User Guide

DynaMic

1

Contents

Welcome

DynaMic and accessories

Important DynaMic figures

Controls

Getting starting

Charging DynaMic
Battery status indication
Vibration alarm indication
Switch on DynaMic

Using DynaMic

User cases

Pass around microphone
Talking
Colored rings
DynaMic Data Logging
Programming

The MultiTalker Network

Initiating a MultiTalker Network
How to use a MultiTalker Network
Leaving a MultiTalker Network
Practical tips

Troubleshooting

Important notices

Service and warranty

Declaration of conformity

2

Welcome

DynaMic FM transmitter is ideally suited to the needs of teachers and suitable for use in
regular schools as well as special schools.

DynaMic, the inspiro’s passaround microphone is designed to work exclusively alongside
inspiro in the MultiTalker Network. With its simple, robust and childproof design DynaMic
integrates insprio’s high performance FM technology.

Please read this manual carefully to benefit from all the features of your DynaMic FM
transmitters. Ask your hearing care professional if you have any questions.

With proper care and usage, your DynaMic will support your communication needs for
many years.

DynaMic is a quality product developed by Phonak.
Phonak is the world leader in FM technology, innovation and reliability based in
Switzerland.

Further resources:
To find out more about DynaMic, as well as about Phonak FM in general, we recommend
visiting the following websites:

www.eSchoolDesk.com

This is a special website specifically dedicated to providing support to teachers,
but also to parents and other DynaMic users. Short movies available present for
example farious functions and trouble shooting for FM systems aim to provide
assistance in daily life.

www.phonak.com

This is Phonak home page. Go on the product section and click on the FM
systems. You can find useful information about inspiro and DynaMic as well as
FM receivers.

www.FMLibrary.com

This is an online scientific library about FM systems.

3

DynaMic and accessories

DynaMic is delivered with:

• Desk stand

• Clamp

• Colored rings

All the accessories can also be ordered separately.

1 DynaMic microphone

2. Desk stand (base and legg) with clamp

3/8”, 5/8”

3. Colored rings: red, yellow, green

4. Charging unit

5. Replacement microphone head

4

Important DynaMic figures

General:

Operates only with inspiro in MultiTalker Network

Length : 21 cm
Antenna length: 15 cm
Weight: 110g

Operating time and charging:

• Operating time if the battery is fully charged: up to 10 hours

• Charging time for an 80% charge approx. 1 hour

• Charging time for an 100% charge approx. 2 hours

Operating range (FM transmission):

• Operating range to initiator inspiro :

- inside 8 m

- outside 15 m

5

Controls

1. Slider Off/Mute/On
The slider puts the DynaMic in one of the three mode.

2. Reset button
This button gives the possibility to reset the DynaMic. The parameters stored in the flash
are not affected by this operation. Use a pen to press the button.

3. Built-in vibrator
The vibration alarm provides information on the status of the battery and operation.

4. FM Antenna
It emits FM to the receivers in the hearing instruments.

5. Mini USB interface
Interface for charging and programming

6. The LED indicates the following functionalities:

• battery status,

• charging,

• error states

1

2

3

4

5

6
