Sharp FP-R30CX User Manual
R
FP-R30CX
AIR PURIFIER
OPERATION MANUAL
ENGLISH
PURIFICATEUR D’AIR
Free Standing
Type mobile
*Plasmacluster is a trademark of Sharp Corporation.
*Plasmacluster est une marque de commerce de Sharp Corporation.
MANUEL D’UTILISATION
FRANÇAIS
This product earned the ENERGY STAR by meeting
strict energy efficiency guidelines set by the US EPA.
US EPA does not endorse any manufacturer claims
of healthier indoor air from the use of this product.
The energy efficiency of this ENERGY STAR qualified model is measured based on a ratio between the
model’s CADR for Dust and the electrical energy it
consumes, or CADR/Watt.
Ce produit a le droit de porter la marque ENERGY
STAR après avoir répondu à des critères stricts en ce
qui concerne l’efficacité énergétique, tels qu’établis
par l’agence EPA aux É-U. L’agence EPA aux É-U
n’appuie aucunement les témoignages publicitaires
du fabricant indiquant que ce produit rend l’air intérieur
des locaux plus sain.
L’efficacité énergétique de ce modèle, qui bénéficie
de la reconnaissance ENERGY STAR, est mesurée
par le rapport entre le DAP (débit d’air purifié) du
modèle et l’énergie électrique qu’il consomme, soit le
rapport DAP/Watt.
Please read before operating your new Air Purifier
The air purifier draws in room air from its air intake, lets the air pass through a
Active Carbon Filter (deodorization filter) and a True HEPA Filter (dust collection filter) inside of the unit, then discharges the air from its air outlet. The air
purifier unit repeats this process by moving its internal fan.
As air passes through, a new True HEPA Filter can remove 99.97% of dust
particles, of as small as 0.3 microns. The Active Carbon Filter gradually absorbs
odor elements as they repeatedly pass through the filter. (Odor elements are
absorbed by True HEPA Filter as well.)
Some odor ingredients absorbed by the filters may become separated and
may be discharged through the air outlet and result in additional odor. Depending on the usage environment, especially when the product is used in a
condition significantly more severe than household use, this odor may become strong in a shorter period than expected.
If the odor persists, then the filters are fully expended and it is necessary to
purchase the optional replacement filter kit FZ-R30HFU.
NOTE
• The air purifier is designed to remove air-suspended dust and odor, but not harmful gases (for example, carbon monoxide contained in cigarette smoke). If the odor sources still exist, it cannot completely remove the odor. (for example, odors from construction materials and pet odors).
• It is suggested to open the window a bit when you are smoking in order to facilitate ventilation.
ENGLISH
FEATURES
Plasmacluster Ion Control
Your new air purifier will control the ratio
of negative ions and positive ions depending on the condition of the room.
• Clean Mode
Approximately the same numbers of positive and negative ions are discharged.
• Ion Control Mode
Plenty of negative ions exist in natural
surroundings such as waterfalls or forests.
In this mode, negative ions will be released in an increased rate.
• AUTO Plasmacluster Ion Mode
The unit will switch between Clean Mode
and Ion Control Mode automatically depending on the amount of impurities in the
air detected by the odor sensor.
• Filters
1) Active Carbon Filter
Absorbs odor elements.
2) True HEPA (High Efficiency
Particulate Air) Filter.
High-efficiency particle collection including pollen and dust.
Declaration of Conformity
SHARP AIR PURIFIER FP-R30CX
This device complies with Part 18 of FCC
rules.
Responsible Party:
SHARP ELECTRONICS CORPORATION
Sharp Plaza,
Mahwah, New Jersey 07430-2135
TEL: 1-800-BE-SHARP
CONTENTS
• FOR CUSTOMER ASSISTANCE(U.S)....
• CONSUMER LIMITED WARRANTY(U.S)
•
FOR CUSTOMER ASSISTANCE(CANADA)...
•
LIMITED WARRANTY(CANADA) ........ E-5
IMPORTANT SAFETY INSTRUCTIONS ....
•WARNING .................................................... E-6
• CAUTIONS CONCERNING OPERATION ...E-7
• REMOTE CONTROL LIMITATIONS ............E-7
• INSTALLATION GUIDELINES .....................E-7
• FILTER GUIDELINES .................................. E-7
PART NAMES .......................................... E-8
• MAIN UNIT DISPLAY ...................................E-8
• INCLUDED ................................................... E-8
• BACK ........................................................... E-8
PREPARATION........................................ E-9
• INSERTING BATTERIES
IN THE REMOTE CONTROL ...................... E-9
• REMOTE CONTROL USE ........................... E-9
• FILTER INSTALLATION ............................ E-10
OPERATION .......................................... E-12
• MAIN UNIT OPERATION .......................... E-12
• REMOTE CONTROL OPERATION .......... E-14
CARE AND MAINTENANCE ................. E-15
• MAIN UNIT ................................................ E-15
• ODOR SENSOR ....................................... E-15
• FILTER CLEANING ................................... E-15
• FILTER REPLACEMENT
GUIDELINES ............................................ E-16
TROUBLE SHOOTING.......................... E-17
SPECIFICATIONS ................................. E-18
E-2
E-3
E-4
E-6
ENGLISH
FRANÇAIS
Declaration of Conformity
SHARP AIR PURIFIER FP-R30CX
This ISM device complies with Canadian
ICES-001
Responsible Party:
SHARP ELECTRONICS OF CANADA LTD.
335 Britannia Road East Mississauga,
Ontario L4Z 1W9 Canada
TEL: (905) 568-7140
Thank you for purchasing the SHARP Air Purifier. Please read this manual carefully for the correct usage information. Before using this product, be sure to read the section: “Important Safety
Instructions.”
After reading this manual, retain it in a convenient location for future reference.
E-1
