Sinbo SHC-4357 User Manual

SHC 4357 RECHARGEABLE HAIR CLIPPER

INSTRUCTION MANUAL

EN

RU

10

5

- 1 -

11

7

2

1

4

3

6

8 9

ENGLISH

SHC 4357 RECHARGEABLE HAIR CLIPPER
INSTRUCTION MANUAL

The hair clipper is a part of the hair clipper set and is intended for hair cutting and
thinning.

DESCRIPTION

1. Housing, 2. On / Off switch, 3. Indicator light, 4. Charge socket, 5. Adapter, 6. Socket
inlet, 7. Comb adjustment lever, 8. Lubricant Oil, 9. Cleaning brush, 10. Detachable comb

11. Detachable blades

FEATURES
Charging time: 8 hours
Working time: 50 minutes

Built in Ni-Cd 2*600mA battery
AC230V, 50Hz, 3W

SAFETY MEASURES

Read this instruction manual carefully before using the unit and keep it for future
reference or the whole unit operation period. Use the unit for intended purposes only,
as specified in this manual. Mishandling of the unit may lead to its breakage and cause
harm to the user or damage to his/her property.

• Before the first connecting the unit to the mains for battery charging, make sure that
your home mains voltage corresponds to power adapter operating voltage.

• The power adapter cord must not:
– touch hot objects and surfaces,
– be immersed into water,
– run over sharp edges of furniture,
– be used as a handle for carrying the unit.

• Do not touch the power adapter body with wet hands.

• Use the unit to cut only dry hair.

• Use the unit to cut only natural human hair.

• Do not use the unit to cut artificial hair and animal hair.

• Use only the attachments and the adapter supplied.

• Do not use the unit in places with high temperature and relative humidity more than
80%.

• Do not use the unit outdoors.

• Charge the battery at the temperature from +5°C to +35°C.

• Never use the unit if the attachment combs are broken or damaged or if the blades are
damaged.

ATTENTION! Keep the unit dry. Never immerse the hair clipper and the power adapter
into water or other liquids.

- 2 -

• Always keep the blades clean and lubricated.

• After each use of the hair clipper clean the attachments and the blade block with the
brush supplied to remove the cut-off hair.

• Never leave the operating unit unattended.

• Switch the hair clipper off during breaks between operation cycles or when you are not
using it.

• Do not allow children to touch the power adapter body during the unit charging.

• Do not allow children to use the units as a toy.

• This unit is not intended for usage by children.

• During the unit operation and breaks between operations cycles, place the unit out of
reach of children and disabled persons.

• The unit is not intended for usage by physically or mentally disabled persons (including
children) or by persons lacking experience or knowledge if they are not under supervision
of a person who is responsible for their safety or if they are not instructed by this person
on the usage of the unit.

• For children safety reasons do not leave polyethylene bags used as a packaging
unattended.

Attention! Do not allow children to play with polyethylene bags or packaging film.

Danger of suffocation!

• Do not attempt to repair the unit. Do not disassemble the unit by yourself, if any
alfunction is detected or after it was dropped, unplug the unit and apply to any authorized
service center from the contact address list given in the warranty certificate.

• To avoid damages, transport the unit in the original package only.

• Keep the unit in a dry cool place out of reach of children and disabled persons.

THE UNIT IS INTENDED FOR HOUSEHOLD USE ONLY, ITS COMMERCIAL USAGE AND
USAGE IN PRODUCTION AREAS AND WORK SPACES IS PROHIBITED.

BEFORE THE FIRST USE

After unit transportation or storage at low temperature keep it for at least three hours
at room temperature before switching on.
– Unpack the unit completely and remove any advertisement stickers that can prevent
the unit operation.
– Check the unit for damages; do not use it in case of damages.
– Before connecting the power adapter, make sure that voltage of the mains corresponds
to unit operating voltage.
– Charge the battery and lubricate them blade block following the recommendations
below.
The hair clipper can operate only on the built-in rechargeable battery.

Battery charging

Full charging of the accumulator battery is enough approximately for 35 minutes of
continuous operation.

- 3 -

– Switch the hair clipper off, setting the power switch to the “O” position.
– Insert the power adapter cord plug into the connection socket on the lower side of the
unit body.
– Place the hair clipper on a flat stable surface.
– Plug the power adapter plug into the mains socket, the charging indicator will light
up red.
– The full charging time for the accumulator battery is 10-12 hours; do not exceed it to
avoid reducing the battery operating life.
– After the battery is charged, unplug the power adapter from the mains, remove the
adapter cord plug from the connection socket, the charging indicator will go out.

Attention:

– Strictly follow the sequence of operations when connecting the power adapter. First
connect the power adapter jack to the socket and then connect the power adapter plug
to the mains socket.
– Charge the battery the first 2-3 times for 10-12 hours. The following charging cycle
time should not exceed 8 hours.
– To prolong the battery operating life, it should be discharged completely before each
charging cycle.
– Do not charge the batteries at temperature below +5°C and above +35°C.
– If you have not used the hair clipper for a month or more, charge it completely before
use.
– Never leave the unit connected to the mains unattended.

Lubricating the blade block

Before using the unit for the first time, remove the blade block and lubricate it with oil
(supplied with the unit).
– To remove the blade block, place the clipper with the blades up and press on the upper
edge of the blade block with your thumb to release it from the locking frame.
– The points for applying the lubricating oil are marked with arrows. Apply not more than
1 drop of oil to each point.
– To install the blade block, first insert its lower part into the installation place and then
carefully press on the upper edge of the blades until clicking to lock it.
– Let the hair clipper operate for approximately 30 seconds to spread the oil across the
rubbing surfaces. After that remove the surplus oil with a dry cloth or a paper towel.

Notes:

– Always set the blade height switch to the lower position to avoid difficulties when
installing the blade block to its place.
– Lubricate the blades after every use of the hair clipper.
– Use only the oil supplied with the set.
– Do not use vegetable oil or oil that includes solvents. Solvents will evaporate, leaving
thick grease that may slow down the blades motion.

- 4 -

Blade height switch 0.8 mm/1.8 mm

When the switch is in the lower (usual) position, the cutting length is 1.8 mm.
To reduce the cutting length to 0.8 mm set the switch to the upper position.

Universal attachment

The universal attachment has 6 positions for different hair cutting length. It is indicated
on the scale situated on the left side of the hair clipper body:
– universal attachment for 3 mm, 6 mm, 9 mm, 12 mm, 15 mm, 18 mm hair length.
– Switch the unit off by setting the power switch to the position "O" before installing,
removing or changing the universal attachment.
– To install the universal attachment, insert its guides into the corresponding grooves
on both sides of the hair clipper body and slide the attachment as far as it will go to lock
it.
– To adjust the cutting length, turn the adjuster counter/clockwise with your thumb to
set the required hair cutting length according to the scale.

Attention: Do not try to adjust the cutting length with the adjuster during the unit operation,
because when the power switch is set to the position «I», the adjuster is blocked.

Hair thinning function

The unit has the hair thinning function which allows to visually improve the hairstyle by
thinning out hair. Hair thinning makes the hairstyle lighter and accentuates the hair
texture. Due to thinning out the haircut keeps its style for a long time. Hair thinning
means cutting off separate locks. It allows achieving smooth transition between
locks of different length. Hair thinning is performed at the final phase of hair cutting.
To extend the hair thinning comb, move the lock to the utmost right position.
To remove the hair thinning comb, move the lock to the utmost left position.

USING THE HAIR CLIPPER

– For cordless use of the unit, charge the battery fully following the recommendations
above.

Hair cutting

– The hair should be clean and dry.
– Before cutting hair, switch the hair clipper on by setting the power switch to
the position «I».
– Make sure that the hair clipper operates normally and the blades move smoothly.
If there is excess oil on blades, remove it with a dry cloth or a paper tissue.
– Switch the unit off by setting the switch to the position «O», then install the
universal attachment .
– Seat a person so that his/her head is approximately at your eye level, cover the person’s

- 5 -
