ENGLISH
LCD HDTV
Owner’s Manual
Table of Contents . . . . 4
ESPAÑOL
TV de LCD HDTV
Manual de Instrucciones
Contenido . . . . . . . . . 19
FRANÇAIS
TVHD ACL
Manuel d’instructions
Table des matières . . 33
Need assistance?
Visit our Web site at
www.sanyoctv.com
or call toll free
1-800-877-5032
We can Help!
DP19648
© 2008 Sanyo Manufacturing Corporation
Welcome to the World of Sanyo
Thank you for purchasing this Sanyo LCD High-Definition
Digital Television. You made an excellent choice for
Performance, Reliability, Features, Value, and Styling.
2
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit fully into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
15. If an outside antenna is connected to the television
equipment, be sure the antenna system is grounded so
as to provide some protection against voltage surges
and built up static charges. In the U.S. Selection 810-21
of the National Electrical Code provides information with
respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrodes.
16. An outside antenna system should not be located in the
vicinity of overhead power lines or other electrical light
or power circuits, or where it can fall into such power
lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from
touching such power lines or circuits as contact with
them might be fatal.
EXAMPLE OF ANTENNA GROUNDING ACCORDING
TO NATIONAL ELECTRICAL CODE,ANSI/NFPA 70
“Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”
17. Wall or Ceiling Mounting—The product should be
mounted to a wall or ceiling only as recommended by
the manufacturer.
18. "Apparatus shall not be exposed to dripping or splashing
and no objects filled with liquids, such as vases, shall be
placed on the apparatus."
19. When the MAINS plug is used as the disconnect device,
the disconnect device shall remain readily operable.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A
RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THIS
UNIT.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
3
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
CAUTION: FCC Regulations state that improper modifications or unauthorized changes to this unit may void the
user’s authority to operate the unit.
Hello!
I’m your new Sanyo Wide-screen LCD HDTV.
Don’t plug me in just yet! Please read this manual carefully so you can learn about my many features, such as,
my integrated HD Tuner, V-Guide control, Digital
Channels, my PC Input and many more...
TRADEMARKS
Manufactured under license from Dolby
Laboratories. “Dolby” is a trademark of Dolby
Laboratories.
“As an Energy Star® Partner, Sanyo
Manufacturing Corporation has determined that this product meets the
Energy Star® guidelines for energy
efficiency.”
This symbol on the nameplate
means the product is Listed by
Underwriters’ Laboratories Inc. It is
designed and manufactured to
meet rigid U.L. safety standards
against risk of fire, casualty and
electrical hazards.
PROTECTING THE LCD SCREEN
The screen can be damaged if it is not maintained
properly. Do not use hard objects such as hard
cloth or paper. Do not use excessive pressure
when cleaning the screen; excessive pressure can cause permanent discoloration or dark spots.
NEVER spray liquids on the
screen.
HANDLING PRECAUTIONS
• Handle by the cabinet only. Never touch the
screen when handling.
• Excessive pressure on the screen can cause
permanent discoloration or dark spots.
• Handling damage is not covered under warranty.
SPECIFICATIONS
Power Requirement: Source: AC 120V, 60Hz
AC Power Consumption (average): 50 watts
CONTAINS MERCURY LAMPS,
DISPOSE OF PROPERLY
4
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . 2
FCC INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
PROTECTING THE LCD SCREEN . . . . . . . . . . . . . . . . . . . . . .3
PRECAUTIONS—
Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
VIEWING ANGLES (BRIGHTNESS) . . . . . . . . . . . . . . . . . . .4
DETACHING THE TV TILT STAND . . . . . . . . . . . . . . . . . . . .4
GETTING STARTED—
Remote Control Battery Installation . . . . . . . . . . . . . . . .5
Antenna Connections for off-air or cable . . . . . . . . . . .5
Controls and Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Analog Signal / Stereo Audio Out . . . . . . . . . . . . . . . . . 6
Digital Signal / Digital Audio Out . . . . . . . . . . . . . . . . . .6
Power Connection / Initial Channel Search . . . . . . . . .7
PC CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
PC Menu Navigation Map . . . . . . . . . . . . . . . . . . . . . . . .8
PC MONITOR OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . .8
PC Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
PC Monitor Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
PC Menu Operating Tips . . . . . . . . . . . . . . . . . . . . . . . . .8
Manual Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
REMOTE CONTROL OPERATION . . . . . . . . . . . . . . . . . . . . .9
ON-SCREEN MENU OPERATION—
Menu Navigation Map . . . . . . . . . . . . . . . . . . . . . . . . . .10
Manual Channel Search . . . . . . . . . . . . . . . . . . . . . . . .10
Channel Scan Memory . . . . . . . . . . . . . . . . . . . . . . . . . .11
Adding Channels to Scan Memory . . . . . . . . . . . . .11
Deleting Channels from Scan Memory . . . . . . . . . .11
V-Guide (Parental Control)
V-Guide Operation . . . . . . . . . . . . . . . . . . . . . . . . . . .12
V-Guide Operation (Advanced) . . . . . . . . . . . . . . . .13
Picture / Sound Adjustment
Adjusting the Picture / Sound Manually . . . . . . . . .14
Advanced Picture / Sound Adjustments . . . . . . . . .14
Digital Captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Energy (Power) Saver . . . . . . . . . . . . . . . . . . . . . . . . . . .14
HELPFUL HINTS (PROBLEMS/SOLUTIONS) . . . . . . . . . .15
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
DETACHING THE HDTV TILT STAND
Tools Needed: Phillips screwdriver
Important Note: Place HDTV face down on a
padded or cushioned surface to protect the
screen and finish.
1
Remove the two (2) screws from the metal
bracket. CAUTION: Hold the stand firmly as
you remove the last screw.
VIEWING ANGLES (BRIGHTNESS)
ADJUSTING THE ANGLE
NOTE: Use the Tilt feature to
adjust the vertical angle
for optimum viewing.
DIMENSIONS
Width: 18.9 in.
Height: 15.1 in.
Depth: 7.2 in.
Vertical
Horizontal
WALL MOUNTING: VESA standard interface
(100 x 100)
Use the four (4) screws that are threaded into the
wall mounting inserts on the back of your HDTV
to secure it to a wall mounting kit.
NOTE: Wall Mounting kit is not supplied.
LCD Mounting screws measurements:
M4 Diameter, Length—10mm (maximum)
NOTE: The picture may appear too dark when
viewed outside normal viewing angles.
5
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
GETTING STARTED—
BATTERY INSTALLATION
Install batteries in the remote control
(2 ”AA”, not included).
PRECAUTIONS
To ensure safe operation, please
observe the following precautions:
Replace both batteries at the same
time. Do not use a new battery with a
used battery.
There’s a risk of explosion if a battery is
replaced by an incorrect type.
Do not expose the Remote Control Unit to
moisture or heat.
Match the “+” and “–” signs on the
batteries with marks inside the
remote control.
THE TUNER IN THIS HDTV CAN RECEIVE :
a. Digital and Analog off-air signals from an
antenna.
OR
b. Analog or ClearQAM cable channels from a
direct Cable TV connection.
NOTES: You must use the on-screen MENU to Search
for ClearQAM Cable channels. (See page 10.)
For the best picture, connect your Cable box
or Satellite receiver to the Video1, 2, or 3
Input jacks.
This HDTV can receive ANY unscrambled RF
signal being broadcast.
ANTENNA
CABLE
OR
ANALOG / DIGITAL
ANTENNA IN
ANTENNA CONNECTION FOR
OFF-AIR SIGNALS OR CABLE
LEFT-SIDE PANEL
RIGHT-SIDE
PANEL
S-Video Input (VIDEO1)
Digital Audio Output (Coaxial)
AV Input (VIDEO1 - Composite)
Component Video Input (VIDEO2 or VIDEO3)
Stereo Audio Out (L/R) Jacks
PC Input and Stereo Audio (Mini)
• MONITOR RGB (D-SUB)
• AUDIO R/L (Stereo Mini Jack)
Analog / Digital Antenna Input
CONTROLS AND JACKS
Volume
– + keys
Power
key
Channel
keys
6
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
1
Analog Signal Connections—
Video1 (optional)
Connect an analog device, such as, an Analog
Cable Box, Satellite Receiver, or VCR
Composite connectors are included on your
new HDTV to provide continued compatibility
with older analog devices, such as a VCR. The
S-Video connector will provide the best analog
resolution. If you have an S-Video connector
on your old analog equipment, you should use
it instead of the standard video connector.
(Cables are not supplied.)
1. Connect an AV cable to the VIDEO 1 jacks on
the HDTV and to your analog AV equipment,
as shown. Match the connector colors to
jack colors.
2. Press the INPUT key to step through the
signal inputs to select Video 1.
STEREO AUDIO OUT JACKS (OPTIONAL STEP)
FIXED ANALOG
1A
Connect the Stereo Audio Out jacks to
a stereo amplifier, as shown.
NOTE:Do not connect external speakers directly to
the Stereo Audio out jacks.
ANALOG DEVICE
2
Digital Signal Connections—
Video2 & Video3 (optional)
Connect digital devices, such as, an HD Cable
Box, HD Satellite Receiver and/or DVD Player
The Component jacks on this HDTV will accept
various HDTV video signals, making Component
a great choice for picture quality and resolution.
1. Connect a Component cable to a set of
Green, Blue, and Red video jacks (Video2 or
Video3) on the HDTV and to your digital
device, as shown. (Cable is not supplied.)
2. Connect an Audio cable to the matching set
of White and Red audio jacks, as shown.
(Cable is not supplied.)
3. Press the INPUT key to step through the
signal inputs to select Video 2 or Video 3.
DIGITAL AUDIO OUT JACK (OPTIONAL STEP)
2A
Connect the Digital Audio output to a
multichannel receiver, as shown.
NOTE:Dolby®Digital 5.1 audio is available at the
Digital Audio Output only when received as
part of a Digital Antenna signal being viewed
on the screen.
DVD PLAYER OR
SIMILAR DEVICE
GETTING STARTED—CONNECTIONS
STEREO AMP
MULTICHANNEL
RECEIVER
7
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
POWER CONNECTION
3
Plug in AC power cord
(120V AC, 60 Hz).
4
Press the POWER key.
(Follow the on-screen
instructions.)
To 120V AC outlet
INITIAL CHANNEL SEARCH
5
Press the CHANNEL (Up) key to search
for signals connected to the Antenna
terminal (Initial Display).
Channel Search will check for Antenna and
Cable signals. If Antenna signals are detected,
the HDTV searches for both analog and digital
off-air channels. If Cable signals are detected,
the HDTV will search for analog Cable channels.
Channels are stored in Channel Memory and
can be scanned using the CHANNEL (Up)
and (Down) keys.
If no Antenna signals are detected, the HDTV
will begin an AV search.
If neither of these searches detected a valid
signal, the HDTV will tune to input Video1.
INITIAL DISPLAY
AV SEARCH
NOTE:Be sure all the external video devices you con-
nected to the HDTV are powered ON before
you begin an AV Search.
6
Press the CHANNEL (Down) key to
search for signals from devices you connected to the AV input jacks (Initial Display).
AV Search will begin checking the AV inputs for
valid signals, beginning with input Video1.
When a valid signal is detected, the search
process ends and the HDTV tunes to that input
source.
If a valid signal is not detected on any of the AV
inputs, the HDTV will tune to input Video1.
CHANNEL SEARCH DISPLAY
AV SIGNAL SEARCH DISPLAY
GETTING STARTED—POWER CONNECTION / CHANNEL SEARCH
8
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
PC CONNECTIONS
PC MONITOR OPERATION
PC PREPARATION
To avoid an “Out of Range” condition, preset
your PC’s output resolution to an XGA value, such
as, 1024 x 768, before you disconnect it from your
regular monitor.
PC MONITOR SETUP
The Frequency, Resolution, Dot Clock, Phase,
Horizontal Position, and Vertical Position are set
automatically when Auto Adjustment is selected.
PC MENU OPERATING TIPS
Picture and Sound settings in the PC Menu do not
affect other input settings.
Press RESET twice to reset ALL settings to factory
defaults. (See page 9.)
MANUAL ADJUSTMENTS
Color Temp.—Press ENTER to choose setting.
Dot Clock—Dot Clock adjusts the Dot frequency
to match your computer’s dot frequency.
Phase—Adjust the Phase when the picture
appears to flicker or is blurred.
H–Position—Moves the image horizontally.
V–Position—Moves the image vertically.
Power Saving—When the HDTV no longer detects
H- and V-sync signals from the PC, it switches to
standby mode. It will return to normal operation
when H- and V-sync signals are again detected.
Reset PC Settings—Resets all the PC Menu
options to Factory default values.
NOTE: Before connecting any cables, disconnect
the AC Power Cords of both the HDTV and
Personal Computer from the AC outlets.
1
Connect an RGB cable from the monitor output on your PC to the RGB connector on the
HDTV and tighten the screws. (Monitor Cable
not supplied.)
2
Insert one end of a Stereo Mini-Audio cable
into the PC Audio Out jack and the other end
into the HDTV PC Audio Input jack. (Stereo
Mini-Audio Cable not supplied.)
HINT: Volume can be adjusted both from the PC and
the HDTV
VOLUME and keys.
3
Select Auto Adjustment from the PC Setup
Menu.
NOTE: Power on the HDTV and any other peripheral equipment before powering on the computer.
PC MENU NAVIGATION MAP
9
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
Audio Key—Press to select the desired audio
mode, if available.
Sleep Key—Press SLEEP then “0” to set the
Off Timer. Off time can be set in 30-minute
increments up to 3 hours.
NOTE:The Off Timer cancels if the TV is turned off or if
a power failure occurs.
Caption Key—Press to select mode options:
Digital CC1 ~ CC6, or Analog CC1 ~ CC4,
QuikCap, or OFF. (QuikCap turns captions on
or off with the Mute function.) Digital
Captions can be changed using the menu
settings.
Volume Keys—Press VOL – + to decrease or
increase the audio volume.
Mute Key—Press to mute or restore the sound.
1– – Key—For Cable channels above 99, press
this key, then press the other two numbers.
REMOTE CONTROL OPERATION
PIX Shape Key—Press to choose between
options Pix1 ~ Pix4. Available options depend
on the signal and the broadcast’s aspect ratio.
Input Key—Press to select the source to
view: Analog RF, Digital RF, Video 1, Video 2,
Video 3, or PC Input.
Info Key—Press to display Channel Banner
information.
Digital Antenna Banner may contain: Tuner
ID, Channel Number, Station ID, Program
Rating, Signal Strength, Detailed Program
Info, Audio Information, & Program Title.
Analog Antenna Banner may contain: Tuner
ID, Channel Number, Station ID, Program
Rating, & Audio Information.
Cable Banner may contain: Tuner ID,
Channel Number, Station ID (analog only),
Program Rating, Signal Strength, & Audio
Information.
Reset Key—Press this key twice to restore factory settings. The TV will automatically start
Channel Search and clear customized settings.
NOTE:The Channel Scan Memory database will be
replaced.
Number Keys—Press two keys to select a
channel. Example: Press 0 then 6 to select
channel 6. (See #14.)
Channel Scanning (CH ) Keys—Press to
scan through the channels in memory.
Recall Key—Press to switch between the last
two channels selected.
Menu Navigational Keys:
Menu—Press to display on-screen menu.
Cursor (up) (down) keys—Press these
keys to move the cursor up and down.
Cursor < (left) > (right) keys—Press these
keys to move the cursor left and right.
Enter Key—Press to select an option from
the menu system, when required.
Exit Key—Press to exit from the menu.
12
13
11
14
Point
towards TV
11
12
13
14
10
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
IMPORTANT FACT: This HDTV maintains only one database of digital channels. Therefore, when you search for
cable channels, the database of antenna digital channels
will be deleted. You will only be able to receive those
ClearQAM channels your cable company provides.
ON-SCREEN MENU OPERATION
MANUAL CHANNEL SEARCH
MANUAL CHANNEL SEARCH HAS THREE CATEGORIES
• Cable • Air(Antenna) • Digital Add-On
Cable Search looks for analog cable channels and
unscrambled (ClearQAM) digital cable channels.
This search will take several minutes. After the
search is complete, the HDTV will tune to the lowest ClearQAM channel, if available. Otherwise, the
HDTV will tune to the lowest analog cable channel.
Air(Antenna) Search will search for analog and
digital channels that are broadcast over-the-air.
After the search is complete, the HDTV will tune to
the lowest Digital channel or the lowest analog
channel. If no digital or analog channels are
found, the HDTV will tune to Video 1.
Digital Add-On Search will add new digital channels that are found to the Channel Scan Database.
1
Press the MENU key on the remote control to
display the Main menu. (See page 9.)
2
Use the CURSOR keys to highlight
Manual Channel Search. Press ENTER.
3
Use the CURSOR keys to select Cable,
Air (Antenna), or Digital Add-On.
After the search is complete, the HDTV will exit the
menu system and return to normal TV viewing.
MENU NAVIGATION MAP
MAIN MENU SUB-MENU OPTIONS
NOTE:“Not available” will appear on the screen
when an option is unavailable.
TUNING MODE UNAVAILABLE MENU OPTION(S)
Analog RF Digital Caption
Digital RF None (all Menu options available)
Video 1 Manual Channel Search, Channel Scan
Memory, Digital Caption
Video 2/3 Manual Channel Search, Channel Scan
Memory, Digital Caption, V-Guide
NOTE: For information on local digital channels,
visit www.antennaweb.org.
11
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
DELETING CHANNELS FROM SCAN MEMORY
3
Use the CHANNEL or NUMBER keys to
select the channel you want to Delete.
NOTE: Use the 1– – key to select cable channels
above 99.
4
Press ENTER to Delete the channel from
Channel Scan Memory.
5
Press EXIT to return to normal TV viewing.
(Menu operations continued on page 12.)
IMPORTANT FACTS: When a digital channel is deleted, all of that channel’s sub-channels are deleted as
well. Only previously deleted digital channels can be
added back to the Channel Scan Memory.
Tune to “deleted” channels using the number keys. If
one digital sub-channel is added back to the Channel
Scan Memory list, all of that channel’s sub-channels
will be added back.
This Display
appears after
you press
ENTER.
After 3 seconds the TV screen will display “Delete?”
After 3 seconds the TV screen will display “Add?”
CHANNEL SCAN MEMORY
Channel Scan Memory is a database of active
channels you scan through using the CHANNEL
keys. Customize it by deleting or adding
channels.
1
Press the MENU key on the remote control to
display the Main menu. (See page 9.)
2
Use the CURSOR keys to highlight
Channel Scan Memory. Press ENTER.
ADDING CHANNELS TO SCAN MEMORY
3
Use the NUMBER keys to select the channel
you want to Add.
NOTE: Use the 1– – key to select cable channels
above 99.
4
Press ENTER to Add the channel to Channel
Scan Memory.
This Display
appears after
you press
ENTER.
Channel Scan
Memory Screens
12
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
STANDARD V-GUIDE RATINGS—AT-A-GLANCE
MPAA (Movie) RATING
BLOCKED RATINGS
(Lock symbol)
TV RATING
CONTENT RATING
V-GUIDE (PARENTAL CONTROL)
NOTE: THIS FEATURE IS DESIGNED TO COMPLY
WITH THE UNITED STATES OF AMERICA’S FCC
V-CHIP REGULATIONS. THEREFORE, IT MAY
NOT FUNCTION WITH BROADCASTS THAT
ORIGINATE IN OTHER COUNTRIES.
This Sanyo television is equipped with an electronic V-Chip to interpret MPAA (Motion Picture
Association of America) and TV Parental
Guidelines rating codes. When these codes are
detected, the HDTV will automatically display or
block the program, depending upon choices you
make when setting up the V-Guide system.
Use this feature to block automatically programs
with content you deem as inappropriate for your
children to view.
MORE INFORMATION
Additional information about MPAA and V-Chip
rating can be found at: www.mpaa.org and
www.v-chip.org, respectively.
V-GUIDE OPERATION
1
Use the CURSOR keys to highlight
V-Guide in the Main menu. Press ENTER.
2
Use the CURSOR keys to highlight On,
in the V-Guide menu. Press ENTER.
3
Use the CURSOR keys to highlight
Adjust. Press ENTER.
4
Use the CURSOR and < > keys to select
MOVIE, TV, or Content Ratings. (A green
square will appear beside the selected item.)
NOTE:Content ratings are under the letters FV, D, L,
S, and V.
5
Press the ENTER key to Block or Unblock
selected rating. A lock symbol will appear
beside the selected rating option indicating
that it is blocked
.
OPERATING TIPS
V-Guide settings are effective for Analog chan-
nels, Digital channels, and Video1 signals.
You can block portions of a TV rating by
choosing one or more of the Content ratings
(D, L, S, and V). By blocking just the L and S
content ratings of TV-14, for example, TV-14
rated programs with a D and/or V content rating could still be viewed.
ON-SCREEN MENU OPERATION (CONTINUED)
13
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
REGIONAL V-GUIDE OPERATION (ADVANCED)
V-Chip Regional Ratings 5 (RRT5) is an advanced
V-Chip ratings system for digital channels that
are received with an antenna. Your new Sanyo
HDTV supports this alternative system.
When the HDTV detects compatible RRT5 data, it
is downloaded and stored in memory and the
menu is modified to include an advanced adjustment option.
When the Adjust (Advanced) setup option is
selected the Advanced Rating screen appears.
1
Use the CURSOR keys to highlight
V-Guide in the Main menu. Press ENTER.
2
Use the CURSOR keys to highlight On,
in the V-Guide control menu. Press ENTER.
3
Use the CURSOR keys to highlight
Adjust (Advanced). Press ENTER.
4
Use the CURSOR and < > keys to select
a rating.
HINT: There may be more ratings than can be displayed
on one screen. When vertical scroll bars appear,
use the
CURSOR
keys to gain access to the
additional ratings.
5
Press the ENTER key to Block or Unblock
selected rating. A Lock symbol will appear
beside the selected rating option indicating
that it is blocked.
The advanced rating table will reflect previous
choices you may have made.
NOTE:If the HDTV is reset to factory defaults or if a
Manual Cable Search is performed, only the
Adjust option will appear in the menu. The
Adjust (Advanced) option will reappear when the
HDTV again detects RRT5 data.
The V-Guide ratings screen below is just an
example. Actual rating options will vary by
region. For example, the RRT5 ratings for San
Francisco, California may differ from those in
Little Rock, Arkansas.
14
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
ENERGY (POWER) SAVER
This power saving feature reduces the backlight
brightness level. The options are:
• OFF—the feature is off and the power con-
sumption is normal.
• LOW—power saving level is low and the back-
light brightness level is lower than normal.
• HIGH—power saving level is high and the back-
light brightness is set to the lowest level.
1
Use the CURSOR keys to highlight
Energy Saver. Press ENTER.
2
Use the CURSOR keys to select Off, Low,
or High.
NOTE: The Energy Saver settings level varies with the
Picture/Sound mode.
DIGITAL CAPTIONING
Captioning is textual information that may be
transmitted with the picture and sound. Digital
Captions can be changed using the menu settings.
1
Use the CURSOR keys to highlight
Digital Caption. Press ENTER.
2
Use the CURSOR keys to select an option
and the CURSOR
< > to adjust the value.
PICTURE / SOUND ADJUSTMENT
Choose Auto to accept predetermined values for
each parameter or choose Manual to adjust
Picture / Sound values to your preferences.
ADJUSTING THE PICTURE / SOUND MANUALLY
1
Use the CURSOR keys to highlight
Picture / Sound. Press ENTER.
2
Use the CURSOR keys to highlight
Manual. Press ENTER.
3
Use the CURSOR keys to highlight Color,
Tint, Contrast, Brightness, Sharpness, or Tone.
4
Use the CURSOR < > keys to adjust the levels.
ADVANCED PICTURE / SOUND ADJUSTMENTS
5
To change the Digital Noise Reduction,
Dynamic Contrast, or Loud Sound Suppressor
settings, press the right CURSOR (
>) key,
select On or Off and press ENTER.
6
Press EXIT to return to normal TV viewing.
ON-SCREEN MENU OPERATION (CONTINUED)
15
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
HELPFUL HINTS—Problems/Solutions
If you are having problems with your HDTV,
check this trouble shooting chart to find one or
more possible solutions.
Before returning your HDTV, please visit our
website at www.sanyoctv.com or call us
toll free at
1.800.877.5032.
We can Help!
Problem: Check these Conditions: Try these Solutions: Page No.
No picture, sound
(Digital Picture)
Check antenna/external connections
May be station trouble, NO signal
broadcast.
MUTE function may be ON.
Adjust antenna.
Try a different channel.
Press RESET twice to restart channel
search. (All customized settings will be
cancelled.)
Adjust Volume.
5 ~ 9
No Captioning
Check if station is broadcasting a
Closed-Caption signal.
Select another channel.
Press CAPTION to select
captioning mode.
9, 14
Cannot customize
Caption
Digital Caption signal is not being
broadcast.
Press CAPTION to select Analog
captioning.
9, 14
Cannot display picture on a full screen
Press PIX SHAPE to change setting.
9
Poor Picture/Sound
(watching Analog)
Check if program is in color.
Check antenna/external connections.
Color or Tint misadjusted.
May be station trouble.
Maybe MUTE function is ON.
Try a different channel.
Adjust antenna.
Press RESET twice to restart channel
search.
Adjust Volume and/or Image.
9
“No Signal”
message appears on
screen
Check Audio / Video connections.
Check external equipment
connections.
Check external equipment setting.
Check antenna connection.
Press INPUT.
Switch on external equipment.
Turn antenna, install signal booster.
Set external equipment output connections to match input connections.
5 ~ 9
Pixilation of Digital
Press INFO and check signal
strength.
Turn antenna, install signal booster.
Install outdoor Digital antenna.
5, 9
Cannot select or
scan some channels
Channel may be removed from memory.
Check antenna connections.
No digital signal being broadcast.
V-Guide is set to block programming.
Weak Signal.
Select Channel Scan Memory to add
channels or start channel search.
Set V-Guide to “ALLOW ALL” or press
RESET twice to clear all settings and
restart channel search.
Turn antenna, install signal booster.
5,
9 ~ 11
No Cable channels
above number 13
Cable Channel Indicator C should
appear next to channel number.
Search for Cable channels using Manual
Channel Search.
10
Remote Control
will not operate TV
Check batteries.
Check if TV is plugged in.
Replace batteries.
Aim remote control at front of TV.
5, 7, 9
Cabinet makes popping sound.
This is a normal condition during
warm-up and cool down of the plastic
cabinet parts.
Loading...
