Rotel RB-981 User Manual

POWER

RB-981

STEREO POWER AMPLIFIER

AMPLIFICATEUR DE PUISSANCE STÉRÉO

STEREO-ENDSTUFE

FINALE DI POTENZA STEREO

ETAPA DE POTENCIA ESTEREOFONICA

POWER AMPLIFIER RB-981

PROTECTION BRIDGED MONO

Owner’s Manual

Guide d’utilisation

Bedienungsanleitung

Manuale di Istruzioni

Manual de Instrucciones

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

APPLICABLE FOR USA, CANADA OR WHERE
APPROVED FOR THE USAGE

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT. INSERT FULLY.

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU AU FOND.

WARNING:
There are no user serviceable parts inside. Refer all servicing to
qualified service personnel.

WARNING:
To reduce the risk of fire or electrical shock, do not expose the unit
to moisture or water. Do not allow foreign objects to get into the
enclosure. If the unit is exposed to moisture, or a foreign object
gets into the enclosure, immediately disconnect the power cord
from the wall. Take the unit to a qualified service person for in­spection and necessary repairs.

Read all the instructions before connecting or operating the unit. Keep this
manual so you can refer to these safety instructions.

Heed all warnings and safety information in these instructions and on the
product itself. Follow all operating instructions.

Clean the unit only with a dry cloth or a vacuum cleaner.

This symbol is to alert the user to the
presence of uninsulated dangerous
voltages inside the product's enclosure
that may constitute a risk of electric shock.

This symbol is to alert the user to important
operating and maintenance (service)
instructions in this manual and literature
accompanying the product.

Keep the ventilation inlets on the unit unobstructed. For example, do not place
the unit on a bed, sofa, rug, or similar surface that could block the ventilation
slots. If the unit is placed in a bookcase or cabinet, there must be sufficient
clearance around the unit and ventilation of the cabinet to allow proper cooling.

Keep the unit away from radiators, heat registers, stoves, or any other
appliance that produces heat.

The unit must be connected to a power supply only of the type and voltage
specified on the rear panel of the unit.

Connect the unit to the power outlet only with the supplied 2-pin polarized
power supply cable or an exact equivalent. Do not modify the supplied cable in
any way. Do not attempt to defeat grounding and/or polarization provisions. The
cable should be connected to a 2-pin polarized wall outlet, matching the wide
blade of the plug to the wide slot of the receptacle. Do not use extension cords.

Do not route the power cord where it will be crushed, pinched, bent at severe
angles, exposed to heat, or damaged in any way. Pay particular attention to the
power cord at the plug and where it exits the back of the unit.

The power cord should be unplugged from the wall outlet if the unit is to be left
unused for a long period of time.

Immediately stop using the unit and have it inspected and/or serviced by a
qualified service agency if:

• The power supply cord or plug has been damaged.

• Objects have fallen, or liquid has been spilled, into the unit.

• The unit has been exposed to rain.

• The unit shows signs of improper operation

• The unit has been dropped or damaged in any way

Place the unit on a fixed, level surface strong
enough to support its weight. Do not place the
unit on a moveable cart that could tip over.

Figure 1: Controls and Connections

Commandes et prises
Bedienelemente und Anschlüsse
Controlli e collegamenti
Controles y Conexiones

POWER AMPLIFIER RB-981

POWER

PROTECTION BRIDGED MONO

STEREO POWER AMPLIFIER RB-981

1 2 3

4

WARNING:TO REDUCE THE RISK OF FIRE

OR ELECTRICAL SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE.

SPEAKER IMPEDANCE

STEREO 4 OHMS MINIMUM
BRIDGED 8 OHMS MINIMUM

SPEAKERS

LEFTRIGHT

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

AVIS: RISQUE DE CHOC ELECTRIQUE–NE PAS OUVRIR

LEFT INPUTRIGHT INPUT

POWER AMPLIFIER

MODEL NO. RB-981

POWER CONSUMPTION: 400W

SERIAL NO.

5

6

5

7
