SHARP XG-P10XE Service Manual

XG-P10XE

SERVICE MANUAL SERVICE-ANLEITUNG

S80H2XG-P10XE

LCD PROJECTOR LCD PROJEKTOR

MODEL MODELL

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

Im lnteresse der Benutzersicherheit (erforderliche Sicherheitsregeln in einigen Ländern) muß das Gerät in seinen Originalzustand gebracht werden. Außerdem dürfen für die spezifizierten Bauteile nur identische T eile verwendet werden.

XG-P10XE

CONTENTS INHALT

Page

» SPECIFICATIONS...................................................... 2

» NOTE TO SERVICE PERSONNEL............................ 3

» OPERATION MANUAL ............................................... 5

» REMOVING OF MAJOR PARTS ...............................11

» RESETTING THE TOTAL LAMP TIMER .................. 16

» THE OPTICAL UNIT OUTLINE ................................ 17

» CONVERGENCE AND FOCUS ADJUSTMENT ........ 18

» ELECTRICAL ADJUSTMENT................................... 25

» ADJUSTING THE PC INTERFACE .......................... 32

» TROUBLE SHOOTING TABLE ................................ 33

» CHASSIS LAYOUT................................................... 94

» BLOCK DIAGRAM .................................................... 96

» OVERALL WIRING DIAGRAM .................................. 98

» DESCRIPTION OF SCHEMATIC DIAGRAM........... 100

» WAVEFORMS......................................................... 101

» SCHEMATIC DIAGRAM......................................... 102

» PRINTED WIRING BOARD ASSEMBLIES ............ 154

» PARTS LIST

ELECTRICAL PARTS ........................................ 162

CABINET AND MECHANICAL PARTS .............. 188

ACCESSORIES PARTS .................................... 192

PACKING PARTS............................................... 192

» PACKING OF THE SET.......................................... 193

» TECHNISCHE DATEN ............................................. 48

» HINWEISE FÜR DAS WARTUNGSPERSONAL...... 49

» BEDIENUNGSANLEITUNG ..................................... 51

» ENTFERNEN DER HAUPTTEILE ............................ 57

» NULLSTELLUNG DES LAMPEN-

BETRIEBSSTUNDENZÄHLERS (GESAMTZEIT).... 62

» ÜBERSICHT DER OPTIKEINHEIT .......................... 63

» EINSTELLUNG VON KONVERGENZ UND

BRENNPUNKT ......................................................... 64

» ELEKTRISCHE EINSTELLUNG............................... 71

» EINSTELLUNG DER PC-SCHNITTSTELLE ............ 78

» FEHLERSUCHTABELLE.......................................... 79

» CHASSIS-ANORDNUNG ......................................... 94

» BLOCKSCHALTBILD................................................ 96

» GESAMTSCHALTPLAN ........................................... 98

» BESCHREIBUNG DES SCHEMATISCHEN

SCHALTPLANS ...................................................... 100

» WELLENFORMEN ................................................. 101

» SCHEMATISCHER SCHALTPLAN ........................ 102

» LEITERPLATTENEINHEITEN ................................ 154

» ERSATZTEILLISTE

ELEKTRISCHE BAUTEILE................................ 162

GEHÄUSE UND MECHANISCHE BAUTEILE... 188

ZUBEHÖRTEILE................................................ 192

VERPACKUNGSTEILE...................................... 192

» VERPACKEN DES GERÄTS.................................. 193

Seite

SHARP CORPORATION

XG-P10XE

Specifications

Product type

Model

Video system

Display method

LCD panel

Lens

Projection lamp

Contrast ratio

Video input signal

S-video input signal

Component input signal

Horizontal resolution

Audio output

Computer RGB input signal

Pixel clock

Vertical frequency

Horizontal frequency

Computer control signal

Speaker system

Rated voltage

Input current

Rated frequency

Power consumption

Operating temperature

Storage temperature

Cabinet

I/R carrier frequency

Laser pointer of remote control

Dimensions (approx.)

Weight (approx.)

Supplied accessories

Replacement parts

LCD Projector XG-P10XE PAL/SECAM/NTSC 3.58/NTSC 4.43/DTV 480P/DTV 720P/DTV 1080I LCD panel × 3, RGB optical shutter method Panel size: 33mm (1.3") (20.0 [H] × 26.6 [W] mm) Display method: Translucent TN liquid crystal panel Drive method: TFT (Thin Film Transistor) Active Matrix panel No. of dots: 786,432 dots (1,024 [H] × 768 [V]) 1–1.3× zoom lens, F1.7–2.3, f = 49.1–63.8 mm 200 W UHP lamp 250:1 RCA Connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75 Ω terminated RCA Connector: AUDIO, 0.5 Vrms more than 22 kΩ (stereo) 4-pin Mini DIN connector Y (luminance signal): 1.0 Vp-p, sync negative, 75 Ω terminated C (chrominance signal): Burst 0.286 Vp-p, 75 Ω terminated BNC Connector (INPUT 1) Y:1.0 Vp-p, sync negative, 75 Ω terminated

B: 0.7 Vp-p, 75 Ω terminated

P P

R: 0.7 Vp-p, 75 Ω terminated

520 TV lines (video input), 750 TV lines (DTV 720P input, Dot by Dot) 2 W + 2 W (stereo) 15-

PIN MINI D-SUB CONNECTOR (INPUT 1, 2), 5 BNC CONNECTOR (INPUT 1):

RGB separate/composite sync/sync on green type analog input: 0–0.7 Vp-p, positive, 75 Ω terminated

TEREO MINIJACK: AUDIO, 0.5 Vrms, more than 22 kΩ (stereo)

ORIZONTAL SYNC. SIGNAL: TTL level (positive/negative) or composite sync (Apple only)

ERTICAL SYNC. SIGNAL: Same as above

V 12–230 MHz 43–200 Hz 15–126 kHz 9-pin Mini DIN female connector (RS-232C Input Port) 5 cm (1

⁄32") round × 2

AC 110–120/220–240 V

3.2 A/1.6 A 50/60 Hz 300 W + 5°C to + 40°C

– 20°C to + 60°C

Plastic 38 kHz Wave length: 650 nm / Max. output: 1 mW / Class II Laser Product 261 × 139 × 356 mm (W × H × D) (main body only) 261 × 156 × 411.5 mm (W × H × D) (including adjustment feet and projecting parts)

7.3 kg Remote control, Two AA size batteries, Power cord (1.8m), Computer RGB cable (3m), Computer audio cable (3m), Three BNC-RCA adaptors, PS/2 mouse control cable (1 m), USB mouse control cable (1.5 m), DIN-D-sub RS-232C cable (15 cm), Remote mouse receiver, Extra air filter, Lens cap (attached), CD-ROM, LCD projector operation manual, LCD projector quick references, Sharp Advanced Presentation Software operation manual Standard lens unit (CLNS-0169CE02), Lamp unit (Lamp/cage module) (BQC-XGP10XE/1), Remote control (RRMCG1590CESA), AA size batteries, Power cord, Computer RGB cable (QCNW-5304CEZZ), Computer audio cable (QCNW-4870CEZZ), BNC-RCA adaptors (QPLGJ0107GEZZ), PS/2 mouse control cable (QCNW-5113CEZZ), USB mouse control cable (QCNW-5680CEZZ), DIN-D-sub RS-232C cable (QCNW-5288CEZZ), Remote mouse receiver (RUNTK0673CEZZ), Air filter (PFILD0088CEZZ), Lens cap (PCAPH1056CESA), CD-ROM (UDSKA0026CEN1), LCD projector operation manual (TINS-7068CEZZ), LCD projector quick references (TINS-7070CEZZ, TINS-7171CEZZ, TINS-7172CEZZ), Sharp Advanced Presentation Software operation manual (TINS-7069CEZZ)

This SHARP projector uses LCD (Liquid Crystal Display) panels. These very sophisticated panels contain 786,432 pixels ( × RGB) TFTs (Thin Film Transistors). As with any high technology electronic equipment such as large screen TVs, video systems and video cameras, there are certain acceptable tolerances that the equipment must conform to.

Specifications are subject to change without notice.

This unit has some inactive TFTs within acceptable tolerances which may result in illuminated or inactive dots on the picture screen. This will not affect the picture quality or the life expectancy of the unit.

NOTE TO SERVICE PERSONNEL

UV-RADIATION PRECAUTION

234567890123456789012345678901212345678901234

The light source, metal halide lamp, in the LCD projector emits small amounts of UV-Radiation.

AVOID DIRECT EYE AND SKIN EXPOSURE.

To ensure safety please adhere to the following:

1. Be sure to wear sun-glasses when servicing the projector with the lamp turned “on” and the top enclosure removed.

XG-P10XE

Lamp Replacement

Note:

Since the lamp reaches a very high temperature during units operation replacement of the lamp should be done at least one hour after the power has been turned off. (to allow the lamp to cool off.) Installing the new lamp, make sure not to touch the lamp (bulb) replace the lamp by holding its reflector 2 . [Use original replacement only.]

Lamp

Reflector

2. Do not operate the lamp outside of the lamp housing.

3. Do not operate for more than 2 hours with the enclosure removed.

UV-Radiation and Medium Pressure Lamp Precautions

1. Be sure to disconnect the AC plug when replacing the lamp.

2. Allow one hour for the unit to cool down before servicing.

3. Replace only with same type lamp. Type CLMPF0064DE11 or BQC-XGP10XE/1 rated 85V/ 200W.

4. The lamp emits small amounts of UV-Radiation, avoid direct-eye contact.

5. The medium pressure lamp involves a risk of explosion. Be sure to follow installation instructions described below and handle the lamp with care.

DANGER ! –– Never turn the power on without the lamp to avoid electric-shock or damage of the devices since the stabilizer generates high voltages at its start.

Since small amounts of UV-Radiation are emitted from an opening between the duct cover and the lamp housing, it is recommended to place the LENS CAP on the opening during servicing to avoid eye and skin exposurem (Fig. 1).

Note: Please obtain a lens cap before servicing a

model XG-P10XE that is received without one.

LENS CAP

Figure 1.

XG-P10XE

Usage Guidelines

Cautions Concerning the Laser Pointer

The laser pointer on the remote control emits a laser beam from the laser pointer window. This is a Class II laser which may impair your sight if directed into the eyes. The two marks shown on the left are caution labels for the laser beam.

• Do not look into the laser pointer window or shine the laser beam on yourself or others. (The laser beam used in this product is harmless when directed onto the skin. However, be careful not to project the beam directly into the eyes.)

• Always use the laser pointer at temperatures between + 5°C and + 40°C.

• Use of controls or adjustments, or performance of procedures other than

those specified herein may result in hazardous radiation exposure.

Laser pointer window

CAUTION

POTENTIAL HAZARD OF GLASS P AR TICLES. SEE OPERA TION MANUAL.

ATTENTION

LAMPE. D ANGER POTENTIEL DE PARTICULES DE VERRE. SE REPORTER A U MODE D’EMPLOI.

+40˚C

+5˚C

LAMP MAY RUPTURE.

RUPTURE POSSIBLE DE LA

Caution Concerning the Lamp Unit

Potential hazard of glass particles if lamp ruptures. Please have Sharp Authorised LCD Projector Dealer or Service Centre replace lamp if rupture occurs.

Cautions Concerning the Setup of the Projector

For minimal servicing and to maintain high image quality, SHARP recommends that this projector be installed in an area free from humidity, dust and cigarette smoke. If the projector is used in these environments, the lens and filter will need to be cleaned (or the filter replaced) more often, and internal cleaning may become necessary. As long as the projector is regularly cleaned, use in these environments will not reduce the overall operation life of the unit. Internal cleaning should only be performed by a Sharp Authorised LCD Projector Dealer or Service Centre.

Notes on Operation

• The exhaust vent, the lamp cage cover and adjacent areas may be extremely hot during projector operation. To prevent injury,do not touch these areas until they have sufficiently cooled.

• Allow at least 10 cm of space between the cooling fan (exhaust vent) and the nearest wall or obstruction.

• If the cooling fan becomes obstructed, a protection device will automatically turn off the projector lamp. This does not indicate a malfunction. Remove the projector power cord from the wall outlet and wait at least 10 minutes. Then turn on the power by plugging the power cord back in. This will return the projector to the normal operating condition.

Location of Controls

Projector

MUTE button

POWER indicator

POWER buttons (ON/OFF)

XG-P10XE

LAMP REPLACEMENT indicator

TEMPERATURE WARNING indicator

VOLUME buttons (+/–)

BLACK SCREEN button

ADJUSTMENT buttons

Front and Top View

Foot releases

Side and Rear View

LENS button

INPUT button

FREEZE button

ENLARGE button

/ " / \ / | )

(

Speakers

MENU button

AUTO SYNC button

RESIZE button

GAMMA button

UNDO button

ENTER button

Cooling fan (Exhaust vent)

Air filter/Cooling fan (Intake vent)

Remote control sensor

Remote control sensor Cooling fan (Intake vent)

Kensington Security Standard connector

AUDIO INPUT 1 terminal (3.5 mm stereo minijack)

INPUT 1 port (HD 15)

15 pin/BNC switch

VIDEO INPUT 3 terminal (RCA)

AUDIO INPUT 3 terminals (RCA)

RS-232C port

(9-pin Mini DIN)

WIRED REMOTE

control input terminal

1 2

Carrying handle

INPUT 2 port (HD 15)

AUDIO INPUT 2 terminal (3.5 mm stereo minijack)

INPUT 1 terminals: BNC

), G/G sync (Y), B (PB),

(R (P HD/C sync, VD)

OUTPUT port for INPUT 1, 2 (HD 15)

AUDIO OUTPUT terminal (3.5 mm stereo minijack)

AC socket

S-VIDEO INPUT terminal (4-pin Mini DIN)

XG-P10XE

Operating the Wireless Mouse Remote Control

Remote Control

Font View

POWER buttons

SCREEN button

RIGHT-CLICK/

ENTER button

FREEZE button

ADJUSTMENT

MUTE button

(ON/OFF)

LENS/BLACK

MOUSE/

switch

VOLUME buttons (+/–)

LASER POINTER/ MENU button

MOUSE/ ADJUSTMENT buttons (

UNDO buttonINPUT button

AUTO SYNC button

RESIZE buttonENLARGE button

GAMMA buttonTOOLS button

BACKLIGHT button

' / " / \ / | )

T op View

Remote control signal transmitter

Laser pointer window

Rear View

LEFT-CLICK button

Bottom View

Inserting the batteries

Press in on the arrow

mark and slide in the direction of the arrow to remove the battery cover.

Battery

cover

Wired remote control input

Insert two AA size

batteries, making sure their polarities match the + and – marks inside the battery compartment.

Battery

compartment

Insert the side tabs of the battery cover into their slots and press the cover in until it is properly seated.

Battery

cover

Using the Remote Control as a Wireless Mouse

XG-P10XE

The remote control has the following three functions:

• Projector control

MOUSE/ADJUSTMENT switch

(Remote control)

• Wireless mouse

• Laser pointer

MOUSE

ADJ.

Wireless mouse

Laser pointer

MOUSE

ADJ.

Projector control

Remote Control/Mouse Receiver Positioning

• The remote control can be used to control the projector within the ranges shown below.

• The remote mouse receiver can be used with the remote contr ol to contr ol the mouse functions of a connected

computer within the ranges shown below.

• The signal from the remote control can be reflected off a screen for easy operation. However, the effective distance of the signal may differ due to the screen material.

Controlling the Projector

Remote control

7 m

30˚

Using the Wireless Mouse

Remote control

30˚

45˚

30˚

45˚

30˚

Remote contol

4 m

120˚

Remote mouse receiver

XG-P10XE

VIDEORL AUDIO

Use as a Wireless Mouse

Be sure the supplied remote mouse receiver is connected to your computer.

MOUSE

ADJ.

Slide the MOUSE/ADJUSTMENT switch to MOUSE.

Effective buttons in MOUSE mode

• The wireless mouse may not operate correctly if your computer serial port is not correctly set up. Refer to the computer ’s

• For one-button mouse systems, use either the LEFT-CLICK or RIGHT-CLICK button.

Using the remote control in a dark room

Press BACKLIGHT, and the buttons will light up. Green lights refer to mouse operations, and red lights to projector adjustments.

Button name

LASER POINTER/MENU BLACK SCREEN/LENS

RIGHT-CLICK/ENTER

MOUSE/ADJUSTMENT

LEFT-CLICK

POWER ON/OFF VOLUME+ / -

MUTE

Position of MOUSE/ADJUSTMENT switch

LASER POINTER (GREEN) BLACK SCREEN (GREEN)

RIGHT-CLICK GREEN)

MOUSE (NOT LIT) ON (NOT LIT)

BLACK SCREEN

LASER POINTER

LEFT-CLICK

MOUSE

RIGHT-CLICK

operation manual for details of setting up/installing the mouse driver.

Button name

MOUSE ADJ.

MENU (RED) LENS (RED) ENTER (RED) ADJUSTMENT (NOT LIT)

—

ON (RED)

INPUT UNDO FREEZE AUTO SYNC ENLARGE RESIZE TOOLS GAMMA

Position of MOUSE/ADJUSTMENT switch

MOUSE

ON (RED)

ADJ.

Use as a Laser Pointer

MOUSE

ADJ.

Slide the MOUSE/ADJUSTMENT switch to MOUSE.

Press LASER POINTER (

Wired Remote Control

When the button is released, the light automatically goes off.

• For safety, the laser pointer automatically goes off after 1 minute of continuous use. To turn it on, release LASER POINTER (

CAUTION

) and press again.

3.5 mm stereo minijack cable (sold separately)

) to activate the laser pointer.

When the remote control cannot be used due to the range or positioning of the projector (rear projection, etc.), connect a 3.5 mm stereo minijack cable (sold separately) from the wired remote control input on the bottom of the remote control to the WIRED REMOTE control input terminal on the rear of the projector.

• The laser pointer and wireless mouse functions can still be operated with the wired remote control.

Connection Pin Assignments

Analog Computer 1 and 2 Signal Input Ports: 15-pin mini D-sub female connector

Computer Input

Analog

1. Video input (red)

2. Video input (green/sync on green)

3. Video input (blue)

4. Reserve input 1

5. Composite sync

6. Earth (red)

7. Earth (green/sync on green)

8. Earth (blue)

9. Not connected

10. GND

11. GND

12. Bi-directional data

13. Horizontal sync signal

14. Vertical sync signal

15. Data clock

6 11

Component Input

Analog

1. P

(CR)

2. Y

3. P

(CB)

4. Not connected

5. Not connected

6. Earth (P

)

7. Earth (Y)

8. Earth (P

)

RS-232C Terminal: 9-pin Mini DIN female connector

Pin No. Signal Name I/O Reference

1 CD Not connected 2 RD Receive Data Input Connected to internal circuit 3 SD Send Data Output Connected to internal circuit 4 ER Not connected 5 SG Signal Ground Connected to internal circuit 6 DR Data Set Ready Output Not connected 7 RS Request to Send Output Connected to internal circuit 8 CS Clear to Send Input Connected to internal circuit 9 CI Not connected

Pin No. Signal Name I/O Reference

1 VCC +3.3V (Reserved) Output Not connected 2 RD Receive Data Input Connected to internal circuit 3 SD Send Data Output Connected to internal circuit 4 EXIR Detector of Option Unit Input Not connected

(Reserved) 5 SG Signal Ground Connected to internal circuit 6 ERX IR Receive Signal from Input Not connected

IR Amplifier (Reserved) 7 RS Request to Send Output Connected to internal circuit 8 CS Clear to Send Input Connected to internal circuit 9 ETX IR Transmit Signal Output Not connected

(Reserved)

RS-232C Port: 9-pin D-sub male connector of the DIN-D-sub RS-232C cable

9. Not connected

10. Not connected

11. Not connected

12. Not connected

13. Not connected

14. Not connected

15.

Not connected

XG-P10XE

Dimensions

Rear View

T op View

53 19

Side View

60.5

356

55.5

139

281

261

Front View

17 81

199

Bottom View

Units: mm

REMOVING OF MAJOR PARTS

1.Removing the Intake cover, lamp unit and lens cover.

1-1. Detach the Intake cover. 1-2. Remove the four lock screws off the inner filter frame. Detach the frame. 1-3. Remove the lock screw off the lamp cover. Slide and detach the lamp cover. 1-4. Remove the three lock screws off the lamp unit and detach the lamp unit. 1-5. Remove the lens cover lock screw, and turn and detach the lens cover.

2.Removing the rear cabinet.

2-1. Remove the four lock screws off the terminal board. 2-2. Remove the six lock screws off the rear cabinet. Detach the rear cabinet.

1-1

Intake Cover

XG-P10XE

2-1

Lamp Unit

1-4

1-2

Inner Filter Frame

1-5

Lens Cover

2-2

1-3

Lamp Cover

Rear Cabinet

XG-P10XE

3.Removing the top cabinet.

3-1. Remove the four lock screws off the top cabinet. 3-2. Unhook the top cabinet by pressing the center of both sides of the bottom cabinet as well as the hook on the

front (all marked with `). Slowly lift the back of the cabinet and disconnect the operation key unit connector (KY) and the speaker connector (SP). Then detach the top cabinet.

Operation Key Unit

Top Cabinet

3-1

(SP)

3-2

(KY)

3-1

XG-P10XE

4.Removing the PWB units

4-1. Remove the six lock screws off the PC I/F unit. Lift and detach the unit off the output unit. 4-2. Disconnect the connectors from the output unit. 4-3. Remove the four lock screws off the output units. Remove also the lock screw off the ground fixture and

detach the ground fixture. Lift and detach the output, terminal and signal units.

Optical Mechanism Unit

(FD)

(F)

(AZ)

(FE)

Output Unit

(EA)

(RP)

(GP)

(BP)

(RC) (D)(Q)(L) (FA)(SO)(FB)

4-3

Output Unit

4-1

PC I/F Unit

4-2

Terminal Unit

Ground Fixture

Signal Unit

4-3

Bottom Cabinet

XG-P10XE

5.Removing the optical mechanism unit

5-1. Remove the two lock screws off the lamp socket holder. Detach the holder. 5-2. Disconnect the ground wire from the power unit. 5-3. Disconnect the connector(BA) from AC power switch and connector (PF) from the ballust unit. 5-4. Remove the six lock screws off the optical mechanism unit. Lift and detach the unit.

5-4

Optical Mechanism Unit

5-1

Duct Fan Unit

5-3

(BA)

(PF)

5-2

XG-P10XE

(PA)

(BA)

6-1

6-2

7-1

8-1

to Inlet Unit

Ballast/PFC/ Sound-Out Unit

Inlet Unit

Power Unit

AC Power Switch (for Lamp replacement)

6.Removing the ballast / PFC / sound-out unit assembly.

6-1. Disconnect the ground wire from the inlet unit. 6-2. Remove the two lock screws off the ballast/PFC/sound-out unit assembly. Detach the assembly.

7.Removing the power unit

7-1. Remove the three lock screws off the power PWB. Detach the power unit.

8.Removing the AC power switch and inlet unit.

8-1. Remove the two lock screws off the AC power switch, disconnect the connector (PA) from the inlet unit, and

detach the AC power switch and the inlet unit.

XG-P10XE

RESETTING THE TOTAL LAMP TIMER

When the lamp has been replaced, reset the total lamp timer in the following steps. Resetting procedure

1. While holding down the “ENTER”, “ADJ."” and “ADJ.|” keys on the set at the same time, turn on the POWER ON key.

2. Now the total lamp timer is reset to zero. “000H” appears on the screen.

ENTER ADJ." ADJ.|

Lamp

The lamp in this projector operates for approximately 1,000 cumulative hours, depending on the usage environment. It is recommended that the lamp be replaced after 900 cumulative hours of use or when you notice a significant deterioration of the picture and colour quality . The lamp usage time can be checked with the On-screen Display.

CAUTION

• Intense light hazard. Do not attempt to look into the aperture and lens while the projector is operating.

• As the usage environment can vary significantly, the projector lamp may not operate for 1,000 hours.

Condition

The LAMP REPLACEMENT indicator lights up red, and “LAMP”

” will flash in yellow in the

and “ lower-left corner of the picture.

A significant deterioration of the picture and colour quality occurs.

The power will automatically turn off and the projector will enter standby mode.

“LAMP” and “ the lower-left corner of the picture, and the power will turn of

” will flash in red in

• Lamp has been used for over 900

hours.

• Lamp has been used for over 1,000 hours.

Problem

Possible Solution

• Purchase a replacement lamp unit (lamp/cage module) of the current type BQC-XGP10XE/1 from your nearest Sharp Authorised LCD Projector Dealer or Service Centre.

• Replace the lamp. If you wish, you may have the lamp replaced at your nearest Sharp Authorised LCD Projector Dealer or Service Centre.

THE OPTICAL UNIT OUTLINE

Layout of the optical system

Note: Layout for positioning the optical system.

Projection Lens

1/2λ plate

Sapphire glass Polarizing plate

Incident polarizing plate B

XG-P10XE

1/2λ plate + polarizing plate

Incident polarizing plate R

Dichroic coating (B transmission)

BLUE

AL-coated mirror B

G03 L2

Relay lens 1

Relay lens 2

G02 L2

AL-coated mirror B

AL-deposited face

B-LCD

Cross dichroic prism

G-LCD

Incident polarizing plate G

Marking

BLUE

G01

Relay lens 1

UV-absorption-filter

Condenser lens G

GREEN

G reflector

* M3

R-LCD

Condenser lens R

1/2λ plate

Sapphire glass Polarizing plate

Marking

AR coating

Dichroic coating

PBS(polarization beam splitter)

Dichroic coating (R transmission)

AL-coated mirror R

RED

AL-deposited face

(R reflection)

B/G reflector

* The M3 mirrors have a coating

wedge (for different film thickness). Set up these mirrors, with their markings positioned as shown above, so that their coated faces and both sides be in the correct directions.

UHP lamp

(Light source)

AL-deposited face

PBS aperture

Fly-eye lens (outgoing light)

UV-IR coating

Fly-eye lens (incoming light)

AL-coated mirror W

XG-P10XE

CONVERGENCE AND FOCUS ADJUSTMENT

» Start the convergence and focus adjustments with the top cabinet and the LCD cover

removed but the power on. Use the remote control to adjust the image. Take the following procedures.

1. Focusing the projection lens

(A) Replacing all the 3 LCD panels

1. Before replacing all the 3 LCD panels, project an image on the screen and bring it into focus.

2. Replace the panels with new ones. But until the focus has been completely readjusted, be careful not to change the distance between the set and the screen, nor to move the projection lens focus and zoom rings. If the focus is readjusted with a different positional relation, the relation between the projection distance and the screen size is affected. In other words, a short-distance image (40 WIDE, for example) may get out of the focus range, or a long-distance image (300 WIDE, for example) may come out of focus.

(B) Replacing 1 or 2 of the 3 LCD panels

1. In adjusting the focus after replacement of one or two LCD panels, project an image on the screen and turn the projection lens focus ring to get the non-replaced LCD panel into focus.

2. But until the focus has been completely adjusted for the new LCD panels, be careful not to change the distance between the set and the screen, nor to move the projection lens focus and zoom rings. (If the distance has been changed or the projection lens readjusted, repeat the above steps 1 and 2.)

2. Adjusting the G-LCD panel

(A) Focus adjustment. (Make this adjustment on the white-only screen.)

1. Right-and-left focus adjustment (θY direction) . Loosen the lock screws "b" and "c" and insert the eccentric screwdriver into the notch and hole "b". Turn the screwdriver until the right and left halves on the screen get into focus. First get the right and left halves in balance. Then improve the accuracy while making the adjustment 2 below.

2. Top-center-bottom focus adjustment (θX and Z directions). Loosen the lock screws "a" and "c" and insert the eccentric screwdriver into the notch and hole "a" or "c". Turn the screwdriver until the top, center and bottom on the screen get into focus. In adjusting this top-tobottom focus, temporarily tighten the lock screw "b" to fix the θY direction adjustment.

3. Repeat the above steps 1 and 2 to finely adjust the focus. Finally tighten up all the lock screws.

Notes :

1 Carefully proceed with the focus adjustment because the adjusting directions are correlated. 2 In adjusting the convergence and focus, do not move the projection lens zoom and focus rings until the end

of all the adjustments.

(B) Convergence adjustment

» The G-LCD panel has no convergence adjustment mechanism. Use this panel as convergence adjustment

reference.

3. B-LCD panel adjustment (the same for the R-LCD panel)

(A) Focus adjustment

» T ake the same procedure as for the G-LCD panel focus adjustment. Note that the adjustment range is small

in the Z direction. If the convergence is quite different between the B-LCD and G-LCD panels, roughly adjust the convergence first and then the focus.

(B) Convergence adjustment

» Use a crosshatch pattern signal for this adjustment.

Make the adjustment just for the G-colour and the relevant colour. (1) Loosen the convergence lock screw "d". (2) With the G-LCD panel’s screen center as reference, adjust the B-LCD panel in the X, Y and θZ directions. (3) Finally tighten up the convergence lock screw "d".

Notes :

1 The eccentric cam is used for convergence adjustment. This means that the cam’s turning and the linear

movement are not always uniform.

2 This model is not equipped with the LCD image adjustment mechanism. This is because the dichroic prism

is used for image formation. When the LCD panels all get into the best focus, the images are almost completely converged.

Convergence and Focus Adjustments Mechanism

XG-P10XE

TOP VIEW

Lock screw "a"

Notch and hole "a" (Use an eccentric screwdriver.)

FRONT

R-LCD

B-LCD

θY

Lock screws "c"

Notch and hole "c" (Use an eccentric screwdriver.)

Notch and hole "b" (Use an eccentric screwdriver.)

G-LCD

Lock screw "b" (θY direction)

Notch and hole "c" (Use on eccentric screwdriver.)

SIDE VIEW

G-LCD panel mounting screws

θY

G-LCD

G adjusting plate

SIDE VIEW (from inside)

Eccentric cam (X direction adjustment)

Eccentric cam (Y direction adjustment)

R·B adjusting plate

R·B-LCD

SIDE VIEW (from outside)

Eccentric cam (θZ direction adjustment)

Lock screw "d" (convergence adjustment)

θZ

R·B-LCD

R·B adjusting plate

R·B-LCD panel mounting screws

XG-P10XE

CUT

Convergence and Focus Adjustments at a Glance

Adjustment directions

Adjustment Direction Definition Direction of LCD panel

X direction LCD right and left

Convergence Y direction LCD top and bottom

θZ direction Rotation around Z axis LCD turning axis Z direction LCD optical axis

Focus θX direction Rotation around X axis LCD top-to-bottom flapping

θY direction Rotation around Y axis LCD right-to-left flapping

Convergence and Focus Adjustment for the Optical Mechanism

Colour Adjustment Direction

X direction ±0.8mm Eccentric cam Eccentric cam adjusting wrench d Hex wrench

Convergence Y direction ±0.8mm Eccentric cam Eccentric cam adjusting wrench d Hex wrench

R/B θZ direction ±1° Eccentric cam Eccentric cam adjusting wrench d Hex wrench colours Z direction ±0.8mm

Focus θX direction ±1°

θY direction ±1°

Z direction ±0.2mm

G colour Focus θX direction ±1° Same as for R and B colours

θY direction ±1°

Movement

Position Adjusting tool

Notch and hole "a" & "c" Notch and hole "a" & "c" Notch and hole "b" & "c"

Eccentric screwdriver a, c

Lock screw

a, c b, c

Tightening tool

Phillips screwdriver, *Hex wrench

Focus Adjustments the Other Way

Lock screw Position Related direction

a Notch and hole "a" Z and θX directions b Notch and hole "b" θY direction c Notch and hole "c" Z, θX and θY directions

Convergence and Focus Adjusting and Tightening Tools

Tool Specific or General Tool code Configuration

Eccentric cam Specific 9DASPN-XGNV1U adjusting wrench

Eccentric screwdriver Specific 9EQDRiVER-NV1A

100

9EQLNC-XGNV1U

Hex wrench General (redesigned)

9EQLNC-XGNV4U

Phillips screwdriver General — For M2.6 pan-head machine screw

*Hex wrench General —

Preferably use a 70 mm or longer screwdriver (with a handle).

7.5

XG-P10XE

Replacing the LCDs

With the top cabinet removed

(1)Disconnect the LCD flat cable from the output PWB connector. (2)Remove the lock screws "b" and "c". Detach the R/B adjusting plate or the G adjusting plate together with the LCD

panel. (3)Separate the LCD panel from the adjusting plate. (4)Mount a new LCD panel in the reverse order of the above steps (1), (2) and (3).

~ Readjust the convergence and focus. Note that the G LCD panel needs no convergence adjustment and has

a small adjustment range in the Z direction.

TOP VIEW

Lock screws "c"

R-LCD

FRONT

SIDE VIEW

Lock screws "c"

Lock screws "b"

G-LCD

θY

B-LCD

Lock screws "c"

SIDE VIEW

G adjusting plate

G-LCD

R·B-LCD

R·B adjusting plate

R·B-LCD panel mounting screws

θZ

G-LCD panel

mounting screws

XG-P10XE

Adjusting the optical axis of the mirrors (M1, M5 and M6)

The optical axis must be readjusted if an eclipse happens with the R. G or B mirrors. Generally speaking, this adjustment is needed when any of the internal optical components has been replaced.

Adjustment procedure required when any of the panels has been replaced or the convergence has been adjusted

(1)Disconnect the flat cables of all the LCD panels. (2)Let the lamp light up. (3)To adjust the G mirror, shield the R and B mirrors with shielding plates (You can use a business card or the like to

block the light). (4)Loosen the lock screw of the M1 adjust lever. (5)Looking at the G image on the screen, turn or slide the M1 adjust lever until the eclipse on the screen disappears.

Tighten up the screw. (6)To adjust the R mirror, shield the G and B mirrors and adjust the M5 adjust lever . For the B mirror, shield the R and

G mirrors and adjust the M6 adjust lever.

(Take the same steps 4 and 5 above.) (7)Remove all the shielding plates to have a white image.

Make sure there is no eclipse.

Lock screws

Shielding plate B

adjust lever

slide turn

FRONT

Shielding plate R

Shielding plate G

adjust lever

Lock screws

turn

slide

turn

adjust lever

Lock screws

Adjusting the lamp duct.

Lock screws

Lamp duct

XG-P10XE

turn

Cooling-Fan (Exhaust)

Adjustment procedure reguired when the lamp has been replaced and you can see ununifomity. (Case of Right and Left have ununifomity on the screen)

(1) Let the lamp light up. (2) Receive the white pattern signal at 100%. (3) Loosen the lock screws of the lamp duct. (4) Looking at the white image on the screen, turn the lamp duct until the uniformity comes to best point on the screen. (5) Tighten the lock screws of the lamp duct. (Tighten torque is 10±2kg·cm)

XG-P10XE

Adjustment of incident polarizing plate. (Carry it out when removing polarizingplate.)

Screw C

Notch & Hole C

Notch & Hole B

Screw A

Notch & Hole A

Screw B

(From the condition that the top cabinet opens.)

1.Remove a screws, earth plate from the output PWB.

2.Extend each FFC cable of R, G, B (Using QCNW-4852CEZZ:Extension Cable 32-pin LCD Panel-Output) and try

so that it can move a PWB so that it can see the part which adjusts polarizing plate from the top.

3.Turn on the power, and indicate a black screen on the screen. <Adjusting the G-LCD incident polarizing plate.>

4.Move an output PWB so that you can see screw B and notch & hole B.

5.Put an eccentric screwdriver in notch & hole B, and loosen screw B.

(Loosen it too much, and be careful that the screw doesn't come off.)

6.Adjust with the eccentric screwdriver in the place where a brightness is the lowest, and tighten screw B, and fix it

with seeing a black screen. Adjust it with screw C and notch & hole A when adjusting incident polarizing plate of R-LCD. Adjust it with screw C and notch & hole C when adjusting incident polarizing plate of B-LCD.

❈Adjust it in the turn of Green, Red, Blue with 3 place of RGB as well when adjusting it. ❈Be careful not to make it short-circuit when moving an output PWB.

Colour adjustment

Red

Green

Blue

polarizing plate adjustment polarizing plate adjustment polarizing plate adjustment

Adjustment directionAmount of adjustment. Adjustment place form

θ direction ±1° Notch & Hole A θ direction ±1° Notch & Hole B θ direction ±1° Notch & Hole C

Ajdustment jig Fixing screw Fixed screw tool. eccentric screwdriver eccentric screwdriver eccentric screwdriver

A Phillips screwdriver B Phillips screwdriver C Phillips screwdriver

XG-P10XE

ELECTRICAL ADJUSTMENT

Hook up a signal generator, or a DOSV or Mac personal computer to the projector in order to feed the signals specified in the Adjusting conditions.

No. Adjusting point Adjusting conditions Adjusting procedure

1 EEPROM

initialization

1. Turn on the power (make sure the lamp lights up) and warm up the unit for 15 minutes.

» Make the following settings:

Press S2601 to call up the process mode and execute S2 and S4 in the SSS menu. Now the system, with the PC board not included, is initialized. Do not execute S1 because otherwise the PC board will be initialized. To adjust the PC board, follow the instruction in "Adjusting the PC Interface". (See page 32)

2 3.3V power

supply adjustment

3 2.6V power

supply adjustment

4 R drive 1. Make the following choice.

1. Turn on the power.

2. Connect the digital voltmeter to TP7201.

1. Turn on the power.

2. Connect the digital voltmeter to TP7202.

Group : A/D

2. Feed the 100% red-only signal. Make the following choice. Group : A/D Subject : R-D

» Adjust VR704 so that the voltmeter should read

3.300 V ±100 mV.

» Adjust R705 so that the voltmeter should read

2.600 V ±50 mV.

» Using the control switches or the remote controller

buttons, adjust the data so that the signal becomes bit-less (noise).

5 B drive 1. Feed the 100% blue-only

signal. Make the following choice. Group : A/D Subject : B-D

6 G drive 1. Feed the 100% green-only

signal. Make the following choice. Group : A/D Subject : G-D

» Using the control switches or the remote controller

buttons, adjust the data so that the signal becomes bit-less (noise).

» Using the control switches or the remote controller

buttons, adjust the data so that the signal becomes bit-less (noise).

XG-P10XE

No. Adjusting point Adjusting conditions Adjusting procedure

7 RGB 1 system

black level signal amplitude (odd-numbered)

8 Offset voltage

adjustment

1. Make the following choice: Group : OUTPUT 1 Subject : R1-BLK

R1-GAIN

For green, choose the sub-

jects G1-BLK and G1-

GAIN. For blue, choose the subjects B1-BLK and B1-GAIN.

2. Connect the oscilloscope to TP1101 for red.

TP1201 for green TP1301 for blue

1. Feed the 50% R, G, B pattern signal.

2. Select the following subject. Group : OUTPUT2 Subject : R-OFFSET

Select the subjects G-OFFSET and B-OFFSET for the green and blue colours, respectively.

» Choose the subject R1-GAIN and adjust the sig-

nal amplitude to 3.25 ±0.03 Vp-p using the control switches or the remote controller buttons.

» Next, choose the subject R1-BLK and adjust the

white peak level to 2.25Vp-p ±0.02V.

2.25Vp-p

» Make the same adjustments for green and blue.

» Using the control switches or the remoto controller

buttons, adjust the every 6 dots vertical lienes are same brightness.

3.25Vp-p

9 P SIGNAL 1. Connect the oscilloscope to

TP1102 for red.

TP1202 for green TP1302 for blue.

2. Make the following choice: Group : OUTPUT 2 Subject : PSIG-H

: PSIG-L

10 Sample-and-

hold pulse phase RCK-PHASE GCK-PHASE BCK-PHASE

1. Feed the XGA mode 75-Hz black signal.

2. Make the following choice: Group : OUTPUT 3 Subject : SH-PHASE (Have the standard level at

8.) Fix the RCK-, GCK- and BCK-PHASE settings all to

» Adjust the PSIG waveform to the one shown below.

PSIG

2.5V DC 5.0V DC (Adjust with PSIG-L.)(Adjust with PSIG-H.)

GND

» For the green and blue colours, make sure their wave-

forms are similar to that of the red colour.

» Using the control switches or the remote controller

buttons, make sure that the “OUTPUT 3” characters are not blurry and there is no ghost image. If such blur or ghost occurs, finely adjust the setting in the range of 7~9.

No. Adjusting point Adjusting conditions Adjusting procedure

XG-P10XE

11 RGB counter-

voltage adjustment

12 RGB gradation

regeneration adjustment

13 RGB white

balance

1. Feed the black-and-red (25%) stripe signal (XGA).

2. Make the following choice: Group : OUTPUT 3 Subject : RC (R)

1. Feed the INFO COM. gray scale and colour bar pattern.

2. Make the following choice: Group : OUTPUT 1 Subject : G1-BLK

1. Feed the 32-step gray scale signal (XGA 60Hz). Group : OUTPUT 1 Subject : R1-BLK (R)

R1-GAIN(R) B1-BLK (B) B1-GAIN(B)

» Using the control switches or the remote controller

buttons, adjust the data in order to minimize the flicker.

» Make the same adjustment for BC (B) and GC (G). » See if the image is equally adjusted at the center

and both sides of the screen. If not, readjust the setting to have the image equal at right and left.

» Make sure that scale (white side) to No.251 and

scale (black side) to No.8 can be seen.

» If white scale can't be seen properly, readjust with

G1-BLK.

4812

249 251

» Adjust the R1-BLK and B1-BLK data for the black

balance on the gray scale. Then adjust the R1GAIN and B1-GAIN data for the center-to-white balance on the gray scale. (Adjust to the best point.)

14 Horizontal

center

15 Video picture

adjustment

1. Feed the NTSC monoscope pattern signal.

2. Group : VIDEO 2 Subject : N358-DLY (0)

N443-DLY (0) PAL-DLY (3) SECAM-DLY (0)

Make sure the settings are

as above.

3. Group : VIDEO 1 Subject : NTSC-H

1. Feed the split colour bar signal. Group : VIDEO 1 Subject : PICTURE

2. Connect the oscilloscope between pin (1) of P801 and GND.

» Using the control switches or the remote controller

buttons, adjust the data to have the same overscan.

» Using the control switches or the remote controller

buttons, adjust the black-to-white (100%) level difference to 1.2 ±0.03 Vp-p.

100% White

1.2Vp-p

XG-P10XE

100% White Red

No. Adjusting point Adjusting conditions Adjusting procedure

16 Video OFFSET

adjustment

1. Feed the split colour bar signal. Group : VIDEO 2 Subject : VBOS(R)

VROS(G) VROS(B)

2. Press the control switch or mute button of R/C. (GAMMA compensation is set up for the process.).

» Using the control switches or the remote controller

buttons, adjust the black portion of the signal becomes bit-less.

17 Video AGC

18 Video

brightness adjustment

19 Tint

1. Feed the split colour bar signal. Group : VIDEO 1 Subject : AGC

2. Press the control switch or the remote control’s mute button (to set the gamma correction to the process setting).

1. Feed the baseband (split colour bar) signal. Group : VIDEO 1 Subject : BRIGHT

2. Press the control switch or the remote control’s mute button (to set the gamma correction to the process setting).

1. Feed the split colour bar signal. Group : VIDEO 1 Subject : TINT

» Using the control switches or the remote controller

buttons, adjust the 100% portion of white signal becomes bit-less .

» Using the control switches or the remote controller

buttons, adjust the setting until the black signal becomes bit-less.

» Using the control switches or the remote controller

buttons, adjust the data to have the -(B-Y) waveform downhill straight.

20 NTSC colour

saturation level

2. Connect the oscilloscope to pin (4) of P801.

1. Feed the split colour bar signal. Group : VIDEO 1 Subject : N-COLOR

2. Connect the oscilloscope to pin (1) of P801.

» Using the control switches or the remote controller

buttons, adjust the difference between the 100% white portion and the red portion to 0.10 ±0.02 Vp-p.

(same as 100% white)

No. Adjusting point Adjusting conditions Adjusting procedure

XG-P10XE

21 PAL colour

saturation level

22 SECAM colour

saturation level

1. Feed the PAL colour bar signal. Group : VIDEO 1 Subject : P-COLOR

2. Connect the oscilloscope to pin (1) of P801.

1. Feed the SECAM colour bar signal. Group : VIDEO 1 Subject : S-COLOR

2. Connect the oscilloscope to pin (1) of P801.

» Using the control switches or the remote controller

buttons, adjust the difference between the 100% white portion and the red portion to 0.20 ±0.01 Vp-p.

100% White Red

» Using the control switches or the remote controller

buttons, adjust the data to have a level difference of 0.20 ±0.01 Vp-p between the 100% white portion and the red portion.

100% White Red

23 Video white

balance

24 DVD Contrast 1. Feed the colour bar signal

25 DVD Tint 1. Feed the colour bar signal

1. Feed the NTSC monoscope pattern signal Group : VIDEO 2 Subject : R1-GAIN

B1-GAIN

of the 480I component signal to the BNC G(Y) input terminal.

2. Select the following subject. Group : DVD Subject : CONTRAST

of the 480I component signal to the BNC Y, Pb and Pr input terminals. Feed the sync signal only for the Y signal.

2. Select the following subject. Group : DVD Subject : TINT

» Using the control switches or the remote controller

buttons, adjust so that the entire screen looks evenly colourless.

» Using the control switches or the remote controller

buttons, adjust the 100% portion of white signal becomes bit-less .

» Using the control switch or the button on the

remote controller, adjust the B-Y waveform to form a straight slope.

3. Connect the oscilloscope to pin (2) of P801.

XG-P10XE

No. Adjusting point Adjusting conditions Adjusting procedure

26 DVD Colour 1. Feed the colour bar signal

of the 480I component signal to the BNC G(Y) input terminal.

2. Select the following subject. Group : DVD Subject : COLOR

3. Connect the oscilloscope to pin (1) of P801.

27 DVD input

system panel signal amplitude adjustment

1. Feed the 10 step signal to G(Y) terminal of BNC terminal.

2. Select the following subject. Group : DVD Subject : R1-GAIN

B1-GAIN

3. Connect the oscilloscope toTP1101(R) and TP1201 (G)

» Adjust the level difference between the 100% white

and red portions to 0.13 ±0.02 Vp-p.

100% White Red

» Choose R1-GAIN, and adjust so that the amplitude

of the R signal and the amplitude of the G signal may become the same.

» As for blue as well, adjust it in the same way.

28 DVD White

balance adjuustment

29 Colour

irregularity correction position

30 Colour

irregularity correction gain (in case of colourirregularity)

4. Connect the oscilloscope toTP1301(B) and TP1201 (G)

1. Feed the NTSC monoscope signal to G(Y) input terminal of the BNC terminal.

2. Select the following subject. Group : DVD Subject : R1-BLK

B1-BLK

1. Feed the gray-only RGB colour signal. (XGA 60Hz)

2. Find the colour irregularity position on the screen.

3. Group : NOKO Subject : NOKO-RL

1. Feed the gray-only RGB colour signal. (XGA 60Hz)

» Adjust so that a white balance may become the best

condition by using the control switch or buttons of the R/C.

» If the colour is irregular, adjust the NOKO-RL data.

Set it to R for the right-hand colour irregularity and to L for the left-hand one.

» If there is no colour irregularity, turn off the saw-

tooth correction using SW4201.

» Adjust R4215 to minimize the right-hand and left-

hand colour irregularity.

+ 89 hidden pages

SHARP XG-P10XE Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
