Siemens M56 User Manual

M56
Contents
1
Safety Information ..................... 4
Antenna care ........................... 4
Phone operation ...................... 4
Electronic devices ..................... 5
SAR ............................................. 8
Overview of the phone ............ 10
Display symbols (selection) ..... 12
Getting started ......................... 14
Insert SIM card/battery ........... 14
Charge battery ....................... 15
Switch on, off/PIN entry ........... 16
Switching on for the first time 16
Standby mode ........................ 17
General instructions ................. 18
User guide ............................. 18
Menu controls ........................ 18
Security .................................... 20
Codes .................................... 20
My phone ................................. 22
Calling ...................................... 23
Dialing with number keys ....... 23
End call .................................. 23
Set volume ............................. 23
Redial previous numbers ........ 23
If the number is busy .............. 24
Accept call ............................. 24
Reject call .............................. 25
Speakerphone ........................ 25
Swapping between 2 calls ...... 25
Multi Party ............................. 27
Text entry .................................28
è Default Book ........................ 32
Phonebook ................................33
<New Entry> ..........................33
Call (search for an entry) ......... 34
Change entry ..........................34
] Voice mail/mailbox .............36
Addressbook .............................37
<New Entry> ..........................37
Change entry ..........................38
Call (search for an entry) ......... 39
Addressbook menu .................39
Voice Dialing .......................... 40
Groups ......................................41
Z Call Log .................................. 42
Z Durat/Charges ........................43
] SMS ..................................... 44
Write/send text messages .......44
Picture&Sound .......................45
SMS to group .......................... 46
Read SMS ..............................46
Ring tones, icons ... ................47
SMS Archive ...........................48
] MMS .................................... 49
Write/send MMS messages ......49
Receive MMS ..........................52
Read MMS ..............................52
] E-mail ..................................55
Write/send e-mails ..................55
Receive e-mail ........................ 56
Read new e-mail .....................56
See also Index at the end of this User Guide
2
Contents
] Message profiles ............... 59
SMS profiles ........................... 59
MMS profile ........................... 60
E-mail settings ....................... 61
] CB Services ......................... 63
É Surf & Fun ........................... 64
Internet browser (WAP) .......... 64
Games & More ....................... 67
m Setup ................................. 70
Display ................................... 70
Tones/Alerts ........................... 72
Dynamic Light ........................ 74
Keys ....................................... 75
Phone Setup .......................... 75
Clock ..................................... 78
Connectivity ........................... 79
Security ................................. 82
Network ................................. 84
Accessories ............................ 85
~ Profiles ............................... 87
Favorites .................................. 89
ç Organizer ........................... 90
Calendar ................................ 90
Appointment ......................... 92
Tasks ..................................... 94
Notes ..................................... 95
Missed Alarms ........................ 96
Voice Memo ........................... 97
Time Zones ............................ 98
[ Extras ...................................99
Alarm Clock ............................99
Calculator ...............................99
Currency Conv ......................100
Stopwatch ............................101
Countdown .........................101
Camera (Accessories) ............ 102
Voice command ....................104
Remote synchronization .......105
SIM services (optional) ..........106
Fast access key ....................... 107
Ñ File Manager .................... 109
Send... .....................................111
Notes A-Z ................................112
Questions & Answers ..............120
Customer care ........................123
Specifications .........................125
Exposure to radiofrequency
signals ..................................125
Technical data ..................... 125
Care and maintenance ...........126
Accessories .............................127
U.S. FDA .................................. 129
FCC/Industry Canada Notice ...135
Ten Driving Safety Tips ...........136
Intellectual Property ...............138
Battery quality statement ......139
Index .......................................140
See also Index at the end of this User Guide
Safety precautions
Information for parents
Please read the operating instructions and safety precautions carefully before use. Explain the content and the hazards associated with using the phone to your children.
Remember to comply with legal requirements and local restric­tions when using the phone. For example in airplanes, filling sta­tions, hospitals or while driving.
Cell phones can interfere with the functioning of medical devices such as hearing aids or pacemakers. Keep at least 20 cm/9 inches between phone and pacemaker. When using the cell phone hold it to the ear which is further away from the pacemaker. For more infor­mation consult your physician.
The SIM card and MultiMediaCard may be removed. Caution! Small parts like this could be swallowed by young children.
The mains voltage specified on the power supply unit (Volt) must not be exceeded. Other­wise the charging device may be destroyed.
The ring tone (p. 73), info tones (p. 74) and handsfree talking are reproduced through the loudspeaker. Do not hold the phone to your ear when it rings or when you have switched on the handsfree function (p. 25). Otherwise you risk serious per­manent damage to your hear­ing.
Important:
Improper use will invalidate the warranty!
Only use original Siemens bat­teries (100 % mercury-free) and – charging devices. Otherwise you risk serious damage to health and property. The battery could explode, for instance.
You may only open the phone to replace the battery (100 % mer­cury-free), SIM card or MultiMediaCard. You must not open the battery under any circumstances. All other changes to this device are strictly prohibited and will invali­date the operating license.
Please dispose of unwanted batteries and phones as permit­ted by the laws in your country.
The phone may cause interfer­ence in the vicinity of TV sets, radios and PCs.
Use Siemens original accesso­ries only. This will avoid poten­tial risks to health or property and ensure compliance with all relevant regulations.
3
4
Safety Information
Important
Read this information before using your wireless handheld phone.
As this mobile phone is equipped with a fixed (non-retractable) antenna, some paragraphs in the below text may not be applicable.
Antenna care
Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations.
Phone operation
Normal position
Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.
Tips on efficient operation For your phone to operate most
efficiently:
• Extend your antenna fully (if applicable).
• Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.
Driving
Laws pertaining to the use of mobile phones while driving vary significantly from state-to-state and sometimes even from locality-to­locality within states. For example, some areas may allow persons to use their mobile phones only if they employ a hands-free device, and some areas may prohibit the use of mobile phones entirely. Accordingly, Siemens recommends that persons check the laws for the areas in which they drive or will be driving. For areas where the use of mobile phones while driving is permitted, Siemens encourages persons to use their phones responsibly and to employ hands-free devices. Also, if using your phone while driving, please:
• Give full attention to driving – driving safely is your first responsibility;
• Use hands-free operation, if available;
• Pull off the road and park before making or answering a call, if driving conditions so require.
Safety Information
5
For vehicles equipped with Air Bags
An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.
Electronic devices
Most modern electronic equipment is shielded from radiofrequency (RF) signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturer’s Association recommends that a minimum separation of six inches (6”) be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.
Persons with pacemakers:
• should ALWAYS keep the phone more than six inches from their pacemaker when the phone is turned ON;
• should not carry the phone in a breast pocket;
• should use the ear opposite the pacemaker to minimize the potential for interference;
• should turn the phone OFF immediately if there is any reason to suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider or your hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult the manufacturers of your devices to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.
6
Safety Information
Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so require.
Airplanes
FCC and Airline Regulations prohibit using your phone while in the air. Turn your phone OFF when requested by the airline.
Check and comply with the policy of your airline regarding the use of your phone while the airplane is on the ground.
Blasting areas
To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way radio.” Obey all signs and instructions.
Potentially explosive atmospheres
Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often but not always clearly marked. They include: fueling areas such as gasoline stations; below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles, such as grain, dust or metal powders; and any other area where you would normally be advised to turn off your vehicle engine.
Emergency calls (SOS)
Your wireless phone can be used to make emergency calls. You can make an emergency call from the main display screen. Enter the local emergency number such as 911 and then press the A key.
This phone, like any wireless phone, operates using radio signals, wireless and landline networks, and user-programmed functions. Because of this, connections in all conditions cannot be guaranteed. Therefore, you should never rely
Safety Information
solely on any wireless phone for essential communications (for example, medical emergencies). Remember – to make or receive any calls, the phone must be switched on and be used in a service area that has adequate signal strength. Emergency calls might not be possible on all wireless phone networks or when certain network services or phone features are in use. Check with local service providers regarding their network features.
Always make certain that your phone is properly charged before attempting any emergency calls. If you allow your battery to discharge, you will be unable to receive or make calls, including emergency calls. You must then wait a few minutes after the charging begins to place any emergency calls.
When making an emergency call, remember to give all of the necessary information as accurately as possible. Remember that your wireless phone might be the only means of communication at the scene of an accident, therefore you should not terminate the call until given permission to do so.
7
8
SAR
ABSORPTION RATE (SAR) INFORMATION
THIS SIEMENS M56 PHONE MEETS THE GOVERNMENT'S REQUIREMENTS FOR EXPOSURE TO ELECTROMAGNETIC FIELDS.
Your cell phone is a radio transmitter and receiver. It is designed and man­ufactured not to exceed the emission limits for exposure to radio fre­quency (RF) energy established by the Federal Communications Com­mission (FCC) of the U.S. Govern­ment and by Health Canada. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines were developed and confirmed by inde­pendent scientific organizations through periodic and thorough eval­uation of scientific studies*. The lim­its include a substantial safety mar­gin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for cell phones employs a unit of measure­ment known as the Specific Absorp­tion Rate, or SAR. The SAR limit established by the FCC and by Health Canada is 1.6 W/kg**. Tests for SAR are conducted using standard oper­ating positions accepted by the FCC and by Industry Canada with the phone transmitting at its highest cer­tified power level in all tested fre­quency bands. Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base sta­tion, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and the manufacturer must certify to the FCC and Industry Canada that it does not exceed the limit estab­lished by each government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body), reported to the FCC and available for review by Industry Canada. The highest SAR value for this model phone when testest for use at the ear is
and when worn on the body
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Internet Association (CTIA) web-site at www.phonefacts.net or the Cana­dian Wireless Telecommunications Association (CWTA) website www.cwta.ca.
SAR information on this Siemens M56 phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID PWX-M56.
0.98 W/kg***
0.48 W/kg***
+
is
While there may be differences between the SAR levels of various phones and at various positions, all Siemens products meet the governmental requirements for safe RF exposure.
+
For body worn operation, this
mobile phone has been tested and meets FCC RF exposure guidelines when used with a Siemens accesory designated for this product or when used with a carry accessory that contains no metal and that positions the handset at least 1.5 cm/0.59 in from the body. Use of other carry accessories may not ensure compliance with FCC RF exposure guidelines.
* The World Health Organization
(WHO, CH-1211 Geneva 27, Switzerland), on the basis of the actual knowledge, does not see any necessity for special precautionary measures when using cell phones. Further information:
www.who.int/peh-emf, www.mmfai.org, www.my-siemens.com.
** averaged over 1 g of tissue. ***SAR values may vary depending
on national requirements and network bands. SAR information for different regions can be found at www.my-siemens.com
SAR
9
10
A
1
Call key
Dial phone number/name displayed, take calls. Show last phone numbers dialed in standby mode.
B
2
On/Off/End key
• Switched off: hold down to switch on.
• During a conversation or in an application
(except for Surf &Fun): press briefly to finish.
• In menus: press briefly to go back a level. Hold down to return to standby mode.
• In standby mode: hold down to switch off phone.
Overview of the phone
3 Control key
In lists and menus:
G Scroll up/down. D C
During a call:
Select function.
Menu level back.
_ªg
Service provider
01.06.2003 10:10
NewMMS Menu
D
In standby mode:
E F D C
Open call menu.
Voice control (hold down).
Open Addressbook/Phonebook.
Open menu.
GPRS info.
Overview of the phone
1 Integrated antenna
Do not interfere unnecessarily with the phone above the battery cover. This reduces the sig­nal quality.
11
2 Loudspeaker 3 Display icons
Signal strength/ GPRS available/ battery level.
4 Soft keys
The current functions of these keys are shown in the bottom line of the display as
§text§/symbol (e.g. d).
5 Input keys
Numbers, letters.
*
6
• In standby mode: switch all audible signals
• For incoming calls: only switch off ring
7
In standby mode: switch key lock on/off.
Hold down
on/off (except alarm).
tones.
#
Hold down
8 Microphone
9 Dynamic Light
Two LEDs on each side indicate different functions visually (set, p. 74).
: Device interface
Connection for charger, headset etc.
_ªg
Service provider
01.06.2003 10:10
NewMMS Menu
12
Display symbols
Signal strength
_
Charging
h d
Battery charging status, e.g., 50 %
Phonebook/Addressbook
è
Records
Z
Surf & Fun
É
Organizer
ç
Messages
]
Profiles
~
[
Extras
File system
Ñ
Settings
m
All calls are forwarded
n
Ringer off
j
Short ring (beep) only
k
Ringer only if caller is stored in
l
Phonebook/Addressbook
Ø
Alarm set
Alarm clock activated
Ö
µ
Key lock activated
Phone numbers/names:
On the SIM card
¢
¡
On the SIM card (PIN2 protected)
In the phone memory
v
Display symbols (selection)
No network access
²
p,o
Function activated/deactivated
Phonebook/Addressbook
N
ABC/
Indicates whether upper or lower-
Abc/abc
case letters are active Text input with T9
™ «
Activated and available
ª
Registered
Temporarily interrupted
GPRS download
©
WAP online
Ê
WAP via GPRS online
Ë
Ì
WAP no network
Headset mode
±
Auto answer feature on
Organizer/Extras symbols
Memo
u
Call
v
Appointment
w
Dictating mach./Voice memory
x
Birthday
{
Alarm clock/stopwatch
y/æ
Depending on the service provider, some of the symbols shown here may vary from those in the phone.
Soft keys
] í ì \ 
·
O
Display symbols (selection)
Message received.
MMS received.
MMS notification received.
Voice mail received.
Data received.
Picture received.
Melody received.
Unanswered call.
Store in Phonebook/ Addressbook.
Retrieve from Phonebook/ Addressbook.
Change Phonebook/ Addressbook.
13
14
Getting started
Insert SIM card/battery
The service provider supplies you with a SIM card on which all the important data for your line is stored. If the SIM card has been delivered in credit-card size, snap the smaller segment out and remove any rough edges.
• Remove cover upwards in the direction of the arrow
1
• Insert the SIM card in the opening with the contact area facing down- wards and push gently until it engages below the holder (make sure the angled corner is in the correct position
2
1.
2).
• Insert the battery sideways into the phone wards
3, then press down-
4 until it engages.
4
3
5
• To remove, press the retaining tab
5 then lift the battery out.
• Insert the cover in the lower
6, then press downwards
edge
7 until it engages.
7
6
Additional information
Always switch off your phone before removing the battery!
Only 3V SIM cards are supported. Please contact your service provider if you have an older card.
Functions without SIM card.............p. 119
Getting started
m
4
15
Charge battery
The battery is not fully charged when delivered. Plug charger cable into the bottom of the phone, plug power supply unit into a mains power socket and charge for at least two hours.
z
y
x
6
c
w
b
a
9
2
jkl
5
v
tu
8
i
h
g
0
rs
q
p
7
Charge symbol not visible
If the battery has been discharged fully the charge icon is not visible when the charger is plugged in. It will appear after up to two hours. In this case the battery is fully charged after 3–4 hours.
Only use the charger provided! Display while in service
Charge level display during opera­tion (empty-full):
adg
A beep sounds when the battery is nearly empty. The battery level is
Display when charging is in progress
h During charging.
Charging time
An empty battery is fully charged after about 2 hours. Charging is only possible within a temperature range of +41 °F – 104 °F. If the temperature rises/falls 41 °F above/below this, the charge symbol flashes a warning. The mains voltage specified on the power supply unit must not be exceeded.
Note
Your phone's display is delivered with a protective film. Remove this film before getting started. Electrostatic charging can in rare cases lead to discoloring at the edge of the display. This
will, however, disappear of its own accord after 10 minutes at the most.
only shown correctly during an unbroken charging/discharging cycle. You should therefore not remove the battery unnecessarily and where possible not finish the charging
process early.
Additional information
The charger heats up when used for long periods. This is normal and not dangerous.
Operating time................................. p. 116
Outside your home network ............ p. 116
16
Switch on, off/PIN entry
Switch on/off
B
Hold down On/Off/End key to switch on or off.
Enter PIN
The SIM card can be protected with a 4- to 8-digit PIN.
J
§OK§ Confirm entry with right
Additional information
Change PIN ......................................p. 20
Other network ................................... p. 84
SIM card problems .......................... p. 117
Clear SIM card barring ...................... p. 21
Enter the PIN using the number keys. The charac­ters ensure nobody can read your PIN on the display. Correct errors with §Clear§.
soft key. Logging on to the network will take a few seconds.
appear to
****
Please enter
your PIN:
* * * *
Clear OK
Switching on for the first time
Time/Date
The clock can be set to the right time once at start-up.
§Yes§ Press.
J
§OK§ Press. The time and date
Time Zones
Set the time zone for your area.
F
§Set§ ... and set.
Additional information
If the battery is removed for longer than 30 seconds, the clock must be reset.
Additional clock settings ...................p. 78.
First enter the date (day/ month/year), then the time (24 hours, including seconds).
are updated.
Select the required time zone from list ...
Switch on, off/PIN entry
17
Phonebook or Addressbook
You can choose whether you want to use the Phonebook on the SIM card or the internal Addressbook as stan­dard.
You can copy the SIM card Phone­book to the Addressbook on the phone. Please do not interrupt this pro-
cedure. During this time do not accept incoming calls. Follow instructions in
the display. To copy data on the SIM card at a
later time, highlight entries (see p. 114) and copy these with the function Copy Into 9 (Phonebook options menu, p. 34).
You can change the standard phone­book at any time (p. 32).
Signal strength.
_ Strong receive signal. ^ A weak signal reduces the
call quality and may lead to loss of the connection. Change your location.
Emergency number (SOS)
Only to be used in real emergencies!
By pressing the soft key §SOS§ you can make an emergency call on any net­work without a SIM card and without entering a PIN (not available in all countries).
Standby mode
_g
Service provider
01.06.2003 10:10
NewMMS Menu
When the name of the service pro­vider appears on the display, the phone is in standby mode and ready for use.
The left soft key may have different functions pre-assigned.
B
Additional information
}
Hold down the On/Off/End key to return to standby mode from any situation.
SIM services (optional)............p. 106
18
General instructions
User guide
The following symbols are used to explain operation:
J
B
A
D
<>
§Menu§
L
Enter numbers or letters.
On/Off/End key.
Call key.
Press the control key on the side indicated.
Soft keys
Displays a soft-key function.
Function dependent on service provider, may require special registration.
Menu controls
The steps needed to reach a function are shown in a condensed form in this user guide, e. g. to display call list for missed calls:
§Menu§
KZKMissed Calls
This corresponds to:
1
§Menu§ Open menu.
2
E
_g
Service provider
01.06.2003 10:10
NewMMS Menu
From standby mode: press
right soft key.
Messages 5
èZ
]
ç]~
[
Favorit. Select
Select Call Log Z.
Press top of control key.
É
Ñm
General instructions
19
3
Call Log 2
ç]~
Favorit. Select
§Select§ Press.
Press right soft key to open the
Call Log submenu.
Call Log 2-1
4
§Select§ Press.
Z
Missed Calls Received Calls Dialed Calls
Press right soft key to open the
Missed Calls list.
èZ
Z
Ñm
[
Select
É
5
F
6
§View§ Press.
7
Z
Office +55523765489 Carol
Scroll to the required entry.
Press control key at the bot­tom to scroll down.
Z
+55523765489 Carol Service provider
Press left soft key to show phone number with date, time and number of calls.
N View
Carol +55524765476
01.06.2003 10:10 Calls: 5
Missed Calls
View Options
Missed Calls
View Options
OK Options
20
Security
Codes
The phone and SIM card are pro­tected against misuse by several security codes.
Keep these confidential numbers in a safe place where you can access them again if required.
PIN
PIN2
PUK PUK2
Phone code
§Menu§
PIN Control
The PIN is usually requested each time the phone is switched on. You can deactivate this feature but you risk unauthorized use of the phone. Some service providers do not per­mit deactivating the control.
Protects your SIM card (per­sonal identification number).
This is needed to set the charge detail display and to access additional functions requiring special SIM cards.
Key code. Used to unlock SIM cards after the wrong PIN has been entered repeatedly.
Protects your phone. Must be entered at the first security setting.
KmKSecurity KCodes KSelect function
§Select§ Press.
J Enter PIN.
§OK§ Confirm input.
§Change§ Press.
§OK§ Confirm.
Change PIN
You can change the PIN to any 4 to 8 digit number you find easier to remember.
J Enter current PIN.
§OK§ Press.
§OK§ Enter new PIN.
J
,
§OK§ Repeat new PIN.
J
,
Change PIN2
(Display only if PIN2 is available). Proceed as with Change PIN.
Security
§Menu§KmKSecurity
KCodes
Chg.Phonecode
(Change phone code) You define the phone code
(4–8 digits) when you call up a phone-code protected function for the first time. It is then valid for all phone-code protected functions.
Clear SIM card barring
If the PIN is entered incorrectly three times, the SIM card is barred. Enter the PUK (MASTER PIN), provided by your service provider with the SIM card, according to instructions. If the PUK (MASTER PIN) has been lost, please contact your service provider.
Additional information
Screensaver......................................p. 71
Keylock ............................................. p. 75
Further security settings ....................p. 82
21
Loading...
+ 50 hidden pages
