Page 1
®
Industrial Bar Code Printers
CL6XXe Printer
Parts List
Page 1-1
P/N 9001088
Rev . A
Page 2
SA T O Industrial Bar Code Printers
Table of Contents
CL6XXe Page
Parts List
Base Cover Assembly...............................................................................................3
Frame Assembly......................................................................................................12
Print Head Assembly ..............................................................................................19
Ribbon Assembly ....................................................................................................23
Feed Roller Assembly.............................................................................................28
Main PCB Assembly................................................................................................31
Interface Option.......................................................................................................32
Dispenser Assembly Option ..................................................................................33
Cutter Assembly Option .........................................................................................40
PCMCIA Memory Option.........................................................................................44
SATO CL6XXe Printer Parts List
Rev . APage 2
Page 3
Base Cover Assembly
SATO Industrial Bar Code Printers
Rev . A
SATO CL6XXe Printer Parts List
Page 3
Page 4
Base Cover Assembly
SA T O Industrial Bar Code Printers
SATO CL6XXe Printer Parts List
Rev . APage 4
Page 5
SATO Industrial Bar Code Printers
Base Cover Assembly
Rev . A
SATO CL6XXe Printer Parts List
Page 5
Page 6
Base Cover Assembly
SA T O Industrial Bar Code Printers
SATO CL6XXe Printer Parts List
Rev . APage 6
Page 7
SATO Industrial Bar Code Printers
Base Cover Assembly
Rev . A
SATO CL6XXe Printer Parts List
Page 7
Page 8
Base Cover Assembly
NO. CODE DESCRIPTION QTY
1 PH1720101 Base Frame 1
2 MH4300621 S-tight screw 1
3 PE6721100 Foot 4
4 PV2720100 Foot rubber 4
5 MD4301021 Pan head screw 4
6 PH1720200 Center frame 1
7 MD4400821 Pan head screw 5
8 PV9720200 Bush 1
9 PZ0725001 Cover Rear 1
10 MD4300821 Pan head screw 6
12 PH1720400 Front frame 1
13 MD3401021 Pan head screw 3
14 MD4400821 Pan head screw 2
SA T O Industrial Bar Code Printers
15 PV9720600 Bush 1
16 KA500821A Power Supply 1
19 HD100311A Fuse (6.3A,250V) 1
20 MD4300621 Pan head screw 4
21 RH1727700 Power Supply Cable 1
22 PA1729700 PCB Bracket 1
24 MD4300821 Pan head screw 4
25 PE6771001 Memory card cover 1
26 PB5A20001 Head Screw 1
27 PH1720700 Lid 1
28 MD4300821 Pan head screw 2
SATO CL6XXe Printer Parts List
Rev . APage 8
Page 9
SATO Industrial Bar Code Printers
Base Cover Assembly
NO. CODE DESCRIPTION QTY
31 PA1722300 Hinge bracket (A) 2
32 PA1722400 Hinge bracket (B) 2
33 PB5720100 Screw 2
34 PB5720200 Screw 2
35 NB5100030 Spring 8
36 ND3120024 E-Ring 2
37 MD4300821 Pan head screw 4
39 PR4720100 Cover RH 1
40 MD4300821 Pan head screw 4
41 PH2720100 Window 1
42 NA1030022 Plain washer 2
43 NB0030022 Spring washer 2
44 MT1300522 Hex nut 2
45 PH1720601 Cover LH 1
46 MD4300821 Pan head screw 5
50 PE6720900 Hinge cover (LH) 1
51 PE6721000 Hinge cover (RH) 1
52 MA7300625 Truss screw 4
53 PR4725000 Key Board Cover (CL608e) 1
54 PE6720800 Switch button 1
55 PA1728600 Plate 1
56 PR4725100 Key Board Cover (CL612e) 1
57 PR4720300 Dip-sw cover 1
58 MH0300821 P tight screw 1
59 MD4301021 Pan head screw 3
60 MD3300521 Pan head screw 1
Rev . A
SATO CL6XXe Printer Parts List
Page 9
Page 10
Base Cover Assembly
NO. CODE DESCRIPTION QTY
61 PH0720200 Front cover 1
62 PA1722500 Front cover bracket (A) 1
63 PA1722600 Front cover bracket (B) 1
64 MH0300821 P tight screw 6
65 PA1724000 Tear-off cutter 1
66 MH0300821 P tight screw 2
67 MD4300821 Pan head screw 2
68 PR1340500 Brush 1
69 MH0300821 P tight screw 2
70 PH0720300 Cover RH sub 1
71 MH0300821 P tight screw 4
74 PA1729100 Paper holder 1
75 PE1720300 Label stopper 1
76 PA4520300 Stopper spring 1
77 MH0300821 P tight screw 1
78 NA1030022 Plain washer 1
80 PA1729200 Roller bracket 2
81 PB0723600 Shaft (Unwind) 2
82 PE3720200 Roller 12
83 PE3720500 Roller 12
84 ND0040030 E-Ring 4
85 MD4300821 Pan head screw 6
86 PA1723700 Unwind bracket (A) 1
87 MD4300821 Pan head screw 2
88 MD4300821 Pan head screw 2
89 MD4400821 Pan head screw 1
SA T O Industrial Bar Code Printers
SATO CL6XXe Printer Parts List
Rev . APage 10
Page 11
SATO Industrial Bar Code Printers
Base Cover Assembly
NO. CODE DESCRIPTION QTY
91 PR3720100 Unwind Bracket (B) 1
92 MD4300821 Pan head screw 2
93 PB0722500 Shaft (unwind) 1
94 ND0030030 E-Ring 2
97 QC6725000 Sticker (Route DIP SW) 1
98 QC6722300 Sticker 1
100 QC6685403 Log Name Plate 1
104 MA0300622 Pan head screw 2
105 JG900411A Cap 1
106 RJ1721600 KB PCB Set 1
107 MH0300821 P tight screw 1
108 RH1720400 Control Panel 1
1 10 RH1745700 Cable Assy 1
111 MH0250621 P-tight screw 1
1 15 PE6A21900 Micro Driver 1
116 JG100551A CK clamp 1
Rev . A
SATO CL6XXe Printer Parts List
Page 11
Page 12
Frame Assembly
SA T O Industrial Bar Code Printers
CL608
SATO CL6XXe Printer Parts List
CL612
Rev . APage 12
Page 13
Frame Assembly
SATO Industrial Bar Code Printers
Rev . A
SATO CL6XXe Printer Parts List
Page 13
Page 14
Frame Assembly
SA T O Industrial Bar Code Printers
SATO CL6XXe Printer Parts List
Rev . APage 14
Page 15
Frame Assembly
SATO Industrial Bar Code Printers
Rev . A
SATO CL6XXe Printer Parts List
Page 15
Page 16
Frame Assembly
NO. CODE DESCRIPTION QTY
1 MD4400821 Pan head screw 2
2 MD4401621 Pan head screw 2
3 PL1720601 Engine Frame 1
4 PA1721600 Support frame (A) 1
5 MD4301422 Pan head screw 2
6 PV9720500 Bush 1
8 PR3720400 Paper guide 1
9 PV9720900 Sensor protector 1
10 PD1720800 Sensor protector 1
11 MD4301422 Pan head screw 3
12 PE3720300 Roller 2
13 PB2740100 Collar 2
SA T O Industrial Bar Code Printers
14 MD4301021 Pan head screw 2
15 PA1729500 Guide plate (A) 1
16 QC6771800 Sticker(Green) 1
17 PB2721100 Collar 1
18 PC1720700 Spring (Guide) 1
19 MD4301422 Pan head screw 1
22 PA1722900 Guide plate (B) 1
23 MD4300821 Pan head screw 1
24 PA1723000 Side frame 1
25 MD4300821 Pan head screw 4
26 PA1720800 Frame bracket 1
27 MD4400821 Pan head screw 2
28 PR4720400 Latch handle (A) 1
29 PR1720600 Latch handle(B) 1
SATO CL6XXe Printer Parts List
Rev . APage 16
Page 17
Frame Assembly
NO. CODE DESCRIPTION QTY
31 PC2720100 Spring (latch handle) 1
32 PB0723700 Shaft (latch handle) 1
33 MJ1400524 W-point screw 4
34 ND0050030 E-Ring 1
35 PA1720900 Plate (adjust A) 1
36 PL2720100 Adjust collar 1
37 MD4300821 Pan head screw 1
38 MD4400821 Pan head screw 1
39 PA1721000 Plate (adjust B) 1
40 MD4400821 Pan head screw 1
41 PR7720500 Platen Roller Sub (CL612) 1
42 PR7720600 Feed Roller Sub (CL612) 1
43 PR7720100 Platen Roller Sub (CL608) 2
SATO Industrial Bar Code Printers
44 MD4300821 Pan head screw 4
45 PT8180064 Timing belt (CL608) 1
46 PL1720100 Motor pulley (CL608) 1
47 MJ1400524 W-point screw 2
48 PB0720800 Shaft (idle gear) 1
49 PT1112060 Ball supporter 2
50 PE8720100 Gear 1
51 PE8720400 Gear pulley 1
52 ND0040030 E-Ring 2
53 PL1720400 Motor Pulley (CL612) 1
55 PA1729600 Tension bracket 1
56 MD4300821 Pan head screw 2
57 PA1723200 Tension bracket (B) 1
58 PB2720400 Collar 1
59 MD4401021 Pan head screw 1
61 PC0740100 Spring (tension) 1
62 MA0301221 Pan head screw 1
63 MT1300522 Hex nut 1
Rev . A
64 PE8720300 Gear 1
65 PE3720100 Tension roller 2
66 PB2720600 Collar 3
SATO CL6XXe Printer Parts List
Page 17
Page 18
Frame Assembly
NO. CODE DESCRIPTION QTY
67 MD4401421 Pan head screw 2
68 MD4401621 Pan head screw 1
69 PB0721100 Shaft (head ) 1
70 PA0720100 Collar 1
71 NB0050022 Spring washer 1
72 MN1501030 Hex hole bolt 1
75 MA0301221 Pan head screw 2
76 MT1300522 Hex nut 2
77 MD3300622 Pan head screw 1
78 PA3730200 Sensor bracket (ribbon) 1
79 MD3300622 Pan head screw 1
80 PA1723500 Switch bracket 1
SA T O Industrial Bar Code Printers
81 MD4300821 Pan head screw 1
84 PB0723800 Label guide shaft 1
85 MA0301221 Pan head screw 2
86 PT6720100 Cushioning rubber 1
87 MA0301221 Pan head screw 2
88 PB2720500 Collar 1
91 RH1721000 Ribbon sensor cord 1
92 MA0300622 Pan head screw 2
93 RH1721200 Head open sw cord 1
94 MD3201221 Pan head screw 2
96 RH1720500 Stepper Motor Assy 1
97 MD3401221 Pan head screw 3
98 RH1724100 Pitch sensor cord 1
99 MD3300622 Pan head screw 2
100 RH1721400 Paper end SW cord set 1
101 MD3201221 Pan head screw 2
102 MA0401421 Pan Screw 1
103 MT1400722 Hex nut 1
104 PC0720200 Spring (Tension) 1
106 PT8187064 Timing Belt (CL612) 1
107 PL1720500 Pulley (CL612) 2
108 MJ1300424 W-point screw 4
SATO CL6XXe Printer Parts List
Rev . APage 18
Page 19
Print Head Assembly
SATO Industrial Bar Code Printers
Rev . A
SATO CL6XXe Printer Parts List
Page 19
Page 20
Print Head Assembly
SA T O Industrial Bar Code Printers
SATO CL6XXe Printer Parts List
Rev . APage 20
Page 21
Print Head Assembly
NO. CODE DESCRIPTION QTY
1 PA1721700 Head frame (LH) 1
2 MA0301221 Pan head screw 2
3 MT1300522 Hex nut 2
4 PA1721800 Head frame (RH) 1
5 PA1721200 Plate (adjust C) 1
6 PL2720100 Adjust collar 1
7 MD4300821 Pan head screw 2
9 PD1720400 Stay 1
10 MD3401021 Pan head screw 4
11 PA1721500 Support plate (B) 1
12 MD4300821 Pan head screw 2
13 PB2720100 Collar 2
14 MD3401021 Pan head screw 2
SATO Industrial Bar Code Printers
15 PR1720100 Roller 1
16 ND0060030 E-Ring 1
17 PR0720700 Feed roller 1
18 PL2720400 Bush 4
19 PE8720100 Gear 1
20 ND0040030 E-Ring 2
23 PE1720100 Cam (head pressure) 2
24 PB0720600 Shaft (head pressure) 1
25 ND0040030 E-Ring 2
26 PE1720200 Knob 1
27 PE6720500 Protecter (B) 1
28 MD4300821 Pan head screw 1
29 PV9720100 Bush 1
30 PC0720100 Spring (open) 1
Rev . A
SATO CL6XXe Printer Parts List
Page 21
Page 22
Print Head Assembly
NO. CODE DESCRIPTION QTY
31 PA1727100 Head Bracket (A) (CL608) 1
32 PA1727200 Head Bracket (B) (CL608) 1
33 PC1720100 Spring (head) (CL608) 2
34 PB2720200 Collar 1
35 PB2720300 Collar 2
36 PB2720400 Collar 1
37 MD4402021 Pan head screw 1
38 MD4401021 Pan head screw 3
39 PR1720200 Head sub holder (CL608) 1
40 MD4300821 Pan head screw 2
41 PR1721400 Head sub holder(CL612) 1
43 PA1721400 Head cable cover 1
44 MD4300621 Pan head screw 2
SA T O Industrial Bar Code Printers
45 PC1690201 Spring 2
46 MN1301630 Hex hole bolt 2
47 RH1727700 Power & Head Power Cord Set 1
48 RH1775201 Print Head Cable Assy 1
49 GH000661A Print Head (CL608) 1
50 PB0723400 Post (Head) 2
51 PR4721000 Plate(Ribbon) (CL608) 1
52 PR4721100 Plate(Ribbon) (CL612) 1
53 PA1721900 Head bracket (A) (CL612) 1
54 PA1722000 Head bracket (B) (CL612 1
55 PC1720400 Spring (head) (CL612) 2
56 GH000511A Print Head (CL612) 1
SATO CL6XXe Printer Parts List
Rev . APage 22
Page 23
Ribbon Assembly
SATO Industrial Bar Code Printers
Rev . A
SATO CL6XXe Printer Parts List
Page 23
Page 24
Ribbon Assembly
SA T O Industrial Bar Code Printers
SATO CL6XXe Printer Parts List
Rev . APage 24
Page 25
Ribbon Assembly
SATO Industrial Bar Code Printers
Rev . A
SATO CL6XXe Printer Parts List
Page 25
Page 26
Ribbon Assembly
NO. CODE DESCRIPTION QTY
1 PE4720100 Ribbon boss 2
2 PE2720100 Collor 6
3 PA4690900 Spring 8
4 MH0300521 P tight screw 8
5 PT2301020 Oilless dry metal 2
6 PA0680400 Disc 2
7 PC1730100 Spring 2
8 PE2730100 Stopper collar 2
9 PB5730100 Adjust screw 2
10 MA0303022 Pan head screw 2
11 PB0720400 Shaft (ribbon) 2
14 PE4720200 Plate holder boss 2
15 MA0301821 Pan head screw 1
SA T O Industrial Bar Code Printers
16 MA0302522 Pan head screw 1
17 MT1300522 Hex nut 1
18 MH1250621 P-tight screw 4
19 PA0680300 Lining 2
20 PC0730100 Spring (back) 1
21 PE1681100 Guide plate (B) 1
22 PE7720100 Disc plate (A) 1
25 PE6720100 Disc plate cover 1
26 MD4300821 Pan head screw 3
27 PA0730100 Guide plate 2
28 PA0730200 Hold plate 2
29 PA1720700 Ribbon frame 1
30 MD4400821 Pan head screw 5
31 PA1731000 Adjust plate 2
32 MD4300621 Pan head screw 4
33 MD4400821 Pan head screw 2
34 PT1114080 Ball supporter 2
35 PT1112080 Ball supporter 2
36 PR1720400 Pulley 1
37 ND0060030 E-Ring 1
38 PT8131064 Timing belt 1
SATO CL6XXe Printer Parts List
Rev . APage 26
Page 27
Ribbon Assembly
NO. CODE DESCRIPTION QTY
41 PR1770100 Pulley 1
42 PC0760500 Spring (ribbon) 1
43 NA1030022 Plain washer 1
44 MH0300821 P tight screw 1
45 MT1400722 Hex nut 1
46 MD3401221 Pan head screw 1
SATO Industrial Bar Code Printers
Rev . A
SATO CL6XXe Printer Parts List
Page 27
Page 28
Feed Roller Assembly
SA T O Industrial Bar Code Printers
SATO CL6XXe Printer Parts List
Rev . APage 28
Page 29
SATO Industrial Bar Code Printers
Feed Roller Assembly
Rev . A
SATO CL6XXe Printer Parts List
Page 29
Page 30
Feed Roller Assembly
NO. CODE DESCRIPTION QTY
1 PR3720500 Paper lid 1
2 PR4721300 Paper lid cover 1
3 PA1720400 Roller bracket (A) 1
4 PA1720500 Roller bracket (B) 1
5 PE2730300 Stopper collar 2
6 PC1720601 Spring (pressure) 2
7 MA0301221 Pan head screw) 2
8 MT1300522 Hex nut) 2
9 MD4300821 Pan head screw) 2
12 PB0720500 Shaft (pressure) 1
13 PE3720200 Roller 6
14 PE3720500 Roller 6
SA T O Industrial Bar Code Printers
15 ND0040030 E-Ring 2
16 MD4300821 Pan head screw 2
17 MA7300625 Truss screw 2
20 PV3720100 PCB bracket (A) 1
21 PA1729400 PCB Bracket (D) 1
22 MA0300622 Pan head screw 2
23 PB2720800 Collar 1
24 MJ9300622 Thin head screw 1
25 MD4300821 Pan head screw) 1
26 PA1720300 Lid bracket 1
27 PC2740200 Spring (open) 1
28 PA3742100 Latch handle 1
29 PC2740300 Spring (latch) 1
31 PB0741100 Shaft (lid) 2
32 ND0020030 E-Ring 4
33 MD4401621 Pan head screw 1
36 RH1724300 Pitch sensor cord(SEN2) 1
SATO CL6XXe Printer Parts List
Rev . APage 30
Page 31
Main PCB Assembly
SATO Industrial Bar Code Printers
Rev . A
NO. CODE DESCRIPTION QTY
1 RJ1771200 Main PCBA 1
2 PC9730100 Spring (Lock) 1
3 PA3739900 Connector lock 1
4 MD4300621 Pan head screw 5
5 RJ7770200 Memory PCB Assy-B 1
8 RJ7770300 Memory PCB (4 MB Memory Option) 1
SATO CL6XXe Printer Parts List
Page 31
Page 32
Interface Option
SA T O Industrial Bar Code Printers
1
NO. CODE DESCRIPTION QTY
1 MD3300622 Screw 2
2 WCL404070 IEEE-1284 Parallel Interface 1
3 WCL404051 Serial Interface 1
4 WCL404060 USB Interface 1
5 11S000158 Ethernet Interface 1
6 11S000136 CX/TX Interface 1
2 3
4 5
6
SATO CL6XXe Printer Parts List
Rev . APage 32
Page 33
SATO Industrial Bar Code Printers
Dispenser Assembly Option
Rev . A
SATO CL6XXe Printer Parts List
Page 33
Page 34
SA T O Industrial Bar Code Printers
Dispenser Assembly Option
SATO CL6XXe Printer Parts List
Rev . APage 34
Page 35
SATO Industrial Bar Code Printers
Dispenser Assembly Option
Rev . A
SATO CL6XXe Printer Parts List
Page 35
Page 36
SA T O Industrial Bar Code Printers
Dispenser Assembly Option
SATO CL6XXe Printer Parts List
Rev . APage 36
Page 37
SATO Industrial Bar Code Printers
Dispenser Assembly Option
NO. CODE DESCRIPTION QTY
1 PH0720400 Dispense cover 1
2 MH0300821 P tight screw 4
3 PA1724701 Dispense frame 1
4 PB0721600 Post (latch) RH 1
5 PB0721700 Post (latch) LH 1
6 MD4300621 Pan head screw 2
7 PA1724600 Dispense bar 1
8 PA1724500 Adjust plate 1
9 MD4300621 Pan head screw 1
12 MD4301021 Pan head screw 1
13 MD4300821 Pan head screw 1
14 MA7300625 Truss screw 2
15 PA1724800 Dispense cover bracket 1
16 MD4300621 Pan head screw 1
17 PB0721400 Shaft (Guide) 1
18 ND0030030 E-Ring 4
19 PE1720400 Dispense bracket 1
20 PE1570300 Dispense sensor bracket 2
21 MH0250621 P-tight screw 2
24 PA1724400 Roller bracket 1
25 PR1340500 Brush 1
26 PR1520200 Pressure roller sub assy 1
27 PB0721200 Shaft (Pressure roller) 1
28 ND0040030 E-Ring 2
29 PC1010200 Head spring 2
30 PE2730300 Stopper collar 2
Rev . A
SATO CL6XXe Printer Parts List
Page 37
Page 38
SA T O Industrial Bar Code Printers
Dispenser Assembly Option
NO. CODE DESCRIPTION QTY
31 MD4300821 Pan head screw 2
32 MH0300821 P tight screw 5
33 PB0721300 Shaft (Dispense roller) 1
34 PE3520600 Dispense roller 7
35 ND0020030 E-Ring 1
36 PE8720800 Gear 1
37 PB2720100 Collar 1
38 MD4401421 Pan head screw 1
41 PR0720300 Feed roller 1
42 PE8720700 Gear 1
43 PT1112060 Ball supporter 2
44 PA1680200 Ball supporter clamp 1
45 ND0040030 E-Ring 1
46 MD4300821 Pan head screw 1
47 PA1725200 Rewind frame 1
48 MD4300821 Pan head screw 2
49 PA1725100 Side frame 1
50 MD4300621 Pan head screw 4
53 PE8721000 Gear pulley 1
54 PB0721800 Shaft (Idle gear) 1
55 PR4720600 Rewind belt 1
56 PR1720700 Rewind handle 1
57 PB0721900 Shaft (rewind) 1
58 PB4720100 Rewind core 2
59 PL2720200 Bush 1
SATO CL6XXe Printer Parts List
Rev . APage 38
Page 39
SATO Industrial Bar Code Printers
Dispenser Assembly Option
NO. CODE DESCRIPTION QTY
61 NA0060022 Plain washer 2
62 ND0040030 E-Ring 3
63 MD4301221 Pan head screw 2
64 PC3720100 Rewind knob 1
65 PA1724900 Flange 2
66 PJ4720100 Facing 2
67 PE8721100 Gear 1
68 PB9720100 Adjust nut 1
69 NB5100030 Spring 2
70 MT1400722 Hex nut 1
73 PA1725300 Idle shaft bracket 1
74 PB0722000 Shaft (Idle gear) 1
75 PE8721200 Pulley 1
76 PE8520500 Rewind pulley 1
77 PT1112060 Ball supporter 2
78 ND0040030 E-Ring 1
79 MD4300621 Pan head screw 1
80 MD4300621 Pan head screw 4
81 PT8095064 Timing belt 1
84 PE8720900 Gear pulley 1
85 PB2720200 Collar 1
86 MD4402221 Pan head screw 1
87 PA1725400 Belt cover 1
88 MD4300621 Pan head screw 1
89 PA1723100 Tension bracket (A) 1
90 PE3720100 Tension roller 1
91 PB2720600 Collar 1
92 MD4300821 Pan head screw 2
93 MD4401421 Pan head screw 1
98 RH1721100 Dispense sensor cord 1
Rev . A
SATO CL6XXe Printer Parts List
Page 39
Page 40
Cutter Assembly Option
SA T O Industrial Bar Code Printers
SATO CL6XXe Printer Parts List
Rev . APage 40
Page 41
SATO Industrial Bar Code Printers
Cutter Assembly Option
Rev . A
SATO CL6XXe Printer Parts List
Page 41
Page 42
Cutter Assembly Option
NO. CODE DESCRIPTION QTY
1 PR1720800 Cutter set 1
2 PR1691401 Cutter pulley 1
3 MJ1300424 W-point screw 2
4 PA1725500 Sensor slit 1
5 MD4300621 Pan head screw 1
6 PB0722200 Shaft (Idle gear) 1
7 PL1720700 Pulley 1
8 MJ1300424 W-point screw 2
9 PT1107030 Ball supporter 2
12 PU3112060 Timing belt 2
13 PB0722100 Post (Idle gear) 2
14 PA1725600 Sensor bracket 1
15 MD4300821 Pan head screw 4
SA T O Industrial Bar Code Printers
16 MD3300621 Pan head screw 2
17 PL1720300 Motor pulley 1
18 MJ1300424 W-point screw 2
19 MD4300821 Pan head screw 2
22 PA1725700 Cover bracket (A) 1
23 MD4301021 Pan head screw 2
24 PA1728500 Cutter protect (B) 1
25 MD4300621 Pan head screw 1
26 MD3401021 Pan head screw 1
27 MT1300521 Hex nut 2
28 PA1726200 Cutter protect (A) 1
29 PA6720200 Cutter plate 1
30 MD3300621 Pan head screw 1
SATO CL6XXe Printer Parts List
Rev . APage 42
Page 43
SATO Industrial Bar Code Printers
Cutter Assembly Option
NO. CODE DESCRIPTION QTY
31 PA1726000 PCB bracket 1
32 MD3300621 Pan head screw 4
33 PA2720700 Cover Bracket (E) 1
34 MD4300621 Pan head screw 2
35 PA2720500 Cover BR(E) 1
36 MD4301021 Pan head screw 1
37 PB0722300 Feed roller (Cutter) 1
38 ND0020030 E-Ring 2
41 PB0722400 Shaft (Feed roller) 1
42 PR1720900 Roller (Cutter) 2
43 ND0050030 E-Ring 2
44 PE8721400 Pulley 1
45 PV9720700 Rubber-Ring 1
46 PB2720700 Collar 1
47 ND0020030 E-Ring 1
48 PR1721000 Cover (Cutter) 1
49 PA2720400 Cover Bracket (D) 1
50 PA2720800 Cover Bracket (G) 1
51 MH0300821 P tight screw 4
52 MD4301021 Pan head screw 5
61 RJ1723500 Cutter PCB set 1
62 RH1727501 CutterPower Cord Set 1
63 RH1727800 Cutter Cable Set 1
64 RH1722200 Cutter Motor with cord 1
65 RH1722300 Cutter sensor cord 1
Rev . A
SATO CL6XXe Printer Parts List
Page 43
Page 44
PCMCIA Memory Option
SA T O Industrial Bar Code Printers
NO. CODE DESCRIPTION QTY
1 RJ4770100 PCMCIA Memory Option 1
NOTE: PCMCIA Memory Card not included with the option.
SATO CL6XXe Printer Parts List
Rev . APage 44
Loading...
