Installation Instructions
PHOTOSWITCH Bulletin 42CB High Speed 18mm Cylindrical
IMPORTANT: SAVE THESE INSTRUCTIONS FOR FUTURE USE.
Description
Bulletin 42CB are high speed 18mm cylindrical sensors
available in several sensing modes, with various detection
ranges.
The Fixed Focus Diffuse uses a visible red LED, all the other
sensing modes use an infrared LED.
These sensors are available with 10–30V DC, either PNP or
NPN output and selectable light/dark operate mode on each
sensor.
The sensitivity adjustment potentiometer and two LED
indicators are mounted in the rear. The LED’s show the
output is energized (yellow) and power is on (green).
Fast response time and the high switching frequency of all the
Bulletin CB sensors (1kHz) allows for accurate detection of
objects moving at high speed.
The right angle orientation of this bulletin reduces the overall
dimension of the sensor, and reduces the chance of
accidental tearing.
Wiring
NPN Output PNP Output
L.O./D.O. (see below)
White
2
+
Brown
1
Black
4
Out
Blue
3
Ċ
Load
Features (continued)
S Short circuit protection
S Reverse polarity protection
S Single turn sensitivity adjustment potentiometer
S Output energized (yellow) and power on (green) LED indi-
cators
S Selectable light or dark operation (L.O./D.O.)
General Specifications
Relative Humidity 35 to 85%
Ambient Temperature -13°F to 158°F (-25°C to +70°C)
Lens Material Acrylic
Housing Material Polyamide
Operating Environment IEC IP65
Weight 90 grams (3.1oz)
Micro QuickĆDisconnect Versions
Output
34
1 2
10-30V DC ( + )
White
2
Brown
1
Black
4
Blue
3
L.O./D.O.
+
Out
Load
Ċ
( - )
L.O./D.O.
Output Select
Selection of the output state: (white wire must be connected for operation): L.O. (White –), D.O. (White +)
Dimensions—mm (inches)
Cable Version
Indicators
QuickĆDisconnect Version
(0.39)
6
(0.24)
10
12
(0.47)
Indicators
6
(0.24)
14.5
(0.57)
80
(3.14)
58
(2.28)
80
(3.14)
M18 X 1
4
(0.16)
58
(2.28)
Power Indicator
(Green)
Output Indicator
(Yellow)
M18 X 1
4
(0.16)
21
(0.83)
24
(0.95)
Adjustment
Potentiometer
M12 X 1
Retroreflective Polarized Retroreflective Standard Diffuse Fixed Focus Diffuse
Field of View
1.3° 1.6°
Transmitting LED Infrared 880nm Visible red 660nm Infrared 880nm Visible red 660nm
Connections Cable Version:
Catalog Numbers
Ending in -L2
QuickĆDisconnect Versions:
Catalog Numbers
Ending in -M4
15° for Catalog Numbers
42CB-D1L_AF-__
5.5° for Catalog Numbers
42CB-D1L_AL-__
4 conductor 300V
PVC jacketed right
angle cable 6.5ft (2m)
4Ćpin DC right angle
micro style
7.8° for 12mm focal point
2.9° for 25mm focal point
1.2° for 50mm focal point
Retroreflective
Operating Distance
Reflector 3:1 Margin 1:1 Margin
78mm (3in) 0.08m-5.4m (0.27ft-17.7ft) 0.08m-7.2m (0.27ft-23.6ft )
Polarized Retroreflective
Operating Distance
Reflector 2:1 Margin 1:1 Margin
78mm (3in) 0.2m-2m (0.67ft-6.7ft) 0.2m-2.8m (0.67ft-9ft)
Standard Diffuse
Operating Distance with White Paper
3:1 Margin 2:1 Margin 1:1 Margin Catalog Number
4.5cm (1.7in) 7.5cm (2.9in) 15cm (5.9in) 42CB-D1LNAF-L2
30cm (11.8in) 60cm (23.6in) 100cm (39.3in) 42CB-D1LNAL-L2
42CB-D1LPAF-L2
42CB-D1LNAF-M4
42CB-D1LPAF-M4
42CB-D1LPAL-L2
42CB-D1LNAL-M4
42CB-D1LPAL-M4
Fixed Focus Diffuse
Operating Distance
Focal Point Catalog Number
12mm (0.47in) 42CB-C2LNAY-L2
25mm (0.98in) 42CB-C2LNAZ-L2
50mm (1.96in) 42CB-C2LNAC-L2
42CB-C2LPAY-L2
42CB-C2LNAY-M4
42CB-C2LPAY-M4
42CB-C2LPAZ-L2
42CB-C2LNAZ-M4
42CB-C2LPAZ-M4
42CB-C2LPAC-L2
42CB-C2LNAC-M4
42CB-C2LPAC-M4
Retroreflective
Light/Dark
Light/Dark
Light/Dark
NPN
Light/Dark
PNP
Operating
Voltage
10-30V DC 20mA
Supply
Current
Polarized Retroreflective
Operating
Voltage
10-30V DC 20mA
Supply
Current
Standard Diffuse
Operating
Voltage
10-30V DC 20mA
Supply
Current
Output
Energized
Light/Dark
Selectable
Output
Energized
Light/Dark
Selectable
Output
Energized
Light/Dark
Selectable
Output Characteristics Catalog Number
Type
NPN
PNP
Max Load
Current
100mA 10µA 500µs
Max Leakage
Current
Response
Time
Cable QuickĆDisconnect
42CB-U1LNA-L2 42CB-U1LNA-M4
42CB-U1LPA-L2 42CB-U1LPA-M4
Output Characteristics Catalog Number
Type
NPN
PNP
Max Load
Current
100mA 10µA 500µs
Max Leakage
Current
Response
Time
Cable QuickĆDisconnect
42CB-P2LNA-L2 42CB-P2LNA-M4
42CB-P2LPA-L2 42CB-P2LPA-M4
Output Characteristics Catalog Number
Type
NPN
PNP
Max
Load
Current
100mA 10µA 500µs
Max
Leakage
Current
Respons
e Time
1:1 Margin Cable QuickĆDisconnect
15cm (5.9in) 42CB-D1LNAF-L2 42CB-D1LNAF-M4
100cm (39.3in) 42CB-D1LNAL-L2 42CB-D1LNAL-M4
15cm (5.9in) 42CB-D1LPAF-L2 42CB-D1LPAF-M4
100cm (39.3in) 42CB-D1LPAL-L2 42CB-D1LPAL-M4
Fixed Focus Diffuse
Output Characteristics Catalog Number
Operating
Voltage
10-30V DC 20mA
Supply
Current
Output
Energized
Light/Dark
Selectable
Type
NPN
PNP
Accessories
Description Catalog Number
12mm Fixed Focus Lens Adaptor 61-6723
25mm Fixed Focus Lens Adaptor 61-6724
50mm Fixed Focus Lens Adaptor 61-6725
Right Angle Mounting Bracket 60-2615
Straight Mounting Bracket 60-2616
Max
Load
Current
100mA 10µA 500µs
Max
Leakage
Current
Response
Time
Focal Point Cable QuickĆDisconnect
12mm (0.47in) 42CB-C2LNAY-L2 42CB-C2LNAY-M4
25mm (0.98in) 42CB-C2LNAZ-L2 42CB-C2LNAZ-M4
50mm (1.96in) 42CB-C2LNAC-L2 42CB-C2LNAC-M4
12mm (0.47in) 42CB-C2LPAY-L2 42CB-C2LPAY-M4
25mm (0.98) 42CB-C2LPAZ-L2 42CB-C2LPAZ-M4
50mm (1.96in) 42CB-C2LPAC-L2 42CB-C2LPAC-M4
Publication 75009–077–01(C)
November 1995
Printed in Italy
