Siemens M8000, M9000 User Manual

SPARC® Enterprise

M8000/M9000 Servers

Product Notes

For XCP version 1072

Order No. U41813-J-Z816-1-76
Part No. 820-6008-10
September 2008, Revision A

Copyright 2008 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara, California 95054, U.S.A. and FUJITSU LIMITED, 1-1, Kamikodanaka
4-chome, Nakahara-ku, Kawasaki-shi, Kanagawa-ken 211-8588, Japan. All rights reserved.

Sun Microsystems, Inc. and Fujitsu Limited each own or control intellectual property rights relating to products and technology described in
this document, and such products, technology and this document are protected by copyright laws, patents and other intellectual property laws
and international treaties. The intellectual property rights of Sun Microsystems, Inc. and Fujitsu Limited in such products, technology and this
document include, without limitation, one or more of the United States patents listed at http://www.sun.com/patents and one or more
additional patents or patent applications in the United States or other countries.

This document and the product and technology to which it pertains are distributed under licenses restricting their use, copying, distribution,
and decompilation. No part of such product or technology, or of this document, may be reproduced in any form by any means without prior
written authorization of Fujitsu Limited and Sun Microsystems, Inc., and their applicable licensors, if any. The furnishing of this document to
you does not give you any rights or licenses, express or implied, with respect to the product or technology to which it pertains, and this
document does not contain or represent any commitment of any kind on the part of Fujitsu Limited or Sun Microsystems, Inc., or any affiliate of
either of them.

This document and the product and technology described in this document may incorporate third-party intellectual property copyrighted by
and/or licensed from suppliers to Fujitsu Limited and/or Sun Microsystems, Inc., including software and font technology.

Per the terms of the GPL or LGPL, a copy of the source code governed by the GPL or LGPL, as applicable, is available upon request by the End
User. Please contact Fujitsu Limited or Sun Microsystems, Inc.

This distribution may include materials developed by third parties.
Parts of the product may be derived from Berkeley BSD systems, licensed from the University of California. UNIX is a registered trademark

in the U.S. and in other countries, exclusively licensed through X/Open Company, Ltd.
Sun, Sun Microsystems, the Sun logo, Java, Netra, Solaris, Sun Ray, Answerbook2, docs.sun.com, OpenBoot, and Sun Fire are trademarks or

registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.
Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited.
All SPARC trademarks are used under license and are registered trademarks of SPARC International, Inc. in the U.S. and other countries.

Products bearing SPARC trademarks are based upon architecture developed by Sun Microsystems, Inc.
SPARC64 is a trademark of SPARC International, Inc., used under license by Fujitsu Microelectronics, Inc. and Fujitsu Limited.
The OPEN LOOK and Sun™ Graphical User Interface was developed by Sun Microsystems, Inc. for its users and licensees. Sun acknowledges

the pioneering efforts of Xerox in researching and developing the concept of visual or graphical user interfaces for the computer industry. Sun
holds a non-exclusive license from Xerox to the Xerox Graphical User Interface, which license also covers Sun’s licensees who implement OPEN
LOOK GUIs and otherwise comply with Sun’s written license agreements.

United States Government Rights - Commercial use. U.S. Government users are subject to the standard government user license agreements of
Sun Microsystems, Inc. and Fujitsu Limited and the applicable provisions of the FAR and its supplements.

Disclaimer: The only warranties granted by Fujitsu Limited, Sun Microsystems, Inc. or any affiliate of either of them in connection with this
document or any product or technology described herein are those expressly set forth in the license agreement pursuant to which the product
or technology is provided. EXCEPT AS EXPRESSLY SET FORTH IN SUCH AGREEMENT, FUJITSU LIMITED, SUN MICROSYSTEMS, INC.
AND THEIR AFFILIATES MAKE NO REPRESENTATIONS OR WARRANTIES OF ANY KIND (EXPRESS OR IMPLIED) REGARDING SUCH
PRODUCT OR TECHNOLOGY OR THIS DOCUMENT, WHICH ARE ALL PROVIDED AS IS, AND ALL EXPRESS OR IMPLIED
CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE
EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID. Unless otherwise expressly set forth in such agreement, to the
extent allowed by applicable law, in no event shall Fujitsu Limited, Sun Microsystems, Inc. or any of their affiliates have any liability to any
third party under any legal theory for any loss of revenues or profits, loss of use or data, or business interruptions, or for any indirect, special,
incidental or consequential damages, even if advised of the possibility of such damages.

DOCUMENTATION IS PROVIDED “AS IS” AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON­INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID.

Please

Recycle

Copyright 2008 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara, California 95054, U.S.A. et FUJITSU LIMITED, 1-1, Kamikodanaka
4-chome, Nakahara-ku, Kawasaki-shi, Kanagawa-ken 211-8588, Japon. Tous droits réservés.

Entrée et revue tecnical fournies par Fujitsu Limited sur des parties de ce matériel.
Sun Microsystems, Inc. et Fujitsu Limited détiennent et contrôlent toutes deux des droits de propriété intellectuelle relatifs aux produits et

technologies décrits dans ce document. De même, ces produits, technologies et ce document sont protégés par des lois sur le copyright, des
brevets, d’autres lois sur la propriété intellectuelle et des traités internationaux. Les droits de propriété intellectuelle de Sun Microsystems, Inc.
et Fujitsu Limited concernant ces produits, ces technologies et ce document comprennent, sans que cette liste soit exhaustive, un ou plusieurs
des brevets déposés aux États-Unis et indiqués à l’adresse http://www.sun.com/patents de même qu’un ou plusieurs brevets ou applications
brevetées supplémentaires aux États-Unis et dans d’autres pays.

Ce document, le produit et les technologies afférents sont exclusivement distribués avec des licences qui en restreignent l’utilisation, la copie,
la distribution et la décompilation. Aucune partie de ce produit, de ces technologies ou de ce document ne peut être reproduite sous quelque
forme que ce soit, par quelque moyen que ce soit, sans l’autorisation écrite préalable de Fujitsu Limited et de Sun Microsystems, Inc., et de leurs
éventuels bailleurs de licence. Ce document, bien qu’il vous ait été fourni, ne vous confère aucun droit et aucune licence, expresses ou tacites,
concernant le produit ou la technologie auxquels il se rapporte. Par ailleurs, il ne contient ni ne représente aucun engagement, de quelque type
que ce soit, de la part de Fujitsu Limited ou de Sun Microsystems, Inc., ou des sociétés affiliées.

Ce document, et le produit et les technologies qu’il décrit, peuvent inclure des droits de propriété intellectuelle de parties tierces protégés par
copyright et/ou cédés sous licence par des fournisseurs à Fujitsu Limited et/ou Sun Microsystems, Inc., y compris des logiciels et des
technologies relatives aux polices de caractères.

Par limites du GPL ou du LGPL, une copie du code source régi par le GPL ou LGPL, comme applicable, est sur demande vers la fin utilsateur
disponible; veuillez contacter Fujitsu Limted ou Sun Microsystems, Inc.

Cette distribution peut comprendre des composants développés par des tierces parties.
Des parties de ce produit pourront être dérivées des systèmes Berkeley BSD licenciés par l’Université de Californie. UNIX est une marque

déposée aux Etats-Unis et dans d’autres pays et licenciée exclusivement par X/Open Company, Ltd.
Sun, Sun Microsystems, le logo Sun, Java, Netra, Solaris, Sun Ray, Answerbook2, docs.sun.com, OpenBoot, et Sun Fire sont des marques de

fabrique ou des marques déposées de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays.
Fujitsu et le logo Fujitsu sont des marques déposées de Fujitsu Limited.
Toutes les marques SPARC sont utilisées sous licence et sont des marques de fabrique ou des marques déposées de SPARC International, Inc.

aux Etats-Unis et dans d’autres pays. Les produits portant les marques SPARC sont basés sur une architecture développée par Sun
Microsystems, Inc.

SPARC64 est une marques déposée de SPARC International, Inc., utilisée sous le permis par Fujitsu Microelectronics, Inc. et Fujitsu Limited.
L’interface d’utilisation graphique OPEN LOOK et Sun™ a été développée par Sun Microsystems, Inc. pour ses utilisateurs et licenciés. Sun

reconnaît les efforts de pionniers de Xerox pour la recherche et le développement du concept des interfaces d’utilisation visuelle ou graphique
pour l’industrie de l’informatique. Sun détient une license non exclusive de Xerox sur l’interface d’utilisation graphique Xerox, cette licence
couvrant également les licenciés de Sun qui mettent en place l’interface d’utilisation graphique OPEN LOOK et qui, en outre, se conforment
aux licences écrites de Sun.

Droits du gouvernement américain - logiciel commercial. Les utilisateurs du gouvernement américain sont soumis aux contrats de licence
standard de Sun Microsystems, Inc. et de Fujitsu Limited ainsi qu’aux clauses applicables stipulées dans le FAR et ses suppléments.

Avis de non-responsabilité: les seules garanties octroyées par Fujitsu Limited, Sun Microsystems, Inc. ou toute société affiliée de l’une ou l’autre
entité en rapport avec ce document ou tout produit ou toute technologie décrit(e) dans les présentes correspondent aux garanties expressément
stipulées dans le contrat de licence régissant le produit ou la technologie fourni(e). SAUF MENTION CONTRAIRE EXPRESSÉMENT
STIPULÉE DANS CE CONTRAT, FUJITSU LIMITED, SUN MICROSYSTEMS, INC. ET LES SOCIÉTÉS AFFILIÉES REJETTENT TOUTE
REPRÉSENTATION OU TOUTE GARANTIE, QUELLE QU’EN SOIT LA NATURE (EXPRESSE OU IMPLICITE) CONCERNANT CE
PRODUIT, CETTE TECHNOLOGIE OU CE DOCUMENT, LESQUELS SONT FOURNIS EN L’ÉTAT. EN OUTRE, TOUTES LES
CONDITIONS, REPRÉSENTATIONS ET GARANTIES EXPRESSES OU TACITES, Y COMPRIS NOTAMMENT TOUTE GARANTIE
IMPLICITE RELATIVE À LA QUALITÉ MARCHANDE, À L’APTITUDE À UNE UTILISATION PARTICULIÈRE OU À L’ABSENCE DE
CONTREFAÇON, SONT EXCLUES, DANS LA MESURE AUTORISÉE PAR LA LOI APPLICABLE. Sauf mention contraire expressément
stipulée dans ce contrat, dans la mesure autorisée par la loi applicable, en aucun cas Fujitsu Limited, Sun Microsystems, Inc. ou l’une de leurs
filiales ne sauraient être tenues responsables envers une quelconque partie tierce, sous quelque théorie juridique que ce soit, de tout manque
à gagner ou de perte de profit, de problèmes d’utilisation ou de perte de données, ou d’interruptions d’activités, ou de tout dommage indirect,
spécial, secondaire ou consécutif, même si ces entités ont été préalablement informées d’une telle éventualité.

LA DOCUMENTATION EST FOURNIE “EN L’ETAT” ET TOUTES AUTRES CONDITIONS, DECLARATIONS ET GARANTIES EXPRESSES
OU TACITES SONT FORMELLEMENT EXCLUES, DANS LA MESURE AUTORISEE PAR LA LOI APPLICABLE, Y COMPRIS
NOTAMMENT TOUTE GARANTIE IMPLICITE RELATIVE A LA QUALITE MARCHANDE, A L’APTITUDE A UNE UTILISATION
PARTICULIERE OU A L’ABSENCE DE CONTREFACON.

Contents

Preface vii

Technical Support vii

Software Resources vii

Accessing Documentation viii

Fujitsu Siemens Computers Welcomes Your Comments viii

General Information about XCP 1

Supported Firmware and Operating System 1

Solaris OS Patch Information 2

Patches for SPARC64 VI Processors 2

Patches for SPARC64 VII Processors 2

Updating to XCP 3

Resetting the XSCF Firmware 3

Updating from a Version Earlier Than XCP 1050 3

Updating from a Version Earlier Than XCP 1070 4

Functionality Issues and Limitations 4

Limitations for SPARC64 VII Processors 4

General Functionality Issues and Limitations 4

Information about Hardware 7

v

Hardware Issues and Workarounds 7

Sun Crypto Accelerator 6000 Cards 7

Information about Software 8

XCP Issues and Workarounds 8

Solaris OS Issues and Workarounds 12

Software Documentation Updates 27

Identifying Degraded Memory in a System 29

Identifying Different Memory Sizes in a System Board 29

Using the showdevices Command 29

Using the prtdiag Command to Identify Memory Size 30

Identifying Permanent Memory in a Target Board 31

CPU Upgrade 32

Installation Notes 32

Updating the OpenBoot PROM Firmware With Processor Upgrade 32

Adding SPARC64 VII Processors to a Domain Using DR 32

Adding a New CMU Equipped with SPARC64 VII as a New Domain 33

Upgrading an On-CMU SPARC64 VI to SPARC64 VII, or Adding SPARC64 VII

to an Existing CMU, to an Existing Domain Configured with SPARC64
VI 35

Adding a New CMU Equipped with SPARC64 VII to an Existing Domain

Configured with SPARC64 VI 38

vi SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

Preface

These product notes contain late-breaking information about the SPARC® Enterprise
M8000/M9000 server hardware, software, or documentation that became known
after the documentation set was published.

Technical Support

If you have technical questions or issues that are not addressed in the SPARC
Enterprise M8000/M9000 servers documentation, contact a sales representative or a
certified service engineer.

Software Resources

The Solaris™ Operating System and Sun Java™ Enterprise System software are
preinstalled on your SPARC Enterprise M8000/M9000 servers.

Contact a sales representative or a certified service engineer for software resources
for your SPARC Enterprise M8000/M9000 servers.

Note – For latest patch information go to:

http://support.fujitsu-siemens.com

Installation information and README files are included in the patch download.

vii

Accessing Documentation

Instructions for installing, administering, and using your SPARC Enterprise
M8000/M9000 servers are provided in the SPARC Enterprise M8000/M9000 servers
documentation set.
The documentation set is available for download from the following website:

http://manuals.fujitsu-siemens.com/

Note – Information in these product notes supersedes the information in the SPARC

Enterprise M8000/M9000 servers documentation set.

Solaris documentation is available at:

http://www.sun.com/documentation

Fujitsu Siemens Computers Welcomes Your Comments

If you have any comments or requests regarding this manual, or if you find any
unclear statements in the manual, please state your points specifically, and forward
it to a sales representative or a certified service engineer.

Please include the title and part number of your document with your feedback.

viii SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

General Information about XCP 1072

This section describes the general information about XCP 1072.

■ Supported Firmware and Operating System

■ Updating to XCP

■ Functionality Issues and Limitations

Supported Firmware and Operating System

The following firmware and operating system (OS) are supported in this release.

TABLE 1 Firmware and Operating System Versions

Firmware and Operaing System Version

XSCF Control Package (XCP) 1072

Solaris™ Operating System

SPARC64 VI processors: 10 8/07 or later

10 11/06, with required patches

SPARC64 VII processors: 10 5/08 or later

10 8/07, with required patches

1

Note – By using the Solaris 10 8/07 installation DVD, you cannot boot the domain

mounted with the SPARC64 VII processors. When you newly install Solaris OS to a
domain mounted with the SPARC64 VII processors, use the Solaris 10 5/08
installation DVD to install Solaris 10 5/08.

For XCP, you can download the latest files of firmware at the following websites.

Global Site:

http://www.fujitsu.com/sparcenterprise/firmware/

Japanese Site:

http://primeserver.fujitsu.com/sparcenterprise/download/firmware/

Solaris OS Patch Information

This section lists mandatory patches for the SPARC Enterprise M8000/M9000
servers.

Patches for SPARC64 VI Processors

These patches are required for servers running Solaris 10 11/06.

■ 118833-36 (Install 118833-36 before 125100-04.)

■ 125100-04 or later

■ 120068-03 or later

■ 123839-07 or later

■ 125424-01 or later

■ 125075-01 or later

■ 125670-02 or later

The patches are not required for servers running Solaris 10 8/07 OS or later.

Patches for SPARC64 VII Processors

These patches are required for servers running Solaris 10 8/07 and mounting
SPARC64 VII processors.

Note – Apply the patches in the following order. For the procedures of CPU

upgrade including the patches, see “CPU Upgrade” on page 32.

2 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

■ 119254-51 or later

■ 125891-01 or later

■ 127755-01 or later

■ 127127-11

The patches are not required for servers running Solaris 10 5/08 OS or later.

Note – See “Software Resources” on page vii for information on how to find the

latest patches. Installation information and README files are included in the patch
download.

Patches for Emulex PCI-E Cards

The following Emulex cards require drivers supplied in patch 120222-26:

■ XSEFC402AF Sun StorageTek Enterprise Class 4Gb Dual-Port Fibre Channel PCI-

E HBA

■ XSEFC401AF Sun StorageTek Enterprise Class 4Gb Single-Port Fibre Channel PCI-

E HBA

Updating to XCP 1071 or Later

To update your XCP to XCP 1071 or later, please pay attention to the following
points depending on your current XCP version.

You can upgrade to XCP 1071 or later from XCP version 1050 or higher. Refer to the
SPARC Enterprise M4000/M5000/M8000/M9000 Servers XSCF User’s Guide for
instructions.

Resetting the XSCF Firmware

After updating the XCP firmware to 1071 or later, do not fail to reset the XSCF by
using the rebootxscf(8) command.

General Information about XCP 1072 3

Updating from a Version Earlier Than XCP 1050

■ You cannot update to XCP 1071 or later directly.

If you are currently running a version earlier than XCP 1050, you must first
update to an interim version of XCP between 1050 and 1070 (inclusive) before
updating to XCP 1071 or later. Refer to the product notes document for the
interim version for instructions.

■ Delete any accounts named "admin".

Any accounts named admin must be deleted prior to updating to XCP 1050 or
later. This account name is reserved in XCP 1050 and higher. Use the
deleteuser(8) command to delete the account.

Updating from a Version Earlier Than XCP 1070

On a domain which has been in operation during the XCP update to XCP 1071 or
later, when you perform Dynamic Reconfiguration (DR) to add or replace the
SPARC64 VII processors, you need to update the OpenBoot™ PROM firmware. The
OpenBoot PROM firmware is updated as you update the XCP and restart the
domain. For this reason, it is strongly recommended to restart all the domains after
you update the firmware to XCP 1071 or later, regardless of whether you added or
replaced the SPARC64 VII processors.

Functionality Issues and Limitations

This section describes the known issues and limitations at the time of this release.

Limitations for SPARC64 VII Processors

Caution – You must complete the upgrades to the XCP firmware and to Solaris OS

before inserting the CPU/memory board unit of SPARC 64 VII processors into the
chassis.

On a SPARC Enterprise M9000 server, if a single domain includes 16 boards
containing SPARC64 VII processors, then SunVTS 7.0ps2 software will not start.
(CR ID: 6720922)

4 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

General Functionality Issues and Limitations

Caution – For dynamic reconfiguration (DR) and hot-plug issues, see TABLE 4.

■ Domains using the ZFS file system cannot use Dynamic Reconfiguration.

■ The maximum number of IOUA (Base I/O Card) cards per domain is limited to

six cards.

■ Do not use the internal CD-RW/DVD-RW drive unit and the TAPE drive unit at

the same time.

■ For this XCP release, the XSCF browser user interface (XSCF Web) does not

support the External I/O Expansion Unit Manager feature.

■ The XSCF does not support the Log Archiving feature.

■ When using XSCF as the NTP server of the domain, configure it so as not to block

the ICMP protocol of the DNS server and the NTP server which the XSCF refers
to.

■ When you use the external power control interface of the external power

controller, the following notification signals are not supported:

■ the OS panic or the server hardware error signal (*CPUN/RTNU)

■ the server hardware error signal (power fail, temperature error, and fan error)

(*ALARM)

■ For 1027A-Z/X1027A-Z, PCIe Dual 10 Gigabit Ethernet Fiber XFP cards, these

limits apply:

■ Do not use more than two cards per domain.

■ Do not use these cards in an External I/O Expansion Unit.

■ For 4447A-Z/X4447A-Z, PCIe Quad-port Gigabit Ethernet Adapter UTP cards,

these maximum limits apply:

■ No more than two cards in an External I/O Expansion Unit.

■ No more than eight cards in a SPARC Enterprise M8000/M9000 servers.

■ In case that Solaris OS is a single user mode, if you switch from the domain　

console to the XSCF Shell, Solaris OS might start up in multi-user. When you
operate the single user mode for Solaris OS, do not switch from the domain
console to the XSCF Shell.

■ We recommend the domain to use the XSCF Unit as NTP server. In this case, pay

attention to the following points:

■ XSCF must be connected to an external NTP server

■ When you connect one or more NTP servers in addition to XSCF, connect the

same NTP server as XSCF is using

For details on NTP server, contact a service engineer. For details on NTP settings,
refer to the SPARC Enterprise M4000/M5000/M8000/M9000 Servers XSCF User's
Guide.

General Information about XCP 1072 5

■ On the SPARC Enterprise M8000/M9000 servers with XCP 1050 or later, the dual

XSCF Unit feature is working. Therefore, you can not downgrade SPARC
Enterprise M8000/M9000 servers with XCP 1050 or later to XCP 1040 or XCP
1041, which does not support dual XSCF Unit feature.

■ You cannot use the following user account names, as they are reserved for system

use: root, bin, daemon, adm, operator, nobody, sshd, rpc, rpcuser, ldap,
apache, ntp, admin, and default.

■ The Firefox 3 is not supported in XSCF Web.

■ Using the XSCF Web, when you import XCP or update the firmware, Session ID

error may be displayed on the web browser. And in the Autologout setting, when
you specify the timeout period as over 30 minutes, Internal Server Error might be
displayed when you perform the firmware update. Please close the current
browser and open the new browser to reconnect to XSCF Web.

■ When you use the XSCF Web, if a plug-in such as the search tool installed with

the browser, remove the plug-in or disable the pop-up blocking.

■ XSCF-LAN is compliant with auto-negotiation. When you connect XSCF-LAN

and the network device which has been fixed to the full-duplex mode, according
to the IEEE 802.3 rule, XSCF-LAN communicates in the half-duplex mode. Due to
this, network communication speed may slow down or communication error may
occur. Do not fail to set the network device which connects with XSCF-LAN to the
auto-negotiation mode.

■ While you are performing DR operation to a COD board, do not execute the

addcodlicense(8)/deletecodlicense(8)/setcod(8) command.

■ The restoredefaults(8) command is not supported in this release.

■ If your domain is running one of the following versions of Solaris OS:

■ Solaris 10 5/08 OS

■ An earlier version of Solaris 10 OS with patch ID 127127-11

Then you must set the following parameter in the system specification file
(/etc/system):

set heaplp_use_stlb=0

Then reboot the domain.
For more information, refer to CR 6718173 in

TAB LE 4.

6 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

Information about Hardware

This section describes the special instructions and the issues about the SPARC
Enterprise M8000/M9000 servers hardware.

■ Hardware Issues and Workarounds

Hardware Issues and Workarounds

TABLE 2 lists known hardware issues and possible workarounds.

TABLE 2 Hardware Issues and Workarounds

CR ID Description Workaround

6433420 The domain console might display a Mailbox

timeout or IOCB interrupt timeout error during
boot.

6557379 Power cables are not redundant on single

power feed servers without the dual power
feed option.

Issue a reset -all command from the
OpenBoot PROM (OK) prompt and reboot.

On servers that have single power feed, all
power cables must be connected and powered
on at all times.

Sun Crypto Accelerator 6000 Cards

If you are not using the correct version of the Sun Crypto Accelerator (SCA) 6000
card driver, hot-plug operations on SCA 6000 cards can cause Sun SPARC Enterprise
M4000/M5000 servers to panic or hang. Version 1.1 of the SCA6000 driver and
firmware supports hot-plug operations after the required bootstrap firmware
upgrade has been performed. Version 1.0 of the SCA6000 driver does not support
hot-plug and should not be used.

Information about Hardware 7

Information about Software

This section describes the special instructions and the issues about the SPARC
Enterprise M8000/M9000 servers software.

■ XCP Issues and Workarounds

■ Solaris OS Issues and Workarounds

■ Software Documentation Updates

■ Identifying Degraded Memory in a System

■ Identifying Different Memory Sizes in a System Board

■ Identifying Permanent Memory in a Target Board

■ CPU Upgrade

XCP Issues and Workarounds

TABLE 3 lists known XCP issues and possible workarounds.

TABLE 3 XCP Issues and Workarounds

ID Description Workaround

RTIF1­070418-009

RTIF1­070528-002

8 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

While XSCF is running, a process may go
down, a watchdog timeout may occur, or a
hang-up may occur. After this, XSCF may
reset.

While XSCF is running, watchdog timeout
may occur and XSCF may reboot.

Check that XSCF is started. to be translated. If
not started, stop all the domains and then
execute the system power off/on (AC
OFF/ON). To turn on the system power that
you turned off, wait at least 30 seconds before
power-on.

Check that XSCF is started. If not started, stop
all the domains and then execute the system
power off/on (AC OFF/ON). To turn on the
system power that you turned off, wait at least
30 seconds before power-on.

TABLE 3 XCP Issues and Workarounds (Continued)

ID Description Workaround

RTIF1­070823-001

Using the XSCF Web, when you selected SSH
on the snapshot screen, the maximum number
of character input for Host, Directory, ID, and

To specify the value which exceeds the
maximum number of character input for the

XSCF Web, use XSCF Shell.
Password doesn't correspond to the maximum
number of character input on the XSCF Shell.

RTIF1­070824-002

RTIF1­070824-005

On the XSCF Web, when you select Domain
Mode Configuration to perform various
settings, the pop-up screen may not appear but
"Undefined" may be displayed on the screen.

On the XSCF Web, when you changed the
Refresh Interval value of the Monitor Message

Select Domain Mode Configuration one more

time and perform the settings. Or once

terminate the XSCF Web and then perform the

settings.

Ignore the pop-up and close the screen.

Frame, the invalid pop-up "Confirmation
Domain mode" may appear.

RTIF1­070824-006

On the tab browser, to the same host, when
you perform multiple log-in with the user

When you use the tab browser, do not perform

multiple log-in to the same host.
accounts of different user privileges, the user
privilege of the last log-in user account will be
applied to those pages which you've already
logged in.

RTIF1­070824-011

While using FireFox2, in the Configuration
policy setting on the Domain Configuration

From the Menu, select the Domain

Configuration page again.
screen, when you specify a domain which is in
operation, an error display pop-up appears.
When you click on the Back button on this
error display pop-up and click on the Cancel
button on the inquiry screen to re-display the
data, the system remains in the error message
screen.

RTIF1­070904-001

CLIs should display "Permission denied" when
it is executed in Standby XSCF.

Only the following CLIs can be executed on

the Standby XSCF: snapshot(8),

switchscf(8).

Do not attempt to run any other CLI on the

Standby. Such attempts will report various

errors.

RTIF1­070904-004

The latest communication field in
showarchiving(8) command is not updated
regularly.

Disabling and re-enabling archiving refreshes

the Latest communication field in

showarchiving(8) output.

RTIF1­070914-003

When the XSCF switching performed, there
may be "SCF: Board control error (DMA
timeout)" stored in the error log.

There is no workaround.

This message can be safely ignored.

Information about Software 9

TABLE 3 XCP Issues and Workarounds (Continued)

ID Description Workaround

RTIF1­070914-025

RTIF1­071102-002

RTIF1­071116-001

When you execute XCP Sync on the Firmware
Update page, after 15 minutes, the error
message "Another flashupdate is now
processing" or "The page cannot be displayed"
may appear.

The snmp daemon might quit. To restart the snmp daemon, issue the

After using the addfru(8) or replceafru(8)
command for active replacement without the
diagnostic test in the maintenance menu,
further DR operation might fail with a
misleading message regarding the board being
unavailable for DR.

There is no workaround. However, the XCP
Sync process has been continuously executed.
Check the XSCF update completion message
on the monitoring message to confirm the
completion of Sync process.

command setsnmp enable.

Do not fail to execute the diagnosis in the
maintenance menu of the addfru(8) or
replacefru(8) command. In case of missing
the diagnostic test in the maintenance menu of
the addfru(8) or the replacefru(8)
command, execute the testsb(8) command or
delete the CPU/memory board unit using the

deletefru(8) command and then retry the
addfru(8) command.

RTIF1­071116-005

While system power on, when the XSCF
switching performed by switchscf(8)

There is no workaround. This message can be

safely ignored.
command, PANIC might be generated in XSCF
before it switches, and "SHUTDOWN timeout"
may be stored in the error log.

RTIF1­071126-002

When the server is being installed, and the
mainline switch is turned on for the first time,
these error messages might be displayed:

PSU shortage

XSCF watchdog timeout
XSCFU hang-up is detected

Turn off the system AC power, then turn it on

again.

When the error log is displayed again, turn off

the system AC power, then turn it on again. To

turn on the system power that you turned off,

wait at least 30 seconds before power-on.

XSCF process down detected

RTIF1­071129-003

An error log cannot be registered in XSCF
when the following message is displayed on

There is no workaround.

Solaris OS by the External I/O Expansion Unit
error:

SUNW-MSG-ID: SUN4-8000-4P, TYPE:

Fault

RTIF1­080404-002

When you use the command setsnmpusm
passwd to set a password, if you set a

Always set a password of at least eight

characters.
password of fewer than eight characters, a
segmentation fault occurs.

10 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

TABLE 3 XCP Issues and Workarounds (Continued)

ID Description Workaround

RTIF1­080512-001

When you specify "localhost" to the
hostname of the sethostname(8) command

Do not specify "localhost" to the hostname of

the sethostname(8) command.
and reset XSCF by using the
applynetwork(8) and the rebootxscf(8)
commands, a process goes down in XSCF.

RTIF1­080526-001

When the system is stressed with many faults,
the fmd process on the service processor might

Reboot the service processor using the XSCF

command rebootxscf(8).
hang. Once this happens, fma commands on
the service processor can fail or hang.

RTIF1­080725-001

RTIF1­080725-002

RTIF1­080725-003

RTIF1­080725-004

RTIF1­080808-001

In setsnmp addv3traphost, when the
authentication failed due to the reasons such
as the trap host not working, or the wrong
user name or password, the subsequent SNMP
traps will not be notified.

When the SNMPv3 trap has been set, after the
watchdog timeout occurred in XSCF and XSCF
reset, the subsequent SNMP traps will not be
notified.

The initial value that set with the
setdomparam set-defaults option differs
from the initial value of OpenBoot PROM.

parameters current value expected value

diag-level none(0x00) min(0x20)
auto-boot? false(0x00) true(0xff)

After set the Daylight Saving Time by using
the XSCF shell, XSCF Web does not show the
correct time in the Logs menu.

On the cluster system using the
PRIMECLUSTER software, when there are 10
or more RCI units, the RCI busy status may be
temporarily unreleased and output the
following syslog message:

SA_pprcir.so to test host host_name
failed

There is no workaround.

Confirm that the SNMP trap host is working

and re-execute the setsnmp(8) command

using the correct user name.

There is no workaround.

In the OpenBoot PROM prompt (ok>), execute

the set-defaults command to restore the

OpenBootPROM environmental variables to

the initial value.

There is no workaround.

Use the showlogs(8) command of the XSCF

shell.

Refer to the manual of the PRIMECLUSTER

software to check the cluster status. If no

problem found on the status, this message can

be safely ignored. If any problem, follow the

instructions on the manual to solve the

problem.

Information about Software 11

Solaris OS Issues and Workarounds

TABLE 4 lists known Solaris OS issues and possible workarounds

TABLE 4 Solaris OS Issues and Workarounds

CR ID Description Workaround

5076574 A PCIe error can lead to an invalid fault

diagnosis on a large M8000/M9000 domain.

6303418 A SPARC Enterprise M9000 server with a

single domain and 11 or more fully populated
system boards might hang under heavy stress.

6416224 System performance can degrade using a

single NIC card with more than 5,000
connections.

This bug has been fixed in Solaris 10 5/08.
For Solaris 10 8/07 or earlier, this has been

fixed in patch 127127-11.
[Workaround]
Create a file /etc/fm/fmd/fmd.conf

containing the following lines;

setprop client. buflim 40m
setprop client. memlim 40m

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 120011-01.

[Workaround]
Do not exceed 170 CPU threads.
Limit the number of CPU threads to one per

CPU core by using the Solaris psradm
command to disable the excess CPU threads.
For example, disable all odd-numbered CPU
threads.

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 120011-08.

[Workaround]
Use multiple NIC cards to split network

connections.

6441349 The system may hang if there is an I/O error

in the system.

12 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 120011-07.

There is no workaround.

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6449315 The Solaris OS cfgadm(1M) command does

not unconfigure a DVD drive from a domain
on a SPARC Enterprise M8000/M9000 server.

Disable the Volume Management Daemon
(vold) before unconfiguring a DVD drive with
the cfgadm(1M) command.

To disabl e vold, stop the daemon by issuing
the command /etc/init.d/volmgt stop.
After the device has been removed or inserted,
restart the daemon by issuing the command
/etc/init.d/volmgt start.

6459540 The DAT72 internal tape drive on SPARC

Enterprise M8000/M9000 may time out during

Add the following definition to
/kernel/drv/st.conf:

tape operations.

tape-config-list=
"SEAGATE DAT DAT72-000",
"SEAGATE_DAT____DAT72-000",
"SEAGATE_DAT____DAT72-000";
SEAGATE_DAT____DAT72-000=

1,0x34,0,0x9639,4,0x00,0x8c,0x8c,
0x8c,3;

There are four spaces between SEAGATE DAT
and DAT72-000.

6466617 Performing a hot plug operation with the PCI-

Express slot too quickly interrupts a PCI leaf

Pause a few seconds between the issue of each
cfgadm -c command.

reset and occurs the following error:

cfgadm: Component system is busy
error

6472153 If you create a Solaris OS Flash archive on a

non-SPARC Enterprise M4000/M5000 sun4u
server and install it on a SPARC Enterprise

This bug has been fixed in Solaris 10 5/08.
For Solaris 10 8/07 or earlier, this has been

fixed in patch 137046-01.

M4000/M5000 sun4u server, the console's TTY
flags will not be set correctly. This can cause
the console to lose characters during stress.

[Workaround]
Just after installing Solaris OS from a Solaris

Flash archive, telnet into the SPARC Enterprise
M4000/M5000 server to reset the console's
TTY flags a follows:

# sttydefs -r console
# sttydefs -a console -i "9600 hupcl

opost onlcr crtscts" -f "9600"

This procedure is required only once.

Information about Software 13

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6481002 Installing the Solaris OS from the network

using certain PCI-Express cards may cause a
panic.

If you are using a Sun PCI-E Dual Gigabit
Ethernet Adapter MMF card or a Sun PCI-E
Dual Gigabit Ethernet Adapter UTP card, do
not install the Solaris using either of these
cards. Instead, use other network devices, such
as the onboard Gigabit Ethernet or another
network device.

6485555 On-board Gigabit Ethernet NVRAM

corruption could occur due to a race condition.
The window of opportunity for this race

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 120011-08.

condition is very small.

There is no workaround.

6496337 The "cpumem-diagnosis" module may fail to

load after uncorrectable error(UE) panic.
Systems will function correctly but events

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 125369-05.
normally automatically diagnosed by FMA
using this module will require manual
diagnosis.

Example:

SUNW-MSG-ID: FMD-8000-2K, TYPE:
Defect, VER: 1, SEVERITY: Minor

EVENT-TIME: Thu Feb 15 15:46:57 JST
2007

PLATFORM: SUNW,SPARC-Enterprise,
CSN: BE80601007, HOSTNAME: col2-ff-

[Workaround]

If problem occurred, implement the following

workaround:

1. Remove the following file.

# rm /var/fm/fmd/ckpt/cpumem­diagnosis/cpumem-diagnosis

2. Restart fmd service.

# svcadm restart fmd

em7-d0

To avoid this problem in advance,

add "rm -f /var/fm/fmd/ckpt/cpumem-

diagnosis/cpumem-diagnosis" in

/lib/svc/method/svc-dumpadm file as

below.

#
# We haven't run savecore on a

dump device yet
#
savedev=none

rm -f /var/fm/fmd/ckpt/cpumem­diagnosis/cpumem-diagnosis

#

14 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6498283 Using the DR deleteboard(8) command

while psradm operations are running on a
domain might cause a system panic.

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 120011-07.

There is no workaround.

6499304 CPU isn't offlined and unexpected message is

displayed on console when many correctable
error(CE) occurs.

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 125369-05.

Example:

SUNW-MSG-ID: FMD-8000-11, TYPE:
Defect, VER: 1, SEVERITY: Minor
EVENT-TIME: Fri Feb 2 18:31:07 JST

[Workaround]
Check CPU status on XSCF.

2007
PLATFORM: SPARC-Enterprise, CSN:

BE80601035, HOSTNAME: FF2-35-0

6502204 Unexpected error messages may be displayed

on console on booting after CPU UE panic.
Example:

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 125369-05.

SUNW-MSG-ID: FMD-8000-11, TYPE:
Defect, VER: 1, SEVERITY: Minor
EVENT-TIME: Tue Jan 9 20:45:08 JST
2007

PLATFORM: SUNW,SPARC-Enterprise,

[Workaround]
If you see unexpected messages, use the XSCF

command showdomainstatus(8) to check
system status on XSCF.

CSN: 2030636002, HOSTNAME: P2-DC1­16-d0

6502750 Notification message for inserted or removed

card by PCI hot plug may not output.

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 120011-08.

6505921 Correctable error on the system PCIe bus

controller generates an invalid fault.

There is no workaround.

This bug has been fixed in Solaris 10 5/08.
For Solaris 10 8/07 or earlier, this has been

fixed in 120011-14 and 125369-05.

[Workaround]
Create a file /etc/fm/fmd/fmd.conf
containing the following lines;

setprop client.buflim 40m
setprop client.memlim 40m

Information about Software 15

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6508432 Many correctable errors (CE) may occur, and

despite these are the correctable errors,
domain may panic.

This bug has been fixed in Solaris 10 8/07.

For Solaris 10 11/06, this has been fixed in

patch 120011-08.

[Workaround]

Set the following to /etc/system and then

reboot the domain:

set pcie:pcie_aer_ce_mask = 0x2001

6508434 The domain may panic when an additional

PCI-X card is installed or a PCI-X card is
replaced by using PCI hot plug.

This bug has been fixed in Solaris 10 8/07.

For Solaris 10 11/06, this has been fixed in

patch 120011-08.

[Workaround]

Do not insert a different type of PCI-X card on

the same PCI slot by using PCI hot plug.

6509337 s10s_u3 wanboot fails - The server returned

This bug has been fixed in Solaris 10 8/07.
416: Requested Range Not Satisfiable.

6510861 When Dual-Channel Ultra320 SCSI Card

(SE0X7SC2F, SE0X7SC2X) is mounted,
correctable errors(CE) occur and system may
panic.

6511374 Unexpected error messages may be displayed

on console after changing the system
configuration.

Example:

WARNING: Translation error source
/LSB0/B0/0, PA 3c000000000, target
/LSB0/B0/20000000

This bug has been fixed in Solaris 10 8/07.

For Solaris 10 11/06, this has been fixed in

patch 120011-08.

[Workaround]

Add the following entry to the /etc/system

file and then reboot the system:

set pcie:pcie_aer_ce_mask = 0x31c1

This message can be safely ignored.

16 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6515648 "Replumb Failed" error appears when

dr@0:SB1::memory fails.

Once the DR operation is complete, it can be
plumbed up manually.

Example steps to re-plumb the interface
manually:

# ifconfig interface plumb xxx.xxx.xxx.xxx
netmask + broadcast + up

# ifconfig interface group group-name
# ifconfig interface addif xxx.xxx.xxx.xxx

-failover deprecated up

This workaround assumes that the
/etc/hostname.interface file is correctly
configured for the IPMP group and does not
need any modification. The IP addresses used
in the example above should match what was
previously used and what matches the
/etc/hostname.<interface> file.

6516135 Ap_Id format and devices may not be shown

correctly by cfgadm(1M).

Use the following operations to display all of
the PCI slots.

1) devfsadm (at Solaris prompt)

2) cfgadm

6519290 Large amounts of I/O on swap devices can

cause the system to appear hung by
overwhelming the I/O system. The amount of

Set the following to /etc/system and then
reboot the domain:

set maxfastscan=0x2000

I/O required can be generated through a
number of ways, eg memory shortage, heavy
use of /tmp etc.

6520990 Domain may cause a panic when

deleteboard(8) command for kernel board
by using Dynamic Reconfiguration (DR).

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 120011-08.

6522017 DR and ZFS may not be used in the same

domain.

[Workaround]
To mask this error, add the following entry to

the /etc/system file.

set drmach:fmem_timeout = 30

Reduce the amount of kernel memory that ZFS
can allocate by setting the zfs_arc_max
parameter in the /etc/system file. The
following example sets the maximum size to
512 Mbytes.

set zfs_arc_max = 0x20000000

Information about Software 17

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6522433 After the CPU hardware error occurred, the

fmdump(1M) command on the domain may
display an incorrect faulty component.

This bug has been fixed in Solaris 10 5/08. For

Solaris 10 8/07 or earlier, this has been fixed in

patch 127127-11.

[Workaround]

Check system status on XSCF.

6527781 The cfgadm command fails while moving the

DVD/DAT drive between two domains.

This bug has been fixed in Solaris 10 8/07.

For Solaris 10 11/06, this has been fixed in

patch 125081-06.

There is no workaround. To reconfigure

DVD/Tape drive, execute reboot -r from

the domain exhibiting the problem.

6527811 The showhardconf(8) command on the XSCF

cannot display PCI card information that is
installed in External I/O Expansion Unit, if the

This bug has been fixed in Solaris 10 5/08.

For Solaris 10 8/07 or earlier, this has been

fixed in patch 128346-01.
External I/O Expansion Unit is configured

using PCI hotplug.

6529714 Warning messages occur while trying to

There is no workaround.

There is no workaround.
configure more than four X4447A-Z or
X1027A-Z1 cards into one I/O Boat.

6530178 DR addboard(8) command can hang. Once

problem is observed, further DR operations are
blocked. Recovery requires reboot of the

This bug has been fixed in Solaris 10 8/07.

For Solaris 10 11/06, this has been fixed in

patch 120011-07.
domain.

There is no workaround.

6530288 Ap_Id format may not be shown correctly by

cfgadm(1M) command.

This bug has been fixed in Solaris 10 8/07.

For Solaris 10 11/06, this has been fixed in

patch 120011-07.

There is no workaround.

6530753 Some of the PCI slots in the External I/O

Expansion Unit PCI slots are not displayed
during a normal boot operation.

Use one of the following operations to display

all of the PCI slots.

• boot -r (at open boot prompt)

• devfsadm -C (at Solaris prompt)

• cfgadm (twice at Solaris prompt)

6531036 The error message network

initialization failed appears

There is no workaround. This message can be

safely ignored.
repeatedly after a boot net installation.

18 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6531668 System hangs when executing parallel hot

There is no workaround.

plug operation with SP DR in suspend phase.

6532215 volfs or dscp service may fail when domain is

booted.

Restart the service if the failure is observed. To
avoid the problem, issue the following
commands.

svc:/platform/sun4u/dscp:default:
Method "/lib/svc/method/svc-dscp
start" failed with exit status 95.

# svccfg -s dscp setprop
start/timeout_seconds=count: 300

# svccfg -s volfs setprop

svc:/system/filesystem/volfs:defaul
t: Method or service exit timed
out. Killing contract 59.

6533686 DR deleteboard(8) and moveboard(8)

start/timeout_seconds=count: 300
# svcadm refresh dscp
# svcadm refresh volfs

This has been fixed in patch 138397-01.
operations might fail if the target board
includes permanent memory.

Example for messages on domain:

drmach: WARNING: DR parellel copy
timeout

dcs: <xxxx> config_change_state:
Hardware specific failure:
unconfigure SB1: DR parellel copy
timeout

[Workaround]

Try DR operations again.

To avoid this issue, before performing DR

operations using deleteboard(8) and

moveboard(8) commands on a board that

includes permanent memory, follow these

steps:

1. Add the following line to the System
Configuration file (/etc/system):

set drmach:drmach_disable_mcopy = 1

2. Reboot the domain.

6534471 Domains might panic. This bug has been fixed in Solaris 10 8/07.

6535018 In Solaris domains that include SPARC64 VII

This has been fixed in patch 137111-01.
processors, workloads that make heavy use of
the Solaris kernel might not scale as expected
when you increase the thread count to a value
greater than 256.

[Workaround]

For Solaris domains that include SPARC64 VII

processors, limit domains to a maximum of

256 threads.

6535564 PCI hot plug to PCI slot #0, #1 or External I/O

Expansion Unit may fail on XSB added by DR.

This bug has been fixed in Solaris 10 8/07.

For Solaris 10 11/06, this has been fixed in

patch 120011-08.

[Workaround]

Use DR instead of PCI hot plug if need to add

or remove PCI card on the XSB.

Information about Software 19

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6536564 showlogs(8) and showstatus(8) command

on XSCF might report wrong I/O component
due to wrong diagnosis by Solaris Fault

This bug has been fixed in Solaris 10 5/08.
For Solaris 10 8/07 or earlier, this has been

fixed in patch 125369-05.

management Architecture when faults in I/O
devices occur.

[Workaround]
To avoid this problem, issue the following

commands on the domain.

# cd /usr/platform/SUNW,SPARC­Enterprise/lib/fm/topo/plugins

# mv ioboard.so ioboard.so.orig
# svcadm restart fmd

If the following messages are displayed on the
domain, contact a service engineer.

Example:

SUNW-MSG-ID: SUNOS-8000-1L, TYPE:
Defect, VER: 1, SEVERITY: Minor

EVENT-TIME: Sun May 6 18:22:24 PDT
2007

PLATFORM: SUNW,SPARC-Enterprise,
CSN: BE80601007, HOSTNAME: sparc

6537511 Bluetooth partner is hung during security tests

Restart application server.

execution.

6539084 Under Solaris 10 11/06, there is a low

This bug has been fixed in Solaris 10 8/07.
probability of a domain panic during reboot
when the Sun Quad GbE UTP x8 PCIe
(X4447A-Z) card is present in a domain.

6539909 Under Solaris 10 11/06, do not use the

following I/O cards for network access when
you are using the boot net install

There is no workaround.

Use an alternate type of network card or

onboard network device to install the Solaris

OS via the network.
command to install the Solaris

OS:

• X4447A-Z/X4447A-Z, PCIe Quad-port

Gigabit Ethernet Adapter UTP

• X1027A-Z/X1027A-Z, PCIe Dual 10 Gigabit

Ethernet Fiber XFP

20 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6542632 Memory leak in PCIe module if driver attach

fails.

This bug has been fixed in Solaris 10 8/07.
For Solaris 10 11/06, this has been fixed in

patch 120011-09.

There is no workaround.

6545143 When kcage thread is expanding the kcage

area, if the user stack exists in the expanded
area, its area is demapped and might cause a

This bug has been fixed in Solaris 10 5/08. For
Solaris 10 8/07 or earlier, this has been fixed in

patch 127111-08.
ptl_1 panic during the flushw handler
execution.

6545685 If the following message displayed on the OS

console, memory degradation or XSB
deconfiguration may occur in the subsequent

There is no workaround.

This bug has been fixed in Solaris 10 5/08.

For Solaris 10 8/07 or earlier, this has been

fixed in patch 127111-08.
reboot.

[Workaround]
Example:

mc-opl: WARNING: mc-opl rewrite
timeout on /LSB0/B0

Add the following to /etc/system and then

reboot the domain:

set mc-opl: mc_max_rewrite_loop =

20000

6546188 The system panics when running hotplug

(cfgadm(1M)) and DR operations
(addboard(8) and deleteboard(8)) on the

This bug has been fixed in Solaris 10 5/08.

For Solaris 10 8/07, this has been fixed in

patch 127741-01.
following cards:

• X4447A-Z, PCI-e Quad-port Gigabit

Ethernet Adapter UTP

• X1027A-Z1, PCI-e Dual 10 Gigabit Ethernet

There is no workaround.

Fiber XFP Low profile Adapter

6551356 The system panics when running hotplug

(cfgadm(1M)) to configure a previously
unconfigured card. The message "WARNING:

This bug has been fixed in Solaris 10 5/08.

For Solaris 10 8/07, this has been fixed in

patch 127741-01.
PCI Expansion ROM is not accessible" will be

seen on the console shortly before the system
panic. The following cards are affected by this
defect:

• X4447A-Z, PCI-e Quad-port Gigabit

Ethernet Adapter UTP

• X1027A-Z1, PCI-e Dual 10 Gigabit Ethernet

Fiber XFP Low profile Adapter

[Workaround]

Perform cfgadm -c disconnect to

completely remove the card. After waiting at

least 10 seconds, the card may be configured

back into the domain using the cfgadm -c

configure command.

Information about Software 21

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6559504 Messages of the form nxge: NOTICE:

nxge_ipp_eccue_valid_check: rd_ptr = nnn
wr_ptr = nnn will be observed on the console

This bug has been fixed in Solaris 10 5/08.
For Solaris 10 8/07, this has been fixed in

patch 127741-01.

with the following cards:

• X4447A-Z, PCI-e Quad-port Gigabit
Ethernet Adapter UTP

• X1027A-Z1, PCI-e Dual 10 Gigabit Ethernet

[Workaround]
These messages can be safely ignored.

Fiber XFP Low profile Adapter

6564934 Performing a DR deleteboard(8) operation

on a board which includes Permanent Memory
when using the following network cards

This bug has been fixed in Solaris 10 5/08.
For Solaris 10 8/07, this has been fixed in

patch 127741-01.

results in broken connections:

• X4447A-Z, PCI-e Quad-port Gigabit
Ethernet Adapter UTP

• X1027A-Z1, PCI-e Dual 10 Gigabit Ethernet
Fiber XFP Low profile Adapter

[Workaround]
Re-configure the affected network interfaces

after the completion of the DR operation. For
basic network configuration procedures, refer
to the ifconfig man page for more
information.

6568417 After a successful CPU DR deleteboard(8)

operation, the system panics when the
following network interfaces are in use:

This bug has been fixed in Solaris 10 5/08. For
Solaris 10 8/07 or earlier, this has been fixed in
patch 127111-02.

• X4447A-Z, PCI-e Quad-port Gigabit
Ethernet Adapter UTP

• X1027A-Z1, PCI-e Dual 10 Gigabit Ethernet
Fiber XFP Low profile Adapter

[Workaround]
Add the following line to /etc/system and

reboot the system:

set ip:ip_soft_rings_cnt=0

6571370 Use of the following cards have been observed

to cause data corruption in stress test under
laboratory conditions:

This bug has been fixed in Solaris 10 5/08. For
Solaris 10 8/07, this has been fixed in patch
127741-01.

• X4447A-Z, PCI-e Quad-port Gigabit
Ethernet Adapter UTP

• X1027A-Z1, PCI-e Dual 10 Gigabit Ethernet
Fiber XFP Low profile Adapter

[Workaround]
Add the following line in /etc/system and

reboot the system: set

nxge:nxge_rx_threshold_hi=0

6572827 On SPARC Enterprise M8000/M9000 servers,

There is no workaround.
one of the columns in the IO Devices section of
the output from prtdiag -v is "Type". This
reports "PCIe", "PCIx", "PCI" or "UNKN" for
each device.

The algorithm used to compute this value is
incorrect. It reports "PCI" for PCI-X leaf
devices and "UNKN" for legacy PCI devices.

22 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6584984 On SPARC Enterprise M8000/M9000 servers,

busstat(1M) command may cause rebooting
of domains.

This bug has been fixed in Solaris 10 5/08. For
Solaris 10 8/07 or earlier, this has been fixed in
patch 127127-11.

There is no workaround. Do not use
busstat(1M) command.

Check for the availability of a patch for this
defect.

6588555 XSCF failover during DR operation to the

permanent memory might cause domain
panic.

Do not start an XSCF failover while a DR
operation is running. Wait for a DR operation
to finish before starting the failover. If you
start the failover first, wait for the failover to
finish before starting the DR operation.

6588650 On occasion, the system is unable to DR after

There is no workaround.

an XSCF failover or XSCF reboot.

6589546 prtdiag(8) command does not show all I/O

devices of the following cards:

• XSEFC402AF Sun StorageTek Enterprise
Class 4Gb Dual-Port Fibre Channel PCI-E
HBA

• XSEFC401AF Sun StorageTek Enterprise
Class 4Gb Single-Port Fibre Channel PCI-E
HBA

6589644 After added the system board by DR, when the

switching occurred on the redundant XSCF
Units, the domain console may hang up.

6592302 Unsuccessful DR operation leaves memory

partially configured.

This bug has been fixed in Solaris 10 5/08.　
For Solaris 10 8/07 or earlier, this has been
fixed in patch 127127-11.

[Workaround]
Use prtdiag -v for full output.

The console can be recovered by pressing
Ctrl-q (the "Ctrl" key and the "q" key).

Tr y deleteboard(8) again.

Information about Software 23

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6614737 The DR deleteboard(8) and moveboard(8)

This has been fixed in patch 137111-01.

operations might hang if any of the following
conditions exist:

• A DIMM has been degraded.

• The domain contains system boards with

[Workaround]
Avoid performing DR operations if any of the

listed conditions exist.

different memory size.

To determine whether the system contains
degraded memory, use the XSCF
showstatus(8) command. For sample output,
see “Identifying Degraded Memory in a

System” on page 29.

To determine whether the domain contains
system boards with different memory sizes,
display the list of memory sizes using the
XSCF showdevices(8) command or the
prtdiag(8) command on the domain. For
sammple of output, see “Identifying Different

Memory Sizes in a System Board” on page 29

If a DR command hangs, reboot the domain to
recover.

6619224 For Solaris domains that include SPARC 64 VII

This has been fixed in patch 137111-03.
processors, a single domain of 256 threads (128
cores) or more might hang for an extended
period of time under certain unusual
situations. Upon recovery, the uptime
command will show extremely high load
averages.

[Workaround]

For Solaris domains that include SPARC 64 VII

processors, do not exceed a domain size of 256

virtual CPUs in a single Solaris domain. This

means a maximum of 32 CPU chips in a single

domain configuration (maximum

configuration for an M8000 server).

6623226 The Solaris command lockstat(1M) or the

dtrace lockstat provider might cause a system

Do not use the Solaris lockstat(1M)

command or the dtrace lockstat provider.
panic.

6625734 Systems with large number of processors in a

single domain environment may have
suboptimal performance with certain
workloads.

Use processor sets to bind application

processes or LWPs to groups of processors.

Refer to the psrset(1M) man page for more

information.

24 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6632549 fmd service on domain might fail to

This has been fixed in patch 138050-01.

maintenance mode after DR operations.

[Workaround]
If fmd service fails, issue the following

commands on the domain to recover:

# svcadm clear fmd

6660168 If a ubc.piowbeue-cpu error occurs on a

domain, the Solaris Fault Management
cpumem-diagnosis module might fail, causing

If FMA service fails, issue the following
command on the domain to recover:

# svcadm clear fmd

an interruption in FMA service.
If this happens, you will see the following

output in the console log:

SUNW-MSG-ID: FMD-8000-2K, TYPE:

Then restart cpumem-diagnosis:

# fmadm restart cpumem-diagnosis

Defect, VER: 1, SEVERITY: Minor
EVENT-TIME: Fri Apr 4 21:41:57 PDT

2008
PLATFORM: SUNW,SPARC-Enterprise,

CSN: 2020642002, HOSTNAME:
<hostname>

SOURCE: fmd-self-diagnosis, REV:

1.0
EVENT-ID: 6b2e15d7-aa65-6bcc-bcb1-

cb03a7dd77e3
DESC: A Solaris Fault Manager

component has experienced an error
that required the module to be
disabled. Refer to
http://sun.com/msg/FMD-8000-2K for
more information.

AUTO-RESPONSE: The module has been
disabled. Events destined for the
module will be saved for manual
diagnosis.

IMPACT: Automated diagnosis and
response for subsequent events
associated with this module will
not occur.

REC-ACTION: Use fmdump -v -u
<EVENT-ID> to locate the module.
Use fmadm reset <module> to reset
the module.

Information about Software 25

TABLE 4 Solaris OS Issues and Workarounds (Continued)

CR ID Description Workaround

6660197 DR might cause the domain to hang if either of

This has been fixed in patch 138397-01.
the following conditions exist:

• A domain contains 256 or more CPUs.

• Memory error occurred and the DIMM has

been degraded.

[Workaround]

1. Set the following parameterin the system
specification file (/etc/system):

set drmach:drmach_disable_mcopy = 1

2. Reboot the domain.

6679370 The following message may be output on the

console during the system booting, the

Add the following to /etc/system and then

reboot the domain.
External I/O Expansion Unit adding by
hotplug, or the FMEMA operating by DR.

set pcie_expected_ce_mask = 0x2001

SUNW-MSG-ID: SUN4-8000-75, TYPE:
Fault, VER: 1, SEVERITY: Critical

...
DESC:
A problem was detected in the PCI-

Express subsystem.
Refer to http://sun.com/msg/SUN4-

8000-75 for more information.
...

6565553
6674266

DR deleteboard(8) and moveboard(8)
operations might fail.

There is no workaround.

Try DR operations again.
Example for messages on domain:

drmach: WARNING: Device driver
failure: /pci

dcs: <xxxx> config_change_state:
Hardware specific failure:
unconfigure SB1: Device driver
failure: /pci

6718173 If your domain is running one of the following

versions of Solaris OS, the system might
panic/trap during normal operation:

• Solaris 10 5/08 OS

Set the following parameter in the system

specification file (/etc/system):

set heaplp_use_stlb=0

Then reboot the domain.

• An earlier version of Solaris 10 OS with

patch ID 127127-11

26 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

Software Documentation Updates

This section contains late-breaking software information that became known after
the documentation set was published and corrections in the SPARC Enterprise
M8000/M9000 servers software documentation.

The corrections for SPARC Enterprise M4000/M5000/M8000/M9000 servers XSCF
Reference Manual, if not otherwise specified, also apply to the man pages which
XSCF provides. And they supersede the information on the man pages.

TABLE 5 lists known documentation updates.

TABLE 5 Software Documentation Updates

Title Page Number Update

All SPARC Enterprise
M8000/M9000 servers
documentation

SPARC Enterprise
M4000/M5000/M8000/
M9000 Servers XSCF
User’s Guide

SPARC Enterprise
M4000/M5000/M8000/
M9000 Servers XSCF
Reference Manual

Page 2-30 The maximum length of the user name is 31 characters.

Page 2-91 Table 2-22 DCL Information, Configuration policy's "System :

Page 8-18 First paragraph in 8.1.11 is now refered as below:

adduser(8)
command

console(8)
command

When there is the section "SPARC Enterprise M8000/M9000
Servers Documentation" in the Preface, the following document
will be added.

SPARC Enterprise/PRIMEQUEST Common Installation Planning
Manual (C120-H007)

Table 2-4 User Accounts Adminstration erroneously documents
a maximum user name length of 32 characters.

Removal of a domain (domain deactivated)" is now refered to as
below:

"Hardware is degraded in units of domains or the relevant
domain is stopped without degradation.

If the system hangs or any of the messages shown below is
output during the firmware update, retry the firmware update.
It might be completed successfully.

The maximum length of the user name is 31 characters. The
OPERANDS of the adduser(8) command erroneously
documents a maximum user name length of 32 characters.

The note in DESCRIPTION is changed as follows:
When you return to XSCF shell console without logging out

from the domain, the return causes automatically logging out
from the domain.

Information about Software 27

TABLE 5 Software Documentation Updates (Continued)

Title Page Number Update

SPARC Enterprise
M4000/M5000/M8000/
M9000 Servers XSCF
Reference Manual

sendbreak(8)
command

setdscp(8)
commands

viewaudit(8)
command

setdcl(8)
command

The sendbreak(8) command will not work when the secure
mode is set to on while the mode switch on the operator panel
is set to locked. Refer to the setdomainmode(8) for more
information.

The references to site planning guide of the caution in
EXAMPLES are now referenced to as administration guide.

The viewaudit(8) man pages show incorrect output for
Example 5 and Example 6.

The action when option is set to policy and when value is set to
system will be changed as below:

Deactivates the target system for an error detected by a
diagnosis.

SPARC Enterprise
M4000/M5000/M8000/

setaudit(8)
command

By using the -t option, at most four values may be set, instead

of two.
M9000 Servers XSCF
Reference Manual and
XSCF manpages

28 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

Identifying Degraded Memory in a System

1. Log in to XSCF.

2. Type the following command:

XSCF> showstatus

The following example identifies DIMM number 00A on CMU#3 has degraded
memory..

XSCF> showstatus
CMU#3 Status:Normal;
* MEM#00A Status:Degraded;

Identifying Different Memory Sizes in a System Board

To identify if the domain contains system boards with different memory sizes, you
can use either of the following commands to display the list of memory sizes:

■ showdevices(8) command on the XSCF

■ prtdiag(1M) command on the domain

Using the showdevices Command

1. Log in to XSCF.

Information about Software 29

2. Type the following command:

XSCF> showdevices -d domain_id

The following example displays 00-0 has 64GB of memory while the other system
boards have 16GB.

XSCF> showdevices -d 1
Memory:

------­ board perm base domain target deleted remaining
DID XSB mem MB mem MB address mem MB XSB mem MB mem MB
01 00-0 63680 0 0x0000004000000000 260288
01 03-0 16384 7384 0x0000034000000000 260288
01 03-1 16384 0 0x0000030000000000 260288
01 03-2 16384 0 0x000002c000000000 260288
01 03-3 16384 0 0x0000028000000000 260288

Using the prtdiag Command to Identify Memory Size

■ On the domain, execute the prtdiag command.

# prtdiag

The following example displays different memory sizes.

# prtdiag
============================ Memory Configuration ============================
Memory Available Memory DIMM # of Mirror Interleave
LSB Group Size Status Size DIMMs Mode Factor

--- ------ ------------------ ------- ------ ----- ------- ---------­00 A 32768MB okay 2048MB 16 no 8-way
00 B 32768MB okay 2048MB 16 no 8-way
03 A 8192MB okay 2048MB 4 no 2-way
03 B 8192MB okay 2048MB 4 no 2-way
04 A 8192MB okay 2048MB 4 no 2-way
04 B 8192MB okay 2048MB 4 no 2-way
05 A 8192MB okay 2048MB 4 no 2-way
05 B 8192MB okay 2048MB 4 no 2-way
06 A 8192MB okay 2048MB 4 no 2-way

30 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

Identifying Permanent Memory in a Target Board

1. Log in to XSCF.

2. Execute the following command:

XSCF> showdevices -d domain_id

The following example shows a display of the showdevices -d command where 0
is the domain_id.

XSCF> showdevices -d 0

...

Memory:

------­ board perm base domain target deleted remaining
DID XSB mem MB mem MB address mem MB XSB mem MB mem MB
00 00-0 8192 0 0x0000000000000000 24576
00 00-2 8192 1674 0x000003c000000000 24576
00 00-3 8192 0 0x0000034000000000 24576

...

The entry for column 4 perm mem MB indicates the presence of permanent memory
if the value is non-zero.

The example shows permanent memory on 00-2, with 1674 MB.

If the board includes permanent memory, when you execute the deleteboard(8)
command or the moveboard(8) command, the following notice appears:

System may be temporarily suspended, proceed? [y|n]:

Information about Software 31

CPU Upgrade

This section describes the procedure to mount the SPARC64 VII processor on the
SPARC Enterprise M8000/M9000 server.

■ Adding a New CMU Equipped with SPARC64 VII as a New Domain

■ Upgrading an On-CMU SPARC64 VI to SPARC64 VII, or Adding SPARC64 VII to

an Existing CMU, to an Existing Domain Configured with SPARC64 VI

■ Adding a New CMU Equipped with SPARC64 VII to an Existing Domain

Configured with SPARC64 VI

Installation Notes

Note – Before upgrading firmware to XCP 1071 or later, refer to “Updating to XCP”

on page 3.

Caution – You must complete the upgrades to the XCP firmware and to Solaris

before inserting SPARC 64 VII processors into the chassis.

Updating the OpenBoot PROM Firmware With Processor Upgrade

If you have added SPARC64 VII processors to a domain and upgraded from an XCP
version earlier than 1070, you must restart the domain to complete the update to the
OpenBoot PROM firmware in the target domain.

Adding SPARC64 VII Processors to a Domain Using DR

Before adding SPARC64 VII CPUs to a domain using dynamic configuration (DR) for
the first time, you must already have performed the following steps:

1. Upgrade to XCP 1071 or later and a compatible version of Solaris.

2. Reboot the domain.

32 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

Adding a New CMU Equipped with SPARC64 VII as a New Domain

1. Log in to the XSCF on an account with platform administrative privileges.

2. Use the showstatus(8) command to confirm that a component in Faulted or

Deconfigured status doesn't exist.

XSCF> showstatus

If no failures found, the following message appears: "No failures found in
System Initialization." In case of other messages, contact a service engineer

before proceeding to the next step.

3. Change the key position on the operator panel from Locked to Service.

4. Collect an XSCF snapshot to archive system status prior to upgrade.

This will be help in case any problem occurred in this procedure.

XSCF> snapshot -t user@host:directory

5. Update the XCP version to 1071 or later.

Before updating the XCP, be sure to see “Updating to XCP” on page 3.
For the XCP updating procedures, see the SPARC Enterprise
M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.

6. After updating the XCP, reset the XSCF.

XSCF> rebootxscf

7. After resetting the XSCF, log in to the XSCF again.

8. Mount the CPU module (CPUM) on the CMU for add-on.

For the procedure, see the description about the CPU module installation in Section

6.4.1, "Replacing a CPU module" in the SPARC Enterprise M8000/M9000 Servers
Service Manual.

9. Mount the CMU, described in step 8, on the server.

a. Executing the addfru(8) command and select “CMU/IOU” from the maintenance

menu.

XSCF> addfru

b. Perform the operation according to the instructions displayed in the

maintenance menu, referring to “6.2 Active Replacement and Hot Replacement”
in SPARC Enterprise M8000/M9000 Servers Service Manual.

Information about Software 33

Note – Do not fail to execute the diagnosis of newly mounted CMU in the maintenance

menu of addfru(8) command.

10. Confirm that the mounted CPU module has been recognized by the server, and the
error indicator asterisk (*) is not displayed.

XSCF> showhardconf -M

11. Confirm no abnormality occurred by using showlogs error -v and
showstatus(8) commands.

XSCF> showlogs error -v
XSCF> showstatus

If you encounter any hardware abnormality of the XSCF contact a

service engineer.

12. Move the key position on the operator panel from Service to Locked.

13. Sets the following for the CMU.

■ Set up XSB.

■ Set up the domain

■ Set up the CPU operational mode of the domain.

For each setting, see the SPARC Enterprise M4000/M5000/M8000/M9000 Servers XSCF
User’s Guide.

14. Use the setdomainmode(8) command, disable the autoboot function of the
domain.

For detail, see the SPARC Enterprise M4000/M5000/M8000/M9000 Servers XSCF User’s
Guide.

15. Power on the domains.

XSCF> poweron -d domain_id

16. Confirm that the target domain has been correctly started.

XSCF> showlogs power

17. Confirm no abnormality occurred by using showlogs error -v and
showstatus(8) commands.

XSCF> showlogs error -v
XSCF> showstatus

If you encounter any hardware abnormality of the XSCF contact a

34 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

service engineer.

18. Install Solaris 10 5/08.

19. Use the setdomainmode(8) command, enable the autoboot function of the

domain.

For detail, see the SPARC Enterprise M4000/M5000/M8000/M9000 Servers XSCF User’s
Guide. The autoboot function is applied by a domain reboot.

Upgrading an On-CMU SPARC64 VI to SPARC64 VII, or Adding SPARC64 VII to an Existing CMU, to an Existing Domain Configured with SPARC64 VI

1. When the Solaris OS version is Solaris 10 8/07, upgrade it to Solaris 10 5/08 or

apply the mandatory patches described in “Solaris OS Patch Information” on

page 2.

2. To use SPARC64 VII processors, apply the relevant patches to the software in use,
if necessary.

3. Log in to the XSCF on an account with platform administrative privileges.

4. Use the showstatus(8) command to confirm that a component in Faulted or
Deconfigured status doesn't exist.

XSCF> showstatus

If no failures found, the following message appears: "No failures found in
System Initialization." In case of other messages, contact a

before proceeding to the next step.

5. Turn off the power to a domain assigned the CMU of which you upgrade or add
the CPU.

XSCF> poweroff -d domain_id

6. Confirm that the target domain stopped.

XSCF> showlogs power

7. Change the key position on the operator panel from Locked to Service.

Information about Software 35

service engineer

8. Collect an XSCF snapshot to archive system status prior to upgrade.

This will be help in case any problem occurred in this procedure.

XSCF> snapshot -t user@host:directory

9. Update the XCP version to 1072.

Before updating the XCP, be sure to see “Updating to XCP” on page 3.
For the XCP updating procedures, see the SPARC Enterprise
M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.

10. After updating the XCP, reset the XSCF.

XSCF> rebootxscf

11. After resetting the XSCF, log in to the XSCF again.

12. Power on the target domain, and apply OpenBoot PROM firmware.

XSCF> poweron -d domain_id

It stops at ok prompt. It is not necessary to start Solaris OS.

13. Check the updated OpenBoot PROM version.

The OpenBoot PROM version of XCP 1071 is 02.03.0000.

XSCF> version -c cmu -v

DomainID 00 : 02.02.0000
DomainID 01 : 02.02.0000
DomainID 02 : 02.03.0000
DomainID 03 : 02.03.0000
...
DomainID 15 : 02.02.0000

XSB#00-0 : 02.02.0000 (Current), 01.01.0000 (Reserve)
XSB#00-1 : 02.02.0000 (Current), 01.01.0000 (Reserve)
XSB#00-2 : 02.02.0000 (Current), 01.01.0000 (Reserve)
XSB#00-3 : 02.02.0000 (Current), 02.01.0000 (Reserve)
XSB#01-0 : 02.02.0000 (Reserve), 02.03.0000 (Current)
XSB#01-1 : 02.02.0000 (Reserve), 02.03.0000 (Current)
XSB#01-2 : 02.02.0000 (Reserve), 02.03.0000 (Current)
XSB#01-3 : 02.02.0000 (Reserve), 02.03.0000 (Current)
...

In case that the OpenBoot PROM version of the XSB to which the resource of the
target CMU has been assigned is not displayed as 02.03.0000, contact a
engineer.

36 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

service

14. Turn off the power to the target domain.

XSCF> poweroff -d domain_id

15. Upgrade an on-CMU SPARC64 VI processors to SPARC64 VII processors, or add
SPARC64 VII processors to an existing CMU.

■ For upgrading the CPU, operate by hot replacement, referring to "6.2 Active

Replacement and Hot Replacement" in SPARC Enterprise M8000/M9000 Servers
Service Manual.

■ For adding the CPU, operate by hot replacement, referring to "6.2 Active

Replacement and Hot Replacement" in SPARC Enterprise M8000/M9000 Servers
Service Manual.

Note – Do not fail to execute the diagnosis of newly mounted CMU in the maintenance

menu of replacefru(8) command.

16. Confirm that the mounted CPU module has been recognized by the server, and the
error indicator asterisk (*) is not displayed.

XSCF> showhardconf -M

17. Confirm no abnormality occurred by using showlogs error -v and
showstatus(8) commands.

XSCF> showlogs error -v
XSCF> showstatus

If you encounter any hardware abnormality of the XSCF contact a

service engineer.

18. Move the key position on the operator panel from Service to Locked.

19. In case of addition, sets the following for the CMU.

■ Set up XSB.

■ Set up the LSB.

■ Add the XSB to the domain.

For each setting, see the SPARC Enterprise M4000/M5000/M8000/M9000 Servers XSCF
User’s Guide.

20. Set up and confirm the CPU operational mode of the domain.

For detail, see the SPARC Enterprise M4000/M5000/M8000/M9000 Servers XSCF User’s
Guide.

Information about Software 37

21. Power on the target domains.

XSCF> poweron -d domain_id

22. Confirm that the target domain has been correctly started.

XSCF> showlogs power

23. Confirm no abnormality occurred by using showlogs error -v and
showstatus(8) commands.

XSCF> showlogs error -v
XSCF> showstatus

If you encounter any hardware abnormality of the XSCF contact a

service engineer.

Adding a New CMU Equipped with SPARC64 VII to an Existing Domain Configured with SPARC64 VI

1. When the Solaris OS version is Solaris 10 8/07, upgrade it to Solaris 10 5/08 or

apply the mandatory patches described in “Solaris OS Patch Information” on

page 2.

2. To use SPARC64 VII processors, apply the relevant patches to the software in use,
if necessary.

3. Log in to the XSCF on an account with platform administrative privileges.

4. Use the showstatus(8) command to confirm that a component in Faulted or
Deconfigured status doesn't exist.

XSCF> showstatus

If no failures found, the following message appears: "No failures found in
System Initialization." In case of other messages, contact a

before proceeding to the next step.

service engineer

5. Turn off the power to a domain assigned the CMU of which you add the CPU.

XSCF> poweroff -d domain_id

6. Confirm that the target domain stopped.

XSCF> showlogs power

38 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

7. Change the key position on the operator panel from Locked to Service.

8. Collect an XSCF snapshot to archive system status prior to upgrade.

This will be help in case any problem occurred in this procedure.

XSCF> snapshot -t user@host:directory

9. Update the XCP version to 1071 or later.

Before updating the XCP, be sure to see “Updating to XCP” on page 3.
For the XCP updating procedures, see the SPARC Enterprise
M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.

10. After updating the XCP, reset the XSCF.

XSCF> rebootxscf

11. After resetting the XSCF, log in to the XSCF again.

12. Power on the target domain, and update OpenBoot PROM firmware.

XSCF> poweron -d domain_id

It stops at ok prompt. It is not necessary to start Solaris OS.

13. Check the updated OpenBoot PROM version.

The OpenBoot PROM version of XCP 1071 is 02.03.0000.

XSCF> version -c cmu -v

DomainID 00 : 02.02.0000
DomainID 01 : 02.02.0000
DomainID 02 : 02.03.0000
DomainID 03 : 02.03.0000
...
DomainID 15 : 02.02.0000

XSB#00-0 : 02.02.0000 (Current), 01.01.0000 (Reserve)
XSB#00-1 : 02.02.0000 (Current), 01.01.0000 (Reserve)
XSB#00-2 : 02.02.0000 (Current), 01.01.0000 (Reserve)
XSB#00-3 : 02.02.0000 (Current), 01.01.0000 (Reserve)
XSB#01-0 : 02.02.0000 (Reserve), 02.03.0000 (Current)
XSB#01-1 : 02.02.0000 (Reserve), 02.03.0000 (Current)
XSB#01-2 : 02.02.0000 (Reserve), 02.03.0000 (Current)
XSB#01-3 : 02.02.0000 (Reserve), 02.03.0000 (Current)
...

Information about Software 39

In case that the OpenBoot PROM version of the XSB to which the resource of the
target CMU has been assigned is not displayed as 02.03.0000, contact a
engineer.

14. Turn off the target domain.

XSCF> poweroff -d domain_id

15. Mount the CPU module (CPUM) on the CMU for add-on.

For the procedure, see the description about the CPU module installation in Section

6.4.1, "Replacing a CPU module" in the SPARC Enterprise M8000/M9000 Servers
Service Manual.

16. Mount the CMU, described in step 15, on the server. .

a. Executing the addfru(8) command and select “CMU/IOU” from the maintenance

menu.

XSCF> addfru

b. Perform the operation according to the instructions displayed in the

maintenance menu, referring to “6.2 Active Replacement and Hot Replacement”
in SPARC Enterprise M8000/M9000 Servers Service Manual.

Note – Do not fail to execute the diagnosis of newly mounted CMU in the maintenance

menu of addfru(8) command.

service

17. Confirm that the mounted CPU module has been recognized by the server, and the
error indicator asterisk (*) is not displayed.

XSCF> showhardconf -M

18. Confirm no abnormality occurred by using showlogs error -v and
showstatus(8) commands.

XSCF> showlogs error -v
XSCF> showstatus

If you encounter any hardware abnormality of the XSCF contact a

service engineer.

19. Move the key position on the operator panel from Service to Locked.

20. Sets the following for the CMU.

■ Set up XSB.

■ Set up the LSB.

■ Add the XSB to the domain.

40 SPARC Enterprise M8000/M9000 Servers Product Notes for XCP Version 1072 • September 2008

■ Set up the CPU operational mode of the domain.

For each setting, see the SPARC Enterprise M4000/M5000/M8000/M9000 Servers XSCF
User’s Guide.

21. Power on the target domains.

XSCF> poweron -d domain_id

22. Confirm that the target domain has been correctly started.

XSCF> showlogs power

23. Confirm no abnormality occurred by using showlogs error -v and
showstatus(8) commands.

XSCF> showlogs error -v
XSCF> showstatus

If you encounter any hardware abnormality of the XSCF contact a service engineer.

Information about Software 41
