Sharp UX-P115 User Manual

MODEL

UX-P115

1. Installation

2. Sending Faxes

3. Receiving Faxes

4. Making Copies

5. Special Functions

6. Printing Lists

7. Maintenance

8. Troubleshooting

FACSIMILE

OPERATION MANUAL

WARNING - FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and the receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

ABOUT THE TELEPHONE CONSUMER PROTECTION ACT OF 1991

"The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device to send any message via a telephone facsimile machine unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission the following information:

(1) The date and time of transmission.

(2) Identification of either the business, business entity or individual sending the message.

(3) Telephone number of either the sending machine, business, business entity or individual.

In order to program this information into your facsimile machine, please refer to the appropriate instructions in the operation manual."

ENERGY STA R

As an determined that this product meets the ENERGY

STA R

guidelines for energy efficiency.

partner, SHARP has

FOR YOUR RECORDS

Please record the model number and serial number below, for easy reference, in case of loss or theft. These numbers are located on the rear side of the unit.Space is also provided for other relevant information.

Model Number UX-P115 Serial Number Date of Purchase Place of Purchase

Introduction

Welcome, and thank you for choosing a Sharp fax machine! The features and specifications of your new Sharp fax are shown below.

Automatic dialing 30 numbers

Imaging film Initial starter roll (included with machine):

32 ft. (10 m) (approx. 30 letter-size pages)

Replacement roll (not included):

UX-5CR 164 ft. (50 m) (one roll yields

approx. 150 letter-size pages)

Memory size* 448 KB (approx. 24 average pages)

Modem speed 9,600 bps with automatic fallback to lower

speeds.

Transmission time* Approx. 15 seconds

Resolution Horizontal: 203 pels/inch (8 pels/mm)

Vertical:

Standard: 98 lines/inch (3.85 lines/mm) Fine /Halftone:

196 lines/inch (7.7 lines/mm)

Super fine:

391 lines/inch (15.4 lines/mm)

Automatic document feeder

Recording system Thermal transfer recording

Halftone (grayscale) 64 levels

Compression scheme MR, MH, Sharp(H2)

Display 16-digit LCD display

Applicable telephone line Public switched telephone network

*Based on Sharp Standard Chart at standard resolution in Sharp special mode, excluding time for protocol signals (i.e., ITU-T phase C time only)

10 pages max. (letter/A4, 20 lb paper)

Paper tray capacity Letter: Approx. 50 sheets (20-lb. copier paper

at room temperature; maximum stack height should not be higher than the line on the tray) Legal: 5 sheets Recommended paper weight is 20-lb. Copy Bond

Compatibility ITU-T (CCITT) G3 mode

Input document size Automatic feeding:

Width: 5.8 to 8.5" (148 to 216 mm) Length: 5.5 to 11" (140 to 279 mm)

Manual feeding:

Width: 5.8 to 8.5" (148 to 216 mm) Length: 5.5 to 23.6" (140 to 600 mm)

Effective scanning width 8.3" (210 mm) max.

Effective printing width 8.3" (210 mm) max.

Contrast control Automatic/Dark selectable

Reception modes TEL/FAX

Copy function Single / Multi (99 copies/page)

Telephone function Yes (cannot be used if power fails)

Power requirements 120 V AC, 60 Hz

Operating temperature 41 - 95 °F (5 - 35°C)

Humidity 25 - 85 % RH

Power consumption Standby: 3.6 W

Maximum: 100 W

Dimensions (without attachments)

Width: 12.9" (327 mm) Depth: 7.6" (193 mm) Height: 6.4" (163 mm)

Weight (without

Approx. 6.2 lbs. (2.8 kg)

attachments)

As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

Important safety information

Do not disassemble this machine or attempt any procedures not described in this manual. Refer all servicing to qualified service personnel.

Do not install or use the machine near water, or when you are wet. For example, do not use the machine near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool. Take care not to spill any liquids on the machine.

Unplug the machine from the power outlet and telephone jack and consult a qualified service representative if any of the following situations occur:

- Liquid has been spilled into the machine or the machine has been exposed to rain or water.

- The machine produces odors, smoke, or unusual noises.

- The power cord is frayed or damaged.

- The machine has been dropped or the housing damaged.

Do not allow anything to rest on the power cord, and do not install the machine where people may walk on the power cord.

This machine must only be connected to a 120 V, 60 Hz, grounded (3-prong) outlet. Connecting it to any other kind of outlet will damage the machine and invalidate the warranty.

Never insert objects of any kind into slots or openings on the machine. This could create a risk of fire or electric shock. If an object falls into the machine that you cannot remove, unplug the machine and consult a qualified service representative.

Do not place this machine on an unstable cart, stand or table. The machine could be seriously damaged if it falls.

Never install telephone wiring during a lightning storm.

Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

Never touch bare telephone wires or terminals unless the telephone line has been disconnected at the network interface.

Use caution when installing or modifying telephone lines.

Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.

Do not use a telephone to report a gas leak in the vicinity of the leak.

The power outlet must be installed near the equipment and must be easily accessible.

Table of Contents

A Look at the Operation Panel 6

1. Installation 8

Unpacking Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Loading the Imaging Film . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Loading Printing Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Entering Your Name and Fax Number . . . . . . . . . . . . . . . . . . . . . . . 16

Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setting the Reception Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2. Sending Faxes 23

Transmittable Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Loading the Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Adjusting the Resolution and Contrast . . . . . . . . . . . . . . . . . . . . . . . 25

Sending a Fax by Normal Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Sending a Fax by Automatic Dialing. . . . . . . . . . . . . . . . . . . . . . . . . 28

Sending a Fax From Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

3. Receiving Faxes 40

Using FAX Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Using TEL Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Optional Reception Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Substitute Reception to Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

4. Making Copies 47

5. Special Functions 49

Caller ID (Requires Subscription to Service) . . . . . . . . . . . . . . . . . . 49

Distinctive Ring (Requires Subscription to Service) . . . . . . . . . . . . . 54

Blocking Reception of Unwanted Faxes. . . . . . . . . . . . . . . . . . . . . . 56

Polling (Requesting a Fax Transmission). . . . . . . . . . . . . . . . . . . . . 57

Table of Contents

6. Printing Lists 58

7. Maintenance 61

8. Troubleshooting 64

Problems and Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Messages and Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Clearing Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Ordering Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

FCC Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Quick Reference Guide 77

Guía de referencia rápida 78

Index 79

A Look at the Operation Panel

1 2 3 4 5 86 9

SPEAKER

STOP

COPY/HELP

START/MEMORY

SPEAKER key

Press this key to listen to the line and fax tones through the speaker when

RESOLUTION/

RECEPTION MODE

FLASH

POLL

HOLD

SPEED

1210 11

REDIAL

TEL FAX

FUNCTION

GHI

PQRS

ABC1DEF

2 3

JKL

TUV

WXYZ

MNO

faxing a document (page 27). Note: This is not a speakerphone. You must pick up the handset to talk with the other party.

RESOLUTION / RECEPTION MODE key

When a document is in the feeder, press this key to adjust the resolution for faxing or copying (page 25). At any other time, press this key to select the reception mode (an arrow in the display will point to the currently selected reception mode; page 20).

FLASH key

This key is used for Call Waiting and other special services that require subscription from your phone company. Your phone company will provide you with details on how to use the key.

POLL key

Press this key after dialing another fax machine to receive a document (previously loaded in the other machine’s feeder) without assistance from the operator of the other machine (page 57).

HOLD key

Press this key to put the other party on hold during a phone conversation (page 43).

Display

This displays messages and prompts to help you operate the machine.

UP and DOWN arrow keys

Enlarge/reduce setting: When making a copy of a document, press these keys to select an enlarge/reduce setting (page 47). Volume setting: When a document is not in the feeder, press these keys to change the handset volume when the handset is lifted, the speaker volume when the SPEAKER key has been pressed, or the ringer volume at any other time (page 21). FUNCTION key settings: Press these keys after pressing the FUNCTION key to scroll through the FUNCTION MODE settings.

Number keys

Use these keys to dial numbers, and enter numbers and letters when storing auto-dial numbers.

Panel release

Press this release to open the operation panel.

STOP key

Press this key to cancel an operation before it is completed.

COPY/HELP key

When a document is in the feeder, press this key to make a copy of a document (page 47). At any other time, press this key to print out the Help List, a quick reference guide to the operation of your fax machine.

START/MEMORY key

Press this key after dialing to begin fax transmission (page 27). Press this key before dialing to send a fax through memory (page 37).

SPEED key

Press this key to dial a fax or voice number using an abbreviated 2-digit Speed Dial number (pages 29 and 33).

Left and right arrow keys

Auto-dial numbers: When sending a fax or making a phone call, press these keys to scroll through your auto-dial numbers (page 34), the “REVIEW CALLS” list (only available if you have Caller ID; page 51), and the last number dialed (redial; page 36). FUNCTION key settings: Press the right arrow key after scrolling with the up and down arrow keys to select a FUNCTION key setting.

FUNCTION key

Press this key followed by the arrow keys to select special functions and settings.

1. Installation

Unpacking Checklist

Before setting up, make sure you have all of the following items.

Paper tray Paper tray

extension

Handset Handset cord

Operation manual

Telephone line cord

Points to keep in mind when setting up

If any are missing, contact your dealer or retailer.

Gears (2)

Imaging film (initial starter roll)

Do not place the machine in direct sunlight.

About condensation

If the machine is moved from a cold to a warm place, it is possible that condensation may form on the scanning glass, preventing proper scanning of documents for transmission. To remove the condensation, turn on the power and wait approximately two hours before using the machine.

Do not place the machine near heaters or air conditioners.

Keep dust away from the machine.

Keep the area around the machine clear.

Connections

Connecting the handset

Connect the handset as shown and place it on the handset rest.

♦ The ends of the handset cord are identical, so they will go into either jack.

Make sure the handset cord goes into the jack marked with a handset symbol on the side of the machine!

Use the handset to make ordinary phone calls, or to transmit and receive faxes manually.

Connecting the power cord

1. Installation

Plug the power cord into a 120 V, 60 Hz, grounded AC (3-prong) outlet.

Caution!

Do not plug the power cord into any other kind of outlet. This will damage the machine and is not covered under the warranty.

The machine does not have a power on/off switch, so the power is turned on and off by simply plugging in or unplugging the power cord.

Connections

Connecting the telephone line cord

Insert one end of the line cord into the jack on the back of the machine marked TEL. LINE. Insert the other end into a standard (RJ11C) single-line wall telephone jack.

TEL.LINE

Setting the dial mode

The fax machine is set for tone dialing. If you are on a pulse dial line, you must set the fax machine for pulse dialing. Press the keys on the operation panel as follows:

FUNCTION

Press once and once.

Press once and twice.

Press once.

Select the dial mode:

TONE: PULSE:

Press to exit.

STOP

Display:

OPTION SETTING

DIAL MODE

1=TONE, 2=PULSE

The display briefly shows your selection, then:

DISTINCTIVE

Comments:

♦ The fax machine is not designed for use on a line which has call waiting,

call forwarding, or certain other special services offered by your telephone company. If you attempt to use the fax machine in conjunction with any of these services, you may experience errors during transmission and reception of facsimile messages.

♦ The fax machine is not compatible with digital telephone systems.

♦ If your area experiences a high incidence of lightning or power surges, we

recommend that you install surge protectors for the power and telephone lines. Surge protectors can be purchased at most telephone specialty stores.

Attach the paper tray and paper tray extension

Attach the paper tray.

Connections

1. Installation

Attach the paper tray extension.

Insert horizontally and rotate up

Note: The paper tray extension has a top side and a bottom side. If you cannot insert the tabs into the holes, turn the support over.

Click!

Loading the Imaging Film

Your fax uses a roll of imaging film to create printed text and images. The print head in the fax applies heat to the imaging film to transfer ink to the paper. Follow the steps below to load or replace the film.

The initial starter roll of imaging film included with your fax can print about 30 letter-size pages.

Remove the paper from the paper tray and open the operation panel (press

➊).

If you are loading the imaging film for the first time, go to Step 4.

Remove the used film and empty spool.

When replacing the film, use a roll of Sharp UX- 5CR imaging film. One roll can print about 150 letter-size pages.

Use only Sharp Genuine Supplies with this logo:

Remove the two green gears from the spools.

DO NOT DISCARD THE TWO GREEN GEARS!

Loading the Imaging Film

Remove the new roll of imaging film from its packaging.

• Cut the band that holds the rolls

together.

Insert the green gears.

Make sure the gears fit into the slots in the ends of the rolls.

Insert the film into the print compartment.

Thick roll to rear

1. Installation

1 slot

2 slots

Fit ends of rolls onto hubs

Rotate the front gear as shown until the film is taut.

Close the operation panel (press down on both sides to make sure it clicks

into place).

Loading Printing Paper

You can load letter or legal size paper in the paper tray. Recommended paper weight is 20-lb. Copy Bond. The maximum number of sheets is as follows:

Letter size:

Legal size:

Fan the paper, and then tap the edge against a flat surface to even the stack.

Make sure the stack edges are even.

Insert the stack of paper into the tray,

• If paper remains in the tray, take it out and combine it into a single stack

with the new paper.

• Be sure to load the paper so that printing takes place on the print side of

the paper. Printing on the reverse side may result in poor print quality.

Approx.

maximum stack height should not be higher than the line on the tray)

5 sheets

50 sheets (

20-Ib.

copier paper at room temperature;

PRINT SIDE DOWN

•

GENTLY LOAD PAPER INTO THE PAPER TRAY

•

DO NOT FORCE IT DOWN INTO THE FEED SLOT

The stack should not be higher than this line

Note: Do not use paper that has already been printed on, or paper that is curled.

Note: If at any time the display shows the

alternating messages at right, check the printing paper. If the tray is empty, add paper. If there is paper in the tray, take it out and then reinsert it.

When you are finished, press .

START/MEMORY

ADD PAPER &

PRESS START KEY

Loading Printing Paper

Setting the paper size

The fax has been set at the factory to scale received faxes to letter size paper. If you loaded legal paper, you must change the paper size setting to LEGAL.

1. Installation

FUNCTION

Press once and once.

Press once and twice.

Press once.

Select the paper size:

LETTER: LEGAL:

Press to return to the date and time display.

STOP

Display:

OPTION SETTING

PAPER SIZE SET

1=LETTER,2=LEGAL

The display briefly shows your selection, then:

COPY CUT-OFF

Print contrast setting

Your fax has been set at the factory to print at normal contrast. If desired, you can change the print contrast setting to LIGHT.

FUNCTION

Press once and once.

Display:

OPTION SETTING

Press once and 3 times.

Press once.

Select the print contrast:

NORMAL: LIGHT:

Press to return to the date and time display.

STOP

PRINT CONTRAST

1:NORMAL

The display briefly shows your selection, then:

PAPER SIZE SET

Entering Your Name and Fax Number

Before you can begin sending faxes, you must enter your name and fax (telephone) number. You also need to set the date and time.

Important!

FCC regurations require that your name, telephone/fax number, and the date and time appear on each fax message you send. Enter your name and fax number here and set the date and time as explained in the following section to have the fax machine include this information automatically at the top of your fax messages.

STOP

Once you enter this information, it will automatically appear at the top of each fax page you send.

2 3

5 6

START/MEMORY

FUNCTION

Press once and twice.

Press once.

FUNCTION

Display:

ENTRY MODE

OWN NUMBER SET

ENTER FAX #

Entering Your Name and Fax Number

Enter your fax number by pressing the number keys (max. 20 digits).

• To insert a space between digits, press .

1. Installation

• To clear a mistake, press .

START/MEMORY

Press to enter the fax number in memory.

Enter your name by pressing number keys for each letter as shown in

SPEAKER

the chart below. Up to 24 characters can be entered.

Example: SHARP = 7777 44 2 777 7

SPACE =

A =

B =

C =

D =

E =

F =

G =

H =

I =

J =

K =

L =

M =

N =

O =

P =

Q =

R =

S =

T =

U =

V =

W =

X =

Y =

Z =

♦ To enter two letters in succession that require the same key, press

after entering the first letter.

♦ To clear a mistake, press .

SPEAKER

♦ To enter a lower case letter, continue pressing the key for the letter until the

lower case letter appears. To enter one of the following symbols, press

or repeatedly: . / ! " # $ % & ’ ( ) + + , - : ; < = > ? @ [ ¥ ] ^ _ ' { | }

START/MEMORY

Press

Press to return to the date and time display.

STOP

Display:

DATE&TIME SET

) (

Setting the Date and Time

The date and time appear in the display and are printed at the top of every page you fax. Set the date and time as shown below.

STOP

2 3

5 6

START/MEMORY

FUNCTION

Press once and twice.

Press once and once.

The currently set date

Press once.

Enter a two-digit number for the month (“01” for January, “02” for February, “12” for December, etc.).

Example: January

0 1

appears (example):

FUNCTION

Display:

ENTRY MODE

DATE&TIME SET

DATE 08-15-2004

DATE 01-15-2004

• To correct a mistake, press to move the cursor back to the mistake and

then enter the correct number.

Enter a two-digit number for the day (“01” to “31”).

Example: the 5

0 5

DATE 01-05-2004

Setting the Date and Time

Enter the year (four digits).

Example: 2004

Enter a two-digit number for the hour (“01” to “12”) and a two-digit number for the minute (“00” to “59”).

Example: 9:25

Press to select A.M. or to select P.M.

START/MEMORY

Press to start the clock.

Press to return to the date and time display.

STOP

0 9

0 0 4

The currently set time appears (example):

TIME 12:19 PM

TIME 09:25 PM

ANTI JUNK #

Daylight Saving Time

If desired, you can set the clock to move forward and backward automatically at the beginning and end of Daylight Saving Time. Follow these steps:

1. Installation

FUNCTION

Press once and once.

Press once and 5 times.

Press once.

Press to select YES, or to select NO.

Press to return to the date and time display.

STOP

OPTION SETTING

DAY LIGHT SAVE

1=YES, 2=NO

RECEIVE RATIO

Setting the Reception Mode

Your fax has two modes for receiving incoming faxes:

FAX mode: Select this mode when you only want to receive faxes on your line. The fax machine will automatically answer all calls on four rings and receive incoming faxes.

TEL mode: Select this mode when you want to receive both phone calls and faxes on the line connected to the fax machine. All calls, including faxes, must be answered by picking up the fax machine's handset or an extension phone connected to the same line.

Setting the reception mode

Make sure a document

RESOLUTION/

RECEPTION MODE

press until the arrow in the display points to the desired mode.

is not loaded in the document feeder

, and then

♦ Note: When a document is loaded in the document feeder, pressing

RESOLUTION/

RECEPTION MODE

RESOLUTION/

RECEPTION MODE

For more information on receiving faxes in FAX and TEL modes, see Chapter

Receiving Faxes

adjusts the resolution for faxing and copying.

RESOLUTION/

2 3

5 6

RECEPTION MODE

(page 40).

TEL

JAN-01 10:30

TEL

JAN-01 10:30

FAX

Volume Adjustment

You can adjust the volume of the speaker, handset, and ringer using the up and down arrow keys.

SPEAKER

2 3

5 6

Speaker

SPEAKER

Press

Press or until the display shows the desired volume level.

Display:

SPEAKER: HIGH

1. Installation

• Press again to turn off the

SPEAKER

speaker.

SPEAKER: MIDDLE

SPEAKER: LOW

Volume Adjustment

Handset

When talking through the handset,

press or until the display shows the desired volume level.

Display:

RECEIVER: HIGH

• Note: The volume reverts to MIDDLE

each time you replace the handset.

Ringer

Press or .

(Make sure has not been pressed, the handset is not lifted, and a

document is not loaded in the feeder.)

• The ringer will ring once at the selected

level, then the date and time will reappear in the display.

If you selected RINGER: OFF OK ?,

press .

SPEAKER

START/MEMORY

RECEIVER: MIDDLE

RECEIVER: LOW

Display:

RINGER: HIGH

RINGER: MIDDLE

RINGER: LOW

RINGER: OFF OK ?

2. Sending Faxes

Transmittable Documents

Size and weight

The size and weight of documents that you can load in the document feeder depend on whether you load one page at a time or several pages at once.

Loading one page at a time:

Minimum size

5.8" (148 mm)

5.5" (140 mm)

Maximum size

8.5"

(216 mm)

(600 mm)

Minimum weight Maximum weight

14 lbs. (52 g/m² )

42 lbs. (157 g/m²)

23.6"

Loading up to 10 pages at once:

Minimum size Maximum size

5.8" (148 mm)

5.5" (140 mm)

8.5" (216 mm)

Minimum weight Maximum weight

14 lbs. (52 g/m² )

21.5 lbs. (80 g/m²)

Note: Letters or graphics on the edges of a document will not be scanned.

11" (279 mm)

Faxes

2. Sending

0.2"(5 mm)

8.3"(210 mm)

0.2"(5 mm)

Letters in the shaded area will not be scanned.

Note: The full width of documents less than

8.3” (210 mm) wide is scanned.

Loading the Document

Other restrictions

♦ The scanner cannot recognize yellow, greenish yellow, or light blue ink.

♦ Ink, glue, and correcting fluid on documents must be dry before they pass

through the document feeder.

♦ All clips, staples, and pins must be removed from documents before loading

in the feeder. If these are not removed, they may damage the machine.

♦ Documents which are patched, taped, torn, smaller than the minimum size,

carbon backed, easily smudged, or have a slippery coated surface should be photocopied, and the copy loaded in the feeder.

Loading the Document

Up to 10 pages can be placed in the feeder at one time. The pages will automatically feed into the machine starting from the bottom page.

♦ If you need to send or copy more than 10 pages, place the additional pages

gently and carefully in the feeder just before the last page is scanned. Do not try to force them in, as this may cause double-feeding or jamming.

♦ If your document consists of several large or thick pages which must be

loaded one at a time, insert each page into the feeder as the previous page is being scanned. Insert gently to prevent double-feeding.

Adjust the document guides to the width of your document.

Insert the document face down in the document feeder. The top edge of the

document should enter the feeder first.

• READY TO SEND will appear in the

display.

+ 58 hidden pages
