Sharp LC 60LE640U, LC 70LE640U, LC 52LE640U, LC-70C640U, LC-60C640U User Manual

Download

LC-80LE633U

ENGLISHFRANÇAISESPAÑOL

ENGLISHFRANÇAISESPAÑOL ENGLISHFRANÇAISESPAÑOL

LC-70LE640U LC-60LE640U LC-52LE640U

LIQUID CRYSTAL TELEVISION TÉLÉVISEUR ACL TELEVISOR CON PANTALLA

DE CRISTAL LÍQUIDO

OPERATION MANUAL MODE D'EMPLOI MANUAL DE OPERACIÓN

LC-70C6400U LC-60C6400U LC-52C6400U

IMPORTANT : Please read this operation manual before starting operating the equipment.

IMPORTANT : Veuillez lire ce mode d'emploi avant de commencer à utiliser l'appareil.

IMPORTANTE : Lea este manual de operación antes de comenzar a operar el equipo.

LC-80LE633U LC-70LE640U LC-60LE640U LC-52LE640U

LC-70C6400U LC-60C6400U LC-52C6400U

LIQUID CRYSTAL TELEVISION

ENGLISH

OPERATION MANUAL

IMPORTANT: To aid reporting in case of loss or theft, please record the TV's model and serial numbers in the space provided. The numbers are located at the rear and right side of the TV.

Model No.:

Serial No.:

IMPORTANT INFORMATION

ENGLISH

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

The lightning ﬂash with arrow-head

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

CAUTION:

WARNING: FCC Regulations state that any unauthorized changes or modiﬁcations to this equipment not expressly

approved by the manufacturer could void the user's authority to operate this equipment.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product's enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

IMPORTANT INFORMATION

CAUTION:

This product satisﬁes FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.

DECLARATION OF CONFORMITY:

SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-80LE633U/LC-70LE640U/LC-60LE640U/ LC-52LE640U/LC-70C6400U/LC-60C6400U/LC-52C6400U This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RESPONSIBLE PARTY:

For Business Customers: URL http://www.sharpusa.com

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07495-1163 TEL: 1-800-BE-SHARP

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Wireless Radio

For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible. This device is going to be operated in 5.15–5.25GHz frequency range, it is restricted in indoor environment only. Important: Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Wireless Radio

For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible. The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure. Note that this is not intended to prohibit transmission of control or signaling information or the use of repetitive codes where required by the technology. Important: Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

“Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820 of the National Electrical Code that provides guidelines for proper grounding and, in particular, speciﬁes that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”

This product qualiﬁes for ENERGY STAR when "Home" is selected for "TV Location". Setting "TV Location" to "Home" allows the TV to achieve an energy-saving status for household use.

DEAR SHARP CUSTOMER

Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years of trouble-free operation of your product, please read the Important Safety Instructions carefully before using this product.

IMPORTANT SAFETY INSTRUCTIONS

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or ﬁre. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully before using the product.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories speciﬁed by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Additional Safety Information

15) Power Sources—This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

16) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of ﬁre or electric shock.

17) Object and Liquid Entry—Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a ﬁre or electric shock. Never spill liquid of any kind on the product.

18) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualiﬁed service personnel under the following conditions:

a) When the AC cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the product, c) If the product has been exposed to rain or water, d) If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment

of other controls may result in damage and will often require extensive work by a qualiﬁed technician

to restore the product to its normal operation, e) If the product has been dropped or damaged in any way, and f) When the product exhibits a distinct change in performance - this indicates a need for service.

19) Replacement Parts—When replacement parts are required, be sure the service technician has used replacement parts speciﬁed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in ﬁre, electric shock, or other hazards.

20) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

21) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product according to the method recommended by the manufacturer.

IMPORTANT SAFETY INSTRUCTIONS

• Outdoor Antenna Grounding — If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges.

Article 810 of the National Electrical Code, ANSI/NFPA 70,

provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

ANTENNA LEAD IN WIRE

ELECTRIC SERVICE EQUIPMENT

GROUND CLAMP

NEC — NATIONAL ELECTRICAL CODE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING

ELECTRODE SYSTEM (NEC ART 250)

• Water and Moisture — Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the manufacturer's instructions. Use only the mounting hardware recommended by the manufacturer.

• Selecting the location — Select a place with no direct sunlight and good ventilation.

• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings since insufﬁ cient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer's instructions are followed.

• The front panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.

• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including ampliﬁ ers) that produce heat.

• The Liquid Crystal panel is a very high technology product with 2,073,600 pixels, giving you ﬁ ne picture details.

Occasionally, a few non-active pixels may appear on the screen as a ﬁ xed point of blue, green or red. Please note that

this does not affect the performance of your product.

• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.

• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

• To prevent ﬁ re, never place any type of candle or ﬂ ames on the top or near the TV set.

• To prevent ﬁ re or shock hazard, do not place the AC cord under the TV set or other heavy items.

• Do not display a still picture for a long time, as this could cause an afterimage to remain.

• To prevent ﬁ re or shock hazard, do not expose this product to dripping or splashing.

No objects ﬁ lled with liquids, such as vases, should be placed on the product.

• Do not insert foreign objects into the product. Inserting objects in the air vents or other openings may result in ﬁ re or electric shock. Exercise special caution when using the product around children.

Precautions when transporting the TV

• When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always carry the TV by two people holding it with two hands — one hand on each side of the TV.

Caring for the cabinet

• Use a soft cloth (cotton, ﬂ annel, etc.) and gently wipe the surface of the cabinet.

• Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of the main unit cabinet or cause cracking.

• Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.

• If the cabinet is very dirty, wipe with a soft cloth (cotton, ﬂ annel, etc.) soaked in neutral detergent diluted with water and thoroughly wrung out, and then wipe with a soft dry cloth.

• Avoid using benzene, thinner, and other solvents, as these may deform the cabinet and cause the paint to peel off.

• Do not apply insecticides or other volatile liquids.

Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period of time. Plasticizers

inside the plastic may cause the cabinet to deform and cause the paint to peel off.

IMPORTANT SAFETY INSTRUCTIONS

Caring for the front panel

• Turn off the main power and unplug the AC cord from the wall outlet before handling.

• Gently wipe the surface of the front panel with a soft cloth (cotton, ﬂ annel, etc.).

To protect the front panel, do not use a dirty cloth, liquid cleaners, or a chemical cloth (wet/dry

sheet type cloth, etc.). This may damage the surface of the front panel.

• Wiping with a hard cloth or using strong force may scratch the surface of the front panel.

• Use a soft damp cloth to gently wipe the front panel when it is really dirty.

(It may scratch the surface of the front panel when wiped strongly.)

• If the front panel is dusty, use an anti-static brush, which is commercially available, to clean it.

• To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved cleaning cloths are

available directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800-BE-SHARP for ordering, or VISIT http://www.sharpusa.com/SharpDirect.

CHILD SAFETY:

It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

THE ISSUE

• The home theater entertainment experience is a growing trend and larger ﬂ at panel displays are popular purchases. However, ﬂ at panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations.

• Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and cause injury.

THIS MANUFACTURER CARES!

• The consumer electronics industry is committed to making home entertainment enjoyable and safe.

TUNE INTO SAFETY

• One size does NOT ﬁ t all. Follow the manufacturer’s recommendations for the safe installation and use of your ﬂ at panel display.

• Carefully read and understand all enclosed instructions for proper use of this product.

• Don’t allow children to climb on or play with furniture and television sets.

• Don’t place ﬂ at panel displays on furniture that can easily be used as steps, such as a chest of drawers.

• Remember that children can become excited while watching a program, especially on a “larger than life” ﬂ at panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down.

• Care should be taken to route all cords and cables connected to the ﬂ at panel display so that they cannot be pulled or grabbed by curious children.

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

• Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL).

• Follow all instructions supplied by the display and wall mount manufacturers.

• If you have any doubts about your ability to safely install your ﬂ at panel display, contact your retailer about professional installation.

• Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.

• A minimum of two people are required for installation. Flat panel displays can be heavy.

Note: CEA is the preeminent trade association promoting growth in the $161 billion U.S. consumer electronics industry. More than 2,200 companies enjoy the beneﬁ ts of CEA membership, including legislative advocacy, market research, technical training and education, industry promotion and the fostering of business and strategic relationships

IMPORTANT INFORMATION ............................. 1-2

DEAR SHARP CUSTOMER .................................... 3

IMPORTANT SAFETY INSTRUCTIONS ............. 3-5

Supplied Accessories............................................. 7

QUICK REFERENCE

Attaching the Stand ............................................ 7

QUICK INSTALLATION TIPS ............................... 8

Experiencing HD Images ..................................... 8

Using the Remote Control Unit ........................... 8

Preparation

Antennas ............................................................ 9

Installing Batteries in the Remote Control Unit ..... 9

Part Names

TV (Front) .......................................................... 10

TV (Rear/Side) ................................................... 10

Remote Control Unit ......................................... 11

Introduction to Connections

Types of Connection ......................................... 12

Displaying an External Equipment Image ........... 12

Connecting to External Equipment

Connecting a Blu-ray Disc/DVD Player or

HD Cable/Satellite Set-top Box ................ 13-14

Connecting a VCR, Game Console,

Camcorder or Cable/Satellite Set-top Box ..... 14

Connecting a Surround System/Audio System

Connecting a PC .............................................. 16

Watching TV

Turning On/Off the Power ................................. 17

Initial Installation .......................................... 17-19

Direct Button Operation

INPUT .......................................................... 20

Changing Channels ...................................... 20

Changing Volume ......................................... 20

MUTE........................................................... 20

Sleep Timer .................................................. 20

FREEZE ....................................................... 20

FLASHBACK ................................................ 21

SmartCentral ................................................ 21

NETFLIX ....................................................... 21

AV MODE .................................................... 21

AUDIO.................................................... 21-22

Closed Captions and

Digital Closed Captions .............................. 22

VIEW MODE ................................................. 23

On-Screen Display Menu

On-Screen Display Menu Operation .................. 24

Menu Operation Buttons ................................... 24

Menu Items ....................................................... 25

Picture Settings .......................................... 26-27

Audio Settings .................................................. 28

Power Control .................................................. 29

System Options .......................................... 30-32

Initial Setup ................................................. 33-36

Information ................................................. 37-39

... 15

Enjoying Photo/Music/Video Playback

Connecting a USB Memory Device/

USB Hard Drive .............................................. 40

Connecting a Home Network (DLNA) Server ..... 40

Selecting the Folders to Play Back .................... 41

Playing Back Files on a USB Memory Device/

Home Network (DLNA) Server ................. 42-46

Other Viewing Options

Presetting Remote Control Function ................. 47

Operating the Connected Equipment .......... 47-48

Using AQUOS LINK

Controlling HDMI Equipment

Using AQUOS LINK .................................. 49-51

Link Operation Menu .................................. 51-52

Using a PC

Displaying a PC Image on the Screen ............... 53

Adjusting the PC Image .................................... 54

Setting Audio Input ........................................... 54

PC Compatibility Chart ..................................... 54

Control of the TV ........................................ 55-56

Using the Internet

Connecting to the Internet ................................ 57

Internet Setup ............................................. 58-59

AQUOS Advantage Live .................................... 59

Entering Text (Software Keyboard) .................... 60

Using the Browser ...................................... 61-63

Using Applications via the Internet .............. 64-65

Appendix

Attaching the Stand (for LC-80LE633U) ............ 66

Removing the Stand ......................................... 67

Setting the TV on the Wall ........................... 68-69

Troubleshooting .......................................... 70-71

Troubleshooting - Error Message ...................... 71

Trademarks ........................................................... 72

Speciﬁ cations

TV............................................................... 73-74

Optional Accessory ........................................... 74

Wireless LAN .................................................... 75

Information on the Software License for

This Product ................................................. 76-78

Calling for Service ................................................ 79

LIMITED WARRANTY ........................................... 79

Dimensional Drawings

•

The dimensional drawings for the LCD TV set are shown on the inside back cover.

• The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from the actual operations.

• The examples used throughout this manual are based on the LC-70LE640U model.

Supplied Accessories

Make sure the following accessories are provided with the product.

LC-80LE633U

707/8 inches

Remote control unit (g1)

■

• The illustrations above are for explanation purposes and may vary slightly from the actual accessories.

Page 8

Operation manual (g1)

• Always use the AC cord supplied with the TV.

“AAA” size battery (g2)

Page 9

Connection guide (g1)

■

Stand unit (g1)

Pages 7, 66

1,800 mm (approx.)

AC cord (g1)

Page 9

QUICK REFERENCE

Attaching the Stand

• Before attaching (or detaching) the stand, unplug the AC cord.

• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.

CAUTION

• Attach the stand in the correct direction.

• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.

• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.

• After attaching the stand to the TV, do not hold the stand when you put up, set up, move or lay down the TV.

LC-70LE640U/LC-60LE640U/LC-52LE640U/LC-70C6400U/LC-60C6400U/LC-52C6400U

■

Refer to page 66 for the instructions on the installation of the LC-80LE633U.

Conﬁ rm that there are 12 screws (8 long screws

and 4 short screws) supplied with the stand unit.

Insert and tighten the 4 screws into the 4 holes on

the rear of the TV.

Set the post for the stand unit onto the

polystyrene foam. Attach the base to the post.

Insert and tighten the 8 screws into the 8 holes

on the bottom of the base.

• Hold the stand unit securely with one hand, and then tighten the screws.

Insert the stand into the openings on the bottom of the TV.

• Make sure that the stand is ﬁ rmly inserted into the TV. Improper installation may result in tilting of the TV set.

Soft cushion

FRONT

Long screws

Short screws

• In the installation procedure, be careful not to catch your ﬁ ngers between the TV set and the ﬂ oor.

QUICK REFERENCE

QUICK INSTALLATION TIPS

Attach your antenna to the back of the television.

(See page 9.) Connect the AC plug for the television into the AC

outlet.

LC-80LE633U

AC outlet

• Bundle the cords properly with the cable tie.

LC-70LE640U LC-70C6400U

LC-60/52LE640U LC-60/52C6400U

AC outlet

Experiencing HD Images

An HDTV without an HD source is just an ordinary TV. To enjoy HD images on the TV, you should get HD programming from the following:

• Over-the-air broadcasting via HD quality antenna

• HD cable/satellite subscription

• HD compatible external equipment

• For information on updating to HD programming, ask your cable/satellite service provider.

Using the Remote Control Unit

Use the remote control unit by pointing it towards the remote control sensor on the TV. Objects between the remote control unit and the remote control sensor may prevent proper operation.

17´ (5 m)

30º 30º

30º

Remote control sensor

• Place the TV close to the AC outlet, and keep the power plug within reach.

• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT

TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE AC CORD CONNECTED.

When turning on the TV for the ﬁ rst time, press

POWER on the television.

• For model LC-80LE633U, the control panel is located on the left side of the TV as seen from the front.

POWER

Insert the batteries into the remote control unit. (See

page 9.)

• Speakers cannot be detached from the TV.

• The TV angle cannot be adjusted.

Cautions regarding the remote control unit

■

• Do not expose the remote control unit to shock. In addition, do not expose the remote control unit to liquids, and do not place in an area with high humidity.

• Do not install or place the remote control unit under direct sunlight. The heat may cause deformation of the remote control unit.

• The remote control unit may not work properly if the remote control sensor on the TV is under direct sunlight or strong lighting. In such cases, change the angle of the lighting or the TV, or operate the remote control unit closer to the remote control sensor.

IMPORTANT:

IF THE UNIT DOES NOT POWER ON - UNPLUG THE TELEVISION FROM THE OUTLET AND REPEAT THE INSTALLATION STEPS.

IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.

Preparation

Antennas

To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector, plug it into the antenna terminal at the rear of the TV set. For connecting the antenna cable to the TV, use commercially available cables.

Connecting Antenna Cable

• Connect the antenna cable to the TV using one of the methods in the illustration as shown (1,2,3 or 4).

Home Antenna

Cable without a CATV

converter

VHF/UHF antenna

Combination VHF/

UHF antenna

Cable TV lead-In

75-ohm coaxial cable (round)

terminal (75-ohm)

Coaxial cable

Home Antenna terminal (75-ohm)

Coaxial cable

300-ohm twin-lead cable (ﬂat)

Separate VHF/UHF

antenna

VHF

NTENNA

UHF ANTENNA

300-ohm twin-lead cable

75-ohm coaxial cable

1. A 75-ohm system is generally a round cable with F-type connector that can easily be attached to a terminal without tools.

300/75-ohm adapter

OUT

Combiner

To TV antenna terminal

F-type connector

75-ohm coaxial cable (round)

2. A 300-ohm system is a ﬂ at “twin-lead” cable that can be attached to a 75-ohm terminal through a 300/75-ohm adapter.

300-ohm twin-lead cable (ﬂ at)

NOTICE

F-type connector should be ﬁ nger-tightened only.

When connecting the RF cable to the TV set, do not tighten F-type connector with tools. If tools are used, it may cause damage to your TV set. (The breaking of internal circuit, etc.)

75-ohm coaxial cable

Installing Batteries in the Remote Control Unit

If the remote control fails to operate TV functions, replace the batteries in the remote control unit.

1 Open the battery cover.

2 Insert two “AAA” size batteries (supplied with

the product).

• Place the batteries with their terminals corresponding to the (e) and (f) indications in the battery compartment.

3 Close the battery cover.

F-type connector

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.

• Do not mix batteries of different types. Different types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage in old batteries.

• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can cause a rash. If you ﬁ nd any chemical leakage, wipe thoroughly with a cloth.

• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.

• If you will not be using the remote control unit for an extended period of time, remove batteries from it.

Part Names

TV (Front)

OPC sensor *

TV (Rear/Side)

POWER

button

INPUT

button

Channel buttons (CHU/V)

Volume buttons (VOLk/l)

Remote control sensor

Center Icon illumination (See page 32.)

* OPC: Optical Picture Control (See page 26.)

*1*2

RS-232C terminal

PC IN terminal

VIDEO 2

terminals

VIDEO 1

terminals

COMPONENT

terminals

AUDIO OUT terminal

USB 1 terminal

HDMI 1 terminal

ARC: Audio Return Channel (See pages 49 and 50.)

HDMI 2 terminal

USB 2

terminal

ETHERNET

terminal

*1 See pages 12 to 16 and 49 for external equipment connection. *2 See pages 12, 17 and 24 for button operations.

For model LC-80LE633U, the control panel is located on the left side of the TV as seen from the front.

*3 See page 54 for details on the Audio Select function.

Antenna/ Cable in

DIGITAL AUDIO OUTPUT terminal

AUDIO IN terminal

(shared for PC IN and HDMI 1) *3

HDMI 3 terminal

HDMI 4 terminal

Part Names

Remote Control Unit

4 5

20 21

8 9

10 11

23 24

25 26

28 29

• When using the remote control unit, point it at the TV.

1 POWER: Switch the TV power on or enter standby. (See

page 17.)

2TV, STB, DVD•VCR, AUDIO: Switches the remote

control for TV, STB, BD, DVD, VCR and AUDIO operation. (See pages 47 to 48 for details.)

* To enter the code registration mode, you need to press

an appropriate button (STB, DVD•VCR or AUDIO) and

DISPLAY at the same time.

3 External equipment operational buttons: Operate the

external equipment.

4 OPTION: Display the Link Operation Menu screen. This

button will function only when AQUOS LINK is used. (See pages 49 to 52 for details.)

5 SLEEP: Set the sleep timer. (See page 20.) 60–9: Set the channel. (See page 20.) 7 • (DOT): (See pages 20 and 47.) 8 CC: Display captions from a closed-caption source. (See

page 22.)

AV MODE: Select an audio or video setting. (See page 21.)

9 10 MUTE: Mute the sound. (See page 20.)

11 VOLk/l: Set the volume. (See page 20.) 12 MENU: Display the menu screen. (See page 24.) 13 AAL: Display the TVkWeb screen. (See pages 59 to 63

for details.)

14a/b/c/d, ENTER: Select a desired item on the screen. 15 EXIT: Turn off the menu screen. 16 FAVORITE CH: Set the favorite channels. (See page 34.) 17 A, B, C, D: Select 4 preset favorite channels in 4 different

categories. (See page 34.)

While watching, you can toggle the selected channels by

pressing A, B, C and D.

18 DISPLAY: Display the channel information. 19 POWER (SOURCE): Turns the power of the external

equipment on and off.

20 FREEZE: Set the still image. Press again to return to

normal screen. (See page 20.)

21 AUDIO: Selects the MTS/SAP or the audio mode during

multichannel audio broadcasts. (See pages 21 to 22.)

22 ENT: Jumps to a channel after selecting with the 0–9

buttons.

23 FLASHBACK: Return to the previous channel or external

input mode. (See page 21.)

24 VIEW MODE: Select the screen size. (See pages 23 and

53.)

25 INPUT: Select a TV input source. (TV, HDMI1, HDMI2,

HDMI3, HDMI4, COMPONENT, VIDEO1, VIDEO2, PC IN, Home Network (DLNA), USB) (See pages 12 and 20.)

26 CHU/V: Select the channel. (See page 20.) 27 SmartCentral: Display the application window. (See

page 21.)

28 RETURN: Return to the previous menu screen. 29 NETFLIX: Display the Netﬂ ix screen. (See page 21.) 30 FAV APP 1, 2, 3: You can assign your favorite

applications to these buttons. (See page 34.)

Introduction to Connections

INPUT

HDMI1

HDMI2

HDMI3

Types of Connection

For connecting the TV to external equipment, use commercially available cables.

• The illustrations of the terminals are for explanation purposes and may vary slightly from the actual products.

Connecting to video equipment or PC

■

Image quality differs depending on the terminal used. To enjoy clearer images, check the output terminals of your external equipment and use its appropriate terminals for higher quality images.


Quality

Terminal

on the TV

Cable

HDMI-certiﬁed cable

Ø 3.5 mm stereo minijack cable

DVI-HDMI conversion cable

Component video cable

Terminal on external

equipment

AUDIO

DVI OUT

Pages 13, 15, 16

Pages 13, 16

Audio cable

Standard

Quality

Connecting to audio equipment

■

Terminal on the TV

Ø3.5 mm stereo minijack to RCA audio cable

AV cable

Cable

Optical ﬁber cable

Terminal on external

equipment

OPTICAL

DIGITAL AUDIO INPUT

ANALOG AUDIO IN

Displaying an External Equipment Image

To view external source images, select the input source by pressing INPUT on the remote control unit or on the TV.

• For model LC-80LE633U, the control panel is located on the left side of the TV as seen from the front.

Example

Input

AIR

INPUT

Press INPUT.

• The INPUT list screen displays.

Press a/b to select the input source.

• You can also select the input source by pressing INPUT. Each time INPUT is pressed, the input source toggles.

HDMI1 HDMI2 HDMI

HDMI

• An image from the selected source automatically displays.

• If the corresponding input is not plugged in, you cannot change the input. Be sure to connect the equipment beforehand.

Page 14

Page 15

Connecting to External Equipment

You can connect many types of external equipment to your TV. To view external source images, select the input source from INPUT on the remote control unit or on the TV. (See pages 12 and 20.) For connecting the TV to external equipment, use commercially available cables.

CAUTION

• To protect equipment, always turn off the TV before connecting any external equipment.

• Please read the relevant operation manual (Blu-ray disc player, etc.) carefully before making connections.

Connecting a Blu-ray Disc/DVD Player or HD Cable/Satellite Set-top Box

When using HDMI cable (HDMI 1, 2, 3 or 4):

■

The HDMI (High Deﬁ nition Multimedia Interface) terminal is an audio-video interface that enables a connection for audio and video signals using a single cable. The HDMI terminal supports high-resolution video input.

• Blu-ray disc player • DVD player

• HD cable/satellite set-top box

HDMI-certiﬁed cable

HDMI OUT

• To enjoy 1080p display capability, connect your external equipment using an HDMI-certiﬁ ed cable or a component cable and set the equipment to 1080p output.

• Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.

• When you connect external equipment using a DVI-HDMI conversion cable or when you connect ARC-compatible equipment, use HDMI 1.

When using DVI-HDMI conversion cable (HDMI 1):

■

Blu-ray disc player •DVD player

•

• HD cable/satellite set-top box

DVI-HDMI conversion cable

Ø 3.5 mm stereo minijack cable

AUDIO DVI OUT

• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in addition to connecting a DVI-HDMI conversion cable to the HDMI 1 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO IN terminal and set "Audio Select" to "HDMI+Analog". (See page 54.)

Connecting to External Equipment

When using Component cable (COMPONENT):

■

• Blu-ray disc player • DVD player

• HD cable/satellite set-top box

Audio cable

AUDIO-R (Red)

AUDIO-L (White)

COMPONENT OUT

(Red)

• To enjoy 1080p display capability, connect your external equipment using an HDMI-certiﬁ ed cable or a component cable and set the equipment to 1080p output.

• See page 13 for connecting a Blu-ray disc player, DVD player or an HD cable/satellite set-top box to the HDMI terminal.

Y (Green) PB (Blue)

Component video cable

Connecting a VCR, Game Console, Camcorder or Cable/Satellite Set-top Box

When using Composite cable (VIDEO 1 or 2):

■

• Game console • VCR

• Camcorder • Cable/Satellite set-top box

VIDEO (Yellow)

AUDIO-L (White)

AUDIO-R (Red)

AV cable

Connecting to External Equipment

Connecting a Surround System/Audio System

When connecting an AV ampliﬁ er for surround system

■

HD Cable/Satellite set-top box

HDMI-certiﬁed cable *1

OPTICAL

DIGITAL AUDIO INPUT

HDMI INHDMI OUT

HDMI OUT

Optical ﬁber cable *2

• Letting the TV output the audio to an AV ampliﬁ er:

*1 When you connect ARC-compatible equipment, use the HDMI 1 terminal. *2 If the equipment to be connected is not compatible with the ARC, connect an optical ﬁ ber cable.

• If the image is not in sync with the audio, check the settings of the connected surround system.

When connecting an Audio ampliﬁ er

■

It is possible to output audio through the DIGITAL AUDIO OUTPUT terminal. (See page 30 for details.) PCM audio outputs from the terminal.

Optical ﬁber cable

OPTICAL

DIGITAL AUDIO INPUT

• Depending on the connected equipment, audio will not output from the DIGITAL AUDIO OUTPUT terminal in HDMI connection. In this case, set the audio formats of the connected equipment to PCM, 32/44.1/48 kHz. Optical digital audio will be output in 2-ch stereo when it is from the external equipment connected to the TV using an HDMI cable.

•

Ø3.5 mm stereo minijack to RCA audio cable

ANALOG AUDIO IN

• See page 31 for details on the Output Select function.

Connecting to External Equipment

Connecting a PC

Refer to page 54 for a list of PC signals compatible with the TV.

When using HDMI cable (HDMI 1, 2, 3 or 4):

■

HDMI-certiﬁed cable

HDMI OUT

• Depending on the board, only video signals may be output. In this case, in addition to connecting an HDMI-certiﬁ ed cable to the HDMI 1 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO IN terminal and set "Audio Select" to "HDMI+Analog". (See page 54.)

The HDMI terminals only support digital signal.

•

When using DVI-HDMI conversion cable (HDMI 1):

■

DVI-HDMI conversion cable

DVI OUT

Ø 3.5 mm stereo minijack cable

AUDIO

• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in addition to connecting a DVI-HDMI conversion cable to the HDMI 1 terminal, connect

a Ø 3.5 mm stereo minijack cable

to the AUDIO IN

terminal and set "Audio Select" to "HDMI+Analog". (See page 54.)

When using analog RGB cable (PC IN):

■

Analog RGB cable

(D-sub 15-pin cable or VGA cable)

Ø 3.5 mm stereo minijack cable

RGBAUDIO

• When using an analog RGB cable, input the audio signal to the AUDIO IN terminal of PC IN.

• When connecting a PC to the PC IN, set "Audio Select" to "Video+Audio". (See page 54.)

Watching TV

Turning On/Off the Power

POWER

POWER (On/Standby)

Press POWER on the TV or on the remote control unit to turn the power on.

• For model LC-80LE633U, the control panel is located on

the left side of the TV as seen from the front.

• The Initial Installation starts when the TV powers on for the

ﬁ rst time. If the TV has been turned on before, the Initial Installation will not be invoked. For changing the settings of the Initial Installation, perform "EZ setup" on the Initial Setup menu on page 33.

Press POWER on the TV or on the remote control unit again to turn the power off.

• The TV enters standby and the image on the screen

disappears.

• If you are not going to use this TV for a long period of time,

be sure to remove the AC cord from the AC outlet.

• Weak electric power is still consumed even when the TV is

turned off.

Initial Installation

When you turn on the TV for the ﬁ rst time, it will automatically memorize the broadcasting channels available in the region where you live. Perform the following steps before you press POWER on the remote control unit.

Insert the batteries into the remote control unit. (See page 9.)

2. Connect the antenna cable to the TV. (See page 9.)

3. Plug in the AC cord to the AC outlet. (See page 8.)

Language (Language setting)

Select from among 3 languages: English, French and Spanish.

Press a/b to select the desired language listed

on the screen, and then press ENTER.

Language

Location & Time

TV Location

Antenna & Cable/STB

Air/Cable

CH Search

Completed

Location & Time

Make settings for the country, area and time zone where you use the TV.

Press a/b to select "United States", "Canada" or

"Mexico", and then press ENTER.

United States

Canada

Mexico

English

Français

Español

Watching TV

Press a/b to select the time zone where you are

using the TV, and then press ENTER.

Example

EST

CST

MST

PST

AKST

HAST

• The time zone differs depending on the selected country.

• The factory preset value is the time zone for the capital of the selected country.

Press a/b to select the Daylight Savings Time,

and then press ENTER.

Auto

Manual

Off

• “Auto” is the default selection.

TV Location

Select "Home" or "Store" for the location where you plan to install the TV. This product qualiﬁ es for ENERGY STAR in Home mode default setting.

Press c/dto select "Home" or "Store".

Press ENTER to enter the setting.

Select

Home

Home: “Power Saving” is set to "Advanced", and AV

MODE is set to "STANDARD".

Store: “Power Saving” is set to "Off" and AV MODE is

set to "DYNAMIC (Fixed)". Picture Reset and Feature Demo can be set.

Picture Reset: AV MODE will be set to "DYNAMIC (Fixed)"

regardless of whether Picture Reset is "On" or "Off". If you select "On", AV MODE will be reset to "DYNAMIC (Fixed)" if there is no operation for 30 minutes. When "Off" is selected, AV MODE will be set to "DYNAMIC (Fixed)".

Feature Demo: When “On” is selected, after all the settings

are completed, the Feature Demo screen is displayed if there is no operation for several minutes.

Store

Antenna & Cable/STB

Select the type of connection you will use to watch TV.

Press c/d to select "Antenna & Cable" or "Set-

top box", and then press ENTER.

Antenna & Cable

Set-top box

To watch TV via an antenna or cable

connection (without using a set-top box):

Select "Antenna & Cable", and then go to step 7.

To watch TV via a set-top box:

Select "Set-top box", and then press ENTER.

To watch TV, select the input source

corresponding to the terminal connected to the set-top box. When doing so, you must make the setting to skip "TV". Press c/d to select "On", and then press ENTER.

• When this is set to "On", the channel on the TV cannot be changed using the remote control unit or menu. (e.g. CH U/V, Favorite CH, etc.)

• See page 30 for details on the Input Skip function.

Press INPUT to select the input source

Off

corresponding to the terminal connected to the set-top box. Make the necessary settings on the connected external equipment.

• See the operation manual of the connected equipment for setting up the equipment.

Air/Cable (Antenna setting)

Make sure what kind of connection is made with your TV when selecting "Air" or "Cable".

Press c/dto select "Air" or "Cable".

Press ENTER to enter the setting.

Air

Cable

• ENERGY STAR qualiﬁ cation is based on AV MODE "STANDARD".

Watching TV

CH Search (Channel search)

Channel auto search makes the TV look for all channels viewable in the set area.

When "Air" is selected in Antenna setting:

Press

c/d

to select "Start", and then press

ENTER.

Start

Cancel

When "Cable" is selected in Antenna setting:

Pressa/b to select "Analog & Digital Search

Start" to search both analog and digital broadcasts, or to select “Analog Search Start” to search only analog broadcasts, and then press ENTER.

Analog & Digital Search Start

Analog Search Start

Cancel

• The Channel search will start automatically.

• To exit the Channel search screen, select "Cancel", and then press ENTER.

The Channel search results may include

scrambled channels or channels that are not viewable in the set area. Press

c/d

to select "Yes", and then press ENTER to remove scrambled channels.

Yes

Completed

The settings conﬁ rmation screen is displayed.

Conﬁ rm the information displayed on the screen, and then press ENTER.

Examples of the settings conﬁ rmation screen

When one or more channel is received after "Antenna & Cable" was selected in step 6 and a search was carried out.

Language : English Location & Time : United States/EST/Auto TV Location : Home Antenna & Cable/STB : Antenna & Cable Air/Cable : Air Search Result : Digital 4ch Analog 7ch

Press the INPUT button,

then the right arrow d,

to see the list of channels found.

When no channel is received after "Antenna & Cable" was selected in step 6 and a search was carried out.

Language : English Location & Time : United States/EST/Auto TV Location : Home Antenna & Cable/STB : Antenna & Cable Air/Cable : Cable Search Result : No channel

Channel not found.

Antenna/Cable are not properly connected

or Air/Cable setup is incorrect.

Please check your Antenna/Cable connection

and Air/Cable setup.

When "Set-top box" was selected in step 6 and a search was carried out.

Language : English Location & Time : United States/EST/Auto TV Location : Home Antenna & Cable/STB : Set-top box TV Input Skip : On

Please make sure to change INPUT to the speciﬁc input terminal you are connecting

your set-top box to get the picture. Closed caption, sub-channel audio

and channel selection need to be selected

with your set-top box.

•

If no channel is found, conﬁ rm the type of connection made with your TV and try "EZ Setup" again. (See page 33.)

•

For changing the settings of the Initial Installation, perform "EZ setup" on the Initial Setup menu on page 33.

•

To see the list of channels found during Channel search, press INPUT, and then press

Direct Button Operation

INPUT

To view external source images, select the input source by pressing INPUT on the remote control unit or on the TV.

Press INPUT.

• The INPUT list screen displays.

Press a/b or press INPUT again to select the

input source.

• An image from the selected source automatically displays.

• Each time INPUT is pressed, the input source toggles.

• If the corresponding input is not plugged in, you cannot change the input. Be sure to connect the equipment beforehand.

•

See pages 12 to 16 and 49 for external equipment connection.

Changing Channels

You can change channels in several ways.

Method 1 Using CH Method 2 Using remote control buttons 0-9, • (DOT).

Method 3

Selecting the program from Channel list.

Press INPUT on the remote control unit.

Press

Press a/b to select the desired channel, and then

•

U/V

on the remote control unit or on the TV.

Examples: To select a 1 or 2-digit channel number (e. g., Channel 5): Press 5 ENT. To select a 3-digit channel number (e. g., Channel 115): Press 1 1 5 ENT. To select a 4-digit channel number (e. g., Channel 22.1):

Press 2 2 • (DOT) 1 ENT.

• The INPUT list displays.

c/d

• The Channel list displays.

to select "AIR" or "CABLE".

press ENTER.

When selecting a 1-digit channel number, it is not necessary to press 0 before the number. When you enter 0-9 only, channel selection will be made if there is no operation within a few seconds. If you push "0" by itself, nothing will happen. Complete the above steps within a few seconds. When you enter 0-9 and • (DOT), channel selection will be made if there is no operation within a few seconds.

Changing Volume

You can change the volume by pressing VOLk/l on the TV or on the remote control unit.

•

To increase the volume, press VOLk.

•

To decrease the volume, press VOLl.

Audio status

Output device

Speaker Variable sound Mute

•

When "Output Select" is set to "Variable", the indicator on the screen changes as shown below.

Output Select

Fixed Variable

•

See page 31 for details on the Output Select function.

MUTE

Mutes the current sound output. Press MUTE.

•

" " will be displayed on the screen for 30 minutes, and the sound is silenced.

•

Within 30 minutes of pressing MUTE, mute can be canceled by pressing VOLk/l or MUTE.

•

Mute will be canceled after 30 minutes have passed. However, the TV will not suddenly output a loud sound as the volume level is set to 0 automatically.

Sleep Timer

Allows you to set a time when the TV automatically switches to standby. Press SLEEP.

•

The remaining time displays when the sleep timer has been set.

•

Each time you press SLEEP, the remaining time switches as shown below.

Off 30 60 90 120

•

When set, the time automatically starts counting down.

•

If you want to adjust the sleep timer, you can press SLEEP twice then change the time setting.

•

When it is 5 minutes before the time expires, the remaining time will start to keep appearing every minute.

•

Select "Off" by pressing SLEEP to cancel the sleep timer.

•

The TV will enter standby when the remaining time reaches 0.

FREEZE

Allows you to capture and freeze a moving image that you are watching. Press FREEZE.

•

A moving image is captured.

•

Press FREEZE again to cancel the function.

•

When this function is not available, "No displaying still image available." will display.

•

The still image automatically goes out after 30 minutes.

•

If you are using the freeze function and a broadcast activates the V-CHIP BLOCK, the freeze function will be canceled and a V-CHIP BLOCK message will appear.

• You can have the same settings by choosing "Freeze" on the menu items. (See page 30.)

Direct Button Operation

FLASHBACK

Press FLASHBACK to switch to the previously tuned channel or previous input mode.

•

Press FLASHBACK again to switch back to the currently tuned channel.

•

FLASHBACK will not work if no channel has been changed after the TV is turned on.

SmartCentral

Allows you to directly activate various types of applications.

Press SmartCentral to display the application

window.

Press a/b/c/d to select the desired application,

and then press ENTER.

• If “ ” is displayed after you switch to USB mode, check the USB connection.

• If “ ” or “ ” is displayed after you switch to Home Network (DLNA) mode or after you connect to the Internet, check your TV’s network settings and connection.

• See pages 41 and 64 for details of viewable applications.

• You can display the application window by choosing “APPS” on the menu items. (See page 30.)

• When this function is not available, “Can not operate this function now” will display.

NETFLIX

Displays the Netﬂ ix screen.

Press NETFLIX.

• To enjoy Netﬂ ix, you need to make:

—a broadband Internet connection (See page 57.) —settings of Internet Setup (See pages 58 and 59.) —adjustments for Netﬂ ix (See page 64.)

AV MODE

AV MODE gives you several viewing options to choose from to best match the surrounding environment of the TV, which can vary due to factors like room brightness, type of program watched or the type of image input from external equipment.

Press AV MODE. Current AV MODE displays.

•

Press AV MODE again before the mode displayed on the screen disappears. The mode changes as shown below:

Example: When the input source is TV, COMPONENT, VIDEO 1 or 2

AUTO STANDARD MOVIE GAME

DYNAMIC (Fixed)

Example: When the input source is PC IN or HDMI 1 to 4

AUTO

DYNAMIC (Fixed) DYNAMIC

STANDARD

DYNAMIC

MOVIE

USER [TV]

GAME

USER[ ]

AUTO: Optimizes the image quality automatically based

on the room brightness and image signal.

STANDARD:

lighting.

MOVIE: For a movie. GAME: Lowers image brightness for easier viewing. PC: For PC. USER: Allows the user to customize settings as desired.

You can set the mode for each input source.

DYNAMIC: For a clear-cut image emphasizing high

contrast, useful for sports viewing.

DYNAMIC (Fixed): Changes the image and sound

settings to the factory preset values. No adjustments are allowed.

•

You can select a different AV MODE item for each input mode. (For example, select STANDARD for TV input and DYNAMIC for COMPONENT.)

•

When you play games, "GAME" is recommended for AV MODE.

•

You cannot set "GAME" or "PC" when the TV is connected to the Internet or when the input source is "Home Network (DLNA)" or "USB".

• You can have the same settings by choosing "AV MODE" on the menu items. (See page 26.)

For a highly deﬁ ned image in a normal

AUDIO

MTS/SAP stereo mode

■

The TV has a feature that allows reception of sound other than the main audio for the program. This feature is called Multi-channel Television Sound (MTS). The TV with MTS can receive mono sound, stereo sound and Secondary Audio Programs (SAP). The SAP feature allows a TV station to broadcast other information, which could be audio in another language or something completely different like weather information.

You can enjoy Hi-Fi stereo sound or SAP broadcasts where available.

• Stereo broadcasts: View programs like live sporting events, shows and concerts in dynamic stereo sound.

• SAP broadcasts: Receive TV broadcasts in either MAIN or SAP sound.

MAIN sound: The normal program soundtrack (either in mono or stereo). SAP sound: Listen to a second language, supplementary commentary or other information. (SAP is mono sound.)

If stereo sound is difﬁ cult to hear.

• Obtain a clearer sound by manually switching to ﬁ xed mono-sound mode.

You can change MTS as shown below to match the television broadcast signal.

Press AUDIO to toggle between audio modes.

Examples: when receiving MTS and SAP

STEREO mode: STEREO + SAP mode:

MAIN + SAP mode: MONO mode: MONO

STEREO MONO

ST(SAP) SAP(ST) MONO

MAIN SAP

Direct Button Operation

Digital broadcasting audio mode

■

The types of audio transmitted in a digital broadcast include SURROUND as well as MONO and STEREO. In addition, it is possible for multiple audio tracks to accompany a single video track.

Press ENTER to toggle between audio modes.

Example: when receiving Digital broadcasting

STEREO (Audio1) STEREO (Audio2) SURROUND (Audio3)

• MTS only operates while in TV mode.

• You can have the same settings by choosing “Change Audio” on the menu items. (See page 30.)

Closed Captions and Digital Closed Captions

Your TV is equipped with an internal Closed Caption decoder. It allows you to view conversations, narration and sound effects as subtitles on your TV. Closed Captions are available on some TV programs and on some VHS home video tapes at the discretion of the program provider.

Digital Closed Caption service is a new caption service available only on digital TV programs (also at the discretion of the service provider). It is a more ﬂ exible system than the original Closed Caption system, because it allows for a variety of caption sizes and font styles. When the Digital Closed Caption service is in use, it will be indicated by the appearance of a 3-letter abbreviation that also indicates the language of the Digital Closed Captions: ENG (English), SPA (Spanish), FRA (French) or other language codes.

Not all programs and VHS videotapes offer closed captions. Please look for the “1” symbol to ensure that captions will be shown.

In the Closed Caption system, there can be more than one caption service provided. Each is identiﬁ ed by its own number. The “CC1” and “CC2” services display subtitles of TV programs superimposed over the program's picture.

In the Closed Caption system, the “Text1” or “Text2” services display text that is unrelated to the program being viewed (e.g., weather or news). These services are also superimposed over the program currently being viewed.

Press CC.

•

This will present the Closed Caption information display.

Press CC while the Closed Caption information is

still on the screen.

• Press repeatedly until you select the desired closed caption service.

Air

DIGITAL

22.1

Audio : STEREO

Video 480p (4:3) CC 1/2 CC1: Ratings : NONE

: NONE

• Depending on the number of caption services in the signal being received, you will see information such as 1/2 or 1/4 displayed. 1/2 means “the ﬁ rst of two services”.

Example:

If a program has three services (Digital CC(ENG), CC1 and Text1), the closed caption display will toggle in this sequence:

1/3 ENG 2/3 CC1 3/3 Text1 Off

• The CC button keeps a record of the last service selected in its memory. If the last closed caption mode (e.g. 1/3 ENG) you selected is not available for the next program, or on another channel, the closed caption service that is available is automatically selected, and this service appears in parentheses, e.g. “1/3(CC1)”. Closed Caption services that appear in parentheses will not be stored in the CC button's memory as your last selected service. Only services that you have selected with the CC button are stored.

Examples:

In a case where there are two closed caption services provided (for instance, Digital CC(ENG) and CC1), and Digital CC(ENG) is displayed as your current selection, if Digital CC(ENG) is not broadcast for the next program, the other closed caption service, CC1, will be displayed in parentheses. A closed caption service appears in parentheses because the service you selected is not available and a different service is displayed on your screen. “1/1(CC1)” is displayed instead of “1/2/ENG”.

• When “Power Saving” is set to “Standard” or “Advanced”, the Power Saving leaf icon appears on the channel information window. See page 29 for details of Power Saving settings.

• See page 31 for detailed closed caption settings.

• When the program contains no closed caption, “--” displays in the closed caption information.

• If the language code, e.g. “ENG”, is not found on Digital TV programs, “--” will be shown.

• Four kinds of closed caption service (CC1, CC2, Text1, Text2) are potentially available, but a broadcast may contain none or only some of these services at the discretion of the program provider.

• When TV+Web is displayed, Closed Captions are not available.

• You can have the same settings by choosing "Change CC" on the menu items. (See page 30.)

Closed Caption information

Direct Button Operation

VIEW MODE

For HD programs

■

Stretch Dot by Dot (Full Screen) S.Stretch (Smart stretch) Zoom

You can select the screen size.

Press VIEW MODE.

•

The View Mode menu displays.

•

The menu lists the View Mode options selectable for the type of video signal currently being received.

Press VIEW MODE or a/b while the View Mode menu is displayed to select a

desired item on the menu.

• You can sequentially select a View Mode that has its own aspect ratio.

•

You can have the same settings by choosing "View Mode" on the menu items. (See page 30.)

Suitable for viewing widescreen 1.78:1 aspect ratio program, stretch mode will still show very thin black bands at the top and bottom of the screen.

•

When using Dot by Dot or Full Screen, it is possible to see noise or bars around different outer portions of the screen. Please change view mode to correct this.

For 4:3 programs

■

Example: Screen size images

Side Bar S.Stretch (Smart stretch) Zoom Stretch

Suitable for viewing conventional 4:3 programs in their normal format.

For USB-Video, DLNA-Video or Internet applications

■

Example: Screen size images

Input signal Auto Original

Dot by Dot (1080i/p only):

Detects the resolution of the signal and displays an image with the same number of pixels on the screen. Full Screen (720p only): You can select "Full Screen" only when receiving a 720p signal.

Suitable for stretching 4:3 programs to ﬁ ll the screen.

Suitable for viewing widescreen 2.35:1 anamorphic DVDs in full screen.

Suitable for viewing widescreen 2.35:1 aspect-ratio programs in full screen.

This mode is useful for 1.78:1 DVDs. When viewing 1.85:1 DVDs, stretch mode will still show very thin black bands at the top and bottom of the screen.

Keeps the original aspect ratio in a full screen display.

Displays an image by an original size.

On-Screen Display Menu

On-Screen Display Menu Operation

LCFONT embedded

System Options

: Select : Enter

Press MENU to display the MENU screen.

Press MENU to exit.

Initial

Information

Setup

ENTER

RETURN

: Back

Picture Settings

: Exit

Picture Settings

AV MODE (Changing Pic.Quality)

OPC

Backlight

[ b5] a16 b16

Contrast

[b30] 0

Brightness

[0]

a30 b30

Color

[ b2] a30 b30

Tint

[0]a30

Sharpness

[ b2] a10 b10

Advanced

Reset

Pressc/d to select the desired menu. Pressa/b to select a speciﬁ c adjustment item,

and then press ENTER.

• Additional related adjustment items may be displayed. Press

to select the desired item.

a/b

Adjust the item while referring to the guide

display.

• Operations vary depending on the function or item. Refer to the guide display corresponding to the menu setting screen for button operations.

Example

[STANDARD]

[On:Display]

b40

b30

Example

System Options

: Select : Enter

Guide display

• This indicates the buttons that can be operated on the

Initial

Information

Setup

ENTER

RETURN

: Back

Picture Settings

: Exit

Picture Settings

AV MODE (Changing Pic.Quality)

OPC

Backlight

[ b5] a16 b16

Contrast

[b30] 0

Brightness

[0]a30 b30

Color

[ b2] a30 b30

Tint

[0]a30

Sharpness

[ b2] a10

Advanced

Reset

[STANDARD]

displayed screen. The guide display varies depending on the menu setting screen.

•

The operations for some selected items may be displayed

in the operational guide bar at the bottom of the screen.

Item displayed in blue

• This indicates the item currently selected.

•

Press ENTER to go to the adjustment screen for this item.

Item in brackets

• This indicates the current setting for the item.

Item displayed in white

• This indicates that the item can be selected.

Item displayed in gray

• This indicates that the item cannot be selected. There are various reasons why the items cannot be

selected, but the main reasons are as follows: —Nothing is connected to the selected input terminal. —

The function is not compatible with the current input signal.

b40

b30

b10

• Menu options differ in the selected input modes, but the operating procedures are the same.

• The screens in the operation manual are for explanation purposes (some are enlarged, others cropped) and may vary slightly from the actual screens.

• The order of explanations for each menu item in the following pages is not necessarily in accordance with the alignment of the items on the screen.

LCFONT:

• This product is embedded with LC Font technology, which was developed by SHARP Corporation for clearly displaying easyto-read characters on LCD screens.

Menu Operation Buttons

Using the remote control

Use the following buttons on the remote control to operate the menu.

MENU: Press to open or close the menu screen.

a/b/c/d

ENTER: Press to go to the next step or complete the

RETURN: Press to return to the previous step.

: Press to select a desired item on the screen or

adjust a selected item.

setting.

Using the control panel of the main unit

You can also operate the menu with the control panel of the main unit. Button operations on the control panel correspond to the ones on the remote control as shown below.

• For model LC-80LE633U, the control panel is located on the left side of the TV as seen from the front.

MENU: MENU on the

INPUT: ENTER on the

CHU/V: Cursora/

VOLk/l: Cursorc/

remote control.

on the remote control.

On-Screen Display Menu

Menu Items

• When AV MODE is set to "AUTO", part of the menu may not be displayed correctly or the setting range of the menu may be changed.

• Some menu items may not be displayed depending on the selected input source.

Picture Settings

AV MODE (Changing Pic.Quality) ..... Page 26

OPC ................................................ Page 26

Backlight ......................................... Page 26

Contrast .......................................... Page 26

Brightness ....................................... Page 26

Color ............................................... Page 26

Tint .................................................. Page 26

Sharpness ....................................... Page 26

Advanced ................................. Pages 26-27

C.M.S.-Hue ........................... Page 26

C.M.S.-Saturation ................. Page 26

C.M.S.-Value......................... Page 26

Color Temp. ......................... Page 27

Motion Enhancement ............ Page 27

Active Contrast ..................... Page 27

Gamma Adjustment .............. Page 27

Black Level............................ Page 27

Film Mode ............................. Page 27

Digital Noise Reduction ......... Page 27

Monochrome ........................ Page 27

Range of OPC ....................... Page 27

Reset .............................................. Page 26

Audio Settings

Auto Volume ................................... Page 28

Treble .............................................. Page 28

Bass................................................ Page 28

Balance ........................................... Page 28

Surround ......................................... Page 28

Bass Enhancer ................................ Page 28

Clear Voice ...................................... Page 28

Reset .............................................. Page 28

Power Control

Audio Only ...................................... Page 29

Power Saving .................................. Page 29

No Signal Off ................................... Page 29

No Operation Off ............................. Page 29

System Options

View Option ..............................Pages 30, 45

APPS .................................... Page 30

USB Operation Panel ............ Page 45

Home Network (DLNA)

Operation Panel .................... Page 45

View Mode ............................ Page 30

Freeze ................................... Page 30

Change Audio ....................... Page 30

Change CC ........................... Page 30

AQUOS LINK Setup ........................ Page 50

Input Terminal Setting......... Pages 30-31, 54

Audio Setup .......................... Page 30

PC input ................................ Page 54

Audio Select .......................... Page 54

Input Skip.............................. Page 30

Input Label ............................ Page 30

HDMI Setup .......................... Page 31

Output Select ........................ Page 31

Color System ........................ Page 31

Menu Design ................................... Page 31

Channel Selecting Effect ....... Page 31

Program Title Display ............ Page 31

Position ................................. Page 31

Caption Setup ....................... Page 31

Game Play Time .............................. Page 31

Operation Lock Out ......................... Page 32

Icon Light Up Setting ....................... Page 32

Demo Mode .................................... Page 32

Initial Setup

EZ Setup ......................................... Page 33

Language .............................. Page 33

Location & Time .................... Page 33

TV Location ........................... Page 33

Antenna & Cable/STB ........... Page 33

Air/Cable ............................... Page 33

CH Search ............................ Page 33

Completed ............................ Page 33

Broadcasting Setup.................. Pages 33-34

CH Setup .............................. Page 33

Favorite CH ........................... Page 34

Antenna Setup-DIGITAL ........ Page 34

Internet Setup .................... Pages 55, 58-59

Language ........................................ Page 34

Setup ..................................... Page 46

DivX

Individual Setup ........................ Pages 34-36

Secret No. ............................ Page 34

Parental CTRL ................ Pages 34-36

Wall Mount Audio Setup .................. Page 34

FAV APP Key Assign ....................... Page 34

Reset .............................................. Page 34

Information

Identiﬁ cation .................................... Page 37

Digital Caption Info. ........................ Page 37

Software Update ...................... Pages 37-39

Manual Update .............. Pages 37-39

Auto Update Setting .............. Page 37

Netﬂ ix Help ...................................... Page 64

VUDU Help ...................................... Page 64

On-Screen Display Menu

Picture Settings

Adjusts the picture to your preference with the following picture settings.

Example

Picture Settings

AV MODE (Changing Pic.Quality)

OPC

Backlight

[ b5] a16

Contrast

[b30] 0

Brightness

[0]

a30 b30

Color

[ b2] a30 b30

Tint

[0]a30

Sharpness

[ b2] a10

Advanced

Reset

Press MENU to display the MENU screen, and then

pressc/d to select "Picture Settings".

Press a/bto select a speciﬁ c adjustment item.

• Select "Advanced" and then press ENTER to set

"C.M.S.-Hue", "C.M.S.-Saturation", "C.M.S.-Value",

"Color Temp.", "Motion Enhancement", "Active Contrast", "Gamma Adjustment", "Black Level", "Film Mode", "Digital Noise Reduction", "Monochrome" or "Range of OPC".

Press a/b(orc/d) to select the desired setting,

and then press ENTER.

Press MENU to exit.

Selected item

Backlight The screen dims The screen

Contrast For less contrast For more contrast Brightness For less

Color For less color

Tint Skin tones

Sharpness For less

• For resetting all Picture adjustment items to the factory preset values, press a/b to select "Reset", press ENTER, pressa/b to select "Yes", and then press ENTER.

[STANDARD]

[On:Display]

b16

b40

b30

b10

button

brightness

intensity

become reddish

sharpness

button

brightens

For more brightness For more color intensity Skin tones become greenish For more sharpness

AV MODE (Changing Pic.Quality)

The audio and video settings can be changed to suit the program or input content being watched. Select from the following AV modes.

When the input source is TV, COMPONENT,

■

VIDEO 1 or 2:

AUTO/STANDARD/MOVIE/GAME/USER/DYNAMIC/ DYNAMIC(Fixed)

When the input source is PC IN or HDMI 1 to 4:

■

AUTO/STANDARD/MOVIE/GAME/PC/USER/DYNAMIC/ DYNAMIC(Fixed)

• The selectable items vary depending on the input source.

• You can select AV MODE by pressing AV MODE on the remote control unit. See page 21 for details of AV MODE settings.

OPC Setting

Automatically adjusts the brightness of the screen.

Off: The brightness is ﬁ xed at the value set in "Backlight". On: Automatically adjusts. On:Display: Displays the OPC effect on the screen while

adjusting the brightness of the screen.

•

When set to "On", the Optical Picture Control (OPC) senses the surrounding light and automatically adjusts the backlight brightness. Make sure nothing obstructs the OPC sensor, which could affect its ability to sense surrounding light.

•

When set to "On:Display", OPC effect displays on the screen while the OPC adjusts the screen brightness.

OPC:

Advanced Picture Settings

This TV provides various advanced functions for optimizing the picture quality.

C.M.S. (Color Management System)

Color tone is managed using the six-color adjustment setting.

C.M.S.-Hue: This is a standard to adjust the color either

more reddish or more bluish in tone.

C.M.S.-Saturation: Increases or decreases the

saturation of a selected color.

C.M.S.-Value: A higher value makes the image brighter.

A lower value makes the image darker.

•

For resetting all adjustment items to the factory preset values, press

ENTER

to select "Reset", and then press

a/b

On-Screen Display Menu

Color Temp. (Color Temperature)

For a better white balance, use color temperature correction.

High: White with bluish tone Mid-High: Middle: Mid-Low: Low: White with reddish tone

White balance can be adjusted between a maximum of +30 and a minimum of –30 for each color temperature.

R Gain (LO/HI): –30 through +30 G Gain (LO/HI): –30 through +30 B Gain (LO/HI): –30 through +30

•

For resetting all adjustment items to the factory preset values, press

ENTER

to select "Reset", and then press

a/b

Motion Enhancement

Use Motion Enhancement to view fast-action video more clearly.

LC-70LE640U/LC-60LE640U/LC-52LE640U

■

120Hz High/120Hz Low: For obtaining a clearer image. Off: Normal image.

LC-80LE633U/LC-70C6400U/LC-60C6400U/

■

LC-52C6400U

AquoMotion240: Turns the LED backlight on or off to

display motion picture more smoothly and clearly.

120Hz High/120Hz Low: For obtaining a clearer image. Off: Normal image.

• "Motion Enhancement" may cause image noise. If this occurs, turn the function "Off".

• When AV MODE is set to "GAME" or "PC", or PC format is being input, "Motion Enhancement" is not available.

Active Contrast

Automatically adjusts the image contrast according to the scene.

On: Automatically adjusts the image contrast. Off: No adjustment.

Gamma Adjustment

Adjusts the differences of picture tones between bright parts and dark parts. The adjustment range of the gamma can be set to a maximum of +2 and a minimum of –2 by pressing c or d.

Black Level

Adjusts on-screen black level to your preferred level.

High: The black level gets brighter. Low: The black level gets darker.

Film Mode (3:2 pull-down)

Automatically detects a ﬁ lm-based source (originally encoded at 24 frames/second), analyzes it then recreates each still ﬁ lm frame for high-deﬁ nition picture quality.

Advanced: Adjust effect to reduce judder from ﬁ lm

contents. Select a desired level of judder reduction from 0 to +10.

Standard: Detects, analyzes, converts ﬁ lm source. Off: Normal viewing mode.

•

"Film Mode" does not function depending on input signal type.

•

"Film Mode" does not function when you set AV MODE to "GAME" or “PC”.

•

"Standard" does not function when channel display shows an input signal resolution of 480p, 720p, or 1080p.

Digital Noise Reduction

Produces a clearer video image.

Auto: Automatically adjusts the level of noise reduction. High/Middle/Low: Select a desired level for viewing a

clearer video image.

Off: No adjustment.

• "Digital Noise Reduction" is not available when you set AV MODE to "PC" or PC format is being input.

• When AV MODE is set to "GAME", "Auto" is not available.

Monochrome

For viewing a video in monochrome.

On: For viewing in monochrome. Off: Normal color.

Range of OPC

The brightness level range of the OPC sensor's automatic adjustments can be set according to your preferences. The adjustment range of the OPC sensor can be set to a maximum of +16 and a minimum of –16.

Max.: –15 through +16 Min.: –16 through +15

•

The "Range of OPC" settings are active only when "OPC" is set to "On".

•

The maximum setting cannot be set to a smaller number than the minimum setting.

•

The minimum setting cannot be set to a bigger number than the maximum setting.

•

Depending on the brightness of the surrounding light, the OPC sensor might not operate if the adjustment range is small.

•

"Black Level" is available for input signal from Composite Video, Component 480i and analog broadcasts (air and cable).

On-Screen Display Menu

Audio Settings

You can adjust the sound quality to your preference with the following settings.

Example

Audio Settings

Auto Volume

Treble

[0]a15 b15

Bass

[0]a15

Balance

[ 0] L

Surround

Bass Enhancer

Clear Voice

Reset

Press MENU to display the MENU screen, and then

pressc/d to select "Audio Settings".

Press a/b to select a speciﬁ c adjustment item.

• Select “Auto Volume”, "Surround", "Bass Enhancer" or "Clear Voice", and then press ENTER to set each item.

Press a/b (or c/d) to select the desired setting,

and then press ENTER.

Press MENU to exit.

Selected item

Treble For weaker treble For stronger treble Bass For weaker bass For stronger bass Balance Decrease audio

[Off]

b15

[Off]

[On]

[Off]

button

from the right speaker

button

Decrease audio from the left speaker

Auto Volume

Different sound sources sometimes do not have the same loudness level, such as a program and its commercial breaks. The Automatic Volume Control (Auto Volume) reduces this problem by equalizing levels.

High: Reducing the loudness gaps among different

sound sources strongly.

Middle:

Low: Reducing the loudness gaps among different

sound sources slightly.

•

Audio Settings menu is grayed out when “Output Select” is set to “Variable”. (See page 31.)

Surround

The surround function produces Surround effect from the speakers.

On: Makes it possible to enjoy natural, realistic surround

sound.

Off: Outputs the normal sound.

•

Audio Settings menu is grayed out when "Output Select" is set to "Variable". (See page 31.)

•

For some discs, setup may be required on your BD/DVD player. In this case, please refer to the operation manual of your BD/DVD player.

Bass Enhancer

This function allows you to enjoy bass-enhanced sound.

On: Bass Enhancer function is on. Off: Normal sound.

•

Audio Settings menu is grayed out when "Output Select" is set to "Variable". (See page 31.)

Clear Voice

This function emphasizes speech against background noise for greater clarity.

•

Audio menu is grayed out when "Output Select" is set to "Variable". (See page 31.)

•

For resetting Audio adjustment items to the factory preset values, press a/b to select "Reset", press ENTER, press

to select "Yes", and then press ENTER.

a/b

•

Audio Settings menu is grayed out when "Output Select" is set to "Variable". (See page 31.)

On-Screen Display Menu

Power Control

Power control setting allows you to save energy.

Example

Power Control

Audio Only

Power Saving

No Signal Off

No Operation Off

Press MENU to display the MENU screen, and then

pressc/d to select "Power Control".

Press a/b to select a speciﬁ c adjustment item,

and then press ENTER.

Press a/b (or c/d) to select the desired setting,

and then press ENTER.

Press MENU to exit.

• Skip this step for "Audio Only".

Audio Only

When listening to music from a music program, you can turn the screen off and enjoy audio only.

On: Audio is output without screen image. Off: Both screen images and audio are output.

[ Standard]

[Enable]

[Disable]

Power Saving

This function allows you to set the Power Saving level in order to decrease the power consumption and

increase the backlight lifespan.

Standard: Optimizes power reduction based upon video

content. When set to "Standard", " " appears on the screen.

Advanced: Optimizes power reduction based upon video

content and engages OPC. When set to "Advanced", " " appears on the screen.

Off: This function does not work.

•

"Power Saving" does not function when you set AV MODE

"AUTO" or

•

You cannot select a different Power Saving item for each AV MODE.

When "Power Saving" is set, the "OPC" settings for all AV Modes will automatically change. —If you set "OPC" to "On" when "Power Saving" is set to

"Standard", then the "Power Saving" setting will change to "Advanced".

—When you change the "Power Saving" setting from

"Advanced" to "Off" or to "Standard", "OPC" will be set to "Off".

—"AUTO" and "DYNAMIC (Fixed)" will remain set to "Off".

•

When "Power Saving" is set to "Standard" or "Advanced", the Power Saving leaf icon appears to the left of "OPC" in the Picture Settings menu screen.

"DYNAMIC (Fixed)".

No Signal Off

This function allows the TV to automatically shut the power down when there is no signal received.

Enable: The power will automatically shut down if there is

no signal for 15 minutes.

Disable: This function does not work.

•

The screen image will return to normal when a button (except those for audio adjustment, such as VOL, MUTE) is pressed.

A conﬁrmation screen appears.

Yes: The setting will be changed. No: The setting will not be changed.

•

When it is 5 minutes before the power shuts down, the remaining time will start to keep appearing every minute.

•

When a TV program ﬁ nishes, this function may not operate.

No Operation Off

This function allows the TV to automatically shut the power down when there is no operation.

Enable: The power will automatically shut down if there is

no operation for 3 hours.

Disable: This function does not work.

A conﬁrmation screen appears.

Yes: The setting will be changed. No: The setting will not be changed.

•

When it is 5 minutes before the power shuts down, the remaining time will start to keep appearing every minute.

On-Screen Display Menu

System Options

Example

System Options

View Option

AQUOS LINK Setup

Input Terminal Setting

Menu Design

Operation Lock Out

Icon Light Up Setting

Demo Mode

Press MENU to display the MENU screen, and then

pressc/d to select "System Options".

Press a/b to select a speciﬁ c adjustment item and

then press ENTER.

Press a/b (or c/d) to select the desired setting,

and then press ENTER.

Press MENU to exit.

View Option

These functions are useful for adjusting the audio and video settings. The View Option functions can be operated with the remote control unit.

APPS

The application window can be displayed by selecting "APPS" on the MENU screen.

• You can display the application window by pressing

SmartCentral on the remote control unit. (See page 21.)

View Mode

This function changes the screen size. Select "View Option" on the menu to display the View Mode menu screen. The View Mode menu varies depending on the input source.

• You can select View Mode by pressing VIEW MODE on the remote control unit. — See page 23 for adjusting the video being input from a

TV, other audiovisual equipment, USB-Video, DLNAVideo or Internet applications. See page 53 for adjusting the video being input from a PC.

—

[Off]

[On]

Freeze

Allows you to capture and freeze a moving image that you are watching.

• You can select Freeze by pressing FREEZE on the remote control unit. See page 20 for details of Freeze function.

Change Audio

Allows you to change the audio when multiple audio is available for the program you are watching.

• You can change Audio by pressing AUDIO on the remote control unit. See pages 21 to 22 for details of Audio function.

Change CC

Allows you to change the Closed Caption display. Select "Change CC" on the menu to display the Closed Caption information.

• The information displayed varies depending on the program you are watching.

• You can change Closed Caption by pressing CC on the remote control unit. See page 22 for details of Closed Caption function.

Input Terminal Setting

Audio Setup

You can output digital audio to an AV ampliﬁ er or similar device whose DIGITAL AUDIO INPUT terminal is connected to the DIGITAL AUDIO OUTPUT terminal on the TV. Please select an audio output format compatible with the audio format of the program you are watching and the equipment connected.

PCM: The optical output terminal outputs audio signal

in PCM form. If your digital audio system does not support Dolby Digital, select "PCM".

Dolby Digital: The optical output terminal outputs audio

signal in Dolby Digital form. It reproduces sound from surround program of digital.

Input Skip

This setting allows you to skip the TV, HDMI or PC IN Input ("TV", "PC IN", "HDMI 1", "HDMI 2", "HDMI 3" and "HDMI 4") on the Input Selection operation.

Yes: Skips the input. No: Does not skip input.

Input Label

Lets you set the input terminal displayed when using the INPUT list or channel display. Press

a/b/c/d

select the new name for the input mode.

•

Using the software keyboard, you can enter up to

10 characters for text. (See page 60.)

•

You cannot change labels if the input source is TV, Home Network (DLNA) or USB.

On-Screen Display Menu

HDMI Setup

To watch an HDMI or PC IN equipment image, select "HDMI 1", "HDMI 2", "HDMI 3" or "HDMI 4" from the INPUT list using INPUT on the remote control unit or on the TV.

Auto View:

Enable: To use View Mode based on signal

recognition, including an HDMI signal.

Disable: No function.

•

Refer to your external equipment operation manual for the signal type.

•

When connecting a DVI-HDMI conversion adapter/cable to the HDMI terminal, the image may not come in clearly.

Output Select

Allows you to select what controls the audio output.

Fixed: Sound via speaker is adjusted with VOLk/l on

the remote control unit or on the TV.

Sound via the AUDIO OUT terminal is not adjustable

and outputs at a consistent level.

Variable: Sound via the AUDIO OUT terminal is adjusted

with VOLk/l on the remote control unit or on the TV.

Sound via speaker is muted.

Color System

Select the video signal system compatible with your equipment from the list below:

Auto/NTSC/PAL-M/PAL-N

•

"Color System" can only be set for the VIDEO 1 or 2.

•

If you have already set the Secret No., input the 4-digit secret number here. See page 34 for setting a secret number.

Menu Design

Position

For adjusting a picture's horizontal and vertical position.

H-Pos.: Centers the image by moving it to the left or

right.

V-Pos.: Centers the image by moving it up or down.

•

For resetting adjustments to the factory preset values, pressa/b to select "Reset", and then press ENTER.

•

When connecting a PC to the HDMI terminal, the image position will be automatically adjusted. It cannot be manually adjusted.

•

The screen position variable ranges depend on the View Mode or the signal type. The ranges can be seen on the position-setting screen.

•

Adjustments are stored separately according to input source.

• "Position" does not work when USB mode, Home Network (DLNA) mode or an Internet application is used.

Caption Setup

This function allows you to adjust the closed caption screen appearance to suit your preference. You can adjust 7 items: "Caption Size", "Font Style", "Foreground Color", "Foreground Opacity", "Background Color", "Background Opacity" and "Character Edge".

Example:

Selectable items available for "Font Style".

Default: The font speciﬁ ed by broadcasting station or

default font.

Type 0: Proportional font used in the MENU screen. Type 1: Monospaced with serifs. Type 2: Proportionally spaced with serifs. Type 3: Monospaced without serifs. Type 4: Proportionally spaced without serifs. Type 5: Casual font type. Type 6: Cursive font type. Type 7: Small capitals.

Channel Selecting Effect

You can select whether to use transition effects when changing channels.

Yes: A transition effect is used when the channel is

changed.

No: No function.

• In some cases, "Channel Selecting Effect" does not work.

Program Title Display

Select the CH display when changing channels for digital broadcasting.

Yes: "Program Info." displays. No: "Program Info." does not display.

•

For resetting adjustments to the factory preset values, pressa/b to select "Reset", and then press ENTER.

•

The default value depends on the broadcasting station.

Game Play Time

This function displays the elapsed game time so you do not lose track of the time. To display the elapsed time, select "GAME" for the AV MODE before starting the game.

On: The elapsed time is displayed every 30 minutes when

you switch to GAME mode in external input mode.

Off: No adjustment.

On-Screen Display Menu

Operation Lock Out

This function locks the operation buttons on the TV and the remote control.

Off: No adjustment. RC Control Lock: All buttons on the remote control are

locked.

Button Control Lock: All buttons on the TV, except

POWER, are locked.

When “RC Control Lock” or “Button Control Lock” is selected, a conﬁ rmation screen appears.

Yes: Locks the operation buttons. No: No adjustment.

• To unlock the buttons on the remote control by using the control panel of the main unit (see page 24):

Press MENU to display the MENU screen,

press VOLk/l to select "System Options", and then press INPUT.

Press CHU/V to select "Operation Lock Out", and

then press INPUT.

Press

Press MENU to exit.

•

To unlock the buttons on the TV, press MENU on the remote control, and then select "Off" in

Out"

CHU/

to select "Off"

, and then press INPUT

"Operation Lock

Icon Light Up Setting

When this function is set to "On", the LED on the front of the TV turns on.

Demo Mode

You can select the image from several types of demo mode.

LC-70LE640U/LC-60LE640U/LC-52LE640U

■

SmartCentral/Feature Demo/Auto Play

LC-80LE633U/LC-70C6400U/LC-60C6400U/

■

LC-52C6400U

AquoMotion240/SmartCentral/Feature Demo/ Auto Play

If you have selected "Auto Play", you need to select the desired playback type(s), and then set the playback time.

Continuous: Play Demos continuously. 10 min.: Play Demos every 10 minutes. 20 min.: Play Demos every 20 minutes.

•

This function will be canceled when you press EXIT on the

remote control unit.

•

When "Demo Mode" is set to "SmartCentral" or "Feature Demo", pressing FREEZE pauses/restarts demo.

•

"Demo Mode" may not be selected depending on input signal type or application status.

•

"Demo Mode" may be automatically canceled depending on input signal type.

• "On" is the factory preset value. If you want to turn off the LED, set the function to "Off".

On-Screen Display Menu

Initial Setup

Example

Initial Setup

EZ Setup

Broadcasting Setup

Internet Setup

Language

DivX® Setup

Individual Setup

Wall Mount Audio Setup

FAV APP Key Assign

Reset

Press MENU to display the MENU screen, and then

pressc/d to select "Initial Setup".

Press a/b to select a speciﬁ c adjustment item,

and then press ENTER.

• When you select "EZ Setup", "CH Setup", "Parental CTRL" or "Reset", you can enter the 4-digit secret number here. See page 34 for setting a secret number.

Press a/b (or c/d) to select the desired setting,

and then press ENTER.

Press MENU to exit.

EZ Setup

You can run EZ Setup again, even after setting up the preset channels.

Language: Select from among 3 languages (English,

French and Spanish).

Location & Time: Make settings for the country, area

and time zone where you use the TV.

Select your country: Select either "United States", "Canada",

or "Mexico".

Select your time zone: Select your time zone. The available

settings differ depending on the selected country.

Select DST (Daylight Savings Time): Select "Auto", "Manual"

or "Off".

TV Location: Select "Home" or "Store" for the location

where you plan to install the TV. This product qualiﬁ es for ENERGY STAR in Home mode default setting.

Home: "Power Saving" is set to "Advanced", and AV MODE is

set to "STANDARD".

Store:

"Power Saving" is set to "Off" and AV MODE is set to "DYNAMIC (Fixed)". Picture Reset and Feature Demo can be set. Picture Reset: AV MODE will be set to "DYNAMIC (Fixed)"

Feature Demo: When "On" is selected, after all the settings

are completed, the Feature Demo screen is displayed if there is no operation for several minutes.

• ENERGY STAR qualiﬁ cation is based on AV MODE "STANDARD".

[English]

[No]

Antenna & Cable/STB: Select the type of connection

you will use to watch TV.

Air/Cable: Make sure what kind of connection is made

with your TV when selecting "Air" or "Cable".

CH Search: Channel auto search makes the TV look for

all channels viewable in the set area.

• If "Cable" is selected for Antenna setting, scrambled channels are removed after the Channel search has been completed.

Completed:

The settings conﬁ rmation screen is displayed.

Conﬁ rm the information displayed on the screen.

•

See Initial Installation on pages 17 to 19 for setting each item.

•

If no channel is found, conﬁ rm the type of connection made with your TV and try "EZ Setup" again.

•

If you select "Analog Search Start" and initiate the channel search, the CH Memory for Cable Digital will be deleted.

Broadcasting Setup

CH Setup

If Initial Installation does not memorize all the channels in your region, follow the instructions below to manually memorize the channels.

Air/Cable: Make sure what kind of connection is made

with your TV when selecting "Air" or "Cable".

CH Search: Channel auto search makes the TV look for

all channels viewable in the set area.

CH Memory: You can select the channels to skip in each

ANALOG (Air), ANALOG (Cable), DIGITAL (Air) and DIGITAL (Cable).

On: Skips channels. (Channel selection disabled using CH

U/V

Off: Does not skip channels. (Channel selection enabled using

CHU/V.)

Remove Scrambled CH: This function makes the TV

look for and then delete digital cable channels that are scrambled and so unavailable in the set area. The process may take more than 20 minutes.

Yes: Starts to remove scrambled channels. No: This function does not work.

•

See Initial Installation on pages 17 to 19 for setting each item.

•

If no channel is found, conﬁ rm the type of connection made with your TV and try channel search again.

•

If you select "Analog Search Start" and initiate the channel search, the CH Memory for Cable Digital will be deleted.

On-Screen Display Menu

Favorite CH (Favorite Channel Setting)

This function allows you to program 4 favorite channels, in 4 different categories. By setting the favorite channels in advance, you can select your favorite channels easily.

To register your favorite channel:

Select "Register" and then press ENTER. Press a/b/c/

to select the position in the category, and then press

ENTER to register.

To delete your favorite channel: Select "1 Data Clear" and then press ENTER. Press

a/b/c/d

then press ENTER. Select "Yes" and then press ENTER.

To delete all the favorite channels, select "All Data Clear".

•

Before setting the channel, select the channel you want to register as a favorite channel.

•

You can display the "Favorite CH" screen by pressing FAVORITE CH on the remote control.

to select the channel you want to delete, and

Antenna Setup-DIGITAL

In order to receive digital air broadcasts, you need a digital broadcast antenna. You can conﬁ rm the antenna conﬁ guration through the "Antenna SetupDIGITAL" screen. If necessary, adjust the direction of the antenna to obtain the maximum signal strength.

Signal Strength: The signal strength of DIGITAL channel

is displayed. The signal information is based on the current channel.

Channel Strength: Input the 2-digit channel number

to check the signal strength of the selected channel. Make sure the signal is strong enough for each channel.

• This function is available for DIGITAL (Air) only.

Language

You can also select a language from the Initial Setup menu. Select from among 3 languages: English, French and Spanish.

Wall Mount Audio Setup

This selects the optimal audio for the program you are currently watching even when the TV is mounted to a wall.

Yes: Selects the optimal audio. No: No adjustment.

FAV APP Key Assign

You can assign your favorite applications to the FAV APP 1, 2, and 3 buttons on the remote control. After

assigning an application to a button, you can press that button to display the top screen of the assigned application.

Current Setup: Checks the current setting. APP1/APP2/APP3: You can assign your favorite

applications displayed on the screen to these buttons.

• For resetting adjustments to the factory preset values, pressa/b to select "Reset", and then press ENTER.

Reset

If complex adjustments are made and the settings cannot be restored to normal, you can reset the settings to the factory preset values.

•

If you have already set the Secret No., input the 4-digit secret number here.

•

The Channel Setup settings will not be changed.

•

The Language settings will not be changed.

•

The Secret number settings will not be changed.

•

The TV Location settings will not be changed.

Individual Setup

Secret No.

Allows you to use a secret number to protect certain settings from being accidentally changed.

IMPORTANT:

Three conditions must be met to enable the V-Chip (see pages 35 to 36):

Secret No. is registered.

V-Chip/V-Chip (DTV Only) settings have been made.

• The “V-Chip (DTV Only)” will only be selectable when a new rating system can be downloaded via digital broadcasting in the U.S.

3. "

Status" is set to "On".

Setting the Secret No.

■

You can set and change the secret number by using

0-9.

Yes: Changes or sets the Secret No. No: The conﬁ rmation screen to clear the Secret No.

appears when the Secret No. has been set. When the Secret No. has not been set, the previous screen will be displayed.

Secret No. Clear

■

You can clear your secret number.

Yes: Your secret number is cleared. No: Your secret number is not cleared.

•

As a precautionary measure, make a note of your secret number and keep it in a familiar place.

•

If the secret number is cleared, the Status setting automatically sets to "Off". "V-Chip" and "Status" will not be selectable from the menu.

Parental CTRL (Parental Control Setting)

Status

Used to enable or disable the parental control function. This function will not be selectable from the menu if you do not ﬁ rst conﬁ gure your secret number.

On: Enables Parental CTRL. Off: Disables Parental CTRL.

On-Screen Display Menu

V-Chip

V-CHIP is an electronic ﬁ ltering device built into your TV. This tool gives parents a great degree of control over broadcasts accessed by their children. It allows parents to select programs judged suitable for child viewing while blocking ones judged not suitable. It does so automatically once you activate the V-CHIP feature in your TV. "V-Chip" and "Status" will not be selectable from the menu if you do not ﬁ rst conﬁ gure your secret number.

•

The U.S. has two rating systems for viewing content: TV Parental Guidelines and movie ratings.

•

The TV Parental Guidelines work in conjunction with the V-CHIP to help parents screen out inappropriate television shows from their children.

•

Movie ratings are used for original movies rated by the Motion Picture Association of America (MPAA) as watched on cable TV and not edited for television. The V-CHIP can also be set to block MPAA-rated movies.

•

The setting automatically enters "Block" for any ratings below your selection.

•

If Status is not set to "On", the conﬁ guration settings will not work.

MPAA (Voluntary movie rating system)

■

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

PG-13

NC-17

NONE

Pressa/b to adjust the item to your desired position. "

" indicates the item is blocked. Press MENU to exit.

G: General audiences. All ages admitted. PG: Parental guidance suggested. Some material may not be

suitable for children.

PG-13: Parents strongly cautioned. Some material may be

inappropriate for children under 13.

R: Restricted. Under 17 requires accompanying parent or

adult guardian (age varies in some jurisdictions).

NC-17: No one 17 and under admitted. X: X is an older rating that is uniﬁ ed with NC-17 but may be

encoded in the data of older movies.

•

Voluntary movie rating system only uses an age-based rating.

TV Parental Guidelines

■

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

NONE

Pressa/b to adjust the item to your desired position. "

" indicates the item is blocked. Press MENU to exit.

Suggested age

TV-Y: All children. TV-Y7: Directed to older children. TV-G: General audience. TV-PG: Parental Guidance suggested. TV-14: Parents strongly cautioned. TV-MA: Mature audience only.

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

NONE

When setting an individual content-based rating item:

Press d or ENTER to access blocked content

items from the currently selected age-based rating item.

Press a/b to select an individual item, and then

press ENTER to unblock it (" " is removed). Repeat the same steps for the other items.

Press c or RETURN to register after all individual

content rating items are set.

Content

FV: Fantasy violence. V: Violence. S: Sexual situation. L: Adult language. D: Sexually suggestive dialog.

Content

Suggested age

Rating

FV V S L

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

: The content rating can be set, but this rating is not

normally broadcast by TV stations.

: Content rating can be set.

On-Screen Display Menu

Canadian Rating Systems (Canadian English ratings and Canadian French ratings)

•

The TV rating systems in Canada are based on the Canadian Radio-Television and Telecommunications Commission (CRTC) policy on violence in television programming.

•

While violence is the most important content element to be rated, the structure developed takes into consideration other program content like language, nudity, sexuality and mature themes.

•

When setting the V-CHIP on the Canadian system you can choose either the Canadian English ratings or the Canadian French ratings.

Canadian English Ratings

■

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

C8+

14+

18+

NONE

Pressa/b to adjust the item to your desired position. "

" indicates the item is blocked. Press MENU to exit.

E: Exempt: Includes news, sports, documentaries and other

information programming; talk shows, music videos, and variety programming.

C: Children: Intended for younger children under the age of 8

years. Pays careful attention to themes that could threaten their sense of security and well-being.

C8+: Children over 8 years old: Contains no portrayal

of violence as the preferred, acceptable, or only way to resolve conﬂ ict; nor encourage children to imitate dangerous acts which they may see on the screen.

G: General: Considered acceptable for all age groups.

Appropriate viewing for the entire family, contains very little violence, physical, verbal or emotional.

PG: Parental Guidance: Intended for a general audience, but

may not be suitable for younger children (under the age of 8) because it could contain controversial themes or issues.

14+: Over 14 years: Could contain themes where violence

is one of the dominant elements of the storyline, but it must be integral to the development of plot or character. Language usage could be profane and nudity present within the context of the theme.

18+: Adults: Intended for viewers 18 years and older and

might contain depictions of violence, which while related to the development of plot, character or themes, are intended for adult viewing. Could contain graphic language and portrayals of sex and nudity.

Canadian French Ratings

■

Example

MPAA

TV Guidelines

Can. English Ratings

Can. French Ratings

8ans+

13ans+

16ans+

18ans+

NONE

Pressa/b to adjust the item to your desired position. "

" indicates the item is blocked. Press MENU to exit.

E: Exempt programming. G: General: All ages and children, contains minimal direct

violence, but may be integrated into the plot in a humorous or unrealistic manner.

8ans+: General but inadvisable for young children: May

be viewed by a wide public audience, but could contain scenes disturbing to children under 8 who cannot

distinguish between imaginary and real situations. Recommended for viewing with parent. 13ans+: Over 13 years: Could contain scenes of frequent

violent scenes and therefore recommended for viewing with

parent. 16ans+: Over 16 years: Could contain frequent violent scenes

and intense violence. 18ans+: Over 18 years: Only for adult viewing. Could contain

frequent violent scenes and extreme violence.

How to temporarily release the V-CHIP BLOCK

■

When the V-CHIP BLOCK is working and censors a broadcast, "V-CHIP HAS BEEN ACTIVATED." displays.

Press ENTER while the V-CHIP is working, and

then the secret number setting menu displays.

Input the 4-digit secret number by using 0–9. At this

time V-CHIP BLOCK temporarily releases.

Reactivating the temporarily released V-CHIP

■

BLOCK

You can reactivate the temporarily released V-CHIP BLOCK as shown below.

•

Select "Status" setting from the Parental CTRL menu to

reactivate BLOCK. (See page 34.)

•

Select "V-Chip" setting ("MPAA", "TV Guidelines", "Can.

English Ratings" or "Can. French Ratings") from the

Parental CTRL to reactivate BLOCK. (See pages 35 to 36.)

•

Switch off the TV power.

•

Performing any of the three above will activate the V-CHIP

BLOCK.

On-Screen Display Menu

Identiﬁcation

Software Update

Digital Caption Info.

Information

Example

Information

Identiﬁcation

Digital Caption Info.

Software Update

Netﬂix Help

VUDU Help

Press MENU to display the MENU screen, and then

pressc/d to select "Information".

Press a/b to select a speciﬁ c adjustment item,

and then press ENTER.

Press a/b (or c/d) to select the desired setting,

and then press ENTER.

Press MENU to exit.

Identiﬁ cation

The current version of the TV software is displayed.

Digital Caption Info. (Digital Caption Information)

This function allows viewing of digital closed caption information for the digital broadcast program being viewed.

•

This list is not displayed for analog broadcasts or external input audio/video.

•

This information is not included in CC1, CC2, Text1, or Text2, and is not displayed in a list.

Software Update

This is used to upgrade the system software to enhance the TV functions.

Press a/b to select “Software Update”, and then

press ENTER.

• If you have already set the Secret No., go to step 3.

Example

Input the 4-digit secret number by using 0-9.

Software Update

Enter your Secret No.

Press a/b to select “Manual Update” or “Auto

Update Setting”, and then press ENTER.

• The operations thereafter vary depending on the setting.

Manual Update

Select the method for manually updating the software.

USB Update: Updates the software using a USB memory

device containing the update ﬁ le. (See pages 38 to 39.)

Network Update: Downloads the update ﬁ le via the

network and then updates the software. (See page 38.)

• A broadband connection and Internet Setup are required to

update the software using the network.

59.)

• It may take time to access and download the update

depending on the Internet connection and other factors.

(See pages 57 to

Auto Update Setting

When the TV is on, or when an Internet application is being accessed, this function enables the TV to connect to the network and check for updates automatically.

Yes: Enables Auto Update Setting. No: Disables Auto Update Setting.

Press MENU to display MENU screen, and then

pressc/d to select “Information”.

When an update is available, a message is displayed. Pressc/d to select "Yes", and then press ENTER to display the download screen. (See page 38.)

Yes

• This function does not work when a broadband connection

or Internet Setup is not available.

•

A message may also be displayed when an application is

running. The message varies depending on the application.

On-Screen Display Menu

Updating the Software via the Network

■

Press a/bon the Manual Update screen to select

"Network Update", and then press ENTER.

•

The TV connects to the network and checks for updates.

• To cancel, press ENTER.

Connecting to Internet..

Checking for the latest software version..

Accessing..

Abort

The current version of the TV and the latest version

of software are displayed. To update the TV software, select “Yes”, and then press ENTER.

Latest software version has been found.

A software update is available.

Current Version

XXXXXXXX

Latest Version

XXXXXXXX

Estimated Update Time

Update time may change depending on the network environment

• When a server connection cannot be established or an update is not available, a message is displayed. If a server connection cannot be established, check the broadband connection and Internet Setup.

Proceed with update?

Cannot reach the server.

Check the network settings and try again.

The TV does not need to be updated.

NoYes

CAUTION

• Do not unplug the AC cord while the software is

being updated.

When the software is successfully updated, a

screen is displayed indicating that the update process is completed. A screen indicating that the update is completed is displayed. 4 seconds later, the TV restarts automatically.

Software update is complete.

Update Version

XXXXXXXX

• If the software was not updated successfully, check the broadband connection and Internet Setup, and then try updating the software again.

Failed to complete update.

Please retry from Software Update menu.

Updating the Software with a USB Memory Device

■

To check for the availability of a software update, visit http://www.sharpusa.com/products/support/. If you

have any questions, please call 1-800-BE-SHARP (800-237-4277).

CAUTION

• Do not remove the USB memory device or unplug the AC cord while the software is being updated.

• Be sure to properly follow the whole procedure described below, step by step. Otherwise, for example, the TV cannot read the data in the USB memory device and software updating will fail.

Insert the USB memory device with the update ﬁ le

into the USB 1 or USB 2 terminal on the TV.

• When you update the software, use only one USB terminal. Either USB 1 or USB 2 is usable.

After the update ﬁ le is downloaded, the software

update process begins.

Downloading the latest software..

Update Version

XXXXXXXX

30%

Abort

Updating to the latest software..

Update Version

XXXXXXXX

Remote control operation is disabled during update process.

50%

Do not unplug AC cord.

Press a/b on the Manual Update screen to select

"USB Update", and then press ENTER.

On-Screen Display Menu

Press ENTER to start checking the data in the USB

memory device.

Insert the USB memory device

containing the software update ﬁle.

During the data checking, “Checking” blinks.

Now checking the data

in the USB memory device.

Checking

• The current version of the TV software and the version of the update ﬁ le on the USB memory device are displayed.

Example

Software update ﬁle is detected

in the USB memory device.

Start update?

Current Version : UXXXXXX1 Update Version : UXXXXXX2

NoYes

• If the USB memory device is not properly installed or the correct update ﬁ le cannot be found on the USB memory device, an error message is displayed.

Check the ﬁ le on the USB memory device, and then

reinsert the USB memory device correctly.

Software update ﬁle is not detected in the USB memory device.

Conﬁrm that you have transferred the ﬁle

to the USB memory device and retry software update.

There is more than one software ﬁle in the USB memory device.

Conﬁrm that only the software update ﬁle is

in the USB memory device.

To update the TV software with the update ﬁ le,

select “Yes”, and then press ENTER.

Software update ﬁle is detected

in the USB memory device.

Start update?

Current Version : UXXXXXX1 Update Version : UXXXXXX2

NoYes

Example

Now updating

Update Version : UXXXXXX2

30%

Remote Control operation is disabled during Update process.

Do not unplug AC cord.

CAUTION

• Do not remove the USB memory device or unplug

the AC cord while the software is being updated.

When the software is successfully updated, a

screen is displayed indicating that the update process is completed.

After this screen is displayed, the TV automatically

turns off and then turns on again.

Example

Software update is complete.

Update Version : UXXXXXX2

• If the update has failed, check the ﬁ le in the USB memory device and try Software Update again.

Failed to complete update.

Retry Software Update.

If system Update fails again,

contact the customer service center.

Update Version : UXXXXXX2

After the screen shown below is displayed, press

ENTER.

System software was successfully updated.

Remove the USB memory device.

Enjoying Photo/Music/Video Playback

You can connect the TV to a USB memory device, USB hard drive or home network (DLNA) server to enjoy viewing pictures, listening to music, and watching videos.

• Depending on the USB memory device/USB hard drive/home network (DLNA) server, the TV may not be able to recognize the recorded data.

• It may take time to read the recorded data if the USB memory device/USB hard drive/home network (DLNA) server contains many ﬁ les or folders.

• Use only alphanumeric characters for naming ﬁ les.

• File names over 80 characters (may vary depending on character set) may not be displayed.

Connecting a USB Memory Device/USB Hard Drive

Insert the USB memory device with recorded photos, music or videos into the USB 1 or USB 2 terminal on the TV.

• If USB memory devices are inserted into both terminals, the USB 1 terminal has priority.

• When connecting a USB hard drive, be sure to use a hard drive with an AC adapter.

• Do not remove a USB memory device or memory card from the TV while transferring ﬁ les, using the slide show function, or switching screens, or before you exit "USB" from the INPUT list.

• Do not insert and remove a USB memory device/USB hard drive to and from the TV repeatedly.

• When using a card reader, be sure to insert Memory ﬁ rst before using the card reader.

• USB input cannot be selected when displaying the browser. Close the browser ﬁ rst.

CAUTION

• Do not use a USB extension cable when connecting a USB memory device to the USB terminal on the TV.

• Using a USB extension cable with the USB memory device may prevent the TV from performing correctly.

Connecting a Home Network (DLNA) Server

Connect the TV to the home network (DLNA) server using an ETHERNET cable.

• You can also connect a Home Network (DLNA) server by using a wireless LAN.

ETHERNET cable

Home network (DLNA) server

• Do not disconnect a home network (DLNA) server from the TV while transferring ﬁles, when a screen is switching to another or before you exit "Home Network (DLNA)" from the INPUT list.

• Do not connect and disconnect a home network (DLNA) server from the TV repeatedly.

Router

Enjoying Photo/Music/Video Playback

Selecting the Folders to Play Back

• To play back data on a USB memory device, insert the USB memory device on the TV. USB mode is selected automatically. (Go to step 2)

• Use the following procedure to switch back to USB mode after switching from USB mode to another mode.

Select "USB" or "Home Network (DLNA)" from

INPUT list screen.

Press D.

Press a/b (or c/d) to select the drive/server

where you want to ﬁ nd your ﬁ les, and then press ENTER.

• For USB mode, select the drive.

• When in DLNA mode, select the server.

Press c/d to select "Photo", "Music" or "Video",

and then press ENTER.

Example


Music

Video

Press c/d to select the desired folder, and then

press ENTER.

USB Device Compatibility

USB device USB Memory, USB card reader (Mass

File system FAT/FAT32/NTFS (USB hard drive only) Photo ﬁ le

format Music ﬁ le

format

File

extension

.avi AVI

.mkv MKV

.asf

.wmv

.mp4

.mov .3gp

.vro

.mpg

.mpeg

• Progressive format jpeg ﬁ les are not supported.

• USB 1.1 devices may not be played properly.

• Operation using USB hubs is not guaranteed.

• Some video ﬁ le formats may not be played depending on the ﬁ le.

• Some images may not be displayed in the appropriate aspect ratio depending on the ﬁ le format.

Storage class), USB hard drive

JPEG (.jpg) (DCF2.0 compliant)

MP3 (.mp3) Bitrate: 32k, 40k, 48k, 56k, 64k, 80k, 96k, 112k, 128k, 160k, 192k, 224k, 256k, 320kbps Sampling frequency: 32k, 44.1k, 48kHz

Video ﬁ le format

Container Video Audio

ASF

MP4

(SMP4)

DivX 3.11/4.x/5.1/6.0

XviD

H.264

MPEG4

Motion Jpeg

DivX 3.11/4.x/5.1/6.0

XviD

H.264

MPEG4

DivX 3.11/4.x/5.1/6.0

XviD

MPEG4

VC-1

Windows Media Video v9

H.264

MPEG4

Motion Jpeg

MPEG2 MPEG1

MP3

Dolby Digital

LPCM

ADPCM

MP3

Dolby Digital

LPCM

ADPCM

MP3

Dolby Digital

LPCM

WMA

MP3 AAC

Dolby Digital

MPEG LPCM

Home Network (DLNA) Server Compatibility

• The Media screen can be displayed even by using the application window. To display the application window, press SmartCentral. (See page 21.)

• You cannot switch the input mode if a USB memory device is not connected.

• You do not need to select the drive/server in step 2 when there is only one drive in the connected USB memory device or there is only one home network (DLNA) server connected to the TV.

• 16 is the maximum number of USB drives and 10 is the maximum number of home network (DLNA) servers that can be displayed.

• If the TV is turned off and then on again, the number assigned to the USB drive may change.

• "VIEW MODE" is ﬁ xed during the Photo or Music mode. During "Video mode", you can select "Auto" or "Original".

• The key guide display disappears automatically after a particular time has elapsed. To display the key guide display again, press DISPLAY.

Photo ﬁ le format JPEG Music ﬁ le format LPCM, MP3 Video ﬁ le format MPEG2-PS, MPEG2-TS,

WMV, ASF, MP4, MOV, AVI

• Progressive format jpeg ﬁ les are not supported.

• Some video ﬁ le formats may not be played depending on the ﬁ le or the server.

Enjoying Photo/Music/Video Playback

Playing Back Files on a USB Memory Device/Home Network (DLNA) Server

Photo Mode

Viewing Thumbnails

Example

...... picture 5picture 4picture 2picture 1 picture 3

This screen image is for the USB mode. It may be slightly different in the Home network (DLNA) mode.

Viewing Individual Photos

The photo selected on the thumbnail selection screen is displayed.

Buttons for individual display operation

Buttons Description

c/d

RETURN Return to the thumbnail selection screen. A (red) Rotate the photo by 90 degrees to the left. B (green) Rotate the photo by 90 degrees to the right.

• Rotating photos only applies to the temporarily selected item and this setting is not saved.

• The key guide display disappears automatically after a particular time has elapsed. To display the key guide display again, press DISPLAY.

Go to the previous/next photo in the same directory.

Slide Show

The photos displayed on the thumbnail selection screen are displayed as a slide show.

Buttons for slide show operation

Buttons Description

RETURN Return to the thumbnail selection screen. D (yellow) Display the USB MENU/Home Network

(DLNA) Menu screen.

Buttons for thumbnail operations

Buttons Description

a/b/c/d

ENTER When selecting a folder icon:

RETURN Return to the previous process. A (red) USB mode:

B (green) Display the music list screen. You can select

C (blue)* Start the slide show. D (yellow) Display the USB MENU/Home Network

* This function is available only for the USB mode.

• When there are invalid photo ﬁ les, the X mark will be displayed for the ﬁ le. (USB mode only.)

• You can see the ﬁ le name, shooting date, ﬁ le size and pixel size of the selected photo in the lower-left corner of the screen (shooting date is only available in the EXIF ﬁ le format).

Select a desired item.

Enter this directory.

When selecting a photo thumbnail:

Enlarge the photo.

Select the images to be displayed. Press this button to add or remove a checkmark.

Home Network (DLNA) mode:

Display the Media screen.

the background music to be played for the slide show.

(DLNA) Menu screen.

• The selected BGM is played repeatedly.

• The slide show continues until you press RETURN.

• For setting the slide show speed, select "Select Slide Show Interval" on the USB MENU/Home Network (DLNA) Menu screen.

• The key guide display disappears automatically after a particular time has elapsed. To display the key guide display again, press DISPLAY.

Enjoying Photo/Music/Video Playback

USB Menu

On the menu to be displayed in USB mode, use

to select an item and make settings to your

preferences.

USB MENU

Select Slide Show BGM

Set All Slide Show Image

Reset All Slide Show Image

Remove USB Device

Select Slide Show Interval

■

Specify the length of time before the next image appears.

Press

to select the desired length of the time, and

then press ENTER.

5sec/10sec/30sec/60sec

• For DLNA mode, follow the same procedure.

• Depending on the photo ﬁ les, the length of the slide show interval may differ from the selected interval time.

Select Slide Show BGM

■

The music list screen appears when you select "Select Slide Show BGM". You can select the music to be played in the background while the slide show is being displayed.

Select the music you want to play from the music

list.

• For operations on the music list screen, see "Music Mode".

Press RETURN to display the thumbnail selection

screen, and then press C to start the slide show and the background music.

Example

[10sec]Select Slide Show Interval

Music Mode

Example

...... music 5music 4music 2music 1 music 3

3:42 4:55

4:35

4:08 4:20 3:55 4:26

SONG_03.MP3

0:14 / 4:35

SONG_01.MP3 SONG_02.MP3

SONG_03.MP3

SONG_04.MP3 SONG_05.MP3 SONG_06.MP3 SONG_07.MP3

I I

I I I I

This screen image is for the USB mode. It may be slightly different in the Home network (DLNA) mode.

Buttons for music mode

Buttons Description

/b/c/dSelect a desired item.

ENTER When selecting a folder icon:

Enter this directory.

When selecting a music ﬁ le:

Play music.

RETURN Return to the previous process. A (red) USB mode:

Select the music to be played back. Press this button to add or remove a checkmark.

Home Network (DLNA) mode:

Display the Media screen.

B (green) Stop music. C (blue) Play/Pause music. D (yellow)* Display the USB MENU screen.

* This function is available only for the USB mode.

• When there are invalid music ﬁ les, the X mark will be displayed for the ﬁ le. (USB mode only.)

• The displayed play time may differ slightly from the actual play time depending on the ﬁ les.

USB Menu

On the menu to be displayed in USB mode, use

/b to select an item and make settings to your

preferences.

Example

USB MENU

Set All Auto Play

Reset All Auto Play

Remove USB Device

• All of the music ﬁ les are selected by default.

Set/Reset All Slide Show Image

■

Selecting "Set All Slide Show Image" or "Reset All Slide Show Image" will display the thumbnail selection screen. On the screen, set or reset the images to be displayed in the slide show.

Set All Slide Show Image: Checkmarks are added to all

the images.

Reset All Slide Show Image: Remove all the

checkmarks from all the images.

Remove USB Device

■

To remove the USB device properly, use c/d to select "Yes" and then press ENTER.

* For details, see "Remove USB Device".

Set/Reset All Auto Play

■

Selecting "Set All Auto Play" or "Reset All Auto Play" will display the music list screen. On the screen, set or reset the music to be played back in the slide show.

Set All Auto Play: Checkmarks are added to all the

music ﬁ les.

Reset All Auto Play: Remove all the checkmarks from

all the music ﬁ les.

Enjoying Photo/Music/Video Playback

Video Mode

Example

VIDEO_01.avi VIDEO_02.divx

VIDEO_03.divx

VIDEO_04.avi VIDEO_05.divx VIDEO_06.divx VIDEO_07.avi

I I

I I I I

This screen image is for the USB mode. It may be slightly different in the Home network (DLNA) mode.

Buttons for ﬁ le selecting operations

Buttons Description

/b/c/dSelect a desired item.

ENTER When selecting a folder icon:

RETURN A (red) USB mode:

(yellow)

* This function is available only for the USB mode.

Enter this directory. When selecting a video ﬁ le: Play the video.

Return to the previous process.

Select/deselect items (checkmarks are added to the selected items).

Home Network (DLNA) mode:

Display the Media screen.

* Display the USB MENU screen.

...... video 5video 4video 2video 1 video 3

3:42 4:55

4:35

4:08 4:20 3:55 4:26

Buttons for playing mode

Buttons Description

Go to the beginning of a ﬁ le by pressing once and the previous ﬁ le by pressing a twice.

b d

Go to the next ﬁ le.

USB mode:

The fast forward speed changes every time you pressd. After playing to the end, the TV goes to the next ﬁ le and starts to play.

Home Network (DLNA) mode:

Jump forward in a video. *2

USB mode: The reverse speed changes every time you pressc. After going back to the beginning, the TV starts to play the same ﬁ le.

Home Network (DLNA) mode:

Jump back in a video. *2

ENTER USB mode:

Pause the video.

Home Network (DLNA) mode:

Play/Pause the video. *2

RETURN

Go back to the ﬁ le selection screen.

A (red)*1 Jump to the scene where playback was last

stopped.

(green)

Stop a video.

C (blue) Display the USB/home network (DLNA)

operation panel.

(yellow)

*1 Display the USB MENU screen.

0-9*1 Jump to a point in the video during playback of

a ﬁ le without chapters. You can jump to a later point by pressing a higher number.*3

*1 These functions are available only for the USB mode. *2 Jump forward/back and play/pause may not be available

depending on the ﬁ les.

*3 During playback of a ﬁ le without chapters, playback points

are set automatically. Playback points are set at intervals of

a one-tenth of playback time. Example for a ﬁ le with a playback time of 100 minutes: Pressing 1 jumps 10 minutes forward, and pressing 2 jumps 20 minutes forward. Pressing 0 returns to the start of the ﬁ le being played back.

Enjoying Photo/Music/Video Playback

Using the operation panel

■

You can use the operation panel for video playback operations. You can call up this operation panel by pressing MENU after you press a/b to select "USB Operation Panel"/"Home Network (DLNA) Operation Panel" from "System Options" > "View Option".

Example

Audio CC

Resume

Title

jump

Buttons for using the USB operation panel







)

Audio Change the audio when multiple audio is

CC Change the Closed Caption display. Title Displays the title (edition). Resume

jump

* During playback of a ﬁ le without chapters, playback points

are set automatically. Playback points are set at intervals of a

one-tenth of playback time. Example for a ﬁ le with a playback time of 100 minutes: Playback points are set every 10 minutes. Pressing one time after viewing the ﬁ le for 15 minutes jumps to the 20-minute playback point.

• Reverse/fast forward continues from one ﬁ le to another

during continuous playback.

• Use "CC" on the operation panel to change the Closed

Caption display. You can also switch the Closed Caption display by using "System Options" > "View Option" > "Change CC" or by pressing CC on the remote control unit.

• Use "Audio" on the operation panel to change the audio.

You can also switch the audio by using "System Options" > "View Option" > "Change Audio".

Hold down to go in reverse. Starts playback. Hold down to fast forward. Video without chapters: Press one time to

return to the previous playback point.* Press two times to return to the previous ﬁ le. Video with chapters: Press one time to return to the previous chapter. Press two times to return to the previous ﬁ le.

Sets pauses and still pictures. Video without chapters: Press one time to

advance to the next playback point.* Press two times to display the next ﬁ le. Video with chapters: Press one time to advance to the next chapter. Press two times to display the next ﬁ le.

available for the video you are watching. Playback stops.

Jump to the scene where playback was last stopped.

Buttons for using the Home Network (DLNA) operation panel



)

Starts playback. Go to the beginning of a ﬁ le by pressing once

or to the previous ﬁ le by pressing twice. Sets pauses and still pictures. Go to the next ﬁ le. Playback stops. Jump back in a video. Jump forward in a video.

USB Menu

On the menu to be displayed in USB mode, use

to select an item and make settings to your

preferences.

Menu for ﬁ le selecting operations

Example

USB MENU

Set All Auto Play

Reset All Auto Play

Remove USB Device

* See page 43 for details on the Remove USB Device

function.

Set/Reset All Auto Play

■

Selecting "Set All Auto Play" or "Reset All Auto Play" will display the video list screen. On the screen, set or reset the video to be played back in the slide show.

Set All Auto Play: Checkmarks are added to all the

video ﬁ les.

Reset All Auto Play: Remove all the checkmarks from

all the video ﬁ les.

Menu for playing mode

Example

USB MENU

Title (Edition)

Chapter

Show Video Information

Remove USB Device

* See page 43 for details on the Remove USB Device

function.

Title (Edition)/Chapter

■

Selecting "Title (Edition)" or "Chapter" will display a list of titles/chapters contained in the video ﬁ le. Select the title or chapter you want to play back.

• The selected title or chapter is played back.

• "0-9" is displayed for ﬁ les without chapters. Playback jumps to the playback point of the selected number.

• If there is Edition information, this screen is displayed when the title is selected.

• If there is no title or edition, you cannot select "Title (Edition)".

• "Chapter" cannot be selected when there is no chapter.

Show Video Information

■

The information of the current ﬁ le is displayed.

Enjoying Photo/Music/Video Playback

DivX® Setup

This is the function to conﬁ rm your registration code. You need to register the code at http://www.divx.com.

Press MENU to display the menu screen.

Pressc/d to select "Initial Setup", and then press

ENTER. Pressa/b to select "DivX® Setup", and then

press ENTER.

DivX

■

You can ﬁ nd your registration code on this menu. You need to register the TV at http://www.divx.com before playing the DivX content.

■

You can ﬁ nd your deregistration code on this menu. You need to deregister the TV at http://www.divx.com to release the registration.

VOD registration

DivX

VOD deregistration

• This function is available only for the USB mode.

• This function may not work while an Internet application is being used.

Other Viewing Options

Presetting Remote Control Function

You can operate the connected AV products (AV receiver, cable box, SAT tuner, DTV, VCR, BD, DVD, LD) using the presetting manufacturer function of your remote control unit.

7 8

9 10

12 13

Presetting manufacturer codes

Press an appropriate button (STB, DVD•VCR or

AUDIO) to operate the connected equipment.

Press an appropriate button (STB, DVD•VCR or

AUDIO) and DISPLAY at the same time to enter the code registration mode.

Press 0–9 to enter the manufacturer code. (See

page 48.)

• Preset mode is ﬁ nished once the LED no longer lights up.

After registering the code, the LED will stop blinking

then turn off after one second. (If you perform an incorrect operation, the LED will blink quickly then turn off.)

Operating the Connected Equipment

To operate the connected equipment, press STB, DVD•VCR or AUDIO to select your device. (STB

(cable/satellite set-top box), BD, DVD, VCR or AUDIO.) The remote control unit button will function as follows.

• When you operate VCR, BD or DVD, press INPUT to select the terminal connected to your device.

• CABLE and SAT cannot be selected at the same time.

1 POWER (SOURCE)

• Turns the connected equipment power on and off.

• Starts playback. (VCR, BD, DVD)

*

• Rewinds the tape and allows picture search. (VCR)

• Hold down to go in reverse. (BD, DVD)

• Stops the tape transport. (VCR)

• Playback stops when pressed. With some Blu-ray disc/

DVD players, pressing the button twice may open the disc tray. (BD, DVD)

• Pressing quickly once takes you to the start of the chapter

currently playing. Each time you press it, you move back to the start of the previous chapter. (BD, DVD)

6 0–9, • (DOT) (STB)

• Press a button (or buttons) that corresponds to the

channel that you wish to watch.

• Rapidly advances the tape and allows picture search.

(VCR)

• Hold down to fast forward. (BD, DVD)

)

• Sets pauses and still pictures. (VCR, BD, DVD)

• Pressing quickly once takes you to the start of the next

chapter. Each time you press it, you move ahead to the start of the next chapter. (BD, DVD)

10(REC

• Starts recording. (VCR)

11 FLASHBACK

• Press to switch between the current channel and the

channel you were watching immediately before. Some manufacturers do not preset FLASHBACK. (STB)

CHU/

• Press CHU or CHV to tune in to a higher or lower

• Press to select the channel of the TV tuner on the VCR.

13 MENU

• When this button is pressed, the BD/DVD menu will

•a/b/c/d: Press the button to select items on the STB

Press the button to select items on the BD/DVD menu

• ENTER: Press to activate the selected function. (STB,

channel. (STB)

(VCR)

display. (BD, DVD)

a/b/c/d

GUIDE screen or STB MENU screen. (STB)

screen. (BD, DVD)

BD, DVD)

, ENTER

Other Viewing Options

Manufacturer codes

VCR BRAND

AUDIO DYNAMICS BROCKSONIC CANON CRAIG CURTIS MATHIS DBX EMERSON GE INSTANT REOLYA JC PENNEY JVC KENWOOD MAGNAVOX MAGNIN MEMOREX MONTGOMERY WARD NEC PANASONIC PENTAX PHILCO PHILIPS QUASAR REALISTIC SAMSUNG SHARP SONY SYLVANIA TATUNG TEAC TMK YAMAHA

BD/DVD/LD BRAND

DENON JVC KENWOOD MAGNAVOX MARANTZ MITSUBISHI PANASONIC PHILIPS PIONEER PROSCAN RCA SAMSUNG SHARP SONY TOSHIBA YAMAHA ZENITH

REMOTE CONTROL CODE

NUMBER

09 13 04 12 04 09 10, 13, 14 04 04 04 09, 16, 17, 22 09 04, 05, 06 12 04 02 09 04, 18, 19, 20, 21 05 04, 05 04, 05, 06 04 01, 02 11, 12 01, 02, 03 07, 08, 15 04, 05, 06 09 09 10 09

REMOTE CONTROL CODE

NUMBER

24 31 36 26 26 28 24, 37 26, 38 30, 33, 35 25 25, 39 29, 34 23, 32, 41, 42 27, 40 26 24 26

STB BRAND

ANVISION CABLE STAR DISH NETWORK DIRECTV EAGLE G.INSTRUMENT GERROLD JERROLD

REMOTE CONTROL CODE

NUMBER

04, 05 04, 05 39, 40 41 05 02, 03, 10, 11, 17, 20 17 02, 03, 10, 11, 12, 20, 25-34

MAGNAVOX

04, 05, 08, 12, 15, 16,

18, 19, 22, 23 MOTOROLA OKA SIGMA PANASONIC PHILIPS

14, 21

04, 05, 08, 13, 15, 16,

18, 19, 22, 23 PIONEER RANDTEK RCA S.ATLANTA VIEWSTAR

04, 05

14, 36*, 37*

01, 09, 24

04, 05, 08, 13, 15, 16,

18, 19, 22, 23 ZENITH

• Numbers marked with * are SAT codes, all others are STB codes.

AUDIO BRAND

SHARP SHARP (SOUND BAR)

06, 35

REMOTE CONTROL CODE

NUMBER

01 02

• Depending on the brand, the codes of some BD players may not be supported.

Using AQUOS LINK

Controlling HDMI Equipment Using AQUOS LINK

What’s AQUOS LINK?

• Using the HDMI CEC (Consumer Electronics Control) protocol, with AQUOS LINK you can interactively operate

compatible system equipment (Blu-ray disc equipment, AV ampliﬁ er, DVD).

• By connecting AQUOS LINK-compatible devices with HDMI-certiﬁ ed cables to the TV, you can control a

recorder or AV ampliﬁ er using the remote control of the TV.

• AQUOS LINK allows you to operate the HDMI-connected equipment with one remote control.

Connecting AQUOS BD Player via AQUOS LINK-compatible Audio system

HDMI-certiﬁed cable Optical ﬁber cable

HDMI-certiﬁed cable *

* Use HDMI 1 to connect ARC-compatible equipment.

Example

AQUOS BD Player

• For connecting the TV to AQUOS LINK-compatible equipment, use commercially available cables.

• Point the remote control toward the TV, not to connected HDMI equipment.

• Video noise may occur depending on the type of HDMI cable used. Make sure to use an HDMI-certiﬁ ed cable.

• Up to 3 pieces of HDMI recording equipment and one AV ampliﬁ er can be connected using this system.

• These operations affect the HDMI equipment selected as the current input source. If the equipment does not operate, turn on the equipment and select the appropriate input source using INPUT.

• The AQUOS LINK feature may not operate properly when an HDMI splitter or AV selector unit is used. These devices may cause interruptions to the image and/or sound.

AQUOS LINK-compatible

Audio system

Back panel

horizontal inputs

Back panel

vertical inputs

Connected AQUOS LINK-compatible devices can be operated without changing the settings of the remote control unit.

OPTION button will function only when AQUOS LINK is used.

One Touch Play

■

While the TV is in standby mode, it automatically turns on and plays back the image from the HDMI source.

■

One Touch Recording

(

Press

REC while you are viewing a broadcast received with the AQUOS LINK-compatible recorder. The AQUOS LINK automatically recognizes the connected HDMI device and starts recording.

■

Single remote control

The AQUOS LINK automatically recognizes the connected HDMI device and you can control the TV and the devices as if using a universal remote control.

■

Control the AQUOS LINK-compatible audio system

Set the volume of AQUOS LINK-compatible audio system.

• The above description is an example of the AQUOS LINK function.

• The steps in “AQUOS LINK Setup” on page 50 need to be completed beforehand.

• Refer to this operation manual and the operation manual of the AQUOS LINK device

to be used with this TV.

Using AQUOS LINK

AQUOS LINK Setup

Example

System Options

System Options AQUOS LINK Setup

AQUOS LINK Control

Auto Power On

Selecting Recorder

Channel Select Key

Audio Return Channel

Press MENU to display the MENU screen, and then

pressc/d to select "System Options".

Press a/b to select “AQUOS LINK Setup”, and

then press ENTER.

Press a/b to select a speciﬁ c item, and then press

ENTER.

Press a/b (or c/d) to select the desired setting,

and then press ENTER.

Press MENU to exit.

AQUOS LINK Control

Select AQUOS LINK Control to disable AQUOS LINK function even when an AQUOS LINK-compatible HDMI device is connected to the TV. This function prevents the device from starting to operate unexpectedly.

On: You can operate AQUOS LINK-compatible

Off: AQUOS LINK function does not work.

[On]

[Yes]

[Auto]

equipment.

Channel Select Key

This function can be set for each input terminal.

On: The remote control unit of the TV can be used to

select the channel, display program information, and perform other operations of the connected AQUOS LINK-compatible recorder.

Off: This function does not work.

Audio Return Channel

This function allows you to listen to the TV audio via audio equipment without using an optical ﬁ ber cable, which conventionally is required.

Requirements for using an ARC-compatible AV ampliﬁ er:

• ARC-compatible AV ampliﬁ er connected to the ARCcompatible HDMI terminal (HDMI 1). (Refer to the operation manual of the ARC-compatible equipment for details.)

• Use of an ARC-compatible cable.

Auto: You can listen to the TV audio with ARC-

compatible audio equipment.

Off: This function does not work.

• If the TV audio cannot be output from the AV ampliﬁ er even

after making the necessary settings, connect the TV to the AV ampliﬁ er with an optical ﬁ ber cable and select “Off”.

One Touch Playback

Auto Power On

If this is activated, the One Touch Play function is enabled.

Yes: While the TV is in standby mode, it automatically

turns on and plays back the image from the HDMI source.

No: This function does not work.

Selecting Recorder

When multiple AQUOS LINK-compatible devices are connected, this function allows you to set the recorder for recording when you press

(

REC on the TV’s

remote control unit.

Pressa/b to select the recorder for recording.

AQUOS LINK allows you to operate the HDMIconnected equipment with one remote control.

Pressd to start playing back a title.

• The last played program is played back. You can use the

following buttons during broadcast viewing.

Buttons Description

POWER

(SOURCE)

)

• The buttons 7/8 do not function with the following

Blu-ray disc players currently available.

- BD-HP20U, BD-HP50U

Turns the power of the HDMI connected devices on and off.

Hold down to go in reverse.

Starts playback.

Hold down to fast forward.

Playback stops.

Sets pauses and still pictures.

Pressing quickly once takes you to the start of the chapter currently playing. Each time you press it, you move back to the start of the previous chapter.

Pressing quickly once takes you to the start of the next chapter. Each time you press it, you move ahead to the start of the next chapter.

Using AQUOS LINK

Link Operation Menu

One Touch Recording

This function allows easy one-touch recording of the program being viewed on the TV to AQUOS LINKcompatible equipment with a recording function by simply pressing

Prepare the connected AQUOS LINK-compatible recorder for recording. Check the following items.

• Make sure that the antenna cable is connected.

• Check that there is sufﬁ cient available space on the recording media (HDD, DVD, etc.).

• On the TV, use “AQUOS LINK Setup” and “Selecting Recorder” to select the equipment for recording.

• By default, the recorder connected to HDMI 1 is selected for recording.

Press (REC to start recording.

• When you are viewing a broadcast received with the AQUOS LINK-compatible recorder selected in "Selecting Recorder", recording to the AQUOS recorder of the broadcast being viewed starts.

• When you are viewing a broadcast received with equipment other than the AQUOS LINK-compatible recorder selected in "Selecting Recorder" or other external input equipment, pressing (REC on the remote control does not start recording.

Use the Link Operation Menu to stop recording.

Press OPTION to display the Link Operation

Menu screen. Pressa/b to select “Stop Recording”, and

then press ENTER.

(

REC on the remote control.

Link Operation

Recorder Power On/Off

Device Operation panel

Play from Rec. List

Show Start Menu

Change Media of Device

Link Booking (Rec. Book)

Change Audio Output Device

Change Surround Mode

HDMI Device Selection

AQUOS LINK Setup

[By AQUOS SP]

Link Operation

Start Recording

Stop Recording

Start/Stop Recording

You can also use the Link Operation Menu for recording on the connected AQUOS LINK-compatible equipment.

Press OPTION to display the Link Operation Menu

screen.

Select “Start Recording”, and then press ENTER to

start recording.

• You can also start recording by pressing (REC on the remote control unit.

Select “Stop Recording”, and then press ENTER to

stop recording.

The Link Operation Menu allows you to make adjustments during operation of AQUOS LINKcompatible equipment.

Press OPTION to display the Link Operation Menu.

Press a/b to select the desired item, and then

press ENTER.

• Speciﬁ c operations differ depending on the item you select. Following are the basic operations for each item.

Using AQUOS LINK

Recorder Power On/Off

You can manually turn on/off the power of the connected AQUOS LINK-compatible equipment. Each time you press ENTER, the connected equipment switches on or off.

Device Operation Panel

You can use the device operation panel to control playback operations.

Pressa/b/c/d to select the desired operation.

• This function works only when AQUOS LINK-compatible equipment with the Device Operation Panel function is connected.

Play from Rec. List

This function allows you to display the title list for the connected equipment and to play back the title you want to enjoy.

Before using this function

Power on the AQUOS LINK-compatible equipment, and select the appropriate external input.

Select the title with a/b/c/d, and then press d to start playback.

• This function works only when AQUOS LINK-compatible equipment is connected.

Show Start Menu

You can call up a setup menu from the connected AQUOS LINK-compatible equipment.

• Depending on the status of the equipment (recording or in standby mode, etc), the setup menu will not be displayed.

• The setup menu will not be displayed with the player BDHP20U currently available.

Change Media of Device

You can switch the media (HDD or DVD) for playback or recording on the AQUOS LINK-compatible recorder.

• The Media type toggles each time you press ENTER in "Change Media of Device".

Link Booking (Rec. Book)

You can call up the AQUOS LINK-compatible recorder's EPG and preset timer recordings using the TV's remote control.

Select the program on the recorder's EPG.

• You can use a/b/c/d, ENTER, RETURN, EXIT and the colored buttons.

• This function works only when an AQUOS LINK-compatible recorder is connected.

• Refer to the operation manual of the recorder for details.

Change Audio Output Device

You can select to listen to the TV sound only from the AQUOS LINK-compatible audio system.

By AQUOS audio SP: The sound from the TV speaker is

muted and only the sound from the AQUOS LINKcompatible audio system is audible.

• You can use VOL+/- and MUTE.

By AQUOS SP: The sound is output from the TV

speaker.

Change Surround Mode

You can manually change the AQUOS AUDIO speaker system's sound mode. The sound mode changes each time you press ENTER.

• Refer to the operation manual of the AQUOS LINKcompatible audio system for details.

HDMI Device Selection

If multiple HDMI devices are connected in a daisy chain, you can specify which device to control here. Pressa/b to select the desired device from a list of connected HDMI devices, and then press ENTER.

AQUOS Link Setup

You can also display the AQUOS LINK Setup screen from the Link Operation Menu.

Using a PC

Displaying a PC Image on the Screen

VIEW MODE

You can select the screen size.

Press VIEW MODE.

• The View Mode menu displays.

• The menu lists the View Mode options selectable for the type of video signal currently being received.

Press VIEW MODE or a/b while the View Mode menu is displayed to select a

desired item on the menu.

• You can sequentially select a View Mode that has its own aspect ratio.

• Connect the PC before making adjustments. (See page 16.)

• Selectable screen size may vary with input signal type.

• You can have the same settings by choosing "View Mode" on the menu items. (See page 30.)

Example: Screen size images

Input signal Normal Zoom Stretch Dot by Dot

4:3

Input signal Stretch Dot by Dot

16:9 An image fully ﬁ lls the

Keeps the original aspect ratio in a full screen display.

screen.

For viewing widescreen programs. The top and bottom of the image is cropped.

Detects the resolution of the signal and displays an image with the same number of pixels on the screen.

An image fully ﬁ lls the screen.

Detects the resolution of the signal and displays an image with the same number of pixels on the screen.

Using a PC

View Option

Input Terminal Setting

AQUOS LINK Setup

Menu Design

System Options

Example

Press MENU to display the MENU screen, and then

pressc/d to select "System Options".

Press a/b to select "Input Terminal Setting", and

then press ENTER.

Press a/b to select "PC input" or "Audio Select",

and then press ENTER.

Press a/b to select a speciﬁ c adjustment item,

and then press ENTER to set each item.

Press a/b (or c/d) to select or adjust the desired

setting, and then press ENTER.

Adjusting the PC Image

Auto Sync. (for Analog PC Input Mode Only)

For automatically adjusting the PC image.

Yes: Auto Sync. starts and "Now adjusting the image."

displays.

No: This function does not work.

Setting Audio Input

Audio Select

This function sets the terminal to output the computer audio. The adjustment items vary depending on the input source. Select the input source corresponding to the terminal connected to the PC and then adjust the desired item.

PC IN

■

Video: Select this when the TV and PC are connected

using an analog RGB cable and the audio is not input.

Video+Audio: Select this when the TV and PC are

connected using an analog RGB cable and the audio is input via a Ø 3.5 mm stereo minijack.

HDMI 1

■

HDMI(Digital): Select this when the TV and PC are

connected using an HDMI-certiﬁ ed cable and audio is input via the same cable.

HDMI+Analog: Select this when the TV and PC are

connected using a DVI-HDMI conversion cable and the audio is input via a Ø 3.5 mm stereo minijack.

• When "Audio Select" is set to "HDMI(Digital)", sound will not be produced if you use only an HDMI-certiﬁ ed cable to connect HDMI-compatible equipment. To produce sound, you should make an analog audio connection.

• If you want to connect HDMI-compatible equipment using only an HDMI-certiﬁ ed cable, set "Audio Select" to "HDMI(Digital)".

• When "Auto Sync." is successful, "Completed" displays. If not, "Auto Sync." failed.

• "Auto Sync." may fail even if "Completed" displays.

• "Auto Sync." may fail if the computer image has low resolution, has unclear (black) edges, or is moved while executing "Auto Sync.".

• Be sure to connect the PC to the TV and switch it on before starting "Auto Sync.".

Fine Sync.

Ordinarily you can easily adjust the picture as necessary to change image position using "Auto Sync.". In some cases, however, manual adjustment is needed to optimize the image.

• For resetting all "Fine Sync." adjustment items to the factory preset values, press a/b to select "Reset", and then press ENTER.

• It is not necessary to adjust the "Clock" or "Phase" when a digital signal is being input, so it cannot be selected.

• The default cursor position may not be in the center, because the screen position variable ranges may be asymmetrical.

• The screen position variable ranges depend on the View Mode or the signal type. The ranges can be seen on the position-setting screen.

H-Pos.: Centers the image by moving it to the left or right. V-Pos.: Centers the image by moving it up or down. Clock: Adjust when the image ﬂ ickers with vertical

stripes.

Phase: Adjust when characters have low contrast or

when the image ﬂ ickers.

PC Compatibility Chart

It is necessary to set the PC correctly to display XGA and WXGA signal.

Resolution

720 x 400

VGA

XGA 1024 x 768

WXGA 1360 x 768

VGA and XGA are registered trademarks of International Business Machines Corp.

640 x 480

800 x 600SVGA

Horizontal Frequency

31.5 kHz

37.9 kHz

37.5 kHz

35.1 kHz

37.9 kHz

48.1 kHz

46.9 kHz

48.4 kHz

56.5 kHz

60.0 kHz

47.7 kHz

64.0 kHzSXGA 1280 x 1024 60 Hz O

65.3 kHzSXGA+ 1400 x 1050 60 Hz O

75.0 kHzUXGA 1600 x 1200

67.5 kHz1080p 1920 x 1080 60 Hz

Vertical

Frequency

70 Hz 60 Hz

72 Hz 75 Hz 56 Hz 60 Hz 72 Hz 75 Hz 60 Hz 70 Hz 75 Hz 60 Hz

60 Hz

VESA

Standard

O O O O O O O O O O O

EZ Setup

Internet Setup

Language

Broadcasting Setup

Initial Setup

[English]

Using a PC

Control of the TV

• The TV can be controlled from a PC, control panels

• Use a cross-type RS-232C cable, ETHERNET cable

• This operation system should be used by a person who is

■

Connect to the TV with the following settings made for IP on the PC.

IP protocol: TCP/IP Host IP address: Set the IP address on the TV menu Service: None (Do not select Telnet or SSH) TCP port#: Set a port number on the TV menu

When you set your ID and password on the TV menu, you need to enter them as soon as you connect to the TV.

• The connection will be cut off when there has been no

7 8 9 10

and other devices using the RS-232C or IP.

(commercially available) or wireless LAN for the connections.

accustomed to using computers.

Communication conditions for IP

(Control port)

communication for 3 minutes.

IP Control Setup

Example

Press MENU to display the MENU screen, and then

pressc/d to select "Initial Setup".

Press a/b to select "Internet Setup", and then

press ENTER.

Press a/b to select "Network Setup", and then

press ENTER.

Press a/b to select "IP Control Setup", and then

press ENTER.

Press c/d to select "Change", and then press

ENTER.

To use IP Control, press c/d to select "Enable",

and then press ENTER.

Set the device name. Set your login ID and password. Set the port to use with IP Control.

Conﬁ rm the settings, and then press "OK".

Communication conditions for RS-232C

■

Set the RS-232C communication settings on the PC to match the TV's communication conditions. The TV's communication settings are as follows:

Baud rate: 9,600 bps Data length: 8 bits Parity bit: None Stop bit: 1 bit Flow control: None

Communication procedure

■

Send the control commands from the PC via the RS232C or IP. The TV operates according to the received command and sends a response message to the PC. Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending the next command.

Command format

■

Eight ASCII codes eCR

C1 C2 C3 C4 P1 P2 P3 P4

Command 4-digits

Command 4-digits: Command. The text of four characters. Parameter 4-digits: Parameter 0–9, x, blank, ?

Parameter

■

Parameter 4-digits

Return code

Input the parameter values, aligning left, and ﬁ ll with blank(s) for the remainder. (Be sure that 4 values are input for the parameter.) When the input parameter is not within an adjustable range, “ERR” returns. (Refer to “Response code format”.) Any numerical value can replace the “x” on the table.

0009

a 30

Response code format

■

Normal response

Return code (0DH)

When “?” is input for some commands, the present setting value responds.

Problem response (communication error or incorrect command)

ERR

????

Return code (0DH)

Using a PC

Command table

■

• Commands not indicated here are not guaranteed to operate.

CONTROL ITEM COMMAND

POWER ON COMMAND SETTING

POWER SETTING

INPUT SELECTION TOGGLE

AV MODE SELECTION

VOLUME POSITION

VIEW MODE

MUTE SURROUND AUDIO SELECTION SLEEP TIMER

CHANNEL

CC DEVICE NAME MODEL NAME SOFTWARE VERSION IP PROTOCOL VERSION REMOTE CONTROL BUTTONS

TV 1-8

H-POSITIONH-POSITION V-POSITION CLOCK PHASE

DIRECT CHANNEL (ANALOG)

DIRECT CHANNEL (DIGITAL)

CH UP CH DOWN

RSPW

ITGD ITVD IAVD

AVMD

VOLM HPOS VPOS CLCK PHSE

WIDE

MU T E

ACSU ACHA OFTM

DCCH

DA2P * * * * DC2 U * * * _

DC2 L * * * _

DC1 0 * * * * DC1 1 * * * * CHUP CHDW CLCP TVNM1___ MNR D 1 _ _ _ SWV N 1 _ _ _

IPPV1___ RCKY * * _ _

PARAMETER

_Off

2 _ _ _ On [IP]

(Toggle)

1: HDMI 1, 2: HDMI 2, 3: HDMI 3, 4: HDMI 4,

5: COMPONENT, 6: VIDEO 1, 7: VIDEO 2, 8: PC 0: (Toggle), 1: STANDARD, 2: MOVIE, 3: GAME,

4: USER, 5: DYNAMIC (Fixed), 6: DYNAMIC, 7: PC, 100: AUTO

Volume (0–60)

Only PC mode. (0–180)

Only PC mode. (0–40)

0: (Toggle) [AV], 1: Side Bar [AV], 2: S.Stretch [AV]

3: Zoom [AV], 4: Stretch [AV], 5: Normal [PC] 6: Zoom [PC], 7: Stretch [PC], 8: Dot by Dot [PC] [AV], 9: Full Screen [AV] 10: Auto [USB-Video, DLNA-Video or Internet applications], 11: Original [USB-Video, DLNA-Video or Internet applications]

0: (Toggle), 1: On, 2: Off

*___

0: (Toggle), 1: On, 2: Off

(Toggle)

x___

0: Off, 1: OFF TIMER – 30 MIN., 2: OFF TIMER – 60 MIN.,

3: OFF TIMER – 90 MIN., 4: OFF TIMER – 120 MIN. The channel number of TV

(1–135)

(1-999)

(0-999)

(0-9999) (0-6383) The channel number of TV +1

The channel number of TV

(Toggle)

0-9: 0-9, 10: DOT, 11: ENT, 12: POWER, 13: DISPLAY, 14: POWER (SOURCE) 15: 18: 23: OPTION, 24: SLEEP, 27: CC, 28: AV MODE, 29: VIEW MODE, 30: FLASHBACK, 31: MUTE, 32: VOL -, 33: VOL +, 34: CH 36: INPUT, 38: MENU, 39: SmartCentral , 40: ENTER, 41: a, 42: b, 43: c, 44: d, 45: RETURN, 46: EXIT, 47: FAVORITE CH, 48: Surround, 49: AUDIO, 50: A (red), 51: B (green), 52: C (blue), 53: D (yellow), 54: FREEZE, 55: FAV APP 1, 56: FAV APP 2, 57: FAV APP 3, 59: NETFLIX

–

), 19: ., 20: +, 21: /, 22:

*, 16: ,, 17: -,

U, 35: CH V,

(

REC,

CONTROL CONTENTS

The Power On command rejected. The Power On command accepted.1 _ _ _ On [RS-232C] The Power On command accepted. When the power is in standby mode, commands also go to waiting status and so power consumption is just about the same as usual. With the commands in waiting status, the Center Icon Illumination on the front of the TV lights up. It shifts to standby.P O W R 0 _ _ _ Power Off Power On1 _ _ _ Power On It input-switches by the toggle. (It is the same as an input change key) It input-switches to TV. (A channel remains as it is. (Last memory))

Although it can choose now, it is toggle operation in inside.

The screen position variable ranges depend on the View Mode or the signal type. The ranges can be seen on the position-setting screen.

0: Although it can choose now, it is toggle operation in inside. 1: Only available when 4:3 signal is being input. 5, 6: Only available when 4:3 signal is being input. 8: [PC] Available except when UXGA is being input. [AV] Only available when 1080i/p is being input. 9: Only available when 720p is being input. 10, 11: Available when USB-Video, DLNA-Video or Internet application is used.

An input change is included if it is not TV display. In Air, 2–69ch is effective. In Cable, 1–135ch is effective.

DIGITAL Air (Two-Part numbers, 2-digit plus 2-digit)(0100-9999) DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit) Front half of DIGITAL CABLE CHANNEL NO. (Designate major channel) DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit) Rear half of DIGITAL CABLE CHANNEL NO. (Designate minor channel) DIGITAL Cable (One-Part numbers, 5-digit, less than 10,000) DIGITAL Cable (One-Part numbers, 5-digit, more than 10,000) If it is not TV display, it will input-switch to TV. (same function as CHU) If it is not TV display, it will input-switch to TV. (same function as CHV) Toggle operation of a closed caption. The device name set in "IP Control Setup" is displayed. The model name of the TV The current version of the TV software is displayed. The currently supported version of IP protocol is displayed.

• If an underbar (_) appears in the parameter column, enter a space.

• If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL CONTENTS.

• Any numerical value can replace the “x” on the table.

Using the Internet

By connecting your TV to a broadband system, you can access the Internet from the TV.

• Use "AQUOS ADVANTAGE LIVE" to obtain the latest software and receive online user support. (See page 59.)

• You can enjoy a variety of streaming content and Internet applications. (See page 64.)

Connecting to the Internet

• To connect your TV to the Internet, you must have a broadband Internet connection.

• If you do not have a broadband Internet connection, consult the store where you purchased your TV or ask your Internet service provider or telephone company.

• When an Internet connection is made, an Ethernet and wireless connection cannot be used at the same time. Use only one of the connection types. (See page 58.)



Using an ETHERNET cable

Use an ETHERNET cable (commercially available) to connect the ETHERNET terminal on the TV to your broadband router (commercially available).

ETHERNET cable

LAN

Broadband router

InternetModem



Using the wireless LAN

This TV is equipped with a wireless LAN function. For a wireless LAN connection, you must use "Wireless Setup" to connect the access point and TV. (See page 58.)

Wireless LAN router/

access point

• This TV has a built-in wireless LAN function. Using a separate wireless USB LAN adapter may result in radio communications that do not comply with regulations on radio communications. Therefore, do not use a separate wireless LAN adapter.

• A wireless LAN connection and performance cannot be guaranteed for all residential environments. In the following cases, the wireless LAN signal may be poor or drop, or the connection speed may become slower.

- When used in buildings made with concrete, reinforced steel, or metal

- When placed near objects that obstruct the signal

- When used with other wireless devices that emit the same frequency

- When used in the vicinity of microwave ovens and other devices that emit a magnetic ﬁ eld, electrostatic charge, or

electromagnetic interference

• When there is signiﬁ cant interference in the 2.4-GHz frequency (such as from other wireless LAN devices, Bluetooth® devices,

2.4-GHz cordless telephones, and microwave ovens), it is recommended that you use a wireless LAN router/access point that supports IEEE802.11a/n (5 GHz) and set the access point to transmit at 5 GHz. For setup details, see the operation manual of your access point.

InternetModem

EZ Setup

Internet Setup

Language

Broadcasting Setup

Initial Setup

[English]

Using the Internet

Internet Setup

Example

Press a/b to select "Push button", and then press

ENTER.

• To conﬁ gure the setting via PC, select "PIN code". Follow the on-screen instructions and the operation manual of the access point to conﬁ gure the settings.

Select "Next" to complete the settings.

• The connection process starts and the WPS button on the access point can be pressed.

Press the WPS button on the access point.

• Pressing the WPS button displays a conﬁ rmation screen. Please wait until a connection is established.

When a connection is established, the connection

details are displayed. Press ENTER.

Connection Type

Press MENU to display the MENU screen, and then

pressc/d to select "Initial Setup".

Press a/b to select "Internet Setup", and then

press ENTER.

Press a/b to select "Network Setup", and then

press ENTER.

Press a/b to select "Connection Type", and then

press ENTER.

Press c/d to select "Wired" or "Wireless", and

then press ENTER.

• If you select "Wired", the signal is detected and setup is performed automatically. Use "IP Setup" to check and change the settings as necessary. (See page 59.)

• If you select "Wireless", use "Wireless Setup" to conﬁ gure the access point settings.

Wireless Setup

If your access point supports Wi-Fi Protected Setup (WPS), it is recommended that you use this function for the wireless connection. You can press the WPS button on the access point to conﬁ gure the settings automatically.

• The name of the WPS button function may differ depending on the access point. See the operation manual of the access point for details.

Conﬁ rm the current settings in "Connection Type".

• If "Wired" is selected, press c/d to select "Wireless".

Press a/b to select "Wireless Setup", and then

press ENTER.

• Conﬁ rm the settings. If each setting item is correct, press MENU to exit.

• If you are conﬁ guring the wireless setup for the ﬁ rst time or changing the settings, go to step 3.

Press c/d to select "Change", and then press

ENTER.

Press a/b to select "WPS", and then press

ENTER.

• To select and register an access point manually, select "Search" or "Manual Setup" and make the necessary settings.

• Operations cannot be guaranteed when used with access points that do not have Wi-Fi® certiﬁ cation.

• A wireless LAN router/access point is required to connect the TV to the Internet using a wireless LAN. See the operation manual of your access point for setup.

• If your access point is set to a stealth mode (that prevents detection by other devices), you may not be able to establish a connection. In this case, disable the stealth mode on the access point.

• A stable connection speed is required to play back streaming content. Use an Ethernet connection if the wireless LAN speed is unstable.

• Before transferring to a third party or disposal, be sure to initialize the wireless LAN settings.

• Please follow the legislation in your country when using the wireless LAN outdoors.

Interactive Service

If you do not want other people to connect to the Internet in your absence, you can make settings to keep the TV away from the Internet.

Press MENU to display the MENU screen, and then

pressc/d to select “Initial Setup”.

Press a/b to select “Internet Setup”, and then

press ENTER.

Press a/b to select “Interactive Service”, and then

press ENTER.

• Input the 4-digit secret number by using 0-9.

Press c/d to select “No”, and then press ENTER.

• If you want to allow Internet connection, select “Yes”, and then press

Press MENU to exit.

ENTER

Using the Internet

Checking Your Internet Connection

Press AAL to display the TV+Web screen.

• If " " or " " is displayed after you connect to the Internet, check your TV's network settings and connection.

• When the AQUOS ADVANTAGE LIVE screen appears, now you are connected to the Internet.

• You can also display the AQUOS ADVANTAGE LIVE screen by pressing FAV APP on the remote control unit. See page 34 for details on the FAV APP key Assign function.

• If you have failed to connect to the Internet in the above operation, then an error message will appear. In this case, press EXIT to exit from the connected TV feature to make changes to the network settings.

• If you still cannot connect to the Internet, please consult your Internet service provider or telephone company.

• When an application is used, you cannot make settings for "Internet Setup". If you need to make the settings of "Internet Setup", press EXIT to exit from the connected TV feature.



If you cannot connect to the Internet

Perform the procedures below to check your TV's network settings.

IP Setup

Press EXIT to exit from the connected TV feature.

Press MENU to display the MENU screen, and then

pressc/d to select “Initial Setup”.

Press a/b to select “Internet Setup”, and then

press ENTER.

Press a/b to select “Network Setup”, and then

press ENTER.

Press a/b to select “IP Setup”, and then press

ENTER.

• Check that numbers are displayed for each setting.

• If there are any settings without numbers, specify the numbers by following the on-screen instructions.

• For information on how to enter text, see page 60.

Example

Setting IP information

Change

[Current Setup]

Initialize

IP Address : Auto Setup Netmask : Auto Setup Gateway : Auto Setup DNS : Auto Setup MAC Address : XX:XX:XX:XX:XX:XX

AQUOS Advantage Live

This function can be used to display up-to-date information and allow you to receive support service over the network.

Press AAL.

• You can also display the AQUOS ADVANTAGE LIVE screen by pressing FAV APP on the remote control unit. See page 34 for details on the FAV APP key Assign function.

• When you are not connected to the Internet, a network function explanation screen is displayed. The services displayed vary depending on circumstances.

Press a/b/c/d to select the desired service.

Press EXIT to exit from the connected TV feature.

• The display may change as a result of a software update.

• When displaying TV+Web with a channel in which the V-Chip is enabled, the cursor keys on the remote control unit do not function.

Press MENU to exit.

Using the Internet

Entering Text (Software Keyboard)

When you are editing an input screen or specifying the Ethernet settings used for accessing the Internet, enter text from the software keyboard.

• You can enter up to 128 characters for text.

• Some special characters or diacritics may not be available depending on where you enter the text.

The text you enter is displayed as you type it in. To move the cursor (the current input position), use “

Pressc/d to select the type of characters entered: alphabet, number or sign. (The selectable types depend on the input source.)

While you are entering text, likely input conversion candidates are displayed based on what you typed in.

• You can also enter text by pressing A, B or C on the remote

control unit.

” or “ ” on the software keyboard.

Enters a space.

Caps Off/Caps On/Caps Lock If “alphabet” is selected in “Character Set”, this switches characters between uppercase and lowercase. Each time you press ENTER, the character type switches as shown below: Caps Off: all the characters are lowercased Caps On: only the ﬁ rst character is uppercased Caps Lock: all the characters are uppercased

Done

Applies the entered information and closes the software keyboard.

Quit

Closes the software keyboard without applying the entered information.

• You can also close the software keyboard by pressing EXIT on the remote control unit.

Displays the icon “ ”, indicating that a new line has been inserted.

Clear

Erases the character string.

• When the cursor is somewhere in a line: the character string to the right of the cursor will be erased.

• When the cursor is at the right end of a line: the entire line will be erased.

Delete

If the cursor is at the right end of a line, this erases text one character at a time.

• You can also delete text by pressing RETURN on the remote control unit.

Buttons Description

ENTER Performs the processing for the button currently in the focus.

EXIT

RETURN When the cursor is at the end of a sentence, this acts as a backspace. 0-9 Directly enters the single-byte number for that button. A (red) Directly enters prediction candidate 1. B (green) Directly enters prediction candidate 2. C (blue) Directly enters prediction candidate 3.

D (yellow) Enters a space.

Moves the focus up. When the focus is at the top edge, this moves the focus to the opposite edge (bottom edge). Moves the focus down. When the focus is at the bottom edge, this moves the focus to the opposite edge (top edge). Moves the focus left. When the focus is at the left edge, this moves the focus to the opposite edge (right edge). When the focus is on “Character Set”, this selects the character type (moving backwards). When the focus is in an input box, this moves the cursor in the input box to the left. Moves the focus right. When the focus is at the right edge, this moves the focus to the opposite edge (left edge). When the focus is on “Character Set”, this selects the character type (moving forwards). When the focus is in an input box, this moves the cursor in the input box to the right.

Closes the software keyboard without applying the original input elements for the entered text. Erases the text in the input box where the cursor is currently located.

Using the Internet

:Tool

:Scroll

XXX

Using the Browser

ENTER,a/b/c/

• Press and then press ENTER.

EXIT

• Press the button to return to the TV screen.

RETURN

• Press the button to return to the previous page.

Example : The image shown below, which is only for

XXX

Tab

If content on a page is continued on another page, directions to that page are shown clearly. You can use a/b/c/d to go to the continuation of a page.

• Where there is link text or a link image in the

direction pressed, the text or image is selected ﬁ rst. If this happens, press the same direction button several times.

When “z” is displayed in a page:

• The page failed to load successfully, or it contains images with formats that cannot be displayed on the TV. Try

reloading the page by selecting “ ” (see page 62) in the toolbar.

a/b/c/d

explanation, is subject to change.

to select a link that you want to jump,

:Tool

Pages with security protection are clearly shown as such.

:Scroll

About links

• Web pages on the Internet often include “links” that allow you to jump to other web pages (or sites).

• “Links” can take various forms, including words or images, but they always work in the same way letting you jump to the link destination when you select them.

• Selected items (such as links of text input ﬁ elds) are enclosed in a yellow frame.

• You can jump from a “link” to the corresponding link destination.

CAUTION

• If the power is cut due to a power failure or the TV being unplugged while you are using the Internet, information such as bookmarks or cookies may not be saved correctly.

When a security notiﬁ cation window is displayed:

• Press

ENTER

• This window appears when you visit a web page that has security protection, or when you move from a protected page to an unprotected page.

• In “Security Settings” you can set whether or not this window is displayed. (See page 63.)

When a cookie conﬁ rmation window appears: Choose whether or not to accept the cookie (see page 63), and then press

• In “Cookies” settings you can set whether or not this window is displayed. You can also opt to delete all the cookies at once. (See page 63.)

to close the window.

ENTER

To users who access the Internet from a PC

• When you access the Internet from this TV, the procedures may not be the same as regular browser-based access on a PC.

• You cannot download ﬁ les.

• You cannot view a history of the pages you have visited.

• You cannot change the startup page displayed when you start AQUOS ADVANTAGE LIVE.

• Pop-up windows appear in separate tabs.

• On some pages, video and audio cannot be played, and text or images may not be displayed correctly.

Using the Internet

Using the Toolbar

You can use the toolbar to control the browser and to specify settings.

Press D to display the toolbar.

Pressc/d to select a function, and then press

ENTER.

Selected item Description

Displays the linked page in a new tab.

Displays the Tab menu.

Returns to the previous page.

Goes back to the AQUOS ADVANTAGE LIVE when you have viewed the previous page.

Refreshes the page. Interrupts a page while it is loading.

Displays the AQUOS ADVANTAGE LIVE.

Saving the URL of the Current Page

Adding a web page to your bookmarks allows you to return to that page later by simply selecting it from your list of bookmarks.

Display the page that you want to bookmark.

Press D to display the toolbar.

”

“

Pressc/d to select

press ENTER.

Select “Yes”, and then press ENTER.

• The page is added to your bookmarks.

in the toolbar, and then

Opening a Bookmarked Page

Press D to display the toolbar.

”

“

Pressc/d to select

press ENTER.

• Your bookmarks list is displayed.

Pressa/b/c/d to select the page you want to

access, and then press ENTER.

• The selected page is displayed.

• If you have bookmarked 11 or more web pages, press to scroll through your bookmarks list.

c/d

When opening a bookmark in a new tab:

Press A instead of ENTER.

• The Bookmarks menu appears.

Select “Open in New Tab”, and then press

ENTER.

in the toolbar, and then

Select this to open a bookmark.

Adds the current page to your bookmarks.

Displays the Browser menu.

Using Tabs

You can use tabs to view up to 3 web pages at the same time. Each page appears in a separate tab, and you can switch between the tabs.

Press B to display the Tab menu.

• You can also display the Tab menu by clicking “ ” in the toolbar.

Selected item Description

Select This Displays the web page in the

Close This Tab Closes the selected tab.

Close Other Tabs Closes the other (unselected) tabs.

Create New Tab Creates a new tab.

Pressc/d to select a tab.

Pressa/b to select the item you want to use, and

then press ENTER.

selected tab.

•

You can also press C to close a tab.

•

You can also press A to create a tab.

Editing Bookmarks

You can rearrange or delete the bookmarks.

Press D to display the toolbar.

”

“

Pressc/d to select

press ENTER.

• Your bookmarks list is displayed.

Pressa/b to select the title you want to edit from

the bookmarks list, and then press A.

• The Bookmarks menu appears.

Switching between the URL and title name

■

Select “Display by Address” or “Display by Title” in the Bookmarks menu, and then press ENTER.

Rearranging displayed items

■

Pressa/b to select “Move Up” or “Move Down”, and then press ENTER.

Deleting bookmarks

■

Pressa/b to select “Delete”, and then press

ENTER.

• To delete all the bookmarks, select “Delete All”.

Pressc/d to select “Yes”, and then press

ENTER.

in the toolbar, and then

Using the Internet

Browser Settings

You can check or modify your browser settings from the Browser menu. The Browser menu includes a display settings menu and a security settings menu.

Press D to display the toolbar.

”

“

Pressc/dto select

press ENTER.

Pressc/d to select the settings menu you want to

access.

Pressa/b to select and conﬁ rm the item you want

to set.

Pressa/b/c/d to specify the required setting,

and then press ENTER.

Press D to exit.

View Settings

Zoom In/Out:

Zoom in: Displays content enlarged to 200%. Normal: Displays content at 100%. Zoom out: Displays content reduced to 75%.

Encoding: Selects the desired encoding from the list below:

Western (ISO-8859-1)/Unicode (UTF-8)

Page Information: Displays information about the currently

displayed page.

Reset:

Yes: Resets the browser settings. No: Does not reset the browser settings.

in the toolbar, and then

Security Settings

Security:

Save Setting: If you select this option, a message is

displayed when you move from a protected page to an unprotected page. To change this setting, remove the tick, select “Save Setting” and then press ENTER.

Root Certiﬁ cates/CA Certiﬁ cates: Displays the list of

certiﬁ cates. To disable a certiﬁ cate, select the certiﬁ cate to be disabled and press A to display the sub-menu. Select “Disable”, and then press ENTER.

• Disabled certiﬁ cates are shown unticked in the certiﬁ cate list screen.

Cookies:

Accept all: Select this option to accept all cookies. Reject all: Select this option when you do not want to

accept cookies.

Prompt before accepting: When you open a page

that uses cookies, this option displays a conﬁ rmation message.

Delete All Cookies: Deletes all your cookies.

Server Certiﬁ cates: Displays certiﬁ cates for the connected

server.

Browser Information: Displays browser information.

•

This product contains NetFront Browser of ACCESS CO., LTD.

•

ACCESS, the ACCESS logo and NetFront are registered trademarks or trademarks of ACCESS CO., LTD. in the United States, Japan and/or other countries.

reserved.

•

This software is based in part on the work of the Independent JPEG Group.

• “Reset” does not reset the certiﬁ cation enable/disable and Encoding settings.

Using the Internet

Using Applications via the Internet

By connecting the TV to the Internet, you can enjoy a variety of broadband content, including videos, movies, music, photos, and games.

Please check that the most current software is loaded on TV by selecting "Auto Update Setting" on "Software Update" (see page 37) or by visiting http://www.sharpusa.com/products/support/

to check for a download of the newest software version.

Press SmartCentral to display the application

window.

Example

APP1 APP2 APP3

Pressa/b/c/d to select the desired application,

and then press ENTER.

• If " " or " " is displayed after you connect to the Internet, check your TV's network settings and connection.

• When using this TV to access an Internet application for the ﬁ rst time, the Disclaimer appears on the screen. Pressa/b to select "Agree", and then press ENTER. (You must select "Agree" to use the application.)

• Additional applications will be available in the future.

The screen for the selected application is displayed.

Follow the on-screen instructions for each application.

• Check the web site of the provider for details on setup and use of the functions.

Example

Information

Identiﬁcation

Digital Caption Info.

Software Update

Netﬂix Help

VUDU Help

Deactivating Netﬂ ix Function

Press MENU to display the menu screen.

Press c/d to select "Information", and then press

ENTER.

Press a/b to select "Netﬂ ix Help", and then press

ENTER.

Press c/d to select "Deactivate", and then press

ENTER.

• To conﬁ rm the Netﬂ ix status, check the information displayed on the screen and click "OK".

Deactivating the VUDU Function

Press MENU to display the menu screen.

Pressc/d to select "Information", and then press

ENTER.

Pressa/b to select "VUDU Help", and then press

ENTER.

Pressc/d to select "Yes", and then press

ENTER.

• These applications are provided by content providers. The available applications vary depending on your country or region.

• The delivery speed of applications varies depending on the network speed. Check the web site of the provider for details on application setup and other information.

Using the Internet

When you access the Internet application for the ﬁ rst time, the following appears.

• This message is available only in English.

DISCLAIMERS

This Sharp device facilitates the access to content and services provided by third parties. The content and services accessible via this device belong to and may be proprietary to third parties. Therefore, any use of such third party content and services must be in accordance with any authorization or terms of use provided by such content or service provider. Sharp shall not be liable to you or any third party for your failure to abide by such authorization or terms of use. Unless otherwise speciﬁ cally authorized by the applicable content or service provider, all third party content and services provided are for personal and non-commercial use; you may not modify, copy, distribute, transmit, display, perform, reproduce, upload, publish, license, create derivative works from, transfer or sell in any manner or medium any content or services available via this device.

Sharp is not responsible, nor liable, for customer service-related issues related to the third party content or services. Any questions, comments or service-related inquiries relating to the third party content or service should be made directly to the applicable content or service provider.

You may not be able to access content or services from the device for a variety of reasons which may be unrelated to the device itself, including, but not limited to, power failure, other Internet connection, or failure to conﬁ gure your device properly. Sharp, its directors, ofﬁ cers, employees, agents, contractors and afﬁ liates shall not be liable to you or any third party with respect to such failures or maintenance outages, regardless of cause or whether or not it could have been avoided.

ALL THIRD PARTY CONTENT OR SERVICES ACCESSIBLE VIA THIS DEVICE IS PROVIDED TO YOU ON AN “AS-IS” AND “AS AVAILABLE” BASIS AND SHARP AND ITS AFFILIATES MAKE NO WARRANTY OR REPRESENTATION OF ANY KIND TO YOU, EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT, FITNESS FOR A PARTICULAR PURPOSE OR ANY WARRANTIES OF SUITABILITY, AVAILABILITY, ACCURACY, COMPLETENESS, SECURITY, TITLE, USEFULNESS, LACK OF NEGLIGENCE OR ERROR-FREE OR UNINTERRUPTED OPERATION OR USE OF THE CONTENT OR SERVICES PROVIDED TO YOU OR THAT THE CONTENT OR SERVICES WILL MEET YOUR REQUIREMENTS OR EXPECTATIONS.

SHARP IS NOT AN AGENT OF AND ASSUMES NO RESPONSIBILITY FOR THE ACTS OR OMISSIONS OF THIRD PARTY CONTENT OR SERVICE PROVIDERS, NOR ANY ASPECT OF THE CONTENT OR SERVICE RELATED TO SUCH THIRD PARTY PROVIDERS.

IN NO EVENT WILL SHARP AND/OR ITS AFFILIATES BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE, CONSEQUENTIAL OR OTHER DAMAGES, WHETHER THE THEORY OF LIABILITY IS BASED ON CONTRACT, TORT, NEGLIGENCE, BREACH OF WARRANTY, STRICT LIABILITY OR OTHERWISE AND WHETHER OR NOT SHARP AND/OR ITS AFFILIATES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Examples of Application Logos

Appendix

Attaching the Stand (for LC-80LE633U)

• Before attaching (or detaching) the stand, unplug the AC cord.

• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.

CAUTION

• Attach the stand in the correct direction.

• Do not remove the stand from the TV unless using a wall mount bracket to mount it.

• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.

• After attaching the stand to the TV, do not hold the stand when you put up, set up, move or lay down the TV.

Before attaching the stand to the TV, build a work table on which to rest the TV.

• To build the table, use the cushioning materials used in the

packaging.

TOP-L

FRONT

• Of the cushioning materials used, TOP-C is also used

during stand unit assembly. Be sure to assemble the stand unit before building the work table.

Stand Unit Assembly

■

Conﬁ rm that there are 12 screws (8 long screws

and 4 short screws) supplied with the stand unit.

Set the post for the stand unit onto the TOP-C.

Attach the base to the post.

Insert and tighten the 8 screws into the 8 holes

TOP-R

TOP-C

on the bottom of the base.

Hold the stand unit securely with one hand, and then

•

tighten the screws.

Long screws

The case is equipped with push-in tabs to hold

the cushioning materials in place. Push in the tabs (2 for each location) to secure the cushioning materials in the case.

Push-in tabs

After you have built the work table, spread a

blanket or similar soft cloth over the table and then lay the TV display down on the covered table.

• Do not use a small table for this.

Attaching the Stand to the TV

■

Insert the stand into the openings on the bottom of

the TV.

• Make sure that the stand is ﬁ rmly inserted into the TV. Improper installation may result in tilting of the TV set.

Insert and tighten the 4 screws into the 4 holes on

the rear of the TV.

FRONT

Building the Work Table

■

Insert each of the cushioning materials in the

respective directions shown in the ﬁ gure.

• Insert TOP-L and TOP-R into the left and right sides of the case respectively.

• Insert TOP-C to ﬁ t between the lines on the other side of the case.

TOP-L

TOP-R

CASE

LINE

TOP-C

Short screws

• In the installation procedure, be careful not to catch your ﬁ ngers between the TV set and the ﬂ oor.

Appendix

Removing the Stand

•

Before detaching (or attaching) the stand, make sure to turn off the TV and unplug the AC cord.

CAUTION

LC-80LE633U/LC-70LE640U/LC-60LE640U/LC-70C6400U/LC-60C6400U

■

• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.

1 2

Unfasten the four screws used to secure the stand in place.

LC-52LE640U/LC-52C6400U

■

Before attaching/detaching the stand

• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.

Detach the stand from the TV.

Unfasten the four screws used to secure the stand in place.

• In the installation procedure, be careful not to catch your ﬁ ngers between the TV set and the ﬂ oor.

Detach the stand from the TV. (Hold the stand so it will not drop from the edge of the base area.)

Appendix

Setting the TV on the Wall

LC-70LE640U/LC-60LE640U/LC-52LE640U/LC-70C6400U/LC-60C6400U/LC-52C6400U

■

CAUTION

• This TV should be mounted on the wall only with the wall mount bracket AN-52AG4 (SHARP). The use of other wall mount brackets may result in an unstable installation and may cause serious injuries.

• Installing the TV requires special skill that should only be performed by qualiﬁ ed service personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or mounting that results in accident or injury.

Using an optional bracket to mount the TV

You can ask a qualiﬁ ed service professional about using an optional AN-52AG4 bracket to mount the TV on the wall.

•

• Carefully read the instructions that come with the bracket before beginning work.

Hanging on the wall

AN-52AG4 (See the bracket instructions for details.)

• Due to the terminal conﬁguration on this TV, when you wall-mount this model, make sure there is enough space between the wall and the TV for the cables.

• To use this TV mounted on a wall, remove the AC cord holder and the covers at the 4 locations on the rear of the TV, and then use the screws supplied with the wall mount bracket to secure the bracket to the rear of the TV.

wall mount bracket.

Vertical mounting

Angular mounting

LC-70LE640U LC-70C6400U

N-52AG4

0/5°

About setting the TV angle

LC-70LE640U/LC-70C6400U

• The center of the display:

/64 inch (10.0 mm) above the “c”

position.

LC-60LE640U/LC-60C6400U

• The “e” position is at the center of the display.

LC-52LE640U/LC-52C6400U

• The center of the display: 213/64inches (56.0 mm) under the “e” position.

• Refer to the operation manual of AN-52AG4 for details.

LC-60/52LE640U LC-60/52C6400U

Appendix

■

LC-80LE633U

The wall mount kit (sold separately) allows you to mount the TV on the wall. For detailed information on installing the wall mount, see the instructions provided with the product. We recommend you to contact a technician for assistance when installing it. SHARP is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own.

CAUTION

• Install your wall mount on a solid wall perpendicular to the ﬂ oor. When you want to attach the wall mount to surfaces other than plaster board, please contact your nearest retailer/adviser for additional information. If you install the TV on a ceiling or slanted wall, it may fall and result in severe personal injury. Always have two people mount the TV on a wall.

Wall Mount Kit Speciﬁ cations

Standard dimensions for wall mount kits are shown below.

(375)

Max

(175)

Max

WALL

WALL MOUNT KIT

/64(18.3)

Min

35/32(80)

WALL MOUNT UNIT

MOUNTING HOLES

SCREW

CABINET

DEPTH OF MOUNTING HOLES

/64(12)

(400) /

Max

137/64(40)

Max

1325/64(340)

(200)

235/8(600) A

WALL MOUNT KIT *

M8*

• VESA screw hole specs (A - B) in millimeters

• Standard screw

• Quantity

*1Must be smaller than the shaded area.

Use 1.25 pitch screws.

235/8-153/

(600 - 400)

• Do not mount the TV at a tilt.

• Due to the terminal conﬁ guration on this TV, when you wall-mount this model, make sure there is enough space between the wall and the TV for the cables.

• To use this TV mounted on a wall, remove the cable tie as needed.

• Do not use screws that do not comply with the VESA standard screw speciﬁ cations.

• Do not use screws that are longer than the standard length. Screws that are too long may cause damage to the inside of the TV set.

• Do not fasten the screws too ﬁ rmly or loosely. This may damage the product or cause the product to fall, leading to personal injury. SHARP is not liable for these kinds of accidents.

• SHARP is not liable for product damage or personal injury when a non-VESA or non-speciﬁ ed wall mount is used or the consumer fails to follow the product installation instructions.

Do not install the wall mount kit while your TV is turned on. It may result in personal injury due to electric shock.

Appendix

Troubleshooting

Problem Possible Solution

• No power • Check if you pressed POWER on the remote control unit.

• Unit cannot be operated. • External inﬂ uences such as lightning, static electricity, may cause improper

• Remote control unit does not operate.

• Picture is cut off/with sidebar screen.

• Strange color, light color, or color misalignment

• Power is suddenly turned off. • Is the sleep timer set? Page 20

• No sound • Is connection to other components correct? Pages 12 to 16 and 49

• Is the AC cord disconnected? Page 8

• Has the power been turned on? Page 17

operation. In this case, operate the unit after ﬁ rst turning off the power of the TV or unplugging the AC cord and replugging it in after 1 or 2 minutes.

• Is the equipment to be operated by the remote control unit set correctly? Press TV to set the remote control unit to the setting for operating the TV.

• Are batteries inserted with polarity (e,f) aligned? Page 9

• Are batteries worn out? (Replace with new batteries.)

• Are you using it under strong or ﬂ uorescent lighting?

• Is a ﬂ uorescent light illuminated near the remote control sensor?

• Is "RC Control Lock" selected in "Operation Lock Out"? Page 32

• Is the image position correct? Pages 31 and 54

• Are screen mode adjustments such as picture size made correctly?

Pages 23 and 53

• Adjust the picture tone. Pages 26 and 27

• Is the room too bright? The picture may look dark in a room that is too bright.

• Check the power control settings. Page 29

• The unit's internal temperature has increased. Remove any objects blocking vent or clean.

• Is the volume too low? Page 20

• Is "Variable" selected in "Output Select"? Page 31

• Have you pressed MUTE on the remote control unit? Page 20

• Check the audio output of the connected external equipment. Is the volume too

low or muted?

• When external equipment is connected via an HDMI cable, you may need to

conﬁ gure the audio to be output through the HDMI cable.

• When audio is not output from external equipment connected to the PC IN or HDMI

1 terminal, check the "Audio Select" setting.

• Even when external equipment is connected using an HDMI-certiﬁ ed cable, an audio

cable connection may be required depending on the type of equipment and the media being played back. In this case, in addition to connecting an HDMI-certiﬁ ed cable to the HDMI 1 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO IN terminal and set "Audio Select" to "HDMI+Analog".

• When connecting a PC via an HDMI-certiﬁ ed cable, check the following:

- Is the audio output of the PC conﬁ gured correctly? Check the audio output settings and output audio format in Sound Properties on the PC. Only PCM format audio can be output. Compressed audio (with a sampling rate of 32kHz, 44.1kHz, or 48kHz) and DTS format audio cannot be output.

- Depending on the board, only video signals may be output. In this case, in addition to connecting an HDMI-certiﬁ ed cable to the HDMI 1 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO IN terminal and set "Audio Select" to "HDMI+Analog".

• If you are using a DVI-HDMI conversion cable to connect external equipment to the TV, check the following:

- Is an audio cable connected? The DVI-HDMI conversion cable is for video only.

Connect a Ø 3.5 mm stereo minijack cable to listen to the audio.

- Is HDMI 1 being used? When the TV is connected to another HDMI terminal, the

audio and video are not output together even if a Ø 3.5 mm stereo minijack cable is connected to the shared AUDIO IN terminal for PC IN and HDMI 1.

Check the "Audio Select" setting. Set "Audio Select" to "HDMI+Analog".

Page 54

Page 17

Page 54

Appendix

Problem Possible Solution

• No picture • Is connection to other components correct? Pages 12 to 16 and 49

• Picture quality of HD programs is poor.

• The TV sometimes makes a cracking sound.

• The AQUOS ADVANTAGE LIVE

cannot be displayed.

• Some Internet functions used on

a PC are not available from the TV.

• Is the correct input selected? Pages 12 and 20

• Is "On" selected in "Audio Only"? Page 29

• If the PC image is not displayed, check the following:

- When connecting a laptop PC to the TV, check that display output mode of the PC is set to external monitor.

- Check the resolution setting on the PC. Is a non-compatible signal being input?

Page 54

• To enjoy HD images from external equipment, you are required to set up HDMI connection or component connection.

• If the program content is not of HD quality, HD images cannot be displayed. Check that the program you are viewing provides HD images.

• The HD cable/satellite set-top box may need to be conﬁ gured to output HD images via cable/satellite.

• The cable/satellite broadcast may not support a signal resolution of 1080p.

• This is not a malfunction. This happens when the cabinet slightly expands and contracts according to change in temperature. This does not affect the TV's performance.

• Is the ETHERNET cable connected correctly?

• Check the settings of "Internet Setup".

• The TV has only limited functions compared with regular PC browsers.

Page 57

Pages 58 to 59

Page 61

Troubleshooting - Error Message

The example of an error message

displayed on a screen

• Failed to receive broadcast. E202 • Check the antenna cable. Check that the antenna is correctly

• No broadcast now. E203 • Check the broadcast time in the program guide.

• An incompatible audio signal has been received. Change the output device audio settings to PCM.

Error code Possible Solution

setup.

— • This message is displayed when an audio format other than

PCM is input. (Dolby Digital and DTS audio formats are not supported.)

Set the audio output format of connected external HDMI

equipment to PCM. Refer to the operation manual of the external equipment for

setting details.

Cautions regarding use in high and low temperature environments

• When the unit is used in a low temperature space (e.g. room, ofﬁ ce), the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.

• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a heater, as this may cause the cabinet to deform and the front panel to malfunction. Storage temperature: f4°F to e140°F (f20°C to e60°C)

Appendix

CLEARING THE SECRET NUMBER

If you forget the secret number, clear the secret number using the following procedure.

Select an item from the list below to display the secret number input screen. (For operating the on-screen

display menu, see page 24.)

• "Color system" (

• "EZ Setup" or "Reset" (

• "CH Setup” (

• "Parental CTRL" (

• "Interactive Service" (

• "Software Update" (

Press and hold both CHU and VOLk on the TV simultaneously until the message appears on the screen.

➝

"Input Terminal Setting" ➝System Options menu).

➝

"Broadcasting Setup" ➝Initial Setup menu).

Initial Setup menu).

➝

"Individual Setup" ➝Initial Setup menu).

➝

"Internet Setup" ➝Initial Setup menu).

➝

Information menu).

The secret number is .

• As a precautionary measure, make a note of your secret number above, and keep it in a safe place.

Trademarks

• SmartCentral is a registered trademark of Sharp Corporation.

• Products that have earned the ENERGY STAR® are designed to protect the environment through superior energy

efﬁ ciency.

• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby

Laboratories.

• “HDMI, the HDMI logo and High-Deﬁ nition Multimedia Interface are trademarks or registered trademarks of HDMI

Licensing LLC in the United States and other countries.”

• DivX®, DivX Certiﬁ ed®, DivX Plus® HD and associated logos are trademarks of Rovi Corporation or its subsidiaries

and are used under license.

• The Wi-Fi CERTIFIED Logo is a certiﬁ cation mark of the Wi-Fi Alliance.

• The Wi-Fi Protected Setup Mark is a mark of the Wi-Fi Alliance.

• DLNA®, the DLNA Logo and DLNA CERTIFIED™ are trademarks, service marks, or certiﬁ cation marks of the Digital

Living Network Alliance.

•

This product is embedded with LC Font technology, which was developed by SHARP Corporation for clearly

displaying easy-to-read characters on LCD screens. However, other fonts are used for some screen pages, too.

• ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This

is an ofﬁ cial DivX Certiﬁ ed convert your ﬁ les into DivX videos.

• ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certiﬁ ed

Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

• Netﬂ ix and the Netﬂ ix logo are the registered trademarks of Netﬂ ix, Inc.

device that plays DivX video. Visit divx.com for more information and software tools to

and LC logo mark are registered trademarks of SHARP Corporation.

device must be registered in order to play purchased DivX

• VUDU™ is a trademark of VUDU, Inc.

Speciﬁ cations

LCD panel

Item

Model:

LC-80LE633U

LC-70LE640U/LC-70C6400U

Size 80o Class (80o Diagonal) 70o Class (69

Resolution 2,073,600 pixels (1,920 g 1,080)

Model:

Diagonal)

TV-standard (CCIR) American TV Standard ATSC/NTSC System

VHF/UHF VHF 2-13ch, UHF 14-69ch

CATV 1-135ch (non-scrambled channel only)

TV Function

Receiving Channel

Digital Terrestrial Broadcast (8VSB)

Digital cable

(64/256 QAM)

2-69ch

1-135ch (non-scrambled channel only)

Audio multiplex BTSC System

Audio out 10 W g 2

HDMI 1 HDMI in with HDCP, Audio in (Ø 3.5 mm stereo jack), ARC

HDMI 2 HDMI in with HDCP

Back panel vertical inputs

HDMI 3 HDMI in with HDCP

HDMI 4 HDMI in with HDCP

AUDIO OUT Audio out (Ø 3.5 mm stereo jack)

USB 1 Photo/Music/Video mode, Software update

COMPONENT COMPONENT in

VIDEO 1 AV in

Terminals

Back panel surface inputs

VIDEO 2 AV in

PC IN

ANALOG RGB (PC) in (15-pin mini D-sub female connector), Audio in (Ø 3.5 mm stereo jack)

RS-232C 9-pin D-sub male connector

75q Unbalance, F Type g 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)

Optical Digital audio output g 1 (PCM/Dolby Digital)

Back panel horizontal inputs

ANT/CABLE

AUDIO IN Audio in (Ø 3.5 mm stereo jack)

DIGITAL AUDIO OUTPUT

ETHERNET Network connector

USB 2 Photo/Music/Video mode, Software update

OSD language English/French/Spanish

Power Requirement AC 120 V, 60 Hz

Power Consumption 307 W (0.1 W Standby with AC 120 V) 228 W (0.1 W Standby with AC 120 V)

Weight

Dimension

(Wg H g D) (inch)

Operating temperature

Emergency alert messages via Cable are unreceivable.

The dimensional drawings are shown on the inside back cover.

TV + stand 123.5 lbs./56.0 kg 86.0 lbs./39.0 kg

TV only 114.6 lbs./52.0 kg 79.4 lbs./36.0 kg

TV + stand 73

TV only 73 5/

45 3/

43 25/

32°F to e104°F (0°C to e40°C)

17 3/

3 29/

6319/

39 47/

38 7/

13 1/

3 1/

• As part of policy of continuous improvement, SHARP reserves the right to make design and speciﬁ cation changes for product improvement without prior notice. The performance speciﬁ cation ﬁ gures indicated are nominal values of production units. There may be some deviations from these values in individual units.

Speciﬁ cations

LCD panel

Item

LC-60LE640U/LC-60C6400U

Size 60o Class (60

Model:

Diagonal) 52o Class (52

Resolution 2,073,600 pixels (1,920 g 1,080)

LC-52LE640U/LC-52C6400U

Model:

Diagonal)

TV-standard (CCIR) American TV Standard ATSC/NTSC System

VHF/UHF VHF 2-13ch, UHF 14-69ch

CATV 1-135ch (non-scrambled channel only)

TV Function

Receiving Channel

Digital Terrestrial Broadcast (8VSB)

Digital cable

(64/256 QAM)

2-69ch

1-135ch (non-scrambled channel only)

Audio multiplex BTSC System

Audio out 10 W g 2

HDMI 1 HDMI in with HDCP, Audio in (Ø 3.5 mm stereo jack), ARC

HDMI 2 HDMI in with HDCP

Back panel vertical inputs

HDMI 3 HDMI in with HDCP

HDMI 4 HDMI in with HDCP

AUDIO OUT Audio out (Ø 3.5 mm stereo jack)

USB 1 Photo/Music/Video mode, Software update

COMPONENT COMPONENT in

VIDEO 1 AV in

Terminals

Back panel surface inputs

VIDEO 2 AV in

PC IN

ANALOG RGB (PC) in (15-pin mini D-sub female connector), Audio in (Ø 3.5 mm stereo jack)

RS-232C 9-pin D-sub male connector

75q Unbalance, F Type g 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)

Optical Digital audio output g 1 (PCM/Dolby Digital)

Back panel horizontal inputs

ANT/CABLE

AUDIO IN Audio in (Ø 3.5 mm stereo jack)

DIGITAL AUDIO OUTPUT

ETHERNET Network connector

USB 2 Photo/Music/Video mode, Software update

OSD language English/French/Spanish

Power Requirement AC 120 V, 60 Hz

Power Consumption 188 W (0.1 W Standby with AC 120 V) 150 W (0.1 W Standby with AC 120 V)

Weight

Dimension (Wg H g D)

(inch) Operating temperature

TV + stand 61.7 lbs./28.0 kg 56.2 lbs./25.5 kg

TV only 56.2 lbs./25.5 kg 49.6 lbs./22.5 kg

TV + stand 54

TV only 54 17/

34 11/

33 1/

32°F to e104°F (0°C to e40°C)

13 1/

2 59/

479/

30 23/

29 3/

13 1/

2 27/

Optional Accessory

The listed optional accessory is available for the Liquid Crystal Television. Please purchase them at your nearest shop.

• Additional optional accessories may be available in the near future. When purchasing, please read the newest catalogue for compatibility and check the availability.

Part name Model number

Wall mount bracket

AN-52AG4 (for LC-70LE640U/LC-60LE640U/ LC-52LE640U/LC-70C6400U/ LC-60C6400U/LC-52C6400U)

Speciﬁ cations

Wireless LAN

This TV has received the following certiﬁ cations.

- Wi-Fi CERTIFIED™ (certiﬁ cation program from the Wi-Fi Alliance

- Wi-Fi Protected Setup™ (certiﬁ cation program from the Wi-Fi Alliance

FCC This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modiﬁ cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. To comply with the FCC RF exposure compliance requirements, this device and its antenna must not be co-located or operated in conjunction with any other antenna or transmitter. The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems; The maximum antenna gain permitted (for devices in the bands 5250-5350 MHz and 5470-5725 MHz) to comply with the e.i.r.p. limit; and High-power radars are allocated as primary users (meaning they have priority) of the bands 5250-5350 MHz and 5650-5850 MHz and these radars could cause interference and/or damage to LE-LAN devices.

COFETEL This equipment operates on a secondary basis and, consequently, must accept harmful interference, including from station of the same kind, and may not cause harmful interference to systems operating on a primary basis. CONTAINS TRANSMITTER MODULE COFETEL ID: RCPSHTW11-1252 Brand: SHARP Model: TWFM-B005D

Speciﬁ cation

Standard IEEE 802.11a/b/g/n

Frequency Band

Security

Modulation

2412-2484 MHz 5150-5850 MHz

Static WEP (64/128 bit key Index 1 only) WPA-PSK (TKIP) WPA2-PSK (AES)

DBPSK@1Mbps DQPSK@2Mbps CCK@5.5/11Mbps BPSK@6/9 Mbps QPSK@12/18Mbps 16-QAM@24Mbps 64-QAM@48/54Mbps and above, Rx up to 300Mbps

)

Information on the Software License for This Product

Software composition

■

The software included in this product is comprised of various software components whose individual copyrights are held by SHARP or by third parties.

Software developed by SHARP and open source software

■

The copyrights for the software components and various relevant documents included with this product that were developed or written by SHARP are owned by SHARP and are protected by the Copyright Act, international treaties, and other relevant laws. This product also makes use of freely distributed software and software components whose copyrights are held by third parties. These include software components covered by a GNU General Public License (hereafter GPL), a GNU Lesser General Public License (hereafter LGPL) or other license agreement.

Obtaining source code

■

Some of the open source software licensors require the distributor to provide the source code with the executable software components. GPL and LGPL include similar requirements. For information on obtaining the source code for the open source software and for obtaining the GPL, LGPL, and other license agreement information, visit the following website:

http://www.sharpusa.com/gpl We are unable to answer any questions about the source code for the open source software. The source code for

the software components whose copyrights are held by SHARP is not distributed.

Acknowledgements

■

The following are some of the open source software components included in this product:

• linux kernel/busybox/glibc/zlib/libpng/libjpeg/libiconv/DirectFB/OpenSSL/XMLRPC-EPI/mtd-utils/Expat/Qt/

U-Boot/PlayReady/AGG(ver2.3)/device-mapper/libfreetype/cURL/libxml2/lua/lua-xmlreader/lua-slncrypto/ Ffmpeg/SQLite/libzzip/c-ares/librt/libjanus/NTP

For the complete list, please see the URL above.

Software Copyrights

■

PlayReady

Portions of this software are based in part on the work of the Independent JPEG Group.

This product includes cryptographic software written by Eric Young (eay@cryptsoft.com).

Contact: Nokia Corporation (qt-info@nokia.com)

This product contains technology subject to certain intellectual property rights of Microsoft. Use or distribution of this technology outside of this product is prohibited without the appropriate lisense(s) from Microsoft. Content owners use Microsoft PlayReadyTM content access technology to protect their intellectual property, including copyrighted content. This device uses PlayReady technology to access PlayReadyprotected content and/or WMDRM-protected content. If the device fails to properly enforce restrictions on content usage, content owners may require Microsoft to revoke the device’s ability to consume PlayReady-protected content. Revocation should not affect unprotected content or content protected by other content access technologies. Content owners may require you to upgrade PlayReady to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade.

Information on the Software License for This Product

Fraunhofer IIS and Thomson Multimedia MPEG Layer-3 audio compression technology licensed by Fraunhofer IIS and Thomson Multimedia.

Nellymoser, Inc Speech compression and decompression technology licensed by Nellymoser, Inc.

Sorenson Media, Inc Sorenson

Sun Microsystem, Inc ADPCM speech compression algorithm is used with the permission of Sun Microsystems, Inc.

NTP

Permission to use, copy, modify, and distribute this software and its documentation for any purpose

cURL COPYRIGHT AND PERMISSION NOTICE Copyright © 1996-2009, Daniel Stenberg, <daniel@haxx.se>. All rights reserved. Permission to use, copy, modify, and distribute this software for any purpose with or without fee is

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR

Except as contained in this notice, the name of a copyright holder shall not be used in advertising or

You cannot use the MP3 compressed audio within the Software for real time or live broadcasts. If you require an MP3 decoder for real time or live broadcasts, you are responsible for obtaining this MP3 technology license.

SparkTM video compression and decompression technology licensed from Sorenson Media,

Inc.

with or without fee is hereby granted, provided that the above copyright notice appears in all copies and that both the copyright notice and this permission notice appear in supporting documentation, and that the name University of Delaware not be used in advertising or publicity pertaining to distribution of the software without speciﬁ c, written prior permission. The University of Delaware makes no representations about the suitability this software for any purpose. It is provided "as is" without express or implied warranty.

hereby granted, provided that the above copyright notice and this permission notice appear in all copies.

IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

otherwise to promote the sale, use or other dealings in this Software without prior written authorization of the copyright holder.

Information on the Software License for This Product

OpenSSL LICENSE ISSUES The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and

See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and

4. The names "OpenSSL Toolkit" and "OpenSSL Project" must not be used to endorse or promote

5. Products derived from this software may not be called "OpenSSL" nor may "OpenSSL" appear in

6. Redistributions of any form whatsoever must retain the following acknowledgment:

THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT "AS IS" AND ANY EXPRESSED OR IMPLIED

This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product

Original SSLeay License Copyright © 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the following conditions are

This can be in the form of a textual message at program startup or in documentation (online or textual)

Redistribution and use in source and binary forms, with or without modiﬁ cation, are permitted provided

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and

4. If you include any Windows speciﬁ c code (or a derivative thereof) from the apps directory (application

i.e. this code cannot simply be copied and put under another distribution licence [including the GNU Public Licence.]

the original SSLeay license apply to the toolkit.

case of any license issues related to OpenSSL please contact openssl-core@openssl.org.

that the following conditions are met:

following disclaimer.

the following disclaimer in the documentation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must display the following acknowledgment: "

This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit.

(http://www.openssl.org/)

products derived from this software without prior written permission. For written permission, please contact openssl-core@openssl.org.

their names without prior written permission of the OpenSSL Project.

This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit

(http://www.openssl.org/)

WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

includes software written by Tim Hudson (tjh@cryptsoft.com).

aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com). Copyright remains Eric Young’s, and as such any Copyright notices in the code are not to be removed. If this package is used in a product, Eric Young should be given attribution as the author of the parts of the library used.

provided with the package.

that the following conditions are met:

1. Redistributions of source code must retain the copyright notice, this list of conditions and the following disclaimer.

the following disclaimer in the documentation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must display the following acknowledgement: "

This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)

The word ‘cryptographic’ can be left out if the rouines from the library being used are not cryptographic related :-).

code) you must include an acknowledgement: "

This product includes software written by Tim Hudson (tjh@cryptsoft.com) THIS SOFTWARE IS PROVIDED BY ERIC YOUNG "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. The licence and distribution terms for any publically available version or derivative of this code cannot be changed.

Calling for Service

For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or customer assistance, please call 1-800-BE-SHARP.

LIMITED WARRANTY

CONSUMER LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the ﬁrst consumer purchaser that this Sharp brand Liquid Crystal Display product (the “Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.

This warranty does not apply to any appearance items of the Product or if the serial number or model number afﬁxed to the Product has been removed, defaced, changed, altered or tampered with. This warranty does not cover installation or signal reception problems. This limited warranty will not apply if the Product has been or is being used in a commercial setting or application; this warranty is meant solely for the non-commercial, household use of the Product by consumers in their home or residence. If you intend to or already use this Product for commercial purposes or in a commercial setting, there are warranties available to cover your use of this Product, the terms of which may vary. Please contact 1-888-GO-SHARP for further information.

In order to enforce your rights under this limited warranty, you should follow the steps set forth below. You must be able to provide proof of purchase to the servicer, which proof must include the date of purchase.

To the extent permitted by applicable state law, the warranties set forth are in lieu of, and exclusive of, all other warranties, express or implied. Speciﬁcally ALL OTHER WARRANTIES OTHER THAN THOSE SET FORTH ABOVE ARE EXCLUDED, ALL EXPRESS AND IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR USE, AND FITNESS FOR A PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED. IF, UNDER APPLICABLE STATE LAW, IMPLIED WARRANTIES MAY NOT VALIDLY BE DISCLAIMED OR EXCLUDED, THE DURATION OF SUCH IMPLIED WARRANTIES IS LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

The warranties given herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser and only for the time periods set forth herein. No other representations or promises made by anyone are permitted. Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulﬁllment of all liabilities and responsibilities of Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. Sharp does not warrant nor shall Sharp be liable, or in any way responsible, for Products which have been subject to abuse (including, but not limited to, improper voltage), accident, misuse, negligence, lack of reasonable care, alteration, modiﬁcation, tampering, misuse, improper operation or maintenance or any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than a Sharp authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some states do not allow limits on warranties or on remedies for breach in certain transactions; in such states, the limits herein may not apply.

THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND PUERTO RICO.

Model Speciﬁc Section

Your Product Model Number & Description:

Warranty Period for this Product: One (1) year parts and labor from the date of purchase.

Additional Exclusions from Warranty Coverage (if any):

Where to Obtain Service: From a Sharp Authorized Servicer located in the United States. To ﬁnd the

What to do to Obtain Service: Contact your Sharp Authorized Servicer to obtain in home service for this

LC-80LE633U/LC-70LE640U/LC-60LE640U/LC-52LE640U/ LC-70C6400U/LC-60C6400U/LC-52C6400U LCD Color Television (Be sure to have this information available when you need service for your Product.)

In order for the Product to be serviced, the Product must be readily available to the servicer, free and clear of any complex or non-standard installation, mounting or other encumbrance which would unreasonably interfere with servicing the Product. The Servicer will remount the Product after service, provided that such remounting is not into a complex or non-standard installation. Any additional labor and materials required to remove and/or reinstall a Product above and beyond the foregoing are not covered by this warranty, may result in additional charges and are the responsibility of the consumer. Image Retention resulting from a ﬁxed image being displayed for long periods of time is not covered by this Limited Warranty (see Operation Manual on how to prevent this).

location of the nearest Sharp Authorized Servicer, please call Sharp toll free at 1-800-BE-SHARP.

product. The Servicer will come to your location and if necessary remove the unit for repair at the Servicer’s facility and return the set to you once completed. Be sure to have Proof of Purchase available.

TO OBTAIN PRODUCT INFORMATION OR PURCHASE ACCESSORIES AND EXTENDED WARRANTIES, CALL 1-800-BE-SHARP

OR VISIT www.sharpusa.com

Dimensional Drawings

LC-80LE633U

(1112)

(1145)

(336)

69 47/

(1771.20)

73 5/16 (1862)

7 1/

(609)

(179)

(996.30)

29 1/32 (737) 17 3/

23 5/8 (600)

(200)

(400)

2 31/

(63)

3 1/2 (89)

3 29/

(434)

Unidad: pulgada (mm)

(99)

Unit: inch (mm)

Unité: pouce (mm)

16 37/

(421)

LC-70LE640U/LC-70C6400U

63 19/32 (1615)

21 7/64 (536)

15 3/4 (400)

(1009)

(976)

(115)

60 19/32 (1538.88)

8 15/32 (215)

(865.62)

(538)

(190)

(400)

5 (136)

/64

/8 (333)

/64

(137)

2 1/64 (51)

3 1/2 (89)

7 59/ (201)

(263)

5°

(461)20

(512)

Active area/Área activa/Zone active

Thinnest part/Parte más delgada/Partie la plus mince

AN-52AG4

Dimensional Drawings

LC-60LE640U/LC-60C6400U

5417/32 (1385)

/64 (536)

153/4 (400)

815/32 (215)

(872)

(839)

(52)

5211/32(1329.12)

(747.63)

(470)

(230)

(400)

5 (146)

417/ (115)

/64 (27.9)

/8 (333)

AN-52AG4

/64 (74)

Unit: inch (mm)

Unité: pouce (mm)

Unidad: pulgada (mm)

(156)

5°

(395)17

(442)

(169)

LC-52LE640U/LC-52C6400U

479/16 (1208)

/64 (536)

153/4 (400)

815/32 (215)

(771)

(739)

(17)

4523/64(1152.0)

(648.0)

(419)

(286)

(400)

5 (143)

13 1/8 (333)

(114)

/64 (26.4)

/32 (72)

AN-52AG4

(159)

(51)

5°

(345)15

(391)

Active area/Área activa/Zone active

Thinnest part/Parte más delgada/Partie la plus mince

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07495-1163

SHARP CORPORATION

Printed in Mexico Imprimé au Mexique Impreso en México TINS-F419WJN1 12P03-MX-NM

Sharp LC 60LE640U, LC 70LE640U, LC 52LE640U, LC-70C640U, LC-60C640U User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

IMPORTANT INFORMATION

DEAR SHARP CUSTOMER

IMPORTANT SAFETY INSTRUCTIONS

Contents

Supplied Accessories

QUICK REFERENCE

Attaching the Stand

QUICK INSTALLATION TIPS

Experiencing HD Images

Using the Remote Control Unit

Preparation

Antennas

Installing Batteries in the Remote Control Unit

Part Names

TV (Front)

TV (Rear/Side)

Remote Control Unit

Introduction to Connections

Types of Connection

Displaying an External Equipment Image

Connecting to External Equipment

Connecting a Blu-ray Disc/DVD Player or HD Cable/Satellite Set-top Box

Connecting a VCR, Game Console, Camcorder or Cable/Satellite Set-top Box

Connecting a Surround System/Audio System

Connecting a PC

Watching TV

Turning On/Off the Power

Initial Installation

Direct Button Operation

INPUT

Changing Channels

Changing Volume

MUTE

Sleep Timer

FREEZE

FLASHBACK

SmartCentral

NETFLIX

AV MODE

AUDIO

Closed Captions and Digital Closed Captions

VIEW MODE

On-Screen Display Menu

On-Screen Display Menu Operation

Menu Operation Buttons

Menu Items

Picture Settings

Audio Settings

Power Control

System Options

Initial Setup

Information

Enjoying Photo/Music/Video Playback

Connecting a USB Memory Device/USB Hard Drive

Connecting a Home Network (DLNA) Server

Selecting the Folders to Play Back

Playing Back Files on a USB Memory Device/Home Network (DLNA) Server

Other Viewing Options

Presetting Remote Control Function

Operating the Connected Equipment

Using AQUOS LINK

Controlling HDMI Equipment Using AQUOS LINK

Link Operation Menu

Using a PC

Displaying a PC Image on the Screen

Adjusting the PC Image

Setting Audio Input

PC Compatibility Chart

Control of the TV

Using the Internet

Connecting to the Internet

Internet Setup

AQUOS Advantage Live

Entering Text (Software Keyboard)

Using the Browser

Using Applications via the Internet
