Sony DAV-HDX475 User Manual

0 (0)

3-283-031-11(1)

DVD Home Theatre System

Operating Instructions

DAV-HDX275 / HDX276 / HDX475

WARNING

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

Caution – The use of optical instruments with this product will increase eye hazard.

Do not install the appliance in a confined space, such as a bookcase or built-in cabinet.

To prevent fire, do not cover the ventilation of the apparatus with news papers, table-cloths, curtains, etc. And don’t place lighted candles on the apparatus.

To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus.

Batteries or batteries installed apparatus shall not be exposed to excessive heat such as sunshine, fire or the like.

In door use only.

This appliance is classified as a CLASS 1 LASER product. This marking is loca ted on the rear exterior.

For the customers in the U.S.A

the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product.

Model No. DAV-HDX275/DAV-HDX276/DAVHDX475

Serial No.______________

Date of Manufacture Marking is located on the bottom exterior.

The following FCC statement applies only to the version of this model manufactured for sale in the USA. Other versions may not comply with FCC technical regulations.

WARNING

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna (aerial).

– Increase the separation between the equipment and

receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Owner’s Record

The model and serial numbers are located at the rear exterior of the control unit. Record the serial number in

CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

• Install this system so that the AC power cord (mains lead) can be unplugged from the wall socket immediately in the event of trouble.

Note on power cord plug shapes (Saudi Arabian model only)

For AC 220 V wall sockets

Make sure that the 13 A 3-pin plug (Type BF) is securely attached to the power cord. (The 13 A 3-pin plug is attached when shipped from the factory.)

For AC 127 V wall sockets

1 Remove the 13 A 3-pin plug using a

screwdriver.

2 Attach the supplied parallel blade plug (Type

A).

Precautions

On power sources

• AC power cord (mains lead) must be changed only at the qualified service shop.

• The unit is not disconnected from the AC power source (mains) as long as it is connected to the wall outlet (mains), even if the unit itself has been turned off.

About This Operating

About the S-AIR function

Instructions

• The instructions in this Operating Instructions describe the controls on the remote. You can also use the controls on the unit if they have the same or similar names as those on the remote.

• The instructions in this manual are for DAVHDX275, DAV-HDX276, and DAVHDX475. DAV-HDX275 is the model used for illustration purposes. Any difference in operation is clearly indicated in the text, for example, “DAV-HDX275 only.”

• The Control Menu items may vary depending on the area.

• “DVD” may be used as a general term for a DVD VIDEO, DVD+RW/DVD+R, and DVDRW/DVD-R.

• Measurements are expressed in feet (ft) for North American models.

• The default setting is underlined.

(DAV-HDX275/DAV-HDX475 only)

The system is compatible with the S-AIR function, which allows transmission of sound between S-AIR products wirelessly. The following S-AIR products can be used with the system:

• Surround amplifier: You can enjoy surround speaker sound wirelessly.

• S-AIR receiver: You can enjoy system sound in another room.

These S-AIR products can be purchased as an option (the S-AIR product lineup differs depending on the area).

Notes or instructions for the surround amplifier or S-AIR receiver in this operating instructions refer only to when the surround amplifier or S-AIR receiver is used. For details on the S-AIR function, see “Using an S-AIR Product” (page 77).

Table of Contents

About This Operating Instructions..........4

About the S-AIR function.......................4

Playable Discs......................................... 6

Getting Started

Step 1: Assembling

the Speakers ........................... 13

Step 2: Positioning the System... 18 Step 3: Connecting the System... 22 Step 4: Performing the Quick

Setup........................................ 35

Step 5: Enjoying Sound from all the

Speakers.................................. 38

Sound Adjustment

Enjoying Surround Sound by Using

Decoding Mode ..............................40

Selecting the Sound Mode .................... 42

Enjoying Multiplex Broadcast Sound ... 42

Disc

Playing a Disc ....................................... 43

Using Play Mode...................................49

Searching/Selecting a Disc ...................52

Playing MP3 Files/JPEG Image Files... 54

Enjoying DivX® Videos....................... 57

Adjusting the Delay Between the Picture

and Sound .......................................59

Restricting Playback of the Disc...........59

Using the Setup Display........................61

Tuner

Presetting Radio Stations......................70

Listening to the Radio...........................71

Control for HDMI/External Audio Device

Using the Control for HDMI Function for

“BRAVIA” Sync ............................73

Using the DIGITAL MEDIA PORT

Adapter ........................................... 76

Using an S-AIR Product .......................77

Other Operations

Getting Optimal Surround Sound for a

Room .............................................. 83

Calibrating the Appropriate Settings

Automatically................................. 84

Controlling the TV with the Supplied

Remote ........................................... 85

Using the Sound Effect......................... 86

Using the Sleep Timer .......................... 86

Changing the Brightness of the Front

Panel Display.................................. 87

Viewing Information About the Disc ... 87

Returning to the Default Settings ......... 90

Additional Information

Precautions............................................ 91

Notes about the Discs ........................... 92

Troubleshooting.................................... 93

Self-diagnosis Function ...................... 100

Specifications...................................... 101

Glossary.............................................. 103

Language Code List ............................ 105

Index to Parts and Control .................. 106

Guide to the Control Menu Display ... 110

Index ................................................... 113

Playable Discs

Type Disc logo Characteristics Icon

DVD VIDEO • DVD VIDEO

• DVD-R/DVD-RW in DVD VIDEO format or video mode

• DVD+R/DVD+RW in DVD VIDEO format

VR (Video Recording) mode

• DVD-R/DVD-RW in VR (Video Recording) mode (except for DVD-R DL)

Super Audio CD • Super Audio CD

VIDEO CD • VIDEO CD (Ver. 1.1 and 2.0 discs)

• Super VCD

• CD-R/CD-RW/CD-ROM in video CD format or Super VCD format

CD • Audio CD

• CD-R/CD-RW in audio CD format

DATA CD – • CD-R/CD-RW/CD-ROM in

DATA CD format, containing MP3 files1), JPEG image files2), and DivX video files conforming to ISO 9660

3)4)5)

, and

Level 1/

Level 2, or Joliet (extended format)

DATA DVD – • DVD-ROM/DVD-R/DVD-RW/

DVD+R/DVD+RW in DATA DVD format, containing MP3 files1), JPEG image files2), and DivX video files

3)4)5)

, and conforming to UDF (Universal Disk Format)

MP3 (MPEG1 Audio Layer 3) is a standard format defined by ISO/MPEG which compresses audio data. MP3 files

must be in MPEG1 Audio Layer 3 format.

JPEG image files must conform to the DCF image file format. (DCF “Design rule for Camera File system”: Image

standards for digital cameras regulated by Japan Electronics and Information Technology Industries Association (JEITA).)

Except for United Kingdom and North American models.

DivX® is a video file compression technology, developed by DivX, Inc.

DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.

A logical format of files and folders on CD-ROMs, defined by ISO (International Organization for

Standardization).

“DVD-RW,” “DVD+RW,” “DVD+R,”“DVD VIDEO,” and the “CD” logos are trademarks.

Example of discs that the system cannot play

The system cannot play the following discs:

• CD-ROM/CD-R/CD-RW other than those recorded in the formats listed on page 6

• CD-ROM recorded in PHOTO CD format

• Data part of CD-Extra

• CD Graphics disc

• DVD Audio

• DATA DVD that does not contain MP3 files, JPEG image files, or DivX video files*

* Except for United Kingdom and North American models.

• DVD-RAM

Also, the system cannot play the following discs:

• A DVD VIDEO with a different region code (page 8)

• A disc that has a non-standard shape (e.g., card, heart)

• A disc with paper or stickers on it

• A disc that has the adhesive of cellophane tape or a sticker still left on it

Note about CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/DVD+RW

In some c ases, CD-R/CD-RW/DVD-R /DVD-RW/DVD+R /DVD+RW cannot be played on th is system due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software. The disc will not play if it has not been correctly finalized. For more information, refer to the operating instructions for the recording device. Note that some playback functions may not work with some DVD+RWs/DVD+Rs, even if they have been correctly finalized. In this case, view the disc by normal playback. Also some DATA CDs/DATA DVDs created in Packet Write format cannot be played.

Music discs encoded with copyright protection technologies

This product is designed to play back discs that conform to the Compact Disc (CD) standard. Recently, various music discs encoded with copyright protection technologies are marketed by some record companies. Please be aware that among those discs, there are some that do not conform to the CD standard and may not be playable by this product.

Note on DualDiscs

A DualDisc is a two sided disc product which mates DVD recorded material on one side with digital audio material on the other side. However, since the audio material side does not conform to the Compact Disc (CD) standard, playback on this product is not guaranteed.

About Multi Session CD

• This system can play a Multi Session CD when an MP3 file is contained in the first session. Any subsequent MP3 files recorded in later sessions can also be played back.

• This system can play a Multi Session CD when a JPEG image file is contained in the first session. Any subsequent JPEG image files recorded in later sessions can also be played back.

• If MP3 files and JPEG image files in music CD format or video CD format are recorded in the first session, only the first session will be played back.

Region code

Your system has a region code printed on the rear of the unit and will only play a DVD labeled with the same region code.

A DVD VIDEO labeled will also play on this system. If you try to play any other DVD VIDEO, the message [Playback prohibited by area limitations.] will appear on the TV screen. Depending on the DVD VIDEO, no region code indication may be given even though playing the DVD VIDEO is prohibited by area restrictions.

ALL

Note about playback operations of a DVD or VIDEO CD

Some playback operations on a DVD or VIDEO CD may be intentionally set by software producers. Since this system will play a DVD or VIDEO CD according to the disc contents the software producers designed, some playback features may not be available. Be sure to read the operating instructions supplied with the DVD or VIDEO CD.

Copyrights

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

This system incorporates with Dolby* Digital and Dolby Pro Logic (II) adaptive matrix surround decoder and the DTS** Digital Surround System.

* Manufactured under license from Dolby Laboratories.

“Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories.

** Manufactured under license from DTS, Inc.

“DTS” and “DTS Digital Surround” are registered trademarks of DTS, Inc.

This system incorporates High-Definition Multimedia Interface (HDMITM) technology. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

“BRAVIA” and are trademarks of Sony Corporation.

“S-AIR” and its logo are trademarks of Sony Corporation.

Getting Started

Unpacking

DAV-HDX275/DAV-HDX276

Getting Started

• Front speakers (2)

• AM loop antenna (aerial) (1)

• R6 (size AA) batteries (2)

• Center speaker (1)

• Surround speakers (2)

• Subwoofer (1)

• FM wire antenna (aerial) (1)

• Speaker cords (6, red/white/ green/gray/blue/purple)

•Video cord (1)

• Remote commander (remote) (1)

• Calibration mic (1)

• Foot pads (1 set)

• DIGITAL MEDIA PORT adapter (TDM-iP10) (1) (North American models only)

• Operating Instructions

• Speaker and TV connections (card)

DAV-HDX475

• Front speakers (2)

• Center speaker (1)

• Surround speakers (2)

• Subwoofer (1)

• AM loop antenna (aerial) (1)

• FM wire antenna (aerial) (1)

• Speaker cords (6, red/white/ green/gray/blue/purple)

• Video cord (1)

• Remote commander (remote) (1)

• R6 (size AA) batteries (2)

• Calibration mic (1)

• Foot pads (1 set)

• Posts (2)

• Bases (2)

• Mounting plates (2)

• Post covers (2)

• Screws (large, with washer) (4)

• Screws (small) (6)

• DIGITAL MEDIA PORT adapter (TDM-iP10) (1)

• Operating Instructions

• Speaker and TV connections (card)

Getting Started

Inserting batteries into the remote

Insert two R6 (size AA) batteries (supplied) by matching the 3 and # ends on the batteries to the markings inside the compartment. To use the remote, point it at the remote sensor on the unit.

Getting Started

Note

• Do not leave the remote in an extremely hot or humid place.

• Do not use a new battery with an old one.

• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.

• Do not expose the remote sensor to direct sunlight or lighting apparatus. Doing so may cause a malfunction.

• If you do not intend to use the remote for an extended period of time, remove the batteries to avoid possible damage from battery leakage and corrosion.

Attaching the foot pads to the subwoofer

Attach the foot pads (supplied) to the bottom of the subwoofer to stabilize the subwoofer and prevent it from slipping.

Remove the foot pads from the mount seat.

Step 1: Assembling the Speakers

(DAV-HDX475 only)

Before connecting the speakers, attach the speaker stand to the speaker. (For the front speakers)

Use the parts as follows:

• Front speakers (2)

• Speaker cords (2, red/white)

•Posts (2)

• Bases (2)

• Mounting plates (2)

• Post covers (2)

• Screws (large, with washer) (4)

• Screws (small) (6)

About how to connect the speaker cords to the SPEAKER jacks, see page 24.

Note

• Spread a cloth on the floor to avoid damaging the floor when you assemble the speakers.

• You can use the speaker without the speaker stand by installing it on the wall (page 18).

1 Thread the speaker cord through the hole in the base and post.

The connector and color tube of the speaker cords are the same color as the label of the jacks to be connected.

Use the speaker cords as follows:

• Front speaker (L): White

• Front speaker (R): Red Be careful with the orientation of the post. Thread the speaker cord (and the speaker system cord)

into the end of the post that has two holes.

Getting Started

Post

Bottom of the base

Two holes

Speaker cord

Top of the base

2 Attach the post cover to the other end of the post.

Orient the slot toward you, attach the post cover so that the slot of the post engages with the tab of the post cover, then secure with the screw.

Thread the speaker cord through the hole of the post cover.

Getting Started

Speaker cord

Hole

Upper part of the post

Post cover

Screw (small)

3 Lay the post in the slot of the speaker, slide the post to the end of the slot, then secure

the post with the mounting plate and screws.

Select the speaker whose jack color on its rear panel matches the color tube of the speaker cord.

Post cover

Be careful the orientation of the post cover when placing the post.

Secure two screws (large, with washer).

Rear of the speaker

Mounting plate

4 Connect the speaker cords to the speaker.

Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with the color tube to 3, and the speaker cord without the color tube to #.

Color tube Front speaker (L): White Front speaker (R): Red

Rear of the speaker

5 Attach the post to the base.

Insert the post so that the slit on the lower part of the post aligns with the projection of the base, then secure the post with the two screws.

Post

Slit

Getting Started

Projection

Base

Screws (small)

Note

• Make sure that the slot on the post aligns with the projection of the base by rotating the post slightly.

6 Adjust the height of the speaker.

Loosen (but do not remove) the screws, adjust the height of the speaker, then secure the screws. Adjust the speaker of one side, then adjust another speaker by checking lines as a guide.

Note

• When adjusting the height of the speaker, grasp the speaker so that the speaker does not fall.

Getting Started

Lines

Post

Loosen two screws.

7 Take up any speaker cord slack.

Take up slack in the speaker cord by pulling from the bottom of the base.

Secure the speaker cord by running it through the slot.

Adjust the length of the cord.

Secure two screws.

Fully-assembled illustration

Front speaker (L): White label

Front speaker (R): Red label

White

Getting Started

Red

Step 2: Positioning the System

For the best possible surround sound, all the speakers other than the subwoofer should be placed at the same distance from the listening position (A). However, this system allows you to place the center speaker up to 1.6 meters (5 ft) closer (B) and the surround speakers up to 5.0 meters (16 ft) closer (C) to the front speakers. The front speakers can be placed from 1.0 to 7.0 meters (3 to 23 ft) (A) from the listening position.

Getting Started

Place the system as illustrated below.

DAV-HDX275/DAV-HDX276

A Front speaker (L (left)) B Front speaker (R (right)) C Center speaker D Surround speaker (L (left)) E Surround speaker (R (right)) F Subwoofer G Unit

Top view

C C

* Not supplied.

DAV-HDX475

A Front speaker (L (left)) B Front speaker (R (right)) C Center speaker D Surround speaker (L (left)) E Surround speaker (R (right)) F Subwoofer G Unit

Top view

C C

Getting Started

* Not supplied.

Note

• Do not set the speakers in an inclined position.

• Do not place the speakers in locations that are:

– Extremely hot or cold

– Dusty or dirty

– Very humid

– Subject to vibrations

– Subject to direct sunlight

• Use caution when placing the speakers and/or speaker stands attached to the speakers on a specially treated (waxed, oiled, polished, etc.) floor, as staining or discoloration may result.

• Do not use any type of abrasive pad, scouring powder, or solvent such as alcohol or benzine.

• Do not lean or hang on the speaker, as the speaker may fall down.

• When you change the positions of the speakers, Sony recommends that you change the settings. For details, see “Getting Optimal Surround S ound for a Room” (page 83) and “Ca librating the Appropriate Settings Automatically” (page 84).

To install the speakers on a wall

Before installing the speakers on a wall, connect the speaker cord to the speaker. Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with the color tube to 3, and the speaker cord without the color tube to #.

Color tube Front speaker (L): White Front speaker (R): Red Center speaker: Green Surround speaker (L): Blue Surround speaker (R): Gray

1 Prepare screws (not supplied) that are suitable for the hole on the back of each speaker.

See the illustrations below.

30 mm (1 3/16 inches)

Getting Started

2 Fasten the screws to the wall.

DAV-HDX275/DAV-HDX276

For the center speaker

8 to 10 mm

/32 to 13/32

(

DAV-HDX475

For the center speaker

inch

)

4 mm (

/32 inch)

145 mm

/4 inches)

145 mm

/4 inches)

5 mm

(

/32 inch)

10 mm

/32 inch)

(

For the other speakers

8 to 10 mm

(

/32 to 13/32

For the front speakers

inch

)

Hole on the back of the speaker

8 to 10 mm

(

/32 to 13/32

For the surround speakers

/32 to 13/32

(

inch

8 to 10 mm

inch

)

/32 to 13/32

(

8 to 10 mm

inch

100 mm

4 inches

)

(

)

3 Hang the speakers on the screws.

Hole on the back of the speaker

Note

5 mm

/32 inch)

(

10 mm

/32 inch)

(

Rear of the speaker

• Use screws that are suitable for the wall material and strength. As a plaster board wall is especially fragile, attach the screws securely to a beam and fasten them to the wall. Install the speakers on a vertical and flat wall where reinforcement is applied.

• Contact a screw shop or installer regarding the wall material or screws to be used.

• Sony is not responsible for accident or damage caused by improper installation, insufficient wall strength or improper screw installation, natural calamity, etc.

Getting Started

Step 3: Connecting the System

See the connection diagram below, and read the additional information from 1 to 5 on the following pages.

Note

• Be sure to make connections securely to avoid hum and noise.

• When you connect another component with a volume control, turn up the volume of the other components to a level

Getting Started

where sound is not distorted.

DAV-HDX275/DAV-HDX276

3 DIGITAL MEDIA PORT adapter

3 Portable audio source

3 VCR, digital satellite receiver,

or PlayStation, etc.

2 TV

1 Front speaker (L)

1 Surround speaker (L)

4 AM loop antenna (aerial)

4 FM wire antenna (aerial)

5 AC power cord (mains lead)

1 Center speaker

1 Subwoofer

1 Front speaker (R)

1 Surround speaker (R)

:Signal flow

DAV-HDX475

3 DIGITAL MEDIA PORT adapter

3 Portable audio source

3 VCR, digital satellite receiver,

or PlayStation, etc.

Getting Started

2 TV

1 Front speaker (L)

1 Surround speaker (L)

4 AM loop antenna (aerial)

4 FM wire antenna (aerial)

5 AC power cord (mains lead)

1 Center speaker

1 Subwoofer

1 Front speaker (R)

1 Surround speaker (R)

:Signal flow

1 Connecting the Speakers

The connector and color tube of the speaker cords are the same color as the label of the jacks to be connected. Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with the color tube to 3, and the speaker cord without the color tube to #. Do not catch the speaker cord insulation in the speaker terminals.

Getting Started

Color tube

Rear of speaker

(+)

Connector

(–)

When connecting to the unit, insert the connector until it clicks.

DAV-HDX276

Rear panel

SUBWOOFER

TV/VIDEO

DIGITAL IN

COAXIAL OPTICAL

SPEAKER

CENTER SUBWOOFER

SPEAKER

CENTER

To the center speaker (green)

To the subwoofer (purple)

SPEAKER

FRONT R FRONT L SUR R SUR L

HDMI OUT

DMPORT

DC5V

0.7A MAX

COMPONENT VIDEO OUT

B/CBPR/CR

TV/VIDEO

VIDEO

OUT

AUDIO INYRL

To the surround speaker (L) (blue)

To the surround speaker (R) (gray)

SPEAKER

FRONT L

FRONT R

To the front speaker (R) (red)

To the front speaker (L) (white)

ANTENNA

COAXIAL 75

DAV-HDX275/DAV-HDX475

Rear panel

SPEAKER

FRONT R FRONT L SUR R SUR L

SPEAKER

CENTER SUBWOOFER

TV/VIDEO

DIGITAL IN

COAXIAL OPTICAL

HDMI OUT

DC5V

0.7A MAX

ANTENNA

EZW-T100

COMPONENT VIDEO OUT

B/CBPR/CR

DMPORT

COAXIAL 75

TV/VIDEO

VIDEO

OUT

AUDIO INYRL

Getting Started

SPEAKER

SUBWOOFER

CENTER

To the center speaker (green)

To the subwoofer (purple)

To the surround speaker (L) (blue)

To the surround speaker (R) (gray)

SPEAKER

FRONT L

FRONT R

To the front speaker (R) (red)

To the front speaker (L) (white)

2 Connecting the TV

Use the parts as follows:

•Video cord (1)

To listen to TV sound from the six speakers of the system, connect the TV and the system with the audio cord (not supplied) (A).

Getting Started

For video output to your TV, check the video input jacks of the TV, and select connection method A, B, or C. Picture quality improves in order from A (standard) to C (HDMI).

When the TV has the digital optical or coaxial output jack, you can improve sound quality by connecting with the digital cord (B).

DAV-HDX276

Digital optical cord (not supplied)

Audio cord (not supplied)

Digital coaxial cord (not supplied)

To the digital coaxial output jack of the TV

To the digital optical output jack of the TV

SPEAKER

CENTER SUBWOOFER

TV/VIDEO

DIGITAL IN

COAXIAL OPTICAL

SPEAKER

FRONT R FRONT L SUR R SUR L

HDMI OUT

DMPORT

DC5V

0.7A MAX

TV/VIDEO

To the AUDIO OUT jacks of the TV

ANTENNA

COMPONENT VIDEO OUT

B/CBPR/CR

COAXIAL 75

TV/VIDEO

VIDEO OUT

AUDIO INYRL

White Red

Rear panel

HDMI** cable (not supplied)

To the HDMI IN jack of the TV

Component video cord (not supplied)*

Green Blue Red

To the COMPONENT VIDEO IN jacks of the TV

Video cord (supplied)

VIDEO

OUT

To the VIDEO IN jack of the TV

DAV-HDX275/DAV-HDX475

Digital optical cord (not supplied)

Digital coaxial cord (not supplied)

To the digital coaxial output jack of the TV

To the digital optical output jack of the TV

SPEAKER

CENTER SUBWOOFER

TV/VIDEO

DIGITAL IN

COAXIAL OPTICAL

SPEAKER

FRONT R FRONT L SUR R SUR L

HDMI OUT

DC5V

0.7A MAX

HDMI** cable (not supplied)

COMPONENT VIDEO OUT

DMPORT

Component video cord (not supplied)*

Audio cord (not supplied)

White Red

TV/VIDEO

To the AUDIO OUT jacks of the TV

ANTENNA

COAXIAL 75

Rear panel

VIDEO

Video cord (supplied)

OUT

B/CBPR/CR

EZW-T100

TV/VIDEO

VIDEO

OUT

AUDIO INYRL

Green Blue Red

Getting Started

To the VIDEO IN jack of

To the HDMI IN jack of the TV

To the COMPONENT VIDEO IN jacks of the TV

the TV

* If your TV accepts progressive format signals, use this connection and set the output signal of the system to

progressive format (page 37).

** HDMI (High-Definition Multimedia Interface)

If your TV has the HDMI jack, use this connection and select the type of output signal (page 37).

Note

• During the “D MPORT” function, video signal is not output from the HDMI OUT and COMPONENT VIDEO OUT jacks.

• The system can accept both digital and analog signals. Digital signals have priority over analog signals. (COAXIAL has priority over OPTICAL.) If the digital signal ceases, the analog signal will be processed after 2 seconds.

• You can connect another component, such as a VCR, digital satellite receiver, or PlayStation, to the TV/VIDEO jacks (A or B) instead of the TV.

To change the color system (PAL or NTSC) (Asian, Australian, and Middle Eastern models only)

Depending on the TV to be connected, you may be required to select either PAL or NTSC for the color system. The initial setting of the system for Australian and Middle Eastern models is PAL. The initial setting of the system for Asian models is NTSC.

1 Turn off the system by pressing "/1. 2 Turn on the system by pressing "/1 while pressing X on the unit.

Getting Started

Each time you perform this operation, the color system toggles between PAL and NTSC. “NTSC” lights up in the front panel display when the color system is set to NTSC.

3 Connecting the other components

You can enjoy the connected component using the six speakers of the system.

• Portable audio source: A

• DIGITAL MEDIA PORT adapter: B

DAV-HDX276

Stereo mini-plug cord (not supplied)

To the portable audio source

Front panel

ANTENNA

SPEAKER

CENTER SUBWOOFER

TV/VIDEO

DIGITAL IN

COAXIAL OPTICAL

SPEAKER

FRONT R FRONT L SUR R SUR L

HDMI OUT

COMPONENT VIDEO OUT

DMPORT

DC5V

0.7A MAX

B/CBPR/CR

TV/VIDEO

VIDEO

OUT

AUDIO INYRL

COAXIAL 75

Rear panel

Getting Started

• You can connect another

DC5V

0.7A MAX

DMPORT

component, such as VCR, instead of the TV. For connection details, s ee pa ge

26.

DIGITAL MEDIA PORT adapter

DAV-HDX275/DAV-HDX475

Getting Started

SPEAKER

CENTER SUBWOOFER

TV/VIDEO

DIGITAL IN

COAXIAL OPTICAL

Stereo mini-plug cord (not supplied)

To the portable audio source

Front panel

EZW-T100 slot (See “Wireless system option” (page 31).)

ANTENNA

SPEAKER

FRONT R FRONT L SUR R SUR L

HDMI OUT

EZW-T100

COMPONENT VIDEO OUT

DMPORT

DC5V

0.7A MAX

B/CBPR/CR

TV/VIDEO

VIDEO

OUT

AUDIO INYRL

COAXIAL 75

Rear panel

Screws*

• You can connect another

DC5V

0.7A MAX

DMPORT

component, such as VCR, instead of the TV. For connection details, s ee pa ge

26.

DIGITAL MEDIA PORT adapter

* CAUTION

Please do not remove the screws before installing the EZW-T100 (page 77).

To connect the DIGITAL MEDIA PORT adapter

Connect a DIGITAL MEDIA PORT adapter (TDM-iP10 is supplied for North American models only) to the DMPORT jack. For details, see “Using the DIGITAL MEDIA PORT Adapter” (page 76).

Note

• Connect the DIGITAL MEDIA PORT adapter so that the V marks are aligned. When disconnecting, pull out while

pressing A.

+ 86 hidden pages
