LIQUID CRYSTAL TELEVISION TÉLÉVISEUR À CRISTAUX

LIQUIDES TELEVISOR DE CRISTAL

LÍQUIDO

OPERATION MANUAL MODE D’EMPLOI MANUAL DEL USUARIO

LC-70LE660U

LC-70C6600U LC-60LE660U LC-60C6600U LC-80LE661U LC-70EQ30U LC-70LE661U LC-60EQ30U

LC-60LE661U

1. Part Names

1- 1. TV 1- 2. Remote Control Unit

2. Watching TV

2- 1. Displaying an External Equipment Image 2- 2. Initial Installation

3. Direct Button Operation

3- 1. Changing Channels 3- 2. Changing Volume 3- 3. MUTE 3- 4. FREEZE 3- 5. FLASHBACK 3- 6. SmartCentral 3- 7. NETFLIX 3- 8. AUDIO 3- 9. Sleep Timer 3- 10. AV MODE 3- 12. Closed Captions and Digital Closed Captions 3- 14. VIEW MODE

4. On-Screen Display Menu

4- 1. Introduction 4- 3. On -Screen Display Menu Operation 4- 4. Menu Operation Buttons 4- 5. Initial Setup 4- 14. Information 4- 17. Picture Settings 4- 21. Audio Settings 4- 22. Smart TV 4- 25. System Options

5. Enjoying Photo/Music/Video Playback

5- 1. Preparation 5- 2. Selecting the Folders to Play Back 5- 4. Playing Back Files on a USB Memory Device/Home Network Server 5- 9. Presetting Remote Control Function 5- 12. Operating the Connected Equipment

6. Using LINK Operation

6- 1. Controlling HDMI Equipment Using LINK Operation 6- 3. Link Operation Menu 6- 5. Using a Smartphone with the TV

7. Using a PC

7- 1. Adjusting the PC Image 7- 2. Setting Audio Input 7- 3. Control of the TV 7- 9. PC Compatibility Chart

8. Using the Internet

8- 1. Connecting to the Internet 8- 2. Internet Setup 8- 5. Entering Text (Software Keyboard) 8- 7. Using the Browser 8- 11. Using Keyboard and Mouse 8- 12. Using Applications via the Internet 8- 14. Notes

9. Using the Miracast devices

9- 1. Miracast devices

10. Appendix

10-1. Removing the Stand 10-2. Setting the TV on the Wall 10-6. Troubleshooting

11. Specifications

11-1. TV (For LE660 and C6600U models) 11-2. TV (For LE661U model) 11-3. TV (For EQ30U model) 11-4. Wireless LAN

12-1. Trademarks

13. Dimensional Drawings

14. SmartCentral Terms of Use / Privacy Policy

15. Software License

ENG Contents

ENG Important1

ENG Important2

ENG Important3

ENG Important4

ENG Important5

Part Names

(Front)

*1 *2

(Side)

(Rear)

*1 See the Setup Guide. *2

*3 *4 *5 *6 For LE661U and EQ30U models only.

See page 4-18. See page 4-26.

See pages 2-1 and 4-4 for button operations.

And see page 6-1 for external equipment connection. See page 7-2 for details on the Audio Select function. See page 6-2. for details on the Audio Return Channel. See page 6-5. for details on the MHL function. See page 4-12 for details on the Input Select function.

The illustrations and on-screen displays in this operation manual are for explanation purposes

and may vary slightly from the actual operations.

The examples used throughout this manual are based on the LC- 60LE661U model.

ENG 1- 1

Part Names

1 POWER: 2

AUDIO operation.

(See pages 5-9 to 5-12 for details.)

* To enter the code registration mode, you need to press an appropriate button ( or

3 4 5

Operation is used.

(See pages 6-1 to 6-4 for details.)

(See page 3-9.)

(See pages 3-1

(See page 3-12 to 3 -13)

(See page 3-10.)

(See page 3-3.)

(See page 3-2.)

(See page 4-1.)

14 15 16 17

(See page 4-7.)

While watching, you can toggle the selected channels by pressing

19 20

Remote Control Unit

Switch the TV power on or enter standby.

TV, STB, DVD•VCR, AUDIO: Switches the remote control for TV, STB, BD, DVD, VCR and

AUDIO) and MANUAL at the same time. External equipment operational buttons: Operate the external equipment. DISPLAY: Display the channel information. OPTION: Display the Link Operation Menu screen. This button will function only when LINK

SLEEP: Set the sleep timer.

0–9: Set the channel.

• (DOT): Set the channel.

CC: Display captions from a closed-caption source.

AV MODE: Select an audio or video setting.

MUTE: Mute the sound.

VOL+/-: Set the volume.

MENU: Display the menu screen.

2D/3D: This button is not available.

/ / / , (ENTER): Select a desired item on the screen.

EXIT: Turn off the menu screen.

FAV CH: Set the favorite channels.

A, B, C, D: Select 4 preset favorite channels in 4 different categories.

MANUAL: Display the operation manual.

POWER (SOURCE): Turns the power of the external equipment on and off.

and 5-12.)

A, B, C and D.

STB, DVD•VCR

NOTE

When using the remote control unit,

point it at the TV.

The appearance of the remote

control unit varies by the time when you purchased the product.

ENG 1- 2

Part Names

21 FREEZE:

(See page 3-4.)

(See page 3-8.)

23 24

(See page 3-5.)

(See pages 3-14 to 3 -16.)

(See page 2-1.)

(See page 3-1.)

(See page 3-6.)

29 30

If you press the NETFLIX button when the TV is turned off, the TV turns on and the NETFLIX screen is displayed.

(See page 3-7.)

(See page 8-12.)

Remote Control Unit (Continue)

Set the still image. Press again to return to normal screen.

AUDIO: Selects the MTS/SAP or the audio mode during multichannel audio broadcasts.

ENT: Jumps to a channel after selecting with the 0–9 buttons.

FLASHBACK: Return to the previous channel or external input mode.

VIEW MODE: Select the screen size.

INPUT: Select a TV input source.

CH / : Select the channel.

SmartCentral: Display the application window.

RETURN: Return to the previous menu screen.

NETFLIX: Display the Netflix screen.

FAV APP 1, 2, 3: You can assign your favorite applications to these buttons.

NOTE

When using the remote control unit,

point it at the TV.

The appearance of the remote

control unit varies by the time when you purchased the product.

ENG 1- 3

Watching TV

To view external source images, select the input source by pressing unit or on the TV.

Displaying an External Equipment Image

INPUT on the remote control

Example

You can also select the input source by pressing INPUT. Each time INPUT is pressed, the input source toggles.

1 Press INPUT.

The INPUT list screen displays.

2 Press

/ to select the input source.

An image from the selected source

automatically displays.

ENG 2- 1

Watching TV

Initial Installation

Perform the following steps before you press POWER on the remote control unit.

1. Insert the batteries into the remote control unit.

2. Connect the antenna cable to the TV.

3. Plug in the AC cord to the AC outlet.

Language (Language setting)

Select from among 3 languages: English, French and Spanish.

1 Press

/ to select the desired language listed on the

screen, and then press ENTER.

Location & Time

Make settings for the country, area and time zone where you use the TV.

2 Press

3 Press / to select the time zone where you are using

/ to select "United States", "Canada" or

"Mexico", and then press ENTER.

the TV, and then press ENTER.

The time zone differs depending on the selected

country.

The factory preset value is the time zone for the capital

of the selected country.

Example

ENG 2- 2

Watching TV

Initial Installation (Continue)

4 Press / to select the Daylight Savings Time, and then

press ENTER.

"Auto" is the default selection.

TV Location

Select "Home" or "Store" for the location where you plan to install the TV. This product qualifies for ENERGY STAR in Home mode default setting.

5 Press / to select "Home" or "Store".

Press ENTER to enter the setting.

Home: AV MODE is set to "STANDARD (ENERGY

STAR)".

Store: AV MODE is set to "DYNAMIC (Fixed)". Picture

Reset and Feature Demo can be set.

Picture Reset: AV MODE will be set to "DYNAMIC (Fixed)" regardless of whether Picture Reset is "On" or "Off".

If you select "On" and there is no operation for 30

minutes:

- AV MODE will be reset to "DYNAMIC (Fixed)".

When "Off" is selected:

- Even after 30 minutes elapses, AV MODE is not reset to "DYNAMIC (Fixed)".

Feature Demo: When "On" is selected, after all the settings are completed, the Feature Demo screen is displayed if there is no operation for several minutes.

NOTE

ENERGY STAR qualification is based on AV MODE

"STANDARD (ENERGY STAR).

ENG 2- 3

Watching TV

Initial Installation (Continue)

Antenna & Cable/STB

Select the type of connection you will use to watch TV.

6 Press

To watch TV via an antenna or cable connection (without using a set-top box):

Select "Antenna & Cable", and then go to step 7. To watch TV via a set-top box:

/ to select "Antenna & Cable" or "Set-top box",

and then press ENTER.

Select "Set-top box", and then press ENTER. Check that the set- top box connected to the TV is on.

To watch TV, select the input source corresponding to the terminal connected to the set- top box.

See page 4-12 for details on the Input Skip function.

Press INPUT to select the input source corresponding to the terminal connected to the set- top box. Make the necessary settings on the connected external equipment.

See the operation manual of the connected equipment for

setting up the equipment.

Air/Cable (Antenna setting)

Make sure what kind of connection is made with your TV when selecting "Air" or "Cable".

7 Press Press ENTER to enter the setting.

/ to select "Air" or "Cable".

ENG 2- 4

Watching TV

Initial Installation (Continue)

CH Search (Channel search)

Channel auto search makes the TV look for all channels viewable in the set area.

8 When "Air" is selected in Antenna setting: Press

/ to select "Start", and then press ENTER.

When "Cable" is selected in Antenna setting:

Press

/ to select "Analog & Digital Search Start" to search both analog and digital broadcasts, or to select "Analog Search Start" to search only analog broadcasts, and then press ENTER.

The Channel search will start automatically. To exit the Channel search screen, select "Cancel", and

then press ENTER.

Smart TV

When you connect to the Internet on the TV, select the desired connection method and follow the instructions shown on the display.

Wireless LAN connection is possible only when the WPS

(push button) method is used. If any other method is used, make settings by Smart TV > Internet Setup.

(See pages 8-2 to 8-4.)

9 Press

10 Press / to select "Wired" or "Wireless", and then

/ to select "Yes", and then press ENTER.

press ENTER.

ENG 2- 5

Watching TV

Initial Installation (Continue)

Connection using an ETHERNET cable:

Select "Wired" and press ENTER. Confirm that the TV is properly connected with the

router, and then press "Next". Follow the instructions on the display to perform the connection test.

Wireless LAN connection by the WPS method:

Select "Wireless" and press ENTER. Follow the instructions on the display, and finalize the

connection after testing its viability.

NOTE

After you finish configuring the network settings,

configure the "TV Name Setting".

(See pages 4-24, 7-3.)

When you change the network settings, refer to Smart TV

> Internet Setup.

(See pages 8-2 to 8-4.)

Completed

11 The settings confirmation screen is displayed. Confirm

the information displayed on the screen, and then press

ENTER.

Examples of the settings confirmation screen When "Antenna & Cable" was selected in step 6.

ENG 2- 6

Watching TV

Initial Installation (Continue)

NOTE

If no channel is found, confirm the type of connection

made with your TV and try "Easy Setup" again.

(See page 4-5.)

When "Set-top box" was selected in step 6.

Click "OK" to display the confirmation screen for input

source switching.

Show the input list: You can check the current connection

status of external equipment. Confirm which input terminal is connected to the set -top box.

OK: Clicking "OK" will complete the Easy Setup procedure.

NOTE

For changing the settings of the Initial Installation, perform

"Easy Setup" on the Initial Setup menu on

page 4-5.

ENG 2- 7

Direct Button Operation

Changing Channels

You can change channels in several ways.

Method 1 Using CH Method 2 Using remote control buttons 0-9, • (DOT).

Examples: To select a 1 or 2-digit channel number (e. g., Channel

Press 5 To select a 3 -digit channel number (e. g., Channel

Press 1 To select a 4 -digit channel number (e. g., Channel

Press 2

/ on the remote control unit or on the TV.

5):

ENTER

115):

1 5 ENTER

22.1):

2 • (DOT) 1 ENTER

NOTE

When selecting a 1 -digit channel number, it is not

necessary to press 0 before the number.

When you enter 0-9 only, channel selection will be made

if there is no operation within a few seconds. If you push "0" by itself, nothing will happen. Complete the above steps within a few seconds. When you enter 0-9 and • (DOT), channel selection will

be made if there is no operation within a few seconds.

ENG 3- 1

Direct Button Operation

Changing Volume

You can change the volume by pressing VOL+/- on the TV or on the remote control unit.

To increase the volume, press VOL +. To decrease the volume, press VOL -.

Audio status

Output device

Speaker Variable sound Mute

When "Output Select" is set to "Variable", the indicator on

the screen changes as shown below.

NOTE

See page 4-12 for details on the Output Select function.

Output Select

Fixed Variable

ENG 3- 2

Direct Button Operation

MUTE

Mutes the current sound output. Press MUTE.

" " will be displayed on the screen for 30 minutes, and

the sound is silenced.

NOTE

Within 30 minutes of pressing MUTE, mute can be

canceled by pressing VOL+/- or MUTE.

Mute will be canceled after 30 minutes have passed.

However, the TV will not suddenly output a loud sound as the volume level is set to 0 automatically.

ENG 3- 3

Direct Button Operation

FREEZE

Allows you to capture and freeze a moving image that you are watching. Press FREEZE.

A moving image is captured. Press FREEZE again to cancel the function.

NOTE

When this function is not available, "No displaying still

image available." will display.

If you are using the freeze function and a broadcast

activates the V-CHIP BLOCK, the freeze function will be canceled and a V- CHIP BLOCK message will appear.

ENG 3- 4

Direct Button Operation

FLASHBACK

Press FLASHBACK to switch to the previously tuned channel or previous input mode.

Press FLASHBACK again to switch back to the currently

tuned channel.

NOTE

FLASHBACK will not work if no channel has been

changed after the TV is turned on.

ENG 3- 5

Direct Button Operation

SmartCentral

Allows you to directly activate various types of applications.

1 Press SmartCentral to display the application window.

Press SmartCentral again to switch back to the

currently tuned channel.

2 Press

NOTE

/ to select the desired application, and then

press ENTER.

If " " is displayed, check the USB connection. If " " or " " is displayed, check your TV’s

network settings and connection.

See page 5-2, 8-7 to 8-12 for details of viewable

applications.

When this function is not available, "Can not operate this

function now" will display.

ENG 3- 6

Direct Button Operation

NETFLIX

Displays the Netflix screen.

Press NETFLIX.

NOTE

If you press the NETFLIX button when the TV is turned off, the TV turns on and the NETFLIX screen is displayed.

To enjoy Netflix, you need to make:

—a broadband Internet connection

(See page 8-1.)

—settings of Internet Setup

(See pages 8-2 to 8-4.)

—adjustments for Netflix

(See page 8-13.)

ENG 3- 7

Direct Button Operation

Examples: when receiving MTS and SAP

AUDIO

MTS/SAP stereo mode

The TV has a feature that allows reception of sound other than the main audio for the program. This feature is called Multi-channel Television Sound (MTS). The TV with MTS can receive mono sound, stereo sound and Secondary Audio Programs (SAP). The SAP feature allows a TV station to broadcast other information, which could be audio in another language or something completely different like weather information.

You can enjoy Hi-Fi stereo sound or SAP broadcasts where available.

Stereo broadcasts: View programs like live sporting

events, shows and concerts in dynamic stereo sound.

SAP broadcasts: Receive TV broadcasts in either MAIN

or SAP sound. MAIN sound: The normal program soundtrack (either in mono or stereo). SAP sound: Listen to a second language, supplementary commentary or other information. (SAP is mono sound.)

If stereo sound is difficult to hear.

Obtain a clearer sound by manually switching to fixed

mono -sound mode. You can change MTS as shown below to match the television broadcast signal. Press AUDIO to toggle between audio modes.

STEREO mode:

STEREO + SAP mode: MAIN + SAP mode: MONO mode: MONO

Digital broadcasting audio mode

The types of audio transmitted in a digital broadcast include SURROUND as well as MONO and STEREO. In addition, it is possible for multiple audio tracks to accompany a single video track. Press AUDIO to toggle between audio modes.

Example: when receiving Digital broadcasting

NOTE

MTS only operates while in TV mode. You can have the same settings by choosing "Change

Audio" on the menu items.

(See page 4-25.)

ENG 3- 8

Direct Button Operation

Sleep Timer

Allows you to set a time when the TV automatically switches to standby. Press SLEEP.

The remaining time displays when the sleep timer has

been set.

Each time you press SLEEP, the remaining time switches

as shown below.

When set, the time automatically starts counting down. If you want to adjust the sleep timer, you can press

SLEEP twice then change the time setting.

When it is 5 minutes before the time expires, the

remaining time will start to keep appearing every minute.

NOTE

Select "Off" by pressing SLEEP to cancel the sleep timer. The TV will enter standby when the remaining time

reaches 0.

ENG 3- 9

Direct Button Operation

AV MODE

AV MODE gives you several viewing options to choose from to best match the surrounding environment of the TV, which can vary due to factors like room brightness, type of program watched or the type of device connected. You can use USER Mode to create customized settings for each TV input. These settings will be automatically saved on each input for convenience. Press AV MODE. Current AV MODE displays.

Press AV MODE again before the mode displayed on the

screen disappears.

The mode changes as shown below:

ENG 3- 10

Direct Button Operation

AV MODE (Continue)

STANDARD (ENERGY STAR): For a highly defined image

in a normal lighting.

MOVIE: For a movie. PC: For PC. USER: Allows the user to customize settings as desired.

You can set the mode for each input source.

DYNAMIC: For a clear-cut image emphasizing high

contrast, useful for sports viewing.

DYNAMIC (Fixed): Changes the image and sound settings

to the factory preset values. No adjustments are allowed.

NOTE

You can select a different AV MODE item for each input

mode. (For example, select STANDARD (ENERGY STAR) for TV input and DYNAMIC for COMPONENT.)

You can have the same settings by choosing "AV MODE"

on the menu items.

(See page 4-17.)

ENG 3- 11

Direct Button Operation

Closed Captions and Digital Closed Captions

Your TV is equipped with an internal Closed Caption decoder. It allows you to view conversations, narration and sound effects as subtitles on your TV. Closed Captions are available on some TV programs and on some VHS home video tapes at the discretion of the program provider. Digital Closed Caption service is a new caption service available only on digital TV programs (also at the discretion of the service provider). It is a more flexible system than the original Closed Caption system, because it allows for a variety of caption sizes and font styles. When the Digital Closed Caption service is in use, it will be indicated by the appearance of a 3- letter abbreviation that also indicates the language of the Digital Closed Captions: ENG (English), SPA (Spanish), FRA (French) or other language codes. Not all programs and VHS videotapes offer closed captions. Please look for the " be shown. In the Closed Caption system, there can be more than one caption service provided. Each is identified by its own number. The "CC1" and "CC2" services display subtitles of TV programs superimposed over the program’s picture. In the Closed Caption system, the "Text1" or "Text2" services display text that is unrelated to the program being viewed (e.g., weather or news). These services are also superimposed over the program currently being viewed.

" symbol to ensure that captions will

1 Press CC.

This will present the Closed Caption information

display.

2 Press CC while the Closed Caption information is still on

the screen.

Press repeatedly until you select the desired closed

caption service.

Depending on the number of caption services in the

signal being received, you will see information such as 1/2 or 1/4 displayed. 1/2 means "the first of two services".

Example:

If a program has three services (Digital CC(ENG), CC1 and Text1), the closed caption display will toggle in this sequence:

The CC button keeps a record of the last service selected

in its memory. If the last closed caption mode (e.g. 1/3 ENG) you selected is not available for the next program, or on another channel, the closed caption service that is available is automatically selected, and this service appears in parentheses, e.g. "1/3(CC1)". Closed Caption services that appear in parentheses will not be stored in the CC button’s memory as your last selected service. Only services that you have selected with the CC button are stored.

ENG 3- 12

Direct Button Operation

Closed Captions and Digital Closed Captions (Continue)

Examples:

In a case where there are two closed caption services provided (for instance, Digital CC(ENG) and CC1), and Digital CC(ENG) is displayed as your current selection, if Digital CC(ENG) is not broadcast for the next program, the other closed caption service, CC1, will be displayed in parentheses. A closed caption service appears in parentheses because the service you selected is not available and a different service is displayed on your screen. "1/1(CC1)" is displayed instead of "1/2/ENG".

NOTE

See page 4-26 for detailed closed caption settings.

When the program contains no closed caption, "-- "

displays in the closed caption information.

If the language code, e.g. "ENG", is not found on Digital

TV programs, "- -" will be shown.

Four kinds of closed caption service (CC1, CC2, Text1,

Text2) are potentially available, but a broadcast may contain none or only some of these services at the discretion of the program provider.

When a web page is displayed, Closed Captions are not

available.

You can have the same settings by choosing "Change

CC" on the menu items.

(See page 4-25.)

ENG 3- 13

Direct Button Operation

VIEW MODE

You can select the screen size.

1 Press VIEW MODE.

The View Mode menu displays. The menu lists the View Mode options selectable for the type of video signal currently being received.

2 Press VIEW MODE or

You can sequentially select a View Mode that has its own aspect ratio.

NOTE

You can have the same settings by choosing "View Mode" on the menu items.

(See page 4-25.)

For HD programs

Stretch

/ while the View Mode menu is displayed to select a desired item on the menu.

Dot by Dot (Full Screen) S.Stretch (Smart stretch) Zoom

Suitable for viewing wide -

screen 1.78:1 aspect ratio

program, stretch mode will

still show very thin black

bands at the top and

bottom of the screen.

NOTE

When using Dot by Dot or Full Screen, it is possible to see noise or bars around different outer portions of the screen. Please

change view mode to correct this.

"Dot by Dot" when the

number of pixels on the

screen and the resolution of

the signal are the same.

"Full Screen" when the

number of pixels on the

screen and the resolution of

the signal are different. In

either case, the image fully

fills the screen.

Suitable for stretching 4:3

programs to fill the screen.

Suitable for viewing wide -

screen 2.35:1 aspect-ratio

programs in full screen.

ENG 3- 14

Direct Button Operation

VIEW MODE (Continue)

For 4:3 programs Example: Screen size images

Side Bar S.Stretch (Smart stretch) Zoom Stretch

Suitable for viewing

conventional 4:3 programs in

their normal format.

For USB-Video, Home Network Video or Internet applications Example: Screen size images

Input signal Auto Original Stretch

Suitable for stretching 4:3

programs to fill the screen.

Keeps the original

aspect ratio in a full

screen display.

Suitable for viewing wide screen 2.35:1 anamorphic

DVDs in full screen.

Displays an image by

an original size.

An image fully fills the

This mode is useful for 1.78:1

DVDs. When viewing 1.85:1 DVDs, stretch mode will still

show very thin black bands at

the top and bottom of the

screen.

ENG 3- 15

Direct Button Operation

VIEW MODE (Continue)

For PC Example: Screen size images

Input signal Normal Stretch Dot by Dot

Keeps the original aspect

ratio in a full screen display.

NOTE

Connect the PC before making adjustments. See the Setup Guide. Selectable screen size may vary with input signal type.

An image fully fills the

screen.

Detects the resolution of the

signal and displays an image

with the same number of pixels

on the screen.

ENG 3- 16

On-Screen Display Menu

Introduction

LCFONT embedded

Guide display

This indicates the buttons that can be operated on the

displayed screen. The guide display varies depending on the menu setting screen.

The operations for some selected items may be displayed

in the operational guide bar at the bottom of the screen.

Item displayed in blue

This indicates the item currently selected. Press ENTER to go to the adjustment screen for this

item.

Item in brackets

This indicates the current setting for the item.

ENG 4- 1

Item displayed in white

This indicates that the item can be selected.

Item displayed in gray

This indicates that the item cannot be selected.

There are various reasons why the items cannot be

selected, but the main reasons are as follows: — Nothing is connected to the selected input terminal. — The function is not compatible with the current input

signal.

— When this conflicts with other functions, you must change

the settings for the other functions.

On-Screen Display Menu

Introduction (Continue)

About Menu Items

Some menu items may not be displayed depending on the

selected input source.

NOTE

The screens in the operation manual are for explanation

purposes (some are enlarged, others cropped) and may vary slightly from the actual screens.

The order of explanations for each menu item in the

following pages is not necessarily in accordance with the alignment of the items on the screen.

LCFONT:

This product is embedded with LC Font technology, which

was developed by SHARP Corporation for clearly displaying easy-to- read characters on LCD screens.

ENG 4- 2

On-Screen Display Menu

On-Screen Display Menu Operation

Example

1 Press MENU to display the MENU screen. 2

Press / to select the desired menu.

Press / to select a specific adjustment item, and then

press ENTER.

Additional related adjustment items may be displayed.

Press

/ to select the desired item.

Adjust the item while referring to the guide display. Operations vary depending on the function or item.

Refer to the guide display corresponding to the menu setting screen for button operations.

ENG 4- 3

3 Press MENU to exit.

NOTE

Menu options differ in the selected input modes, but the

operating procedures are the same.

On-Screen Display Menu

Menu Operation Buttons

Using the remote control

Use the following buttons on the remote control to operate the menu.

MENU: Press to open or close the menu screen.

/ / / : Press to select a desired item on the screen or

adjust a selected item. ENTER: Press to go to the next step or complete the setting.

RETURN: Press to return to the previous step.

Using the control panel of the TV

You can also operate the menu with the control panel of the TV. Button operations on the control panel correspond to the ones on the remote control as shown below.

MENU: MENU on the remote control. INPUT: ENTER on the remote control. CH

/ : Cursor / on the remote control.

VOL+/-: Cursor

/ on the remote control.

ENG 4- 4

On-Screen Display Menu

Example

Initial Setup

NOTE

For operating the on-screen display menu,

see page 4-3.

Easy Setup

You can run Easy Setup again, even after setting up the preset channels.

Language: Select from among 3 languages (English,

French and Spanish).

Location & Time: Make settings for the country, area and

time zone where you use the TV.

Select your country: Select either "United States", "Canada" or "Mexico".

Select your time zone: Select your time zone. The available settings differ depending on the selected country.

Select DST (Daylight Savings Time): Select "Auto", "Manual" or "Off".

TV Location: Select "Home" or "Store" for the location

where you plan to install the TV. This product qualifies for ENERGY STAR in Home mode default setting.

Home: AV MODE is set to "STANDARD (ENERGY STAR)".

Store: AV MODE is set to "DYNAMIC (Fixed)". Picture Reset and Feature Demo can be set.

Picture Reset: AV MODE will be set to "DYNAMIC (Fixed)" regardless of whether Picture Reset is "On" or "Off". If you select "On", AV MODE will be reset to "DYNAMIC (Fixed)" if there is no operation for 30 minutes. When "Off" is selected, even after 30 minutes elapses, AV MODE is not reset to "DYNAMIC (Fixed)".

Feature Demo: When "On" is selected, after all the settings are completed, the Feature Demo screen is displayed if there is no operation for several minutes.

ENERGY STAR qualification is based on AV MODE

"STANDARD (ENERGY STAR)".

Antenna & Cable/STB: Select the type of connection you

will use to watch TV.

Air/Cable: Make sure what kind of connection is made

with your TV when selecting "Air" or "Cable".

CH Search: Channel auto search makes the TV look for

all channels viewable in the set area.

Smart TV: When you connect to the Internet on the TV,

confirm the connection method and make adjustments.

Wireless LAN connection is possible only when the

WPS (push button) method is used. If any other method is used, make settings by Smart TV > Internet Setup.

(See pages 8-2 to 8-4.)

Completed: The settings confirmation screen is displayed.

Confirm the information displayed on the screen.

NOTE

See Initial Installation on

pages 2-2 to 2-7 for setting each item.

If no channel is found, confirm the type of connection

made with your TV and try "Easy Setup" again.

If you select "Analog Search Start" and initiate the

channel search, the CH Memory for Cable Digital will be deleted.

ENG 4- 5

On-Screen Display Menu

Example

Initial Setup (Continue)

Language

You can also select a language from the Initial Setup menu. Select from among 3 languages: English, French and Spanish.

NOTE

To change the language of the manual, select "MENU" >

"Initial Setup" > "Language" to change the language. Then, press MANUAL again.

TV Channel Setup

Channel Setup

If Initial Installation does not memorize all the channels in your region, follow the instructions below to manually memorize the channels.

Air/Cable: Make sure what kind of connection is made

with your TV when selecting "Air" or "Cable".

CH Search: Channel auto search makes the TV look for

all channels viewable in the set area.

CH Memory: You can select the channels to skip in each

ANALOG (Air), ANALOG (Cable), DIGITAL (Air) and DIGITAL (Cable).

On: Skips channels. (Channel selection disabled using CH

/ .)

Off: Does not skip channels. (Channel selection enabled using CH

NOTE

See Initial Installation on

pages 2-2 to 2-7 for setting each item.

If no channel is found, confirm the type of connection

made with your TV and try channel search again.

If you select "Analog Search Start" and initiate the

channel search, the CH Memory for Cable Digital will be deleted.

/ .)

ENG 4- 6

On-Screen Display Menu

Example

Initial Setup (Continue)

TV Channel Setup

Favorite CH (Favorite Channel Setting)

This function allows you to program 4 favorite channels, in 4 different categories. By setting the favorite channels in advance, you can select your favorite channels easily.

To register your favorite channel:

Select "Register" and then press ENTER. Press

select the position in the category, and then press ENTER to register.

To delete your favorite channel:

Select "1 Data Clear" and then press ENTER. Press

to select the channel you want to delete, and then

press ENTER. Select "Yes" and then press ENTER.

To delete all the favorite channels, select "All Data Clear".

NOTE

Before setting the channel, select the channel you want

to register as a favorite channel.

You can display the "Favorite CH" screen by pressing

FAV CH on the remote control.

/ / / to

/ / /

Antenna Setup-DIGITAL

In order to receive digital air broadcasts, you need a digital broadcast antenna. You can confirm the antenna configuration through the "Antenna Setup-DIGITAL" screen. If necessary, adjust the direction of the antenna to obtain the maximum signal strength.

Signal Strength: The signal strength of DIGITAL channel

is displayed. The signal information is based on the current channel.

Channel Strength: Input the 2 -digit channel number to

check the signal strength of the selected channel. Make sure the signal is strong enough for each channel.

This function is available for DIGITAL (Air) only.

ENG 4- 7

On-Screen Display Menu

Example

Initial Setup (Continue)

Individual Setup

Secret No.

Allows you to use a secret number to protect certain settings from being accidentally changed.

IMPORTANT:

Three conditions must be met to enable the V -Chip

1. Secret No. is registered.

2. V -Chip/V-Chip (DTV Only) settings have been made.

The "V- Chip (DTV Only)" will only be selectable when

a new rating system can be downloaded via digital broadcasting in the U.S.

3. "Status" is set to "Enable".

Setting Secret No. You can set and change the secret number by using 0-9.

New Secret No.: Changes or sets the Secret No. Confirm Secret No: Enter Secret No. to confirm.

NOTE

As a precautionary measure, make a note of your secret

number and keep it in a familiar place.

Parental Control (Parental Control Setting)

V-Chip

V- CHIP is an electronic filtering device built into your TV. This tool gives parents a great degree of control over broadcasts accessed by their children. It allows parents to select programs judged suitable for child viewing while blocking ones judged not suitable. It does so automatically once you activate the V-CHIP feature in your TV. "V-Chip" and "Status" will not be selectable from the menu if you do not first configure your secret number.

The U.S. has two rating systems for viewing content: TV

Parental Guidelines and movie ratings.

The TV Parental Guidelines work in conjunction with the

V- CHIP to help parents screen out inappropriate television shows from their children.

Movie ratings are used for original movies rated by the

Motion Picture Association of America (MPAA) as watched on cable TV and not edited for television. The V- CHIP can also be set to block MPAA-rated movies.

NOTE

The setting automatically enters "Block" for any ratings

below your selection.

If Status is not set to "Enable", the configuration settings

will not work.

MPAA (Voluntary movie rating system)

Press / to adjust the item to your desired position. "

" indicates the item is blocked. Press MENU to exit.

G: General audiences. All ages admitted. PG: Parental guidance suggested. Some material may not

be suitable for children. PG-13: Parents strongly cautioned. Some material may be inappropriate for children under 13. R: Restricted. Under 17 requires accompanying parent or adult guardian (age varies in some jurisdictions).

NC-17: No one 17 and under admitted. X: X is an older rating that is unified with NC-17 but may be

encoded in the data of older movies.

NOTE

Voluntary movie rating system only uses an age-based

rating.

Example

ENG 4- 8

On-Screen Display Menu

Example

Initial Setup (Continue)

Individual Setup

Parental Control (Parental Control Setting)

TV Parental Guidelines

Suggested age

TV-Y: All children. TV-Y7: Directed to older children. TV-G: General audience. TV-PG: Parental Guidance suggested. TV-14: Parents strongly cautioned. TV-MA: Mature audience only. When setting an individual content-based rating item:

1 Press

2 Press

3 Press

or ENTER to access blocked content items from

the currently selected age-based rating item.

/ to select an individual item, and then press ENTER to unblock it (" steps for the other items.

or RETURN to register after all individual

content rating items are set.

Example

" is removed). Repeat the same

Content

FV: Fantasy violence. V: Violence. S: Sexual situation. L: Adult language. D: Sexually suggestive dialog.

Rating

TV-Y TV-Y7

Suggested age

: The content rating can be set, but this rating is not

normally broadcast by TV stations.

: Content rating can be set.

Canadian Rating Systems (Canadian English ratings and Canadian French ratings)

The TV rating systems in Canada are based on the

Canadian Radio -Television and Telecommunications Commission (CRTC) policy on violence in television programming.

While violence is the most important content element to

be rated, the structure developed takes into consideration other program content like language, nudity, sexuality and mature themes.

When setting the V-CHIP on the Canadian system you

can choose either the Canadian English ratings or the Canadian French ratings.

TV-G TV-PG TV-14 TV-MA

Content

FV V S L D

ENG 4- 9

On-Screen Display Menu

Example

Initial Setup (Continue)

Individual Setup

Parental Control (Parental Control Setting)

Canadian English Ratings

E: Exempt: Includes news, sports, documentaries and

other information programming; talk shows, music videos, and variety programming.

C: Children: Intended for younger children under the age of

8 years. Pays careful attention to themes that could threaten their sense of security and well-being.

C8+: Children over 8 years old: Contains no portrayal of

violence as the preferred, acceptable, or only way to resolve conflict; nor encourage children to imitate dangerous acts which they may see on the screen.

G: General: Considered acceptable for all age groups.

Appropriate viewing for the entire family, contains very little violence, physical, verbal or emotional.

PG: Parental Guidance: Intended for a general audience,

but may not be suitable for younger children (under the age of 8) because it could contain controversial themes or issues.

14+: Over 14 years: Could contain themes where violence

is one of the dominant elements of the storyline, but it must be integral to the development of plot or character. Language usage could be profane and nudity present within the context of the theme.

18+: Adults: Intended for viewers 18 years and older and

might contain depictions of violence, which while related to the development of plot, character or themes, are intended for adult viewing. Could contain graphic language and portrayals of sex and nudity.

Canadian French Ratings

E: Exempt programming. G: General: All ages and children, contains minimal direct

violence, but may be integrated into the plot in a humorous or unrealistic manner.

8ans+: General but inadvisable for young children: May be

viewed by a wide public audience, but could contain scenes disturbing to children under 8 who cannot

distinguish between imaginary and real situations. Recommended for viewing with parent. 13ans+: Over 13 years: Could contain scenes of frequent

violent scenes and therefore recommended for viewing

with parent. 16ans+: Over 16 years: Could contain frequent violent

scenes and intense violence. 18ans+: Over 18 years: Only for adult viewing. Could

contain frequent violent scenes and extreme violence.

How to temporarily release the V- CHIP BLOCK

When the V -CHIP BLOCK is working and censors a broadcast, "V -CHIP HAS BEEN ACTIVATED." displays.

1 Press ENTER while the V- CHIP is working, and then the

secret number setting menu displays. 2 Input the 4-digit secret number by using 0–9 . At this time

V- CHIP BLOCK temporarily releases.

ENG 4- 10

On-Screen Display Menu

Example

Initial Setup (Continue)

Individual Setup

Parental Control (Parental Control Setting)

Reactivating the temporarily released V- CHIP BLOCK

You can reactivate the temporarily released V-CHIP BLOCK as shown below.

Select "Status" setting from the Parental Control menu to

reactivate BLOCK.

Select "V -Chip" setting ("MPAA", "TV Guidelines", "Can.

English Ratings" or "Can. French Ratings") from the Parental Control to reactivate BLOCK.

(See pages 4-8 to 4-10.)

Switch off the TV power. (When "Quick Start Mode" is

"OFF".)

NOTE

Performing any of the three above will activate the V -

CHIP BLOCK.

Status

Used to enable or disable the parental control function. This function will not be selectable from the menu if you do not first configure your secret number.

Quick Start Mode

When this function is activated, you can reduce the TV's start-up time or even let the TV in standby mode start displaying images and so on via the connected equipment on the network.

NOTE

Setting "Quick Start Mode" to "On" consumes more

power.

ENG 4- 11

On-Screen Display Menu

Example

Initial Setup (Continue)

Input Settings

HDMI auto view

When you view images sent from external equipment in an HDMI connection, this function allows the image size on the TV to automatically switch to an appropriate one.

NOTE

Refer to your external equipment operation manual for the

signal type.

Digital Audio Output

You can output digital audio to an AV amplifier or similar device whose DIGITAL AUDIO INPUT terminal is connected to the DIGITAL AUDIO OUT terminal on the TV. Please select an audio output format compatible with the audio format of the program you are watching and the equipment connected.

PCM: For connecting to equipment that does not support

Dolby Digital and DTS. The same audio (main, sub, or main/sub) as the audio of the program being viewed is output.

2- channel audio with a sampling rate of 48 kHz or less is

output as linear PCM audio.

Bitstream: For connecting to an audio system that

supports Dolby Digital and DTS. Audio is output through both the main and sub channels.

NOTE

Analog channel audio and video input audio are output in

PCM mode even when "Bitstream" is selected.

PCM digital input signals are output in PCM mode even

when "Bitstream" is selected.

Audio Select

This function sets the terminal to output the computer audio. The adjustment items vary depending on the input source. Select the input source corresponding to the terminal connected to the PC and then adjust the desired item. To perform the operation, refer to "Initial Setup" > "Input Settings" > "Audio Select".

(See page 7-2.)

Output Select

Allows you to select what controls the audio output.

Fixed: Sound via speaker is adjusted with VOL+/- on the

remote control unit or on the TV. Sound via the AUDIO OUT terminal is not adjustable and

outputs at a consistent level. Variable: Sound via the AUDIO OUT terminal is adjusted

with VOL+/- on the remote control unit or on the TV. Sound via speaker is muted.

Input Select

For image input applied to the COMPONENT IN or VIDEO IN terminal, switch to “ COMPONENT” or “ VIDEO”, respectively.

COMPONENT: Select component video VIDEO: Select composite video.

NOTE

If no (color) image display, try changing to another signal

type.

Check the operation manual of the external equipment for

the signal type.

Input Skip

This setting allows you to skip the TV, HDMI or PC IN Input ("TV, PC IN, COMPONENT, HDMI 1, HDMI 2, HDMI 3 and VIDEO") on the Input Selection operation.

ENG 4- 12

On-Screen Display Menu

Example

Initial Setup (Continue)

Input Settings

Color System

Select the video signal system compatible with your equipment from the list below:

Auto/NTSC/PAL-M/PAL-N

NOTE

"Color System" can only be set for the TV or VIDEO IN.

LINK Setup

Make the settings to use LINK Operation. Set the settings with "Initial Setup" > "Input Settings" > "LINK Setup".

(See page 6-2.)

Fine Sync.

You can adjust the position on the image input from a PC the settings with "Initial Setup" > "Input Settings" > "Fine Sync.".

(See page 7-1.)

Reset

If complex adjustments are made and the settings cannot be restored to normal, you can reset the settings to the factory preset values.

If you have already set the Secret No., input the 4-digit

secret number here.

NOTE

The Channel Setup settings will not be changed. The Language settings will not be changed. The TV Location settings will not be changed.

ENG 4- 13

On-Screen Display Menu

Example

Information

NOTE

For operating the on-screen display menu,

see page 4-3.

Identification

The current version of the TV software is displayed.

Digital Caption Info. (Digital Caption Information)

This function allows viewing of digital closed caption information for the digital broadcast program being viewed.

NOTE

This list is not displayed for analog broadcasts or external

input audio/video.

This information is not included in CC1, CC2, Text1, or

Text2, and is not displayed in a list.

Software Update

This is used to upgrade the system software to enhance the TV functions.

1 Press MENU to display the MENU screen, and then

press

2 Press

3 Press

/ to select "Information".

/ to select "Software Update", and then press

ENTER.

/ to select "Manual Update" or "Auto Update

Setting", and then press ENTER.

The operations thereafter vary depending on the

setting.

Auto Update Setting

When the TV is on, or when an Internet application is being accessed, this function enables the TV to connect to the network and check for updates automatically. When an update is available, a message is displayed. Press

/ to select "Yes", and then press ENTER to display the download screen.

(See page 4-16.)

NOTE

This function does not work when a broadband

connection or Internet Setup is not available.

A message may also be displayed when an application is

running.The message varies depending on the application.

Manual Update

Select the method for manually updating the software.

USB Update: Updates the software using a USB memory

device containing the update file. (See "Updating the Software with a USB Memory Device".)

Network Update: Downloads the update file via the

network and then updates the software.

(See page 4-16.)

NOTE

A broadband connection and Internet Setup are required

to update the software using the network.

(See pages 8-2 to 8-4.)

It may take time to access and download the update

depending on the Internet connection and other factors.

Updating the Software with a USB Memory Device

To check for the availability of a software update, visit http://www.sharpusa.com/products/support/. If you have any questions, please call 1-800 -BE-SHARP (800-237- 4277).

ENG 4- 14

On-Screen Display Menu

Example

Information (Continue)

Software Update

Manual Update

CAUTION

Do not remove the USB memory device or unplug the

AC cord while the software is being updated.

Be sure to properly follow the whole procedure

described below, step by step. Otherwise, for example, the TV cannot read the data in the USB memory device and software updating will fail.

1 Insert the USB memory device with the update file into

the USB terminal on the TV.

2 Press / on the Manual Update screen to select "USB

Update", and then press ENTER.

3 Press ENTER to start checking the data in the USB

memory device.

4 During the data checking, "Checking" blinks.

The current version of the TV software and the version

of the update file on the USB memory device are displayed.

If the USB memory device is not properly installed or

the correct update file cannot be found on the USB memory device, an error message is displayed. Check the file on the USB memory device, and then reinsert the USB memory device correctly.

ENG 4- 15

On-Screen Display Menu

Example

Information (Continue)

Software Update

Manual Update

CAUTION

Do not remove the USB memory device or unplug the

AC cord while the software is being updated.

5 When the software is successfully updated, a screen is

displayed indicating that the update process is completed.

After this screen is displayed, the TV automatically turns

off and then turns on again.

If the update has failed, check the file in the USB

memory device and try Software Update again.

6 Remove the USB memory device.

Updating the Software via the Network

1 Press

2 The current version of the TV and the latest version of

3 After the update file is downloaded, the software update

CAUTION

4 When the software is successfully updated, a screen is

Manual

Displays the built -in operation manual on the screen. You can read information about how to use this device.

/ on the Manual Update screen to select

"Network Update", and then press ENTER.

The TV connects to the network and checks for

updates.

To cancel, press ENTER.

software are displayed. To update the TV software, select "Yes", and then press ENTER.

When a server connection cannot be established or an

update is not available, a message is displayed. If a server connection cannot be established, check the broadband connection and Internet Setup.

process begins.

Do not unplug the AC cord while the software is

being updated.

displayed indicating that the update process is completed. A screen indicating that the update is completed is displayed. 4 seconds later, the TV restarts automatically.

If the software was not updated successfully, check the

broadband connection and Internet Setup, and then try updating the software again.

ENG 4- 16

On-Screen Display Menu

Example

Picture Settings

Adjusts the picture to your preference with the following picture settings.

NOTE

For operating the on-screen display menu, see page 4-3.

Selected item button button

Backlight The screen dims The screen

Contrast For less contrast For more contrast Brightness For less brightness For more

Color For less color

Tint Skin tones become

Sharpness For less sharpness For more

For resetting all Picture adjustment items to the factory

preset values, press

ENTER, press ENTER.

intensity

reddish

/ to select "Reset", press

/ to select "Yes", and then press

brightens

brightness For more color

intensity Skin tones

become greenish

sharpness

AV MODE (Changing Pic.Quality)

The audio and video settings can be changed to suit the program or input content being watched.

NOTE

The selectable items vary depending on the input source

and on the model of your TV.

You can select AV MODE by pressing AV MODE on the

remote control unit.

See page 3-10 for details of AV MODE settings.

ENG 4- 17

On-Screen Display Menu

Example

Picture Settings (Continue)

Automatic Light Sensor(Light Sensor)

Automatically adjusts the brightness of the screen.

Off: The brightness is fixed at the value set in "Backlight". On: Automatically adjusts. On:Display: Displays the Light Sensor effect on the screen

while adjusting the brightness of the screen.

NOTE

When set to "On", the Light Sensor senses the

surrounding light and automatically adjusts the backlight brightness. Make sure nothing obstructs the Light Sensor, which could affect its ability to sense surrounding light.

When set to "On:Display", Light Sensor effect displays on

the screen while the Light Sensor adjusts the screen brightness.

Advanced

Motion Enhancement

Use Motion Enhancement to view fast- action video more clearly.

Selected item Description

AquoMotion480

(EQ30U only)

AquoMotion240 Turn the LED backlight on or off

120Hz For obtaining a clearer image. Off Original image.

NOTE

"Motion Enhancement" may cause image noise. If this

occurs, turn the function "Off".

Digital Noise Reduction

Produces a clearer video image.

Auto: Automatically adjusts the level of noise reduction. High/Middle/Low: You can select a desired level for

viewing a clearer video image.

Off: No adjustment.

Drivers precision clarity during fast motion scenes.

for 120Hz drive display.

ENG 4- 18

On-Screen Display Menu

Example

Picture Settings (Continue)

Advanced

C.M.S. (Color Management System)

Color tone is managed using the six-color adjustment setting.

C.M.S.-Hue: This is a standard to adjust the color either

more reddish or more bluish in tone.

C.M.S.-Saturation: Increases or decreases the saturation

of a selected color. C.M.S.-Value: A higher value makes the image brighter. A lower value makes the image darker.

NOTE

For resetting all adjustment items to the factory preset

values, press ENTER.

/ to select "Reset", and then press

Color Temp. (Color Temperature)

For a better white balance, use color temperature correction. High: White with bluish tone

Middle:

Low: White with reddish tone

Fine tuning the color temperature

White balance can be adjusted between a maximum of +30 and a minimum of –30 for each color temperature.

NOTE

For resetting all adjustment items to the factory preset

values, press ENTER.

/ to select "Reset", and then press

ENG 4- 19

On-Screen Display Menu

Example

Picture Settings (Continue)

Advanced

Active Contrast

Automatically adjusts the image contrast according to the scene.

On: Produces high contrast image. Off: No adjustment.

Film Mode (3:2 pull-down)

This function provides high-quality playback of images originally encoded at 24 frames/second, such as films.

Advanced: Adjusts effects to reduce judder film contents.

You can select a desired level of judder reduction from 0

to +10. Standard: Plays back image with equal display time for

each frame, reproducing movie theater experience.

Off: Normal viewing mode.

NOTE

"Film Mode" does not function depending on input signal

type.

"Standard" does not function depending on input signal

type.

Monochrome

For viewing a video in monochrome.

Reset

Returns Picture Settings to their factory preset values. To reset, select "YES" and then press ENTER.

ENG 4- 20

On-Screen Display Menu

Example

Audio Settings

You can adjust the sound quality to your preference with the following settings.

NOTE

For operating the on-screen display menu,

see page 4-3.

Selected

item

Treble For weaker treble For stronger treble Bass For weaker bass For stronger bass Balance Decrease audio from

NOTE

The Audio menu is grayed out when "Output Select" is

set to "Variable".

(See page 4-12.)

For resetting Audio adjustment items to the factory preset

values, press

/ to select "Yes", and then press ENTER.

Surround

The surround function produces Surround effect from the speakers.

NOTE

The Audio Settings menu is grayed out when "Output

Select" is set to "Variable".

(See page 4-12.)

For some discs, setup may be required on your BD/DVD

player. In this case, please refer to the operation manual of your BD/DVD player.

Auto Volume

Different sound sources sometimes do not have the same loudness level, such as a program and its commercial brakes, The Automatic Volume Control(Auto Volume) reduces this problem by equalizing.

ON: Reduces the loudness gaps among different sound

source. The result is automatically adjusted according to

the sound sources.

OFF: No adjustment.

button button

the right speaker

/ to select "Reset", press ENTER, press

Decrease audio from the left speaker

Reset

Returns Audio Settings to their factory preset values. To reset, select "YES" and then press ENTER.

ENG 4- 21

On-Screen Display Menu

Example

Smart TV

Dashboard

You can display a list of the main Smart TV settings.

Internet Setup

Configures LAN and Internet settings.

(See page 8-2 to 8-4.)

AQUOS Remote Control

Set this function when operating the TV from equipment connected by LAN or wireless LAN.

(See page 7-3.)

ENG 4- 22

On-Screen Display Menu

Example

Smart TV (Continue)

Wallpaper

Activating the function will display still images when the TV is in standby mode.

Wallpaper Mode

Configures Wallpaper Mode settings.

Off: Nothing will be displayed. On: Still images will be displayed when the TV is in

standby mode.

Data Source

For the wallpaper, you can select either the still images pre installed in the TV or your favorite still images stored in the USB memory device.

Pre-Installed: The images pre-installed in the TV will be

displayed in a slideshow. USB: Your favorite images stored for the wallpaper will

appear.

If only a single still image is stored in the USB memory

device, that image will be displayed as the wallpaper.

When there are multiple still images in the memory, all

the images will be displayed in a slideshow.

NOTE

Images are displayed in 3-minute intervals as a

slideshow.

When you display images by using the USB memory

device:

Create a folder named "WP" in the root directory of the

USB memory device (the first directory when the USB memory device is opened), and store into the folder the still images you want to display for the wallpaper.

You must insert the USB memory device to the TV before

turning off the TV.

If there are images on the USB memory device but they

do not appear on the screen, switch to USB mode and check whether the image files on the USB memory device are shown correctly.

Timer Setting

You can set the length of time the TV will remain in the Wallpaper Mode.

3 hours/6 hours/12 hours/24 hours

NOTE

No buttons except for POWER work even while the still

images are being displayed.

If the ready- for -use USB memory device is not inserted,

the still images pre-installed in the TV will be displayed in a slideshow even when "Data Source" is set to "USB".

Because the USB memory device cannot be detected

immediately after the TV is turned on from standby mode, the wallpaper pre -installed in the TV may be displayed even when "Data Source" is set to "USB".

The still images will be displayed until the set time has

elapsed.

ENG 4- 23

On-Screen Display Menu

Example

Smart TV (Continue)

Miracast

You can connect a device such as a Miracast-compatible smartphone or tablet to the TV.

(See page 9-1.)

Advanced

TV Name Setting

Set this function when operating the TV from equipment connected by LAN or wireless LAN.

(See page 7-3.)

Use the software keyboard when you need to input text at TV Name Setting.

Software Keyboard

ABC

Switches character to uppercase. If "abc" is pressed again, switches character to lowercase.

":&12"

Changes character set into the alphabet, numbers, symbols, etc.

Applies the entered information and closes the software keyboard.

space

Enters a space.

DEL

Erases the character string.

Netflix Help

You can deactivate the Netflix function. Refer to "Smart TV" > "Advanced" > "Netflix Help" and select "Deactivate".

(See page 8-13.)

VUDU Help

To deactivate the VUDU function, refer to "Smart TV" > "Advanced" > "VUDU Help" and select "Yes".

(See page 8-13.)

ENG 4- 24

On-Screen Display Menu

Example

System Options

NOTE

For operating the on-screen display menu,

see page 4-3.

Power Control

Power control setting allows you to save energy.

No Signal Off

When this function is enabled, the TV automatically shuts down if no signal is received for more than 15 minutes.

NOTE

When it is 5 minutes before the power shuts down, the

remaining time will start to keep appearing every minute.

When a TV program finishes, this function may not

operate.

No Operation Off

When you enable this function, the TV automatically shuts down if no operation is performed for more than 3 hours.

NOTE

When it is 5 minutes before the power shuts down, the

remaining time will start to keep appearing every minute.

View option

View Mode

This function changes the screen size. Select "View Option" on the menu to display the View Mode menu screen. The View Mode menu varies depending on the input source.

Change Audio

MPX

Allows you to change the audio when multiple audio is available for the program you are watching.

NOTE

You can change Audio by pressing AUDIO on the remote

control unit.

See page 3-8 for details of Audio function.

Audio Only

When listening to music from a music program, you can turn the screen off and enjoy audio only.

NOTE

The screen image will return to normal when a button

(except those for audio adjustment, such as VOL,

MUTE) is presses.

Change CC

Allows you to change the Closed Caption display. Select "Change CC" on the menu to display the Closed Caption information.

The information displayed varies depending on the

program you are watching.

NOTE

You can change Closed Caption by pressing CC on the

remote control unit.

See pages 3-12 to 3- 13 for details of Closed Caption

function.

ENG 4- 25

On-Screen Display Menu

Example

System Options (Continue)

Caption Setup

This function allows you to adjust the closed caption screen appearance to suit your preference.

Size/Edge Effect/Edge Color/Text Color/Background Color/Text Opacity/Background Opacity

NOTE

The default value depends on the broadcasting station.

Startup Screen

With this function activated, the SHARP logo will be displayed when you turn on the TV.

NOTE

This function is not available when the TV is set to "Quick

Start Mode".

Front Indicator Light

When this function is set to "On", the LED on the front of the TV turns on.

NOTE

"On" is the factory preset value. If you want to turn off

the LED, set the function to "Off".

Demo

You can select the image from several types of demo mode.

NOTE

What kinds of setting item are available depends on the

model of your TV.

"Demo" may not be selected depending on input signal

type or application status.

"Demo" may be automatically canceled depending on

input signal type.

ENG 4- 26

Enjoying Photo/Music/Video Playback

You can connect the TV to a USB memory device, USB hard drive or Home Network server to enjoy viewing pictures, listening to music, and watching videos.

Insert the USB memory device with recorded photos, music or videos into the USB terminal on the TV.

Connect the TV to the Home Network server using an ETHERNET cable.

Preparation

NOTE

Depending on the USB memory device/USB hard drive/Home Network server, the TV may not

be able to recognize the recorded data.

It may take time to read the recorded data if the USB memory device/USB hard drive/Home

Network server contains many files or folders. Use only alphanumeric characters for naming files. File names over 80 characters (may vary depending on character set) may not be displayed.

Connecting a USB Memory Device/USB Hard Drive

When connecting a USB hard drive, be sure to use a hard drive with an AC adapter. Do not remove a USB memory device or memory card from the TV while transferring files, using

the slide show function, or switching screens, or before you exit "USB" from the INPUT list. Do not insert and remove a USB memory device/USB hard drive to and from the TV repeatedly. When using a card reader, be sure to insert a USB memory device first.

CAUTION

Do not use a USB extension cable when connecting a USB memory device to the USB

terminal on the TV.

Using a USB extension cable with the USB memory device may prevent the TV from

performing correctly.

Connecting a Home Network Server

You can also connect a Home Network server by using a wireless LAN.

NOTE

Do not disconnect a Home Network server from the TV while transferring files, when a screen is

switching to another or before you exit "Home Network" from the INPUT list.

Do not connect and disconnect a Home Network server from the TV repeatedly.

ENG 5- 1

Enjoying Photo/Music/Video Playback

Selecting the Folders to Play Back

To play back data on a USB memory device, insert the

USB memory device on the TV.

Use the following procedure to switch back to USB mode

after switching from USB mode to another mode.

1 Select "USB" or "Home Network" from INPUT list screen. 2 Press

3 Press / to select the desired folder, and then press

/ to select "Photo", "Music" or "Video", and

then press ENTER.

ENTER.

"VIEW MODE" is fixed during the Music mode. During

"Video mode", you can select ”Auto", "Original" or "Stretch".

During "Video mode", videos that are smaller than the

number of pixels on the screen are displayed at their original size. In these cases, switch "VIEW MODE" to "Auto" to have the video fill the screen.

Example

NOTE

The Media screen can be displayed even by using the

application window. To display the application window, press SmartCentral.

(See page 3-6.)

16 is the maximum number of USB drives and 10 is the

maximum number of Home Network servers that can be displayed.

USB Device Compatibility

USB device USB Memory, USB card reader (Mass

File system FAT/FAT32/NTFS (USB hard drive only) Photo file

format Music file

format

Storage class), USB hard drive

JPEG (.jpg) (DCF2.0 compliant)

MP3 (.mp3) Bitrate: 32k, 40k, 48k, 56k, 64k, 80k, 96k, 112k, 128k, 160k, 192k, 224k, 256k, 320kbps Sampling frequency: 32k, 44.1k, 48kHz

ENG 5- 2

Enjoying Photo/Music/Video Playback

Selecting the Folders to Play Back (Continue)

Video file format

File

extension

.avi AVI

.mkv MKV

.asf

.wmv

.mp4 MP4

.mpg

.mpeg

Container Video Audio

ASF

WMV

MPG

MPEG-1

MPEG-4 SP/ASP(XviD) MPEG-4 AVC

(H.264)

Motion JPEG

MPEG-1

MPEG-2

MPEG-4 SP/ASP(XviD) MPEG-4 AVC

(H.264)

MPEG-4 SP/ASP(XviD)

WMV 7/8/9

MPEG-4 SP/ASP(XviD) MPEG-4 AVC

(H.264)

Motion JPEG

MPEG-1

MPEG-2

MPEG-

Audio

LPCM

MS-ADPCM

DTS AC3

MPEG-

Audio

LPCM

MS-ADPCM

DTS AC3

LPCM

WMA

MPEG-

Audio

LPCM

MS-ADPCM

AC3

MPEG-

Audio

LPCM

MS-ADPCM

AC3

NOTE

Progressive format jpeg files are not supported. USB 1.1 devices may not be played properly. Operation using USB hubs is not guaranteed. Some video file formats may not be played depending on

the file.

Some images may not be displayed in the appropriate

aspect ratio depending on the file format.

Home Network Server Compatibility

Photo file format JPEG Music file format LPCM, MP3 Video file format AVI, ASF, MP4, WMV, MPG

NOTE

Progressive format jpeg files are not supported. Some video file formats may not be played depending on

the file or the server.

ENG 5- 3

Enjoying Photo/Music/Video Playback

Playing Back Files on a USB Memory Device/Home Network Server

NOTE

The screen images in this section are for the USB mode.

It may be slightly different in the Home Network mode.

Photo Mode

Viewing Thumbnails

Example

Buttons for thumbnail operations

Buttons Description

/ / / Select a desired item.

ENTER When selecting a folder icon:

RETURN Return to the previous process. A (red) Clear the file information display. B (green) C (blue) D (yellow)

NOTE

A few seconds after the cursor is positioned on a

thumbnail, the file information is displayed in the right of the center of the screen.

Enter this directory. When selecting a photo thumbnail: Start the slide show.

ENG 5- 4

Enjoying Photo/Music/Video Playback

Playing Back Files on a USB Memory Device/Home Network Server (Continue)

Slide Show

The photos displayed on the thumbnail selection screen are displayed as a slide show.

Buttons for slide show operation

Buttons Description

RETURN Return to the thumbnail selection screen. B (green) Previous file C (blue) Displaying/hiding operation guidance D (yellow) Next file

NOTE

Rotating photos only applies to the temporarily selected

item and this setting is not saved.

ENG 5- 5

Enjoying Photo/Music/Video Playback

Playing Back Files on a USB Memory Device/Home Network Server (Continue)

Music Mode

Buttons for music mode

/ / / Select a desired item.

ENTER When selecting a folder icon:

RETURN Return to the previous process. A (red) Clear the file information display. B (green) C (blue) D (yellow)

NOTE

The displayed play time may differ slightly from the actual

play time depending on the files.

A few seconds after the cursor is positioned on a

thumbnail, the file information is displayed in the right of the center of the screen.

Example

Buttons Description

Enter this directory. When selecting a music file: Play music.

ENG 5- 6

Enjoying Photo/Music/Video Playback

Playing Back Files on a USB Memory Device/Home Network Server (Continue)

Video Mode

Example

Buttons for file selecting operations

Buttons Description

/ / / Select a desired item.

ENTER When selecting a folder icon:

RETURN Return to the previous process. A (red) Clear the file information display. B (green) C (blue) D (yellow)

Enter this directory. When selecting a video file: Play the video.

NOTE

A few seconds after the cursor is positioned on a

thumbnail, the file information is displayed in the right of the center of the screen.

ENG 5- 7

Enjoying Photo/Music/Video Playback

Playing Back Files on a USB Memory Device/Home Network Server (Continue)

Buttons for playing mode

A (red) Subtitle B (green) Previous file C (blue) Display/hide operation guide D (yellow) Next file RETURN Go back to the file selection screen.

Buttons Description

Stop playback Stop playback Fast forward Fast rewind

ENG 5- 8

Enjoying Photo/Music/Video Playback

Presetting Remote Control Function

You can operate the connected AV products (AV receiver, cable box, SAT tuner, DTV, VCR, BD, DVD, LD) using the presetting manufacturer function of your remote control unit.

Presetting manufacturer codes

1 Press an appropriate button (STB, DVD•VCR or AUDIO)

to operate the connected equipment.

2 Press an appropriate button (STB, DVD•VCR or AUDIO)

and MANUAL at the same time to enter the code registration mode.

3 Press 0–9 to enter the manufacturer code.

Preset mode is finished once the LED no longer lights

up.

4 After registering the code, the LED will stop blinking then

turn off after one second. (If you perform an incorrect operation, the LED will blink quickly then turn off.)

Manufacturer codes

STB BRAND

ANVISION 04, 05 CABLE STAR 04, 05 DISH NETWORK 39, 40 DIRECTV 41 EAGLE 05 G.INSTRUMENT 02, 03, 10, 11, 17, 20 GERROLD 17 JERROLD 02, 03, 10, 11, 12, 20, 25-34 MAGNAVOX 04, 05, 08, 12, 15, 16, 18, 19,

MOTOROLA 38 OKA SIGMA 07 PANASONIC 14, 21 PHILIPS 04, 05, 08, 13, 15, 16, 18, 19,

PIONEER 07 RANDTEK 04, 05 RCA 14, 36*, 37* S.ATLANTA 01, 09, 24 VIEWSTAR 04, 05, 08, 13, 15, 16, 18, 19,

ZENITH 06, 35

NOTE

Numbers marked with * are SAT codes, all others are

STB codes.

REMOTE CONTROL

CODE NUMBER

22, 23

ENG 5- 9

Enjoying Photo/Music/Video Playback

Presetting Remote Control Function (Continue)

BD/DVD/LD BRAND

DENON 24 JVC 31 KENWOOD 36 MAGNAVOX 26 MARANTZ 26 MITSUBISHI 28 PANASONIC 24, 37 PHILIPS 26, 38 PIONEER 30, 33, 35 PROSCAN 25 RCA 25, 39 SAMSUNG 29, 34 SHARP 23, 32, 41, 42 SONY 27, 40 TOSHIBA 26 YAMAHA 24 ZENITH 26

Depending on the brand, the codes of some BD players

may not be supported.

REMOTE CONTROL

CODE NUMBER

VCR BRAND

AUDIO DYNAMICS 09 BROCKSONIC 13 CANON 04 CRAIG 12 CURTIS MATHIS 04 DBX 09 EMERSON 10, 13, 14 GE 04 INSTANT REOLYA 04 JC PENNEY 04 JVC 09, 16, 17, 22 KENWOOD 09 MAGNAVOX 04, 05, 06 MAGNIN 12 MEMOREX 04 MONTGOMERY WARD 02 NEC 09 PANASONIC 04, 18, 19, 20, 21 PENTAX 05 PHILCO 04, 05 PHILIPS 04, 05, 06 QUASAR 04 REALISTIC 01, 02 SAMSUNG 11, 12

REMOTE CONTROL

CODE NUMBER

ENG 5- 10

Enjoying Photo/Music/Video Playback

Presetting Remote Control Function (Continue)

VCR BRAND

SHARP 01, 02, 03 SONY 07, 08, 15 SYLVANIA 04, 05, 06 TATUNG 09 TEAC 09 TMK 10 YAMAHA 09

REMOTE CONTROL

CODE NUMBER

AUDIO BRAND

SHARP 01 SHARP (SOUND BAR) 02

REMOTE CONTROL

CODE NUMBER

ENG 5- 11

Enjoying Photo/Music/Video Playback

Operating the Connected Equipment

To operate the connected equipment, press STB, DVD•VCR or AUDIO to select your device. (STB (cable/satellite set-top box), BD, DVD, VCR or AUDIO.) The remote control unit button will function as follows.

When you operate VCR, DVD or BD, press INPUT to

select the terminal connected to your device.

CABLE and SAT cannot be selected at the same time.

1 POWER (SOURCE)

Turns the connected equipment power on and off.

Starts playback. (VCR, BD, DVD)

Rewinds the tape and allows picture search. (VCR) Hold down to go in reverse. (BD, DVD)

Stops the tape transport. (VCR) Playback stops when pressed. With some Blu -ray

disc/DVD players, pressing the button twice may open the disc tray. (BD, DVD)

Pressing quickly once takes you to the start of the

chapter currently playing. Each time you press it, you move back to the start of the previous chapter. (BD, DVD)

6 0–9, • (DOT)

Press a button (or buttons) that corresponds to the

channel that you wish to watch.(STB)

Rapidly advances the tape and allows picture search.

(VCR)

Hold down to fast forward. (BD, DVD)

Sets pauses and still pictures. (VCR, BD, DVD)

Pressing quickly once takes you to the start of the next

chapter. Each time you press it, you move ahead to the start of the next chapter. (BD, DVD)

10 FLASHBACK

Press to switch between the current channel and the

channel you were watching immediately before. Some manufacturers do not preset FLASHBACK. (STB)

11 CH /

Press CH or CH to tune in to a higher or lower

channel. (STB)

Press to select the channel of the TV tuner on the

VCR. (VCR)

12 MENU

When this button is pressed, the BD/DVD menu will

display. (BD, DVD)

/ / / , ENTER

/ / / : Press the button to select items on the STB GUIDE screen or STB MENU screen. (STB) Press the button to select items on the BD/DVD menu screen. (BD, DVD)

ENTER: Press to activate the selected function. (STB,

BD, DVD)

ENG 5- 12

Using LINK Operation

What’s LINK Operation?

Connected LINK-compatible devices can be operated without changing the settings of the remote control unit. The

Control the LINK -compatible audio system

Set the volume of LINK- compatible audio system.

Controlling HDMI Equipment Using LINK Operation

Using the HDMI CEC (Consumer Electronics Control) protocol, with LINK Operation you can

interactively operate compatible system equipment (Blu-ray disc equipment, AV amplifier, DVD).

LINK Operation allows you to operate the HDMI-connected equipment with one remote control.

NOTE

For connecting the TV to LINK -compatible equipment, use commercially available cables. Point the remote control toward the TV, not to connected HDMI equipment. Video noise may occur depending on the type of HDMI cable used. Make sure to use an HDMI-

certified cable.

Up to 3 pieces of HDMI recording equipment and one AV amplifier can be connected using this

system.

These operations affect the HDMI equipment selected as the current input source. If the

equipment does not operate, turn on the equipment and select the appropriate input source using INPUT.

The LINK feature may not operate properly when an HDMI splitter or AV selector unit is used.

These devices may cause interruptions to the image and/or sound.

OPTION button will function only when LINK Operation is used.

NOTE

The steps in "LINK Setup" on

page 6-2 need to be completed beforehand.

Refer to this operation manual and the operation manual of the LINK device to be used with this

TV.

ENG 6- 1

Using LINK Operation

Controlling HDMI Equipment Using LINK Operation (Continue)

LINK Setup

Make the settings to use LINK Operation. Set the settings with "Initial Setup" > "Input Settings" > "LINK Setup".

Link Operation

Select LINK Operation Control to disable the LINK function even when a LINK- compatible HDMI device is connected to the TV. This function prevents the device from starting to operate unexpectedly.

Auto Power On

If this is activated, the One Touch Play function is enabled. While the TV is in standby mode, it automatically turns on and plays back the image from the HDMI source.

Audio Return Channel

This function allows you to listen to the TV audio via audio equipment without using an optical fiber cable, which conventionally is required.

Requirements for using an ARC- compatible AV amplifier:

ARC-compatible AV amplifier connected to the ARC-

compatible HDMI IN terminal. (HDMI IN 1) (Refer to the operation manual of the ARC-compatible equipment for details.)

Use of an ARC-compatible cable.

Auto: You can listen to the TV audio with ARC-compatible

audio equipment.

Off: This function does not work.

NOTE

If the TV audio cannot be output from the AV amplifier

even after making the necessary settings, connect the TV to the AV amplifier with an optical fiber cable and select "Off".

ENG 6- 2

Using LINK Operation

Link Operation Menu

The Link Operation Menu allows you to make adjustments during operation of LINK- compatible equipment.

1 Press OPTION to display the Link Operation Menu. 2 Press

/ to select the desired item, and then press

ENTER.

Specific operations differ depending on the item you

select. Following are the basic operations for each item.

Recorder Power On/Off

You can manually turn on/off the power of the connected LINK-compatible equipment. Each time you press ENTER, the connected equipment switches on or off.

ENG 6- 3

Using LINK Operation

Link Operation Menu (Continue)

Show Start Menu

You can call up a setup menu from the connected LINKcompatible equipment.

NOTE

Depending on the status of the equipment (recording or in

standby mode, etc), the setup menu will not be displayed.

Change Audio Output Device

You can select to listen to the TV sound only from the

LINK-compatible audio system.

By AQUOS audio SP: The sound from the TV speaker is

muted and only the sound from the LINK-compatible audio system is audible.

• You can use VOL+/- and MUTE.

By AQUOS SP: The sound is output from the TV speaker.

HDMI Device Selection

If multiple HDMI devices are connected in a daisy chain, you can specify which device to control here. Press

/ to select the desired device from a list of

connected HDMI devices, and then press ENTER.

LINK Setup

You can also display the LINK Setup screen from the Link Operation Menu.

ENG 6- 4

Using LINK Operation

Using a Smartphone with the TV

This function enables you to connect the TV to a smartphone that supports Mobile High-Definition Link (MHL™ ) using an MHL cable. To connect the TV to your MHL -compatible smartphone, be sure to use an MHL cable (commercially available).

You can view pictures and video on a large screen. You can play back music files.

NOTE

An MHL- compatible portable device is required to use

this function. Connect the device to the HDMI IN 3 terminal.

This product incorporates MHL 1.

Auto Power On

When an MHL-compatible device is connected to the TV, the TV turns on automatically.

This function operates when "LINK Operation" is set to

"On".

(See page 6-2.)

Auto Input Selection

When an MHL-compatible device is connected while the TV is on, the input mode is selected automatically.

This function operates when "LINK Operation" is set to

"On".

(See page 6-2.)

Operation Using the Remote Control

The remote control of the TV can be used to operate a portable device.

/ / / , ENTER, EXIT, 0-9, • (DOT), ENT, etc.

The operations vary depending on the connected

equipment and content being viewed.

ENG 6- 5

Using a PC

You can adjust the position of the image input from a PC by selecting "Initial Setup" > "Input Settings" > "Fine Sync.".

Ordinarily you can easily adjust the picture as necessary to change image position using "Auto Sync.". In some cases, however, manual adjustment is needed to optimize the image.

Adjusting the PC Image

Fine Sync.

Input Signal: Select the input signal.

1024x768 1360x768

Auto Sync.: For automatically adjusting the PC image.

Yes: Auto Sync. starts and "Now adjusting the image." is displayed.

No: This function does not work. H-Pos.: Centers the image by moving it to the left or right. V-Pos.: Centers the image by moving it up or down. Clock: Adjust when the image flickers with vertical stripes. Phase: Adjust when characters have low contrast or when the image flickers.

NOTE

"Auto Sync." may fail if the computer image has low resolution, has unclear (black) edges, or is

moved while executing "Auto Sync.". Be sure to connect the PC to the TV and switch it on before starting "Auto Sync.". It is not necessary to adjust the "Clock" or "Phase" when a digital signal is being input, so it

cannot be selected. The default cursor position may not be in the center, because the screen position variable

ranges may be asymmetrical. The screen position variable ranges depend on the View Mode or the signal type. The ranges

can be seen on the position -setting screen.

ENG 7- 1

Using a PC

HDMI 2

Setting Audio Input

Audio Select

HDMI2(Digital): Select this when the TV and PC are connected using an HDMI -certified cable

and audio is input via the same cable.

HDMI+Analog: Select this when the TV and PC are connected using an HDMI-certified cable

and the audio is input via a Ø 3.5 mm stereo minijack.

NOTE

When "Audio Select" is set to "HDMI+Analog", sound will not be produced if you use only an

HDMI- certified cable to connect HDMI- compatible equipment. To produce sound, you should

make an analog audio connection. If you want to connect HDMI- compatible equipment using only an HDMI-certified cable, set

"Audio Select" to "HDMI2(Digital)".

ENG 7- 2

Using a PC

Set this function when operating the TV from equipment connected by LAN or wireless LAN. To perform the operation, refer to "Smart TV".

AQUOS Remote Control

When "AQUOS Remote Control" is selected, "Change" will be highlighted. Press

Detailed Settings

Make the detailed settings (Login ID, password, etc.). Follow the on -screen instructions to configure the settings.

Set the name of the TV displayed on other network devices.

Connect to the TV with the following settings made for IP on the PC.

When you set your ID and password on the TV menu, you need to enter them as soon as you connect to the TV.

Set the RS -232C communication settings on the PC to match the TV's communication conditions. The TV's communication settings are as follows:

Communication procedure

Send the control commands from the PC via the RS -232C or IP. The TV operates according to the received command and sends a response message to the PC. Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending the next command.

Control of the TV

The TV can be controlled from a PC, control panels and other devices using the RS-232C or IP. Use a cross-type RS- 232C cable, ETHERNET cable (commercially available) or wireless LAN for

the connections.

NOTE

This operation system should be used by a person who is accustomed to using computers.

AQUOS Remote Control

TV Name Setting

Use the software keyboard to set the name.

See page 4-24 for details on the software keyboard.

ENTER.

Communication Conditions for IP

IP protocol: TCP/IP Host IP address: Set the IP address on the TV menu Service: None (Do not select Telnet or SSH) TCP port#: Set a port number on the TV menu (Control

NOTE

When you use this function, make settings for "AQUOS Remote Control". The connection will be cut off when there has been no communication for 3 minutes.

Communication Conditions for RS-232C (For LE661U and EQ30U models only)

Baud rate: 9,600 bps Data length: 8 bits Parity bit: None Stop bit: 1 bit Flow control: None

port)

ENG 7- 3

Using a PC

Command format

Eight ASCII codes +CR

Command 4-digits: Command. The text of four characters. Parameter 4-digits: Parameter 0–9, x, blank, ?

Parameter

Input the parameter values, aligning left, and fill with blank(s) for the remainder. (Be sure that 4 values are input for the parameter.) When the input parameter is not within an adjustable range, "ERR" returns. (Refer to "Response code format".) Any numerical value can replace the "x" on the table.

Response code format

Normal response

Problem response

Command table

*1 Select "Initial Setup" from the menu screen and set "Quick Start Mode" to "On" to enable the

Control of the TV (Continue)

(communication error or incorrect command)

Commands not indicated here are not guaranteed to operate.

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS

POWER ON COMMAND SETTING

POWER SETTING P O W R 0 _ _ _ Power Off It shifts to

INPUT SELECTION

Power On command.

NOTE

If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL

CONTENTS.

Any numerical value can replace the "x" on the table.

TOGGLE I T G D x _ _ _ (Toggle) It input -switches

TV I T V D 0 _ _ _ It input -switches

R S P W 0 _ _ _ Off The Power On

1 _ _ _ On [RS -232C] The Power On

2 _ _ _ On [IP] The Power On

1 _ _ _ Power On Power On *1

command rejected.

command accepted. (For LE661U and EQ30U models only)

command accepted.

standby.

by the toggle. (It is the same as an input change key)

to TV. (A channel remains as it is. (Last memory))

ENG 7- 4

Using a PC

Control of the TV (Continue)

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS

INPUT SELECTION

AV MODE SELECTION A V M D * _ _ _ 0: (Toggle),

VOLUME V O L M * * * _ Volume (0- 100) POSITION H-

1-6 I A V D * _ _ _ 1: HDMI IN 1,

POSITION V-

POSITION CLOCK C L C K * * * _ (0-100) PHASE P H S E * * _ _ (0-63)

H P O S * * * _ (-50-50) For PC input.

V P O S * * * _ (-50-50)

2: HDMI IN 2, 3: HDMI IN 3, 4: VIDEO IN 1, 5: COMPONENT/VIDEO IN 2, 6: PC IN

1: STANDARD (ENERGY STAR), 2: MOVIE, 4: USER, 5: DYNAMIC (Fixed), 6: DYNAMIC, 7: PC

Although it can choose now, it is toggle operation in inside.

The screen position variable ranges depend on the View Mode or the signal type. The ranges can be seen on the positionsetting screen.

CONTROL

ITEM

VIEW MODE W I D E * * _ _ 0: (Toggle) [AV],

MUTE M U T E * _ _ _ 0: (Toggle),

NOTE

If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL

CONTENTS.

Any numerical value can replace the "x" on the table.

COMMAND PARAMETER CONTROL CONTENTS

1: Side Bar [AV], 2: S.Stretch [AV] 3: Zoom [AV], 4: Stretch [AV, USB- Video, Home Network Video or Internet applications], 5: Normal [PC] 7: Stretch [PC], 8: Dot by Dot [PC] [AV], 9: Full Screen [AV] 10: Auto [USB Video, USB -Photo, Home Network Video, Photo or Internet applications], 11: Original [USBVideo, USB -Photo, Home Network Video, Photo or Internet applications]

1: On, 2: Off

0: Although it can choose now, it is toggle operation in inside. 1: Only available when 4:3 signal is being input. 5: Only available when 4:3 signal is being input. 8: [PC] Available except when UXGA is being input. [AV] Only available when 1080i/p is being input. 9: Only available when 720p is being input. 10, 11: Available when USBVideo, USB Photo, Home Network Video, Photo or Internet application is used.

ENG 7- 5

Using a PC

Control of the TV (Continue)

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS

SURROUND A C S U * _ _ _ 0: (Toggle),

AUDIO SELECTION

SLEEP TIMER O F T M * _ _ _ 0: Off,

A C H A x _ _ _ (Toggle)

1: On, 2: Off

1: OFF TIMER - 30 MIN., 2: OFF TIMER - 60 MIN., 3: OFF TIMER - 90 MIN., 4: OFF TIMER - 120 MIN.

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS

CHANNEL DIRECT

NOTE

If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL

CONTENTS.

Any numerical value can replace the "x" on the table.

CHANNEL (ANALOG)

DIRECT CHANNEL (DIGITAL)

D C C H * * * _ The

D A 2 P * * * * (0100-

D C 2 U * * * _ (1-999) DIGITAL Cable (Two-Part

D C 2 L * * * _ (0-999) DIGITAL Cable (Two-Part

channel number of TV (1-135)

9999)

An input change is included if it is not TV display. In Air, 2 -69ch is effective. In Cable, 1-135ch is effective.

DIGITAL Air (Two- Part numbers, 2-digit plus 2-digit)

numbers, 3-digit plus 3-digit) Front half of DIGITAL CABLE CHANNEL NO. (Designate major channel)

numbers, 3-digit plus 3-digit) Rear half of DIGITAL CABLE CHANNEL NO. (Designate minor channel)

ENG 7- 6

Using a PC

Control of the TV (Continue)

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS

CHANNEL DIRECT

CC C L C P x _ _ _ (Toggle) Toggle

DEVICE NAME T V N M 1 _ _ _ The device

MODEL NAME M N R D 1 _ _ _ The model

CHANNEL (DIGITAL)

CH UP C H U P x _ _ _ The channel

CH DOWN C H D W x _ _ _ The channel

D C 1 0 * * * * (0-9999) DIGITAL Cable

D C 1 1 * * * * (0-6383) DIGITAL Cable

number of TV +1

number of TV

-1

(One-Part numbers, 5digit, less than 10,000)

(One-Part numbers, 5digit, more than 10,000)

If it is not TV display, it will input- switch to TV. (same function as CH

)

If it is not TV display, it will input- switch to TV. (same function as CH

)

operation of a closed caption.

name set in “TV Name Setting” is displayed.

name of the TV

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS SOFTWARE

VERSION

IP PROTOCOL VERSION

NOTE

If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL

CONTENTS.

Any numerical value can replace the "x" on the table.

S W V N 1 _ _ _ The current

I P P V 1 _ _ _ The currently

version of the TV software is displayed.

supported version of IP protocol is displayed.

ENG 7- 7

Using a PC

Control of the TV (Continue)

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS

REMOTE CONTROL BUTTONS

R C K Y * * _ _ 0-9: 0-9,

10: DOT, 11: ENT, 12: POWER, 13: DISPLAY, 14: POWER (SOURCE) 15: 16:

, 17: 18: 19: 20:

, 21: 23: OPTION, 24: SLEEP, 27: CC, 28: AV MODE, 29: VIEW MODE, 30: FLASHBACK, 31: MUTE, 32: VOL -, 33: VOL +, 34: CH 35: CH 36: INPUT, 38: MENU, 39: SmartCentral, 40: ENTER, 41:

42:

43:

44:

, 45: RETURN, 46: EXIT, 47: FAV CH, 49: AUDIO, 50: A (red), 51: B (green), 52: C (blue), 53: D (yellow), 54: FREEZE, 55: FAV APP 1, 56: FAV APP 2, 57: FAV APP 3, 59: NETFLIX, 60: AAL, 61: MANUAL

, ,

NOTE

If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL

CONTENTS.

Any numerical value can replace the "x" on the table.

ENG 7- 8

Using a PC

It is necessary to set the PC correctly to display XGA and WXGA signal.

PC Compatibility Chart

Resolution

VGA

SVGA 800 x 600

XGA 1024 x 768

WXGA 1360 x 768 47.7 kHz 60 Hz

SXGA 1280 x 1024 64.0 kHz 60 Hz

SXGA+ 1400 x 1050 65.3 kHz 60 Hz

UXGA 1600 x 1200 75.0 kHz 60 Hz

1080p 1920 x 1080 67.5 kHz 60 Hz ―

VGA and XGA are registered trademarks of International Business Machines Corp.

720 x 400 31.5 kHz 70 Hz —

640 x 480

Horizontal

Frequency

31.5 kHz 60 Hz

37.9 kHz 72 Hz

37.5 kHz 75 Hz

35.1 kHz 56 Hz

37.9 kHz 60 Hz

48.1 kHz 72 Hz

46.9 kHz 75 Hz

48.4 kHz 60 Hz

56.5 kHz 70 Hz

60.0 kHz 75 Hz

Vertical

Frequency

VESA Standard

ENG 7- 9

Using the Internet

By connecting your TV to a broadband system, you can access the Internet from the TV.

Using an ETHERNET cable

Use an ETHERNET cable (commercially available) to connect the ETHERNET terminal on the TV to your broadband router (commercially available).

Using the wireless LAN

This TV is equipped with a wireless LAN function. For a wireless LAN connection, you must use "Wireless Setup" to connect the access point and TV.

You can enjoy a variety of streaming content and Internet applications.

(See pages 8-12 to 8 -13.)

Connecting to the Internet

To connect your TV to the Internet, you must have a broadband Internet connection. If you do not have a broadband Internet connection, consult the store where you purchased your

TV or ask your Internet service provider or telephone company.

When an Internet connection is made, an Ethernet and wireless connection cannot be used at

the same time. Use only one of the connection types.

NOTE

This TV has a built -in wireless LAN function. Using a separate wireless USB LAN adapter may

result in radio communications that do not comply with regulations on radio communications. Therefore, do not use a separate wireless LAN adapter.

A wireless LAN connection and performance cannot be guaranteed for all residential

environments. In the following cases, the wireless LAN signal may be poor or drop, or the connection speed may become slower.

- When used in buildings made with concrete, reinforced steel, or metal

- When placed near objects that obstruct the signal

- When used with other wireless devices that emit the same frequency

- When used in the vicinity of microwave ovens and other devices that emit a magnetic field, electrostatic charge, or electromagnetic interference

ENG 8- 1

Using the Internet

Internet Setup

Perform the procedure below to make adjustments or to confirm the settings for accessing the Internet.

1 Press MENU to display the MENU screen, and then

press ENTER.

2 Press 3 Press

4 Press

5 Press

6 Press

7 Press MENU to exit.

/ to select "Smart TV", and then press ENTER.

/ to select "Internet Setup", and then press

ENTER.

/ to select "Connection Type", "Wired Setup" or

"Wireless Setup", and then press ENTER.

Select ”Wired Setup" or "Wireless Setup" when you

make general adjustments to connect to the Internet.

/ to select a specific item, and then press

ENTER.

/ (or / ) to select the desired setting, and

then press ENTER.

Connection Type

Select the connection type.

Wired: The signal is detected and setup is performed

automatically. Use "Wired Setup" to check and change the settings as necessary.

Wireless: Configure the access point settings on "Wireless

Setup".

ENG 8- 2

Using the Internet

Internet Setup (Continue)

Wireless Setup

Make adjustments and confirm the settings necessary for wireless LAN connection (such as search for the access point and registration of it).

WPS

WPS push button: Allows the TV to automatically

establish the connection using a button on the access point.

WPS PIN code: Sets up the connection by registering a

PIN code for the access point.

Search: Searches for and selects the access point to be

connected.

Manual Setup: Allows you to make the connection by

entering an SSID for the access point. If your access point supports Wi-Fi Protected Setup (WPS push button method), it is recommended that you use this function for the wireless connection. You can press the WPS button on the access point to configure the settings automatically.

The name of the WPS button function may differ

depending on the access point. See the operation manual of the access point for details.

1 Confirm the current settings in "Connection Type".

If "Wired" is selected, press / to select "Wireless".

2 Select the desired connection method and follow the

instructions shown on the display.

3 When a connection is established, the connection details

are displayed. Press ENTER.

NOTE

Operations cannot be guaranteed when used with access

points that do not have Wi -Fi ® certification.

A wireless LAN router/access point is required to connect

the TV to the Internet using a wireless LAN. See the operation manual of your access point for setup.

If your access point is set to a stealth mode (that

prevents detection by other devices), you may not be able to establish a connection. In this case, disable the stealth mode on the access point.

A stable connection speed is required to play back

streaming content. Use an Ethernet connection if the wireless LAN speed is unstable.

Before transferring to a third party or disposal, be sure to

initialize the wireless LAN settings.

Please follow the legislation in your country when using

the wireless LAN outdoors.

ENG 8- 3

Using the Internet

Internet Setup (Continue)

Wired Setup

You can make adjustments manually for the IP.

You can switch the "Connect Type" to "AUTO" or

"Manual". Check that numbers are displayed for each setting. If there are any settings without numbers, specify the

numbers by following the on- screen instructions. Input the IP address etc by using remote control buttons

0-9.

ENG 8- 4

Using the Internet

Entering Text (Software Keyboard)

When you are editing an input screen or specifying the Network settings used for accessing the Internet, enter text from the software keyboard.

NOTE

You can enter up to 128 characters for text. Some special characters or diacritics may not be available depending on where you enter the text.

The text you enter is displayed as you type it in.

To move the cursor (the current input position), use "

While you are entering text, likely input conversion candidates are displayed based on what you typed in.

CapsLock

If "alphabet" is selected, this switches characters between uppercase and lowercase. Each time you press ENTER, the character type switches.

" or " " on the software keyboard.

Symbol

Press ENTER to select the type of characters entered: alphabet, or sign.

BackSpace/Delete

Erases text one character at a time.

ENG 8- 5

Using the Internet

Entering Text (Software Keyboard) (Continue)

Enter

Applies the entered information and closes the software keyboard.

Space

Enters a space.

Clear

Erases the character string.

When the cursor is somewhere in a line: the character

string to the right of the cursor will be erased. When the cursor is at the right end of a line: the entire

line will be erased.

Closes the software keyboard without applying the entered information.

Buttons on the

remote control unit

/ / / Moves the focus. When moved at

ENTER Performs the processing for the

EXIT Closes the software keyboard RETURN

0-9 Directly enters the single-byte

the far edge, the focus moves to the opposite edge.

button currently in the focus.

without applying the original input elements for the entered text.

number for that button.

Description

ENG 8- 6

Using the Internet

Using the Browser

1 Press SmartCentral, press / to select the browser

icon from the application window, and then press ENTER.

Press SmartCentral again to switch back to the

currently tuned channel.

Buttons for Using the Browser ENTER,

EXIT

RETURN

/ / /

Press / / / to select a link that you want to jump,

and then press ENTER.

Press the button to return to the TV screen.

Press the button to return to the previous page.

NOTE

Restrictions apply to window display.

ENG 8- 7

Using the Internet

Using the Browser (Continue)

Selected

item

Description

Allows you to go back to the previous page.

Allows you to go to the next page.

Refreshes the page. Interrupts a page while it is loading.

Displays the home page.

Selected item Description

Displays the bookmarks list.

Displays your browsing history.

Configures browser settings.

Using the Toolbar

You can use the toolbar to control the browser and to specify settings.

1 Press

Browsing Web Contents

You can display the web content you want to enjoy.

1 Press

2 Enter an address, and then press ENTER.

/ to select a function, and then press ENTER.

/ to move to the address area in the toolbar, and

then press ENTER.

The Enter Address menu is displayed.

The web content you want to view is displayed.

ENG 8- 8

Using the Internet

Using the Browser (Continue)

CAUTION

If the power is cut due to a power failure or the TV being

unplugged while you are using the Internet, information

such as bookmarks or cookies may not be saved

correctly.

To users who access the Internet from a PC

When you access the Internet from this TV, the

procedures may not be the same as regular browserbased access on a PC.

On some pages, video and audio, text or images may

not be displayed correctly.

About links

Web pages on the Internet often include "links" that allow

you to jump to other web pages (or sites).

"Links" can take various forms, including words or images,

but they always work in the same way letting you jump to the link destination when you select them.

Selected items (such as links of text input fields) are

enclosed in a frame.

You can jump from a "link" to the corresponding link

destination.

DISCLAIMERS

SHARP corporation bears no responsibility regarding the content and quality of the content provided by the content serve provider.

ENG 8- 9

Using the Internet

Using the Browser (Continue)

Browser Settings

You can check or modify your browser settings from the Browser menu.

1 Press

2 Press

/ to select " " in the toolbar, and then press

ENTER.

/ / / to specify the required setting, and then

press ENTER.

ENG 8- 10

Using the Internet

Using Keyboard and Mouse

You can use a keyboard or mouse for operating the TV while using the browser.

When you use the USB devices, connect the device to the

USB terminal on the TV.

NOTE

The keyboard and mouse can only be used on a browser

screen.

The keyboard or mouse may not operate properly

depending on the application being used.

ENG 8- 11

Using the Internet

Using Applications via the Internet

By connecting the TV to the Internet, you can enjoy a variety of broadband content, including videos, music and photos.

Please check that the most current software is loaded on TV by selecting "Auto Update Setting" on "Software Update"

(see page 4-14) or by visiting

http://www.sharpusa.com/products/support/ to check for a download of the newest software version.

Use the application window to access your favorite Internet applications. Press SmartCentral to display the application window. Follow the on -screen instructions for each application.

When using this TV to access an Internet application for

the first time, the Disclaimer appears on the screen.

Press

/ to select "Agree", and then press ENTER.

(You must select "Agree" to use the application.) Check the web site of the provider for details on setup

and use of the functions.

NOTE

If " " or " " is displayed , check your TV's

network settings and connection. Additional applications will be available in the future. These applications are provided by content providers. The

available applications vary depending on your country or

region. The delivery speed of applications varies depending on

the network speed. Check the web site of the provider

for details on application setup and other information.

Using the Application Window

During Dock Display

You can move the application icons.

1 Select an application, and then press . 2 Press

Move the Icons

You can move the icons of the more commonly used applications closer to the left. Press

Saving Favorite Applications

You can set your favorite applications to the FAV APP1, 2, and 3 buttons on the remote control for easier startup.

The applications whose icons are moved onto during Dock Display will be assigned to the FAV APP 1, 2 and 3 buttons respectively.

/ to move the icon to the desired location.

Example

, and

ENG 8- 12

Using the Internet

Using Applications via the Internet (Continue)

Deactivating Netflix Function

You can deactivate the Netflix function. Refer to "Smart TV" > "Advanced" > "Netflix Help" and select "Deactivate".

To confirm the Netflix status, check the information

displayed on the screen and click "OK".

Deactivating the VUDU Function

To deactivate the VUDU function, refer to "Smart TV" > "Advanced" > "VUDU Help" and select "Yes".When you access the Internet application for the first time, the following appears.

This message is available only in English.

AQUOS Advantage Live

When you select this app on the SmartCentral screen, you can use the remote support function from the support center and display the network status.

ENG 8- 13

Using the Internet

Notes

DISCLAIMERS

This SHARP device facilitates the access to content and services provided by third parties. The content and services accessible via this device belong to and may be proprietary to third parties.

Therefore, any use of such third party content and services must be in accordance with any authorization or terms of use provided by such content or service provider. SHARP shall not be liable to you or any third party for your failure to abide by such authorization or terms of use. Unless otherwise specifically authorized by the applicable content or service provider, all third party content and services provided are for personal and non -commercial use; you may not modify, copy, distribute, transmit, display, perform, reproduce, upload, publish, license, create derivative works from, transfer or sell in any manner or medium any content or services available via this device.

SHARP is not responsible, nor liable, for customer service-related issues related to the third party content or services. Any questions, comments or service -related inquiries relating to the third

party content or service should be made directly to the applicable content or service provider. You may not be able to access content or services from the device for a variety of reasons which may be unrelated to the device itself, including, but not limited to, power failure, other Internet connection, or failure to configure your device properly. SHARP, its directors, officers, employees, agents, contractors and affiliates shall not be liable to you or any third party with respect to such failures or maintenance outages, regardless of cause or whether or not it could have been avoided.

ALL THIRD PARTY CONTENT OR SERVICES ACCESSIBLE VIA THIS DEVICE IS PROVIDED TO YOU ON AN "AS-IS" AND "AS AVAILABLE" BASIS AND SHARP AND ITS AFFILIATES MAKE

NO WARRANTY OR REPRESENTATION OF ANY KIND TO YOU, EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY WARRANTIES OF MERCHANTABILITY, NONINFRINGEMENT, FITNESS FOR A PARTICULAR PURPOSE OR ANY WARRANTIES OF SUITABILITY, AVAILABILITY, ACCURACY, COMPLETENESS, SECURITY, TITLE, USEFULNESS, LACK OF NEGLIGENCE OR ERROR-FREE OR UNINTERRUPTED OPERATION OR USE OF THE CONTENT OR SERVICES PROVIDED TO YOU OR THAT THE CONTENT OR SERVICES WILL MEET YOUR REQUIREMENTS OR EXPECTATIONS.

SHARP IS NOT AN AGENT OF AND ASSUMES NO RESPONSIBILITY FOR THE ACTS OR OMISSIONS OF THIRD PARTY CONTENT OR SERVICE PROVIDERS, NOR ANY ASPECT OF THE

CONTENT OR SERVICE RELATED TO SUCH THIRD PARTY PROVIDERS.

IN NO EVENT WILL SHARP AND/OR ITS AFFILIATES BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE, CONSEQUENTIAL OR

OTHER DAMAGES, WHETHER THE THEORY OF LIABILITY IS BASED ON CONTRACT, TORT, NEGLIGENCE, BREACH OF WARRANTY, STRICT LIABILITY OR OTHERWISE AND WHETHER OR NOT SHARP AND/OR ITS AFFILIATES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Examples of Application Logos

ENG 8- 14

Using the Miracast devices

When you connect a device such as a Miracast- compatible smartphone or tablet to this TV, you can enjoy video and audio from the device on the TV's large screen and speakers.

Miracast devices

1 Select the "Smart TV" > "Miracast". 2 Enable the Miracast function on the Miracast device and connect to the TV.

(The TV screen changes according to the behavior of the device)

NOTE

When the TV is turned off or the connection is ended on the device, you must connect the

device again.

For details about the operation of the Miracast -compatible device, check the manual for that

device.

When the Miracast device is connected to the TV over a wireless LAN, Miracast video may be

distorted and Miracast audio may be interrupted depending on the status of the TV's connection to the access point.

ENG 9- 1

Sharp LC-60C6600U, LC-60EQ30U, LC-60LE661U, LC-70C6600U, LC-70EQ30U User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents
