To prevent fire or shock hazard, do not
expose the unit to rain or mo ist u r e.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabi ne t.
To prevent fire, do not cover the ventil at ion of the
apparatus with news papers, table-cloths, curtains, etc.
And don’t place lighted candle s on the apparatus.
To prevent fire or shock hazard, do not place obje c ts
filled with liquids, such as vases , on the ap pa ratus.
Don’t throw away the battery with
general house waste, dispose of it
correctly as chemical was te.
This appliance is
classifie d as a CLASS 1
LASER product. This
marking is located on the
rear exterior.
Notes on DTS audio playback
Excessive noise may be heard from the speakers when
you play DTS format CDs if the decode format is set to
PCM (page 60) or monaural sound (1/L, 2/R)
(page 39). Set the volume to minimum and be care fu l
not to damage your speaker system.
IMPORTANT NOTICE
Caution: This system is capable of holding a still video
image or on-screen display ima ge on your television
screen indefinitely. If you leave the still video image or
on-screen display image displayed on your TV for an
extended period of time, you risk permanent damage to
your television screen. Proje ct ion tel ev isi ons are
especially susceptible to this.
ENERGY STAR
®
ENERGY STAR® is a U.S. registered
mark.
As an E
NERGY STAR
®
partner, Sony
Corporation has determined that this
product meets the E
NERGY STAR
guidelines for energy efficiency.
This system incorporates Dolby* Dig ita l, Dolby Pro
Logic (II) adaptive matrix surround decoder, and the
DTS** Digital Surround System.
* Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro Logic” and the doubleD symbol are trademarks of Dolby Laboratories.
**Manufacture d unde r lic e nse from Digital Theater
Systems, Inc. “DTS” and “DTS Digital Surround”
are registered trademarks of Digital Theater
Systems, Inc.
US and foreign patents licensed from Dolby
Laboratories.
• All CD-Rs othe r than musi c and V CD form at
CD-Rs
• Data part of C D -Extras
• DVD-ROMs
• D VD Audio discs
Note
Some CD-Rs/CD-RWs or DVD-Rs/DVD-RWs cannot
be played on this system depending upon the format or
the recording quality or physical condition of the disc,
or the characteristics of the reco rd ing device.
Furthermore, the disc will not play if it has no t be en
correctly finalized. For more information, see the
operating instructions for the recording device.
Region code of DVDs you can
play on this system
Your system has a region code printed on the
back of the unit and will only play DVDs labeled
with identical region code.
DVDs labeled will also be played on this
system.
If you try to play any other DVD, the message
“Playback prohibited by area limitations.” will
appear on the TV screen .
ALL
Depending on the DVD, no region code
indication may be la beled even though play in g
the DVD is prohibited by area restrictions.
The region code is located below the
COMPONENT VIDEO OUT jacks on the rear
panel.
Note on playback operations of
DVDs and VIDEO CDs
Some playba ck operatio ns of DVDs an d VIDEO
CDs may be intentionally set by software
producers. Since this system plays DVDs and
VIDEO CDs ac cording to the disc co nt ents the
software producers designed, som e playback
features may not be availab l e. Also, ref er to the
instructions supplied with the DVDs or VIDEO
CDs.
Note on PBC (Playback Control)
(VIDEO CDs)
This system conforms to Ver. 1.1 and Ver. 2.0 of
VIDEO CD standards. You can enjoy two kinds
of playback depending on the disc type.
Disc typeYou can
VIDEO CDs
without PBC
functions
(Ver. 1.1 discs)
VIDEO CDs
with PBC
functions
(Ver. 2.0 discs)
Enjoy video playback (moving
pictures) as well as music.
Play interactive software using
menu screens displayed on the TV
screen (PBC Playback), in addition
to the video playback functions of
Ver. 1.1 discs. Moreover, you can
play high-resolution still pictures, if
they are included on the disc.
Copyrights
This product inc or porates copyright prot ection
technology that is protecte d by U.S. p atents and
other in tellectua l p roperty ri g hts. Use of this
copyright pr ot ection technology must be
authorized by Macrovision, and is intended for
home and other limited viewing uses onl y unless
otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
GB
5
List of Buttons and Reference Pages
123
How to use this page
Use this page to find the location of bu tto ns an d oth er
parts of the system that are mentioned in the text.
Main unit
ALPHABETICAL ORDER
A – L
CD SYNC HI-DUB qg (51)
Deck A wg
Deck B qd
DIGITAL wa (66)
DISC SELECT 3 (23, 26)
DISC 1 indicator es (23)
DISC 2 indicator ea (23)
DISC 3 indicator e; (23)
DISC 4 indicator wl (23)
DISC 5 indicator wk (23)
Display window 2
DISPLAY qh (34, 59, 71)
DVD ef (11, 23, 26, 34, 48, 51,
?/1 (power) 1
Z (open/close) 4
A Z (deck A) wh
Z B (deck B) 0
hH (play) 5
X (pause) 6
x (stop) 7
./> (go back/go forward)
8
–/m, M/+ (rewind, fast
forward) 9
Z
hH
X
x
>
.
+
M
m
–
Z
4
5
6
7
8
9
q;
qa
qs
qd
qf
qg
waw;wfqlqkqj
GB
6
qh
Remote Control
v
V
1 2 3 456 7
ALPHABETICAL ORDER
A – EF – ST – V
2.1CH/MULTI* e; (56, 60, 67)
ALBUM +/– ed (26)
AMP MENU 9 (20, 21, 37, 56,
60)
ANGLE ek (42)
AUDIO el (39)
CLEAR ql (29, 30, 36, 41)
CLOCK/TIMER SELECT* wf
(54, 64)
CLOCK/TIMER SET wf (22, 53,
64)
D.SKIP 5 (24)
digipad 7 (8, 57)
DISPLAY 4 (8, 38, 59)
DSP EDIT* ej (57)
DVD qh (23, 26, 28, 51)
DVD DISPLAY* qa (26, 30, 32,
38, 39, 41, 42, 43, 81)
DVD MENU qa (31)
DVD SETUP* 9 (32, 37, 44)
DVD TOP MENU qg (31)
EFFECT* es (55, 57, 62, 67)
ENTER 6 (8, 20, 21, 22, 25, 26,
28, 30, 31, 32, 39, 41, 42, 43,
47, 52, 53, 56, 57, 58, 60, 64,
71)
FUNCTION 0 (26, 66)
GAME MODE eh (55)
GROOVE* ef (55)
KARAOKE PON* eh (62)
MOVIE MODE es (55, 56)
MUSIC MODE ej (55)
Numeric buttons wd
P FILE* el (58)
PLAY MODE/DIRECTION w;
29, 49)
RETURN O e; (31, 41, 43)
SCAN/SLOW t / T ra
(24)
SELECT wk
SHIFT qd (26, 32, 37, 44, 47, 54,
55, 56, 57, 58, 60, 62, 64, 67)
SLEEP wg (63)
SONY TV DIRECT qj (61)
SUBTITLE ea (42)
TAPE A/B qs (50, 51, 62)
TOOL MODE ef (55)
TUNER MEMORY* w; (47)
TUNER/BAND qf (47, 49)
TUNING +/– ra
TV/VIDEO wh (11)
TV ?/11 (11)
TV CH +/– 3 (11)
TV VOL +/– 2 (11)
VOLUME +/– 8 (37)
BUTTON DESCRIPTIONS
?/1 (power) qk
hH (play) wk
X (pause) r;
x (stop) wl
. (go back) wj
> (go forward) wj
m (rewind) ra
M (fast forward) ra
V/v/B/b/ENTER eg
>10 wa
* To use these functions, press the
button while pressing SHIFT.
List of Buttons and Reference Pages
wh
wg
wf
wd
ws
wa
w;
ql
wj
ra
r;
el
ek
ej
B
eh
V
Bb
v
wk
wl
ea
ed
ef
e;
es
eg
qd
qg
qjqk
qs
qf
qh
890qa
GB
7
digipad operations
The remote is equipped with an uni que digipad multi controlling device. You can control vario us
operations with this digipad. When touching the digipad, do not use utensil whose end is sharpened.
When this unit does not respond to the di gi pad operations, press th e digipad a little harder.
DVD, TUNER, TAPE A/B functions
Basic operationDVD, TUNER, TAPE A/B
Tap oncehH (Start pl ayback)*
Tap twicex (Stop playback)
* When you tap the digipad while playing a DVD/VIDEO CD/CD/Super Audio CD,
playback pauses. Tap again to resume play ba ck .
Slide from the lef t to the right> (AMS +, preset +)**
Slide from the right to the left. (AMS –, preset –)**
Slide from lower side to upper sideM (Fast forward, tuning +)**
Slide from upper side to lower sidem (Rewind, tuning –)**
**If you keep on moving , you can o pe rate as pressing and holding these buttons.
Adjusting the equalizer curve in EQ EDIT operations (page 57)
The curve made by sliding the finger is reflected in the displa y.
Selecting parameters in DSP EDIT and other adjustments
(page 57)
Slide in the direction until you reach the value you want (refer to each of the
operations).
A
B
Adjusting the position of the digipad
When the digipad operation is not carried out properly or when you replace the
batteries, perform the following proced ure. When carrying out this operation, make
sure to point the remote toward the main unit.
1 Turn on the system.
2 Press DISPLAY and . on the remote at the same time.
“CALIBRATION” flashes in the display.
3 Tap the dot at the left upper corner of the digipa d.
“A PUSHED” appears in the display, then “CALIBRATION” flashes.
4 Tap the dot at the right bottom cor ne r of the digi pa d.
“B PUSHED” appears in the display, then “CALIBRATION” flashes.
5 Press ENTER on the remote.
“CAL END” appears in the display.
GB
8
Equipments for the wireless system
Rear amplifier
Receives the sound from the IR receiver and
sends to the rear speakers. Conne ct the rear
speakers and the IR receiver to the rear amplifier.
ALPHABETICAL ORDER
A – Z
ON LINE (indicator) 3 (15)
ON/STANDBY (indicator) 2 (15)
POWER 1 (15)
12
Tip
To attach the IR receiver stand, push th e co rd upward
and insert the stand to IR receiver. Make sure both delta
marks on IR receiver and stand are aligned.
List of Buttons and Reference Pages
IR receiver
Delta marks
IR receiver
stand
POWER
ON/STANDBY
ON LINE
3
IR transmitter
Transmits the sound by the infrared ray. Connect it
to the system.
IR receiver
Receive the so und by the infr ared ray. Co nnect it
to the rear amplifier.
About the wireless system
This wireless system adopts th e Dig ital Infrared
Audio Transmission syst em (page 77). The
following diagram indicates the infrared
transmission area (the range th at the infrared
rays can reach).
Top view
IR transmitter
Side view
IR transmitter
Infrared signal
10
10
Approx. 10m
IR receiver
Infrared signal
10
10
Approx. 10m
IR receiver
GB
9
Getting Started
1: Placing the speakers
Attaching the speaker pads
Before connecting the center speaker and rear
speakers, stic k t he supplied speake r pads to the
bottom of the center speaker and rear speakers to
stabilize the spe akers and prevent them f rom
slipping.
Rear speaker
Center speaker
Positioning the speakers
We recommend to place the system as follows:
Sub wooferMain unit
?/1
Z
hH
X
x
>
.
+
M
m
–
Z
Z
Front speaker
(Left)
Front speaker
(Right)
Front speaker
(Left)
Front speaker
(Right)
?/1
Z
hH
X
x
>
.
+
M
m
–
Z
Z
Optional stand WS-FLX9
Sub woofer
(not supplied)
Main unit
When placing the s peakers on top of the sub
woofer and the main unit, be sure to place the
foot of the speakers to fit in the hollows on top
of the sub woofer and t h e main unit.
Notes
• Keep the speaker cords away from the antennas to
prevent noise.
• Do not place the rear speakers on top of a TV. This
may cause color distortion in the TV screen.
• Be sure to connect both rear left an d right speakers.
Otherwise, the sound will not be hear d.
10
GB
Preventing th e speaker s from
falling
When you place th e speakers on top of t he sub
woofer and the main unit, do the following.
1 Place the speaker support on the su b w oofer
and the main unit. Ti ghten one of the screws
(1) lightly to temporarily fix the speaker
support, tighten the other scre w to fi x (2),
then tighten th e fi rst screw (1) firmly.
Speaker support
Screw (1)*
2: Inserting three R6 (size
AA) batteries into the
remote
e
E
e
e
E
E
Getting Started
Screw (2)*
* Main unit: Screw
Sub woofer: Screw
3 3 ×10
3 3.5 ×20
2 Insert the spea ker support in the slot of th e
front speakers . Tighten two screws whi l e
threading the r ear boards of the front
speakers.
Screw*
Slot
* 3 3.5 × 14
Note
When carrying the syste m, do not lift the fro nt speakers
only.
Operating a Sony TV
You can use the following buttons on the remote
to operate a Sony TV.
ToPress
Turn the TV on or offTV ?/1.
Switch the TV’s video inputTV/VIDEO.
Change the TV channelsTV CH +/–.
Adjust the volume of the TV
speaker(s)
Tip
When the remote no longer operates the system,
replace all the batterie s wit h new ones .
Note
If you do not use the remote for a long period of time,
remove all the batteries to avoid possible damage from
battery leakage.
TV VOL +/–.
Notice for carrying this system
Do the following to protect the DVD
mechanism. Us e buttons on the unit.
1 Turn on the system, then press DVD.
Make sure that all discs are removed
from the unit.
2 Hold down DVD, then press ?/1 until
“LOCK” appears.
3 Release ?/1 first, then release DVD.
4 Unplug the AC power cord.
11
GB
3-a: Hooking up the system (Wireless setting)
8
Do the following procedures 1 to 0 to hook up your system using the supplied cords and accessories.
You can also hook up the system using the wired setting (page 18).
IR transmitter
AM loop antenna
FM antenna
Center speaker
6
7
5
3
Front speaker
(Right)
1
Front speaker
(Left)
Sub woofer
12
8
IR receiver
7
4
–
+
–
+
Rear speaker
(Right)
Rear amplifier
GB
2
Rear speaker
(Left)
Connect theTo the
Front speakersSPEAKER FRONT L (white) and R (red) terminals
Center speakerSPEAKER CENTER (green) terminal
Sub wooferSPEAKER WOOFER (purple) terminal
Rear speakersSPEAKER REAR L (blue) and R (gray) terminals of the rear amplifier
IR transmitterDIR-T1 (pink) jack of the system
IR receiverDIR-R1 jack (light blue) of the rear amplifier
Getting Started
Note on the speaker cords
The connector and the color tube of the spe ak er co rd s
are the same color as the speaker/rear amplifier
terminal to be connected .
1 Connect the front speakers, center
speaker and sub woofer.
Main unit
Front speakers, center speaker and
sub woofer
Red (3)
Black (#)
Color tube
Note
Be sure to match the speaker cord to the appropriate
terminal on the components: 3 to 3, and # to #. If
the cords are reversed, the sound will be distorted and
will lack bass.
2 Connect the rear amplifier and rear
speakers.
Rear amplifier
Rear speakers
Red (3)
Black (#)
Color tube
3 Connect the IR transmitter to the DIR-
T1 jack of the unit.
Main unit
DIR-T1
from the IR transmitter
continued
13
GB
4 Connect the IR receiver to the DIR-R1
jack of the rear amplifier.
Rear amplifier
DIR-R1
from the IR receiver
Note
The cords of the IR transmitter an d IR rec ei ve r are
specifically for this system onl y. You cannot use a
commercially available extension cord.
5 Connect the FM/AM antennas.
Set up the AM loop antenna, then connect
it.
M
A
5
7
M
F
L
IA
X
A
O
C
Extend the FM lead antenna horizontally.
AM loop antenna
6 Connect the video input jack of your TV
to the VIDEO OUT jack with the video
cable.
VIDEO OUT
Tips
• For even higher quality video image s;
– Use an optional component video cable to connect
the COMPONENT VIDEO input jacks on your
TV to the COMPONENT VIDEO OUT jacks of
this system. If your TV is compatible with
progressive format file signals, use this connection
and set “COMPONENT OUT” to
“PROGRESSIVE” in “SCREEN SETUP”
(page 34).
– Use an optio na l S- vi de o ca ble to c onne c t the S
VIDEO input jack on your TV to the S VIDEO
OUT jack of this system.
• If you connect a video deck between this unit and the
TV, you may experience video leakage when
watching the video signal from this unit. Do not
connect a video deck between this unit and th e TV.
7 For models with a voltage selector, set
VOLTAGE SELECTOR to the posit ion
of your local power line voltage.
Refer to the print on your system’s/rear
amplifier’s VOLTAGE SELECTOR for
available settings.
Main unit
VOLTAGE
SELECTOR
220V 230-
120V*
Rear amplifier
VOLTAGE
SELECTOR
110V–120V*220V–240V
240V
14
When using a TV
Turn on the TV and select the video input so you can
view the pictures from th is s ystem.
GB
* Saudi Arabian Model 120 – 127 V
8 Connect the power cords of the
system/rear amplifier to a wall outlet.
The demonstration appears in the display of
the system. When you press ?/1, the
system turns on and the demonstration
automatically ends.
If the supplied adapter on the plug does not
fit your wall outlet, detach it from the plug
(only for models equipped with an adapter).
9 Set the color system according to your
TV.
The color syst em is factor y set to NTSC f or
region code 3 model s, and PAL for other
region code models. Each time you per form
the procedure belo w , t he color system
changes as follows:
NTSC y PAL
Use the buttons on the unit.
1 Press ?/1 to turn off the system.
2 Press ?/1 while holding down X.
The system turns on and the color system
is changed.
0 Make sure you set the connection
setting to “R. C. WIRELESS” in AMP
MENU (page 20).
Note
No sound is output from the rear speakers when
the connection setting is set to “R. C. WIRED”
(page 20).
Notes
• Do not install the IR receiver in a place exposed to
direct sunlight or st rong light such as an incandescent
lamp.
• Do not use the IR transmitter or IR receiver that is not
supplied with the system.
• Make sure you set “R. C. WIRELESS” when using
wireless setting or “R. C. WIRED” when using wired
setting. If you do not set the proper setting, no sound
is output from the rear speakers. For deta ils, see
“Specifying distance, posi tion, height and
connection method of the speakers ” (p ag e20).
Setting the wireless speaker
system
After connecting the speakers , rear amplifier, I R
transmitter, IR receiver and the AC power cords,
adjust the wireless system for good
transmission.
1 Press ?/1 on the system and POWER
on the rear amplifier.
The system and rear amplifier turn on and
the ON/STANDB Y indicator on the rear
amplifier lights up in red.
2 Place the IR transmitter and IR receiver
to face each other.
Adjust the position of the IR transmitter and
IR receiver until the ON/STANDBY and
ON LINE indicators on the rear amplifier
turn green.
Notes
• Make sure that there is no obs tr uc tion such as a
person or object between the IR transmitter and IR
receiver. Otherwise, the sound from the rear speakers
may be interrupted.
• If the ON LINE indicator on the rear amplifier ligh ts
up in red, the transmission is incompleted. Adjust the
position of the IR transmitter and IR receiver until
the ON/STANDBY and ON LINE indicators on the
rear amplifier light up in gre en .
• If the ON/STANDBY indicator on the rear amplifier
flashes in red, it means that the IR receiver is
receiving signals from a different Sony infrared
system. In this case, turn off the other system or
move the IR receiver so that the ON/STANDBY
indicator on the rear amplifier light s up in gr e en.
• The LED of the IR transmitter does not turn off while
the system is on. This is not a malfunction. To tu rn
off the LED of the IR transmitter, set the system to
Power Saving Mode (page 59).
Tip
The IR transmitter stand can be rotated for the
adjustment.
Getting Started
continued
15
GB
Example of installation
Position the IR transmitter and IR receiver
facing each other as shown below.
Make sure that th er e are no obstacles b et w een
the IR transmitter and IR receiver. Then,
orientate the IR transmitter and IR receiver unti l
the ON/STANDBY and ON LINE indicators on
the surround ampl ifier light up in gr een.
123 546
qs
qa
7890
1Front speaker (Left)
2Sub woofer
3Center speaker
4TV
5Main unit
6Front speaker (Right)
7Rear speaker (Right)
8Listening position
9Rear ampl if ier
0Rear speaker (Left)
qaIR receiver
qsIR transmitte r
Installing the IR transmitter
and IR receiver on a wall
We recommend that you install the IR
transmitter and IR receiver on a wall when:
– There are obstacles between the IR
transmitter and IR receiver.
– people often move between the IR transmitter
and IR receiver.
When you install both the IR transmitter and IR
receiver on a wall, be sure to install the IR
receiver first before you install the IR
transmitter.
To hang the IR receiver on a wall
1 Fix a commercially available screw into the
wall so that it protrudes 4 mm.
4 mm
2 Hang the slot of the IR receiver on the
screw.
Make sure that the IR receiver does not move after
installation.
IR receiver
16
Slot
GB
To install the IR transmitter on a
wall
1 Rotate the stand of the IR transmitter.
IR transmitter
Stand
2 Fix 2 commercially available screws into the
wall so that they protrude 4 mm.
Make sure the screws 30 mm apart.
30 mm
4 mm
Tip
Store the cords in the troughs as shown be low.
IR transmitter
Getting Started
Troughs
Notes
• Use the screws that are suitable for the material and
strength of the wall.
• Do not install the I R tr a nsmitter or IR receiver to a
wall of low strength.
• Sony is not liable for any damage or ac ci dent
incurred by incorrect installation (i.e. low strength
wall, etc.), incorrect use of this product, or natural
disaster.
• Detach the IR transmitter or IR receiver from the
wall first before you connect or disconnect the cords.
3 Hang the slot of the IR transmitter on the
screw.
Make sure that the IR transmitter does not move
after installation.
IR transmitter
Slot
Stand
17
GB
3-b: Hooking up the system (Wired setting)
This is the hooking up method to directly connect the rear speakers to the main unit. For details, refer
to step 1 in “3-a: Hooking up the system (Wireless setting)” (page 12).
To Center speaker
AM loop antenna
FM antenna
Rear speaker
(Right)
Connect theTo the
Front speakersSPEAKER FRONT L (white) and R (red) terminals
Rear speakersSPEAKER REAR L (blue) and R (gray) terminals
Center speakerSPEAKER CENTER (green) terminal
Sub wooferSPEAKER WOOFER (purple) terminal
To Front speaker (Right)
To Front speaker (Left)
To Sub woofer
Rear speaker
(Left)
To complete the hooking up
Perform the following connections and settings described in “3-a: Hooking up the system (Wireless
setting)” (page 12).
– AM/FM antennas connection (Step 5 )
– Vi d e o ca ble connection to your TV and the system (Step 6)
– The system’s VOLTAGE SELECTOR setting (for models with voltage selector only) (Step 7)
– The system’s pow er cord connection (Step 8)
– Color system setting to your TV after turning on the system (Step 9)
Then, set the connection setting to “R. C. WIRED” in AMP MENU (page 20).
18
GB
Notes
• Before connecting the center speaker and rear
speakers, make sure you attach the spe aker pads to
the bottom of the respective speakers (page 10).
• When you use the speakers in wired sett ing, make
sure to set “R. C. WIRED” in AMP MENU. No
sound is output from the rear spe akers when set to
“R. C. WIRELESS” (factory s etting). For detai ls, see
“Specifying distance, posi tion, height and
connection method of the speakers ” (p ag e20).
4: Setting up your
speakers
Getting Started
Positioning the speakers
For the best possible surround sound, all the
speakers othe r than the su b woofer sho uld be the
same distance fr om the listening posi tion (A).
However, if necessary, this system allo ws you to
place the center speaker up to 1.5 meters closer
(B) and the rear speakers up to 4.5 meters closer
(C) to the listening position.
The front speakers can be placed from 1. 0 t o
12.0 meters (A) from the listening position.
You can place the sub woofer in any position.
You can place the rea r s peakers either behind
you or to the side, depending on the shape of
your room, etc.
When the rear speakers are placed to the side
B
AA
C
When the rear speakers are placed behind you
B
AA
Note
Do not place the center and rear speakers farther away
from the listening position than the front speakers.
C
CC
continued
19
GB
Specifying distance, position,
height and connection
method of the speakers
Use the remote for the operation .
1 Press AMP MENU repeatedly until
“AMP MENU” appears.
2 Press ENTER.
3 Sit in your listening position and press
V or v repeatedly to select the items to
be set.
• Adjustable items
– Distance of the front, rear, and center
speakers
– Position an d hei ght of the rear speakers
– Connecti on me thod of the rear speakers
4 Press B or b repeatedly to select the
parameter you want.
The selected parameter appears.
5 Rep eat step s 3 and 4 to set other
parameters.
6 Press ENTER.
Tip
You can use the digipad instead of the cursor buttons
(V/v/B/b).
x DISTANCE
You can vary the distance of each sp eaker as
follows. The default settings are underlined.
• FRONT 2.4 m
Front speaker dis t ance can be set in 0.1 m
steps from 1.0 to 12.0 m .
• CENTER 2.4 m
Center speaker distance can be set in 0.1 m
steps from the front speaker distance to 1.5 m
closer to your listening position.
• REAR 1.5 m
Rear speaker distance can be set in 0.1 m steps
from a distance equal to the front speaker
distance to a dista nce 4.5 m closer to your
listening position.
Note
If each of the front or rear speakers are not placed an
equal distance from your listening position, set the
distance of the closest speaker.
(front speake rs distance)
(center speaker distance)
(rear speakers distance)
x Rear speaker position and
height
Specify the positi on and height of the rear
speakers. The de fault settings are und er l ined.
Position diagram
90
AA
45
BB
20
• R. PL. BEHIND
Select this if the re ar speakers are loc ated in
the section B.
• R. PL. SIDE
Select this if the re ar speakers are loc ated in
the section A.
Height diagram
CC
60
DD
30
•R. HGT. LOW
Select this if the re ar speakers are loc ated in
the section D.
• R. HGT. HIGH
Select this if the re ar speakers are loc ated in
the section C.
x Connection method of the rear
speakers
Select the method for connecting the rear
speakers. The default setting is underlined.
• R. C. WIRELESS
Select this when you use the rear speakers in
wireless setting (page 12).
• R. C. WIRED
Select this when you use the rear speakers in
wired setting (pa ge 1 8).
20
GB
5: Specifying the speaker
parameters
Use the remote for the operation.
1 From your listen ing position, press
AMP MENU.
Adjustable menus and parameters are
described below.
2 Press V or v repeatedly until “LEVEL
MENU” appears.
3 Press ENT ER.
4 Press V or v repeatedly to select the
parameter.
5 Press B or b repeatedly to select the
setting you want.
6 Repeat steps 4 to 5 to set other
parameters.
7 Press ENT ER.
Tips
• You can use the digipad instead of the cursor buttons
(V/v/B/b).
• You can use “SPEAKER SETUP” in the Setup
Display to specify the balance, le ve l, and test tone
parameters (page 36).
Adjustable parameters
The default settings are in the parentheses.
x BALANCE
• FRNT L___R: (center)
Balance between the front left and right
speakers.
• REAR L___R: (center)
Balance between the rear left and right
speakers.
Range: 6 ste ps t o t he left an d 6 s te ps to the rig ht
(13 steps)
x LEVEL
•REAR: (0 dB)
Level of the rear spea kers (–6 dB to +6 dB,
1 dB steps).
• CENTER: (0 dB)
Level of the cente r sp eaker (–6 dB to +6 dB,
1 dB steps).
• SUB W.: (+2 dB)
Level of the sub woofer (–6 dB to +6 dB, 1 dB
steps).
x D.COMP.
• D.COMP.: (OFF)
Dynamic range compression.
Range: OFF, 0.1 to 0.9, STD, MAX
“OFF” does not compress the dynamic range.
“0.1” to “0.9” settings allow you to compres s
the dynamic range in small steps. “STD”
reproduces the sound track with the dynamic
range intended by the recording en gi neer.
“MAX” provides a great compressio n of the
dynamic range.
x TEST TONE
• TEST TONE: (OFF)
Test tone output.
Range: OFF, ON
“ON” outputs the test tone from each speaker
in sequence. Adjust th e LEVEL and
BALANCE parameters so that the volume
level of the test tone from each speaker
sounds the same using the remote from your
listening position. Select “OFF” to turn off the
test tone.
Notes
• When 2.1CH/MULTI is set to “2.1CH” (page 60),
you cannot set rear speaker balance, center level, rear
level.
• Dynamic range compression is possible with Dolby
Digital sources only.
Getting Started
21
GB
6: Setting the clock
1 T urn on the system.
2 Press CLOCK/TIMER SET on the
remote.
3 Press . or > repeatedly to set the
hour.
4 Press ENTER on the remote.
5 Press . or > repeatedly to set the
minutes.
6 Press ENTER on the remote.
To adjust the clock
1 Press CLO CK/ T IMER SE T on the remote.
2 Press . or > repeatedly to select
“CLOCK SET?”, then press ENTER on the
remote.
3 Do the same procedures as step 3 to 6
above.
Note
The clock settings are canceled when you di sc onne c t
the power cord or if a power failure occur s.
22
GB
DVD/VIDEO CD/CD/Super Audio CD/MP3
Playing discs
Playing a disc
— Normal Play/Shuffle Play/Repeat
Play/Scan/Slow-motion Play
Loading a disc
1 Press DISC SELECT repeatedly to
select the disc tray you want to open.
2 Press Z.
The front panel slides down and the disc
tray slides out.
3 Place a disc with the label side up on
the disc tray.
When you play
a 8 cm disc,
place it on the
inner circle of
the tray.
4 Press Z to close the disc tray.
To insert other discs, repeat the same
procedure.
When a disc is inserted in the dis c tr ay, th e
corresponding dis c indicator (1 to 5 from
top) lights up.
Note
When the disc tray slides out, you cannot open the
cassette deck.
Before playing a DVD or a VIDEO CD, tu rn on
your TV and select the video input. Depending
on the DVD or VIDEO CD, some operations
may be different or restricted. R ef er to the
operating instructions supplied with the disc.
Disc tray number
1 DISC
DISC
Track numb erPlaying time
1 When playback is stopped, press PLAY
MODE/DIRECTION on the remote
repeatedly until the mode you want
appears in the display.
SelectTo play
ALL DISCS
(Normal Play)
1DISC
(Normal Play)
ALBM
(Normal Play)
ALL DISCS
SHUF
(Shuffle Play)
1DISC SHUF
(Shuffle Play)
ALBM SHUF
(Shuffle Play)
PGM
(Program Play)
All discs in the disc tray
continuously.
The tracks on the disc you have
selected in original order.
All MP3 audio tracks in the
album on the disc you have
selected in original order.
The tracks on all discs in
random order.
The tracks on the disc you have
selected in random order.
All MP3 audio tracks in the
album on the disc you have
selected in random order.
The tracks on all discs in the
order you want them to be
played (see “Creating your
own program” on page 28).
DVD/VIDEO CD/CD/Super Audio CD/MP3
2 Press DISC SELECT repeatedly to
select the disc you want to play.
3 Press hH.
If you press hH when DVD is selected
as the function (press DVD) and the disc
tray is closed, playback starts.
continued
23
GB
Notes
• You cannot change the play m ode dur ing pl ayback.
• You cannot use 1DISC SHUF or ALBM SHUF
Shuffle Play with DVDs. You can use ALL DISCS
SHUF except for DVDs.
Other operations
ToDo this
Stop playbackPress x.
Pause playbackPress X.
Press again to resume playback.
Select a trackDuring playback or pause, press
Find a point in a
track
(Lock Search
function)
(Except for MP3)
Select a discPress D.SKIP on the re mote.
Exchange other
discs during
playback
Remove the disc Press DISC SELECT repeatedly
> (to go forward) or . (to
go back).
Press M or m during
playback. To return to normal
play, press hH.
For DVDs, VIDEO CDs or Super
Audio CDs, press m or M
once to start searching. Pr es s
again to increase the search speed.
Each time you release and press
the button, the speed changes
sequentially:
M: FF1 t FF2 t FF1
m: FR1 t FR2 t FR1
Press DISC SELECT repeatedly
to select the dis c tray that c ontains
the disc you want to change, then
press Z. Press Z again to cl o s e
the tray.
to select the dis c tray that c ontains
the disc you want to remove, then
press Z.
ToDo this
Play repeatedly*1
(Repeat Play)
Press REPEAT/FM MODE on the
remote during playback until
“REP” or “REP1” appears. The
repeat range changes according to
the play mode:
•ALL
on all discs up to 5 times.
•1DISC
titles on a single disc.
•ALBM
single album (MP3 only).
•REP1
or track. You cannot use this
function with certain DVDs,
when playing VIDEO CDs with
PBC functions.
You cannot select “REP” during
ALL DISCS SHUF mode, but you
can select “REP1”.
To cancel Repeat Play, press
REPEAT/FM MODE on the
remote until “REP” and “REP1”
disappear.
Locate a point
quickly in fast
forward or fast
reverse (scan)
During playback, press SCAN/
SLOW t or T on the
remote. To return to normal
playback, press hH.
For DVDs, VIDEO CDs or Super
Audio CDs, two speeds are
available. Each time you press the
button, the indic a tion cyclically
changes as follows:
Playback direction:
FF1M
Opposite direction:
FR1m
Change the
playback speed
(Slow-motion
play)
During pause mode, press SCAN/
*3
SLOW t or T on the
remote. To return to normal
playback, press hH.
Two speeds are available. Each
time you press the button, the
indication cyclically cha nge s as
follows:
Playback direction:
SLOW2
Opposite direction (DVD only):
SLOW2
: For all the tracks or titles
: For all the tracks or
: For all the tracks on a
: For a single title, chapter
*2
t FF2M*2
*2
t FR2m*2
*4
y SLOW1
*4
y SLOW1
*4
*4
24
GB
*1
You cannot select “REP1” during P ro gr am Pl ay.
*2
The FF2M/FR2m playback spee d is fast er than
FF1M/FR1m.
*3
DVD and VIDEO CD only. Slow-motion reverse
play for DVD only.
*4
The SLOW2/SLOW2playback speed is
slower than SLOW1/SLOW1.
Note
If DVD playback is paused for approximately one
hour, the system automatically turns off.
Tips
• You can use the digipad for the disc operati ons .
• Pressing DVD while the power is off automatically
turns the power on.
• Depending on the disc, a menu may appear on the TV
screen. You can play the disc interactive ly by
following the instructions on the menu (see page 31
for DVD, and see page 31 for VIDEO CD).
• You can use the Control Menu to play rep ea t edl y
(page 30).
• When disc access takes a long time, set “DVD
POWER ON” by DVD power manage function
(page 48).
To enter track number using the
remote
You can also select the track you want using the
remote during Normal Play.
Press the numeric buttons, then press EN TER.
The playback automatically starts.
Playing a disc with MP3
audio tracks
About MP3
MP3 (MPEG 1 Audio Layer-3) is a standard
technology a nd forma t f or com pres si ng a s oun d
sequence. The track is compressed to about 1/10
of its original size . Sounds outside the range of
human hearing are compressed while the sounds
we can hear are not compressed.
Notes on discs
You can play MP3 audio tracks recorded on
CD-ROMs, CD-Rs (recordable CDs), or CD-RWs
(rewritable CDs).
The disc must be in the ISO9660* level 1, leve l 2 or
Joliet format.
*ISO9660 Format
The most common international standard for the
logical format of tracks and albums on a CD- R OM.
There are several s pecificat ion lev els. In Level 1, tr ack
names must be in the 8.3 format (no more tha n ei ght
characters in the name, no more than three characters
in the extension “.MP3”) and in capital letters. Album
names can be no longer than eight characters. There
can be no more than eight nested album levels. Level 2
specifications allow album name s a nd trac k na me s up
to 31 characters long.
Playing a disc
DVD/VIDEO CD/CD/Super Audio CD/MP3
— Normal Play/Shuffle Play/Repeat
Play
This system lets you play the di sc with MP3
audio tracks in different play modes.
Disc tray number
1 DISC
DISCMP3
Track number Playing time
continued
25
GB
1 Press DVD (or FUNCTION on the
remote repeatedly until “DVD” appears
in the display).
2 When playback is stopped, press PLAY
MODE/DIRECTION on the remote
repeatedly until the mode you want
appears in the display.
SelectTo play
ALL DISCS
(Normal Play)
1DISC
(Normal Play)
ALBM
(Normal Play)
ALL DISCS
SHUF
(Shuffle Play)
1DISC SHUF
(Shuffle Play)
ALBM SHUF
(Shuffle Play)
PGM
(Program Play)
All discs in the disc tray
continuously.
The tracks on the disc you have
selected in original order.
All MP3 audio tracks in the
album on the disc you have
selected in original order.
The tracks on all discs in
random order.
The tracks on the disc you have
selected in random order.
All MP3 audio tracks in the
album on the disc you have
selected in random order.
The tracks on all discs in the
order you want them to be
played (see “Creating your
own program” on page 28).
3 Press DISC SELECT repeatedly to
select the disc you want to play.
4 Press hH.
Other operations
ToDo this
Stop playbackPress x.
Pause playbackPress X.
Press again to resume playback.
Select an album
of MP3 tracks
Select a track During playback or pause, press
Use the remote for the operation.
1 Press DVD DISPLAY while
pressing SHIFT.
The Control Menu appears in
the on-scre en display.
2 Press V or v repeatedly to
select (ALBUM), then
press ENTER or b.
The list of albums contained in
the disc appears.
3 Press V or v repeatedly to
select an album you want to
play, then press ENTER.
You can select an album by
pressing B or b, or A L BUM +
or – while pressing SHIFT.
4 Press V or v repeatedly to
select (TRACK), then
press ENTER.
The list of tracks contained in
the current album appears.
When the list of all tracks or
albums cannot be displayed on
the window, the ju mp bar
appears. Press b to select the
jump bar icon, and then scroll
the jump bar to display t h e r est
of the list using V/v.
5 Press V or v repeatedly to
select a track, then press
ENTER.
> (to go forward) or . (to
go back).
26
GB
Loading...
+ 58 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
