Rockwell Automation FactoryTalk Batch Components Installation Manual

Installation and Upgrade Guide

FactoryTalk Batch Components Installation and Upgrade Guide

FactoryTalk

Batch Components 14.00

Rockwell Automation Publication BATCH-IN002C-EN-D - October 2020 Supersedes Publication BATCH-IN002B-EN-D - November 2018

Original Instructions

FactoryTalk Batch Components Installation and Upgrade Guide

personal injury or death, property damage, or economic loss.

Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss.

Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.

IMPORTANT

Identifies information that is critical for successful application and understanding of the product.

Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may reach dangerous

temperatures.

Labels may be on or inside the equipment, for example, a motor control center, to alert people to potential Arc Flash. Arc Flash

for Personal Protective Equipment (PPE).

Important User Information

Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards.

Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required to be carried out by suitably trained personnel in accordance with applicable code of practice.

If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.

In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.

The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for actual use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software described in this manual.

Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is prohibited.

Throughout this manual, when necessary, we use notes to make you aware of safety considerations.

WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment, which may lead to

ATTENTION:

Labels may also be on or inside the equipment to provide specific precautions.

SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous voltage may be present.

BURN HAZARD:

ARC FLASH HAZARD:

will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL Regulatory requirements for safe work practices and

Preface

FactoryTalk Batch system

Pre-installation administrative

Install FactoryTalk Batch

overview

tasks

About this manual 7 Legal Notices 7

Additional resources 8

Chapter 1

Server placement guidelines 14 FactoryTalk Batch View 14

Installation information about FactoryTalk Batch View 15 System requirements and supported software overview 15 Select installation instructions for each computer 18

Chapter 2

Obtain administrator privileges on target computer 21 Prepare the operating system 21

Windows configuration requirements 22

Configure the Windows Server operating system 22

Configure the Windows desktop operating system 23

DEP settings 24 Create users and user groups 24 Update Windows Firewall settings 25

Windows Firewall exceptions 26 Configure the Remote Registry service 27 Set the system date and time 27 Prepare the SQL Server installation 27

Install Reporting Services for SQL Server 2017 28

Configure Reporting Services for SQL Server 2012 or SQL Server

2014 29

Configure SQL Server 2016 for reporting services 30

Configure Reporting Services for SQL Server 2017 31

Configure Windows Firewall for FactoryTalk Event Archiver 32

Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Chapter 3

Install the FactoryTalk Batch components 36

FactoryTalk Updater 39

Modify an installation 39

Post-installation tasks for FactoryTalk Batch components 40

Configure the FactoryTalk network directory 41

Configure SQL Server 2017 to enable FactoryTalk Event Archiver

with Reporting Services 41

Table of Contents

Install FactoryTalk Batch Client

Install FactoryTalk Batch

FactoryTalk Activation

Upgrade FactoryTalk Batch

Configure SQL Server 2014 or SQL Server 2016 to enable

FactoryTalk Event Archiver with Reporting Services 43

Configure SQL Server 2012 to enable FactoryTalk Event Archiver

with Reporting Services 43

Grant access to the FactoryTalk Batch directory on the SQL Server

computer 44

Add a server to the FactoryTalk Batch system 44

Event log settings 45

Create a shared directory 45

Define redundant servers (optional) 46

Configure server options 47

Set security on logs and journals folders 48

Configure browser compatibility view settings 49

Chapter 4

Install the FactoryTalk Batch Client 52

components

Material Manager Server components

Material Manager Client components

Chapter 5

Install the FactoryTalk Batch Material Manager Server 54 Post-installation for FactoryTalk Batch Material Manager Server 55

Identify the material database 55

Chapter 6

Install the FactoryTalk Batch Material Manager Client components 57

Chapter 7

Cumulative unit licensing 60

Chapter 8

Pre-upgrade tasks for FactoryTalk Batch 61

Allow the Message Queue to clear for FactoryTalk Batch Material

Manager 62

Export XML or RDB recipes to binary 62

Back up files 62

Uninstall a previous version of FactoryTalk Batch 64 Upgrade the FactoryTalk Batch components 64 Post-upgrade tasks 65

Restore backup files 65

Migrate area models from FactoryTalk Batch version 13.00 or

13.00.02 67

Migrate recipes from FactoryTalk Batch version 13.00 or 13.00.02 67

Troubleshoot FactoryTalk Batch

installation or upgrade

Use FactoryTalk Batch with a

Install FactoryTalk eProcedure

Uninstall FactoryTalk Batch version 14.00

Index

Windows Workgroup

Table of Contents

Convert binary recipes to XML or RDB 68

Convert migrated recipes back to XML format 68 Convert migrated recipes back to RDB format 69

Configure recipe storage 69

Chapter 9

Manually configure the Windows Firewall 71 Define or reset a disabled FactoryTalk Administrator account 72

Communication with FactoryTalk Batch Server times out 72 Configure Internet Explorer security settings for Trusted Sites 73 Internet Explorer intranet zone 73 Run as Administrator on eProcedure Client on Windows Server operating systems 73 Manually recreate the masterrecipes database 74

Appendix A

Windows Workgroup 75

Create Windows accounts 75 Add an incoming firewall rule 75 Disable Administrative Approval Mode 76

Client components

Appendix B

Install the FactoryTalk eProcedure Client 78

Post-FactoryTalk eProcedure Client component installation 79

Set the Internet Explorer home page for FactoryTalk eProcedure Clients 79 Configure Internet Explorer to view FactoryTalk eProcedure pages 79

Configure Internet Explorer compatibility view settings 80

Select Windows theme in Windows 7 81

Appendix C

Uninstall the FactoryTalk Batch system 83

Uninstall the FactoryTalk Batch components 83

Uninstall FactoryTalk Batch Material Manager 84 Delete the default directories 84 Delete databases 85

About this manual

Legal Notices

Preface

This guide provides information and procedures for installing and upgrading

a FactoryTalk®

• FactoryTalk Batch

• FactoryTalk eProcedure®

• FactoryTalk® Event Archiver Database, with Batch Reports and

Database Management Tool

• FactoryTalk Batch Material Manager

• FactoryTalk® Batch View

This guide is organized into a conceptual overview of a FactoryTalk Batch system that includes information about pre-installation administrative tasks, followed by installation and post-installation procedures for the different system components.

Readers should be familiar with installing Windows applications and configuring operating system options.

Before starting installation or upgrade of FactoryTalk Batch components, review FactoryTalk Batch release notes and product compatibility information at the Product Compatibility and Download Center (PCDC)

Batch system, which includes:

Rockwell Automation publishes legal notices, such as privacy policies, license

agreements, trademark disclosures, and other terms and conditions on the

Legal Notices

page of the Rockwell Automation website.

End User License Agreement (EULA)

You can view the Rockwell Automation End User License Agreement (EULA) by opening the license.rtf file located in your product's install folder on your hard drive.

The default location of this file is:

C:\Program Files (x86)\Common Files\Rockwell\license.rtf

Open Source Software Licenses

The software included in this product contains copyrighted software that is licensed under one or more open source licenses.

You can view a full list of all open source software used in this product and their corresponding licenses by opening the oss_license.txt file located your product's OPENSOURCE folder on your hard drive. This file is divided into these sections:

Preface

Resource

Description

FactoryTalk Batch Components Installation and

Provides information and procedures for FactoryTalk

Server components.

Additional resources

• Components Includes the name of the open source component, its version number, and the type of license.

• Copyright Text Includes the name of the open source component, its version number, and the copyright declaration.

• Licenses Includes the name of the license, the list of open source components citing the license, and the terms of the license.

The default location of this file is:

C:\Program Files (x86)\Common Files\Rockwell\Help\<product name>\Release Notes\OPENSOURCE\oss_licenses.txt

You may obtain Corresponding Source code for open source packages included in this product from their respective project web site(s). Alternatively, you may obtain complete Corresponding Source code by contacting Rockwell Automation via the Contact form on the Rockwell Automation website:

http://www.rockwellautomation.com/global/aboutus/contact/contact.page. Please include "Open Source" as part of the request

text.

Following is a comprehensive list of documentation for the FactoryTalk® Batch products from Rockwell Automation.

Installation, Quick Start, and Getting Results Guides

Upgrade Guide (BATCH-IN002)

FactoryTalk Batch View Quick Start Guide (FTBVS-QS001)

FactoryTalk Batch View HMI Controls Quick Start Guide

(BATCH-QS001D)

Batch system installation. Includes information for FactoryTalk Batch Material Manager, FactoryTalk Event Archiver, and associated FactoryTalk Batch Client and

Provides information about using FactoryTalk Batch View to create, view, and command control recipes, acknowledge prompts and signatures, view equipment phases and diagnostic information, and view profile information.

Provides a general overview of FactoryTalk Batch View HMI Controls.

FactoryTalk Batch eProcedure® Getting Results Guide (BWEPRO-GR011)

FactoryTalk Batch Getting Results Guide (BATCH-GR011)

Explains the basics of FactoryTalk Batch eProcedure.

Introduces the basics of automated batch manufacturing and the FactoryTalk Batch product components.

Resource

Description

FactoryTalk Batch Material Manager Getting

(BWMTR-GR011)

Introduces the basics of FactoryTalk Batch Material

Resource

Description

reference for the formulator.

your Logix 5000 controller.

FactoryTalk Batch Server.

Preface

Results Guide

User Guides

FactoryTalk Batch ActiveX Controls User Guide (BATCH-UM013)

FactoryTalk Batch Material Editor User Guide (BWMTR-UM001)

FactoryTalk Batch Equipment Editor User Guide (BATCH-UM004)

FactoryTalk Batch PhaseManager™ User Guide (BATCHX-UM011)

Manager.

Provides information and instructions for using the FactoryTalk Batch ActiveX Custom Controls.

Provides access to information and procedural instructions required to configure materials and the containers to hold them. The material data is stored in the material database, which is used to create materialbased recipes. This information is intended as a

Provides information on creating and maintaining an equipment database (area model). The area model is stored in a file with a .cfg file extension and is available to all other FactoryTalk Batch programs, including the Recipe Editor, View, and Phase Simulator.

Describes the integration of the FactoryTalk Batch software with the Studio 5000 Logix Designer® application and the Logix 5000™ family of controllers. The integration simplifies the configuration and maintenance of the FactoryTalk Batch automation system, provides better communication between the FactoryTalk Batch Server and the Logix 5000 controller, and significantly reduces the programming effort required to develop the phase logic code that resides in

FactoryTalk Batch Recipe Editor User Guide (BATCH-UM006)

FactoryTalk Batch View HMI Controls User Manual (FTBVS-UM003)

FactoryTalk Batch View User Manual (FTBVS-UM002)

FactoryTalk eProcedure Client User Guide (BWEPRO-UM001)

Provides instructions on using FactoryTalk Batch Recipe Editor to create and configure master recipes for use in batch automation. The interface is based on IEC 61131-3 sequential function charts to graphically organize recipes into procedures, unit procedures, operations, and phases. Build recipes using either the SFC format or a table-based format.

Provides details about using FactoryTalk Batch View HMI Controls to monitor and interact with the production process within a FactoryTalk View SE Display Client.

Provides information and procedural instructions for using FactoryTalk Batch View in a modern and intuitive portal into a comprehensive batching solution for effective operations, leveraging its own web server using HTML5 technology to provide native connectivity into a

Provides information and procedural instructions required to create and command batches using the FactoryTalk eProcedure Client, and can be used as a reference information by the operator.

Preface

Resource

Description

FactoryTalk Event Archiver User Guide (BATCH-

Provides information and instructions specific to the

system administrator and production supervisor.

Resource

Description

operators, such as the FactoryTalk Batch Server.

Resource

Description

FactoryTalk Batch ActiveX Controls Library

(BATCH-RM001)

Provides reference information and procedural

those who want to develop custom interfaces.

UM012)

FactoryTalk Batch View User Guide (legacy) (FTBVS-UM001)

Administrator Guides

FactoryTalk Batch Administrator Guide (BATCH-UM003)

FactoryTalk Batch eProcedure Administrator Guide (BWEPRO-UM011)

FactoryTalk Event Archiver. Intended for use by the

Provides information and instructions on how to use FactoryTalk Batch View to initiate and execute FactoryTalk Batch automation processing. FactoryTalk Batch View secured objects are located in the FactoryTalk Diagnostics and are modified using the FactoryTalk Administration Console. A system administrator can customize FactoryTalk Batch View security to meet the needs of the facility. FactoryTalk Batch View is used in conjunction with a Human-Machine Interface (HMI).

Provides instructions for configuring security and services, and implementation and use of components not typically accessed or used by batch operators, such as the FactoryTalk Batch Server.

Provides procedures specific to FactoryTalk Batch eProcedure, such as implementing security and configuring the user-defined area Active Server Page. Included are instructions for tasks specific to FactoryTalk Batch, such as configuring security and services to support FactoryTalk Batch eProcedure. Provides instructions on the implementation and use of components not typically accessed or used by batch

FactoryTalk Batch Material Manager Administrator Guide

(BWEPRO-UM011)

Reference Guides

Reference Guide

FactoryTalk Batch Material Server API Technical Reference (BWMTR-RM001)

FactoryTalk Batch PCD Programming Reference Manual (BATCH-RM004)

Provides information and instructions specific to FactoryTalk Batch Material Manager. Intended for use by the system administrator and database administrator.

instructions for the FactoryTalk Batch ActiveX Custom Controls.

Provides access to information regarding the interface between the FactoryTalk Batch Material Server and the FactoryTalk Batch Material Editor and FactoryTalk Batch. It is intended to be used as a reference information by

Provides information and instructions about the FactoryTalk Batch PCD interface design. It is intended to be used as a reference guide.

Resource

Description

FactoryTalk Batch Server API Reference Manual

Provides information regarding the interface between the

Preface

(BATCH-RM003)

FactoryTalk Batch System Files Reference Manual (BATCH-RM005)

FactoryTalk Batch eProcedure Instruction File Design Reference Manual

(BWEPRO-RM001)

FactoryTalk Batch Server and FactoryTalk Batch View — the Server Application Programming Interface (API). It is intended to be used as a reference guide by those who want to develop custom interfaces.

Provides the technical information for configuration and maintenance of a FactoryTalk Batch system. It can be used as a reference information for implementation engineers and the system administrator.

Includes information about the building of instruction files for use in equipment database creation and recipe development. This information is intended to be used as a reference by the instruction file author.

View or download publications at

http://www.rockwellautomation.com/literature

. To order paper copies of technical documentation, contact your local Allen-Bradley® distributor or sales representative.

Site Level

eProcedure Clients

FactoryTalk Batch Material Manager

FactoryTalk Batch Server, eProcedure Server, and for Master Recipe Storage

Chapter 1

FactoryTalk Batch system overview

FactoryTalk Batch components are configurable products that help define, manage, monitor, and control manufacturing at local or remote sites. A typical FactoryTalk Batch architecture consists of one or more computers on a single network; there can be up to ten FactoryTalk Batch servers in a FactoryTalk Batch system that includes Material Manager. Review the application release notes, manuals, installation information for the FactoryTalk Batch components planned for your architecture before setting up the FactoryTalk Batch system.

This diagram illustrates an example of a FactoryTalk Batch network.

Clients FactoryTalk Batch Material Server

SQL Server FactoryTalk Batch Clients TCP/IP Plant Floor

FactoryTalk Batch View Server FactoryTalk Batch Server connects to SQL Server

FactoryTalk Batch Clients Proprietary Network Process-Connected Device (PCD) FactoryTalk Event Archiver Database

Chapter 1 FactoryTalk Batch system overview

FactoryTalk Batch Server.

Server placement FactoryTalk Batch View

Use these guidelines to decide where to place FactoryTalk Batch system servers on the network:

guidelines

• Install the eProcedure Server and the FactoryTalk Batch Server on the same computer.

Tip: The FactoryTalk Batch View Server is installed automatically with the

• Install the FactoryTalk Batch Material Manager Server on a computer with SQL Server.

• Do not install the FactoryTalk Batch Material Manager Server on the same computer as the FactoryTalk Batch Server.

• A maximum of ten FactoryTalk Batch Servers can exist in a FactoryTalk Batch network that includes FactoryTalk Batch Material Manager Server.

• Install the FactoryTalk Event Archiver Database and Management Tool on a computer with SQL Server.

• For best performance, install the FactoryTalk Event Archiver Database and Management Tool on a different computer than the FactoryTalk Batch Server.

FactoryTalk Batch View is a modern, browser-based interface that allows you

to initiate and control the batch process anywhere there is an internet connection. The FactoryTalk Batch View interface adapts across smartphones, such as iOS and Android, to tablets and PCs. Users can access real-time information and interact with their process from the plant floor to the production office.

FactoryTalk Batch View is well-suited for large industrial facilities that have workstation infrastructure limitations and require multiple access points across the plant. With personalized user profiles that are tailored to the user, such as language switching options, workers at different levels of the organization can stay mobile yet connected to their process operations.

Key capabilities of the solution include:

• A modern web interface offers adaptation to new or existing platforms and environments with backward compatibility to previous versions of FactoryTalk Batch software; single-server architecture allows for new features and functions to be added with minimal impact to operations.

• Information-enabled and secure. Uses common system security policies for access control similar to any workstation, as a node on the plant network.

• Interfaces support multiple mobile devices and are easily integrated with HMI screens onto workstations.

browsers such as Google Chrome or Microsoft Edge.

Installation information

about FactoryTalk Batch

System requirements and

The FactoryTalk Batch View Server is installed automatically with the FactoryTalk Batch Server. The FactoryTalk Batch View web client does not require any additional installation.

Chapter 1 FactoryTalk Batch system overview

View

Tip: FactoryTalk Batch View performs best with Chromium-based

If you are using a FactoryTalk View SE Display Client, install the FactoryTalk® Batch View HMI controls to provide an interface that allows users to monitor and interact with the production process. The FactoryTalk Batch View HMI controls consist of:

• BatchesList control: Creates control recipes, displays current control recipes, and commands a control recipe. In FactoryTalk View SE, maps to BatchViewHMI.BatchesList in the Insert an ActiveX Control dialog box and the Property Panel.

• PromptsList control: Displays a list of prompts that are waiting to be acknowledged, a list of electronic signatures associated with a batch that are waiting for signoff, and instructions waiting to be acknowledged. In FactoryTalk View SE, maps to BatchViewHMI.PromptsList in the Insert an ActiveX Control dialog box and the Property Panel.

• SFC control: Enables the ability to command batches during FactoryTalk View SE run-time on the Details and Summary pages of the SFC. In FactoryTalk View SE, maps to BatchViewHMI.SFC in the Insert an ActiveX Control dialog box and the Property Panel.

• Full control: Accesses the entire FactoryTalk Batch View site. In FactoryTalk View SE, maps to BatchViewHMI.FullView in the Insert an ActiveX Control dialog box and the Property Panel.

supported software overview

For more information about FactoryTalk Batch View, see the FactoryTalk Batch View online help.

Review these minimum and recommended system requirements for installing, configuring, and running FactoryTalk Batch components. Unless noted these requirements assume that no other applications are installed on the computer. Preferred operating systems and software applications are prioritized for support, testing, and post-release patch qualifications.

Hardware requirements

• Server requirements

• 8 GB of RAM memory

• 100 GB free hard disk space

• Intel® Core™ i5 standard power processor or greater

• Client requirements

Chapter 1 FactoryTalk Batch system overview

Supported operating systems

• 4 GB of RAM memory

• 30 GB free hard disk space

• Intel Core i5 standard power processor or greater

• Windows Server®

• Windows Server 2019 Standard Edition (preferred)

• Windows Server 2016 Standard Edition (preferred)

• Windows Server 2019 DataCenter Edition

• Windows Server 2016 DataCenter Edition

• Windows Server 2012 R2 Standard Edition or DataCenter

• Windows Server 2012 Standard Edition or DataCenter

• Windows®

• Windows 10 Professional (64-bit) Build 1909 or later (preferred)

• Windows 10 Enterprise (64-bit) Build 1909 or later

Supported database applications

(for storing recipes, materials, reports, and journal archives)

• SQL Server®

• SQL Server 2019 (English version only)

• SQL Server 2017 (English version only)

• SQL Server 2016 Service Pack 1 (English version only)

• SQL Server 2014 Service Pack 3 (32-bit and 64-bit, English version

only)

• SQL Server 2012 Service Pack 4 (32-bit and 64-bit, English version

only)

Web browsers

(for eProcedure Client only)

• Internet Explorer® 11(32-bit)

(for FactoryTalk Batch View only)

• Google® Chrome™ browser (preferred)

• Microsoft Edge™ based on Chromium version: 80.0.361.50 or higher

• Apple® Safari®

• Firefox®

Chapter 1 FactoryTalk Batch system overview

Logix firmware requirements

(for FactoryTalk Batch only)

• Firmware version 18 or later on ControlLogix 5570 and CompactLogix 5370 family of controllers – for integration of PhaseManager with FactoryTalk Batch

• Firmware version 32 or later on ControlLogix 5580 and CompactLogix 5380 family of controllers – for integration of PhaseManager with FactoryTalk Batch

• Firmware version 29 or later - for integration of SequenceManager with FactoryTalk Batch

Logix Designer requirements

(for FactoryTalk Batch only)

• Logix Designer version 18 or later - for synchronization of PhaseManager with FactoryTalk Batch Equipment Editor

FactoryTalk View SE requirements

(for integration of FactoryTalk Batch View HMI Controls and legacy FactoryTalk Batch ActiveX controls only)

• FactoryTalk View SE version 12.0 (preferred)

• FactoryTalk View SE version 11.0

FactoryTalk Services requirements

• FactoryTalk Services Platform version 6.20 (CPR 9 SR 12) or later

• FactoryTalk Linx version 6.20 (CPR 9 SR 12) or later

• FactoryTalk Activation Manager version 4.04 or later

Rockwell Automation Test Environment

Rockwell Automation tests software products under a standard configuration of operating systems and antivirus software. For additional information see the Knowledgebase Document ID:

Antivirus Software.

PN24 - Rockwell Software Products and

Chapter 1 FactoryTalk Batch system overview

IMPORTANT

Compatibility and Download Center (PCDC).

IMPORTANT

Select installation

Warranty

The warranty does not cover systems that do not meet the minimum requirements for the version of software.

FactoryTalk Batch components for version 14.00 support only the versions of operating systems. For more information about supported operating systems and other Rockwell Software product version support, refer to the

U.S. English

Product

• The FactoryTalk Batch Server computer cannot be configured as a:

• Domain controller

• DHCP server

• WINS server

• RAS server

• DNS server

• Master Browser

• The FactoryTalk Batch Server computer does not support replication.

• Install FactoryTalk Batch software on an NTFS formatted hard drive,

as Windows security features are available only for drives formatted to use NTFS.

• Warranty does not cover systems with modified DCOM configuration settings. Configuring settings using DCOMCNFG may stop the FactoryTalk Batch Server and prevent the FactoryTalk Batch Service Manager from functioning correctly.

FactoryTalk Batch version 14.00 components do not support touch screen technology.

instructions for each computer

After completing the pre-installation administrative tasks, follow the installation instructions for each computer in the system, or repeat the installation instructions for several computers based on your FactoryTalk Batch system configuration. For example, if the FactoryTalk Batch system

includes a FactoryTalk Batch Server and several FactoryTalk Batch Clients, determine which components to install on each computer. Each set of installation instructions includes a checklist of all related tasks and specific post-installation tasks for the component.

• Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and

FactoryTalk Event Archiver on page 35

• Install FactoryTalk Batch Client components on page 51

• Install FactoryTalk Batch Material Manager Server components on

page 53

• Install FactoryTalk Batch Material Manager Client components on

page 57

• Install eProcedure Client components on page 77

Chapter 1 FactoryTalk Batch system overview

If you are upgrading your system from a previous version of FactoryTalk Batch use the Upgrade FactoryTalk Batch

instructions.

Obtain administrator Prepare the operating

Chapter 2

Pre-installation administrative tasks

This section describes administrative tasks to perform before installing FactoryTalk Batch components. Tasks include:

privileges on target computer

• Obtain administrator privileges on target computer on page 21

• Prepare the operating system on page 21

• Create users and user groups on page 24

• Update Windows Firewall settings on page 25

• Configure the Remote Registry service on page 27

• Set the system date and time on page 27

• Prepare the SQL Server installation on page 27

To install each of these software applications on the target computer, you must be logged onto the computer using an account that has administrator privileges on the computer and that has been granted permission to create databases, stored procedures, and logins on SQL Server.

• FactoryTalk Batch Server

• FactoryTalk Batch Client

• FactoryTalk Event Archiver

• FactoryTalk eProcedure Server

• FactoryTalk eProcedure Client

• FactoryTalk Batch Material Manager Server

• FactoryTalk Batch Material Manager Client

system

Before starting the installation procedure close any open applications.

Before installing FactoryTalk Batch Server, FactoryTalk Material Manager Server, or FactoryTalk eProcedure Server components make sure that the operating system for the target computer is properly configured.

Server operating systems and desktop operating systems have different configuration requirements.

Pre-installation configuration task include:

• Configure the Windows Server operating system

• Configure the Windows desktop operating system

Chapter 2 Pre-installation administrative tasks

Tip: FactoryTalk Batch Server does not require any additional configuration of Windows Server 2016 or 2019.

Windows configuration

Configure the Windows

If setting up new computers for the FactoryTalk Batch system, install the operating system using the default settings. Then configure the operating

requirements

system as described for the components.

Configure the Windows Server operating system features to support FactoryTalk Batch Server, FactoryTalk Batch Material Manager Server, or

Server operating system

FactoryTalk eProcedure Server.

To configure the Windows Server operating system

1. If installing FactoryTalk Batch Server enable the required server

Tip: All supported operating systems are tested and warrantied for FactoryTalk Batch version 14.00.

features:

• In Server Manager, select Add Roles and Features.

• In Add Roles and Features Wizard, select Next.

• For Installation Type, select Role-based or feature-based

installation.

• For Server Selection, choose Select a server from the server pool,

and then choose the appropriate server from the Server Pool list and then select Next.

• (Windows Server 2012) For Server Roles, select Application Server.

2. If installing FactoryTalk Batch Material Manager Server go to Features, and select Message Queuing.

3. If installing FactoryTalk eProcedure Server, enable these additional settings under Web Server (IIS) > Role Services.

• IIS6 Management Compatibility

• IIS6 Metabase compatibility

• IIS6 Management Console

• Web Server > Application Development:

• For Windows Server 2012:

• ASP

• ASP.NET 3.5

• ASP.NET 4.5

• For Windows Server 2016 or Windows Server 2019

• ASP

• ASP .NET 3.5

• ASP .NET 4.7

• Web Server

IMPORTANT

Enabling some features automatically selects new required

for Windows desktop operating systems.

Configure the Windows

desktop operating system

Chapter 2 Pre-installation administrative tasks

• Common HTTP Features

additional features and updates the feature list accordingly. Select Add Feature to accept the default selections for these options.

4. Verify the selections, and then select Install.

5. When the installation process is complete, select Close.

Perform this procedure to configure the Windows desktop operating system for the FactoryTalk Batch Material Manager Server, and FactoryTalk eProcedure Server. Use the Turn Windows features on or off control panel item for this configuration process.

Tip: FactoryTalk Batch Server and Client components do not require any additional configuration

To configure Windows desktop operating system

1. On the computer where the FactoryTalk Batch Material Manager

Server or FactoryTalk eProcedure Server will be installed, select

Control Panel > Programs > Turn Windows features on or off.

Windows Features opens.

Tip: In Windows Features the box next to the feature name represents the installation status of the feature:

• A checkmark represents a fully installed feature.

• A black square represents an installed feature with optional features

that are not enabled.

•

Empty boxes represent uninstalled features.

2. If installing FactoryTalk Batch Material Manager Server select

Microsoft Message Queue (MSMQ) Server. Microsoft Message Queue (MSMQ) Server Core is selected by default.

3. If installing FactoryTalk Batch eProcedure Server select these features:

• Internet Information Services

• Web Management Tools

• IIS 6 Management Compatibility

- IIS 6 Management Console

- IIS 6 Metabase and IIS 6 configuration compatibility

• IIS Management Console

• Internet Information Services > World Wide Web Services

• Application Development Features

-.Net Extensibility 3.5

-.Net Extensibility 4.6

-ASP

-ASP .NET 3.5

Chapter 2 Pre-installation administrative tasks

DEP settings

Create users and user

4. Select OK to enable the features and close the dialog box.

Data Execution Prevention (DEP) uses hardware and software security features to prevent the execution of malicious code in Windows operating

systems.

Rockwell Automation supports DEP OptIn and OptOut settings. For more information, see Microsoft KB article 875352

Before installing FactoryTalk Batch, you must create at least one domain user account that serves as the FactoryTalk Batch Server user account. If your

groups

installation includes FactoryTalk Batch Material Manager Server you must

also create several domain user groups. When you run the installation program you will need to provide the FactoryTalk Batch Server user account and password for the FactoryTalk Batch Server and FactoryTalk Batch Material Manager Server to run under.

-ASP .NET 4.6

-ISAPI Extensions

-ISAPI Filters

• Common HTTP Features

- Static Content

FactoryTalk Batch users/user groups

The installation of the FactoryTalk Batch Server creates the Windows user group batchsvr_group on the FactoryTalk Batch Server. This group is automatically assigned all the user rights and default access permissions required for the FactoryTalk Batch Server to function correctly.

The installation adds the FactoryTalk Batch Server user account to the following:

• Administrators group

• batchsvr_group

• Batch COM+ Application

• FactoryTalk Batch Server service

• FactoryTalk Event Archiver service

• FactoryTalk eProcedure Server service (eProcedure Server installation)

The services for the FactoryTalk Batch Server, FactoryTalk Event Archiver, FactoryTalk eProcedure Server, and the Batch COM+ Application require identical user accounts to support the FactoryTalk Batch Server functionality.

IMPORTANT

When managing the Windows Firewall settings externally, the installation program

Update Windows Firewall

Chapter 2 Pre-installation administrative tasks

FactoryTalk Batch Material Manager user groups

For FactoryTalk Batch Material Manager, you must create these required domain user groups.

Required domain user groups

• MTBatchServer

Add the FactoryTalk Batch user account under which the FactoryTalk Batch Server service is running to the MTBatchServer group. This is the group that the FactoryTalk Batch Server uses to access the material database.

• MTGeneral

Required to use Material Editor.

• MTLotAuthor

Add any domain users that require the ability to add, edit, and delete material lots in the Material Editor.

• MTMaterialAuthor

settings

Add any domain users that require the ability to add, edit, and delete materials and containers in the Material Editor.

• MTMaterialViewer

Add any domain users that require read-only access to materials and containers in the Material Editor. The installation adds the five domain groups and domain user account for the FactoryTalk Batch Material Manager Server to the appropriate COM+ roles and/or local user groups. For more information about security settings, see Security settings in the FactoryTalk Batch Material Manager Administrator Guide.

To allow the installation program to configure the firewall exceptions

automatically, enable the Windows Firewall Service prior to installation. The

installation program uses the Rockwell Software Windows Firewall

Configuration Utility to add the necessary exceptions.

cannot change the Windows Firewall settings.

The installation program updates Windows Firewall settings to allow these applications to communicate through the firewall:

• FactoryTalk Batch Server

• FactoryTalk Batch Client

• FactoryTalk Event Archiver

• FactoryTalk eProcedure Server

• FactoryTalk eProcedure Client

• FactoryTalk Batch Material Manager Server

• FactoryTalk Batch Material Manager Client

Chapter 2 Pre-installation administrative tasks

Windows Firewall Exceptions

• batchsvr.exe (Batch server installs)

• OPCEnum.exe

• batchvew.exe (Batch client installs)

• Port 1433 TCP (SQL Server installs)

• EventClientMultiplexer.exe

• Port 135 TCP

• EventServer.exe

• Port 80 TCP (FactoryTalk eProcedure Client installs)

• Flexsvr.exe

• RDcyHost.exe

• FTCounterMonitor.exe

• RnaDiagnosticsSrv.exe

• FTSPVStudio.exe

• RnaDiagReceiver.exe

FTSysDiagSvcHost.exe

RnaDirServer.exe

iexplore.exe

RsvcHost.exe

Imgrd.exe

VStudio.exe

IMPORTANT

Windows Firewall

Typically, Windows Firewall appears under Control Panel > System and Security > Windows Firewall. For more information, see the Windows

operating system for the current installation.

If the Windows Firewall is enabled when you install FactoryTalk Batch or

FactoryTalk eProcedure applications, the installation program adds the

exceptions

following exceptions to the local computer:

• DaClient.exe • Port 137 NetBIOS Name Service

•

NmspHost.exe

•

If the Windows Firewall is enabled, and not externally controlled, the Windows Firewall Configuration Utility runs automatically during installation. If this utility does not run automatically, manually run it on each computer in your FactoryTalk Batch system after installing servers or clients.

To manually run the FactoryTalk Windows Firewall Configuration Utility, navigate to Start > Rockwell Software > Windows Firewall Configuration Utility.

If you are using a different firewall with your system, add equivalent exceptions to enable communication through the firewall by the FactoryTalk Batch components.

IMPORTANT

Configure the Remote

Registry service

Set the system date and

Prepare the SQL Server

time

Chapter 2 Pre-installation administrative tasks

Remote Registry is enabled to support network synchronization of the

FactoryTalk Batch components across computer boundaries. Before installing

the FactoryTalk Batch Server or FactoryTalk Batch Material Manager Server

on any operating system, configure the Remote Registry service for automatic startup.

To configure the Remote Registry service

1. Navigate to Control Panel > System and Security > Administrative Tools. Double-click Services.

2. In the Services (Local) pane, right-click Remote Registry and select

Properties.

3. For Startup type, select Automatic.

4. Select OK.

Set the date and time on each computer on the FactoryTalk Batch network to the same date and time.

The dates and times for all computers on the network must match each other so that events, journals, and logs in the FactoryTalk Batch system are properly synced.

installation

These applications can use SQL Server:

• FactoryTalk Batch Server (to store recipes in RDB format)

• FactoryTalk Event Archiver (to archive batch event records and to use

Batch reports)

• FactoryTalk Batch Material Manager Server (to store materials for

recipes)

Install a supported version of SQL Server as listed in the System requirements and supported software overview section and select these features:

• Database Engine Services

• Reporting Services (if using FactoryTalk Event Archiver with Batch

reports)

Configuration of SQL Server Reporting Services differs depending on the version of SQL Server installed. Reporting Services for SQL Server 2017 are installed separately.

Visit the Microsoft website (https://www.microsoft.com/en-us/sql-server/sql-

server-downloads) to get the latest supported version of SQL Server for the

FactoryTalk Batch system.

Consider these items when installing SQL Server for use with the FactoryTalk Batch system:

Chapter 2 Pre-installation administrative tasks

• Before starting the FactoryTalk Batch installation create a SQL Server

• The user installing FactoryTalk Batch Material Manager must have

• SQL Server can reside on the same computer as the FactoryTalk Batch

• If using a single SQL Server installation, install SQL Server on the

• If using a single SQL Server installation for recipes, Batch reports, and

• Support for named instances:

database login for the user that will performing the FactoryTalk Batch installation. Make sure that the user account has been granted dbcreator permissions in SQL Server. That permission is required to create a database.

Read and Write access to the SQL Server database.

Server.

same computer where the FactoryTalk Batch Material Manager Server will be installed.

materials, use the default instance name (MSSQLSERVER). The FactoryTalk Batch Material Manager Server supports only default instances.

• FactoryTalk Batch and the FactoryTalk Batch Material Manager Server do not support named instances.

• FactoryTalk Event Archiver supports named instances.

Install Reporting Services for SQL Server 2017 or

SQL Server 2019

• Add TCP Port 1433 as an exception in the Windows Firewall to store recipes from FactoryTalk Batch Recipe Editor on a remote SQL Server.

• Install the FactoryTalk Event Archiver Management Tool on the same computer as SQL Server.

For SQL Server installation instructions, see the SQL Server Installation Guide on the Microsoft website.

If using SQL Server 2017 or SQL Server 2019 you must install the corresponding SQL Server eporting Services to create FactoryTalk Batch report using FactoryTalk Event Archiver.

You can download SQL Server 2017 Reporting Services and

SQL Server 2019 Reporting Services from the Microsoft web site.

To install Reporting Services

1. Go to the location where you downloaded Report Services. Right-click

SQLServerReportingServices.exe and select Run as administrator to start the installer.

2. On the Welcome page, select Install Reporting Services.

3. In Choose an edition to install either select the Developer free edition or enter your product key and then select Next.

4. Read and agree to the license terms and conditions and then select Next.

Tip: The default path is C:\Program Files\Microsoft SQL Server Reporting Services.

user credentials.

Tip: If a message appears stating that Web Services have not been

Configure Reporting

Services for SQL Server 2012 or SQL Server 2014

Chapter 2 Pre-installation administrative tasks

5. Select Next to install the report server only. Reporting Services uses the Database Engine installed with SQL Server to store the report server database.

6. In Specify an install location accept the default location for the report server. Select Install to continue.

7. If prompted to restart your computer, do so.

Configure SQL Server Reporting Services so that FactoryTalk Event Archiver can create FactoryTalk Batch reports.

Tips:

• Use this procedure if the "Install only" option was selected when installing Reporting Services, or when modifying an existing SQL Server installation to add the Reporting Services feature and the option to configure reporting services was not selected.

• Use the same user account for installing FactoryTalk Batch and FactoryTalk Event Archiver and configuring Reporting Services. If using a different user account, the application might prompt repeatedly for

To configure Reporting Services for FactoryTalk Event Archiver

1. Locate and open the Reporting Services Configuration Manager.

2. In Reporting Services Configuration Connection, configure these

items:

• In Server Name, specify the name of the computer with the report

server instance.

• In Report Server Instance, select the default instance

(MSSQLSERVER) from the list.

• Select Connect.

3. In Reporting Services Configuration Manager, select Report Manager URL.

assigned, select Web Service URL from the Connect pane, accept the defaults, and click Apply before returning to this page.

4. Select the URLs link to open Home - Report Manager in a web browser.

• For an inactive link, select Apply to activate the link.

• When accessing the Report Manager page for the first time,

warning messages might be displayed. To continue, select Close for any warning.

Chapter 2 Pre-installation administrative tasks

Tip: Make sure that the group or user specified is granted EXECUTE and INSERT

complete.

IMPORTANT

select Close or Add for each warning.

Configure SQL Server 2016

5. In Home - Report Manager, select Folder Settings.

6. In Security, select New Role Assignment.

7. In New Role Assignment, in Group or user name, enter a group or a

8. Select the Role check box to select all of the roles.

9. Select OK. The new role displays on the SQL Server Security page.

If you are using SQL Server 2016 with FactoryTalk Batch the reporting services configuration is slightly different than in previous versions

for reporting services

Tip: Some configurations might require:

• An additional login to the site

• Starting the browser using the Run as administrator option

• Adding the Report Manager URL to the Local intranet zone if using

Internet Explorer with the Enhanced Security Configuration enabled.

user name to allow these users to run reports. Use the format domain_name\account_name.

permissions to the BatchHistoryEX and ReportServer databases after installation is

To configure Reporting Services for SQL Server 2016

1. In the Windows search bar, type Reporting Service Configuration

Manager and then select the app to open it.

2. In Reporting Services Configuration Connection, select the report server instance to configure.

a. In Server Name, specify the name of the computer on which the

report server instance is installed.

b. In Report Server Instance, select the SQL Server Reporting

Services instance to configure. Only report server instances for this version of SQL Server appear in the list.

c. Click Connect. The Reporting Services Configuration Manager

opens.

3. On the left pane, select Web Portal URL.

4. In the Web Portal URL pane (on the right), select the URLs: link to open SQL Server Reporting Services in a web browser.

If the link is not active, select Apply to activate the link.

If this is the first time accessing the SQL Server Reporting Services page, depending on your browser security settings,

you might receive several warning messages. To continue,

5. If prompted to log into Reporting Services log in as a user with

administrative permissions to the BatchHistoryEX and ReportServer databases.

complete.

Tip: FactoryTalk Diagnostics version 6.20 uses the same default port as SQL Server 2017

Configure Reporting

Services for SQL Server 2017

Chapter 2 Pre-installation administrative tasks

6. In Home - SQL Server Reporting Services, select Manage folder.

7. In Security, select + Add group or user.

8. In New Role Assignment, for Group or user name enter the domain\user name that was used when SQL Server was installed.

Tip: Make sure that the group or user specified is granted EXECUTE and INSERT permissions to the BatchHistoryEX and ReportServer databases after installation is

9. Select Role to select all of the roles.

10. Select OK. The new role is added to the list on the SQL Server Reporting Services Security page.

If you are using SQL Server 2017 with FactoryTalk Batch the reporting services configuration is slightly different than in SQL Server 2016.

Before you can install FactoryTalk Batch with FactoryTalk Event Archiver, you must configure the Web Service URL, database and Web Portal URL.

To configure Reporting Services for SQL Server 2017

1. In the Windows search bar, type Report Server Configuration

Manager and then select the app to open it.

2. In Report Server Configuration Connection, select the report server instance to configure.

d. In Server Name, specify the name of the computer on which the

report server instance is installed.

e. In Report Server Instance, select the SQL Server Reporting

Services instance to configure. Only report server instances for this version of SQL Server appear in the list.

f. Click Connect. The Report Server Configuration Manager opens.

3. On the left pane, select Web Service URL.

Reporting Services. If you are planning to run both applications on the same server, configure a different port value for the Web Service URL.

4. Select Apply to accept the default values. Observe the Results pane. If all tasks completed successfully, continue the configuration.

5. On the left pane, select Database.

6. Under Current Report Server Database, select Change Database to open the Report Server Database Configuration Wizard.

7. On the Action page, select Create a new report server database then select Next.

8. On the Database Server page complete the settings:

• In Server Name type the name of the SQL Server.

• In Authentication Type select Current User - Integrated Security.

Chapter 2 Pre-installation administrative tasks

IMPORTANT

complete.

Configure Windows Firewall

9. On the Database page, in Database Name provide a name for the

10. On the Credentials page specify an existing account that the report

11. On the Summary page confirm the settings are correct and then select

12. Once the report server database is created, select Finish to close the

13. On the left pane, select Web Portal URL.

14. Select Apply to accept the default values. Observe the Results pane. If

15. In the Web Portal URL pane (on the right), select the URLs: link to

• Select Test Connection to verify the user account can login to the

server.

• Select Next.

initial reporting database and then select Next.

server will use to connect to the report server database and then select

Next.

wizard.

all tasks completed successfully, continue the configuration.

open SQL Server Reporting Services in a web browser.

If this is the first time accessing the SQL Server Reporting Services page, depending on your browser security settings,

you might receive several warning messages. To continue, select Close or Add for each warning.

for FactoryTalk Event Archiver

16. In Execution Account, select Specify an execution account.

17. In Account enter the domain\user name and password that was used when SQL Server was installed.

Tip: Make sure that the group or user specified is granted EXECUTE and INSERT permissions to the BatchHistoryEX and ReportServer databases after installation is

18. Select Apply. Observe the Results pane and verify the task completed successfully.

If you are running Windows Firewall on the same computer as the SQL Server, remote connections to the SQL Server will be blocked unless the SQL Server and SQL Browser service can communicate through the firewall. You will have to add an exception in Windows Firewall for these services to make connection from the FactoryTalk Batch Archiver client to the remote

FactoryTalk Batch Archiver SQL Server.

By default, SQL Server uses static TCP port number 1433 for the default instance MSSQLSERVER. If you configure SQL Server to use a static port other than the default port add that port to the firewall exception list instead of the default port.

Alternatively, you can configure SQL Server to use a dynamic port. If you use dynamic port allocation, you specify port number zero in the network configuration. Once SQL Service restarts, it requests a free port number from the operating system and assigns that port to SQL Server. When dynamic

Chapter 2 Pre-installation administrative tasks

ports are used, the SQL Browser service provides the port number to the requesting FactoryTalk Batch component.

To configure Windows Firewall for a SQL Server using static ports

1. On the client computer, open Windows Defender Firewall and choose

Advanced Settings.

2. Select Inbound Rules and click New Rule.

3. Follow the New Inbound Rule Wizard making these selections:

a. For Rule Type, select Port and then click Next.

b. For Protocol and Ports, select TCP and enter the port 1433 (default)

or the static port number configured for SQL Server and then click Next.

c. For Action, select Allow the Connection and then click Next.

d. For Profile, select the appropriate network profile (Domain,

Private, or Public) and then click Next.

Tip: Most organizations use a domain network. You can check your network information from Control Panel >Network and Sharing Center.

e. (optional) For Name, type a name and description for the inbound

rule. Click Finish.

4. Click New Rule again to create another inbound rule.

5. Follow the New Inbound Rule Wizard making these selections:

a. For Rule Type, select Port and then click Next.

b. For Protocol and Ports, select UDP and enter the port 1434 and then

click Next.

c. For Action, select Allow the Connection and then click Next.

d. For Profile, select the appropriate network profile and then click

Next.

e. (optional) For Name, type a name and description for the inbound

rule. Click Finish.

To configure Windows Firewall for a SQL Server using dynamic ports

1. On the client computer, open Windows Defender Firewall and choose

Advanced Settings.

2. Select Inbound Rules and click New Rule.

3. Follow the New Inbound Rule Wizard making these selections:

a. For Rule Type, select Program and then click Next.

b. For Program, select This program path and then click Browse.

Chapter 2 Pre-installation administrative tasks

4. Click New Rule again to create another inbound rule.

5. Follow the New Inbound Rule Wizard making these selections:

a. Select Port radio button on the first page and then click Next.

c. Enter the path to your SQL Server executable then click Open.

Example: C:\Program Files\Microsoft SQL Server\MSSQL17.MSSQLSERVER\MSSQL\Binn\sqlservr.exe.

d. Confirm the path is correct and then click Next.

e. For Action, select Allow the Connection and then click Next.

f. For Profile, select the appropriate network profile and then click

Next.

g. (optional) For Name, type a name and description for the inbound

rule. Click Finish.

b. Select UDP and enter the port 1434 and then click Next.

c. Select Allow the Connection and then click Next.

d. Select the appropriate network profile and then click Next.

e. (optional) Add a name and description for the inbound rule. Click

Finish.

After completing these steps the FactoryTalk Event Archiver client will be able to connect to the FactoryTalk Event Archiver remote SQL Server.

Pre-Installation administration tasks

Tasks

Notes



Obtain administrator privileges on target

Pre-Installation operating system configuration

Chapter 3

Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Installing the FactoryTalk Batch Server, eProcedure Server and FactoryTalk Event Archiver software requires that you perform pre-installation tasks to prepare your environment before installing the software. After the installation is complete, you will perform some post-installation configuration to get your system ready for production use.

Tip: If a FactoryTalk Batch Server already exists, see Install the FactoryTalk Batch client on

52 to install FactoryTalk Batch Client components on a different computer.

page

This section provides instructions for installing the FactoryTalk Batch Server, eProcedure Server, and FactoryTalk Event Archiver software on the same computer.

Tip: We recommend using the default installation directories for all components.

Use this checklist to help you successfully set up the FactoryTalk Batch environment:

computer



Create users and user groups



Update Windows firewall settings



Configure the Remote Registry service



Set the system date and time



Prepare the SQL Server installation



Configure the Windows Server operating system for the FactoryTalk Batch Server and eProcedure Server



Configure the Windows desktop operating system for the FactoryTalk Batch Server and eProcedure Server

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Installation



Install the FactoryTalk Batch components the components

Post-Installation configuration

Services

directory on the SQL Server computer

Add a server to the FactoryTalk Batch system

Configure event log settings

Configure server options

Set security on logs and journals folders

Configure browser compatibility view settings

steps to resolve is displayed.

Install the FactoryTalk



Run FactoryTalk Updater to check for updates



Configure the FactoryTalk network directory



Configure <MSSQL> to enable FactoryTalk Event Archiver with Reporting Services

• Configure SQL Server 2017 to enable

FactoryTalk Event Archiver with Reporting Services

• Configure SQL Server 2014 or SQL Server

2016 to enable FactoryTalk Event Archiver with Reporting Services

• Configure SQL Server 2012 to enable

FactoryTalk Event Archiver with Reporting



Grant access to the FactoryTalk Batch



Create a shared directory



Define redundant servers (optional)



After preparing the computer operating systems, install the FactoryTalk Batch Server, FactoryTalk eProcedure Server, FactoryTalk Batch View Server, and

Batch components

FactoryTalk Event Archiver components.

• The FactoryTalk Batch Server controls system information, phases, and recipes.

• The FactoryTalk eProcedure Server:

• Provides services to the FactoryTalk Batch Server to use HTML

instruction files.

• Formats parameters and report parameters from material-based

recipes into instruction files.

• The FactoryTalk Event Archiver stores the FactoryTalk Batch ASCII electronic batch records (.evt files) into a SQL Server database. The database can be queried for batch data or can be used by the optional FactoryTalk Batch reporting tools to generate web-based batch reports.

Tip: Prerequisite checks are run automatically to ensure a successful installation. If an issue occurs during installation, an error message with

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Default installation of FactoryTalk Batch components

The default FactoryTalk Batch installation includes:

• FactoryTalk Services Platform v6.20.00 (always installed with FactoryTalk Batch, FactoryTalk eProcedure, and FactoryTalk Batch Material Manager).

• FactoryTalk Activation v4.03.03 (always installed with FactoryTalk Batch, FactoryTalk eProcedure, and FactoryTalk Batch Material Manager).

• FactoryTalk Linx v6.20.00 (always installed with FactoryTalk Batch, FactoryTalk eProcedure, and FactoryTalk Batch Material Manager).

• FactoryTalk Batch v14.00 (includes Batch Server, Editors and Legacy Client, and FactoryTalk Batch View Server v2.00).

• FactoryTalk Batch View Server (v2.00; installed only if FactoryTalk Batch is selected).

• FactoryTalk Event Archiver Components v14.00 (includes Database and Reporting Services and Management Tool).

• Tools (FactoryTalk Updater Agent v2.00.00).

Optional components available for installation are:

• FactoryTalk eProcedure v14.00 (includes Database and Reporting Services and Management Tool).

• FactoryTalk Batch Material Manager (includes Server Components and Client Components).

• FactoryTalk Batch HMI Controls v2.0.

• Tools (FactoryTalk Updater Server v2.00.00 and FactoryTalk Updater

Client v2.00.00)

To install the FactoryTalk Batch Server, FactoryTalk eProcedure, FactoryTalk Batch View Server, and FactoryTalk Event Archiver components

1. Run Setup.exe.

2. On the Setup page, select Customize.

3. On the Customize page:

• Select and then expand FactoryTalk Batch v14.00. The Batch Server

and Editors and Legacy Client options are installed by default. Clear either option to remove it from the installation. Removing both options removes FactoryTalk Batch and all other default components from the installation.

• Select and then expand FactoryTalk Event Archiver Components

v14.00. The Server Components and Client Components options are installed by default. Clear either option to remove it from the

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Reports support named instances.

Tip: The installation progress wheel and the specific components and supporting

installation. Removing both options removes FactoryTalk Event Archiver Components v14.00 from the installation.

• Select and then expand FactoryTalk eProcedure v14.00. Select the

Server Components and Client Components options to install them with FactoryTalk eProcedure v14.00.

• Select and then expand Tools. FactoryTalk Updater Agent v2.00.00

is installed by default. Select all options to include them in the installation.

4. On the Permission Requested page:

• Select Yes, allow changes to this computer.

5. On the Options page:

• Network Directory is required and is selected by default.

• To store recipes in SQL Server instead of individual files, select

Recipe Storage.

• Enter a port to use for the FactoryTalk Batch View Server. Port 443 is

the default and is the recommended port.

• Select Next.

6. On the System Details page, complete these fields:

• In User Name, enter the domain\user name for user account

created for the FactoryTalk Batch Server Service to run under. If the user account is in the current domain, the domain does not need to be specified.

• In Password enter the password for the domain\user name.

• Select Next.

7. (optional) On the Event Archiver SQL Connection page, if installing FactoryTalk Event Archiver components, complete these items:

• In Server Name, enter the SQL Server name.

• In Instance Name, enter the instance name if using a named

instance.

Tip: If using a single SQL Server installation for recipes, Batch reports, and materials, use the default instance name MSSQLSERVER. The FactoryTalk Batch Material Server supports only default instances. If using multiple SQL Server installations, FactoryTalk Event Archiver Batch

• In Data Source Name, enter the data source name.

• Select Include Batch Reports.

• Select Next.

8. On the Connection Validated page, select Install.

9. On the End User License Agreements page, review the agreement and

10. If the Would you like to install this device software page appears,

select Accept all.

select Install.

files are displayed.

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

FactoryTalk Updater

Modify an installation

11. (optional) If prompted on the Almost There page, select Activate your software, and then select Next.

12. If prompted on the That's it page, restart the computer.

When you start the installation process for your FactoryTalk Batch system one

of the optional installation components is FactoryTalk Updater. FactoryTalk Updater assists in management of installed Rockwell Automation software by announcing new versions and patch roll-ups for the software on your computer. Registering for updates is not required to receive announcements from the FactoryTalk Updater. FactoryTalk Updater includes these components:

• FactoryTalk Updater Agent The agent collects information and activation license data from the

Rockwell Automation software installed on the computer. Install the FactoryTalk Updater Agent on each computer that requires data collection.

• FactoryTalk Updater Client Displays information collected by the FactoryTalk Updater Server

and enables you to review updates and patches.

• FactoryTalk Updater Server Communicates with online FactoryTalk Updater Agents to receive

collected data. Connects to the Product Compatibility and Download Center to retrieve the latest software information. Responds to requests from the FactoryTalk Updater Client. Supports ~100 online Agents. To avoid issues, limit FactoryTalk Updater Server installations to one instance per intranet.

System logs and some application data are stored in this folder:

C:\Users\Public\Documents\Rockwell\Updater\Data

The logs and application data can be helpful when contacting Rockwell Automation Technical Support. System logs are automatically deleted after 90 days.

Tip: To receive notifications of new versions and patch roll-ups, the FactoryTalk Updater application requires access to the Download Center web service. Verify that the firewall does not block access to this URL: https://api.rockwellautomation.com/es-be-pcdc-vpcprod/

See the FactoryTalk Updater help for more information about using FactoryTalk Updater.

Use the Modify and Repair installation method to change the optional

components selected with the FactoryTalk Batch system installation or to run a repair operation on installed components. If at least one FactoryTalk Batch component is already installed when the installation program is started, an

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Component

Supported when modifying an

Not supported when modifying an install

FactoryTalk Batch

Manager

Adding a client to an existing

Adding a server to an existing client

Management Tool installation

Post-installation tasks for

option to modify the current installation is displayed in the installation wizard. You can also access Modify and Repair by opening Windows Control Panel and selecting Change for a Rockwell Automation software application.

Options for modifying an installation vary, based on the components installed. Options that are supported and not supported when modifying an installed component are:

install

FactoryTalk eProcedure FactoryTalk Material

•

server installation

•

installation

• Removing the individual client or server

FactoryTalk Batch components

FactoryTalk Event Archiver

• Adding the Management tool to an existing Database install if the Include Batch Reports option was selected during the initial installation

• Adding the Management tool to an existing Database installation if the Include Batch Reports option was not selected during the initial installation

• Adding the Database to an existing Management tool installation

• Removing the individual Database or

To modify an installation

1. Run Setup.exe.

2. On the Setup page, select Modify.

3. On the Modify page, select the components to install.

4. Select Next.

5. Complete any remaining pages that open. The pages and options vary based on the components selected.

6. On the Modification Complete page, select Close.

After installing the FactoryTalk Batch Server, FactoryTalk eProcedure Server, FactoryTalk Batch View Server, and FactoryTalk Event Archiver components there are several settings that should be configured before putting the system into production. Review these tasks to determine which items are applicable to your installation:

• Configure the FactoryTalk network directory

• Configure SQL Server to enable FactoryTalk Event Archiver with

Reporting Services

• Grant access to the FactoryTalk Batch directory on the SQL Server computer

• Add a server to the FactoryTalk Batch system

• Configure event log settings

• Create a shared directory

• Configure server options

IMPORTANT

All users of the FactoryTalk Batch Reporting Services must have a user login and read

or groups when adding the login account for the FactoryTalk Batch Server.

Configure the FactoryTalk

network directory

Configure SQL Server 2017

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

• Define redundant servers

• Set security on logs and journals folders

• Configure browser compatibility view settings

If you are installing FactoryTalk Batch components on a new system, FactoryTalk Batch installation will install FactoryTalk Services Platform and configure the computer as the FactoryTalk network directory server for the

rest of the system. After installing additional components, use the Specify FactoryTalk Directory Location utility to point each computer in the network to the FactoryTalk Directory network directory server.

To configure a network directory client computer

1. On each participating network directory client computer, go to

Rockwell Software > Specify FactoryTalk Directory Location.

2. At the prompt, log on to the network directory with a Windows Administrator account.

3. In FactoryTalk Directory Server Location Utility, select Browse.

4. In FactoryTalk Directory Server Configuration, select Remote computer, then specify the name of the computer to use as the network directory server, and select OK.

5. When prompted, log on to the network directory.

to enable FactoryTalk Event Archiver with Reporting Services

If single sign-on is enabled on the computer when the location of the network directory server changes, the single sign-on session terminates and you must log on to the new network directory server. The user name and password entered become the new single sign-on credentials for all participating FactoryTalk products on the computer.

6. When prompted, restart the computer.

If including reporting services in the FactoryTalk Batch system installation, you must configure SQL Server to enable FactoryTalk Event Archiver with Reporting Services to connect to and insert records into the FactoryTalk Batch database. This procedure uses SQL Server Management Studio to set up permissions for the BatchHistory or BatchHistoryEx database.

See the FactoryTalk Event Archiver User Guide to configure the reporting option

for End of Batch or Incremental.

and write access to the source databases, such as BatchHistoryEx or the FactoryTalk® Alarms and Events FTAE_Historian databases. Add any additional users

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

transfer to other databases.

To configure SQL Server 2017 to enable FactoryTalk Event Archiver with Reporting Services

1. Start SQL Server Management Studio.

2. In Connect to Server for Server type, select Database Engine.

3. Confirm the server name and authentication method are correct, then select Connect.

4. In Object Explorer, expand Security > Logins.

5. Right-click Logins and select New Login to add a FactoryTalk Batch Server user login.

6. In Login name, type the name of the Batch Server user account.

7. Select Search to validate the account is correct.

8. In Default database, select either BatchHistory or BatchHistoryEx.

9. Under Select a page, select User Mapping.

10. Under Users mapped to this login select the checkbox for either the BatchHistory or BatchHistoryEX database.

11. Under Database role membership for: <database name> select the checkboxes for db_datareader and db_datawriter then select OK.

Tip: Confirm that BatchHistory or BatchHistoryEX. Each database is configured independently. Role membership added for the master database does not

has been replaced with either

12. In Object Explorer, expand Databases, right-click the BatchHistory or BatchHistoryEx database, and select Properties.

13. Under Select a page, select Permissions.

14. Under Users or roles select the Batch Server user account.

15. Under Permissions for <SQL_Server_name\user_account>: select the checkboxes in the Grant column for these permissions:

• Insert

• Connect

• Execute

Tip: Confirm that user account. Each user account permission set is configured independently.

<user_account>

has been replaced with the Batch Server

16. Select OK to apply the configuration.

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

IMPORTANT

All users of the FactoryTalk Batch Reporting Services must have a user login and read

or groups when adding the login account for the FactoryTalk Batch Server.

Configure SQL Server 2014 Configure SQL Server 2012

or SQL Server 2016 to enable FactoryTalk Event Archiver with Reporting Services

See the FactoryTalk Event Archiver User Guide to configure the reporting option for End of Batch or Incremental.

and write access to the source databases, such as BatchHistoryEx or the FactoryTalk® Alarms and Events FTAE_Historian databases. Add any additional users

To configure SQL Server 2014 or SQL Server 2016 to enable FactoryTalk Event Archiver with Reporting Services

1. From SQL Server Management Studio, add a FactoryTalk Batch Server

user login to the Security > Logins folder on the SQL Server instance.

2. Set the default database to BatchHistory or BatchHistoryEx.

3. Under User Mapping, select the BatchHistory or BatchHistoryEX database.

4. Select db_datareader, db_datawriter, and select OK.

5. In Databases, right-click the BatchHistory or BatchHistoryEx database, and select Properties.

6. Select Permissions.

7. Select the Batch Server user account from the list.

8. Grant Execute, Insert, and Connect permissions.

If including reporting services in the FactoryTalk Batch system installation, you must configure SQL Server to enable FactoryTalk Event Archiver with

to enable FactoryTalk Event Archiver with Reporting

Reporting Services to connect to and insert records into the FactoryTalk Batch database. This procedure uses SQL Server Management Studio to set up permissions for the BatchHistory or BatchHistoryEx database.

Services

To configure SQL Server 2012 to enable FactoryTalk Event Archiver

with Reporting Services

1. In SQL Server Management Studio, Security > Logins area, add a log

in account for the FactoryTalk Batch Server (the account created in the pre-installation).

2. Grant CONNECT to privilege for the FactoryTalk Batch Server user account on either the BatchHistory or BatchHistoryEX database.

3. Grant INSERT privilege for the FactoryTalk Batch Server user account on either the BatchHistory or BatchHistoryEX database.

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Grant access to the Add a server to the

FactoryTalk Batch directory

4. Under BatchHistory\Programmability or BatchHistoryEX\Programmability, add the EXECUTE permission for

the FactoryTalk Batch Server user account to dbo.BHInsert properties.

5. For BatchHistoryEX\Programmability, add the EXECUTE permission for the FactoryTalk Batch Server user account to dbo.BHRecovery properties.

By default, the FactoryTalk Batch directory on the SQL Server computer is not shared to domain users. Therefore, domain users cannot access the appropriate application .log file when an error message refers them to it.

on the SQL Server computer

FactoryTalk Batch system

To enable domain users to read application logs, share the FactoryTalk Batch directory on the SQL Server computer in the FactoryTalk Batch system to

domain users and give the share Read-Only permissions.

If your FactoryTalk Batch system includes a Material Manager server you will need to configure the system with the newly installed servers and synchronize your FactoryTalk Batch system. The synchronization process copies the

network model data from your computer to each of the computers included in your FactoryTalk Batch system. Use the Network Editor utility to perform this procedure.

The Network Editor is a utility that allows you to indicate where other FactoryTalk Batch and/or FactoryTalk Batch Material Manager servers are located on the network. This network configuration information simplifies integration with other FactoryTalk products and the process of reconfiguring a system. The computers running FactoryTalk Batch components that have been installed need to be present in the network model for your system. Each Material Manager server can support ten FactoryTalk Batch servers. After the initial install each computer has a local network model that needs to be synchronized for the components to work together.

The Network Editor is installed automatically with the FactoryTalk Batch and Material Servers.

To select a network model

1. Open the Network Editor.

2. In the Network Editor toolbar, click the Select Network Model button.

3. Type the computer name in the "Enter the object name to select" area,

or click the Advanced button to search for a computer.

4. Click OK.

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

IMPORTANT

Administrative privileges are required to create a shared directory.

Event log settings

Create a shared directory

To add a server

1. Open the Network Editor.

2. In the Hierarchy pane, select the type of server to add.

3. Click Add Server.

4. In the Alias box, type an alias name. This is the name that displays in

the Network Editor.

5. In the Computer Name box, type the computer name, or use the

browse button to locate and select the computer from the list of computers on your domain.

6. Click the Synchronize button.

7. Click OK.

The Network Editor refreshes and the results of the synchronization process display in the Results pane.

The Windows Event Log service records application, system, and security

information.

Logging events can fill log space very quickly. If logging is enabled, we recommend that you configure the Windows Application and Services logs on Windows Server to use the Overwrite events as needed setting.

For more information about event log settings, see Modify Event Log Settings in the FactoryTalk Batch Administrator Guide.

A shared directory allows computers on the network to read from and write to

a common recipe, area model, or data file.

The FactoryTalk Batch installation creates a shared directory named

BATCHCTL where the FactoryTalk Batch software is installed (the default is C:\Program Files (x86)\Rockwell Software\Batch).

If you installed your project files in a different directory, configure that directory as a shared directory.

To create a shared directory

1. Navigate to the project file directory, then right-click the folder, and select the sharing option.

2. Use the File Sharing dialog box to add each user or user group name

that requires access to the project file directory.

3. Repeat for each user or user group, including the user accounts used

by the FactoryTalk Batch Server and FactoryTalk Event Archiver.

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Define redundant servers

4. Select Share.

Configure FactoryTalk Batch to store batch journals and batch restart information in two separate locations. If there is a hardware failure on the

(optional)

primary FactoryTalk Batch Server computer, using a secondary server allows for a manual failover.

The second computer must be capable of running the server. Redundant servers are defined by specifying the primary and secondary restart paths. If the system experiences a failure, these paths indicate where system files are written. If a secondary path is not specified, FactoryTalk Batch does not write any secondary files.

FactoryTalk Batch can be configured to store batch journals and batch restart information in two separate locations.

To define redundant servers

1. From the FactoryTalk Batch Equipment Editor Options menu, click Server Options.

2. Select the Restart Control tab.

3. In the Restart Type area, click on a selection, or accept the default,

Warm Restart.

4. Click the Primary Path browse button. The Select Directory dialog box

opens.

5. Select the MyProject\restart folder located in the BATCHCTL share on

the primary server’s hard drive (the default is c:\Program Files

(x86)\Rockwell Software\Batch\MyProject\restart), and then click OK.

6. Click the Secondary Path browse button. The Select Directory dialog

box opens.

7. Locate and select the MyProject\restart folder located in the

BATCHCTL share on the secondary server’s hard drive, and then click OK.

8. Repeat steps 1 through 7 on the redundant server computer, selecting

the Batch\MyProject\restart folder on the redundant server as the Primary Path. The Secondary Path can remain blank or point to another redundant server. Additionally, you must configure a data server to communicate with the process controller on the redundant

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

directories are defined.

where the batchsvr.ini resides on the computer.

Configure server options

server computer. The redundant server computer needs to communicate with the process controller that is running the phase logic.

Tip: You must also verify that the primary and secondary journal project

Before configuring the FactoryTalk Batch Server, make sure that all project directories are shared. Configure the FactoryTalk Batch Server using the

FactoryTalk Batch Equipment Editor Server Options dialog box.

Tip: In FactoryTalk Batch Equipment Editor, access Options > Server Options, Project Settings tab. Verify that the location listed in Initialization File Name is

Server options has several tabs:

• Project settings. Used to set directories for the Primary Journal,

Secondary Journal, Error Logging, Instructions (if you are using FactoryTalk eProcedure), and Equipment Database, configure recipe storage locations, and enable recipe versioning.

• Restart Control. Used to specify a restart method to initiate in the

event of a server computer failure.

• Batch Reporting. Used to select the reporting application for

generating Batch reports and archiving Batch data.

• Archiver Event Filters. Used to determine what electronic Batch

record data FactoryTalk Event Archiver writes to the Batch history database.

• Batch Server. Used to select and configure FactoryTalk Batch Server

options (including the hold propagation type), watchdog communications timeout settings, FactoryTalk Event Archiver log file size, minimum disk space required to add a batch, default batch ID, and whether to enable/disable event journal signatures.

• Cross Invocation Descriptors and Defaults. Used to specify cross

invocation labels and set default cross invocation strings for different resource types.

• Hyperlink Descriptors and Defaults. Specifies the hyperlink labels and

default values used with different resource types. This feature is used in conjunction with FactoryTalk eProcedure only.

• Material Policies. Used define what action to take when the

communication to the Material Server is lost and how to respond to a split feed. These features are used in conjunction with FactoryTalk Batch Material Manager only.

Make sure to configure the FactoryTalk Batch Server to allow each network computer to read from and write to the appropriate project directories and the FactoryTalk Batch Server and Archiver initialization files.

Changing items such as FactoryTalk Batch Server information, area model, and the error logging directory take effect when the server is restarted.

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

IMPORTANT

FactoryTalk Batch does not support the use of mapped drives. Do not use mapped

IMPORTANT

Notepad, the FactoryTalk Batch Server may not run due to an access error.

Set security on logs and

Changing items such as the recipe directory and batch journal directory take effect the next time the server accesses these items. None of the items in FactoryTalk Event Archiver configuration require the server to be restarted. These changes take effect the next time the server needs that configuration item.

drives for project directories.

For more information about configuring server options, see the FactoryTalk Batch Administrator Guide.

To prevent losing data in the log files and the event journal (.evt) files, set security permissions on the logs and event journal folders. The system

journals folders

administrator determines who needs access to these files and assigns the

appropriate permissions. The accounts under which the FactoryTalk Batch Server and FactoryTalk Event Archiver are running must be given full access to these folders.

FactoryTalk Batch Server continues writing information to log files and event journals (.evt) even when they are open. If a file is opened and then saved, data that may have been written to the event journal or log file while the file is open is lost. Use Notepad to open log files. If a log file is opened with a program other than

To set security on logs and journals folders

1. In Windows Explorer, locate the folder.

2. Right-click the folder and then select Properties.

3. Select the Security tab, select Edit, and then select Add.

4. From the Select Users, Computers, Service Accounts, or Groups dialog box, select Advanced and then select Find Now.

5. Select a user or group from the Search results list, and then select OK.

6. Repeat for each user or group that requires access to the folder.

Tip: Be sure to add the FactoryTalk Batch Server user account and then configure the account with Full Control permissions.

7. Select OK to return to the Properties dialog box.

8. From the Group or user name list, select a user or group, and then select the permissions in the Permissions area. Repeat for each user or group.

9. Select OK.

Chapter 3 Install FactoryTalk Batch Server, FactoryTalk eProcedure Server, and FactoryTalk Event Archiver

Configure browser

compatibility view settings

Configure Internet Explorer Compatibility View settings for the FactoryTalk eProcedure Client to ensure that:

• The FactoryTalk eProcedure Client command buttons work and display correctly.

• The current user is displayed and has permissions to view the batch list.

• The buttons on the left side are all the same size.

To configure Compatibility View settings

1. In Internet Explorer, select Tools > Compatibility View settings.

2. In Add this website, enter the FactoryTalk eProcedure server name and select Add.

Pre-Installation administration tasks

Tasks

Notes

Set the system date and time

Installation

Chapter 4

Install FactoryTalk Batch Client components

When installing FactoryTalk Batch Client components use these guidelines:

• Before installing the FactoryTalk Batch Clients, install and configure the Windows operating system, and install other required software that will be used with the FactoryTalk Batch system.

• Before beginning the installation, complete all the pre-installation administrative tasks.

• Install the FactoryTalk Batch Server before installing FactoryTalk Batch Client.

• Instructions for installing the FactoryTalk Batch Clients are based on installing clients on a computer networked with other FactoryTalk Batch system computers.

Tip: We recommend using the default installation directories for all components.

Use this checklist to help you successfully set up the FactoryTalk Batch Client components:



Obtain administrator privileges on target computer



Update Windows firewall settings



Install the FactoryTalk Batch Client

Chapter 4 Install FactoryTalk Batch Client components

steps are provided.

Batch Client.

Install the FactoryTalk

Installing the FactoryTalk Batch Client also installs these components:

Batch Client

• FactoryTalk Batch Equipment Editor

• FactoryTalk Batch Recipe Editor

• Legacy FactoryTalk Batch View

• Legacy ActiveX® Controls

• FactoryTalk Batch Service Manager

Tip: Prerequisite checks are run automatically to verify that the required software is present on the target computer. If an issue occurs during installation, suggested resolution

To install the FactoryTalk Batch Client

1. Run Setup.exe.

2. On the Setup page, select Customize.

3. On the Customize page:

• Expand FactoryTalk Batch v14.00.

• Clear the Batch Server selection.

• Select FactoryTalk Batch Editors and Legacy Client.

• Clear all other selections.

Tip: FactoryTalk Services Platform, FactoryTalk Activation, FactoryTalk Linx, FactoryTalk Updater Agent are installed automatically with the FactoryTalk

• Select Next.

4. On the Options page, select Next.

5. On the System Details page, complete these items:

• Under Server Node, in Name, enter the name of the FactoryTalk

Batch Server.

• Under User Account, in User Name, enter the domain name\user

name used to install the FactoryTalk Batch Server.

• Select Install.

6. On the End User License Agreements page, review the agreement and select Accept all.

7. If prompted on the That's it page, restart the computer.

Tip: We recommend using the default installation directories for all components.

Pre-Installation administration tasks

Tasks

Notes

Configure the remote registry service

 Set the system date and time



Prepare the SQL Server installation

system

Installation

Server

Post-installation tasks

Identify the material database

Add a server to the FactoryTalk Batch system

Chapter 5

Install FactoryTalk Batch Material Manager Server components

Use FactoryTalk Batch Material Manager to track material consumption in FactoryTalk Batch recipes.

Use this checklist to help you successfully set up the FactoryTalk Batch Material Manager environment:



Obtain administrator privileges on target computer



Create users and user groups



Update Windows firewall settings



Configure Microsoft Message Queuing Service

• Configure the Windows Server operating

system

• Configure the Windows desktop operating



Install the FactoryTalk Batch Material Manager



Chapter 5 Install FactoryTalk Batch Material Manager Server components

target computer. If an issue occurs during installation, suggested resolution steps are provided.

Tip: FactoryTalk Services Platform v6.20.00 is always installed with FactoryTalk Batch Material Manager v14.00.

Install the FactoryTalk

Use this procedure to install the FactoryTalk Batch Material Manager Server.

Batch Material Manager Server

Tip: Prerequisite checks are run automatically to verify that the required software is present on the

To install the FactoryTalk Batch Material Manager Server:

1. Run Setup.exe.

2. On the Setup page, select Customize.

3. On the Customize page:

• Select and expand FactoryTalk Batch Material Manager v14.00.

• Select Server Components.

• Clear all other selections.

• Select Next.

4. On the Permission Requested page, select Yes, allow changes to this computer, and then select Next.

Installing this component will make these changes to users and groups:

• MTUsers will be assigned permissions to the MaterialBasedRecipe

database

• MTBatchServer will be added to the MTBatchServer role.

• MTLotAuthor will be added to the MTLotAuthor role.

• MTMaterialAuthor will be added to the MTMaterialAuthor role.

• MTMaterialViewer will be added to MTMaterialViewer role.

5. On the Options page:

• Under Material Activity Journal select Record activity to the

MaterialBasedRecipe_MAJ database if you will be using

FactoryTalk Event Archiver reporting with FactoryTalk Batch Material Manager.

• Select Next.

6. On the System Details page, complete these fields:

• Under User Account in User Name, enter the domain\user name for

user account created for the FactoryTalk Batch Material Manager Server to run under. If the user account is in the current domain, the domain does not need to be specified.

• In Password enter the password for the domain\user name.

• Select Install.

7. On the End User License Agreements page, review the agreement and select Accept all.

8. (optional) If prompted on the Almost There page, select Activate your software, and then select Next.

9. If prompted on the That's it page, restart the computer.

IMPORTANT

opens and reads the databases.

Post-installation for

FactoryTalk Batch Material

Identify the material

Manager Server

database

Chapter 5 Install FactoryTalk Batch Material Manager Server components

After installing the FactoryTalk Batch Material Manager Server, complete these configuration items before transitioning the system into production:

• Identify the material database

• Add a server to the FactoryTalk Batch system

(If the Material Manager Server is on a different server than the FactoryTalk Batch server)

Configure the FactoryTalk Batch Material Manager Server with the location of the SQL database that contains the materials for the recipes.

To identify the material database

1. Navigate to Rockwell Software > Network Editor. The Network Editor window opens with the Material Server selected

by default.

2. Select Configure. The Configure MaterialTrack dialog box opens. The default database is materialbasedrecipe.

3. In the MaterialTrack Database box, enter the name of the database, and select OK.

The Network Editor does not verify database names. Changes made to the database name are immediate for the clients and servers. If the database name is invalid, the Material Editor will not open. Before changing the database name, check the spelling of the database name and synchronize the Network Editor. After changing the database name, confirm that the Material Editor

4. Select Synchronize.

5. Select File > Exit, and then select Yes to exit the Network Editor.

Tip: We recommend using the default installation directories for all components. target computer. If an issue occurs during installation, suggested resolution steps are provided.

Install the FactoryTalk

Chapter 6

Install FactoryTalk Batch Material Manager Client components

This section provides instructions on how to install the FactoryTalk Batch Material Manager Client components.

Use this procedure to install the FactoryTalk Batch Material Manager Client.

Batch Material Manager Client components

Tip: Prerequisite checks are run automatically to verify that the required software is present on the

To install the FactoryTalk Batch Material Manager Client

1. Run Setup.exe.

2. On the Customize page:

• Select and expand FactoryTalk Batch Material Manager v14.00.

• Select Client Components.

• Clear all other selections.

Tip: FactoryTalk Services Platform v6.20.00 is always installed with FactoryTalk Batch Material Manager v14.00.

• Select Next.

3. If prompted, on the System Details page, specify the name of a computer that has the FactoryTalk Batch Server installed, and select Install.

4. On the End User License Agreements page, review the agreement, and select Accept all.

5. On the That's it page, if prompted to do so, restart your computer.

IMPORTANT

(optional) FactoryTalk Activation Server

Activation files for FactoryTalk Batch and eProcedure

Chapter 7

FactoryTalk Activation

FactoryTalk® Activation Manager is the license application for FactoryTalk Batch and eProcedure. FactoryTalk Activation Manager is not necessary on client installations or any FactoryTalk Batch Material Manager installations. At the end of the installation wizard you can activate the software or continue without activation.

Some features may not be available until the software is activated.

The FactoryTalk Batch Server computer requires the FactoryTalk Activation Manager to enable communication with the FactoryTalk Activation Server. FactoryTalk Activation Manager and FactoryTalk Batch View Server are installed automatically on computers where the FactoryTalk Batch Server resides. FactoryTalk Activation Manager is also installed automatically on computers where the eProcedure Server resides. FactoryTalk Activation Manager can be installed on all FactoryTalk Batch Server computers.

FactoryTalk Activation Manager for FactoryTalk Batch and eProcedure

Server that includes:

• FactoryTalk Batch Server

• FactoryTalk Activation Client

• eProcedure Server

•

FactoryTalk Batch View Server

FactoryTalk Batch Material Manager Server and Client

Chapter 7 FactoryTalk Activation

IMPORTANT

Cumulative unit licensing

Client computer that includes:

• FactoryTalk Batch Client

• eProcedure Client

•

FactoryTalk Batch View

The FactoryTalk Batch Server checks for valid licenses and the correct number of unit licenses for FactoryTalk Batch and eProcedure at start up.

FactoryTalk Activation Licensing for the FactoryTalk Batch Server

Follow these licensing guidelines:

• The FactoryTalk Batch Server installs the FactoryTalk Activation Server on the FactoryTalk Batch Server machine.

• To obtain activation files for FactoryTalk Batch components, identify the Host ID of the FactoryTalk Activation Server computer.

In this scenario, the FactoryTalk Batch Server starts only if it finds valid activation files for FactoryTalk Batch.

If a license does not exist on the designated FactoryTalk Activation Server, a prompt asks for a serial number and product key. The installer attempts to download the license from the licensing service. If an Internet connection is not available, skip the on-line activation and obtain activation files using one of these alternative methods:

• Go to: https://activate.rockwellautomation.com/

• Use the FactoryTalk Activation Manager on a computer that has

Internet access.

• If Internet access is not available, call Rockwell Automation Technical Support and request an activation file be sent by email.

Software licenses are split into a product license and multiple unit licenses.

For example, a 30-unit FactoryTalk Batch product contains a 30-unit FactoryTalk Batch Server license, which includes a bundled license for FactoryTalk Batch Server, eProcedure Server, and FactoryTalk Batch Material Manager Server, and 30 new unit licenses.

When the FactoryTalk Batch Server starts, it performs a license check to determine which applications have a license. It then attempts to check out individual unit licenses up to the number of units specified in the area model. The FactoryTalk Batch Server then sets the maximum number of allowable units to the total number of successful individual unit license checkouts.

Pre-upgrade tasks

Tasks

Notes



Batch

FactoryTalk Batch component upgrade tasks

Post-upgrade tasks



Migrate recipes from FactoryTalk Batch version 13.00 or 13.00.02

RDB



(optional)



Configure recipe storage

Pre-upgrade tasks for

Chapter 8

Upgrade FactoryTalk Batch

If you have an existing FactoryTalk Batch system, you can upgrade the environment instead of doing a new installation.

Use this checklist to help you to successfully upgrade the FactoryTalk Batch environment:



Allow the Message Queue to clear for Material Manager

Export XML or RDB recipes to binary Back up files Uninstall a previous version of FactoryTalk



Upgrade the FactoryTalk Batch components



Restore back up files Migrate area models from FactoryTalk Batch

version 13.00 or 13.00.02



(optional) Convert binary recipes to XML or

Convert migrated recipes back to XML format



Convert migrated recipes back to RDB format (optional)

FactoryTalk Batch

This section describes steps to perform before upgrading the software,

including:

• Allowing the Message Queue to clear (Material Manager)

• If using XML or RDB recipes, exporting them to binary

• Backing up existing data files

• Uninstalling previous versions of FactoryTalk Batch components

Chapter 8 Upgrade FactoryTalk Batch

IMPORTANT

When installing FactoryTalk Batch 14.00 with RDB support,

Allow the Message Queue to Export XML or RDB recipes Back up files

clear for FactoryTalk Batch Material Manager

Allow the message queues for communication to clear between the

FactoryTalk Batch Material Manager Server and the Material Activity Journal.

This procedure applies to FactoryTalk Batch Material Manager only.

To allow the Message Queue to clear

1. Navigate to Computer Management.

2. In the Computer Management window, expand Services and Applications > Message Queuing, and then select the Private Queues folder.

The list of queues is displayed in the right pane.

3. Wait until the number of messages in the Material, Material_0, and material_track0-4 queues reaches 0.

4. Close Computer Management.

to binary

Post-upgrade tasks

Restore backup files

Chapter 8 Upgrade FactoryTalk Batch

After upgrading the FactoryTalk Batch software, perform these tasks before putting the system into production:

• Restoring back-up files

• Migrating area models and binary recipes, including XML or RDB

recipes that were exported to binary before the upgrade

• (Optional) Converting binary recipes back to XML or RDB

Before opening the FactoryTalk Batch Recipe Editor or the FactoryTalk Batch

Equipment Editor, restore backed up files to their original locations. This preserves the Batch Server and Client files and the databases for use with the upgraded version of FactoryTalk Batch.

Do not delete installed FactoryTalk Batch, eProcedure, or Material Manager product files from their installed locations. Removing product files from their original locations may cause unexpected failures and error messages in the Microsoft Install Resiliency feature. Instead, replace or overwrite the product files with other files of the same name. For example, overwrite BatchIDCreation.dll, RAMSCustom.dll and other hot fix files,

FactoryTalk Batch Server files

Restore these FactoryTalk Batch Server files by placing them in the appropriate directories.

• Batcharc.ini (Batch\bin folder) (if customized). Prior to restoring a customized Batcharc.ini file:

• Open the newly installed Batcharc.ini file.

• Copy the ArchiverTableName and ArchiverConnectionString lines.

• Paste these lines into the back up Batcharc.ini file, and then use that

file as the restore file. Restoring the Batcharc.ini file without copying these lines may

revert the newly created connection string. If this occurs, restore the new connection string with the Archiver Setup application.

• BatchIDCreation.dll (Batch\bin folder) (if customized)

• BatchID Custom folder (if customized)

• Simulator configuration files (.sim files in any folder)

• DSDF files (Batch\Data Servers folder) (if customized)

FactoryTalk Batch Client files

Restore these FactoryTalk Batch Client files by placing them in the appropriate directories.

• Customized *.bmp files (Batch\bmp folder)

Chapter 8 Upgrade FactoryTalk Batch

IMPORTANT

Do not restore the FactoryTalk Batch version 13 module .ini

the previous installation.

IMPORTANT

Updates to the BatchHistoryEx database overwrite any customizations made to

• Binary recipes (if using XML or RDB, first update the exported binary versions after upgrading the FactoryTalk Batch software, and then export them back to XML or RDB format)

• Area models (Batch\<project name>\recipes folder)

files. The .ini files are only restored when you are reverting to

FactoryTalk eProcedure files

Restore these FactoryTalk eProcedure files to their original locations:

• Customized Instruction files

• Customized User.asp files

• Any other customized files that support the customized User.asp

FactoryTalk Material Manager databases and files

Restore these FactoryTalk Material Manager files and databases to their original locations:

• Customized Instruction files

• Materialserver.log file (Batch\bin folder)

• MaterialBasedRecipe database

• MaterialBasedRecipe_MAJ database

• Any other material-based recipe databases unique to the facility

Tip: After restoring the material database, use SQL Server Management Studio to run the MaterialTrack_db_schema_Procedures.sql script, which deletes the old stored

procedures and adds the new stored procedures. The script is located at: C:\Program Files (x86)\Rockwell Software\Batch\Scripts.

FactoryTalk Event Archiver databases and files

During installation of FactoryTalk Event Archiver during installation an option to overwrite the existing database or migrate data from the BatchHistory (or BatchHistoryEx) database to the new FactoryTalk Batch

14.00 database is provided. Because of this, you do not need to restore the backup files created before the upgrade. Those files were created to support reverting your system to the previous version if necessary.

FactoryTalk Event Archiver reports. You will need to recreate all customized reports after the upgrade. Do not attempt to perform a full database backup and restore instead of allowing the installation program to overwrite or migrate the databases. A full database backup and restore will overwrite changes made to the schema as part of the upgrade.

IMPORTANT

Batch Equipment Editor User Guide

Migrate area models from

FactoryTalk Batch version

Migrate recipes from

13.00 or 13.00.02

After upgrading FactoryTalk Batch you must migrate any area models and recipes to the 14.0 schema so they can be used by the system.

Chapter 8 Upgrade FactoryTalk Batch

Prerequisites

• Use the FactoryTalk Administration Console to confirm that any linked FactoryTalk and Windows users and groups that are required by signature templates are configured in the FactoryTalk Network Directory.

To migrate area models from FactoryTalk Batch version 13.00 or

13.00.02

1. Open FactoryTalk Batch Equipment Editor.

2. Select File > Open.

3. Navigate to and select the version 13 area model.

4. When prompted to update the equipment database, select Yes.

FactoryTalk Batch version

If the area model uses signature templates, and no FactoryTalk users and groups match, the Security Permissions in the signature template are empty and require configuration. FactoryTalk Batch Equipment Editor displays a list of signature templates on which translation of security descriptors failed in the Invalid Signoffs dialog box.

5. Make a note of the affected templates and select OK. The migration completes.

If the Phase Failure enumeration set of an area model has ordinal values greater than 32767, reconfigure the values after migration. See System enumeration sets in the

6. Save the area model.

7. Open each signature template and configure the Signoff Permissions. See Create a Signature Template in the FactoryTalk Batch Equipment Editor User Guide for detailed instructions.

The FactoryTalk Batch Recipe Editor schema has changed from version 13 to version 14. When opening the Recipe Editor, some recipes might require translation before using the Recipe Editor.

FactoryTalk

13.00 or 13.00.02

These instructions are for recipes stored in the default binary files and for migrating the binary recipes export of XML or RDB recipes.

Chapter 8 Upgrade FactoryTalk Batch

use the list while addressing the errors.

Convert binary recipes to

Convert migrated recipes

To migrate recipes from FactoryTalk Batch version 13.00 or 13.00.02

1. Open FactoryTalk Batch Equipment Editor.

2. Select Options > Server Options.

3. In the Server Options dialog box, Store Recipes Using section, select Binary Files and set the path to the binary files.

4. Open the binary area model that was backed up before upgrading. FactoryTalk Batch Equipment Editor prompts to migrate the area model. Accept the migration and then save the file.

5. If errors occur during migration, stop and address the errors in the area model.

6. Open FactoryTalk Batch Recipe Editor.

7. If prompted to translate recipes, select Yes.

8. (optional) If auditing is enabled, enter appropriate comments in the Audit Comments dialog box

9. Select OK. The Recipes Requiring Verification dialog box displays all recipes that require verification.

10. (optional) Select Verify All to verify the listed recipes. The Verification Process Results dialog box opens. If any errors occur during translation, they are displayed in the top portion of the dialog box.

11. Double-click an error message to open the recipe to the error.

Tip: Select all of the error or warning text and copy it to a text editor to

XML or RDB

back to XML format

12. Close the dialog box. The verified recipes are copied back into the working set of recipes.

13. (optional) If auditing is enabled, the Audit Comments dialog box opens prior to saving the recipes. Enter appropriate comments, and then select OK.

After installing the latest version of FactoryTalk Batch components and migrating the area model, convert binary format recipes to an XML or RDB format if needed.

Use this procedure to convert updated binary recipes back to XML format.

To convert migrated recipes back to XML format

1. Open FactoryTalk Batch Equipment Editor.

2. Select Options > Server Options.

3. In the Server Options dialog box, Store Recipes Using section, select XML Files and set the path to the XML recipe location.

4. Open FactoryTalk Batch Recipe Editor.

5. Select File > Import Recipe Into Working Set.

Tip: If SQL Server is not installed on the same computer as the Batch

databases in the Server Options dialog box.

Convert migrated recipes

back to RDB format

Configure recipe storage

Chapter 8 Upgrade FactoryTalk Batch

6. In the Import Recipe into XML directory dialog box, select Binary Files and set the path to the location of the translated binary files.

7. In the Recipe Name list, select all the recipes, and then select Import. Recipes are imported into the working set of recipes in XML format.

Use this procedure to convert migrated binary recipes back to RDB format.

To convert migrated recipes back to RDB format

1. In FactoryTalk Batch Equipment Editor, select Options > Server

Options.

2. In the Server Options dialog box, under Store Recipes Using, select SQL Server Database.

3. Select the node and database to store recipes.

Tip: The default database is masterrecipes. Substitute a different database name, if needed.

4. Open FactoryTalk Batch Recipe Editor.

5. Select File > Import Recipe Into Working Set.

6. In the Import Recipe into Database dialog box, select Binary Files and set the path to the location of the migrated binary files.

7. In the Recipe Name list, select all the recipes, and then select Import to convert the recipes to RDB format and store in the database.

Recipes can be stored either as binary files, in a SQL Server Database, or as XML files

To configure recipe storage

1. Open FactoryTalk Batch Equipment Editor.

2. On the menu bar, select Options to open the Server Options dialog box

3. Under Store Recipes Using, select one of these options for storing recipes:

• Binary Files (default format): Stores recipes in separate files

according to the recipe level and specified directory: Stores procedures as .bpc files

Stores unit procedures as .upc files Stores operations as .uop files

• Microsoft SQL Server Database: Stores recipes in a SQL Server

database.

Client, perform a custom installation of SQL Server and install the Client

Tools Connectivity option. This displays a list of available SQL Server

Chapter 8 Upgrade FactoryTalk Batch

• XML Files: Stores recipes in separate .xml files:

Stores procedures as .pxml files Stores unit procedures as .uxml files Stores operations as .oxml files

4. Select OK to apply the configuration settings.

Manually configure the

Chapter 9

Troubleshoot FactoryTalk Batch installation or upgrade

At release time, this application presents certain circumstances and errors that require troubleshooting. This section supplies troubleshooting topics that indicate possible causes and solutions.

• Manually configuring the Windows Firewall

• Defining or resetting a disabled Administrator account

• Communication with the FactoryTalk Batch Server timing out

• Configuring Internet Explorer security settings for Trusted Sites

• Internet Explorer’s intranet zone

• Running as Administrator for eProcedure Client on Windows Server

operating system

• Recreating the masterrecipes database

Windows Firewall

If the Windows Firewall is enabled, and not externally controlled, the Windows Firewall Configuration Utility runs automatically. If this utility does not run automatically, manually run it on each computer in the FactoryTalk Batch system after installing servers or clients.

To manually configure the Windows Firewall

1. Navigate to All Programs > Rockwell Software > FactoryTalk Tools >

Windows Firewall Configuration Utility. The configuration utility

starts.

2. If the firewall is not enabled, a dialog box may open. Select Yes to enable the firewall and continue.

3. On the Rockwell Software Windows Firewall Configuration Utility dialog box, review the list of suggested changes and select Accept.

4. On the Confirm Windows Firewall Changes dialog box, verify that the New Firewall State is set to On with Exceptions.

5. Select OK. For a complete list of the exceptions made by the Windows Firewall

Configuration Utility, refer to FactoryTalk Batch Windows Firewall exceptions in the FactoryTalk Batch Administrator Guide.

Chapter 9 Troubleshoot FactoryTalk Batch installation or upgrade

Define or reset a disabled

Communication with

FactoryTalk Administrator account

The FactoryTalk Directory Configuration Wizard runs silently during the FactoryTalk Service Platform installation or upgrade. Run the wizard manually to define or reset a disabled Administrator account. FactoryTalk Batch and FactoryTalk Batch ActiveX Controls store client configuration settings in the Local and Network Directory.

To define or reset a disabled FactoryTalk Administrator account

1. Open the FactoryTalk Directory Configuration Wizard located within

the installed FactoryTalk Batch applications. The FactoryTalk Directory Configuration Wizard opens.

2. Select one or more options, and then select Next.

• Configure the FactoryTalk Network Directory

• Configure the FactoryTalk Local Directory

3. Complete one or more pages:

• In Reconfigure FactoryTalk Network Directory, enter the User

name and Password for an existing Network administrator account. Re-enter the password in the Confirm password box, and then select Next.

• In Reconfigure FactoryTalk Local Directory, enter the User name

and Password for an existing Local administrator account. Re-enter the password in the Confirm password box, and then select Next.

FactoryTalk Batch Server times out

4. On the Summary window, select Close.

Tip: For more detailed information on FactoryTalk Directory installation and configuration, select the Help button on the wizard, or view the FactoryTalk Administration Console help file.

If the FactoryTalk Batch and eProcedure Servers run on a workgroup, add an Incoming Firewall Rule to allow the FactoryTalk Batch Service Manager to connect to the Server in a timely manner. For more information about adding an Incoming Firewall Rule, see Add an incoming firewall rule.

Disable Administrative Approval Mode for all administrators on the FactoryTalk Batch Server when running on a workgroup. This ensures that administrators do not have to install or run programs using elevated privileges.

For more information about disabling Administrative Approval, see Disable Administrative Approval Mode.

Configure Internet Explorer

security settings for

Internet Explorer intranet

Run as Administrator on

Trusted Sites

Use these instructions to configure Internet Explorer security settings for

Trusted Sites.

Chapter 9 Troubleshoot FactoryTalk Batch installation or upgrade

To configure Internet Explorer security settings for Trusted Sites

1. Using Internet Explorer, open Settings > Internet Options.

2. Select the Security tab.

3. Select Trusted sites.

4. Under Security level for this zone, drag the slider to lower the security level for the Trusted sites zone to Low or Medium-low.

5. If the eProcedure Trusted sites differ from the default installation, select Sites to open the Trusted sites dialog box.

• Under Websites, scroll through the list and verify that the

eProcedure Server computer and about:blank sites are listed.

• If the eProcedure Server computer and about:blank sites are not

listed, select Add and add them.

• Select Close when finished.

zone

eProcedure Client on

6. Select OK to apply the changes.

The installation of the eProcedure Server installs a Security_HKLM_Only key and sets the key to 1 (enabled). The key exists in the location:

HKEY_LOCAL_MACHINE\Software\Policies\Microsoft\Windows\CurrentVe rsion\Internet Settings

Internet Explorer uses intranet security settings when:

• The Security_HKLM_Only key is 0 (disabled) or removed

• The eProcedure Server name does not appear on the list of trusted sites

• The site qualifies as an intranet site

Configure the ActiveX settings for the intranet zone.

To launch the eProcedure Client on a computer running Windows Server you must be logged in with an account that has administrator privileges.

Windows Server operating systems

To run as Administrator on Windows Server operating systems:

• Right-click the eProcedure Client icon and select Run as administrator.

Chapter 9 Troubleshoot FactoryTalk Batch installation or upgrade

createmasterrecipedb.bat file is not required.

Tip: This batch file uses the default database name

It executes these SQL

• createrecipetables.sql

Manually recreate the

If the database name is not masterrecipes, follow these steps to edit the .bat

masterrecipes database

file and the createmasterrecipedb.sql script to specify the name of the database and recreate it.

If the database needs to be recreated at any time, the .bat file can also be used to recreate it.

Tip: If Store recipes in RDB format was selected when installing FactoryTalk Batch, running the

Prerequisites

• Use the Rockwell Software\Batch\Scripts\createmasterrecipedb.bat file to recreate the recipe database.

scripts in the Batch\Scripts folder to create the database and tables:

• createmasterrecipedb.sql

masterrecipes.

To manually recreate the masterrecipes database

1. Edit Batch\Scripts\createmasterrecipedb.bat using a text editor.

Replace masterrecipes with the database filename.

2. Edit the createmasterrecipedb.sql script using either SQL Server Management Studio or another editor to specify the database file name.

3. Run the Batch\Scripts\createmasterrecipedb.bat file to create the database and tables.

Windows Workgroup

Create Windows accounts

Add an incoming firewall

Appendix A

Use FactoryTalk Batch with a Windows Workgroup

This appendix includes instructions for using FactoryTalk Batch components on a Windows workgroup.

This section describes steps to configure FactoryTalk Batch to run under a Windows Workgroup.

If the FactoryTalk Batch system runs under a Windows Workgroup, you will need to perform these additional tasks:

rule

• Create Windows accounts

• Add an incoming firewall rule

• Disable Administrative Approval Mode

If the FactoryTalk Batch application servers use a local account, create Windows accounts with the same name and password on all computers in the

workgroup.

Add incoming firewall rules for these applications:

• FactoryTalk Batch Server

• eProcedure Server

• FactoryTalk Batch Material Manager Server

To add an incoming firewall rule

On the computer where the component is being installed:

1. Navigate to Windows Firewall with Advanced Security.

2. Select Inbound Rules, right-click Inbound Rules, and then select New Rule.

3. In the New Inbound Rule Wizard, select the following values:

• In Rule Type, select Port.

• In Protocol and Ports, select TCP and in Specific local ports, type

49157.

• In Action, select Allow the connection.

• In Profile, select all profiles (Domain, Private, Public).

Appendix A Use FactoryTalk Batch with a Windows Workgroup

IMPORTANT

computer. Additionally, when this setting is changed, the computer must be restarted.

Disable Administrative

• In Name, in the Name box, enter Port 49157 TCP, and then select

Finish.

• Verify that Port 49157 TCP rule exists in the Inbound Rules list.

• Close Windows Firewall with Advanced Security.

Disable the User Account Control: Run all administrators in Admin Approval Mode security policy setting on the FactoryTalk Batch Server computer when

Approval Mode

running on a Windows Workgroup. This ensures that users do not have to install or run programs using elevated privileges.

To disable Administrative Approval Mode

If this security setting is configured to Disabled, the Windows Security Center notifies you that the overall security of the operating system has been reduced. As a result of this change Windows User Account Control (UAC) is not used, and any security benefits and risk mitigations that are dependent on UAC are not present on the

1. On the FactoryTalk Batch Server, navigate to Control Panel >

Administrative Tools > Local Security Policy.

2. Expand Local Polices and select Security Options.

3. Locate User Account Control: Run all Administrators in Admin Approval Mode and double-click it.

4. In the Local Security Setting tab, select Disabled, and then select OK.

5. Verify that User Account Control: Run All Administrators in Admin Approval Mode displays as Disabled.

6. Close the Local Security Policy window.

Tip: We recommend using the default installation directories for all components.

Appendix B

Install FactoryTalk eProcedure Client components

The FactoryTalk eProcedure Client uses Internet Explorer to enable operators to run batch recipes that contain manual instruction phases and automated phases.

Before beginning the installation, complete all the pre-installation administrative tasks.

Install the FactoryTalk Batch Server and FactoryTalk eProcedure Server components before installing FactoryTalk eProcedure Client components.

Be aware of these limitations regarding FactoryTalk eProcedure components:

• The FactoryTalk eProcedure Client requires installation of MSXML 4.0 on the FactoryTalk eProcedure Server machine to properly render the Instruction page. Due to security risks, the FactoryTalk Batch installation no longer installs MSXML 4.0.

Use FactoryTalk Batch View v1.02 to view FactoryTalk eProcedure clients or manually install the msxml.msi located in the [root folder]\Redist\MSXML_4.0SP3\ folder.

• Any Visual Basic® scripting in instructions should be converted to JavaScript.

Browsers such as Microsoft Edge, Google Chrome browser, Mozilla Firefox, and Apple Safari, do not support Visual Basic scripting. In these browsers, Visual Basic scripting actions are ignored and no error message is displayed.

• The user must be a member of the Administrators group to run the FactoryTalk eProcedure Client on a Windows Server computer and to obtain the required privileges to execute the FactoryTalk eProcedure Client.

• The FactoryTalk eProcedure Client is not supported on a computer running the Windows Server 2012 Data Center and Windows Server 2016 Data Center operating systems. Use FactoryTalk Batch View v1.02 to view FactoryTalk eProcedure clients.

Appendix B Install FactoryTalk eProcedure Client components

Important:

target computer. If an issue occurs during installation, suggested resolution steps are provided.

Install the FactoryTalk

The FactoryTalk eProcedure Client is a web-based application that creates and commands batches. A batch is composed of a combination of process-

eProcedure Client

connected phase logic and instruction files that step the operator through the manual process of producing a batch of products.

Tip: Prerequisite checks are run automatically to verify that the required software is present on the

To install the FactoryTalk eProcedure Client Components

1. Run Setup.exe.

2. On the Setup page, select Customize.

3. On the Customize page:

To run the FactoryTalk eProcedure Client on a Windows Server machine, first do the following:

• Disable Internet Explorer Enhanced Security Configuration.

• Obtain the required privileges to execute the FactoryTalk

eProcedure Client, right-click the FactoryTalk eProcedure Client icon and select Run as administrator.

• Select FactoryTalk eProcedure v14.00.

• Select Client Components.

• Select Next.

4. On the Options page, Network Directory is required and is selected by default. Select Next.

5. On the System Details page, complete these items:

• In User Name, enter the domain\user name for the FactoryTalk

Batch Server or Material Server to run under. If the user account is in the current domain, the domain does not need to be specified.

• In User Account, enter the user account for use by the FactoryTalk

Batch Server.

• Select Next.

6. On the End User License Agreements page, review the agreement and

select Accept all.

7. If prompted on the That's it page, restart the computer.

Post-FactoryTalk

eProcedure Client

Set the Internet Explorer

Configure Internet Explorer

component installation

home page for FactoryTalk eProcedure Clients

Post-installation configuration of the FactoryTalk eProcedure Client computer includes these tasks:

• Set the Internet Explorer home page for FactoryTalk eProcedure Clients

• Configure Internet Explorer to view FactoryTalk eProcedure pages

• Configure Internet Explorer compatibility view settings

• Select the Windows Classic theme in Windows 7

The FactoryTalk eProcedure Client install sets the home page only for the user who installed the product. Any other users who will be using the FactoryTalk eProcedure Client on that computer must set the FactoryTalk eProcedure Client as the home page.

Appendix B Install FactoryTalk eProcedure Client components

To set the Internet Explorer home page for FactoryTalk eProcedure Clients

to view FactoryTalk eProcedure pages

1. In Internet Explorer, select Tools > Internet Options.

2. In the Home page box, enter http://<computer name>/FactoryTalk eProcedure/ (where <computer name> is the name of the Server where the FactoryTalk eProcedure Server is installed).

3. Select OK.

Use these instructions to configure Internet Explorer to view FactoryTalk eProcedure pages.

To configure Internet Explorer to view FactoryTalk eProcedure

pages

1. In Internet Explorer, select Tools > Internet Options.

Tip: If using the global policy editor, use gpedit.msc.

2. Select the Security tab.

3. Select Trusted sites and then select Sites.

Appendix B Install FactoryTalk eProcedure Client components

from successfully operating.

Configure Internet Explorer

Tip: When adding sites to Internet Explorer Security Zones, be aware that:

• The FactoryTalk eProcedure installation modifies the Trusted sites

• Third-party computer and network security products, like Symantec,

4. In the Trusted sites dialog box, verify that Require server verification (https:) for all sites in this zone is disabled.

5. In the Add this Web site to the zone box, type http://<name of computer hosting FactoryTalk eProcedure server>. Select Add to add the Web site to the Web sites box.

6. In the Add this Web site to the zone box, type about:blank. Select Add to add about:blank to the list of websites.

7. In the Add this Web site to the zone box, type about:internet. Select Add to add about:internet to the list of websites.

8. Close the Trusted sites dialog box.

9. In the Internet Explorer Options dialog box, select Custom Level.

10. In the Security Settings dialog box, select Enable for these options:

security setting for the local computer. This provides all users with consistent FactoryTalk eProcedure Client operation. The instructions provided in this guide enable the current user to customize the FactoryTalk eProcedure Client operation and addition of sites into the current user's Internet Explorer security zones. Incorrectly following the instructions may result in undesired FactoryTalk eProcedure Client behavior or damage to the configuration of the computer, or both.

interact with Internet Explorer to secure computing environments. Modifying the default FactoryTalk eProcedure installation may lock down some settings and prevent the FactoryTalk eProcedure Client

compatibility view settings

• Download signed ActiveX controls

• Download unsigned ActiveX controls

• Initialize and script ActiveX controls not marked safe

• Run ActiveX controls and plug-ins

• Script ActiveX controls marked safe for scripting

11. Select OK. A confirmation message is displayed.

12. Select Yes to change the security settings and close the Security Settings dialog box.

13. Select OK. If prompted, restart the computer.

Use these instructions to configure the Internet Explorer compatibility view settings.

To configure Internet Explorer compatibility view settings

1. From Internet Explorer, select Tools > Compatibility View Settings.

2. In Add this website, enter the eProcedure server name as http://<computer name>, and select Add.

3. Refresh the Internet Explorer browser.

Internet Explorer security settings for Trusted Sites.

Select Windows theme in

Windows 7

Tip: To enable the current user to maintain a separate set of eProcedure Client security settings than those for the local computer, see Configure

Appendix B Install FactoryTalk eProcedure Client components

Windows 7 requires the Windows Classic theme to use the eProcedure Client. Using other themes (such as Windows Basic) may cause unpredictable issues with color and display.

To select the Windows Classic theme in Windows 7

1. Select Start > Control Panel > Appearance and Personalization >

Personalization.

2. Select the Windows Classic theme.

3. Select Close.

Tip: Users must have administrative privileges on the target computer to uninstall the software.

Uninstall the FactoryTalk

Batch system

Uninstall the FactoryTalk

Appendix C

Uninstall FactoryTalk Batch version 14.00

This section describes how to uninstall FactoryTalk Batch version 14.00.

Use this procedure to uninstall all FactoryTalk Batch components on the computer at once.

Prerequisites

Batch components

• Close all FactoryTalk Batch applications.

• Stop all Batch services.

To uninstall the FactoryTalk Batch System

1. Navigate to Control Panel > Programs and Features, and then select

Uninstall a Program.

2. On the Uninstall or change a program page, select FactoryTalk Batch system and select Uninstall. The Uninstall page opens with all FactoryTalk Batch installed components on the computer selected.

3. Select Uninstall. The uninstall program removes all FactoryTalk Batch components.

4. Select Close.

As an alternative to uninstalling the entire FactoryTalk Batch System, use the Uninstall page to uninstall unnecessary components and keep useful components. Multiple components can be selected.

Prerequisites

• Close all FactoryTalk Batch applications.

• Stop all Batch services.

Appendix C Uninstall FactoryTalk Batch version 14.00

Uninstall FactoryTalk Batch

Delete the default

To uninstall the FactoryTalk Batch components

1. Navigate to Control Panel > Programs and Features, and then select

Uninstall a Program.

2. On the Uninstall or change a program page, select a FactoryTalk Batch component and select Uninstall.

3. On the Uninstall page, select the check box next to each component to remove.

4. Select Uninstall. The uninstall program removes the selected FactoryTalk Batch components.

5. Select Close.

Uninstall FactoryTalk Batch Material Manager to move it to another server or to permanently uninstall FactoryTalk Batch Material Manager if it is not

Material Manager

being used.

Prerequisites

directories

• Close all FactoryTalk Batch applications.

• Stop all Batch services.

• Allow the Message Queue to clear

To uninstall FactoryTalk Batch Material Manager

1. Navigate to Control Panel > Programs and Features, and then select

Uninstall a Program.

2. On the Uninstall or change a program page, select FactoryTalk Batch Material Manager and select Uninstall.

3. On the Uninstall page, verify the FactoryTalk Batch Material Manager option is selected, and then select Uninstall. The uninstall program removes FactoryTalk Batch Material Manager.

4. Select Close.

Delete the default directories or the directories of the FactoryTalk Batch components after uninstalling the applications to free up space on the file system.

To delete the default directories

1. In Windows Explorer, expand the Program Files (x86) folder, and

select the Rockwell Software folder. The Batch folder displays in the right pane.

Delete databases

Appendix C Uninstall FactoryTalk Batch version 14.00

2. Right-click the Batch folder and select Delete. A message box confirms the deletion.

3. Select Yes.

4. Close Windows Explorer.

After uninstalling FactoryTalk Batch, delete any remaining databases in SQL Server to free up space in the database.

Databases that might be present are:

• BatchHistory or BatchHistoryEx

• MaterialBasedRecipe

• MaterialBasedRecipe_MAJ

• Sample2_Materials

To delete databases

1. Open SQL Server Management Studio and expand Databases.

2. Right-click the database and select Delete.

3. Click OK.

Index

accounts 73 administrator privileges 19, 33, 49, 51

back up 59, 60, 62, 63 batchhistory 14, 33, 41, 60, 63, 83

compatibility view 33, 47, 78

data execution prevention (DEP) 22 database 13, 14, 22, 25, 33, 34, 37, 41, 53,

60, 62, 63, 65, 66, 72, 81, 82, 83 date 23, 25, 33, 49, 51, 63, 65, 66 delete 22, 33, 60, 63, 81, 82, 83 directories 33, 34, 42, 43, 50, 60, 65, 66,

70, 76 disabled 69, 70, 71, 74, 77

firewall 15, 20, 23, 25, 33, 49, 51, 60, 69,

70, 73, 74

placement, servers 14 post-installation 33, 38, 47, 51, 53, 77 post-upgrade 59, 63 pre-installation 19, 59

RDB 59, 60, 62, 63, 65, 66, 67, 72 recipes 15, 25, 33, 51, 53, 59, 60, 62, 63,

65, 66, 67, 72 redundant 33, 44 remote registry 25, 33 reporting services 25, 27, 33, 41 restart 33, 44, 50, 52, 55, 62, 76, 77

server options 33, 45, 65, 66, 67 SQL Server 13, 14, 15, 25, 27, 33, 41, 42, 51,

60, 63, 67, 72, 83 start 15, 25, 27, 34, 37, 44, 50, 52, 55, 57,

58, 62, 69, 76, 77, 79 system overview 13 system requirements 13, 14, 15, 20, 25, 33,

34, 49, 50, 76, 79

time 14, 25, 27, 33, 49, 51, 69, 70, 72 troubleshooting 69

uninstall 59, 60, 62, 81, 82, 83 upgrading 59, 62, 63, 69 users 22, 27, 41, 42, 65

identify 21, 33, 53, 57 installing 7, 15, 19, 20, 25, 33, 34, 49 instructions 18 Internet Explorer 15, 47, 69, 71, 77, 78

licensing 57, 58 logs 25, 33, 42, 43, 46

Windows Server 15, 20, 71 workgroup 73

XML 59, 60, 62, 63, 65, 66, 67

MasterRecipes 60, 66, 72 message queuing 60 migrate 62, 65, 66, 67

Rockwell Automation support

Technical Support Center

Find help with how-to videos, FAQs, chat, user forums, and product notification

rok.auto/support

Knowledgebase

Access Knowledgebase articles.

rok.auto/knowledgebase
