Sony KDL-55EX723, KDL-55EX720, KDL-46EX723, KDL-46EX720, KDL-46EX523 User Manual

...

Download

i-Manual online

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Print Font Size

Top Page

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

KDL-60EX720/55EX720/46EX720/40EX720/32EX720

Trademark information

i-Manual online

Print Font Size

Top Page > How to Use i-Manual

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

How to Use i-Manual

Displays the on-screen instruction manual (this manual).

Displays the on-screen instruction manual (this manual). Please review the Setup Guide (Operating Instructions) accompanying this television for

important information on usage.

Indicators on the i-Manual screen

: Previous page indicator : Previous layer indicator

: Next page indicator

Color button operation indicator

i-Manual operations

To return to the previous layer/proceed to the next layer, press / . To step through pages, press To jump to the top page of i-Manual, press the corresponding color button. To bookmark the page/remove bookmark, press the corresponding color button. To operate the TV or change settings, press i-MANUAL to exit i-Manual.

Some features can be started directly from the i-Manual. Press to start the feature when [Use this feature] is displayed at the bottom of the screen.

/ .

Return to Top

i-Manual online

How to Use i-Manual

“BRAVIA” TV Features

Print Font Size

Top Page > “BRAVIA” TV Features

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

3D Feature Presence Sensor “BRAVIA” Internet Video Wireless LAN Ready “BRAVIA” Sync with “Control for HDMI” Skype Ready TrackID™/Music Search/Video Search

Return to Top

i-Manual online

How to Use i-Manual

Watching TV

Print Font Size

Top Page > Watching TV

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

3D Feature Rovi On Screen Guide™ Favorites Wide Mode Picture Mode Photos/Music/Videos Twin Picture (PIP) Twin Picture (P&P)

Return to Top

i-Manual online

How to Use i-Manual

Settings/Home Menu

Print Font Size

Top Page > Settings/Home Menu

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

About the Home Menu

Settings

Picture & Display Sound Preferences i-Manual Channels & Inputs Network Product Support

Return to Top

i-Manual online

How to Use i-Manual

Using Other Equipment/Internet

Print Font Size

Top Page > Using Other Equipment/Internet

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

VCR/DVD Player Audio System USB Device (e.g. Digital Camera) Picture Frame HDMI Equipment Internet/Wireless LAN Home Network Media Remote PC

Return to Top

i-Manual online

How to Use i-Manual

Parts Description

Print Font Size

Top Page > Parts Description

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Remote Control

Top Upper Middle Lower Bottom Rear

TV Controls and Indicators

Front Right

Terminals

Rear Right

Return to Top

i-Manual online

How to Use i-Manual

Troubleshooting

Print Font Size

Top Page > Troubleshooting

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Picture Symptoms: General Picture Symptoms: TV Program Picture Symptoms: 3D Picture Symptoms: Connected Equipment Sound Symptoms Wireless Network Connection Symptoms Internet Video Symptoms Internet Widget Symptoms Home Network (DLNA) Symptoms Other Symptoms

Return to Top

i-Manual online

How to Use i-Manual

Bookmarks

Print Font Size

Top Page > Bookmarks

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

How to Use Bookmarks

Return to Top

i-Manual online

Programs/Broadcasts/Channels

Print Font Size

Top Page > Index

Age restriction Auto Program Favorite items

Picture/Display

Current Time External input display settings External input selection Light Sensor Motionflow PC Picture Frame Picture settings

Sound

Audio out settings (external) Headphones settings Sound settings

Initial Setup Recommendations

Presence Sensor Pro Picture Setup Scene Select Screen settings Screen settings (for PC) Screen types Side-by-side picture display Two picture display

Speaker settings TV start-up sound

Remote Control Buttons

3D GUIDE HOME

Connection

Audio System Digital Still Camera HDMI device Home Network

Other Equipment

“BRAVIA” Sync-compatible equipment Digital Still Camera Photo/music/video playback

Network

INTERNET VIDEO TrackID

PC Wired LAN Wireless LAN Adapter (USB)

Slideshow Sync Menu USB Auto Start

DLNA-certified media server

Internet content update Internet Video

Other

Renderer settings Wireless LAN

Auto Shut-off Eco settings Home Menu

Idle TV Standby Power Saving Timer

Return to Top

i-Manual online

“BRAVIA” TV Features

3D Feature Presence Sensor “BRAVIA” Internet Video Wireless LAN Ready “BRAVIA” Sync with “Control for HDMI” Skype Ready TrackID™/Music Search/Video Search

Print Font Size

Top Page > i-Manual online map

Watching TV

3D Feature Rovi On Screen Guide™ Favorites Wide Mode Picture Mode Photos/Music/Videos Twin Picture (PIP) Twin Picture (P&P)

Settings/Home Menu

About the Home Menu

Settings

Picture & Display

Picture Adjustments 3D Settings Screen (for inputs other than a PC) Screen (for PC input) Pro Picture Setup

Sound

Sound Adjustments MTS Audio Speakers Headphone/Audio Out Headphone Speaker Link Audio Out HDMI/DVI Audio Source Key Tone Startup Sound TV Position

Return to Top

Preferences

Scene Select

Eco Clock/Timers Language Region Closed Captions (CC) Parental Lock Info Banner Recommendation Picture Adjustments Lock

Initial Setup i-Manual Channels & Inputs

Manage Inputs

Cable/Antenna

Auto Program

Add Digital Channels

Show/Hide Channels

Edit Channel Labels

Program Information Source

Analog Fine Tune

Video 2/Component Selection

HDMI Settings

USB Auto Start Network

Network Setup

Refresh Internet Content

Home Network Setup Product Support

Contact Sony

Signal Diagnostics

Automatic Software Download

Software Update

Using Other Equipment/Internet

VCR/DVD Player Audio System USB Device (e.g. Digital Camera) Picture Frame HDMI Equipment

Connecting HDMI Equipment Viewing from HDMI Equipment “BRAVIA” Sync with “Control for HDMI”

Internet/Wireless LAN

Wireless LAN Ready Wired LAN Browsing Websites

Return to Top

“BRAVIA” Internet Video

Photomap

What’s New

Home Network

Connecting to a Home Network Renderer Display Settings for Media Servers

Media Server Troubleshooting Media Remote PC

Parts Description

Remote Control

Top

Upper

Middle

Lower

Bottom

Rear

TV Controls and Indicators

Front

Right

Terminals

Rear

Right

Troubleshooting

Return to Top

Bookmarks

How to Use Bookmarks

Return to Top

i-Manual online

Print Font Size

Top Page > Licensing Information

Licensing Information

Macintosh is a trademark of Apple Inc., registered in the U.S. and other countries.

HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Fergason Patent Properties, LLC: U.S. Patent No. 5,717,422 U.S. Patent No. 6,816,141

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Rovi and Rovi On Screen Guide are trademarks of Rovi Corporation and/or its subsidiaries.

The Rovi On Screen Guide system is manufactured under license from Rovi Corporation and/or its subsidiaries.

The Rovi On Screen Guide system is protected by one or more United States patents of Rovi Corporation and/or its subsidiaries.

Rovi Corporation and/or its subsidiaries and related affiliates are not in any way liable for the accuracy or availability of the program schedule information or other data in the Rovi On Screen Guide system and cannot guarantee service availability in your area. In no event shall Rovi Corporation and/or its related affiliates be liable for any damages in connection with the accuracy or availability of the program schedule information or other data in the Rovi On Screen Guide system.

Blu-ray Disc is a trademark.

“BRAVIA” and

, S-Force, BRAVIA Sync, and are trademarks or registered marks of Sony Corporation.

“PlayStation” is a registered trademark and “PS3” is a trademark of Sony Computer Entertainment Inc.

DLNA®, the DLNA Logo and DLNA CERTIFIED® are trademarks, service marks, or certification marks of the Digital Living Network Alliance.

TrackID is a trademark or registered trademark of Sony Ericsson Mobile Communications AB.

Music and video recognition technology and related data are provided by Gracenote®. Gracenote is the industry standard in music recognition technology and related content delivery. For more information, please visit

www.gracenote.com.

CD, DVD, Blu-ray Disc, and music and video-related data from Gracenote, Inc., copyright © 2000-present Gracenote. Gracenote Software, copyright © 2000-present Gracenote. One or more patents owned by Gracenote apply to this product and service. See the Gracenote website for a nonexhaustive list of applicable Gracenote patents. Gracenote, CDDB, MusicID, MediaVOCS, the Gracenote logo and logotype, and the “Powered by Gracenote” logo are either registered trademarks or trademarks of Gracenote in the United

States and/or other countries.

Your BRAVIA TV is ENERGY STAR® qualified in the “Home” mode.

It meets strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and Department of Energy. ENERGY STAR is a joint program of these government agencies, designed to promote energy efficient products and practices.

Changes to certain features, settings, and functionalities of this TV (i.e. Rovi On Screen Guide, Picture/Sound, Light Sensor, Power Savings) can increase or change the power consumption.

Depending upon such changed settings, the power consumption may exceed the limits required for the ENERGY STAR qualification in the “Home” mode.

Applicable trademark information depends on your TV model/region/country.

Return to Top

i-Manual online

Print Font Size

Top Page > “BRAVIA” TV Features > 3D Feature

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

3D Feature

Brings you the experience of 3D (threedimensional) pictures and graphics using 3D Glasses.

This feature lets you experience powerful 3D entertainment, such as stereoscopic 3D games and 3D Blu-ray Discs.

Turn the 3D Glasses on, then put them on to watch 3D content.

3D Glasses TDG - BR250

3D effect is available only when pictures are displayed in full screen. Additional viewers with 3D Glasses can also enjoy 3D content. The 3D Glasses are supplied or available as an optional accessory, depending on your TV model.

In some regions/countries, the 3D Glasses may not be available. The 3D Glasses TDG-BR250 may not be available in some regions/countries. If unavailable, use

other compatible 3D Glasses. If [Motionflow] is set to other than [Off], the smooth movement of the picture may be lost as the

picture process to minimize screen flicker is applied. In such a case, set [Motionflow] to [Off] to display the original picture.

Watching the following pictures in 3D

Regular 2D picture Side-by- side picture Over-under picture

1. Press 3D to display the 3D Menu.

2. Press 3D repeatedly to toggle through [3D Display] modes.

[Simulated 3D]: Displays regular 2D pictures in simulated 3D. [Side-by-Side]: Displays side-by-side pictures in 3D. [Over-Under]: Displays over-under pictures in 3D. [Off]: Displays pictures as they are.

3. Press RETURN to exit the 3D Menu.

Simulated 3D effect may be less pronounced with some picture sources. Perceived simulated 3D effect may vary from person to person. Simulated 3D display mode automatically switches back to 2D display mode an hour after its

activation.

Watching 3D content in 2D

Press 3D to display the 3D Menu.

2. Press 3D to select [Off] in [3D Display].

3. Press RETURN to exit the 3D Menu.

The 3D display mode is automatically selected when a 3D signal is detected. To prevent 3D display mode from being automatically selected when a 3D signal is detected,

press HOME, then select

→ [Picture & Display] → [3D Settings] → [Auto 3D] → [Off].

3D Sync Transmitter and 3D Glasses communication range

The recommended viewing angle and distance are shown in the illustrations. To enjoy the best 3D effect, the preferred viewing position needs to be kept within the range where the 3D Sync Transmitter works.

Side viewOverhead view

45°

120°

1-6 m (3-20 ft.)

3D Sync Transmitter

Recommended viewing angle and distance may vary depending on the TV’s location and room conditions.

Do not put anything in front of the 3D Sync Transmitter. Doing so may affect its function. Signals between the 3D Sync Transmitter and 3D Glasses may be interrupted if an infrared device

is used near the TV.

1-6 m (3-20 ft.)

30°

3D Menu

You can adjust the following settings from the 3D Menu.

Press 3D, then select the desired setting → the desired option.

3D Display

When 3D pictures are displayed: Switches between the 3D and 2D display modes. When non-3D pictures are displayed: [Simulated 3D]: Displays regular 2D pictures in simulated 3D. [Side-by-Side]: Displays side-by-side pictures in 3D.

Two near-identical pictures for 3D viewing are displayed side-by-side.

[Over-Under]: Displays over-under pictures in 3D.

Two near-identical pictures for 3D viewing are displayed one above the other.

[Off]: Displays pictures as they are.

3D Depth Adjustment

Adjusts the depth of 3D pictures on the screen.

Available only for content with 3D signals. Selecting [0] is recommended for normal use. 3D effect may be less pronounced depending on the settings.

Simulated 3D Effect

Heightens/lessens the 3D effect when you display 2D pictures in simulated 3D.

3D Glasses Brightness

Sets the image brightness when using 3D display mode.

By selecting [Auto], image brightness through the 3D Glasses is automatically adjusted in conjunction with the [Picture Mode] setting.

Return to Top

i-Manual online

Print Font Size

Top Page > “BRAVIA” TV Features > Presence Sensor

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Presence Sensor

Reduces power consumption by automatically turning the picture off and switching the TV to standby mode when no viewer is detected.

This feature reduces power consumption by monitoring a viewer presence via the built-in sensor. When no viewer is detected in front of the TV for a preset time, the picture automatically turns off, while leaving only the TV sound on. Additionally, after 30 minutes in picture off mode, the TV will switch to standby mode.

To set [Presence Sensor], press HOME, then select

Sensor] → the desired option.

→ [Preferences] → [Eco] → [Presence

Presence Sensor detection range

Overhead view

6 m (20 ft.)

Presence Sensor

80°

Sensor detection range illustrated in the figure is based on normal room conditions. Even if a person is in front of the TV, the sensor may not detect anything if the person does not

Side view

6 m (20 ft.)

30°

move.

The sensor may not work when the ambient temperature changes due to air conditioning, etc. The sensor is sensitive to movement from side to side and up and down and is less sensitive to

the viewer’s forward or backward movement. Sensor detection range may vary depending on the TV’s location, room temperature and lighting

conditions.

Return to Top

i-Manual online

Print Font Size

Top Page > “BRAVIA” TV Features > “BRAVIA” Internet Video

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

“BRAVIA” Internet Video

Brings videos, movies and much more through the broadband Internet connection to your TV.

This feature serves as a gateway to Internet content, delivering a variety of on-demand entertainment straight to your TV. You can enjoy video content, including movies and cartoons.

1. Make a broadband Internet connection.

For details, see the information on wireless/wired LAN in “Internet/Wireless LAN” in this manual.

2. Press INTERNET VIDEO, then select [BRAVIA Internet Video] → the desired service.

INTERNET

VIDEO

3. Highlight the desired content, then press .

If you experience difficulties with this feature, check that the Internet connection is set up properly. Information about the highlighted icon appears in the information banner. The interface to Internet content depends on the Internet content providers. Services block video content based on the [Parental Lock] setting of the TV. Some service

providers do not support this function. To update “BRAVIA” Internet Video content services, press HOME, then select

[Refresh Internet Content].

→ [Network] →

Seeking forward/backward in video content

Press the buttons on the remote control that correspond with the control indications on the screen.

Control indications

Return to Top

i-Manual online

If your wireless router

Print Font Size

Top Page > “BRAVIA” TV Features > Wireless LAN Ready

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Wireless LAN Ready

Provides a wireless network connection for your TV by inserting a USB Wireless LAN Adapter into your TV’s USB port.

By inserting the USB Wireless LAN Adapter UWA-BR100 (as of December 2010) into your TV’s USB port, you can create a wireless network connection.

USB Wireless LAN Adapter

Internet

Modem Wireless router

(access point)

The USB Wireless LAN Adapter is supplied or available as an optional accessory, depending on your TV model. In some regions/countries, the USB Wireless LAN Adapter may not be available.

If your TV has two USB ports, be sure to connect the USB Wireless LAN Adapter to the upper USB port.

Connecting to your wireless LAN

Set up your wireless router (or access point).

For details, refer to the instruction manual of your wireless router (or access point).

2. Check your wireless LAN environment using the following chart.

Tip for smooth video streaming: Change the setting of your wireless router (or access point) to

802.11n and 5GHz if possible. For details on how to change the setting, refer to the instruction manual of your wireless router (or access point).

Do you use a secure wireless LAN?

YES →

Do you use a wireless router (or access point) compatible with Wi-Fi Protected Setup (WPS)?

YES →

If your wireless router (or access point) has a WPS button, proceed to TYPE 1.

(or access point) has a

PIN code, proceed to

↓

Proceed to TYPE 4. Proceed to TYPE 3.

↓

TYPE 2.

If your wireless router (or access point) has both a WPS button and PIN code, proceed to TYPE 1.

TYPE 1: Secured network using the WPS button

Check the WPS button location on your wireless router (or access point) and verify how to

use it.

2. Press HOME, then select → [Network] → [Network Setup].

The start-up screen appears.

3. Select [Wireless Setup] → [WPS (Push Button)], then follow the on-screen instructions.

TYPE 2: Secured network using the PIN code

Press HOME, then select → [Network] → [Network Setup].

The start-up screen appears.

2. Select [Wireless Setup] → [WPS (PIN)], then follow the on-screen instructions.

TYPE 3: Secured network using SSID and security key

Check the SSID (wireless network name) and security key (WEP or WPA key) of your

wireless router (or access point). If you do not know them, refer to the instruction manual of your wireless router (or access point).

2. Press HOME, then select → [Network] → [Network Setup].

The start-up screen appears.

3. Select [Wireless Setup] → [Scan].

4. Select a network from the list of scanned wireless networks, then follow the on-screen

instructions.

TYPE 4: Unsecured network using only SSID

Check the SSID (wireless network name).

If you do not know the SSID, refer to the instruction manual of your wireless router (or access point).

2. Press HOME, then select → [Network] → [Network Setup].

The start-up screen appears.

3. Select [Wireless Setup] → [Scan].

4. Select a network from the list of scanned wireless networks, then follow the on-screen

instructions.

Return to Top

i-Manual online

Print Font Size

Top Page > “BRAVIA” TV Features > “BRAVIA” Sync with “Control for HDMI”

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

“BRAVIA” Sync with “Control for HDMI”

Helps communicate with “BRAVIA” Synccompatible equipment (e.g. BD player, AV amplifier) using HDMI CEC.

With the “Control for HDMI” function, “BRAVIA” Sync helps communicate with “BRAVIA” Synccompatible equipment using HDMI CEC (Consumer Electronics Control).

Activating “Control for HDMI” (“BRAVIA” Sync)

Press HOME, then select → [Channels & Inputs] → [HDMI Settings] → [Control for

HDMI] → [On].

2. Activate “Control for HDMI” on the connected equipment.

For details, refer to the instruction manual of the connected equipment.

“Control for HDMI” (“BRAVIA” Sync) is only available for the connected Sony equipment that has the “BRAVIA” Sync logo or is compatible with “Control for HDMI.”

When specific Sony equipment compatible with “Control for HDMI” (“BRAVIA” Sync) is connected and powered on, and [Control for HDMI] is set to [On], “BRAVIA” Sync is automatically activated on the equipment.

Available “BRAVIA” Sync operations

BD/DVD player

Automatically turns the “BRAVIA” Sync-compatible equipment on and switches the input to that equipment when you select it from the Home Menu or Sync Menu.

Automatically turns the TV on and switches the input to the connected equipment when the equipment starts to play.

Automatically turns the connected equipment off when you turn the TV off. Controls menu operation (

connected equipment through the TV’s remote control.

AV amplifier

Automatically turns the connected AV amplifier on and switches the sound output from the TV speaker to the audio system when you turn the TV on. This function is only available if you have previously used the AV amplifier to output TV sound.

/ / / ), playback (e.g. , ) and channel selection of the

Automatically switches the sound output to the AV amplifier by turning the AV amplifier on when

the TV is turned on. Automatically turns the connected AV amplifier off when you turn the TV off. Adjusts the volume (VOL +/–) and mutes the sound (MUTING) of the connected AV amplifier

through the TV’s remote control.

When connecting a digital audio system that is compatible with Audio Return Channel (ARC) technology, connect to HDMI IN 1 with an HDMI cable. If connecting a system that is incompatible with “Control for HDMI” or Audio Return Channel, an additional audio connection via DIGITAL AUDIO OUT (OPTICAL) is necessary.

Video camera

Automatically turns the TV on and switches the input to the connected video camera when the connected video camera is turned on.

Automatically turns the connected video camera off when you turn the TV off. Controls menu operation (

connected equipment through the TV’s remote control.

/ / / ), playback (e.g. , ) and channel selection of the

Controlling “BRAVIA” Sync- compatible equipment

You can control “BRAVIA” Sync-compatible equipment by the TV’s remote control.

Press SYNC MENU, then select [HDMI Device Selection] → the desired equipment.

SYNC MENU

Any “BRAVIA” Sync-compatible equipment (except audio system) is listed as a new input source under

[Inputs] in the Home Menu.

Sync Menu

Sync Menu provides the following items. Press SYNC MENU, then select the desired item.

HDMI Device Selection

Enables selection of “BRAVIA” Sync-compatible equipment to control by the TV’s remote control.

Device Control

Displays the menu, options and title list of the connected equipment, or turns the equipment off.

Speakers

Switches the speaker output between the TV and connected audio equipment.

TV Control

Displays the menu and options of the TV, or shows/hides the display items on the TV screen.

Return to TV

Returns to the TV tuner.

Return to Top

i-Manual online

Print Font Size

Top Page > “BRAVIA” TV Features > Skype Ready

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Skype Ready

Enjoy free Skype™-to-Skype voice and video calls to friends and family anywhere in the world with a compatible TV webcam and an Internet connection.

Skype allows you to make free video and voice calls from the comfort of your living room. Enjoy widescreen video calls by connecting the optional Camera and Microphone Unit CMU-BR100. Note that a stable Internet connection is also required.

You can use your existing Skype account or create a new one on your TV. Select [Skype] in the [Applications] menu, connect your TV camera, log in and start enjoying widescreen video calls from your living room.

If you want to call a friend who is not on Skype, you could make great savings by calling them on their landline or mobile using Skype.

To use this feature, the TV has to be connected to the Internet. For more information on Skype, please visit

http://www.Skype.com/

No emergency calls. Skype is not a replacement for your telephone and can’t be used for emergency calling.

Skype may not be available while some other applications are being used. Use of a wireless network connection may cause audio/image degradation. Connect the optional Camera and Microphone Unit directly to the TV’s USB port. Do not connect it

via a USB hub. Audio and video calls are free to other people on Skype. For other Skype services such as low

cost calls to mobile phones and landlines, Skype Credit or a subscription is required. Skype is a trade mark of Skype Limited or its related companies. This product / application has not

been checked, verified, certified or otherwise approved or endorsed by Skype Limited, Skype Communications S.a.r.l. or any of their related companies.

Skype, associated trade marks and logos and the “S” symbol are trade marks of Skype Limited.

The sound quality of the microphone may deteriorate in a noisy environment.

How to use Skype on your TV

Using Skype while watching TV

With the menu screen displayed on the right, you can operate Skype even while watching TV. It is easy to start a Skype call by selecting a contact from your contact list or history.

Receiving a call while watching TV

A message window notifies you of an incoming call, allowing you to answer the call.

Connecting the optional Camera and Microphone Unit CMU-BR100

Attach the camera to the top (or rear) of the TV, then connect the USB cable to the TV’s USB port.

The Camera and Microphone Unit captures your voice.

Creating your Skype account (required only if you have no account yet)

Press HOME, then select → [Skype].

2. Follow the on-screen instructions to create your account.

About the status icons in the Home Menu

When [Skype] in [Applications] of the Home Menu is selected, a status icon appears next to [Skype], indicating the status of your Skype account. Each status icon indicates as follows:

: Auto Sign in error, : Online, : Away, : Do Not Disturb, : Invisible

Making a call

Voice and video calls can be initiated in a couple of different ways.

From your Skype contact list

Select a contact or phone number from the contact list. Press HOME, then select

contact/phone number to call → [Video Call]/[Voice Call].

You can add contacts to the contact list from the call history list, after dialing a phone number, or finding a contact from the Skype directory.

Status Icons: A status icon is displayed next to your contacts, so you know if they are available to have a conversation. The list below indicates their availability:

: Online, : Away, : Do Not Disturb, : Offline, : Offline (with call forwarding

enabled),

Using the call history list

Select a contact or phone number from the call history list. Press HOME, then select

number to call → [Video Call]/[Voice Call].

: Phone contact, : Offline (with voice mail enabled), : Pending authorization

→ [Skype] → [Contacts] → the

→ [Skype] → [History] → the contact/phone

The icons in the history list indicate the following:

: Missed call, : Incoming call, : Outgoing call, : Voice mail, : Authorization

request

Dialing a phone number

Enter a phone number using the dial pad.

1. Press HOME, then select Number].

2. Enter a phone number, then select [Call].

Adding new Skype friends to your contact list

Search the Skype directory by entering the Skype name, full name or e-mail address of the person to call.

1. Press HOME, select

2. Enter a Skype name, full name or e-mail address, then select [Search] → the contact/phone

number to call → [Video Call]/[Voice Call].

→ [Skype] → [Tools] → [Call Phone

→ [Skype] → [Tools] → [Find Contacts].

Receiving a call

You can receive a call even while watching TV or using other applications. When the following screen notifies you of an incoming call, select [Video Call] or [Voice Call] to

answer.

While using another application, an incoming call notification is displayed using the full screen.

Features/options

Use the menu bar at the bottom of the screen for call options.

Menu bar

For the best audio quality during a Skype call, use the speakers that are built into the TV instead of using an external audio system. To use the TV speakers, press OPTIONS, then select

[Speakers] → [TV Speakers].

When the other party is displayed in full screen, you can show/hide the menu bar by pressing DISPLAY.

Return to Top

i-Manual online

Print Font Size

Top Page > “BRAVIA” TV Features > TrackID™/Music Search/Video Search

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

TrackID™/Music Search/Video Search

Searches for information about music heard from your TV, video, and related information by exploring the database.

TrackID™

This feature searches for information about music heard from your TV. You can obtain information about music played on the current program, external input, connected USB storage device, etc.

1. While music is playing, press TrackID.

A message appears displaying the number of search results. The search results are stored in [Bookmarks].

TrackID

2. Press to launch the [Music Search] application for detailed information.

3. Select a search result in the list.

To use this feature, the TV has to be connected to the Internet. After making Internet connection and completing [Network Setup], perform [Refresh Internet Content]. Press HOME, then select

→ [Network] → [Refresh Internet Content].

The search may fail if dialog or sound effects of the current program are too loud. Information may not be obtainable depending on the music.

Music Search/Video Search

[Music Search] extends a TrackID™ search by exploring the database. You can also start a new search for information about other music by entering a keyword (track title, album name and/or artist name).

[Video Search] allows you to search for information about videos by entering a keyword (video

title or cast) and exploring the database. You can use [Video Search] in the same manner as

[Music Search]. To launch the application and start a new search, follow the procedure below.

1. Press HOME, then select → [Music Search] or [Video Search].

2. Select [Text Search] → [New Search].

3. For [Music Search]: Enter a keyword.

For [Video Search]: Select [Video Title] or [Cast Member], then enter a keyword.

The [Music Search] screen is used as an example.

Artwork

Displays image of selected item (e.g. album jacket).

Content tabs

In case of [Music Search]: Enables access to information about track, artist, and album.

In case of [Video Search]: Enables access to information about video, cast, and content-related links.

Details

Displays details about the selected tab.

Search Apps/Add to Bookmarks

[Search Apps]: Enables a search for related content in other applications. [Add to Bookmarks]: Adds the currently displayed item to Bookmarks for later

viewing.

Bookmarks

In case of [Music Search]: Lists TrackID™ search results and items previously added to Bookmarks. In case of [Video Search]: Lists results previously added to Bookmarks.

History

Lists a history of viewed items.

Text Search

Searches for information via keyword (e.g. track title, artist name, video title).

Managing Bookmarks

You can delete a Bookmark, or protect it from being automatically deleted when the maximum

number of Bookmarks is exceeded.

To add Bookmarks:

1. Select [Track]/[Artist]/[Album] in the [Music Search] application, or [Video]/[Cast] in the [Video

Search] application.

2. Select [Add to Bookmarks].

To delete a single Bookmark:

1. In the [Music Search]/[Video Search] application, select [Bookmarks] → the Bookmark to

delete.

2. Press OPTIONS, then select [Delete].

To delete all Bookmarks:

1. In the [Music Search]/[Video Search] application, select [Bookmarks].

2. Press OPTIONS, then select [Delete All].

Protected Bookmarks will not be deleted.

To protect a Bookmark:

1. In the [Music Search]/[Video Search] application, select [Bookmarks] → the Bookmark to

protect.

2. Press OPTIONS, then select [Protect].

To unprotect a Bookmark:

1. In the [Music Search]/[Video Search] application, select [Bookmarks] → the Bookmark to

unprotect.

2. Press OPTIONS, then select [Unprotect].

Return to Top

i-Manual online

Print Font Size

Top Page > Watching TV > 3D Feature

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

3D Feature

Brings you the experience of 3D (threedimensional) pictures and graphics using 3D Glasses.

This feature lets you experience powerful 3D entertainment, such as stereoscopic 3D games and 3D Blu-ray Discs.

Turn the 3D Glasses on, then put them on to watch 3D content.

3D Glasses TDG - BR250

In some regions/countries, the 3D Glasses may not be available. The 3D Glasses TDG-BR250 may not be available in some regions/countries. If unavailable, use

other compatible 3D Glasses. If [Motionflow] is set to other than [Off], the smooth movement of the picture may be lost as the

picture process to minimize screen flicker is applied. In such a case, set [Motionflow] to [Off] to display the original picture.

Watching the following pictures in 3D

Regular 2D picture Side-by- side picture Over-under picture

1. Press 3D to display the 3D Menu.

2. Press 3D repeatedly to toggle through [3D Display] modes.

3. Press RETURN to exit the 3D Menu.

activation.

Watching 3D content in 2D

Press 3D to display the 3D Menu.

2. Press 3D to select [Off] in [3D Display].

3. Press RETURN to exit the 3D Menu.

The 3D display mode is automatically selected when a 3D signal is detected. To prevent 3D display mode from being automatically selected when a 3D signal is detected,

press HOME, then select

→ [Picture & Display] → [3D Settings] → [Auto 3D] → [Off].

3D Sync Transmitter and 3D Glasses communication range

Side viewOverhead view

45°

120°

1-6 m (3-20 ft.)

3D Sync Transmitter

Recommended viewing angle and distance may vary depending on the TV’s location and room conditions.

Do not put anything in front of the 3D Sync Transmitter. Doing so may affect its function. Signals between the 3D Sync Transmitter and 3D Glasses may be interrupted if an infrared device

is used near the TV.

1-6 m (3-20 ft.)

30°

3D Menu

You can adjust the following settings from the 3D Menu.

Press 3D, then select the desired setting → the desired option.

3D Display

Two near-identical pictures for 3D viewing are displayed side-by-side.

[Over-Under]: Displays over-under pictures in 3D.

Two near-identical pictures for 3D viewing are displayed one above the other.

[Off]: Displays pictures as they are.

3D Depth Adjustment

Adjusts the depth of 3D pictures on the screen.

Available only for content with 3D signals. Selecting [0] is recommended for normal use. 3D effect may be less pronounced depending on the settings.

Simulated 3D Effect

Heightens/lessens the 3D effect when you display 2D pictures in simulated 3D.

3D Glasses Brightness

Sets the image brightness when using 3D display mode.

By selecting [Auto], image brightness through the 3D Glasses is automatically adjusted in conjunction with the [Picture Mode] setting.

Return to Top

i-Manual online

Print Font Size

Top Page > Watching TV > Rovi On Screen Guide™

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Rovi On Screen Guide™

Provides up to 24 hours of program information and easy personalization of program listings.

This feature provides up to 24 hours of program information and easy personalization of program listings. You can search for programs by category or keyword.

Press GUIDE to display the program guide.

GUIDE

To change the information source for program information (to Broadcaster or to Guide), press HOME, then select setting.

When [Broadcaster] is selected for the source of program information, the TV will not display a program guide, but each individual program will have program information shown onscreen when the channel is tuned.

Rovi On Screen Guide is available with connection to your cable service or with over-the-air antenna signal.

You must connect your signal directly to the TV’s CABLE or ANTENNA input without using a settop box.

Be sure to complete the initial setup to use this feature. DAM (Download Acquisition Mode) is used for software updates and/or collecting data for Rovi On

Screen Guide. When DAM is activated, power consumption may increase.

→ [Channels & Inputs] → [Program Information Source] → the desired

Video preview window

Displays the last viewed TV channel before entering the guide. You can also set this to preview the program that is selected within the program listings.

Information box

Shows detailed program information.

Rovi On Screen Guide menu area

Enables selection of the following features.

[TV Listings]: Shows up to 24 hours of program listings, and organizes the program listings by category.

[Browse/Search]: Searches for programs by browsing through categories, or by entering a keyword or title.

[Ads]: Provides advertisements from Rovi On Screen Guide sponsors. [Settings]: Adjusts the settings for the Rovi On Screen Guide. [My TV]: Organizes the program listings.

Ad panels

Provides advertisements from Rovi On Screen Guide sponsors.

Channel logo

Displays the broadcaster’s channel logo.

Listings grid

Enables selection of a program to watch or to obtain program information.

Organizing the program listings – My TV

You can organize the program listings by profile (e.g. Movie, Sport, Kids), and create your own profile to organize your favorite programs, channels or keywords. Select [My TV] from the menu area to launch.

Channels you add to the main profile of [My TV] will automatically appear as your favorite channels in [Favorites/History].

Return to Top

i-Manual online

Print Font Size

Top Page > Watching TV > Favorites

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Favorites

Provides quick access to your frequently used and recently viewed items, such as TV channels, external inputs or your media files.

This feature provides quick access to your frequently used and recently viewed items, such as TV channels or external inputs (e.g. game console, DVD player). You can manage various items including your media files, Internet content and Widgets, and select them from Favorites.

Press HOME, then select

A slideshow automatically starts when a folder of photos is selected. Internet content (e.g. Internet Video, Widgets) may not be available in some regions/countries. Recently viewed items are cleared every time the TV is turned off.

→ the desired item.

Managing Favorites

You can add/remove items in Favorites.

1. Display the desired item, or select one in the Home Menu.

2. Press OPTIONS, then select [Add to Favorites] or [Remove from Favorites].

Return to Top

i-Manual online

Print Font Size

Top Page > Watching TV > Wide Mode

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Wide Mode

Selects a screen format from a range of screen types according to your preferences.

This feature is for you to select a screen format to better fit content you are viewing. Press WIDE repeatedly to select the desired option, then press

WIDE

Based on the original signal source, a black frame or black bars may surround the picture.

Changing the wide mode from 4:3 original source

Wide Zoom

Enlarges the picture to fill a 16:9 screen, preserving the original picture as much as possible.

Normal

Displays a 4:3 picture in its original size. Side bars are shown to fill the 16:9 screen.

Full

Stretches the 4:3 picture horizontally, to fill the 16:9 screen.

Zoom

Displays the cinemascopic (letter box format) picture in the correct proportion.

Captions

Stretches the picture horizontally to fill a 16:9 screen, while fitting captions in the screen.

Changing the wide mode from 16:9 original source

Wide Zoom

Enlarges the picture to fill a 16:9 screen, preserving the original picture as much as possible.

Normal

Displays a picture in its original size.

Full

Displays a 16:9 picture in its original size.

Zoom

Displays the cinemascopic (letter box format) picture in the correct proportion.

Captions

Stretches the picture horizontally to fill a 16:9 screen, while fitting captions in the screen.

Changing the wide screen mode for PC Timing

800 x 600 Normal Full 1 Full 2

1,280 x 768 Normal Full 1 Full 2

Return to Top

i-Manual online

Print Font Size

Top Page > Watching TV > Picture Mode

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Picture Mode

Allows you to select the picture mode according to your preference.

You can select the picture mode according to your preference. Press HOME, then select

the desired option.

→ [Picture & Display] → [Picture Adjustments] → [Picture Mode] →

The option you can select may vary depending on the situation. Unavailable options are grayed out or not displayed.

Return to Top

i-Manual online

Print Font Size

Top Page > Watching TV > Photos/Music/Videos

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Photos/Music/Videos

Plays photos/music/videos in the connected USB storage device or your home network on your TV.

You can play photos/music/videos in the connected USB storage device or your home network on your TV.

1. Connect the USB storage device or connect to your home network.

For details, see “USB Device (e.g. Digital Camera)” or “Connecting to a Home Network” in this manual.

2. Press HOME, then select → [Photos], [Music] or [Videos] → the desired USB device or

media server.

3. Select files or folders to play from the list.

Photo playback automatically starts when you connect a USB storage device after turning on the TV, and [Slideshow] or [Thumbnail View] is selected in the [USB Auto Start] settings. Photo files must be stored in a folder under the DCIM folder for automatic playback start. Also, the folder name under the DCIM folder is required to be a combination of 3 numerals and 5 letters (can include “_”), for example, 101MSDCF.

When connecting a Sony digital camera to the TV with a USB cable, USB connection settings on your camera need to be set to [Auto] or [Mass Storage] mode.

For details on compatible devices, file formats, etc., see “USB Device (e.g. Digital Camera)” or “Connecting to a Home Network” in this manual.

Return to Top

i-Manual online

Print Font Size

Top Page > Watching TV > Twin Picture (PIP)

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Twin Picture (PIP)

Displays two pictures (e.g. PC input and TV program) on the screen simultaneously.

This feature lets you watch two pictures simultaneously. You can have a picture from any input source displayed in full screen, and an input source excluding PC displayed in an inset window.

1. Press OPTIONS, then select the option as follows.

For PC input: Select [Twin Picture].

For other than PC input: Select [Twin Picture] → [PIP].

2. Press / to switch audio output between the two pictures.

Moving the inset window

Press / .

Available combination of two pictures varies depending on your region/country. Available inputs may vary depending on the TV model. If two pictures with different vertical frequency signals (e.g. a picture in full screen with 24p and a

picture in an inset window with 60i) are displayed simultaneously, the smooth movement of the picture in an inset window may be lost.

If [CineMotion] is set to [Auto 1], the smooth movement of the picture in an inset window may be lost. (For [Motionflow] compatible models only.) To remedy this, set to [Auto 2] or [Off]. Press HOME, then select 2]/[Off].

→ [Picture & Display] → [Picture Adjustments] → [CineMotion] → [Auto

Return to Top

i-Manual online

Print Font Size

Top Page > Watching TV > Twin Picture (P&P)

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Twin Picture (P&P)

Provides side-by-side display of two pictures (e.g. connected equipment and TV program).

This feature provides side-by-side display of two pictures. You can simultaneously enjoy, for example, a picture from connected equipment and TV program.

1. Press OPTIONS, then select [Twin Picture] → [P&P].

2. Press / to switch audio output between the two pictures.

The highlighted picture is audible.

Changing the picture size

Press / to select the picture.

2. Press / repeatedly to change the size.

This function is not available with PC input. Available combination of two pictures varies depending on your region/country. If two pictures with different vertical frequency signals (e.g. a left picture with 24p and a right

picture with 60i) are displayed side-by-side, the smooth movement of the right picture may be lost.

Return to Top

i-Manual online

Print Font Size

Top Page > Settings/Home Menu > About the Home Menu

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

About the Home Menu

The Home Menu provides quick access to program listings, input sources, the settings menu of your TV and more.

With the Home Menu, you can customize your TV settings. The Home Menu also provides access to various content, such as TV channels, media files, applications, etc.

1. Press HOME to display the Home Menu.

HOME

Side bar

Categories

2. Press / to select a category.

3. Press / to select an item in the side bar, then press .

Tip on how to configure your TV settings

In the “Settings” section of this manual, you can find instructions on how to access the setting at the left of each description. Use these instructions to help configure your TV settings.

Categories in the Home Menu

The category icons organize your TV settings and TV features for quick and easy access.

Settings Provides the settings that allow you to customize your TV.

Widgets Enables access to Widgets.

Available Widgets depend on your region/country. If Widgets are unavailable, the [Widgets] category is not displayed.

MAC address and IP address are transmitted automatically from the

TV to servers while an Internet connection is available. The servers

are under the control of Sony, and MAC address will never be

transmitted to servers controlled by other parties.

Applications Launches applications such as [Music Search], [Internet Browser],

etc.

Qriocity Enables access to the “Qriocity” online service.

This service is available depending on your region/country.

Internet Content Enables access to Internet services for TV.

Recommendations Presents recommendations for programs you may like, based on

your viewing history.

To show/hide [Recommendations], press HOME, then select →

[Preferences] → [Recommendation] → [On]/[Off].

This function may not be available depending on your region, country and broadcasting conditions.

TV Allows you to select a list of TV channels, or a program guide.

Program guide is available depending on your TV model or region.

Media Enables selection of media files (photo, music, video) to play in a

connected USB storage device or your home network.

Inputs Enables selection of equipment connected to the TV.

Favorites/History Displays items in Favorites and recently viewed items.

The items you can select may vary depending on the situation. Unavailable items are grayed out or not displayed.

Return to Top

i-Manual online

How to Use i-Manual

Picture & Display

Print Font Size

Top Page > Settings/Home Menu > Picture & Display

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Picture Adjustments 3D Settings Screen (for inputs other than a PC) Screen (for PC input) Pro Picture Setup

Return to Top

i-Manual online

How to Use i-Manual

Sound

Print Font Size

Top Page > Settings/Home Menu > Sound

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Sound Adjustments MTS Audio Speakers Headphone/Audio Out Headphone Speaker Link Audio Out HDMI/DVI Audio Source Key Tone Startup Sound TV Position

Return to Top

i-Manual online

How to Use i-Manual

Preferences

Print Font Size

Top Page > Settings/Home Menu > Preferences

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Scene Select Eco Clock/Timers Language Region Closed Captions (CC) Parental Lock Info Banner Recommendation Picture Adjustments Lock Initial Setup

Return to Top

i-Manual online

Print Font Size

Top Page > Settings/Home Menu > i-Manual

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

i-Manual

Displays the on-screen instruction manual (this manual).

Displays the on-screen instruction manual (this manual). Please review the Setup Guide (Operating Instructions) accompanying this television for

important information on usage.

Indicators on the i-Manual screen

: Previous page indicator : Previous layer indicator

: Next page indicator

Color button operation indicator

i-Manual operations

Some features can be started directly from the i-Manual. Press to start the feature when [Use this feature] is displayed at the bottom of the screen.

/ .

Return to Top

i-Manual online

How to Use i-Manual

Channels & Inputs

Print Font Size

Top Page > Settings/Home Menu > Channels & Inputs

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Manage Inputs Cable/Antenna Auto Program Add Digital Channels Show/Hide Channels Edit Channel Labels Program Information Source Analog Fine Tune Video 2/Component Selection HDMI Settings USB Auto Start

Return to Top

i-Manual online

How to Use i-Manual

Network

Print Font Size

Top Page > Settings/Home Menu > Network

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Network Setup Refresh Internet Content Home Network Setup

Return to Top

i-Manual online

How to Use i-Manual

Product Support

Print Font Size

Top Page > Settings/Home Menu > Product Support

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Contact Sony Signal Diagnostics Automatic Software Download Software Update

Return to Top

i-Manual online

Print Font Size

Top Page > Using Other Equipment/Internet > VCR/DVD Player

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

VCR/DVD Player

Connect a VCR or DVD player to your TV. The type of cable depends on your player’s output terminals.

You can connect a VCR or DVD player to your TV. Use a connection cable appropriate for your player’s output terminals.

HDMI connection

VCR/DVD player

HDMI cable (not supplied)

HDMI connection is recommended for optimum picture quality.

Component video connection

VCR/DVD player

Component video

cable (not

supplied)

Audio cable (not supplied)

Composite connection

VCR/DVD player

Composite video/audio cable

(not supplied)

Viewing pictures from connected equipment

Turn on the connected equipment.

2. Press INPUT, then select the desired input source.

INPUT

Return to Top

i-Manual online

Print Font Size

Top Page > Using Other Equipment/Internet > Audio System

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Audio System

Connect an audio amplifier or home theater system with digital input to your TV.

You can connect an audio amplifier or home theater system with digital input to your TV. Use an appropriate connection cable.

Optical audio connection

Audio system

Optical audio cable (not supplied)

HDMI connection

Audio system

HDMI cable (not supplied)

When connecting a digital audio system that is compatible with “Control for HDMI” (“BRAVIA” Sync) and Audio Return Channel (ARC) technology, connect to HDMI IN 1 with an HDMI cable. If connecting a system that is incompatible with “Control for HDMI” or Audio Return Channel, an additional audio connection via DIGITAL AUDIO OUT (OPTICAL) is necessary.

Audio cable connection

Audio system

Audio cable (not supplied)

When using an external audio system, audio out of the TV can be controlled using the TV’s remote control.

To output the sound from the connected audio system, press HOME, then select

→ [Sound] →

[Headphone/Audio Out] → [Audio Out].

Return to Top

i-Manual online

Print Font Size

Top Page > Using Other Equipment/Internet > USB Device (e.g. Digital Camera)

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

USB Device (e.g. Digital Camera)

Plays photos/music/videos on the TV screen by connecting a Sony digital still camera or other USB-compatible device.

You can enjoy photo, music and video files stored in a Sony digital still camera, camcorder or USB storage device by connecting the device via a USB cable.

USB Storage Device

USB cable (not supplied)

Playing photos/music/videos

Press HOME, then select → [Photos], [Music] or [Videos] → the desired USB device.

2. Select files or folders to play from the list.

When connecting a Sony digital camera to the TV with a USB cable, USB connection settings on your camera need to be set to [Auto] or [Mass Storage] mode.

Displaying a 3D Sweep Panorama photo is available only when [Slideshow Effect] is set to [Simple]. (This feature is available on 3D-compatible models only.) To confirm the setting, press

OPTIONS, then select [Playback Method] → [Slideshow Effect] → [Simple].

Scrolling a panoramic photo is available only when [Slideshow Effect] is set to

[Simple]/[Crossfade]. To confirm the setting, press OPTIONS, then select [Playback Method] → [Slideshow Effect] → [Simple]/[Crossfade].

Compatible USB devices/formats

USB viewer supports FAT12, FAT16, FAT32 and exFAT file systems.

USB playback of the following photo file formats is available:

- JPEG (JPEG format files with the extension “.jpg” and conforming to DCF 2.0 or Exif 2.21)

- RAW (ARW/ARW 2.0 format files with the extension “.arw”) (For preview only.)

- MPO (files with the extension “.mpo”) Only the panoramic JPEG files in the following horizontal/vertical sizes can be scrolled. (If the JPEG

file is edited on a PC, etc., scroll may not be possible.)

- For horizontal scroll: 4912/1080, 7152/1080, 3424/1920, 4912/1920, 12416/1856, 8192/1856, 5536/2160, 3872/2160, 10480/4096

- For vertical scroll: 1080/4912, 1080/7152, 1920/3424, 1920/4912, 1856/12416, 1856/8192, 2160/5536, 2160/3872, 4096/10480

USB playback of the following music file formats is available:

- MP3 (files with the extension “.mp3” that have not been copyrighted)

- WAV (files with the extension “.wav”)

- WMA (files with the extension “.wma”) USB playback of the following video file formats is available:

- AVCHD (files with the extension “.mts” or “.m2ts”)

- MP4 (AVC) (files with the extension “.mp4”)

- MP4 (MPEG4) (files with the extension “.mp4”)

- MPEG1 (files with the extension “.mpg”)

- MPEG2 (files with the extension “.mpg”)

- WMV (files with the extension “.wmv” or “.asf”) Video files are located in the following folder structure (hierarchal position):

/AVCHD/BDMV/STREAM/00000.MTS /PRIVATE/AVCHD/BDMV/STREAM/00000.MTS /MP_ROOT/100ANV01/MAHA0001.MP4

Avoid losing your files by backing up all your media files stored on a USB device. Sony cannot accept responsibility for lost or damaged data stored on a USB device.

Depending on the file, playback may not be possible even when using the supported formats.

Return to Top

i-Manual online

Print Font Size

Top Page > Using Other Equipment/Internet > Picture Frame

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Picture Frame

You can set a photo in the connected USB device, network device or preset picture folder to be displayed for a specified time.

1. While the desired photo is displayed, press OPTIONS, then select [File Actions] → [Picture

Frame].

2. Press HOME, then select → [Photos] → [Picture Frame].

The TV automatically switches to standby mode after a specified time.

Return to Top

i-Manual online

How to Use i-Manual

HDMI Equipment

Print Font Size

Top Page > Using Other Equipment/Internet > HDMI Equipment

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Connecting HDMI Equipment Viewing from HDMI Equipment “BRAVIA” Sync with “Control for HDMI”

Return to Top

i-Manual online

How to Use i-Manual

Internet/Wireless LAN

Print Font Size

Top Page > Using Other Equipment/Internet > Internet/Wireless LAN

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Wireless LAN Ready Wired LAN Browsing Websites “BRAVIA” Internet Video Photomap What’s New

Return to Top

i-Manual online

How to Use i-Manual

Home Network

Print Font Size

Top Page > Using Other Equipment/Internet > Home Network

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Connecting to a Home Network Renderer Display Settings for Media Servers Media Server Troubleshooting

Return to Top

i-Manual online

Print Font Size

Top Page > Using Other Equipment/Internet > Media Remote

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Media Remote

Allows a mobile device (e.g. smartphone, PC) to work as the TV’s remote control via the network.

This feature allows a mobile device (e.g. smartphone, PC) to work as the TV’s remote control via the network. In addition to the basic remote control functionality, you can enter text using the mobile device when the TV’s software keyboard is displayed. In case of a smartphone, you can use your smartphone to browse “BRAVIA” Internet Video content to play on the TV, or start the TrackID™ search by shaking your smartphone (availability of this function depends on the setting of your smartphone).

The following is required to use this feature.

In case of a smartphone: Android OS-equipped phone or iPhone on which the “Media Remote” application downloaded and installed.

In case of a PC: “Remote Keyboard” application installed PC.

Performing the mutual registration (required only for the first time)

Connect the TV and mobile device to the same home network.

2. Launch the “Media Remote”/“Remote Keyboard” application on the mobile device, then

search for the TV in the home network. The detected device list appears on the mobile device.

3. Select the TV in the detected device list, then perform the required operation on the TV.

To use this feature, [Remote Device / Renderer] needs to be set to [On]. To confirm the setting, press HOME, then select

Renderer] → [Remote Device / Renderer] → [On].

The information about the “Media Remote” and “Remote Keyboard” applications is as of March

2011. The names and available functions of these applications are subject to change.

→ [Network] → [Home Network Setup] → [Remote Device /

Return to Top

i-Manual online

Print Font Size

Top Page > Using Other Equipment/Internet > PC

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Enjoy music, pictures and other content from your PC by connecting it with dedicated cables.

D-sub 15 cable (not supplied)

Audio cable (not supplied)

For some Apple Macintosh computers, it may be necessary to use an adapter (not supplied). If an adapter is used, connect the adapter to the computer before connecting the HD15-HD15 cable.

You can connect an HDMI-compatible PC with an HDMI cable.

PC input signal reference chart

VGA

- Horizontal (Pixel)/Vertical (Line): 640/480

- Horizontal frequency (kHz)/Vertical frequency (Hz): 31.5/60

- Standard: VGA SVGA

- Horizontal (Pixel)/Vertical (Line): 800/600

- Horizontal frequency (kHz)/Vertical frequency (Hz): 37.9/60

- Standard: VESA Guidelines XGA

- Horizontal (Pixel)/Vertical (Line): 1024/768

- Horizontal frequency (kHz)/Vertical frequency (Hz): 48.4/60

- Standard: VESA Guidelines WXGA

- Horizontal (Pixel)/Vertical (Line): 1280/768, 1280/768, 1360/768

- Horizontal frequency (kHz)/Vertical frequency (Hz): 47.4/60, 47.8/60, 47.7/60

- Standard: VESA

SXGA (Full HD model only)

- Horizontal (Pixel)/Vertical (Line): 1280/1024

- Horizontal frequency (kHz)/Vertical frequency (Hz): 64.0/60

- Standard: VESA HDTV* (Full HD model only)

- Horizontal (Pixel)/Vertical (Line): 1920/1080

- Horizontal frequency (kHz)/Vertical frequency (Hz): 67.5/60

- Standard: CEA-861*

This TV’s PC input does not support Sync on Green or Composite Sync. This TV’s PC VGA input does not support interlaced signals. For optimum picture quality, it is recommended to use the signals in the chart. In plug and play,

signals with a 60 Hz vertical frequency will be detected automatically. (PC reboot may be necessary.)

* The 1080p timing when applied to the HDMI input will be treated as a video timing and not a PC

timing. This will affect the [Preferences] and [Picture & Display] settings. To view PC content, set [Scene Select] to [Graphics], [Wide Mode] to [Full], and [Display Area] to [Full Pixel]. ([Display Area] is configurable only when [Auto Display Area] is set to [Off].)

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Top

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Top

INPUT

TrackID

i-MANUAL

POWER

BD/DVD operating buttons

INPUT

Press to display a list of inputs.

TrackID

Searches for information about the music currently playing.

i-MANUAL

Press to display the on-screen instruction manual (this manual).

POWER

Press to turn on the TV or to enter standby mode.

BD/DVD operating buttons

/ : Go to the beginning of the previous/next title/chapter/scene/track.

/ : Fast reverse/fast forward the disc when pressed during playback.

: Pause or re-start playback.

: Play a disc at normal speed.

: Stop playback.

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Upper

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Upper

3D WIDE NETFLIX SCENE INTERNET VIDEO QRIOCITY

Press to display the 3D Menu.

WIDE

Press to change the wide mode.

NETFLIX

Press to access the “NETFLIX” online service.

This feature (button) may not be available in some regions/countries. Details can be referred in Sony website.

SCENE

Press to display the [Scene Select] menu. Select the desired scene option for

optimum sound and picture quality.

INTERNET VIDEO

Press to access Internet content on the Home Menu.

QRIOCITY

Press to access the “Qriocity” online service.

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Middle

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Middle

SYNC MENU GUIDE RETURN DISPLAY

/ / / / OPTIONS HOME

SYNC MENU

Press to display the “BRAVIA” Sync Menu and then select connected HDMI equipment from [HDMI Device Selection].

[Control for HDMI] (“BRAVIA” Sync) is only available for connected Sony equipment that has the “BRAVIA” Sync logo or is compatible with “Control for HDMI.”

GUIDE

Press to display the program guide.

The Guide feature is available depending on your region/country.

RETURN

Press to return to the previous screen or exit from the menu.

DISPLAY

Press once to display information about the channel/program/input you are viewing. The information will time out in a few seconds or press again to exit.

/ / / /

Press / / / to move the on-screen cursor. Press to select/confirm a highlighted item.

OPTIONS

Press to display a list of convenient functions and menu shortcuts. The menu items vary based on the current input and/or content.

HOME

Press to display the TV Home Menu.

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Lower

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Lower

Color buttons 0-9

CC/SUBTITLE

Color buttons

When the color buttons are available, an operation guide appears on the screen.

0-9

Press 0-9 to select a channel.

Use with 0-9 to select digital channels. For example, to enter 2.1, press 2, ,

CC/SUBTITLE

Press to turn closed captions/subtitles on or off (when the feature is available).

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Bottom

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Bottom

VOL +/– MUTING CH +/– JUMP

VOL +/–

Press to adjust the volume.

MUTING

Press to mute the sound. Press again to restore the sound.

CH +/–

Press to select the next (+) or previous (–) channel.

JUMP

Press to jump back and forth between two channels or inputs. The TV alternates between the current channel or input and the last channel or input that was selected.

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Rear

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Rear

(TV standby)

Press to turn on the TV or to enter standby mode.

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Front

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Front

Light sensor Remote control sensor

(Picture off/Timer)

(Standby) I (Power) 3D Sync Transmitter

Light sensor

Senses room light level and adjusts the screen brightness accordingly. Do not put anything near the sensor. Doing so may affect its function.

Remote control sensor

Receives signals from the remote control. Do not put anything near the sensor. Doing so may affect its function.

(Picture off/Timer)

Lights up in green when you select [Picture Off]. Lights up in orange when you set the timer. Lights up in and/or blinks orange during a software upgrade.

(Standby)

Lights up in red when your TV is in standby mode, PC power saving mode or during a software upgrade.

I (Power)

Lights up in green when the TV is on.

3D Sync Transmitter

Emits the 3D sync signal.

Do not put anything in front of the 3D Sync Transmitter. Doing so may affect its function.

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Right

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Right

(Power) CH +/– (Channel)

+/- (Volume) (Input select)

HOME

(Power)

Press to turn on the TV or to enter standby mode.

CH +/– (Channel)

Press to select the next (+) or previous (–) channel.

In the TV menu, these buttons will work as / .

+/- (Volume)

Press to adjust the volume.

In the TV menu, these buttons will work as / .

(Input select)

Press to display a list of inputs.

In the TV menu, this button will work as .

HOME

Press to display the TV Home Menu.

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Rear

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Rear

LAN DIGITAL AUDIO OUT (OPTICAL) CABLE/ANTENNA VIDEO IN 1 VIDEO IN 2, COMPONENT IN HDMI IN 1/3/4

LAN

Connects to an existing network using an Ethernet cable.

DIGITAL AUDIO OUT (OPTICAL)

Connects to the optical audio input of digital audio equipment that is PCM/Dolby Digital compatible.

CABLE/ANTENNA

RF input that connects to your cable or over-the-air antenna.

VIDEO IN 1

Connect with a composite video cable. When connecting mono equipment, connect to the L (MONO) audio jack.

VIDEO IN 2, COMPONENT IN

This input can be used as composite video input or as component video input. When connecting mono equipment, connect to the L (MONO) audio jack.

For composite use, connect to VIDEO IN 2 for video, and to AUDIO (L/R) of COMPONENT IN for audio signals.

For component connection, use Y, PB, PR for video signals and also connect to AUDIO (L/R) for audio signals.

The TV will automatically detect and switch between VIDEO IN 2 and COMPONENT IN. To manually set the input type, press HOME, select

→ [Channels & Inputs] → [Video 2/Component Selection].

HDMI IN 1/3/4

HDMI (High-Definition Multimedia Interface) provides an uncompressed, alldigital audio/video interface between this TV and any HDMI-equipped audio/video equipment. In addition, when you connect equipment that is compatible with “Control for HDMI,” communication with the connected equipment is supported.

Be sure to use only an authorized HDMI cable bearing the HDMI logo. If connecting a digital audio system that is compatible with Audio Return

Channel (ARC) technology, use HDMI IN 1. If not, an additional connection with DIGITAL AUDIO OUT (OPTICAL) is necessary.

If the equipment has a DVI jack, connect it to HDMI IN 4 through a DVI HDMI adapter interface (not supplied), and connect the equipment’s audio out jacks to PC/HDMI 4 AUDIO IN.

Return to Top

i-Manual online

Print Font Size

Top Page > Parts Description > Right

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Right

USB 1

USB 2 HDMI IN 2 PC IN AUDIO OUT/

USB 1

You can enjoy photo, music and video files stored on a USB device.

USB 2

You can enjoy photo, music and video files stored on a USB device.

HDMI IN 2

Be sure to use only an authorized HDMI cable bearing the HDMI logo. If connecting a digital audio system that is compatible with Audio Return

Channel (ARC) technology, use HDMI IN 1 on the rear of the TV. If not, an additional connection with DIGITAL AUDIO OUT (OPTICAL) is necessary.

If the equipment has a DVI jack, connect it to HDMI IN 4 through a DVI HDMI adapter interface (not supplied), and connect the equipment’s audio out jacks to PC/HDMI 4 AUDIO IN on the rear of the TV.

PC IN

Connects to a personal computer’s video and audio output connector. Can also

be connected to other analog RGB equipment.

For some Apple Macintosh computers, it may be necessary to use an adapter (not supplied). If this is the case, connect the adapter to the computer before connecting the HD15-HD15 cable.

It is recommended to use a PC cable with ferrite cores. To input PC sound, connect to the AUDIO IN jack on the rear of the TV

using an audio cable.

AUDIO OUT/

Connect with an audio cable or headphones. You can listen to TV sound through your stereo system or headphones. To set the sound output for headphones or an external audio system, press HOME, select

→ [Sound] → [Headphone/Audio Out].

When you set [Audio Out] in [Headphone/Audio Out], select [Fixed] or [Variable], press HOME, select

→ [Sound] → [Audio Out].

Return to Top

i-Manual online

Print Font Size

Top Page > Troubleshooting > Picture Symptoms: General

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Picture Symptoms: General

Picture quality is not as good as viewed at the store. Dotted lines or stripes appear. No color./Dark picture./Color is not correct./Picture is too bright. The screen alternates between dark and bright. Blurry picture or poor color. Wide Mode changes automatically. Suddenly the picture becomes small. Black box on screen. Black bands appear at the edges of the screen. Certain programs on DVD or other digital sources display a loss of detail, especially during

fast-motion or dark scenes.

Picture quality is not as good as viewed at the store.

Picture quality depends on the signal content. See the specifications to display the best possible picture for that signal.

Dotted lines or stripes appear.

Keep the TV away from noise sources such as cars, motorcycles, or hair-dryers. If using the 300-ohm twin lead, move the excess lead away from the TV or try using the 75-

ohm coaxial cable (not supplied) instead.

No color./Dark picture./Color is not correct./Picture is too bright.

Press OPTIONS, then select [Picture Adjustments] to make adjustments. Adjust [Picture Mode] in [Picture Adjustments]. If you set [Power Saving] to [Low] or [High], black level will be enhanced. If [Presence Sensor] is set to [Moderate], the screen darkens temporarily when the sensor does

not recognize any facial patterns, or the picture turns off after no movement is detected for a preset time. (For Intelligent Presence Sensor-compatible models only.)

The screen alternates between dark and bright.

If [Presence Sensor] is set to [Moderate], the screen darkens temporarily when the sensor does not recognize any facial patterns, or the picture turns off after no movement is detected for a preset time. (For Intelligent Presence Sensor-compatible models only.)

Blurry picture or poor color.

Transporting the TV from a cold to a warm location or a sudden change in room temperature may cause moisture condensation, resulting in a blurry picture or poor color. Turn off your TV

and wait a few hours before powering on again.

Wide Mode changes automatically.

When changing the channel or video input, if [4:3 Default] in [Screen] is not set to [Off], the current [Wide Mode] setting is automatically replaced with the [4:3 Default] setting. To lock in [Wide Mode] selected with WIDE on the remote control, set [4:3 Default] to [Off].

Check the [Auto Wide] setting in [Screen].

Suddenly the picture becomes small.

The picture becomes smaller during commercials due to the method used by a provider to broadcast content. When HD content channels switch to SD content (commercials), the picture may be small with a black border.

[Auto Wide] will not expand the picture while the content switches, since the content information is regulated by the channel signal provider. You can manually change the [Wide Mode] setting if desired, which will remain in effect until you change the channel/input or manually change the [Wide Mode] setting again.

Black box on screen.

A text option is selected although no text is available. To deactivate this feature, set [CC Display] to [Off]. If you are trying to select closed captioning, select [CC1] instead of [Text1] [Text4] (options may not be available depending on your region/country).

Black bands appear at the edges of the screen.

Some wide screen programs are filmed in aspect ratios that are greater than 16:9 (this is especially common with theatrical releases). Your TV will show these programs with black bands at the top and bottom of the screen. For more details, check the documentation that came with your DVD (or contact your program provider).

Programs in 4:3 aspect ratio will have bands on the left and right sides of the screen. Programs broadcasted in HD formats (720p and 1080i) with 4:3 content will commonly have

black bands on the left and right sides of the screen which are added by the broadcaster. [Auto Wide] will not expand the picture when the black bands on the sides of the screen are

added by the broadcaster. You can manually set [Wide Mode] to [Wide Zoom] or [Zoom], which will remain in effect until you change the channel/input or manually change the [Wide Mode] setting again.

Certain programs on DVD or other digital sources display a loss of detail, especially during fast-motion or dark scenes.

Less detail than usual or artifacts (small blocks, dots or pixelation) may appear on the screen, due to the digital compression of the source content used by certain digital broadcasts and DVDs. The degree of visible artifacts depends on the clarity and resolution of the TV.

Return to Top

i-Manual online

Print Font Size

Top Page > Troubleshooting > Picture Symptoms: TV Program

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Picture Symptoms: TV Program

You cannot receive any channels. You cannot receive or select channels. Some digital cable channels are not displayed. Broadcast HD formats have poor quality. Ghosting or double images appear. Only snow noise or black picture appears on the screen. Noisy picture. Photo images appear small on the screen. Photo images or folders take time to display. Some channels are blank. You cannot view digital channels.

You cannot receive any channels.

Check the antenna/cable connection. Make sure the [Cable/Antenna] setting is correct for your TV signal source. If using CATV STB, refer to its instruction manual for installation.

You cannot receive or select channels.

Perform [Auto Program] to add receivable channels that are not present in the TV’s memory. To receive or select cable channels, make sure that signal type in the channel settings is set to

[Cable]. To receive or select channels by antenna, make sure signal type is set to [Antenna].

Some digital cable channels are not displayed.

Certain cable companies have limitations on the broadcast of digital cable channels. Check with your cable company for more information.

The digital cable channel may be set to [Hidden] in [Show/Hide Channels].

Broadcast HD formats have poor quality.

Content and signal quality are regulated by the signal provider. Many HD channels and content are actually upscaled versions of standard-definition broadcasts. The picture is affected by the quality of the signal received, which varies between channel and program.

Ghosting or double images appear.

Check cable or antenna connections. Check the antenna location and direction.

Set [Motionflow] to [Standard] or [Off]. (For [Motionflow] compatible models only.)

Only snow noise or black picture appears on the screen.

Check if the antenna is broken or bent. Check if the antenna has reached the end of its serviceable life (3-5 years in normal use, 1-2

years at the seaside).

Noisy picture.

Make sure that the antenna is connected using a 75-ohm coaxial cable. Keep the antenna cable away from other connecting cables. To avoid TV interference, make sure to use an undamaged antenna cable.

Photo images appear small on the screen.

Photo images may not be displayed in full screen depending on the resolution or aspect ratio of the file.

Photo images or folders take time to display.

Depending on the image dimension, file size, and number of files in a folder, some photo images or folders take time to display.

The first time a camera is connected to the TV via USB cable, it may take up to a couple of minutes for the photos to display.

Some channels are blank.

The channel is for scrambled/subscription service only. Subscribe to a pay TV service. The channel is used only for data (no picture or sound). Contact the broadcaster for transmission details.

You cannot view digital channels.

Ask a local installer if digital transmissions are provided in your area. Upgrade to a higher gain antenna.

Return to Top

i-Manual online

Print Font Size

Top Page > Troubleshooting > Picture Symptoms: 3D

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Picture Symptoms: 3D

3D pictures are not displayed. 3D effect is weak. A 3D Sweep Panorama photo cannot be displayed. Black bars appear on both sides of the screen when watching 3D pictures. 3D display automatically switches on when 3D signal is detected. The message [3D signal has been detected] automatically appears when 3D signal is

detected. 3D Glasses do not fit properly. LED indicator on the 3D Glasses flashes. You cannot turn the 3D Glasses on. You cannot charge the 3D Glasses. (Applies only to TDG-BR250/BR200.)

3D pictures are not displayed. 3D effect is weak.

Be sure that there are no obstacles between the 3D Sync Transmitter and the 3D Glasses. Replace the battery in the 3D Glasses, or charge the battery if the 3D Glasses have a

rechargeable battery. Be sure that the 3D Glasses are powered on. If two pictures are displayed side-by-side, press 3D to display the 3D Menu, then press 3D

repeatedly until [Side-by-Side] appears. If two pictures are displayed one above the other, press 3D to display the 3D Menu, then press 3D repeatedly until [Over-Under] appears.

If the [3D Menu] setting screen appears and 3D pictures are not displayed, turn off the device that plays 3D content and turn it on again.

Perceived 3D effect may vary from person to person. 3D effect may be less pronounced if ambient temperature is low. 3D effect may be less pronounced and the display color will be shifted if you lie down or tilt your

head.

A 3D Sweep Panorama photo cannot be displayed.

Displaying a 3D Sweep Panorama photo is available only when [Slideshow Effect] is set to

[Simple]. To confirm the setting, press OPTIONS, then select [Playback Method] → [Slideshow Effect] → [Simple].

Displaying a 3D Sweep Panorama photo via the DLNA-certified media server is not available.

Black bars appear on both sides of the screen when watching 3D pictures.

Black bars appear on both sides of the screen in order to process 3D signals for the simulated 3D display mode or when adjusting the depth of 3D pictures in [3D Depth Adjustment].

3D display automatically switches on when 3D signal is detected.

Set to manually turn the 3D display on or off. Press HOME, then select

Display] → [3D Settings] → [Auto 3D] → [Off].

→ [Picture &

The message [3D signal has been detected] automatically appears when 3D signal

is detected.

Deactivate the [3D Signal Notification] setting. Press HOME, then select

Display] → [3D Settings] → [3D Signal Notification] → [Off].

3D Glasses do not fit properly.

→ [Picture &

(The following adjustments apply only to TDG-BR100.)

Set both the switches on either side for a comfortable fit. Close the temple arms slightly inwards to set the switch. (

Bend (adjust) the temple frames for a comfortable fit. ( Adjust the nose pad for your nose. (

LED indicator on the 3D Glasses flashes.

)

(The following illustration shows TDG-BR100.)

Flashes every few seconds: Indicates the glasses are powered on. Flashes 3 times: Indicates the glasses have been powered off. The glasses turn off if you hold

the power button down for 2 seconds, or if no signal from the 3D Sync Transmitter is detected for more than 5 minutes.

Flashes 3 times every 3 seconds: Indicates the battery capacity is almost running out. Replace the battery, or charge the battery if the 3D Glasses have a rechargeable battery.

LED Indicator

You cannot turn the 3D Glasses on.

Replace the battery. (Applies only to TDG-BR100/BR50. TDG-BR100 is used as an example in the following instructions and illustrations.)

1. Open the battery cover using a coin, etc.

2. Push the edge of the battery and remove it at an angle.

3. Insert a battery (CR2032) with its positive (+) side facing up.

4. Close the battery cover using a coin, etc.

5. Make sure the cover is closed.

TDG-BR100 TDG-BR100

Battery (CR2032)

Coin, etc.

When opening or closing the battery cover, be sure to insert a coin, etc., into the slot.

You cannot charge the 3D Glasses. (Applies only to TDG - BR250/BR200.)

Check if the TV is turned on. The 3D Glasses cannot be charged if the TV is in standby mode. Check if the 3D Glasses are turned off. The 3D Glasses must be turned off to charge. Check if the USB cable is connected properly.

Return to Top

i-Manual online

100

Print Font Size

Top Page > Troubleshooting > Picture Symptoms: Connected Equipment

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks

Index

i-Manual online map

Picture Symptoms: Connected Equipment

No picture from some video sources. Poor picture quality on PC input.

No picture from some video sources.

Check the connection between the optional video equipment and TV. Press INPUT. Press HOME, then select

Poor picture quality on PC input.

Adjust the resolution. Adjust [Pitch] and [Phase].

→ the desired input.

Return to Top

Sony KDL-55EX723, KDL-55EX720, KDL-46EX723, KDL-46EX720, KDL-46EX523 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

KDL-60EX720/55EX720/46EX720/40EX720/32EX720

How to Use i-Manual

“BRAVIA” TV Features

Watching TV

Settings/Home Menu

Using Other Equipment/Internet

Parts Description

Troubleshooting

Bookmarks
