons to turn on the backlight.

The battery loses its charge even when the system is turned off.

, Because battery power is used even when the system is turned off,

it is recommended that you charge the battery frequently.

Screen

The screen suddenly turns dark.

, If "Backlight Auto-Off" under (Power Save Settings) has been

set, the LCD screen's backlight will automatically turn off if the system is left inactive for the set amount of time.

, If "Auto Sleep" under (Power Save Settings) has been set, the

system will automatically enter sleep mode if left inactive for the set amount of time.

The screen is dark and hard to see.

, The screen may appear dark, depending on the angle of viewing.

Use the display button on the system front to adjust the brightness.

Black or continuously lit pixels on the screen do not disappear.

, LCD screens are made with highly precise technology, but in some

cases, black (dark) pixels or continuously lit pixels may appear on the screen. This is not a system malfunction. For details, see "Precautions" ( page 7).

The color of the screen does not look right.

, If "Theme" under (Theme Settings) is set to "Original", the

background color will automatically change at the beginning of each month.

Sound

There is no sound.

, Check that the volume is not set to zero. Try raising the volume. , Check that the mute setting is not on. Press the sound button on the

system front to clear the mute setting.

, When headphones are connected, no sound is output from the

system speakers.

, See also "There is no sound, or the sound quality from the

headphones is poor." ( page 19).

The volume does not turn up.

, If "AVLS" under (Sound Settings) is set to "On", the

maximum volume level is restricted.

Sound quality is poor.

, If the system is used in an area where there are vibrations, or if it

is near strong magnetic objects such as a television, the sound may be distorted and there may be increased background noise. Try moving the system to a different location.

UMD™

The system does not recognize the UMD™.

, Check that the UMD™ is properly inserted (label is facing the

system rear, etc.). Try taking out the UMD™ and reinserting it.

, Check that the UMD™ recorded surface is clean. If not, wipe it

gently with a soft cloth.

The UMD™ doesn't play properly.

, If moisture condensation occurs, remove the UMD™ from the

system and do not use the system for several hours until the condensation evaporates.

Upon starting a UMD™, a message recommending an update is displayed.

, Update the system software. For details on updates, refer to the

Quick Reference booklet supplied with the system.

Memory Stick Duo™

The Memory Stick Duo™ cannot be inserted.

, Set the Memory Stick Duo™ in the proper direction when

inserting.

The system does not recognize the Memory Stick Duo™.

, If Memory Stick Duo™ media is formatted using a PC, it may not

be recognized by the PSP® system. If this happens, copy any data you want to keep on the PC, and then go to (System Settings)

"Format Memory Stick™" and re-format.

, Check that the Memory Stick Duo™ is properly inserted. Try

taking out the Memory Stick Duo™ and reinserting it.

Before requesting service

Troubleshooting

, Check that the Memory Stick Duo™ connector is clean. If not, the

data may not load properly. Wipe the connector with a cotton swab.

The system can't save or load data.

, Check that there is sufficient free space on the Memory Stick

Duo™ to save data.

, There may be a problem with the Memory Stick Duo™. Try using

another Memory Stick Duo™, if available.

Video

The UMD™VIDEO does not operate.

, If the playback conditions have been set by the software

developer, the UMD™VIDEO may not play as described in this manual.

Videos do not play.

, Depending on the bit rate, certain videos may not be playable on

the system. Check that the video files were converted at a bit rate of 768 kbps or lower.

The system does not recognize a video data item.

, Video data of types that are not compatible with the system will

not be recognized.

, If the file or folder name on the Memory Stick Duo™ is changed,

or if the file or folder is moved to another location using a PC, the system may not recognize it.

Before requesting service

Music

Music does not play.

, Tracks with an expiration date or a limited number of playing

times may not be playable on the system.

, In some cases, copyright-protected music data cannot be played.

Tracks from other groups do not play.

, Check that the Group Mode feature is turned off. When turned on,

tracks from only one group can be played.

The system does not recognize music data.

, Check that the music data is saved in the correct folder on the

Memory Stick Duo™. For details, refer to the user's guide ( page 6).

, Music data of types that are not compatible with the system will

not be recognized.

A group on a Memory Stick Duo™ cannot be deleted.

, If there is non-music data in the group, the group cannot be

deleted.


Images do not display.

, Depending on the image data size, certain images are not

viewable.

, If images are edited using a PC, they may not be viewable.

The system does not recognize the image data.

, Check that the data is saved in the correct folder on the Memory

Stick Duo™. For details, refer to the user's guide ( page 6).

, If the file or folder name on the Memory Stick Duo™ is changed,

or if the file or folder is moved to another location using a PC, the system may not recognize it.

, Images that are not compatible with the PSP® system will not be

recognized.

A folder on a Memory Stick Duo™ cannot be deleted.

, If there is non-image data in the folder, the folder cannot be

deleted.

Network

A connection to the network cannot be established.

, Check that the WLAN switch on the left side of the system is

turned on.

, If "WLAN Power Save" under (Power Save Settings) is set to

"On", you may not be able to transmit data correctly.

, There may be too much distance between the system and the

access point or the system and the other player.

, Check that the network settings are correct. Refer to the

instructions supplied with the network equipment and by your Internet service provider to make the correct network settings.

, Depending on the access point setting, you may need to enter the

system's MAC address. You can check the MAC address under

(System Settings) "System Information".

, When communicating with another system in ad hoc mode, both

systems must be set to the same channel. You can check the currently set channel under (Network Settings) "Ad Hoc Mode".

The Web page won't display properly.

, Some Web pages may not display properly.

Headphones with remote control

There is no sound, or the sound quality from the headphones is poor.

, Check that the headphones are fully inserted into the system. , Check that the headset connector and the headphone plug are

clean. If not, wipe them with a dry, soft cloth.

, See also "There is no sound." ( page 17).

The remote control does not work.

, Check that the headphones are fully inserted in the system. , Check that the remote control is not in hold mode. If it is, clear

hold mode.

Other issues

The system or AC adaptor is warm.

, During use, the system or AC adaptor may become warm. This is

not a malfunction.

The system is turned on, but does not operate.

, Check that the system is not in hold mode. If it is, slide the power/

hold switch up to clear hold mode.

, Try sliding the power/hold switch up and holding until the power

indicator turns off. The system will be completely turned off. Then turn on the system again.

Troubleshooting

Before requesting service

The system does not function properly.

, Static electricity and other similar occurrences may affect the

system's operation. Remove the battery pack and AC adaptor, wait for about 30 seconds and then restart the system.

When the buttons are pressed, there are no key tones.

, If "Key Tone" under (Sound Settings) is set to "Off", no sound

is produced.

The date and time are reset.

, If the battery is not recharged and runs out, or if the battery pack

is replaced, the system date and time settings may be reset. Follow the on-screen instructions to set the time and date.

The PSP® system is not recognized by the PC when connected using a USB cable.

, When using a USB hub or other devices, depending on the

operating environment of the PC, the Memory Stick Duo™ inserted in the system may not be recognized by the PC. Try connecting the system directly to the PC using a USB cable.

You forgot your password.

, If you restore default settings under (System Settings)

"Restore Default Settings", the system password will be reset to "0000". For details, refer to the user's guide ( page 6). Note that if you restore default settings, settings you have adjusted for options other than the system password will also be cleared. Once cleared, these custom settings cannot be restored by the system.

Before requesting service

Limited warranty

LIMITED HARDWARE WARRANTY AND LIABILITY

Sony Computer Entertainment America (SCEA) warrants to the original purchaser that each of the constituent products of this PSP® system shall be free from defects in material and workmanship for a period of one (1) year from the date of purchase (the "Warranty Period"). If one or more of the above-identified products is determined to be defective during the Warranty Period, SCEA's liability shall be limited to the repair or replacement of this product with a new or refurbished product at SCEA's option. For the purpose of this Limited Warranty, "refurbished" means a product that has been returned to its original specifications. You must call 1-800-345-7669 to receive instructions, and then must deliver the product, freight prepaid, to the authorized service facility specified to obtain repair/replacement services.

THIS WARRANTY SHALL NOT APPLY IF THIS PRODUCT: (a) IS USED WITH PRODUCTS NOT SOLD OR LICENSED BY SCEA (INCLUDING, BUT NOT LIMITED TO, NON-LICENSED GAME ENHANCEMENT DEVICES, CONTROLLERS, ADAPTORS AND POWER SUPPLY DEVICES) OR OTHERWISE NOT COMPATIBLE WITH THIS PRODUCT; (b) IS USED FOR COMMERCIAL PURPOSES (INCLUDING RENTAL) OR IS MODIFIED OR TAMPERED WITH; (c) IS DAMAGED BY ACTS OF GOD, MISUSE, ABUSE, NEGLIGENCE, ACCIDENT, WEAR AND TEAR, UNREASONABLE USE, OR BY OTHER CAUSES UNRELATED TO DEFECTIVE MATERIALS OR WORKMANSHIP; (d) HAS HAD THE SERIAL NUMBER ALTERED, DEFACED OR REMOVED; (e) HAS HAD THE WARRANTY SEAL ON THE SYSTEM ALTERED, DEFACED OR

REMOVED; OR (f) IF AN UNAUTHORIZED PROGRAM I S USED TO ALTER THE SYSTEM SOFTWARE. THIS WARRANTY DOES NOT COVER PRODUCTS SOLD AS IS OR WITH ALL FAULTS, OR CONSUMABLES (SUCH AS BATTERIES). PROOF OF PURCHASE IN THE FORM OF A BILL OF SALE OR RECEIPTED INVOICE WHICH IS EVIDENCE THAT THE UNIT IS WITHIN THE WARRANTY PERIOD MUST BE PRESENTED TO OBTAIN WARRANTY SERVICE.

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. ANY APPLICABLE IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. IN NO EVENT SHALL SCEA BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS P RODUCT. SOME STATES OR PROVINCES DO NOT ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS AND SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATIONS OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSION MAY NOT APPLY TO YOU.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province. This warranty is valid only in the United States and Canada.

The warranty offered by Sony Computer Entertainment America on your PSP® system is the same whether or not you register your product.

Limited warranty

LIMITED HARDWARE WARRANTY AND LIABILITY

Service policy

SCEA's policy with regards to product servicing is as follows:

The following measures may be taken during the product service process. By submitting for product servicing you agree to accept these measures.

• The PSP® system software will be updated.

• Protective stickers or seals that have been placed on the system by customers may be removed.

• PSP® system settings may be changed.

LIMITED HARDWARE WARRANTY AND LIABILITY

Additional information

Specifications

Design and specifications are subject to change without notice.

PSP® (PlayStation®Portable) system

LCD screen

Sound Stereo speakers

Internal disc drive Read-only UMD™ drive

Interface

Power source

Maximum power consumption

4.3 inches (16:9) full-transparent type, TFT drive Approximately 16,770,000 colors displayed

DC IN 5V connector Charging terminals Headset connect or IR port Hi-Speed USB DC OUT connector Memory Stick Duo™ slot Wireless LAN (IEEE 802.11b)

AC adaptor: DC 5.0 V Rechargeable battery pack: Lithium-Ion rechargeable battery pack

Approx. 6 W (when charging)

External dimensions

Weight

Operating environment temperature

Compatible codecs

Approx. 170 × 23 × 74 mm / 6 ¾ × 1 × 3 in (width × height × depth) (excludes largest projection)

Approx. 280 g / 10 oz (including battery pack)

5°C - 35°C / 41°F - 95°F

Video:

H.264/MPEG-4 AVC Main Profile

UMD™

Memory Stick™

Level 3

Music:

H.264/MPEG-4 AVC Main Profile Level 3, Linear PCM, ATRAC3plus™

For details, refer to the user's guide ( page 6).

UMD™ laser

Wave length 655 - 665 nm

Power Max. 0.28 mW

Type Semiconductor, continuous

Additional information

Specifications

Wireless LAN

Standard IEEE 802.11b

Security

Modulation format DS-SS (IEEE 802.11b compliant)

WEP (128-bit/64-bit) WPA-PSK (TKIP) WPA-PSK (AES)

AC adaptor

Input AC 100-240 V, 50/60 Hz

Output DC 5 V, 2000 mA (2A)

Approx. 46 × 22 × 76 mm / 1

External dimensions

Weight Approx. 100 g / 3.53 oz

(width × height × depth) (excludes largest projection)

Battery pack

Battery type Lithium-ion rechargeable battery

Voltage DC 3.6 V

Capacity 1800 mAh

Specifications

Memory Stick Duo™ (supplied with the Value Pack)

• Compatible with MagicGate™

• Supports parallel data transfer (high-speed data transfer). This type of high-speed data transfer can be used only with compatible devices. Transfer speed will vary depending on the device used.

• Includes capacity that can a ctually be used (user capacity) and space reserved for system files. The user capacity of the supplied product is approximately 30 MB.

Software

Software developed by the NetBSD Foundation, Inc. and its contributors is used for the communication functions of this product.

5 ×

5 × 3 in

For more information, see http://www.scei.co.jp/psp-license/pspnet.txt

This product adopts S3TC texture compression technology under license from S3 Graphics, Co., Ltd.

This product includes RSA BSAFE® Cryptographic software from RSA Security Inc. RSA, BSAFE are either registered trademarks or trademarks of RSA Security Inc. in the United States and/or other countries. RSA Security Inc. All rights reserved.

U.S. and foreign patents licensed from Dolby Laboratories.

MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.

+ 56 hidden pages
