Switch off in hospitals or in the
vicinity of medical devices, e.g.
hearing aids. Mobile phones
can interfere with the function of
these devices. A minimum distance of 20 cm between pacemaker and mob ile phone should
be kept. When using the mobile
phone hold it to the ear which is
further removed from the pacemaker.
Always use the handsfree kit for
calls while driving (p. 91).
Mobile phones must be
switched off at all times in an aircraft. To prevent accidental activation, see (p. 53).
Switch off near petrol stations,
fuel depots, chemical plants or
blasting operations. Mobile
phones can interfere with the
operation of technical installations.
The ring tone and handsfree
talking are reproduced via the
loudspeaker. Do not hold the
phone to the e ar when it rings or
when you have activated the
handsfree function. Otherwise
you risk serious, lasting damage
to hearing.
SIM card may be removed. Caution! Small parts could be swallowed by children.
The mains voltage specified on
the power supply unit must not
be exceeded.
We recommend you use only
original Siemens batteries
(100% mercury-free) and charging devices. Otherwise considerable health risks and damage
to the product cannot be excluded.
Neither the phone nor the battery (100% mercury-free) may
be opened under any circumstances (except when exchanging the battery, SIM card or top
shell). Any other changes to this
device are strictly prohibited, as
they will invalidate the approval
criteria required for operation of
the unit.
Please note:
Dispose of used batteries and
phones according to the legal
regulations.
Mobile phones can interfere
with the operation of nearby
TVs, radios or PCs.
We recommend you use only
original Siemens accessories to
avoid possible damage and to
comply with the existing regulations.
Improper use invalidates the warranty!
4
Overview of the phone
Loudspeaker
Display indicators
Signal strength/
GPRS available/
battery level.
A
Call key
Dial displayed phone
number or name, accept
calls.
In standby mode:
Display the last calls.
*
Hold down
In standby mode:
Switch signal tones on and
off (see also p. 82).
Microphone
On the underside.
Device interface
Connection for charger,
headset etc.
Control key at the top/at the
bottom
Press at the bottom: Open
Phonebook (in standby mode).
Hold down at the top: Start
voice dialling (in standby
mode).
Press at the top: Start volume
adjustment (during a call). Then
press at the top/at t he bottom to
make your setting.
Scroll up and down in menus
and lists.
_ ª g
Service provider
01.10.200212:30
Games...Menu
_ ª g
Service provider
01.10.200212:30
Games...Menu
Integrated antenna
Do not interfere with the
phone above the battery
cover unnecessarily. This
reduces the signal strength.
B
On/Off/End key
Press briefly:
End call/function or return
to standby mode . In menus:
one menu level back.
Hold down:
Switch phone on/off.
From menus: Return to the
standby mode.
#
Hold down
In standby mode: Switch
key lock on and off.
Control key on the left/on the right
Press the control key on the outside
left or right, to call up the function
that is displayed as text or icon on the
grey fields above the key. These are
in standby mode (factory default):
§Games...§ or e.g.
}
(SIM services) and
§Menu§ (main menu).
Getting Started
The front and back covers of the casing (CLIPit™ Covers, my-CLIPit™: p. 13 and
p. 90) as well as the keypad can be changed in a matter of seconds - no tools
required. Please switch the phone off first:
To attach
To remove
5
Note
Your phone's display and the display cover of the top shell are del ivered with a protective film.
Remove this film before getting started.
In rare cases the static discharge may cause discolouration at the edges of the display. However this will disappear within 10 minutes.
To avoid damage to the display, the phone should not be used without the upper shell.
6
Getting Started
Insert SIM card/battery
The service provider supplies you
with a SIM card on which all the important data for your line is stored. If
the SIM card has been delivered in
credit card size, snap the smaller
segment out and remove any rough
edges.
, then lift
.
p
q
n
n
, lift battery at
p
• Press grooved area
cover in the direction indicated by
the arrow
o
o
• Press latch in the direction indicated by the arrow
the cutout on the side of the
phone, then tilt upwards and re-
.
move
q
• Insert SIM card in the opening,
contacts pointing downwards
(make sure the angled corner is in
correct position
until it engages
). Push gently
r
.
s
s
r
• Insert battery in the phone side-
, then press downwards
ways
t
until it engages
u
.
u
t
• Replace cover and press downwards until it engages.
Note
Always switch off phone before removing
the battery!
Only 3-Volt SIM cards are supported.
Please contact your service provider if you
have an older card.
Functions without SIM card............... p. 84
Getting Started
7
Charge battery
The battery is not fully charged
when delivered. Plug in the charger
cable at the bottom of the phone,
plug in the power supply unit to the
mains power socket and charge for
least two hours.
h
Charging time
An empty battery is fully charged after about 2 hours. Charging is only
possible in an ambient temperature
of 5°C to 40°C (the charge icon flashes as a warning when the temperature is 5°C above/below this range).
The voltage specified on the power
supply unit must not be exceeded.
To use the full performance of the
battery, the battery must be fully
charged and discharged at least five
times.
Display when charging is
in progress
Charge icon not visible
If the battery is totally discharged no
charge icon is displayed when the
charger is plugged in. It is displayed
after 2 hours at most. In this case
the battery is fully charged after
3-4 hours.
Only use the charger provided!
Display while in service
Charge level display during operation (empty-full):
a
A beep sounds when the battery is
nearly empty. The charge level of the
battery is displayed correctly only after uninterrupted charging/discharging. You should not remove the battery unnecessarily and not end
charging prematurely, if possible.
dg
Note
The charger heats up when used for long
periods. This is normal and not dangerous.
Operating times .................................p. 79
Quality declaration for the battery..... p. 80
8
General Instructions
User Guide
The following symbols are used to
explain operation:
Enter numbers or letters.
J
B
A
G
H
§Menu
L
On/Off/End key.
Call key.
Press control key at the top/at the bottom to scroll up
and down.
Press control key on the left/on the right to call a
function.
Displays a function.
Function depends on the
service provider, special
registration may be necessary.
Control key
Steps for calling a function are
shown in a condensed form in this user guide, e.g.: to display the call list
for missed calls:
RecordsKMissed calls
K
§Menu§
This corresponds to:
n
§Menu§Open menu.
o
F
_g
Service provider
01.10.200212:30
Games...
From standby mode: Press
control key on the right.
Phonebook
]
Messages
Records
Scroll to Records.
Press control key at the bottom to scroll downwards.
Menu
Select
General Instructions
9
p
§Select§Press.
q
§Select§Press.
Z Records
Press control key on the right
to open the Records submenu.
Missed calls
Calls received
Calls dialled
Press control key on the right
to open the list of Missed calls.
Messages
Groups
Select
Select
r
F
s
§View§Press.
+49892325678
Office
Carol
Scroll to the required
entry.
Press control key at the bottom to scroll downwards.
+49892325678
Office
Carol
Press control key on the left to
display the phone number with
date and time.
t
01.10.200212:30
ViewOptions
ViewOptions
Office
+49322325774
CallOK
10
Switch on, off / PIN entry
Switch on/off
B
Hold down On/Off/End key
to switch on or off.
Enter PIN
The SIM card can be protected with a
4-8 digit PIN.
J
§OK§Press the control key on
Enter the PIN code using
the number keys (the display shows a series of asterisks, if you make a
mistake press §Clear§).
Enter PIN:
* * * *
ClearOK
the right to confirm the in-
put.
Logging on to the net-
work will take a few seconds.
Standby mode
_g
Service provider
01.10.200212:30
Games...
When the name of the service provider/logo appears on the display,
the phone is in standby mode and
Other network....................................p. 70
Deactivate/activate screensaver .......p. 57
Set display contrast...........................p. 58
Set time ............................................. p. 63
Menu
Security
11
ed against misuse by several security
codes.
Keep these confidential numbers in a
safe place where you can access them
again if required.
PIN
PIN2
PUK
PUK2
Phone
code
§Menu§
Protects your S IM card (personal identification number).
This is needed to set the charg e
detail display and to access additional functions on special
SIM cards.
Key code. Used to unlock SIM
cards after the wrong PIN has
been entered.
Protects some func tions of your
phone. Must be defined at the
first security setting.
SetupKSecurity
K
K
then select function
Codes
PIN control
The PIN is usually requested each
time the phone is switched on. You
can deactivate this feature but you
risk unauthorised use of the phone.
Some service providers do not permit deactivation of the control.
§Select§Press.
J
§OK§Confirm input.
§Change§Press.
§OK§Confirm.
Enter PIN.
Change PIN
You can change the PIN to any
4-8 digit number you may find
easier to remember.
J
§OK§Press.
J
J
Enter old PIN.
§OK§ Enter new PIN.
,
§OK§ Repeat new PIN.
,
Change PIN2
(displayed only if PIN 2 is available).
Proceed as with Change PIN.
12
Security
ChangePhonecode
You define and enter the phone
code (4 - 8 digits) when calling a
phone code protected function
(e.g. babysitter, p. 18) for the first
time. It is then valid for all protected
functions.
If it is entered incorrectly three times
the phone is locked. Contact the Siemens Service (p. 88).
Clear SIM card barring
If the PIN is entered incorrectly three
times, the SIM card is barred. Enter
the PUK (MASTER PIN) provided by
your service provider with the SIM
card, according to instructions. If the
PUK (MASTER PIN) has been lost,
please contact your service provider.
Note
Screensaver...................................... p. 57
Auto key lock..................................... p. 60
Further security settings.................... p. 68
Prevent accidental
activation
Even if PIN use is deactivated (p. 11)
confirmation is required to switch on
the phone.
This prevents accidental activation
of the phone, e.g. when you are carrying it in a bag or when you are travelling in an aircraft.
B
§OK
§Cancel§Press (or no further input)
Hold down.
Please confirm switch on
OKCancel
Press to switch on the
phone.
to stop switch-on procedure. The phone does not
switch on.
My phone
13
tions so that you can adapt it to meet
your personal requirements.
Ring tones
Assign individual ring tones to caller
groups or anniversaries (p. 59).
The sound manager is available for
managing the ring tones (p. 41).
Logo, Screensaver, Animation
Adjust your phone according to your
own wishes in the following ways to
give it a personal touch:
To switch on
Select a bitmap style and a greeting
(p. 57) that you create yourself.
Screensaver
You can set an analogue clock, an individual picture or an animation as
screensaver (p. 57).
(Provider) logo
Select an individual picture to replace the network provider’s logo/
name (p. 57).
Where do I get what?
You can order additional ring tones,
logos and screensavers on the Internet and receive them via SMS:
Pick out the required
phone number from the
list, then press...
... to dial.
Store number .........................p. 19
Making a phone call
15
When a number is busy
If the called number is busy or cannot be reached because of network
problems several options are available (depending on the service provider). An incoming call or any other
use of the phone interrupts these
functions.
Either
Auto redial previous numbers
§Auto dial§ Press. The number is auto-
Or
Call back
§Call back§ Press. Your phone rings
Or
Reminder
§Prompt§Press. A beep reminds you
matically dialled for up to
15 minutes at increasing
intervals. End with:
End key.
B
L
when the busy number is
free. Press the Call key to
dial the number.
to redial the displayed
phone number after
15 minutes.
Accept call
i
+498912345
ReplyReject
The phone must be switched on
(standby mode). An incoming call
will interrupt any other use of the
phone.
§Reply§Press.
Or
Press.
A
If the phone number has been transmitted by the network, it is displayed. If the number and the name
are stored in the Phonebook, the corresponding name is displayed instead. If set, a picture or an animation can be displayed instead of the
bell icon (p. 22).
Reject call
§Reject§Press.
Or
B
Note
Accept call using any key ..................p. 60
Press briefly.
Missed calls ...............................p. 27
16
Making a phone call
Handsfree
You can put the phone aside during
a call. You can then hear the caller
via the loudspeaker.
_g
vv
Carol
menu
Handsfr.
§Handsfr.§ Activate handsfree
§Yes§Activate.
G
§Handsfr.§ Deactivate.
Note
To avoid damage to hearing always deac-
tivate the "handsfree function" before
holding the phone to your ear!
y menu§ Call menu .......................... p. 18
function.
_g
Handsfr.
Control volume.
<
menu
<
Held call
You can call another number during
a call.
y menu§ Open call menu.
HoldThe current call is put on
Now dial the new phone number
(also from Phonebook:
When the new connection is established:
y menu§ Open call menu
SwapSwap back and forth be-
Call waiting/Swap
You may need to register for this
function with the service provider
and set your phone accordingly
(p. 60).
During a call, you may be advised
that there is another call waiting.
You will hear a special tone during
the call. You have the following options:
hold.
_g
Call held
Back
).
F
tween both calls.
L
Making a phone call
17
Accept the waiting call
§Swap§Accept the waiting call
End the current call:
B
§Yes§Return to the held call.
Or
§No§The held call is ended.
and place the current call
on hold. To swap between the two calls, proceed as above.
Press. The following query is displayed: "Return to
the call on hold?"
Reject waiting call
§Reject§Reject the waiting call.
Or
§Divert§If this is set, the waiting
The caller hears the busy
tone.
call will be diverted to the
mailbox for example
(setting, p. 60).
End current call
B
§Reply§Accept the new call.
End the current call.
Conference
Call up to 5 parties one by one and
link them together in a phone conference. Some of the functions described may not be supported by
your service provider or may have to
be enabled specially.
You have established a connection:
y menu§ Open menu and select
Hold. The current call is
put on hold. Now dial a
new number. When the
new connection is established ...
y menu§ ... open menu and select
Conference. The held call is
joined.
Repeat procedure until all participants are linked together (up to
5participants).
L
End
B
All calls in the conference
are ended simultaneously
when the End key is
pressed.
18
Making a phone call
Call menu
The following functions are only
available during a call:
y menu§ Open menu.
Swap
Hold
Micro-
phone
Handsfree
Volume
Confe-
rence
Duration/
charges
Send
DTMF
tones
Call
transfer
L
Main menu
Call status
(p. 16)
(p. 16)
Switch microphone on/off. If
switched off, the person on
the other end of the line cannot hear you (muting).
Alternatively:
down.
(p. 16)
Adjust handset volume.
(p. 17)
While the connection continues, the call duration and (if
set, p. 28) the charge details
are displayed.
(p. 76)
The original call is joined to
the second one. For you,
both calls are now ended.
Access to the main menu.
List all held and active calls
(e.g. participants in a conference).
*
Hold
Babysitter
Only one phone number can be dialled.
D
Switch on
§Menu§
§Select§Press.
J
When first prompted you define and
enter the phone code (4 - 8 digits).
Please do not forget this code!
§OK§Confirm input.
§Change§Press.
Q
§OK§Confirm On.
Switch off
#
J
§OK§Confirm input.
§Change§Press.
§OK§Confirm Off.
Note
Change phone code ..........................p. 12
Hold down control key on
the right.
K
SetupKSecurity
Babysitter
K
Enter phone code:
/
Select phone number
J
from the Phonebook
(p. 19) or enter a new
one.
Hold down.
Enter phone code.
Phonebook
19
bers in the Phonebook with a special
name. To dial them, simply highlight
the name. If a phone number is
stored with a name, it appears on
the display when you are called. Entries that belong together can be
combined to form a group.
<New entry>
F
D
G
J
Number:
Enter phone number always with
prefix.
Name:
Enter (Text entry, p. 20).
Open Phonebook (in
standby mode).
<Own numbers>
<New entry>
<Group>
Select
Select <New entry>.
Activate input fields.
Make the following entries. The maximum
number of characters
available is shown at the
top of the display.
Group:
Default: No group
§Change§Entries can be organised
by groups (p. 24) for
example:
VIP, Leisure, Office, Family
Location:
Default: SIM
§Change§Select a storage location:
SIM, Protected SIM or Mobile
(p. 21).
Record no.:
Each entry is automatically assigned
a number under which it can also be
selected (p. 20).
Service numbers ...............................p. 80
Store control codes ...........................p. 76
20
Phonebook
Text entry
Press number key repeatedly until the required letter is displayed. The cursor advances after a short delay.
2
Ä, ä /1-9Umlauts and numbers are dis-
§Clear Press briefly to delete the let-
G
#
*
0
1
Press once for a, twice for b
etc. The first let ter of a name is
automatically written in UPPERCASE.
Holddown: Writes the digit.
played after the relevant letters.
ter before the cursor.
Hold down to delete th e whole
name.
Move the cursor (forward/
back).
Press briefly: Switch between: abc, Abc,T9abc,
T9
Abc, 123. Status indicator in
the top line of the display.
Hold down: All input modes
are displayed.
Press briefly: Select special
characters (p. 77).
Hold down: Open input menu
(p. 78).
Press once/repeatedly:
. , ? ! @ / & ~ + - :
Hold down: Write 0
Space. Only with T9: Press
twice = skip line.
Call/search for an entry
F
J
A
Open Phonebook.
/
Select a name with the
G
first letter and/or scroll.
Dial number.
Call with Record no.
A record number is automatically assigned to every new entry in the
Phonebook.
J
#
A
Enter record number (in
standby mode).
Press.
Press.
Edit entry
G
§Options§ Press and select Change.
G
J
§Save§Press.
Select entry in the Phonebook.
Select required input
field.
Make your changes.
Phonebook
21
Phonebook menu
§Options
View
Change
New
entry
Delete
Delete all
Voicedialling
Send
SMS...
Animation
Capacity
Open menu.
Display entry.
Display entry for changes.
Create a new Phonebook
entry.
Delete entry from the Phonebook.
Select storage lo cation. Delete
all entries after confirmation.
Use voice dialling to make an
entry (p. 23).
as entry: Send Phonebook
entry as vCard to recipient.
as text: Send entry as text of
an SMS message.
Assign an individual animation
to the phone number (p. 22).
Display the maximum memory
and the available capacity for
SIM, Protected SIM, phone
memory, animations and
voice dialling.
Location:
An entry can be moved to different
storage locations in the Phonebook
(change entry, p. 20).
SIM (standard)
Entries that are stored in the Phonebook on the SIM card can also be
used on a different GSM Phone.
Protected SIM
Phone numbers can be stored in protected locations on a special SIM
card. A PIN 2 is needed for editing
(p. 11).
Mobile
Phonebook entries are stored in the
memory of the mobile phone when
the memory of the SIM card is full.
Symbols in the opened entry
¢,
¡,
›
Å,Ã,Ä,
°
¢
¡
L
v
v
Storage location (p. 21)
Picture (p. 22)
Groups (p. 24)
Ç
Voice dialling (p. 23)
22
Phonebook
Assign animation
Assign an individual animation to
phone numbers. This animation will
appear in the display when there is a
call from this number.
Assign animation
F
G
§Options Open menu.
§Select§Select
G
§Load§The previewp. 39 is
§Select§The animation is assigned
Open Phonebook.
Select entry.
oAnimation.
Select Own animat. or
Own pictures.
Select Animation.
opened and the animation is displayed.
to the phone number. It
appears with a
in the Phonebook.
›
symbol
Delete/change animation
If an animation is assigned to a
phone number, it can be deleted or
replaced.
G
§Options§ Press.
§Select§Select
§Delete The assignment is cleared
Or
§Select§The current animation is
Note
Animations can simply be pictures.
An animation can be assigned to several
phone numbers.
Add pictures/animations....................p. 40
Siemens City Portal...........................p. 13
Select entry with anima-
›
in the Phone-
tion
book.
Animation.
p
after confirmation.
displayed.
Phonebook
23
Voicedialling
You can dial phone numbers by simply saying a name.
Up to 20 voice recordings for voice
dialling or voice commands (p. 47)
can be stored in the phone (not on
the SIM card!).
Record recording
F
G
§Options§
Voicedialling
§Start§Start the recording.
A short signal sounds. Now say the
name and repeat it when prompted
by a signal tone and a display
prompt. A beep confirms the recording that is saved automatically.
°
Open Phonebook.
Select entry.
Open menu.
Select and confirm
with §Yes§.
Identification of entries
with voice dialling in the
Phonebook.
Apply voice dialling
E
Now say the name, the phone
number is dialled.
Note
Noisy environments may affect the recognisability.
Hold down. Start voice dialling (in standby mode).
Delete/redo recording
You can delete or redo the voice recording for a Phonebook entry.
F
G
§Options Open menu.
G
§Delete Press. Delete voice record-
Or
§Select§You can play back the re-
Open Phonebook.
Select entry with voice
dialling.
Select
p Voicedialling.
ing with §Yes§. The Phonebook entry itself is not
affected.
cording or redo it.
24
Groups
it is best to assign them to a group,
e.g.: VIP, Leisure, Office, Family
§Menu§
K
Groups
Select function:
K
SMS to group
A memo (SMS) can be sent as a "circular" to all members of a group.
Each SMS is charged separately!
G
§Select§Press. The group is con-
J
A
A
Select a group
(the number of the entries is listed behind the
group name).
Å VIP(6)
à Leisure(9)
Office(12)
Ä
Select
firmed and the editor is
opened.
Compose message.
Press. The first recipient is
displayed.
Press. The SMS is sent.
Each send operation must be confirmed. It is possible to skip individual recipients.
Call to group
You can call up to 5 group members
one by one and link them together in
a conference (function may need to
be enabled by the service provider).
G
§Select§Press. The members of
G
§Change§Press. Mark entry/unmark
Select a group.
the group are listed.
Select the entries you
want to call.
entry.
Anne
o
Barbara
p
Carol
p
ChangeOK
L
Groups
25
§OK§Confirm selection. The
A
§Options
first entry is dialled. When
the connection has been
established, the call is put
on hold.
Proceed by calling the
next entry until all marked
entries are called (up to 5,
depending on the service
provider).
Open menu e.g. to link
the calls on hold in a con-
.
ference
(2)
Ã
v
Barbara
Next: Carol
DialOptions
Call to group menu
§Options
Dial
Skip
Conference
Swap
Hold
Open menu.
Dial current entry.
Skip next number.
Link all calls on hold in a
conference (p. 17).
Accept the waiting call and
put the current call on hold
(p. 16).
Put call on hold to call another entry.
Microphone
Handsfree
Volume
Duration/
charges
Send DTMF
tones
Call trans-
L
fer
Main menu
Call status
Switch the microphone on
or off. If it is switched off, the
person on the other end of
the line cannot hear you
(muting).
Alternatively:
Hold down.
*
Call via the loudspeaker.
Adjust handset volume.
While the connection continues, the call duration and
(if set, p. 28) the call time/
cost are displayed.
(p. 76)
The original call is joined to
the second one. For you,
both calls are now ended.
Direct access to the main
menu.
List all held and active calls
(e.g. participants in a conference).
26
Groups
Group setup
K
§Menu§
G
§Rename§ Change group name.
§Select§Display members of the
<New entry>
§View§Display entry.
§Options See below.
GroupsKGroup setup
Å VIP(6)
à Leisure(9)
Office(12)
Ä
RenameSelect
Select a group.
group.
<New entry>
Barbara
Carol
ViewOptions
Make your entries as in
Phonebook (p. 19).
Group entry menu
§Options
View
Change
New entry
Remove
Remove all
Voicedialling
Send SMS...
Animation
Open menu.
Display entry.
Open entry for changes.
Enter new member.
Remove entry only from the
group. It is still available in
the Phonebook.
Remove all entrie s from the
group.
Start voice dialling to an entry (p. 23).
as entry: Send Phon ebook
entry to recipient.
as text: Send entry as text
of an SMS message.
Assign an individual animation to the phone number
(p. 22).
Records
27
bers of calls for convenient redialling.
Records
K
§Menu§
§Select§Press.
G
§Select§Press.
G
A
Or
§View§Display information on
The following call lists are available:
Missed calls
The phone numbers of calls
that you have received but not answered are stored for call back purposes.
Requirement: The network supports
the "Caller Identity" feature.
Calls received
All accepted calls are listed. Requirement:
The network supports the "Caller
Identity" feature.
Choose call list.
Select phone number.
Dial phone number.
the phone number.
L
Icon in standby mode for
missed call. When you
press the control key (on
the left), the phone
number is displayed.
L
Calls dialled
Access to the last ten numbers you
dialled.
A
Erase records
The contents of all call lists are
deleted.
Call list menu
The call list menu can be called up if
an entry is highlighted.
§Options§ Open call list menu.
View
Correct no.
Save no. to
d
Delete
Delete all
Note
Duration/charges .............................. p. 28
Fast access in standby
mode.
View entry.
Load number into display
and correct it there if
necessary.
Store entry in the
Phonebook.
Delete entry after
confirmation.
Delete all entries of the call
list after confirmation.
28
Duration/charges
You can display the charge details
and the duration of calls as you
speak as well as setting a unit limit
for outgoing calls.
RecordsKDuration/charges
K
§Menu§
After you have made the charge detail settings, you can display the call
duration/charges for the various call
types or you can display the credit
balance.
Select a function:
Last call
All outgoing calls
All incom. calls
Remain. units
Charge settings
§Select§Display the data.
When displayed, you can:
§Reset§Reset display.
§OK§End display.
Charge settings
§Menu§
Conv.
(PIN 2 query)
Enter the currency in which the
charge details are to be shown.
Personal rate
(PIN 2 query)
Enter the charges per unit/period.
A/c limit
(PIN 2 query)
Special SIM cards allow you or the
service provider to define a credit or
period after which the phone is
barrred for outgoing calls.
§Change§Press, enter PIN 2.
A/c limit Activate.
J
§OK§confirm.
Then confirm the credit or reset the
counter. The display of the credit
balance of Prepaid cards may vary
depending on the service provider.
Auto display
Call duration and charges of the last
call are automatically displayed after
each call.
RecordsKDuration/charges
K
K
Charge settings
Enter the number of the
units and ...
L
L
L
Messages (SMS)
29
You may transmit and receive very
long messages (up to 760 characters) on your phone, which are automatically composed from several
"normal" SMS messages (note the
accruing charges).
Depending on the service provider,
e-mails and faxes can also be sent or
e-mails can be received via SMS
(change setting if necessary, p. 66).
Read messages
Display indicates a new
]
Press the control key on the left to
read the message.
Date/time
No./sender
Message
G
§Reply§Reply menu shown
§Options§ Inbox/outbox menu
message
Scroll through the message line by line.
below.
(p. 30).
.
_g
Service provider
01.10.2002 23:45
]
01.10.200223:45
017198987676
Do we meet tomorrow?
ReplyOptions
Menu
Pictures and sounds in SMS
Pictures or sounds can be part of mes-
sages you receive.
Pictures are shown in the message,
sounds are indicated as notes. If a
note is reached when scrolling
through the message, the corresponding sound is played (to send
pictures and sounds see p. 33).
Note
Message store full ....................p. 79
T
Use §highlighted§ phone no./URL .....p. 80
Reply menu
§Reply§Open the reply menu.
Write message
Change
Answer is YES
Answer is NO
Call back
Delay
Thanks
When the message has been edited
in the editor, it can be stored or sent
with §Options§.
Create a new reply
text.
Edit message receiv ed
or assign a new text
to it.
Add YES to the
message.
Add NO to the
message.
Append a standard
text to the message as
a reply.
30
Messages (SMS)
Inbox/outbox
K
K
Symbol
ƒ
…
View
Reply
Send
Change
Delete
Delete all
Messages
Inbox / or Outbox /
Barbara
ƒ
Carol
…
023598765432
…
ViewOptions
Inbox /
Read
Unread
Read entry.
Directly answer incoming
SMS messages.
Dial number or select from
the Phonebook, then send.
Open editor for changes.
Delete selected message.
Delete all entries after
confirmation.
Outbox /
Not sent
Sent
§Menu§
The list of saved messages is shown.
§Options§ See below.
Inbox/outbox menu
Different functions are available depending on the context:
§Options§ Open menu.
Picture &
Sound
(p. 33)
Capacity
Status report
Mark as
unread
Save no. to
d
Move to
archive
Send with...
List pictures and sounds included in the message.
Display maximum and
available capacity.
(Outbox list only) Request
delivery confirmation for
L
messages sent.
Mark the message as
unread.
Copy a selected phone
number to the Phonebook.
Move message to the archive.
Change SMS profile before
sending (p. 66).
Archive
K
§Menu§
The list of the messages recorded in
the archive is shown. Different functions are available depending on the
context.
MessagesKArchive
Messages (SMS)
31
Archive menu
§Options§ Open menu.
View
Mark
Delete
Delete all
Rename
Sort
Attributes
Capacity
Read entry.
Highlight text to be edited.
Delete selected message.
Delete all saved messages
after confirmation.
Rename the entry.
Set sort criteria (alphabetical, time).
Display name, size and
date.
Display maximum and
available capacity for SMS
archive, special graphics
etc.
Compose a message
§Menu§
J
MessagesKNew SMS
K
Text input using "T9" (p. 73)
allows you to quickly create long SMS messages
using just a few key entries.
§Delete§ Press briefly to de-
lete letter by letter, hold
down to delete the entire
word.
A
Q
§OK§Confirm. The message is
§OK§Return to the message.
§Options§ Open menu and select
Display in the uppermost line:
™
abc/Abc/
T9
T9
SMSDisplay title.
1Number of the required SMS
739Number of characters still
Note
Insert pictures&sounds into text ........p. 33
If Message type, Validity period, Service
centre are requested ....................... p. 66
Transmit ring tones............................p. 41
You can change the current profile
(change settings, p. 66).
K
§Menu§
G
§Select§Press to activate. The cur-
Irrespective of this setting, you may
always decide before sending an
SMS which profile you want to use
(see text menu §Options§
with..., p. 32).
MessagesKSMS profiles
Select a profile.
rent profile is selected.
K
Send
34
Surf & fun
Internet (WAP)
Get the latest WAP information from
the Internet that is specifically adapted to the display options of your
phone. In addition, you can download games and applications to your
phone via WAP. Internet access may
require registration with the service
provider.
Internet access
Surf & funKInternet
K
§Menu§
The browser is activated as soon as
you call up the function. If necessary, set how the Internet access
should be made (see in the browser
menu Setup
The start menu appears, for
example:
G
§Select§Confirm.
You can now surf the Internet. For
further instructions see p. 83.
Start with..., p. 35).
K
Í
Start menu
1 Homepage
2 Bookmarks
Resume
3
Select required function.
L
É
Select
Start menu
Homepage
Bookmarks
Resume
Profiles
Inbox
Exit browser
The connection to the Internet provider's portal is
established (may be set/
preset by the service provider).
Display upto 10 URLs
stored in the phone for fast
access.
Call up recently visited
pages that are still in the
memory.
Set up to 5 access profiles
(p. 64).
Inbox for messages from
the WAP server.
Close the browser and
clear down the connection.
End connection
B
Hold down to end the
connection.
Surf & fun
35
Browser menu
If the browser is active, the menu
can be activated as follows:
A
or
E
Homepage
Bookmarks
Resume
Go to URL
Show URL
Reload
Disconnect
More ...
Exit browser
Press
Í
confirm.
The first WAP Internet
page that is displayed after connection is established (may have been
set/preset by the service
provider).
Display upto 10 URLs
stored in the phone for
fast access.
Call up recently visited
pages that are still in the
memory.
Enter URL for directly accessing an Internet address, e.g.
wap.my-siemens.com
Show the Internet address of the current page.
The page is reloaded.
End connection.
See below.
Close the browser and
clear down the connection.
More ...
Profiles
Reset
SetupFont size
Inbox
About
Openwave
Set up to 5 access profiles
(p. 64).
Delete the pages last visited (cache).
Protocol parameters
•Push
• Push can force online
• Timeout for unanswered
network requests
• GPRS linger time
Security
• Connection prompt
• Secure prompt
• Current certificate
• CA certificates
• Private Key PINs
• Encryption
Start with...
•Start menu
• Browser menu
• Homepage
• Resume
• Bookmarks
Inbox for messages from
the WAP server.
Display the browser
version.
36
Surf & fun
Note
Homepage: The control key (left/right) may
be assigned functions that are controlled
online from the homepage of your service
provider such as "link" or "menu". The contents of the option menus are also variable.
Displays:
ÍBrowser menu
É
Ê
Ë
ÌNo network
Enter special characters:
0
Offline
Online
GPRS Online
Press repeatedly for:
. , ? ! @ / & ~ + - :
WAP Profiles
Preparation of the phone for Internet
access depends on the service provider currently used:
• If the settings have already beenmade by your service provider you
may begin immediately.
• If access profiles have been assigned by your service provider select a profile and activate it.
• The access profile must be set
manually (p. 64).
WAP profiles may be barred from
manual setting by your service provider. If necessary, check with your
service provider for details.
Activate WAP Profiles
You can change the current profile
each time before accessing the Internet.
Setup
K
§Menu§
G
§Select§Press to activate. The cur-
Connectivity
K
WAP Profiles
K
Select a profile.
rent profile is selected.
Your Internet browser is licensed by:
Surf & fun
37
Games & more
Download games and other applications via WAP/HTTP (p. 82, p. 78).
You are advised about relevant applications on the Internet.
Downloading can start after a game/
application has been selected. You
can now use the application/play the
game.
Most applications include instructions.
Note
Java™ information ............................ p. 79
The ISP access for HTTP must be
configured to download applications p. 65
Activate an HTTP profile ................... p. 39
Activate a WAP profile ...................... p. 36
Sounds (ring tone) /
Silent alert on/off .............................. p. 58
Applications and games can be
found at:
wap.my-siemens.com
or on the Internet at:
www.my-siemens.com/city
Games and applications
Applications and links that are already stored in the phone are found
under:
Surf & funKGames & more
K
§Menu§
Application
¦
§
Game
MySiemens
É
OptionsSelect
Different functions are available
depending on which entry is
highlighted:
Carry out game/application offline
¦
§Select§ Executable application
§
§Select§ README only (p. 78);
É
§Internet§ The selected Internet
can be started immediately.
Load game/application online
Application still has to be
downloaded.
Go to a link (optional)
page is loaded.
38
Surf & fun
Receive information
If information which is required, say,
by an application that has already
been installed, is received via SMS
symbol appears in the display.
¦
the
By pressing the control key (on the
left), the relevant application is started and the information is processed.
Note
The following key control is used for many
games (virtual joystick):
13
2
5
8
6
9
4
7
Games & More menu
All functions required for managing
your files are found in this Options
menu:
§Options§ Open menu.
Delete
Rename
HTTP Profiles
Details
Sort
Delete selected application.
Rename selected applications.
Select access profile
(p. 65).
Show details of the application (name, version, size,
path, producer, date).
Set sort criteria (alphabetical, time).
More info
Reinstall
Capacity
Download further instructions via Internet (WAP), if
available.
Reinstall an application
(update).
Display available capacity
(in kByte) for sound manager, bitmap viewer, Games &
More and SMS archive.
HTTP Profiles
Preparation of the phone depends
on the service provider currently
used:
• If the settings have already beenmade by your service provider you
may begin immediately.
• If access profiles have been assigned by your service provider select a profile and activate it.
• The access profile must be set
manually (p. 65).
If necessary, check with your service
provider for details.
Surf & fun
39
Activate HTTP profile
§Menu§
G
§Select§Press to activate.
Setup
K
K
Connectivity
HTTP Profiles
K
Select a profile.
WAP can be used to download applications from
the Internet. Downloading or running applications
will not affect or change the software already installed on your Java™-enabled mobile phone.
Siemens excludes all warranty and liability claims
in respect of or in connection with any applications subsequently installed by the customer
and any software not included in the original delivery package. The same applies to functions enabled subseq uently at the custom er's instigation.
The purchaser bears sole risk for the loss of,
damage to, and any defects arising in this device
or the applications or software and for any direct
damage or consequential damage of whatever
nature resulting from the use of these applications or software. For technical reasons, such applications or software and subsequent enabling of
certain functions are lost in the event of the device being replaced/re-supplied and may be lost if
it is repaired. In these cases the purchaser will
need to download the application again or re-enable it. Siemens does not warranty or guarantee or
accept any liability for the customer's ability to
download or enable applications again or to do so
free of charge.
Bitmap viewer
Set animations, logos and screensaver as required in your phone.
Start bitmap viewer
You will find animations/pictures
and links stored in the phone under:
K
§Menu§
G
Different functions are available
depending on which entry is highlighted:
Own animations/Own pictures
G
§Select§Press.
G
§Dwnload§ The animation/picture is
URL (optional)
Go to the link and surf online
§Internet§ The selected Internet
Screensaver/Logo
See picture menu §Options§ p. 40.
Surf & funKBitmap viewer
Select storage location or
link:
Own animations
Own pictures
URL
Select folder.
Select animation/picture.
displayed.
page is loaded.
40
Surf & fun
Receive pictures
_g
01.10.200212:30
—
If a picture (graphic/screensaver) has
been received via SMS the
bol appears in the display. By pressing the control key (on the left), the
bitmap viewer is started and the picture is displayed.
When downloading via WAP, the bitmap viewer opens automatically. For
Internet addresses see p. 13.
Display available capacity
(in kByte) for sound manager, bitmap viewer, Games &
More and SMS archive.
Send pictures via SMS
Open bitmap viewer and activate the
required picture then:
§Options§ Open menu.
§Send§ Enter recipient or use
Phonebook
§OK§Confirm.
·.
Picture menu
§Options§ Open menu.
Send
Load
Discard
Delete
As screen-
saver
Use as
logo
Send picture via SMS.
Load new picture to the bitmap viewer.
Delete current graphic from
the buffer.
Delete selected picture.
Use current graphic as
screensaver.
Use current graphic as (provider) logo (see also p. 57).
Surf & fun
41
Sound manager
You can use the sound manager to
record, play and manage sounds,
ring tones and melodies (also melodies for several voices). If you wish,
you can also download further ring
tones from the Internet if you have
stored URLs (links).
K
§Menu§
A list of the stored ring tones/melodies is displayed:
%
$
i
É
Surf & funKSound manager
Ring tones/melodies that
you have recorded yourself or that have been
received via SMS or downloaded by WAP/HTTP.
Ring tones/melodies that
you have stored from the
content of an SMS. You
can re-send these via
SMS/EMS.
Unmodifiable ring tones
stored in the phone.
URL (optional): Surf online to download ring
tones/melodies.
§Internet§ The selected
Internet page is loaded.
É Load via HTTP (optional):
§Internet§ Enter Internet
address (URL). You can
start downloading with
§OK§.
Individual recording
You can use the microphone built into the telephone to record tones,
melodies or sounds. These recordings can then be used as ring tones.
<New sound>
My Sound 1
%
My Sound 2
%
Select
G
§Record§Press.
Select <New sound>.
Please start
°
recording
InfoRecord
Recording starts. The
maximum time available
and recording duration
are displayed.
0:20 / 2:45 min
Stop
42
Surf & fun
§Stop§End recording.
§Repeat§ Start new record-
ing.
§Save§Enter the name under
§OK§ Confirm.
Note
If there is a call during the recording, the recording is stored under a standard name
and can be renamed later.
which the recording
should be stored.
Playback
<New sound>
My Sound 1
%
My Sound 2
%
PlayOptions
G
§Play§The selected sound is
§Stop§End playback.
Note
The melody is converted into a device-specific format only when it is played for the first time. A short delay may occur.
Select recording.
played continuously.
Sound manager menu
Different functions are available depending on which entry is highlighted.
§Options§ Open menu.
Play
Ring tone
for...
Volume
Delete
Rename
Attributes
Capacity
Play sound.
Assign a function/an anniversary to the ring tone.
Set the playback volume.
Delete sound.
Rename sound.
Display name, size and recording time.
Display available capacity
(in kByte) for sound manager, bitmap viewer,
Games & More and SMS
archive.
Surf & fun
43
Receive melody
_g
01.10.200212:30
–
If a melody has been received via
SMS a note
Press the control key (on the left), to
start the sound manager.
When downloading via WAP/HTTP,
the sound manager automatically
opens as soon as the process is comleted (Internet addresses, p. 13;
WAP-Profil, p. 36; HTTP profile,
p. 38).
–
appears in the display.
Menu
Ring tone for...
You can choose a special melody for
the call types/functions listed below.
Surf & funKSound manager
K
§Menu§
§Options§ Open menu.
G
G
§Select§Confirm.
G
§Select§Confirm.
Note
For Other calls, a special ring tone can be
assigned to each of two phone numbers,
depending on your network provider.
Select Klingelton für .....
Select call type/function:
d Calls
Group calls
Other calls
Alarms
Messages
Cell broadcast
Choose a melody from
the list.
44
Organiser
Alarm clock
K
§Menu§
Use this function to set a single time
for the alarm call. The alarm sounds
even when the phone is switched
off.
§On§ / §Off§ Activate/deactivate the
Setting
§Edit§Display the set time and
G
§Edit§Set the days for the alarm
§OK§Confirm settings.
OrganiserKAlarm clock
Mo Tu We Th Fr Sa Su
alarm.
dates for the alarm calls.
Set the time for the alarm
call (hh:mm).
Navigate to the days.
call.
Note
y
y
z
Alarm clock switched on.
Alarm clock active (display in
standby mode).
Alarm clock switched off.
z 07:30
EditOn
Alarms
K
§Menu§
New appointment
G
G
Type:
u
v
w
Description: A short description can
be entered.
Reoccurrence: Select period for
repeating the alarm.
Date: Enter start date.
Time: Enter start time.
§Save§Store the appointment.
OrganiserKAlarms
<New entry>
15.05.2002 11:30 u
16.05.2002 12:00
ViewOptions
Select <New entry>.
Make the entries field by
field.
Memo. A text with up to
19 letters may be added.
Call. Enter phone number.
Shown with alarm.
Meeting.
Note
§Options§ See list menu, p. 45.
If an alarm is missed it appears in the list of
missed appointments (p. 47).
Organiser
45
Greetings
K
§Menu§
Your phone will remind you of special events so you do not forget them
any more.
New event
G
G
Type:
{
|
t
Name: Enter a short description.
Date: Enter start date.
Time: Enter start time.
OrganiserKGreetings
Select <New entry>.
Make the entries field by
field.
Birthday
Anniversary
Special event
Note
·
§Options§ See list menu.
Greetings are automatically set to recur annually.
If an alarm is missed it appears in the list of
missed appointments (p. 47).
50 entries for appointments and greetings
and 10 entries for notes can be made in the
organiser.
Copy name from the Phonebook.
List menu
§Options§ Open menu.
View
Activate/
Deactivate
Change
New entry
Delete
Delete all
Send SMS...
Capacity
Display entry.
Activate or deactivate
alarm (only if the alarm has
not elapsed yet or is a
greeting).
Open appointment for
editing.
Enter new appointment.
Delete entry.
Delete all appointments after confirmation.
as entry: Send alarm to
recipient.
as text: Send alarm as
SMS message.
Display number of entries.
46
Organiser
Reminder
An alarm will remind you of the
event twice:
• 24 hours before the date of the
event as entered.
• On the day of the event with the
following options:
§Options§ Open menu
SMS
Call
Pause
Off
If an alarm is missed (e.g. because
you are making a phone call) it appears in the list of missed appointments (p. 47) with the same options
as described above.
Note
An alarm sounds even when the phone is
switched off (the phone does not switch to
standby mode). To deactivate it press
any key.
Deactivate all alarms .........................p. 53
Set time .............................................p. 63
Alarm activated
i
§Pause§Repeats the alarm after
Send an SMS with standard (changeable) text.
Dial the phone number.
Repeat the alarm after
5 minutes.
Stop the alarm.
j
Alarm deactivated.
5minutes.
Notes
K
Save
Text input
(p. 73)
Line feed
Clear text
Send
OrganiserKNotes
Select <New entry>.
Enter the text, up to
50 letters (with T9 support, p. 73).
Store the entry.
T9 preferred: Activate/
deactivate T9 input.
Input language: Se lect the
language in which the text
is to be composed.
Enter line break.
Delete the note.
Send entry as text of an
SMS message.
§Menu§
Use your phone as a scratchpad.
New entry
G
J
§Options§ Open menu.
SaveStore the entry.
Text menu
§Options§ Open menu.
Organiser
47
Display entry
G
§View§Open note.
Select entry
Notes menu
§Options§ Open menu.
View
Change
New entry
Delete
Delete all
Confidential
Send
Capacity
Note
We recommend that you do not store any
passwords (PIN, TAN etc.) as notes.
Display entry.
Display the entry for
changes.
Enter a new note.
Delete entry.
Delete all notes after
confirmation.
Protect notes entry with
phone code (p. 11).
Send entry as text of an
SMS message.
Display number of entries.
Missed alarms
K
§Menu§
Events with alarm which you have
missed are listed and can be
displayed.
OrganiserKMissed alarms
Note
50 entries for appointments and greetings
and 10 entries for notes can be made in the
organiser.
Voice command
Phone functions can be started by
simply saying a name. Up to 20 voice
recordings for voice dialling (p. 23)
or voice commands can be stored in
your phone (not on the SIM card!).
Organiser
K
§Menu§
K
Voice command
A list of the functions available is
displayed.
G
§Record§Press.
§Yes§Confirm selected
§Start§Start recording.
A short signal sounds. Now say a
command corresponding to the
function and repeat it when prompt-
ed by a signal tone and a screen display. A beep confirms the recording
that will be saved automatically.
Select a function.
function.
48
Organiser
Apply
E
When you now say the command,
the function will be carried out.
Note
Noisy environments may affect the
recognisability.
Hold down. Start voice
control (in standby
mode).
Voice command menu
G
§Options§
Playing
New record
Delete
Delete all
Select the required entry
with a voice command.
Open menu.
Play back the recording belonging to the entry.
Redo the recording for an
entry.
Delete entry.
Delete all entries after
confirmation.
Calculator
K
§Menu§
J
Or
§. =+ - * /§Press control key repeat-
J
#
OrganiserKCalculator
Enter number
(up to 8 digits).
Function "+" or "-".
edly on the right.
Repeat procedure with
other numbers.
Result is displayed.
Calculator functions
§. =+ - * /§Press control key repeatedly
.
=Result.
+
*
/
± Toggle between "+" and "-".
%Convert to percentage.
Ï
Ð
eExponent (maximum of two
Special keys:
*
0
on the right:
Set decimal point.
Addition.
Subtraction.
Multiplication.
Division.
Save the number displayed.
Retrieve the number saved.
digits).
Set decimal point.
Add (hold down).
Organiser
49
Currency conv.
K
§Menu§
You may calculate the exchange
rates between three different currencies.
Organiser
Currency conv.
K
Enter the currency
If no currency has been entered yet,
press §OK§ for the first input.
Otherwise:
§Options§
New entry Select, then if:
§List§Press and select 1st Euro
§Select§Confirm.
Open menu
Only Euro currencies:
currency.
FSelect second field.
§List§Press and select 2nd Euro
§Select§Confirm.
§OK§Confirm.
J
§OK§Confirm.
J
currency.
Euro currencies and/or other
currencies:
Enter symbols for the
currencies.
Enter exchange rates.
Store with §Options
and §OK§.
Calculator functions
§§. =§§Press control key repeatedly
.
=Calculator result.
Ð
on the right:
Set decimal point.
Retrieve a saved numbe r from
the calculator.
Convert
Any combination of calculations
may be made between the entered
currencies.
G
§Select§Confirm.
J
#
Select a combination of
currencies from the list.
Enter amount
(up to 12 digits).
The result is displayed.
§Repeat§ Repeat conversion
with other data.
Calculator menu
§Options§
Start
New entry
Change
Delete
Delete all
Open menu.
Enter the value to be
calculated.
Enter two new currencies.
Change the two currencies.
Delete the two currencies.
Delete all currency
combinations.
50
Voice message/Mailbox
Most service providers offer you an
external answering service. In this
mailbox, a caller may leave a voice
message for you
• if your phone is switched off or
not ready to receive,
• if you do not want to answer calls,
• if you are making a phone call
(and if Call waiting is not active,
p. 60).
If the voice mail service is not part of
your service provider's user package,
you will need to register for it and
the settings must be made manually.
The procedure described below may
vary slightly depending on the service provider.
Settings
Your service provider supplies you
with two phone numbers:
Mailbox number
You call this phone number to listen
to the voice mails left for you. To set
it up:
K
§Menu§
Select phone number from Phonebook or dial/change it and confirm
with §OK§.
Call divert
Calls are diverted to this phone
number. To set it up:
MessagesKVoice message
L
K
§Menu§
J
§OK§Registration at the net-
For further information on call divert, see p. 60.
Play back messages
A new voice mail can be announced
as follows:
Or
…
Or
You receive a call with an automatic
announcement.
Call your mailbox and play the message(s) back.
1
Outside your home network, you
may need to dial a different mailbox
number and enter a password to access your mailbox.
Divert
e.g. UnansweredKSet
K
Dial the number of the
mailbox.
work will be confirmed
after a few seconds.
\
Icon including beep.
A text message announces a new voice mail.
Hold down (if necessary
enter mailbox number
once only).
Confirm with §OK§ or §Mail-
box§ depending on your
service provider.
L
CB services
51
mation services (info channels). If reception is activated, you receive
messages on the activated topics in
your "Topic list".
MessagesKCell broadcast
K
§Menu§
Reception
You can activate and deactivate the
CB service. If the CB service is activated, the standby time of the phone
will be reduced.
L
Read new CB
All unread CB messages are
displayed.
Topic list
You can add an unrestricted number
of topics to this personal list from the
topic index (Topic index). You can
preset 10 entries with their channel
numbers (ID) and, if applicable, with
their names.
New topic
Select New topic.
• If no topic index (Topic index) is
available enter a topic with its
channel number and confirm
with §OK§.
• If the topic index has already been
transmitted select a topic and confirm with §OK§.
Selection from a list
§Options§ Open list menu.
If a topic is selected in the list you
can have a look at it, activate, deactivate, edit or delete it.
Auto display
CB messages are displayed in standby mode, longer messages are automatically scrolled. This display can
be activated/deactivated for all or
only new messages.
To switch to "full page view":
#
, then press §View CB§.
Topic index
The list of topics is displayed for you
to choose from. If none are displayed, you must enter the channel
numbers (ID) manually (Topic list).
Please contact your service provider
for details.
L
CB languages
You may define whether you want to
receive Cell Broadcast messages in a
specific language only or in all languages.
Displays
,
o
…
ƒ
Topic activated/deactivated.
p
New messages received on
the topic.
Messages already read.
52
Profiles
are made with one function.
• Five profiles are standard with default settings, they can be
changed however:
Normal envi.
Quiet environ.
Noisy environ.
Car Kit
Headset
• You can set two personal profiles
(<Empty>).
• The special profile Aircraft mode is
fixed and cannot be changed
(p. 53).
If the phone is used by several people, they can each activate their own
settings by selecting their individual
profile.
Activate
Profiles
K
§Menu§
G
§Select§Activate the profile.
Select default profile or
personal profile.
Normal envi.
¾
Quiet environ.
½
Noisy environ.
¾
OptionsSelect
Active profile.
½
Setup
Edit a default profile or create a new
personal profile:
When you have finished setting a
function, you return to the profile
menu where you can change a further setting.
Select profile.
Profiles
53
Profile menu
§Options§ Open menu.
Change settings
Copy from
Rename
Change profile
settings.
Copy settings from
another profile.
Rename personal
profile.
Car Kit
If an original Siemens Car Kit is used
(p. 91) the profile is activated automatically as soon as the phone is inserted into the cradle (p. 72).
Headset
If an original Siemens headset is
used (p. 90), the profile is activated
automatically as soon as the headset
is plugged in (p. 72).
Aircraft mode
All alarms (appointments, alarm
clock) are deactivated. It is not possi-ble to modify this profile. When you select this profile, the phone is
switched off after a prompt.
Activate
G
§Select§Activate the profile.
Normal operation
The next time you switch on the
phone and return to normal operation the default profile Normal envi.
will be activated.
Scroll to Aircraft mode.
A security prompt mu st be
confirmed.
The phone switches itself
off automatically.
54
K
My menu
Create your own menu with frequently used functions, phone numbers or WAP pages.
The list of 10 entries available is preset. However you can change it according to your wishes.
My menu
Activate
G
§Select§Press.
Or
A
Select the required entry.
If the selected entry is a
phone number, you can
also call it with the
Call key.
Change settings
You can replace any preset entry (1-
10) with another entry from the selection list of My menu.
G
§Options§ Press.
Change settings
§Set§Press.
G
§Set§Press.
If you have selected a phone number
or a WAP favourite as a new entry,
the relevant application opens for
you to choose from.
Select the required entry.
Select.
Select the new entry in the
selection list.
Reset all
After confirmation and after entering the phone code, the default entries are set.
Fast access key
55
You can program an important
phone number or a function on the
control key (on the left) and the
number keys 2 to 9 (speed dialling
numbers). The phone number can
then be dialled or the function can
be started at the touch of a button.
Note
The control key (on the left) may already
have been preset by the service provider
(e.g. access to "
not be possible to modify this key assignment.
The soft key may sometimes be replaced
automatically by
message for example.
Available key assignments:
Internet (WAP) ..................................p. 34
Games & more .................................. p. 37
Alarms............................................... p. 44
Greetings .......................................... p. 45
Notes................................................. p. 46
Screensaver...................................... p. 57
} SIM-services "). It may
]/\
to access a new
Control key (on the left)
A function/number can be programmed on the control key (on the
left) for fast access.
Change
_g
Service provider
01.10.200223:45
InternetMenu
§Internet§ Pressbriefly.
§Edit§Scroll to the application in
the list.
• Assign a new application (e.g. New
SMS) to the control key (on the
left).
• Special case Phone number. Select a
name (e.g. "Carol") from the
Phonebook for assignment to th e
control key (on the left).
§Select§Confirm setting.
Apply
The setting "Carol" is used here only
as an example.
§Carol§Hold down.
56
Fast access key
Speed dialling keys
Number keys 2 to 9 can be used as
speed dialling numbers for fast access. For available key assignments
see p. 55. Number key 1 is reserved
for the mailbox number (p. 50).
Change
In standby mode:
J
§Set§Press.
Or
§New SMS§ Press briefly (if set with
§Edit§Scroll to the application in
§Select§Confirm setting.
Press number key (2 - 9).
If the key is not assigned:
New SMS for example).
the list.
Special case Phone num-
ber. Pick out a name for
assignment to the key
from the Phonebook.
Special case Bookmarks.
Select a URL for assignment of the key from the
bookmark list.
Apply
Select a stored phone number or
start a stored application (e.g. New
SMS).
In standby mode e.g.:
3
The assignment of the number key 3
is displayed above the control key
(on the right) e.g.:
§New SMS§ Hold down.
Or simply
3
Press.
Hold down.
Setup
57
Display
K
§Menu§
Language
Set the language of the display text.
When "automatic" is set, the language of your home service provider
is us ed. If a lang ua ge t ha t yo u d o n ot
understand happens to be set, the
phone can be reset to the language
of your home service provider with
the following input:
*
Text input
T9 preferred
Activate/deactivate intelligent text
entry.
Input language
Select language in which the message is to be composed. Languages
with T9 support are marked by the
T9 symbol.
Screensaver
The screensaver shows a picture on
the display as soon as a period that
can be set by you has elapsed. The
function is ended by an incoming
call or by pressing any key. You can
also receive and store screensavers
via SMS/WAP.
SetupKDisplay
K
# 0 0 0 0 #
Select a function
A
Screensaver menu.
Enable
Style
Animation
Preview
Timeout
Security
Activate screensaver.
Analog clock or Bitmap/
Animation.
Assign a Bitmap/Animati-
on to the screensaver. The
screensaver is activated
automatically.
Display the screensaver.
Set period after which the
screensaver starts.
Phone code protected termination of the screensaver.
Logo (provider logo)
Select a picture.
Bitmap style
You can select between two animations which are shown for example
when entering a PIN.
Own greeting
Your own greeting is displayed instead of an animation when you
switch on the phone.
§Edit§On/Off.
J
§OK§Confirm change.
Delete old message and
create new message.
58
Setup
Big letters
You can choose between two font
sizes for the display.
Illumination
Can be switched on and off
(switching it off increases the
standby time).
Contrast
You can set the display contrast.
G
Press control key at the
top/at the bottom repeatedly to set the display
contrast.
Audio
K
§Menu§
You can set the tones that sound in
specific situations to suit your particular tastes.
Ringer setting
On/OffActivate/deactivate all
BeepReduce ringer to a short
SetupKAudio
Select a function.
K
ring tones.
beep.
Note
k
Display: Beep.
jDisplay: Ringer off.
Switch off ringer ................................ p. 82
Silent alert
To avoid being disturbed by the ringer, you can activate the silent alert
instead. The silent alert can also be
activated in addition to the ringer
(e.g. in a noisy environment). This
function is deactivated when the
battery is being charged.
Volume
You can set the volume separately
for the following call types/functions.
G
§Select§Press.
G
§Select§Confirm.
Note
If two independent phone numbers are
registered for your phone, you can set different volumes for them (p. 70).
Select:
d Calls
Group calls
Other calls
Alarms
Messages
Cell broadcast
Set volume.
Displays rising volume.
Setup
59
Ring tones
You can assign special ring tones to
the call types/functions listed below .
G
§Select§Press.
G
§Select§Confirm.
Note
Sound manager ................................ p. 41
You can receive individual ring tones via
SMS (p. 29) or download them via WAP
and HTTP (p. 41).
Select:
d Calls
Group calls
Other calls
Alarms
Messages
Cell broadcast
Choose ring tone.
Call screening
Only calls from numbers that are in
the Phonebook or in a predefined
group are signalled audibly or by silent alert. Other calls are only displayed.
If you do not accept these calls, they
are diverted to your mailbox
(ifset,p.50).
Note
l
Display:
when call screening is
activated.
L
Key tones
You can set the acoustic key tone:
Click or Tone or Silent
Minute beep
During the call, you hear a beep after
every minute as a reminder of the
time elapsed.
Info tones
Set service and alarm tones:
On/OffActivate/deactivate alarm
Extended If activated, service tones
tones.
are reproduced for an
extended range of
functions.
60
Setup
Keys
K
§Menu§
Any to answer
Use any key to accept incoming calls
(except
Auto key lock
If Auto key lock is activated, the keypad is locked automatically if no key
has been pressed for one minute in
standby mode. This prevents the
phone from being used accidentally.
However you can still be called and
you can still make an emergency
call.
The keypad can also be directly
locked and unlocked as follows.
#
Key tones
You can set the type of acoustic key
tone:
Click or Tone or Silent
SetupK Keys
Select a function.
K
).
B
Hold down
.
Device
K
§Menu§
Call waiting
If you are registered for this service,
you can check whether it is set and
you can activate/deactivate it
(p. 16).
Hide ID
When you make a call, your phone
number can be displayed on the recipient's display (depending on the
service providers).
To suppress this display, you can activate the "Hide ID" mode for the
next call or for all subsequent calls.
You may need to register separately
with your service provider for these
functions.
Divert
You can set the conditions for which
calls are diverted to your mailbox or
other numbers.
Set divert:
The most common condition for
divert is:
SetupKDevice
Select a function.
K
L
L
Setup
61
Unanswered calls
G
§Select§Press.
SetSelect.
J
or
·
§OK§Confirm. After a short
All calls
All calls are diverted.
n
Select Unanswered.
(covers the Not reachable,
No reply, Busy conditions,
see right)
Enter the phone number
to which the caller will
be diverted (if not done
already)
select this phone number
from the Phonebook or
via §Mailbox§.
pause, the setting is confirmed by the network.
Symbol in the top line of
the display in standby
mode.
L
L
Spec. divert
Not reachable
Divert if the phone is switched off or
out of range.
No reply
A call is only diverted after a delay
(depends on the network). The
period can be set to a maximum of
30 seconds in 5 second intervals.
Busy
Divert if a call is in progress. If Call
waiting is activated (p. 16), you will
hear the call waiting tone during
acall.
Receiving fax
Fax calls are diverted to a
number with a fax connection.
Receiving data
Data calls are diverted to a
phone number with a PC connection.
Status check
You can check the current divert status for all conditions.
L
L
L
62
Setup
After a short pause, the current situation is transmitted by the network
and displayed.
p
o
s
Clear all
All set diversions are cleared.
Note
Note that the divert is stored in the network
and not in the phone (when the SIM card is
changed for example).
Check condition or delete it
First select the condition.
§Select§Press.
Check status Select
or
Delete Select.
Reactivate divert
The last divert has been stored. Proceed as
with "Set divert". The stored phone number
is displayed. Confirm number.
Edit phone number
Proceed as with "Set divert". When the
stored number is displayed:
§Delete§Press. The phone number is
Enter new number and confirm.
Condition set.
Not set.
Display, if status is un-
known (e.g. on a new
SIM card).
L
deleted.
K
§Menu§
SetupKDevice
Select a function.
K
Fact. settings
The phone is reset to the default values (factory setting) (does not apply
to SIM card and network settings).
Alternative input in standby mode:
# 9 9 9 9 #
*
A
Phone identity
The phone ID (IMEI) is displayed. Th is
information may be useful for customer service.
Alternatively enter in standby mode:
# 0 6 #
*
Setup
63
Clock
K
§Menu§
Time/date
The clock must be set correctly once
at start-up.
§Edit§Press.
J
Format date
DD.MM.YYYY or MM/DD/YYYY
Auto display
The time display in standby mode
can be switched on and off.
Buddhist year
Switch to the Buddhistic calendar
(not available in all models).
SetupKClock
Select a function.
K
First enter the date (day/
month/year), then the
time (24 hours, including
seconds).
Note
If the battery is removed for more than
about 30 seconds, the clock must be reset.
Setting of the date format to:
DD: Day (2-digit)
MM:Month (2-digit)
YYYY: Year (4 digit)
Auto off
The phone switches off each day at
the set time.
Activate:
§Time§Press.
J
§OK§Confirm.
Deactivate:
§Manual§Press.
§OK§Confirm.
Auto timezone
If this feature is activated, you
will be asked if you want to change
the time whenever you cross into a
new time zone (if this feature is supported by the network with which
you are registering).
Enter time (24 h clock).
L
64
Setup
Connectivity
K
§Menu§
GPRS
(General Packet Radio S ervice)
GPRS is a new method for transmit-
ting data faster in the mobile network. If you use GPRS, you can be
connected to the Internet permanently if the network capacities
suffice.
Some service providers do not yet
support this service.
dial-up via GPRS (CHAP
Challenge Authentication
Procedure) or deactivate
it (PAP Personal Authentication Procedure).
L
WAP profile settings
Up to 5 WAP profiles can be set (may
be barred by the service provider).
The entries may vary depending on
your service provider. To set a new
profile:
G
§Edit§Open menu.
Select profile.
GSelect profile range and
make your settings/entries field by field.
§Edit§The entry card is dis-
If necessary, check with your service
provider for details:
Profile
name:
WAP Parameters
L
played.
Enter/change name.
IP address: * Enter IP
address.
Port: * Enter port number.
Homepage: Enter homepage
(p. 3 4), if not set by the service
provider.
Linger time: Enter time in
seconds after which a connection should be ended if no input or data exchange takes
place.
*) depends on the service
provider, if necessary enter
2nd IP address and 2nd
port.
Setup
65
CSD settings
(Circuit
Switched
Data)
GPRS
settings
(General
Packet
Radio
Service)
§Save§The settings are stored
Dial-up no.: Enter ISP
number.
Call type: Select ISDN or
Analogue.
Login name: Enter login
name.
Password: Enter password
(shown as a series of
asterisks).
GPRS deactivated: Yes/No.
APN: Enter the address of
your service provider.
Login name: Enter login
name.
Password: Enter password
(shown as a series of
asterisks)
and the profile list is
shown.
Activate the set WAP
profile (p. 36).
Set HTTP profiles
Up to 5 profiles can be defined (may
have been barred by the service provider). The settings have normally
been carried out by the service provider in advance. To set a new profile:
GSelect profile.
§Options§ Open menu.
Change settings
Select and confirm.
G
§Edit§The entry card is
If necessary, check with your service
provider for details:
HTTP parameters
CSD settings
(Circuit
Switched
Data)
GPRS
settings
(General
Packet
Radio
Service)
§Save§The settings are stored
Select profile range and
make your settings/entries field by field.
displayed.
Linger time: Enter time in sec-
onds after which a connection
should be terminated if no input or data exchange takes
place.
Dial-up no.: Enter ISP
number.
Call type: Select ISDN or An-
alogue.
Login name: Enter login
name.
Password: Enter password
(shown as a series of asterisks).
APN: Enter the address of
your service provider.
Login name: Enter login
name.
Password: Enter password
(shown as a series of asterisks).
DNS1/DNS 2: (optional)
and the profile list is
shown.
Activate the set HTTP profile (p. 39).
66
Setup
Set SMS profiles
§Menu§
A maximum of 5 SMS profiles can be
set. They define the transmission
characteristics for an SMS. The presetting depends on the SIM card inserted.
To set a new profile:
SetupKConnectivity
K
K
Select a function.
GSelect profile.
§Options§ Open menu.
Change settings Select and confirm.
Service
centre
Recipient
Message
type
Enter or change the phone
numbers of the service centre
as supplied by the service provider.
Enter the standard recipient
for this transmission profile or
select from the Phonebook.
Manual
The message type is requested for each message.
Standard text
Normal SMS message.
Fax
Transmission via SMS.
E-mail
Transmission via SMS.
New
You may need to obtain the
required code number from
your service provider.
Validity
period
Status
report
L
Direct
L
reply
SMS via
GPRS
L
Select the period in which the
service centre tries to deliver
the message:
*) Maximum period that the
service provider permits.
You are given confirmation of
the successful or unsuccessful delivery of a sent message.
This service may be subje ct to
a charge.
The reply to your message is
handled via your service centre when Direct Answer is
activated (for information
please contact your service
provider).
When this function is activated, SMS messages are automatically sent via GPRS
(if available).
Requirement: GPRS is activated (p. 64). Ensure that
your service provider offers
this function.
Setup
67
Fax/data mode using a PC
§Menu§
With the phone and a connected PC,
you can transmit and receive faxes
and data. Appropriate software for
data communication/fax communication must be available on your PC
and there must be a connection to
the phone.
Fax and data services must be enabled by the service provider. Different networks support different types
of fax/data reception; please contact
your service provider for details.
§Edit§Set the required mode.
Rec fax/data
Your service provider can give
you a number for telephoning and a
fax/data number.
The call is signalled by a special ringer a nd the type of call (fax or data) is
displayed.
Now start the communication program in your PC to receive the fax/
data.
SetupKConnectivity
K
K
Fax/data mod.
Select a function.
K
L
Send vce/fax
Set this function on the phone before
transmission so that you can switch
from voice mode to fax mode.
While the connection is being setup,
the following function is available
for two seconds:
§Voice/fx§ Switch to Send vce/fax
Voice/fax rec
(Only if a special fax or data number
is not available).
Start the required communication
program in your PC and switch on
the function at the phone during the
call (the PC accepts the connection).
End transmission
End transmission with PC software
and/or press
mode; you may now send
a fax.
.
B
L
68
Setup
Security
K
§Menu§
The phone and SIM card are protected against misuse by several security
codes.
Codes
PIN control, Change PIN, Change PIN2,
ChangePhonecode, see p. 11.
Babysitter
(Phone code protected)
Only one phone number can be di-
alled. Hold down control key on the
right (p. 18).
Allow only
(PIN 2/phone code protected)
Dialling is restricted to the numbers
in the Phonebook, new entries are
not possible. If only area codes are
entered, the relevant phone numbers can be added to these manually
before dialling.
Depending on whether the Phonebook is stored on the SIM card or in
the phone, the PIN 2 or phone code
is requested before changes can be
made.
SetupKSecurity
Select a function.
K
d
L
Only
‚
(PIN 2 protected)
The dialling options are restricted to
SIM protected numbers in the
Phonebook. If only area codes are
entered, the relevant phone numbers can be added to these manually
before dialling.
Last 10 only
(Phone code protected)
Calls are limited to the call list of "di-
alled numbers" (p. 27). This list can
be filled with phone numbers specifically for this purpose:
First delete the call list, then create
"new entries" by dialling phone numbers and cancelling before the connection is established.
This SIM only
(Phone code protected)
Your phone is prevented from being
used with a different SIM card.
L
L
L
Setup
69
Barrings
Barring restricts the use of your SIM
card (not supported by all service
providers). You need a 4 digit password which your service provider
will give you. You may need to be
registered separately for each
barring.
All outgoing
All outgoing calls except emergency
number 112 and 999 are barred.
Outgo internat
Only national calls can be made.
Out.int.x home
International calls are not permitted.
However you can make calls to your
home country when abroad.
All incoming
The phone is barred for all incoming
calls (the forwarding of all calls to
the mailbox offers a similar effect).
When roaming
You do not receive calls when you
are outside your home network. This
means that no charges are incurred
for incoming calls.
L
Status check
The following information can be
displayed after a status check:
p
o
s
Clear all
All barrings are cleared. A password
which the service provider will give
you is necessary for this function.
Barring set.
Barring not set.
Status unknown
(e.g. new SIM card).
70
Setup
Network
K
§Menu§
Line
This function is only displayed if it is
supported by the service provider.
Two independent phone numbers
must be registered on the phone.
Select
Select the currently used phone
number.
‘
Lock line
(Phone code protected)
You may limit usage to one phone
number.
Network info
The list of GSM networks currently
available is displayed.
²
SetupKNetwork
Select a function.
K
L
Display the current phone
number.
Note
Settings for phone numbers.............. p. 82
Indicates forbidden service providers (depending
on SIM card).
Choose network
The network search is restarted. This
is useful if you are not on your home
network or want to register on a dif-ferent network. The network info list
is rebuilt when Auto network is set.
Auto network
Activate/deactivate, see also "Choose
network" above. If "Automatic net-
work" is activated, the next network
is dialled in the order of your "preferred networks". Otherwise a different network can be selected manually from the list of the available GSM
networks.
Net operator
A list of all known GSM network providers worldwide is displayed with
the current codes.
Pref. network
The service providers you prefer
when you leave your home network
can be entered here (e.g. if there are
several networks that differ in price).
Note
If the field strength of the preferred network
is not strong enough when you switch the
phone on, the mobile phone may register
with a different network. This can change
when the telepho ne is next switched on or if
you manually select another network.
Setup
71
Your service provider is displayed:
§List§Display list of preferred
Create new entry:
• Select empty line, press §Entry§,
Change/delete entry:
• Select entry, press §Change§, then
Band selection
Select either GSM 900 or GSM 1800.
networks.
then select another entry from the
list of service providers and confirm.
select a different entry from the
list of service providers and confirm it or press §Clear§.
L
Fast search
When this function is active, network reconnection is speeded up
(standby time is reduced).
User group
§Menu§
If offered by the service provider,
this service enables groups to be
formed. These have access for example to internal (company) information or special tariffs apply to them.
Check with your service provider for
details.
Active
Activate/deactivate function. "User
group" must be deactivated for normal phone use (phone code, p. 11).
Select group
You may select or add groups other
than the preferred groups (see below). The service provider supplies
you with code numbers for the
groups.
Outgo. access
In addition to network control for a
user group, it is possible to set
whether outgoing calls outside the
group are permitted. If the function
is deactivated, only calls within the
group are permitted.
Preferred grp
If activated, only calls within this
standard user group can be made
(depending on the network configuration).
SetupKNetwork
K
K
Select a function.
L
72
Setup
Accessories
K
§Menu§
Car Kit
If an original Siemens Car Kit is used
(p. 91) the profile is activated automatically as soon as the phone is inserted into the cradle.
User-definable settings
Auto answer
(factory default: off)
Calls are accepted automatically after a few seconds.
±
®
Auto off
(factory default: 2 hours)
The phone is powered by the car's
power supply. The time between
switching off the ignition and deactivation of the phone can be adjusted.
SetupKAccessories
Select a function.
K
Indication on the display.
Switch between the
phone and Car Kit Portable during a call.
Automatic settings:
• Permanent illumination:
switched on.
• Auto key lock: switched off.
• Charging the phone battery.
• Automatic activation of the Car Kit
profile (p. 53) when the phone is
inserted.
Headset
If an original Siemens Headset is
used (p. 90) the profile is automatically activated when the headset is
plugged in.
User-definable settings
Auto answer
(factory default: off)
Calls are accepted automatically after a few seconds (except where the
ringer is switched off or set to beep).
You should therefore be wearing the
headset.
Automatic setting
Accept call with the Call key or PTT
key (Push To Talk) when the key lock
is activated.
Auto answer
If you fail to notice an incoming call there is
a risk that it may be overheard by others.
Text entry with "T9"
73
"T9" deduces the correct word from
the individual key entries by making
comparisons with an extensive dictionary.
Setup
K
§Menu§
SetupKDisplayKText input
Activate, deactivate T9
T9 preferred Select.
p
§Select§ Confirm.
Activate T9.
™
on the display indicates for example whether lowercase/uppercase is
active.
Select input language
Select the language in which you
want to compose your message.
Input language Select.
§Select§ Confirm, the new lan-
guage is set.
Languages with T9 sup-
port are marked by the
T9 symbol.
Create a word using T9
Since the display changes as you
proceed it is best if you finish a word
without looking at the display.
You simply press the keys where the
relevant letter is located once only.
For "hotel", for example:
Press briefly for
#
T9
Abc then
4 6 8 3 5
1
Do not use special characters such as
Ä but write the standard character,
e.g. A, T9 will do the rest for you.
Note
0
F
#
*
T9 dictionaries for other languages can be
found at: www.my-siemens.com/t9
Press. A blank ends a
word.
Full stop. Ends a word when a
blank follows. Acts as a wildcard character for an apostrophe/hyphen in the word:
e. g. §provider.s = provider’s.
Press control key at the bot tom
to end a word.
Press briefly: Switch be-
tween: abc, Abc,T9abc,
T9
Abc, 123. Status indicator in
the top line of the display.
Hold down: All input modes
are displayed.
Pressbriefly: Write special
characters (p. 77).
Hold down to open the input
menu (p. 78).
74
Text entry with "T9"
T9 word suggestions
If several options are found in the
dictionary for a key sequence (a
word), the most probable is displayed first. If the word you want has
not been recognised, the next suggestion from T9 may be correct.
The word must be§highlighted§.
Then press
»
»
If the word you want is not in the dictionary, it may be written without
T9.
To add a word to the dictionary:
§Spell§Select.
The last suggestion is deleted and
the word may now be entered without T9 support. Press §Save§ to add it
automatically to the dictionary.
The displayed word is replaced with a different
word. If this word is also
incorrect,
press again. Repeat until
the correct word is displayed.
™
SMS 1748
At 8 h we are ___
Spell
»
Correct a word
Words created using T9:
G
»
§Clear§Deletes the character to
Words not created using T9:
G
§Clear§Deletes the character to
J
Note
Within a "T9 word", individual letters may
not be edited without removing T9 first. In
most cases it is better to rewrite the complete word.
T9® Text Input is licensed under one or more of
the following: U.S. Pat. Nos. 5, 818, 437, 5, 953,
541, 5, 187, 480, 5, 945, 928, and 6, 011, 554; Canadian Pat. No. 1,331,057; United Kingdom Pat.
No. 2238414B; Hong Kong Standard Pat. No.
HK0940329; Republic of Singapore Pat. No.
51383; Euro. Pat. No. 0 842 463 (96927260 .8) DE/
DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional
patents are pending worldwide.
M ov e w or d b y w or d t o t he
left/right until the required word is highlighted.
Scroll through the T9
word suggestions again.
the left of the cursor and
displays a new possible
word!
Move character by character to the left/right.
the left of the cursor.
Characters are inserted at
the cursor position.
Display indicators
Signal strength.
_
h
Charging.
d
Battery level.
All calls are diverted.
n
Ringer off.
j
Short ringer (beep) only.
k
Ringer only, if the caller is stored
l
in the Phonebook.
i
Alarm set.
Alarm clock active.
y
µ
Key lock active.
Phone numbers/names:
On the SIM card
¢
¡
On the SIM card (PIN 2
protected).
In the phone memory.
v
No network access.
²
p,o
Function activated/deactivated.
Phonebook.
Q
ABC/
Abc/abc
Indicates whether upper- or lowercase letters are active.
™
Text input with T9.
«
GPRS activated.
ª
GPRS available.
WAP Online.
¦
Display symbols (selection)
WAP via GPRS Online.
Ë
WAP No network.
Ì
Headset mode.
Loudspeaker Car Kit.
®
Additional handset mode.
œ
Car Kit active.
³
Auto answer feature on.
±
Organiser symbols
Memo.
u
Meeting.
w
Call.
v
Birthday.
{
Anniversary.
|
Important event.
t
Control key (on the left/on the right)
]
Message received.
Voice mail
\
Unanswered call.
Picture received.
—
Meldody/ring tone received.
–
SIM memory full.
T
SIM services.
}
Store in Phonebook.
Retrieve from Phonebook.
·
T9 word selection.
»
received.
75
76
Notes A-Z
Control codes (DTMF)
Send control code
You can enter control codes (digits)
during a call so that an answering
machine can be controlled remotely.
These digits are directly transmitted
as DTMF tones (control codes). The
sounds can also be heard when the
microphone is switched off.
y menu§ Open call menu.
Send DTMF tones Select.
Use the Phonebook
Store phone numbers and control
codes ( DTMF tones) in the Phonebook like a normal entry.
J
0
J
0
J
§ Save §Press.
You can also store the DTMF tones
(digits) without a phone number and
send them during a call.
Enter phone number.
Press until a "+" appears
on the display (pause for
connection setup).
Enter DTMF signals
(digits).
If necessary enter further
pauses of three seconds
each to ensure correct
processing at the destination.
Enter a name.
CSD
(Circuit Switched Data)
Data transfer is made via a data connection to a default IP address of
your network provider or service provider. This connection can be used
for the exchange of data (e.g. for acces to the Internet or for downloading games and applications as well
as for using WAP services).
As long as this connection is established in order to use services or to
download applications from the Internet, charges for connection accrue according to the price list of
your network provider or service
provider.
Divert set
§Divert§
Diverts the caller to the mailbox, for
example, if Busy (p. 60) is set and
the Call waiting (p. 60) function is
activated.
Emergency number(SOS)
By pressing the control key §SOS , you
can make an emergency call on any
network without a SIM card and
without entering a PIN (not available
in all countries).
This must only be used in real emergencies!
Notes A-Z
77
EMS
(Enhanced Messaging Service)
Besides (formatted) texts, you can
also send
• pictures (bitmaps),
•sounds,
• animations (sequence of 4 pictures)
using the EMS.
The segments specified above can
be together or transmitted individually on an SMS. With EMS, pictures
and sounds can also be sent (e.g. as
ring tones and screensavers). This
can cause messages that exceed the
length of a single SMS. In this case a
concatenation of individual segments to a single message is made.
Enter special characters
*
¿¡ _; . , ?! +- :
%~ " ’
¥
1) Line skip
G
§Select§Select character.
Press briefly. The character
map is displayed:
* / ( ) <=>
$£€#@\ &§
Navigate to character.
1)
¤
Extending numbers in the
Phonebook
When entering a phone number in
the Phonebook, digits can be replaced by a question mark "?":
*
These wildcards must be completed
for the call.
Select the phone number in the
Phonebook to call:
A
J
A
GPRS
(General Packet Radio Service)
GPRS is a new method for transmit-
ting data in the mobile network faster. If you use GPRS, you can be connected to the Internet permanently
if the network capacities suffice.
Some service providers do not yet
support this service.
Hold down.
Press.
Replace "?" with digits.
Press to dial phone
number.
L
78
Notes A-Z
HTTP
(Hypertext Transfer Protocol)
HTTP is the name for the protocol
that controls transmission of data in
the Internet. Via HTTP connections,
you can download applications and
games (Games & More, p. 37) and
ring tones (sound manager, p. 41)
for several voices (polyphone ring
tones) from the Internet. For information on the configuration of the
HTTP connection using HTTP profiles
see p. 65.
Input menu
During text input:
*Hold down. The input
menu is displayed:
Format
Mark text
Copy/Add
Input language
International dialling codes
Many international dialling codes
are stored in your phone.
is not neces-
In standby mode (
sary when dialling from the Phonebook):
0
§ +List §Press.
Select the required country. The international dialling code is displayed. Now add the national
number (in many countries without
the first digit) and press the Call key.
JAD § and JAR
Three file types occur when using
Java™:
The JAD file (Java Descriptor)
These files contain information on
the application (JAR file) and their
address for downloading. By activating a JAD file, the connection to the
Internet is established and the executable application is loaded.
The JAR file (Java archive)
This file includes the executable application. By activating a JAR file, the
application is started.
0
Hold down until a "+" is displayed. This replaces the
first two digits of the international dialling code.
¦
Notes A-Z
79
Combined files
These files result from JAR files being
loaded via JAD files. In this case the
JAD file is inserted into the JAR file.
The display icon is the same as for
JAR files.
The following icons appear when using
Java™:
§
JAD file
JAR file
¦
Java
™
Java™ allows you to use numerous
games and applications on your mobile phone. You can download these
applications from the Internet and
install them on your mobile phone.
The application can be started after
installation. Please refer to the operating instructions for each application.
Siemens does not guarantee that the
downloaded and installed Java applications work well with your mobile
phone (see also p. 39).
T Message store full
The SIM memory is full when the
message symbol flashes. No more
SMS messages can be received. Delete or save messages (p. 30).
Operating times
A fully charged battery provides 60
to 300 hours of standby time or 90
to 360 minutes of talk time. The
standby times/talk times are average
values and depend on the operating
conditions (see table):
Operation
carried out
Calling130 to 60 minutes
Display back
light *
Network
search
* key input, games, organiser etc.
If the phone is exposed to heat the
standby time is considerably reduced. Avoid exposing the phone to
direct sunlight or placing it on a radiator.
Time
Decrease in the
(min)
standby time by
130 minutes
15 to 10 minutes
Outside the home network
If you are outside your "home network" your phone automatically dials a different GSM network (p. 70).
Own numbers
You can enter your "own numbers"
in the Phonebook (e.g. fax) for information. These numbers can be
changed or deleted and also sent as
an SMS.
80
Notes A-Z
Phone number memo
If you enter a number with the keypad during a call, the person on the
other end of the line can hear the
numbers being entered. It can be
stored or dialled after the current call
has ended.
Phone number/URL in SMS
Numbers §highlighted§ in the message
can be dialled (press
be stored in the Phonebook (p. 19).
URLs (Internet addresses) and the
HTTP download can be accessed directly (press
(p. 36) and HTTP settings (p. 38)!
A) or they can
A). Check your WAP
Quality declaration for battery
The capacity of your mobile phone
battery is reduced each time you
charge/discharge it. Storing the battery at temperatures that are too
high or too low also causes a gradual
loss of capacity. This can cause the
operating times of your mobile
phone to reduce significantly per usage cycle.
The battery is, however, designed to
be charged and fully discharged
within a period of six months from
when the mobile phone was purchased. Following this six-month period, we recommend replacing your
battery if you experience a significant drop in performance. Only purchase original Siemens batteries.
Quick menu selection
All menu functions are numbered internally. By entering these numbers
one after the other the function may
be started at once.
For example, to compose a new
SMS:
§ Menu §Press.
1
1
If your service provider offers additional functions (SIM services) in the
menu system, the numerical order
may change.
for Messages
for New SMS
Service numbers
Numbers that you are offered by
your service provider may be stored
in the Phonebook. You can call local
or nationwide information services
or use services of the service provider.
Signal strength
_
^
Strong signal.
A weak signal reduces the
call quality and may lead
to loss of the connection.
Change your location.
Notes A-Z
81
SIM card problems
You have inserted your SIM card, but
the following message appears:
Please insert SIM card
Please ensure that the card is correctly inserted and the contacts are
clean; if necessary, clean them with
a dry cloth. If the card is damaged,
please contact your service provider.
See also "Questions & Answers",
p. 85.
SIM services ( optional)
Your service provider may offer special applications such as mobile
banking, stock market etc. via the
SIM card.
If you have such a SIM card the SIM
services will appear at the top of the
main menu or directly above the
control key (on the left).
}
If there is more than one application
they are displayed in the "SIM services" menu.
§Menu§
With the SIM services menu, your
phone is ready for the future and will
support additions to your service
provider's user package. For further
information, please contact your
service provider.
Symbol of the SIM
services.
SIM serv
K
L
SMS status report
If the phone was unable to send the
message to the service centre a retry
option is available. If this attempt
also fails, contact your service
provider.
The message sent! text only indicates
that the message has been transmitted to the service centre which now
tries to deliver the message within a
certain period.
See also "Validity", p. 66.
SMS Push
Th i s f un ct io n a ll ow s y ou t o c al l u p a n
Internet address (URL) directly from
an SMS you received. After selecting
it, the URL is highlighted. By pressing
the Call key
automatically started and the highlighted Internet address is called up.
Athe WAP browser is
Software version
To display the software version of
your phone in standby mode enter:
# 0 6 #, then press §Info§.
*
82
Notes A-Z
Switch off ringer
Switch off the ringer only for the
current call/alarm (not if "Any key answer" p. 60, is active):
*
The call is still displayed. When you
now accept or reject the call or
switch the phone off and on again,
this function is ended.
Hold down.
Switch on/off all sounds
All signal tones (also the ringer) can
be deactivated and activated in
standby mode:
*
A call is still displayed. Silent alert remains active if it has been activated
previously. The audio settings are
not affected. By switching the phone
off and on again, this function is also
ended (see also p. 82).
Hold down.
T9 language versions
If you want to load another dictionary (T9 language version) to support
writing SMS in a different language,
a comprehensive selection of dictionaries to be downloaded via the
Internet and the relevant installation
notes can be found at:
www.my-siemens.com/t9
Two phone numbers
Special settings can be made for
each phone number (e.g. melody,
call divert etc.). Switch to the required number first.
To switch the phone number/line in
standby mode:
0
§Line 1§ Press.
Press.
L
WAP
(Wireless Application Protocol)
A technical standard that is the basis
of the connection between mobile
radio networks and the Internet.
WAP enables mobile surfing using
the mobile phone in the Internet,
downloading of games and applications and the use of WAP services
such as news, stock exchanges or
information.
Notes A-Z
83
WAP usage
Start with...
You can set which functions are to
be displayed after Internet access:
A
More ...Select.
SetupSelect.
Start with...
Enter the Internet address (URL)
A WAP page must be shown on the
display (online or offline). Then:
A
Go to URL Select.
J
Special characters for WAP usage:
0
Open the browser menu.
Select, then select from
the list:
Start menu
Browser menu
Homepage
Resume
Bookmarks
Open the browser menu.
Enter URL and confirm.
The connection is established.
Press repeatedly for:
. , ? ! @ / & ~ + - :
Bookmarks (URL)
You can store a list of your favourite Internet addresses (URL)
in the phone (available offline and
online, depending on the service
provider):
Save:
A
Bookmarks Select.
Add bookmark
(Empty) Select.
§Menu§Open menu.
§Edit§Select, enter name/head-
Save§Press.
A
Bookmarks Select.
G
§Go§The selected call is set up.
Open the browser menu.
Online (save):
The current WAP address
is added as a bookmark.
Offline (save):
er and URL and confirm.
Apply:
Open the browser menu.
Select entry.
L
84
Changing the home page
The address of the homepage is entered in the (access) profile (p. 66).
You can change it in standby mode
(if permitted by the service
provider!):
K
§Menu§
Select the profile for example:
e-Commerce Select.
§Edit§The entry card is dis-
WAP Parameters, then select
J
§Save§Press.
Setup
K
Connectivity
K
WAP Profiles
played.
Homepage.
Enter new address. Go to
the end of the entry card.
Notes A-Z
Without SIM card
If you switch on the phone without
SIM card, you can use a few functions of the phone.
§ Menu §Press control key (on the
§ SOS §Emergency number, SOS
right). The functions are
displayed.
Questions&Answers
If you have any questions about using your phone, visit us at
www.my-siemens.com/customercare anytime. In addition we have listed some frequently
asked questions and answers below.
QuestionPossible causesPossible solution
Phone cannot
be switched on.
Standby time is
too short.
Charging error
(charge icon
not displayed).
SIM error.SIM card not correctly inserted.Make sure that the SIM card is correctly
On/Off key not pressed long
enough.
Flat battery.Charge battery. Check charging indicator in the
When calling custome r service, please have
ready your receipt and the phone identity
number (IMEI, to display press
software version (to display press
then §Info§) and if necessary your Siemens
#06#), the
*
#06#,
*
Service customer number.
Specifications/maintenance
89
Declaration of conformity
Siemens Information and Communication mobile hereby declares that
the phone described in this user
guide is in compliance with the essential requirements and other relevant provisions of European Directive 1999/5/EC (R&TTE).
The declaration of conformity (DoC)
concerned has been signed. Please
call the company hotline if you require a copy of the original.
Technical data
GSM class4 (2 Watt)
Frequency range: 880-960 MHz
GSM class:1 (1 Watt)
Frequency range: 1,710-1,880 MHz
Weight:80 g
Dimensions:100.7x43.9x20.8 mm
Li-Ion battery:700 mAh
Operating temper-
ature:
Standby time:60 h - 300 h
Talk time:90 min - 360 min
SIM card:3.0 V
SAR0.49 W/kg*
* This applies to the phone together with the
front and back covers and keyboard supplied with the phone.
(69 ccm)
-10 °C to 55 °C
Maintenance tips
• The SIM card should be treated
with the same care as a cheque
guarantee card. Do not bend or
scratch it or expose it to static
electricity.
• Clean the card with a damp cloth
or an antistatic wipe without
chemical cleaning agents.
• Protect the phone from moisture
and shocks. Do not expose your
phone to direct sunlight.
• Remove the battery if you are not
going to use the phone for extended period s of time (more than
one month).
Phone ID
You will need the following details if you
lose your phone or SIM card. Please enter
here
If you lose your phone or SIM card contact
your service provider immediately to prevent misuse.
90
Accessories
Basics
Li-Ion Battery (700 mAh)
L36880-N5601-A100
Spare battery.
Travel Charger
L36880-N5601-A104 (Euro)
L36880-N5601-A105 (UK)
Travel charger with an extended input volt-
age rate of 100-240V.
Desk Top Charger
L36880-N4501-A101
The desktop charger enables convenient
charging of the mobile phone and an additional battery.
Headset PTT
L36880-N5601-A108
Headset with PTT key for activating the
voice recognition and accepting and ending
calls.
Carry Set
L36880-N5601-A119
Features a belt clip and a retaining clip for
discretely fastening the mobile phone to
clothes or in bags.
CLIPit™ Covers
Exchangeable top and bottom covers can be
obtained in specialist shops. Visit our online
shop.
Carrying Cases
Several carrier bags can be obtained in specialist shops. Visit our online shop under:
Original Siemens Accessories
www.siemens.com/
mobilestore
Data/Applications
Data Cable RS232
L36880-N5601-A110
To connect the mobile phone to the serial
RS232 port of the PC.
Data Cable USB
L36880-N5601-A111
To connect the mobile phone to the USB
port of your PC. With load function.
Sync Pack
L36880-N5601-A103
Table cradle for your mobile phone. Allows
data exchange and simultaneously charges
the phone on the power supply unit at home.
Features a Desktop Stand, a Data Cable
RS232 und a Y adapter.
Accessories
91
Car Solutions
Car Charger
L36880-N5601-A106
Charger for the cigarette lighter socket in
your car.Car Kit Portable
L36880-N5601-A109
Handsfree kit with integrated loudspeaker
and microphone and auto answer feature.
Simply plug into the cigarette lighter socket.
Ideal for mobility between vehicles.
Mobile Holder
L36880-N5601-A116
Cradle without antenna port.
Mobile Holder Antenna
L36880-N4501-A117
Mobile holder for connecting an outdoor an-
tenna. Ideal in combination with Headset
PTT or Car Kit Portable.
Basic Car Pack
L36880-N5601-A118
Allows handsfree talking an d simultaneously
charges the mobile phone in the car. Features a Car Charger, a Headset PTT and a Y
adapter.
Car Kit Comfort
L36880-N5701-A100
Handsfree kit with first-class digital call qual-
ity and utmost ease of use. Includes all components needed for installation. The
individual antenna solution can be obtained
from your specialist dealer.
ty for more than 150 names. Electronics box
with connection for fax and email transmission via your notebook. Includes all components needed for installation. The individual
antenna solution can be obtained from your
specialist dealer.
Car Kit Upgrade for Car Kit Comfort and
Car Kit Voice I
L36880-N5701-A104
Cradle for upgrading your Car Kit Comfort
and Car Kit Voice I handsfree kit.
Car Kit Upgrade for Car Kit Voice II
L36880-N5701-A105
Cradle for upgrading your Car Kit Voice II
handsfree kit.
Optional Car Kit accessories
Car Handset ............ L36880-N3015-A123
VDA Adapter Cable.. L36880-N4001-A121
Car Data Adapter..... L36880-N5701-A108
Push To Talk Key.....L36880-N4501-A135
Products can be obtained in specialist
shops. Visit our online shop under:
Original Siemens Accessories
www.siemens.com/
mobilestore
92
SAR (European Union)
THIS MODEL OF PHONE MEETS THE
EU REQUIREMENTS FOR EXPOSURE
TO RADIO WAVES.
Your mobile phone C55 is a radio
transmitter and receiver. It is designed and manufactured not to exceed the limits for exposure to radio
frequency (RF) energy recommended by The Council of the European
Union. These limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the
general population. The guidelines
were developed by independent scientific organisations through periodic and thorough evaluation of scientific studies. The limits include a
substantial safety margin designed
to assure the safety of all persons, regardless of age and health.
The exposure standard for mobile
phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit recommended by The Council of the
European Union is 2.0 W/kg.* Tests
for SAR have been conducted using
standard operating positions with
the phone transmitting at its highest
certified power level in all tested frequency bands. Although the SAR is
determined at the highest certified
power level, the actual SAR level of
the phone while operating can be
well below the maximum value. This
is because the phone is designed to
operate at multiple power levels so
as to use only the power required to
reach the network. In general, the
closer you are to a base station antenna, the lower the power output.
Before a phone model is available for
sale to the public, compliance with
the European R&TTE directive must
be shown. This directive includes as
one essential requirement the protection of the health and the safety
for the user and any other person.
The highest SAR value for this model
phone C55 when tested for compliance against the standard was 0.49
W/kg. While there may be differences between the SAR levels of various
phones and at various positions,
they all meet the EU requirements
for RF exposure.
* The SAR limit for mobile phones
used by the public is 2.0 watts/kilogram (W/kg) averaged over ten
grams of tissue. The limit incorporates a substantial margin of safety
to give additional protection for the
public and to account for any variations in measurements. SAR values
may vary depending on national reporting requirements and the network band. For SAR information in
other regions please look under
product information at
www.my-siemens.com
SAR (international)
93
THIS MODEL PHONE MEETS REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your mobile phone C55 is a radio
transmitter and receiver. It is designed and manufactured not to exceed the limits for exposure to radio
frequency (RF) recommended by international guidelines (ICNIRP).
These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines were
developed by independent scientific
organisations through periodic and
thorough evaluation of scientific
studies. The guidelines include a
substantial safety margin designed
to assure the safety of all persons, regardless of age and health.
The exposure standard for mobile
phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit stated in the international guidelines is
2.0 W/kg*. Tests for SAR are conducted using standard operating positions with the phone transmitting
at its highest certified power level in
all tested frequency bands. Although
the SAR is determined at the highest
certified power level, the actual SAR
of the phone while operating can be
well below the maximum value. This
is because the phone is designed to
operate at multiple power levels so
as to use only the power required to
reach the network. In general, the
closer you are to a base station, the
lower the power output of the
phone.
The highest SAR value for this model
phone C55 when tested for use at
the ear is 0.49 W/kg. While there
may be differences between the SAR
levels of various phones and at various positions, they all meet the relevant international guidelines for RF
exposure.
* The SAR limit for mobile phones
used by the public is 2.0 watts/kilogram (W/kg) averaged over ten
grams of body tissue. The guidelines
incorporate a substantial margin of
safety to give additional protection
for the public and to account for any
variations in measurements. SAR values may vary depending on national
reporting requirements and the network band. For SAR information in
other regions please look under
product information at
www.my-siemens.com
94
Index
Accepted calls, call list
Accessories
......................................90
Account limit
....................27
...................................28
Activate
HTTP profile
phone profile
Aircraft mode, profile
.................................39
...............................52
.....................53
Alarm
alarm clock
anniversaries
appointments
Alarm clock
Alarm tones
All calls, divert
All calls, duration/charges
Screensaver
Second call
Second phone number
Security
......................................11, 68
Security codes
Service centre, provider
............................3
...............................39, 57
.......................................17
...................70
.................................11
.................67
Service numbers (Siemens)
Service tones
...................................59
Setup
............................................58
audio
clock
.............................................63
data exchange
display
divert
group
keys
...............................................60
phone
security
Short message (SMS)
Siemens City Portal
Signal strength
Silent alert
.............................64
..........................................57
............................................60
............................................26
...........................................60
.........................................68
.....................29
......................... 13
................................80
........................................58
SIM card
clear barring
insert
problems
SIM services
................................12
..............................................5
................................81, 85
.....................................81
SMS
..........................................30
archive
delete
...........................................30
Inbox/Outbox
..............................30
insert pictures and sounds
read
..............................................29
set profiles
status report
text entry with T9
...................................66
................................67
.......................73
...........88
.........33
to group
write
Software version
SOS
Sound Manager
Sounds in SMS
Special characters
Speed dialling keys
Standby mode
Standby time
Start menu WAP
Status report, SMS
Storage location number
Surf&Fun
Swap
